42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Machines and installations constructed therefrom, for the thermal treatment of rubbish and waste, in particular for use in waste incineration installations and sludge incineration installations, industrial installations, power plants; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Separators [machines], in particular, Electrical separators for filter and flue-gas cleaning installations, water separators in water treatment installations, high voltage units being parts of electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion equipment; Refuse incinerators, Boilers, Machines and installations composed thereof for treating organic residues, Namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for warehouses for a number of/many spare and wear parts connected globally by data transmission/the internet for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, waste incineration and flue gas cleaning installations, automated electronic receipt of replacement orders for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, and for waste incineration and flue gas cleaning installations; Research and information services, research, research for goods offers in databases, digital management of replacement and wearing parts by means of computers and an internet connection. Technological services, Relating to the following sectors, Treating and disposing of non-radioactive waste and recyclable goods, Namely construction of the aforesaid machines and installations; Technical consultancy, Especially, Relating to the following sectors, Process optimisation services, Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing; Industrial analysis of the operation of the aforesaid machines and installations; Design and development of computer hardware and software for the aforesaid machines and installations for treating and disposing of non-radioactive waste and recyclable goods.
The invention relates to a sliding grate (100) for a combustion furnace (101), comprising multiple grate bar rows (2a, 2b), each of which has a grate bar support (5a, 5b), multiple grate bars (3a, 3b) being connected to said grate bar support via first ends (4a, 4b) of the grate bars, wherein surfaces (7a, 7b) of the grate bars (3a, 3b) form a grate bar surface (8) for transporting a layer of fuel (1) along a flow direction (F), and the grate bars (3a, 3b) of adjacent grate bar rows (2a, 2b) lie one over the other in the manner of roof tiles such that the second end (6a, 6b) of each grate bar (3a, 3b) is supported on a surface (7a, 7b) of an adjacent grate bar (3a, 3b) in the flow direction (F). At least some of the grate bar rows (2a, 2b) are grate bar rows (2a) which are driven by a driving means (9), and a first drive movement (A1) can be introduced into the grate bars (3a) of the driven grate bar rows (2a) via the driving means (9) so that a relative movement is produced between the grate bars (3a) of the driven grate bar rows (2a) and the grate bars (3b) of the non-driven grate bar rows (2b). According to the invention, the surfaces (7a, 7b) of the grate bars (3a, 3b) of at least some grate bar rows (2a, 2b) have a nonplanar surface contour (13a, 13b) such that a second drive movement (A2) can be introduced into the grate bars (3a, 3b) that have second ends (6a, 6b) supported on the nonplanar surface contour (13a, 13b) as a result of the relative movement between the grate bars (3a, 3b) of driven and non-driven grate bar rows (2a, 2b).
The invention relates to a supporting device (3) for supporting a load body (1), comprising a lower construction (4) and a central construction (11) that can be adjusted relative to same in the vertical direction (V), wherein the lower construction (4) cooperates with a first bearing region (B1) in order to dissipate a supporting force (FK) that can be introduced into the central construction by the load body (1) via a second bearing region (B2), wherein the supporting force (FK) that can be introduced into the central construction (11) can be transmitted onto the lower construction (4) in the vertical direction (V) by load elements (4e, 9, 10a, 10b) and/or by adjusting elements (12, 13, 13c, 16, 17, 23), wherein a distance (A) can be adjusted by the adjusting elements (12, 13, 13c, 16, 17, 23) in the vertical direction (V) between the lower construction (4) and the central construction (11), and a distance (A) between the lower construction (4) and the central construction (11) that is adjusted by the adjusting elements (12, 13, 13c, 16, 17, 23) can be fixed by the load elements (4e, 9, 10a, 10b) in order to set the supporting force (FK) acting on the supporting device (3).
F22B 37/24 - Supporting, suspending, or setting arrangements, e.g. heat shielding
F16M 7/00 - FRAMES, CASINGS OR BEDS OF ENGINES, MACHINES OR APPARATUS, NOT SPECIFIC TO ENGINES, MACHINES OR APPARATUS PROVIDED FOR ELSEWHERE; STANDS; SUPPORTS - Details of attaching or adjusting engine beds, frames, or supporting-legs on foundation or base; Attaching non-moving engine parts, e.g. cylinder blocks
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely tube ball mills and vibrating tube mills, in particular Sifting machines namely Drum screening machines and Vibrating screening machines, Screens for screening machines, in particular Shredders, in particular Breakers namely Jaw crushers, Machines and installations composed thereof for recycling residues, In particular for producing ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Photo-copying Machines, Installations composed thereof, for the following purposes, Thermal treatment of waste and trash, In particular, Use, in relation to the following fields, Refuse incinerators, Sewage sludge incineration installations, Industrial plants, Power stations; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Waste traps Photo-copying Machines, namely Electrical separators for filter and flue-gas cleaning installations, water separators in water treatment installations, high voltage units being parts of electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion equipment; Refuse incinerators, Boilers, Machines and installations composed thereof for treating organic residues, Namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for a number of/many replacement and wearing parts warehouses connected globally by data transmission/the internet for power plants, installations for treating and disposing of non-radioactive waste and recyclable products, waste incineration and flue gas purification installations, automated electronic receipt of replacement orders for power plants; Installations for processing and removing non-radioactive waste and recycling goods and for waste burning and flue gas cleaning installations, research and information, research, research of goods provided from databases, digital management of replacement and wear parts by means of computer and internet connection. Technological services, in relation to the following fields, Treating and disposing of non-radioactive waste and recyclable goods, Namely construction of the aforesaid machines and installations; Technical consultancy, Especially, in relation to the following fields, Process optimisation services, Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing; Industrial analysis of the operation of the aforesaid machines and installations; Design and development of computer hardware and software for the aforesaid machines and installations for treating and disposing of non-radioactive waste and recyclable goods.
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Photo-copying Machines, Installations composed thereof, for the following purposes, Thermal treatment of waste and trash, In particular, Use, in relation to the following fields, Refuse incinerators, Sewage sludge incineration installations, Industrial plants, Power stations; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Separators [machines], namely, Electric separators for filter and flue gas purification installations, Water separators in water treatment installations, High-voltage units being parts for electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion equipment; Refuse incinerators, Boilers, Machines and installations composed thereof for treating organic residues, Namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for several/many warehouses for replacement and wearing parts connected globally via data transmission/the internet for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, waste incineration and flue gas purification installations, automated electronic receipt of orders for replacement parts for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods and for waste incineration and flue gas purification installations, research and information services, research, research for goods offers in databases, digital management of replacement and wearing parts by means of computers and an internet connection. Technological services, in relation to the following fields, Treating and disposing of non-radioactive waste and recyclable goods, Namely construction of the aforesaid machines and installations; Technical consultancy, Especially, in relation to the following fields, Process optimisation services, Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing; Industrial analysis of the operation of the aforesaid machines and installations; Design agency services, Development, In connection with the following goods, Computer hardware and software, For the aforesaid machines, installations for treating and disposing of non-radioactive waste and recyclable goods.
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Machines and installations constructed therefrom, for the thermal treatment of rubbish and waste, in particular for use in waste incineration installations and sludge incineration installations, industrial installations, power plants; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Waste traps Photo-copying Machines, namely Electrical separators for filter and flue-gas cleaning installations, water separators in water treatment installations, high voltage units being parts of electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion equipment; Refuse incinerators, Boilers, Machines and installations composed thereof for treating organic residues, Namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for warehouses for a number of/many replacement and wear parts connected globally by data transmission/the internet for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, waste incineration and flue gas cleaning installations, automated electronic receipt of replacement orders for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, and for waste incineration and flue gas cleaning installations, research and information services, research, research for goods offers in databases, digital management of replacement and wearing parts by means of computers and an internet connection. Technological services, in relation to the following fields, Treating and disposing of non-radioactive waste and recyclable goods, Namely construction of the aforesaid machines and installations; Technical consultancy, Especially, in relation to the following fields, Process optimisation services, Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing; Industrial analysis of the operation of the aforesaid machines and installations; Design and development of computer hardware and software for the aforesaid machines and installations for treating and disposing of non-radioactive waste and recyclable goods.
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Machines and installations constructed therefrom, for the thermal treatment of rubbish and waste, in particular for use in waste incineration installations and sludge incineration installations, industrial installations, power plants; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Waste traps Photo-copying Machines, namely Electrical separators for filter and flue-gas cleaning installations, water separators in water treatment installations, high voltage units being parts of electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion equipment; Refuse incinerators, Boilers, Machines and installations composed thereof for treating organic residues, Namely via mechanical biological waste treatment for the production of recyclable materials, Namely compost, Ferrous metals, Non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, Namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for warehouses for a number of/many replacement and wear parts connected globally by data transmission/the internet for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, waste incineration and flue gas cleaning installations, automated electronic receipt of replacement orders for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, and for waste incineration and flue gas cleaning installations, research and information services, research, research for goods offers in databases, digital management of replacement and wearing parts by means of computers and an internet connection. Technological services, in relation to the following fields, Treating and disposing of non-radioactive waste and recyclable goods, Namely construction of the aforesaid machines and installations; Technical consultancy, Especially, in relation to the following fields, Process optimisation services, Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing; Industrial analysis of the operation of the aforesaid machines and installations; Design agency services and Development, in relation to the following goods: Computer hardware and software for the aforesaid machines and installations for treating and disposing of non-radioactive waste and recyclable goods.
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Photo-copying Machines, Installations composed thereof, for the following purposes, Thermal treatment of waste and trash, In particular, Use, in relation to the following fields, Refuse incinerators, Sewage sludge incineration installations, Industrial plants, Power stations; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Waste traps Photo-copying Machines, namely Electrical separators for filter and flue-gas cleaning installations, water separators in water treatment installations, high voltage units being parts of electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion equipment; Refuse incinerators, Boilers, Machines and installations composed thereof for treating organic residues, Namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for warehouses for a number of/many replacement and wear parts connected globally by data transmission/the internet for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, waste incineration and flue gas cleaning installations, automated electronic receipt of replacement orders for power plants, installations for treating and disposing of non-radioactive waste and recyclable goods, and for waste incineration and flue gas cleaning installations, research and information services, research, research for goods offers in databases, digital management of replacement and wearing parts by means of computers and an internet connection. Technological services, in relation to the following fields, Treating and disposing of non-radioactive waste and recyclable goods, Namely construction of the aforesaid machines and installations; Technical consultancy, Especially, in relation to the following fields, Process optimisation services, Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing; Industrial analysis of the operation of the aforesaid machines and installations; Design and development of computer hardware and software for the aforesaid machines and installations for treating and disposing of non-radioactive waste and recyclable goods.
9.
Steinmüller Babcock Environment NIPPON STEEL ENGINEERING GROUP
37 - Construction and mining; installation and repair services
39 - Transport, packaging, storage and travel services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Machines and installations composed thereof for waste treatment and disposal, including thermal treatment of waste and trash, in particular for use in waste incineration installations and sewage sludge incineration installations, industrial installations, power stations; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Separators (machines), in particular electric separators, namely electric separators for filtering and flue gas purification installations, water separators in water treatment installations, high-voltage units being parts for electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion equipment; Refuse incinerators, Boilers, Machines and installations composed thereof for treating organic residues, Namely via mechanical biological waste treatment for the production of recyclable materials, Namely compost, Ferrous metals, Non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, Namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for a number of/many replacement and wearing parts warehouses connected globally by data transmission/the internet for power plants, installations for treating and disposing of non-radioactive waste and recyclable products, waste incineration and flue gas purification installations, automated electronic receipt of replacement orders for power plants; Installations for processing and removing radioactive waste and recyclable products and for waste burning and flue gas cleaning installations, research and information, research, research of goods provided from databases, digital management of replacement and wear parts by means of a computer and internet connection. Assembly, fix, Maintenance and Maintenance of machines for crushing, sorting and classifying rubbish, all the aforesaid for the treatment and removal of non-radioactive waste and recyclable products; Assembly, fix, Servicing and maintenance of machines and installations compiled thereof for waste treatment and removal, all the aforesaid for the treatment and removal of non-radioactive waste and recyclable products; Assembly, fix, Maintenance and Maintenance of goods for the treatment and removal of non-radioactive waste and recyclable products, including for the purpose of commissioning and testing; Assembly, fix, Maintenance and Maintenance of installations for the treatment and removal of non-radioactive waste and recyclable products, including for the purpose of commissioning and testing. Storage of goods, in particular for the treatment and removal of non-radioactive waste and recyclable products, for storing replacement parts for installations for treating non-radioactive waste and recyclable products, waste incineration installations, storage of recyclable products, warehouse management relating to the treatment and removal of non-radioactive waste and recyclable products and consultancy relating thereto. Technological services for the treatment and removal of non-radioactive waste and recyclable products, Namely construction of the aforesaid machines and installations; Technical consultancy, In particular for process optimisation and Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing.
