An x-ray imaging system for generating images of a pipe weld from which weld quality defects may be detected, comprises an x-ray emitter for emitting a beam of x-ray photons in a projection pattern, a first photon detector, a second photon detector, and an orbital travel assembly. The first photon detector is for sensing a first detection pattern of photons emitted from the x-ray emitter and passing through a portion of the weld. The second photon detector is for sensing a second detection pattern of photons emitted from the x-ray emitter and passing through the portion of the weld. The orbital travel assembly is for supporting the x-ray emitter and the first and second photon detectors as they travel along an orbital weld path of the weld at least partly around the pipe in a direction of travel. The second photon detector is positioned behind the first photon detector in the direction of travel along the orbital weld path, such that the second photon detector is configured to sense the second detection pattern after the first photon sensor detects the first detection pattern, in use.
G01N 23/04 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by transmitting the radiation through the material and forming images of the material
An x-ray imaging system for generating images of a pipe weld from which weld quality defects may be detected, comprises an x-ray emitter for emitting a beam of x-ray photons in a projection pattern, a first photon detector, a second photon detector, and an orbital travel assembly. The first photon detector is for sensing a first detection pattern of photons emitted from the x-ray emitter and passing through a portion of the weld. The second photon detector is for sensing a second detection pattern of photons emitted from the x-ray emitter and passing through the portion of the weld. The orbital travel assembly is for supporting the x-ray emitter and the first and second photon detectors as they travel along an orbital weld path of the weld at least partly around the pipe in a direction of travel. The second photon detector is positioned behind the first photon detector in the direction of travel along the orbital weld path, such that the second photon detector is configured to sense the second detection pattern after the first photon sensor detects the first detection pattern, in use.
G01N 23/04 - Investigating or analysing materials by the use of wave or particle radiation, e.g. X-rays or neutrons, not covered by groups , or by transmitting the radiation through the material and forming images of the material
An orbital welder for welding together two pipes to be welded. The welder may include a fall brake for preventing a freefall of the welder. The welder may include a splatter shield for preventing dust from entering an outer housing and fowling sensitive machine components. The welder may include a weld torch assembly with manual adjustments. The welder may include an automatic lead/lag adjustment and control of that adjustment during a welding operation to automatically transition from a first weld zone to a second weld zone.
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 9/095 - Monitoring or automatic control of welding parameters
B23K 31/02 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to soldering or welding
B23K 37/02 - Carriages for supporting the welding or cutting element
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
F16L 1/10 - Accessories therefor, e.g. anchors for aligning
An orbital welder for welding together two pipes to be welded. The welder may include a fall brake for preventing a freefall of the welder. The welder may include a splatter shield for preventing dust from entering an outer housing and fowling sensitive machine components. The welder may include a weld torch assembly with manual adjustments. The welder may include an automatic lead/lag adjustment and control of that adjustment during a welding operation to automatically transition from a first weld zone to a second weld zone.
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 31/02 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to soldering or welding
B23K 37/02 - Carriages for supporting the welding or cutting element
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
F16L 1/10 - Accessories therefor, e.g. anchors for aligning
B23K 9/095 - Monitoring or automatic control of welding parameters
A pipe positioning and welding combination comprises a pipe positioner and a welder, for manipulating ends of pipes to be welded and welding the pipe ends together. The pipe positioner comprises a main beam and a pair of grapples mounted on the main beam, the grapples for grabbing and securing a pipe. The welder comprises a welding bug including a welding torch, a bug rail on which the welding bug is configured to be guided, a deformation ring, and a sensor assembly. The deformation ring includes a plurality of substantially radially extending and/or extendable shoes configured to engage an outer surface of a pipe to be welded. The sensor assembly includes at least one substantially radially inwardly directed sensor connected to a mount on the welder. The welding bug is configured for reliable connection to the bug rail and movement along the bug rail in an arc substantially parallel with a pipe welding area. The deformation ring and/or the sensor assembly include at least one pivotable clamshell structure for selectively surrounding a pipe. The welder is configured to be mounted to the pipe positioner, and the clamshell structure is openable in concert with the grapples to receive pipe ends and closable after closing of the grapples to surround a weld region of a pipe.
