1.

CYLINDER


Numéro d'application JP2025044710
Numéro de publication 2026/196729
Statut Délivré - en vigueur
Date de dépôt 2025-12-22
Date de publication 2026-09-24
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Seki Yuhei

Abrégé

This cylinder (10) comprises a cylinder tube (12), a head cover (14), a rod cover (16), a piston unit (26), and a tie rod (22). The cylinder tube (12) has an inner tube (12a) that forms a cylinder chamber (24), and an outer tube (12b) that covers the outside of the inner tube (12a) and forms a passage space (28) between the outer tube and the inner tube (12a). Guide protrusions (30, 32) protrude from at least one among the inner tube (12a) and the outer tube (12b) toward the passage space (28). The guide protrusions (30, 32) restrict the displacement direction of the tie rod (22) to only the axial direction, thereby facilitating assembly.

Classes IPC  ?

  • F15B 15/14 - Dispositifs actionnés par fluides pour déplacer un organe d'une position à une autreTransmission associée à ces dispositifs caractérisés par la structure de l'ensemble moteur le moteur étant du type à cylindre droit

2.

CONNECTION DEVICE


Numéro d'application 19475509
Statut En instance
Date de dépôt 2024-03-08
Date de la première publication 2026-09-24
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Takanashi, Akihito
  • Kawamoto, Takahiro

Abrégé

A connection device has a first joined body and a second joined body. The first joined body has an extension part that extends along an insertion/removal direction and that is inserted into an insertion hole formed in the second joined body. The outer peripheral surface of the extension part has a first step part and a second step part. The second step part is positioned farther inward than the first step part between the first step part and the base end of the extension part, the second step part engaging with the second joined body. The first step part engages with the second joined body after the engagement of the second step part is released.

Classes IPC  ?

  • F16L 37/084 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique
  • F16L 37/56 - Accouplements du type à action rapide pour tuyaux à double-paroi ou à canaux multiples

3.

VALVE DEVICE


Numéro d'application 19473172
Statut En instance
Date de dépôt 2023-12-19
Date de la première publication 2026-09-17
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Watanabe, Takashi

Abrégé

A valve device is provided with a nozzle that has a flow hole through which a fluid flows; a support member that supports the nozzle; a valve body that has a piezoelectric element and opens and closes an opening of the flow hole by driving of the piezoelectric element; and a position adjustment mechanism for adjusting the position of the nozzle with respect to the valve body. The position adjustment mechanism has an urging member for urging the nozzle toward the valve body; and a stopper member for preventing movement of the nozzle due to the urging member by coming into contact with the nozzle.

Classes IPC  ?

  • F16K 1/52 - Dispositifs pour le réglage additionnel du débit
  • F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos
  • F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme

4.

SUCTION PAD


Numéro d'application JP2025009416
Numéro de publication 2026/191014
Statut Délivré - en vigueur
Date de dépôt 2025-03-12
Date de publication 2026-09-17
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Saito Junichi
  • Yamamoto Shuhei

Abrégé

A suction pad (10) comprises: a body (12) having a negative pressure chamber (20); and a sponge part (14) that is attached to an attachment surface (19) of the body and comes into contact with an object (W) to be suctioned. A plurality of connection holes (18a) for connecting the negative pressure chamber and the exterior are formed in the attachment surface. The sponge part contains a material having semi-open/semi-closed cells. One suction hole (26) connected to the plurality of connection holes, and an edge portion (28) surrounding the suction hole are formed in the sponge part. The height (H1) of the edge portion in the suction direction is longer than the height difference (H2) of the surface of the object to be suctioned.

Classes IPC  ?

  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion

5.

TRANSPORT IMPLEMENT


Numéro d'application JP2026003269
Numéro de publication 2026/191395
Statut Délivré - en vigueur
Date de dépôt 2026-01-30
Date de publication 2026-09-17
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Takeda Atsushi

Abrégé

[Problem] Disclosed is a transport implement with which it is possible to easily perform packing work. [Solution] A transport implement (10) according to the present invention comprises: a dunnage (11) placed on a pallet (80); and support members (20A, 20B) made of foamed resin that are placed on the dunnage (11) and that support cargo (90A, 90B) from below. Further, the support members (20A, 20B) are formed with a pair of first fork insertion holes (21) for lifting the support members (20A, 20B), a second fork insertion hole (22) for lifting the cargo (90A, 90B), and a first positioning recessed portion (26) that opens to outer surfaces and lower surfaces of the support members (20A, 20B). The dunnage (11) is formed with a first positioning protruding portion (16) that engages with the first positioning recessed portion (26) in a concave-convex manner and that is exposed from an outer surface opening (26K).

Classes IPC  ?

  • B65D 81/05 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu spécialement adaptés pour protéger leur contenu des dommages mécaniques maintenant le contenu en position éloignée des parois de l'emballage ou des autres pièces du contenu
  • B65D 19/44 - Éléments ou dispositifs pour placer les objets sur les plates-formes

6.

LOCK UNIT AND LEVEL CORRECTOR


Numéro d'application JP2026004409
Numéro de publication 2026/191422
Statut Délivré - en vigueur
Date de dépôt 2026-02-06
Date de publication 2026-09-17
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kunita Akihisa

Abrégé

A lock unit (22) comprises: a first bush (28) through which a rod (20) extending in the axial direction is inserted; a second bush (30) which is disposed so as to be spaced apart from the first bush (28) in the axial direction and through which the rod (20) is inserted; and a lock mechanism (42) which presses a braking member against the rod (20) in the direction intersecting the axial direction between the first bush (28) and the second bush (30) so as to generate a holding force between the rod (20) and each of the first bush (28) and the second bush (30).

Classes IPC  ?

  • F16D 63/00 - Freins non prévus ailleursFreins combinant plusieurs des types mentionnés dans les groupes
  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion

7.

CLIP-TYPE CONNECTOR AND DEVICE


Numéro d'application 19679743
Statut En instance
Date de dépôt 2026-05-17
Date de la première publication 2026-09-17
Propriétaire SMK Corporation (Japon)
Inventeur(s) Koyama, Yuki

Abrégé

A clip-type connector includes: a base portion having a main surface; a wall portion extending upright from the base portion; a first elastic portion and a second elastic portion, the first elastic portion and the second elastic portion being located on a side of the wall portion opposite to the base portion and separated from each other in a direction along the main surface; a coupling portion that couples the first elastic portion and the second elastic portion, the coupling portion facing the main surface and being located on a side of the first elastic portion and the second elastic portion opposite to the wall portion; and a first extension portion between the first elastic portion and the second elastic portion, the first extension portion extending from the coupling portion toward the wall portion.

