A chair includes a backrest, a seat and legs. The seat includes a cushion formed with a net-like structure made of a thermoplastic resin and having a thickness, a seat plate configured to support the cushion, and an outer covering configured to cover the cushion. An upper surface of the cushion includes a first place that has a first hardness and that is configured to support a sitting person's buttock, a second place that is located outside of the first place when seen in a plan view and that has a second hardness higher than the first hardness, and a third place that is located outside of the second place when seen in a plan view and that has a third hardness higher than the second hardness.
A chair includes a lower structure configured to be placed on a floor surface (F), a backrest support member supported by the lower structure body, and a backrest supported by the backrest support member. The backrest includes a backrest body fixed to the backrest support member and provided with an opening portion (S2) that opens downward, and a tensile material provided in the backrest body and having a lower end portion that is locked on the backrest body. The backrest body includes a plate-shaped backrest main body fixed to the backrest support member and provided with a load-supporting surface that supports a load of a seated person. The backrest support member is inserted into the opening portion of the backrest body and is disposed on a rear side of the backrest main body.
A load-supporting structure for a chair includes a receiving surface component provided with a curved receiving surface configured to receive a load from a seated person; a load supporter supporting the receiving surface component from a back side of the receiving surface; and a curved shape-changing portion configured to change a curvature radius of the receiving surface from a curvature radius in an initial state thereof to a greater curvature radius than that in the initial state in accordance with a load received by the receiving surface component. The receiving surface component generates a biasing force for returning the curvature radius of the receiving surface to that in the initial state.
This chair comprises: a seat; a backrest; an elastic member; and a support structure. The elastic member is configured: to elastically deform in the vertical direction and a first direction due to rotation of the backrest; and to return the seat and the backrest to an initial position by imparting a restoring force arising from the elastic deformation to the seat and the backrest.
A47C 1/033 - Reclining or easy chairs having coupled adjustable supporting parts the parts being movably-coupled seat and back-rest the coupling member being a flexible strip
This chair comprises: a seat; a backrest; and a support structure that supports the seat and the backrest. The backrest includes arm parts and a back receiving part. The support structure includes: a first shaft; a second shaft; a third shaft; a fourth shaft; a support base; an arm support part; and a support link.
A47C 3/026 - Rocking chairs with seat, or seat and back-rest unit, elastically mounted in a rigid frame with a central column, e.g. rocking office chairs; Tilting chairs
Provided is a spatial structure which makes it possible to store an article attractively. A spatial structure 1 comprises a free-standing frame body 2 that has a plurality of support columns 3 and beams 4 which link the upper parts of the support columns 3 so as to intersect therewith. An article storage space 20 is formed at at least one of the intersecting parts of the beams 4.
Provided is a power transmission unit and power system, according to one embodiment of the present disclosure, comprising: an input shaft connected to a drive shaft of an internal combustion engine; an output shaft connected to a driven device in a power transmittable manner; a transmission mechanism connecting the input shaft and the output shaft; and a motor generator having a rotary shaft connected through the transmission mechanism to the input shaft and the output shaft. The motor generator, when viewed from the axial direction of the input shaft, is arranged in an outer radial direction crossing the axial direction with respect to the input shaft.
B60K 6/40 - Arrangement or mounting of plural diverse prime-movers for mutual or common propulsion, e.g. hybrid propulsion systems comprising electric motors and internal combustion engines the prime-movers consisting of electric motors and internal combustion engines, e.g. HEVs characterised by apparatus, components or means specially adapted for HEVs characterised by the assembly or relative disposition of components
B60K 6/36 - Arrangement or mounting of plural diverse prime-movers for mutual or common propulsion, e.g. hybrid propulsion systems comprising electric motors and internal combustion engines the prime-movers consisting of electric motors and internal combustion engines, e.g. HEVs characterised by apparatus, components or means specially adapted for HEVs characterised by the transmission gearings
B60K 6/383 - One-way clutches or freewheel devices
B60K 6/387 - Actuated clutches, i.e. clutches engaged or disengaged by electric, hydraulic or mechanical actuating means
A backrest (6) of a chair includes a backrest main body (20) that receives the load from the seated person, and a skin material that covers the backrest main body (20), wherein the skin material has a side opening through which an optional member (lumbar support (200)) can be inserted and arranged, the skin material has a front skin material located on the front side of the backrest main body (20) and a back skin material located on the back side of the backrest main body (20), the side opening is formed by separating the front skin material and the back skin material, the backrest main body (20) includes slits (23) penetrating in the front-rear direction, and locking members (130) that engage with the slits (23) in the front-rear direction are attached to one of the front skin material and the back skin material.