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 26/282 - Seam welding of curved planar seams of tube sections
B23K 31/02 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to soldering or welding
B23K 37/02 - Carriages for supporting the welding or cutting element
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
F16L 1/10 - Accessories therefor, e.g. anchors for aligning
WELDING TORCH POSITIONER FOR HOLDING AND POSITIONING A WELDING TORCH FOR WELDING TWO PIPE SEGMENTS TOGETHER, AND WELDING APPARATUS (5) FOR WELDING TWO PIPE SEGMENTS TOGETHER WITH SUCH POSITIONER
The present application relates to a welding torch positioner (100) for holding and positioning a welding torch for welding two pipe segments together, the pipe segments positioned colinearly along a longitudinal axis and abutting at ends to define a weld gap between the ends, comprises a torch holder assembly (200) and a base assembly (300). The torch holder assembly (200) comprises an angle block assembly and a quick angle lock assembly, the angle block assembly including a receptacle for securely holding the torch and also including a first plurality of mounts. Each of the first plurality of mounts is configured to determine a respective discrete relative angle of attachment of the angle block assembly to the quick angle lock assembly, the quick angle lock assembly including a shaped connector projection and/or receptacle and also including a first mount. The first mount is selectively connectible to each of the first plurality of mounts to secure the angle block assembly to the quick angle lock assembly at any of a first plurality of relative angles determined respectively by each of the first plurality of mounts. The base assembly (300) includes a quick angle lock receptacle and/or projection for mating connection with the shaped connector projection or receptacle, respectively, of the quick angle lock assembly, thereby to secure the torch holder assembly (200) to the base assembly (300). The base assembly (300) is for attachment to a welder arm of a welding apparatus.
Provided is an apparatus for coating a girth weld and a cutback region surrounding said girth weld, said apparatus having lateral travel at least equal to the length of the cutback region and circumferential rotational travel around the pipe. The apparatus can provide a multiple component coating accurately and safely, without the need for solvent flushing of the apparatus.
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 37/02 - Carriages for supporting the welding or cutting element
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
8.
Apparatus and method for discretely positioning a welding torch
Provided is an apparatus for coating a girth weld and a cutback region surrounding said girth weld, said apparatus having lateral travel at least equal to the length of the cutback region and circumferential rotational travel around the pipe. The apparatus can provide a multiple component coating accurately and safely, without the need for solvent flushing of the apparatus.
A non-destructive system for detecting anomalies in weldment of a pipeline is provided including an imaging apparatus, an anomaly detection unit, and a computing device. The imaging apparatus produces image segments corresponding to segments of the circumferential area of the weldment. The anomaly detection unit includes an artificial intelligence platform that processes and analyzes the image segments to identify at least one of a type, size, and location of a welding anomaly within the weldment using a database of truth data. The computing device includes a graphical user interface that displays the image segments with an overlay of information relating to at least one of the type, size, and location of the welding anomaly to the user.
G06F 19/00 - Digital computing or data processing equipment or methods, specially adapted for specific applications (specially adapted for specific functions G06F 17/00;data processing systems or methods specially adapted for administrative, commercial, financial, managerial, supervisory or forecasting purposes G06Q;healthcare informatics G16H)
Provided is an apparatus for coating a girth weld and a cutback region surrounding said girth weld, said apparatus having lateral travel at least equal to the length of the cutback region and circumferential rotational travel around the pipe. The apparatus can provide a multiple component coating accurately and safely, without the need for solvent flushing of the apparatus.
B05B 13/04 - Means for supporting workArrangement or mounting of spray headsAdaptation or arrangement of means for feeding work the spray heads being moved during operation
B05B 12/08 - Arrangements for controlling deliveryArrangements for controlling the spray area responsive to condition of liquid or other fluent material discharged, of ambient medium or of target
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05B 7/26 - Apparatus in which liquids or other fluent materials from different sources are brought together before entering the discharge device
ABSTRACTA sprayer apparatus for coating a girth weld and a cutback region surrounding the girth weld on a steel pipe, the steel pipe having a longitudinal axis, comprises a frame, an arm, and a controller. The frame includes a roller carriage configured for rollably mounting theframe to a track mounted substantially circumferentially around the pipe, the frame alsoincluding a powered propulsion assembly for propelling the roller carriage along the track substantially circumferentially around the pipe. The arm extends or is extendable from the frame, the arm supporting a spray head. The frame also includes: a powered indexing assembly for moving the arm and the spray head longitudinally relative to the frame; acartridge for storing a liquid to be sprayed onto the pipe via the spray head; a poweredcartridge gun for forcing the liquid out of the cartridge to the spray head; and a pressurized air supply for delivering pressurized air to the spray head to control the liquid spray from the spray head. The controller is configured for controlling: the powered propulsion assembly and the powered indexing assembly; and the powered cartridge gun and/or a pressure level of the pressurized air supply to the spray head.Date Recue/Date Received 2020-12-16
The present application relates to a field system and methods that can be deployed in the application of pipe welding. The field system provides many embodiments relating to pipe welding systems and methods, that can be used in combination with one another, or individually. Such welding systems and methods, include, for example, internal welding systems and methods, tie-in welding system and methods, pipe inspection systems and methods, pipe handling systems and methods, internal pipe cooling systems and methods, non-destructive testing systems and methods, as well as remote interface and database systems and methods (uLog), to name a few. The application further relates to welded pipes that result from some or all of such processes.
