This hose with a metal fitting comprises a hose 2, a metal fitting 3, and a sleeve 4. One end portion of the hose 2 is connected to a metal fitting tubular portion 31 of the metal fitting 3. The sleeve 4 covers the hose 2 and the metal fitting tubular portion 31. The sleeve 4 comprises a first tubular portion 41 covering the metal fitting tubular portion 31, and a second tubular portion 42 covering the hose 2. The second tubular portion 42 has a smaller diameter than the first tubular portion 41. The second tubular portion 42 has a length at least equal to 8 mm. The second tubular portion 42 has a thickness at least equal to 1 mm. A hardness of the second tubular portion 42 is at least equal to 70 and at most equal to 95, as measured in conformance with JIS K6253 using a type A durometer.
A method includes: an inner pipe insertion step of inserting an inner pipe to between a cored bar and a metal movable claw; a designated section corrugated portion formation step of forming a corrugated portion in a first designated section by pressing the first designated section of the inner pipe radially inward by the metal movable claw and plastically deforming the first designated section; a movable claw moving step of moving the metal movable claw outward in the radial direction of the inner pipe; and an inner pipe moving step of moving a second designated section that is the next designated section to between the cored bar and the metal movable claw.
B21D 53/06 - Making other particular articles heat exchangers, e.g. radiators, condensers of metal tubes
F28D 7/10 - Heat-exchange apparatus having stationary tubular conduit assemblies for both heat-exchange media, the media being in contact with different sides of a conduit wall the conduits being arranged one within the other, e.g. concentrically
A resin pipe 30 and a resin member 31 are fixed to a setting portion 5 provided on the front side of a base 6, and a timing pulley 13 which is provided on the back side of the base 6 and to which a light emission unit 3 is attached is rotated. As a result, the light emission unit 3 applies laser light 20 to a junction 32 between the resin pipe 30 and the resin member 31 while revolving around the junction 32. This makes it easy to fuse and join the entire outer circumferential surface of the resin pipe 30 with the entire inner circumferential surface of the resin member 31, which are variously shaped and sized.
Provided is a snap-fit engagement connector that can prevent a pipe from pulling out from the interior of the connector body section. When a pipe (50) is inserted into the interior of a connector body section (1), a distal-end portion of a hook part (33) of a retainer (3) makes contact with a spool part (51) from an opening (11) side of the connector body section (1). The hook part (33) is provided with a curved portion (33a) that protrudes toward the opening (11) side of the connector body section (1). The curved section (33a) is formed in a shape that bends toward the opening (11) side of the connector body section (1), and then folds toward the side away from the opening (11) side of the connector body section (1). The apex of the curved section (33a) is positioned closer to the interior of the connector body section (1) than the surface of the connector body section (1) on an internal space (12) side.
F16L 37/088 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members combined with automatic locking by means of a split elastic ring
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
5.
METHOD FOR MANUFACTURING DOUBLE-PIPE HEAT EXCHANGER
The present invention comprises an inner-pipe insertion step for inserting an inner pipe 3 between a core 1 and a metal movable claw 2, a designated-section wave-shaped-part formation step for forming a wave-shaped part 3h (3a) in a first designated section 3a of the inner pipe 3 by pressing the first designated section 3a radially inward to cause the first designated section 3a to plastically deform, a movable claw movement step for causing the metal movable claw 2 to move in the radially outward direction of the inner pipe 3, and an inner pipe movement step for causing a second designated section 3b serving as a subsequent designated section to move between the core 1 and the metal movable claw 2.