Provided is a partition capable of a smooth change of direction and having excellent straightness. A partition 20 has a pair of guidance means 10, 10 which are guided along a guide rail 5 at an upper end of a partition body 30, and comprises a wheel 12 that is capable of traversing a floor surface F in a central section of a lower end.
Provided is a spatial structure allowing a moving panel to move to an adjacent guide rail by bypassing a support column in an intersection part between beams. The present invention comprises a frame body 2 capable of free-standing and having a plurality of support columns 3, a plurality of beams 4 that couple upper portions of the support columns 3 to each other such that the beams 4 intersect with one another, and guide rails 5 which are provided along the beams 4 and by which a moving panel 9 is movably supported, wherein the two guide rails 5 adjacent to each other across the support column 3 in the intersection part of the beams 4 are connected to each other via a bridge rail 13.
A clutch unit (20) includes a coupling element (23) configured to, in a power transmission enabled manner, couple an output shaft (13) of an engine (10) and an input shaft (16) of a hydraulic pump (15) driven by driving force of the engine (10), and a motor generator (18) configured to generate driving force separately from the engine (10), in which the motor generator (18) is disposed to avoid the coupling element (23) as viewed from an axial direction of the output shaft (13).
B60K 6/40 - Arrangement or mounting of plural diverse prime-movers for mutual or common propulsion, e.g. hybrid propulsion systems comprising electric motors and internal combustion engines the prime-movers consisting of electric motors and internal combustion engines, e.g. HEVs characterised by apparatus, components or means specially adapted for HEVs characterised by the assembly or relative disposition of components
B60K 6/387 - Actuated clutches, i.e. clutches engaged or disengaged by electric, hydraulic or mechanical actuating means
B60K 6/36 - Arrangement or mounting of plural diverse prime-movers for mutual or common propulsion, e.g. hybrid propulsion systems comprising electric motors and internal combustion engines the prime-movers consisting of electric motors and internal combustion engines, e.g. HEVs characterised by apparatus, components or means specially adapted for HEVs characterised by the transmission gearings
A clutch unit (20) includes a coupling element (23) configured to, in a power transmission enabled manner, couple an output shaft (13) of an engine (10) and an input shaft (16) of a hydraulic pump (15) driven by driving force of the engine (10), and a motor generator (18) configured to generate driving force separately from the engine (10), in which the coupling element (23) includes a driving-side coupling portion (23a) configured to be coupled to a first coupling portion (11a) that is provided in the output shaft (13), and a driven-side coupling portion (23b) configured to be coupled to a second coupling portion (15a) that is provided in the input shaft (16) and that is configured to be coupled to the first coupling portion (11a).
B60K 6/36 - Arrangement or mounting of plural diverse prime-movers for mutual or common propulsion, e.g. hybrid propulsion systems comprising electric motors and internal combustion engines the prime-movers consisting of electric motors and internal combustion engines, e.g. HEVs characterised by apparatus, components or means specially adapted for HEVs characterised by the transmission gearings
A chair of an aspect of the present disclosure includes: a support base; and a chair body including a seat frame that extends in the forward-rearward direction and forms at least part of a seat, and a back frame that is provided in the rear end of the seat frame to be pivotable around an axis O1 extending in the left-right direction, extends upward from the seat frame, and forms at least part of a backrest. The support base includes a slider that supports, in front of the axis O1, the seat frame movably in the forward-rearward direction, and a backrest-supporting shaft that supports, below the axis O1, the back frame pivotably around an axis O2 extending in the left-right direction.