Provided is a production method that is for a briquette and that comprises a step for obtaining a briquette having a water content of 5 wt% or less by molding a molding raw material containing a powder carbonized coal and a binder and drying the same at 60-100°C. The binder contains an aqueous solution of a polyvinyl alcohol having a saponification degree of more than 99.3 mol% and a polymerization degree of 1700 or more. The powder carbonized coal is a pulverized coal obtained by drying and carbonizing a coal including brown coal and/or subbituminous coal.
In this ring block stacked structure, carbon blocks are stacked in a spiralling shape from two locations at the same time to facilitate furnace construction, shorten the construction period, extend the lifetime of the carbon blocks, and contribute to improving economy and productivity. Starter blocks 14 are arranged at the bottommost level, where stacking of basic blocks 13 is begun. The starter blocks 14 consist of sloped blocks 11 and sloped adjustment blocks 15, which have a sloped upper surface, and rectangular sub-blocks 12. The ring-form circumferential portion is divided into four arcuate areas of 90° each, and the upper surfaces of the sloped blocks 11 and the sloped adjustment blocks 15 are configured so as to have a continuous slope in each arcuate area. The sub-blocks 12 are arranged above sloped blocks 11 located in two opposite arcuate areas. The basic blocks 13 are arranged on sloped blocks 11 on which sub-blocks 12 are not arranged and on the sub-blocks 12.
This blast furnace stove device (1) has: a blast furnace stove (4) which performs an air blowing operation for blowing hot air to a blast furnace (2) and a combustion operation for combusting fuel gas within the blast furnace stove; a fuel gas supply line (5) through which BFG obtained from the blast furnace (2) is supplied as a fuel gas to the blast furnace stove (4); and a blower (52) which is disposed in the fuel gas supply line (5) so as to boost the pressure of the BFG. The fuel gas supply line (5) extracts the BFG from the downstream side of a furnace-top pressure recovery facility (35) in a furnace-top gas recovery line (3) for extracting the BFG from a furnace top (21) of the blast furnace (2). Motive power for the blower (52) is supplied from an exhaust air pressure recovery facility (441) which recovers exhaust pressure and exhaust heat from exhaust gas of the blast furnace stove (4) during the combustion operation.
Provided is a method for producing reformed coal, the method having a dry distillation step for dry-distilling coal at 300-650°C to obtain dry-distilled coal, and an oxidation treatment step in which the dry-distilled coal is subjected to oxidation treatment for 10-60 minutes in a temperature range from more than 200°C to no more than 240°C.
The invention relates to a system for producing energy from conventional waste utilization, consisting of: a combustion chamber (1) having a combustion grate; an exhaust gas cleaning system (3); an evaporator (2, 9, 13, 14); a steam drum (10, 15, 16); a steam turbine (4); a generator (12); a condenser (12); a flue (19); and lines, wherein: the steam generator (9) consists at least of a low-pressure (LP) evaporator (13) and a high-pressure (HP) evaporator (14) and each evaporator (13, 14) is assigned a steam drum (15, 16) and a separate condenser (17.1, 17.2); and the condensers (17.1, 17.2) couple the evaporators (13, 14) to an ORC turbine (28). The invention further relates to a method for producing energy. The system according to the invention and the method according to the invention combine, in a conventional waste incineration system (waste incineration system), a conventional steam boiler with an ORC process, with the advantage that the corrosion caused by exhaust gases at the steam boiler is minimized by means of a special heating surface circuit, high efficiency being achievable at the same time.
F01K 25/08 - Plants or engines characterised by use of special working fluids, not otherwise provided for; Plants operating in closed cycles and not otherwise provided for using special vapours
F01K 3/18 - Plants characterised by the use of steam or heat accumulators, or intermediate steam heaters, therein having heaters
F23G 5/00 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels
Provided is a squeezing device (10) that is provided with a first and a second squeeze roll (2, 3) disposed so as to be rotatable and a supply part (48) for supplying a to-be-squeezed object (W1) between circumferential surfaces (2a, 3a) of the first and second squeeze rolls, and that squeezes the to-be-squeezed object between the circumferential surfaces of the first and second squeeze rolls, wherein one or more grooves (2b, 3b), which extend around the entire circumference of the circumferential surface and into which the to-be-squeezed object makes entry, are formed at at least one of the circumferential surfaces of the first and second squeeze rolls, and the total width of the one or more grooves in the axial direction of the first or second squeeze roll is not more than 150% of a feeding width that allows the to-be-squeezed object to be fed from the supply part to between the circumferential surfaces.
B30B 9/20 - Presses specially adapted for particular purposes for squeezing-out liquid from liquid-containing material, e.g. juice from fruits, oil from oil-containing material using rotary pressing members, other than worms or screws, e.g. rollers, rings, discs
B30B 3/06 - Presses characterised by the use of rotary pressing members, e.g. rollers, rings, discs co-operating with one another, e.g. with co-operating cones arranged one within another, e.g. with a roller disposed within a rotating ring and co-operating with the inner surface thereof
This drying method is for drying an article to be dried (W3) that contains moisture, in a drying device (1) which includes at least a fluidizing chamber (12) and a mixing chamber (14). In the method, a pre-dried article (W1) obtained by pre-drying an article to be dried (W3) is supplied to the inside of the fluidizing chamber (12), and in that state, the article is fluidized into a fluidized pre-dried article (W2), and this fluidized pre-dried article (W2) is moved to the inside of the mixing chamber (14), which is separated from the fluidizing chamber (12) by a partition (13) and which communicates with the fluidizing chamber via a through-hole (13a) formed in the bottom of the partition (13). In this state, an article to be dried (W3) is fed from above the through-hole (13a) to be mixed with the fluidized pre-dried article (W2).
F26B 3/08 - Drying solid materials or objects by processes involving the application of heat by convection, i.e. heat being conveyed from a heat source to the materials or objects to be dried by a gas or vapour, e.g. air the gas or vapour flowing through the materials or objects to be dried so as to loosen them, e.g. to form a fluidised bed
F23K 1/04 - Heating fuel prior to delivery to combustion apparatus
F26B 17/10 - Machines or apparatus for drying materials in loose, plastic, or fluidised form, e.g. granules, staple fibres, with progressive movement with movement performed by fluid currents, e.g. issuing from a nozzle
Provided is a sliding seismic isolation device which has high durability and can achieve much lower friction properties. This sliding seismic isolation device 10 is configured from: an upper shoe 1 and a lower shoe 2 respectively having a sliding surfaces 1c and a sliding surface 2c which are curved; and a steel sliding body 3 provided between the upper shoe 1 and the lower shoe 2 and having an upper surface 3a and a lower surface 3b that are curved and contact the respective shoes 1,2 wherein a double fabric layer 5 is attached, through an adhesive layer 4, on the upper surface 3a and the lower surface 3b of the sliding body, the double fabric layer 5 is formed of PTFE fibers 5a, 5b and fibers 5c, 5d having higher tensile strengths than the PTFE fibers 5a, 5b, and the PTFE fibers 5a, 5b are located on the sliding surface 1c, 2c sides of the upper shoe 1 and the lower shoe 2. A fluorine-coated layer 6 is present on the surface of the double fabric layer 5, and a lubricant oil layer 7 is present on the surface of the fluorine-coated layer 6.
F16F 15/02 - Suppression of vibrations of non-rotating, e.g. reciprocating, systems; Suppression of vibrations of rotating systems by use of members not moving with the rotating system
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
This disclosure addresses the problem of supporting various fuel types with a simple configuration. A gasification burner 1 comprises a fuel pipe 10 configured so as to circulate fuel, a cylindrical cooling member 30 configured so as to circulate a cooling liquid therein, and a cylindrical nozzle tip 20 disposed between the fuel pipe 10 and the cooling member 30 near the distal ends of these. An oxidizing agent through-hole 21b that penetrates the nozzle tip 20 so as to extend along the axial direction of the nozzle tip 20 is provided in the cylinder wall of the nozzle tip 20. The nozzle tip 20 and the fuel pipe 10, and/or the nozzle tip 20 and the cooling member 30, are screwed together with a screw.
The present invention relates to a plasma torch, a plasma torch forward end electrode, and a molten metal heating device. The plasma torch 10 is used to generate a plasma P between the plasma torch 10 and a molten metal M, inside a tundish comprising a storage tank for storing the molten metal M, and a lid 102b opened upward and covering an opening of the storage tank. The plasma torch 10 comprises: a main body 18 produced from metal, so constituted as to be insertable into a through-hole 102d provided in the lid 102b, in such a manner that a lower end section 18a thereof, which is to face the molten metal M when the molten metal M is to be heat-processed by the plasma P, becomes positioned inside the tundish; and a forward end electrode 20 produced from graphite, attached to the lower end section 18a of the main body 18.
Heat resistant spheroidal graphite cast iron with excellent creep resistance that contains, in mass%, C: 3.0%-4.3%, Si: 1.5% to less than 3.0%, Mn: 0.4% or less, a graphite spheroidizing agent made of at least one of Mg, mischmetal, Ce and Ca: 0.010-0.15%, P: 0.20% or less, S: 0.050% or less, Ni: 0.50-1.5%, Cu: 0.20% to less than 0.8%, and Mo: 0.50-1.5%, the balance being made of Fe and unavoidable impurities.
This method for producing a saccharification enzyme to saccharify a lignocellulosic biomass is provided with with a recovery step, a cellobiose production step, and a saccharification enzyme production step, wherein: the recovery step, cellobiose production step, and saccharification enzyme production step are different, independent reaction steps; first saccharification-enzyme-producing bacteria and second saccharification-enzyme-producing bacteria are bacteria that produce a first saccharification enzyme and a second saccharification enzyme having at least cellulase activity, respectively; the first saccharification-enzyme-producing bacteria and the second saccharification-enzyme-producing bacteria may be the same bacterial species or different bacterial species; and the cellulase is an enzyme mixture having BGL, endoglucanase, and cellobiohydrolase activity.
A palm trunk processing method comprises: a grinding step for defibrating and grinding palm trunks into soft structure and vascular bundles using a grinder; a hydration step for hydrating the palm trunks, which have been ground in the grinding step, with water in an amount equal to or less than the upper limit for the amount of moisture that the palm trunks can absorb; and a compression step for compressing the pulverized palm trunks, which have been hydrated in the hydration step.
Provided is a facility for producing an alloyed galvanized steel sheet, with which while achieving reduction in facility manufacturing costs by eliminating a cooling blower from a heat retention zone, it is also possible to provide a variety of heat patterns and thereby produce various types of steel sheets. Also provided is a method for producing an alloyed galvanized steel sheet. This facility 100 for producing an alloyed galvanized steel sheet is equipped with a temperature-rising zone Z1, a heat retention zone Z2 and a cooling zone Z3 provided in this order. In the cooling zone Z3, first and second cooling blowers 32, 33 are disposed. A connection duct 40 is provided between the heat retention zone Z2 and a position on the suction side of the first blower 32, the connection duct 40 having a first control valve 41 between the heat retention zone Z2 and said position. An emission duct 50 communicating with the outside through a second control valve 51 is provided at a position on the discharge side of the first cooling blower 32. In the heat retention zone Z2, an opening/closing gate 22 for sucking in outside air is provided at a position on the upstream side in the direction of conveyance of a steel sheet. The facility for producing an alloyed galvanized steel sheet is equipped with a control unit 60 that provides operation in the facility in a heat retention mode and a cooling mode.
