Abrégé

A method of operating a solenoid valve can include applying power to a coil of the solenoid valve, interrupting power to the coil upon a first increase in power consumption of the coil, detecting a first on-time when power is applied to the coil, re-applying power to the coil upon a first condition becoming satisfied, interrupting power to the coil upon a second increase in power consumption of the coil, detecting a second on-time when power is re-applied to the coil, comparing the first on-time with the second on-time, and detecting when an armature of the solenoid valve has physically shifted based at least in part on the comparing. Detecting when the armature of the solenoid valve has physically shifted can include determining that the second on-time is greater than the first on-time.

Classes IPC  ?

• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme
• H01F 7/06 - Électro-aimantsActionneurs comportant des électro-aimants
• H01F 7/08 - Électro-aimantsActionneurs comportant des électro-aimants avec armatures

Abrégé

A switch assembly for a valve actuator can include a bracket, a rotatable switch rotatably coupled to the bracket at an adjustable angle, a fixed switch fixedly mounted to the bracket, an arm rotatably coupled to the bracket, and an adjustable switch trigger coupled to the arm. The rotatable switch can be tripped by the valve actuator and a trip point of the rotatable switch can be calibrated by setting the adjustable angle. The fixed switch can be tripped by the switch trigger on the arm and a trip point of the fixed switch can be set by adjusting the switch trigger relative to the arm. The assembly can include a calibration fixture for calibrating the switch assembly to the valve actuator independently of the valve actuator.

Classes IPC  ?

• F16K 31/04 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un moteur
• F16K 31/52 - Moyens mécaniques d'actionnement à manivelle, excentrique ou came

Abrégé

A switch assembly for a valve actuator can include a bracket, a rotatable switch rotatably coupled to the bracket at an adjustable angle, a fixed switch fixedly mounted to the bracket, an arm rotatably coupled to the bracket, and an adjustable switch trigger coupled to the arm. The rotatable switch can be tripped by the valve actuator and a trip point of the rotatable switch can be calibrated by setting the adjustable angle. The fixed switch can be tripped by the switch trigger on the arm and a trip point of the fixed switch can be set by adjusting the switch trigger relative to the arm. The assembly can include a calibration fixture for calibrating the switch assembly to the valve actuator independently of the valve actuator.

Classes IPC  ?

• H01H 3/02 - Organes moteurs, c.-à-d. pour actionner le mécanisme d'entraînement par une force mécanique extérieure à l'interrupteur
• H01H 11/00 - Appareillages ou procédés spécialement adaptés à la fabrication d'interrupteurs électriques
• H01H 35/26 - Interrupteurs actionnés par le changement de pression du fluide, par les ondes de pression du fluide, ou par le changement d'écoulement du fluide Détails
• H01H 49/00 - Appareils ou procédés spécialement adaptés à la fabrication de relais ou d'éléments de relais

Abrégé

A switch assembly for a valve actuator can include a bracket, a rotatable switch rotatably coupled to the bracket at an adjustable angle, a fixed switch fixedly mounted to the bracket, an arm rotatably coupled to the bracket, and an adjustable switch trigger coupled to the arm. The rotatable switch can be tripped by the valve actuator and a trip point of the rotatable switch can be calibrated by setting the adjustable angle. The fixed switch can be tripped by the switch trigger on the arm and a trip point of the fixed switch can be set by adjusting the switch trigger relative to the arm. The assembly can include a calibration fixture for calibrating the switch assembly to the valve actuator independently of the valve actuator.

Classes IPC  ?

• F16K 31/04 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un moteur
• F16K 31/52 - Moyens mécaniques d'actionnement à manivelle, excentrique ou came

Abrégé

A silencing choke for a solenoid valve can include a base and a stem configured to be coupled to an armature and can be configured for at least partially reducing or eliminating noise caused by armature bounce. A choke can be configured for limiting maximum flow through an orifice during at least a portion of a valve transition, which can include creating a state of orifice limited flow during the occurrence of armature bounce. A choke can be configured for at least partially reducing cross flow among ports and for limiting a maximum flow rate through at least one flow path of a valve.

Classes IPC  ?

• F16K 11/24 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont plusieurs éléments de fermeture ne se déplacent pas comme un tout actionnés par des organes de commande distincts à soupape électromagnétique, p. ex. pour machines à laver
• F16K 47/02 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour empêcher les coups de bélier ou le bruit
• F16K 11/044 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des soupapes ou des clapets à corps de soupape ou de clapet mobiles situés entre des sièges de soupape ou de clapet
• F16K 47/16 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour diminuer la pression, l'organe régulateur étant distinct de l'élément de fermeture l'organe régulateur étant un cône
• F16K 11/22 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont plusieurs éléments de fermeture ne se déplacent pas comme un tout actionnés par des organes de commande distincts chacun étant propre à une soupape, p. ex. conjugués pour former clapet à voies multiples

Abrégé

A silencing choke for a solenoid valve can include a base and a stem configured to be coupled to an armature and can be configured for at least partially reducing or eliminating noise caused by armature bounce. A choke can be configured for limiting maximum flow through an orifice during at least a portion of a valve transition, which can include creating a state of orifice limited flow during the occurrence of armature bounce. A choke can be configured for at least partially reducing cross flow among ports and for limiting a maximum flow rate through at least one flow path of a valve.

Classes IPC  ?

• F16K 1/54 - Dispositifs pour modifier la façon dont le débit varie pendant le fonctionnement de la soupape
• F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• F16K 47/04 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour diminuer la pression, l'organe régulateur étant incorporé dans l'élément de fermeture

Abrégé

A solenoid valve can include a valve body and an actuator. The actuator can include an actuator housing, a coil disposed in the actuator housing and a core tube extending from the valve body through and beyond the actuator housing when the actuator is properly installed on the valve body. A monitoring assembly can include a target on the core tube and a detector configured to detect the target when the actuator is properly installed on the valve body and/or core tube.

Classes IPC  ?

• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

Abrégé

A solenoid valve can include a valve body and an actuator. The actuator can include an actuator housing, a coil disposed in the actuator housing and a core tube extending from the valve body through and beyond the actuator housing when the actuator is properly installed on the valve body. A monitoring assembly can include a target on the core tube and a detector configured to detect the target when the actuator is properly installed on the valve body and/or core tube.

Classes IPC  ?

• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme

Abrégé

A poppet assembly for a valve can include a valve stem for cooperating with a valve actuator, a first valve member (120) coupled to the valve stem (119) in a fixed position and configured to sealingly engage a first orifice (110a) and a second valve (121) member coupled to the valve stem and configured to sealingly engage a second orifice (110b). The second valve member can include a coupler (128) for coupling the second valve member to the valve stem and a seal (132) configured to couple to the coupler and the valve stem. The second valve member can be configured for achieving proper spacing between the valve members for simultaneous contact with their respective orifices without the need for more costly and time consuming components or assembly methods.

Classes IPC  ?

• F16K 1/44 - Détails du siège ou du corps de soupape pour les soupapes à double siège
• F16K 1/48 - Fixation des corps de soupapes aux tiges des soupapes

Abrégé

A poppet assembly for a valve can include a valve stem for cooperating with a valve actuator, a first valve member coupled to the valve stem in a fixed position and configured to sealingly engage a first orifice and a second valve member coupled to the valve stem and configured to sealingly engage a second orifice. The second valve member can include a coupler for coupling the second valve member to the valve stem and a seal configured to couple to the coupler and the valve stem. The second valve member can be configured for achieving proper spacing between the valve members for simultaneous contact with their respective orifices without the need for more costly and time consuming components or assembly methods.

Classes IPC  ?

• F16K 1/32 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation Détails
• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage

Abrégé

A module for a solenoid valve can include a body having a module inlet, a module outlet, a flow path fluidically between the inlet and the outlet, a module orifice and a module valve seat fluidically disposed in the flow path, a reservoir disposed within the body, a sensor in sensing communication with the reservoir, a first coupler configured to couple with a solenoid actuator and a second coupler configured to couple with a valve body. The flow path can include an inlet flow path from the module inlet to the module orifice and an outlet flow path from the module orifice to the module outlet. The reservoir can be in fluid communication with at least one of the inlet flow path and the outlet flow path. The module outlet can be disposed in fluid communication with the second coupler and configured to sealingly engage a valve seat.