This chair (1) has: a support structure (40); a backrest (20) supported by the support structure so as to be capable of rotating about a first axis (42a) extending in the width direction of the support structure, it being possible to displace the backrest to an inclined state of being inclined rearward from an initial state; a regulating part (93) that regulates rotation of the backrest about the first axis; a return part (92) causing the backrest in the inclined state to return to the initial state; a first operation member (95) for allowing a seated person to operate the regulating part (93); a second operation member (80) for allowing the seated person to operate the return part (92); and a base member (91) that supports the first operation member (95) and the second operation member (80), the base member (91) extending in the width direction, the first operation member (95) being supported by a first support part (912) provided to one width-direction end of the base member (91), and the second operation member (80) being supported by a second support part (913) provided to the other width-direction end of the base member (91).
A47C 1/024 - Reclining or easy chairs having independently-adjustable supporting parts the parts, being the back-rest, or the back-rest and seat unit, having adjustable inclination
A47C 1/032 - Reclining or easy chairs having coupled adjustable supporting parts the parts being movably-coupled seat and back-rest
A47C 3/026 - Rocking chairs with seat, or seat and back-rest unit, elastically mounted in a rigid frame with a central column, e.g. rocking office chairs; Tilting chairs
A spring member (60) is provided such that the biasing direction thereof is directed to the front-rear direction and includes a front-side engagement portion (62) provided on a spring front portion and a rear-side engagement portion (63) provided on a spring rear portion. A seat (5) includes a front-side spring seat portion (55) which engages with the front-side engagement portion (62). A backrest (20) or a support structure (41) includes a rear-side spring seat portion (65) which engages with the rear-side engagement portion (63) and an adjustment portion (70) which adjusts, together with the rear-side spring seat portion (65), the position of the rear-side engagement portion (63) in the up-down direction. An upper limit position (T1) of the rear-side engagement portion (63) of the spring member (60) adjusted by the adjustment portion (70) is above an axial center (C1) about which the backrest (20) is rotatably supported by the support structure (41).
A47C 7/44 - Support for the head or the back for the back with elastically-mounted frame
A47C 3/026 - Rocking chairs with seat, or seat and back-rest unit, elastically mounted in a rigid frame with a central column, e.g. rocking office chairs; Tilting chairs
A booth includes a booth main body including a facing panel, a right-side panel, and a left-side panel, a top plate, and an inclined panel that extends from a booth left front-end portion of the right-side panel of the booth main body while being inclined to become farther from the facing panel toward the right-side panel in the plan view and forms an entrance into the booth main body between the inclined panel and a booth right front-end portion of the right-side panel of the booth main body. The top plate includes a panel side edge portion that extends along at least the facing panel and the right-side panel, and a front edge portion that includes a first edge portion that becomes closer to the facing panel from a first end on the right-side panel side of the front edge portion toward the left-side panel.
E04H 1/12 - Small buildings or other erections for limited occupation, erected in the open air or arranged in buildings, e.g. kiosks, waiting shelters for bus stops or for filling stations, roofs for railway platforms, watchmen's huts or dressing cubicles
This chair (1) comprises: a supporting structure (41); a backrest (20) that is supported by the supporting structure so as to be rotatable about an axis extending along the width direction of the supporting structure and that can be displaced to a tilted state of being tilted rearward from an initial state; a biasing portion (60) that biases the backrest in the tilted state toward a direction for returning to the initial state; an adjustment portion (70) that adjusts the biasing force of the biasing portion; and an operation portion (80) that is connected to the adjustment portion and that actuates the adjustment portion. The biasing portion is provided to the backrest or the supporting structure. The adjustment portion is provided to the backrest. The operation portion is disposed rearward of the axis, and at one side of the backrest in the width direction.
A47C 7/44 - Support for the head or the back for the back with elastically-mounted frame
A47C 3/026 - Rocking chairs with seat, or seat and back-rest unit, elastically mounted in a rigid frame with a central column, e.g. rocking office chairs; Tilting chairs
This load-supporting structure (A) for a chair comprises: a receiving surface-forming part (20, 40) having a curved receiving surface (20a, 40a) for receiving a load from a seated person; a load support part (5, 7) supporting the receiving surface-forming part from behind the receiving surface; and a curved shape changing part (50) which changes the radius of curvature of the receiving surface from the radius of curvature in an initial state to a relatively large radius of curvature in response to the load received by the receiving surface-forming part, wherein the receiving surface-forming part generates a biasing force that returns the radius of curvature of the receiving surface to the initial state.
