A temporary protective roof system comprising: a first roof support beam (2) configured for providing main support and strength to a roof; a first tarpaulin (15); a first elongated rail structure (30) having a tarpaulin attachment interface (96) for attachment of the first tarpaulin (15) to the first elongated rail structure (30) and a rail holder (35) for detachably fastening the first elongated rail structure (30) to the first roof support beam (2); wherein the rail holder (35) of the first elongated rail structure (30) comprises at least two moveable locking pins (68) for disconnectable engagement with the first roof support beam (2).
E04G 21/24 - Mesures de sécurité ou de protection pour éviter d'endommager les parties du bâtiment ou les finitions pendant la construction
E04G 21/28 - Mesures de sécurité ou de protection pour éviter d'endommager les parties du bâtiment ou les finitions pendant la construction contre les intempéries
E04H 15/36 - Moyens de support, p. ex. armatures en forme d'arche
E04H 15/64 - Attaches de couvertures de tentes ou d'abris provisoires
A modular keder rail comprising: a first elongated structural member (21) having a keder groove (31-34) extending along the length of the first structural member (21) and a first recess (37a) located at a first end face of the first structural member (21); a second elongated structural member (22) having a keder groove (31-34) extending along the length of the second structural member (22) and a first recess (37b) located at a first end face of the second structural member (22); and a first gasket arrangement (36); wherein the first and second elongated structural members (21, 22) are configured for being arranged next to each other, such that the first recesses (37a, 37b) of the first and second structural members (21, 22) faces each other; and wherein the first gasket arrangement (36) is configured to be located in the first recesses (37a, 37b) and to be compressed between the first and second structural members (21, 22) for providing a weatherproof seal between the first and second structural members (21, 22).
E04G 21/24 - Mesures de sécurité ou de protection pour éviter d'endommager les parties du bâtiment ou les finitions pendant la construction
E04G 21/28 - Mesures de sécurité ou de protection pour éviter d'endommager les parties du bâtiment ou les finitions pendant la construction contre les intempéries
E04B 1/24 - Structures comportant des éléments porteurs allongés, p. ex. colonnes, poutres, ossatures les pièces porteuses étant métalliques
E04B 1/58 - Assemblages pour les constructions du bâtiment en général d'éléments de construction en forme de barre
E04H 15/64 - Attaches de couvertures de tentes ou d'abris provisoires
A keder roof system comprising a first elongated rail structure (30) with a first keder groove (31) and a first tarpaulin (15) having a rectangular form with first and second opposite side edges, wherein the first tarpaulin (15) has a first keder chord (38) located along the first side edge and second keder chord (39) located along the second side edge, and wherein the first keder chord (38) is configured for being inserted into, and slidingly moveable within, the first keder groove (31) of the first elongated rail structure (30). The keder roof system further comprises a first shuttle arrangement (40) fastened to the first tarpaulin (15), wherein the first shuttle arrangement (40) has a rope attachment structure (83). The keder roof system further comprises a pull rope (14) configured for being attached to the rope attachment structure (83) of the first shuttle arrangement (40). The first elongated rail structure (30) comprises a rope guiding structure (52) configured for holding and guiding the pull rope (14) along the first elongated rail structure (30) at a location outside of the first keder groove (31). Moreover, the pull rope (14) and a portion of the first shuttle arrangement (40) are configured to pass through the rope guiding structure (52) of the first elongated rail structure (30) when the first tarpaulin (15) is being mounted on the first elongated rail structure (30).
E04G 21/24 - Mesures de sécurité ou de protection pour éviter d'endommager les parties du bâtiment ou les finitions pendant la construction
E04G 21/28 - Mesures de sécurité ou de protection pour éviter d'endommager les parties du bâtiment ou les finitions pendant la construction contre les intempéries
E04H 15/54 - Couvertures de tentes ou d'abris provisoires
E04H 15/64 - Attaches de couvertures de tentes ou d'abris provisoires
E04B 7/02 - ToitsStructure des toits en ce qui concerne l'isolation avec des pentes planes, p. ex. toits en bâtière
A temporary protective roof system comprising: a first roof support beam (2) configured for providing main support and strength to a roof; a first tarpaulin (15); a first elongated rail structure (30) having a tarpaulin attachment interface (96) for attachment of the first tarpaulin (15) to the first elongated rail structure (30) and a rail holder (35) for detachably fastening the first elongated rail structure (30) to the first roof support beam (2); wherein the rail holder (35) of the first elongated rail structure (30) comprises at least two moveable locking pins (68) for disconnectable engagement with the first roof support beam (2).
The invention concerns a platform unit (1) for use with a scaffolding structure (100). The platform unit (1) comprising a worker's platform (2) and a ladder (10) for climbing onto the worker's platform (2). The platform unit (1) further comprises a first tipping prevention member (20, 50, 3) which is adapted to interact with a substantially horizontal longitudinally extending first support member (101, 103) of the scaffolding structure (100), a second tipping prevention member (30) which is adapted to interact from below with a substantially horizontal longitudinally extending second support member (102), which second support member (102) is vertically spaced apart from the first support member (101, 103), wherein at least a part (62) of at least one of the first and second tipping prevention members (20, 50, 3, 30) is vertically adjustable for enabling attachment and detachment of the platform unit (1) to said scaffolding structure (100), and at least three rollers (5, 24, 28, 29, 36, 37) for supporting the platform unit (1), wherein each of the rollers (5, 24, 28, 29, 36, 37) is adapted to rest against either said first support member (101, 103) or said second support member(102), such that the platform unit (1) is rollingly movable in the longitudinal direction.
E04G 1/24 - Échafaudages reposant principalement sur le sol comprenant essentiellement une structure de base particulièreÉchafaudages reposant principalement sur le sol comprenant essentiellement des parties particulières de liaison avec le sol, p. ex. des étais inclinés, des roues
E04G 1/28 - Échafaudages reposant principalement sur le sol conçus pour procurer un support uniquement à une faible hauteur
E04G 5/10 - Marchepieds ou échelles spécialement adaptés pour les échafaudages
E04C 1/39 - Éléments de construction en forme de blocs ou autre pour la construction de parties de bâtiments caractérisés par des adaptations particulières, p. ex. servant à loger des conduites, à former des frises, des corniches ou des tablettes, à ancrer des sablières ou des dormants de portes, pour claustra
A coupling member includes a hook-shaped coupling part arranged to be hooked into a gripping part of an upright and a locking arrangement switchable between a locking position and a release position. Further, the locking arrangement includes a pivotally attached first clamping part and a wedge-shaped locking part, which is slidable between a locking position and a release position. The wedge-shaped locking part is arranged to push the first clamping part towards the upright and the gripping part by means of wedge action. Moreover, the first clamping part comprises two transversally spaced apart side parts which jointly define a cavity there between. The first clamping part is arranged externally on the hook-shaped coupling part, and is arranged partly within the cavity. Further, each of the side parts includes fastening means for pivotal attachment of the first clamping part to the hook-shaped coupling part.
E04G 7/12 - Brides ou pinces pour éléments croisés
E04G 7/32 - Barres ou éléments d'échafaudage avec des pièces d'assemblage fixées de façon inamovible les éléments d'assemblage utilisant des coins
E04G 7/34 - Barres ou éléments d'échafaudage avec des pièces d'assemblage fixées de façon inamovible les éléments d'assemblage utilisant un engagement positif, p. ex. des crochets ou des broches
E04G 7/30 - Barres ou éléments d'échafaudage avec des pièces d'assemblage fixées de façon inamovible
