Abrégé

A fastening system for fastening an article to a heating hose, a corresponding heating hose and an application system having a corresponding fastening system. The fastening system is provided for a holder of the fastening system to be fastened magnetically to an end cap of the heating hose.

Classes IPC  ?

• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• H01F 7/02 - Aimants permanents

Abrégé

An application system for applying a flowable medium, in particular a hot melt adhesive, to a substrate, and a heating hose for supplying a flowable medium to an application device for applying the flowable medium to a substrate. In the application system, the application device and the heating hose are coupled detachably to one another via a connection piece, wherein the connection piece has a receiving section for a filter insert.

Classes IPC  ?

• B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
• B01D 29/11 - Filtres à éléments filtrants stationnaires pendant la filtration, p.ex. filtres à aspiration ou à pression, non couverts par les groupes ; Leurs éléments filtrants avec des éléments filtrants en forme de sac, de cage, de tuyau, de tube, de manchon ou analogue
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

A heated hose for passage of a free-flowing medium, for example for the passage of a hot-melt adhesive. The heated hose has an angled attachment piece, wherein the attachment piece has a first limb and, angled with respect to the first limb, a second limb, wherein the attachment piece has a through-channel which runs through the limbs to allow the free-flowing medium to pass through the attachment piece, and wherein the attachment piece has a coupling connector for producing a fluidic connection between the heated hose and an external apparatus, by coupling the external apparatus along a coupling axis of the coupling connector.

Classes IPC  ?

• F16L 43/02 - Coudes; Siphons adaptés pour être utilisés avec des moyens de blocage particuliers
• B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• F16L 37/084 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique
• F16L 53/35 - Chauffage par résistance ohmique

Abrégé

A double-action piston pump of an application system for applying a fluid medium to a substrate, wherein the piston pump has a piston which is movable between a first reversal point and a second reversal point for delivering the fluid medium, wherein on reaching the first reversal point and the second reversal point, the movement direction of the piston is reversed, wherein during an output period, the fluid medium is output by means of an output device, and during an interruption period, an output of the fluid medium by means of the output device is interrupted, wherein during the interruption period, the movement direction of the piston is reversed, wherein on reversal of the movement direction during the interruption period, the piston is situated at an intermediate position between the first reversal point and the second reversal point.

Classes IPC  ?

• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• F04B 9/133 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p.ex. de la vapeur ou de l'air avec plusieurs chambres de pompage avec deux organes de pompage liés mécaniquement le mouvement alternatif des organes de pompage étant obtenu par un moteur à double effet à fluide compressible
• F04B 49/06 - Commande utilisant l'électricité

Abrégé

A sealing arrangement having a rod seal for sealing a cavity for a flowable medium in the region of a rod includes an output apparatus for discharging the flowable medium. The rod is movably supported in a housing to be displaced in an axial direction. The housing has a bearing portion, wherein the rod seal is supported in a fixed manner and wherein the rod extends through the bearing portion and the rod seal so that a first rod portion and a second rod portion are arranged at different sides of the bearing portion. The first rod portion is located at a side facing the cavity and the second rod portion is located at a side facing away from the cavity. The rod seal is arranged at the side of the bearing portion facing the first rod portion and has a first sealing lip and a second sealing lip that are spaced apart from each other in the axial direction and circumferentially contact the rod. The bearing portion facing the cavity has a discharge structure having a support face which circumferentially surrounds the rod. The rod seal is in abutment with the support face and the support face has a diameter which increases in the direction of the second rod portion.

Classes IPC  ?

• F16J 15/3236 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p.ex. joints toriques avec au moins une lèvre ayant plusieurs lèvres dont au moins une lèvre pour chaque surface, p.ex. conditionnements en U

Produits et services

Melting apparatus in the nature of machine tools for melting adhesives; Melting apparatus in the nature of machine tools for coating melting materials; Machines for melting thermoplastic materials; Machines for melting adhesives; Machines for melting coating materials

Abrégé

A melter for preparing a molten medium, in particular for preparing a molten adhesive, has a melting tank that has a melting chamber for receiving and melting a medium to be melted. The melter has a heating device for heating the melting chamber. The melting chamber has an upper chamber section and a lower chamber section. The melting tank has a dispensing opening that can be fluidly connected to a delivery device for delivering the molten medium. The melting tank further has a drain opening. The dispensing opening and the drain opening open into the lower chamber section. The melter further has a closure body for closing the drain opening. In a closed position, the closure body closes the drain opening and an end section of the closure body projects into the lower chamber section.

Classes IPC  ?

• B29B 13/02 - Conditionnement ou traitement physique de la matière à façonner par chauffage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B29K 105/00 - Présentation, forme ou état de la matière moulée

Produits et services

Melting apparatus for adhesives or coating materials; Machines for melting thermoplastic materials; Machines for melting adhesives, Machines for melting coating materials.

Abrégé

A melter for preparing a molten medium, in particular for preparing a molten adhesive, has a housing and a melting tank formed within the housing. The melter further has a filling opening for introducing the medium to be melted. The melter further has a wall section which encircles the filling opening. The melter further has an insulating body which encircles the filling opening and covers the wall section. The insulating body is elastically deformable for use in such a melter.

Classes IPC  ?

• B29B 13/02 - Conditionnement ou traitement physique de la matière à façonner par chauffage
• F27D 5/00 - Supports, grilles ou appareillage analogue pour la charge à l'intérieur du four
• B32B 37/12 - Procédés ou dispositifs pour la stratification, p.ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par l'usage d'adhésifs

Abrégé

A method for operating a double-action piston pump of an application system for applying a fluid medium to a substrate, wherein the piston pump has a piston which is movable between a first reversal point and a second reversal point for delivering the fluid medium, wherein on reaching the first reversal point and the second reversal point, the movement direction of the piston is reversed, wherein during an output period, the fluid medium is output by means of an output device, and during an interruption period, an output of the fluid medium by means of the output device is interrupted, wherein during the interruption period, the movement direction of the piston is reversed, wherein on reversal of the movement direction during the interruption period, the piston is situated at an intermediate position between the first reversal point and the second reversal point.

Classes IPC  ?

• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• F04B 9/133 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p.ex. de la vapeur ou de l'air avec plusieurs chambres de pompage avec deux organes de pompage liés mécaniquement le mouvement alternatif des organes de pompage étant obtenu par un moteur à double effet à fluide compressible
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• F04B 49/06 - Commande utilisant l'électricité

Abrégé

A heated hose for delivering a liquid, in particular for delivering an adhesive has a flexible hose for the passage of the liquid, an insulating layer surrounding the flexible hose, and a heating device surrounding the flexible hose. The heating device is arranged between the flexible hose and the insulating layer. The insulating layer has a strip-shaped insulating material that is wound helically around the flexible hose. The strip-shaped insulating material contains an aerogel.

Classes IPC  ?