Classes IPC  ?

  • H01R 11/22 - Pièces d'extrémité se terminant par une pince à ressort
  • H01R 4/18 - Connexions conductrices de l'électricité entre plusieurs organes conducteurs en contact direct, c.-à-d. se touchant l'un l'autreMoyens pour réaliser ou maintenir de tels contactsConnexions conductrices de l'électricité ayant plusieurs emplacements espacés de connexion pour les conducteurs et utilisant des organes de contact pénétrant dans l'isolation effectuées uniquement par torsion, enroulage, pliage, sertissage ou autre déformation permanente par sertissage
  • H01R 4/48 - Connexions par serrageConnexions par ressort utilisant un ressort, un clip, ou un autre organe élastique
  • H01R 43/027 - Appareils ou procédés spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation de connecteurs de lignes ou de collecteurs de courant ou pour relier les conducteurs électriques pour connecter des conducteurs au moyen de pinces

8.

SOLENOID PUMP


Numéro d'application JP2025044172
Numéro de publication 2026/186261
Statut Délivré - en vigueur
Date de dépôt 2025-12-17
Date de publication 2026-09-10
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Okita Yuzuru
  • Suzuki Takamitsu
  • Kohno Masashi

Abrégé

A body (12, 30) of a solenoid pump (10) is provided with an input-side valve seat (22) and an output-side valve seat (24), and a movable unit (38) includes a diaphragm valve (40) and a movable iron core (44). The diaphragm valve abuts against the input-side valve seat and the output-side valve seat, a pump chamber (46) is formed between the diaphragm valve and the body, and the input-side valve seat is formed at a position closer to the diaphragm valve than the output-side valve seat.

Classes IPC  ?

  • F04B 17/04 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs électriques utilisant des solénoïdes
  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant

9.

MAGNET GRIPPER


Numéro d'application JP2026006916
Numéro de publication 2026/186556
Statut Délivré - en vigueur
Date de dépôt 2026-02-25
Date de publication 2026-09-10
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yajima Hisashi
  • Ando Mizuki

Abrégé

A magnet gripper (10), in which a magnetic flux passing through a top yoke (34) changes by the operation of a magnetic flux control mechanism, is provided with a columnar center pole (54) comprising a ferromagnetic body. One end surface of the center pole faces an end surface of the top yoke, and the other end of the center pole has a workpiece suction surface (58).

Classes IPC  ?

  • H01F 7/02 - Aimants permanents
  • H01F 7/20 - Électro-aimantsActionneurs comportant des électro-aimants sans armature

10.

FLUID SUPPLY CONTROL DEVICE


Numéro d'application JP2025007285
Numéro de publication 2026/181310
Statut Délivré - en vigueur
Date de dépôt 2025-02-28
Date de publication 2026-09-03
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Fujiwara Yuto

Abrégé

A fluid supply control device (12) comprises: a first fluid control unit (30) that supplies a driving fluid to a first chamber (R1) in an actuator (14); a second fluid control unit (32) into which flows a second discharge fluid discharged from a second chamber (R2) in the actuator; a flow path switching unit (34) that causes the driving fluid to flow into one of the first fluid control unit and the second fluid control unit by switching a flow path; and a switching control unit (36) that causes the flow path switching unit to switch the flow path into which the driving fluid flows if a second chamber pressure (P2) in the second chamber is lower than a prescribed pressure (Pt).

Classes IPC  ?

  • F15B 11/04 - Systèmes comportant essentiellement des moyens particuliers pour commander la vitesse ou la puissance d'un organe de sortie pour commander la vitesse

11.

FLUID SUPPLY CONTROL DEVICE AND DOOR DRIVE SYSTEM


Numéro d'application JP2025034914
Numéro de publication 2026/181388
Statut Délivré - en vigueur
Date de dépôt 2025-10-01
Date de publication 2026-09-03
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Fujiwara Yuto

Abrégé

A fluid supply control device (12) is provided with: a flow path switching unit (34) to which a first flow path (L1) and a second flow path (L2) are connected, the first flow path (L1) being connected to a first chamber (R1) in an actuator (14) and having an inflow of a driving fluid supplied to the first chamber, the second flow path (L2) being connected to a second chamber (R2) in the actuator (14) and having an inflow of the driving fluid supplied to the second chamber, the flow path switching unit (34) supplying the driving fluid to the first chamber or the second chamber by switching the flow paths; and a switching control unit (36) which causes the flow path switching unit to switch the flow path into which the driving fluid is caused to flow when a second chamber internal pressure (P2) in the second chamber becomes lower than a predetermined pressure (Pt).

Classes IPC  ?

  • F15B 20/00 - Dispositions propres à la sécurité pour systèmes de manœuvre utilisant les fluidesUtilisation des dispositifs de sécurité dans les systèmes de manœuvre utilisant des fluidesMesures d'urgence pour les systèmes de manœuvre utilisant des fluides

12.

MAGNET GRIPPER


Numéro d'application JP2025041774
Numéro de publication 2026/181445
Statut Délivré - en vigueur
Date de dépôt 2025-12-01
Date de publication 2026-09-03
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yajima Hisashi
  • Wakamatsu Shuhei

Abrégé

A magnet gripper (10) includes: a permanent electromagnet (M) having a first permanent magnet (12), a second permanent magnet (14), and a coil (16); a yoke (18); and pole pieces (20). The yoke (18) is in contact with the second permanent magnet (14). The pole piece (20) has a contact portion (20c) in contact with the yoke (18), and a holding portion (20h) extending from the contact portion (20c). A magnetic substance W can be held by magnetic force by end portions (20e) of the holding portions, the end portion being spaced apart from the contact portion (20c) in an extending direction (De) in which the holding portion (20h) extends from the contact portion (20c).

Classes IPC  ?

  • H02N 15/00 - Dispositifs de maintien ou de lévitation utilisant l'attraction ou la répulsion magnétique, non prévus ailleurs
  • H01F 7/02 - Aimants permanents

13.

LOCK UNIT AND LEVEL CORRECTOR


Numéro d'application JP2026004408
Numéro de publication 2026/181667
Statut Délivré - en vigueur
Date de dépôt 2026-02-06
Date de publication 2026-09-03
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kazama Akihiro

Abrégé

A lock unit (22) comprises a first lock piston (36) and a lock ring (42) inside a first cylinder chamber (26). The lock ring (42) is disposed in a first tapered hole (36a) of the first lock piston (36) and has a diameter which reduces as the axial position changes to thereby fasten a rod (20) by wedge effect. The lock ring (42) has a plurality of lock pieces (44) each having an arc-shaped cross section. The lock pieces (44) occupy an angular range of less than 360° in the circumferential direction inside the first tapered hole (36a). The lock pieces (44) adjacent to each other form therebetween a gap (44c) that enables the lock pieces (44) to move in the circumferential direction.