B21D 53/06 - Making other particular articles heat exchangers, e.g. radiators, condensers of metal tubes
B21D 53/08 - Making other particular articles heat exchangers, e.g. radiators, condensers of both metal tubes and sheet metal
F28D 7/10 - Heat-exchange apparatus having stationary tubular conduit assemblies for both heat-exchange media, the media being in contact with different sides of a conduit wall the conduits being arranged one within the other, e.g. concentrically
F28F 1/42 - Tubular elements or assemblies thereof with means for increasing heat-transfer area, e.g. with fins, with projections, with recesses the means being both outside and inside the tubular element
A resin pipe 30 and a resin part 31 are fixed to a setting portion 5 disposed at a front side of a stand 6; and laser light 20 is radiated onto a bonding section 32 where the resin pipe 30 and the resin part 31 are to be bonded while an emission unit 3 is rotated around the bonding section 32 by rotating a timing pulley 13 that is attached to a rear side of the stand 6 and to which the emission unit 3 is attached. Accordingly, it is possible to easily perform weld bonding on the entire outer circumferential surface of the resin pipe 30, which may have various shapes and sizes, and the entire inner circumferential surface of the resin part 31.
A non-crosslinked rubber laminate which is a rubber laminate includes a butyl rubber-containing layer stacked with an ethylene propylene diene rubber and/or ethylene propylene rubber-containing layer, wherein such non-crosslinked rubber laminate is characterized in that the ethylene propylene diene rubber and/or ethylene propylene rubber-containing layer is a rubber-containing layer that contains a low-molecular-weight polyolefin, a phenolic resin, and a crosslinking agent, where: the low-molecular-weight polyolefin is contained by 40 to 70 parts by weight, the phenolic resin is contained by 1 to 4 parts by weight, and the crosslinking agent is contained by at least 1 part by weight, relative to the ethylene propylene diene rubber and/or ethylene propylene rubber constituting a total of 100 parts by weight. An air conditioning hose made of the rubber laminate, for example, can accommodate POE-based lubricating oils and retain vibration absorption characteristics.
F16L 11/04 - Hoses, i.e. flexible pipes made of rubber or flexible plastics
B32B 25/16 - Layered products essentially comprising natural or synthetic rubber comprising polydienes or poly-halodienes
B32B 25/18 - Layered products essentially comprising natural or synthetic rubber comprising butyl or halobutyl rubber
C08J 5/12 - Bonding of a preformed macromolecular material to the same or other solid material such as metal, glass, leather, e.g. using adhesives
C08L 23/16 - Ethene-propene or ethene-propene-diene copolymers
F16L 11/08 - Hoses, i.e. flexible pipes made of rubber or flexible plastics with reinforcements embedded in the wall
8.
Sealing device and rubber hose continuous vulcanizing device provided with same, and sealing method and rubber hose continuous vulcanizing method provided with same
A connector (100) connects to a pipe (50) provided with a spool part (50a) (annular protrusion) on an end section outer periphery, the connector comprising a connector body (1), a checker (2), and a retainer (3). The checker (2) includes: a pressing section (7); and a projecting section (10) which is formed on the rear surface of the pressing section (7) and in which a side surface (10a) thereof at the tip end on a spool part (50a)-side is an inclined surface. The checker (2) is pushed into an insertion completion position from a temporary stop position, thereby causing the projecting section (10) to fit into the rear side of the spool part (50a), and to press the corner of the spool part (50a) with the inclined surface.
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
F02M 37/00 - Apparatus or systems for feeding liquid fuel from storage containers to carburettors or fuel-injection apparatusArrangements for purifying liquid fuel specially adapted for, or arranged on, internal-combustion engines
A connector connectable to a pipe having an annular protrusion on an end portion outer circumference thereof includes a connector main body having, at an end thereof, a pipe insertion hole into which the pipe is inserted; a checker to be pushed in from a temporary stopping position with respect to the connector main body to a completely inserted position with respect to the connector main body; and a retainer disposed inside the connector main body, which is configured to restrict a movement of the checker from the temporary stopping position to the completely inserted position, before the pipe is inserted into the connector main body. The retainer has a retainer lock part in a lower end portion of the retainer. A retainer-locker, which locks the retainer lock part, is provided in a bottom portion on a pipe insertion hole side of the connector main body.
