A portable vacuum cleaner includes a main body equipped with a suction duct, and a suction motor housed in the main body and configured to generate an air flow through the suction duct. The main body includes an air exhaust circuit through which the air flow generated by the suction motor is exhausted to the outside of the main body. The air exhaust circuit includes a filter having a generally cylindrical shape and delimiting an internal chamber fluidly connected to an air discharge orifice of the suction motor, and an acoustic absorption wall extending at least partly into the internal chamber of the filter, an internal surface of the filter and the acoustic absorption wall delimiting a first air conduit and a second air conduit in each of which is configured to circulate a part of the air flow.
A47L 9/00 - LAVAGE OU NETTOYAGE DOMESTIQUE; ASPIRATEURS EN GÉNÉRAL - Parties constitutives ou accessoires des aspirateurs, p.ex. moyens mécaniques pour commander l'aspiration ou pour entraîner une action de battement; Dispositifs de rangement spécialement conçus pour les aspirateurs ou les pièces de ceux-ci; Véhicules porteurs spécialement conçus pour les aspirateurs
The invention relates to a metal cooking vessel (10) that is compatible with induction heating, the vessel having a cooking face and a heating face (12), comprising a metal substrate (2) made of aluminium or an aluminium alloy, and also an expanded metal insert (3) made of ferromagnetic material, the expanded metal insert (3) being inserted at least partially into the metal substrate (2) on the side of the heating face (12), the expanded metal insert (3) having an inter-strand opening diameter. According to the invention, the expanded metal insert (3) has, in its central portion, a central opening (38) and/or at least one non-central opening (32), having an opening section at least equal to twice the inter-strand opening diameter, preferably at least equal to three times the inter-strand opening diameter, more preferably at least equal to four times the inter-strand opening diameter, preferably at least equal to five times the inter-strand opening diameter. The invention also relates to an item of cookware and to an electrical cooking appliance comprising a metal cooking vessel (10) of this kind.
The invention relates to a detachable handle (1) comprising a lock (15); a toggle movement device (19) comprising a lever (21) that is mounted so as to pivot between a first lever position and a second lever position, a connecting rod (22) configured to move the lock (15) in translation between a locked position and an unlocked position when the lever (21) is moved between the first lever position and the second lever position, a pivot shaft (23) mounted on the lever (21) so as to slide in a sliding direction (D2) and on which the connecting rod (22) is pivotably mounted, and a movable member (25) mounted on the lever (21) so as to slide in the sliding direction (D2) and to which the pivot shaft is attached; and an anti-reverse device (31) comprising a blocking member (32) having a through-opening (33) through which the movable member extends, the blocking member being capable of co-operating with the movable member (25) via bracing.
The food heating appliance (2) comprises: a base (3) that includes a receiving surface (5) and a lower heating device (6); a bowl (8) that rests on the receiving surface (5) and delimits an inner volume (9) intended to contain food, the inner volume (9) of the bowl (8) being less than 1.3 liters; and a lid (23) that includes an upper heating element (25) and is configured to be placed over the bowl (8).
The invention relates to a detachable handle (1) comprising a grip body (7); an inner bearing member (13) and an outer bearing member (8) configured to bear, respectively, against an inner surface and an outer surface of a side wall (4) of a cooking utensil (2); a lock (15); a toggle movement device (19) comprising a lever (21) mounted so as to pivot between a first lever position and a second lever position, and a connecting rod (22) configured to move the lock (15) in translation between a locked position and a released position when the lever (21) is moved between the first lever position and the second lever position; and an anti-reverse device, (29) comprising at least one notch provided on a fixed portion of the detachable handle (1) and at least one tooth provided on the connecting rod (22), or vice versa.
The bowl (8) comprises: an inner volume (9) intended to contain food; an upper peripheral edge (11) delimiting an upper opening (12) through which food can be introduced into the inner volume (9); a bowl body (13) at least partially delimiting the inner volume (9), the bowl body (13) being made of metal and being provided with a bottom wall (13.1) and a peripheral wall (13.2) extending from the bottom wall (13.1); and a thermally insulating layer (14) which is made of a thermally insulating material, the thermally insulating layer (14) at least partially covering an outer surface of the peripheral wall (13.2) of the bowl body (13) and also covering an upper end of the peripheral wall (13.2) of the bowl body (13) and partially covering an inner surface of the peripheral wall (13.2) of the bowl body (13).
The food heating appliance (2) comprises: a base (3) provided with a receiving surface (5); a bowl (8) that rests on the receiving surface (5) and delimits an inner volume intended to contain food; and a lid (23) that includes an upper heating element and is configured to be placed over the bowl (8). The base (3) comprises a support structure (37) that supports the lid (23) and is configured to provide an access opening allowing the bowl (8) to be put in place and removed by at least one translational movement parallel to a plane of extent of the receiving surface (5).
The food heating appliance (2) comprises: a base (3) having a receiving surface (5); a bowl (8) that rests on the receiving surface (5) and delimits an inner volume (9) intended to contain food, the bowl (8) having an upper peripheral edge (11); and a lid (23) that is supported by the base (3) and is configured to be placed over the bowl (8), the lid (23) comprising an upper heating element (25) configured to heat food contained in the bowl (8) at least by radiation, the lid (23) having a heat shield portion (28) that is configured to be arranged inside the bowl (8) in such a way that the upper peripheral edge (11) of the bowl (8) is not directly subject to radiation by the upper heating element (25).
The food heating appliance (2) comprises: a base (3) provided with a receiving surface (5); a bowl (8) that rests on the receiving surface (5) and delimits an inner volume (9) intended to contain food; and a lid (23) that is supported by the base (3) and is mounted so as to be movable between a closing position and an opening position, the lid (23) comprising an upper heating element (25) configured to heat food contained in the bowl (8) as well as a protruding gripping portion (36) configured to protrude beyond a side wall of the bowl (8) when the lid (23) is in the closing position.
- Hairstyling appliance with multiple blowing modes, comprising a push-push button control mechanism - The invention relates to a hairstyling appliance (1) comprising means for generating an air flow according to different blowing modes, a push-push button control mechanism (21) for controlling each transition of the appliance from one of the blowing modes to another of the blowing modes, and a housing (23) which has an access opening (24) inscribed in a plane (Po), and within which the button is mounted translatably movably between a released position and a depressed position in which a contact portion (22) of the button is arranged inside the housing, the access opening having a diameter (Do1) of between 28 mm and 50 mm and said contact portion being at a maximum distance (Dmax1) from the plane (Po) of between 5 mm and 40 mm when the button is in the depressed position. - Hairstyling appliances.
The invention relates to a cooking appliance comprising a cooking chamber (4); an air venting circuit (12) that comprises a venting opening (13); a filtering device (18) configured to filter out cooking fumes flowing through the air venting circuit (12); a user interface (15); and a control unit (16). The cooking appliance (1) comprises a first operating mode, wherein the filtering device (18) is configured to filter out cooking fumes flowing through the air venting circuit (12), and a second operating mode, wherein the cooking fumes are able to flow freely out of the cooking appliance (1), and the control unit (16) is configured to control the operation of the cooking appliance (1) according to the first operating mode or according to the second operating mode on the basis of an operating parameter selected by a user via the user interface (15).
A47J 36/38 - MATÉRIEL DE CUISINE; MOULINS À CAFÉ; MOULINS À ÉPICES; APPAREILS À PRÉPARER LES BOISSONS - Éléments, détails ou accessoires des récipients de cuisson pour éliminer ou condenser les vapeurs de cuisson dans les ustensiles de cuisine
12.
STEAM IRONING AND/OR SMOOTHING APPLIANCE COMPRISING AN ELECTRIC PUMP
The invention relates to a steam ironing and/or smoothing appliance (1) comprising a heating body (4) comprising an instantaneous-vaporization chamber (6), an electric pump (3) and a treatment surface comprising at least one steam outlet hole (12A), the heating body (4) comprising an electrical resistor (5) and a mechanical thermostat (7), characterized in that the pump (3) is powered by a power supply circuit which takes into account the open or closed state of the mechanical thermostat (7), the power supply circuit modifying the operating conditions of the pump (3) depending on the state of the thermostat (7), the pump (3) operating at a first flow rate when the thermostat (7) is in a closed state and at a second flow rate when the thermostat (7) is in an open state, the first flow rate being lower than the second flow rate.
D06F 75/26 - Dispositions de commande ou d'indication de la température
D06F 75/08 - Fers à repasser à chauffage électrique interne
D06F 75/14 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par de l'eau contenue dans un réservoir supporté par le fer
D06F 75/16 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par de l'eau contenue dans un réservoir supporté par le fer le réservoir étant chauffé pour produire la vapeur
D06F 75/24 - Aménagements de moyens de chauffage à l'intérieur du fer; Dispositions pour la distribution, la conduite ou l'emmagasinage de la chaleur
Disclosed is a cooking appliance comprising: - a cooking space arranged to receive food to be cooked, - cooking means (30) comprising cooking ventilation means (30C) arranged to generate a cooking air flow and heating means arranged to heat the cooking air flow so as to allow the food that is to be cooked and is received in the cooking space to cook by convection, - stirring means arranged to stir the food that is to be cooked and is received in the cooking space, - a lid (11) that is removable and/or movable between an open position allowing access to the cooking space and a closed position preventing access to the cooking space, characterized in that the lid (11) includes at least one vent (41) arranged to variably adjust a gas exchange surface between the cooking space and an environment outside the cooking appliance.