B23K 31/00 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups
F28D 7/00 - Heat-exchange apparatus having stationary tubular conduit assemblies for both heat-exchange media, the media being in contact with different sides of a conduit wall
B23K 37/00 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass
F28F 3/02 - Elements or assemblies thereof with means for increasing heat-transfer area, e.g. with fins, with recesses, with corrugations
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
Disclosed herein is a rotational roller apparatus for use with a pipeline unit. The pipeline unit is received in a pipeline for welding and/or inspection. The rotational roller is attached to and is able to support at least a portion of the weight of the pipeline unit. The rotational roller unit also includes an extension member and a reduced friction base. The reduced friction base is attached to an end of the extension member so that the rotational roller has a retracted and an extended configuration. In the extended configuration, the reduced friction base contacts an interior of the pipeline and supports at least a portion of the weight of the pipeline unit and thereby allows the unit to be rotated about a longitudinal axis within the pipeline.
A system for welding two pipes includes a first pipe clamp, a second pipe clamp, a weld torch, an inspection detector, a motor, one or more processors, and a grinder. The weld torch is configured to create a weld joint between the pipes at an interface region between the pipes. The inspection detector is configured to emit an inspection beam of radiation. The motor is operatively associated with the inspection detector to direct the inspection beam of radiation along the weld joint between the pipes. The one or more processors are operatively associated with the inspection detector to determine a profile of the weld joint between the pipes. The grinder is configured to grind at least a portion of the weld joint between the pipes based on the profile of the weld joint between the pipes.
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
A field system for welding two pipes includes a first pipe engagement structure, a second pipe engagement structure, one or more weld torches, a motor and one or more processors. The one or more weld torches are configured to be positioned within the pipes to create an internal weld at an interface region between the pipes. The motor is operatively associated with the one or more weld torches to rotate the one or more weld torch along the interface region between the pipes. The one or more processors control the motor and the one or more weld torches. The one or more processors operate the motor and the one or more weld torches to generate a complete circumferential weld along the interface region by rotating the one or more weld torches along the interface region in a single rotational direction until the complete circumferential weld is completed.
B23K 37/00 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 9/095 - Monitoring or automatic control of welding parameters
B23K 31/12 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to investigating the properties, e.g. the weldability, of materials
B23K 37/02 - Carriages for supporting the welding or cutting element
B23K 9/127 - Means for tracking lines during arc welding or cutting
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
A welded pipe assembly includes a first and a second metal pipes, and a welded joint or welded material connecting the first pipe with the second pipe. The first and second metal pipes each have a length of at least 30′ and an exterior diameter of less than 24″. The weld material includes a plurality of weld pass layers including a first internal pass layer and a second internal pass layer disposed on top of the first internal pass layer. The second internal pass layer is positioned closer to an interior longitudinal axis of the welded first and second pipes than the first internal pass layer. The welded joint includes a first internal bevel formed in the first metal pipe and a second internal bevel formed in the second metal pipe. The first internal pass layer is disposed in a region defined by the first and the second internal bevels.
B23K 31/12 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to investigating the properties, e.g. the weldability, of materials
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 37/00 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
Apparatus, systems, processes, control systems, means and methods for near-weld gas purging and welding. A focused circumferential near-weld purge gas delivery system for pipeline welding. A near-weld purge rig which has a near-weld purge gas channel and which achieves a low oxygen concentration proximate to a pipe gap for welding. The gas used for purging is also directed against an interior surface of the pipe to be welded. The directed gas cools the pipe to a desired temperature.