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
F16L 37/088 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members combined with automatic locking by means of a split elastic ring
The present invention addresses the problem of providing a rubber laminate which is obtained by joining two rubber layers by means of crosslinking without blending a different rubber component or using an adhesive, while retaining the characteristics of the respective rubber layers, and which is able to be suited to POE-based lubricants if used in hoses for air conditioners, while retaining vibration absorbing characteristics. The present invention provides, as a solution, an uncrosslinked rubber laminate which is obtained by laminating a butyl rubber-containing layer and an ethylene propylene diene rubber-containing and/or ethylene propylene rubber-containing layer, and which is characterized in that: the ethylene propylene diene rubber-containing and/or ethylene propylene rubber-containing layer contains a low-molecular-weight polyolefin, a phenolic resin and a crosslinking agent; and 40-70 parts by weight of the low-molecular-weight polyolefin, 1-4 parts by weight of the phenolic resin and 1 part by weight or more of the crosslinking agent are contained per 100 parts by weight of the total of the ethylene propylene diene rubber and/or the ethylene propylene rubber.
B32B 25/08 - Layered products essentially comprising natural or synthetic rubber comprising rubber as the main or only constituent of a layer, next to another layer of a specific substance of synthetic resin
F16L 11/08 - Hoses, i.e. flexible pipes made of rubber or flexible plastics with reinforcements embedded in the wall
12.
SEALING DEVICE AND RUBBER HOSE CONTINUOUS VULCANIZING DEVICE PROVIDED WITH SAME, AND SEALING METHOD AND RUBBER HOSE CONTINUOUS VULCANIZING METHOD PROVIDED WITH SAME
Damage to an outer surface of a rubber hose due to rubbing is prevented while sealing performance and productivity are secured. A sealing device comprises: a pipe 11 having one end thereof connected to a vulcanization pipe and into which a pressurized liquid is injected via an injection port 11a provided in a lateral surface on the other end side thereof; a ring-shaped member 12 attached to the pipe 11 so as to seal an opening on the other end side of the pipe 11 and having a hole 12a through which a rubber hose is passed, the hole 12a being larger in diameter than an outer diameter of the rubber hose; and a pump by which an amount of liquid larger than an amount of liquid discharged out of the pipe 11 via a gap between the hole 12a and the rubber hose is injected into the injection port 11a.
Provided is a connector 100, in which a retainer 3 that constitutes the connector has a retainer lock part 13 at the lower end thereof. A locking hole 6d (retainer locking part) in which the retainer lock part 13 is locked is provided in the bottom on a pipe insertion hole 1a side within a connector main body 1. A pipe 50 is inserted into the connector main body 1 from the pipe insertion hole 1a to make the retainer 3 tilt toward the pipe insertion hole 1a side with the retainer lock part 13 as a support point, and as a result it becomes possible to push a checker 2 into the connector main body 1 from a temporary stopping position to a completely inserted position.
F16L 37/12 - Couplings of the quick-acting type in which the connection between abutting or axially-overlapping ends is maintained by locking members using hooks, pawls, or other movable or insertable locking members
14.
Vulcanization-bonded laminate, and rubber composition used therefor
Provide a laminate constituted by epichlorohydrin rubber layer and fluororubber layer that are strongly vulcanization-bonded together. A rubber laminate constituted by vulcanization-bonding an epichlorohydrin rubber layer that contains at least (a) magnesium oxide, (b) polythiol vulcanizing agent, (c) at least one type of compound selected from 1,8-diazabicyclo (5,4,0) undecene-7,1,5-diazabicyclo (4,3,0) nonene-5, and salts thereof, (d) at least one type of compound selected from organic phosphonium salts and organic ammonium salts, and (e) maleic anhydride modified polybutadiene, and a fluororubber layer; wherein such rubber laminate is characterized in that: the content of the polythiol vulcanizing agent (b) in the epichlorohydrin rubber layer is 0.3 to 1.2 parts by weight per 100 parts by weight of the epichlorohydrin rubber; and the content of the maleic anhydride modified polybutadiene (e) in the epichlorohydrin rubber layer is 0.3 to 1.5 parts by weight per 100 parts by weight of the epichlorohydrin rubber.
