In one aspect, a method for manufacturing a pre-molding and/or a radome for radar devices for vehicles includes forming a pre-molding having at least one contact element for electrically contacting a heating unit for heating the radome. When forming the pre-molding, the at least one contact element is at least partially overmolded with plastic.
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
B29L 31/34 - Electrical apparatus, e.g. sparking plugs or parts thereof
H01Q 1/42 - Housings not intimately mechanically associated with radiating elements, e.g. radome
In one aspect, an actuating drive for an electrical assembly of a motor vehicle includes a drive train which includes a drive transmission, with the drive transmission having at least one rotatably mounted, first transmission element. The actuating drive also includes a locking unit for locking the drive train, which includes a self-locking locking transmission that has at least one rotatably mounted, second transmission element that is mechanically operatively connected to the first transmission element of the drive transmission. The first transmission element of the drive transmission and the second transmission element of the locking transmission (are mounted rotatably about a common axis of rotation. Furthermore, the first transmission element has a first toothing and the second transmission element has a second toothing which differs from the first toothing.
In one aspect, an actuating drive for an electrical assembly of a motor vehicle includes a drive train, which includes a drive transmission and a drive motor for driving the drive transmission. The actuating drive also includes having a locking unit for locking the drive train, which includes a self-locking locking transmission that is operatively connected to the drive transmission, and a locking motor for driving the locking transmission. The actuating drive further includes a control unit for controlling the drive motor and the locking motor. The control unit is designed such that the drive motor and the locking motor can be operated, in particular in a starting operation, asynchronously and/or with a time delay relative to one another.
In one aspect, a bearing unit for a motor and at least one gear element of an actuating drive includes at least one fixing element with which the motor is fixable and/or mountable in a housing of the actuating drive. The bearing unit also includes at least one ring gear having at least one securing section, the at least one ring gear being fixable and/or non-rotatably mountable in the housing via the at least one securing section. Additionally, the bearing unit includes at least one bearing axle that connects the at least one ring gear and the at least one fixing element.
In one aspect, a gear train component for a planetary gear train and/or for a transmission gearing of an actuating drive has at least one gear train element. The at least one gear train element is in the form of a stamped part, such as a fine stamped part, a fine blanked part and/or a precision stamped part.
A tow hitch assembly (1) for attachment to a vehicle, said tow hitch assembly (1) comprising a hitch arm (2), a housing (3) attachable to the vehicle, and an actuator assembly (4) attached to the housing (3). The hitch arm (2) is attached to a first shaft (5) rotatably supported by the housing (2). The tow hitch assembly (1) further comprises a one-way wrap spring clutch (9) operatively connecting the first shaft (5) and the actuator assembly (4). The wrap spring clutch (9) is connected to the first shaft (5) without gears.
B60D 1/24 - Traction couplingsHitchesDraw-gearTowing devices characterised by arrangements for particular functions
B60D 1/54 - Traction couplingsHitchesDraw-gearTowing devices characterised by the mounting collapsible or retractable when not in use, e.g. hide-away hitches
A method for manufacturing a coated object, in which a partially cured intermediate object formed from a dual-curable material is formed by an additive manufacturing method, in which at least some regions of the partially cured intermediate object are coated with a coating material and in which the partially cured intermediate object is completely cured in a curing step to form the object. In one aspect, a polyurethane resin is used as the dual-curable material.
A contact device includes a first plug connector, which for forming a plug contact is pluggable onto a corresponding second plug connector of a first component, and comprising at least one first abutment section, which for forming a pressure contact is pressable against a second abutment section of a second component and/or of an additional element that is connectable to the second component. At least one spring section is provided between the first plug connector and the first abutment section and/or between a fastening section of the additional element and the second abutment section. The spring section presses the two abutment sections against one another with an elastic force when the two components are electrically connected to one another. The first plug connector is designed as a push-on sleeve, so that it is pluggable onto a second plug connector, designed as a plug, of the first component.
H01R 13/24 - Contacts for co-operating by abutting resilientContacts for co-operating by abutting resiliently mounted
H01R 43/26 - Apparatus or processes specially adapted for manufacturing, assembling, maintaining, or repairing of line connectors or current collectors or for joining electric conductors for engaging or disengaging the two parts of a coupling device
A computer-implemented method for dividing a virtual three-dimensional overall model of a body into at least two virtual partial models, includes:
Creating a virtual separating surface for the overall model of the body, which has a three-dimensional cell-conforming shape;
Creating the overall model of the body with a lattice structure formed from a plurality of cells; and
Dividing the overall model along the cell-conforming separating surface into two partial models,
so that when the overall model is divided, common struts of the lattice structure, which are each part of at least one cell of one partial model and part of at least one adjacent cell of the other partial model are divided by means of the cell-conforming separating surface in such a way that the corresponding cells remain closed.
G06F 30/27 - Design optimisation, verification or simulation using machine learning, e.g. artificial intelligence, neural networks, support vector machines [SVM] or training a model
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
B29C 64/307 - Handling of material to be used in additive manufacturing
11.
METHOD FOR PRODUCING A COMPOSITE BODY AND COMPOSITE BODY
A method for producing a composite body from at least two partial bodies, at least one of the partial bodies being produced in an additive manufacturing process, includes exposing the at least two partial bodies to a solvent atmosphere, so that one surface of the partial body is smoothed. The at least two partial bodies are placed in the chamber in such a way that they touch at least one joining surface and that the solvent atmosphere creates a material connection between the at least two partial bodies on the at least one joining surface.
