Abrégé

A utility slat for a rolling shutter comprises a single-walled slat body with a U-shaped channel formed in the slat body that defines an interior space for receiving additional features, such as a rolling shutter locking device. A cover is removably coupled to the slat body to enclose the interior space.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E05B 65/00 - Serrures pour emplois particuliers

Abrégé

An egress system for a motorized rolling shutter, comprises an articulated shutter curtain that is raised or lowered by winding or unwinding the curtain about a rotatable cylinder. A planetary gear system comprises a sun gear, planet gears, a planet carrier, and a ring gear. Rotation of the planet carrier is driven by a motor, and ring gear is rotationally coupled to the cylinder. In motorized operation, the rotation of the sun gear is arrested by a brake, such that the rotation of the planet carrier causes the planet gears to rotate, which drive the rotation of the ring gear and cylinder. When the motor is inoperable, the brake is released to permit rotation of the sun gear, which permits the planet gears to rotate without rotation of the planet carrier, and allows the manual rotation of the ring gear and cylinder.

Classes IPC  ?

• E06B 9/08 - Fermetures du type à rouleau
• E06B 9/68 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique
• E06B 9/80 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement

Abrégé

An egress system for a motorized rolling shutter, comprises an articulated shutter curtain that is raised or lowered by winding or unwinding the curtain about a rotatable cylinder. A planetary gear system comprises a sun gear, planet gears, a planet carrier, and a ring gear. Rotation of the planet carrier is driven by a motor, and ring gear is rotationally coupled to the cylinder. In motorized operation, the rotation of the sun gear is arrested by a brake, such that the rotation of the planet carrier causes the planet gears to rotate, which drive the rotation of the ring gear and cylinder. When the motor is inoperable, the brake is released to permit rotation of the sun gear, which permits the planet gears to rotate without rotation of the planet carrier, and allows the manual rotation of the ring gear and cylinder.

Classes IPC  ?

• E06B 9/80 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement
• E06B 9/60 - Tambours à ressorts actionnés uniquement par des éléments de fermeture
• E06B 9/72 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'intérieur du rouleau
• E06B 9/74 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique conçus pour la manœuvre électrique ou manuelle au choix

Abrégé

A ballistic panel for a rolling shutter assembly covering an opening may include a ballistic panel cover and a plurality of ballistic sheets disposed within the ballistic panel cover. Each ballistic sheet may be fabricated from a high-strength material and have a sheet upper edge, a sheet lower edge and oppositely disposed sheet lateral edges. The plurality of ballistic sheets may be attached to each other proximate the sheet upper edges and not attached to each other along the sheet lower edges and the sheet lateral edges such that the plurality of ballistic sheets slide relative to each other when the plurality of ballistic sheets are rolled up around the sheet upper edges. The ballistic panel may be attached to a shutter curtain of a rolling shutter assembly at the sheet upper edges to roll up around a shutter support member without bunching and rippling.

Classes IPC  ?

• F41H 5/24 - BlindagePlaques de blindageBoucliers à usage statique, p. ex. dans les fortifications
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/58 - Dispositifs de guidage

Abrégé

A ballistic panel (80) for a rolling shutter assembly (10, 140) covering an opening may include a ballistic panel cover (90) and a plurality of ballistic sheets (92) disposed within the ballistic panel cover (90). Each ballistic sheet (92) may be fabricated from a high-strength material and have a sheet upper edge (100), a sheet lower edge (102) and oppositely disposed sheet lateral edges (104). The plurality of ballistic sheets (92) may be attached to each other proximate the sheet upper edges (100) and not attached to each other along the sheet lower edges (102) and the sheet lateral edges (104) such that the plurality of ballistic sheets (92) slide relative to each other when the plurality of ballistic sheets (92) are rolled up around the sheet upper edges (100). The ballistic panel (80) may be attached to a shutter curtain (30, 140) of a rolling shutter assembly (10, 140) at the sheet upper edges (100) to roll up around a shutter support member (20) without bunching and rippling.

Classes IPC  ?

• F41H 5/04 - Structure des plaques composées de plus d'une couche
• E06B 5/10 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Classes IPC  ?

• E06B 5/10 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• F41H 5/04 - Structure des plaques composées de plus d'une couche

Abrégé

A security device for reinforcing a structure such as a door against cutting or other forms of attack, comprises a hollow casing with an interior space, and first and second rod assemblies positioned in the interior space under compression. The first rod assembly comprises a first rod and a first spring, and the second rod assembly comprises a second rod and a second spring. The first and second rod assemblies are parallel, and the first and second springs do not overlap. The first and second rods only have point contact with the casing.

Classes IPC  ?

• E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages
• E06B 3/70 - Vantaux de porte
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Abrégé

A slat for a rolling shutter is provided that is formed as a single walled, continuous bent sheet. The slat includes a body having a hook-shaped engaging track at a first end, and a receiving track at the second end comprising a guard member and a hook-shaped lip member that form a pocket for receiving the engaging track of another slat. The guard member includes a portion of the sheet that is bent over on itself. The lip member extends from the guard member, and is spaced apart from the guard member to define an aperture that is sized and shaped to receive the engaging track of the other slat.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/165 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues avec des lattes s'escamotant l'une dans l'autreVolets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues avec des lattes entre lesquelles la distance peut être modifiée
• E06B 9/34 - Stores à lamelles ou similaires, p. ex. stores vénitiens à lamelles horizontales, p. ex. non levables du type à rouleau
• E06B 9/386 - Détails des lamelles

Abrégé

A security device for reinforcing a structure such as a door against cutting or other forms of attack, comprises a hollow casing with an interior space, and first and second rod assemblies positioned in the interior space under compression. The first rod assembly comprises a first rod and a first spring, and the second rod assembly comprises a second rod and a second spring. The first and second rod assemblies are parallel, and the first and second springs do not overlap. The first and second rods only have point contact with the casing.