B32B 25/04 - Layered products essentially comprising natural or synthetic rubber comprising rubber as the main or only constituent of a layer, next to another layer of a specific substance
B32B 25/16 - Layered products essentially comprising natural or synthetic rubber comprising polydienes or poly-halodienes
F16L 11/04 - Hoses, i.e. flexible pipes made of rubber or flexible plastics
A butyl rubber composition is preferably used for an intermediate rubber layer 3 of a composite flexible hose formed by laminating, from the inner side, an innermost layer 2, intermediate rubber layer 3, fiber reinforcement layer 4, and an external rubber layer 5 in this order. The butyl rubber composition includes halogenated butyl rubber, styrene-isobutylene block copolymer, white filler, white reinforcing agent, brominated alkylphenol-formaldehyde resin, phenol resin, and methylol melamine, and 5 to 45 parts by weight of the styrene-isobutylene block copolymer is added to 100 parts by weight of the halogenated butyl rubber.
C08L 23/28 - Compositions of homopolymers or copolymers of unsaturated aliphatic hydrocarbons having only one carbon-to-carbon double bondCompositions of derivatives of such polymers modified by chemical after-treatment by reaction with halogens or halogen-containing compounds
F16L 11/08 - Hoses, i.e. flexible pipes made of rubber or flexible plastics with reinforcements embedded in the wall
B32B 25/14 - Layered products essentially comprising natural or synthetic rubber comprising copolymers in which synthetic rubber constituents predominate
B32B 25/18 - Layered products essentially comprising natural or synthetic rubber comprising butyl or halobutyl rubber
F16L 11/04 - Hoses, i.e. flexible pipes made of rubber or flexible plastics
C08L 53/00 - Compositions of block copolymers containing at least one sequence of a polymer obtained by reactions only involving carbon-to-carbon unsaturated bondsCompositions of derivatives of such polymers
C08L 61/06 - Condensation polymers of aldehydes or ketones with phenols only of aldehydes with phenols
C08L 61/28 - Condensation polymers of aldehydes or ketones with only compounds containing hydrogen attached to nitrogen of aldehydes with heterocyclic compounds with melamine
16.
VULCANIZATION-BONDED LAMINATE, AND RUBBER COMPOSITION FOR USE IN SAME
Provided is a laminate in which a fluororubber and an epichlorohydrin rubber are strongly vulcanization-bonded to each other. A rubber laminate in which an epichlorohydrin rubber layer and a fluororubber layer are vulcanization-bonded to each other, wherein the epichlorohydrin rubber layer comprises at least (a) magnesium oxide, (b) a polythiol-type vulcanizing agent, (c) at least one compound selected from 1,8-diazabicyclo(5,4,0)undecane-7, 1,5-diazabicyclo(4,3,0)nonene-5 and salts thereof, (d) at least one compound selected from an organic phosphonium salt and an organic ammonium salt and (e) maleic anhydride-modified polybutadiene, said rubber laminate being characterized in that the contents of the polythiol-type vulcanizing agent (b) and the maleic anhydride-modified polybutadiene (e) are 0.3 to 1.2 parts by weight and 0.3 to 1.5 parts by weight, respectively, relative to 100 parts by weight of the epichlorohydrin rubber.
This butyl rubber composition is suitable for an intermediate rubber layer (3) etc. of a composite flexible hose formed by laminating, in order, from the inside, an innermost layer (2), the intermediate rubber layer (3), a fiber reinforcement layer (4), and an outer rubber layer (5). The butyl rubber composition is formed by combining halogenated butyl rubber, a styrene-isobutylene block copolymer, a white filler, a white reinforcing agent, a brominated alkylphenol formaldehyde resin, a phenolic resin, and methylol melamine. Five to forty-five parts by weight of the styrene-isobutylene block copolymer are combined with respect to 100 parts by weight of the halogenated butyl rubber.
