A light-emitting module for a flash, according to the present invention, comprises: a circuit board; a light-emitting unit mounted on the upper surface of the circuit board; a lens module unit that is disposed above the light-emitting unit and diffuses light emitted from the light-emitting unit; and a housing coupled to the circuit board and the lens module unit and surrounding the light-emitting unit, wherein the the lens module unit and the housing are molded by a double injection method to be coupled to each other, and a side surface of the lens module unit is coupled to a portion of the housing by the double injection method.
F21K 9/237 - Détails des enceintes ou des boîtiers, c.-à-d. des parties entre l’élément générateur de lumière et le socleAgencement des composants à l’intérieur des enceintes ou des boitiers
F21K 9/69 - Détails des réfracteurs faisant partie de la source lumineuse
F21S 2/00 - Systèmes de dispositifs d'éclairage non prévus dans les groupes principaux ou , p. ex. à construction modulaire
F21V 5/04 - Réfracteurs pour sources lumineuses de forme lenticulaire
F21V 15/01 - Boîtiers, p. ex. matériau ou assemblage de parties du boîtier
F21V 11/00 - Écrans non couverts par les groupes , , ou
B29C 45/14 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet en incorporant des parties ou des couches préformées, p. ex. moulage par injection autour d'inserts ou sur des objets à recouvrir
A control unit of an earbud device equipped with a biosignal sensor of the present invention is configured to perform the steps of: determining the current wearing state information related to the current wearing state of the housing on the basis of sensing information from the wearing state sensor; determining an operation profile of the biosignal sensor on the basis of the current wearing state information; and controlling the operation of the biosignal sensor on the basis of the determined operation profile.
The present invention relates to an array antenna device. The array antenna device comprises: a base substrate; an array antenna module part which is positioned on the base substrate and which has a plurality of array antenna modules; and an alignment guide unit positioned between adjacent array antenna modules among the plurality of array antenna modules so as to limit the positions of respective array antenna modules positioned to be adjacent to each other.
H01Q 1/02 - Dispositifs de dégivrageDispositifs de séchage
H01Q 3/26 - Dispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la phase relative ou l’amplitude relative et l’énergie d’excitation entre plusieurs éléments rayonnants actifsDispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la distribution de l’énergie à travers une ouverture rayonnante
The present invention relates to a photoplethysmography sensor module. The photoplethysmography sensor module comprises: a first light-receiving substrate, which has a first light-receiving layer and a first light-receiving terminal connected to the first light-receiving layer; a second light-receiving substrate, which is positioned on the first light-receiving substrate and has a second light-receiving layer and a second light-receiving terminal connected to the second light-receiving layer; a first light-emitting substrate, which is positioned on the second light-receiving substrate and has a first light-emitting layer and a first light-emitting terminal connected to the first light-emitting layer; a second light-emitting substrate, which is positioned on the first light-emitting substrate and has a second light-emitting layer and a second light-emitting terminal connected to the second light-emitting layer; a first contact substrate, which is connected to the first light-receiving terminal and the second light-receiving terminal; a second contact substrate, which is connected to the first light-emitting terminal and the second light-emitting terminal; and a third contact substrate, which is connected to the first contact substrate and the second contact substrate.
The present invention relates to a photoplethysmography sensor module comprising: a light-transmissive housing having light exit areas and light entry areas and transmitting light; light emitters positioned so as to correspond to the light exit areas of the housing; light detectors positioned so as to correspond to the light entry areas; and a flexible substrate on which the light emitters and the light detectors are positioned, wherein the outer surface of the light-transmissive housing is flat, and the inner surface thereof, opposite to the outer surface, is curved.
This method by which an electronic device determines the positions of sensors for monitoring the state of a tire installed in a vehicle, according to the present invention, comprises the steps of: identifying traveling direction information about the vehicle; receiving acceleration information from a plurality of sensors of the vehicle; identifying reception strength information for wireless signals received from the plurality of sensors; and determining, on the basis of the traveling direction information, the acceleration information, and the reception strength information, information about the positions at which the plurality of sensors are installed respectively, wherein the step of determining the information about the positions includes a step for determining lateral position information among the information about the positions on the basis of the traveling direction information and the acceleration information about the vehicle, and a step for determining longitudinal position information among the information about the positions on the basis of the reception strength information.
This semiconductor package has an open portion formed on one end of a conductor track on a base plate and has a connection conductor connected, through direct contact, to a connection pad placed within the open portion, thereby improving the stability of signal transmission for a semiconductor chip group. As the one end of the semiconductor package is open to allow direct contact between the connection pad and the connection conductor, the present invention has a shorter electrical path between the connection pad and an external circuit and thus has the effects of reducing electrical loss during signal transmission and significantly enhancing the stability of signal transmission. The present invention ensures signal quality by minimizing electrical interference when processing high-frequency signals.
H01L 25/07 - Ensembles consistant en une pluralité de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide les dispositifs étant tous d'un type prévu dans une seule des sous-classes , , , , ou , p. ex. ensembles de diodes redresseuses les dispositifs n'ayant pas de conteneurs séparés les dispositifs étant d'un type prévu dans la sous-classe
This dielectric filter has a plurality of resonance units arranged in vertical and horizontal configurations on upper, lateral, and lower sides of a dielectric block, increasing frequency selectivity, and enabling miniaturization of the filter, thus providing a simplified coupling structure and facilitating adjustment of frequency response characteristics. The present invention has an effect of providing a miniaturized filter by arranging a plurality of resonance units in vertical and horizontal configurations on the upper, lateral, and lower sides of a dielectric block. The present invention can increase frequency selectivity and effectively suppress unnecessary bands, thereby maintaining excellent filtering performance even in high-frequency bands and improving the transmission efficiency of a communication device.
The present invention relates to a method for managing low-power operation of an electronic device, the method managing the electronic device comprising a plurality of sensors and a control means for controlling the operation of the plurality of sensors such that the electronic device operates with low power while being mounted on an object to be detected, thereby increasing the power efficiency of a small electronic device having a limited battery mounting space and enabling significant extension of the battery usage time.
A61F 13/44 - Garnitures absorbantes, p. ex. serviettes ou tampons hygiéniques pour application externe ou interne au corpsMoyens pour les maintenir en place ou les fixerApplicateurs de tampons comportant un matériau radio-opaque ou des moyens pour signaler la présence de matériau résiduel
A61F 13/42 - Garnitures absorbantes, p. ex. serviettes ou tampons hygiéniques pour application externe ou interne au corpsMoyens pour les maintenir en place ou les fixerApplicateurs de tampons avec un indicateur ou une alarme d'humidité
H02M 1/00 - Détails d'appareils pour transformation
The present invention relates to a sensor module and, more particularly, to a sensor module comprising: a circuit board having a coupling region and an extension region extending from the coupling region to one side; a sensor package coupled to one surface of the coupling region and comprising a package substrate, a sensor chip mounted on the package substrate, and a molding part for molding the sensor chip; and a coupling part that connects the circuit board with the sensor package, wherein the circuit board comprises: a plurality of first signal terminals formed on the top surface of the coupling region; a first dummy terminal surrounding the plurality of first signal terminals; and a transmission line that transmits an electrical signal between the first signal terminals and a signal processing unit of a main device, the package substrate comprises: a plurality of second signal terminals electrically connected to the first signal terminals; and a second dummy terminal surrounding the plurality of second signal terminals, and the coupling part comprises: a first coupling part respectively electrically connecting the plurality of first signal terminals with the second signal terminals; and a second coupling unit connecting the first dummy terminal with the second dummy terminal to form a waterproof portion.
The present invention relates to an array antenna module comprising: a circuit board including a first layer, a second layer, a third layer, and a fourth layer, which are vertically stacked; a beamforming driving chip mounted on the fourth layer; a control terminal coupled to the fourth layer; and an RF terminal coupled to the fourth layer, wherein the circuit board includes a plurality of antennas formed on the first layer and arranged in a predetermined shape, via holes penetrating the second layer and the third layer so as to connect the respective antennas and the beamforming driving chip, a first ground part formed on the second layer, having predetermined repeated patterns repeatedly formed thereon, and surrounding the via holes, a second ground part formed on the third layer and surrounding the via holes, and a mounting terminal formed on the fourth layer and coupled to the beamforming driving chip.
H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids
H01Q 21/06 - Réseaux d'unités d'antennes, de même polarisation, excitées individuellement et espacées entre elles
H01Q 3/34 - Dispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la phase relative ou l’amplitude relative et l’énergie d’excitation entre plusieurs éléments rayonnants actifsDispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la distribution de l’énergie à travers une ouverture rayonnante faisant varier la phase par des moyens électriques
The present invention relates to an antenna package module. The antenna package module comprises: a base substrate including a first substrate layer and a second substrate layer stacked on each other; an antenna unit coupled to a first surface of the base substrate; a driving chip coupled to a second surface of the base substrate to transmit and receive signals to and from the antenna unit; a molding unit coupled to the second surface of the base substrate and encapsulating the driving chip; and a connector unit formed on the second surface of the base substrate to transmit and receive signals to and from the driving chip. The first substrate layer and the second substrate layer have different dielectric constants, the first substrate layer includes a first metal layer having a first thickness, and the second substrate layer includes a second metal layer having a thickness different from that of the first metal layer.