This chair (100) comprises: a lower structure (1) provided to a floor surface (F); a backrest support member (22) supported by the lower structure; and a backrest (4) supported by the backrest support member. The backrest has: a backrest body (5) which is fixed to the backrest support member and in which an opening (S2) open downward is formed; and an upholstery material (50) which is provided to the backrest body and has a lower end section locked to the backrest body. The backrest body is fixed to the backrest support member, has formed therein a load support surface (40a) which supports the load of an occupant, and has a plate-like backrest main body (40). The backrest support member is inserted into the opening of the backrest body and is disposed on the rear side of the backrest main body.
This panel unit (10) comprises a support structure (20) and a pair of panel materials (30) which are disposed on both sides of the support structure (20) so as to sandwich the support structure (20). The support structure (20) comprises: a lower connection part (25) which is provided in a lower end section (21b) of the support structure (20) in the panel unit (10), and to which an upper end section of the support structure (20) in another panel unit (10) that is disposed below the panel unit (10), or an upper end section (72t) of a base leg (70) disposed on a installation surface (F) can be connected; and an upper connection part (26) which is provided in an upper end section of the support structure (20) in the panel unit (10), and to which a lower end section (21b) of the support structure (20) in another panel unit (10) that is disposed above the panel unit (10) can be connected.
17 - Rubber and plastic; packing and insulating materials
Goods & Services
architectural acoustic products, namely, sound absorbers in the form of decorative panels composed primarily of resins or polyester; acoustic products, namely, sound absorbers in the form of decorative panels composed primarily of resins and polyester; acoustic products, namely, sound absorbers in the form of decorative panels composed primarily of non-metal materials in the nature of resins or polyester
A clutch unit (20) comprises: a coupling element (23) that couples, in a manner that enables power transmission, an output shaft (13) of an engine (10) and an input shaft (16) of a hydraulic pump (15) driven by the driving force of the engine (10); and a motor-generator (18) that generates a driving force separate from that of the engine (10). The coupling element (23) comprises: a driving-side coupling part (23a) that is coupled to a first coupling part (11a) provided to the output shaft (13); and a driven-side coupling part (23b) that is coupled to a second coupling part (15a) provided to the input shaft (16) and capable of coupling with the first coupling part (11a).
B60K 17/04 - Arrangement or mounting of transmissions in vehicles characterised by arrangement, location, or kind of gearing
B60K 17/28 - Arrangement or mounting of transmissions in vehicles characterised by arrangement, location, or type of power take-off
B60K 6/40 - Arrangement or mounting of plural diverse prime-movers for mutual or common propulsion, e.g. hybrid propulsion systems comprising electric motors and internal combustion engines the prime-movers consisting of electric motors and internal combustion engines, e.g. HEVs characterised by apparatus, components or means specially adapted for HEVs characterised by the assembly or relative disposition of components
A clutch unit (20) comprises: a coupling element (23) that couples, in a manner that enables power transmission, an output shaft (13) of an engine (10) and an input shaft (16) of a hydraulic pump (15) driven by the driving force of the engine (10); and a motor-generator (18) that generates a driving force separate from that of the engine (10). The motor-generator (18) is disposed so as to avoid the coupling element (23) as viewed from the axial direction of the output shaft (13).
B60K 17/02 - Arrangement or mounting of transmissions in vehicles characterised by arrangement, location, or kind of clutch
B60K 17/04 - Arrangement or mounting of transmissions in vehicles characterised by arrangement, location, or kind of gearing
B60K 17/28 - Arrangement or mounting of transmissions in vehicles characterised by arrangement, location, or type of power take-off
B60K 1/00 - Arrangement or mounting of electrical propulsion units
B60K 6/40 - Arrangement or mounting of plural diverse prime-movers for mutual or common propulsion, e.g. hybrid propulsion systems comprising electric motors and internal combustion engines the prime-movers consisting of electric motors and internal combustion engines, e.g. HEVs characterised by apparatus, components or means specially adapted for HEVs characterised by the assembly or relative disposition of components
A chair (1) according to one embodiment of the present disclosure comprises: a support base (12); and a chair body (3) including a seat frame (120) that extends in the front-back direction and constitutes at least a portion of a seat (100), and a back frame (123) that is provided to a back end of the seat frame (120) so as to be rotatable around an axis line O1 along the left-right direction, and that extends upward from the seat frame (120) and constitutes at least a portion of a seat back (101). The support base (12) includes: a slider that supports the seat frame (120) in front of the axis line O1 so as to be movable in the front-back direction; and a seat back support shaft that supports the back frame (123) below the axis line O1 so as to be rotatable around an axis line O2 along the left-right direction.