Classes IPC  ?

  • F16D 63/00 - Freins non prévus ailleursFreins combinant plusieurs des types mentionnés dans les groupes
  • F15B 15/26 - Mécanismes de blocage
  • F16D 65/18 - Mécanismes d'actionnement pour freinsMoyens pour amorcer l'opération de freinage à une position prédéterminée disposés dans, ou sur le frein adaptés pour rapprocher les organes par traction
  • F16D 121/02 - Pression de fluide
  • F16D 127/02 - Mécanismes de desserrage ou de relâchement

14.

POSITION DETECTION SENSOR AND BATTERY PACK


Numéro d'application JP2026004452
Numéro de publication 2026/176974
Statut Délivré - en vigueur
Date de dépôt 2026-02-06
Date de publication 2026-08-27
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Kanda Yusuke
  • Oshima Yuta

Abrégé

A position detection sensor (10) can detect the position of a detection target while being attached to an attachment target (200). Said position detection sensor comprises: a sensor body (12) that is attached to an attachment target; and a battery pack (14) that is detachably attached to the sensor body, wherein the battery pack includes a battery (64) for supplying power to the sensor body, a battery substrate (66) to which the battery is attached, and a covering portion (70) which has electrical insulation properties and which integrally covers the battery and the battery substrate.

Classes IPC  ?

  • G01D 5/12 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens électriques ou magnétiques
  • H01M 50/202 - Boîtiers ou cadres autour du boîtier primaire d’une seule cellule ou d’une seule batterie
  • H01M 50/244 - Boîtiers secondairesBâtisDispositifs de suspensionDispositifs de manutentionSupports caractérisés par leur procédé de montage
  • H01M 50/296 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les bornes des blocs de batterie

15.

BATTERY-TYPE SENSOR DEVICE


Numéro d'application JP2025043668
Numéro de publication 2026/172645
Statut Délivré - en vigueur
Date de dépôt 2025-12-15
Date de publication 2026-08-20
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Kanda Yusuke
  • Gando Takashi

Abrégé

A battery-type sensor device (10) comprises: a receiver (26) that receives wireless signals; a reception control unit (34) that controls the receiver and puts the receiver in a state of being capable of receiving wireless signals at a reception cycle (T1) equivalent to a first cycle; and a setting unit (36) that, if the receiver cannot receive a specific wireless signal for a prescribed period or cannot continuously receive a specific wireless signal a prescribed number of times, sets the reception cycle to be a second cycle longer than the first cycle.

Classes IPC  ?

16.

4BAR FACTORY


Numéro d'application 1931836
Statut Enregistrée
Date de dépôt 2026-03-18
Date d'enregistrement 2026-03-18
Propriétaire SMC Corporation (Japon)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
  • 37 - Services de construction; extraction minière; installation et réparation
  • 41 - Éducation, divertissements, activités sportives et culturelles
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Metal pipe fittings for compressed air pipes; metal couplings for flexible tubing; valve manifolds of metal for use with hydraulic and pneumatic systems; joints and manifolds of metal for compressed pneumatic and hydraulic equipment; metal washdown, spray nozzles for commercial and industrial use; valves of metal, namely, smooth vent valves for fluid, other than parts of machines; metal slit valves for fluid, other than parts of machines; manually air operated metal valves; manually operated metal finger valves; manually operated metal hand valves; multifunctional manually operated metal valves; manually operated metal pressure release valves; manually operated metal angle valves; manually operated metal vacuum valves; manually operated metal straight valves; manually operated metal smooth vent valves; manually operated metal drain valves; manually operated metal slit valves; floating joint connectors of metal; air storage tanks of metal, not for use in scuba diving; cylinders of metal for compressed air, gas and liquid, sold empty. Pneumatic valve actuators; compressed air machine components, namely, cylinders, valves, and air grips; valves being parts of machines operated pneumatically and by air; pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems being sold as a unit with manufacturing machines; pressure reducers as parts of machines; back pressure valves as parts of machines; pressure transducers as parts of machines; pressure switches as parts of machines; pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems sold as a unit with manufacturing machines; pressure regulators being parts of machines; pressure switches being replacement parts of compressed air machines; air filters for pneumatic controls being part of machines; air filters being replacement parts of compressed air machines; air compressors; gas compressors; compressors for machines; compressors as parts of machines, motors and engines; pneumatic air preparation equipment, namely, airline filters, lubricators, and regulators, all being parts of machines; pneumatic linear actuators, other than for land vehicles; parts for pneumatic blow guns, namely, inflator tips, inflator valves, valve adapters, nozzles, nipples, couplers, connectors and pivots; rotary compressors; rotary blowers; rotary pumps; pneumatic lubricators, pneumatic and hydraulic valves for use in machines, pneumatic and hydraulic actuators, pneumatic and hydraulic filters for use in machines, pneumatic and electric positioners, and pneumatic and hydraulic parts for all of the above; filters for hydraulic machines; filter parts being parts of pneumatic filters for industrial automation machines, namely, filter elements and bowls; silencers for pneumatic components of industrial automation machines; air operated valves being parts of machines; finger valves being parts of machines; hand valves, being parts of machines; multi-functional valves being parts of machines; non-electric couplers being parts of machines sold in combination with pneumatic and hydraulic equipment; compressed air cylinders being pneumatic control devices for industrial automation machines; residual pressure released valves being parts of machines; check valves being parts of machines; exhaust valves being parts of machines; safety speed control valves being parts of machines; air saving valves being parts of machines; air filters for mechanical purposes; pneumatic lubrication machines; vacuum regulators being parts of machines; electro pneumatic and hydraulic regulators being parts of machines; electronic vacuum regulators being parts of machines; booster regulators being parts of machines; electro pneumatic and hydraulic proportional control valve; ejector valves being parts of machines; free mount cylinders being parts of machines; pneumatically operated regulators; hydraulic cylinders being parts of machines; cylinder auto-switches for machines; electropneumatic positioners being parts of machines; pneumatic positioners being parts of machines; valve positioners being parts of machines; cylinder positioners being parts of machines; dual positioners being parts of machines; lock-up valves sold as a unit for pneumatic instrumentation equipment; actuators for use in switching valves of metal; odor removal filters being parts of machines; hydraulic mechanical and pneumatic controllers including multi-channel controllers, all the foregoing being parts of machines; regulator manifolds being parts of machines for industrial automation machines; vacuum ejectors being parts of machines; pressure control equipment, namely, pressure regulators being parts of machines; flow switches as parts of machines; mechanical valves being parts of machines; pressure regulators for pneumatic systems; pressure relief valves for pneumatic systems; automatic inlet control valves for reciprocating air compressors; pneumatic and hydraulic directional control valves for use in automated production machinery; control valves for regulating the flow or the pressure of gases and liquids, namely, pneumatic regulators, pneumatic relays, pneumatic and hydraulic switches; pneumatically operated micro mist separator regulators; pneumatically operated pressure regulators for industrial automation equipment; pneumatically direct operated precision regulators for industrial automation equipment. Pressure sensors; pressure recorders; pressure gauges; automatic pressure control machines and instruments; manometers being pressure gauges; manifold absolute pressure (MAP) sensors; pressure transmitters; pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems; pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems; testing equipment for measuring the temperature, pressure, position or form of workpieces in a machine tool; pressure indicators; pressure test connectors for testing pressure of fluids in hydraulic or pneumatic systems; control valves for regulating the flow of gases and liquids; pressure indicator plugs for valves; boost gauges; control valves for regulating the flow or the pressure of gases and liquids, namely, pressure and flow switches; cylinder auto-switches, electric; solenoid switches for water, oil, air, high pressure, gas, vacuum, steam and dust collectors; electronic relay valves for controlling gas or fluids; manifolds for electric regulators for industrial automation machines; electronic vacuum regulators; electropneumatic regulators for industrial automation equipment; booster regulator for industrial automation equipment; pressure gauges for clean room; pressure gauges for clean regulator; pressure gauges with switch; electric flow switches for industrial automation machines; downloadable computer software for selection of optimal system models for the operation of air pressure systems; downloadable computer software for analysis of pneumatic energy savings. Pressure regulators for gas installations; pressure regulators for gas pipes and lines; air filters for industrial installations; air filtering installations; bag filters, namely, air filters for industrial use; drain valves sold as a unit for air preparation equipment. Non-metal fittings for flexible compressed air pipes; non-metal couplings for flexible tubing; nonmetallic tube fittings; nylon tubing for connecting pneumatic components. Providing expert advice on the installation, repair and maintenance of pneumatic and hydraulic apparatus and other machinery by way of computer network. Providing recognition by the way of awards and contests to reward participants who demonstrate lower energy consumption and reduced CO2 emissions by reducing air pressure in industrial manufacturing facilities. Software as a service (SAAS) services, namely, hosting software for use by others for selection of optimal system models for the operation of air pressure systems; software as a service (SAAS) services, namely, hosting software for use by others for analysis of pneumatic energy savings; providing expert advice on the design of pneumatic and hydraulic apparatus and other machinery by way of computer network.