A47J 36/38 - MATÉRIEL DE CUISINE; MOULINS À CAFÉ; MOULINS À ÉPICES; APPAREILS À PRÉPARER LES BOISSONS - Éléments, détails ou accessoires des récipients de cuisson pour éliminer ou condenser les vapeurs de cuisson dans les ustensiles de cuisine
The invention relates to a milk foaming device (30), which comprises: - a main body (32) comprising a first inlet port (36), suitable for receiving steam and/or hot water, a second inlet port (38) suitable for receiving milk, a first foaming chamber and a foamed milk outlet port; and - a milk supply device (34) suitable for being connected to the main body (32) and comprising a milk dispensing nozzle (48). According to the invention, the foaming device comprises a cleaning tool (100) suitable for cleaning the milk dispensing nozzle and a housing (102) for receiving the cleaning tool, the cleaning tool (100) being suitable for being removably positioned in the receiving housing (102).
Disclosed is a cooking appliance comprising: - a cooking space arranged to receive food to be cooked, - cooking means comprising cooking ventilation means (30C) arranged to generate a cooking air flow and heating means arranged to heat the cooking air flow so as to allow the food that is to be cooked and is received in the cooking space to cook by convection, characterized in that the heating means comprise at least one carbon-fiber heating element (30B) and in that the cooking appliance comprises stirring means arranged to stir the food that is to be cooked and is received in the cooking space.
Disclosed is a cooking appliance comprising: - a cooking space arranged to receive food to be cooked, - cooking means (30) comprising cooking ventilation means (30C) arranged to generate a cooking air flow and heating means arranged to heat the cooking air flow so as to allow the food that is to be cooked and is received in the cooking space to cook by convection, - a lid (11) that is removable and/or movable between an open position allowing access to the cooking space and a closed position preventing access to the cooking space, characterized in that the lid (11) comprises two walls (12) that are located one on top of the other and are arranged to form a passage for a cooling air flow between the two walls (12) located one on top of the other.
The invention relates to an electric cooking appliance (1) comprising a housing (2) that comprises a cooking vessel (3) defining a cooking chamber (4); a lid (8) configured to assume an open position and a closed position; a heating device (9) configured to heat food contained in the cooking chamber (4); a control unit (10) configured to control the operation of the electric cooking appliance (1); and a first electrical connection device (11) arranged in an upper portion of the housing (2) and configured to be electrically connected to a second electrical connection device (13) provided on a removable cooking or preparation accessory (14) that is intended to be arranged on the housing (2) when the lid (8) is in the open position. The first electrical connection device (11) is configured to supply power to the removable cooking or preparation accessory (14).
The present invention relates to a coating (3) for a household article on a metal support (2), wherein one of the faces (3a) contacts the metal substrate (2) and the other face (3b) is visible to the user, said coating comprising one or more layers, each layer comprising one or more polyaryletherketones (PAEK) and at least one of the layers being made up of: - a PEAK-based polymer phase; - one or more fillers; - optionally one or more additives; - optionally one or more colouring agents.
A47J 36/02 - Emploi de matériaux spécifiés, p.ex. double-fonds avec une plaque de cuivre ou une plaque isolante
B05D 5/06 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces pour obtenir des effets, finis ou des structures de surface particuliers pour obtenir des effets multicolores ou d'autres effets optiques
19.
System For Reversibly Attaching An Accessory To A Hot Water/Steam Dispensing Outlet, Corresponding Accessory And Beverage Dispensing Machine
A system for reversibly attaching an accessory to a hot water and/or steam dispensing outlet of a beverage dispensing machine includes a main body and a locking element. The locking element is received in the main body and includes two elastically deformable arms designed to cooperate with at least one locking relief formed on the dispensing outlet. The arms are configured to be moved between a position in which the accessory is locked to the dispensing outlet and an unlocked position.
The invention relates to a food preparation appliance (1) comprising a housing (2); a cooking vessel (4) configured to receive food to be cooked; a lid (9) configured to occupy a closed position in which the lid (9) prevents access to the cooking vessel (4) and an open position in which the lid (9) allows access to the cooking vessel (4); a stirring paddle (18) arranged in the cooking vessel (4); a rotation-driving device (22) arranged in the cover (9) and configured to rotate the stirring paddle (18); and a hot-air cooking device (15) comprising a fan (16) mounted on the cover (9) and configured to generate an airflow and a heating element (17) attached to the cover (9) and configured to heat the airflow generated by the fan (16).
A47J 43/046 - Machines de ménage non prévues ailleurs, p.ex. pour moudre, mélanger, agiter, pétrir, émulsionner, fouetter ou battre les aliments, p.ex. actionnées par moteur à outils actionnés du côté du fond
A47J 43/07 - Eléments ou parties constitutives, p.ex. outils pour mélanger ou pour battre
A47J 43/044 - Machines de ménage non prévues ailleurs, p.ex. pour moudre, mélanger, agiter, pétrir, émulsionner, fouetter ou battre les aliments, p.ex. actionnées par moteur à outils actionnés du côté du haut
The invention relates to an electric cooking appliance (2) comprising a main body (3) that houses a cooking vessel (4) defining a cooking space (5); a lid (6) configured to prevent access to the cooking vessel (4); and a hot-air heating device (7) comprising an air circulation device configured to generate an airflow in the cooking space (5), and a heating element configured to heat the airflow generated by the air circulation device. The hot-air heating device (7) is removable and has a use configuration in which the hot-air heating device (7) is arranged outside the cooking space (5) and a storage configuration in which the hot-air heating device (7) is stored inside the cooking space (5).
The invention relates to a drive system for a food preparation appliance comprising at least one first working tool and at least one second working tool, the drive system comprising: • a motor module comprising at least: - a first drive output, and - a second drive output; • a drive module (400), comprising at least: - a mounting interface (410), and - a movable input coupler (420) which is provided to be coupled with the first drive output or be coupled with the second drive output, characterised in that the drive module (400) further comprises a control mechanism (430) which is arranged between the mounting interface (410) and the input coupler (420) and is provided to: - be actuated by the first working tool, or - be actuated by the second working tool.
- The invention relates to an assisted breathing device (1) comprising a main body (2) including a front central element (3) and a member (6) for keeping the main body immobile with respect to the head of the user, a blower module (7) remote from the main body in order to generate an air flow, the front central element supporting an air distribution outlet, the main body of which ensures positioning away from the respiratory tract and in a centred manner along a vertical axis included in a median sagittal plane (Ps) of the head of the user, the air distribution outlet comprising an opening with a surface area of between 10 cm² and 42 cm², and a porous medium for homogenising the air flow covering the opening. - Assisted breathing devices.
A62B 18/08 - Masques ou casques respiratoires, p.ex. pour assurer une protection contre les agents chimiques ou pour l'emploi à hautes altitudes - Parties constitutives des casques ou masques à gaz, p.ex. fenêtres, sangles, transmetteurs de voix, dispositifs de signalisation
24.
CLEANING DEVICE EQUIPPED WITH A WASTE GUIDE CHANNEL
The cleaning device (2) comprises a main body (3) delimiting a suction chamber; and a waste guide channel (16), open downwards, having a front opening (17), a rear opening (18) opening into the suction chamber, and two lateral guide walls (19) configured to orient waste, coming into contact against the lateral guide walls (19), towards the rear opening (18). Each of the lateral guide walls (19) has a first lateral guide surface (21) and a second lateral guide surface (22) which are substantially planar, the two first lateral guide surfaces (21) converging towards each other in the direction of the rear opening (18), the two second lateral guide surfaces (22) being arranged between the two first lateral guide surfaces (21) and converging towards each other in the direction of the rear opening (18).
The cleaning device (2) comprises a main body (3) having a suction mouth (6) and a suction chamber fluidically connected to the suction mouth (6); a waste guide channel (16) which is open downwards and which has a front opening (17), a rear opening (18) opening into the suction chamber, and two lateral guide walls (19) located on either side of the rear opening (18) and converging towards each other in the direction of the rear opening (18) so as to orient waste, coming into contact against the lateral guide walls (19) during a forward movement of the cleaning device (2), towards the rear opening (18). Each of the lateral guide walls (19) has a lower edge (19.1) having an inclination, with respect to a transverse direction, which increases in the direction of the rear opening (18).
The cleaning device (2) comprises a main body (3) delimiting a suction chamber; and a waste guide channel (16), open downwards, having a front opening (17), a rear opening (18) opening into the suction chamber, and two lateral guide walls (19) configured to orient waste, coming into contact against the lateral guide walls (19), towards the rear opening (18). Each of the lateral guide walls (19) has a first lateral guide surface (21) and a second lateral guide surface (22) which are substantially planar, the two first lateral guide surfaces (21) converging towards each other in the direction of the rear opening (18), the two second lateral guide surfaces (22) being arranged between the two first lateral guide surfaces (21) and converging towards each other in the direction of the rear opening (18).
