12.
MEASURING LOCAL CRITICAL DIMENSION UNIFORMITY OF AN ARRAY OF TWO-DIMENSIONAL STRUCTURAL ELEMENTS
A method, a system, and a non-transitory computer readable medium for measuring a local critical dimension uniformity of an array of two-dimensional structural elements, the method may include obtaining an acquired optical spectrometry spectrum of the array; feeding the acquired optical spectrometry spectrum of the array to a trained machine learning process, wherein the trained machine learning process is trained to map an optical spectrometry spectrum to an average critical dimension (CD) and a local critical dimension uniformity (LCDU); and outputting, by the trained machine learning process, the average CD and the LCDU of the array.
An integrated metrology system for evaluating semiconductor wafers, the metrology system comprises a main body that has a rear side and a front side; the front side defines a front border of the main body; one or more detachable supporting units that are detachably coupled to the main body and support the main body while extending outside the front border; and at least one auxiliary supporting unit that is configured to support the main body at an absence of the one or more detachable supporting units
G01N 21/88 - Investigating the presence of flaws, defects or contamination
G01N 23/04 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by transmitting the radiation through the material and forming images of the material
A61B 50/10 - Furniture specially adapted for surgical or diagnostic appliances or instruments
A method, a system, and a non-transitory computer readable medium for accurate Raman spectroscopy. The method may include executing at least one iteration of the steps of: (i) performing, by an optical measurement system, a calibration process that comprises (a) finding a misalignment between a region of interest defined by a spatial filter, and an impinging beam of radiation that is emitted from an illuminated area of a sample, the impinging beam impinges on the spatial filter; and (b) determining a compensating path of propagation of the impinging beam that compensates the misalignment; and (ii) performing a measurement process, while the optical measurement system is configured to provide the compensating path of propagation of the impinging beam, to provide one or more Raman spectra.
G01N 21/27 - ColourSpectral properties, i.e. comparison of effect of material on the light at two or more different wavelengths or wavelength bands using photo-electric detection
A system and methods for OCD metrology are provided including receiving reference parameters, receiving multiple sets of measured scatterometric data, and receiving an optical model designed to generate one or more sets of model scatterometric data according to a set of pattern parameters, and training a machine learning model by applying, during the training, target features including the reference parameters, and by applying input features including the sets of measured scatterometric data and the sets of model scatterometric data, such that the trained machine learning model estimates new wafer pattern parameters from subsequently sets of measured scatterometric data.
A system and methods for OCD metrology are provided including receiving multiple first sets of scatterometric data, dividing each set into k sub-vectors, and training, in a self-supervised manner, k2 auto-encoder neural networks that map each of the k sub-vectors to each other. Subsequently multiple respective sets of reference parameters and multiple corresponding second sets of scatterometric data are received and a transfer neural network (NN) is trained. Initial layers include a parallel arrangement of the k2 encoder neural networks. Target output of the transfer NN training is set to the multiple sets of reference parameters and feature input is set to the multiple corresponding second sets of scatterometric data, such that the transfer NN is trained to estimate new wafer pattern parameters from subsequently measured sets of scatterometric data.
A system and methods for OCD metrology are provided including receiving training data for training an OCD machine learning (ML) model, including multiple pairs of corresponding sets of scatterometric data and reference parameters. For each of the pairs, one or more corresponding outlier metrics are by calculated and corresponding outlier thresholds are applied whether a given pair is an outlier pair. The OCD ML model is then trained with the training data less the outlier pairs.