• F16L 59/02 - Forme ou configuration de matériaux isolants, avec ou sans revêtement formant un tout avec les matériaux isolants
• F16L 53/34 - Chauffage des tuyaux ou des systèmes de tuyaux en utilisant des champs électriques, magnétiques ou électromagnétiques, p.ex. chauffage par induction, diélectrique ou par micro-ondes
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide

Produits et services

Machines and machine parts for processing glues or coating materials; machines and machine parts for dispensing adhesives; machines and machine parts for applying coating materials; apparatus for heating adhesive or coating materials; apparatus for melting adhesive or coating materials; apparatus for transporting adhesive or coating materials; apparatus for melting and transporting adhesive or coating materials; application heads for adhesive or coating materials; heating pipes as machine components; taping [tying] machines other than for office use; tape binders for books other than office use; gluing machines; edge gluing machines; connecting machines; labelers; glue guns; control apparatus as machine components. Sensors, detectors and monitoring instruments for controlling the application of an adhesive or coating material; sensors, detectors and monitoring instruments for controlling the consumption of adhesives or coating materials; software for monitoring, analyzing, controlling machines and machine parts for processing glues or coating materials; testing and quality control devices. Engineering and consultation services, all concerning the use and treatment of adhesives or coating materials.

Produits et services

Machines and structural machine parts thereof for processing glues or coating materials; apparatus in the nature of machines for heating adhesive or coating materials; apparatus in the nature of machines for melting adhesive or coating materials; apparatus in the nature of machines for transporting adhesive or coating materials; apparatus in the nature of machines for melting and transporting adhesive or coating materials; machine components, namely, applicator heads for electrically driven, pneumatically driven, electro-pneumatically driven and hydraulically driven machines for applying hot-melt glues and dispersion adhesives; machine components and accessories for gluing with hot-melts, namely, heated hoses; taping and tying machines other than for office use; tape binder machines for books other than office use; plywood gluing machines; edge gluing machines; labelers in the nature of automatic industrial labeling machines for applying labels to containers and bottles; hot-melt glue guns; control apparatus in the nature of electronic controllers of machines for processing glues, dispensing adhesives or applying coatings as machine components Electronic sensors, detectors and monitoring instruments in the nature of gauges used for controlling the application of adhesives or coating materials applied by application machinery; electronic sensors, detectors and monitoring instruments in the nature of gauges used for controlling the consumption of adhesives or coating materials applied by application machinery; downloadable and recorded software for monitoring, analyzing and controlling machines and machine parts for processing glues or coating materials; testing and operating quality control devices in the nature of gauges Engineering and consultation services in the field of engineering, all concerning the use and treatment of adhesives or coating materials

Abrégé

A device and method for dispensing a flowable medium has a housing with an interior space and a rod mounted in the housing that is movable between a first end position and a second end position and passes through a diaphragm mounted in a sealed manner in the housing radially on the outside and in the rod radially on the inside. The diaphragm divides the interior space into a first cavity and a second cavity separated from the first cavity in a fluid tight manner. The flowable medium can flow through at least one channel that opens into the first cavity, and is dispensed through a dispensing opening. A sealing section of the rod closes the dispensing opening in the first end position and is at a distance from the dispensing opening in the second end position. A pressure medium acts on the diaphragm in the second cavity.

Classes IPC  ?

• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B29B 13/02 - Conditionnement ou traitement physique de la matière à façonner par chauffage
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• F16K 41/12 - Joints d'étanchéité pour tiges avec un diaphragme, p.ex. en forme de soufflet ou de tube le diaphragme étant sensiblement plat
• F16K 1/00 - Soupapes ou clapets, c. à d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation
• F16K 1/32 - Soupapes ou clapets, c. à d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation - Détails

Abrégé

A device for dispensing a flowable medium, includes a housing having a cavity for receiving the flowable medium, a rod mounted in a bearing section of the housing, wherein the rod is movable by means of an actuator between a first end position and a second end position in an axial direction, a dispensing opening, opening into the cavity, for dispensing the flowable medium, wherein the rod has a sealing section, wherein the sealing section closes the dispensing opening in the first end position and is arranged at a distance from the dispensing opening in the second end position, a bellows seal for sealing off the bearing section from the cavity, wherein the rod passes through the bellows seal, wherein the bellows seal is mounted in a sealed manner on the rod and in a sealed manner on the housing, wherein a first section of the bellows seal is connected to the rod in a manner fixed relative to the rod, and a second section of the bellows seal is connected to the housing in a manner fixed relative to the housing, wherein the bellows seal has at least one compensating section for compensating an axial compression or extension of the bellows seal, wherein the compensating section projects radially relative to adjoining regions of the bellows seal, and having at least one channel, opening into the cavity, through which the flowable medium can flow into the cavity, wherein a projection of a center line of a channel section of the at least one channel, said channel section opening into the cavity, onto a projection plane formed perpendicularly to the axial direction forms a circle tangent of a circle formed concentrically with the rod.

Classes IPC  ?

• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B29B 13/02 - Conditionnement ou traitement physique de la matière à façonner par chauffage

Abrégé

A delivery unit for dispensing adhesive having a housing, a melting apparatus arranged within the housing for melting the adhesive, a distributing device for dispensing molten adhesive in at least one line connectable to the distributing device, and a pump for conveying the molten adhesive through the distributing device, wherein the housing has a plurality of outer side faces, two of the outer side faces are of a flat configuration and arranged perpendicular to a support plane of the delivery unit on a base and substantially at a right angle to each other, and wherein the distributing device, in a region in which the line is connectable to a connector of the distributing device, has a boundary surface of a flat configuration. The two outer side faces are arranged at a distance apart with the boundary surface therebetween forming an obtuse angle with each of the two outer side faces.

Classes IPC  ?

• B05B 9/00 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs
• B05B 9/01 - Pistolets pulvérisateurs
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide

Produits et services

Machines and parts of machines for processing adhesives or coating materials; Machines and parts of machines for dispensing adhesives; Machines and parts of machines for applying coating materials; Apparatus for heating adhesives or coating materials; Apparatus for melting adhesives or coating materials; Apparatus for conveying adhesives or coating materials; Apparatus for melting and conveying adhesives or coating materials; Application heads for applying adhesives or coating materials; Heating hoses being parts of machines; Taping [tying] machines other than for office use; Spine taping machines, other than for office use; Gluing machines; Edge banding machines; Splicing machines; Labellers [machines]; Glue guns; Control apparatus for all the aforesaid goods, included in this class; Parts and accessories for all the aforesaid goods, included in this class. Technical planning and consultancy relating to the use and processing of adhesives or coating materials.

Abrégé

A device for intermittently applying a flowable substance to a substrate includes an applicator nozzle for applying the flowable substance to the substrate, a tank for holding the flowable substance, a pump for delivering the substance, wherein the pump is actively connected to the tank, and further including an actuator actively connected to the pump and transferred into two positions, in a first position the actuator conducts the substance to the applicator nozzle, and in a second position the actuator blocks the feed to the applicator nozzle, and further including a control device for activating the actuator and for regulating the speed of the pump. A method for applying the substance using the device is also provided.