Classes IPC  ?

• E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages
• E06B 3/70 - Vantaux de porte
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Classes IPC  ?

• E05C 9/18 - Parties constitutives des moyens d'immobilisation de fermeture ou des moyens fixes de retenue pour les extrémités de barres
• E05C 9/22 - Moyens de guidage pour barres, tringles ou câbles coulissants
• E06B 3/36 - Aménagements des battants caractérisés par le genre de mouvementAménagements des battants modèles dans les ouverturesCaractéristiques des battants ou châssis ayant trait uniquement au genre de mouvement du battant pour un seul genre de mouvement avec un axe de rotation vertical unique sur l'un des côtés de l'ouverture, ou tournant dans l'ouverture
• E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages

Abrégé

A modular security door system comprises a hollow core door and reinforcing member. The hollow core door has an inner space, and an opening into the inner space. A housing is positioned in the inner space, for receiving the reinforcing member. The opening is aligned with the housing for insertion of the reinforcing member into the housing. In another embodiment, the reinforcing member is plate-shaped. A bracket having a channel is positioned on an outer side of a door face, the channel sized and shaped to receive an edge of the plate-shaped reinforcing member. In another embodiment, the plate-shaped reinforcing member has a laminated structure with at least two layers made of different materials. The layers may be laminated together to form the reinforcing member before installation on the door, or may be assembled on the door.

Classes IPC  ?

• E05C 9/22 - Moyens de guidage pour barres, tringles ou câbles coulissants
• E05C 9/18 - Parties constitutives des moyens d'immobilisation de fermeture ou des moyens fixes de retenue pour les extrémités de barres
• E05C 19/00 - Autres dispositifs spécialement conçus pour le blocage des battants
• E06B 3/36 - Aménagements des battants caractérisés par le genre de mouvementAménagements des battants modèles dans les ouverturesCaractéristiques des battants ou châssis ayant trait uniquement au genre de mouvement du battant pour un seul genre de mouvement avec un axe de rotation vertical unique sur l'un des côtés de l'ouverture, ou tournant dans l'ouverture
• E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages

Abrégé

A modular security door system comprises a hollow core door and reinforcing member. The hollow core door has an inner space, and an opening into the inner space. A housing is positioned in the inner space, for receiving the reinforcing member. The opening is aligned with the housing for insertion of the reinforcing member into the housing. In another embodiment, the reinforcing member is plate-shaped. A bracket having a channel is positioned on an outer side of a door face, the channel sized and shaped to receive an edge of the plate-shaped reinforcing member. In another embodiment, the plate-shaped reinforcing member has a laminated structure with at least two layers made of different materials. The layers may be laminated together to form the reinforcing member before installation on the door, or may be assembled on the door.

Classes IPC  ?

• E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages

Produits et services

(1) Metal security grilles (2) Non-metal security grilles

Produits et services

Metal security grilles

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors; metal gates; and metal security grilles. Non-metal shutters for windows and doors; and non-metal screens and storm panels for windows and doors. Display cases for merchandise; and security cabinets. Installation and repair of shutters, screens, overhead doors, gates, and grilles.

Produits et services

(1) Metal shutters for windows and doors; metal screens for windows and doors; metal gates; metal grilles (2) Non-metal shutters for windows and doors; non-metal screens and storm panels for windows and doors (3) Display cases for merchandise; security cabinets (1) Installation and repair of metal and non-metal roll shutters for windows and doors, metal and non-metal screens for windows and doors, overhead doors, gates, and metal and non-metal security grilles.

Produits et services

(1) Metal shutters for windows and doors; metal screens for windows and doors; metal gates; metal grilles (2) Non-metal shutters for windows and doors; non-metal screens and storm panels for windows and doors (3) Display cases for merchandise; security cabinets (1) Installation and repair of metal and non-metal roll shutters for windows and doors, metal and non-metal screens for windows and doors, overhead doors, gates, and metal and non-metal security grilles.

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors; metal gates; and metal security grilles. Non-metal shutters for windows and doors; and non-metal screens and storm panels for windows and doors. Display cases for merchandise; and security cabinets. Installation and repair of shutters, screens, overhead doors, gates, and grilles.

Produits et services

(1) Metal shutters for windows and doors; metal screens for windows and doors; metal gates; metal grilles (2) Non-metal shutters for windows and doors; non-metal screens and storm panels for windows and doors (3) Display cases for merchandise; security cabinets (1) Installation and repair of metal and non-metal roll shutters for windows and doors, metal and non-metal screens for windows and doors, overhead doors, gates, and metal and non-metal security grilles.

Produits et services

(1) Metal shutters for windows and doors; metal screens for windows and doors; metal gates; metal grilles (2) Non-metal shutters for windows and doors; non-metal screens and storm panels for windows and doors (3) Display cases for merchandise; security cabinets (1) Installation and repair of metal and non-metal roll shutters for windows and doors, metal and non-metal screens for windows and doors, overhead doors, gates, and metal and non-metal security grilles.