Classes IPC  ?

• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage

Abrégé

A solenoid valve can include a valve body having an inlet and an outlet, a solenoid actuator and a module coupled to the valve body and the solenoid actuator. A module can include a module inlet disposed in fluid communication with the valve inlet, a module outlet disposed in fluid communication with the valve outlet, a module orifice and a module valve seat disposed along a module flow path fluidically between the module inlet and the module outlet and a sensor coupled to the module and disposed in sensing communication with the module flow path.

Classes IPC  ?

• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• G01L 19/14 - Boîtiers
• G01L 19/00 - Détails ou accessoires des appareils pour la mesure de la pression permanente ou quasi permanente d'un milieu fluent dans la mesure où ces détails ou accessoires ne sont pas particuliers à des types particuliers de manomètres

Abrégé

A valve can include a valve body having an inlet, an outlet, an orifice disposed fluidically between the inlet and the outlet, a fitting having a first end configured to be removably coupled with at least one of the inlet and the outlet of the valve body and a second end configured to be coupled to a fluid conduit, and a retainer configured to at least partially resist uncoupling of the fitting from the valve body. A fitting can be configured to slidingly and sealingly engage at least a portion of an inlet and/or outlet bore. A retainer can be configured to couple with a valve body and a fitting. A fitting can be or include a crimp or press fitting, in whole or in part.

Classes IPC  ?

• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• F01L 1/344 - Systèmes de distribution à soupapes, p. ex. à soupapes de levage caractérisés par des moyens de changer la période d'une soupape sans changer la durée de l'ouverture en modifiant la position angulaire relative entre le vilebrequin et l'arbre à came, p. ex. à l'aide d'un engrenage hélicoïdal
• H01F 7/16 - Armatures à mouvement rectiligne

Abrégé

A valve can include a valve body having an inlet, an outlet, an orifice disposed fluidically between the inlet and the outlet, a fitting having a first end configured to be removably coupled with at least one of the inlet and the outlet of the valve body and a second end configured to be coupled to a fluid conduit, and a retainer configured to at least partially resist uncoupling of the fitting from the valve body. A fitting can be configured to slidingly and sealingly engage at least a portion of an inlet and/or outlet bore. A retainer can be configured to couple with a valve body and a fitting. A fitting can be or include a crimp or press fitting, in whole or in part.

Classes IPC  ?

• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
• F16L 37/14 - Raccords par insertion d'un élément entre surfaces à unir, p. ex. par un bout de fil, une goupille, une chaîne

Abrégé

A solenoid valve (300), comprising a solenoid enclosure (302) having a conduit opening (304) configured to have wires (116) disposed there through; a solenoid coil (312) disposed at least partially within the solenoid enclosure (302); a valve body (102) coupled to the solenoid enclosure (302); and a test connection (100) coupled to the solenoid enclosure (302), wherein the test connection (100) comprises a body (102) removably coupled to the conduit opening (304); and a plurality of test leads (106) accomodated into the body (102); wherein each of the plurality of test leads has a first end (103A, 103B, 118A, 118B) connectable with the solenoid coil (312). A method of configuring a valve including providing one or more test connections coupled to the valve, testing the valve prior to final installation using the test connection, removing the test connection and permanently installing the valve.

Classes IPC  ?

• H01R 13/52 - Boîtiers protégés contre la poussière, les projections, les éclaboussures, l'eau ou les flammes
• F16K 31/02 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques
• H01R 13/74 - Montage des pièces de couplage dans les ouvertures d'un panneau

Abrégé

A test connection for a valve can include a plug configured to be removably coupled with a conduit opening, an electrical coupler coupled to the plug, and one or more test leads coupled to the electrical coupler. One or more test leads can be removably coupled with a solenoid coil or other valve component. A method of configuring a valve can include providing one or more test connections coupled to the valve, testing the valve prior to final installation using the test connection, removing the test connection and permanently installing the valve.

Classes IPC  ?

• G01M 3/40 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation de moyens électriques, p. ex. par observation de décharges électriques
• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme
• H01R 13/52 - Boîtiers protégés contre la poussière, les projections, les éclaboussures, l'eau ou les flammes

Abrégé

A valve can include a body having an inlet and an outlet coaxial about an axis, a stationary valve seat between the inlet and the outlet, one or more valve members slideably coupled to the valve body and adapted to optionally couple with the valve seat, one or more biasing devices adapted to bias the valve member(s) in one or more longitudinal directions, and one or more actuators adapted to optionally move the valve member(s) into and/or out of sealing engagement with the valve seat. An actuator assembly can include one or more of an electrohydraulic actuator and an electromechanical actuator, among others.

Classes IPC  ?

• F16K 1/44 - Détails du siège ou du corps de soupape pour les soupapes à double siège
• F16K 1/52 - Dispositifs pour le réglage additionnel du débit
• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• F16K 31/122 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un piston
• F16K 31/124 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un piston servo-commandé
• F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
• F16K 31/53 - Moyens mécaniques d'actionnement à engrenage
• F16K 31/42 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et au moyen d'organes actionnés électriquement dans les canalisations d'entrée ou de refoulement du moteur à fluide
• F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte

Abrégé

A valve can include a body having an inlet and an outlet coaxial about an axis, a stationary valve seat between the inlet and the outlet, one or more valve members slideably coupled to the valve body and adapted to optionally couple with the valve seat, one or more biasing devices adapted to bias the valve member(s) in one or more longitudinal directions, and one or more actuators adapted to optionally move the valve member(s) into and/or out of sealing engagement with the valve seat. An actuator assembly can include one or more of an electrohydraulic actuator and an electromechanical actuator, among others.

Classes IPC  ?

• F16K 31/02 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques
• F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte

Abrégé

A pinch valve (700) can include a finger guard (750) or tubing retainer for blocking at least a portion of a tube slot (114). A headpiece (710) for a pinch valve can include a tube slot for receiving tubing (112) and can be adapted to couple with a guard. A guard can include a base (752) and an extension (754) and can be removably coupled to a headpiece (710). The extension can be adapted to block at least a portion of a tube slot.

Classes IPC  ?

• F16K 31/122 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un piston
• F16K 7/04 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire dont l'étranglement est assuré par une force extérieure radiale
• F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme

Abrégé

A pinch valve can include a finger guard or tubing retainer for blocking at least a portion of a tube slot. A headpiece for a pinch valve can include a tube slot for receiving tubing and can be adapted to couple with a guard. A guard can include a base and an extension and can be removably coupled to a headpiece. The extension can be adapted to block at least a portion of a tube slot.

Classes IPC  ?

• F16K 7/06 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire dont l'étranglement est assuré par une force extérieure radiale par tige filetée, came ou autre moyen mécanique
• F16K 7/02 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire
• F16K 7/04 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire dont l'étranglement est assuré par une force extérieure radiale

Abrégé

A solenoid control circuit (100) makes measurements during operation to determine the state of a solenoid (L1) and provides for rapid re-energization of a solenoid (L1) upon detection of a dropout condition. A method of controlling the solenoid (L1) includes closing an input switch (Q2), cycling a low side switch (Q1) based on voltage drop across a resistor (R1), opening the input switch (Q2) after a time interval, closing the low side switch (Q1) and driving a discharge switch (Q3) to control the discharge current rate from an energy storage device (C1) to the solenoid (L1). The method can include determining a condition of the solenoid (L1) based on a time interval between actuation of comparators (CMP1, CMP2) and maintaining a level of energy in the energy storage device (C1) sufficient to cause the solenoid to produce a magnetic field for actuating a valve.

Classes IPC  ?