17.

CONTROL DEVICE FOR ELECTRIC ACTUATOR, ELECTRIC ACTUATOR SYSTEM, CONTROL METHOD FOR ELECTRIC ACTUATOR, AND PROGRAM


Numéro d'application JP2026002767
Numéro de publication 2026/168239
Statut Délivré - en vigueur
Date de dépôt 2026-01-28
Date de publication 2026-08-13
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Watanabe Hirofumi
  • Inagaki Kaito

Abrégé

A control device (14) for an electric actuator (12) including a drive device (100) provided with a moving element (106) and a motor (200) that moves the moving element comprises: a determination unit (26) that determines, on the basis of a signal from a magnetic sensor (208) output in accordance with the rotation of a rotor (204) of the motor, whether the moving element has reached a preset braking start position (PB) in front of an end (PE) of the movement range of the moving element; and a braking control unit (30) that controls the motor so as to reduce the movement velocity (V) of the moving element if the determination unit has determined that the moving element has reached the braking start position.

Classes IPC  ?

  • H02P 3/06 - Dispositions pour l'arrêt ou le ralentissement de moteurs, génératrices électriques ou de convertisseurs dynamo-électriques pour arrêter ou ralentir individuellement un moteur dynamo-électrique ou un convertisseur dynamo-électrique

18.

MOTOR CONTROL DEVICE, MOTOR CONTROL METHOD, AND PROGRAM


Numéro d'application JP2026002768
Numéro de publication 2026/168240
Statut Délivré - en vigueur
Date de dépôt 2026-01-28
Date de publication 2026-08-13
Propriétaire
  • SMC CORPORATION (Japon)
  • MABUCHI MOTOR CO., LTD. (Japon)
Inventeur(s)
  • Watanabe Hirofumi
  • Inagaki Kaito
  • Hirose Koji
  • Arai Shoya
  • Takamori Yasuyuki

Abrégé

A motor control device (14) for controlling a motor (200) that moves a mover (106) comprises a control unit (30) that applies a short brake to the motor at a position right before the mover comes into contact with an object. A motor control method for controlling a motor that moves a mover includes a control step (S4) for applying a short brake to the motor at a position right before the mover comes into contact with an object. This program causes a computer to execute the motor control method.

Classes IPC  ?

  • H02P 3/22 - Dispositions pour l'arrêt ou le ralentissement de moteurs, génératrices électriques ou de convertisseurs dynamo-électriques pour arrêter ou ralentir individuellement un moteur dynamo-électrique ou un convertisseur dynamo-électrique pour arrêter ou ralentir un moteur à courant alternatif par freinage sur court-circuit ou sur résistance
  • H02P 6/24 - Dispositions pour l'arrêt

19.