Classes IPC  ?

• B05B 12/08 - Aménagements de commande de la distribution; Aménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible
• B05D 5/10 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces pour obtenir des effets, finis ou des structures de surface particuliers pour obtenir une surface adhésive
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B42C 9/00 - Application de colle ou d'adhésif particulier à la reliure
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B05B 9/04 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs caractérisés par les moyens d'alimentation en liquide ou en autre matériau fluide comportant une pompe

Abrégé

A device for applying a flowable substance to at least one substrate includes an applicator nozzle in the form of a slotted nozzle which has a stationary nozzle body with an inlet opening, a flow duct, and a nozzle slot, wherein the flowable substance is delivered through the applicator nozzle and passes from the inlet opening into the flow duct and from there to the nozzle slot, and is discharged through an outlet opening of the nozzle slot that is arranged in an outer region of the nozzle body, wherein the applicator nozzle further has a slide valve movable relative to the nozzle body in the longitudinal extent of the outlet opening and contacts the outer region of the nozzle body for modifying the covering of the outlet opening. The longitudinal extent of the flow duct is at least as great as the longitudinal extent of the nozzle slot.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B42C 9/00 - Application de colle ou d'adhésif particulier à la reliure
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide

Produits et services

Apparatus and machines for applying hot-melts and dispersion adhesives; apparatus for applying hot-melts; machine components for drum kettles; machine components, in particular applicator heads for hot-melts and dispersion adhesives; electronically operated applicator heads for gluing with dispersion adhesives; electro-pneumatic operated applicator heads for gluing with hot-melts; machine parts for gluing with polyurethane (PUR) adhesives; machine components and accessories for gluing with hot-melts, in particular application units, applicator heads, modules, nozzles, hoses, heating apparatus, pumps and sensors; glue application systems for rotary printing machines, including application systems for hot-melts and dispersion adhesives, machines for gluing book spines and bindings; machine components, in particular for coating heads for coating surfaces with hot-melts; machine components, in particular modular coating heads in installations for coating hot-melts and dispersion adhesives; machine components, in particular for hot-melt and polyurethane (PUR) kettles; machine components for gluing with hot-melts, including polyurethane (PUR) and dispersion adhesives in the wood processing industry; machine components, in particular for gluing machines with hot-melts, in particular profile coating machines, edge gluing machines, apparatus for repairing wood; machine components, in particular for applying glue onto cardboard, corrugated cardboard and plastic; machine components, in particular for gluing with hot-melts for labeling packaging; machine components, in particular for the preparation and application of sealing and insulating materials. Hand-operated adhesive application systems with hot-melts, in particular manual applicators. Electronic controls for machines and apparatus for the preparation of hot-melts and dispersion adhesives; apparatus for setting and monitoring the preparation of hot-melts and dispersion adhesives, in particular electronic controls for glue application and glue monitoring, sensors for monitoring glue, optical components and systems for quality control and assurance.

Produits et services

Electronic publications, including downloadable ones. Printed promotional material; advertising pamphlets; printing products (printed matter). Publication of printed matter for advertising purposes; publication of advertising material online; promotion, advertising and marketing of websites online; organization of fairs, exhibitions and presentations for commercial or advertising purposes.

Produits et services

(1) Adhesive application systems, namely hotmelt and dispersion adhesives applicator machines; Application machines for applicating hot melt adhesives and dispersion adhesives; Adhesive melter; Drum unloaders; Machine components, namely application heads for the processing of hot melt, dispersion adhesives and reactive hot melt adhesives (PUR); Electronically controlled application heads for the processing of hot melt, dispersion adhesives and reactive hot melt adhesives (PUR); Electro pneumatic application heads for the processing of hot melt, dispersion adhesives and reactive hot melt adhesives (PUR); Manual application systems for the processing of hot melt adhesives, namely hot melt glue guns; Hotmelt application machine components, namely applicators, application heads for the processing of hotmelt, dispensing modules, cold glue hoses, heated hoses, heaters and pumps; Gluing systems for rotary printing machines comprising hotmelt and coldglue application machines; Machines for coating book spines; Machine components, namely coating heads for hot melt adhesive; Machine components, namely modular coating heads for hot melt adhesives and dispersion adhesives; Machine components for gluing machines for industrial use in the wood processing industry, namely, application heads, coating heads; Machine components for hot melt adhesive processing machines, in particular profile wrapping machines, edge banding machines, wood repair systems; Machine components for the application of adhesives and liquids to cardboards, corrugated cardboards and plastics, namely applicators, application heads for the processing of adhesives and liquids; Machine components for machines for the processing and application of sealants and insulating materials, namely applicators, application heads for the processing of sealants and insulating materials, dispensing modules, hoses, heated hoses, heaters and pumps (2) Electronic controllers for machines and components for the processing of hot melt adhesives and dispersion adhesives; Equipment for the parameterization and monitoring of the processing of hot melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring; Temperature sensors for adhesive monitoring; Quality control devices for quality monitoring and quality assurance, namely optical systems and components for measuring adhesive quality parameters and adhesive application quality parameters comprising cameras, photodetectors, optical sensors and infrared sensors

Produits et services

(1) Adhesive application systems, namely hotmelt and dispersion adhesives applicator machines; Application machines for applicating hot melt adhesives and dispersion adhesives; Adhesive melter; Drum unloaders; Machine components, namely application heads for the processing of hot melt, dispersion adhesives and reactive hot melt adhesives (PUR); Electronically controlled application heads for the processing of hot melt, dispersion adhesives and reactive hot melt adhesives (PUR); Electro pneumatic application heads for the processing of hot melt, dispersion adhesives and reactive hot melt adhesives (PUR); Manual application systems for the processing of hot melt adhesives, namely hot melt glue guns; Hotmelt application machine components, namely applicators, application heads for the processing of hotmelt, dispensing modules, cold glue hoses, heated hoses, heaters and pumps; Gluing systems for rotary printing machines comprising hotmelt and coldglue application machines; Machines for coating book spines; Machine components, namely coating heads for hot melt adhesive; Machine components, namely modular coating heads for hot melt adhesives and dispersion adhesives; Machine components for gluing machines for industrial use in the wood processing industry, namely, application heads, coating heads; Machine components for hot melt adhesive processing machines, in particular profile wrapping machines, edge banding machines, wood repair systems; Machine components for the application of adhesives and liquids to cardboards, corrugated cardboards and plastics, namely applicators, application heads for the processing of adhesives and liquids; Machine components for machines for the processing and application of sealants and insulating materials, namely applicators, application heads for the processing of sealants and insulating materials, dispensing modules, hoses, heated hoses, heaters and pumps (2) Electronic controllers for machines and components for the processing of hot melt adhesives and dispersion adhesives; Equipment for the parameterization and monitoring of the processing of hot melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring; Temperature sensors for adhesive monitoring; Quality control devices for quality monitoring and quality assurance, namely optical systems and components for measuring adhesive quality parameters and adhesive application quality parameters comprising cameras, photodetectors, optical sensors and infrared sensors