The present invention relates to a smart diaper having an improved structure, which minimizes skin problems of a wearer, increases an electrical connection force with a detection line of the diaper when a sensing device is mounted on the diaper, and minimizes a foreign body sensation or discomfort of the wearer when the sensing device is mounted on the diaper.
A61F 13/42 - Garnitures absorbantes, p. ex. serviettes ou tampons hygiéniques pour application externe ou interne au corpsMoyens pour les maintenir en place ou les fixerApplicateurs de tampons avec un indicateur ou une alarme d'humidité
A61F 13/44 - Garnitures absorbantes, p. ex. serviettes ou tampons hygiéniques pour application externe ou interne au corpsMoyens pour les maintenir en place ou les fixerApplicateurs de tampons comportant un matériau radio-opaque ou des moyens pour signaler la présence de matériau résiduel
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
The present invention relates to a tire monitoring system. The tire monitoring system comprises: a first housing; a second housing which is coupled to the first housing so as to form an interior space and which includes an opening; a substrate which is accommodated in the interior space and which has a control unit and a sensor unit mounted thereon, the sensor unit being positioned to face the opening; and a gasket blocking the opening, allowing air to flow into the interior space, and blocking the ingress of foreign substances.
B60C 23/04 - Dispositifs avertisseurs actionnés par la pression du pneumatique montés sur la roue ou le pneumatique
B60C 23/00 - Dispositifs pour mesurer, signaler, commander ou distribuer la pression ou la température des pneumatiques, spécialement adaptés pour être montés sur des véhiculesAgencement sur les véhicules des dispositifs de gonflage des pneumatiques, p. ex. des pompes ou des réservoirsAménagements pour refroidir les pneumatiques
F16J 15/3296 - Agencements pour la surveillance de l’état physique ou du fonctionnement des joints élastiquesAgencements pour le contrôle des joints élastiques, p. ex. de leur géométrie ou rigidité
The present invention relates to a tire monitoring device comprising: a sensor unit which is located on a substrate and detects a state of a tire; an antenna device located on the substrate; and first and second communication units which are located on the substrate, are connected to different parts of the antenna device, respectively, and use different communication schemes.
This camera module comprises: a printed circuit board having one or more insertion holes formed at regular intervals; an image sensor chip which is mounted on the printed circuit board and detects light as an electrical signal; a housing coupled to the upper surface of the printed circuit board, having formed thereon one or more solder pins protruding downward by a predetermined length, wherein the solder pins are respectively vertically and downwardly inserted into the insertion holes; and a coupling portion for coupling solder melted by heating solder balls by a laser beam, to the solder pins, so as to bond the housing and the printed circuit board, wherein each of the solder pins is made of a different material such that the shrinkage rate of the solder varies when soldering is performed using the laser beam.
This stacked photoplethysmography sensor can improve the accuracy of photoplethysmography by enhancing the positional relationship between a light-emitting element and a light-receiving element. The stacked photoplethysmography sensor of the present invention enhances the positional relationship between the light-emitting element and the light-receiving element so as to improve a light reception effect, thereby significantly improving the accuracy of blood flow measurement. The present invention can be processed in various forms by using a flexible film, such that accurate measurement results can be obtained while wearing discomfort to a user is minimized.
This stacked photo-plethysmography sensor package formed in a free curved surface can form a light-emitting unit and a light-receiving unit in a free curved surface shape to be applied to the miniaturization and thinning of an electronic device, and improve the positional relationship between a light-emitting element and a light-receiving element to improve the accuracy of photo-plethysmography. The stacked photo-plethysmography sensor can improve the accuracy of photo-plethysmography by improving the positional relationship between the light-emitting element and the light-receiving element. The stacked photo-plethysmography sensor according to the present invention improves the positional relationship between the light-emitting element and the light-receiving element to improve the light receiving effect, thereby greatly improving the accuracy of plethysmography. The present invention can be processed in various forms by using a flexible film, thereby having the effect of obtaining an accurate measurement result while minimizing wearing inconvenience for a user.
This coupling device for assembling a stacked photo-plethysmography sensor package can be employed in the miniaturization and thinning of electronic devices as the device assembles, using various jig devices, a stacked photo-plethysmography sensor package in which a light emitting unit and a light receiving unit are formed as free-form surfaces having a curved shape.
Specifically, the objective of the present invention is to provide an array antenna device capable of controlling antenna performance such that, if a failure occurs in an antenna unit of an antenna part capable of beamforming, radiation can be performed in a beamforming direction as similar as possible to a conventional normal beamforming direction by using a normal unit in the vicinity of which the failure occurs.
H01Q 3/26 - Dispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la phase relative ou l’amplitude relative et l’énergie d’excitation entre plusieurs éléments rayonnants actifsDispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la distribution de l’énergie à travers une ouverture rayonnante
H01Q 1/02 - Dispositifs de dégivrageDispositifs de séchage
H01Q 21/06 - Réseaux d'unités d'antennes, de même polarisation, excitées individuellement et espacées entre elles
Disclosed in the present invention is an array antenna device having a combined heat sink, which effectively dissipates heat generated in an antenna module whilst optimizing antenna performance, and improves the control and RF connection efficiency with respect to a plurality of antenna units (160).
The present invention relates to an array antenna device having a failure management function, capable of checking whether an individual unit of a beamforming array antenna has a failure, and if a failure is detected, determining the location of the antenna individual unit in which the failure has been detected, and guiding the failure location of the individual unit of the beamforming array antenna and maintenance and repair for the failure.
The present invention relates to a tire monitoring device and, more specifically, to a tire monitoring device having an improved function and structure, the monitoring device including: a function unit in which an electric circuit including a pressure sensor and having sensing and wireless transmission and reception functions is mounted on a PCB; a power supply unit provided at a lower portion of the function unit to supply power to the function unit; a power terminal for connecting circuits of the power supply unit and the function unit; a top case and a bottom case which are vertically coupled to each other to accommodate the aforementioned components; a top molding unit provided between an upper portion of the function unit and the top case; a bottom molding unit provided between the power supply unit of a lower portion of the function unit and the bottom case; and a reinforcing molding unit spread and cured on a portion except for the pressure sensor by a coupling pressure force of the top case in a state of being applied to an upper portion of the top molding unit.
The present invention relates to a device for remotely sensing whether urination or defecation has occurred and, more specifically, to a urine and feces sensing device that can be mounted on a diaper pad by means of a detachable means provided on the upper surface of a cover unit of the device and detachable in correspondence with a counterpart on the diaper pad, the urine and feces sensing device comprising a detachable unit that, when mounted on the counterpart in correspondence therewith, maintains the state in which a terminal portion of the device is accurately connected to a specific location in a conductive pattern provided on the diaper pad.
A61F 13/42 - Garnitures absorbantes, p. ex. serviettes ou tampons hygiéniques pour application externe ou interne au corpsMoyens pour les maintenir en place ou les fixerApplicateurs de tampons avec un indicateur ou une alarme d'humidité
A61F 13/44 - Garnitures absorbantes, p. ex. serviettes ou tampons hygiéniques pour application externe ou interne au corpsMoyens pour les maintenir en place ou les fixerApplicateurs de tampons comportant un matériau radio-opaque ou des moyens pour signaler la présence de matériau résiduel
A61F 13/49 - Garnitures absorbantes, p. ex. serviettes ou tampons hygiéniques pour application externe ou interne au corpsMoyens pour les maintenir en place ou les fixerApplicateurs de tampons caractérisées par la forme spécialement adaptées pour être portées autour de la taille, p. ex. couches-culottes
25.
CAMERA MODULE AND CAMERA MODULE MANUFACTURING DEVICE
The present invention relates to a camera module and a camera module manufacturing device and, more specifically, to a camera module and a camera module manufacturing device, in which a housing and a substrate are joined by a laser solder jetting method at the side surface of a camera module having a solder ring mounted thereto, to quickly and easily assemble the camera module. According to the present invention, compared to other processes using epoxy and the like, the manufacturing process thereof can be simplified so that the manufacturing quality of a camera is improved, and the process time thereof can be significantly shortened.
B23K 35/02 - Baguettes, électrodes, matériaux ou environnements utilisés pour le brasage, le soudage ou le découpage caractérisés par des propriétés mécaniques, p. ex. par la forme
An embodiment light emitting module includes a housing part including a bottom portion and a side portion that is upright upward from an outer perimeter portion of the bottom portion, an electrode part coupled by being inserted into an opening in the bottom portion, and a light emitting part mounted on the electrode part.
The present invention relates to a wearable electronic device comprising a heart rate sensor module, the wearable electronic device comprising: a housing comprising a main housing which accommodates at least one electronic component, a protruding housing protruding from one side of the main housing, a connection housing connecting the main housing and the protruding housing in a curved shape, and a window which is coupled to a portion of the connection housing and is formed as a curved surface; a base substrate comprising a mounting portion which is formed as a curved surface and faces one surface of the window, a support portion which supports the mounting portion, and a connection portion extending from the support portion; a light emitting portion located in the mounting portion; and a light receiving portion located in the mounting portion, wherein the light emitting portion and the light receiving portion are formed to be curved according to a curved shape of the mounting portion.