A47C 1/032 - Reclining or easy chairs having coupled adjustable supporting parts the parts being movably-coupled seat and back-rest
A47C 3/026 - Rocking chairs with seat, or seat and back-rest unit, elastically mounted in a rigid frame with a central column, e.g. rocking office chairs; Tilting chairs
A backrest includes: a backrest body against which a seated person leans a back thereof, a backrest support positioned behind and supporting the backrest body; and an armrest body provided outside in a width direction of the backrest body and supported by the backrest support so as to move up and down at a position separated from the backrest body. A chair includes the above-described backrest.
Automatic warehousing systems; storage systems, mechanically
operated; automatic transportation systems [machines for use
in moving equipment]; lifting and conveying machines and
apparatus for use in automatic storage of goods; machines
for the automatic storage and retrieval of goods; loading
and unloading machines; handling apparatus for loading and
unloading; conveyors [machines].
This booth (1) comprises: a booth main body (10) comprising a front panel (11), a right-side panel (12), and a left-side panel (13); a top plate (20A); and an inclined panel (14) that extends on an incline from a booth left-front end (10a) of the left-side panel (13) of the booth main body (10), towards the right-side panel (12), in the planar view, so as to extend away from the front panel (11), said inclined panel (14) forming an entrance/exit (100e) to/from the inside of the booth main body, between the inclined panel (14) and a booth right-front end (10b) of the right-side panel (12) of the booth main body (10). The top plate (20A) comprises: panel-side edges (21) along at least the front panel (11) and the right-side panel (12); and a front edge (22A) having a first edge (22a) that approaches the front panel (11) side from a first end (22e) on the right-side panel (12) side, towards the left-side panel (13) side.
E04H 1/12 - Small buildings or other erections for limited occupation, erected in the open air or arranged in buildings, e.g. kiosks, waiting shelters for bus stops or for filling stations, roofs for railway platforms, watchmen's huts or dressing cubicles
E04B 1/343 - Structures characterised by movable, separable, or collapsible parts, e.g. for transport
This curing sheet (11) adheres to a surface (50a) of an existing concrete column (50) to cover a finished surface (55a) of repair mortar (55) filled into a repair groove part (52). The curing sheet (11) includes, on the rear surface side adhering to the surface of the concrete column (50), a non-adhesive partition part (12), and an adhesive annular partition part (13) continuously provided on the outer peripheral portion of the non-adhesive partition part (12) in an annular shape. In a state in which the non-adhesive partition part (12) is superimposed on the entire finished surface (55a) of the repair mortar (55), the adhesive annular partition part (13) adheres to a region surrounding the outside of the finished surface (55a) of the repair mortar (55), so that the curing sheet (11) is attached to cover the finished surface (55a) of the repair mortar (55).
This sofa seat structure is provided with a seat main body (11, 41) and a ground contact part (14) which is provided at the bottom of the seat main body (11, 41) and which supports the seat main body (11, 41); the seat main body (11, 41) comprises a lower structure (111, 141) which configures the bottom part of the seat main body (11, 41) and is supported by the ground contact part (14), and an upper structure (112, 142) which is stacked on top of the lower structure (111, 141) and configures the top of the seat main body (11, 41), wherein the lower structure (111, 141) comprises a support member (15, 43) which supports the upper structure (112, 142) and an outer wall (16, 44) which covers the support member (15, 43), the outer wall (16, 44) being formed from a resin.