4BAR factory


Numéro d'application 1931833
Statut Enregistrée
Date de dépôt 2026-03-18
Date d'enregistrement 2026-03-18
Propriétaire SMC Corporation (Japon)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
  • 37 - Services de construction; extraction minière; installation et réparation
  • 41 - Éducation, divertissements, activités sportives et culturelles
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Metal pipe fittings for compressed air pipes; metal couplings for flexible tubing; valve manifolds of metal for use with hydraulic and pneumatic systems; joints and manifolds of metal for compressed pneumatic and hydraulic equipment; metal washdown, spray nozzles for commercial and industrial use; valves of metal, namely, smooth vent valves for fluid, other than parts of machines; metal slit valves for fluid, other than parts of machines; manually air operated metal valves; manually operated metal finger valves; manually operated metal hand valves; multifunctional manually operated metal valves; manually operated metal pressure release valves; manually operated metal angle valves; manually operated metal vacuum valves; manually operated metal straight valves; manually operated metal smooth vent valves; manually operated metal drain valves; manually operated metal slit valves; floating joint connectors of metal; air storage tanks of metal, not for use in scuba diving; cylinders of metal for compressed air, gas and liquid, sold empty. Pneumatic valve actuators; compressed air machine components, namely, cylinders, valves, and air grips; valves being parts of machines operated pneumatically and by air; pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems being sold as a unit with manufacturing machines; pressure reducers as parts of machines; back pressure valves as parts of machines; pressure transducers as parts of machines; pressure switches as parts of machines; pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems sold as a unit with manufacturing machines; pressure regulators being parts of machines; pressure switches being replacement parts of compressed air machines; air filters for pneumatic controls being part of machines; air filters being replacement parts of compressed air machines; air compressors; gas compressors; compressors for machines; compressors as parts of machines, motors and engines; pneumatic air preparation equipment, namely, airline filters, lubricators, and regulators, all being parts of machines; pneumatic linear actuators, other than for land vehicles; parts for pneumatic blow guns, namely, inflator tips, inflator valves, valve adapters, nozzles, nipples, couplers, connectors and pivots; rotary compressors; rotary blowers; rotary pumps; pneumatic lubricators, pneumatic and hydraulic valves for use in machines, pneumatic and hydraulic actuators, pneumatic and hydraulic filters for use in machines, pneumatic and electric positioners, and pneumatic and hydraulic parts for all of the above; filters for hydraulic machines; filter parts being parts of pneumatic filters for industrial automation machines, namely, filter elements and bowls; silencers for pneumatic components of industrial automation machines; air operated valves being parts of machines; finger valves being parts of machines; hand valves, being parts of machines; multi-functional valves being parts of machines; non-electric couplers being parts of machines sold in combination with pneumatic and hydraulic equipment; compressed air cylinders being pneumatic control devices for industrial automation machines; residual pressure released valves being parts of machines; check valves being parts of machines; exhaust valves being parts of machines; safety speed control valves being parts of machines; air saving valves being parts of machines; air filters for mechanical purposes; pneumatic lubrication machines; vacuum regulators being parts of machines; electro pneumatic and hydraulic regulators being parts of machines; electronic vacuum regulators being parts of machines; booster regulators being parts of machines; electro pneumatic and hydraulic proportional control valve; ejector valves being parts of machines; free mount cylinders being parts of machines; pneumatically operated regulators; hydraulic cylinders being parts of machines; cylinder auto-switches for machines; electropneumatic positioners being parts of machines; pneumatic positioners being parts of machines; valve positioners being parts of machines; cylinder positioners being parts of machines; dual positioners being parts of machines; lock-up valves sold as a unit for pneumatic instrumentation equipment; actuators for use in switching valves of metal; odor removal filters being parts of machines; hydraulic mechanical and pneumatic controllers including multi-channel controllers, all the foregoing being parts of machines; regulator manifolds being parts of machines for industrial automation machines; vacuum ejectors being parts of machines; pressure control equipment, namely, pressure regulators being parts of machines; flow switches as parts of machines; mechanical valves being parts of machines; pressure regulators for pneumatic systems; pressure relief valves for pneumatic systems; automatic inlet control valves for reciprocating air compressors; pneumatic and hydraulic directional control valves for use in automated production machinery; control valves for regulating the flow or the pressure of gases and liquids, namely, pneumatic regulators, pneumatic relays, pneumatic and hydraulic switches; pneumatically operated micro mist separator regulators; pneumatically operated pressure regulators for industrial automation equipment; pneumatically direct operated precision regulators for industrial automation equipment. Pressure sensors; pressure recorders; pressure gauges; automatic pressure control machines and instruments; manometers being pressure gauges; manifold absolute pressure (MAP) sensors; pressure transmitters; pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems; pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems; testing equipment for measuring the temperature, pressure, position or form of workpieces in a machine tool; pressure indicators; pressure test connectors for testing pressure of fluids in hydraulic or pneumatic systems; control valves for regulating the flow of gases and liquids; pressure indicator plugs for valves; boost gauges; control valves for regulating the flow or the pressure of gases and liquids, namely, pressure and flow switches; cylinder auto-switches, electric; solenoid switches for water, oil, air, high pressure, gas, vacuum, steam and dust collectors; electronic relay valves for controlling gas or fluids; manifolds for electric regulators for industrial automation machines; electronic vacuum regulators; electropneumatic regulators for industrial automation equipment; booster regulator for industrial automation equipment; pressure gauges for clean room; pressure gauges for clean regulator; pressure gauges with switch; electric flow switches for industrial automation machines; downloadable computer software for selection of optimal system models for the operation of air pressure systems; downloadable computer software for analysis of pneumatic energy savings. Pressure regulators for gas installations; pressure regulators for gas pipes and lines; air filters for industrial installations; air filtering installations; bag filters, namely, air filters for industrial use; drain valves sold as a unit for air preparation equipment. Non-metal fittings for flexible compressed air pipes; non-metal couplings for flexible tubing; nonmetallic tube fittings; nylon tubing for connecting pneumatic components. Providing expert advice on the installation, repair and maintenance of pneumatic and hydraulic apparatus and other machinery by way of computer network. Providing recognition by the way of awards and contests to reward participants who demonstrate lower energy consumption and reduced CO2 emissions by reducing air pressure in industrial manufacturing facilities. Software as a service (SAAS) services, namely, hosting software for use by others for selection of optimal system models for the operation of air pressure systems; software as a service (SAAS) services, namely, hosting software for use by others for analysis of pneumatic energy savings; providing expert advice on the design of pneumatic and hydraulic apparatus and other machinery by way of computer network.

20.

CYLINDER DEVICE


Numéro d'application 19155365
Statut En instance
Date de dépôt 2023-12-08
Date de la première publication 2026-08-13
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Tamura, Ken

Abrégé

A cylinder device includes a guide member fixed to a body; a piston member displaced only in the axial direction; a piston rod displaceable in the circumferential direction and the axial direction; and a conversion mechanism that converts some of the displacement of the piston member to circumferential displacement. The conversion mechanism includes an L-shaped displacement switching groove provided to the guide member; a helical groove provided to the piston member and inclined with respect to the axial direction; and a link pin supported by the piston rod and that moves along the displacement switching groove and the helical groove.

Classes IPC  ?

  • F15B 15/06 - Schéma mécanique de montage caractérisé par les moyens transformant le mouvement de l'élément entraîné par le fluide en mouvement de l'organe terminal qui est actionné pour la transformation mécanique d'un mouvement rectiligne en un mouvement non rectiligne

21.

