A hose reel includes a spool on which a hose is supported. The hose has a number of coils per layer when disposed on the spool. The hose reel includes a motor to drive rotation of the spool at a rate of rotation, a sensor to generate a rotation signal indicative of rotation of the spool, and a controller. The controller is to identify a current wrap layer of the hose about the spool based on a revolution count and the number of coils per layer and determine an effective spool diameter that corresponds with the current wrap layer of the hose. Responsive to identifying a change in the effective spool diameter, the controller is to adjust a control signal provided to the motor to change the rate of rotation of the spool to maintain a constant linear speed during winding or unwinding of the hose.
A fuel delivery system and method for controlling a fuel delivery system includes a fuel control device including a valve and an electronic sensor assembly integrated to the fuel control device and is arranged to detect an operational positioning of the valve, to generate a record of the real-time activation of the valve, and to compare records of real-time activation against a schedule of fuel deliveries to detect unauthorized fuel access.
B67D 7/04 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes for transferring fuels, lubricants or mixed fuels and lubricants
F16K 37/00 - Special means in or on valves or other cut-off apparatus for indicating or recording operation thereof, or for enabling an alarm to be given
A hose reel includes a frame, a spool supported on the frame for rotation relative to the frame, a motor supported on the frame to provide motive power to the spool, a level wind device supported on the frame to guide a hose during winding and unwinding; the level wind device being selectively linked to the rotation of the spool and including a disengagement clutch for selectively decoupling the operation of the level wind device from the rotation of the spool. The hose reel may be selectively operated to provide a power-out assist during unwinding that provides a power level to the motor less than a threshold power necessary to drive the spool in the unwinding direction.
A bypass valve assembly includes a housing having an inlet, an outlet, and a flow passageway to allow flow of a liquid from the inlet to the outlet and a valve seat disposed about the flow passageway between the inlet and the outlet. A movable poppet is disposed in the housing to engage the valve seat in a closed position and to disengage the valve seat in an open position when pressure of the liquid in the flow passageway exceeds a preset value to allow flow of the liquid through the flow passageway. A rotatable flow control valve is disposed in the housing between the inlet and the outlet. An actuator is coupled to the flow control valve to actuate and move the flow control valve to control flow of the liquid between the inlet and the outlet when the poppet is engaged with the valve seat.
F16K 11/02 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with all movable sealing faces moving as one unit
A valve assembly includes a housing body defining a first opening, a second opening and an internal chamber. A first mechanism is provided in the housing body to control fluid between the first opening and the interior chamber and a second mechanism is provided in the housing body to control fluid between the second opening and the interior chamber. The first and second control mechanisms operate independently.
F16K 1/32 - Lift valves, i.e. cut-off apparatus with closure members having at least a component of their opening and closing motion perpendicular to the closing faces Details
F16K 11/10 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with two or more closure members not moving as a unit
F16L 55/24 - Preventing accumulation of dirt or other matter in pipes, e.g. by traps, by strainers
A valve assembly includes a housing body defining a first opening, a second opening and an internal chamber. A first mechanism is provided in the housing body to control fluid between the first opening and the interior chamber and a second mechanism is provided in the housing body to control fluid between the second opening and the interior chamber. The first and second control mechanisms operate independently.
F16K 11/22 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with two or more closure members not moving as a unit operated by separate actuating members with an actuating member for each valve, e.g. interconnected to form multiple-way valves
B01D 29/33 - Self-supporting filtering elements arranged for inward flow filtration
F16K 39/02 - Devices for relieving the pressure on the sealing faces for lift valves
F16K 51/00 - Other details not peculiar to particular types of valves or cut-off apparatus
F16K 27/02 - Construction of housingsUse of materials therefor of lift valves
A bypass valve assembly includes a housing having an inlet, an outlet, and a flow passageway to allow flow of a liquid from the inlet to the outlet and a valve seat disposed about the flow passageway between the inlet and the outlet. A movable poppet is disposed in the housing to engage the valve seat in a closed position and to disengage the valve seat in an open position when pressure of the liquid in the flow passageway exceeds a preset value to allow flow of the liquid through the flow passageway. A rotatable flow control valve is disposed in the housing between the inlet and the outlet. An actuator is coupled to the flow control valve to actuate and move the flow control valve to control flow of the liquid between the inlet and the outlet when the poppet is engaged with the valve seat.