• H01F 7/18 - Circuits en vue d'obtenir des caractéristiques de fonctionnement souhaitées, p. ex. pour un fonctionnement lent, pour l'excitation successive des enroulements, pour l'excitation à grande vitesse des enroulements
• H02M 3/155 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu sans transformation intermédiaire en courant alternatif par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs
• H01H 47/04 - Circuits autres que ceux appropriés à une application particulière du relais et prévue pour obtenir une caractéristique de fonctionnement donnée ou pour assurer un courant d'excitation donné en vue de modifier le fonctionnement du relais en vue de retenir l'armature en position d'attraction, p. ex. avec un courant réduit ou interrompu

Abrégé

A solenoid control circuit can make measurements during operation to determine the state of a solenoid and can provide for rapid re-energization of a solenoid upon detection of a dropout condition. A method of controlling a solenoid can include closing an input switch, cycling a low side switch based on voltage drop across a resistor, opening the input switch after a time interval, closing the low side switch and driving a discharge switch to control the discharge current rate from an energy storage device to an inductor. The method can include determining a condition of the inductor based on a time interval between actuation of comparators and maintaining a level of energy in the energy storage device sufficient to cause the inductor to produce a magnetic field for actuating a valve.

Classes IPC  ?

• H01F 7/18 - Circuits en vue d'obtenir des caractéristiques de fonctionnement souhaitées, p. ex. pour un fonctionnement lent, pour l'excitation successive des enroulements, pour l'excitation à grande vitesse des enroulements
• H01H 47/04 - Circuits autres que ceux appropriés à une application particulière du relais et prévue pour obtenir une caractéristique de fonctionnement donnée ou pour assurer un courant d'excitation donné en vue de modifier le fonctionnement du relais en vue de retenir l'armature en position d'attraction, p. ex. avec un courant réduit ou interrompu
• H02M 3/155 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu sans transformation intermédiaire en courant alternatif par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs

Abrégé

A control module for a pinch valve can include a housing, a controller, a display, one or more indicators and one or more sensors, such as flow sensors, proximity sensors or tube sensors. A control module can support monitoring or operation of one or more pinch valves within a fluid control system. A pinch valve can include one or more control modules and a pinch valve system can include a plurality of pinch valves and a plurality of control modules. A method of controlling a pinch valve can include controlling fluid flow operations based on input from one or more sensors.

Classes IPC  ?

• F16K 7/07 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire dont l'étranglement est assuré par une force extérieure radiale par pression d'un fluide
• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme
• F16K 31/122 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un piston
• F16K 7/04 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire dont l'étranglement est assuré par une force extérieure radiale
• G05D 7/06 - Commande de débits caractérisée par l'utilisation de moyens électriques

Abrégé

Apparatus and method provide a solenoid coil having a field-replaceable status indicator light, such as an LED. The status indicator light lights up when power is supplied to the solenoid coil to indicate the coil is energized and turns off when the coil is no longer energized. This allows technicians and other personnel working in hazardous environments to easily and reliably monitor the operational status of the solenoid coil. An electrical splitter adapter splits power between the solenoid coil and the status indicator light. The splitter adapter allows the status indicator light to be removed without interrupting power to the solenoid coil. Where the power is AC power, a rectifier may be provided on the splitter adapter to convert the AC power to DC power.

Classes IPC  ?

• H01R 31/02 - Pièces intermédiaires pour la distribution d'énergie vers plusieurs circuits en parallèle, p. ex. fiche de dérivation
• H01F 7/06 - Électro-aimantsActionneurs comportant des électro-aimants
• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• G08B 21/18 - Alarmes de situation
• H01R 33/22 - Dispositifs à deux pôles pour culot du type à vis, p. ex. pour lampe
• H02M 7/04 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques

Abrégé

Apparatus and method provide a solenoid coil having a field-replaceable status indicator light, such as an LED. The status indicator light lights up when power is supplied to the solenoid coil to indicate the coil is energized and turns off when the coil is no longer energized. This allows technicians and other personnel working in hazardous environments to easily and reliably monitor the operational status of the solenoid coil. An electrical splitter adapter splits power between the solenoid coil and the status indicator light. The splitter adapter allows the status indicator light to be removed without interrupting power to the solenoid coil. Where the power is AC power, a rectifier may be provided on the splitter adapter to convert the AC power to DC power.

Classes IPC  ?

• H01R 33/22 - Dispositifs à deux pôles pour culot du type à vis, p. ex. pour lampe
• H01R 31/02 - Pièces intermédiaires pour la distribution d'énergie vers plusieurs circuits en parallèle, p. ex. fiche de dérivation
• H01F 7/06 - Électro-aimantsActionneurs comportant des électro-aimants
• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• G08B 21/18 - Alarmes de situation
• H02M 7/04 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques

Abrégé

A valve can include a rib for improving flow, which can include improving a flow rating of the valve and improving the structural integrity of the valve. A valve can include a valve body, one or more inlets for allowing flow into the body, one or more outlets for allowing flow out of the body, one or more flow paths, and one or more ribs for routing fluid in a flow path. A valve can include an orifice fluidically between an inlet and an outlet and one or more ribs disposed upstream and/or downstream of the orifice. A valve can include one or more ribs in an inlet flow path, an outlet flow path or another flow path and a rib can be coupled between two or more portions of a valve.

Classes IPC  ?

• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
• F16K 47/08 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour diminuer la pression, l'organe régulateur étant distinct de l'élément de fermeture
• F16K 1/52 - Dispositifs pour le réglage additionnel du débit

Abrégé

The present disclosure provides a high flow coefficient spool valve (50) through one or more changes in the flow path from a conventional spool valve. The body (56) of the spool valve includes spherically contoured internal grooves (68). The spool (58), slidably engaged inside the body (56), includes concave surfaces between seals (62) that is complementary to the spherically shaped internal grooves (68) of the body. The spherical shape of the body internal grooves (68) and/or concave shape of the spool allow more volume and more laminar flow therebetween, resulting in an increased flow coefficient and flow capacity. The body also is formed with transverse port windows in the port that contour into a bore of the body adjacent the spool. A choke volume in the flow is strategically designed in a parallel flow location rather than a perpendicular flow location to promote laminar flow and lessen turbulence to also increase the flow coefficient.

Classes IPC  ?

• F16K 11/07 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des tiroirs à éléments de fermeture glissant linéairement à glissières cylindriques
• F16K 25/02 - Dispositions utilisant la sortie de fluide des corps de soupapes ou de clapets ou de leurs sièges

Abrégé

The present disclosure provides a high flow coefficient spool valve (50) through one or more changes in the flow path from a conventional spool valve. The body (56) of the spool valve includes spherically contoured internal grooves (68). The spool (58), slidably engaged inside the body (56), includes concave surfaces between seals (62) that is complementary to the spherically shaped internal grooves (68) of the body. The spherical shape of the body internal grooves (68) and/or concave shape of the spool allow more volume and more laminar flow therebetween, resulting in an increased flow coefficient and flow capacity. The body also is formed with transverse port windows in the port that contour into a bore of the body adjacent the spool. A choke volume in the flow is strategically designed in a parallel flow location rather than a perpendicular flow location to promote laminar flow and lessen turbulence to also increase the flow coefficient.

Classes IPC  ?

• F16K 11/07 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des tiroirs à éléments de fermeture glissant linéairement à glissières cylindriques

Abrégé

Systems and methods of controlling a solenoid coil in a solenoid valve provide a controller that allows a supervisory or leakage current to be used in a peak-and-hold driver. The controller introduces a delay time after detection of a dropout voltage that prevents the solenoid coil from being immediately re-energized in order to ensure proper dropout of the solenoid coil. The delay time imposes a wait period during which the controller takes no action with respect to the current in the solenoid coil, allowing the solenoid coil to deenergize and return the valve to its normally-open or normally-closed position. Such use of a delay time may be limited to instances where the controller has already gone through a power-up cycle such that the response time needed by the controller to energize the solenoid coil is minimized, thus reducing the valve startup time.

Classes IPC  ?

• F02D 41/20 - Circuits de sortie, p. ex. pour la commande des courants dans les bobines de commande
• H01F 7/06 - Électro-aimantsActionneurs comportant des électro-aimants
• H01F 7/18 - Circuits en vue d'obtenir des caractéristiques de fonctionnement souhaitées, p. ex. pour un fonctionnement lent, pour l'excitation successive des enroulements, pour l'excitation à grande vitesse des enroulements
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

Abrégé

The present disclosure provides a solenoid valve and associated method of control for compensated performance based on environmental conditions and optionally product life. The solenoid coil power consumption is proactively optimized based on predetermined database information to cross reference a given operating temperature and optionally, valve operating cycles. The net effect is to reduce power consumption under normal conditions and selectively apply higher power to the valve coil when required.