A heart rate sensor module including a curved mounting part is disclosed. The heart rate sensor module including a curved mounting part according to one embodiment of the present invention comprises: a housing including a window formed with a curved surface; a mounting part that is formed with a curved surface and faces one side of the window; a base substrate including a support part supporting the mounting part and a connection part extending from the support part; a light-emitting part located on the mounting part; and a light-receiving part located on the mounting part, wherein the light-emitting part and the light-receiving part are formed to be curved according to the curved shape of the mounting part.
A heart rate sensor module including a vertically stacked light-emitting unit is disclosed. The heart rate sensor module including a vertically stacked light-emitting unit according to one embodiment of the present invention comprises: a housing including a window; a mounting part that faces one side of the window; a base substrate including a support part supporting the mounting part and a connection part extending from the support part; a light-emitting part located on the mounting part; and a light-receiving part located on the mounting part, wherein the light-emitting part is formed such that at least two light-emitting layers having different wavelength bands are stacked in the vertical direction.
The present invention relates to a camera module and, more specifically, to a camera module having an improved structure, comprising: a substrate having an image sensor mounted on the center thereof; a housing which is stacked on the upper portion of the substrate with a filter for protecting the image sensor seated on the center thereof; a housing cap which is stacked on the upper portion of the housing, with a bobbin formed on the center thereof; a lens barrel which is coupled to the inner diameter in the upper end of the bobbin of the housing cap while a lens is accommodated therein; and an optical adjuster which is screw-coupled to the upper surface of the housing cap in a non-exposed state after passing through each portion of corners in the four-directions of the lower surface of the housing, and adjusts an optical axis by adjusting the inclination of the housing cap with respect to the housing through a rotating operation.
H04N 23/68 - Commande des caméras ou des modules de caméras pour une prise de vue stable de la scène, p. ex. en compensant les vibrations du boîtier de l'appareil photo
31.
WAVEGUIDE FILTER AND ELECTRONIC DEVICE INCLUDING SAME FILTER
The present invention relates to a waveguide filter and an electronic device including the filter and, more specifically, to a waveguide filter having an improved structure, and an electronic device including the filter. In the waveguide filter, which is composed of a waveguide structure and components, and the electronic device including the filter, electrical connection of the waveguide filter and an object to be connected (for example, an antenna) is achieved by making the connection path shortest, including by direct electrical connection, thus minimizing loss of radio waves.
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
Produits et services
Alarm sensors for security purposes; wearable activity
trackers for displaying, measuring and uploading physical
activity and fitness related data including time, distance,
steps, activity level, exercise calories and sleep quality;
application software for diaper wetness notification; fall
detectors; motion recognizing sensors; computer application
software for urination detection devices; computer servers
for collecting, analyzing, and storing data from urination
detection devices; urination detection sensors; electrical
measuring devices for urination detection; computer software
for measuring urination patterns; software for emergency
alarms and notifications; thermometers, not for medical
purposes; physical analysis devices for behavioral analysis
(not for medical use). Apparatus and instruments for treatment of urinary
incontinence; mechanical devices to treat incontinence;
motion, angle, and posture measurement devices for medical
diagnostics and medical treatment; medical fecal continence
training devices; temperature sensors for medical use;
diagnostic apparatus for medical purposes; thermometers for
medical purposes; measuring instruments adapted for medical
use; sensors [measurement apparatus], for medical purposes;
specimen cups for medical purposes; urine analysis devices
for medical diagnosis; patient monitoring sensors
[measurement apparatus] for medical purposes.
The present invention relates to an electronic device. The electronic device comprises: a communication module package including an antenna module provided with an antenna unit including at least one antenna that transmits and receives an antenna signal of a first frequency band, and with a frequency conversion unit for converting or inversely converting the antenna signal of the first frequency band to an antenna signal of a second frequency band; a first surface portion facing a radiation surface of the communication module package; a second surface portion positioned to be spaced apart from the first surface portion and facing a mounting surface of the communication module package; and a third surface portion facing one side surface of the communication module package, wherein the communication module package is positioned in a mounting groove formed by being surrounded by the first to third surface portions, and the inner surface of the first surface portion facing the radiation surface is an uneven surface having a concave portion and a convex portion.
The present invention relates to a tire-monitoring device. A tire-monitoring device according to one example of the present invention comprises: a housing having a lower housing and an upper housing having an inner space closed by the coupling thereof; a substrate on which a sensor chip positioned in the inner space and including a pressure sensing hole, and an electric device for driving the sensor chip are mounted; a power source unit, which is positioned below the substrate in the inner space and supplies power to the substrate; a filler for sealing at least the space between the power source unit and the housing; and a molding part, which is provided in the housing and covers the electric device positioned on the substrate without covering at least the upper surface of the sensor chip, wherein the sensor chip has a peripheral region in which a recess formed by means of the molding part and/or the sensor chip is provided.
A kernel type concha body temperature measurement system comprises: an insertion unit inserted into an outer ear; a temperature measurement unit for measuring body temperature of a concha; a mapping table storage unit for storing a mapping table for correcting the measured body temperature of the concha into a core temperature; and a correction unit for correcting the measured body temperature of the concha according to the mapping table.
A shutter drive device is disclosed. The shutter drive device of the present invention comprises: a housing; a function unit disposed in the housing; a drive unit including a magnet and a coil, the magnet moving between a first position and a second position by interactions with the coil; a yoke unit including a first yoke which generates attraction with the magnet when the magnet is in one of the first and second positions; and a shutter unit which, as the magnet moves between the first and second positions, moves between a third position in which the shutter unit covers the function unit and a fourth position in which the shutter unit does not cover the function unit and thus the function unit is exposed to the outside.
The present invention relates to a communication module package comprising: a communication module which comprises a fist substrate, a main antenna disposed at a first surface of the first substrate, a communication control chip disposed at a second surface opposite to the first surface of the first substrate; and an auxiliary antenna module which is opposite to and faces the main antenna, and includes an auxiliary antenna having an antenna hole facing the main antenna.
The present invention relates to a communication module package comprising: a first substrate; a first antenna disposed on a first surface of the first substrate; a communication control chip positioned on a second surface positioned opposite to the first surface of the first substrate; a molding part positioned on the second surface of the first substrate and capsulating the communication control chip; a second substrate including a coupling part facing the first surface of the first substrate and an extending part extending over at least a part of the edge of the first surface of the first substrate; and at least one second antenna disposed on the second substrate, and receiving a wireless communication signal through cooperation with the first antenna to transmit the wireless communication signal to the communication control chip.
H04B 1/50 - Circuits utilisant des fréquences différentes pour les deux directions de la communication
H04B 1/00 - Détails des systèmes de transmission, non couverts par l'un des groupes Détails des systèmes de transmission non caractérisés par le milieu utilisé pour la transmission
H04B 1/401 - Circuits pour le choix ou l’indication du mode de fonctionnement
H04B 5/00 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive
H01Q 1/38 - Forme structurale pour éléments rayonnants, p. ex. cône, spirale, parapluie formés par une couche conductrice sur un support isolant
The present invention relates to a waveguide filter, and more particularly, to a waveguide filter having a continuous hole. A waveguide filter according to an example of the present invention comprises: a ceramic block having a conductive coating layer formed thereon; an input terminal and an output terminal formed on one surface of the ceramic block; a resonance unit which is formed on the other surface facing the one surface and comprises a first resonance group including an input groove facing the input terminal and a plurality of resonance grooves and a second resonance group including an output groove facing the output terminal and a plurality of resonance grooves; a plurality of through portions positioned between the resonance grooves forming each of the first resonance group and the second resonance group; a coupling unit positioned between a resonance groove furthest from the input groove of the first resonance group and a resonance groove furthest from the output groove of the second resonance group; and a blocking unit which is positioned between the first resonance group and the second resonance group and includes a plurality of blocking holes arranged in one direction, wherein the input and output terminals include: a recessed terminal portion that is electrically spaced apart from the conductive coating layer, and is coated with a metal material in a recessed groove and the periphery thereof; and a protruding line protruding from the recessed terminal portion.
H01P 1/207 - Filtres en forme de guides d'ondes creux
H01P 1/213 - Sélecteurs de fréquence, p. ex. filtres combinant ou séparant plusieurs fréquences différentes
H01P 1/162 - Sélecteurs de mode, p. ex. pour empêcher ou favoriser la propagation suivant un mode donnéConvertisseurs de mode absorbant des modes de propagation parasites ou indésirés
40.