Produits et services

(1) Metal shutters for windows and doors; metal screens for windows and doors; metal gates; metal grilles (2) Non-metal shutters for windows and doors; non-metal screens and storm panels for windows and doors (3) Display cases for merchandise; security cabinets (1) Installation and repair of metal and non-metal roll shutters for windows and doors, metal and non-metal screens for windows and doors, overhead doors, gates, and metal and non-metal security grilles.

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors; metal gates; and metal security grilles. Non-metal shutters for windows and doors; and non-metal screens and storm panels for windows and doors. Display cases for merchandise; and security cabinets. Installation and repair of shutters, screens, overhead doors, gates, and grilles.

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors; metal gates; and metal security grilles Non-metal shutters for windows and doors; and non-metal screens and storm panels for windows and doors Display cases for merchandise; and security cabinets Installation and repair of shutters, screens, overhead doors, gates, and grilles

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors; metal gates; and metal security grilles. Non-metal shutters for windows and doors; and non-metal screens and storm panels for windows and doors. Display cases for merchandise; and security cabinets. Installation and repair of shutters, screens for window and doors, overhead doors, gates, and security grilles

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/84 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre le déroulement intempestif
• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation
• E06B 9/88 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques pour limiter le déroulement
• E06B 9/92 - Moyens permettant aux fermetures d'être déplacées en dehors du plan d'ouverture

Abrégé

A lock slat for a rolling shutter comprises a housing having opposite first and second sides. A housing channel is formed between the first and second sides. A cam is coupled to the housing, and is moveable between a locked position to secure the rolling shutter, and an unlocked position. A cam slat is slidably received in the housing channel, and is coupled to the cam. The movement of the cam slat in the housing channel moves the cam between the locked and unlocked positions.

Classes IPC  ?

• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation

Abrégé

A lock slat for a rolling shutter comprises a housing having opposite first and second sides. A housing channel is formed between the first and second sides. A cam is coupled to the housing, and is moveable between a locked position to secure the rolling shutter, and an unlocked position. A cam slat is slidably received in the housing channel, and is coupled to the cam. The movement of the cam slat in the housing channel moves the cam between the locked and unlocked positions.

Classes IPC  ?

• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation
• E06B 9/88 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques pour limiter le déroulement
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/84 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre le déroulement intempestif
• E06B 9/92 - Moyens permettant aux fermetures d'être déplacées en dehors du plan d'ouverture

Abrégé

A locking system for a rolling shutter comprises a housing, a body, and a lock bar. The housing has a longitudinal housing channel. The body has a body channel, and is positioned in and moveable transversely within the housing channel. The lock bar is positioned within the body channel, and is moveable longitudinally to the body and housing between a locked position extending away from the body and an unlocked position retracted toward the body. The movement of the body within the housing channel is coupled to the movement of the lock bar between the locked and unlocked positions.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/11 - Volets à rouleau
• E05B 15/10 - Pênes de serrures ou verrous de sûreté
• E05B 65/00 - Serrures pour emplois particuliers
• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation

Classes IPC  ?

• E05B 15/10 - Pênes de serrures ou verrous de sûreté
• E06B 9/11 - Volets à rouleau
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation

Abrégé

A slat for a rolling shutter comprises a body having a longitudinal channel and a side opening to the channel. A stop bar is slidably received in the body channel and is moveable between an extended position projecting from the body and a withdrawn position retracted toward the body. The stop bar comprises a rack that is actuatable through the side opening to move the stop bar between the extended and withdrawn positions. A pinion is positioned in the body channel in engagement with the rack, the rotation of the pinion actuating the rack to move the stop bar. The pinion is accessible for rotation through the side opening.

Classes IPC  ?

• E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
• E05B 65/00 - Serrures pour emplois particuliers

Abrégé

A slat for a rolling shutter comprises a body having a longitudinal channel
and a side
opening to the channel. A stop bar is slidably received in the body channel
and is moveable
between an extended position projecting from the body and a withdrawn position
retracted
toward the body. The stop bar comprises a rack that is actuatable through the
side opening to
move the stop bar between the extended and withdrawn positions. A pinion is
positioned in the
body channel in engagement with the rack, the rotation of the pinion actuating
the rack to move
the stop bar. The pinion is accessible for rotation through the side opening.

Classes IPC  ?

• E06B 9/11 - Volets à rouleau
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/34 - Stores à lamelles ou similaires, p. ex. stores vénitiens à lamelles horizontales, p. ex. non levables du type à rouleau

Abrégé

A locking system for a rolling shutter comprises a housing, a body, and a lock bar. The housing has a longitudinal housing channel. The body has a body channel, and is positioned in and moveable transversely within the housing channel. The lock bar is positioned within the body channel, and is moveable longitudinally to the body and housing between a locked position extending away from the body and an unlocked position retracted toward the body. The movement of the body within the housing channel is coupled to the movement of the lock bar between the locked and unlocked positions.

Classes IPC  ?

• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation
• E05B 65/00 - Serrures pour emplois particuliers
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/80 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement

Abrégé

A slat for a rolling shutter is provided that is formed as a single walled, continuous bent sheet. The slat includes a body having a hook-shaped engaging track at a first end, and a receiving track at the second end comprising a guard member and a hook-shaped lip member that form a pocket for receiving the engaging track of another slat. The guard member includes a portion of the sheet that is bent over on itself. The lip member extends from the guard member, and is spaced apart from the guard member to define an aperture that is sized and shaped to receive the engaging track of the other slat.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/165 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues avec des lattes s'escamotant l'une dans l'autreVolets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues avec des lattes entre lesquelles la distance peut être modifiée
• E06B 9/34 - Stores à lamelles ou similaires, p. ex. stores vénitiens à lamelles horizontales, p. ex. non levables du type à rouleau
• E06B 9/386 - Détails des lamelles

Abrégé

A rolling shutter comprises first and second slats, each slat having inner and outer sides, a first edge with an engaging track, and a second edge with a receiving track. The receiving track comprises a lip member and a guard member that are spaced apart to form an aperture that is sized and shaped to receive the engaging track of another slat. The engaging track of the first slat is received in the receiving track of the second slat to form an articulating hinge. The hinge has a vertical position with the maximum extension of the first and second slats, and the hinge is rotatable from the vertical position in a backward direction. In one embodiment, the engaging track is hook-shaped and comprises a bend that curves toward the inner side, and a rib positioned at the first edge that projects from the inner side.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Abrégé

A locking system for a rolling shutter that includes a plurality of rolling shutter slats, comprises a guide track with a U-shaped guide channel having a channel base, and first and second channel walls. A lock bar is coupled to the rolling shutter slats. In a locked position, the lock bar extends transverse to the channel base. The lock bar has a notch covered by a breakaway wall that is aligned with the channel base in the locked position. The lock bar may be slidably received in a sleeve that is positioned in the guide channel to increase resistance to torsional forces on the locking system. In an alternative embodiment, the locking system comprises a unitary extruded body, a lock bar, and a handle. A longitudinal channel is formed integrally in the body for receiving the lock bar and handle.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation

Abrégé

A utility slat for a rolling shutter comprises a single-walled slat body with a U-shaped channel formed in the slat body that defines an interior space for receiving additional features, such as a rolling shutter locking device. A cover is removably coupled to the slat body to enclose the interior space.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/34 - Stores à lamelles ou similaires, p. ex. stores vénitiens à lamelles horizontales, p. ex. non levables du type à rouleau
• E06B 9/42 - Parties constitutives ou détails des stores à rouleau, p. ex. dispositifs de suspension, carters de stores

Abrégé

A rolling shutter comprises first and second slats, each slat having inner and outer sides, a first edge with an engaging track, and a second edge with a receiving track. The receiving track comprises a lip member and a guard member that are spaced apart to form an aperture that is sized and shaped to receive the engaging track of another slat. The engaging track of the first slat is received in the receiving track of the second slat to form an articulating hinge. The hinge has a vertical position with the maximum extension of the first and second slats, and the hinge is rotatable from the vertical position in a backward direction. In one embodiment, the engaging track is hook-shaped and comprises a bend that curves toward the inner side, and a rib positioned at the first edge that projects from the inner side.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Abrégé

A utility slat for a rolling shutter comprises a single-walled slat body with a U-shaped channel formed in the slat body that defines an interior space for receiving additional features, such as a rolling shutter locking device. A cover is removably coupled to the slat body to enclose the interior space.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/08 - Fermetures du type à rouleau
• E06B 9/11 - Volets à rouleau
• E06B 9/34 - Stores à lamelles ou similaires, p. ex. stores vénitiens à lamelles horizontales, p. ex. non levables du type à rouleau
• E06B 9/42 - Parties constitutives ou détails des stores à rouleau, p. ex. dispositifs de suspension, carters de stores
• E06B 9/58 - Dispositifs de guidage

Abrégé

A locking system for a rolling shutter that includes a plurality of rolling shutter slats, comprises a guide track with a U-shaped guide channel having a channel base, and first and second channel walls. A lock bar is coupled to the rolling shutter slats. In a locked position, the lock bar extends transverse to the channel base. The lock bar has a notch covered by a breakaway wall that is aligned with the channel base in the locked position. The lock bar may be slidably received in a sleeve that is positioned in the guide channel to increase resistance to torsional forces on the locking system. In an alternative embodiment, the locking system comprises a unitary extruded body, a lock bar, and a handle. A longitudinal channel is formed integrally in the body for receiving the lock bar and handle.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
• E06B 9/80 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement
• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation

Abrégé

A rolling shutter comprises first and second slats, each slat having inner and outer sides, a first edge with an engaging track, and a second edge with a receiving track. The receiving track comprises a lip member and a guard member that are spaced apart to form an aperture that is sized and shaped to receive the engaging track of another slat. The engaging track of the first slat is received in the receiving track of the second slat to form an articulating hinge. The hinge has a vertical position with the maximum extension of the first and second slats, and the hinge is rotatable from the vertical position in a backward direction. In one embodiment, the engaging track is hook-shaped and comprises a bend that curves toward the inner side, and a rib positioned at the first edge that projects from the inner side. The hinge is rotatable from the vertical position in the forward direction, and the rib of the first slat contacts the lip member of the second slat to stop the forward rotation of the hinge.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Abrégé

A utility slat for a rolling shutter comprises a single-walled slat body with a U-shaped channel formed in the slat body that defines an interior space for receiving additional features, such as a rolling shutter locking device. A cover is removably coupled to the slat body to enclose the interior space.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E05B 65/00 - Serrures pour emplois particuliers

Abrégé

A locking system for a rolling shutter having a plurality of shutter slats and a guide track with a U-shaped guide channel having a channel base, comprises a lock bar coupled to the shutter slats with a locked position extending transverse to the channel base. A lock bar notch covered by a breakaway wall is aligned with the channel base in the locked position. The lock bar may be slidably received in a sleeve that is positioned in the guide channel to increase resistance to torsional forces. Alternatively, the locking system comprises a unitary extruded body with a longitudinal channel, and a lock bar, and handle received in the channel. The lock bar is slidable in the channel between an extended locked position and a retracted unlocked position, with the handle positioned in the channel to stop the retraction of the lock bar at the unlocked position.

