Abstract

The invention concerns an industrial steel plant comprising one or more components and a monitoring apparatus of data, said data being parameters acquired by detectors and, possibly, control signals to and from control and actuation systems. In particular, the apparatus is suitable to be used to diagnose faults and control industrial steel plants and processes that use a large number of detectors, and comprises a plurality of processing units and a central process unit. The invention also concerns a diagnostic algorithm able to be executed by a monitoring apparatus according to the invention and a method and a monitoring apparatus according to the invention.

IPC Classes  ?

• G05B 19/05 - Programmable logic controllers, e.g. simulating logic interconnections of signals according to ladder diagrams or function charts

Abstract

An apparatus for supplying gas to a determinate number of injector devices of a melting furnace for the production of metal, including a main feed line, a first secondary feed line and a second secondary feed line which are respectively configured to supply, selectively and in a controlled manner, a process gas, an inert gas and a purge gas to each of the injector devices.

IPC Classes  ?

• F27B 3/22 - Arrangements of air or gas supply devices
• C21C 5/52 - Manufacture of steel in electric furnaces
• G05D 7/06 - Control of flow characterised by the use of electric means

Abstract

A device for maintaining efficient a tapping channel of a furnace for the production of metal, includes a bearing structure and a mobile support means associated with the bearing structure. An operating arm is associated with the support means and terminally provided with a rod. A linear positioner is configured to move the support means along an elongation axis. A corresponding method for maintaining efficient a tapping channel of a furnace for the production of metal is also provided.

IPC Classes  ?

• F27D 3/15 - Tapping equipmentEquipment for removing slag
• F27B 3/19 - Arrangement of devices for discharging

Abstract

The invention concerns an industrial steel plant (50) comprising one or more components (51, 52, 53) and a monitoring apparatus (10) of data, said data being parameters acquired by detectors (11) and, possibly, control signals to and from control and actuation systems (12). In particular, the apparatus (10) is suitable to be used to diagnose faults and control industrial steel plants (50) and processes that use a large number of detectors (11), and comprises a plurality of processing units (13) and a central process unit (14). The invention also concerns a diagnostic algorithm able to be executed by a monitoring apparatus (10) according to the invention and a method and a monitoring apparatus (10) according to the invention.

IPC Classes  ?

• G05B 23/02 - Electric testing or monitoring

Abstract

Apparatus for the production of metal comprising a furnace (11) for melting metal provided with a crucible (12) inside which a metal charge is melted. The furnace (11) is provided with means (14) for tapping a liquid metal disposed on the bottom of the crucible (12) and comprising a tapping channel (15) for the transfer of the liquid metal from the furnace (11). The apparatus also comprises a delivery unit (16) for delivering inert material (S) comprising a delivery device (17) for the selective delivery of the inert material (S) into the tapping channel (15).

IPC Classes  ?

• F27D 3/15 - Tapping equipmentEquipment for removing slag
• F27B 14/06 - Crucible or pot furnacesTank furnaces heated electrically, e.g. induction crucible furnaces, with or without any other source of heat
• F27B 14/12 - Covers therefor
• F27B 14/08 - Details specially adapted for crucible, pot or tank furnaces
• B22D 41/46 - Refractory plugging masses