B23K 37/00 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass
B23K 31/02 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to soldering or welding
B23K 9/29 - Supporting devices adapted for making use of shielding means
A system for welding two pipes includes a first pipe clamp, a second pipe clamp, a weld torch, an inspection detector, a motor, one or more processors, and a grinder. The weld torch is configured to create a weld joint between the pipes at an interface region between the pipes. The inspection detector is configured to emit an inspection beam of radiation. The motor is operatively associated with the inspection detector to direct the inspection beam of radiation along the weld joint between the pipes. The one or more processors are operatively associated with the inspection detector to determine a profile of the weld joint between the pipes. The grinder is configured to grind at least a portion of the weld joint between the pipes based on the profile of the weld joint between the pipes.
B23K 9/095 - Monitoring or automatic control of welding parameters
B23K 9/127 - Means for tracking lines during arc welding or cutting
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
A system for welding two pipes includes a first pipe clamp, a second pipe clamp, a weld torch, an inspection detector, a motor, one or more processors, and a grinder. The weld torch is configured to create a weld joint between the pipes at an interface region between the pipes. The inspection detector is configured to emit an inspection beam of radiation. The motor is operatively associated with the inspection detector to direct the inspection beam of radiation along the weld joint between the pipes. The one or more processors are operatively associated with the inspection detector to determine a profile of the weld joint between the pipes. The grinder is configured to grind at least a portion of the weld joint between the pipes based on the profile of the weld joint between the pipes.
B23K 9/095 - Monitoring or automatic control of welding parameters
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
A welding system includes a welding station having a weld station computer and a weld system in communication with the weld station computer. The weld system includes a supply of weld material, a welding device, and a weld supply motor assembly that moves the weld material to the welder device. The system further includes a weighting device operatively connected with the weld station computer to measure a weight of the supply of weld material and to communicate the weight of the supply of weld material to the weld station computer; and a sensor operatively connected with the weld supply motor assembly and the weld station computer so as to communicate the speed of the weld supply motor assembly to the weld station computer. The weld station computer is operatively connected to the weld supply motor assembly to control the speed of the motor assembly based on the weight data.
The present application relates to a field system and methods that can be deployed in the application of pipe welding. The field system provides many embodiments relating to pipe welding systems and methods, that can be used in combination with one another, or individually. Such welding systems and methods, include, for example, internal welding systems and methods, tie-in welding system and methods, pipe inspection systems and methods, pipe handling systems and methods, internal pipe cooling systems and methods, non-destructive testing systems and methods, as well as remote interface and database systems and methods (uLog), to name a few. The application further relates to welded pipes that result from some or all of such processes.
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
Apparatus, systems, processes, control systems, means and methods for near-weld gas purging and welding. A focused circumferential near-weld purge gas delivery system for pipeline welding. A near-weld purge rig which has a near-weld purge gas channel and which achieves a low oxygen concentration proximate to a pipe gap for welding. The gas used for purging is also directed against an interior surface of the pipe to be welded. The directed gas cools the pipe to a desired temperature.
A welding system includes a welding station having a weld station computer and a weld system in communication with the weld station computer. The weld system includes a supply of weld material, a welding device, and a weld supply motor assembly that moves the weld material to the welder device. The system further includes a weighting device operatively connected with the weld station computer to measure a weight of the supply of weld material and to communicate the weight of the supply of weld material to the weld station computer; and a sensor operatively connected with the weld supply motor assembly and the weld station computer so as to communicate the speed of the weld supply motor assembly to the weld station computer. The weld station computer is operatively connected to the weld supply motor assembly to control the speed of the motor assembly based on the weight data.
A welding system includes a welding station having a weld station computer and a weld system in communication with the weld station computer. The weld system includes a supply of weld material, a welding device, and a weld supply motor assembly that moves the weld material to the welder device. The system further includes a weighting device operatively connected with the weld station computer to measure a weight of the supply of weld material and to communicate the weight of the supply of weld material to the weld station computer; and a sensor operatively connected with the weld supply motor assembly and the weld station computer so as to communicate the speed of the weld supply motor assembly to the weld station computer. The weld station computer is operatively connected to the weld supply motor assembly to control the speed of the motor assembly based on the weight data.
An internal heat exchanger (IHEX) for pipeline welding includes a drive system configured to move the IHEX into a position within at least one pipe section near a weld joint location with another pipe section. The IHEX further includes a cooling section including cooling structure configured to selectively cool one or more interior surface portions of the at least one pipe section, and a controller in communication with the cooling structure and configured to activate the cooling section when the IHEX is at the position within the at least one pipe section.