G01N 21/89 - Investigating the presence of flaws, defects or contamination in moving material, e.g. paper, textiles
G01N 21/95 - Investigating the presence of flaws, defects or contamination characterised by the material or shape of the object to be examined
G06F 15/18 - in which a program is changed according to experience gained by the computer itself during a complete run; Learning machines (adaptive control systems G05B 13/00;artificial intelligence G06N)
A combined OCD and photoreflectance system and method for improving the OCD performance in measurements of optical properties of a target sample. The system comprises (a) either a single channel OCD set-up comprised of a single probe beam configured in a direction normal/oblique to the target sample or a multi-channel OCD set-up having multiple probe beams configured in normal and oblique directions to the target sample for measuring the optical properties of the target sample, (b) at least one laser source for producing at least one laser beam, (c) at least one modulation device to turn the at least one laser beam into at least one alternatingly modulated laser beam, and (d) at least one spectrometer for measuring spectral components of the at least one light beam reflecting off said target sample; wherein the at least one alternatingly modulated laser beam is alternatingly modulating the spectral reflectivity of the target sample,
Photoreflectance (PR) spectroscopy system and method for accumulating separately a "pump on" light beam and a "pump off light beam reflecting off a sample. The system comprises: (a) a probe source for producing a probe beam, the probe beam is used for measuring spectral reflectivity of a sample, (b) a pump source for producing a pump beam, (c) at least one spectrometer, (d) a first modulation device to allow the pump beam to alternatingly modulate the spectral reflectivity of the sample, so that, a light beam reflecting from the sample is altematingly a "pump on" light beam and a "pump off light beam, (e) a second modulation device in a path of the light beam reflecting off the sample to alternatingly direct the "pump on" light beam and the "pump off light beam to the at least one spectrometer, and (f) a computer.
Optical metrology may be used to examine substrates prior to a fabrication operation in order to adjust processing parameters of the fabrication operation. A machine learning model may analyze the optical signals received by an optical metrology tool to propose a temperature distribution to be used in a subsequent fabrication operation. The temperature distribution may improve the uniformity of the wafer and/or achieve a desired target feature value.
Controlling semiconductor device manufacture by acquiring training scatterometric signatures collected at training locations on training semiconductor wafers and corresponding to locations within a predefined design of a training semiconductor device, the training signatures collected after predefined processing steps during manufacture of the device on the training wafers, acquiring manufacturing outcome data associated with the training locations, training a prediction model using the training signatures and the manufacturing outcome data, and applying the prediction model to a candidate scatterometric signature to predict a manufacturing outcome, the candidate signature collected at a candidate location on a candidate semiconductor wafer, the candidate location corresponding to a location within the same predefined design of a candidate semiconductor device, the candidate signature collected after any of the processing steps during manufacture of the candidate device on the candidate wafer.
A measurement system is presented configured for integration with a processing equipment for applying optical measurements to a structure. The measurement system comprises: a support assembly for holding a structure under measurements in a measurement plane, configured and operable for rotation in a plane parallel to the measurement plane and for movement along a first lateral axis in said measurement plane; an optical system defining illumination and collection light channels of normal and oblique optical schemes and comprising an optical head comprising at least three lens units located in the illumination and collection channels; a holder assembly comprising: a support unit for carrying the optical head, and a guiding unit for guiding a sliding movement of the support unit along a path extending along a second lateral axis perpendicular to said first lateral axis; and an optical window arrangement comprising at least three optical windows made in a faceplate located between the optical head at a certain distance from the measurement plane. The optical windows are aligned with the illumination and collection channels for, respectively, propagation of illuminating light from the optical head and propagation of light returned from an illuminated region to the optical head, in accordance with the normal and oblique optical schemes.
G01N 21/95 - Investigating the presence of flaws, defects or contamination characterised by the material or shape of the object to be examined
G01N 23/04 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by transmitting the radiation through the material and forming images of the material
Semiconductor device metrology including creating a time-domain representation of wavelength-domain measurement data of light reflected by a patterned structure of a semiconductor device, selecting an earlier-in-time portion of the time-domain representation that excludes a later-in-time portion of the time-domain representation, and determining one or more measurements of one or more parameters of interest of the patterned structure by performing model-based processing using the earlier-in-time portion of the time-domain representation.
A polarized Raman Spectrometric system for defining parameters of a polycrystalline material, the system comprises a polarized Raman Spectrometric apparatus, a computer-controlled sample stage for positioning a sample at different locations, and a computer comprising a processor and an associated memory. The polarized Raman Spectrometric apparatus generates signal(s) from either small sized spots at multiple locations on a sample or from an elongated line- shaped points on the sample, and the processor analyzes the signal(s) to define the parameters of said polycrystalline material.