F16K 11/02 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with all movable sealing faces moving as one unit
13.
BYPASS VALVE ASSEMBLY WITH INTEGRATED FLOW CONTROL VALVE
A bypass valve assembly includes a housing having an inlet, an outlet, and a flow passageway to allow flow of a liquid from the inlet to the outlet and a valve seat disposed about the flow passageway between the inlet and the outlet. A movable poppet is disposed in the housing to engage the valve seat in a closed position and to disengage the valve seat in an open position when pressure of the liquid in the flow passageway exceeds a preset value to allow flow of the liquid through the flow passageway. A rotatable flow control valve is disposed in the housing between the inlet and the outlet. An actuator is coupled to the flow control valve to actuate and move the flow control valve to control flow of the liquid between the inlet and the outlet when the poppet is engaged with the valve seat.
B66F 9/00 - Devices for lifting or lowering bulky or heavy goods for loading or unloading purposes
B67D 7/36 - Arrangements of flow- or pressure-control valves
F16K 11/08 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with all movable sealing faces moving as one unit comprising only taps or cocks
F16K 17/04 - Safety valvesEqualising valves opening on surplus pressure on one sideSafety valvesEqualising valves closing on insufficient pressure on one side spring-loaded
A dielectric fitting for a pressure regulator includes a flange adapted to be disposed next to a housing of the pressure regulator, an isolator plate disposed next to the flange and adapted to be disposed between the flange and the housing, and an isolator cover disposed between the flange and the isolator plate to electrically isolate the flange from the housing.
F16L 25/02 - Construction or details of pipe joints not provided for in, or of interest apart from, groups specially adapted for electrically insulating the two pipe ends of the joint from each other
G05D 16/06 - Control of fluid pressure without auxiliary power the sensing element being a flexible member yielding to pressure, e.g. diaphragm, bellows, capsule
A dielectric fitting for a pressure regulator includes a flange adapted to be disposed next to a housing of the pressure regulator, an isolator plate disposed next to the flange and adapted to be disposed between the flange and the housing, and an isolator cover disposed between the flange and the isolator plate to electrically isolate the flange from the housing.
F16K 7/12 - Diaphragm cut-off apparatus, e.g. with a member deformed, but not moved bodily, to close the passage with flat, dished, or bowl-shaped diaphragm
A valve assembly includes a housing having an inlet and an outlet spaced from each other, a first chamber defining the inlet, a second chamber defining the outlet, and a valve seat disposed between the first and second chambers, wherein fluid communicates between the first and second chambers. A valve head is disposed in the housing and moveable relative to the housing between an open position spaced from the valve seat and a closed position engaged with the valve seat. A valve stem is coupled to the valve head for moving the valve head between the open and closed positions. The valve stem is coupled to the valve head and rotatably and reciprocally movable for moving the valve head between the open and closed positions. A retainer plate is coupled to the valve head and a valve seal is disposed between the valve head and the retainer plate. The valve head includes an integrally formed rivet that secures the retainer plate to the valve head, thereby retaining the valve seal to the valve head.
F16K 1/48 - Attaching valve members to valve-spindles
F16K 1/10 - Special arrangements for improving the flow, e.g. special shape of passages or casings in which the spindle is inclined to the general direction of flow
F16K 39/02 - Devices for relieving the pressure on the sealing faces for lift valves
F16K 43/00 - Auxiliary closure means in valves, which in case of repair, e.g. rewashering, of the valve, can take over the function of the normal closure meansDevices for temporary replacement of parts of valves for the same purpose
F16K 15/18 - Check valves with actuating mechanismCombined check valves and actuated valves
F16K 31/50 - Mechanical actuating means with screw-spindle
A float gauge assembly for a storage tank having a port with an opening includes a body for attachment to the port of the storage tank and a gauge mountable to the body, the gauge having a gauge face for indicating a level or amount of material present in the storage tank, a float mechanism mounted to the body and cooperating with the gauge, the float mechanism including a float movable relative to the body in an operating position, the float being sized so that the float is unable to be inserted into the storage tank though the opening in the port, and a tube coupled to the float and having a dimension sized for inserting through the opening in the port, and an alignment element configured to rotationally fix the tube to the body when the float is in the operating position so that the gauge face accurately indicates the level of material in the storage tank when mounted to the body.
