The system includes an array of electrodes and a stimulator coupled to the array of electrodes by at least one flexible wire. The array of electrodes are disposed on a flexible carrier configured to wrap around a hypoglossal nerve of a patient. The array of electrodes include a first electrode, a second electrode, and a third electrode. The stimulator includes a control circuit configured to generate a stimulation signal. The stimulator is configured to receive a communication from an external device for selecting at least one of the first electrode, the second electrode, and the third electrode that will participate in stimulating the hypoglossal nerve of the patient.
The invention disclosed herein relates to a system (1) for implanting a neurostimulation lead (2) in a subject's head and facial tissue (3), the system (1) comprising: a stimulation lead (2) configured for implantation in said tissue (3); an introducer (4) configured for temporary insertion into said tissue (3) and comprising a Tube portion (5); a tunneling tool (6) configured for temporary insertion into said tissue (3) and comprising a shaft (7), a shaft tip (9) releasably mounted to the shaft (7), and a pull suture (8) connected to the releasable shaft tip (9); a first trocar (10) configured for insertion into the introducer (4), the first trocar (10) comprising a receiving structure (11) for receiving and retaining the shaft tip (9) of the tunneling tool (6); a guide tube (12) configured for insertion into the introducer (4); a second trocar (13) configured for insertion into the guide tube (12); and a lead holder (14) configured for inserting the stimulation lead (2) through the guide tube (12) into said tissue. The invention further relates to a method of implanting a stimulation lead (2) in a subject's head and facial tissue (3) using said system (1).
The invention disclosed herein relates to a neurostimulation system for treating head and facial pain, the system comprising: an external unit configured for a location external to a subject's body; and an implant unit configured for implantation inside the subject's body; wherein the external unit comprises: a primary coil configured to transmit a stimulation signal to the implant unit; and a power source; wherein the implant unit comprises: a plurality of electrodes; and a secondary coil in electrical communication with the plurality of electrodes, wherein the secondary coil is configured to receive the stimulation signal from the primary coil; and wherein the system is configured, for each stimulation event of a series of stimulation events, to select a sub-group of electrodes from the plurality of electrodes for stimulation delivery, and/or to select a set of stimulation parameter values for stimulation delivery. According to another aspect, the invention relates to a method for selecting a stimulation delivery pattern for an implant unit of said neurostimulation system.
Disclosed herein is a neurostimulation system for treating head pain, the system comprising: an implant unit configured for implantation inside a subject's (700) body; an external unit configured for a location external to the subject's (700) body; and a charging and programming unit; wherein the external unit comprises: a processor; a power source (220); and a primary transmission unit (230) in electrical communication with the power source (220) and the processor; wherein the implant unit comprises: at least one lead (310); at least one pair of modulation electrodes (320) attached to the at least one lead (310); and a secondary transmission unit (330) in electrical communication with the at least one lead (310); and wherein the processor is configured to establish a coupling between the primary transmission unit (230) and the secondary transmission unit (330) and to transmit power from the power source (220) to the implant unit via said coupling. According to another aspect of the present disclosure, an implant unit for use in a neurostimulation system is described, wherein the implant unit is configured for implantation inside a subject's (700) body through an incision (600) subject's (700) skin, and wherein the implant unit is further configured for implantation inside the subject's (700) body through a tunnel (610). According to yet another aspect of the disclosure, a method for electrical stimulation of neuromuscular tissue using a neurostimulation system is described herewith, the method comprising: generating an electrical stimulation pattern with an external unit, the electrical stimulation pattern comprising at least one modulation signal; delivering the electrical stimulation pattern to an implant unit located inside a subject's (700) body; adjusting the electrical stimulation pattern, wherein adjusting the electrical stimulation pattern comprises increasing or decreasing a voltage, a current amplitude, a pulse frequency and/or a pulse width of the electrical stimulation pattern. Such a method may be valuable, for example, in pain management, where the propagation of pain signals is undesired.