OPTICAL FINGERPRINT RECOGNITION SENSOR MODULE AND ELECTRONIC DEVICE USING SAME
The present invention relates to an optical fingerprint recognition sensor module and an electronic device using same. An optical fingerprint recognition sensor module according to one embodiment of the present invention comprises: a flexible base board having a signal transmission part and a seating part, wherein the seating part has an opening, the signal transmission part has a connection portion connected to an external circuit, and an electrode extends and is patterned from the connection portion to the seating part; a reinforcement material positioned on the rear surface of the flexible base board and positioned at a portion corresponding to the opening; a sensor part disposed above the reinforcement material and positioned within the opening of the seating part in order to enable fingerprint recognition; a connection member electrically connecting the sensor part and the electrode to each other; and a molding part made of an insulating material and filling a space in which the connection member is provided.
H01L 27/32 - Dispositifs consistant en une pluralité de composants semi-conducteurs ou d'autres composants à l'état solide formés dans ou sur un substrat commun comprenant des composants qui utilisent des matériaux organiques comme partie active, ou qui utilisent comme partie active une combinaison de matériaux organiques et d'autres matériaux avec des composants spécialement adaptés pour l'émission de lumière, p.ex. panneaux d'affichage plats utilisant des diodes émettrices de lumière organiques
A wave guide filter comprises: a ceramic block having a conductive coating layer formed on the surface thereof; a resonance part formed on one surface of the ceramic block, wherein the resonance part comprises a first resonance group including a plurality of resonance grooves and a second resonance group including a plurality of resonance grooves and opposite to the first resonance group; a coupling part extending through a central part of the ceramic block and formed between the first resonance group and the second resonance group; a notch part including a notch hole which extends through the ceramic block, is spaced apart from the coupling part, and is formed between the first resonance group and the second resonance group; a separation part formed on the other surface opposite to the one surface and having a shape surrounding the opening of the notch hole, wherein the conductive coating layer is not formed on the separation part; and an input terminal and an output terminal formed on the other surface.
The present invention relates to a touch sensor module. The touch sensor module comprises: at least one target sensor located below a target area; and a plurality of defense sensors located below a non-target area that is located adjacent to the target area. At least some of the plurality of defense sensors are electrically connected to each other by means of at least one of a series connection and a parallel connection.
G06F 3/041 - Numériseurs, p. ex. pour des écrans ou des pavés tactiles, caractérisés par les moyens de transduction
G06F 3/044 - Numériseurs, p. ex. pour des écrans ou des pavés tactiles, caractérisés par les moyens de transduction par des moyens capacitifs
G06F 3/045 - Numériseurs, p. ex. pour des écrans ou des pavés tactiles, caractérisés par les moyens de transduction utilisant des éléments résistifs, p. ex. une seule surface uniforme ou deux surfaces parallèles mises en contact
G06F 3/046 - Numériseurs, p. ex. pour des écrans ou des pavés tactiles, caractérisés par les moyens de transduction par des moyens électromagnétiques
A camera system for a vehicle interior of the present invention for solving the problem, comprises: a camera installed inside the vehicle and capable of detecting an infrared band; an infrared light emitting unit for emitting infrared rays in a band detectable by the camera; an image analysis unit for analyzing an image received from the camera; and a control unit for controlling the operation of the infrared light emitting unit according to an analysis result of the image analysis unit.
The present invention relates to an electronic device having a housing formed by a 3D printing method. An electronic device according to an embodiment of the present invention may comprise: a housing that is formed of an insulating material and includes an output part formed by a 3D printing method; and a conductive pattern part that includes an output pattern coupled to the surface of the housing and coupled to the output part, and an extension pattern connected to the output pattern, wherein the output pattern can be formed together with the output part by the 3D printing method.
B29C 64/30 - Opérations ou équipements auxiliaires
B29C 45/14 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet en incorporant des parties ou des couches préformées, p. ex. moulage par injection autour d'inserts ou sur des objets à recouvrir
H05K 5/00 - Enveloppes, coffrets ou tiroirs pour appareils électriques
The present invention relates to a directional microphone apparatus. The directional microphone apparatus comprises: a first substrate; a second substrate having a first sound hole facing the first substrate; spacing materials located between the first substrate and the second substrate to space the first substrate and the second substrate apart from each other; a first MEMS transducer located so as to face the first sound hole; a lower housing located on the first substrate and having a second sound hole; and a second MEMS transducer located on a first surface of the first substrate so as to face the lower housing.
The present invention relates to a microphone package. The microphone package comprises: a substrate; a MEMS transducer located on the substrate and converting, into an electrical signal, a sound applied from the outside; a signal processing unit located on the substrate and processing and outputting the electrical signal input from the MEMS transducer; and a first bonding portion for adhering the MEMS transducer to the substrate and containing a plurality of additives therein, wherein the MEMS transducer is located above the plurality of additives.
H01L 25/065 - Ensembles consistant en une pluralité de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide les dispositifs étant tous d'un type prévu dans une seule des sous-classes , , , , ou , p. ex. ensembles de diodes redresseuses les dispositifs n'ayant pas de conteneurs séparés les dispositifs étant d'un type prévu dans le groupe
H01L 23/00 - Détails de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide
H01L 23/04 - ConteneursScellements caractérisés par la forme
H01L 23/13 - Supports, p. ex. substrats isolants non amovibles caractérisés par leur forme
H01L 23/31 - Encapsulations, p. ex. couches d’encapsulation, revêtements caractérisées par leur disposition
H04R 1/04 - Association constructive d'un microphone avec son circuit électrique
The present invention relates to an antenna structure including: a board which includes an open area and a ground area; first and second antenna elements which are positioned spaced apart on opposite sides of the ground area; an isolation circuit unit which is positioned between the first antenna element and the second antenna element; a first ground pattern which is positioned in the ground area so as to be adjacent to the open area, and is spaced apart from the isolation circuit unit; and a second ground pattern which is positioned on the opposite side of the ground area from the first ground pattern so as to be spaced apart from and facing the first ground pattern. The isolation circuit unit includes: first and second extending units which are respectively connected to the first and second antenna elements; first and second capacitive pattern units which are positioned surrounding, but spaced apart from, a portion of the extending unit among the first and second extending units that is closer; an inductive pattern unit which is positioned between the first and second capacitive pattern units, and on which a conductive pattern is wound in a spiral shape; and first and second connection units which are respectively positioned between the first capacitive pattern unit and the inductive pattern unit and between the second capacitive pattern unit and the inductive pattern unit to connect the first and second capacitive pattern units and the inductive pattern unit.
The present invention relates to a wireless communication device having an antenna. A wireless communication device having an antenna according to an example of the present invention comprises: a substrate on which an electrode is formed; a communication module which is positioned on the substrate and is connected to the electrode; a case which is positioned outside the substrate and the communication module and protects the substrate and the communication module from the outside; and an antenna part which includes an adhesive layer adhered on the inner surface of the case, and an antenna metal layer adhered on the adhesive layer and connected to the electrode, wherein the antenna metal layer comprises: a first oxidation preventing layer which is positioned on the adhesive layer and includes a metal of a first material; a core metal layer which is positioned on the first oxidation preventing layer and includes a metal of a second material different from the first material; and a second oxidation preventing layer which is positioned on the core metal layer and includes a metal of the first material.
The present invention relates to a method for producing an antenna package. A method for producing an antenna package according to one example of the present invention includes: an antenna metal layer forming step in which an antenna metal layer is formed by forming a first oxidation prevention layer on a first surface of a core metal layer, and forming a second oxidation prevention layer on a second surface of the core metal layer, which is the reverse surface of the first surface; an adhesive layer forming step in which an adhesive layer is formed on the first surface of the antenna metal layer; a circuit processing step in which the antenna metal layer and the adhesive layer are cut together and the antenna metal layer is patterned; a sealing solution spraying step in which a sealing solution is sprayed on a second surface of the antenna metal layer, which is the reverse surface of the first surface; a body film layer forming step in which a body film layer is formed on the second surface of the antenna metal layer; and a body film layer cutting step in which the body film layer is cut.
The present invention relates to an antenna package. An antenna package according to an embodiment of the present invention comprises: a base film layer; an adhesive layer provided on the base film layer and having adhesion; and an antenna metal layer provided on the adhesive layer, wherein the antenna metal layer comprises: a first antioxidation layer provided on the adhesive layer and comprising a metal of a first material; a core metal layer provided on the first antioxidation layer and comprising a metal of a second material that is different from the first material; and a second antioxidation layer provided on the core metal layer and comprising the metal of the first material.
The present invention relates to a touch sensor module. The touch sensor module comprises: a spacer; a target part positioned above the spacer and formed from a conductive material; and a coil part positioned below the spacer and comprising a first substrate and a plurality of first coils which are aligned side by side along a first direction on the first substrate and in which a coil adjacent to the first direction is wound in the opposite direction. The inductance of the target part and the coil part changes in accordance with a change in the distance between the target part and the coil part, and the touch sensor module detects the change in the inductance.
The present invention relates to a microphone and, more particularly, to a MEMS microphone. A microphone according to an example of the present invention comprises: a case including a side wall and an upper wall, and having an open lower side; a substrate coupled to the lower side of the case; a MEMS transducer positioned on the substrate and converting sound waves input from the outside into an electrical signal; and a signal processing unit provided on the substrate and amplifying and outputting the electrical signal input from the MEMS transducer, wherein the case is fixed to the substrate by an adhesive layer, and the adhesive layer is positioned between the substrate and the case and includes a metal layer containing tin (Sn) and an insulating layer covering the surface of the metal layer and containing an epoxy-based material.