TEMPERATURE REGULATION DEVICE FOR SEMICONDUCTOR MANUFACTURING DEVICE


Numéro d'application 19158257
Statut En instance
Date de dépôt 2024-02-22
Date de la première publication 2026-08-13
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Niimi, Hirohito
  • Sakaguchi, Tetsuo
  • Takei, Shinpei

Abrégé

A refrigeration circuit includes a compressor; a delivery passage through which refrigerant is delivered from the compressor; a return passage through which refrigerant after temperature regulation is returned to the compressor; first and second circulation passages and through which refrigerant is supplied to a thermal load in a circulating manner; a switching circuit that mutually switches, between the first and second circulation passages, a circulation passage through which refrigerant is delivered to a thermal load and a circulation passage through which refrigerant is received from a thermal load by changing a communication state in which the circulation passages are in communication with the delivery passage and the return passage; a first expansion valve provided in the first circulation passage; and a heat exchanger connected between the first circulation passage and the switching circuit.

Classes IPC  ?

  • F25B 49/02 - Disposition ou montage des dispositifs de commande ou de sécurité pour machines, installations ou systèmes du type à compression
  • F25B 13/00 - Machines, installations ou systèmes à compression, à cycle réversible
  • F25B 41/26 - Disposition des soupapes, p. ex. de soupapes marche-arrêt ou de soupapes de régulation de débit de soupapes d’inversion du flux de fluide
  • H10P 72/00 -

22.

PIPE FITTING


Numéro d'application 19154453
Statut En instance
Date de dépôt 2023-12-13
Date de la première publication 2026-08-06
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Saito, Shuichi
  • Yamanashi, Masanobu
  • Suzuki, Takahiro
  • Takanashi, Akihito

Abrégé

A chuck stored in a sleeve has an engagement piece formed with a claw part capable of being locked to an outer surface of a tube. The sleeve is rotatable between a first rotation position and a second rotation position relative to a body. A pipe fitting includes a cam part that guides the engagement piece along with the rotation of the sleeve in such a way that the distance from the engagement piece to the axial center of the chuck changes. An unlock mechanism removes restriction on the rotation of the sleeve in accordance with the insertion of the tube to a predetermined position.

Classes IPC  ?

  • F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord
  • F16L 19/10 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord avec segments métalliques qui mordent dans la paroi du tuyau le profil du segment étant déformé

23.

Filter


Numéro d'application 30048977
Numéro de brevet D1139820
Statut Délivré - en vigueur
Date de dépôt 2026-02-19
Date de la première publication 2026-08-04
Date d'octroi 2026-08-04
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Maeda, Takuro

24.

CONNECTOR HOUSING


Numéro d'application 19452843
Statut En instance
Date de dépôt 2026-01-19
Date de la première publication 2026-07-30
Propriétaire SMK Corporation (Japon)
Inventeur(s)
  • Takeda, Toshimitsu
  • Makimura, Takanobu
  • Tsujikado, Mieko
  • Taniguchi, Masayuki

Abrégé

A connector housing engageable with and disengageable from a mating housing includes a main body, a housing lever supported by the main body, and a slide lever. The housing lever has a support portion supported by the main body, and an arm extending from the support portion in an engagement direction and formed flexurally displaceable. An operation portion and the arm are supported by the support portion, and are swingable in a seesaw manner. The tip end of the arm has an engagement portion. In a state in which the slide lever is attached at an engagement position, elastic deformation in which the arm is flexed in a separating direction is performed along with contact between the engagement portion and an interference target portion of the mating housing. At the time of engagement with the mating housing, the arm hits the mating housing to emit engagement completion sound.

Classes IPC  ?

  • H01R 13/627 - Fixation du type à action brusque
  • H01R 13/631 - Moyens additionnels pour faciliter l'engagement ou la séparation des pièces de couplage, p. ex. moyens pour aligner ou guider, leviers, pression de gaz pour l'engagement uniquement
  • H01R 13/641 - Moyens pour empêcher, bloquer ou éviter le couplage incorrect par l'indication du couplage incorrectMoyens pour empêcher, bloquer ou éviter le couplage incorrect par l'indication d'un engagement complet ou correct

25.

SENSOR MODULE AND SENSOR DEVICE


Numéro d'application 19144776
Statut En instance
Date de dépôt 2023-01-10
Date de la première publication 2026-07-30
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Ozaki, Norimasa
  • Oshima, Yuta

Abrégé

A sensor module includes an intermediate member, a flexible substrate that is wound around the intermediate member, and a sensor element that comprises a lead part that passes through the flexible substrate and is inserted into the intermediate member. The flexible substrate is wound around the intermediate member so that a first portion of the flexible substrate is superimposed on and in contact with a second portion that differs from the first portion of the flexible substrate; and the lead part passes through the first portion and the second portion and is inserted into the intermediate member.

Classes IPC  ?

  • G01D 5/14 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens électriques ou magnétiques influençant la valeur d'un courant ou d'une tension

26.

Fluid pressure cylinder


Numéro d'application 29854773
Numéro de brevet D1137324
Statut Délivré - en vigueur
Date de dépôt 2022-09-28
Date de la première publication 2026-07-28
Date d'octroi 2026-07-28
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Hariwara, Nobuo

27.

Filter


Numéro d'application 29982404
Numéro de brevet D1134704
Statut Délivré - en vigueur
Date de dépôt 2025-01-06
Date de la première publication 2026-07-14
Date d'octroi 2026-07-14
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Maeda, Takuro

28.

CYLINDER DEVICE


Numéro d'application 19135513
Statut En instance
Date de dépôt 2023-09-12
Date de la première publication 2026-07-09
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Nakajima, Ken
  • Jeoung, Eun-Ho
  • Kim, Seon-Kwan

Abrégé

A cylinder device includes a first cylinder chamber that has a first piston; a second cylinder chamber that has a second piston; a first rod that is connected to the first piston; a second rod that partially overlaps with the first rod in the radial direction and protrudes from a body; and a conversion mechanism that converts displacement of one section in the axial direction of the first rod into displacement in a rotational direction of the second rod, and transmits displacement of another section in the axial direction of the first rod as displacement in the axial direction of the second rod. The second piston is connected to the second rod.

Classes IPC  ?

  • F15B 15/14 - Dispositifs actionnés par fluides pour déplacer un organe d'une position à une autreTransmission associée à ces dispositifs caractérisés par la structure de l'ensemble moteur le moteur étant du type à cylindre droit

29.

FLUID PRESSURE CYLINDER


Numéro d'application 19105902
Statut En instance
Date de dépôt 2022-09-02
Date de la première publication 2026-07-02
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Ono, Ryo

Abrégé

A fluid pressure cylinder includes a cylinder section and an adapter unit detachably mounted to a cylinder tube of the cylinder section. A first input/output port and a second input/output port communicating with a piston chamber are provided in the cylinder tube. A first attachment hole and a second attachment hole are provided in the adapter unit. A first supply/discharge tube and a connected second supply/discharge tube are attached to the first attachment hole and the second attachment hole, respectively.

Classes IPC  ?