Classes IPC  ?

• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage

Abrégé

The present disclosure provides a solenoid valve and associated method of control for compensated performance based on environmental conditions and optionally product life. The solenoid coil power consumption is proactively optimized based on predetermined database information to cross reference a given operating temperature and optionally, valve operating cycles. The net effect is to reduce power consumption under normal conditions and selectively apply higher power to the valve coil when required.

Classes IPC  ?

• G05D 7/06 - Commande de débits caractérisée par l'utilisation de moyens électriques
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

Abrégé

Systems and methods of controlling a solenoid coil in a solenoid valve provide a controller that allows a supervisory or leakage current to be used in a peak-and-hold driver. The controller introduces a delay time after detection of a dropout voltage that prevents the solenoid coil from being immediately re-energized in order to ensure proper dropout of the solenoid coil. The delay time imposes a wait period during which the controller takes no action with respect to the current in the solenoid coil, allowing the solenoid coil to deenergize and return the valve to its normally-open or normally-closed position. Such use of a delay time may be limited to instances where the controller has already gone through a power-up cycle such that the response time needed by the controller to energize the solenoid coil is minimized, thus reducing the valve startup time.

Classes IPC  ?

• H03K 17/28 - Modifications pour introduire un retard avant commutation
• H03K 17/687 - Commutation ou ouverture de porte électronique, c.-à-d. par d'autres moyens que la fermeture et l'ouverture de contacts caractérisée par l'utilisation de composants spécifiés par l'utilisation, comme éléments actifs, de dispositifs à semi-conducteurs les dispositifs étant des transistors à effet de champ

Abrégé

In a method for estimating a remaining lifetime of a solenoid coil of a valve controller operating in a process control system, a record of a duration of activation of the solenoid coil is maintained during operation of the solenoid coil. An operating temperature of the solenoid coil is determined. An estimate of the remaining lifetime of the solenoid coil is generated based on the duration of activation of the solenoid coil and the operating temperature of the solenoid coil.

Classes IPC  ?

• G08B 21/18 - Alarmes de situation
• G05B 23/02 - Test ou contrôle électrique
• G01R 31/00 - Dispositions pour tester les propriétés électriquesDispositions pour la localisation des pannes électriquesDispositions pour tests électriques caractérisées par ce qui est testé, non prévues ailleurs

Abrégé

A valve can include a rib for improving flow, which can include improving a flow rating of the valve and improving the structural integrity of the valve. A valve can include a valve body, one or more inlets for allowing flow into the body, one or more outlets for allowing flow out of the body, one or more flow paths, and one or more ribs for routing fluid in a flow path. A valve can include an orifice fluidicly between an inlet and an outlet and one or more ribs disposed upstream and/or downstream of the orifice. A valve can include one or more ribs in an inlet flow path, an outlet flow path or another flow path and a rib can be coupled between two or more portions of a valve.

Classes IPC  ?

• F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
• F16K 47/08 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour diminuer la pression, l'organe régulateur étant distinct de l'élément de fermeture
• F16K 1/52 - Dispositifs pour le réglage additionnel du débit
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

Produits et services

Catalog ordering services in the fields of valves and valve accessories; electronic catalog services in the fields of valves and valve accessories; mail order catalog services in the fields of valves and valve accessories; advertising by mail order; presentation of goods on communication media, for retail purposes; catalogues, mail order catalogues and online catalogues featuring valves, motion and fluid control products, control systems and air preparation components being retail services. Delivery of goods by mail order.

Abrégé

A solenoid coil assembly for hazardous environments comprises a solenoid coil and an enclosure entirely filled with encapsulation material. The encapsulation material leaves zero or almost zero volume in the enclosure for hazardous material to accumulate in any amount that could explode. This allows the solenoid coil assembly to be constructed without the usual industry standard flame paths. Additionally, the enclosure may be made of physically rigid and strong material such as metal or the like to better withstand harsh and corrosive conditions within hazardous environments without being explosion proof. The walls of such an enclosure need only have a moderate thickness and weight relative to enclosures that are explosion proof, as there is no meaningful risk of an explosion occurring within the enclosure. The combination of a rugged exterior and a zero-volume interior allows the solenoid coil assembly to reduce weight and cost while providing superior environmental protection.

Classes IPC  ?

• H01F 7/08 - Électro-aimantsActionneurs comportant des électro-aimants avec armatures
• H01F 7/12 - Électro-aimantsActionneurs comportant des électro-aimants avec armatures spécialement adaptés au courant alternatif comprenant des dispositifs anti-vibratoires
• H01F 41/00 - Appareils ou procédés spécialement adaptés à la fabrication ou à l'assemblage des aimants, des inductances ou des transformateursAppareils ou procédés spécialement adaptés à la fabrication des matériaux caractérisés par leurs propriétés magnétiques

Abrégé

A solenoid coil assembly for hazardous environments comprises a solenoid coil and an enclosure entirely filled with encapsulation material. The encapsulation material leaves zero or almost zero volume in the enclosure for hazardous material to accumulate in any amount that could explode. This allows the solenoid coil assembly to be constructed without the usual industry standard flame paths. Additionally, the enclosure may be made of physically rigid and strong material such as metal or the like to better withstand harsh and corrosive conditions within hazardous environments without being explosion proof. The walls of such an enclosure need only have a moderate thickness and weight relative to enclosures that are explosion proof, as there is no meaningful risk of an explosion occurring within the enclosure. The combination of a rugged exterior and a zero-volume interior allows the solenoid coil assembly to reduce weight and cost while providing superior environmental protection.

Classes IPC  ?

• H01F 7/128 - Encapsulation, mise sous enveloppe ou scellement
• H01F 7/08 - Électro-aimantsActionneurs comportant des électro-aimants avec armatures
• H01F 41/00 - Appareils ou procédés spécialement adaptés à la fabrication ou à l'assemblage des aimants, des inductances ou des transformateursAppareils ou procédés spécialement adaptés à la fabrication des matériaux caractérisés par leurs propriétés magnétiques
• H01F 7/127 - Assemblage

Abrégé

The present disclosure provides a method and system for measuring increase in wattage to detect a potential winding failure. The increase in watts in the winding occurs when a time-varying magnetic field from active turns of the winding induces a time-varying current on shorted turns of the winding. The resistance through the shorted turns and the induced current result in power usage and increased watts. The wattage increase is much greater than a resistance decrease in the winding by the shorted turns. Measuring the watts results in detecting a shorting winding with greater sensitivity than measuring the resistance. In one embodiment, the winding can be tested offline with a wattmeter and power supply. In another embodiment, the winding in use and its wattage can be monitored continuously or periodically locally or remotely, with an optional sensor to initiate a signal upon reaching a certain percentage increase in watts.

Classes IPC  ?

• G01R 31/06 - Essai de bobinage électrique, p.ex. pour déterminer la polarité

Abrégé

A connector element (100) is disclosed for coupling a first tubular element to a second tubular element, wherein the second tubular element is having an end configuration selected from a threaded end configuration and a non-threaded plain configuration. The connector element is having a threaded element (102) complementary to the threads of the threaded end configuration of the second tubular element, a tube lock (108) that is co-axially arranged with respect to and disposed downstream of the threaded element (102) for holding the second tubular element, and a guide element (104) that is co- axially arranged with respect to and disposed down-stream of the tube lock (108) for guiding the second tubular element.

Classes IPC  ?

• F16L 15/08 - Raccords avec filetageFormes des filetages pour ces raccords avec des éléments supplémentaires
• F16L 19/02 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé
• F16L 25/00 - Structure ou détails de raccords de tuyaux non prévus dans les groupes ou présentant in intérêt autre que celui visé par ces groupes
• F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts

Abrégé

A connector element is disclosed in accordance with one embodiment of the present disclosure. The connector element is for coupling a first tubular element to a second tubular element, wherein the second tubular element is having an end configuration selected from a threaded end configuration and a non-threaded plain configuration. The connector element is having a threaded element complementary to the threads of the threaded end configuration of the second tubular element, a tube lock that is co-axially arranged with respect to and disposed downstream of the threaded element for holding the second tubular element, and a guide element that is co-axially arranged with respect to and disposed down-stream of the tube lock for guiding the second tubular element.