A food preparation appliance includes a housing with at least one supporting leg, a work bowl, and weighing means arranged to weigh food to be prepared. At least one supporting leg includes suspension means having a supporting part, an anchoring part, and elastic return means. The suspension means is arranged to allow a displacement of the supporting part, in that the preparation appliance includes abutment means to limit the displacement of the supporting part, and in that the weighing means are attached between the supporting part and the housing.
A47J 43/07 - Eléments ou parties constitutives, p.ex. outils pour mélanger ou pour battre
G01G 3/14 - Appareils de pesée caractérisés par l'utilisation d'organes déformables par élasticité, p.ex. balances à ressort dans lesquels l'élément de pesée est constitué par un corps solide soumis à une pression ou une traction pendant la pesée utilisant la mesure des variations de la résistance électrique
G01G 21/22 - Plateaux de pesée ou autres récipients de pesée; Plates-formes de pesée
G01G 21/23 - Supports ou suspensions de plates-formes de pesée
28.
METHOD FOR DELIVERING ASCORBIC ACID AND/OR ONE OF ITS DERIVATIVES VIA IONTOPHORESIS
CENTRE NATIONAL DE LA RECHERCHE SCIENTIFIQUE (CNRS) (France)
Inventeur(s)
Salas, Tiffanie
Bolzinger, Marie-Alexandrine
Bordes, Claire
Abrégé
The present invention relates to a cosmetic method for delivering ascorbic acid and/or one of its derivatives through the skin via iontophoresis, preferably bipolar iontophoresis, and/or electrostimulation, the method comprising the following steps: • providing a device comprising a main electrode, a counter-electrode and a power source electrically connected to the main electrode on the one hand and to the counter-electrode on the other hand, the main electrode and the counter-electrode being intended to be in direct or indirect contact with the skin and being separated from one another by a free space; • applying a cosmetic composition comprising ascorbic acid and/or one of its derivatives and one or more cosmetically acceptable additives to the main electrode and the counter-electrode but not to the free space; • applying the device to the skin such that the main electrode and the counter-electrode with the cosmetic formulation are in direct or indirect contact with the skin; • applying, over a certain time period, a direct current with an average current density of 0.03 mA/cm2 to 0.5 mA/cm2, preferably 0.1 mA/cm2 to 0.2 mA/cm2. The present invention also relates to an iontophoresis kit for implementing this method.
This technical unit (6) for a handheld vacuum cleaner comprises a main body (14) accommodating a motor assembly (16), a cable support piece (20), a power connector (22), and a set of first electrical cables extending from the motor assembly (16) to the power connector (22) through the cable support piece (20). The technical unit (6) is configured to be attached, during a phase of assembly of the handheld vacuum cleaner (2), to a handle unit (8) comprising a handle (38) and a housing (40) for receiving the main body (14). According to the invention, the cable support piece (20) is able, during the assembly phase, to be fixed inside the handle (38).
This technical unit (6) for a handheld vacuum cleaner comprises a main body (14) receiving a motor assembly (16), the technical unit (6) being configured to be attached to a handle unit (8) during a vacuum cleaner assembly phase, said handle unit (8) comprising a handle (38) and a housing (40) for receiving the main body. According to the invention, the technical unit (6) also comprises a human-machine interface (28) positioned on an outer face of the main body (14), and the human-machine interface (28) forms a guide rib (114) capable of engaging with a groove (116) of the receiving housing during the assembly phase.
The invention relates to an iron comprising a heating body (4), an upper face whereof is provided with a steam generator, characterised in that the steam generator comprises an external vaporisation chamber (45) enclosing an internal vaporisation chamber (46) and a device (7) for injecting a fluid onto a bottom wall (40) of the internal vaporisation chamber (46), the steam generator comprising a first passage (60) establishing communication between the internal vaporisation chamber (46) and the external vaporisation chamber (45) and comprising a second passage (48) establishing communication between the external vaporisation chamber (45) and a steam distribution circuit leading to at least one steam outlet hole (20) made in the sole plate (2).
D06F 75/18 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par de l'eau contenue dans un réservoir supporté par le fer l'eau étant alimentée lentement, p.ex. goutte à goutte du réservoir au générateur de vapeur
33.
Cooking Element Coated With A Peelable Non-Stick Fluorinated Polymeric Film
The invention relates to a coated cooking element for a kitchen item or electrical cooking apparatus, comprising a metal substrate coated on one side with a peelable film, forming a cooking face, the peelable film comprising one or several layers of fluorinated polymer, a mechanical reinforcing layer and a hotmelt polymer layer arranged on the opposite side to the cooking face and having a melting point higher than 250° C. and lower than or equal to that of at least one of the other layers of the peelable film, the peelable film being assembled with the metal substrate, the hotmelt polymer layer being in contact with the face of the metal substrate. The invention also relates to a method for manufacturing such a coated cooking element and to a cooking article or an electrical cooking appliance having said coated cooking element.
A47J 37/10 - Poêles à frire, p.ex. poêles à frire avec couvercles ou dispositifs d'arrosage intégrés
B32B 7/06 - Liaison entre couches permettant une séparation sans difficultés
B32B 15/08 - Produits stratifiés composés essentiellement de métal comprenant un métal comme seul composant ou comme composant principal d'une couche adjacente à une autre couche d'une substance spécifique de résine synthétique
B32B 27/20 - Produits stratifiés composés essentiellement de résine synthétique caractérisée par l'emploi d'additifs particuliers utilisant des charges, des pigments, des agents thixotropiques
B32B 27/28 - Produits stratifiés composés essentiellement de résine synthétique comprenant des copolymères de résines synthétiques non complètement couverts par les sous-groupes suivants
B32B 37/06 - Procédés ou dispositifs pour la stratification, p.ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par le procédé de chauffage
B32B 37/10 - Procédés ou dispositifs pour la stratification, p.ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par la technique de pressage, p.ex. faisant usage de l'action directe du vide ou d'un fluide sous pression
B32B 37/18 - Procédés ou dispositifs pour la stratification, p.ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par les propriétés des couches toutes les couches existant et présentant une cohésion avant la stratification impliquant uniquement l'assemblage de feuilles ou de panneaux individualisés
B32B 38/10 - Enlèvement de couches ou de parties de couches, mécaniquement ou chimiquement
B32B 43/00 - Opérations spécialement adaptées aux produits stratifiés et non prévues ailleurs, p.ex. réparation; Appareils pour ces opérations
H05B 3/28 - Eléments chauffants ayant une surface s'étendant essentiellement dans deux dimensions, p.ex. plaques chauffantes non flexibles le conducteur chauffant enrobé dans un matériau isolant
34.
COOKING VESSEL PROVIDED WITH A HANDLE FASTENED BY TWO FLUSH RIVETS
The invention relates to a cooking vessel (1a) comprising a side wall (3a) and a handle (4), the handle (4) comprising a connecting part (10) fastened to the side wall (3a), the connecting part (10) comprising an axial portion (14) that extends parallel to the side wall (3a) and is fastened to the side wall (3a) by at least two rivets (20, 21) each comprising a header (24, 25). According to the invention, the axial portion (14) comprises at least two holes (15, 16) for the at least two rivets (20, 21) to pass through, each hole (15, 16) comprising an entry chamfer (17, 18) in which the entire header (24, 25) of the rivet (20, 21) is housed.
A vacuum cleaner nozzle includes a sole provided with a lower face and a suction channel emerging into the lower face; and a front scraping member located at the front of a front edge of the suction channel and delimiting at least in part a central passage opening which is fluidly connected to the suction channel. The front scraping member generally has a V shape having an apex oriented towards a central part of the suction channel, the front scraping member including a first scraping branch extending in a first direction of extension and a second scraping branch extending in a second direction of extension, the first and second scraping branches being configured to orient waste, coming into contact against the front scraping member during a forward movement of the vacuum cleaner nozzle towards the central passage opening.
The invention relates to a domestic fan comprising an electric motor (4), an impeller (3) rotated by the motor (4) and a protective grating (6) arranged around the impeller (3), characterised in that it comprises: an illuminating frame (80) bearing at least one light source (81) arranged on the periphery of the protective grating (6); - a deflector (84) facing the illuminating frame (80) and covering at least one portion of the periphery of the protective grating (6), the deflector (84) reflecting and/or diffusing the light emitted by the illuminating frame (80).
The invention relates to a lighting kit (8) for a domestic fan provided with a protective grille (6), the device comprising at least: - a luminous frame (80) which has an annular shape and supports at least one light source (81), the luminous frame (80) comprising attachment means allowing the frame to be removably attached to the protective grille (6) of the fan; - a deflector (84) which is removably attached to the luminous frame (80), the deflector (84) comprising a front wall (84A) having an outer diameter which substantially matches the diameter of the luminous frame (80), the front wall (84A) extending in front of the luminous frame (80) in order to diffuse and/or reflect the light emitted by this frame.