  • F15B 15/14 - Dispositifs actionnés par fluides pour déplacer un organe d'une position à une autreTransmission associée à ces dispositifs caractérisés par la structure de l'ensemble moteur le moteur étant du type à cylindre droit
  • F15B 15/28 - Moyens pour indiquer la position, p. ex. fin de course

30.

PERMANENT ELECTROMAGNET SYSTEM, CONTROL DEVICE, AND CONTROL METHOD


Numéro d'application JP2025037952
Numéro de publication 2026/140490
Statut Délivré - en vigueur
Date de dépôt 2025-10-29
Date de publication 2026-07-02
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yajima Hisashi
  • Wakamatsu Shuhei

Abrégé

A permanent electromagnet system (16) comprises a permanent electromagnet (10) and a control device (14). The permanent electromagnet includes first permanent magnets (20), a second permanent magnet (22) having a variable magnetization direction, and coils (24). The control device includes an energization control unit (50) that brings the permanent electromagnet into a released state by causing a first current (I1) of the first magnitude (Ie) to flow through the coil, and brings the permanent electromagnet into an adsorbed state by causing a second current (I2) of the second magnitude (If) to flow through the coil in a direction opposite to that of the first current.

Classes IPC  ?

  • H01F 7/20 - Électro-aimantsActionneurs comportant des électro-aimants sans armature
  • H01F 7/02 - Aimants permanents

31.

CONTROL DEVICE


Numéro d'application JP2025038812
Numéro de publication 2026/140523
Statut Délivré - en vigueur
Date de dépôt 2025-11-05
Date de publication 2026-07-02
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yajima Hisashi
  • Wakamatsu Shuhei

Abrégé

A control device (40) controls a permanent electromagnet (10) having a plurality of first permanent magnets (10a) and a plurality of second permanent magnets (10b) and a coil (10c). The electromagnet (10) can switch, by applying a voltage to the coil, between an adsorption state in which a magnetic material (W) can be attracted and a release state in which the adsorption state is released. The control device (40) includes a grouping unit (70) that divides the plurality of second permanent magnets into a plurality of magnet groups (G), and an energization control unit (72) that sequentially performs energization control for each magnet group by applying a voltage to the coil to change a magnetization direction of the second permanent magnets to a direction corresponding to the adsorption state.

Classes IPC  ?

  • H01F 7/20 - Électro-aimantsActionneurs comportant des électro-aimants sans armature
  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion
  • H01F 7/02 - Aimants permanents

32.

PERMANENT ELECTROMAGNET DEVICE


Numéro d'application JP2025041767
Numéro de publication 2026/140693
Statut Délivré - en vigueur
Date de dépôt 2025-12-01
Date de publication 2026-07-02
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yajima Hisashi
  • Wakamatsu Shuhei

Abrégé

A permanent electromagnet device (10) comprises: a plurality of first permanent magnets (10a); a plurality of second permanent magnets (10b); a coil (10c) capable of reversing a magnetization direction of the second permanent magnets (10b); and a top yoke (10t) that covers, from among two end portions of the second permanent magnet, an end portion (10p) closer to a magnetic body (W). Each of the plurality of first permanent magnets is disposed between two of the top yokes, one and the other of the two top yokes is in contact with one end (10s) and the other end (10n) of the first permanent magnet, and total areas of contact surfaces (Sc, Sce) with the first permanent magnet are the same for the plurality of top yokes.

Classes IPC  ?

  • H01F 7/20 - Électro-aimantsActionneurs comportant des électro-aimants sans armature
  • H01F 7/02 - Aimants permanents

33.

SWITCHING VALVE


Numéro d'application JP2025041066
Numéro de publication 2026/126786
Statut Délivré - en vigueur
Date de dépôt 2025-11-26
Date de publication 2026-06-18
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Edamura Kotaro

Abrégé

[Problem] To provide a switching valve in which the actions of a spool valve and a detent mechanism are synchronized. [Solution] A selector valve 1A has a spool valve part 5 for switching the communication state between a plurality of ports by means of spools 8, 10 accommodated in a valve port 7 via which the ports communicate, first and second drive parts 30, 40 for driving the spools by means of a pilot fluid so as to shift the spool valve part to a plurality of switching states, and a detent mechanism part 60 for holding the spool valve part in a specific switching state. The detent mechanism part has an engagement rod 62 movably accommodated in a slide hole 74, a recess 63 provided in a spool, and a detent drive part 64 for causing the engagement rod to engage with and disengage from the recess. The detent drive part has a piston 66, a spring member 67 for biasing the engagement rod to the recess side, a pressure chamber 61b for withdrawing the engagement rod from the recess, and a communication flow passage 68 via which a pilot flow passage 44 and the second chamber 61b communicate.

Classes IPC  ?

  • F16K 35/00 - Dispositions empêchant la mise en action accidentelle ou non autorisée
  • F16K 11/07 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des tiroirs à éléments de fermeture glissant linéairement à glissières cylindriques

34.

LEAKAGE DETECTION DEVICE


Numéro d'application 18993304
Statut En instance
Date de dépôt 2023-04-05
Date de la première publication 2026-06-18
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Katsumata, Koichi
  • Oshima, Yuta

Abrégé

A leakage detection device for detecting leakage of compressed gas includes a microphone that collects an ultrasonic signal which is converted into an electrical signal and outputted. Lock-in amplifiers extract one of the electrical signals having a specific frequency corresponding to a leakage and a calculation circuit calculates a physical amount corresponding to an amplitude value of the signal having the specific frequency. A notification device provides a notification to a user depending on the physical amount calculated by the calculation circuit.

Classes IPC  ?

  • G01M 3/24 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par détection de la présence du fluide à l'emplacement de la fuite en utilisant des vibrations infrasonores, sonores ou ultrasonores

35.

Electric gripper


Numéro d'application 29907154
Numéro de brevet D1130052
Statut Délivré - en vigueur
Date de dépôt 2024-01-04
Date de la première publication 2026-06-16
Date d'octroi 2026-06-16
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kobayashi, Shunya

36.

Ion generation module for ionizer


Numéro d'application 29958808
Numéro de brevet D1130659
Statut Délivré - en vigueur
Date de dépôt 2024-08-21
Date de la première publication 2026-06-16
Date d'octroi 2026-06-16
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Fukawa, Takehito

37.