The method of an embodiment for recovering phosphorus in water that is being treated is provided with: a step for stirring and mixing a specified amount of hydrochloric acid into a slag slurry made of steel making slag and water to obtain a phosphorus recovery slag slurry in which Ca in the steel making slag has been eluted; a step for forming a compound containing phosphorus and Ca by stirring and mixing a phosphorus-containing water to be treated into the phosphorus recovery slag slurry and then leaving the mixture undisturbed to aggregate and precipitate said compound as a solid along with the residue of said steel making slag; and a step for recovering the precipitated solids. In the step for obtaining the phosphorus recovery slag slurry, the hydrochloric acid is added while maintaining the pH of the slag slurry during the hydrochloric acid addition in the range of 4.5-7.0.
A method for producing a compound derived from a lignocellulose-type biomass comprises: a saccharification step of carrying out a saccharification reaction using a pretreated lignocellulose-type biomass and a saccharification enzyme; a fermentation step of adding a saccharification liquor obtained in the saccharification step, a saccharification residue having the saccharification enzyme adsorbed thereon and microorganisms and then carrying out the fermentation of the resultant solution while stirring; a solid-liquid separation step of, subsequent to the fermentation step, subjecting a fermentation product to solid-liquid separation into a fermentation liquor and a fermentation residue having the saccharification enzyme adsorbed thereon; a stirring step of adding water to the fermentation residue having the saccharification enzyme adsorbed thereon, which is the residue obtained in the solid-liquid separation step, and then stirring the resultant solution while keeping the temperature of the solution at a temperature at which the saccharification enzyme can cause a saccharification reaction; and a recycling step of recycling a fermentation residue solution produced in the stirring step to the saccharification step.
A method for producing ethanol comprises: a first fermentation step of carrying out fermentation by fed-batch culture in such a manner that yeast having an ability to utilize xylose is cultured while adding a saccharification liquor derived from a lignocellulose-type biomass to a fermentation vessel; and a second fermentation step of halting the addition of the saccharification liquor at a time point where the volume of the saccharification liquor added reaches a predetermined volume and then carrying out fermentation by batch culture. In the method, the rate of the feeding of the saccharification liquor to the yeast in the first fermentation step is controlled by adjusting the sugar consumption rate of the yeast, and the sugar consumption rate of the yeast is greater than or equal to a largest sugar consumption rate at which the remaining of glucose or xylose in the liquid culture medium does not occur (excluding a sugar consumption rate range in which the remaining of glucose or xylose in the liquid culture medium does not occur) and smaller than or equal to the maximum sugar consumption rate of the yeast.
Provided is a method that enables a dehydration reaction by which an aimed compound is able to be selectively obtained at high yield by suppressing the generation of a by-product in the regeneration of an aromatic amide compound to a corresponding aromatic nitrile compound. Also provided is a method for producing an aromatic nitrile compound, which decreases the number of steps during the dehydration reaction and greatly improves the reaction rate even at or about normal pressure. In addition, the present invention enables the achievement of an efficient method for producing an ester carbonate by applying the above-described production method to a method for producing an ester carbonate. The above-described problem has been solved by a method for producing an aromatic nitrile compound, which comprises a dehydration reaction for dehydrating an aromatic amide compound, and wherein diphenyl ether is used in the dehydration reaction.
The present invention aggregates sludge solubilized by ozone gas (Q) and generates aggregated sludge having a large amount of organic matter. A sludge treatment device (100) is provided with: an ozone reaction tank (10) wherein a liquid (X) containing sludge is supplied and ozone gas (Q) is infused into the liquid (X) to generate bubble sludge (A1); and an addition tank (20) that is provided at a stage following the ozone reaction tank (10) and wherein a first flocculant (G1) is added to the bubble sludge (A1) supplied from the ozone reaction tank (10) and also treated water (Z) is mixed therein to generate a mixed sludge solution (B).
A cable (10) includes a cable body (11) that is formed from a plurality of wires (14) that are integrally bundled; and a pair of sockets (12) to which both end portions of the cable body (11) is separately affixed; at least one of the plurality of wires (14) being a fiber-containing wire (16), which is formed by an optical fiber (17) that extends in a cable length direction (D) and that is protected by a protective tube (18); wherein the optical fiber (17) protrudes from the protective tube (18), in the cable length direction, further outside than the socket (12); and each of the pair of sockets (12) is provided with a spool (30) that removably holds the optical fiber (17) and imparts an initial tensile strain to the optical fiber (17).
G01D 5/353 - Mechanical means for transferring the output of a sensing member; Means for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for converting; Transducers not specially adapted for a specific variable using optical means, i.e. using infrared, visible or ultraviolet light with attenuation or whole or partial obturation of beams of light the beams of light being detected by photocells influencing the transmission properties of an optical fibre
E01D 19/16 - Suspension cables; Cable clamps for suspension cables
G02B 6/44 - Mechanical structures for providing tensile strength and external protection for fibres, e.g. optical transmission cables
G01L 1/24 - Measuring force or stress, in general by measuring variations of optical properties of material when it is stressed, e.g. by photoelastic stress analysis
G01L 5/04 - Apparatus for, or methods of, measuring force, work, mechanical power, or torque, specially adapted for specific purposes for measuring tension in flexible members, e.g. ropes, cables, wires, threads, belts or bands
B63B 21/50 - Anchoring arrangements for special vessels, e.g. for floating drilling platforms or dredgers
B63B 35/44 - Floating buildings, stores, drilling platforms, or workshops, e.g. carrying water-oil separating devices
A checker brick bracket (10) with a metal grille (20) for receiving the checker bricks of a hot blast stove (2) and existing posts (40) disposed between the metal grille (20) and the furnace bottom surface (21), wherein: the bracket comprises coaxial supplementary posts (50) that are disposed coaxially on the outside of the existing posts (40); the coaxial supplementary posts (50) have a post body (51) that is disposed coaxially on the outside of an existing post (40) and a height adjustment mechanism (59) for adjusting the height of the post body (51); and the post body (51) has multiple post tubes (52) that are stacked in the height direction.
The buckling-restrained brace that is capable of being fixed to connected portions of a structure using bolts, the brace includes: a plate member extending in an axial direction, and in which bolt holes for fixing the bolts are formed at end portions of the plate member in the axial direction; and a buckling-restrained member configured to restrain a center portion of the plate member in the axial direction to prevent the plate member from buckling, wherein the buckling-restrained member includes a pipe member surrounding the plate member from the outside in a radial direction, and a filler filling the gap between the pipe member and the plate member, and the plate member includes a fixing plate, a portion of which is embedded in the filler, and the remaining portion is protruded from the filler in the axial direction, and in which the bolt hole is formed at an end portion of the remaining portion in the axial direction.
E04C 3/293 - Joists; Girders, trusses, or truss-like structures, e.g. prefabricated; Lintels; Transoms built-up from parts of different materials the materials being steel and concrete
E04B 1/98 - Protection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
The method for producing ethanol according to the present invention comprises (A) a step for mixing a pretreated lignocellulosic biomass with an enzyme to saccharify the lignocellulosic biomass, and (B) a step for inoculating, with a yeast, and fermenting a saccharification liquid and saccharification residue obtained in step (A), wherein: the yeast is Saccharomyces cerevisiae; and the method comprises, before step (A), or after step (A) but before step (B), (M) a step for determining the concentration of yeast cells in step (B) so as to equal to a preset reference value depending on the concentration of furfural in a liquid containing the pretreated lignocellulosic biomass before step (A) or the saccharification liquid obtained in step (A), wherein the preset reference value is the concentration of yeast cells which is higher than or equal to the critical value of the concentration of yeast cells at which fermentation is not inhibited depending on the concentration of furfural, and the yeast is inoculated in step (B) such that the concentration of yeast cells determined in step (M) is attained.
C12P 1/00 - Preparation of compounds or compositions, not provided for in groups , by using microorganisms or enzymes; General processes for the preparation of compounds or compositions by using microorganisms or enzymes
C12P 7/10 - Ethanol, i.e. non-beverage produced as by-product or from waste or cellulosic material substrate substrate containing cellulosic material
33.
METHOD FOR SUPPLYING HYDROGEN-CONTAINING REDUCING GAS TO SHAFT PART OF BLAST FURNACE
The present invention provides a novel method that is for supplying a reducing gas to the shaft part of a blast furnace, and with which a large amount of the reducing gas containing hydrogen at a high concentration can be supplied to a deeper position in the blast furnace (a place closer to the center axis in the radial direction of the blast furnace), and with which it is possible to reduce the generated amount of CO2 determined as the sum of the CO2 amount that is reduced by conducting hydrogen smelting in the blast furnace and the CO2 amount that is generated during production of the reducing gas supplied to the blast furnace. The method for supplying a reducing gas to the shaft part of a blast furnace according to the present invention is characterized by: modifying a coke oven gas by increasing the temperature thereof to 1200-1800°C in a reactor in which an oxygen-containing gas is supplied to the coke oven gas that has been preheated, to generate a modified gas in which hydrogen gas is enriched; mixing the modified gas with a CO-containing gas in the reactor so that the hydrogen concentration of the reducing gas is adjusted to 15-35 vol% (wet); and supplying the resultant reducing gas to the shaft part of the blast furnace under a condition that the ratio of "flow rate of reducing gas blown into shaft part" / "flow rate of reducing gas blown into tuyere" > 0.42 is satisfied.
A mooring method includes the steps of: transporting a mooring member having a mooring cable which can be connected to a float at one end and an accommodation member installed at the other end of the mooring cable and has an accommodation space therein to a mooring position of the float; accommodating a first heavy weight in at least a part of the accommodation space of the accommodation member at the mooring position; connecting the one end of the mooring cable to the float at the mooring position after the accommodation step; and accommodating a second heavy weight in the accommodation space of the accommodation member by adding the second heavy weight to the first heavy weight or exchanging at least part of the first heavy weight with the second heavy weight at the mooring position after the connection step.
[Problem] To make it possible to perform desulfurization of molten pig iron efficiently and in a short time. [Solution] A molten pig iron processing method comprising: steps for scraping out pre-processing slag from a molten pig iron ladle 9 into a slag chute 4 and for scraping out post-processing slag from a recycling pit 6 into a recycling chute 7; a step for moving the slag chute 4 near a pre-processing slag pit 5 and the recycling chute 7 near the molten pig iron ladle 9; steps for discarding the pre-processing slag from the slag chute 4 into the pre-processing slag pit 5 and for depositing the post-processing slag from the recycling chute 7 into the molten pig iron ladle 9; a step for desulfurization of the molten pig iron in the molten pig iron ladle 9; a step for moving the slag chute 4 near the molten pig iron ladle 9 and the recycling chute 7 near the recycling pit 6 during the desulfurization step; a step for scraping out the post-processing slag from the molten pig iron ladle 9 into the slag chute 4; and a step for depositing the post-processing slag from the slag chute 4 into the recycling pit 6.
The device according to the present invention for producing a compound derived from a lignocellulose-based biomass comprises: a first saccharification unit which contains a pretreated lignocellulose-based biomass and enzymes; a second saccharification unit which contains a first saccharified liquid formed in the first saccharification unit and a first saccharification residue containing lignin to which β-glucosidase (BGL) is adsorbed; and a mechanism for maintaining the solid component concentration in the second saccharification unit higher than the solid component concentration in the first saccharification unit.
The present invention provides a simple and effective device for reducing a fermentation inhibitor in a lignocellulosic biomass, and a method for reducing the fermentation inhibitor. The present invention is a device for reducing a fermentation inhibitor in a lignocellulosic biomass and is provided with a vacuum evaporator that reduces the fermentation inhibitor and has, between a saccharification tank and a fermentation tank, a vacuum pump for cooling a saccharified liquid and a saccharified residue produced by the saccharification tank to 32°C or below. The present invention is a method for reducing a fermentation inhibitor in a lignocellulosic biomass having a vacuum evaporation step for evaporating and reducing the fermentation inhibitor included in the saccharified liquid and the saccharified residue produced in a saccharification step in a vacuum and cooling the saccharified liquid and the saccharified residue produced in the saccharification step to 32°C or below.