G01F 23/34 - Indicating or measuring liquid level or level of fluent solid material, e.g. indicating in terms of volume or indicating by means of an alarm by floats using rotatable arms or other pivotable transmission elements using mechanically actuated indicating means
B23P 19/04 - Machines for simply fitting together or separating metal parts or objects, or metal and non-metal parts, whether or not involving some deformationTools or devices therefor so far as not provided for in other classes for assembling or disassembling parts
A pressure regulator for installing in a fluid flow system. The pressure regulator comprises a body and an identification device coupled to the body. The identification device has a first portion with first identification information and a second portion with second identification information. The second portion of the identification device is separated from the pressure regulator while the first portion of the identification device remains coupled to the pressure regulator. The second portion of the identification device is then affixed to a surface, such as a form.
G09F 3/10 - Fastening or securing by means not forming part of the material of the label itself by an adhesive layer
F16L 55/00 - Devices or appurtenances for use in, or in connection with, pipes or pipe systems
G01M 3/28 - Investigating fluid tightness of structures by using fluid or vacuum by measuring rate of loss or gain of fluid, e.g. by pressure-responsive devices, by flow detectors for pipes, cables, or tubesInvestigating fluid tightness of structures by using fluid or vacuum by measuring rate of loss or gain of fluid, e.g. by pressure-responsive devices, by flow detectors for pipe joints or sealsInvestigating fluid tightness of structures by using fluid or vacuum by measuring rate of loss or gain of fluid, e.g. by pressure-responsive devices, by flow detectors for valves
B21D 39/00 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders
A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve and a pilot valve. An actuator controls both the main valve and the pilot valve. A cam plate interconnects the actuator and the valve assembly. The cam plate provides a quick acting shutoff to quickly move the valve assembly to the closed position. A pivotal and rotatable connector couples the transfer device to the dry break coupler. A lock is integrated with the actuator to lock the valve assembly in the closed position.
F16K 31/143 - Operating meansReleasing devices actuated by fluid for mounting on, or in combination with, hand-actuated valves the fluid acting on a piston
F16K 35/04 - Means to prevent accidental or unauthorised actuation yieldingly resisting the actuation
F16L 29/04 - Joints with fluid cut-off means with a cut-off device in each of the two pipe ends, the cut-off devices being automatically opened when the coupling is applied
F16L 37/36 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings with two lift valves being actuated to initiate the flow through the coupling after the two coupling parts are locked against withdrawal
A method of documenting installation of a fluid handling device in a fluid flow system using a form and an identification device. The identification device has a first portion with first identification information and a second portion with second identification information. The method comprises installing the fluid handling device in the fluid flow system. The method further comprises checking for leaks associated with the fluid handling device installed in the fluid flow system. The second portion of the identification device is separated from the fluid handling device while the first portion of the identification device remains coupled to the fluid handling device after checking for leaks. The second portion of the identification device is then affixed to the form.
B21D 39/00 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders
F16L 55/00 - Devices or appurtenances for use in, or in connection with, pipes or pipe systems
G01M 3/28 - Investigating fluid tightness of structures by using fluid or vacuum by measuring rate of loss or gain of fluid, e.g. by pressure-responsive devices, by flow detectors for pipes, cables, or tubesInvestigating fluid tightness of structures by using fluid or vacuum by measuring rate of loss or gain of fluid, e.g. by pressure-responsive devices, by flow detectors for pipe joints or sealsInvestigating fluid tightness of structures by using fluid or vacuum by measuring rate of loss or gain of fluid, e.g. by pressure-responsive devices, by flow detectors for valves
06 - Common metals and ores; objects made of metal
08 - Hand tools and implements
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
(1) Non-machine element metal valves, namely, manually operated valves, flow valves, angle valves, check valves, vent valves, transfer valves, combination valves, pressure relief valves, control valves for the storage, delivery or dispensing of gas or liquid materials; equipment not forming part of a machine and primarily made of metal, namely, piping, namely, metal pipes for liquid and gas transfer, connections, namely, metal pipe connections, and fittings for metal pipes liquid and gas transfer; hand tools, namely, installation tools for the purpose of installing regulators, valves, piping, connections, and fittings; environmental control apparatuses, namely, pressure regulators for gas installations, namely, steam generating installations and heating installations.
