A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
The present invention provides a method for producing a full engagement Pittsburgh male lock using specific cutting assemblies and protocols that reduce the amount of metal that is removed from the male portion of the corner notches in the duct. Forming of the male portion of the lock is done after the connecting flange forming has been completed as opposed to before the connecting flange forming has been completed.
F16L 13/14 - Non-disconnectable pipe joints, e.g. soldered, adhesive, or caulked joints made by plastically deforming the material of the pipe, e.g. by flanging, rolling
B21D 19/00 - Flanging or other edge treatment, e.g. of tubes
B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
F16L 23/14 - Flanged joints specially adapted for particular pipes for rectangular pipes
Disclosed is a cutting apparatus and method of cutting an insulative material. Said insulative material may be either flexible or rigid in nature. The insulative material is cut via a passive cutting wheel driven across a platen and engaged to a stationary drive belt about the passive cutting wheel axis. Engagement of the stationary drive belt with the passive cutting wheel axis results in a turning of the passive cutting wheel.
B23D 53/04 - Machines or devices for sawing with strap saw blades which are effectively endless in use, e.g. for contour cutting with the wheels carrying the strap mounted shiftably or swingingly, other than merely for adjustment
B23D 55/06 - Sawing machines or sawing devices working with strap saw blades, characterised only by constructional features of particular parts of drives for strap saw bladesSawing machines or sawing devices working with strap saw blades, characterised only by constructional features of particular parts of wheel mountings
B23D 59/00 - Accessories specially designed for sawing machines or sawing devices
B23D 51/16 - Sawing machines or sawing devices working with straight blades, characterised only by constructional features of particular partsCarrying or attaching means for tools, covered by this subclass, which are connected to a carrier at both ends of drives or feed mechanisms for straight tools, e.g. saw blades, or bows
The present invention provides a method for producing a full engagement Pittsburgh male lock using specific cutting assemblies and protocols that reduce the amount of metal that is removed from the male portion of the corner notches in the duct. Forming of the male portion of the lock is done after the connecting flange forming has been completed as opposed to before the connecting flange forming has been completed.
F16L 13/14 - Non-disconnectable pipe joints, e.g. soldered, adhesive, or caulked joints made by plastically deforming the material of the pipe, e.g. by flanging, rolling
B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
F16L 23/14 - Flanged joints specially adapted for particular pipes for rectangular pipes
9.
SYSTEM AND METHOD FOR FORMING A FULL ENGAGEMENT MALE LOCK IN A DUCTLINE
The present invention provides a method for producing a full engagement Pittsburgh male lock using specific cutting assemblies and protocols that reduce the amount of metal that is removed from the male portion of the corner notches in the duct. Forming of the male portion of the lock is done after the connecting flange forming has been completed as opposed to before the connecting flange forming has been completed.
A method of forming a duct section from a web of material includes the steps of forming a series of perforations in a web of material, the series of perforations defining an outline of one of a hole or notch in a finished duct section, forming a male lock bend and a female lock seam in first opposed edges of the web of material, forming flanges in second opposed edges of the web of material, removing the portion of material interior to the series of perforations to form the hole or notch, and bending the web of material to form the finished duct section.
A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
An evaporative cooling system includes an indirect cooling coil containing a cooling fluid to be circulated and a blower assembly configured to generate an inlet air stream through the indirect cooling coil. The cooling fluid in the indirect cooling coil is a slurry of water and phase change material.
F28D 15/00 - Heat-exchange apparatus with the intermediate heat-transfer medium in closed tubes passing into or through the conduit walls
F28D 20/02 - Heat storage plants or apparatus in generalRegenerative heat-exchange apparatus not covered by groups or using latent heat
F28F 23/00 - Features relating to the use of intermediate heat-exchange materials, e.g. selection of compositions
F28C 1/14 - Direct-contact trickle coolers, e.g. cooling towers comprising also a non-direct contact heat exchange
F28D 5/00 - Heat-exchange apparatus having stationary conduit assemblies for one heat-exchange medium only, the media being in contact with different sides of the conduit wall, using the cooling effect of natural or forced evaporation
F28D 20/00 - Heat storage plants or apparatus in generalRegenerative heat-exchange apparatus not covered by groups or
A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
B23K 26/08 - Devices involving relative movement between laser beam and workpiece
B23K 26/12 - Working by laser beam, e.g. welding, cutting or boring in a special environment or atmosphere, e.g. in an enclosure
B23K 26/14 - Working by laser beam, e.g. welding, cutting or boring using a fluid stream, e.g. a jet of gas, in conjunction with the laser beamNozzles therefor
B23K 26/38 - Removing material by boring or cutting
B23K 37/00 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass
B23K 37/02 - Carriages for supporting the welding or cutting element
A method of forming a duct section from a web of material includes the steps of forming a series of perforations in a web of material, the series of perforations defining an outline of one of a hole or notch in a finished duct section, forming a male lock bend and a female lock seam in first opposed edges of the web of material, forming flanges in second opposed edges of the web of material, removing the portion of material interior to the series of perforations to form the hole or notch, and bending the web of material to form the finished duct section.