The present invention is a method for pretreating lignocellulosic biomass that is executed prior to the transition to a steaming step, wherein the method is characterized by having a step for adding a catalyst solution to lignocellulosic biomass so that the water content of the pretreatment reaction system is greater than or equal to the water content of the lignocellulosic biomass, a step for extracting the catalyst solution from the lignocellulosic biomass after the step for adding the catalyst solution, and a step for recovering and circulating the extracted catalyst solution for reuse by being added to the lignocellulosic biomass.
This method for producing a composition derived from lignocellulose-based biomass has: (A) a step for subjecting lignocellulose-based biomass to a hydrolysis treatment including mixing the lignocellulose-based biomass with an acid and steaming the mixture, to produce an acid-steamed product; (M) a step for subjecting the acid-steamed product to a drying treatment to volatize and remove fermentation-inhibiting substances; (N) a step for adding ammonia to the acid-steamed product subjected to the drying treatment to further reduce the amount of the fermentation inhibitory substances, and adjusting the pH of the steamed product subjected to the drying treatment; and (B) a saccharification step for producing, by using an enzyme, a saccharified liquid containing at least one of monosaccharides and oligosaccharides from the acid-steamed product after the addition of the ammonia, wherein a reduction target value of the contained amount of furfural in step (M) is set on the basis of a threshold below which furfural among fermentation-inhibiting substances does not inhibit fermentation, and a reduction in the amount of furfural at step (N), and a reduction target value of the water content of the acid-steamed product in step (M) is set on the basis of a correlation between the furfural content and the water content of the acid-steamed product.
This buckling-restrained brace anchored by a bolt to a part of a building to be anchored comprises a plate member that extends in the axial direction and in which a bolt hole for fixing the bolt is formed in an end in the axial direction, and buckling-restraining material that restrains buckling in the central portion in the axial direction of the plate member. The buckling-restraining material comprises a tube member that encloses the plate member from the outside in the radial direction, and a filling material that is packed between the tube member and the plate member. The plate member comprises an anchoring plate that has a portion thereof embedded in the filling material and the remaining portion thereof extending from the inside the filling material toward the outside in the axial direction, and in which the bolt hole is formed in an end in the axial direction.
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
F16F 7/12 - Vibration-dampers; Shock-absorbers using plastic deformation of members
F16F 15/02 - Suppression of vibrations of non-rotating, e.g. reciprocating, systems; Suppression of vibrations of rotating systems by use of members not moving with the rotating system
In this cable cover damage location detection method, a cable cover damage location detection device is connected to a cable that is formed by covering a bundled plurality of wires with a cover layer, in which an insulating layer and a conductive layer are layered in order from inside to outside in the radial direction of the cable. The cable cover damage location detection device applies a voltage between both end sections of the conductive layer, then applies a voltage between a conductive layer end section of the conductive layer and a wire end section of the wires, detects the voltage between locations in the conductive layer that are separated in relation to the lengthwise direction of the cable, and calculates the location of cable cover damage on the basis of the ratio between a comparative voltage, which is detected when the voltage is applied between the conductive layer end section and the wire end section, and a reference voltage, which is detected when the voltage is applied between the two end sections.
A cable (10) is provided with: a cable body (11) comprising a plurality of wires (14) that are integrally bundled; and a pair of sockets (12) that are fixed to the respective ends of the cable body (11), wherein at least one of the plurality of wires (14) is a fiber-containing wire (16) obtained by securely housing in a protective tube (18) an optical fiber (17) extending in a cable length direction (D), and the optical fiber (17) extends out of the protective tube (18) along the cable length direction (D) beyond the sockets (12), and each of the pair of sockets (12) is provided with a spool (30) that detachably holds the optical fiber (17) so as to impart an initial tensile strain to the optical fiber (17).
G01D 5/353 - Mechanical means for transferring the output of a sensing member; Means for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for converting; Transducers not specially adapted for a specific variable using optical means, i.e. using infrared, visible or ultraviolet light with attenuation or whole or partial obturation of beams of light the beams of light being detected by photocells influencing the transmission properties of an optical fibre
E01D 19/16 - Suspension cables; Cable clamps for suspension cables
G01L 1/24 - Measuring force or stress, in general by measuring variations of optical properties of material when it is stressed, e.g. by photoelastic stress analysis
G01L 5/04 - Apparatus for, or methods of, measuring force, work, mechanical power, or torque, specially adapted for specific purposes for measuring tension in flexible members, e.g. ropes, cables, wires, threads, belts or bands
G02B 6/44 - Mechanical structures for providing tensile strength and external protection for fibres, e.g. optical transmission cables
43.
LIMESTONE/LIME HYDRATE FLUE-GAS CLEANING INSTALLATION HAVING A CLEAN-GAS BYPASS CHANNEL AND A SUMP EXPANSION SYSTEM
The invention relates to a flue-gas desulfurization installation (REA), which has a scrubber having a distribution device for distributing an absorbent into the flue-gas flow flowing through the scrubber and a scrubber sump arranged on the bottom of the scrubber, wherein the following is provided for the use of limestone or lime hydrate as an absorbent: at least one clean-gas bypass channel is associated with a heat transfer device for transferring heat from the flue-gas flow flowing into the scrubber to the clean-gas flow exiting the scrubber and/or a sump expansion system for enlarging the sump volume is associated with the scrubber sump, wherein oxidation air can be supplied to the scrubber sump and/or the sump expansion system and scrubbing suspension from the scrubber sump and/or the sump expansion system can be supplied in the circulation of the distribution device.
The present invention is a method for manufacturing a fermentation product derived from foliage of a gramineous plant, the foliage of the gramineous plant including at least the crown part of a stem, and the method having: (A) a step for adding a hydration liquid to the foliage of the gramineous plant, performing juice extraction, and separating extracted juice and solid content; (B) a step for adding at least one catalyst selected from sulfuric acid, hydrochloric acid, nitric acid, phosphoric acid, sodium hydroxide, potassium hydroxide, and ammonia, or a combination thereof, to the solid content separated in step (A) and performing hydrolysis; (C) a step for mixing the extracted juice obtained in step (A) and a hydrolysate obtained in step (B) and performing saccharification using an enzyme; and (D) a step for fermenting a saccharification liquid obtained in step (C), through use of microbes.
C12P 1/00 - Preparation of compounds or compositions, not provided for in groups , by using microorganisms or enzymes; General processes for the preparation of compounds or compositions by using microorganisms or enzymes
C12M 1/00 - Apparatus for enzymology or microbiology
C12M 1/02 - Apparatus for enzymology or microbiology with heat exchange means
Provided is a retrofitting structure for existing building that does not require the addition of a foundation specific to the retrofitting structure, can implement seismic retrofitting at any floors only of the existing building, and hardly causes a large drawing force resulting from eccentric bending moment that may act on the seismic retrofitting structure. A retrofitting structure 100 for existing building includes: a reinforcing frame 10 including a frame member 11 and a vibration control member 12 interposed in the frame member, the reinforcing frame being provided on an outer wall surface of an existing building B having an overhang T on the outer wall surface so as to surround the overhang T; and a vertical truss member 30 and a horizontal truss member 20 configured to couple the reinforcing frame 10 and the outer wall surface.
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
E04G 23/02 - Repairing, e.g. filling cracks; Restoring; Altering; Enlarging
E04B 1/24 - Structures comprising elongated load-supporting parts, e.g. columns, girders, skeletons the supporting parts consisting of metal
E04B 1/98 - Protection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
SYSTEM FOR RECOVERING PHOSPHORUS FROM RAW WATER TO BE TREATED, METHOD FOR RECOVERING PHOSPHORUS FROM RAW WATER TO BE TREATED, FERTILIZER, RAW MATERIAL FOR FERTILIZER, AND RAW MATERIAL FOR YELLOW PHOSPHORUS
Adopted is a system for recovering phosphorus from raw water to be treated, the system being equipped with: a calcium dissolution reactor (1); a steel-slag feeder (3) for supplying steel slag to the calcium dissolution reactor (1); an acid feeder (4) for supplying an acid to the calcium dissolution reactor (1); a phosphorus recovery reactor (2) for recovering phosphorus from phosphorus-containing raw water to be treated, by the action of a steel-slag slurry from the calcium dissolution reactor (1); a raw-water feeder (5) for supplying the phosphorus-containing raw water to the phosphorus recovery reactor (1); a dehydrator (6) for dehydrating solid matter which has flocculated and sedimented inside the phosphorus recovery reactor (1) upon standing after the supply of the raw water and subsequent stirring for mixing; a treated-water discharge device (7) for sending outside a supernatant resulting from the reaction inside the phosphorus recovery reactor (1); and a dryer (8) for drying dehydrated matter having been dehydrated.
C02F 1/58 - Treatment of water, waste water, or sewage by removing specified dissolved compounds
C05B 11/12 - Fertilisers produced by wet-treating or leaching raw materials either with acids in such amounts and concentrations as to yield solutions followed by neutralisation, or with alkaline lyes using mineral acid using aqueous hydrochloric acid
Provided is a method for operating a coal gasification system (1) which manufactures at least hydrogen gas and carbon monoxide gas by allowing coal to be gasified using the coal gasification system (1) having a two-layer structured coal gasification reaction furnace (20) that includes: a partial oxidization unit (21) which is disposed on a bottom column and partially oxidizes coal; and a pyrolysis unit (22) which communicates with the partial oxidization unit (21), is disposed on a top column, and pyrolyzes the coal. In this method, coal and char are supplied to the partial oxidization unit (21) as well as supplied to the pyrolysis unit (22), and when the weight of ash increases, the amount of fixed carbon supplied into the pyrolysis unit (22) is also increased, said weight of the ash generated from the coal supplied to the partial oxidization unit (21) and is supplied to the pyrolysis unit.
A carbon-dioxide manufacturing facility according to the present invention is provided with a desulfurizing device to be supplied with exhaust gas serving as source gas for manufacturing carbon dioxide, an absorption tower where the exhaust gas from the desulfurizing device and an amine solution come into contact with each other, a regeneration tower that heats the amine solution from the absorption tower, which has absorbed carbon dioxide, a reduction treatment device that contains a reduction catalyst therein and where carbon-dioxide-containing gas from the regeneration tower and the reduction catalyst come into contact with each other, and an adsorption treatment device that contains activated carbon therein and where the carbon-dioxide-containing gas from the reduction treatment device and the activated carbon come into contact with each other.
B01D 53/04 - Separation of gases or vapours; Recovering vapours of volatile solvents from gases; Chemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by adsorption, e.g. preparative gas chromatography with stationary adsorbents
B01D 53/14 - Separation of gases or vapours; Recovering vapours of volatile solvents from gases; Chemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by absorption
A synthesis gas production apparatus (reformer) to be used for a synthesis gas production step in a GTL (gas-to-liquid) process is prevented from being contaminated by metal components. A method of suppressing metal contamination of a synthesis gas production apparatus operating for a GTL process that includes a synthesis gas production step of producing synthesis gas by causing natural gas and gas containing steam and/or carbon dioxide to react with each other for reforming in a synthesis gas production apparatus in which, at the time of separating and collecting a carbon dioxide contained in the synthesis gas produced in the synthesis gas production step and recycling the separated and collected carbon dioxide as source gas for the reforming reaction in the synthesis gas production step, a nickel concentration in the recycled carbon dioxide is not higher than 0.05 ppmv.
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
C10G 49/00 - Treatment of hydrocarbon oils, in the presence of hydrogen or hydrogen-generating compounds, not provided for in a single one of groups , , , , or
C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
C01B 3/54 - Separation of hydrogen or hydrogen containing gases from gaseous mixtures, e.g. purification by contacting with liquids; Regeneration of used liquids including a catalytic reaction
C10G 45/00 - Refining of hydrocarbon oils using hydrogen or hydrogen-generating compounds
The invention relates to a multipass boiler (2) for cooling, or cooling while simultaneously cleaning, a flue gas (1) of a refuse incinerator, said boiler comprising a first flue (3) having a lower opening (5) into which the flue gas (1) is introduced, and a second flue (4), a superheater (8), a heat exchanger (9), a base with a lower opening (12), and an ascending channel (11) through which the flue gas (1) leaves said second flue, there being a downward-moving feed material (6) consisting of spherical parts in the second flue (4) of the boiler, which is removed through the lower opening (12) of the base and fed into the second flue (4) through an upper opening. The solution according to the invention is advantageous in that, by decoupling the superheater from the flue gas, a higher superheating temperature can be achieved, the rate of corrosion of the superheater can be reduced, continuous cleaning of the heating surfaces is achieved, and deposited ash can be ground up and removed from the boiler.