C08L 23/28 - Compositions of homopolymers or copolymers of unsaturated aliphatic hydrocarbons having only one carbon-to-carbon double bondCompositions of derivatives of such polymers modified by chemical after-treatment by reaction with halogens or halogen-containing compounds
C08L 23/20 - Homopolymers or copolymers of hydrocarbons having four or more carbon atoms having four to nine carbon atoms
C08L 53/00 - Compositions of block copolymers containing at least one sequence of a polymer obtained by reactions only involving carbon-to-carbon unsaturated bondsCompositions of derivatives of such polymers
C08L 61/06 - Condensation polymers of aldehydes or ketones with phenols only of aldehydes with phenols
F16L 11/04 - Hoses, i.e. flexible pipes made of rubber or flexible plastics
18.
VULCANIZATION-ADHERED LAMINATE OF FLUORORUBBER AND SYNTHETIC RUBBER
In order to specifically ascertain a vulcanization-adhesion formula for a fluororubber and a synthetic rubber not including a fluororubber such as an NBR or a chloroprene rubber, and thereby provide a vulcanization-adhered laminate in which the fluororubber and the synthetic rubber are solidly adhered by vulcanization without employing scorch preventing means associated with the use of DBU, DBN, and the like, a vulcanization-adhered laminate is disclosed in which a fluororubber layer and a synthetic rubber-containing layer are adhered by vulcanization, and the synthetic rubber layer prior to the vulcanization-adhesion includes (1) to (5): (1) organic peroxide, (2) silica, (3) organic phosphonium salt, (4) maleic anhydride-modified polybutadiene, and (5) magnesium oxide.
B32B 25/14 - Layered products essentially comprising natural or synthetic rubber comprising copolymers in which synthetic rubber constituents predominate
B32B 1/04 - Layered products essentially having a general shape other than plane characterised by feature of form at particular places, e.g. in edge regions
F16L 11/08 - Hoses, i.e. flexible pipes made of rubber or flexible plastics with reinforcements embedded in the wall
12 - Land, air and water vehicles; parts of land vehicles
17 - Rubber and plastic; packing and insulating materials
Goods & Services
Parts for automobiles; parts for two-wheeled motor vehicles;
parts for three-wheeled motor vehicles; parts for bicycles;
parts for power steering devices for automobiles; parts for
power steering devices for automobiles, namely power
steering hoses; parts for power steering devices for
automobiles, namely power steering hoses with joints; parts
for braking devices for automobiles; parts for automobiles,
namely brake hoses; parts for automobiles, namely brake
hoses with joints; parts for braking devices for two-wheeled
motor vehicles; parts for two-wheeled motor vehicles, namely
brake hoses; parts for two-wheeled motor vehicles, namely
brake hoses with joints; parts for braking devices for
bicycles; parts for bicycles, namely brake hoses; parts for
bicycles, namely brake hoses with joints; parts for
suspension devices for automobiles; parts for automobiles,
namely suspension hoses; parts for automobiles, namely
suspension hoses with joints; parts for suspension devices
for two-wheeled motor vehicles; parts for two-wheeled motor
vehicles, namely suspension hoses; parts for two-wheeled
motor vehicles, namely suspension hoses with joints; parts
for suspension devices for bicycles; parts for bicycles,
namely suspension hoses; parts for bicycles, namely
suspension hoses with joints; parts for clutches for
automobiles; parts for clutches for automobiles, namely
clutch hoses; parts for clutches for automobiles, namely
clutch hoses with joints; parts for clutches for two-wheeled
motor vehicles; parts for clutches for two-wheeled motor
vehicles, namely clutch hoses; parts for clutches for
two-wheeled motor vehicles, namely clutch hoses with joints;
parts for transmissions for bicycles; parts for bicycles,
namely transmission hoses; parts for bicycles, namely
transmission hoses with joints. Rubber hoses; plastic hoses; synthetic resin hoses; hoses
with joints; hoses with fittings; hoses with couplings;
non-metal joints for hoses; non-metal fittings for hoses;
non-metal couplings for hoses; connections for hoses, of
synthetic resin; joints for hoses, of synthetic resin;
fittings for hoses, of synthetic resin; couplings for hoses,
of synthetic resin; non-metal joints for rubber hoses;
non-metal fittings for rubber hoses; non-metal couplings for
rubber hoses.