A beverage dispensing machine includes a beverage dispensing head whose position relative to a container receiving area can be adjusted, and a receiving structure for the dispensing head having a first slide and a second slide designed to interact with a respective lateral side of the dispensing head to form a first slide connection and a second slide connection, respectively. The receiving structure also includes a third slide, positioned between the first and second slides and designed to interact with the dispensing head to form a third slide connection. The third slide is closer to the receiving area along the longitudinal axis than the first slide and the second slide.
The autonomous cleaning robot includes a main body including a lower face and a suction opening, opening into the lower face; a wet cleaning device including two mop supports which are each movably mounted in translation relative to the main body in a direction of translation, and two mops mounted respectively on the two mop supports; and two drive wheels configured to roll over the surface to be cleaned and movably mounted in rotation on the main body respectively about two rotation axes which are substantially parallel. The two mop supports are located behind the rotation axes of the drive wheels, and the direction of translation extends substantially parallel to the rotation axes of the two drive wheels.
A47L 11/40 - Machines à nettoyer les planchers, les tapis, les meubles, les murs ou leurs revêtements - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p.ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
A47L 11/30 - Machines à frotter le plancher caractérisées par des moyens pour évacuer le liquide sale à aspiration
Hair treatment device The invention relates to a hair treatment device, notably for shaping, comprising: - two hair treatment jaws that are movable relative to one another between a spaced-apart configuration and a moved-together configuration; - two hair treatment soleplates, each extending over one of the two jaws towards the other one of the two jaws, facing one another in the moved-together configuration of the jaws; - at least one heating element extending into at least one of the two jaws, configured to heat one of the treatment soleplates; - a row of teeth extending inside one of the treatment soleplates towards the other treatment soleplate in the moved-together configuration of the two jaws, with the teeth being made of a material with thermal conductivity of more than 20 Wm-1.K-1; - a steam outlet arranged on one of the jaws and configured to emit steam into the row of teeth in the moved-together configuration of the jaws.
An electric cooking appliance (1) for cooking food, comprising a lower heating structure (2) comprising a cooking vessel (5) having a maximum depth that is greater than 40 mm; an upper heating structure (13) having a cooking plate (16); a pivot connection (15) connecting the upper heating structure (13) to the lower heating structure (2) and configured to allow pivoting of the upper heating structure (13) between a closed position in which the lower heating structure (2) and the upper heating structure (13) delimit a cooking volume (19) in which a food is able to be cooked, and a maximum-opening position in which each of the cooking vessel (5) and the cooking plate (16) is able to support and cook a respective food.
The invention relates to an electric cooking appliance (1) for cooking foodstuffs, the appliance comprising a lower heating structure (2) provided with a cooking accessory (5); an upper heating structure (13) provided with a cooking plate (16); a pivot link (15) connecting the upper heating structure (13) to the lower heating structure (2) and configured to allow the upper heating structure (13) to pivot between a closed position in which the lower heating structure (2) and the upper heating structure (13) define a cooking volume (19) in which a foodstuff is able to be cooked and a maximum opening position in which each of the cooking accessory (5) and the cooking plate (16) is able to support and cook a respective foodstuff; and a collecting tray configured to collect cooking juices and condensates from the cooking plate (16).
The invention relates to an electric cooking appliance (1) for cooking foodstuffs, the appliance comprising a lower heating structure (2) provided with a cooking accessory (5); an upper heating structure (13) provided with a cooking plate (16) and a grip handle (29); a pivot link connecting the upper heating structure (13) to the lower heating structure (2) and configured to allow the upper heating structure (13) to pivot between a closed position in which the lower heating structure (2) and the upper heating structure (13) define a cooking volume in which a foodstuff is able to be cooked and a maximum opening position in which each of the cooking accessory (5) and the cooking plate (16) is able to support and cook a respective foodstuff. The grip handle (29) is movable between a grip position and a stand position.
The invention relates to an assembly (1) for cutting food in a spiral, comprising a drive output (30) intended to be rotated, the cutting assembly integrating a housing (2) comprising a recess (3), a transmission means (22), mounted so as to rotate with respect to the housing, the transmission means coupled to the drive output (30), a food support (4), mounted so as to rotate with respect to the housing, protruding into the recess, a movable cutting element (5) comprising a cutting member (6) arranged within the recess, the movable cutting member (5) comprising a cavity (7) provided with a conical or frustoconical flank (8), arranged facing the food support (4), the cutting member (6) being arranged on the flank (8) so as to cut a food item arranged on the food support (4) that is rotated, the movable cutting element (5) being manually movable so as to vary the distance between the cutting member (6) and the food support (4).
B26D 3/11 - Coupes ayant une forme autre que rectiligne pour obtenir des pièces en spirale ou en hélice
B26D 1/01 - Coupe d'une pièce caractérisée par la nature ou par le mouvement de l'élément coupant; Appareils ou machines à cet effet; Eléments coupants à cet effet comportant un élément qui ne suit pas le mouvement de la pièce
B26D 1/28 - Coupe d'une pièce caractérisée par la nature ou par le mouvement de l'élément coupant; Appareils ou machines à cet effet; Eléments coupants à cet effet comportant un élément qui ne suit pas le mouvement de la pièce ayant un élément coupant se déplaçant autour d'un axe avec un élément coupant non circulaire se déplaçant autour d'un axe sensiblement perpendiculaire à la ligne de coupe et tournant sans arrêt dans le même sens pendant la coupe
B26D 7/06 - Dispositions pour faire avancer ou évacuer les pièces autres que les feuilles, les bandes ou les filaments
B26D 9/00 - Appareillages de coupe combinés avec des appareillages de poinçonnage ou de perforation, ou avec d'autres appareillages de coupe différents
B26D 1/04 - Coupe d'une pièce caractérisée par la nature ou par le mouvement de l'élément coupant; Appareils ou machines à cet effet; Eléments coupants à cet effet comportant un élément qui ne suit pas le mouvement de la pièce ayant un élément coupant se déplaçant linéairement
B26D 3/28 - Fendage d'un matériau pour obtenir des feuillets; Séparation mutuelle des couches par coupe
B26D 7/26 - Moyens de montage ou de réglage de l'outil de coupe; Moyens de réglage de la course de l'outil de coupe
B26D 7/00 - COUPE; DÉTAILS COMMUNS AUX MACHINES POUR PERFORER, DÉCOUPER À L'EMPORTE-PIÈCE, DÉCOUPER, POINÇONNER OU SÉPARER - Parties constitutives de l'appareillage de coupe, découpage, poinçonnage, perforation ou séparation autrement que par coupe
A method of making a cooking utensil and a cooking utensil made using the same. In some embodiments, a method of making a cooking utensil includes applying pressure and heat to a multilayer stack to form a laminate, the multilayer stack including a metal substrate and a first polymer film.
The invention relates to a device for preparing foodstuffs, the device comprising: - a rotary working tool (30) comprising a circumferential side wall (32) having at least one external cutting member (33) adjacent to a through-passage (35); - a housing (20) defining a cavity configured to accommodate the working tool (30), the housing (20) having a tube (25) for introducing the foodstuffs to be cut, the tube (25) having a bearing and centring side portion (26) configured to receive the foodstuffs pushed by the working tool (30) during the cutting thereof; - a pusher (40) that can be moved into the tube (25) in order to push the foodstuffs toward the working tool (30), the pusher (40) having a lower end (42). According to the invention, the lower end (42) has a front portion (43) adjacent to the bearing and centring side portion (26) which is raised in the direction of the bearing and the centring side portion (26).
A method of making a cooking utensil and a cooking utensil made using the same are disclosed herein. In some embodiments, a method of making a cooking utensil includes applying pressure and heat to a multilayer stack to form a laminate, the multilayer stack including a metal substrate, a mesh layer, a first polymer film, and an additional layer having an opening therein, wherein the mesh layer, the first polymer film, and the additional layer are arranged on the same side of the metal substrate, and wherein the opening is sized such that the opening would surround the mesh layer if the additional layer and the mesh layer were disposed in the same plane.
A method of making a cooking utensil and a cooking utensil made using the same. In some embodiments, a method of making a cooking utensil includes applying pressure and heat to a multilayer stack to form a laminate, the multilayer stack including a metal substrate and a first polymer film.
B32B 15/085 - Produits stratifiés composés essentiellement de métal comprenant un métal comme seul composant ou comme composant principal d'une couche adjacente à une autre couche d'une substance spécifique de résine synthétique comprenant des polyoléfines
A47J 36/02 - Emploi de matériaux spécifiés, p.ex. double-fonds avec une plaque de cuivre ou une plaque isolante
B32B 15/18 - Produits stratifiés composés essentiellement de métal comportant du fer ou de l'acier
B32B 27/20 - Produits stratifiés composés essentiellement de résine synthétique caractérisée par l'emploi d'additifs particuliers utilisant des charges, des pigments, des agents thixotropiques
B32B 27/32 - Produits stratifiés composés essentiellement de résine synthétique comprenant des polyoléfines
B32B 37/06 - Procédés ou dispositifs pour la stratification, p.ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par le procédé de chauffage
B32B 37/10 - Procédés ou dispositifs pour la stratification, p.ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par la technique de pressage, p.ex. faisant usage de l'action directe du vide ou d'un fluide sous pression
A method of making a cooking utensil and a cooking utensil made using the same are disclosed herein. In some embodiments, a method of making a cooking utensil includes applying pressure and heat to a multilayer stack to form a laminate, the multilayer stack including a metal substrate, a mesh layer, a first polymer film, and an additional layer having an opening therein, wherein the mesh layer, the first polymer film, and the additional layer are arranged on the same side of the metal substrate, and wherein the opening is sized such that the opening would surround the mesh layer if the additional layer and the mesh layer were disposed in the same plane.
