Abstract

A bolt action rifle having a receiver; a bolt in slidable communication within said receiver, having an elongated body and a bolt head at a first end, and an exposed bolt face with a primer recess cavity having a base with a forward-facing surface, the base having an aperture therein, where the aperture is circumscribed by the forward-facing surface for receiving a propellant charge having an extended primer cap, and a firing pin within the bolt and movable between a disengaged position wherein a firing pin head is receded within the aperture and an engaged position wherein the firing pin head extends beyond the forward-facing surface into the primer recess cavity.

IPC Classes  ?

• F41A 9/55 - Fixed guiding means, mounted on, or near, the cartridge chamber
• F41A 3/24 - Rigid bolt locks, i.e. having locking elements rigidly mounted on the bolt or bolt handle and on the barrel or breech-housing respectively the locking elements effecting a rotary movement about the barrel axis, e.g. rotating cylinder bolt locks hand-operated the locking being effected by rotating the operating handle or lever transversely to the barrel axis the locking elements forming part of the operating handle or lever
• F41A 3/58 - Breakdown breech mechanisms, e.g. for shotguns
• F41A 3/66 - Breech housings or framesReceivers
• F41A 9/58 - Cartridge stopsCartridge positioners
• F41A 9/70 - Arrangements thereon for discharging, e.g. cartridge followers or discharge throats
• F41A 15/06 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for breakdown guns
• F41A 15/14 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for bolt-action guns the ejector being mounted on, or within, the bolt
• F41A 21/12 - Cartridge chambersChamber liners
• F41A 21/48 - Barrel mounting means, e.g. releasable mountings for replaceable barrels
• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F42B 14/06 - Sub-calibre projectiles having sabotsSabots therefor

Abstract

A bolt action rifle having a receiver; a bolt in slidable communication within said receiver, having an elongated body and a bolt head at a first end, and an exposed bolt face with a primer recess cavity having a base with a forward-facing surface, the base having an aperture therein, where the aperture is circumscribed by the forward-facing surface for receiving a propellant charge having an extended primer cap, and a firing pin within the bolt and movable between a disengaged position wherein a firing pin head is receded within the aperture and an engaged position wherein the firing pin head extends beyond the forward-facing surface into the primer recess cavity.

IPC Classes  ?

• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F41A 9/55 - Fixed guiding means, mounted on, or near, the cartridge chamber
• F41A 9/58 - Cartridge stopsCartridge positioners
• F41A 9/70 - Arrangements thereon for discharging, e.g. cartridge followers or discharge throats
• F41A 21/12 - Cartridge chambersChamber liners
• F41A 3/66 - Breech housings or framesReceivers
• F41A 3/24 - Rigid bolt locks, i.e. having locking elements rigidly mounted on the bolt or bolt handle and on the barrel or breech-housing respectively the locking elements effecting a rotary movement about the barrel axis, e.g. rotating cylinder bolt locks hand-operated the locking being effected by rotating the operating handle or lever transversely to the barrel axis the locking elements forming part of the operating handle or lever
• F41A 3/58 - Breakdown breech mechanisms, e.g. for shotguns
• F41A 21/48 - Barrel mounting means, e.g. releasable mountings for replaceable barrels
• F42B 14/06 - Sub-calibre projectiles having sabotsSabots therefor
• F41A 15/06 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for breakdown guns
• F41A 15/14 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for bolt-action guns the ejector being mounted on, or within, the bolt

Abstract

A propellant charge used in a muzzleloading bolt action firearm having a cylindrical casing body for insertion within a breech end of a barrel. The casing body enclosing a propellant charge of predetermined amount, and having a base at the back end with a rim radially extending outwards with a forward surface facing the cylindrical body forward end and mounted flush with the barrel breech end upon insertion. A slot is formed proximate the rim to receive an extension or protrusion of an extractor for removal after firing when the bolt is moved away from the barrel.

IPC Classes  ?