B29C 64/188 - Processes of additive manufacturing involving additional operations performed on the added layers, e.g. smoothing, grinding or thickness control
B29C 64/153 - Processes of additive manufacturing using only solid materials using layers of powder being selectively joined, e.g. by selective laser sintering or melting
09 - Scientific and electric apparatus and instruments
10 - Medical apparatus and instruments
11 - Environmental control apparatus
12 - Land, air and water vehicles; parts of land vehicles
17 - Rubber and plastic; packing and insulating materials
25 - Clothing; footwear; headgear
39 - Transport, packaging, storage and travel services
40 - Treatment of materials; recycling, air and water treatment,
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for processing plastics; machine tools; injection
moulding machines and their inserts (tools) for moulding
plastic parts; manufacturing machines for manufacturing
three-dimensional objects, namely machines for generative
manufacturing processes (additive manufacturing) and
manufacturing plants with such manufacturing machines; 3D
printers; packaging machines; printing machines for printing
on packaging, particularly for footwear; plastic housings
for machines; vehicles parts, namely, engine cases; parts of
engines and motors (except for land vehicles); braking
devices, gear wheels and toothed belts as machine parts;
drive units, other than for land vehicles; control
mechanisms for machines, engines or motors; motor drive
mechanisms [other than for land vehicles]; rotary to linear
actuators; electric motor drives for machines; toothed belts
for engines; gear boxes and couplings other than for land
vehicles; power and motion (torque) converters, other than
for land vehicles; electromechanical machines parts, namely
linear and rotary actuators; motors, other than for land
vehicles; driving motors, other than for land vehicles;
driving motors, electric, other than for land vehicles;
regulators [parts of machines]; vacuum pumps [machines];
check valves (machine parts); gear box casings, other than
for land vehicles; housings for machines, motors and
engines. Electrical and electronic components; electrical and
electronic assemblies; electric plugs, contacts and circuit
carriers; electrical circuit carriers; rigid and flexible
circuit boards; sensors; switches, electric;
electromechanical tactile switches; controllers
(regulators); electric position and motion sensor; electric
and electronic actuators; electric setting devices
(actuators); actuators and sensors for control devices for
machines and motors; electric control devices for the valve,
motor and actuator technology; electronic display devices;
electric control panels; touch pads [electric]; interactive
touch screen terminals; portable computer systems; cases
adapted for mobile phones; touch pads [electronic]; housings
for electrical apparatus, switches (electric) and measuring
apparatus; computer housings; sensors and displays for use
in medical apparatus and instruments; injection-moulded
plastic components as well as additively manufactured
plastic components as circuit carriers for electronic or
mechatronic assemblies. Medical apparatus and instruments; inhalers for medical use,
glucometers. Parts for illumination devices, heating, ventilation and air
conditioning apparatus; heating apparatus for sensors;
electrical heating elements; electric surface heating tapes;
electrical heating elements in the form of foils, cables or
filaments; cooling elements; ventilating louvers as parts of
ventilating installations [air conditioning] for vehicles. Parts and fittings for land vehicles; plastic housings for
parts of land vehicles (other than engines); housing covers
for land vehicle engines; interior panels for vehicles;
components of ceramic for vehicles; couplings for land
vehicles; toothed wheels for land vehicles; gear boxes for
land vehicles; power and motion (torque) converters for land
vehicles; braking systems for vehicles and parts thereof;
brake stops; electronic brakes for vehicles; mirror supports
as accessories for automobiles and electric motor drives
thereof; powertrains, including engines and motors, for land
vehicles; structural parts of bicycles; engines for
bicycles; gearboxes for bicycles. Semi-manufactured plastic; plastics materials in the form of
sections [semi-finished products]; electrical insulating
materials and objects of plastic (insulating material body). Footwear; shoe soles; 3D-printed shoe soles. Storage and delivery of goods. Treatment of materials, in particular surface treatment and
finishing, namely millworking, drilling, grinding,
polishing, printing and laser marking; injection moulding
treatment of plastics and metals into assemblies and
finished products as well as their assembly (processing);
powder injection moulding; injection moulding contract
manufacture; material processing and surface design of
plastic products; customer-specific contract manufacture of
plastics products and plastic profiles as well as assemblies
consisting essentially of plastic products with and without
electrotechnical components; clean-room contract assembly of
apparatus, instruments and components for health care;
printing services; (3D) printing services; custom 3D
printing for others; custom manufacture and assembly
services of products from materials, that can be processed
by additive manufacturing processes, especially polymers,
metals and ceramics; ceramic processing; rental of 3D
printers. Scientific and technological services; technical
consultation services regarding the manufacture and the use
of plastic parts and plastic profiles as well as assemblies
consisting essentially of plastics products with and without
electrotechnical components; development services for new
products in terms of construction or design using plastic
parts, including the construction of experimental tools;
development, rapid prototyping as well as performance,
evaluation, analysis and optimization of trials within the
framework of the development of new products; technical
consultation services and planning of manufacturing
installations and manufacturing machines, especially for the
additive manufacturing; industrial design services; design
services for surfaces.
09 - Scientific and electric apparatus and instruments
10 - Medical apparatus and instruments
11 - Environmental control apparatus
12 - Land, air and water vehicles; parts of land vehicles
17 - Rubber and plastic; packing and insulating materials
25 - Clothing; footwear; headgear
39 - Transport, packaging, storage and travel services
40 - Treatment of materials; recycling, air and water treatment,
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for processing plastics; machine tools; injection
moulding machines and their inserts (tools) for moulding
plastic parts; manufacturing machines for manufacturing
three-dimensional objects, namely machines for generative
manufacturing processes (additive manufacturing) and
manufacturing plants with such manufacturing machines; 3D
printers; packaging machines; printing machines for printing
on packaging, particularly for footwear; plastic housings
for machines; vehicles parts, namely, engine cases; parts of
engines and motors (except for land vehicles); braking
devices, gear wheels and toothed belts as machine parts;
drive units, other than for land vehicles; control
mechanisms for machines, engines or motors; motor drive
mechanisms [other than for land vehicles]; rotary to linear
actuators; electric motor drives for machines; toothed belts
for engines; gear boxes and couplings other than for land
vehicles; power and motion (torque) converters, other than
for land vehicles; electromechanical machines parts, namely
linear and rotary actuators; motors, other than for land
vehicles; driving motors, other than for land vehicles;
driving motors, electric, other than for land vehicles;
regulators [parts of machines]; vacuum pumps [machines];
check valves (machine parts); gear box casings, other than
for land vehicles; housings for machines, motors and
engines. Electrical and electronic components; electrical and
electronic assemblies; electric plugs, contacts and circuit
carriers; electrical circuit carriers; rigid and flexible
circuit boards; sensors; switches, electric;
electromechanical tactile switches; controllers
(regulators); electric position and motion sensor; electric
and electronic actuators; electric setting devices
(actuators); actuators and sensors for control devices for
machines and motors; electric control devices for the valve,
motor and actuator technology; electronic display devices;