A method for use in optical measurements on patterned structures, the method including performing a number of optical measurements on a structure with a measurement spot configured to provide detection of light reflected from an illuminating spot at least partially covering at least two different regions of the structure, the measurements including detecting light reflected from the at least part of the at least two different regions within the measurement spot, the detected light including interference of at least two complex electric fields reflected from the at least part of the at least two different regions, and being therefore indicative of a phase response of the structure, carrying information about properties of the structure.
A semiconductor metrology system including a spectrum acquisition tool for collecting, using a first measurement protocol, baseline scatterometric spectra on first semiconductor wafer targets, and for various sources of spectral variability, variability sets of scatterometric spectra on second semiconductor wafer targets, the variability sets embodying the spectral variability, a reference metrology tool for collecting, using a second measurement protocol, parameter values of the first semiconductor wafer targets, and a training unit for training, using the collected spectra and values, a prediction model using machine learning and minimizing an associated loss function incorporating spectral variability terms, the prediction model for predicting values for production semiconductor wafer targets based on their spectra.
Advertising, marketing and promotional services related to the senior care industry for the purpose of facilitating networking and socializing opportunities for business purposes
Advertising, marketing and promotional services related to the senior care industry for the purpose of facilitating networking and socializing opportunities for business purposes
Advertising, marketing and promotional services related to the senior care industry for the purpose of facilitating networking and socializing opportunities for business purposes
A control system for use in measuring one or more parameters of a patterned structure. The control system is configured as a computer system and comprises: an input utility configured to receive input data comprising raw measured TEM image data, TEMmeas, data indicative of a TEM measurement mode; and a data processor configured to process the raw measured TEM image data, TEMmeas, and generate output data indicative of one or more parameters of a patterned structure. The data processor comprises an optimization module configured and operable to utilize the data indicative of the TEM measurement mode and perform a fitting procedure between the raw measured TEM image data, TEMmeas, and predetermined simulated TEM image data, TEMsimul, and determine one or more parameters of the structure from the simulated image data corresponding to a best fit condition. The predetermined simulated TEM image data, TEMsimul, is based on a parametrized three-dimensional model of features of the patterned structure, and comprises one or more simulated TEM images and a simulated weight map comprising weights assigned to different regions in the simulated TEM image corresponding to different features of the patterned structure.
H01L 21/66 - Testing or measuring during manufacture or treatment
H01J 37/26 - Electron or ion microscopesElectron- or ion-diffraction tubes
G01B 15/02 - Measuring arrangements characterised by the use of electromagnetic waves or particle radiation, e.g. by the use of microwaves, X-rays, gamma rays or electrons for measuring thickness
G01B 11/06 - Measuring arrangements characterised by the use of optical techniques for measuring length, width, or thickness for measuring thickness
G01N 23/225 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by measuring secondary emission from the material using electron or ion microprobes
G01N 21/84 - Systems specially adapted for particular applications
A method and system are presented for use in X-ray based measurements on patterned structures. The method comprises: processing data indicative of measured signals corresponding to detected radiation response of a patterned structure to incident X-ray radiation, and subtracting from said data an effective measured signals substantially free of background noise, said effective measured signals being formed of radiation components of reflected diffraction orders such that model based interpretation of the effective measured signals enables determination of one or more parameters of the patterned structure, wherein said processing comprises: analyzing the measured signals and extracting therefrom a background signal corresponding to the background noise; and applying a filtering procedure to the measured signals to subtract therefrom signal corresponding to the background signal, resulting in the effective measured signal.
G01N 23/201 - Measuring small-angle scattering, e.g. small angle X-ray scattering [SAXS]
G01N 23/20 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by using diffraction of the radiation by the materials, e.g. for investigating crystal structureInvestigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by using scattering of the radiation by the materials, e.g. for investigating non-crystalline materialsInvestigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by using reflection of the radiation by the materials
G01N 23/207 - Diffractometry, e.g. using a probe in a central position and one or more displaceable detectors in circumferential positions
32.