A crease-smoothing cabinet includes
a base;
a top extending opposite and at a distance from the base; and
an expandable curtain intended to extend between the base and the top, so that the base, the top and the curtain together define an enclosed space in the crease-smoothing cabinet when the curtain is expanded and attached to the base and the top.
A crease-smoothing cabinet includes
a base;
a top extending opposite and at a distance from the base; and
an expandable curtain intended to extend between the base and the top, so that the base, the top and the curtain together define an enclosed space in the crease-smoothing cabinet when the curtain is expanded and attached to the base and the top.
The curtain includes a multilayer textile wall including a first layer and a second layer, wherein the first layer is made of a textile material made of elastic fibers and the second layer is made of a waterproof material.
D06F 73/02 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur avec une ou plusieurs chambres de traitement
B32B 5/02 - Produits stratifiés caractérisés par l'hétérogénéité ou la structure physique d'une des couches caractérisés par les caractéristiques de structure d'une couche comprenant des fibres ou des filaments
B32B 27/12 - Produits stratifiés composés essentiellement de résine synthétique adjacente à une couche fibreuse ou filamenteuse
B32B 27/40 - Produits stratifiés composés essentiellement de résine synthétique comprenant des polyuréthanes
A crease-smoothing cabinet includes:
a base;
a top extending opposite and at a distance from the base; and
an expandable curtain configured to extend between the base and the top, so that the base, top and curtain together define an enclosed space in the crease-smoothing cabinet when the curtain is expanded and attached to the base and top. The curtain includes a textile wall and a frame having a plurality of stays, the frame stays being arranged at regular intervals along the textile wall, and in that each portion of the textile wall located between two frame stays has a convex shape, so that the frame and the textile wall ensure accordion-folding and unfolding of the curtain.
D06F 73/02 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur avec une ou plusieurs chambres de traitement
The vacuum cleaner conduit includes first and second rigid conduit parts; a hinge device configured to allow a pivoting of the first and second rigid conduit parts between unfolded and folded configurations; a locking member configured to lock the first and second rigid conduit parts in the unfolded configuration, the locking member being movably mounted between locking and release positions; and an unlocking button slidably mounted between a rest position and an unlocking position, and configured to displace the locking member into the release position. The unlocking button and the hinge device are located on the same side of the vacuum cleaner conduit which is substantially diametrically opposite to the side of the vacuum cleaner conduit where the locking member is located.
The vacuum cleaner conduit includes first and second rigid conduit parts a hinge device configured to allow a pivoting of the first and second rigid conduit parts about a hinge axis and between unfolded and folded configurations; a locking member configured to lock the first and second rigid conduit parts the unfolded configuration; and an unlocking member including two lateral gripping parts located on either side of one of the first and second rigid conduit parts, each of the lateral gripping parts being intersected by a plane parallel to the hinge axis and containing a central longitudinal axis of the vacuum cleaner conduit in the unfolded configuration of the first and second rigid conduit parts.
The invention relates to an autonomous cleaning robot comprising a suction chamber (6) provided with a suction mouth; a rotary cleaning brush (7) accommodated in the suction chamber (6); a waste collection container (16); a waste-guiding channel (17) fluidically connecting the suction chamber (6) to the waste collection container and having an overall cylindrical shape; a lower deflector (18) configured to deflect, upwardly and towards the waste-guiding channel (17), waste projected by the rotary cleaning brush (7) on the lower deflector (18); and an upper deflector (21) configured to deflect, rearwardly and towards the waste collection container (16), waste exiting the waste-guiding channel (17) upwardly.
The invention relates to a method for cooking food using a food preparation apparatus comprising first heating means and second heating means, the method comprising: - a main heating step (T1-T2) for heating the first cooking space, consisting in supplying the first heating means with one or more first instantaneous heating power(s) P1, and - a mixed heating step (T0-T1, T2-T3) consisting in: supplying the first heating means with one or more first instantaneous heating power(s) P1, and supplying the second heating means with one or more second instantaneous heating power(s) P2, wherein, at least during the mixed heating step (T0-T1, T2-T3), a sum of the first instantaneous heating power P1 and the second instantaneous heating power P2 does not exceed a total maximum heating power Pappmax of the food preparation apparatus.
The autonomous cleaning robot comprises a main body (3); a suction unit (14) comprising a suction motor (15); a wet cleaning device located in a rear portion (3.2) of the main body (3); a power battery (21) and two drive wheels (11). The suction unit (14) and the power battery (21) are arranged on either side of the median longitudinal plane (P1) of the main body (3) and in the rear portion of the main body (3). A first axis (B1) passes through the centre of gravity (G1) of the power battery (21) and the geometric centre (C) of the main body (3) is inclined at a first inclination angle (α1) with respect to the median longitudinal plane (P1), and a second axis (B2) passes through the centre of gravity (G2) of the suction unit (14) and the geometric centre (C) of the main body (3) is inclined at a second inclination angle (α2) with respect to the median longitudinal plane (P1).
A47L 9/04 - Buses avec brosses ou agitateurs commandés
A47L 9/06 - Buses avec brosses ou similaires fixes, p.ex. à fixation réglable
A47L 9/10 - Filtres; Séparateurs de poussière; Enlèvement de la poussière; Echange automatique des filtres
A47L 9/28 - Montage de l'équipement électrique, p.ex. adaptation ou fixation à l'aspirateur; Commande des aspirateurs par des moyens électriques
A47L 11/12 - Instruments actionnés par moteur à outils à mouvement alternatif ou oscillant
A47L 11/284 - Machines à frotter le plancher, actionnées par moteur ayant des outils animés d'un mouvement de va-et-vient
A47L 11/40 - Machines à nettoyer les planchers, les tapis, les meubles, les murs ou leurs revêtements - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p.ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
59.
AUTONOMOUS CLEANING ROBOT EQUIPPED WITH WASTE DEFLECTORS
The invention relates to an autonomous cleaning robot comprising: a suction chamber (6); a waste collection container; a connection channel (17) that fluidically connects the suction chamber (6) to the waste collection container; and a waste deflector (24) comprising first and second deflector portions (25, 26) located on either side of the inlet opening of the connection channel (17) and respectively comprising first and second deflection surfaces (25.1, 26.1) which are designed to be oriented towards the surface to be cleaned and which extend transversely to a main direction (D) of movement of the autonomous cleaning robot (2), each of the first and second deflection surfaces (25.1, 26.1) being inclined such that the distance between the surface to be cleaned and said deflection surface increases towards the inlet opening of the connection channel (17).
The invention relates to a knife comprising a blade (1) and a handle (2) having a main gripping portion (200), wherein the main gripping portion (200) of the handle (2) has a shape that widens longitudinally in the longitudinal plane and is defined by a longitudinal widening angle α formed between a lower edge (222) and an upper edge (221), the longitudinal widening angle α having a set value between 3° and 8°, and wherein the distance in the longitudinal plane between the lower edge (222) and the upper edge (221) at a given position in the longitudinal direction (L) defines a handle height (H), and the distance in the longitudinal plane between the lower edge (222) and the projection of the gripping ridge (2233) in the longitudinal plane at a given position in the longitudinal direction (L) defines a lower sagitta (Fi), the ratio between the lower sagitta (Fi) and the handle height (H) being substantially constant at any point on the main gripping portion (200) of the handle (2) in the longitudinal direction (L) and having a set value of between 13% and 20%.
The invention relates to a knife comprising a blade (1) and a handle (2), wherein the handle (2) comprises a plurality of grooves (400) provided on at least one of the sides (23) of the handle, the grooves (400) being distinct from each other, with a reference groove (410) positioned closest to the blade (1) and the other grooves (400) being arranged adjacently starting from the reference groove (410) and going along the handle (2) towards a free end of the handle (2) opposite the blade (1). Each groove (400) has a mean direction of extension (410), the projection of which in the longitudinal plane forms a groove angle γ with the longitudinal direction (L), the reference groove (410) being oriented at a reference groove angle γR comprised between 0° and 10°, and each subsequent groove (400) of the plurality of grooves (400) having a groove angle γ greater than the reference groove angle γR, the respective groove angles γ of two adjacent grooves (400) being different.