Classes IPC  ?

• E05C 9/04 - Aménagement de pênes à action simultanée ou d'autres dispositifs de blocage en des emplacements bien distincts sur le même battant avec deux barres coulissantes déplacées en directions opposées lors de l'immobilisation ou de la libération
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
• E06B 9/58 - Dispositifs de guidage

Abrégé

Ballistic curtains for covering an opening are disclosed. The ballistic curtain may include a guide track mounted above the opening, a ballistic curtain sheet fabricated from an anti-ballistic fabric, and hooks connecting the ballistic curtain sheet to the guide track and being slidable in the guide track so that the ballistic curtain sheet moves between a retracted position and a deployed position where the ballistic curtain sheet covers the opening. Alternatively, the ballistic curtain may the ballistic curtain sheet may hang from a head rail mounted above the opening and have a bottom rail connected to a bottom edge of the ballistic curtain sheet. The ballistic curtain sheet may be stored in a recess above an opening until a trap door is released to allow the ballistic curtain sheet to drop. Alternatively, the ballistic curtain may have deployment mechanisms controlling the storage and deployment of the ballistic curtain sheet.

Classes IPC  ?

• A62C 2/14 - Coupe-feu articulés comportant au moins deux volets
• B32B 5/02 - Produits stratifiés caractérisés par l'hétérogénéité ou la structure physique d'une des couches caractérisés par les caractéristiques de structure d'une couche comprenant des fibres ou des filaments
• B32B 5/26 - Produits stratifiés caractérisés par l'hétérogénéité ou la structure physique d'une des couches caractérisés par la présence de plusieurs couches qui comportent des fibres, filaments, grains ou poudre, ou qui sont sous forme de mousse ou essentiellement poreuses une des couches étant fibreuse ou filamenteuse un autre couche également étant fibreuse ou filamenteuse
• B60J 1/20 - Accessoires, p. ex. déflecteurs d'air, écrans
• E06B 9/13 - Volets à rouleau avec des éléments de fermeture en une seule pièce, p. ex. en tôle ondulée
• E06B 9/24 - Écrans ou autres dispositifs protecteurs contre la lumière, notamment contre la lumière solaireÉcrans similaires pour protection de l'intimité ou pour des raisons esthétiques

Produits et services

Forced entry resistant metal security doors

Produits et services

Forced entry resistant metal security doors

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors

Produits et services

Metal security shutters for doors, windows, screened porches, balconies and patios in homes, apartments and commercial buildings

Produits et services

Metal security shutters for doors, windows, screened porches, balconies and patios in homes, apartments and commercial buildings

Abrégé

A base slat pry stopper, such as a base slat locking bracket, for locking a rolling shutter curtain covering an opening of a structure is disclosed. The base slat pry stopper may include a bracket base plate mounted to an opening bottom wall on an interior side of the shutter curtain, and a base slat engagement portion extending upward from the bracket base plate and above a top surface of the opening bottom wall. When the shutter curtain is unrolled to cover the opening, the base slat engagement portion engages the base slat to prevent the base slat from deflecting upward away from the opening bottom wall when a force applied from an exterior side of the shutter curtain causes the base slat to deflect toward the interior side of the structure and the shutter curtain. The base slat pry stopper may be permanently or removably installed.

Classes IPC  ?

• E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation
• E06B 9/80 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
• E06B 9/58 - Dispositifs de guidage

Abrégé

A base slat pry stopper, such as a base slat locking bracket, for locking a rolling shutter curtain covering an opening of a structure is disclosed. The base slat pry stopper may include a bracket base plate mounted to an opening bottom wall on an interior side of the shutter curtain, and a base slat engagement portion extending upward from the bracket base plate and above a top surface of the opening bottom wall. When the shutter curtain is unrolled to cover the opening, the base slat engagement portion engages the base slat to prevent the base slat from deflecting upward away from the opening bottom wall when a force applied from an exterior side of the shutter curtain causes the base slat to deflect toward the interior side of the structure and the shutter curtain. The base slat pry stopper may be permanently or removably installed.

Classes IPC  ?

• E05B 65/00 - Serrures pour emplois particuliers
• E05C 3/14 - Dispositifs d'immobilisation avec pênes se déplaçant de façon pivotante ou rotative avec action d'une clenche avec poignée de manœuvre ou organe équivalent fixé rigidement à la clenche
• E06B 1/52 - Chambranles adaptés pour portes uniquement
• E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables

Abrégé

A base slat pry stopper, such as a base slat locking bracket, for locking a rolling shutter curtain covering an opening of a structure is disclosed. The base slat pry stopper may include a bracket base plate mounted to an opening bottom wall on an interior side of the shutter curtain, and a base slat engagement portion extending upward from the bracket base plate and above a top surface of the opening bottom wall. When the shutter curtain is unrolled to cover the opening, the base slat engagement portion engages the base slat to prevent the base slat from deflecting upward away from the opening bottom wall when a force applied from an exterior side of the shutter curtain causes the base slat to deflect toward the interior side of the structure and the shutter curtain. The base slat pry stopper may be permanently or removably installed.

Classes IPC  ?