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
Produits et services
Digital thermometers, not for medical purposes; thermometers, not for medical purposes; temperature sensors; downloadable computer application software for mobile phones for measuring temperature; wearable communications apparatus in the nature of smartwatches; wearable telecommunication apparatus, namely, smartwatches, activity trackers; wearable computers in the nature of smartwatches; smartphones in the shape of a watch; wearable activity trackers Infrared thermometers for medical purposes; digital thermometers for medical purposes; thermometers for medical purposes; wearable monitors used to measure biometric data for medical use; heart rate monitors; body composition monitors; diagnostic apparatus for medical purposes, namely, medical diagnostic apparatus for testing for viruses
54.
METHOD FOR PROVIDING TACHOGRAPH DATA OF VEHICLE TACHOGRAPH DEVICE
The present invention provides a method for managing tachograph data of a vehicle tachograph device, the method comprising the steps of: receiving unique identification information of an electronic communication device by a vehicle tachograph device; generating tachograph data by the vehicle tachograph device; granting the electronic communication device access authority to the tachograph data by the vehicle tachograph device; receiving a request for the tachograph data from the electronic communication device by the vehicle tachograph device; confirming the access authority of the electronic communication device by the vehicle tachograph device; and providing the tachograph data by the vehicle tachograph device.
G07C 5/08 - Enregistrement ou indication de données de marche autres que le temps de circulation, de fonctionnement, d'arrêt ou d'attente, avec ou sans enregistrement des temps de circulation, de fonctionnement, d'arrêt ou d'attente
H04L 29/06 - Commande de la communication; Traitement de la communication caractérisés par un protocole
The present invention relates to a biosignal measuring and warning device. The biosignal measuring and warning device comprises: a biosignal sensing unit for measuring a user's biosignal information; a communication unit for communicating with an external apparatus; an operation control unit connected to the biosignal sensing unit and communication unit; a storage unit connected to the operation control unit and having reference numeric values stored therein that are determined according to apparatus type information; and a warning unit connected to the operation control unit to operate under control of the operation control unit, wherein when communication with the apparatus is established to be in a communicable state, the operation control unit stores, in the storage unit, apparatus type information transmitted from the apparatus, determines a reference numeric value for the value corresponding to the apparatus type information in the storage unit, determines the user's current biosignal value received from the biosignal sensing unit, and controls the operation of the warning unit by using the determined reference numeric value and current biosignal value.
The present invention relates to an electronic device, the electronic device comprising: a housing forming an inner space; a signal processing chip positioned in the inner space; a first antenna coupled to the signal processing chip and having at least one first antenna pattern; and a second antenna positioned so as to face the first antenna and having at least one second antenna pattern, wherein the first antenna and the second antenna receive a wireless communication signal by cooperating with each other, and the signal processing chip receives and processes the wireless communication signal.
A touch sensor module of the present invention attenuates an eddy current generated on the lower metal surface of a coil part, and concentrates a magnetic flux generated around a sensor to increase the intensity of an eddy current generated on a sensing target surface, and thus has the effect of improving sensing sensitivity.
In a system comprising a vehicle, a management system including at least one reader installed in the vehicle, and a wearable device for transmitting and receiving data to and from the reader, the management system further comprising an operation server, the present invention provides a method for controlling a management system interworking with a wearable device, comprising: a step in which, when a passenger places the wearable device to be adjacent to the reader, the management system recognizes the wearable device; a step in which the management system determines whether the passenger gets on or off the vehicle; and a step in which the management system transmits the passenger's getting on and off information through the operation server to an administrator terminal or a parent terminal.
G06K 7/10 - Méthodes ou dispositions pour la lecture de supports d'enregistrement par radiation électromagnétique, p. ex. lecture optiqueMéthodes ou dispositions pour la lecture de supports d'enregistrement par radiation corpusculaire
The present invention relates to a directional microphone device comprising: a first substrate including a first sound hole; a first MEMS transducer positioned at the first substrate to correspond to the first sound hole, and outputting a first output signal corresponding to a sound input through the first sound hole; a second substrate including a second sound hole; a second MEMS transducer positioned at the second substrate to correspond to the second sound hole, and outputting a second output signal corresponding to a sound input through the second sound hole; a spacer positioned between the first substrate and the second substrate, and spacing the first substrate and the second substrate; and a signal processing unit positioned at the first substrate or the second substrate, and processing the first and second output signals applied from the first and second MEMS transducers, wherein the signal processing unit calculates a reception time difference between the first output signal and the second output signal to determine the direction of a sound, and controls output states of the first and second output signals according to the determined direction of the sound.
H04R 1/32 - Dispositions pour obtenir la fréquence désirée ou les caractéristiques directionnelles pour obtenir la caractéristique directionnelle désirée uniquement
The present invention provides a terminal structure which comprises: a housing part having a plurality of holes formed therethrough; a plurality of terminal parts inserted into the holes; and coupling parts formed on partial surfaces of the terminal parts, the partial surfaces being in contact with the housing part, wherein the terminal parts and the coupling parts are manufactured by a 3D printer.
H01R 43/16 - Appareils ou procédés spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation de connecteurs de lignes ou de collecteurs de courant ou pour relier les conducteurs électriques pour la fabrication des pièces de contact, p. ex. par découpage et pliage
The present invention comprises: a touch unit including an active region and a non-active region surrounding the active region; at least one sensing coil placed under the active region so as to correspond to the active region and outputting a touch sensing signal according to a touch action on the active region; and at least one reference coil placed under the non-active region so as to correspond to the non-active region and outputting a reference signal according to a touch action on the active region.
The present invention relates to a touch sensor module. The touch sensor module comprises: a bobbin unit having a substrate and an insertion pole protruding from the substrate; a coil unit formed of a coil wire and inserted into the insertion pole; a circuit board connected to the coil unit; and an upper membrane spaced apart by a predetermined distance above the coil unit, wherein the coil unit includes a plurality of coil layers stacked along the height direction of the insertion pole.
The present invention relates to a touch sensor module comprising: a substrate; a coil layer having at least one coil part arranged on the lower surface and/or the upper surface of the substrate; an upper film spaced a determined distance above the coil layer; and a plurality of spacers, which are positioned between the coil layer and the upper film so as to be spaced the determined distance and are made of an elastic material.
The present invention relates to a phased array antenna system, comprising: a data selector having a plurality of output terminals and an input terminal connected to a wireless signal source; a plurality of matching circuit parts each having a plurality of matching circuits of which input terminals are connected to each of the output terminals of the data selector; and a plurality of antennas each connected to the plurality of matching circuit parts.
H01Q 3/30 - Dispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la phase relative ou l’amplitude relative et l’énergie d’excitation entre plusieurs éléments rayonnants actifsDispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne faisant varier la distribution de l’énergie à travers une ouverture rayonnante faisant varier la phase
H01Q 23/00 - Antennes comportant des circuits ou des éléments de circuit actifs qui leur sont intégrés ou liés
The present invention relates to an iris recognition apparatus, comprising: a storage unit in which final eye image data, and location information about and the pixel values of final pupil pixels included in a final pupil area are stored; and an iris extraction unit which splits the final eye image data into as many as unit areas for iris estimation along a predetermined column direction on the basis of the outermost pixel row on one side of the final pupil area, thereby generates a plurality of iris estimation areas, calculates the average pixel values of the final eye image data, corresponding to the respective iris estimation areas, and estimates an iris area by means of the difference between the average pixel values of each iris estimation area and a succeeding iris estimation area, spaced therefrom by a predetermined number in the order, among the plurality of iris estimation areas.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
66.
BODY INFORMATION MEASURING DEVICE AND CONTROL METHOD THEREFOR
The present invention relates to a body information measuring device, the body information measuring device comprising: an image acquiring unit for acquiring and outputting body image data including a plurality of pixels having position information of an X-axis, Y-axis, and Z-axis and pixel values by scanning a body part on which an object is worn; and an operation control unit, connected to the image acquiring unit, for determining the body part on which the object is worn by using the body image data that is applied from the image acquiring unit, extracting from the body image data the position information of the X-axis, Y-axis, and Z-axis of the pixel for the determined body part as preliminary body data, and calculating final body data for the body part by applying a predetermined correction value to the preliminary body data.
The present invention relates to a pupil recognition apparatus, comprising a pupil extraction unit which: extracts pixels having pixel values that are greater than or equal to a first set value, and pixels having pixel values that are less than or equal to a second set value, which is greater than the first set value, from final eye image data, then selects first preliminary pupil pixels by means of pixels having a pixel value that is the same as the first set value, and thereby determines a first preliminary pupil area in which the first preliminary pupil pixels are included; expands the first preliminary pupil area in the directions of first and second rows and in the directions of first and second columns by means of a first to a fourth reference pixel that are respectively located in the uppermost pixel column, bottommost pixel column, leftmost pixel row, and rightmost pixel row of the first preliminary pupil area, and thereby determines a second preliminary pupil area defined by the first and second rows and the first and second columns; and determines a circular area, the diameter of which is the distance between a center pixel located at the center of the second preliminary pupil area, and one among the first row, the second row, the first column, and the second column of the second preliminary pupil area, and determines, as having final pupil pixels, the second preliminary pupil area that is included in the circular area, and determines the area that includes the final pupil pixels as a final pupil area.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
A directional microphone of the present invention comprises a substrate, a first housing, a second housing, a MEMS transducer, and a signal processing element. In an embodiment of the present invention, the substrate may include a first acoustic hole, the first housing may include a second acoustic hole, and the second housing may include a third acoustic hole.