electric control panels; touch pads [electric]; interactive
touch screen terminals; portable computer systems; cases
adapted for mobile phones; touch pads [electronic]; housings
for electrical apparatus, switches (electric) and measuring
apparatus; computer housings; sensors and displays for use
in medical apparatus and instruments; injection-moulded
plastic components as well as plastic components
manufactured with additives as circuit carriers for
electronic or mechatronic assemblies. Medical apparatus and instruments; inhalers for medical use,
glucometers. Parts for illumination devices, heating, ventilation and air
conditioning apparatus; heating apparatus for sensors;
electrical heating elements; electric surface heating tapes;
electrical heating elements in the form of foils, cables or
filaments; cooling elements; ventilating louvers as parts of
ventilating installations [air conditioning] for vehicles. Parts and fittings for land vehicles; plastic housings for
parts of land vehicles (other than engines); housing covers
for land vehicle engines; interior panels for vehicles;
components of ceramic for vehicles; couplings for land
vehicles; toothed wheels for land vehicles; gear boxes for
land vehicles; power and motion (torque) converters for land
vehicles; braking systems for vehicles and parts thereof;
brake stops; electronic brakes for vehicles; mirror supports
as accessories for automobiles and electric motor drives
thereof; powertrains, including engines and motors, for land
vehicles; structural parts of bicycles; engines for
bicycles; gearboxes for bicycles. Semi-manufactured plastic; plastics materials in the form of
sections [semi-finished products]; electrical insulating
materials and objects of plastic (insulating material body). Footwear; shoe soles; 3D-printed shoe soles. Storage and delivery of goods. Treatment of materials, in particular surface treatment and
finishing, namely millworking, drilling, grinding,
polishing, printing and laser marking; injection moulding
treatment of plastics and metals into assemblies and
finished products as well as their assembly (processing);
powder injection moulding; injection moulding contract
manufacture; material processing and surface design of
plastic products; customer-specific contract manufacture of
plastics products and plastic profiles as well as assemblies
consisting essentially of plastic products with and without
electrotechnical components; clean-room contract assembly of
apparatus, instruments and components for health care;
printing services; (3D) printing services; custom 3D
printing for others; custom manufacture and assembly
services of products from materials, that can be processed
by additive manufacturing processes, especially polymers,
metals and ceramics; ceramic processing; rental of 3D
printers. Scientific and technological services; technical
consultation services regarding the manufacture and the use
of plastic parts and plastic profiles as well as assemblies
consisting essentially of plastics products with and without
electrotechnical components; development services for new
products in terms of construction or design using plastic
parts, including the construction of experimental tools;
development, rapid prototyping as well as performance,
evaluation, analysis and optimization of trials within the
framework of the development of new products; technical
consultation services and planning of manufacturing
installations and manufacturing machines, especially for the
additive manufacturing; industrial design services; design
services for surfaces.
40 - Treatment of materials; recycling, air and water treatment,
Goods & Services
Footwear; shoe soles; 3D-printed shoe soles Printing services; 3D printing for others; Custom 3D printing for others; Custom manufacture and assembly of products from materials, that can be processed by additive manufacturing processes, especially polymers, metals and ceramics, namely, custom additive manufacturing and assembly of products for others
09 - Scientific and electric apparatus and instruments
10 - Medical apparatus and instruments
11 - Environmental control apparatus
12 - Land, air and water vehicles; parts of land vehicles
17 - Rubber and plastic; packing and insulating materials
25 - Clothing; footwear; headgear
39 - Transport, packaging, storage and travel services
40 - Treatment of materials; recycling, air and water treatment,
42 - Scientific, technological and industrial services, research and design
Goods & Services
Machines for processing plastics; Machine tools for the cutting and forming of materials; Injection moulding machines and their inserts tools for moulding plastic parts sold as a unit; Manufacturing machines for manufacturing three-dimensional objects, namely, additive manufacturing machines for generative manufacturing processes and machines for additive manufacturing plants being 3D printers; 3D printers; Packaging machines; industrial printing machines for printing on packaging, particularly for footwear; vehicles parts, namely, engine cases; Braking devices in the nature of brakes, gear wheels and toothed drive belts, all being machine parts; Drive units, other than for land vehicles, namely, drives for motors; control mechanisms for machines, engines or motors, namely, hydraulic controls and pneumatic controls; Motor drive mechanisms other than for land vehicles, namely, drives for motors; Linear actuators; hydraulic and pneumatic linear actuators; Electric motor drives for machines; toothed drive belts for engines; Gear boxes and shaft couplings other than for land vehicles; Power and motion torque converters, other than for land vehicles; electromechanical machine parts, namely linear and rotary actuators; Motors, other than for land vehicles; Driving motors, other than for land vehicles; Driving motors, electric, other than for land vehicles; Regulators being parts of machines; Vacuum pumps; Check valves being parts of machines; Gear box casings, other than for land vehicles; bearing housings for machines, motors and engines Electrical and electronic components, namely, electric contractors, protection relays, piezoelectric switches; Electric plugs, contacts and circuit carriers in the nature of electric circuit boards; Electrical circuit carriers in the nature of electrical circuit boards; Rigid and flexible circuit boards; Sensors for measuring distance, not for medical use; Sensors for determining position, distances, velocity, acceleration and temperature; Infrared sensors; LED position sensors; Motion recognizing sensors; Motion sensors; Electric sensors; Ultrasonic sensors; Optical position sensors; Optical sensors; Temperature Sensors; Touchscreen sensors; Photoelectric sensors; Pollutant sensors; Proximity sensors; Sensors and detector units for use in controlling the actuation and operation of automotive safety apparatus and equipment; switches, electric; Electromechanical tactile switches; Electrical controllers; Electric position and motion sensor; Electric and electronic actuators; Electric Setting devices being electrical actuators; Electric actuators and sensors for control devices for machines and motors; Electric control devices for the valves, motors and actuators; electronic display devices, namely, electronic display interfaces; Flat panel display screens; Light emitting diode (LED) displays; Liquid crystal displays; OLED (Organic light emitting diode) display panels; Electric control panels; Electric touch pads; Interactive touch screen terminals; Portable computers; Cases adapted for mobile phones; Electronic touch pads; Housings for electric switches; housings for electrical apparatus and measuring apparatus, namely, electrical transformers, clamp meters for measuring electricity; Computer housings; Sensors and displays for use in medical apparatus and instruments, namely, temperature sensors used in the medical field to measure temperature of medical solutions, electronic stand alone displays for medical images; injection-moulded plastic components as well as additively manufactured plastic components as circuit carriers for electronic or mechatronic assemblies, namely, circuit boards, Cards with integrated circuits, Electronic circuits, Integrated circuit cards and components, Integrated circuit modules Medical apparatus and instruments, namely, implantable ports, lung ventilators with monitoring capability, scalpels, Medical apparatus for facilitating the inhalation of pharmaceutical preparations, Injection device for pharmaceuticals; Inhalers for medical use, glucometers Parts for illumination devices, heating, ventilation and air conditioning apparatus, namely, light bulbs, thermostatic