17 - Rubber and plastic; packing and insulating materials
Goods & Services
Pipe joint, not of metal; hoses for mixer taps; hoses for
automobile air conditioning apparatus; hoses for air
conditioning apparatus; hoses for power steering devices for
automobiles; hoses for clutch devices for two-wheeled motor
vehicles; hoses for braking devices for automobiles; hoses
for braking devices for two-wheeled motor vehicles; oil
cushion hoses for two- wheeled motor vehicles.
12 - Land, air and water vehicles; parts of land vehicles
17 - Rubber and plastic; packing and insulating materials
Goods & Services
Parts for automobiles, namely, hose for automobiles; parts for two-wheeled motor vehicles, namely, hose for two-wheeled motor vehicles; parts for three-wheeled motor vehicles, namely, hose for three-wheeled motor vehicles; parts for bicycles; [parts for power steering devices for automobiles, namely, hose for power steering devices;] [ parts for power steering devices for automobiles, namely, power steering hoses; ] parts for braking devices for automobiles, namely, hose for braking devices for automobiles; parts for automobiles, namely, brake hoses; parts for braking devices for two-wheeled motor vehicles, namely, hose for braking devices for two-wheeled motor vehicles; parts for two-wheeled motor vehicles, namely, brake hoses; parts for braking devices for bicycles, namely, hose for braking devices for bicycles; parts for bicycles, namely, brake hoses; [ parts for suspension devices for automobiles, namely, hose for pneumatic shock absorbers and for hydraulic shock absorbers for automobiles; parts for automobiles, namely, suspension hoses; parts for suspension devices, namely, hose for pneumatic shock absorbers and for hydraulic shock absorbers for two-wheeled motor vehicles; parts for two-wheeled motor vehicles, namely, suspension hoses; parts for suspension devices for bicycles, namely, hose for pneumatic shock absorbers and for hydraulic shock absorbers for bicycles; parts for bicycles, namely, suspension hoses; ] parts for clutches for automobiles, namely, hose for clutches for automobiles; parts for clutches for automobiles, namely, clutch hoses; parts for clutches for two-wheeled motor vehicles, namely, hose for clutches for two-wheeled motor vehicles; parts for clutches for two-wheeled motor vehicles, namely, clutch hoses [ ; parts for transmissions for bicycles, namely, hose for transmissions for bicycles; parts for bicycles, namely, transmission hoses ] [ Rubber hoses for power steering devices for automobiles; ] rubber hoses for braking devices for automobiles, for two-wheeled motor vehicles, and for bicycles; [ rubber hoses for suspension devices, namely, rubber hose for pneumatic shock absorbers and for hydraulic shock absorbers for automobiles, for two-wheeled motor vehicles, and for bicycles; ] rubber hoses for clutches for automobiles, and for two-wheeled motor vehicles; [ rubber hoses for transmissions for bicycles; Plastic hoses for power steering devices for automobiles; ] plastic hoses for braking devices for automobiles, for two-wheeled motor vehicles, and for bicycles; [ plastic hoses for suspension devices, namely, plastic hose for pneumatic shock absorbers and for hydraulic shock absorbers for automobiles, for two-wheeled motor vehicles, and for bicycles; ] plastic hoses for clutches, namely, for automobiles, and for two-wheeled motor vehicles; [ plastic hoses for transmissions for bicycles; Synthetic resin hoses for power steering devices for automobiles; ] synthetic resin hoses for braking devices, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ synthetic resin hoses for suspension devices, namely, synthetic resin for automobiles, for two-wheeled motor vehicles, and for bicycles; ] synthetic resin hoses for clutches, namely, for automobiles, and for two-wheeled motor vehicles; [ synthetic resin hoses for transmissions for bicycles; Rubber, plastic, or synthetic resin hoses with non-metal joints for power steering devices for automobiles; ] rubber, plastic, or synthetic resin hoses with non-metal joints for braking devices, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ rubber, plastic, or synthetic resin hoses with non-metal joints for suspension devices, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles;] rubber, plastic, or synthetic resin hoses with non-metal joints for clutches, namely, for automobiles, and for two-wheeled motor vehicles; [rubber, plastic, or synthetic resin hoses with non-metal joints for transmissions for bicycles; Rubber, plastic, or synthetic resin hoses with non-metal couplings for power steering devices for automobiles;] rubber, plastic, or synthetic resin hoses with non-metal couplings for braking