Classes IPC  ?

• F16L 19/08 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord avec segments métalliques qui mordent dans la paroi du tuyau
• F16L 15/08 - Raccords avec filetageFormes des filetages pour ces raccords avec des éléments supplémentaires
• F16L 19/02 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé
• F16L 25/00 - Structure ou détails de raccords de tuyaux non prévus dans les groupes ou présentant in intérêt autre que celui visé par ces groupes
• F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts

Abrégé

A process control valve with a spring rate adjustment and a spring force adjustment, thereby accommodating tight spring tolerances, such as those encountered in low power and proportional applications. The spring rate and spring force may both be adjusted after the valve has been fully assembled, thereby reducing manufacturing costs.

Classes IPC  ?

• F16K 1/52 - Dispositifs pour le réglage additionnel du débit

Abrégé

A manifold (100) includes an inlet port (102) which defines a flow passage (122) and a plurality of outlet ports (104, 106, 108, 110, 112 and 114) positioned in linear sets on either side of the flow passage. Some of the plurality of outlet ports (108, 110, 112 and 114) in each set are provided with direct operative communication with the flow passage (122) by means of apertures. The ports in each set of outlet ports on either side of the flow channel are operatively connected by an auxiliary passage (128) for conveying the fluid between the outlet ports so as to reduce stagnation pressure zone and maintain uniform pressure distribution at each outlet port.

Classes IPC  ?

• F02C 7/228 - Division du fluide entre plusieurs brûleurs

Produits et services

(1) Catalog ordering services, electronic catalog ordering service and mail order catalog ordering services in the fields of manifolds, manifold blocks, regulators, namely, air regulators, pressure regulators, pilot regulators, manifold regulators, flow regulators, regulators [valves] of metal other than parts of machines; FRLs, namely, combination filters/regulators/lubricators; particulate filters, coalescing filters, lubricators, air bellows, cylinders (machine parts), air cylinders, gas cylinders, fluid actuated cylinders, piston rod assemblies, coils, namely, electromagnetic coils, electric coils, electromagnetic solenoids in the nature of coils, magnetic coils, electromagnetic coils and metal coils; fieldbus electronics, filter replacement elements, and valves, namely, solenoid valves, shut-off valves, water valves, steam valves, pressure valves, poppet valves, spool valves, sleeve valves, lockout valves, pneumatic valves, flow control valves, directional control valves, air pilot valves.

Abrégé

A valve assembly comprising an inlet port (112), an outlet port (114), and a diaphragm (116,122) configured to selectively allow communication between the inlet port and the outlet port, the diaphragm including a first side adjacent the ports and a second side opposed to the ports. The valve preferably includes at least one bleed path (130;138) between the first side and the second side of the diaphragm with a one way flow device (140;142) configured to allow flow from the first side to the second side of the diaphragm and prevent flow from the second side to the first side of the diaphragm. The valve may include a first bleed path (130) from the inlet port (112) to the second side of the diaphragm and a second bleed path (138) from the outlet port (114) to the second side of the diaphragm. Either bleed path, or both, comprise a check valve mounted in the diaphragm.

Classes IPC  ?

• F16K 31/40 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation avec un organe actionné électriquement dans la décharge du moteur

Abrégé

A method of sealing coil leads during encapsulation by placing a lead of a coil in a tube, such that there remains a gap between the lead and the tube; placing the coil in a mold such that the gap remains open to an environment surrounding the mold; and injecting encapsulation material into the closed mold in a liquid state under pressure, thereby causing the material to flow through the gap toward the environment. Injecting encapsulation material into the mold may be done at a rate, temperature, and/or environmental temperature to cause the material to solidify before passing through the gap into the environment. In any case, there is no need to seal the mold to the leads. Each lead of the coil may be placed into an individual tube and/or the tubes may be is formed within a single sleeve.

Classes IPC  ?

• B29C 45/14 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet en incorporant des parties ou des couches préformées, p. ex. moulage par injection autour d'inserts ou sur des objets à recouvrir
• H01F 27/32 - Isolation des bobines, des enroulements, ou de leurs éléments
• H01F 41/12 - Isolement d'enroulements

Abrégé

A method of sealing coil leads during encapsulation by placing a lead of a coil in a tube, such that there remains a gap between the lead and the tube; placing the coil in a mold such that the gap remains open to an environment surrounding the mold; and injecting encapsulation material into the closed mold in a liquid state under pressure, thereby causing the material to flow through the gap toward the environment. Injecting encapsulation material into the mold may be done at a rate, temperature, and/or environmental temperature to cause the material to solidify before passing through the gap into the environment. In any case, there is no need to seal the mold to the leads. Each lead of the coil may be placed into an individual tube and/or the tubes may be is formed within a single sleeve.

Classes IPC  ?

• B29C 45/14 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet en incorporant des parties ou des couches préformées, p. ex. moulage par injection autour d'inserts ou sur des objets à recouvrir
• H01F 41/04 - Appareils ou procédés spécialement adaptés à la fabrication ou à l'assemblage des aimants, des inductances ou des transformateursAppareils ou procédés spécialement adaptés à la fabrication des matériaux caractérisés par leurs propriétés magnétiques pour la fabrication de noyaux, bobines ou aimants pour la fabrication de bobines
• H01F 41/12 - Isolement d'enroulements
• H01F 41/10 - Raccord des connexions aux enroulements
• H01F 5/00 - Bobines d'induction

Abrégé

A method of assuring drop out of a valve assembly comprising detecting a level of a signal from the controller; diverting the signal to a solenoid coil of the valve assembly when the level of the signal is above a predetermined value; and diverting the signal to a load when the level of the signal is below the predetermined value. The level detector may divert the signal away from the coil when the level of the signal is below the predetermined value, thereby ensuring that the coil is fully de-energized in response to the level of the signal being below the predetermined value, while allowing current to flow through the valve assembly, thereby allowing the controller to monitor the integrity of the wiring between the controller and the valve assembly.

Classes IPC  ?

• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
• H01H 47/00 - Circuits autres que ceux appropriés à une application particulière du relais et prévue pour obtenir une caractéristique de fonctionnement donnée ou pour assurer un courant d'excitation donné
• F17D 3/00 - Dispositions pour la surveillance ou la commande des opérations de fonctionnement
• H01F 7/18 - Circuits en vue d'obtenir des caractéristiques de fonctionnement souhaitées, p. ex. pour un fonctionnement lent, pour l'excitation successive des enroulements, pour l'excitation à grande vitesse des enroulements

Abrégé

A method of assuring drop out of a valve assembly comprising detecting a level of a signal from the controller; diverting the signal to a solenoid coil of the valve assembly when the level of the signal is above a predetermined value; and diverting the signal to a load when the level of the signal is below the predetermined value. The level detector may divert the signal away from the coil when the level of the signal is below the predetermined value, thereby ensuring that the coil is fully de-energized in response to the level of the signal being below the predetermined value, while allowing current to flow through the valve assembly, thereby allowing the controller to monitor the integrity of the wiring between the controller and the valve assembly.

Classes IPC  ?

• H01F 7/18 - Circuits en vue d'obtenir des caractéristiques de fonctionnement souhaitées, p. ex. pour un fonctionnement lent, pour l'excitation successive des enroulements, pour l'excitation à grande vitesse des enroulements

Abrégé

A solenoid valve assembly including a process control valve plumbed within a hazardous environment; a solenoid coil mated to the valve and configured to operate the valve, the solenoid coil located within the hazardous environment; a valve coil configured to receive power and transfer that power to the solenoid coil, thereby operating the valve, the valve coil located within the hazardous environment; and a controller coil configured to transmit power to the valve coil, the controller coil located in the hazardous environment

Classes IPC  ?

• F16K 31/02 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

Abrégé

A solenoid valve assembly including a process control valve plumbed within a hazardous environment; a solenoid coil mated to the valve and configured to operate the valve, the solenoid coil located within the hazardous environment; a valve coil configured to receive power and transfer that power to the solenoid coil, thereby operating the valve, the valve coil located within the hazardous environment; and a controller coil configured to transmit power to the valve coil, the controller coil located in the hazardous environment.