valve, fabric air dispersion ducts for distributing and dispensing air, Heating apparatus for vehicles; Heating apparatus for sensors, namely, Heating elements, Heating cushions, electric, not for medical purposes, Electrical heating elements; Electric surface heating tapes, namely, electrical heating tapes; Electrical heating elements in the form of foils, cables or filaments; Cooling elements, namely, Air cooling apparatus, Cooling units for industrial purposes; Ventilating louvers as parts of ventilating air conditioning installations for vehicles Parts and fittings for land vehicles, namely, axels, transmission, windshields; Plastic housings for parts of land vehicles other than engines, namely, axels, differentials, drive gears; Housing covers for land vehicle engines; Interior door and roof panels for vehicles; Components of ceramic for vehicles, namely, brake pads, brake disks, Automotive dashboards, Automotive gear sticks, Automotive interior paneling, Automotive interior trim; Couplings for land vehicles; Toothed wheels for land vehicles; Gear boxes for land vehicles; Power and motion torque converters for land vehicles; Braking systems for vehicles and parts thereof; Brake stops, namely, brake pads, brake disks; Electronic brakes for vehicles; Mirror supports, namely, side view mirrors as accessories for automobiles and specially adapted electric motor drives thereof; Powertrains, namely, engines and motors for land vehicles; Structural parts of bicycles; Engines for bicycles; Gearboxes for bicycles Semi-manufactured plastic, namely, semi-processed plastics; Plastics materials in the form of sections, namely, semi-worked synthetic plastic and synthetic resins as semi-finished products in form of pellets, rods, foils, foams, fibers, films and sheets; Electrical insulating materials and objects of plastic, namely, plastic films for electrical insulation Footwear; shoe soles; 3D-printed shoe soles Storage and delivery of goods Treatment of materials, in particular surface treatment and finishing, namely, millworking, drilling, grinding, polishing, printing, 3D printing for others and laser marking; Injection moulding treatment of plastics and metals into assemblies and finished products as well as their assembly; Powder injection moulding of plastic for others; contract manufacture of injection moulding for others; Material processing, namely, processing of plastics, Ceramic processing, Metal processing, Processing of epoxy resin and surface design of plastic products, namely, engraving, 3D printing for others; Customer-specific contract manufacture of plastics products and plastic profiles as well as assemblies consisting essentially of plastic products with and without electrotechnical components, namely, contract manufacturing and assembly of products in the nature of automobiles, medical instruments, shoe soles, sporting goods, cushions; Clean-room contract assembly of products for others in the nature of apparatus, instruments and components for health care; Printing services; 3D printing for others; Custom 3D printing for others; Three dimensional printing (3DP) services for others; Custom manufacture and assembly of products from materials, that can be processed by additive manufacturing processes, especially polymers, metals and ceramics, namely, custom manufacture and assembly of products in the nature of automobiles, medical instruments, shoe soles; Ceramic processing; Rental of 3D printers Scientific and technological services, namely, scientific research, analysis, testing in the field of plastics processing, additive manufacturing, 3D printing; Technical consultation services in the field of design and development of engineering processes regarding the manufacture and the use of plastic parts and plastic profiles as well as assemblies consisting essentially of plastics products with and without electrotechnical components; Development services for new products in terms of construction or design using plastic parts, including the construction of experimental tools, namely, development of new products for others in the field of plastic materials; Development, rapid prototyping as well as performance, evaluation, analysis and optimization of trials within the framework of the development of new products, namely, design, development, and testing of new products for others in the field of plastic materials; Technical consultation services in the field of planning the design of manufacturing installations and manufacturing machines, especially for the additive manufacturing; Industrial design services; Design services for surfaces, namely, graphic design on surfaces
In an actuator, which can be used, for example, for an electromotive parking brake, and the housing of which is equipped with a gear mechanism, axial and radial bracings of a worm member take place using a bearing bracket, the limbs of which, on both sides, engage the worm member from behind and reach radially beyond its shaft. As seizing protection against a wedging between the worm member and the worm wheel, the bearing bracket can be slightly displaced in the housing. For this purpose, by virtue of the restoring forces exerted by the spring elements, which are then tensioned, the bearing bracket together with the worm member is pushed axially and the worm wheel 20 is turned.
F16H 55/24 - Special devices for taking up backlash
F16H 57/039 - Gearboxes for accommodating worm gears
F16H 1/16 - Toothed gearings for conveying rotary motion without gears having orbital motion involving only two intermeshing members with non-parallel axes comprising worm and worm-wheel
F16H 57/022 - Adjustment of gear shafts or bearings
F16H 57/12 - Arrangements for adjusting or for taking-up backlash not provided for elsewhere
The invention relates to an electric motor-driven locking device (1) of a plug connector half (2) for producing an electric connection with another plug connector half for charging an electric vehicle by plugging the other plug connector half into the plug connector half (2), having a movable locking pin (4) for locking the other plug connector half plugged into the plug connector half (2) and having a position sensor arranged orthogonally to the plug-in direction (3), in particular a Hall effect sensor (7), wherein a magnet (8) which can be moved towards or away from the position sensor by the movement of the locking pin (4) is provided on the locking pin (4) in a manner corresponding to the position sensor.
In an actuator having a reversible motor before a step-down gear, this can be optimized kinetically, geometrically and in terms of material engineering when different step-down ratios become active according to the different torque requirement for application and for release, in a manner dependent on direction of rotation, for example of a parking brake operated by an electric motor. For this purpose, two differently dimensioned idler wheels of the step-down gears that mesh, for example, with a stepped motor pinion, act via freewheels acting in opposite directions on a common gear shaft. Depending on direction of rotation of the motor, the gear shaft thereby rotates at different rpms, delivering correspondingly different torques.
F16H 37/04 - Combinations of toothed gearings only
F16H 3/00 - Toothed gearings for conveying rotary motion with variable gear ratio or for reversing rotary motion
H02K 7/10 - Structural association with clutches, brakes, gears, pulleys or mechanical starters
F16D 41/063 - Freewheels or freewheel clutches with intermediate wedging coupling members between an inner and an outer surface the intermediate members wedging by moving along the inner and the outer surface without pivoting or rolling, e.g. sliding wedges
F16D 41/066 - Freewheels or freewheel clutches with intermediate wedging coupling members between an inner and an outer surface the intermediate members wedging by rolling and having a circular cross-section, e.g. balls all members having the same size and only one of the two surfaces being cylindrical
H02K 7/02 - Additional mass for increasing inertia, e.g. flywheels
H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears
A clutch which reacts to torque overload has a ribbed disc which is produced by plastics injection moulding and which is, along its inner or outer periphery, encapsulated in encircling fashion and on both axial side surfaces by an encompassing ring. Said encompassing ring, owing to shrinkage as a result of cooling, enters into static friction engagement with the ribbed disc, and furthermore engages, by means of bevelled flanks, with ribs running radially on at least one of the side surfaces of the ribbed disc.