• F42B 5/26 - Cartridge cases
• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F42B 5/10 - Cartridges, i.e. cases with propellant charge and missile with self-propelled bullet

Abstract

A break open rifle and bolt action rifle having a barrel extension with a breech end for receiving a propellant charge, a muzzle end with an extended attachment structure for receiving a complementary attachment structure of a barrel, and a chamber disposed within and through the barrel extension having a first diameter at a first end and a narrowing portion adjacent a second end opposite the first end, the narrowing portion having a second diameter smaller than the first diameter, wherein the first diameter of the chamber is sized to receive the propellant charge therein, and the second diameter of the narrowing portion is sized to prevent the propellant charge from being further inserted past the narrowing portion, and to prevent a projectile from being inserted through the chamber from the barrel muzzle end. A bolt action configuration having dual diameter non-rotating bolt with an extractor and ejector mechanism for removing a propellant charge.

IPC Classes  ?

• F41A 15/06 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for breakdown guns
• F41A 15/14 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for bolt-action guns the ejector being mounted on, or within, the bolt
• F41A 9/55 - Fixed guiding means, mounted on, or near, the cartridge chamber
• F41A 9/58 - Cartridge stopsCartridge positioners
• F41A 9/70 - Arrangements thereon for discharging, e.g. cartridge followers or discharge throats
• F41A 21/12 - Cartridge chambersChamber liners
• F41A 3/66 - Breech housings or framesReceivers
• F41A 3/24 - Rigid bolt locks, i.e. having locking elements rigidly mounted on the bolt or bolt handle and on the barrel or breech-housing respectively the locking elements effecting a rotary movement about the barrel axis, e.g. rotating cylinder bolt locks hand-operated the locking being effected by rotating the operating handle or lever transversely to the barrel axis the locking elements forming part of the operating handle or lever
• F41A 3/58 - Breakdown breech mechanisms, e.g. for shotguns
• F41A 21/48 - Barrel mounting means, e.g. releasable mountings for replaceable barrels
• F42B 14/06 - Sub-calibre projectiles having sabotsSabots therefor

Abstract

A break open rifle and bolt action rifle having a barrel extension with a breech end for receiving a propellant charge, a muzzle end with an extended attachment structure for receiving a complementary attachment structure of a barrel, and a chamber disposed within and through the barrel extension having a first diameter at a first end and a narrowing portion adjacent a second end opposite the first end, the narrowing portion having a second diameter smaller than the first diameter, wherein the first diameter of the chamber is sized to receive the propellant charge therein, and the second diameter of the narrowing portion is sized to prevent the propellant charge from being further inserted past the narrowing portion, and to prevent a projectile from being inserted through the chamber from the barrel muzzle end. A bolt action configuration having dual diameter non-rotating bolt with an extractor and ejector mechanism for removing a propellant charge.

IPC Classes  ?

• F41A 9/55 - Fixed guiding means, mounted on, or near, the cartridge chamber
• F41A 9/58 - Cartridge stopsCartridge positioners
• F41A 9/70 - Arrangements thereon for discharging, e.g. cartridge followers or discharge throats
• F41A 21/12 - Cartridge chambersChamber liners
• F41A 3/66 - Breech housings or framesReceivers
• F41A 3/24 - Rigid bolt locks, i.e. having locking elements rigidly mounted on the bolt or bolt handle and on the barrel or breech-housing respectively the locking elements effecting a rotary movement about the barrel axis, e.g. rotating cylinder bolt locks hand-operated the locking being effected by rotating the operating handle or lever transversely to the barrel axis the locking elements forming part of the operating handle or lever
• F41A 3/58 - Breakdown breech mechanisms, e.g. for shotguns
• F41A 21/48 - Barrel mounting means, e.g. releasable mountings for replaceable barrels
• F42B 14/06 - Sub-calibre projectiles having sabotsSabots therefor
• F41A 15/06 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for breakdown guns
• F41A 15/14 - Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamberCartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun for bolt-action guns the ejector being mounted on, or within, the bolt

Abstract

A sabot having an extended casing for containing propellant charge and a slotted top portion for securing a projectile. The propellant charge is ignited by gases that enter the lower portion of the sabot from a puncture developed by the mating of the sabot against a breech plug. The breech plug has a piercing component in the form of a sharpened forward edge to initiate puncture of the breech end of the sabot.