• E06B 9/80 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement
• E06B 9/58 - Dispositifs de guidage
• E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
• E06B 9/00 - Écrans ou dispositifs de protection pour ouvertures, avec ou sans mécanismes de manœuvre ou de fixationFermetures de même structure

Abrégé

A base slat pry stopper, such as a base slat locking bracket, for locking a rolling shutter curtain covering an opening of a structure is disclosed. The base slat pry stopper may include a bracket base plate mounted to an opening bottom wall on an interior side of the shutter curtain, and a base slat engagement portion extending upward from the bracket base plate and above a top surface of the opening bottom wall. When the shutter curtain is unrolled to cover the opening, the base slat engagement portion engages the base slat to prevent the base slat from deflecting upward away from the opening bottom wall when a force applied from an exterior side of the shutter curtain causes the base slat to deflect toward the interior side of the structure and the shutter curtain. The base slat pry stopper may be permanently or removably installed.

Classes IPC  ?

• E05B 65/00 - Serrures pour emplois particuliers
• E05C 3/14 - Dispositifs d'immobilisation avec pênes se déplaçant de façon pivotante ou rotative avec action d'une clenche avec poignée de manœuvre ou organe équivalent fixé rigidement à la clenche
• E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
• E06B 1/52 - Chambranles adaptés pour portes uniquement

Abrégé

A slat for a rolling shutter is provided that is formed as a single walled, continuous bent sheet. The slat includes a body having a hook-shaped engaging track at a first end, and a receiving track at the second end comprising a guard member and a hook-shaped lip member that form a pocket for receiving the engaging track of another slat. The guard member includes a portion of the sheet that is bent over on itself. The lip member extends from the guard member, and is spaced apart from the guard member to define an aperture that is sized and shaped to receive the engaging track of the other slat.

Classes IPC  ?

• E06B 9/00 - Écrans ou dispositifs de protection pour ouvertures, avec ou sans mécanismes de manœuvre ou de fixationFermetures de même structure
• E06B 9/02 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction
• E06B 9/08 - Fermetures du type à rouleau
• E06B 9/24 - Écrans ou autres dispositifs protecteurs contre la lumière, notamment contre la lumière solaireÉcrans similaires pour protection de l'intimité ou pour des raisons esthétiques
• E06B 9/26 - Stores à lamelles ou similaires, p. ex. stores vénitiens
• E06B 9/56 - Dispositions ou dispositifs de manœuvre, de guidage ou de verrouillage pour fermetures à rouleauTambours à ressortsTambours à rubanLeurs dispositions de contrepoids

Abrégé

A slat for a rolling shutter is provided that is formed as a single walled, continuous bent sheet. The slat includes a body having a hook-shaped engaging track at a first end, and a receiving track at the second end comprising a guard member and a hook-shaped lip member that form a pocket for receiving the engaging track of another slat. The guard member includes a portion of the sheet that is bent over on itself. The lip member extends from the guard member, and is spaced apart from the guard member to define an aperture that is sized and shaped to receive the engaging track of the other slat.

Classes IPC  ?

• E06B 9/00 - Écrans ou dispositifs de protection pour ouvertures, avec ou sans mécanismes de manœuvre ou de fixationFermetures de même structure
• E06B 9/02 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction
• E06B 9/08 - Fermetures du type à rouleau
• E06B 9/24 - Écrans ou autres dispositifs protecteurs contre la lumière, notamment contre la lumière solaireÉcrans similaires pour protection de l'intimité ou pour des raisons esthétiques
• E06B 9/26 - Stores à lamelles ou similaires, p. ex. stores vénitiens
• E06B 9/56 - Dispositions ou dispositifs de manœuvre, de guidage ou de verrouillage pour fermetures à rouleauTambours à ressortsTambours à rubanLeurs dispositions de contrepoids

Abrégé

A slat for a rolling shutter is provided that is formed as a single walled, continuous bent sheet. The slat includes a body having a hook-shaped engaging track at a first end, and a receiving track at the second end comprising a guard member and a hook-shaped lip member that form a pocket for receiving the engaging track of another slat. The guard member includes a portion of the sheet that is bent over on itself. The lip member extends from the guard member, and is spaced apart from the guard member to define an aperture that is sized and shaped to receive the engaging track of the other slat.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/386 - Détails des lamelles
• E06B 9/34 - Stores à lamelles ou similaires, p. ex. stores vénitiens à lamelles horizontales, p. ex. non levables du type à rouleau
• E06B 9/165 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues avec des lattes s'escamotant l'une dans l'autreVolets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues avec des lattes entre lesquelles la distance peut être modifiée

Produits et services

Metal roll shutters

Produits et services

Metal shutters for windows and doors; metal screens for windows and doors Non-metal shutters for windows and doors; non-metal screens and storm panels for windows and doors Display cases for merchandise; security cabinets Installation and repair of shutters, screens, overhead doors, doors, gates, and grilles

Abrégé

A slat for use in a rolling shutter is provided. The slat comprises a hooking track located at a first edge of a body and a receiving track located at a second edge of the body. Illustratively, the hooking track has a hook-shaped profile, and the receiving track comprises a lip member and a guard member defining a space adapted to receive therein an engaging track of an adjacent slat. The hooking track and the receiving track are designed to minimize the space required for the rolling shutter to be retracted around a spindle.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Abrégé