F16D 7/02 - Slip couplings, e.g. slipping on overload, for absorbing shock of the friction type
F16D 7/00 - Slip couplings, e.g. slipping on overload, for absorbing shock
F16D 1/072 - Couplings for rigidly connecting two coaxial shafts or other movable machine elements for attachment of a member on a shaft or on a shaft-end non-disconnectable involving plastic deformation
F16D 1/096 - Couplings for rigidly connecting two coaxial shafts or other movable machine elements for attachment of a member on a shaft or on a shaft-end with clamping hubCouplings for rigidly connecting two coaxial shafts or other movable machine elements for attachment of a member on a shaft or on a shaft-end with hub and longitudinal key with radial clamping due to axial loading of at least one pair of conical surfaces using one or more elastic or segmented conical rings forming at least one of the conical surfaces, the rings being expanded or contracted to effect clamping with clamping effected by ring contraction only the ring or rings being located between the shaft and the hub
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
In order to be able to develop the actuator (12), which is introduced in the motor vehicle for comfort functions, so as to be smaller and lighter and more reasonably priced and having increased efficiency without impairing the operation, the worm (17) is relieved of load and the worm wheel (19) is correspondingly reduced in size, by the fact that said worm is driven at a relatively low speed and provides only a small speed reduction in the direction of the worm wheel (19); whereupon the reduced output speed is generated with a correspondingly increased output torque only subsequently, i.e. without further stressing of the worm (17), for example via gears (22) driven in parallel, and is then brought together on the carriers (25) of the latter. In the interests of high efficiency of the worm mechanism (17/19), the flanks thereof are configured only for slight self-locking, and otherwise locking is provided by the latching torque of the motor (13). The latter preferably operates as a multi-phase synchronous polymer motor (13) controllable in speed via the supply frequency thereof and having an external rotor (15). The rotor (15) can be produced with the permanent-magnet assembly thereof and together with the shaft (16) and the worm (17) by multi-component plastics injection moulding.
H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears
H02K 21/22 - Synchronous motors having permanent magnetsSynchronous generators having permanent magnets with stationary armatures and rotating magnets with magnets rotating around the armatures, e.g. flywheel magnetos
H02K 16/00 - Machines with more than one rotor or stator
H02K 1/28 - Means for mounting or fastening rotating magnetic parts on to, or to, the rotor structures
09 - Scientific and electric apparatus and instruments
12 - Land, air and water vehicles; parts of land vehicles
Goods & Services
Apparatus and instruments for controlling and regulating electric drives for single-track and multi-track vehicles, in particular for bicycles; Batteries and accumulators therefor. Bicycles with two or more wheels; Bicycles with combustion engines or electric motors, Electric bicycles, Electric bicycles; Geared motors for land vehicles, in particular for bicycles; Parts and fittings for bicycles, included in class 12.
40 - Treatment of materials; recycling, air and water treatment,
42 - Scientific, technological and industrial services, research and design
Goods & Services
Footwear; sports footwear; sports shoes; football shoes;
athletics shoes; leisure shoes; bath sandals; bath shoes;
parts and accessories for footwear, in particular studs for
football boots, cleats for attachment to sports shoes, heels
(for shoes); heelpieces for footwear; welts for footwear;
tips for footwear and stiffeners for shoes; soles for
footwear; insoles for footwear; intermediate soles; tongues
for shoes; shoe inserts for non-orthopedic purposes;
protective metal members for shoes; toe boxes. Material treatment of fabrics, leather and plastics in the
production of footwear, in particular of sports footwear, as
well as the parts and accessories therefor; custom
manufacture of footwear, in particular of sports footwear,
as well as the parts and accessories therefor; shoe staining
and dyeing, in particular of sports footwear; custom
assembling of materials for others; material treatment
information. Design of shoes, in particular of sports shoes and leisure
shoes, as well as their parts and accessories; research and
development relating to footwear, in particular sports shoes
and leisure footwear; services in the field of science and
technology and research and development related thereto;
technical advice on the production of shoes, in particular
sports shoes and leisure shoes; development services with
regard to new shoes designed for use in construction or
design, in particular sports shoes and leisure shoes, using
textiles, leather and plastics, including the construction
of experimental tools; development, production of prototypes
and implementation, evaluation, analysis and optimization of
test series as part of the development of new shoes, in
particular of sports shoes and leisure shoes.
An adjustment device for a carrier plate which can be pivoted about two mutually orthogonal axes and is configured to receive a motor vehicle mirror, includes one motor per axis for moving a non-rotatably and non-tiltably guided linear drive, which is in engagement via a socket with a joint ball on the carrier plate, and a funnel-shaped hub provided with a hollow shaft. A hollow spherical segment of the funnel-shaped hub engages, by spring tabs, in a depression in the form of a hollow spherical segment in the carrier plate, and a spherical segment of the carrier plate is axially elastically clamped in a hollow spherical segment of a housing for drive trains of the two linear drives, thereby locking the hollow shaft on the housing.
B60R 1/072 - Rear-view mirror arrangements mounted on vehicle exterior with remote control for adjusting position by electrically powered actuator for adjusting the mirror relative to its housing
A particularly cost-effective electric-motor brake actuator which is useable in a highly flexible manner in respect of structural boundary conditions has an integrally formed cup which is equipped with a permanent magnet assembly and can be equipped with a separately manufactured, electromagnetic rotor assembly. In this manner, the equipment outlay is reduced as is the construction costs.
H02K 5/15 - Mounting arrangements for bearing-shields or end plates
F16D 65/18 - Actuating mechanisms for brakesMeans for initiating operation at a predetermined position arranged in or on the brake adapted for drawing members together
A compact battery-free event detector having a switching element, which can be remagnetized in a bistable manner by a magnet in a sensor coil which then provides an event pulse and supplies a non-volatile memory circuit with a downstream non-volatile display, is designed to detect recurring movements by virtue of the switching element being able to be moved back and forth relative to the magnet between the activation and regeneration fields of its two poles. The manual operation of an inhalation or injection piston in a medicament dispenser can therefore be detected, in particular, and a dose of medicament, for instance, can be monitored thereby. The display is preferably created using e-paper or e-ink technology which, like the memory circuit which is operated only sporadically, obtains its energy needed to change the indication from the event pulse from the sensor coil.