Classes IPC  ?

• F16K 31/02 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques

Abrégé

A solenoid valve for use in a hazardous environment requiring a surface temperature of the valve to not exceed a cutoff temperature, the valve comprising coil configured to physically move an armature using an field generated by the coil; a thermal cutoff device having a fusing temperature above the cutoff temperature; and a heating resistor sized and configured to raise thermal cutoff device's temperature to the fusing temperature before the surface temperature exceeds the cutoff temperature. A method of constructing a solenoid valve for use in a hazardous environment requiring a surface temperature of the valve to not exceed a cutoff temperature, the method comprising the steps of: selecting a thermal cutoff device having a fusing temperature above the cutoff temperature; and selecting and configuring a heating resistor to raise thermal cutoff device's temperature to the fusing temperature before the surface temperature exceeds the cutoff temperature.

Classes IPC  ?

• H05B 1/02 - Dispositions de commutation automatique spécialement adaptées aux appareils de chauffage
• H01H 85/02 - Dispositifs de protection dans lesquels le courant circule à travers un organe en matière fusible et est interrompu par déplacement de la matière fusible lorsqu'il devient excessif Détails
• H01H 85/00 - Dispositifs de protection dans lesquels le courant circule à travers un organe en matière fusible et est interrompu par déplacement de la matière fusible lorsqu'il devient excessif
• H01F 7/06 - Électro-aimantsActionneurs comportant des électro-aimants
• H01H 37/32 - Éléments thermosensibles

Abrégé

The present disclosure is directed to systems and methods for controlling energy consumption in a system having a battery and including a controller and one or more solenoids. In accordance with the disclosure, the controller provides a controlling mechanism, such as a control algorithm, that will provide the necessary power to operate the one or more solenoids throughout the range of battery voltage in a manner that optimizes the voltage discharge from the battery and simultaneously maximizes battery life. Further power conservation measures are implemented by using a controller and an associated control algorithm to operate a solenoid throughout the range of battery voltage in a manner that places the discharge of the battery in reduced power consumption operating modes as the capacity of the battery is reduced.

Classes IPC  ?

• H01H 9/00 - Détails de dispositifs de commutation non couverts par
• H01H 47/00 - Circuits autres que ceux appropriés à une application particulière du relais et prévue pour obtenir une caractéristique de fonctionnement donnée ou pour assurer un courant d'excitation donné
• H01H 47/32 - Courant d'excitation fourni par un dispositif semi-conducteur
• H01H 51/30 - Relais électromagnétiques spécialement adaptés pour la commande par courant alternatif

Abrégé

A valve assembly having a valve body (12); at least one port (14) to receive tubing; and a collar group to secure the tubing to the port, wherein the collar group is selected from a first collar group configured to secure the tubing by flattening a washer (40), thereby driving teeth (46) of the washer into the tubing, and a second collar group having a smooth interior surface to which the tubing is bonded, wherein either the first or the second collar groups may be interchangeably threaded onto the port.

Classes IPC  ?

• F16L 19/10 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord avec segments métalliques qui mordent dans la paroi du tuyau le profil du segment étant déformé

Abrégé

A valve assembly having a valve body; at least one port to receive tubing; and a collar group to secure the tubing to the port, wherein the collar group is selected from a first collar group configured to secure the tubing by a flattening a washer, thereby driving teeth of the washer into the tubing, and a second collar group having a smooth interior surface to which the tubing is bonded, wherein either the first or the second collar groups may be interchangeably threaded onto the port.

Classes IPC  ?

• F16L 29/00 - Raccords comportant des moyens pour couper le courant de fluide
• F16L 19/10 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord avec segments métalliques qui mordent dans la paroi du tuyau le profil du segment étant déformé

Abrégé

An automatically adjusting control valve (10) comprises a valve body (12); a valve seat (16) within the valve body; a sealing disc (18) adjacent the valve seat when the valve is closed and offset from the valve seat when the valve is open; an armature (20) adjacent the sealing disc and operable to move the sealing disc linearly within the valve body; a biasing mechanism (22) which biases the armature toward a first position; and an actuation stem (18) configured to overcome the biasing mechanism and move the armature between the first position and a second position upon manual operation. The actuation stem may comprise a portion which engages the armature during movement between the first position and the second position. The portion may be configured to deform to accommodate manufacturing tolerances of the valve.

Classes IPC  ?

• F16K 31/524 - Moyens mécaniques d'actionnement à manivelle, excentrique ou came à came
• F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

Abrégé

An automatically adjusting control valve comprises a valve body; a valve seat within the valve body; a sealing disc adjacent the valve seat when the valve is closed and offset from the valve seat when the valve is open; an armature adjacent the sealing disc and operable to move the sealing disc linearly within the valve body; a biasing mechanism which biases the armature toward a first position; and an actuation stem configured to overcome the biasing mechanism and move the armature between the first position and a second position upon manual operation. The actuation stem may comprise a portion which engages the armature during movement between the first position and the second position The portion may be configured to deform to accommodate manufacturing tolerances of the valve.

Classes IPC  ?

• F16K 31/02 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques
• F16K 31/44 - Moyens mécaniques d'actionnement
• F16K 25/00 - Détails constitutifs relatifs au contact entre corps de soupapes ou de clapets et leurs sièges

Abrégé

A control valve comprising a plurality of interchangeable valve body modules, each module having a main valve cavity and a plurality of separate cross valve communication ports communicating; and at least one interchangeable gasket disposed between adjacent modules and configured to individually communicate the main valve cavity and the communication ports between adjacent valve body modules, wherein the gasket is further configured to selectively communicate between the main valve cavity and a selected one of the cross valve communication ports. In one embodiment, each valve body module further includes a passage communicating with the main valve cavity. In this case, the gasket may be configured to selectively communicate between the passage and the selected one of the cross valve communication ports, thereby selectively communicating between the main valve cavity and the selected one of the cross valve communication ports through the passage by selective orientation of the gasket.

Classes IPC  ?

• F16K 27/00 - Structures des logementsMatériaux utilisés à cet effet

Abrégé

A control valve (10) comprising a plurality of interchangeable valve body modules (12), each module having a main valve cavity (22) and a plurality of separate cross valve communication ports (26a-d) communicating; and at least one interchangeable gasket (14) disposed between adjacent modules and configured to individually communicate the main valve cavity and the communication ports between adjacent valve body modules, wherein the gasket is further configured to selectively communicate between the main valve cavity and a selected one of the cross valve communication ports. In one embodiment, each valve body module further includes a passage (30) communicating with the main valve cavity. In this case, the gasket may be configured to selectively communicate between the passage and the selected one of the cross valve communication ports, thereby selectively communicating between the main valve cavity and the selected one of the cross valve communication ports through the passage by selective orientation of the gasket.

Classes IPC  ?

• F16K 27/00 - Structures des logementsMatériaux utilisés à cet effet
• F15B 13/08 - Assemblages de distributeurs élémentaires utilisés chacun pour la commande d'un seul servomoteur

Abrégé

A system for indicating the status of a valve may include an encapsulation with electronic circuitry disposed at least partially therein, a communication sub-system, a sensor, an indicator and a power source. The encapsulation may be zero volume, and the indicator may include a color changing skin. A method of indicating the status of a valve may include providing a valve, providing a status indicating system, changing a status of the valve, sensing a status of the valve, and indicating a status of the valve. A method of encapsulating a status indicating system may include providing an encapsulant and coupling at least a portion of the system with the encapsulant.

Classes IPC  ?

• E03B 7/07 - Disposition des appareils, p. ex. filtres, commandes du débit, dispositifs de mesure, siphons ou valves, dans les réseaux de canalisations

Abrégé

A system for indicating the status of a valve may include an encapsulation with electronic circuitry disposed at least partially therein, a communication sub-system, a sensor, an indicator and a power source. The encapsulation may be zero volume, and the indicator may include a color changing skin. A method of indicating the status of a valve may include providing a valve, providing a status indicating system, changing a status of the valve, sensing a status of the valve, and indicating a status of the valve. A method of encapsulating a status indicating system may include providing an encapsulant and coupling at least a portion of the system with the encapsulant.