H04R 1/34 - Dispositions pour obtenir la fréquence désirée ou les caractéristiques directionnelles pour obtenir la caractéristique directionnelle désirée uniquement en utilisant un seul transducteur avec des moyens réfléchissant, diffractant, dirigeant ou guidant des sons
Disclosed is an optical sensor package comprising: a base substrate; an optical sensor positioned on the base substrate and having a light receiving surface provided on an upper surface thereof; a housing structure positioned on the base substrate, having the optical sensor accommodated in an inner space thereof, and having a light-transmitting hole provided at a part facing the light receiving surface; and an optical filter positioned above the light receiving surface of the optical sensor, wherein the entire housing structure is made of metal.
An optical sensor package is disclosed. The optical sensor package of the present invention comprises: a base substrate; an optical sensor mounted on the base substrate and having a light receiving surface formed on the top surface thereof; a housing structure having a lower end coupled to the base substrate so as to form an internal space for accommodating the optical sensor and having a light transmitting hole formed in a portion facing the light receiving surface; and an optical filter positioned above the light receiving surface of the optical sensor.
H01L 31/09 - Dispositifs sensibles au rayonnement infrarouge, visible ou ultraviolet
H01L 31/054 - Dispositifs à semi-conducteurs sensibles aux rayons infrarouges, à la lumière, au rayonnement électromagnétique d'ondes plus courtes, ou au rayonnement corpusculaire, et spécialement adaptés, soit comme convertisseurs de l'énergie dudit rayonnement e; Procédés ou appareils spécialement adaptés à la fabrication ou au traitement de ces dispositifs ou de leurs parties constitutives; Leurs détails adaptés comme dispositifs de conversion photovoltaïque [PV] Éléments optiques directement associés ou intégrés à la cellule PV, p.ex. moyens réflecteurs ou concentrateurs de lumière
A wearable device, according to one embodiment of the present invention, comprises: a main body; a display unit, installed in the main body, for displaying an image; an input unit, installed in the main body, for receiving a user input; an illumination sensor, coupled to the input unit, for measuring an illumination value; and a control unit for changing a function of the input unit of the main body according to the illumination value measured by the illumination sensor.
The present invention relates to a sensor package and, more particularly, to a fingerprint sensor package which uses a colorless transparent polyimide film to form a protective layer. The fingerprint sensor package according to an embodiment of the present invention uses a colorless transparent polyimide film for a protective layer on a sensor chip, and thus can reduce the production cost of the fingerprint sensor package and enables more efficient fingerprint recognition.
H01L 23/532 - Dispositions pour conduire le courant électrique à l'intérieur du dispositif pendant son fonctionnement, d'un composant à un autre comprenant des interconnexions externes formées d'une structure multicouche de couches conductrices et isolantes inséparables du corps semi-conducteur sur lequel elles ont été déposées caractérisées par les matériaux
H01L 23/00 - Détails de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide
H01L 23/31 - Encapsulations, p. ex. couches d’encapsulation, revêtements caractérisées par leur disposition
H01L 23/498 - Connexions électriques sur des substrats isolants
73.
OPTICAL SENSOR PACKAGE AND METHOD FOR MANUFACTURING SAME
Disclosed are an optical sensor package and a method for manufacturing the same. The optical sensor package according to the present invention is a light-receiving sensor package for sensing light reflected from the surface of an object to be sensed, and can contribute to slimness of the electronic device on which the same is mounted. The optical sensor package according to the present invention comprises: a base board; a sensor chip which is coupled to the upper surface of the base board, and which comprises a light-receiving surface; a molding portion formed so as to cover a part of the sensor chip on the upper surface of the base board and not to cover the light-receiving surface; an optical filter covering the light-receiving surface; and a flexible circuit board coupled to the lower surface of the base board.
H01L 31/08 - Dispositifs à semi-conducteurs sensibles aux rayons infrarouges, à la lumière, au rayonnement électromagnétique d'ondes plus courtes, ou au rayonnement corpusculaire, et spécialement adaptés, soit comme convertisseurs de l'énergie dudit rayonnement e; Procédés ou appareils spécialement adaptés à la fabrication ou au traitement de ces dispositifs ou de leurs parties constitutives; Leurs détails dans lesquels le rayonnement commande le flux de courant à travers le dispositif, p.ex. photo-résistances
H01L 31/0232 - Dispositifs à semi-conducteurs sensibles aux rayons infrarouges, à la lumière, au rayonnement électromagnétique d'ondes plus courtes, ou au rayonnement corpusculaire, et spécialement adaptés, soit comme convertisseurs de l'énergie dudit rayonnement e; Procédés ou appareils spécialement adaptés à la fabrication ou au traitement de ces dispositifs ou de leurs parties constitutives; Leurs détails - Détails Éléments ou dispositions optiques associés au dispositif
H01L 31/18 - Procédés ou appareils spécialement adaptés à la fabrication ou au traitement de ces dispositifs ou de leurs parties constitutives
An optical sensor package is disclosed. An optical sensor package of the present invention is slim and compact and thus contributes to slimming an electronic device mounted therewith. The optical sensor package of the present invention comprises: a sensor chip including a light-receiving surface; an adhesive film covering the light-receiving surface; and an optical filter coupled to the adhesive film and covering the light-receiving surface, wherein the optical filter has a first wavelength band as a passband, and the adhesive film is transparent in the first wavelength band.
H01L 33/58 - DISPOSITIFS À SEMI-CONDUCTEURS NON COUVERTS PAR LA CLASSE - Détails caractérisés par les éléments du boîtier des corps semi-conducteurs Éléments de mise en forme du champ optique
H01L 33/22 - Surfaces irrégulières ou rugueuses, p.ex. à l'interface entre les couches épitaxiales
H01L 33/48 - DISPOSITIFS À SEMI-CONDUCTEURS NON COUVERTS PAR LA CLASSE - Détails caractérisés par les éléments du boîtier des corps semi-conducteurs
09 - Appareils et instruments scientifiques et électriques
Produits et services
Wireless earphones; wireless apparatus for smart phones; wireless headset or earphones; wireless transmitting and receiving apparatus; wireless speaker; wireless communication devices; Wireless headsets; Headsets for mobile phones; Necklace type headset; Earphones; Headphones; Digital audio processing devices; Speaker units; apparatus processing digital music; Audio electronic apparatus; adapters for connecting mobile phones to hearing aid; Microphones; Temperature sensors; Thermometers not for medical purposes; Smart phones for wrist.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Wireless earphones; wireless apparatus for smart phones; wireless headset or earphones; wireless transmitting and receiving apparatus; wireless speaker; wireless communication devices; Wireless headsets; Headsets for mobile phones; Necklace type headset; Earphones; Headphones; Digital audio processing devices; Speaker units; apparatus processing digital music; Audio electronic apparatus; adapters for connecting mobile phones to hearing aid; Microphones; Temperature sensors; Thermometers not for medical purposes; Smart phones for wrist.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Wireless earphones; wireless apparatus for smart phones; wireless headset or earphones; wireless transmitting and receiving apparatus; wireless speaker; wireless communication devices; Wireless headsets; Headsets for mobile phones; Necklace type headset; Earphones; Headphones; Digital audio processing devices; Speaker units; apparatus processing digital music; Audio electronic apparatus; adapters for connecting mobile phones to hearing aid; Microphones; Temperature sensors; Thermometers not for medical purposes; Smart phones for wrist.
A dielectric filter is disclosed. The dielectric filter of the present invention comprises: a dielectric block that comprises an upper surface, a lower surface facing the upper surface, and a side surface connecting the upper surface and the lower surface; one or more resonance holes that penetrate through the dielectric block between the upper surface and the lower surface; one or more transmission line holes that penetrate through the dielectric block between the upper surface and the lower surface and that are located adjacent to the resonance holes; an external conductor that is continuously formed with the upper surface, the lower surface and the side surface; input/output electrodes that are formed on the lower surface and that are separated from the external conductor; an internal resonance hole conductor that is formed inside the resonance hole and that is electrically connected to the external conductor at the lower surface; an internal transmission line hole conductor that is formed inside the transmission line hole and that is electrically connected to the input/output electrode at the lower surface; a resonance hole conductor pattern that is formed on the upper surface and that is electrically connected to the internal resonance hole conductor at the upper surface; and a transmission line hole conductor pattern that is formed on the upper surface and that is electrically connected to the internal transmission line hole conductor at the upper surface, wherein the resonance hole conductor pattern, the transmission line hole conductor pattern and the external conductor are separated from one another by a non-conductor region of an external surface of the dielectric block.