Abrégé

A slotted nozzle for discharging a liquid adhesive to a narrow edge of a substrate includes a nozzle body, a nozzle slot formed in the nozzle body, a passage in the nozzle body for supplying the adhesive to the nozzle slot, and a slot-shaped outlet opening of the nozzle slot. The nozzle body is configured in the region of averted ends of the nozzle slot that are based on the longitudinal extent of the nozzle slot in such a manner that an increased outlet of the adhesive through the outlet opening takes place in the region of the averted ends of the nozzle slot.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B05C 11/08 - Etalement du liquide ou d'un autre matériau fluide par manipulation de la pièce traitée, p.ex. par inclinaison
• B05D 1/32 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces en utilisant des moyens pour protéger des parties de surface à ne pas recouvrir, p.ex. en se servant de stencils, d'enduits de protection

Produits et services

Apparatus and machines for applying hot-melts and dispersion adhesives; apparatus for applying hot-melts; machine components for drum kettles; machine components, in particular applicator heads for hot-melts and dispersion adhesives; electronic-operated applicator heads for gluing with dispersion adhesives; electro-pneumatic operated applicator heads for gluing with hot-melts; machine parts for gluing with polyurethane adhesives (PUR); machine components and accessories for gluing with hot-melts, in particular application units, applicator heads, hoses, nozzles, modules, sensors, pumps and heating apparatus; glue application systems for rotary printing machines, including application systems for hot-melts and dispersion adhesives, machines for gluing book spines and bindings; machine components, in particular for coating heads for coating surfaces with hot-melts; machine components, in particular modular coating heads in installations for coating hot-melts and dispersion adhesives; machine components, in particular for hot-melt and polyurethane kettles (PUR); machine components for gluing with hot-melts, including polyurethane (PUR) and dispersion adhesives in the wood processing industry; machine components, in particular for gluing machines with hot-melts, in particular profile coating machines, edge gluing machines, apparatus for repairing wood; machine components, in particular for applying glue onto cardboard, corrugated cardboard and plastic; machine components, in particular for gluing with hot-melts for labeling packaging; machine components, in particular for the preparation and application of sealing and insulating materials Hand-operated adhesive application systems with hot-melts, in particular manual applicators Electronic controls for machines and apparatus for the preparation of hot-melts and dispersion adhesives; apparatus for setting and monitoring the preparation of hot-melts and dispersion adhesives, in particular electronic controls for applying glue and glue monitoring, sensors for controlling glue, optical components and systems for quality control and assurance

Produits et services

Apparatus and machines, namely, electrically driven, pneumatically driven, electro-pneumatically driven and hydraulically driven machines for applying hot-melt glues and dispersion adhesives; electric, pneumatic, electro-pneumatic and hydraulic machines for applying hot-melt glues and adhesives; machine components for drum melters in the nature of electric, pneumatic, electro-pneumatic and hydraulic machines for applying hot-melt glues and adhesives; machine components, in particular, applicator heads for electric, pneumatic, electro-pneumatic and hydraulic machines for applying hot-melt glues and dispersion adhesives; electronically operated applicator heads for gluing with dispersion adhesives in the nature of applicator heads for hot-melt glue and adhesive guns; electro-pneumatic operated applicator heads for gluing with hot-melts in the nature of applicator heads for gluing for use with hot-melt glue and adhesive guns; machine parts, in particular, applicator heads for gluing with polyurethane (PUR) adhesives for electric, pneumatic, electro-pneumatic and hydraulic machines for applying hot-melt glues and adhesives; machine components and accessories for gluing with hot-melts, in particular application units, applicator heads, modules, nozzles, hoses, heating apparatus, pumps and sensors for hot-melt glue and adhesive guns; glue application systems for rotary printing machines, namely, electric, pneumatic, electro-pneumatic and hydraulic application machines for applying hot-melt glues and dispersion adhesives, and machines for gluing book spines and bindings; machine components, in particular, applicator heads for coating surfaces with hot-melt glues and adhesives for electric, pneumatic, electro-pneumatic and hydraulic machines for applying hot-melt glues and adhesives; machine components, in particular, modular coating heads for applicator heads for coating hot-melt glues and dispersion adhesives for electric, pneumatic, electro-pneumatic and hydraulic machines for applying hot-melt glues and adhesives; machine components, in particular, drum melters for hot-melt glues and polyurethane (PUR) adhesives for electric, pneumatic, electro-pneumatic and hydraulic machines for applying hot-melt glues and adhesives; machine components for hot-melt gluing machines in the nature of applicator heads for the application of hot-melt glues and adhesives for gluing with hot-melt glues, polyurethane (PUR) adhesives and dispersion adhesives in the wood processing industry; machine components, in particular, machine components for wood profile coating, machine components for wood edge gluing, and machine components for repairing wood, all for use with hot-melt gluing machines; machine components, in particular, machine components for applying glue onto cardboard, corrugated cardboard and plastic for use with hot-melt gluing machines; machine components, in particular, machine components for applying hot-melt glues and adhesives for labeling packaging for use with hot-melt gluing machines; machine components, in particular machine components for applying hot-melt glues and adhesives for use with hot-melt gluing machines used in the preparation and application of sealing and insulating materials Non-electric manual applicators in the nature of hand tools for applying hot melt glues and adhesives Electronic control systems for machines and apparatus for the application of hot-melt glues and dispersion adhesives; apparatus for setting and monitoring the application of hot-melt glues and dispersion adhesives, in particular electronic control systems for glue application and glue monitoring, electronic sensors for monitoring glue, and optical components in the nature of optical transmitters and receivers for quality control and assurance

Produits et services

Electronic publications, including downloadable publications. Promotional publications; Advertising pamphlets; Printed matter. Publication of printed matter for advertising purposes; Publication of publicity materials on-line; Promotion, advertising and marketing of on-line websites; Organization of exhibitions, trade fairs, and marketing events for commercial or advertising purposes.

Produits et services

Application apparatus and machines for hot-melt and dispersion adhesives; Application apparatus for hot-melt adhesives; Machine components for drum melters; Machine components, namely application heads for the processing of hot-melt and dispersion adhesives; Electronically controlled application heads for the processing of dispersion adhesives; Electro-pneumatically controlled application heads for the processing of hot-melt adhesives; Manual application systems for the processing of hot-melt adhesives, namely manual applicators (electric hand tools); Machine components for the processing of PUR adhesives; Components and fittings for hot-melt processing machines, in particular applicators, Application heads, Modules, Nozzles, Hoses, Heating units and Pumps [machines]; Adhesive application systems for rotary printing machines containing hot-melt adhesive and dispersion adhesive application systems, machines for gluing book spines and bookbinding; Machine components, namely coating heads for flat hot-melt adhesive coatings; Machine components, namely modular coating heads in coating installations for hot-melt adhesives and dispersion adhesives; Machine components for PUR hot-melt adhesive melting apparatus; Machine components for the processing of hot-melt adhesives, including PUR and dispersion adhesives in the wood-processing industry; Machine components for hot-melt adhesive processing machines, in particular profile sheathing machines, edge gluing machines, wood repair systems; Machine components for the application of adhesives to cardboard, corrugated cardboard and plastics; Machine components for the processing of hot-melt adhesives in the field of the labelling of containers; Machine components for the processing and application of sealants and insulating materials. Electronic controllers for machines and apparatus for the processing of hot-melt adhesives and dispersion adhesives; Apparatus for parameterisation and monitoring of the processing of hot-melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring, sensors, including sensors for adhesive monitoring; Optical systems and components for quality monitoring and quality assurance.