IPC Classes  ?

• F42B 14/08 - Sabots filled with propulsive chargesRemoving sabots by combustion of pyrotechnic elements or by propulsive-gas pressure
• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F42B 14/06 - Sub-calibre projectiles having sabotsSabots therefor
• F42B 5/067 - Mounting or locking missiles in cartridge cases
• F42B 5/10 - Cartridges, i.e. cases with propellant charge and missile with self-propelled bullet
• F42B 5/18 - Caseless ammunitionCartridges having combustible cases

Abstract

A forend stock for a break open firearm having a housing lug, the housing lug being attached into the lower side of the barrel assembly. A coupler is secured onto the housing lug. At the coupler end opposite the housing lug rod, there is a cylindrical area, and between the two coupler ends, another finished area forming an extended flange. The extended flange has a larger diameter than the cylindrical ends of the coupler. A latch bolt is secured to the forend stock by a cover plate. The latch bolt is topped at one of its ends with a sharp bevel. At its other end, it has a cylindrical post to support a pressure spring, and is held in a longitudinal channel or recess, and arranged such that a user can access an actuator knob for manual handling of the latch bolt. The cover plate assembly has an aperture which the ledges of an extended protrusion of the latch bolt fit within, defining the forward and backward travel limits that the bolt can go in a direction parallel to the axial direction of the barrel.

IPC Classes  ?

• F41C 23/16 - ForestocksHandgripsHand guards
• F41A 3/58 - Breakdown breech mechanisms, e.g. for shotguns

Abstract

A forend stock for a break open firearm having a housing lug, the housing lug being attached into the lower side of the barrel assembly. A coupler is secured onto the housing lug. At the coupler end opposite the housing lug rod, there is a cylindrical area, and between the two coupler ends, another finished area forming an extended flange. The extended flange has a larger diameter than the cylindrical ends of the coupler. A latch bolt is secured to the forend stock by a cover plate. The latch bolt is topped at one of its ends with a sharp bevel. At its other end, it has a cylindrical post to support a pressure spring, and is held in a longitudinal channel or recess, and arranged such that a user can access an actuator knob for manual handling of the latch bolt. The cover plate assembly has an aperture which the ledges of an extended protrusion of the latch bolt fit within, defining the forward and backward travel limits that the bolt can go in a direction parallel to the axial direction of the barrel.

IPC Classes  ?

• F41C 23/16 - ForestocksHandgripsHand guards
• F41A 3/58 - Breakdown breech mechanisms, e.g. for shotguns

Abstract

A sabot having an extended casing for containing propellant charge and a slotted top portion for securing a projectile. The propellant charge is ignited by gases that enter the lower portion of the sabot from a puncture developed by the mating of the sabot against a breech plug. The breech plug has a piercing component in the form of a sharpened forward edge to initiate puncture of the breech end of the sabot.

IPC Classes  ?

• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F42B 14/08 - Sabots filled with propulsive chargesRemoving sabots by combustion of pyrotechnic elements or by propulsive-gas pressure
• F42B 14/06 - Sub-calibre projectiles having sabotsSabots therefor
• F42B 5/067 - Mounting or locking missiles in cartridge cases
• F42B 5/10 - Cartridges, i.e. cases with propellant charge and missile with self-propelled bullet
• F42B 5/18 - Caseless ammunitionCartridges having combustible cases

Abstract

An ammunition system and associated ammunition for firearms, particularly for muzzleloader firearms, having a predetermined amount of propellant charge housed in a casing, and a separate projectile having a sabot. The casing has a cap sealing the casing muzzle end such that the cap and the sabot provide seals to trap propellant gases within the barrel behind the projectile upon firing. The cap top end and sabot bottom end interlock in mechanical communication with one another upon firing allowing the projectile exiting the barrel muzzle end to be responsive to the barrel rifling. The barrel breech end has a chamber bushing for receiving the casing and a tapered muzzle end to prohibit the projectile from entering the casing.