26.
METHOD OF DOCUMENTING INSTALLATION OF A FLUID HANDLING DEVICE IN A FLUID FLOW SYSTEM
A method of documenting installation of a fluid handling device in a fluid flow system using a form and an identification device. The identification device has a first portion with first identification information and a second portion with second identification information. The method comprises installing the fluid handling device in the fluid flow system. The method further comprises checking for leaks associated with the fluid handling device installed in the fluid flow system. The second portion of the identification device is separated from the fluid handling device while the first portion of the identification device remains coupled to the fluid handling device after checking for leaks. The second portion of the identification device is then affixed to the form.
06 - Common metals and ores; objects made of metal
09 - Scientific and electric apparatus and instruments
Goods & Services
EQUIPMENT NOT FORMING PART OF A MACHINE AND PRIMARILY MADE OF METAL, NAMELY, MANUALLY OPERATED VALVES; PIPING, NAMELY, METAL PIPING; CONNECTIONS, NAMELY, METAL PIPE CONNECTORS; METAL PIPE FITTINGS FOR PIPE SYSTEMS USED FOR THE STORAGE, DELIVERY OR DISPENSING OF GAS OR LIQUID MATERIALS Control valves for regulating the flow of gases and liquids, namely, flow valves, angle valves, check valves, vent valves, transfer valves, combination valves, pressure relief valves, control valves
A fluid connector having a longitudinal axis and selective open and closed conditions, includes an elongate conduit member extending along the longitudinal axis, an annular collar disposed about and having axial movement relative to the conduit member between the connector open and closed conditions, and a plurality of split nut members circumferentially distributed about the conduit member and having axial movement relative to the collar between the connector open and closed conditions. The plurality of split nut members and the collar are jointly rotatably about the longitudinal axis, and each split nut member has a distal end defining a threaded nut segment. The split nut member distal ends in the connector closed condition are constrained by the collar against radially separating movement relative to the longitudinal axis and cooperatively define a nut configured to threadedly engage a mating fluid fitting.
F16L 21/06 - Joints with sleeve or socket with a divided sleeve or ring clamping around the pipe ends
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve and a pilot valve. An actuator controls both the main valve and the pilot valve. A cam plate interconnects the actuator and the valve assembly. The cam plate provides a quick acting shutoff to quickly move the valve assembly to the closed position. A pivotal and rotatable connector couples the transfer device to the dry break coupler. A lock is integrated with the actuator to lock the valve assembly in the closed position.
F16L 27/02 - Universal joints, i.e. with mechanical connection allowing angular movement or adjustment of the axes of the parts in any direction
F16L 29/04 - Joints with fluid cut-off means with a cut-off device in each of the two pipe ends, the cut-off devices being automatically opened when the coupling is applied
F16L 37/36 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings with two lift valves being actuated to initiate the flow through the coupling after the two coupling parts are locked against withdrawal
B67D 7/36 - Arrangements of flow- or pressure-control valves
A valve assembly for mounting a pump to a storage tank of a vehicle includes an upper flange, a lower flange, and a wall extending axially between the upper flange and the lower flange, the lower flange being offset by the wall relative to the upper flange to facilitate installation of the pump on the vehicle.
A float gauge assembly for a storage tank having a port with an opening includes a body for attachment to the port of the storage tank and a gauge mountable to the body, the gauge having a gauge face for indicating a level or amount of material present in the storage tank, a float mechanism mounted to the body and cooperating with the gauge, the float mechanism including a float movable relative to the body in an operating position, the float being sized so that the float is unable to be inserted into the storage tank though the opening in the port, and a tube coupled to the float and having a dimension sized for inserting through the opening in the port, and an alignment element configured to rotationally fix the tube to the body when the float is in the operating position so that the gauge face accurately indicates the level of material in the storage tank when mounted to the body.