A duct making apparatus includes a first station configured to accept a formable sheet material and a second station configured to receive the formable sheet material from the first station. The first station includes a mechanism for forming one of a male lock bend and a female lock seam in a leading edge of the formable sheet material. The second station includes a retractable conveyor. Movement of the sheet material from the first station to the second station defines an axis of travel of the sheet material. The retractable conveyor is selectively movable from a first position in which the retractable conveyor is in close association with the first station, and a second position in which the retractable conveyor is spaced from the first station.
B21D 5/10 - Bending sheet metal along straight lines, e.g. to form simple curves by drawing procedure making use of dies or forming-rollers, e.g. making profiles for making tubes
B21D 43/02 - Advancing work in relation to the stroke of the die or tool
B21D 5/01 - Bending sheet metal along straight lines, e.g. to form simple curves between rams and anvils or abutments
B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
A carrier for seam formation and sealing comprising a roller assembly having at least one roller; a housing for holding the roller assembly; a fastening member for mounting the roller to the housing; and the fastening member is an interchangeable mechanism.
B21D 5/14 - Bending sheet metal along straight lines, e.g. to form simple curves by passing between rollers
F16B 5/00 - Joining sheets or plates to one another or to strips or bars parallel to them
B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
F16L 23/14 - Flanged joints specially adapted for particular pipes for rectangular pipes
A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
A sealant system for operation with a metal workpiece comprises a frame, a cam assembly mounted to said frame, a sealant reservoir, a sealant application unit connected to said sealant reservoir, and a control module for coordinating operation of said cam assembly and said sealant reservoir, wherein said control module comprises a temperature sensor for monitoring the temperature of said sealant, an integrated heating system for heating said sealant and a controller in communication with said temperature sensor and said integrated heating system.
B05B 7/16 - Spraying apparatus for discharge of liquids or other fluent materials from two or more sources, e.g. of liquid and air, of powder and gas incorporating means for heating the material to be sprayed
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 9/04 - Apparatus or plant for applying liquid or other fluent material to surfaces by means not covered by groups , or in which the means of applying the liquid or other fluent material is not important for applying liquid or other fluent material to opposite sides of the work
B05C 13/00 - Means for manipulating or holding work, e.g. for separate articles
A sealant system for operation with a metal workpiece comprises a frame, a cam assembly mounted to the frame, a sealant reservoir, a sealant application unit connected to the sealant reservoir, and a control module for coordinating operation of the cam assembly and the sealant reservoir, wherein the control module comprises a temperature sensor for monitoring the temperature of the sealant, an integrated heating system for heating the sealant and a controller in communication with the temperature sensor and the integrated heating system.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 9/04 - Apparatus or plant for applying liquid or other fluent material to surfaces by means not covered by groups , or in which the means of applying the liquid or other fluent material is not important for applying liquid or other fluent material to opposite sides of the work
B05C 13/00 - Means for manipulating or holding work, e.g. for separate articles
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05B 7/16 - Spraying apparatus for discharge of liquids or other fluent materials from two or more sources, e.g. of liquid and air, of powder and gas incorporating means for heating the material to be sprayed
A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
A method of forming a duct section from a web of material includes the steps of forming a series of perforations in a web of material, the series of perforations defining an outline of one of a hole or notch in a finished duct section, forming a male lock bend and a female lock seam in first opposed edges of the web of material, forming flanges in second opposed edges of the web of material, removing the portion of material interior to the series of perforations to form the hole or notch, and bending the web of material to form the finished duct section.
B26F 1/28 - Perforating by non-mechanical means, e.g. by fluid jet by electrical discharges
B26D 5/00 - Arrangements for operating and controlling machines or devices for cutting, cutting-out, stamping-out, punching, perforating, or severing by means other than cutting
B26D 7/00 - Details of apparatus for cutting, cutting-out, stamping-out, punching, perforating, or severing by means other than cutting
A method of forming a duct section from a web of material includes the steps of forming a series of perforations in a web of material, the series of perforations defining an outline of one of a hole or notch in a finished duct section, forming a male lock bend and a female lock seam in first opposed edges of the web of material, forming flanges in second opposed edges of the web of material, removing the portion of material interior to the series of perforations to form the hole or notch, and bending the web of material to form the finished duct section.