devices, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [rubber, plastic, or synthetic resin hoses with non-metal couplings for suspension devices, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] rubber, plastic, or synthetic resin hoses with non-metal couplings for clutches, namely, for automobiles, and for two-wheeled motor vehicles; [ rubber, plastic, or synthetic resin hoses with non-metal couplings for transmissions for bicycles; non-metal joints for use with power steering hoses for automobiles; ] non-metal joints for use with braking hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal joints for use with suspension hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal joints for use with clutch hoses, namely, for automobiles, and for two-wheeled motor vehicles; [ and non-metal joints for use with transmission hoses for bicycles; non-metal fittings for use with power steering hoses for automobiles; ] non-metal fittings for use with braking hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal fittings for use with suspension hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal fittings for use with clutch hoses, namely, for automobiles, and for two-wheeled motor vehicles; [ and non-metal fittings for use with transmission hoses for bicycles; non-metal couplings for use with power steering hoses for automobiles; ] non-metal couplings for use with braking hoses for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal couplings for use with suspension hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal couplings for use with clutch hoses, namely, for automobiles, and for two-wheeled motor vehicles; [ and non-metal couplings for use with transmission hoses for bicycles; non-metal joints made of synthetic resin for use with power steering hoses for automobiles; ] non-metal joints made of synthetic resin for use with braking hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal joints made of synthetic resin for use with suspension hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal joints made of synthetic resin for use with clutch hoses, namely, for automobiles, and for two-wheeled motor vehicles; [ and non-metal joints made of synthetic resin for use with transmission hoses for bicycles; non-metal fittings made of synthetic resin for use with power steering hoses for automobiles; ] non-metal fittings made of synthetic resin for use with braking hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal fittings made of synthetic resin for use with suspension hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal fittings made of synthetic resin for use with clutch hoses, namely, for automobiles, and for two-wheeled motor vehicles; [ and non-metal fittings made of synthetic resin for use with transmission hoses for bicycles; non-metal couplings made of synthetic resin for use with power steering hoses for automobiles; ] non-metal couplings made of synthetic resin for use with braking hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal couplings made of synthetic resin for use with suspension hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal couplings made of synthetic resin for use with clutch hoses, namely, for automobiles, and for two-wheeled motor vehicles; [ and non-metal couplings made of synthetic resin for use with transmission hoses for bicycles; non-metal joints for use with power steering rubber hoses for automobiles; ] non-metal joints for use with braking rubber hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal joints for use with suspension rubber hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; non-metal joints for use with clutch rubber hoses, namely, for automobiles, and for two-wheeled motor vehicles, and non-metal joints for use with transmission rubber hoses for bicycles; non-metal fittings for use with power steering rubber hoses for automobiles; ] non-metal fittings for use with braking rubber hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal fittings for use with suspension rubber hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal fittings for use with clutch rubber hoses, namely, for automobiles, and for two-wheeled motor vehicles; [ and non-metal fittings for use with transmission rubber hoses for bicycles; non-metal couplings for use with power steering rubber hoses for automobiles; ] non-metal couplings for use with braking rubber hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; [ non-metal couplings for use with suspension rubber hoses, namely, for automobiles, for two-wheeled motor vehicles, and for bicycles; ] non-metal couplings for use with clutch rubber hoses, namely, for automobiles, and for two-wheeled motor vehicles [ ; and non-metal couplings for use with transmission rubber hoses for bicycles ]
22.