Raman spectroscopy based measurements in patterned structures
A method and system are presented for use in measuring one or more characteristics of patterned structures. The method comprises: providing measured data comprising data indicative of at least one Raman spectrum obtained from a patterned structure under measurements using at least one selected optical measurement scheme each with a predetermined configuration of at least one of illuminating and collected light conditions corresponding to the characteristic(s) to be measured; processing the measured data, and determining, for each of the at least one Raman spectrum, a distribution of Raman-contribution efficiency (RCE) within at least a part of the structure under measurements, being dependent on characteristics of the structure and the predetermined configuration of the at least one of illuminating and collected light conditions in the respective optical measurement scheme; analyzing the distribution of Raman-contribution efficiency and determining the characteristic(s) of the structure.
H01L 21/66 - Testing or measuring during manufacture or treatment
G01L 1/24 - Measuring force or stress, in general by measuring variations of optical properties of material when it is stressed, e.g. by photoelastic stress analysis
A method and system are presented for use in measuring one or more characteristics of patterned structures. The method comprises: performing measurements on a patterned structure by illuminating the structure with exciting light to cause Raman scattering of one or more excited regions of the pattern structure, while applying a controlled change of at least temperature condition of the patterned structure, and detecting the Raman scattering, and generating corresponding measured data indicative of a temperature dependence of the detected Raman scattering; and analyzing the measured data and generating data indicative of spatial profile of one or more properties of the patterned structure.
A control system is presented for use in measuring one or more parameters of a three-dimensional patterned structure. The control system is configured as a computer system comprising a data processor configured to receive and process raw measured TEM image data, TEMmeas, and generate output data indicative of one or more parameters of a patterned structure. The data processor comprises an optimization module configured and operable to utilize data indicative of one or more parameters of TEM measurement mode and perform a fitting procedure between the raw measured TEM image data, TEMmeas, and a predetermined simulated TEM image data, TEMsimui based on a parametrized three- dimensional model of features of the patterned structure, and generate simulated image data corresponding to a best fit condition, to thereby enable determination therefrom of the one or more parameters of the structure.
H01L 21/66 - Testing or measuring during manufacture or treatment
G01B 15/02 - Measuring arrangements characterised by the use of electromagnetic waves or particle radiation, e.g. by the use of microwaves, X-rays, gamma rays or electrons for measuring thickness
H01J 37/26 - Electron or ion microscopesElectron- or ion-diffraction tubes
G01N 23/225 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by measuring secondary emission from the material using electron or ion microprobes
35.
AN APPARATUS AND METHOD FOR ELECTRICAL TEST PREDICTION
A test site and method are herein disclosed for predicting E-test structure (in-die structure) and/or device performance. The test site comprises an E-test structure and OCD-compatible multiple structures in the vicinity of the E-test structure to allow optical scatterometry (OCD) measurements. The OCD-compatible multiple structures are modified by at least one modification technique selected from (a) multiplication type modification technique, (b) dummification type modification technique, (c) special Target design type modification technique, and (d) at least one combination of (a), (b) and (c) for having a performance equivalent to the performance of the E-test structure.
A method and system are presented for use in controlling a multiple patterning process of n patterning stages subsequently applied to a sample to produce a target pattern thereon. The method comprises: providing intermediate measured data indicative of an optical response of the sample after being patterned by m-th patterning stage, 1≤m
An optical system and method are presented for use in measurements on an upper surface of a layered sample when located in a measurement plane. The optical system is configured as a normal-incidence system having an illumination channel and a collection channel, and comprises an objective lens unit and a light propagation affecting device. The objective lens unit is accommodated in the illumination and collection channels, thereby defining a common optical path for propagation of illuminating light from the illumination channel toward an illuminating region in the measurement plane and for propagation of light returned from measurement plane to the collection channel. The light propagation affecting device comprises an apertured structure located in at least one of the illumination and collection channels, and configured to provide angular obscuration of light propagation path for blocking angular segments associated with light propagation from regions outside the illuminated region.
Controlling an etch process applied to a multi-layered structure, by calculating a spectral derivative of reflectance of an illuminated region of interest of a multi-layered structure during an etch process applied to the multi-layered structure, identifying in the spectral derivative a discontinuity that indicates that an edge of a void formed by the etch process at the region of interest has crossed a layer boundary of the multi-layered structure, determining that the crossed layer boundary corresponds to a preselected layer boundary of the multi-layered structure, and applying a predefined control action to the etch process responsive to determining that the crossed layer boundary corresponds to the preselected layer boundary of the multi -layered structure.