Goods & Services

Ornaments, made of or coated with precious or semi-precious metals or stones, or imitations thereof; Statues and figurines, made of or coated with precious or semi-precious metals or stones, or imitations thereof; Decorative articles [trinkets or jewellery] for personal use; Identification bracelets [jewelry]; Fancy keyrings of precious metals; Objet d'art of enamelled gold; Works of art of precious metal; Objet d'art of enamelled silver; Decorative boxes made of precious metal; Commemorative boxes of precious metal; Boxes of precious metal; Gemstones, pearls and precious metals, and imitations thereof; Fittings for watches; Anchors [clock- and watchmaking]; Barrels [clock- and watchmaking]; Pendulums [clock- and watchmaking]; Bracelets for watches; Watch bands; Clock cases; Watch chains; Watch fobs; Watch clasps; Non-leather watch straps; Watchstraps made of leather; Metal watch bands; Watch straps of plastic; Watch straps of nylon; Watch straps of synthetic material; Watch straps made of metal or leather or plastic; Pendants for watch chains; Buckles for watchstraps; Watches; Watches incorporating a telecommunication function; Watches with the function of wireless communication; Watches incorporating a memory function; Parts for clocks; Watches made of precious metals; Watches made of gold; Clocks and parts therefor; Clocks and watches; Alarm clocks; Horological instruments made of gold; Watch dials; Horological articles; Small clocks; Parts and fittings for horological instruments; Jewellery boxes and watch boxes; Split rings of precious metal for keys; Key charms coated with precious metals; Charms for key rings; Key rings; Key rings [split rings with trinket or decorative fob]; Key rings [trinkets or fobs] of precious metal; Key chains; Metal key chains; Key chains of precious metal; Imitation leather key rings; Key chains as jewellery [trinkets or fobs]; Imitation leather key chains; Key fobs of precious metals; Metal key fobs; Key rings of leather; Key fobs of imitation leather; Key rings, not of metal; Key fobs [rings] coated with precious metal; Time instruments; Key rings and key chains, and charms therefor. Combination walking sticks and umbrellas; Umbrella sticks; Bags for umbrellas; Umbrella handles; Parasols; Umbrellas for children; Rainproof parasols; Umbrellas; Metal parts of umbrellas; Studs of leather; Kid; Leatherboard; Cases of leather or leatherboard; Girths of leather; Shoulder belts [straps] of leather; Straps made of imitation leather; Leather luggage straps; Shoulder straps; Leather cord; Leather straps; Leather for harnesses; Leather for shoes; Labels of leather; Sheets of imitation leather for use in manufacture; Sheets of leather for use in manufacture; Trimmings of leather for furniture; Harness fittings; Imitation leather; Worked or semi-worked hides and other leather; Snakeskin; Leather and imitations of leather; Polyurethane leather; Leather for furniture; Leather sold in bulk; Animal skins; Curried skins; Chamois leather, other than for cleaning purposes; Fur; Furs sold in bulk; Faux fur; Semi-worked fur; Furniture coverings of leather; Boxes of leather or leatherboard; Boxes made of leather; Imitation leather hat boxes; Butts [parts of hides]; Imitation leather sold in bulk; Leathercloth; Shoulder belts; Suitcases; Wheeled luggage; Small suitcases; Leather suitcases; Suitcases with wheels; Portmanteaus; Suitcases with built-in shelves; Gladstone bags; Trunks [luggage]; Travelling trunks; Kori wicker trunks; Trunks and suitcases; Straps for handbags; Luggage; Carry-on bags; Travel luggage; Overnight bags; Hat boxes for travel; Travel garment covers; Travel cases.

Abstract

Apparatus for the production of metal including a furnace for melting metal provided with a crucible inside which a metal charge is melted. The furnace provides for tapping a liquid metal disposed on the bottom of the crucible and includes a tapping channel for the transfer of the liquid metal from the furnace. The apparatus also includes a delivery unit for delivering inert material (S) having a delivery device for the selective delivery of the inert material (S) into the tapping channel.

IPC Classes  ?

• F27B 14/08 - Details specially adapted for crucible, pot or tank furnaces
• F27B 14/06 - Crucible or pot furnacesTank furnaces heated electrically, e.g. induction crucible furnaces, with or without any other source of heat
• F27B 14/12 - Covers therefor
• F27D 3/15 - Tapping equipmentEquipment for removing slag

Abstract

Injection device to inject one or more fluids and/or solids into a metal bath, comprising a cooled main body (11), a fluids emission pipe (16a) suitable to inject at least a first fluid in the direction of the metal bath, and a fluids and/or solids emission pipe (19a) suitable to inject at least a second fluid and/or a solid, in the direction of the metal bath. The device comprises burner means (29), having respective fluids emission pipes (30a, 31a) disposed annularly around both the first injection means (16) and the second injection means (19), so as to define at least two crowns, respectively an internal crown (30) and an external crown (31) around them, said emission pipes (30a, 31a) being suitable to inject respectively at least a comburent fluid and at least a combustible fluid in the direction of the metal bath. The device comprises first valve means (42, 39, 45) able to selectively and respectively connect said fluids emission pipes (16a, 30a, 31a) with respective first feed means of a respective comburent fluid, for example oxygen, or combustible fluid, and second valve means (43, 40, 46) able to selectively and respectively connect, by means of auxiliary pipes (41, 37, 44), the fluids emission pipes (16a, 30a, 31a) with respective second feed means of a respective cleaning fluid, for example compressed air, or an inert gas.

IPC Classes  ?

• C21C 5/52 - Manufacture of steel in electric furnaces
• F27D 3/16 - Introducing a fluid jet or current into the charge
• F27D 3/18 - Charging particulate material using a fluid carrier
• F27D 99/00 - Subject matter not provided for in other groups of this subclass

Goods & Services

Machines and machine tools; motors and engines (except for land vehicles); machine coupling and transmission components (except for land vehicles); agricultural implements other than hand-operated; incubators for eggs. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus for recording, transmission or reproduction of sound or images; magnetic data carriers, recording discs; automatic vending machines and mechanisms for coin-operated apparatus; cash registers, calculating machines, data processing equipment and computers; fire-extinguishing apparatus. Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes.

Goods & Services

Machines and machine tools; motors and engines (except for land vehicles); machine coupling and transmission components (except for land vehicles); agricultural implements other than hand-operated; incubators for eggs. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus for recording, transmission or reproduction of sound or images; magnetic data carriers, recording discs; automatic vending machines and mechanisms for coin-operated apparatus; cash registers, calculating machines, data processing equipment and computers; fire-extinguishing apparatus. Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes.