A slat for use in a rolling shutter is provided. The slat comprises a hooking track located at a first edge of a body and a receiving track located at a second edge of the body. Illustratively, the hooking track has a hook-shaped profile, and the receiving track comprises a lip member and a guard member defining a space adapted to receive therein an engaging track of an adjacent slat. The hooking track and the receiving track are designed to minimize the space required for the rolling shutter to be retracted around a spindle.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/171 - Rouleaux pour voletsFixation des volets à rouleau aux rouleaux
• E06B 9/58 - Dispositifs de guidage

Abrégé

A hinge assembly connecting adjacent panels of an accordion shutter includes a hinge member having a pair of curved arms and a pair of panel connection members each having a pivot shaft. The pivot shafts are received within the corresponding curved arms and retained for rotation therein with the tips of the curved arms received in arm receiving channels of the panel connection members. The adjacent panels may be oriented at an angle of less than 180° with respect to each other when both panel connection members are rotated to positions wherein the tips of curved arms are engaged by the closed ends of the arm receiving channels. The base of the hinge member also has a pair of shoulders, and the adjacent panels are oriented approximately parallel when the panel connection members are rotated to positions wherein the panel connection members are engaged by the shoulders.

Classes IPC  ?

• E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
• E05D 1/04 - Charnières ou gonds sans brochesÉléments remplaçant les charnières ou gonds avec pièce de guidage ayant la forme d'arcs de cercle
• E05D 3/12 - Charnières ou gonds à broches à plusieurs broches à deux broches parallèles et un bras
• E05D 15/12 - Suspensions pour battants pour battants coulissant horizontalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords

Abrégé

A hinge assembly connecting adjacent panels of an accordion shutter includes a hinge member having a pair of curved arms and a pair of panel connection members each having a pivot shaft. The pivot shafts are received within the corresponding curved arms and retained for rotation therein with the tips of the curved arms received in arm receiving channels of the panel connection members. The adjacent panels may be oriented at an angle of less than 180° with respect to each other when both panel connection members are rotated to positions wherein the tips of curved arms are engaged by the closed ends of the arm receiving channels. The base of the hinge member also has a pair of shoulders, and the adjacent panels are oriented approximately parallel when the panel connection members are rotated to positions wherein the panel connection members are engaged by the shoulders.

Classes IPC  ?

• E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon

Abrégé

A hinge assembly connecting adjacent panels of an accordion shutter includes a hinge member having a pair of curved arms and a pair of panel connection members each having a pivot shaft. The pivot shafts are received within the corresponding curved arms and retained for rotation therein with the tips of the curved arms received in arm receiving channels of the panel connection members. The adjacent panels may be oriented at an angle of less than 180° with respect to each other when both panel connection members are rotated to positions wherein the tips of curved arms are engaged by the closed ends of the arm receiving channels. The base of the hinge member also has a pair of shoulders, and the adjacent panels are oriented approximately parallel when the panel connection members are rotated to positions wherein the panel connection members are engaged by the shoulders.

Classes IPC  ?

• E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon

Abrégé

A slat for use in a rolling shutter is provided. The slat comprises a hooking track located at a first edge of a body and a receiving track located at a second edge of the body. Illustratively, the hooking track has a hook-shaped profile, and the receiving track comprises a lip member and a guard member defining a space adapted to receive therein an engaging track of an adjacent slat. The hooking track and the receiving track are designed to minimize the space required for the rolling shutter to be retracted around a spindle.

Classes IPC  ?

• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
• E06B 9/34 - Stores à lamelles ou similaires, p. ex. stores vénitiens à lamelles horizontales, p. ex. non levables du type à rouleau
• E06B 9/58 - Dispositifs de guidage
• E06B 9/00 - Écrans ou dispositifs de protection pour ouvertures, avec ou sans mécanismes de manœuvre ou de fixationFermetures de même structure

Abrégé

A slat for use in a rolling shutter is provided. The slat comprises a hooking track located at a first edge of a body and a receiving track located at a second edge of the body. Illustratively, the hooking track has a hook-shaped profile, and the receiving track comprises a lip member and a guard member defining a space adapted to receive therein an engaging track of an adjacent slat. The hooking track and the receiving track are designed to minimize the space required for the rolling shutter to be retracted around a spindle.

Classes IPC  ?

• E06B 3/12 - Structures dépendant de l'emploi de matériaux spécifiés en métal
• E06B 9/00 - Écrans ou dispositifs de protection pour ouvertures, avec ou sans mécanismes de manœuvre ou de fixationFermetures de même structure
• E06B 9/08 - Fermetures du type à rouleau

Abrégé

The present invention is directed to a rolling protective shutter having an improved stopping mechanism that prevents the shutter from completely rolling up onto the shutter support member, and that is hidden within the shutter housing or the side tracks. The stopping mechanism may include a limit switch operatively connected to a drive motor to detect a disposition of the base slat of the shutter curtain proximate the shutter housing. The limit switch may actuate to turn off the drive motor at an appropriate position to retain the base slat within the side tracks and to prevent damage to the shutter housing due to engagement by the base slat.

Classes IPC  ?

• E06B 9/70 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'extérieur du rouleau

Produits et services

Metal roll shutters

Produits et services

Metal shutters for windows and doors; Metal screens for windows and doors Non-metal shutters for windows and doors; Non-metal screens and storm panels for windows and doors Display cases for merchandise; security cabinets Installation and repair of shutters, screens, overhead doors, doors, gates, and grilles

Produits et services

Display cases for merchandise; Security cabinets

Abrégé

An improvement in a rolling shutter assembly for covering an opening of a structure having an external protective surface, an underlying support structure and a subsurface disposed therebetween. The rolling shutter assembly includes a shutter housing, a shutter support member rotatably disposed within the shutter housing, a shutter coupled to the shutter support member, and a pair of side tracks. The improvement includes a plurality of dowels and corresponding openings through the external protective surface configured to receive the dowels. The dowels are disposed between the subsurface of the wall and the side tracks when the rolling shutter assembly is installed to minimize the portion of the external protective surface that is removed to accommodate the installation of the shutter assembly.