Produits et services

Application apparatus and machines for hot-melt and dispersion adhesives; Application apparatus for hot-melt adhesives; Machine components for drum melters; Machine components, namely application heads for the processing of hot-melt and dispersion adhesives; Electronically controlled application heads for the processing of dispersion adhesives; Electro-pneumatically controlled application heads for the processing of hot-melt adhesives; Manual application systems for the processing of hot-melt adhesives, namely manual applicators (electric hand tools); Machine components for the processing of PUR adhesives; Components and fittings for hot-melt processing machines, in particular applicators, Application heads, Modules, Nozzles, Hoses, Heating units and Pumps [machines]; Adhesive application systems for rotary printing machines containing hot-melt adhesive and dispersion adhesive application systems, machines for gluing book spines and bookbinding; Machine components, namely coating heads for flat hot-melt adhesive coatings; Machine components, namely modular coating heads in coating installations for hot-melt adhesives and dispersion adhesives; Machine components for PUR hot-melt adhesive melting apparatus; Machine components for the processing of hot-melt adhesives, including PUR and dispersion adhesives in the wood-processing industry; Machine components for hot-melt adhesive processing machines, in particular profile sheathing machines, edge gluing machines, wood repair systems; Machine components for the application of adhesives to cardboard, corrugated cardboard and plastics; Machine components for the processing of hot-melt adhesives in the field of the labelling of containers; Machine components for the processing and application of sealants and insulating materials. Electronic controllers for machines and apparatus for the processing of hot-melt adhesives and dispersion adhesives; Apparatus for parameterisation and monitoring of the processing of hot-melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring, sensors, including sensors for adhesive monitoring; Optical systems and components for quality monitoring and quality assurance.

Produits et services

Application apparatus and machines for hot-melt and dispersion adhesives; Application apparatus for hot-melt adhesives; Machine components for drum melters; Machine components, namely application heads for the processing of hot-melt and dispersion adhesives; Electronically controlled application heads for the processing of dispersion adhesives; Electro-pneumatically controlled application heads for the processing of hot-melt adhesives; Manual application systems for the processing of hot-melt adhesives, namely manual applicators (electric hand tools); Machine components for the processing of PUR adhesives; Components and fittings for hot-melt processing machines, in particular applicators, Application heads, Modules, Nozzles, Hoses, Heating units and Pumps [machines]; Adhesive application systems for rotary printing machines containing hot-melt adhesive and dispersion adhesive application systems, machines for gluing book spines and bookbinding; Machine components, namely coating heads for flat hot-melt adhesive coatings; Machine components, namely modular coating heads in coating installations for hot-melt adhesives and dispersion adhesives; Machine components for PUR hot-melt adhesive melting apparatus; Machine components for the processing of hot-melt adhesives, including PUR and dispersion adhesives in the wood-processing industry; Machine components for hot-melt adhesive processing machines, in particular profile sheathing machines, edge gluing machines, wood repair systems; Machine components for the application of adhesives to cardboard, corrugated cardboard and plastics; Machine components for the processing of hot-melt adhesives in the field of the labelling of containers; Machine components for the processing and application of sealants and insulating materials. Electronic controllers for machines and apparatus for the processing of hot-melt adhesives and dispersion adhesives; Apparatus for parameterisation and monitoring of the processing of hot-melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring, sensors, including sensors for adhesive monitoring; Optical systems and components for quality monitoring and quality assurance.

Abrégé

A device for melting adhesive having a melting grill that has a multiplicity of passage openings, and heating elements, wherein the melting grill is heatable by the heating elements and melted adhesive heated by the hot melting grill is dischargeable through the passage openings, the melting grill on that side thereof that faces the adhesive to be melted having ribs. The melting grill has rotatable rods that are disposed beside one another and ribs that are disposed on the rods, the rods and the ribs being heatable by the heating elements, wherein ribs of adjacent rods are aligned so as to be directed toward one another, and the passage cross sections of the passage openings between the rods are modifiable by rotating rods of the melting grill. The device enables varied forms of delivery of solid adhesive to be melted at a high specific melting rate without the adhesive thereby being subjected to damage due to excessive thermal stress.

Classes IPC  ?

• H05B 3/64 - Chauffage par résistance ohmique Éléments de chauffage spécialement adaptés aux fours utilisant des rubans, des tiges ou des fils chauffants
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B29B 13/02 - Conditionnement ou traitement physique de la matière à façonner par chauffage

Abrégé

A device for applying adhesive to a substrate, having an application roller that is rotatable about an axis, an installation for dispensing adhesive to a circumferential area of the application roller, a dispensing region of the application roller for dispensing adhesive from the application roller, and having a doctor blade, wherein the dispensing region for adhesive in the rotation direction of the application roller is located behind the installation for dispensing the adhesive to the application roller and ahead of the doctor blade. In such a device it is provided that the application roller is rotatable about a vertical axis and the excess adhesive wiped by the doctor blade reaches a collection installation that is located below the doctor blade. In a method for applying adhesive to a substrate, excess adhesive that has not been applied to the substrate is disposed of.

Classes IPC  ?

• C09J 5/00 - Procédés de collage en général; Procédés de collage non prévus ailleurs, p.ex. relatifs aux amorces
• B05D 1/28 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par transfert de liquides ou d'autres matériaux fluides, à partir de la surface d'éléments porteurs, p.ex. de pinceaux, tampons, rouleaux
• B05C 1/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est appliqué à la surface de l'ouvrage par contact avec un élément portant le liquide ou autre matériau fluide, p.ex. un élément poreux imprégné du liquide à appliquer sous forme de revê
• B05C 1/08 - Appareillages dans lesquels un liquide ou autre matériau fluide est appliqué à la surface de l'ouvrage par contact avec un élément portant le liquide ou autre matériau fluide, p.ex. un élément poreux imprégné du liquide à appliquer sous forme de revê pour appliquer un liquide ou autre matériau fluide à un ouvrage de longueur indéfinie en utilisant un rouleau
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide
• B27G 11/02 - Récipients à colle; Appareils pour réchauffer ou chauffer la colle
• B27D 5/00 - Travail du placage ou du contre-plaqué par d'autres opérations spécialement adaptées au placage ou au contre-plaqué

Abrégé

The invention relates to a device for conveying a fine-particle medium, in particular a granulate, including a flexible receptacle for receiving the medium, a receiving fixture for fastening of the receptacle in the region of an upper end facing away from a base of the receptacle, and a suction apparatus, inserted from above into the receptacle, for sucking the medium out of the receptacle. The device further includes outside the receptacle, in its base region or its lateral region, an apparatus for acting on the receptacle for the purpose of its deformation. The device ensures that feed interruptions during the conveyance of the fine-particle medium are avoided so that the medium is kept in a conveyable state, whereby an undisturbed automated feed of the medium is secured.

