Described is a hinge for doors of electrical household appliances, including a first lever and a box-shaped element pivoted to each other and movable relative to each other in a tiltable fashion, fixable one to a frame and the other to a door of an electrical household appliance, to make the door movable relative to the frame between a closed position and an open position, a first elastic element connected to the first lever and designed to generate, with a relative deformation, an elastic reaction force designed to compensate at least partially the weight force of the door during the opening or closing of the door, a damping member housed inside a containment cartridge.
Described is a hinge for doors of electrical household appliances, including a first element and a second element pivoted to each other and movable relative to each other in tilting fashion, the first and second elements being fixable one to a frame and the other to a door of an electrical household appliance, for making the door movable with respect to the frame between a closed position and an open position, a lever for connection between the first and the second closing elements, the lever being pivoted on the first element, an elastic element operatively connected to the lever to oppose the weight force of the door during its opening.
A hinge for doors of domestic appliances, comprising a first element and a second element pivoted to each other and movable relative to each other in tilting fashion, the first and second elements being fixable one to a frame and the other to a door of an electrical household appliance, for making the door movable with respect to the frame between a closed position and an open position, a lever for connection between the first and the second closing elements, an elastic element connected to the lever and designed to generate with its own deformation a force of elastic adjustment designed to compensate at least partially the weight force of the door during the opening or closing of the door, means for adjusting the intensity of the elastic reaction force.
A hinge for doors of electrical household appliances, including a box-shaped element and a first lever pivoted on the box-shaped element by means of a pin; one of either the box-shaped element or the first lever being fixable to a frame and the other being fixable to a door, to make the door tiltably movable relative to the frame between a closed position and an open position; first elastic means supported by the box-shaped element and designed to apply an elastic action on the first lever, a rod for connecting the first lever to the first elastic means, positioned in a slidable fashion inside the box-shaped element; a hydraulic damping member for applying a damping action during the reciprocal motion between the first lever and the box-shaped element.
E05F 1/14 - Closers or openers for wings, not otherwise provided for in this subclass spring-actuated for swinging wings with double-acting springs, e.g. for closing and opening or checking and closing
E05F 1/12 - Mechanisms in the shape of hinges or pivots, operated by springs
E05F 5/02 - Braking devices, e.g. checks; Stops; Buffers specially for preventing the slamming of wings
E05F 3/20 - Closers or openers with braking devices, e.g. checks; Construction of pneumatic or liquid braking devices in hinges
A hinge for doors of appliances, including a box-shaped element and a first lever pivoted on the box-shaped element by a first pin; one of the box-shaped element or the first lever being fixable to a frame and the other fixable to a door, to make the door tiltably movable relative to the frame between a closed position and an open position; a first elastic device supported by the box-shaped element for applying an elastic action on the first lever, a rod for connecting the first lever to the first elastic device, the connecting rod being positioned in a slidable fashion inside the box-shaped element; a damping member for applying a damping action during the reciprocal motion of the first lever and the box-shaped element, in the proximity of reaching the closed position; a cartridge containing the hydraulic damping member, the cartridge being fixed to the box-shaped element.
E05F 1/08 - Closers or openers for wings, not otherwise provided for in this subclass spring-actuated
E05F 3/20 - Closers or openers with braking devices, e.g. checks; Construction of pneumatic or liquid braking devices in hinges
E05D 3/18 - Hinges with pins with two or more pins with sliding pins or guides
E05F 3/02 - Closers or openers with braking devices, e.g. checks; Construction of pneumatic or liquid braking devices with pneumatic piston brakes
E05F 3/10 - Closers or openers with braking devices, e.g. checks; Construction of pneumatic or liquid braking devices with liquid piston brakes with a spring, other than a torsion spring, and a piston, the axes of which are the same or lie in the same direction
6.
Actuating system for a door of an electrical domestic appliance
An automatic system for actuating a door of an electrical domestic appliance comprising a frame and a door, the system comprising a first hinge body which can be fixed to the frame, a second hinge body, fixable to the door and connected to the first body to move in a tilting fashion between a first closed position, wherein the door is abutted to the frame, and a second open position, wherein the door is spaced from the frame, allowing access to a compartment of the electrical domestic appliance, means for moving the second body relative to the first body comprising an electric actuator and means for transmitting the motion from the actuator to the second body.
E05F 15/627 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for swinging wings operated by flexible elongated pulling elements, e.g. belts, chains or cables
A47L 15/42 - Washing or rinsing machines for crockery or table-ware - Details
E05F 1/12 - Mechanisms in the shape of hinges or pivots, operated by springs
E05F 1/14 - Closers or openers for wings, not otherwise provided for in this subclass spring-actuated for swinging wings with double-acting springs, e.g. for closing and opening or checking and closing
F24C 15/02 - Doors specially adapted for stoves or ranges
E05F 15/616 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for swinging wings operated by push-pull mechanisms
E05F 15/622 - Power-operated mechanisms for wings using electrical actuators using rotary electromotors for swinging wings operated by push-pull mechanisms using screw-and-nut mechanisms
A hinge for wings or doors, in particular for electrical household appliances, comprises a first element (2) and a second element (3) pivoted to each other and movable relative to each other in tilting fashion, a connecting lever (5) between the elements (2, 3), the lever (5) pivoting on the first element (2), the second element (3) being box-shaped and comprising inside it a spring (7) connected to the lever (5) by a drive rod (8) which can slide at least partly inside the second box-shaped element (3) itself.
A door or wing for electrical household appliances comprises a pivoting element (30) and two hinges (40, 50) mounted along one perimetric side of the pivoting element (30) to join the pivoting element (30) to a frame (2) and make it movable relative to the latter between a closed position and an open position, each of the two hinges (40, 50) comprising a first member and a second, box-shaped member and a lever for connecting the first and second members.
Described is a hinge for wings or doors, in particular for electrical household appliances, comprising a first body (5), a second body (6) and a connecting lever (7) between the first and the second body (5, 6).
The hinge for wings or doors, in particular of electrical appliances, comprises a first box-shaped body, a second box-shaped body, a connecting element between the first and second bodies, and a damper cylinder for applying on the second body an action damping its movement towards the first body.
A connection for hinges of the type having two elements which can rotate relative to one another; the connection comprises a box-shaped body having a base wall and two parallel lateral walls, and can be stably connected to a fixed frame of an electrical appliance.