H01L 21/66 - Testing or measuring during manufacture or treatment
H01L 21/822 - Manufacture or treatment of devices consisting of a plurality of solid state components or integrated circuits formed in, or on, a common substrate with subsequent division of the substrate into plural individual devices to produce devices, e.g. integrated circuits, each consisting of a plurality of components the substrate being a semiconductor, using silicon technology
09 - Scientific and electric apparatus and instruments
Goods & Services
(1) Wireless wearable technology call system in pendant form or in wristband form comprising motion sensors, GPS receivers, GPS transmitters; contactless pendant or wristband readable by a contactless door lock reader in pendant form or in wristband form comprising motion sensors, GPS receivers, GPS transmitters; electronic key for residence door; entry access controller that allows requests for emergency or non-emergency assistance with the press of a button; fall detection monitor in pendant form or in wristband form; security system, namely a motion sensor and a wireless wearable technology in pendant form or in wristband form to detect the presence of a person and to identify the person
40.
OPTICAL SYSTEM AND METHOD FOR MEASUREMENTS OF SAMPLES
A measurement system is presented for use in metrology measurements on patterned samples. The system comprises: at least one light source device configured to generate broadband light, at least one detection device configured to provide spectral information of detected light, and an optical system. The optical system comprises at least an oblique channel system for directing incident light generated by the light source(s) along an oblique illumination channel onto a measurement plane, on which a sample is to be located, and directing broadband light specularly reflected from the sample along a collection channel to the detection device(s). The optical system further comprises an interferometric unit comprising a beam splitting/combining device and a reference reflector device. The beam splitting/combining device is accommodated in the illumination and collection channels and divides light propagating in the illumination channel into sample and reference light beams propagating in sample and reference paths, and combines reflected reference and sample paths into the collection channel to thereby create a spectral interference pattern on a detection plane.
36 - Financial, insurance and real estate services
43 - Food and drink services, temporary accommodation
44 - Medical, veterinary, hygienic and cosmetic services; agriculture, horticulture and forestry services
Goods & Services
(1) Investing in nursing homes, physical rehabilitation centers, and hospices
(2) Operating independent living residences for seniors and retirement living residences
(3) Providing nursing care in homes, independent living residences and retirement living residences; operating nursing homes, physical rehabilitation centers, and hospices
43 - Food and drink services, temporary accommodation
Goods & Services
Retirement home services; providing independent living residences, and assisted living facilities, namely, respite care and elder care day care services; providing assisted living facilities; providing elder care; home care and adult care in the nature of meal preparation
43.
METHOD AND SYSTEM FOR PROCESSING PATTERNED STRUCTURES
A system and method are presented for controlling a process applied to a structure comprising at least one of material removal and material deposition processes. The system comprises: a heating radiation source configured and operable to generate a temperature field profile across a processing area of the structure; and a control unit configured and operable to control operation of said heating radiation source in accordance with a predetermined pattern map within the processing area, so as to create a corresponding pattern selective profile of said temperature field across said processing area providing desired pattern selective distribution of at least one parameter characterizing the process applied to the processing area of the structure.
H01L 21/304 - Mechanical treatment, e.g. grinding, polishing, cutting
H01L 21/67 - Apparatus specially adapted for handling semiconductor or electric solid state devices during manufacture or treatment thereofApparatus specially adapted for handling wafers during manufacture or treatment of semiconductor or electric solid state devices or components
44.
RAMAN SPECTROSCOPY BASED MEASUREMENTS IN PATTERNED STRUCTURES
A method and system are presented for use in measuring one or more characteristics of patterned structures. The method comprises: providing measured data comprising data indicative of at least one Raman spectrum obtained from a patterned structure under measurements using at least one selected optical measurement scheme each with a predetermined configuration of at least one of illuminating and collected light conditions corresponding to the characteristic(s) to be measured; processing the measured data, and determining, for each of the at least one Raman spectrum, a distribution of Raman-contribution efficiency (RCE) within at least a part of the structure under measurements, being dependent on characteristics of the structure and the predetermined configuration of the at least one of illuminating and collected light conditions in the respective optical measurement scheme; analyzing the distribution of Raman- contribution efficiency and determining the characteristic(s) of the structure.