E04B 1/98 - Protection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
Provided is a reinforcement structure for existing buildings that can seismically reinforce only desired levels in an existing building during seismic reinforcement of outer wall faces of the existing building comprising extended portions on the outer wall face without requiring the expansion of a foundation unique to the reinforcement structure and also for which a large pull-out force is unlikely to occur with an eccentric bending moment that can act on the seismic reinforcing structure. A reinforcement structure for existing buildings 100 comprises: a reinforcing frame 10 that is installed so as to enclose an extended portion T on an outer wall face of an existing building B provided with the extended portion T on the outer wall face and for which a damping member 12 is interposed with a frame member 11; and a vertical truss member 30 and a horizontal truss member 20 that connect the reinforcing frame 10 and the outer wall face.
The present invention includes a reactor main body (4) that is formed into a tubular shape having an axis (O) as the center and accumulates a slurry (S); a gas supply line (10) for incorporating a synthesis gas (G) into the reactor main body (4), and a sparger part (5) that is disposed in a lower portion within the reactor main body (4), communicates with the gas supply line (10), and sprays the synthesis gas (G). The sparger part (5) includes a header tube (15) in which a plurality of openings are formed so as to be separated from each other in a first direction and which sprays the synthesis gas (G) from the openings, and a pair of wall surface parts that protrude from the header tube (15), on opposing sides of the plurality of openings and in a direction orthogonal to the first direction.
B01J 8/22 - Chemical or physical processes in general, conducted in the presence of fluids and solid particles; Apparatus for such processes with fluidised particles with liquid as a fluidising medium gas being introduced into the liquid
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
B01J 8/18 - Chemical or physical processes in general, conducted in the presence of fluids and solid particles; Apparatus for such processes with fluidised particles
B01J 4/00 - Feed devices; Feed or outlet control devices
This rotary press-in steel pipe pile is provided with: a steel pipe; a first blade formed in a substantially helical manner at the front end side of the steel pipe and formed with a first notch having a notch angle in the circumferential direction thereof; and a second blade formed in a substantially helical manner at the rear end side of the first blade on the steel pipe and formed with a second notch having a notch angle in the circumferential direction thereof, wherein the first notch of the first blade and the second notch of the second blade are arranged in positions that do not overlap in the circumferential direction, and the notch angle of the second notch is set to be smaller than the notch angle of the first notch.
E02D 5/44 - Concrete or concrete-like piles cast in position making by use of mould-pipes or other moulds with enlarged footing or enlargements at the bottom of the pile
In this cable production method, a filling step (S5) is performed in which a cylindrical hole in a cylindrically-formed socket main body having one end of a wire material disposed in the cylindrical hole therein is filled with a mixture obtained by subsequently mixing, with a preliminary mixture obtained by preliminarily mixing ceramic particles and fly ash, a thermosetting resin.
A cable (10) is provided with a cable body (11) configured of a plurality of integrally bundled wires (14). At least one of the plurality of wires (14) is a fiber built-in wire (16) comprising an optical fiber (17) extending in a cable length direction (D) protected by a protection pipe (18). Between the optical fiber (17) and the protection pipe (18), a plurality of fixing portions (26) fixing the optical fiber (17) and the protection pipe (18) to each other is disposed at intervals along the cable length direction (D). The cable (10) increases the measurement accuracy with regard to tensile force applied to the cable body (11).
G01L 1/24 - Measuring force or stress, in general by measuring variations of optical properties of material when it is stressed, e.g. by photoelastic stress analysis
E01D 19/16 - Suspension cables; Cable clamps for suspension cables
G01K 11/32 - Measuring temperature based on physical or chemical changes not covered by group , , , or using changes in transmittance, scattering or luminescence in optical fibres
G01L 5/04 - Apparatus for, or methods of, measuring force, work, mechanical power, or torque, specially adapted for specific purposes for measuring tension in flexible members, e.g. ropes, cables, wires, threads, belts or bands
G02B 6/44 - Mechanical structures for providing tensile strength and external protection for fibres, e.g. optical transmission cables
57.
OXIDATION BASIN AND METHOD FOR TREATING OUTLET WATER OF A SEAWATER-FLUE GAS SCRUBBER
The invention relates to an oxidation basin for treating outlet water from a seawater-flue gas scrubber for removing sulphur dioxide from the flue gas, in particular from a flue gas scrubber of a power plant, in which the outlet water is mixed together with additional seawater for purposes of sulfate formation and neutralization, wherein the additional seawater is conducted as a primary flow via a supply line and outlet water is conducted as a secondary flow via an additional supply line into the oxidation basin, wherein the flow through of the basin is improved in that the oxidation basin has a distributor chamber having an inlet cross-section and a larger outlet cross-section, defined by the width of the oxidation basin, wherein the distributor chamber receives the primary flow having an inflow direction and diverts the primary flow in the direction of the longitudinal direction of the oxidation basin, and wherein a series of primary flow impediments, arranged substantially parallel to the inflow direction of the primary flow and spaced apart over the width of the oxidation basin, is located in the outlet cross-section of the distributor chamber, between which the primary flow escapes from the distributor chamber.
A method for producing modified coal, said method comprising: a first drying step (S11) for heating air taken from the outside, fluidizing high-water content coal using the heated air to give a fluidized coal bed, and evaporating moisture from the high-water content coal in the fluidized coal bed to give primarily dried coal; a second drying step (S12) for indirectly heating the primarily dried coal, further evaporating moisture from the primarily dried coal to give dried cool and, at the same time, recovering first steam evaporated from the primarily dried coal; a dry distillation step (S20) for dry distilling the dried coal to give modified coal and, at the same time, recovering, as exhaust gas, combustion exhaust gas that remains after supplying dry distillation heat required for dry distillation of the dried coal to thereby generate second steam; and a cooling step (S30) for cooling the modified coal. In the first drying step, the air is indirectly heated by the first steam. In the second drying step, the primarily dried coal is indirectly heated using the second steam.
C10L 9/08 - Treating solid fuels to improve their combustion by heat treatment, e.g. calcining
F26B 3/084 - Drying solid materials or objects by processes involving the application of heat by convection, i.e. heat being conveyed from a heat source to the materials or objects to be dried by a gas or vapour, e.g. air the gas or vapour flowing through the materials or objects to be dried so as to loosen them, e.g. to form a fluidised bed with heat exchange taking place in the fluidised bed
F26B 21/00 - Arrangements for supplying or controlling air or gases for drying solid materials or objects
06 - Common metals and ores; objects made of metal
07 - Machines and machine tools
11 - Environmental control apparatus
35 - Advertising and business services
36 - Financial, insurance and real estate services
37 - Construction and mining; installation and repair services
39 - Transport, packaging, storage and travel services
40 - Treatment of materials; recycling, air and water treatment,
42 - Scientific, technological and industrial services, research and design
45 - Legal and security services; personal services for individuals.
Goods & Services
Building products of metal, materials of metal, other than machines and installations. Machines and installations composed thereof for waste treatment and disposal, including thermal treatment of waste and trash, namely for use in industrial installations, power plants, centrifuges, hydrocyclones and separating installations composed thereof. Heating apparatus and installations, water apparatus and installations, gas apparatus and installations, air conditioning apparatus and installations, waste incineration installations and sewage sludge incineration installations; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, furnace grates, rotary kilns; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Separators (machines), in particular electric separators, namely electric separators for filtering and flue gas purification installations, water separators in water treatment installations, high-voltage units being parts for electric filters; Dust removing installations for cleaning purposes, namely flue gas purification installations; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and furnaces for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases, waste incineration installations, steam boilers, electronic regulating and control apparatus being parts for solar collector installations for hot water generation. Wholesaling of mining, construction, civil engineering and hydraulic engineering apparatus and machines; Administration of holding companies; Consultancy in the field of business operations and administration; Advertising; Market research and opinion polling; Consultancy in the field of business operations. Real estate agencies. Repair of metal products, repair and preservation of machines, services in the field of the installation of industrial machines, apparatus and equipment; Services in the field of stripping shipwrecks and end-of-life vehicles; Services in the field of remediating environmental pollution; Services in the field of constructing communication lines and electric energy lines; Construction services in the field of civil and hydraulic engineering; Services in the field of rental of construction equipment and apparatus; Repair and preservation of power plants; Services in connection with assembly, disassembly, maintenance, monitoring and repair in the field of electric installations; Services in connection with assembly, disassembly, maintenance, monitoring and repair in the field of water, sewage, heating, gas and air conditioning installations; Services in connection with assembly, disassembly, maintenance, monitoring and repair in the field of building installations. Services in the field of transporting goods by road; Services in the field of storage; Services in the field of freight handling. Destruction of waste and trash; Burning of refuse and waste; Recycling of waste and trash; Purification of gases; Gas filtration; Scrapping of vehicles. Services in the field of building planning; Planning and consultancy in the field of architecture; Technical and technological consultancy in the field of power plant installations; Services in the field of engineering and technical consultancy in connection therewith; Research services and technical analysis; Research and development services in the fields of science, engineering, agricultural science and medicine; Services in connection with planning in the field of electric installations; Services in connection with planning in the field of water, sewage, heating, gas and air conditioning installations; Services in connection with planning in the field of building installations. Licensing of intellectual property.
60.
FLOAT MOORING METHOD, MOORING MEMBER, AND METHOD OF RECOVERING SAME
A mooring method according to the present invention includes: a transporting step of transporting a mooring member (1) including a mooring cable (10) of which one end (10a) is connectable to a float and a housing member (20) attached to the other end (10b) of the mooring cable (10) and having a housing space (20s) inside to a mooring position of the float; a first housing step of housing a first heavy load in at least a part of the housing space (20s) of the housing member (20) at the mooring position; a connecting step of connecting the one end (10a) of the mooring cable (10) to the float at the mooring position after the first housing step; and a second housing step of housing a second heavy load in the housing space (20s) of the housing member (20) at the mooring position by, after the connecting step, addition to the first heavy load or at least partial replacement of the first heavy load.
The invention relates to a probe for electrochemical corrosion measurement on a boiler wall or heat-exchanger wall having a tube-web-tube design, which probe is cylindrical and has a segment to be accommodated in a bore in a web of the boiler wall. A simplified fastening mechanism and passive temperature control are provided by designing the segment as a fastening segment for fastening the probe in the web, wherein the fastening segment is coated with a ceramic layer, which electrically insulates the probe from the boiler wall, and the coated fastening segment has, in a cooled state, a first diameter that is less than the diameter of the boiler wall bore and has, in the installed state after reheating, a second larger diameter in such a way that there is a press fit at least between part of the coated fastening segment and the web bore.