Classes IPC  ?

• B65G 53/40 - Dispositifs d'alimentation ou de décharge
• B65D 88/54 - Grands réceptacles caractérisés par des moyens pour faciliter le remplissage ou le vidage
• B05B 7/14 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p.ex. un liquide et de l'air, une poudre et un gaz agencés pour projeter des matériaux en particules
• B65G 53/42 - Ajutages
• B65G 65/40 - Dispositifs pour vider autrement que par le haut
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide

Produits et services

Apparatus and machines for applying hot-melts and dispersion adhesives; apparatus for applying hot-melts; machine components for drum kettles; machine components, in particular applicator heads for hot-melts and dispersion adhesives; electronically operated applicator heads for gluing with dispersion adhesives; electro-pneumatic operated applicator heads for gluing with hot-melts; machine parts for gluing with polyurethane (PUR) adhesives; machine components and accessories for gluing with hot-melts, in particular application units, applicator heads, modules, nozzles, hoses, heating apparatus, pumps and sensors; glue application systems for rotary printing machines, including application systems for hot-melts and dispersion adhesives, machines for gluing book spines and bindings; machine components, in particular for coating heads for coating surfaces with hot-melts; machine components, in particular modular coating heads in installations for coating hot-melts and dispersion adhesives; machine components, in particular for hot-melt and polyurethane (PUR) kettles; machine components for gluing with hot-melts, including polyurethane (PUR) and dispersion adhesives in the wood processing industry; machine components, in particular for gluing machines with hot-melts, in particular profile coating machines, edge gluing machines, apparatus for repairing wood; machine components, in particular for applying glue onto cardboard, corrugated cardboard and plastic; machine components, in particular for gluing with hot-melts for labeling packaging; machine components, in particular for the preparation and application of sealing and insulating materials, hand-operated application systems for gluing with hot-melts, in particular hand-operated applicators (electric hand tools). Electronic controls for machines and apparatus for the preparation of hot-melts and dispersion adhesives; apparatus for setting and monitoring the preparation of hot-melts and dispersion adhesives, in particular electronic controls for glue application and glue monitoring, sensors for monitoring glue, optical components and systems for quality control and assurance.

Abrégé

An apparatus for dispensing flowable substances, having a nozzle having an exit opening for dispensing the substances from the nozzle, and a closure part movable by a control element, disposed outside of the nozzle, and configured to release the exit opening and close the exit opening, in the region of a closure part surface that faces the nozzle end. The closure part surface is delimited, in the movement direction of the closure part from the open position to the closed position, by a leading edge, in the leading direction. The closure part surface is disposed next to the nozzle and at a level upstream from the exit opening, with reference to the flow direction of the substances through the nozzle, in the open position. The closure part can be moved from the open position to the closed position by the control element, such that the leading edge of the closure part surface is moved past the free nozzle end.

Classes IPC  ?

• B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression - Détails
• B65D 83/28 - Buses, leurs moyens de support ou leurs accessoires spécialement adaptés à cet effet
• F16K 23/00 - Clapets pour empêcher le dégouttement des buses
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05B 15/02 - Systèmes ou dispositifs pour nettoyer des orifices d'évacuation
• B01J 4/00 - Dispositifs d'alimentation; Dispositifs de commande d'alimentation ou d'évacuation
• B65D 83/34 - Nettoyage ou prévention de l'obstruction de l'orifice de sortie
• B05B 1/32 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p.ex. à l'aide de conduits de section réglable dans lesquels un élément de valve fait partie de l'orifice de sortie
• B67D 3/00 - Appareils ou dispositifs pour commander le débit du liquide à distribuer par gravité à partir des récipients de stockage

Abrégé

An apparatus for dispensing flowable substances, having a nozzle having an exit opening for dispensing the substances from the nozzle in the region of a free nozzle end, and a closure part that can be moved by means of a control element, disposed outside of the nozzle. The closure part releases the exit opening in an open position and closes the exit opening in a closed position. The control element has a frame, a transfer medium that brings about shape fit and has wheels, the transfer medium generates angle synchronicity of wheels mounted in the frame so as to pivot, a drive for the transfer medium, for pivoting the respective wheel in two opposite pivot directions, a bearing element for the closure part, mounted in wheels so as to pivot. The bearing element is mounted about pivot axles in the wheels, so as to pivot. The pivot axles are disposed in the frame parallel to the pivot axles of these wheels. The closure part is mounted in the bearing element.

Classes IPC  ?

• B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression
• B65D 83/28 - Buses, leurs moyens de support ou leurs accessoires spécialement adaptés à cet effet
• B05B 15/02 - Systèmes ou dispositifs pour nettoyer des orifices d'évacuation
• A47K 5/12 - Distributeurs de savon pour savon liquide ou pâteux
• B67D 7/14 - Aménagements des dispositifs pour commander, indiquer, mesurer ou enregistrer la quantité ou le prix du liquide transféré répondant à l'insertion d'information de programmes enregistrés, p.ex. sur cartes perforées
• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Produits et services

Apparatus and machines for applying hot-melts and dispersion adhesives; apparatus for applying hot-melts; machine components for drum kettles; machine components, in particular applicator heads for hot-melts and dispersion adhesives; electronic-operated applicator heads for gluing with dispersion adhesives; electro-pneumatic operated applicator heads for gluing with hot-melts; machine parts for gluing with polyurethane adhesives (PUR); machine components and accessories for gluing with hot-melts, in particular application units, applicator heads, hoses, nozzles, modules, sensors, pumps and heating apparatus; glue application systems for rotary printing machines, including application systems for hot-melts and dispersion adhesives, machines for gluing book spines and bindings; machine components, in particular for coating heads for coating surfaces with hot-melts; machine components, in particular modular coating heads in installations for coating hot-melts and dispersion adhesives; machine components, in particular for hot-melt and polyurethane kettles (PUR); machine components for gluing with hot-melts, including polyurethane (PUR) and dispersion adhesives in the wood processing industry; machine components, in particular for gluing machines with hot-melts, in particular profile coating machines, edge gluing machines, apparatus for repairing wood; machine components, in particular for applying glue onto cardboard, corrugated cardboard and plastic; machine components, in particular for gluing with hot-melts for labeling packaging; machine components, in particular for the preparation and application of sealing and insulating materials. Hand-operated adhesive application systems with hot-melts, in particular manual applicators. Electronic controls for machines and apparatus for the preparation of hot-melts and dispersion adhesives; apparatus for setting and monitoring the preparation of hot-melts and dispersion adhesives, in particular electronic controls for applying glue and glue monitoring, sensors for controlling glue, optical components and systems for quality control and assurance.