The invention relates to a knife comprising a blade (1) and a handle (2) having a joining portion and a main gripping portion (200), wherein the main gripping portion (200) of the handle (2) has a shape having a longitudinal flaring extending in the longitudinal plane and defined by a longitudinal flaring angle α formed between a lower edge (222) and an upper edge (221), the longitudinal flaring angle α having a set value of between 3° and 8°, and wherein the joining portion is such that the ratio between the lower joining arrow (FiJ) and the joining height (HJ) decreases in the longitudinal direction (L) starting from the blade (1) and going towards the main gripping portion (200).
The invention relates to a portable hair-styling device (1) comprising means for generating an air flow according to two blowing modes, the device having a first face (2) carrying a first air-blowing outlet (3) for blowing the air flow in a first blowing mode, and a second face (4) carrying a second air-blowing outlet (5) for blowing the air flow in a second blowing mode, the device comprising a control system (20) for alternately selecting one or other of the blowing modes, and an indicator system for providing visual information as to which of the blowing modes is selected, the indicator system comprising a visual selection indicator (21', 21'') alternately visible from the one of the first and second faces that carries the air-blowing outlet corresponding to the selected blowing mode. Hair-styling devices.
The invention relates to a portable hairstyling appliance (1) comprising means for generating an air flow (F) in two different blowing modes, the appliance having a first face (4), which bears a first air blowing outlet (2) for blowing the air flow in a first blowing mode, and a second face (5) bearing a second air blowing outlet (3) for blowing the air flow in a second blowing mode, the appliance comprising a control system for selecting either one of the blowing modes and an indicator system for providing visual information to the user as to which one of the blowing modes has been selected in this way, the indicator system comprising a visual selection light indicator (21') which is alternately visible on the side of that one of the faces that bears the air blowing outlet corresponding to the selected blowing mode. The invention relates to the field of hairstyling appliances.
The invention relates to a food-preparation appliance (100), comprising a base (111) forming a stand (112) and a head (115) mounted so as to be movable relative to the base (111) and having a driver driven in rotation by a motor about a first axis of rotation (119), a working container (120) mounted so as to be able to rotate on the stand (112) about a second axis of rotation (129), the first axis of rotation (119) being off-centre with respect to the second axis of rotation (129), a food-processing tool (130') coupled to the driver and extending into the working container (120), and a counter-tool (140') capable of occupying at least two distinct working positions in the working container (120). According to the invention, the food-preparation appliance (100) comprises an operating member (145) configured to move the counter-tool (140') between the at least two distinct working positions, the operating member (145; 245; 245') being movable by the user between at least two control positions, each corresponding to one of the working positions of the counter-tool (140; 140'; 240; 240').
A47J 43/044 - Machines de ménage non prévues ailleurs, p.ex. pour moudre, mélanger, agiter, pétrir, émulsionner, fouetter ou battre les aliments, p.ex. actionnées par moteur à outils actionnés du côté du haut
A47J 43/07 - Eléments ou parties constitutives, p.ex. outils pour mélanger ou pour battre
66.
HOT-AIR COOKING APPLIANCE WITH A REMOVABLE FASTENING DEVICE
Hot-air cooking appliance (3) comprising: a support (5) suitable for being inserted into a cooking chamber (7) of the hot-air cooking appliance (3); a cooking vessel (9) provided with a bottom (11) and with a side wall (13) extending from the bottom (11); a removable fastening device (15) for fastening the cooking vessel (9) on the support (5), the removable fastening device (15) being configured to keep the cooking vessel (9) on the support (5) in a predetermined position while allowing the assembly formed by the support (5) and the cooking vessel (9) to be inserted into and removed from the cooking chamber (7) of the hot-air cooking appliance (3).
A cooking vessel includes a side wall and a handle. The handle includes a connecting piece attached to the side wall. The connecting piece includes an axial portion that extends parallel to the side wall and that is attached to the side wall by at least two rivets.
A cooking vessel includes a side wall and a handle. The handle includes a connecting piece attached to the side wall. The connecting piece includes an axial portion that extends parallel to the side wall and that is attached to the side wall by at least two rivets.
The at least two rivets are arranged in at least two parallel horizontal planes H1, H2, separated by a distance D and the axial portion extends laterally to a vertical plane, perpendicular to the side wall, over a width L less than 30 millimeters, preferably less than 25 millimeters.
Drinking bottle closure with double sealing function for a drinking bottle, at least comprising: - a body base member having a pouring rim surrounding a pouring opening, - a first displaceable sealing element for abutment with a lower abutment edge on the body base member surrounding the pouring opening; - a ballpen drive unit comprising at least one pin (35) fixedly arranged relative to the body base member and a star-shaped member (20) which is rotatable and displaceable relative to the body base member and to which the sealing element is connected, - wherein the star-shaped member (20) has at least one raised tooth profile (23, 24) formed on the outer circumference, along which the pin (35) is guided in a scanning manner, - a second displaceable sealing element for abutment against an upper abutment edge surrounding the pouring opening on the body base member (50); characterized in that - a control base member (30) is provided which is connected to the body base member and has a central recess for receiving the star-shaped member (20), at least one pin (35) projecting radially from there into the recess and being formed resiliently on the control base member (30) or being fastened thereto, and - the star-shaped member (20) is provided on its outer circumference, out- side the raised tooth profile (23), with at least one backstop profile section (26) which has at least one run-up slope and an adjoining stop edge on which the resiliently mounted pin (35) can be fixed.
B65D 47/24 - Fermetures avec dispositifs de décharge autres que des pompes comportant des éléments fonctionnant à la main pour commander l'évacuation avec soupapes
F16J 15/10 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre par garniture non métallique
69.
Cooking Appliance Comprising A Collection Device Configured To Collect Cooking Juices And Condensates
A cooking appliance includes a cooking chamber; a cooking plate that can be moved between a first plate position and a second plate position; and a collection device configured to collect cooking juices from food on the cooking plate and having a collection tray located underneath the cooking plate. The cooking plate includes a drainage port opening into an internal volume of the cooking plate and located plumb with the collection tray, the drainage port being configured to allow the cooking juices contained in the internal volume to drain into the collection tray regardless of the position of the cooking plate.
A vacuum cleaner nozzle includes a main body having a suction mouth; a connecting sleeve fluidly connected to the suction mouth; a hinge device mechanically connecting the connecting sleeve to the main body and configured to allow a tilting of the connecting sleeve forwards and backwards and about a first pivot axis and a tilting of the connecting sleeve leftwards and rightwards and about a second pivot axis; and a pivot blocking device configured to block a pivoting of the connecting sleeve about the second pivot axis at least when the connecting sleeve occupies a predetermined sleeve position.
L'invention concerne un appareil de cuisson (1) comportant une chambre de cuisson (2), une plaque de cuisson (3) déplaçable entre une première position de plaque et une deuxième position de plaque, un dispositif de collecte (7) configure pour collecter des jus de cuisson provenant d'aliments situés sur la plaque de cuisson (3) et comprenant un bac de collecte (8) situé en dessous de la plaque de cuisson (3). La plaque de cuisson (3) comporte un orifice d'évacuation débouchant dans un volume interne de la plaque de cuisson (3) et situé à l'aplomb du bac de collecte (8), l'orifice d'évacuation étant configure pour permettre un écoulement par gravité des jus de cuisson, contenus dans le volume interne, dans le bac de collecte (8) quelle que soit la position occupée par la plaque de cuisson (3).
F24C 15/14 - Plateaux ou rainures pour l'écoulement
F24C 1/00 - Poêles ou fourneaux dans lesquels le combustible ou la source d'énergie n'est pas exclusivement un combustible solide ou d'un type couvert par un seul des groupes ; Poêles ou fourneaux dans lesquels le type de combustible ou d'énergie utilisé n'est pas spécifié
F24C 11/00 - Combinaisons de plusieurs poêles ou fourneaux, p.ex. utilisant chacun un type d'énergie différent
Provided is cookware made from a bonded multi-layer blank assembly. The cookware has a first metal layer, a second metal layer having a cavity with a plurality of spaced-apart posts protruding from a bottom surface of the cavity, and a perforated graphite layer having a thickness of at least 0.010 in. (0.254 mm) and a plurality of spaced-apart holes formed therethrough. The perforated graphite layer is positioned within the cavity of the second metal layer such that the plurality of spaced-apart posts extend through the plurality of spaced-apart holes. The second metal layer is metallurgically bonded to the first metal layer at least via the plurality of spaced-apart posts. A method of making the bonded multi-layer composite cookware is also disclosed.
The invention relates to a cooking appliance, comprising: - a housing (10); - means for acquiring a thickness of a food item to be cooked; - a first type of cooking plate; - cooking means configured to implement at least one specific cooking program on the basis of a thickness to be cooked; - at least one second type of cooking plate, characterised in that: - said at least one second type of cooking plate comprises at least one recessed impression; - and in that, in order to cook a food item with the second type of cooking plate, the cooking means are configured to implement the same specific cooking program on the basis of the thickness of the second food item to be cooked, corrected by the predetermined impression depth.