G01F 23/34 - Indicating or measuring liquid level or level of fluent solid material, e.g. indicating in terms of volume or indicating by means of an alarm by floats using rotatable arms or other pivotable transmission elements using mechanically actuated indicating means
32.
Valve assembly including pressure relief mechanism
A valve assembly includes a housing having a first chamber, a second chamber, a valve seat disposed between the first chamber and the second chamber, a valve head disposed in the housing and moveable relative to the housing, a valve stem operatively coupled to the valve head for moving the valve head between the open and closed positions, and a pressure relief mechanism including a plug coupled to the valve stem and extending along a plug axis in the bore of the valve head moveable relative to the valve head from a sealed position preventing fluid communication through the bore to an unsealed position allowing fluid communication through the bore for relieving pressure differences between the first chamber and the second chamber when the valve head is in the closed position.
F16K 39/02 - Devices for relieving the pressure on the sealing faces for lift valves
F16K 1/20 - Lift valves, i.e. cut-off apparatus with closure members having at least a component of their opening and closing motion perpendicular to the closing faces with pivoted closure members with pivoted discs or flaps with axis of rotation arranged externally of valve member
A pressure regulator includes a housing having an upper housing portion and a lower housing portion, the lower housing portion defining an annular recess and the upper housing portion having a bottom surface, an annular protrusion extending from the bottom surface, a diaphragm disposed between the upper housing portion and the lower housing portion, the diaphragm including an outer lip having a first thickness, a flexible connecting section connected to the outer lip and having a second thickness smaller than the first thickness, and an annular inner section connected to the flexible connecting section, the outer lip having a bottom surface disposed in the annular recess and a top surface, and the protrusion being pressed into the top surface so that the outer lip seals between the upper housing portion and the lower housing portion.
G05D 16/06 - Control of fluid pressure without auxiliary power the sensing element being a flexible member yielding to pressure, e.g. diaphragm, bellows, capsule
A float gauge assembly for a storage tank having a port with an opening includes a body for attachment to the port of the storage tank and a gauge mountable to the body, the gauge having a gauge face for indicating a level or amount of material present in the storage tank, a float mechanism mounted to the body and cooperating with the gauge, the float mechanism including a float movable relative to the body in an operating position, the float being sized so that the float is unable to be inserted into the storage tank though the opening in the port, and a tube coupled to the float and having a dimension sized for inserting through the opening in the port, and an alignment element configured to rotationally fix the tube to the body when the float is in the operating position so that the gauge face accurately indicates the level of material in the storage tank when mounted to the body.
G01F 23/30 - Indicating or measuring liquid level or level of fluent solid material, e.g. indicating in terms of volume or indicating by means of an alarm by floats
G01F 23/32 - Indicating or measuring liquid level or level of fluent solid material, e.g. indicating in terms of volume or indicating by means of an alarm by floats using rotatable arms or other pivotable transmission elements
A valve assembly for mounting a pump to a storage tank of a vehicle includes an upper flange, a lower flange, and a wall extending axially between the upper flange and the lower flange, the lower flange being offset by the wall relative to the upper flange to facilitate installation of the pump on the vehicle.
A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve moveable between a closed-main valve position and an open-main valve position in response to movement of an actuator and a pilot valve moveable between a closed-pilot valve position and an open-pilot valve position in response to movement of the actuator. A configuration of the coupler and the transfer device is coupled together, the coupler valve being in the closed-coupler valve position and the main valve being in the closed-main valve position. A space between a face of the main valve and a face of the coupler valve is minimized to reduce fluid emissions upon uncoupling the transfer device from the coupler.