G08B 5/22 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electric transmissionVisible signalling systems, e.g. personal calling systems, remote indication of seats occupied using electromagnetic transmission
G08B 25/00 - Alarm systems in which the location of the alarm condition is signalled to a central station, e.g. fire or police telegraphic systems
G08B 5/00 - Visible signalling systems, e.g. personal calling systems, remote indication of seats occupied
G01D 5/20 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage by varying inductance, e.g. by a movable armature
26.
Sub-assembly for an electromechanical brake actuator
The invention relates to a subassembly for a brake actuator, which is provided for an electromechanically operated parking brake. The subassembly comprises a drive device and a gearing device, which comprises in succession a first, second and third gear stage for transmitting a torque generated by the drive device. The first gear stage is designed in the form of a gearwheel or belt drive, the second gear stage is designed in the form of a gearwheel mechanism, and the third gear stage is designed in the form of a planetary gear, wherein a planet carrier of the third gear stage receives a first gearing shaft for a sun gear of the planetary gear and an output-side gearwheel of the second gear stage that is coupled to rotate with the sun gear, and bearing elements for planet gears of the third gear stage. The invention further relates to an electromechanical brake actuator and to an electric parking brake, which include the sub-assembly.
The invention relates to a high-resolution capacitive proximity sensor (11) with high-quality haptics and optics, said proximity sensor having a ceramic disk, behind which electrode sectors (18) are located. The ceramic disk is the base (13) of a flat pot (12) which is produced integrally in a ceramic injection molding process. Defined surface structures of the operating surface (14) on the pot base (13) are used in particular for tactile user guidance, while illuminated regions of the pot base (13) are used for optical user guidance, the pot base being axially accessible from the outside. The sensor circuit (16), which is placed in the pot (12) behind the electrode sectors (18), facing away from the operating surface, is surrounded by an electric conductor (27) in order to dissipate electrostatic charges, said conductor preferably being designed as an elastic buffer against the radial assembly environment.
In order to reduce the wall thickness of housing parts produced by means of plastic injection molding and equipped with decorative layers, such as battery covers of mobile devices, it is recommended to change to a starting material that is a fiber composite material equipped on one side with the decorative layer, from which starting material the housing part is formed in a deep drawing process. Even if a thick decorative layer the outer surface of which is highly embossed for haptic reasons is applied, the resulting wall thickness remains far below the wall thickness for a housing part that can be produced by means of injection molding. An even further reduction of the wall thickness is achieved if a fiber composite material is used as the deep drawing starting material for the shaped part, the decorative material being directly foamed or injected onto the surface of the fiber composite material.
B29B 11/16 - Making preforms characterised by structure or composition comprising fillers or reinforcements
B32B 5/02 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by structural features of a layer comprising fibres or filaments
B32B 27/06 - Layered products essentially comprising synthetic resin as the main or only constituent of a layer next to another layer of a specific substance
B32B 1/00 - Layered products having a non-planar shape
B32B 3/30 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids characterised by a layer formed with recesses or projections, e.g. grooved, ribbed
B32B 7/12 - Interconnection of layers using interposed adhesives or interposed materials with bonding properties
B32B 27/08 - Layered products essentially comprising synthetic resin as the main or only constituent of a layer next to another layer of a specific substance of synthetic resin of a different kind
B32B 27/12 - Layered products essentially comprising synthetic resin next to a fibrous or filamentary layer
B29C 51/00 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor
B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
B29C 51/02 - Combined thermoforming and manufacture of the preform
B29C 51/14 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor using multilayered preforms or sheets
B29L 31/34 - Electrical apparatus, e.g. sparking plugs or parts thereof
29.
ELECTRIC-MOTOR BRAKE ACTUATOR OF A MOTOR VEHICLE PARKING BRAKE
A particularly cost-effective electric-motor brake actuator (36) which is useable in a highly flexible manner in respect of structural boundary conditions has an integrally formed cup (17) which is equipped with a permanent magnet assembly (18) and can be equipped with a separately manufactured, electromagnetic rotor assembly (29).
F16D 65/18 - Actuating mechanisms for brakesMeans for initiating operation at a predetermined position arranged in or on the brake adapted for drawing members together
30.
SEMI-FINISHED PRODUCT CONSISTING OF A FIBER COMPOSITE IN A PLASTICS MATRIX AND METHOD FOR OBTAINING COMPONENTS FROM SAID SEMI-FINISHED PRODUCT
Ein Halbzeug aus einem in eine Kunststoffmatrix eingebetteten mehrlagigen Faser-Flächengebilde ist vielseitiger einsetzbar, wenn die gegenseitigen Verschwenkwinkel von unidirektionalen Fasern in den einzelnen Lagen zu erwartenden mechanischen oder elektrischen Anforderungen angepasst werden, mit untereinander vernähten Fasern an den Kreuzungsstellen. Halbzeug aus beliebigen Faser-Flächengebilden in ihrer Kunststoffmatrix lässt sich in einer Presse oder in einer Tiefziehform, aber auch noch in einer Spritzgussform zu einem ebenen oder dreidimensionalen Bauteil verformen, an dessen Matrix etwa im Mehrkomponenten- Spritzguss Funktionselemente unterschiedlicher mechanischer Eigenschaften angespritzt werden. Eine Lackbeschichtung lässt sich durch das Spritzgusswerkzeug hindurch auf eine Oberfläche des Bauelementes aufbringen. Mit auf das Halbzeug aufgebrachten oder in das Halbzeug eingebrachten elektrisch leitfähigen Strukturen lassen sich Leiterbahnen von Schaltungen oder Elektroden von kapazitiven Sensoren realisieren. Brillante Farben werden für die Bauteile erzielt, wenn die Fasern entsprechend eingefärbt und/oder deren Flächengebilde entsprechend farbig hinterlegt sind. Farbabweichungen, insbesondere bei weiß erscheinendem Halbzeug, werden durch Hinterlegung mit Komplementärfarben zu den unerwünschten Farberscheinungen weitestgehend austariert. Für lokale Abstrahlung einer Hinterleuchtung erfährt das Halbzeug beziehungsweise das daraus geformte Bauteil eine rückwärtige Ausfräsung und gegebenenfalls deren Auffüllung mit lichtleitendem Kunststoff.