Produits et services

Application apparatus and machines for hot-melt and dispersion adhesives; Application apparatus for hot-melt adhesives; Machine components for drum melters; Machine components, namely application heads for the processing of hot-melt and dispersion adhesives; Electronically controlled application heads for the processing of dispersion adhesives; Electro-pneumatically controlled application heads for the processing of hot-melt adhesives; Manual application systems for the processing of hot-melt adhesives, namely manual applicators (electric hand tools); Machine components for the processing of PUR adhesives; Components and accessories for hot-melt adhesive processing machines, in particular applicators, application heads, modules, Nozzles, Hoses, Heating units and Pumps; Adhesive application systems for rotary printing machines containing hot-melt adhesive and dispersion adhesive application systems, machines for gluing book spines and bookbinding; Machine components, namely coating heads for flat hot-melt adhesive coatings; Machine components, namely modular coating heads in coating installations for hot-melt adhesives and dispersion adhesives; Machine components for PUR hot-melt adhesive melting apparatus; Machine components for the processing of hot-melt adhesives, including PUR and dispersion adhesives in the wood-processing industry; Machine components for hot-melt adhesive processing machines, in particular profile sheathing machines, edge gluing machines, wood repair systems; Machine components for the application of adhesives to cardboard, corrugated cardboard and plastics; Machine components for the processing of hot-melt adhesives in the field of the labelling of containers; Machine components for the processing and application of sealants and insulating materials. Electronic controllers for machines and apparatus for the processing of hot-melt adhesives and dispersion adhesives; Apparatus for parameterisation and monitoring of the processing of hot-melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring, sensors, including sensors for adhesive monitoring; Optical systems and components for quality monitoring and quality assurance.

Produits et services

Application apparatus and machines for hot-melt and dispersion adhesives; Application apparatus for hot-melt adhesives; Machine components for drum melters; Machine components, namely application heads for the processing of hot-melt and dispersion adhesives; Electronically controlled application heads for the processing of dispersion adhesives; Electro-pneumatically controlled application heads for the processing of hot-melt adhesives; Manual application systems for the processing of hot-melt adhesives, namely manual applicators (electric hand tools); Machine components for the processing of PUR adhesives; Components and accessories for hot-melt adhesive processing machines, in particular applicators, application heads, modules, Nozzles, Hoses, Heating units and Pumps; Adhesive application systems for rotary printing machines containing hot-melt adhesive and dispersion adhesive application systems, machines for gluing book spines and bookbinding; Machine components, namely coating heads for flat hot-melt adhesive coatings; Machine components, namely modular coating heads in coating installations for hot-melt adhesives and dispersion adhesives; Machine components for PUR hot-melt adhesive melting apparatus; Machine components for the processing of hot-melt adhesives, including PUR and dispersion adhesives in the wood-processing industry; Machine components for hot-melt adhesive processing machines, in particular profile sheathing machines, edge gluing machines, wood repair systems; Machine components for the application of adhesives to cardboard, corrugated cardboard and plastics; Machine components for the processing of hot-melt adhesives in the field of the labelling of containers; Machine components for the processing and application of sealants and insulating materials. Electronic controllers for machines and apparatus for the processing of hot-melt adhesives and dispersion adhesives; Apparatus for parameterisation and monitoring of the processing of hot-melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring, sensors, including sensors for adhesive monitoring; Optical systems and components for quality monitoring and quality assurance.

Produits et services

Application apparatus and machines for hot-melt and dispersion adhesives; Application apparatus for hot-melt adhesives; Machine components for drum melters; Machine components, namely application heads for the processing of hot-melt and dispersion adhesives; Electronically controlled application heads for the processing of dispersion adhesives; Electro-pneumatically controlled application heads for the processing of hot-melt adhesives; Manual application systems for the processing of hot-melt adhesives, namely manual applicators (electric hand tools); Machine components for the processing of PUR adhesives; Components and accessories for hot-melt adhesive processing machines, in particular applicators, application heads, modules, Nozzles, Hoses, Heating units and Pumps; Adhesive application systems for rotary printing machines containing hot-melt adhesive and dispersion adhesive application systems, machines for gluing book spines and bookbinding; Machine components, namely coating heads for flat hot-melt adhesive coatings; Machine components, namely modular coating heads in coating installations for hot-melt adhesives and dispersion adhesives; Machine components for PUR hot-melt adhesive melting apparatus; Machine components for the processing of hot-melt adhesives, including PUR and dispersion adhesives in the wood-processing industry; Machine components for hot-melt adhesive processing machines, in particular profile sheathing machines, edge gluing machines, wood repair systems; Machine components for the application of adhesives to cardboard, corrugated cardboard and plastics; Machine components for the processing of hot-melt adhesives in the field of the labelling of containers; Machine components for the processing and application of sealants and insulating materials. Electronic controllers for machines and apparatus for the processing of hot-melt adhesives and dispersion adhesives; Apparatus for parameterisation and monitoring of the processing of hot-melt adhesives and dispersion adhesives, in particular electronic controllers for adhesive application and adhesive monitoring, sensors, including sensors for adhesive monitoring; Optical systems and components for quality monitoring and quality assurance.

Abrégé

An application head for dispensing a flowable medium includes a nozzle chamber in the application head and a nozzle needle movably mounted in the nozzle chamber. A supply channel and a supply line introduce the medium into the nozzle chamber. A drive moves the movable element. A lever arm is movably fastened to the nozzle needle and connected to the drive. The lever arm extends through a membrane of a membrane suspension connect the lever arm movably to the application head and form a seal to prevent escape of the flowable medium. Alternatively, a rocker suspension has a lever arm connectable to the movable element and the drive, a plate element has an opening through which the lever arm extends, a rocker mounting device connects the lever arm movably to the application head and a sealing device prevents any escape of adhesive from the chamber through the plate element opening.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluide; Récupération de l'excès de liquide ou d'un autre matériau fluide