Classes IPC  ?

• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme

Abrégé

A low power solenoid control circuit including a power source in series with a sensing element and a first diode, an inductor to actuate a valve, an energy storage device to store and discharge energy into the inductor, diodes to control current flow, and switches and a controller to control the circuit. The circuit may be operated by closing a first switch, thereby allowing a source current to flow through an inductor; opening the first switch, thereby forcing a charge current to flow through an energy storage device utilizing the inductance of the inductor; repeating these steps until the energy storage device is sufficiently charged; and upon command, closing a second switch, thereby forcing a discharge current to flow from the energy storage device to the inductor causing the inductor to produce an actuating magnetic field thereby actuating a mechanical valve.

Classes IPC  ?

• H01H 9/00 - Détails de dispositifs de commutation non couverts par
• H01H 47/00 - Circuits autres que ceux appropriés à une application particulière du relais et prévue pour obtenir une caractéristique de fonctionnement donnée ou pour assurer un courant d'excitation donné
• H02H 3/08 - Circuits de protection de sécurité pour déconnexion automatique due directement à un changement indésirable des conditions électriques normales de travail avec ou sans reconnexion sensibles à une surcharge
• H02H 9/02 - Circuits de protection de sécurité pour limiter l'excès de courant ou de tension sans déconnexion sensibles à un excès de courant

Abrégé

A low power solenoid control circuit including a power source in series with a sensing element and a first diode, an inductor to actuate a valve, an energy storage device to store and discharge energy into the inductor, diodes to control current flow, and switches and a controller to control the circuit. The circuit may be operated by closing a first switch, thereby allowing a source current to flow through an inductor; opening the first switch, thereby forcing a charge current to flow through an energy storage device utilizing the inductance of the inductor; repeating these steps until the energy storage device is sufficiently charged; and upon command, closing a second switch, thereby forcing a discharge current to flow from the energy storage device to the inductor causing the inductor to produce an actuating magnetic field thereby actuating a mechanical valve.

Classes IPC  ?

• H02M 3/155 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu sans transformation intermédiaire en courant alternatif par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs

Abrégé

The present disclosure is directed to systems and methods for controlling energy consumption in a system having a battery and including a controller and one or more solenoids. In accordance with the disclosure, the controller provides a controlling mechanism, such as a control algorithm, that will provide the necessary power to operate the one or more solenoids throughout the range of battery voltage in a manner that optimizes the voltage discharge from the battery and simultaneously maximizes battery life. Further power conservation measures are implemented by using a controller and an associated control algorithm to operate a solenoid throughout the range of battery voltage in a manner that places the discharge of the battery in reduced power consumption operating modes as the capacity of the battery is reduced.

Classes IPC  ?

• H01H 9/00 - Détails de dispositifs de commutation non couverts par
• H01H 47/00 - Circuits autres que ceux appropriés à une application particulière du relais et prévue pour obtenir une caractéristique de fonctionnement donnée ou pour assurer un courant d'excitation donné
• H01H 47/32 - Courant d'excitation fourni par un dispositif semi-conducteur
• H01H 51/30 - Relais électromagnétiques spécialement adaptés pour la commande par courant alternatif

Abrégé

The present disclosure is directed to systems and methods for controlling energy consumption in a system having a battery and including a controller and one or more solenoids. In accordance with the disclosure, the controller provides a controlling mechanism, such as a control algorithm, that will provide the necessary power to operate the one or more solenoids throughout the range of battery voltage in a manner that optimizes the voltage discharge from the battery and simultaneously maximizes battery life. Further power conservation measures are implemented by using a controller and an associated control algorithm to operate a solenoid throughout the range of battery voltage in a manner that places the discharge of the battery in reduced power consumption operating modes as the capacity of the battery is reduced.

Classes IPC  ?

• H02J 1/04 - Systèmes d'alimentation en courant constant

Produits et services

(1) Valves, namely, solenoid valves, magnet operated valves, valve assemblies, drain valve assemblies, globe valve assemblies, dust collector valves, isolation valves, manual reset valves, pinch valves, valve monitoring systems, actuators, pilot valves, control valves, pulse valves and parts and fittings thereof.