IPC Classes  ?

• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F41A 9/37 - Feeding two or more kinds of ammunition to the same gunFeeding from two sides
• F42B 14/06 - Sub-calibre projectiles having sabotsSabots therefor
• F42B 5/073 - Mounting or locking missiles in cartridge cases using an auxiliary locking element

Abstract

A muzzleloader firearm is converted into a firearm adapted for firing an arrow. The stock assembly of the muzzleloader firearm is retained while the barrel assembly is completely removed, and replaced by an arrow barrel assembly. The arrow barrel assembly has a stock assembly attachment for releasably engaging the stock assembly of the muzzleloader firearm, and a barrel attachment for engaging an inner barrel tube that holds an arrow shaft with a hollow interior and propels the arrow out of the firearm when a blank cap is activated, and an outer shroud to protect the inner barrel tube and enclose a loaded arrow. The arrow barrel assembly rearward end has formed recesses for receiving the blank cap and aligning the rim of the blank cap with the firing pin of the muzzleloader stock assembly.

IPC Classes  ?

• F41C 7/00 - Shoulder-fired smallarms, e.g. rifles, carbines or shotguns
• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F41C 7/11 - Breakdown shotguns or rifles

Abstract

A firearm in-line hammerless percussion firing system comprising: a striker (101) having a firing pin (101a) at a forward or breech end; a striker spring (102) for biasing said striker in a forward position when said striker spring is compressed; a cocking button (103) for compressing said striker spring; a retainer (104) holding said cocking button in a forward position and keeping said striker spring compressed; and a sear (109) pivotally mounted to said firearm for blocking said striker until a lost motion trigger system releases said sear; wherein said trigger system includes a trigger holding said sear in a blocking position and releasing said sear upon movement of said trigger.

IPC Classes  ?

• F41A 19/39 - Cocking mechanisms for other types of guns, e.g. fixed breech-block types, forwardly-slidable barrel types
• F41A 19/10 - TriggersTrigger mountings
• F41A 19/41 - Cocking mechanisms for other types of guns, e.g. fixed breech-block types, forwardly-slidable barrel types for breakdown guns

Abstract

An inline hammerless percussion firing system for muzzleloader firearms with a striker having a firing pin and a striker spring to linearly drive the firing pin forward. A cocking button compresses the striker spring. A pivoting retainer acts against a nut connected to the cocking button to hold the cocking button forward and keep the striker spring compressed. A sear acts to prevent the striker from moving forward until released by a two piece trigger system in which a trigger and trigger edge pivot relative to each other with lost motion before releasing the sear, allowing the trigger edge to move out from below a safety notch in the sear, where firing is prevented, to below a firing notch in the sear to prevent accidental discharges from impact. The cocking button can be released by an uncocking button. Releasing a barrel catch resets firearm to the initial safe position.

IPC Classes  ?

• F41A 19/41 - Cocking mechanisms for other types of guns, e.g. fixed breech-block types, forwardly-slidable barrel types for breakdown guns
• F41A 19/10 - TriggersTrigger mountings
• F41C 9/08 - Muzzle-loading smallarmsSmallarms with flintlock mechanismsAccessories therefor
• F41A 17/56 - Sear safeties, i.e. means for rendering ineffective an intermediate lever transmitting trigger movement to firing pin, hammer, bolt or sear
• F41A 19/12 - SearsSear mountings
• F41A 19/39 - Cocking mechanisms for other types of guns, e.g. fixed breech-block types, forwardly-slidable barrel types