The invention relates to a coated cooking element (1) for a cooking utensil or an electrical cooking appliance comprising a metal substrate (2) coated on at least one face (2a) by a film (3) forming a cooking face (4), the film (3) comprising a layer (3a) arranged on the side opposite the cooking face (4), the layer (3a) comprising one or more semi-crystalline or amorphous thermoplastic polymers, the film (3) being assembled with the metal substrate (2), the layer (3a) being in contact with the face (2a) of the metal substrate (2), and such that the cooking face (4) has a structure (5) that constitutes a protrusion characterised by a maximum profile height Rt, measured according to standard DIN 4768 E of 1 January 1990, of between 10 and 500 µm, preferably between 20 and 100 µm. The invention also relates to a method for manufacturing a coated cooking element, wherein the cooking face (4) has a structure (5), and to a cooking utensil or an electrical cooking appliance comprising the coated cooking element (1).
The present disclosure relates to a steam diffusion cleaning accessory (4), the cleaning accessory (4) comprising: a steam diffusion handle (67), a steam transmission port (670) provided at one end of the handle (67); and a cleaning head (64) extending from the handle (67) at the end provided with the steam transmission port (670), the cleaning head (64) comprising: a scraping element (643) for scraping a surface to be cleaned; a cleaning element (644) suitable for being moistened and intended to come into contact with the surface to be cleaned; and a diffusion channel (645) connected to the transmission port (670) and opening out only between the scraping element (643) and the cleaning element (644), the diffusion channel (645) being provided to diffuse steam from the transmission port (670).
A47L 1/08 - Instruments à main avec des dispositions pour amener des liquides, p.ex. des agents de nettoyage
A47L 11/40 - Machines à nettoyer les planchers, les tapis, les meubles, les murs ou leurs revêtements - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p.ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
The present invention relates to a steam diffusion base (2) comprising a steam generator (21), the steam diffusion base (2) further comprising: a support face (200); a side face (201); and a retainer (2011).
D06F 73/00 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur
D06F 75/12 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par alimentation en eau d'une source extérieure au fer à repasser
The invention relates to a household appliance (1) comprising: a steam diffusion base (2) comprising a steam generator (21), a sensor and a processor; and a steam diffusion accessory (3, 4, 5) comprising a connection member (8) configured to removably connect the steam diffusion accessory (3, 4, 5) to the steam diffusion base (2), the connection member (8) comprising an electronic component (82251); wherein the sensor is configured to measure a value of the electrical resistance of the electronic component (82251) when the steam diffusion accessory (3, 4, 5) is connected to the steam diffusion base (2) by means of the connection member (8) and the processor is configured to control an operation of the steam diffusion base (2) according to a measurement of the value of the electrical resistance read by the sensor. The invention also relates to a method for controlling such a household appliance.
D06F 73/00 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur
D06F 75/12 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par alimentation en eau d'une source extérieure au fer à repasser
The present disclosure relates to an assembly for a vapor diffusion accessory, the assembly comprising a cord and a connection element (8) that is equipped with: a coupling member (81) that includes a clamping piece (811) and a sleeve (812); and a connecting member (821, 822).
A47L 11/34 - Machines pour le traitement des tapis en place par un liquide, une mousse ou une vapeur, p.ex. par de la vapeur d'eau
A47L 11/40 - Machines à nettoyer les planchers, les tapis, les meubles, les murs ou leurs revêtements - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p.ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
D06F 73/00 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur
D06F 75/12 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par alimentation en eau d'une source extérieure au fer à repasser
82.
CONNECTION MEMBER FOR CONNECTING A VAPOR DIFFUSION ATTACHMENT TO A VAPOR DIFFUSION BASE
The present disclosure relates to a connection member (8) for connecting a vapor diffusion attachment (3, 4, 5) to a vapor diffusion base (2), the connection member (8) comprising: a coupling member (81); a cover (822); and a fastening system.
D06F 75/28 - Dispositifs de fixation, de protection ou de support du câble électrique d'alimentation
D06F 75/12 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par alimentation en eau d'une source extérieure au fer à repasser
D06F 87/00 - Appareils pour humidifier ou conditionner autrement l'article à repasser ou à presser
D06F 73/00 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur
The present invention relates to a steam diffusion accessory (3, 4, 5) comprising: a steam diffusion handle (67); and a steam diffusion head (61) comprising: a base (62); and a steam diffusion part (64) comprising: a connector member (641); and two pins (642).
D06F 73/00 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur
D06F 75/10 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser
The present disclosure relates to a steam diffusion base for a household appliance, the steam diffusion base (2) comprising: a casing (20) comprising a face (202), a connection opening (2021) being provided through the face (202); a steam generator which is arranged inside the casing (20); a supply duct (214) which is connected to the steam generator and is provided to diffuse steam from the steam generator to the connection opening (2021); and a closing panel (241) which is pivotally mounted between a deployed position, in which the closing panel (241) closes the connection opening (2021), and a retracted position, in which the closing panel (241) extends inside the casing (20).
D06F 75/12 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par alimentation en eau d'une source extérieure au fer à repasser
H01R 13/453 - Volet ou plaque de recouvrement ouvert par l'engagement de la pièce complémentaire
H01R 13/52 - Boîtiers protégés contre la poussière, les projections, les éclaboussures, l'eau ou les flammes
A47L 11/40 - Machines à nettoyer les planchers, les tapis, les meubles, les murs ou leurs revêtements - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p.ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
The present disclosure relates to an assembly for a vapor diffusion accessory, the assembly comprising: a vapor diffusion duct; and an end piece (75) that includes a mechanical restriction element (76).
D06F 75/12 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par alimentation en eau d'une source extérieure au fer à repasser
The present disclosure relates to a vapor diffusion ironing accessory (3) comprising a vapor diffusion element (6) comprising: a main body (61); and a grip handle (67).
D06F 75/12 - Fers à repasser à chauffage électrique interne avec des moyens pour amener la vapeur sur l'article à repasser la vapeur étant produite par alimentation en eau d'une source extérieure au fer à repasser
D06F 73/00 - Appareils pour le lissage ou l'élimination des faux plis des vêtements ou d'autres articles textiles par formeurs, supports, tendeurs ou cadres intérieurs avec application de chaleur ou de vapeur
A floor cleaning appliance has a main body including a case at least partially by delimited an external wall, a fluid inlet configured to receive a fluid flow from outside the case, at least one means, disposed in the case, configured to act on the fluid flow received through the fluid inlet. The cleaning appliance comprises includes at least two main wheels mounted movable in rotation on the main body, and a protective structure configured to protect the main wheels, the protective structure being disposed outside the case and extending at a distance from the outer wall and covering a portion of the tread of each main wheel.
A47L 5/36 - Aspirateurs munis d'un tube souple entre la buse et le corps; Aspirateurs se fixant sur les escaliers; Aspirateurs se transportant sur le dos
A47L 9/00 - LAVAGE OU NETTOYAGE DOMESTIQUE; ASPIRATEURS EN GÉNÉRAL - Parties constitutives ou accessoires des aspirateurs, p.ex. moyens mécaniques pour commander l'aspiration ou pour entraîner une action de battement; Dispositifs de rangement spécialement conçus pour les aspirateurs ou les pièces de ceux-ci; Véhicules porteurs spécialement conçus pour les aspirateurs
Provided is an article of cookware and a method of making the same. The cookware has at least one stainless steel layer and at least one copper layer metallurgically bonded directly to the at least one stainless steel layer via solid state bonding. The at least one stainless steel layer may be a ferritic stainless steel layer, and the at least one copper layer may be a grain stabilized copper. The at least one stainless steel layer may be made from a 400 series stainless steel, such as a 436 stainless steel alloy, a 439 stainless steel alloy, or a 444 stainless steel alloy. The at least one copper layer may be made from a high purity, oxygen free copper alloy, such as a C101 copper alloy, a C102 copper alloy, or a C107 copper alloy.
A47J 36/02 - Emploi de matériaux spécifiés, p.ex. double-fonds avec une plaque de cuivre ou une plaque isolante
B23K 20/02 - Soudage non électrique par percussion ou par une autre forme de pression, avec ou sans chauffage, p.ex. revêtement ou placage au moyen d'une presse
The invention relates to a portable electric hairstyling appliance (1) comprising a main body (2), a styling head (4) connected to the main body (2) and comprising a rotary portion (16) provided with an element (7) for mechanically engaging the hair, and a module (17) for electrically rotating the rotary portion (16) relative to the main body (2) in a first or a second direction of rotation, the appliance comprising a device for detecting a direction of forced rotation in which the rotary portion is made to rotate when the hair exerts a force counter to the element for mechanically engaging the hair, and a device for automatically selecting the first or the second direction of rotation depending on the detected direction of the forced rotation. The invention relates to the field of hairstyling appliances.
A45D 1/04 - Frisoirs, c. à d. pinces à utiliser très chaudes; Fers à friser, c. à d. fers à utiliser très chauds; Leurs accessoires avec des moyens de chauffage interne, p.ex. par un carburant liquide à l'électricité
A45D 2/12 - Bigoudis ou boucleurs à utiliser parallèlement au cuir chevelu, c. à d. boucleurs à plat
A45D 2/24 - Bigoudis ou boucleurs à utiliser parallèlement au cuir chevelu, c. à d. boucleurs à plat du type en plusieurs pièces, p.ex. avec des pièces coulissantes autres que celles de fixation
A45D 7/02 - Procédés pour onduler, décrêper ou boucler les cheveux thermiques
A45D 20/50 - Peignes ou brosses pour le séchage des cheveux avec moyens de chauffage intérieurs et dispositions pour le passage d'un courant d'air
90.