A housing shell (11) for electrical measurement, control or communications devices, in particular the lower housing part or the battery cover of a mobile telephone, has a high degree of flexural and torsional rigidity despite an extremely small wall thickness with a preferably completely planar outer face (12) because of the planar cut of a thermoplastically laminated fibrous fabric is insert‑moulded in an injection mould along the edge (13) with a thermoplastic frame (14) together with integrally formed functional elements, wherein the frame (14) preferably surrounds an antenna (15) radially and possibly also axially, which antenna is designed, for example, as a single‑layered helical coil (18) in a sandwich with a magnet face (17.2), which is in the form of an unround ring face, in a depression (16.2) running peripherally along the edge (13) and is connected via passages (20), without any intersections, to a transceiver (21) within the housing.
H01Q 1/40 - Radiating elements coated with, or embedded in, protective material
H01Q 1/24 - SupportsMounting means by structural association with other equipment or articles with receiving set
H01Q 7/06 - Loop antennas with a substantially uniform current distribution around the loop and having a directional radiation pattern in a plane perpendicular to the plane of the loop with core of ferromagnetic material
G06K 19/077 - Constructional details, e.g. mounting of circuits in the carrier
H04M 1/02 - Constructional features of telephone sets
32.
ADJUSTMENT DEVICE FOR A PIVOTABLE CARRIER PLATE, PARTICULARLY FOR RECEIVING A MOTOR VEHICLE MIRROR
The invention relates to an adjustment device (11) for a carrier plate (12) which can be pivoted about two axes that are orthogonal to one another, particularly for receiving a motor vehicle mirror. One untiltable and longitudinally-guided linear drive (25), in the form of a pinion-driven rack or a nut-driven spindle (26), engages, per axis, with said carrier plate (12). A joint ball (45) engages in a joint socket (44) opening that extends in a tubular manner parallel to said carrier plate (12), and engages such that it can be marginally displaced therein depending on the incline of the carrier plate (12).
B60R 1/072 - Rear-view mirror arrangements mounted on vehicle exterior with remote control for adjusting position by electrically powered actuator for adjusting the mirror relative to its housing
A housing shell for electrical measuring, controlling and communication devices, in particular the lower housing part of a cellphone, has very great flexural and torsional rigidity in spite of an extremely small wall thickness if it is formed as a part created by a forming operation from the planar blank of a thermoplastically impregnated long-fibered multi-layered mat. Fine-membered functional elements of likewise thermoplastic material are then molded onto the housing shell in an injection mold.
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
B29C 49/70 - Removing or ejecting blown articles from the mould
B29C 51/00 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor
B29C 51/14 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor using multilayered preforms or sheets
B29C 70/46 - Shaping or impregnating by compression for producing articles of definite length, i.e. discrete articles using matched moulds, e.g. for deforming sheet moulding compounds [SMC] or prepregs
B29C 45/00 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor
B29K 105/08 - Condition, form or state of moulded material containing reinforcements, fillers or inserts of continuous length, e.g. cords, rovings, mats, fabrics, strands or yarns
The technological limits in the reduction of the wall thickness of housing parts produced by means of plastic injection molding and equipped with decorative layers, such as battery covers of mobile devices, appear to have been reached. In order to nevertheless further reduce the resulting wall thickness, even significantly, it is recommended to change to a starting material that is a fiber composite material (13) equipped on one side with the decorative layer (11), from which starting material the housing part is formed in a deep drawing process. Even if a thick decorative layer (11) the outer surface (17) of which is highly embossed for haptic reasons is applied, the resulting wall thickness remains far below the wall thickness for a housing part that can be produced by means of injection molding. An even further reduction of the wall thickness is achieved if a fiber composite material (13) is used as the deep drawing starting material for the shaped part, the decorative material being directly foamed or injected onto the surface (16) of the fiber composite material.
B29C 51/00 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor
B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
B29C 51/14 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor using multilayered preforms or sheets
B32B 5/02 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by structural features of a layer comprising fibres or filaments
In order to provide customer-specific colouring of a lightweight high-performance fibre composite material (10) serving as precursor material for thermoformed parts, without any resultant impairment of the haptic properties of the textile (11) therein, colour-pigmented reflective coating material is sprayed onto the entire surface of the textile (11) or onto graphically delimited parts thereof, before the textile (11) thus coloured is laminated to the fibre composite material (10).
B29C 70/08 - Fibrous reinforcements only comprising combinations of different forms of fibrous reinforcements incorporated in matrix material, forming one or more layers, with or without non-reinforced layers
B60R 13/00 - Elements for body-finishing, identifying, or decoratingArrangements or adaptations for advertising purposes
36.
SUB-ASSEMBLY FOR AN ELECTROMECHANICAL BRAKE ACTUATOR
The invention relates to a subassembly (6) for a brake actuator (1), which is provided for an electromechanically operated parking brake. The subassembly (6) comprises a drive device (10) and a gearbox device (7), which comprises in succession a first (12), second (14) and third (16) gear stage for transmitting a torque generated by the drive device (10). The first gear stage (12) is designed in the form of a gearwheel or belt drive, the second gear stage (14) is designed in the form of a gearwheel mechanism, and the third gear stage (16) is designed in the form of a planetary gear, wherein a planet carrier (56) of the third gear stage (16) receives a first gearbox axle (52) for a sun gear (36) of the planetary gear and an output-side gearwheel (34) of the second gear stage (14) that is rotationally coupled to the sun gear (36), and bearing elements (70) for planet wheels (54) of the third gear stage (16). The invention further relates to an electromechanical brake actuator and to an electric parking brake, which comprise the sub-assembly.
Using integrated multi-component assembly injection moulding, a two-part magnetic rotational angle sensor system (15) having high sensing accuracy is very efficiently integrally produced in a tool as a functional unit that can be directly applied, comprising a polymer-bonded permanent magnet as a passive transmitter part (16) in the first section, which can be rotated relative to the material of the active sensor receiver part (17), which material is sprayed thereon and then shrunk, with the potted receiver (22). For this purpose, injection moulding materials are used that are mutually incompatible for adhesion and lift off from one another over the mutual contact regions due to shrinkage.
G01D 5/14 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
In order to ensure that upon destruction of a brittle article, in particular such as a ceramics element (11) in the form of a frame (13) receiving an apparatus (12), if possible no free fragments at all become detached therefrom, according to the invention the frame (13) itself or a plate (26) that is integrally moulded therewith and extends over the frame opening (14) remote from view behind the apparatus (12) is non-positively or positively connected at discrete points or in continuous segments in different regions (20) to a connecting part (17) injection-moulded from tough-elastic material. In turn, the connecting part (17) can simultaneously be configured for detachably fastening the ceramics element (11) to the apparatus (15) or to an alternative construction part (23).