Classes IPC  ?

• E06B 9/11 - Volets à rouleau
• E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation

Abrégé

An improvement in a rolling shutter assembly for covering an opening of a structure having an external protective surface, an underlying support structure and a subsurface disposed therebetween. The rolling shutter assembly includes a shutter housing, a shutter support member rotatably disposed within the shutter housing, a shutter coupled to the shutter support member, and a pair of side tracks. The improvement includes a plurality of dowels and corresponding openings through the external protective surface configured to receive the dowels. The dowels are disposed between the subsurface of the wall and the side tracks when the rolling shutter assembly is installed to minimize the portion of the external protective surface that is removed to accommodate the installation of the shutter assembly.

Classes IPC  ?

• E06B 9/08 - Fermetures du type à rouleau
• E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
• A47H 3/00 - Dispositifs d'attache, de fixation ou de guidage des rubans ou cordons de rideaux ou similaires

Abrégé

An end retention system for a rolling shutter system is provided. The end retention system comprises a fastener that has a head and a shaft, a washer and a spacer. The aperture of the washer is greater than that of the shaft. The shaft is configured for insertion into a shutter slat. A guide track is provided with retention fins spaced apart a distance that is less than the outer diameter of the washer. The guide may include a channel partially bounded by the retention fins and having a width that is greater than the outer diameter of the washer. The washer is located in the channel, and is retained near the slat by the head of and the fastener. An end retention system may have a rigid spacer, or a compressible spacer that is a resilient member located between the head of the fastener and the washer. An arrangement of rigid and compressible spacers in a curtain assembly allows the end retention systems in a curtain to have the same degree of horizontal slip, yet prevents the washers from interfering with one another when the curtain is in a rolled position.

Classes IPC  ?

• A62B 1/10 - Dispositifs pour faire descendre des personnes hors des bâtiments ou dans des situations analogues à l'aide de dispositifs de descente à câble avec mécanisme de freinage pour treuils ou poulies à action mécanique
• E06B 9/58 - Dispositifs de guidage
• E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues

Abrégé

An end retention system (3) for a rolling shutter system is provided. The end retention system (3) comprises a fastener (8) that has a head (21) and a shaft (12, 14), and a washer (9) that has an outer diameter and an aperture (11) having an inner diameter. The inner diameter of the aperture (1 1) of the washer (9) is at least twice the diameter of the shaft (12, 14) of the fastener (8). The shaft (12, 14) is configured for insertion into a screw boss receptacle (10) of a shutter slat (1). The end retention system (3) may also comprise a guide track (43) that has retention fins (46) spaced apart a distance (27) that is less than the outer diameter of the washer (9). The guide (43) may include a channel (48) that partially bounded by the retention fins (46). The channel (48) may have a width that is greater than the outer diameter of the washer (9). The washer (9) is located in the channel (48), and is retained near the slat (1) by the head (21) of the fastener (8).

Classes IPC  ?

• E06B 9/171 - Rouleaux pour voletsFixation des volets à rouleau aux rouleaux

Abrégé

An end retention system for a rolling shutter system is provided. The end retention system comprises a fastener that has a head and a shaft, and a washer that has an outer diameter and an aperture having an inner diameter. The inner diameter of the aperture of the washer is at least twice the diameter of the shaft of the fastener. The shaft is configured for insertion into a screw boss receptacle of a shutter slat. The end retention system may also comprise a guide track that has retention fins spaced apart a distance that is less than the outer diameter of the washer. The guide may include a channel that partially bounded by the retention fins. The channel may have a width that is greater than the outer diameter of the washer. The washer is located in the channel, and is retained near the slat by the head of the fastener.

Classes IPC  ?

• E06B 9/08 - Fermetures du type à rouleau

Abrégé

A removable power supply is provided for use with a motor of a shutter assembly. The removable power supply may include a base housing a battery, a shaft, and a flexible conductor coupled between the base and the shaft. The end of the shaft opposite of the flexible conductor has an electrical interface that is configured to supply power to the motor. The electrical interface is configured for removable coupling to the motor. The shaft may comprise a plurality of telescoping sections, or may be a unitary member. The telescoping sections may be a series of interlocking hallow tubes. The removable power supply may supply power to the motor, thereby allowing a shutter curtain of the assembly to be raised or lowered. Once the shutter curtain is at the desired position, the removable power supply may be removed from the shutter assembly.

Classes IPC  ?

• H02K 7/14 - Association structurelle à des charges mécaniques, p. ex. à des machines-outils portatives ou des ventilateurs
• H02J 7/00 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries
• E06B 9/32 - Dispositifs de manœuvre, de guidage ou de verrouillage

Produits et services

Metal roll shutters Non-metal roll shutters

Produits et services

metal rolling shutters for doors

Produits et services

metal rolling shutters for doors

Produits et services

non-metallic rolling windows and door shutters

Produits et services

metal rolling window shutters plastic poly vinyl rolling window shutters

Produits et services

rolling window shutters

Produits et services

rolling window shutters

Produits et services

rolling window shutters

Produits et services

SHADE AND SHUTTER DEVICE