BEVERAGE DISPENSING MACHINE WITH VERTICALLY DISPLACEABLE MILK FROTHING DEVICE
The beverage dispensing machine (2) is provided with a frame (3); a boiler (6); a dispensing head (5) vertically movable relative to the frame (3); a connecting member configured to be fluidly connected to the boiler (6) and to be supplied with hot water and/or steam from the boiler (6); and a milk frothing device (22) having a connecting portion configured to be mechanically and fluidly connected to the connecting member and to supply hot water and/or steam to the milk frothing device (22). The connecting member is vertically movable relative to the frame (3) and the milk frothing device (22) is height-adjustable and is vertically movable relative to the frame (3) between a lowered position and a raised position.
The cooking appliance includes a first structure having a first hotplate; a second structure having a second hotplate; a first user interface arranged on the first structure; a second user interface arranged on the second structure; a control unit configured to control the operation of the cooking appliance. The cooking appliance has a first mode of use, called grill mode, in which a food item is intended to be enclosed between the first and second hotplates, and a second mode of use, called barbecue mode, in which each of the first and second hotplates can hold and cook a respective food item. The first user interface is used for the first mode of use and the second user interface is used for the second mode of use.
The invention relates to a lid (1) for a culinary article, comprising a gripping member (3) comprising a base (5) attached to the lid (1) and at least one flap (6) which bears a gripping surface (4), the at least one flap (6) being rotatable relative to the base (5) between a stacking position in which the gripping surface (4) is folded towards the lid (1) to allow the stacking of the lid (1) with another similar lid and a gripping position in which the gripping surface (4) is spaced apart from the lid (1), the gripping member (3) comprising an elastic means driving the flap (6) from its stacking position to its gripping position. According to the invention, the at least one flap (6) is made of austenitic stainless steel, or of duplex stainless steel, or of super-austenitic stainless steel, or of alpha-beta titanium alloy, the at least one flap (6) having a C-shape of which a developed length L is greater than 110 millimetres, preferably greater than 160 millimetres.
L' appareil de cuisson (1) comporte une première structure (2) comportant une première plaque de cuisson (3.1) ; une deuxième structure (4) comportant une deuxième plaque de cuisson (5.1) ; une première interface utilisateur (10) disposée sur la première structure (2) ; une deuxième interface utilisateur (11) disposée sur la deuxième structure (4) ; une unité de commande (13) configurée pour commander le fonctionnement de l'appareil de cuisson (1), l'appareil de cuisson (1) présentant un premier mode d'utilisation, dit mode grill, dans lequel un aliment est destiné à etre enserré entre les première et deuxième plaques de cuisson (3.1, 5.1), et un deuxième mode d'utilisation, dit mode barbecue, dans lequel chacune des première et deuxième plaques de cuisson (3.1, 5.1) est apte à supporter et cuire un aliment respectif ; la première interface utilisateur (10) étant dédiée au premier mode d'utilisation et la deuxième interface uti- lisateur (11) étant dédiée au deuxième mode d'utilisation. Figure 1
A47J 36/00 - MATÉRIEL DE CUISINE; MOULINS À CAFÉ; MOULINS À ÉPICES; APPAREILS À PRÉPARER LES BOISSONS - Éléments, détails ou accessoires des récipients de cuisson
Appareil de cuisson (1) pour la cuisson de produits alimentaires, l'appareil de cuisson (1) comportant une première structure (2) comportant une première plaque de cuisson (4) ; une deuxième structure (5) comportant une deuxième plaque de cuisson (7) et une poignée de préhension (8) qui comporte une partie de manipulation (9) ; une liaison pivot (11) reliant la deuxième structure (5) à la première structure (2) et configurée pour permettre un pivotement de la deuxième structure (5) par rapport à la première structure (2) autour d'un axe de pivotement (A) ; une interface utilisateur (18) disposée sur la partie de manipulation (9) ; et une unité de commande configurée pour commander le fonctionnement de l'appareil de cuisson (1). La partie de manipulation (9), qui porte l'interface utilisateur (18), est mobile par rapport au deuxième module de cuisson (6) entre au moins une première position d'utilisation et une deuxième position d'utilisation.
The invention relates to a food preparation device for a food preparation appliance, the device comprising: - an inner rotating shaft (10); - a work tool (20) mounted on the inner rotating shaft (10) via a helical connection, characterised in that: - the food preparation device comprises a drive device (30) with a first rotating hub (31) and a second rotating hub (32); - the inner rotating shaft (10) is capable of being coupled to the first rotating hub (31); - the food preparation device comprises a hollow rotating shaft (40): • mounted on the inner rotating shaft (10) via a pivot or a sliding pivot connection; • comprising a bevelled contact surface (41); and • comprising the second rotating hub (32), wherein the work tool (20) comprises a mating surface (25) arranged so as to come into contact with the bevelled contact surface (41).
The invention relates to an electric fryer (1) comprising a vessel (4) intended to contain a frying bath and an electric immersion heating device (20) configured to be immersed in the frying bath contained in the vessel (4), the vessel (4) having a bottom (11) that has a sloping portion (13) leading to a depression (14) forming a water collection zone, the sloping portion (13) having a slope interruption zone (15) that extends between an upper bottom portion (16) and the depression (14), the electric immersion heating device (20) having heating wires (21) that extend above the sloping portion (13). According to the invention, the heating wires (21) extend above the upper bottom portion (16) without reaching the depression (14).
- The invention relates to a hairstyling appliance (1) comprising a liquid vaporization device, a tank (10), a main body (2), and a system for reversibly assembling and attaching the tank (10) to the main body comprising: - a tenon (24) projecting from the main body and a housing (25) formed in a face (26) of the tank for receiving the tenon and guiding the tank in translation in a direction (Δ) of translation between a first and a second position, the tenon and the housing having catching portions (27, 28) which cooperate when the tank (10) is in the second position, preventing any movement in a direction secant to the direction of translation, and - a device for automatically locking the tank in the second position. - Hairstyling appliances.
The invention relates to an electric fryer (1) comprising a vessel (4) for holding a frying bath, an electric immersion heating device, and a water tank (30), wherein the vessel (4) has a vessel bottom (11), the electric immersion heating device has a heating portion (21) extending above the vessel bottom (11), the water tank (30) is arranged around and below the vessel bottom (11), the water tank (30) has a filling opening (31) arranged laterally with respect to the vessel (4), and the filling opening (31) is arranged higher than the vessel bottom (11). According to the invention, the vessel (4) is removably mounted in an outer housing (2), the outer housing (2) has the filling opening (31) and the water tank (30) is arranged in the outer housing (2).
The invention relates to a steam hairdressing device comprising a liquid vaporisation device, a pump, an electric motor for actuating the pump and a control system for alternately supplying the electric motor with power at least - at a first voltage value (UN) so that the pump supplies the vaporisation device with liquid at a first supply mass flow rate; and - at a second voltage value (UT), different from the first voltage value (UN), such that the pump supplies the vaporisation device with liquid at a second supply mass flow rate, different from the first supply mass flow rate. The invention relates to devices for use in the field of hairdressing.
A45D 1/28 - Frisoirs, c. à d. pinces à utiliser très chaudes; Fers à friser, c. à d. fers à utiliser très chauds; Leurs accessoires avec des moyens pour commander ou indiquer la température
A45D 7/06 - Procédés pour onduler, décrêper ou boucler les cheveux chimiques et thermiques combinés
A45D 24/22 - Peignes avec dispositifs de distribution de liquides, de pâtes ou de poudres
A45D 20/50 - Peignes ou brosses pour le séchage des cheveux avec moyens de chauffage intérieurs et dispositions pour le passage d'un courant d'air
A46B 11/08 - Brosses à réservoir ou autre système permettant l'application de produits, p.ex. peintures, pâtes, eau avec moyens de chauffage
A46B 11/00 - Brosses à réservoir ou autre système permettant l'application de produits, p.ex. peintures, pâtes, eau
A45D 1/00 - Frisoirs, c. à d. pinces à utiliser très chaudes; Fers à friser, c. à d. fers à utiliser très chauds; Leurs accessoires
100.
HOUSEHOLD ARTICLE COMPRISING A SOL-GEL NON-STICK COATING WITH A FINISH LAYER FREE OF SILICA AND OF COLLOIDAL METAL OXIDE
The present invention relates to a sol-gel finish layer of a non-stick coating of a household article, said layer forming a cooking surface and being free of silica and of colloidal metal oxide.
A47J 36/02 - Emploi de matériaux spécifiés, p.ex. double-fonds avec une plaque de cuivre ou une plaque isolante
B05D 3/02 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliqués; Traitement ultérieur des revêtements appliqués, p.ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides par cuisson