A method of forming a duct section from a web of material includes the steps of forming a series of perforations in a web of material, the series of perforations defining an outline of one of a hole or notch in a finished duct section, forming a male lock bend and a female lock seam in first opposed edges of the web of material, forming flanges in second opposed edges of the web of material, removing the portion of material interior to the series of perforations to form the hole or notch, and bending the web of material to form the finished duct section.
A flanged duct blank has a male part defined by lead notches formed at each side of a leading end and has a female part defined by trail notches formed at each side of a trailing end. The male part includes a lock tab. The female part includes a leg part and a Z-bend. The Z-bend includes a leg part and a gap. The duct blank is repeatedly clamped and bent by a pivoting wiper to form a duct portion. The pivoting wiper includes a clench tool that has a retractable rib and a retractable roller. With the lock tab inserted into the Z-bend and the retractable rib engaged with the Z-bend, the retractable roller clenches the leg part over the lock tab to lock the male and female parts together in a duct seam.
F16L 25/00 - Construction or details of pipe joints not provided for in, or of interest apart from, groups
B21D 5/04 - Bending sheet metal along straight lines, e.g. to form simple curves on brakes making use of clamping means on one side of the work
B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
A laser cutting tool with protective enclosure assembly for manipulating a workpiece on a movable platen includes a frame, a top protection assembly, a middle protection shield, a bottom protection assembly and a laser torch head. The top protection assembly, middle protection assembly, and bottom protection assembly are removably mounted to the frame such that they form a cavity enclosing only substantially the laser torch head.
A duct making apparatus includes a first station configured to accept a formable sheet material and a second station configured to receive the formable sheet material from the first station. The first station includes a mechanism for forming one of a male lock bend and a female lock seam in a leading edge of the formable sheet material. The second station includes a retractable conveyor. Movement of the sheet material from the first station to the second station defines an axis of travel of the sheet material. The retractable conveyor is selectively movable from a first position in which the retractable conveyor is in close association with the first station, and a second position in which the retractable conveyor is spaced from the first station.
B21D 5/10 - Bending sheet metal along straight lines, e.g. to form simple curves by drawing procedure making use of dies or forming-rollers, e.g. making profiles for making tubes
A sealant system for operation with a metal workpiece comprises a frame, a cam assembly mounted to said frame, a sealant reservoir, a sealant application unit connected to said sealant reservoir, and a control module for coordinating operation of said cam assembly and said sealant reservoir, wherein said control module comprises a temperature sensor for monitoring the temperature of said sealant, an integrated heating system for heating said sealant and a controller in communication with said temperature sensor and said integrated heating system.
B05B 7/16 - Spraying apparatus for discharge of liquids or other fluent materials from two or more sources, e.g. of liquid and air, of powder and gas incorporating means for heating the material to be sprayed
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 9/04 - Apparatus or plant for applying liquid or other fluent material to surfaces by means not covered by groups , or in which the means of applying the liquid or other fluent material is not important for applying liquid or other fluent material to opposite sides of the work
B05C 13/00 - Means for manipulating or holding work, e.g. for separate articles
A flanged duct blank has a male part defined by lead notches formed at each side of a leading end and has a female part defined by trail notches formed at each side of a trailing end. The male part includes a lock tab. The female part includes a leg part and a Z-bend. The Z-bend includes a leg part and a gap. The duct blank is repeatedly clamped and bent by a pivoting wiper to form a duct portion. The pivoting wiper includes a clench tool that has a retractable rib and a retractable roller. With the lock tab inserted into the Z-bend and the retractable rib engaged with the Z-bend, the retractable roller clenches the leg part over the lock tab to lock the male and female parts together in a duct seam.
B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
A duct making apparatus includes a first station configured to accept a formable sheet material and a second station configured to receive the formable sheet material from the first station. The first station includes a mechanism for forming one of a male lock bend and a female lock seam in a leading edge of the formable sheet material. The second station includes a retractable conveyor. Movement of the sheet material from the first station to the second station defines an axis of travel of the sheet material. The retractable conveyor is selectively movable from a first position in which the retractable conveyor is in close association with the first station, and a second position in which the retractable conveyor is spaced from the first station.