37 - Construction and mining; installation and repair services
39 - Transport, packaging, storage and travel services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor; Machines and installations composed thereof for treating organic residues, namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use; Electronic regulating and control apparatus, being parts for power plants, machines and installations composed thereof for exhaust gas scrubbing. Machines and installations composed thereof for waste treatment and disposal, including thermal treatment of waste and trash, in particular for use in waste incineration installations and sewage sludge incineration installations, industrial installations, power stations; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, Combustion grates, Rotary kilns [for industrial purposes]; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Separators (machines), in particular electric separators, namely electric separators for filtering and flue gas purification installations, water separators in water treatment installations, high-voltage units being parts for electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Refuse incinerators, Boilers, Electronic regulating and control apparatus being parts for solar collector installations for hot water generation. Virtual warehouse management for a number of replacement and wearing parts warehouses connected globally by data transmission/the internet for installations for treating and disposing of non-radioactive waste and recycling products, waste incineration and flue gas purification installations; Automated electronic receipt of replacement part orders for installations for treating and disposing of non-radioactive waste and recycling products and for waste incineration and flue gas purification installations; Research and information, searching for goods offers in databases, digital management of replacement and wearing parts by means of computers and an internet connection. Installation, repair, maintenance and servicing of machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics, machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor, machines and installations composed thereof for treating organic residues, namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use, electronic regulating and control apparatus, being parts for power plants, machines and installations composed thereof for exhaust gas scrubbing, machines and installations composed thereof for waste treatment and disposal, including for the thermal treatment of waste and trash, in particular for use in waste incineration installations and sewage sludge incineration installations, industrial installations, power plants, parts for the aforesaid machines, firing ovens for industrial purposes, industrial firing ovens, furnace grates, cylindrical rotary kilns, gas and air purification installations and machines associated therewith, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, mechanical apparatus for cooling and drying gases and solid particles, separators, in particular electric separators, namely electric separators for filtering and flue gas purification installations, water separators in water treatment installations, high-voltage units being parts for electric filters, dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation, flue gas purification installations and parts therefor, flue gas purification reactors, nitrogen oxide removal installations, machines and furnaces for the thermal treatment of carbon for generating coal gas, gas scrubbers, namely machines and mechanical filters for cleaning gases, waste incineration installations, steam boilers. Storage of goods, in particular for storing replacement parts for installations for treating non-radioactive waste and recycling products, waste incineration installations, storage of recycling products, warehouse management and consultancy in connection therewith. Technological services for treating and disposing of non-radioactive waste and recycling products, namely construction of machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics, machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor, machines and installations composed thereof for treating organic residues, namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use, electronic regulating and control apparatus, being parts for power plants, machines and installations composed thereof for exhaust gas scrubbing, machines and installations composed thereof for waste treatment and disposal, including for the thermal treatment of waste and trash, in particular for use in waste incineration installations and sewage sludge incineration installations, industrial installations, power plants, parts for the aforesaid machines, firing ovens for industrial purposes, industrial firing ovens, furnace grates, cylindrical rotary kilns, gas and air purification installations and machines associated therewith, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, mechanical apparatus for cooling and drying gases and solid particles, separators, in particular electric separators, namely electric separators for filtering and flue gas purification installations, water separators in water treatment installations, high-voltage units being parts for electric filters, dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation, flue gas purification installations and parts therefor, flue gas purification reactors, nitrogen oxide removal installations, machines and furnaces for the thermal treatment of carbon for generating coal gas, gas scrubbers, namely machines and mechanical filters for cleaning gases, waste incineration installations, steam boilers; Technical advice and consultancy, In particular for process optimisation and Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing.
63.
Axially yielding elasto-plastic hysteresis brace and vibration-damping steel-frame structure
The present invention relates to an axially yielding elasto-plastic hysteresis brace including an H-section steel as a steel core, a buckling-restraining member covering an outer periphery of the H-section steel, an unbonded layer filled between the steel core and the buckling-restraining member, and a square steel pipe covering the outer periphery of the buckling-restraining member for reinforcement. For both ends of the H-section steel, one reinforcing plate is welded to each outer surface of each flange so as to be overlapped therewith. The buckling-restraining member is installed so that each reinforcing plate is inserted to the buckling-restraining member through an end thereof by a predetermined length L. And, where the width of the H-section steel as a steel core is given as B and the height thereof is given as H, an insertion length L of each reinforcing plate is set in a range of 2B≦L≦3B and also 2H≦L≦3H.
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
F16F 15/02 - Suppression of vibrations of non-rotating, e.g. reciprocating, systems; Suppression of vibrations of rotating systems by use of members not moving with the rotating system
E04B 1/98 - Protection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
64.
Method for operating blast furnace and method for producing molten pig iron
top; and a fourth step of determining whether an injection rate of the oxygen-enriched air needs to be adjusted, based on a value of the in-furnace superficial gas velocity u.
A start-up method for a hydrocarbon synthesis reaction apparatus, comprising: an initial slurry-loading step in which the slurry is loaded into the reactor at the initial stage of the Fischer-Tropsch synthesis reaction at a lower loading rate than that applied to the reactor in a steady-state operation; and a CO conversion ratio-increasing step in which the liquid level of the slurry in the reactor is raised by adding to the slurry the hydrocarbons synthesized at the early stage of the Fischer-Tropsch synthesis reaction so that the CO conversion ratio is increased in proportion to a rise in the liquid level of the slurry in the reactor.
A support structure (32) for supporting checker bricks (5) of a hot blast stove, the structure comprising slope bricks (7) for supporting the checker bricks (5) and support bricks (6) for supporting the slope bricks (7). The slope bricks (7) have a body (70) and sloped passages (75), which communicate with the through holes (54) of the checker bricks (5) and which open onto the side surface of the body (70). The slope bricks (7) are arranged along imaginary sloped surfaces that partition the interior of the hot blast stove into an upper section and a lower section. Between the slope bricks (7) and the support bricks (6), horizontal passages (35) that communicate with the sloped passages (75) are formed.
Provided are a buckling restrained brace including a core material that has a plate shape and extends along an axis, a restraining member that extends along the axis and covers the core material from an outer peripheral side in a state where both end portions of the core material in an axis direction protrude outside, a filler that is filled between the restraining member and the core material, and a pair of first reinforcing members that each have a plate shape and are installed in both end portions of the core material in the axis direction so as to interpose the core material therebetween from both sides of the core material in a plate width direction, and a load-bearing structure installed with the buckling restrained brace.
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
E04H 9/00 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate
A method for operation of a blast furnace able to greatly reduce the 002 emission and enabling stable production of pig iron over a long period of time in a commercial blast furnace, that is, a method for operation of a blast furnace in which iron ore and coke are charged from a furnace top and is blown in pulverized coal from a usual tuyere, comprising blowing in a gas containing at least one of hydrogen and hydrocarbon from the usual tuyere together with the pulverized coal and blowing a gas comprised of a top gas of the blast furnace from which carbon dioxide and steam is removed from a shaft tuyere into the blast furnace.
Provided is a method for operating a blast furnace which makes it possible to drastically reduce CO2 emissions, and to stably produce pig iron over the long term using a commercial blast furnace. A method for operating a blast furnace into which iron ore and coke are inserted from the blast furnace top, and into which pulverized coal is blown from an ordinary tuyere, the method for operating a blast furnace being characterized in that: a gas containing hydrogen and/or a hydrocarbon is blown in from the ordinary tuyere along with the pulverized coal; and carbon dioxide and water vapor are removed from the furnace-top exhaust gas of the blast furnace, and the furnace-top exhaust gas is then blown into the furnace from a shaft-section tuyere.
Blast furnace gas dry dust collection equipment (1) comprising a dry dust collector (4), an inlet-side pipe (24), an outlet-side pipe (25), a branch pipe (7), a heat exchanger (9), and a mixer (10). The branch pipe (7) is branched from the outlet-side pipe (25) and diverts some of blast furnace gas flowing through the outlet-side pipe (25). The heat exchanger (9) heats or cools the blast furnace gas that flows through a temperature adjustment path (13A). A mixer (10) mixes the blast furnace gas that has been heated or cooled by the heat exchanger (9) with the blast furnace gas flowing through the inlet-side pipe (24), such that the blast furnace gas on the inlet side of the dry dust collector (4) is within a prescribed temperature range.
Saccharomyces cerevisiae (Deposition No. NITE BP-890), which has resistance to limonene and can grow in the presence of limonene at a concentration of 0.1-0.5 wt %, and a method for producing ethanol using the alcoholic fermentation yeast.
C12P 7/12 - Ethanol, i.e. non-beverage produced as by-product or from waste or cellulosic material substrate substrate containing sulfite waste liquor or citrus waste
A hot blast furnace facility comprising: a hot blast furnace; a combustion air pipe that feeds combustion air to the hot blast furnace; a fuel gas pipe that feeds blast furnace gas discharged from a blast furnace, to the hot blast furnace as fuel gas for the hot blast furnace; a flue pipe that feeds the exhaust gas discharged from the hot blast furnace to a chimney; a first preheating means connected to the flue pipe and preheating either the combustion air or the fuel gas, by using heat recovered by heat exchange from the exhaust gas from the hot blast furnace; and a second preheating means having a first heater that combusts some of the blast furnace gas, said second preheating means preheating the other out of the combustion air and the fuel gas, by using the heat generated by the first heater.
The purpose of the present invention is to reduce the overall size of a joining device as a whole while minimizing joint damage when joining laminated material. The present invention employs a friction stir welding tool (1) for joining two pieces of laminated material (120), each comprising a first layer (121) and a second layer (122), while the end faces thereof are mutually abutting, said friction stir welding tool (1) being provided with a tool body (8), a projecting probe (6) formed at one end of the tool body (8) in the axial direction, a shoulder (5) formed closer to the other end of the tool body (8) than the probe (6) and having a larger diameter in a direction orthogonal to the axis than that of the probe (6), and a flow promotion portion (7) formed on the probe (6) and spaced apart from the shoulder (5) by a predetermined distance. The flow promotion portion (7) promotes plastic flow toward the tip of the probe (6) in the lower layer portion of the two pieces of laminated material (120) when the probe (6) is rotating about the axis thereof during joining of the two pieces of laminated material (120).
B23K 20/12 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating the heat being generated by friction; Friction welding
A treatment method for a palm trunks is provided with: a solid-liquid separation step for performing solid-liquid separation by squeezing after crushing of palm trunks; a liquid fuel generating step four distilling liquid components separated in the solid-liquid separation step and generating liquid fuel; a fertilizer generating step for generating fertilizer from a distillate fraction remaining after distillation of the liquid components in the liquid fuel generating step; and a fuel pellet forming step for forming fuel pellets by compressing solid components separated in the solid-liquid separation step. The liquid fuel generating step has a fermentation step wherein the liquid components separated in the solid-liquid separation step are fermented. In the solid-liquid separation step, the water content in the solid components that are separated is squeezed to 35% or less.
JAPAN INTERNATIONAL RESEARCH CENTER FOR AGRICULTURAL SCIENCES (Japan)
Inventor
Wakamura Osamu
Kato Yasuhiko
Nishi Takeshi
Takemaru Hiroshi
Kosugi Akihiko
Arai Takamitsu
Abstract
This ethanol production facility comprises: a crushing device (12) that crushes soft cellulose including starch, to produce a crushed product; a saccharification-and-fermentation device (14) in which the crushed product is saccharified and fermented by adding an enzyme and a yeast into the same tank that contains the crushed product, to produce a saccharified-and-fermented product; a juicing device (16) that juices the saccharified-and-fermented product, to produce a juiced liquid; and a distillation device (18) that distills the juiced liquid, to obtain ethanol.
The temperature difference (cooling water inlet and outlet temperature difference) between a cooling water inlet side temperature and a cooling water outlet side temperature for a cooling water pathway (11) provided for each roll disposition position in which an upper and lower pair of rolls (8) is disposed is found for each roll disposition position. A regression equation that expresses the cooling water inlet and outlet temperature difference in a range from a first roll disposition position to an nth roll disposition position is found from the cooling water inlet and outlet temperature differences for each roll disposition position. The cooling water inlet and outlet temperature difference for each roll is calculated from the regression equation and set as a corrected cooling water inlet and outlet temperature difference. A thermal expansion correction value is found at each roll disposition position from the corrected cooling water inlet and outlet temperature difference for each roll and the relationship, which is found in advance, between the cooling water inlet and outlet temperature difference and the total value for the amount of thermal expansion (combined value for thermal expansion for frame (9) and thermal expansion for continuous casting piece). The amount of reducing by each roll is corrected on the basis of the thermal expansion correction value at each roll disposition position.
A start-up method of a bubble column slurry bed reactor for producing hydrocarbons includes: a first step that fills into a reactor a slurry in which a Fischer-Tropsch synthesis reaction catalyst particles are suspended in a slurry preparation oil with a 5% distillation point of 120 to 270° C., a 95% distillation point of 330 to 650° C., and a sulfur component and an aromatic component of 1 mass ppm or less, and a second step that, in a state where synthesis gas that is primarily hydrogen and carbon monoxide is introduced into the slurry filled into the reactor, raises the temperature of the reactor and starts the Fischer-Tropsch synthesis reaction. As the slurry preparation oil, one containing predetermined components in preset amounts is used. In the first step, the slurry is filled into the reactor in an amount in which airborne droplets do not flow out.
C07C 1/04 - Preparation of hydrocarbons from one or more compounds, none of them being a hydrocarbon from oxides of carbon from carbon monoxide with hydrogen
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
78.