G01N 21/66 - Systems in which the material investigated is excited whereby it emits light or causes a change in wavelength of the incident light electrically excited, e.g. electroluminescence
A method and system are presented for use in measuring characteristic(s) of patterned structures. The method utilizes processing of first and second measured data, wherein the first measured data is indicative of at least one Raman spectrum obtained from a patterned structure under measurements using at least one selected optical measurement scheme each with a predetermined configuration of illuminating and/or collected light conditions corresponding to the characteristic(s) to be measured, and the second measured data comprises at least one spectrum obtained from the patterned structure in Optical Critical Dimension (OCD) measurement session. The processing comprises applying model-based analysis to the at least one Raman spectrum and the at least one OCD spectrum, and determining the characteristic(s) of the patterned structure under measurements.
43 - Food and drink services, temporary accommodation
Goods & Services
Retirement homes; providing independent living, assisted living, and long term care facilities and services, namely, respite care and elder care day care services; providing assisted living facilities; providing elder care; food preparation services provided as a component of home care and adult care
47.
HYBRID MEASUREMENT SYSTEM AND METHOD FOR MEASURING IN THIN FILMS
A measurement method and system are presented for in-line measurements of one or more parameters of thin films in structures progressing on a production line. First measured data and second measured data are provided from multiple measurements sites on the thin film being measured, wherein the first measured data corresponds to first type measurements from a first selected set of a relatively small number of the measurement sites, and the second measured data corresponds to second type optical measurements from a second set of significantly higher number of the measurements sites. The first measured data is processed for determining at least one value of at least one parameter of the thin film in each of the measurement sites of said first set. Such at least one parameter value is utilized for interpreting the second measured data, thereby obtaining data indicative of distribution of values of said at least one parameter within said second set of measurement sites.
43 - Food and drink services, temporary accommodation
Goods & Services
Retirement homes; providing independent living, assisted living, and long term care facilities and services, namely, respite care and elder care day care services; providing assisted living facilities; providing elder care; food preparation services provided as a component of home care and adult care
49.
METHOD FOR USE IN PROCESS CONTROL OF MANUFACTURE OF PATTERNED SAMPLES
A method and system are presented for use in controlling a multiple patterning process of n patterning stages subsequently applied to a sample to produce a target pattern thereon. The method comprises: providing intermediate measured data indicative of an optical response of the sample after being patterned by m-th patterning stage, 1≤m
G01N 21/956 - Inspecting patterns on the surface of objects
G03F 7/00 - Photomechanical, e.g. photolithographic, production of textured or patterned surfaces, e.g. printed surfacesMaterials therefor, e.g. comprising photoresistsApparatus specially adapted therefor
G01B 11/14 - Measuring arrangements characterised by the use of optical techniques for measuring distance or clearance between spaced objects or spaced apertures
H01L 21/66 - Testing or measuring during manufacture or treatment
50.
A METHOD OF MEASUREMENT AND CONTROL OF THE SURFACE POTENTIAL OF A SAMPLE
A method of measurement and control of the surface potential of a sample using measuring the distribution of kinetic energy of charged particles emitted from a surface of a sample. A shift in kinetic energy of the charged particles is determined and the surface potential of the surface of the sample is changed in response the shift in kinetic energy of the charged particles.
G01N 23/22 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by measuring secondary emission from the material
Systems and approaches for semiconductor metrology and surface analysis using Secondary Ion Mass Spectrometry (SIMS) are disclosed. In an example, a secondary ion mass spectrometry (SIMS) system includes a sample stage. A primary ion beam is directed to the sample stage. An extraction lens is directed at the sample stage. The extraction lens is configured to provide a low extraction field for secondary ions emitted from a sample on the sample stage. A magnetic sector spectrograph is coupled to the extraction lens along an optical path of the SIMS system. The magnetic sector spectrograph includes an electrostatic analyzer (ESA) coupled to a magnetic sector analyzer (MSA).
A test structure and method of its manufacture are presented for use in metrology measurements of a sample pattern. The test structure comprises a test pattern comprising a portion of the sample pattern including at least one selected feature and a blocking layer at least partially covering regions of the test structure adjacent to the at least one selected region