B21B 15/00 - Arrangements for performing additional metal-working operations specially combined with or arranged in, or specially adapted for use in connection with, metal-rolling mills
An apparatus for forming a duct includes a bending apparatus and a support apparatus. The bending apparatus includes a table, a cut off beam, and a leaf hinged to a forward edge of the table. The cut off beam is movable toward and away from the table to clamp or release a metal web being fed forward across the table and the leaf. The cut off beam repeatedly clamps the metal web to the table while the leaf pivots toward the cut off beam to form a duct section. The support apparatus includes a cross rod movable along pivoting support arms. As the metal web is bent to form the duct section, the support arms and the cross rod are moved to internally support the duct section.
A flanged duct blank has a male part defined by lead notches formed at each side of a leading end and has a female part defined by trail notches formed at each side of a trailing end. The male part includes a lock tab. The female part includes a leg part and a Z-bend. The Z-bend includes a leg part and a gap. The duct blank is repeatedly clamped and bent by a pivoting wiper to form a duct portion. The pivoting wiper includes a clench tool that has a retractable rib and a retractable roller. With the lock tab inserted into the Z-bend and the retractable rib engaged with the Z-bend, the retractable roller clenches the leg part over the lock tab to lock the male and female parts together in a duct seam.
B21D 5/04 - Bending sheet metal along straight lines, e.g. to form simple curves on brakes making use of clamping means on one side of the work
B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
A finishing apparatus for ductwork having a duct body with at least one open end. The finishing apparatus includes an operation platform for selectively supporting the ductwork and a first wrapping mechanism integrated with the operation platform, the first wrapping mechanism including a first dispenser for dispensing a first film. The finishing apparatus further includes a first cutting mechanism integrated with the first wrapping mechanism. In operation, the first wrapping mechanism selectively dispenses the first film adjacent to and against the open end of the ductwork as the ductwork is moved a predetermined distance down the operation platform. The first cutting mechanism selectively cutting the first film after the ductwork has moved the predetermined distance down the operation platform.
B65B 11/04 - Wrapping articles or quantities of material, without changing their position during the wrapping operation, e.g. in moulds with hinged folders the articles being rotated
A ductmaking apparatus bends a metal web to form a duct blank having a lock seam with male and female portions. Prior to shearing off the duct blank, the apparatus bends the web to form a lock tab that secures the lock seam during subsequent handling of the duct blank.
An apparatus for forming a duct includes a bending apparatus and a support apparatus. The bending apparatus includes a table, a cut off beam, and a leaf hinged to a forward edge of the table. The cut off beam is movable toward and away from the table to clamp or release a metal web being fed forward across the table and the leaf. The cut off beam repeatedly clamps the metal web to the table while the leaf pivots toward the cut off beam to form a duct section. The support apparatus includes a cross rod movable along pivoting support arms. As the metal web is bent to form the duct section, the support arms and the cross rod are moved to internally support the duct section.
(1) Automated coil fed sheet metal slitting, blanking and processing machines; automated duct fabrication machines; and sheet metal shearing and handling machines.
(1) Manufacturing apparatus for the manipulation of metal workpieces, namely, roll forming machines for the manufacture of metal ventilating ducts and transverse duct and flange sections.
An apparatus for forming a duct includes a bending apparatus and a support apparatus. The bending apparatus includes a table, a cut off beam, and a leaf hinged to a forward edge of the table. The cut off beam is movable toward and away from the table to clamp or release a metal web being fed forward across the table and the leaf. The cut off beam repeatedly clamps the metal web to the table while the leaf pivots toward the cut off beam to form a duct section. The support apparatus includes a cross rod movable along pivoting support arms. As the metal web is bent to form the duct section, the support arms and the cross rod are moved to internally support the duct section.
A duct making apparatus bends a metal web to form a duct blank having a lock tab at a forward end and having a Z-fold at a rearward end. Prior to shearing off the duct blank from the metal web, the apparatus bends the duct blank to insert the lock tab into the Z-fold, and further bends the Z-fold to form a clinch tab holding the lock tab into the Z-fold. After shearing off the duct blank from the metal web, the apparatus clinches the clinch tab over the lock tab to form a completed duct blank.
An apparatus for forming a duct includes a bending apparatus and-a support apparatus. The bending apparatus includes a table, a cut off beam, and a leaf hinged to a forward edge of the table. The cut off beam is movable toward and away from the table to clamp or release a metal web being fed forward across the table and the leaf. The cut off beam repeatedly clamps the metal web to the table while the leaf pivots toward the cut off beam to form a duct section. The support apparatus includes a cross rod movable along pivoting support arms. As the metal web is bent to form the duct section, the support arms and the cross rod are moved to internally support the duct section.