A vibration generation apparatus is disclosed. The vibration generation apparatus of the present invention comprises: a case that includes an upper surface, a lower surface facing the upper surface, and a side surface connecting the upper surface and the lower surface; a coil that is fixed and coupled inside the case, and that has wires wound multiple times around a winding axis that is perpendicular to the lower surface, the wound wires being stacked so as to form a side surface; a vibrator that includes a plurality of magnets facing the side surface of the coil, and a weight that is coupled to the magnets; and an elastic part that is disposed between the case and the vibrator and elastically supports the vibrator, wherein the side surface of the coil includes a plurality of flat side surfaces formed of flat surfaces, wherein the plurality of magnets have surfaces formed of flat surfaces respectively facing the plurality of flat side surfaces, and wherein the surfaces and the opposite surfaces thereto are magnetised with different polarities.
H02K 33/02 - Moteurs avec un aimant, un induit ou un système de bobines à mouvement alternatif, oscillant ou vibrant avec des induits entraînés dans un sens par application d'énergie à un système à une seule bobine et ramenés par une force d'origine mécanique, p. ex. par des ressorts
H02K 3/28 - Schémas d'enroulements ou de connexions entre enroulements
H04M 19/04 - Dispositions d'alimentation de courant pour systèmes téléphoniques fournissant un courant de sonnerie ou des tonalités de surveillance, p. ex. tonalité de numérotation ou tonalité d’occupation le courant de sonnerie étant produit aux sous-stations
A vibrator is disclosed. The vibrator of the present invention comprises: a case including an upper surface, a lower surface opposite to the upper surface, and side surfaces connecting the upper surface and the lower surface; a central shaft installed in the vertical direction in the inner space of the case; and a plurality of vibrators placed in different directions on the basis of the central shaft, wherein the vibrator comprises: an armature having one end fixed to the central shaft; a coil which is wound around a part of the armature and generates a magnetic flux in the armature when an electric signal is applied; a first magnet and a second magnet which are opposed and spaced apart from each other with the armature interposed therebetween; and a weight coupled to the other end of the armature.
H02K 33/16 - Moteurs avec un aimant, un induit ou un système de bobines à mouvement alternatif, oscillant ou vibrant avec des induits polarisés se déplaçant dans des directions opposées par inversion de la tension appliquée au système à une seule bobine
A temperature sensor package is disclosed. The temperature sensor package of the present invention comprises: a base substrate having a loading part formed at one end thereof, having input/output terminals formed at the other end thereof, and including a connection circuit part for connecting the loading part and the input/output terminals; a temperature sensor part loaded on and coupled to the loading part; a top cover accommodating the temperature sensor part therein, having a transparent window formed at a part thereof facing the temperature sensor part, coupled to the base substrate, and made from a metal material; and a lens coupled to the transparent window.
G01J 5/12 - Pyrométrie des radiations, p. ex. thermométrie infrarouge ou optique en utilisant des détecteurs électriques de radiations en utilisant des éléments thermoélectriques, p. ex. des thermocouples
H05B 3/14 - Éléments chauffants caractérisés par la composition ou la nature des matériaux ou par la disposition du conducteur caractérisés par la composition ou la nature du matériau conducteur le matériau étant non métallique
Disclosed is an optical sensor device. An optical sensor device, according to the present invention, comprises: a control unit for determining an operation mode; a light emitting unit for emitting light of a particular wavelength; and a light receiving unit comprising a plurality of pixels and for detecting the emitted light reflecting off an object, wherein the light receiving unit detects light by means of activating all or a part of the plurality of pixels if the control unit determines that an operation mode is an iris recognition mode, and detects light by means of activating a part of the pixels activated in the iris recognition mode if the control unit determines that an operation mode is a proximity sensing mode.
G01J 1/02 - Photométrie, p. ex. posemètres photographiques Parties constitutives
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
Disclosed is an electronic device having an infrared optical device. An electronic device having an infrared optical device, according to the present invention, comprises: an infrared ray emitting unit for emitting light in an infrared band; an infrared ray receiving unit for detecting light in the wavelength band of the light emitted by means of the infrared ray emitting unit; a signal processing unit for processing a signal generated by means of the infrared ray receiving unit; an image sensor for detecting light in a visible band; a camera module comprising a lens and a focusing module which moves the lens in an optical axis direction and focuses same; and a control unit for controlling the infrared ray emitting unit, infrared ray receiving unit and camera module in accordance with a selected operation mode, wherein, if a selected operation mode is an iris recognition mode, the infrared ray emitting unit irradiates light on the iris and the infrared ray receiving unit detects the light reflected off the iris and captures an image of the iris and, if a selected operation mode is an infrared focusing mode, the infrared ray emitting unit irradiates light on an object, the infrared ray receiving unit detects light reflected off the object, the signal processing unit calculates the location of the object and the focusing module operates in accordance with the calculation result.
H04N 5/33 - Transformation des rayonnements infrarouges
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
G01J 3/10 - Aménagements de sources lumineuses spécialement adaptées à la spectrométrie ou à la colorimétrie
G02B 7/10 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles avec mécanisme de mise au point ou pour faire varier le grossissement par déplacement axial relatif de plusieurs lentilles, p. ex. lentilles d'objectif à distance focale variable
G03B 13/20 - Télémètres couplés avec dispositifs de mise au point, p. ex. réglage du télémètre mettant automatiquement l'objectif au point
H04N 5/232 - Dispositifs pour la commande des caméras de télévision, p.ex. commande à distance
An antenna structure is disclosed. The antenna structure of the present invention is an antenna structure mounted on an electronic device and comprises: a metal trace which forms at least a part of a housing structure of the electronic device; a circuit board located inside the electronic device; and a dielectric block including first and second line patterns electrically connected to the metal trace and the circuit board.
Disclosed is a lens driving device. A lens driving device, which has a lens barrel accommodating a lens, comprises: a base; a stabilizing carrier positioned on the base; a stabilizing driving unit for moving the stabilizing carrier in the direction meeting the optical axis at a right angle; an autofocus carrier positioned inside the stabilizing carrier; an autofocus driving unit for moving the autofocus carrier in the optical axis direction; and one or more ball bearings supporting the stabilizing carrier such that the stabilizing carrier can move with respect to the base in the direction that meets the optical axis at a right angle.
G02B 7/105 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles avec mécanisme de mise au point ou pour faire varier le grossissement par déplacement axial relatif de plusieurs lentilles, p. ex. lentilles d'objectif à distance focale variable avec des lentilles mobiles spécialement adaptées pour la mise au point rapprochée
G03B 3/10 - Mise au point effectuée par force motrice
G03B 5/06 - Objectif basculant autour d'un axe perpendiculaire à l'axe optique
A lens driving device is disclosed. The lens driving device comprises: a base; an image stabilization carrier positioned on the base; an image stabilization drive unit which moves the image stabilization carrier in a direction orthogonal to an optical axis; an auto-focus carrier positioned inside the image stabilization carrier; an auto-focus drive unit which moves the auto-focus carrier in the direction of the optical axis; and at least one spring for image stabilization which provides support so that the image stabilization carrier may be moved in the direction orthogonal to the optical axis with respect to the base.
G03B 5/00 - Réglage du système optique relatif à l'image ou à la surface du sujet, autre que pour la mise au point présentant un intérêt général pour les appareils photographiques, les appareils de projection ou les tireuses
G03B 7/10 - Réglage effectué uniquement sur la base de la réponse, à l'intensité de l'éclairage reçu par l'appareil, d'un dispositif incorporé sensible à la lumière par un servomoteur procurant l'énergie nécessaire pour actionner l'organe de réglage
G03B 3/10 - Mise au point effectuée par force motrice
G02B 7/04 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles avec mécanisme de mise au point ou pour faire varier le grossissement
A lens driving device is disclosed. The lens driving device comprises: a base; an image stabilization carrier positioned on the base; an image stabilization drive unit which moves the image stabilization carrier in a direction orthogonal to an optical axis; an auto-focus carrier positioned inside the image stabilization carrier; an auto-focus drive unit which moves the auto-focus carrier in the direction of the optical axis; and at least one spring for image stabilization which provides support so that the image stabilization carrier may be moved in the direction orthogonal to the optical axis with respect to the base.
G03B 5/00 - Réglage du système optique relatif à l'image ou à la surface du sujet, autre que pour la mise au point présentant un intérêt général pour les appareils photographiques, les appareils de projection ou les tireuses
G03B 3/10 - Mise au point effectuée par force motrice
G02B 7/09 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles avec mécanisme de mise au point ou pour faire varier le grossissement adaptés pour la mise au point automatique ou pour faire varier le grossissement de façon automatique
Disclosed is a lens driving device. A lens driving device, which has a lens barrel accommodating a lens, comprises: a base; an autofocus carrier disposed on the base; an autofocus driving unit for moving the autofocus carrier in the optical axis direction; a stabilizing carrier positioned on the upper part of the autofocus carrier; a stabilizing driving unit for moving the stabilizing carrier in the direction meeting the optical axis at a right angle; one or more springs supporting so as to enable the autofocus carrier to move with respect to the base in the optical axis direction; and one or more ball bearings positioned between the autofocus carrier and the stabilizing carrier.