Produits et services

(1) Angle valves of metal; automatic control valves of metal; check valves; exhaust valves; manual micro-valves; mechanical and pneumatic slide valves; mechanical and pneumatic spool valves; metal connectors; rotary switch valves; shutoff valves; valve fittings; solenoid valves of metal; motorized valves of metal; micro valves of metal; micro isolation valves of metal; micro-miniature solenoid valves of metal; micro pinch valves of metal; pneumatic valves of metal; air preparation valves of metal; water pipe valves of metal; air operated valves; angle valves; control pistons; dust-removing valves; gas valves; mechanically driven pistons; motorized valves; pilot generators; pneumatic control valves for machines, motors and engines; pneumatic poppet valves; pneumatic valves; pneumatically driven pistons; pneumatically operated valves; pressure valves; pressure-operated valves; pressure-regulating valves; valve actuators; automatic air operated valves; automatic and electric valves; automatic control valves; automatic valves; coils, namely solenoid valve coils; control valves, namely, solenoid operated hydraulic; electric valves for controlling the loss of fluids; electrically-operated valves for industrial use, and valve fittings therefor; electrohydraulic valves and actuators; electromagnetic valves; electronic and electro-magnetic control units, namely, pulse width modulators; electro-pneumatic poppet valves; electro-pneumatic spool valves; oil, water and contaminant filters for use with pneumatic components, valves and process piping; coalescent filters for use with valves and process piping; flow controls; fluid flow control valves; FRL assemblies; gas solenoid valves; gas valves and actuators; gas valves, pilot generators, igniters and adapters/fittings therefor; gas valves; gauges, namely, pressure gauges; isolation valves and parts, fittings and accessories therefor; junction boxes; lubricators, namely, lubricators for use with pneumatic tools, cylinders, motors, and valves; meters, namely, flow control meters for monitoring fluid flow; parts, fittings and accessories for valves, solenoid valves, fluid flow control valves, FRL assemblies, redundant control systems, valve monitoring systems, namely, valve/fittings/fittings for valves, junction boxes, filters, regulators, lubricators, gauges, FRL assemblies, exhaust valves, check valves; parts, fittings and accessories for valves, solenoid valves, isolation valves, pinch valves and valve manifolds, namely, valve fittings/fittings for valves, strainers, flow controls, junction boxes, filters, regulators, lubricators, gauges; pilot valves; pinch valves and parts, fittings and accessories therefor; pinch valves; position indicators; potentiometers; power operated valves for gas burners; pressure monitors; pressure sensors; process control pilot valves; regulators for air pressure control; regulators for fluid pressure control; safety valves; safety valves responsive to alterations in temperature, fluid or air pressure; shut off valves; solenoid operated valves; solenoid pilot valves; solenoid valves and valves for the control of fluid and gases and electrohydraulic actuators; solenoid valves; strainers for use with process piping; thermostatic valves; valve fittings/fittings for valves; valve manifolds and parts, fittings and accessories therefor; valve manifolds; valve monitoring systems comprising actuators, solenoid valves, network cards, junction boxes, connectors, potentiometers, field bus protocols, Reed switches; magnet and solenoid operated valves; magnet and solenoid operated valves for controlling fluid and fluid flow through conduits. (2) Manual angle valves of metal; manual butterfly valves of metal; manual check valves; manual exhaust valves; manual globe valves of metal; manual micro-valves of metal; mechanical slide valves of metal; mechanical spool valves of metal; mechanical micro-valves of metal; metal connectors; manual rotary switch valves; manual shutoff valves of metal; valve fittings for all of the aforesaid goods; manual valves of metal; manual water pipe valves of metal; all of the aforesaid goods composed of metal and not for plumbing; butterfly valves; valve cocks; control pistons for valves; hydraulic controls for valves; mechanically driven pistons for valves; motorized valves; gas pilot generators; electric pilot generators; pneumatic control valves for machines, motors and engines; pneumatic poppet valves; pneumatic valves; pneumatically driven pistons; pneumatically operated valves; pressure valves; speed regulating pistons for valves; pneumatic valve actuators; hydraulic valve actuators; valves as parts of machines; pneumatic flow control valves; machine parts, namely, filters for removing oil and contaminants from air preparation equipment, pneumatic tools, cylinders, motors, and valves, and parts and fittings therefor; pneumatic gas valve actuators; pneumatic slide valves; pneumatic spool valves; lubricators used in compressed air lines to atomize oil into aerosol form for injection into the air stream to extend the life of pneumatic tools, cylinders, motors, and valves; regulators being parts of machines; pneumatic gas valve actuators; machine parts, namely, FRL assemblies, namely, combination filters/regulators/lubricators, namely, units that allow for air filtration, pressure regulation, and air lubrication in one compact unit and parts and fittings therefor; all of the aforesaid goods used as parts of machines; electric actuators; electronic gas valve actuators; automatic air operated valves for the control of fluids; automatic and electric valves for the control of fluids; automatic control valves for the control of fluids; automatic valves; control valves, namely, solenoid operated hydraulic valves; electric valves for controlling the loss of fluids; electrical and electromagnetic regulators for controlling fluids; electrically-operated valves for industrial use, and valve fittings therefor; electrical and electronic controls comprising electrohydraulic valves and actuators for safeguarding power, data and communications networks, industrial processes and critical installations; electromagnetic driven pistons for valves; electromagnetic valves; electro-magnets; electro-pneumatic poppet valves; electro-pneumatic slide valves; electro-pneumatic spool valves; electro-pneumatic flow control valves; fluid flow control valves, namely, electric or electronic valves that regulate discharge under varying pressure conditions to control fluids and sense, regulate and control fluid level or fluid flow and emergency signal transmitters; gas solenoid valves; automatic gas valves and actuators; automatic gas valves, pilot generators, igniters and adapters/fittings therefor; pressure gauges; heating controls, namely, valve regulators, thermostats for heating of residential, commercial and industrial buildings; automatic isolation valves and parts and fittings therefor; jockey pump controllers; magnets for use in valve monitoring systems; manifold assemblies for use with valves; manifolds for use with valves; fieldbus communication network cards for use in valve monitoring systems; parts and fittings for automatic valves, solenoid valves, automatic fluid flow control valves, redundant control systems, valve monitoring systems comprising electrical connectors, electronic timers, junction boxes, fittings for solenoid, isolation and pinch valves, silicone tubing, tubing guides, strainers, flow controls, manifolds, manifold assemblies, filters, regulators, lubricators, gauges, key locks, exhaust valves, check valves, terminal coils, coils and terminals, field bus protocols; parts and fittings for automatic valves, solenoid valves, isolation valves, pinch valves and valve manifolds, flow controls, electronic timers, junction boxes, manifolds, manifold assemblies, gauges and field bus protocols; electronic pilot generators, burners and igniters; adaptors and fittings for electronic pilot generators, burners and igniters; automatic pilot valves; automatic pinch valves and parts and fittings therefor; pistons for valves; position indicators for indicating the current position of a valve; potentiometers; electrical valves for gas burners; pressure monitors; pressure sensors; pressure switches; automatic process control pilot valves; rectifiers; redundant control systems, namely, a pilot valve system comprising redundant logic solvers, keyed bypass components, pressure switches, alarms and signaling means, solenoid valves, block valves, bypass switches, system controllers, digital outputs, isolation valves, and onboard diagnostic processors; automatic regulators for air and temperature regulation; voltage regulators; control valves for regulating the flow or the pressure of gases and liquids, namely, pneumatic regulators; electronic and electric relays; safety valves for incorporation in a fuel line and adapted to close and shut off the supply of fuel in response to excessive temperature; safety valves responsive to alterations in temperature, fluid or air pressure; self-recycling valves adapted to be interconnected so that they operate sequentially in response to a series of air pressure signals; automatic shut down panels; automatic shut off valves; solenoid operated valves; solenoid pilot valves; solenoid valves and valves for the control of fluid and gases and electrohydraulic actuators; solenoid valves; automatic switches; thermocouplers and parts therefor; thermocouples; thermostatic valves; thermostats; transformers; electrical transmitters; valve fittings for automatic valves; automatic valve manifolds and parts and fittings therefor sold together as a unit; air operated valves for controlling fluids; automatic angle valves; automatic depositing valves; automatic dust-removing valves; automatic glove valves; automatic motorized valves; automatic pressure-operated valves; automatic pressure-regulating valves; valves for mechanical use, namely, valves automatically operated by magnetic force and solenoid operated valves; heating control apparatus for cooking apparatus, namely, thermostats and temperature regulators; gas burners and adapters and fittings therefor; electric burners and adapters and fittings therefor; strainers for pipelines; strainers for water lines; tap water faucets; water regulators, namely, metered valves. (3) Butterfly valves of metal; globe valves of metal; mechanical micro-valves; butterfly valves; depositing valves; glove valves; hydraulic controls; speed regulating pistons; accessories for temperature-dependent monitoring and control devices for gas heating apparatus, namely temperature sensors, and acoustical signaling devices; actuators; alarm panels; current monitors; electrical and electromagnetic regulators; electromagnetic driven pistons; electro-magnets; electronic timers; electro-pneumatic slide valves; industrial controls comprising duplex controllers; interface modules; jockey pump controllers; key locks; magnets for use in valve monitoring systems; manifold assemblies; manifolds; parts, fittings and accessories for valves, solenoid valves, fluid flow control valves, FRL assemblies, valve monitoring systems, namely, silicone tubing, tubing guides, electrical connectors, strainers, flow controls, electronic timers, manifolds, manifold assemblies, key locks, terminal coils, coils and terminals, field bus protocols; parts, fittings and accessories for valves, solenoid valves, isolation valves, pinch valves and valve manifolds, namely, silicone tubing, tubing guides, electronic timers, manifolds, manifold assemblies, and key locks, field bus protocols; pilot generators, burners, igniters and adapters/fittings; pistons; pressure switches; propulsion accessories for fluids; range controls; rectifiers; redundant control systems, namely, a pilot valve system comprising redundant logic solvers; keyed bypass components, pressure switches, alarms and signalling means, solenoid valves, block valves, bypass switches, system controllers, digital outputs, isolation valves, and outboard diagnostic processors; relays; self-recycling valves; shut down panels; silicone tubing; thermocouplers and parts therefor; thermocouplers; thermostats; engine generators; electrical transmitters; tubing guides. (1) Distributorship services in the field of valves.

Produits et services

Valves, namely, solenoid valves, magnet operated valves, valve assemblies, drain valve assemblies, globe valve assemblies, dust collector valves, isolation valves, manual reset valves, pinch valves, valve monitoring systems, actuators, pilot valves, control valves, pulse valves and parts, fittings and accessories therefor.

Produits et services

Electro-magnetic and electronic controls, magnet and solenoid operated switches, relays and valves.

Produits et services

Electric and electro-magnetic controls and electronic control equipment; automatic electric switches, valves, magnet and solenoid operated switches and relays.

Produits et services

(1) Safety valve for incorporation in a fuel line and adapted to close and shut off the supply of fuel in response to excessive temperature, valves operable by fluidic and higher pressure air signals, self-recycling valves adapted to be interconnected so that they operate sequentially in response to a series of air pressure signals, and an actuator including a diaphragm for moving a stem in response to pneumatic or hydraulic signals.

Produits et services

(1) Safety valve for incorporation in a fuel line and adapted to close and shut off the supply of fuel in response to excessive temperature, valves operable by fluidic and higher pressure air signals, self-recycling valves adapted to be interconnected so that they operate sequentially in response to a series of air pressure signals, and an actuator including a diaphragm for moving a stem in response to pneumatic or hydraulic signals.

Produits et services

(1) Magnet and solenoid operated valves for controlling fluid flow through conduits. (2) Electromagnetic and electronic controls for industrial applications.

Produits et services

(1) Automatic electrical switches, magnet and solenoid operated switches and relays, and electronic control equipment, all for industrial use.

Produits et services

(1) Magnet or solenoid operated valves for controlling fluid flow through conduits.

Produits et services

(1) Magnet or solenoid operated valves for controlling fluid flow through conduits.