F16L 37/36 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings with two lift valves being actuated to initiate the flow through the coupling after the two coupling parts are locked against withdrawal
F16L 27/02 - Universal joints, i.e. with mechanical connection allowing angular movement or adjustment of the axes of the parts in any direction
F16L 29/04 - Joints with fluid cut-off means with a cut-off device in each of the two pipe ends, the cut-off devices being automatically opened when the coupling is applied
A valve assembly includes a housing having a first chamber, a second chamber, and a valve seat disposed therebetween. A valve head disposed in the housing and is moveable between an open position and a closed position. The valve head defines a bore extending along an axis from the first chamber to the second chamber when the valve head is in the closed position. A valve stem is disposed in the bore and is coupled to the valve head in the bore for moving the valve head between the open and closed positions. The valve assembly allows for selective fluid communication between the first and second chambers to alleviate pressure differences between the first and second chambers. In one embodiment, the valve stem moves in the bore between a sealed position and an unsealed position. In another embodiment, a check valve is disposed in the bore.
F16K 39/02 - Devices for relieving the pressure on the sealing faces for lift valves
F16K 1/10 - Special arrangements for improving the flow, e.g. special shape of passages or casings in which the spindle is inclined to the general direction of flow
F16K 1/48 - Attaching valve members to valve-spindles
F16K 43/00 - Auxiliary closure means in valves, which in case of repair, e.g. rewashering, of the valve, can take over the function of the normal closure meansDevices for temporary replacement of parts of valves for the same purpose
A valve assembly includes a housing defining a cavity and a bore which opens into the cavity. A valve member is disposed in the cavity. The valve member moves between an open position for allowing fluid flow through the housing and a closed position for preventing fluid flow through the housing. An actuator extends through the bore for moving the valve member between the open and closed positions. A packing is positionable in the bore to provide a seal about the actuator for preventing fluid from exiting the housing through the bore. The packing is ejectable from the bore. The valve assembly includes a first and second biasing member. The first biasing member is configured to apply a first force to the packing to provide the seal. The second biasing member is configured to apply a second force to the packing for ejecting the packing from the bore.
A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve and a pilot valve. An actuator controls both the main valve and the pilot valve. A cam plate interconnects the actuator and the valve assembly. The cam plate provides a quick acting shutoff to quickly move the valve assembly to the closed position. A pivotal and rotatable connector couples the transfer device to the dry break coupler. A lock is integrated with the actuator to lock the valve assembly in the closed position.
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Internal valves, shutoff valves, and excess flow valves for controlling the flow of gases and liquids.
(2) Control valves for regulating the flow of gasses and liquids.
A gas convenience outlet is provided for connecting an outdoor grill or other outdoor gas fired appliance to a home gas supply or other fixed position source of fuel gas, such as natural gas or liquid petroleum gas. The outlet includes a case having an open interior and an openable cover with a manifold mounted in the interior. The manifold has an inlet operatively connected with the supply of fuel gas and has one or more outlets. A primary manual shutoff valve located in the interior of the case is operatively connected with the manifold outlet. The outlet includes an outlet connector extending outside the case. The connector has a standardized fitting that releasably couples in gas tight engagement with one or more gas fired appliances by means of standardized appliance connectors, without the need for adaptors and without a loss of performance due to restriction of the gas supply.
A fluid connector having a longitudinal axis and selective open and closed conditions, the connector only in its closed condition adapted to threadedly engage a mating fluid fitting. The fluid connector includes an elongate conduit member extending along the longitudinal axis, an annular collar disposed about and having axial movement relative to the conduit member between the connector open and closed conditions, and a plurality of split nut members circumferentially distributed about the conduit member and having axial movement relative to the collar between the connector open and closed conditions. The plurality of split nut members and the collar are jointly rotatably about the longitudinal axis, and each split nut member has a distal end defining a threaded nut segment. The split nut member distal ends in the connector closed condition are constrained by the collar against radially separating movement relative to the longitudinal axis and cooperatively define a nut configured to threadedly engage a mating fluid fitting. The split nut member distal ends in the connector open condition have an expanded configuration in which, relative to the connector closed condition, they are radially separated from the longitudinal axis and not cooperatively positioned to threadedly engage a mating fluid fitting.