Goods & Services

(1) Apparatus for locomotion by land, namely motocycles, racing bicycles, bicycles; inner tubes, bells, rims, dynamos, lights, brakes, direction indicators, handlebars, pumps, spokes, luggage nets, saddles, racks, all for bicycles; leather and imitations of leather, and goods made of these materials and not included in other classes, namely travel bags, handbags, travelling cases, garment bags, boxes of leather for hats, cosmetic and toiletry bags and cases sold empty, multi-purpose purses, purses, coin purses not of precious metal, wallets, documents cases, briefcases, brief bags, satchels, pouches, waist bags, cases for keys, bags for keys, shopping bags, luggage, suitcases, attaché cases, back packs; animal skins, hides; trunks and travelling bags; umbrellas, parasols and walking sticks; whips, harness and saddlery; clothing, namely cyclist and motorcyclist protective clothing, casual clothing, sports clothing; footwear namely shoes, boots, slippers; headgear namely caps, hats.

Goods & Services

(1) Apparatus for locomotion by land, namely motocycles, racing bicycles, bicycles; inner tubes, bells, rims, dynamos, lights, brakes, direction indicators, handlebars, pumps, spokes, luggage nets, saddles, racks, all for bicycles; leather and imitations of leather, and goods made of these materials and not included in other classes, namely travel bags, handbags, travelling cases, garment bags, boxes of leather for hats, cosmetic and toiletry bags and cases sold empty, multi-purpose purses, purses, coin purses not of precious metal, wallets, documents cases, briefcases, brief bags, satchels, pouches, waist bags, cases for keys, bags for keys, shopping bags, luggage, suitcases, attaché cases, back packs; animal skins, hides; trunks and travelling bags; umbrellas, parasols and walking sticks; whips, harness and saddlery; clothing, namely cyclist and motorcyclist protective clothing, casual clothing, sports clothing; footwear namely shoes, boots, slippers; headgear namely caps, hats.

Goods & Services

Vehicles, except water vehicles;apparatus for locomotion by land and air; bicycles; inner tubes, bells, rims, dynamos, lights, brakes, direction indicators, handlebars, pumps, spokes, luggage nets, saddles, racks, all for bicycles.

Goods & Services

Vehicles; Apparatus for locomotion by land, air or water; Bicycles; Inner tubes, bells, rims, dynamos, lights, brakes, direction indicators, handlebars, pumps, spokes, luggage nets, saddles, racks, all for bicycles. Leather and imitations of leather, and goods made of these materials and not included in other classes; Animal skins, hides; Trunks and travelling bags; Umbrellas, big umbrellas and walking sticks; Whips, harness and saddlery; Attaché cases; Backpacks; Bags (Game -) [hunting accessories]; Beach bags; Briefbags; Card cases [notecases]; Mesh bags not of precious metals; Collars for animals; Clothing for pets; Frames for umbrellas or parasols; Handbag frames; Handbags; Haversacks; Horse blankets; Music cases; Muzzles; Net bags for shopping; Wallets; Purses; Purses, not of precious metal; Satchels; Shopping bags; Sling bags for carrying infants; Straps for soldiers' equipment; Handles for trunks; Umbrella covers; Umbrella handles; Umbrella rings; Umbrella sticks; Vanity cases, not fitted; Walking cane handles; Walking stick seats; Wheeled shopping bags; Vanity cases, not fitted; Casual bags. Clothing, footwear, headgear; Fittings of metal for footwear; Visors; Shoes (Iron fittings for-); Shoes (non-slipping devices for- ); Pockets for clothing; Shirt fronts; Dress shields.

Goods & Services

Vehicles; Apparatus for locomotion by land, air or water; Bicycles; Inner tubes, bells, rims, dynamos, lights, brakes, direction indicators, handlebars, pumps, spokes, luggage nets, saddles, racks, all for bicycles. Leather and imitations of leather, and goods made of these materials and not included in other classes; Animal skins, hides; Trunks and travelling bags; Umbrellas, parasols and walking sticks; Whips, harness and saddlery; Attaché cases; Backpacks; Bags (Game -) [hunting accessories]; Beach bags; Briefbags; Card cases [notecases]; Mesh bags not of precious metals; Collars for animals; Clothing for pets; Frames for umbrellas or parasols; Handbag frames; Handbags; Haversacks; Horse blankets; Music cases; Muzzles; Net bags for shopping; Wallets; Purses; Purses, not of precious metal; Satchels; Shopping bags; Sling bags for carrying infants; Straps for soldiers' equipment; Handles for trunks; Umbrella covers; Umbrella handles; Umbrella rings; Umbrella sticks; Vanity cases, not fitted; Walking cane handles; Walking stick seats; Wheeled shopping bags; Vanity cases, not fitted; Casual bags. Clothing, footwear, headgear; Fittings of metal for footwear; Visors; Shoes (Iron fittings for-); Shoes (non-slipping devices for- ); Pockets for clothing; Shirt fronts; Dress shields.