Abrégé

Application head (15, 115) for dispensing a flowable medium, having a nozzle chamber (10) in the interior of the application head (15, 115) and a nozzle needle (11, 111) which is mounted movably in the interior of the nozzle chamber (10). An opening movement (P) of the nozzle needle (11, 111) opens an outlet opening (12). Furthermore, a feed channel (13) and a feed line are provided, in order for it to be possible to introduce the flowable medium into the nozzle chamber (10). A drive (20) produces the opening movement (P) of the nozzle needle (11, 111). Furthermore, the application head (15, 115) comprises a lever arm (30, 130), the first extreme end (31) of which is fastened movably to a rear end (14) of the nozzle needle (11, 111) and the second extreme end (32) of which is connected to the drive (20).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to an application head (15) for dispensing a free-flowing medium. The application head (15) comprises an injection chamber (10) inside the application head (15) and an injection needle (11) movably mounted inside the injection chamber (10). An opening movement (P) of the injection needle (11) opens an outlet (12). A supply channel (13) and a supply line are also provided in order to introduce the free-flowing medium into the injection chamber (10). A drive (20) generates the opening movement (P) of the injection needle (11). The application head (15) also comprises a lever arm (30), the first end (31) of said arm being movably fixed to a rear end (14) of the injection needle (11) and the second end (32) thereof being connected to the drive. A membrane suspension (33) comprising a membrane (34) is provided, and the lever arm (30) extends through the membrane (34) of the membrane suspension (33). The membrane suspension (33) is used to movably connect the lever arm (30) to the application head (15), and as a seal to prevent the free-flowing medium from leaking out.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to an application head (15) for dispensing a free-flowing medium. The application head (15) comprises an injection chamber (10) inside the application head (15) and an injection needle (11) movably mounted inside the injection chamber (10). An opening movement (P) of the injection needle (11) opens an outlet (12). A supply channel (13) and a supply line are also provided in order to introduce the free-flowing medium into the injection chamber (10). A drive (20) generates the opening movement (P) of the injection needle (11). The application head (15) also comprises a lever arm (30), the first end (31) of said arm being movably fixed to a rear end (14) of the injection needle (11) and the second end (32) thereof being connected to the drive. A membrane suspension (33) comprising a membrane (34) is provided, and the lever arm (30) extends through the membrane (34) of the membrane suspension (33). The membrane suspension (33) is used to movably connect the lever arm (30) to the application head (15), and as a seal to prevent the free-flowing medium from leaking out.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to a hand application device (1) having improved handling capability, in that its individual elements (2, 7, 12) are rotatable and adjustable to one another around four rotational axes (8, 10, 13, 28).

Classes IPC  ?

• B05B 7/02 - Pistolets pulvérisateurs; Appareillages pour l'évacuation
• B05B 9/01 - Pistolets pulvérisateurs
• B24B 23/00 - Machines de meulage portatives, p.ex. à guidage manuel; Accessoires à cet effet
• B24B 27/08 - Machines à couper par meulage portatives
• B23B 45/00 - Perceuses tenues à la main ou perceuses analogues portatives, p.ex. en forme de pistolet; Equipement à cet effet

Abrégé

The invention relates to a method and a device for dispensing a moisture-curing adhesive (K). The device (10) comprises several nozzle openings (11.1 - 11.4) and switchable adhesive supply lines (12). The device (10) can be operated in two operating modes, wherein, in the first operating mode, adhesive (K) is dispensed through all nozzle openings (11.1 - 11.4) and, in the second operating mode, adhesive (K) is dispensed only through a smaller number of nozzle openings (11.1 - 11.2). Each nozzle opening (11.1 - 11.4) is formed at or in a housing (13.1 - 13.4) which comprises an adhesive duct (15) for supplying the adhesive (K) to the nozzle opening (11.1 - 11.4). For each nozzle opening (11.1 - 11.4), there is one flow chamber (16) disposed in the area of the nozzle opening (11.1 - 11.4). A gas supply (17) is connected to the flow chambers (16). The device (10) comprises outlet openings (14.1 - 14.4) in the area of the nozzle opening (11.1 - 11.4), which are arranged in such a manner that adhesive (K) and gas (G) can be dispensed simultaneously through the outlet opening (14.1 - 14.4) during operation.

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

The invention relates to a method and a device (10) comprising several nozzle openings (14.1) and switchable adhesive supply lines (12), wherein adhesive (K) can be dispensed through at least a part of the nozzle openings (14.1). Each nozzle opening (14.1) can be actuated by a high-pressure needle valve or a high-pressure piston valve comprising a needle or a piston (19) that can be moved up and down. For each high-pressure needle valve or high-pressure piston valve, a protective chamber (40) is disposed in the rear area of the needle or piston (19), said protective chamber sealingly surrounding the needle or piston (19). The protective chamber (40) is acted upon by a protective medium (SM).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Produits et services

Hotmelt and coldmelt applicator machines; hotmelt application machines with gear pumps; machine parts, namely, drum unloaders; machine parts, namely, applicator heads for hotmelt and coldglue applicator machines; electrically-controlled cold glue applicator heads for machines; electro-pneumatic and electrically-controlled hot melt glue application heads for machines; machine parts, namely, PUR applicators for hotmelt and coldglue applicator machines; hotmelt application machine components and accessories, namely, applicators, heads, modules, nozzles, hoses, heaters, pumps, and sensors sold in connection therewith; gluing system for rotary offset printing machines comprising hotmelt and coldglue application heads, book spine gluing machines; machine parts, namely, coating heads for wide hotmelt application machines; machine parts, namely, modular coating heads for hotmelt and coldglue application machines; machine parts, namely, PUR hotmelt block melting units, namely, drum unloader melting grill, electric glue guns, hot melt glue guns; engineered-wood gluing machines; machine parts, namely, multimelt universal hotmelt application units, namely, profiles wrapping machines, edge banding machines, wood repair machines, electric glue guns, hot melt glue guns; hand-operated hotmelt applicators, namely, hand applicators Microprocessor controller for hotmelt and coldglue and adhesive operations; devices for parameterization and monitoring of hotmelt and coldglue, namely, electronic pattern controllers, electronic adhesive application controllers, glue detection sensors

Abrégé

The invention relates to a hand application device (1) having improved handling in that the individual elements (2, 7, 12) therefore can be rotated and adjusted with respect to each other about four rotation axes (8, 10, 13, 28).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

Abrégé

A device (10) for spreading a two-component coating material (1), consisting of at least two components, on a flat web-shaped carrier (16) comprises a slotted nozzle (11) provided with an output slot (11.2) whose length (L) defines the width of the coating material (1) application to the carrier (16), wherein the slotted nozzle (11) is provided with two end areas and a nozzle chamber which is arranged inside the slotted nozzle (11) and extends in a parallel to the output slot (11.2) from the first to the second end area. A first mixer (15) is arranged in the region of the first end area. A second mixer (15) is positioned in the region of the second end area. At least one first reservoir (K1) for the first component (A) and at least one second reservoir (K2) for the second component (B) are provided. Transport means (12, 13, 17) are used for individually transporting the first component (A) from the first reservoir (K1) to the first and second mixers (15) and for transporting the second component (b) from the second reservoir (K2) to the first and second mixers (15).

Classes IPC  ?

• B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
• B05C 9/06 - Appareillages ou installations pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par des moyens non prévus dans l'un des groupes , ou dans lesquels le moyen pour déposer le liquide ou autre matériau fluide n'est pas important pour appliquer deux liquides ou autres matériaux fluides différents, ou le même liquide ou matériau fluide deux fois, sur le même côté de l'ouvrage

Produits et services

(1) Application systems for liquid to pastry materials, namely electrical conveyors and electrical pumps for glueing and coating materials.

Produits et services

Electrical apparatus for the application of adhesive materials, including accessories thereof such as applicator heads, heated hoses and control devices.