This sofa (100, 200) is provided with: a block-like front seat member (11) having a front grounding part (16) on a front lower end thereof; a block-like rear seat member (12) having a rear grounding part (17) on a rear lower end thereof; and a joining member (14) for joining the front seat member (11) and the rear seat member (12), wherein at least a front upper surface (11a) of the front seat member (11) serves as a seat surface on which a sitting person sits, and a space (K) passing through the front seat member (11) and the rear seat member (12) in the width direction is formed between the front grounding part (16) and the rear grounding part (17).
This panel (1) has a panel body (10) and a leg (20) that supports the panel body (10). The leg (20) has a shaft (22) that is inserted into the panel body (10), and a leg body (21) to which the shaft (22) is fixed and that is disposed outside of the panel body (10). The leg body (21) is provided with a first rotation stopper (31) that is in direct contact with at least either one of the front face (10A) and the back face (10B) of a panel face of the panel body (10) and that stops rotation of the panel body (10) in one direction around the shaft (22), and a second rotation stopper (32) that is configured to stop the rotation of the panel body (10) in the direction opposite to the one direction.
A management system is a management system which includes a remote work system having at least one master unit and a plurality of slave units which can be remotely operated and a management server, in which each of the plurality of slave units includes a gripping unit that is configured to grip a target, grip the target by means of autonomous control, and, when being connected to the master unit by the management server, grip the target by means of a remote operation by the master unit, the master unit is configured to perform the remote operation on the plurality of slave units, and the management server includes an operation management unit that is configured to connect the master unit and the plurality of slave units when a remote operation is required.
G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control (DNC), flexible manufacturing systems (FMS), integrated manufacturing systems (IMS), computer integrated manufacturing (CIM)
B25J 3/00 - Manipulators of master-slave type, i.e. both controlling unit and controlled unit perform corresponding spatial movements
A panel structure (100) that is provided with a vertical frame (110) and a horizontal frame (120) around the periphery of a plate-shaped body (101) having a rectangular outline, wherein the vertical frame (110) and the horizontal frame (120) have: grooves (111, 121) into which the peripheral edges of the plate-shaped body (101) are disposed; and connection grooves (112, 122) into which a connection member (130), which connects an end of the vertical frame (110) and an end of the horizontal frame (120) at a corner formed by the vertical frame (110) and the horizontal frame (120), is disposed.
E04C 2/38 - Building elements of relatively thin form for the construction of parts of buildings, e.g. sheet materials, slabs, or panels characterised by the shape or structure with attached ribs, flanges, or the like, e.g. framed panels
E04H 1/12 - Small buildings or other erections for limited occupation, erected in the open air or arranged in buildings, e.g. kiosks, waiting shelters for bus stops or for filling stations, roofs for railway platforms, watchmen's huts or dressing cubicles
Furniture (1, 1B) with a top plate includes: a top plate (2); a plurality of support legs (40, 40B) for supporting the top plate (2); and leg-connecting parts (30) that project downward from the bottom surface of the top plate (2) and to which the upper ends of the support legs (40, 40B) are connected. The support legs (40, 40B) each include: a support-leg body (42) extending in the vertical direction and having an upper end face facing a lower end face of the leg-connecting part (30) in the vertical direction; and a connecting projection (41) projecting upward from the support-leg body (42) and connected to the leg-connecting part (30), at a position above the lower end face of the leg-connecting part (30).
This chair back (4) has a chair back body (41) against which a seated person can lean their back, a chair back support part (24) that is positioned on the rear side of the chair back body (41) and that supports the chair back body (41), and armrest bodies (71) that are provided on the width-direction outer sides of the chair back body (41) and that are raisably and lowerably supported by the chair back support part (24) at positions that are set apart from the chair back body (41). This chair (1) has the chair back (4) described above.
An armrest (7) according to the present invention comprises an armrest body (71) on which a seated person rests his/her elbow, and an armrest body support portion (72) that is supported by a support structure of a chair and to which the armrest body is attached in a vertically movable manner, wherein the armrest body support portion includes a first engagement portion (723), and the armrest body extends vertically such that the first engagement portion is disposed between the upper end portion and the lower end portion of the armrest body, and includes a second engagement portion (77) that is locked to the first engagement portion in a vertically slidable manner, and a cover portion (714) that covers the second engagement portion and the first engagement portion to which the second engagement portion is locked.