A flanged duct blank has a male part defined by lead notches formed at each side of a leading end and has a female part defined by trail notches formed at each side of a trailing end. The male part includes a lock tab. The female part includes a leg part and a Z-bend. The Z-bend includes a leg part and a gap. The duct blank is repeatedly clamped and bent by a pivoting wiper to form a duct portion. The pivoting wiper includes a clench tool that has a retractable rib and a retractable roller. With the lock tab inserted into the Z-bend and the retractable rib engaged with the Z-bend, the retractable roller clenches the leg part over the lock tab to lock the male and female parts together in a duct seam.
B21B 15/00 - Arrangements for performing additional metal-working operations specially combined with or arranged in, or specially adapted for use in connection with, metal-rolling mills
49.
CONTINUOUSLY SMOOTHLY ADJUSTABLE AND SELF-ALIGNING VARIABLE WIDTH ROLL FORMING APPARATUS
A roll former has a plurality of paired die assemblies spaced apart across a midline of the roll former, and a web of material is fed through the roll former along the midline for operations by the die assemblies. The spacing between each pair of die assemblies is uniformly adjustable by way of mounting the die assemblies on collector plates movable toward and away from each other by linear actuators such as jack screws. Smoothness of movement is enhanced by supporting the collector plates only on the linear actuators. Precision of positioning is enhanced by using jack screws as the linear actuators.
A roll former has a plurality of paired die assemblies spaced apart across a midline of the roll former, and a web of material is fed through the roll former along the midline for operations by the die assemblies. The spacing between each pair of die assemblies is uniformly adjustable by way of mounting the die assemblies on collector plates movable toward and away from each other by linear actuators such as jack screws. Smoothness of movement is enhanced by supporting the collector plates only on the linear actuators. Precision of positioning is enhanced by using jack screws as the linear actuators.
B21D 5/08 - Bending sheet metal along straight lines, e.g. to form simple curves by drawing procedure making use of dies or forming-rollers, e.g. making profiles making use of forming-rollers
Manufacturing apparatus for the manipulation of metal workpieces, namely the manufacture of metal ventilating ducts and transverse duct and flange sections.
(1) Manufacturing apparatus for the manipulation of metal workpieces, namely, roll forming machines for the manufacture of metal ventilating ducts and transverse duct and flange sections.
55.
Duct blank seam and apparatus for making a duct blank seam
A flanged duct blank has a male part defined by lead notches formed at each side of a leading end and has a female part defined by trail notches formed at each side of a trailing end. The male part includes a lock tab. The female part includes a leg part and a Z-bend. The Z-bend includes a leg part and a gap. The duct blank is repeatedly clamped and bent by a pivoting wiper to form a duct portion. The pivoting wiper includes a clench tool that has a retractable rib and a retractable roller. With the lock tab inserted into the Z-bend and the retractable rib engaged with the Z-bend, the retractable roller clenches the leg part over the lock tab to lock the male and female parts together in a duct seam.
A duct making apparatus bends a metal web to form a duct blank having a lock tab at a forward end and having a Z-fold at a rearward end. Prior to shearing off the duct blank from the metal web, the apparatus bends the duct blank to insert the lock tab into the Z-fold, and further bends the Z-fold to form a clinch tab holding the lock tab into the Z-fold. After shearing off the duct blank from the metal web, the apparatus clinches the clinch tab over the lock tab to form a completed duct blank.
A ductmaking apparatus bends a metal web to form a duct blank having a lock seam with male and female portions. Prior to shearing off the duct blank, the apparatus bends the web to form a lock tab that secures the lock seam during subsequent handling of the duct blank.
A flange-forming apparatus allows a user to automatically adjust the device's roll forming stations, concurrently together, for changing the height of a flange formed into a metal web by the roll forming stations, e.g., for ductwork. The height is adjustable within an infinite range between set maximum and minimum limits. Each roll forming station includes upper and lower roll forming pairs, which cooperate for forming the flange or portion thereof. Each roll forming pair includes a first roll forming portion, and a second, coaxial roll forming portion that is axially moveable towards and away from the first roll forming portion. (The portions are in effect a laterally split roll forming die.) The second roll forming portions are rotatably supported on a plate-like adjustment linkage assembly, which can be shifted, using an array of motor driven screw members, towards or away from the first roll forming portions.
B21D 5/08 - Bending sheet metal along straight lines, e.g. to form simple curves by drawing procedure making use of dies or forming-rollers, e.g. making profiles making use of forming-rollers