F16L 39/00 - Joints or fittings for double-walled or multi-channel pipes or pipe assemblies
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
F16L 37/32 - Couplings of the quick-acting type with fluid cut-off means with fluid cut-off means in each of two pipe-end fittings at least one of two lift valves being opened automatically when the coupling is applied
A system for disabling a vehicle carrying a storage tank includes a coupler component supported by the vehicle for receiving a connection from a delivery line. A cap is attachable to an end of the coupler component for preventing connection of the delivery line when the cap is attached. A proximity sensor is disposed outside of the coupler component and senses whether the cap is attached without making contact with the cap. A switch is in electrically connected to the sensor and disables at least one drive element of the vehicle, e.g., the transmission, when the cap is not attached to the coupler component.
A system for disabling a vehicle carrying a substance in a storage tank includes a holster defining a cavity for receiving a nozzle in fluidic connection to the storage tank when not in use. The holster includes a main body and a bracket. The bracket is affixable to the vehicle and engagable with the main body at a plurality of positions along the main body. The system further includes a sensor for sensing whether the nozzle is received in the holster. The sensor is also in communication with at least one drive element of the vehicle to disable the at least one drive element when the nozzle is not received within the holster.
B60K 28/00 - Safety devices for propulsion-unit control, specially adapted for, or arranged in, vehicles, e.g. preventing fuel supply or ignition in the event of potentially dangerous conditions
A system for disabling a vehicle carrying a substance in a storage tank includes a holster defining a cavity for receiving a nozzle in fluidic connection to the storage tank when not in use. The holster includes a main body and a bracket. The bracket is affixable to the vehicle and engagable with the main body at a plurality of positions along the main body. The system further includes a sensor for sensing whether the nozzle is received in the holster. The sensor is also in communication with at least one drive element of the vehicle to disable the at least one drive element when the nozzle is not received within the holster.
B60K 28/10 - Safety devices for propulsion-unit control, specially adapted for, or arranged in, vehicles, e.g. preventing fuel supply or ignition in the event of potentially dangerous conditions responsive to conditions relating to the vehicle
A system for disabling a vehicle carrying a storage tank includes a coupler component supported by the vehicle for receiving a connection from a delivery line. A cap is attachable to an end of the coupler component for preventing connection of the delivery line when the cap is attached. A proximity sensor is disposed outside of the coupler component and senses whether the cap is attached without making contact with the cap. A switch is in electrically connected to the sensor and disables at least one drive element of the vehicle, e.g., the transmission, when the cap is not attached to the coupler component.
B60K 28/10 - Safety devices for propulsion-unit control, specially adapted for, or arranged in, vehicles, e.g. preventing fuel supply or ignition in the event of potentially dangerous conditions responsive to conditions relating to the vehicle
A valve assembly includes a housing having a first chamber, a second chamber, and a valve seat disposed therebetween. A valve head disposed in the housing and is moveable between an open position and a closed position. The valve head defines a bore extending along an axis from the first chamber to the second chamber when the valve head is in the closed position. A valve stem is disposed in the bore and is coupled to the valve head in the bore for moving the valve head between the open and closed positions. The valve assembly allows for selective fluid communication between the first and second chambers to alleviate pressure differences between the first and second chambers. In one embodiment, the valve stem moves in the bore between a sealed position and an unsealed position. In another embodiment, a check valve is disposed in the bore.
F16K 1/10 - Special arrangements for improving the flow, e.g. special shape of passages or casings in which the spindle is inclined to the general direction of flow
F16K 1/54 - Arrangements for modifying the way in which the rate of flow varies during the actuation of the valve
F16K 25/02 - Arrangements using fluid issuing from valve members or seats
F16K 39/02 - Devices for relieving the pressure on the sealing faces for lift valves
A valve assembly includes a housing having a first chamber, a second chamber, and a valve seat disposed therebetween. A valve head disposed in the housing and is moveable between an open position and a closed position. The valve head defines a bore extending along an axis from the first chamber to the second chamber when the valve head is in the closed position. A valve stem is disposed in the bore and is coupled to the valve head in the bore for moving the valve head between the open and closed positions. The valve assembly allows for selective fluid communication between the first and second chambers to alleviate pressure differences between the first and second chambers. In one embodiment, the valve stem moves in the bore between a sealed position and an unsealed position. In another embodiment, a check valve is disposed in the bore.