Diesel fuel or diesel fuel base stock and production method thereof
Provided is a hydrotreating step (A) containing a hydroisomerization step (A1) that obtains a hydroisomerized oil (a1) by bringing a FT synthesis oil into contact with a hydroisomerization catalyst and/or a hydrocracking step (A2) that obtains a hydrocracked oil (a2) by bringing it into contact with a hydrocracking catalyst, and a fractionation step (B) that transfers at least a portion of the hydrotreated oil (a) composed of the hydroisomerized oil (a1) and/or the hydrocracked oil (a2) to a fractionator and, at the very least, obtains a middle distillate (b1) with a 5% distillation point of 130 to 170° C. and a 95% distillation point of 240 to 300° C., and a heavy oil (b2) that is heavier than the middle distillate (b1).
C10G 67/00 - Treatment of hydrocarbon oils by at least one hydrotreatment process and at least one process for refining in the absence of hydrogen only
C10L 1/06 - Liquid carbonaceous fuels essentially based on blends of hydrocarbons for spark ignition
C10L 10/14 - Use of additives to fuels or fires for particular purposes for improving low temperature properties
C10G 65/14 - Treatment of hydrocarbon oils by two or more hydrotreatment processes only plural parallel stages only
C10L 1/08 - Liquid carbonaceous fuels essentially based on blends of hydrocarbons for compression ignition
C10G 45/58 - Refining of hydrocarbon oils using hydrogen or hydrogen-generating compounds to change the structural skeleton of some of the hydrocarbon content without cracking the other hydrocarbons present, e.g. lowering pour point; Selective hydrocracking of normal paraffins
C10G 47/00 - Cracking of hydrocarbon oils, in the presence of hydrogen or hydrogen-generating compounds, to obtain lower boiling fractions
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
A hot-blast stove construction method in which: the furnace body comprises an iron shell (4) and a lining (5) formed on the inside of the iron shell (4); and the lining (5) comprises a refractory castable (51) disposed inside the iron shell (4), heat-insulating brick (52) disposed inside the refractory castable (51), and firebrick (53) disposed inside the heat-insulating brick (52). The heat-insulating brick (52) and the firebrick (53) are disposed inside the iron shell (4) with spaces therebetween and the refractory castable (51) is injected and solidified between the iron shell (4) and the heat-insulating brick (52).
A coke dry-quenching device (1) is provided with a cleaning chamber (2), a boiler (3), a first gas line (L1) for directing cooling gas from the cleaning chamber (2) to the boiler (3), a second gas line (L2) for directing cooling gas from the boiler (3) to the cleaning chamber (2), a bypass line (L3) for directing a portion of gas passing through the second gas line (L2) to the first gas line (L1), a diffusion line (L4) for directing a portion of the gas passing through the second gas line (L2) to the outside, and an inlet flow rate control part for subtracting the gas flow rates of the bypass line (L3) and the diffusion line (L4) from the gas flow rates of upstream parts (5b, 5c) of the second gas line (L2) to calculate a chamber inlet flow rate, and adjusting the gas flow rate of the diffusion line (L4) or the upstream parts (5c, 5c) of the second gas line (L2) so that the ratio of the chamber inlet flow rate and the rate of discharge of coke from the cleaning chamber (2) approaches a target ratio.
The present invention is provided with a reactor main body (4) formed into a cylindrical shape having an axis (O) as the center and enclosing a slurry (S), a gas supply line (10) for incorporating a synthesis gas (G) into the reactor main body (4), and, disposed within the reactor main body (4) in the lower portion thereof and connected to the gas supply line (10), a sparger part (5) for spraying the synthesis gas (G). The sparger part (5) has a header tube (15), wherein a plurality of openings are formed separated from one another in a first direction, spraying the synthesis gas (G) from the openings, and one pair of wall surface parts protruding from the header tube (15) so as to sandwich the plurality of openings from the two sides in a direction orthogonal to the first direction.
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
B01J 8/22 - Chemical or physical processes in general, conducted in the presence of fluids and solid particles; Apparatus for such processes with fluidised particles with liquid as a fluidising medium gas being introduced into the liquid
C07C 1/04 - Preparation of hydrocarbons from one or more compounds, none of them being a hydrocarbon from oxides of carbon from carbon monoxide with hydrogen
Provided is a blast furnace repair method for repairing a blast furnace that comprises a furnace body and a furnace body tower that are installed on a site foundation. In a state in which an old blast furnace is in operation (S1), the following are performed: a new furnace body construction step (S2) in which a new furnace body tower and a new furnace body are built on a new foundation that is at a separate location from the site foundation; and a foundation splitting step (S3) in which the site foundation is cut into upper and lower sections and split into an upper foundation section on which the old furnace body and the old furnace body tower are installed and a lower foundation section. After performing blast furnace blow-out (S4), the following are performed: an old furnace body extraction step (S5) in which the upper foundation section is pulled out together with the old furnace body and the old furnace body tower; and a new furnace body installation step (S6) in which the new foundation is installed together with the new furnace body tower and the new furnace body on the lower foundation section.
Provided is a high-performance sliding seismic isolation device equipped with a sliding body that achieves a surface pressure of 60 MPa. This sliding seismic isolation device (10) is configured from an upper shoe (1) and a lower shoe (2) respectively equipped with a curved sliding surface (1a, 2a), and a columnar steel sliding body (7) between the upper shoe (1) and the lower shoe (2) and equipped with a curved upper surface (4a) and a curved lower surface (4b) which are in contact with the respective shoes. The upper surface (4a) and the lower surface (4b) of the sliding body (7) are equipped respectively with a double-woven fabric layer (5, 6) comprising a PTFE fiber and a fiber having a higher tensile strength than the PTFE fiber, with the PTFE fiber arranged on the sliding surface (1a, 2a) side of the upper shoe (1) and the lower shoe (2).
F16F 15/02 - Suppression of vibrations of non-rotating, e.g. reciprocating, systems; Suppression of vibrations of rotating systems by use of members not moving with the rotating system
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
84.
Steinmüller Babcock Environment NIPPON STEEL & SUMIKIN ENGINEERING GROUP
37 - Construction and mining; installation and repair services
39 - Transport, packaging, storage and travel services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for crushing, sorting and classifying waste, in particular mills (machines), namely ball-tube mills and vibrating mills, in particular screening machines, namely drum and vibrating screening machines, screens for screening machines, in particular shredders, in particular crushers, namely jaw crushers, machines and installations composed thereof for recycling residues, in particular for obtaining ferrous metals, non-ferrous metals, namely copper and aluminium, paper and plastics; Machines and installations composed thereof for recycling tyres by means of pyrolysis and condensation for oil recovery, in particular heavy and light oil, in particular shredders, feeders (metering devices), rotary pyrolysis tubes, tar extractors, machines and installations composed thereof for using wind energy, and electronic regulating and control apparatus required therefor. Machines and installations composed thereof for waste treatment and disposal, including thermal treatment of waste and trash, in particular for use in waste incineration installations and sewage sludge incineration installations, industrial installations, power stations; Parts for the aforesaid machines, included in class 11; Firing ovens for industrial purposes, industrial firing ovens, Combustion grates, Rotary kilns [for industrial purposes]; Gas and air purification installations and machines relating thereto, including mechanical filters for cleaning industrial gases, dust separators, parts for the aforesaid filters, included in class 11; Mechanical apparatus for cooling and drying gases and solid particles; Separators (machines), in particular electric separators, namely electric separators for filtering and flue gas purification installations, water separators in water treatment installations, high-voltage units being parts for electric filters; Dust removing installations for cleaning purposes, in particular flue gas purification installations, centrifuges, in particular hydrocyclones and installations composed thereof for separation; Flue gas purifying installations and parts therefor, included in class 11; Flue gas purifying reactors, denitrification installations; Machines and ovens for the thermal treatment of carbon for generating coal gas; Gas scrubbers, namely machines and mechanical filters for purifying gases; Combustion reactors; Steam generating apparatus; Machines and installations composed thereof for treating organic residues, namely by means of mechanical-biological waste treatment for obtaining reusable materials, namely compost, ferrous metals, non-ferrous metals and plastics and by means of fermentation for obtaining energy carriers, namely methane and methanol fur further material or energetic use; Installations for solar energy technology, solar power stations and components and apparatus therefor, namely solar cells, rectifiers, electronic regulating and control apparatus and solar installations composed of the aforesaid goods for generating electricity; Electronic regulating and control apparatus, being parts for solar collector installations for producing hot water, and power stations, machines and installations composed thereof for exhaust gas scrubbing. Virtual warehouse management for a number of replacement and wearing parts warehouses connected globally by data transmission/the internet for power stations, waste incineration and flue gas purification installations, automated electronic receipt of replacement part orders for power stations and waste incineration and flue gas purification installations, research and information, searches, searching for goods offers in databases, digital management of replacement and wearing parts by means of computers and an internet connection. Assembly, fix, Maintenance and servicing of the aforesaid goods and installations, including for the purposes of commissioning and trial operation. Storage of goods, In particular for storing replacement parts for power stations and waste incineration installations, storage of recycling products, Storage management and Consultancy and advice relating to the aforesaid. Technological design services, Namely construction of the aforesaid machines and installations; Technical advice and consultancy, In particular for process optimisation and Industrial analyses; Computer programming; Technical inspection of the aforesaid machines and installations within the framework of commissioning and testing.
85.
Hydrocarbon production apparatus and hydrocarbon production process
The hydrocarbon production apparatus is provided with a gas-liquid separator for cooling gaseous state hydrocarbons drawn out from a gas phase portion of a reactor for the Fischer-Tropsch synthesis reaction and liquefying a portion of the hydrocarbons. A light liquid hydrocarbon supply line for supplying light hydrocarbons is disposed between a downstream side line which is downstream from the last stage of a gas-liquid separating unit of the gas-liquid separator, and an upstream side line which is upstream from the last stage of the gas-liquid separating unit of the gas-liquid separator, wherein the downstream side line is a liquid hydrocarbon line on the downstream side through which the light hydrocarbons having cloud points lower than the temperature at an outlet of a cooler in the last stage of the gas-liquid separating unit are flowed.
B01J 8/00 - Chemical or physical processes in general, conducted in the presence of fluids and solid particles; Apparatus for such processes
B01J 8/08 - Chemical or physical processes in general, conducted in the presence of fluids and solid particles; Apparatus for such processes with moving particles
B01J 19/00 - Chemical, physical or physico-chemical processes in general; Their relevant apparatus
B01J 19/24 - Stationary reactors without moving elements inside
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
C07C 1/00 - Preparation of hydrocarbons from one or more compounds, none of them being a hydrocarbon
C07C 1/02 - Preparation of hydrocarbons from one or more compounds, none of them being a hydrocarbon from oxides of carbon
86.
SQUEEZING DEVICE, FUEL PELLET MANUFACTURING FACILITY, AND SQUEEZING METHOD
The present invention is provided with: an inscribed roll (3) which is rotatably disposed; a rotatable ring roll (2) which is disposed such that the inscribed roll (3) is disposed in a space portion formed therein, and the roll-center-to-roll-center distance from the inscribed roll (3) is variable; an inscribe roll rotation means which rotates the inscribed roll (3); a pressing roll (4) which is disposed outside the ring roll (2) and presses the outer peripheral surface of the ring roll (2); an adjustment means (33A) which relatively moves the inscribed roll (3) and the pressing roll (4) in a direction in which the rolls move toward or away from each other to thereby adjust the center-to-center distance between the rotation center of the inscribed roll (3) and the rotation center of the pressing roll (4); and a ring roll rotation means which rotates the ring roll (2). An object to be squeezed that has been put in the space portion of the ring roll (2) is directly squeezed by the inner peripheral surface of the ring roll (2) and the outer peripheral surface of the inscribed roll (3) between the inner peripheral surface of the ring roll (2) and the outer peripheral surface of the inscribed roll (3).
B30B 9/20 - Presses specially adapted for particular purposes for squeezing-out liquid from liquid-containing material, e.g. juice from fruits, oil from oil-containing material using rotary pressing members, other than worms or screws, e.g. rollers, rings, discs
B09B 3/00 - Destroying solid waste or transforming solid waste into something useful or harmless
C10L 5/44 - Solid fuels essentially based on materials of non-mineral origin on vegetable substances
87.