FORMWORK MATERIAL AND METHOD OF CONSTRUCTING CONCRETE STRUCTURE WITH USE THEREOF
[PROBLEMS] To provide a concrete formwork that avoids the problem of detachment at junction of multiple panel main bodies and that is used to construct a building from which satisfactory heat insulation effects can be expected. [MEANS FOR SOLVING PROBLEMS] Both major surfaces of metal core member (1) with a shape of cross section corrugated are laminated with hard foam resin (2), thereby obtaining panel main body (P). This panel main body (P) on its at least one surface is provided with waterproof layer (8). The panel main body at its both sides opposite to each other is provided with joining margins (9,10) having one surface of the corrugated core member exposed.
E04B 2/86 - Walls made by casting, pouring, or tamping in situ made in permanent forms
E04C 2/32 - Building elements of relatively thin form for the construction of parts of buildings, e.g. sheet materials, slabs, or panels characterised by the shape or structure formed of corrugated or otherwise indented sheet-like materialBuilding elements of relatively thin form for the construction of parts of buildings, e.g. sheet materials, slabs, or panels characterised by the shape or structure composed of such layers with or without layers of flat sheet-like material
06 - Common metals and ores; objects made of metal
12 - Land, air and water vehicles; parts of land vehicles
17 - Rubber and plastic; packing and insulating materials
Goods & Services
(1) Pipe couplings for two-wheeled motor vehicles; hose couplings for two-wheeled motor vehicles; pipe fittings for two-wheeled motor vehicles; hose fittings for two-wheeled motor vehicles; fluid brake hoses for two-wheeled motor vehicles; pipe joints for two-wheeled motor vehicles; parts and fittings for two-wheeled motor vehicles.
25.
CONNECTION STRUCTURE FOR DIFFERENT KINDS OF METAL TUBES
A structure for connection between a metal bellows tube (A) and a metal tube (B) of a different material from the bellows tube. A connection section of the bellows tube has a straight tube section (1) in the bellows tube, a nipple (2), a bellows tube reinforcing section (3), and a fastening collar (4), and they are fitted and secured to each other in that order from the inside of the tube. The nipple has a base section (2-1) joined to the reinforcing section and a connection end section (2-2) extending to the metal tube side. The fastening collar has a small diameter section (4-1) on the metal tube side and a large diameter section (4-2) on the bellows tube side. A connection section of the metal tube is constructed from a connection end section (6) of the metal tube and a sleeve (7) secured to the outer side of the connection section. The sleeve (7) has a base section (7-1) joined to the connection section and a fitting end section (7-2) extending to the bellows tube side. The fitting end section of the sleeve is fitted on the small diameter section of the fastening collar, and the outer surface of the connection end section of the nipple and the inner surface of the connection end section of the metal tube are bonded and fixed by heat curing resin, with end surfaces of the bellows tube reinforcing section and of the fastening collar and an end surface of the metal tube made to be in contact or to be close to each other.
F16L 33/26 - Arrangements for connecting hoses to rigid membersRigid hose-connectors, i.e. single members engaging both hoses specially adapted for hoses made of metal
12 - Land, air and water vehicles; parts of land vehicles
17 - Rubber and plastic; packing and insulating materials
Goods & Services
pre-formed plastic and rubber power steering hoses and hydraulic hoses sold for use in automobiles plastic and rubber hoses used in the further manufacture and maintenance of hydraulic and power steering assemblies for automobiles