B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
39.
HOUSING SHELL FOR PORTABLE ELECTRICAL DEVICES AND METHOD FOR THE PRODUCTION THEREOF
A housing shell (11) for electrical measuring, controlling and communication devices, in particular the lower housing part of a cellphone, has very great flexural and torsional rigidity in spite of an extremely small wall thickness if it is formed as a part created by a forming operation from the planar blank of a thermoplastically impregnated long-fibered multi-layered mat. Fine-membered functional elements (14) of likewise thermoplastic material are then molded onto the housing shell (11) in an injection mold.
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
B29C 51/00 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor
B29C 51/14 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor using multilayered preforms or sheets
B29C 69/00 - Combinations of shaping techniques not provided for in a single one of main groups , e.g. associations of moulding and joining techniquesApparatus therefor
B29C 70/46 - Shaping or impregnating by compression for producing articles of definite length, i.e. discrete articles using matched moulds, e.g. for deforming sheet moulding compounds [SMC] or prepregs
H04M 1/02 - Constructional features of telephone sets
40.
HOUSING SHELL FOR PORTABLE ELECTRICAL DEVICES AND METHOD FOR THE PRODUCTION THEREOF
The invention relates to a housing shell (11) for electrical measurement, control, and communication devices, particularly the housing base of a mobile telephone, comprising a very great flexural and torsional rigidity despite extremely low wall thickness, if formed as a molded part from the flat blank of a thermoplastically impregnated long-fiber multilayer mat. Delicate functional elements (14) also made of thermoplastic material are then injected into an injection molded part onto the housing shell (11).
B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
B29C 69/00 - Combinations of shaping techniques not provided for in a single one of main groups , e.g. associations of moulding and joining techniquesApparatus therefor
B29C 51/14 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor using multilayered preforms or sheets
B29C 51/00 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor
B29C 70/46 - Shaping or impregnating by compression for producing articles of definite length, i.e. discrete articles using matched moulds, e.g. for deforming sheet moulding compounds [SMC] or prepregs
H04M 1/02 - Constructional features of telephone sets
41.
Method and device for electrically connecting a functional element contained in a housing
In spite of the absence of a pullout fuse block, functional elements comprising simple socket-type connectors come into contact with an external cable in a mechanically and electrically reliable manner, when said cable has a rod-type or sword-type mating connector which engages directly in the connector by means of a radially protruding return baffle, in a sealed manner, through the rear of an opening in the wall of a housing. If, during the plug-in action, an injection-molded skin which first at least partially closes the opening is enlarged or perforated, the breaking edge nestling against the envelope surface of the mating connector in the plug-in direction provides another retraction block with additional sealing and vibration damping.
H01R 33/00 - Coupling devices specially adapted for supporting apparatus and having one part acting as a holder providing support and electrical connection via a counterpart which is structurally associated with the apparatus, e.g. lamp holdersSeparate parts thereof
An actuator for the electromotive actuation of a parking or stop brake, especially of a private car comprises, downstream on the electric motor, a planetary wheel transmission which is axially cascaded in a multi-stage manner and comprises a centering pin which is radially mounted on the two front ends thereof and extends coaxially to the output shaft, on the radial overdefined bearing arrangement thereof. Respectively one planet carrier comprising a pinion is embodied, along the centering pin, as a sun wheel for the planet wheels on the planet carrier of the following transmission step.
01 - Chemical and biological materials for industrial, scientific and agricultural use
05 - Pharmaceutical, veterinary and sanitary products
07 - Machines and machine tools
09 - Scientific and electric apparatus and instruments
10 - Medical apparatus and instruments
11 - Environmental control apparatus
12 - Land, air and water vehicles; parts of land vehicles
14 - Precious metals and their alloys; jewelry; time-keeping instruments
17 - Rubber and plastic; packing and insulating materials
40 - Treatment of materials; recycling, air and water treatment,
Goods & Services
Artificial resins and other unprocessed plastics; chemical products for use in industry. injection-moulded and sintered products for dental and medical purposes; injection-moulded products for medical apparatus. Machines and machine tools; injection moulding machines and inserts (shaping tools) therefor, for the shaping of plastic parts; powder injection-moulded or sintered shafts, sprockets, gear wheels, screw spindles and sliding bearings being machine parts; parts of motors and engines and power transmission devices of all kinds. Operating status sensors for vehicles, measuring, signalling and checking (supervision) apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; electric circuit boards and assemblies; housing and control elements for communications apparatus; housing and control elements for communications apparatus manufactured by means of metallic and ceramic powder injection moulding, including sintered elements. Artificial limbs and teeth, denture parts. Apparatus for lighting, heating, ventilating and air conditioning and parts therefor; Apparatus for lighting, heating, ventilating and air conditioning and parts therefor for vehicles. Motors and engines and parts therefor, power transmission and braking devices, mirror holders and mirror drives, and display and control elements and other accessories for land vehicles; housing and control elements and parts for vehicle interiors, manufactured by means of metallic and ceramic powder injection moulding; powder injection-moulded or sintered shafts, sprockets, gear wheels, screw spindles and sliding bearings for drive mechanisms. fittings and parts for clocks and watches. Semi-worked plastics; Plastics in extruded form for use in manufacture; electrically insulating materials and objects. Treatment of materials and surface design for plastic parts; services for the mechanical or chemical processing or conversion of inorganic or organic substances or objects; injection moulding and mounting of assemblies by commission order; commissioned assembly services for clean rooms.
44.
METHOD AND DEVICE FOR ELECTRICALLY CONNECTING A FUNCTIONAL ELEMENT CONTAINED IN A HOUSING
In spite of the absence of a pullout fuse block, functional elements (13) comprising simple socket-type connectors (14) come into contact with an external cable (15) in a mechanically and electrically reliable manner, when said cable has a rod-type or sword-type mating connector (16) which engages directly in the connector (14) by means of a radially protruding return baffle, in a sealed manner, through the rear of an opening (18) in the wall (12) of a housing (11). If, during the plug-in action, an injection-moulded skin (19) which first at least partially closes the opening is enlarged or perforated, the breaking edge nestling against the envelope surface of the mating connector (16) in the plug-in direction provides another retraction block with additional sealing and vibration damping.