F16K 1/10 - Special arrangements for improving the flow, e.g. special shape of passages or casings in which the spindle is inclined to the general direction of flow
F16K 1/54 - Arrangements for modifying the way in which the rate of flow varies during the actuation of the valve
F16K 25/02 - Arrangements using fluid issuing from valve members or seats
F16K 39/02 - Devices for relieving the pressure on the sealing faces for lift valves
A valve assembly includes a housing having a first chamber, a second chamber, and a valve seat disposed therebetween. A valve head disposed in the housing and is moveable between an open position and a closed position. The valve head defines a bore extending along an axis from the first chamber to the second chamber when the valve head is in the closed position. A valve stem is disposed in the bore and is coupled to the valve head in the bore for moving the valve head between the open and closed positions. The valve assembly allows for selective fluid communication between the first and second chambers to alleviate pressure differences between the first and second chambers. In one embodiment, the valve stem moves in the bore between a sealed position and an unsealed position. In another embodiment, a check valve is disposed in the bore.
F16K 39/02 - Devices for relieving the pressure on the sealing faces for lift valves
F16K 1/02 - Lift valves, i.e. cut-off apparatus with closure members having at least a component of their opening and closing motion perpendicular to the closing faces with screw-spindle
A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve and a pilot valve. An actuator controls both the main valve and the pilot valve. A cam plate interconnects the actuator and the valve assembly. The cam plate provides a quick acting shutoff to quickly move the valve assembly to the closed position. A pivotal and rotatable connector couples the transfer device to the dry break coupler. A lock is integrated with the actuator to lock the valve assembly in the closed position.
A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve and a pilot valve. An actuator controls both the main valve and the pilot valve. A cam plate interconnects the actuator and the valve assembly. The cam plate provides a quick acting shutoff to quickly move the valve assembly to the closed position. A pivotal and rotatable connector couples the transfer device to the dry break coupler. A lock is integrated with the actuator to lock the valve assembly in the closed position.
A fluid transfer device includes a housing defining a longitudinal axis and a first race. The fluid transfer device includes an actuator having a grasping portion movable relative to the housing. A valve assembly is disposed in the housing and is operatively coupled to the actuator. A connector is pivotally and rotatably coupled to the housing and is threaded to engage a receiver. The connector defines a second race. Bearing members are disposed on the first and second races for allowing rotational movement of the connector relative to the housing. The first and second races enable pivoting of the connector between different angular positions relative to the longitudinal axis to ease coupling of the fluid transfer device to the threaded receiver.
ABSTRACT Or THE DISCLOSURE A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve and a pilot valve. An actuator controls both the main. valve and the pilot valve. A cam plate interconnects the actuator and the valve assembly. The cam plate provides a quick acting shutoff to quickly move the valve assembly to the closed position. A pivotal and rotatable connector couples the transfer device to the dry break coupler. A lock is integrated with the actuator to lock the valve assembly in the closed position. to = . . Date Recue/Date Received 2021-02-22
A fluid transfer system includes a transfer device coupled to a dry break coupler. The transfer device includes a valve assembly moveable between an open and a closed position. The valve assembly includes a main valve and a pilot valve. An actuator controls both the main valve and the pilot valve. A cam plate interconnects the actuator and the valve assembly. The cam plate provides a quick acting shutoff to quickly move the valve assembly to the closed position. A pivotal and rotatable connector couples the transfer device to the dry break coupler. A lock is integrated with the actuator to lock the valve assembly in the closed position.
An improved fuel line connector for connecting a fuel line connection valve to a fuel cylinder outlet valve includes an improved, replaceable tip seal mounted on the tip or nose of the connector valve. The tip seal provides an additional, effective face seal between the connector body and the cylinder outlet valve. The tip seal, being on the fuel line connector, can be maintained and replaced by the party using the vehicle or filling the fuel cylinder.
A self-cleaning bleeder valve comprises an annular housing that is mounted in an opening in a pressure vessel, and a valve member that screws into the housing for movement toward and away from an orifice opening in the housing. The valve member includes a gasket seal and orifice drill at an inner end of the valve member. The orifice is positioned such that when the valve member is screwed into the annular housing, the drill extends through the orifice, automatically cleaning the orifice while restricting the rate of gas flow out of the orifice to the space between the drill and the orifice.