An internal heat exchanger (IHEX) for pipeline welding includes a drive system configured to move the IHEX into a position within at least one pipe section near a weld joint location with another pipe section. The IHEX further includes a cooling section including cooling structure configured to selectively cool one or more interior surface portions of the at least one pipe section, and a controller in communication with the cooling structure and configured to activate the cooling section when the IHEX is at the position within the at least one pipe section.
The present invention is directed to a system for welding together segments of a pipeline. The system includes an external alignment mechanism for externally supporting and manipulating the orientation of pipe segments in order to align relative segments. The system also includes an internal welding mechanism for applying a weld to an interior face joint of the two abutted pipe segments. The internal welding mechanism including a torch for applying a weld, a laser for tracking the weld profile and guiding an articulating head of the torch, and a camera for visually inspecting the weld after the weld is applied.
B23K 9/028 - Seam weldingBacking meansInserts for curved planar seams
B23K 31/02 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to soldering or welding
B23K 37/02 - Carriages for supporting the welding or cutting element
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
B23K 9/095 - Monitoring or automatic control of welding parameters
B23K 9/127 - Means for tracking lines during arc welding or cutting
The present invention is directed to a system for welding together segments of a pipeline. The system includes an external alignment mechanism for externally supporting and manipulating the orientation of pipe segments in order to align relative segments. The system also includes an internal welding mechanism for applying a weld to an interior face joint of the two abutted pipe segments. The internal welding mechanism including a torch for applying a weld, a laser for tracking the weld profile and guiding an articulating head of the torch, and a camera for visually inspecting the weld after the weld is applied.
B23K 37/053 - Auxiliary devices or processes, not specially adapted for a procedure covered by only one of the other main groups of this subclass for holding or positioning work aligning cylindrical workClamping devices therefor
A pipe bending machine has a stiff-back which is driven by a pivioting wedge. A linkage applies force from the actuator to the wedge in a direction parallel to a longitudinal axis of the stiff-back. The stiff-back pivots on a first fulcrum and the wedge slides on a bed which pivots on a second fulcrum. The actuator drives the wedge between the stiff-back and the bed to rotate the stiff-back at the first fulcrum and bend the pipe seated in the stiff-back against the pipe bending face of a die. The conversion of the longitudinalforce applied to the wedge into a transverse force applied to the stiff-back provides a significant mechanical advantage which varies directionally as the stiff-back rotates about its fulcrum to maintain a constant force on the stiff-back.
B21D 7/022 - Bending rods, profiles, or tubes over a stationary forming memberBending rods, profiles, or tubes by use of a swinging forming member or abutment over a stationary forming member only
A pipe bending machine has a beam mounted in see-saw pivotal relation on a fulcrum and spaced apart cradles support the pipe. An actuator initially drives the second cradle and the beam apart to pivot the pipe about the first cradle until the pipe is in contact with the die and thereafter drives the beam away from the second cradle to bend the pipe against the die. The mechanical advantage of the levered operation requires only a single actuator motion to bend the pipe. An external mandrel allows the pipe to be incrementally fed through the bending machine and secures the pipe against cross-sectional distortion during the bending process.
Metallic objects such as steel pipes and shipbuilding plates are welded using complemental bevels in the faces to be welded which, when abutted, define a channel of cruet shaped cross-section. The cruet shaped channel allows the filling weld passes to be performed using a welding instrument oscillated only at tolerance amplitudes in a range of 1.5 mm +/- 0.5 mm rather than bevel width amplitudes. The process can be used in single or double side welding applications.
A method and system for storing, delivering and spooling pipelines, such as underwater pipelines used in off-shore well production systems, enables continuous pipeline reeling operations for multi-mile pipelines without the need for welding stops, a spool base of corresponding multi-mile length, a straight line path from storage to ship and/or stern mooring of the reel carrying vessel. Bending radii for the pipeline from welding to reeling are held to a determined minimum within the range of plastic deformation radii of the pipeline and preferably within the range of elastic bending radii of the pipeline.
A method for girth welding of metallic pipes consists in beveling one pipe end in order that, when it is aligned with an identically beveled pipe end on another pipe, results in a bevel of a 'cruet' design with a rounded bottom part larger than an upper part with parallel walls. The diameter of the welding wire used for the welding method is within 1.2 and 1.4 mm and the wire contains low levels of impurity including sulfur and phosphorus. The welding technique used is a 'strip' technique which does not provide employ weaving or oscillation of the welding torch.