DEVICE FOR PRODUCING DIRECTLY REDUCED IRON AND PROCESS FOR PRODUCING DIRECTLY REDUCED IRON
A device (100) for producing directly reduced iron which is equipped with: a direct reduction furnace in which an iron oxide is contacted with a reducing gas to directly reduce the iron oxide; and a circulation part (20) in which the water and carbon dioxide that are contained in the gas discharged from the furnace are removed to obtain a reducing gas which is to be introduced into the direct reduction furnace (30). The device (100) for producing directly reduced iron is further equipped with: a heating furnace (40) in which a fuel gas having a lower heating value of 2.9-3.8 MJ/Nm3 is burned to heat the reducing gas; a first heat exchange part (13) for preheating the fuel gas; and a second heat exchange part (15) with which the air for combustion to be supplied to the heating furnace (40) is preheated by means of the heat of discharged combustion gas.
A waste gasification and melting furnace that promotes the drying and pyrolytic decomposition of waste in the shaft section, making it possible to limit the conveyance of moisture and volatile components to the bottom of the blast furnace and to reduce the consumption of extra coke. The waste gasification and melting furnace includes a shaft section; a melting furnace section; and a communicating section.
F23G 5/027 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels including pretreatment pyrolising or gasifying
F23G 5/08 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels including supplementary heating
F23G 5/44 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels - Details; Accessories
F23G 5/24 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels with combustion in a vertical, substantially cylindrical, combustion chamber
89.
Hydrogenation refining catalyst and method for producing a hydrocarbon oil
The hydrotreating catalyst of the present invention is a hydrotreating catalyst including a catalyst support including an amorphous composite metal oxide having solid acidity, and at least one active metal supported by the catalyst support and selected from noble metals of Group 8 to Group 10 in the periodic table, wherein the hydrotreating catalyst contains a carbonaceous substance including a carbon atom, and the content of the carbonaceous substance in the hydrotreating catalyst is 0.05 to 1% by mass in terms of the carbon atom.
C10G 45/64 - Refining of hydrocarbon oils using hydrogen or hydrogen-generating compounds to change the structural skeleton of some of the hydrocarbon content without cracking the other hydrocarbons present, e.g. lowering pour point; Selective hydrocracking of normal paraffins characterised by the catalyst used containing crystalline alumino-silicates, e.g. molecular sieves
C10G 45/62 - Refining of hydrocarbon oils using hydrogen or hydrogen-generating compounds to change the structural skeleton of some of the hydrocarbon content without cracking the other hydrocarbons present, e.g. lowering pour point; Selective hydrocracking of normal paraffins characterised by the catalyst used containing platinum group metals or compounds thereof
C10G 45/60 - Refining of hydrocarbon oils using hydrogen or hydrogen-generating compounds to change the structural skeleton of some of the hydrocarbon content without cracking the other hydrocarbons present, e.g. lowering pour point; Selective hydrocracking of normal paraffins characterised by the catalyst used
C10G 45/70 - Aromatisation of hydrocarbon oil fractions with catalysts containing platinum group metals or compounds thereof
C10G 11/18 - Catalytic cracking, in the absence of hydrogen, of hydrocarbon oils with preheated moving solid catalysts according to the "fluidised bed" technique
A vibration control device, comprising a waveform plate (21) formed so that wave peaks (20) successively alternate in a first direction (D1), and a restraining member (22) that clamps the waveform plate (21) on both sides facing in a second direction (D2) and that supports one end (21a) of the waveform plate (21), is provided between a first structural member (12) and second structural members (13, 14, 15) of a bridge (11), for example.
A process for producing a kerosene base fuel according to the present invention comprises removing paraffins having carbon number of 7 or less from a first fraction having an initial boiling point of 95 to 140° C. and a final boiling point of 240 to 280° C. obtained from a hydrotreated oil of a Fischer-Tropsch synthetic oil to obtain a second fraction having a content of paraffins having carbon number of 7 or less of 0.1 to 0.7% by mass.
This buckling-restrained brace is provided with a plate-shape core extending along the axis line, a restraining member which extends along the axis line and covers the core from the outer periphery in a state in which both axial ends of the core protrude, a filling material which is filled between the restraining member and the core, and, on both ends of the core in the axial direction, a pair of plate-shape first reinforcing members which are attached to the core such that the core is held from both sides in the width direction of the plates; this load-bearing structure incorporates this buckling-restrained brace.
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
E04B 1/58 - Connections for building structures in general of bar-shaped building elements
A tap hole apparatus comprises: a steel shell (11); heat-resistant bricks (13) that stretch along the inside of the steel shell (11); a cylindrical housing (16) that passes through the steel shell (11), and is positioned facing the heat-resistant bricks (13); and an annular or cylindrical sealing body (20) that is installed at the end of the housing (16) on the side of the heat-resistant bricks (13). The sealing body (20) comprises: a housing-side seal (221) that provides an airtight seal between the housing (16) and the sealing body, over the entire circumference; and a brick-side seal (222) that provides an airtight seal between the heat-resistant bricks (13) and the sealing body, over the entire circumference.
This hydrocarbon synthesis apparatus is provided with: a reactor for bringing a syngas which comprises carbon monoxide gas and hydrogen gas as main components into contact with a slurry obtained by suspending a solid catalyst in a liquid hydrocarbon compound, and thus synthesizing liquid hydrocarbon compounds by a Fischer-Tropsch process; a filter which is provided in the reactor and which separates the liquid hydrocarbon compounds from the catalyst; and a pulverized catalyst particles discharging means for discharging pulverized catalyst particles to the outside of the reactor, said pulverized catalyst particles being formed by pulverization of the solid catalyst contained in the slurry.
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
B01J 8/22 - Chemical or physical processes in general, conducted in the presence of fluids and solid particles; Apparatus for such processes with fluidised particles with liquid as a fluidising medium gas being introduced into the liquid
B03B 5/28 - Washing granular, powdered or lumpy materials; Wet separating by sink-float separation
B03B 5/64 - Washing granular, powdered or lumpy materials; Wet separating by hydraulic classifiers, e.g. of launder, tank, spiral or helical chute concentrator type of the free settling type
In the hydrocarbon-producing apparatus of the present invention, a vapor- liquid separation tank of a second vapor-liquid separation unit is provided with a filling material layer. A vapor-liquid separation tank of the first vapor-liquid separation unit is provided with a first return line. The vapor-liquid separation tank of the second vapor-liquid separation unit is provided with a second return line. A light component of light oil discharged from a bottom of the vapor-liquid separation tank is returned to a portion between a top side above a return-location from the second return line within the vapor-liquid separation tank of the second vapor-liquid separation unit, and a line directly connected with a cooler installed on the first vapor-liquid separation unit through the first return line. A heavy component of light oil discharged from a bottom of the vapor-liquid separation tank of the second vapor-liquid separation unit is returned to the filling material layer through the second return line.
This hydrocarbon synthesis apparatus is provided with: a reactor for bringing a syngas which comprises carbon monoxide gas and hydrogen gas as main components into contact with a slurry obtained by suspending a solid catalyst in a liquid hydrocarbon compound, and thus synthesizing liquid hydrocarbon compounds by a Fischer-Tropsch process; a filter which is provided in the reactor and which separates the liquid hydrocarbon compounds from the catalyst; and a pulverized catalyst particles discharging means for discharging pulverized catalyst particles to the outside of the reactor, said pulverized catalyst particles being formed by pulverization of the solid catalyst contained in the slurry.
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
B01J 8/22 - Chemical or physical processes in general, conducted in the presence of fluids and solid particles; Apparatus for such processes with fluidised particles with liquid as a fluidising medium gas being introduced into the liquid
B03B 5/28 - Washing granular, powdered or lumpy materials; Wet separating by sink-float separation
B03B 5/64 - Washing granular, powdered or lumpy materials; Wet separating by hydraulic classifiers, e.g. of launder, tank, spiral or helical chute concentrator type of the free settling type
In a hydrocarbon production apparatus, a filler layer is provided at an intermediate position in a gas/liquid separation vessel of a second gas/liquid separation unit, a first return line is provided in a gas/liquid separation vessel of a first gas/liquid separation unit, and a second return line is provided in the gas/liquid separation vessel of the second gas/liquid separation unit. In the first gas/liquid separation unit, a light fraction of a light oil, which is introduced from the bottom of the gas/liquid separation vessel, is returned, through the first return line, to a part which is located between a position closer to the top part relative to a return part of the second return line in the gas/liquid separation vessel of the second gas/liquid separation unit and a position located on a line right in front of the cooler in the first gas/liquid separation unit. In the second gas/liquid separation unit, a heavy fraction of the light oil, which is introduced from the bottom of the gas/liquid separation vessel of the second gas/liquid separation unit, is returned to the filler layer through the second return line.
Provided is a method for welding a clad steel tube (4), the purpose of the method being to improve the corrosion resistance of a portion where friction stir welding (FSW) is started when the welding is performed by friction stir welding from a clad layer side, the welding method comprising a step for circumferentially welding the abutting portions of the ends of the clad steel tube by friction stir welding from the inner side of the clad steel tube in which a clad layer (6) is laminated on the inner periphery of a carbon steel layer (5), wherein an FSW end position (PE) is made to overlap an FSW start position (PS) (by a lap margin (N)), a tool hole (12) formed at the FSW end position is filled in (to form a plugged welded portion (22)) by arc welding using a highly corrosion-resistant welding material (21), and the area (the area from (P1) to (P2)) from the mixed area of the carbon steel layer (5) and the clad layer (6) at the FSW start position (PS) up to the end position where the tool hole (12) is filled in is covered by a padding welding bead (13) formed by arc welding using the highly corrosion-resistant welding material (21) from the inner side of the clad steel tube (4).
B23K 20/12 - Non-electric welding by applying impact or other pressure, with or without the application of heat, e.g. cladding or plating the heat being generated by friction; Friction welding
B21C 37/06 - Manufacture of metal sheets, rods, wire, tubes, profiles or like semi-manufactured products, not otherwise provided for; Manufacture of tubes of special shape of tubes or metal hoses; Combined procedures for making tubes, e.g. for making multi-wall tubes
B23K 28/02 - Combined welding or cutting procedures or apparatus
B23K 9/04 - Welding for other purposes than joining, e.g. built-up welding
99.
CATALYST FOR MANUFACTURING LIGHT HYDROCARBON FROM SYNGAS, METHOD FOR MANUFACTURING SAID CATALYST, AND METHOD FOR MANUFACTURING LIGHT HYDROCARBON FROM SYNGAS
The objective of the present invention is to provide: a catalyst which has relatively low gas product selectivity for methane, etc., and which is not susceptible to runaway and does not clog flow paths, even when productivity in a microchannel reactor is set to be high; a method for manufacturing the catalyst; and a catalyst for manufacturing light hydrocarbons from syngas using the former catalyst. This catalyst for manufacturing a light hydrocarbon from syngas is characterized by having an average particle size of at most 400μm and by containing both a catalyst that contains a metallic compound that is active in Fischer-Tropsch synthesis, the catalyst being active in an exothermic reaction for generating a hydrocarbon from a syngas, and a catalyst that is active in an endothermic reaction for decomposing the generated hydrocarbon and producing a light hydrocarbon therefrom.
B01J 37/02 - Impregnation, coating or precipitation
C07C 1/04 - Preparation of hydrocarbons from one or more compounds, none of them being a hydrocarbon from oxides of carbon from carbon monoxide with hydrogen
There is provided a method for recovering hydrocarbon compounds from a gaseous by-products generated in the Fisher-Tropsch synthesis reaction, the method comprising a pressurizing step in which the gaseous by-products are pressurized, a cooling step in which the pressurized gaseous by-products are pressurized to liquefy hydrocarbon compounds in the gaseous by-products, and a separating step in which the hydrocarbon compounds liquefied in the cooling step are separated from the remaining gaseous by-products.
F25J 3/08 - Separating gaseous impurities from gases or gaseous mixtures
C10G 2/00 - Production of liquid hydrocarbon mixtures of undefined composition from oxides of carbon
C10G 31/06 - Refining of hydrocarbon oils, in the absence of hydrogen, by methods not otherwise provided for by heating, cooling, or pressure treatment