G02B 7/09 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles avec mécanisme de mise au point ou pour faire varier le grossissement adaptés pour la mise au point automatique ou pour faire varier le grossissement de façon automatique
G03B 3/10 - Mise au point effectuée par force motrice
G03B 5/00 - Réglage du système optique relatif à l'image ou à la surface du sujet, autre que pour la mise au point présentant un intérêt général pour les appareils photographiques, les appareils de projection ou les tireuses
89.
FINGERPRINT RECOGNITION SENSOR PACKAGE AND METHOD FOR MANUFACTURING SAME
Disclosed is a fingerprint recognition sensor package. The fingerprint recognition sensor package of the present invention comprises: a base substrate; a fingerprint recognition sensor chip mounted on an upper surface of the base substrate; and a molding unit for covering and sealing the fingerprint recognition sensor chip and the upper surface of the base substrate, wherein the side surfaces of the base substrate are formed as cutting surfaces, and at least a part of the side surfaces of the molding unit are formed as a laser-cutting surface.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
H01L 23/31 - Encapsulations, p. ex. couches d’encapsulation, revêtements caractérisées par leur disposition
H01L 23/00 - Détails de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide
A fingerprint recognition sensor package is disclosed. The fingerprint recognition sensor package of the present invention comprises: a base substrate; a fingerprint recognition sensor chip mounted on an upper surface of the base substrate; a molding unit for covering and encapsulating the sensor chip and a peripheral part of the upper surface of the base substrate having the sensor chip mounted thereon; and a bezel unit arranged so as to encompass the base substrate and at least a part of a lateral surface of the molding unit, wherein the molding unit is formed so as to cover a part excluding at least a part among the outer parts of the upper surface of the base substrate, the bezel unit includes an upper side part encompassing at least a part of the lateral surface of the molding unit, and a lower side part encompassing at least a part of a lateral surface of the base substrate, and the inner diameter of the upper side part is formed so as to be smaller than that of the lower side part.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
H01L 23/31 - Encapsulations, p. ex. couches d’encapsulation, revêtements caractérisées par leur disposition
H01L 23/498 - Connexions électriques sur des substrats isolants
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
Produits et services
Wireless battery charging devices; Wireless ear buds; wireless earphones; wireless headphones; Thermometers, not for medical purposes; Wearable computers in the form wristbands; Wrist-mounted smartphone; Thermometers for exterior of smartphones not for medical purposes; Wireless headsets for smartphones; [ Stylus for smart phones; ] Sensors for the determination of temperatures, positions and distances; Temperature sensors; Smartphones in the form of wristband that is used to monitor various health and wellness issues, such as food intake, sleep patterns, and activity levels; Headsets for mobile telephones; [ Electronic pens; ] Wearable smartphones; Wearable portable media players; Portable battery charging devices Pulse measuring devices; [ Hearing aids; ] Heart rate monitors; Heartbeat measuring apparatus; Fever thermometers; [ medical test kits for diabetes monitoring for home use; ] Infrared thermometers for medical purposes; Wireless heart rate monitor devices for medical use; Thermometers for medical purposes; [ Temperature indicator labels for medical purposes; Ultrasound diagnostic apparatus; ] Clinical thermometers; [ Electronic hearing aids; ] Body fat monitors; [ Programmable hearing aids; Devices for measuring blood sugar; ] Blood pressure measuring instruments; Portable blood pressure measuring apparatus
An optical sensor package is disclosed. The optical sensor package of the present invention comprises: a base substrate; a light-emitting unit, mounted on an upper surface of the base substrate, for generating white light; a light receiving unit, mounted on an upper surface of the base substrate, for detecting at least some of wavelength bands of the light generated by the light- emitting unit; a cover unit comprising a blocking wall positioned between the light-emitting unit and the light receiving unit; and a reflecting surface positioned around the light-emitting unit.
G01B 11/14 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer la distance ou la marge entre des objets ou des ouvertures espacés
Disclosed are a sensor package and a method for preparing same. A sensor package, according to the present invention, comprises: a base substrate; a sensing substrate which is positioned above the base substrate and away from the base substrate and has a signal pattern formed thereon; one or more solder balls which are positioned between the base substrate and the sensing substrate and are for electrically connecting the base substrate and the sensing substrate; a sensor chip which is coupled to the lower side of the sensing substrate and is electrically connected to the signal pattern; and an underfill material which fills the space between the base substrate and the sensing substrate, wherein the lateral side of the base substrate, underfill material and sensing substrate stacked in order is a consecutively-formed cross section.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
H01L 23/488 - Dispositions pour conduire le courant électrique vers le ou hors du corps à l'état solide pendant son fonctionnement, p. ex. fils de connexion ou bornes formées de structures soudées
H01L 23/28 - Encapsulations, p. ex. couches d’encapsulation, revêtements
H01L 21/56 - Encapsulations, p. ex. couches d’encapsulation, revêtements
Disclosed is a method for preparing a sensor package. A method for preparing a sensor package, according to the present invention, comprises the steps of: preparing a sensor package comprising a base substrate, which has a signal pad formed on the upper side thereof and a hole passing through the upper side and lower side thereof, a sensor chip, which is positioned above the base substrate and has a signal terminal electrically connected to the signal pad, and an upper sealing portion which seals between the base substrate and the sensor chip so as to be airtight; testing the airtightness of the upper sealing portion by means of inserting air through the hole; and, if the airtightness test is passed, coupling a lower sealing portion, which seals the hole so as to be watertight, to the lower side of the base substrate.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
H01L 23/28 - Encapsulations, p. ex. couches d’encapsulation, revêtements
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
H01L 23/31 - Encapsulations, p. ex. couches d’encapsulation, revêtements caractérisées par leur disposition
Disclosed is a sensor package. A sensor package according to the present invention comprises: a base substrate; a sensor chip above the upper surface of the base substrate; a glass cover above the upper surface of the sensor chip; and resin material filling the space between the sensor chip and glass cover.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
Disclosed is a sensor package. A sensor package according to the present invention comprises: a base substrate; a sensor chip above the upper surface of the base substrate; a glass cover above the upper surface of the sensor chip; a bezel part surrounding the glass cover; and resin material around the sensor chip to adhere to the sensor chip and the bottom surface of the glass cover.
G01D 5/00 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière
G01D 11/26 - RegardsVerres protecteursScellements pour ceux-ci
G01K 1/00 - Détails des thermomètres non spécialement adaptés à des types particuliers de thermomètres
G01K 1/08 - Dispositifs de protection, p. ex. étuis
G01J 1/02 - Photométrie, p. ex. posemètres photographiques Parties constitutives
G01V 8/12 - Détection, p. ex. en utilisant des barrières de lumière en utilisant un émetteur et un récepteur
G01L 19/00 - Détails ou accessoires des appareils pour la mesure de la pression permanente ou quasi permanente d'un milieu fluent dans la mesure où ces détails ou accessoires ne sont pas particuliers à des types particuliers de manomètres
An information display device is disclosed. The information display device of the present invention comprises: a number display unit on which numbers having at least two digits can be displayed; a short-range wireless communication unit which is connected to a different communication device and can receive data; and a power unit for supplying power to the number display unit and the wireless communication unit, wherein the wireless communication unit receives data regarding speed from the connected different communication device with a predetermined time interval, and displays the data on the number display unit.
A microphone package is disclosed. The microphone package according to the present invention comprises: a base substrate having an acoustic hole; a transducer positioned to cover at least a portion of the acoustic hole on the upper surface of the base substrate; a cover coupled to the base substrate so as to form an inner space in which the transducer is accommodated; and a coupling member coupled to an edge portion of the lower surface of the base substrate.
A vibration motor is disclosed. The vibration motor of the present invention comprises: a housing for forming an inner space; a stator coupled to the inside of the housing; a vibrator vibrating by the electromagnetic force generated between the vibrator and the stator; and an elastic body of which one end is coupled to one surface of the inside of the housing and of which the other end is coupled to the vibrator, wherein a groove portion recessed deeper than the surrounding area is formed on the surface, of the vibrator, facing the elastic body.
H02K 33/02 - Moteurs avec un aimant, un induit ou un système de bobines à mouvement alternatif, oscillant ou vibrant avec des induits entraînés dans un sens par application d'énergie à un système à une seule bobine et ramenés par une force d'origine mécanique, p. ex. par des ressorts
100.
MICROPHONE PACKAGE AND MANUFACTURING METHOD THEREFOR
A microphone package and a manufacturing method therefor are disclosed. The microphone package and the manufacturing method therefor, of the present invention, comprise: a base substrate having an electrode formed on the upper surface thereof; a transducer coupled to the electrode of the base substrate; and a cover coupled to the substrate so as to form an inner space accommodating the transducer, and having an acoustic hole penetrating through the outer surface and the inner surface thereof, wherein the periphery of the acoustic hole of the cover is formed into a thin part having a thickness thinner than that of a peripheral part of the cover.