UNIT MODULE, MODULE SYSTEM, AND COMMUNICATION MODULE


Numéro d'application JP2024042141
Numéro de publication 2026/115674
Statut Délivré - en vigueur
Date de dépôt 2024-11-28
Date de publication 2026-06-04
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kobayashi Yuri

Abrégé

A unit module (18) comprises: a signal processing unit (76) that processes and outputs a first signal; a data communication unit (68) that can perform data communication via a pair of voltage lines (L); a termination resistor (Rt) that is interposed between the pair of voltage lines; a switch (W) that is connected in series to the termination resistor; a switch control unit (70) that switches the switch between an on state and an off state; a communication control unit (78) that causes unit module data to be transmitted by data communication; and a connection identification circuit (66) that outputs the first signal from a subsequent-stage adjacent module or the signal processing unit.

Classes IPC  ?

38.

VALVE DEVICE


Numéro d'application JP2025038740
Numéro de publication 2026/110609
Statut Délivré - en vigueur
Date de dépôt 2025-11-05
Date de publication 2026-05-28
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Shirakawa Satoru

Abrégé

A valve device (10) comprises a housing (12) that has a flow hole (24) through which a fluid flows, a piezo-actuator (46) that is accommodated in the housing and can open/close an opening of the flow hole, a holding member (50) that holds the piezo-actuator, and a screw member (52) that supports the holding member on the housing such that the position of the holding member can be adjusted. The screw member is screwed into a screw hole (82) that is formed in the holding member.

Classes IPC  ?

  • F16K 31/02 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques

39.

PIEZOELECTRIC VALVE


Numéro d'application 19343296
Statut En instance
Date de dépôt 2025-09-29
Date de la première publication 2026-05-21
Propriétaire
  • TDK Corporation (Japon)
  • SMC CORPORATION (Japon)
Inventeur(s)
  • Ohta, Yoshiki
  • Sakamoto, Hideya
  • Abe, Ryunosuke
  • Watanabe, Takashi

Abrégé

A piezoelectric valve includes a housing provided with an inflow hole and an outflow hole for air, and a valve element disposed in the housing and configured to open and close the inflow hole. The valve element is configured by a piezoelectric unit including a plate-shaped piezoelectric element and a diaphragm on which the piezoelectric element is stacked. The inflow hole does not overlap the piezoelectric element but overlaps only the diaphragm when viewed from a stacking direction of the piezoelectric element in the piezoelectric unit.

Classes IPC  ?

  • F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos
  • F16K 7/16 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol disposé pour être déformé contre un siège plat le diaphragme étant actionné mécaniquement, p. ex. par une tige filetée ou par came

40.

PIEZOELECTRIC VALVE


Numéro d'application 19343967
Statut En instance
Date de dépôt 2025-09-29
Date de la première publication 2026-05-21
Propriétaire
  • TDK Corporation (Japon)
  • SMC Corporation (Japon)
Inventeur(s)
  • Ohta, Yoshiki
  • Sakamoto, Hideya
  • Abe, Ryunosuke
  • Watanabe, Takashi

Abrégé

A piezoelectric valve is a piezoelectric valve driven by a DC component, and includes a plurality of piezoelectric elements electrically connected in parallel via electrodes made of a metal-plated film; a conductive diaphragm joined to the plurality of piezoelectric elements via the electrodes; and a resistor electrically connected to the plurality of piezoelectric elements, and an electric resistance value of the resistor is less than an insulation resistance value of each of the piezoelectric elements.

Classes IPC  ?

  • F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos
  • F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
  • H10N 30/00 - Dispositifs piézo-électriques ou électrostrictifs
  • H10N 30/063 - Formation d’interconnexions, p. ex. d’électrodes de connexion de parties piézo-électriques ou électrostrictives multicouches
  • H10N 30/80 - Détails de structure
  • H10N 30/87 - Électrodes ou interconnexions, p. ex. connexions électriques ou bornes

41.

VALVE DEVICE


Numéro d'application JP2024040853
Numéro de publication 2026/105338
Statut Délivré - en vigueur
Date de dépôt 2024-11-18
Date de publication 2026-05-21
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kawamura Shunsuke

Abrégé

This valve device (10) comprises: a body (12) having a plurality of ports (26) through which a fluid flows; a valve element (16); and an operation part (24) that drives the valve element. The valve element is driven by rotating the operation part in a state in which the operation part is pushed into the body. The operation part includes an insertion part (108) having a space (114) into which a portion of the body is inserted when the operation part is pushed into the body. A plurality of through-holes (124) that communicate with the space are formed in the insertion part. A lock member (300) for preventing the insertion of a portion of the body into the space can be attached to the plurality of through-holes.

Classes IPC  ?

  • F16K 35/06 - Dispositions empêchant la mise en action accidentelle ou non autorisée utilisant un organe de commande ou de verrouillage démontable, p. ex. une clé

42.

DETERMINATION DEVICE


Numéro d'application JP2024038514
Numéro de publication 2026/094138
Statut Délivré - en vigueur
Date de dépôt 2024-10-29
Date de publication 2026-05-07
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Katsumata Koichi
  • Oshima Yuta

Abrégé

A determination device (30) for determining the number (N) of magnetic bodies (W) attracted to a magnet gripper (10) comprises: a coil (30c); a decision unit (74) that, on the basis of a first voltage (V1), which is the value of the coil voltage (Vc) at a time point (Tbe) at which a prescribed time (Tb) has elapsed since the start of excitation of the coil, decides on a second voltage (V2) lower than the first voltage; and a determination unit (78) that determines whether the number of the magnetic bodies is one on the basis of the time required (Td) for the value of the coil voltage to reach the second voltage after the coil has been excited, degaussed, and then excited again.

Classes IPC  ?

  • G01R 33/12 - Mesure de propriétés magnétiques des articles ou échantillons de solides ou de fluides
  • B66C 1/08 - Circuits à cet effet

43.

CONTROL DEVICE, MAGNET GRIPPER, SENSOR, AND CONTROL METHOD


Numéro d'application JP2025032439
Numéro de publication 2026/094457
Statut Délivré - en vigueur
Date de dépôt 2025-09-16
Date de publication 2026-05-07
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yajima Hisashi
  • Wakamatsu Shuhei

Abrégé

A control device (12) controls an electro-permanent magnet (10) which is provided with a first permanent magnet (10a), a second permanent magnet (10b), and a coil (10c), and in which the magnetization direction of the second permanent magnet (10b) is reversed when a drive voltage (Vd) is applied to the coil (10c). The control device (12) is provided with: a switching control unit (42) which switches between a detection voltage application control in which a detection voltage (Vt) is applied to the coil (10c), and a detection voltage application stop control in which the application of the detection voltage (Vt) is stopped; and a detection unit (46) which, when the detection voltage (Vt) is applied to the coil (10c), detects whether or not a magnetic body (W) is present on the basis of a measured value (Mv) of a coil current (Ic).

Classes IPC  ?

  • H01F 7/20 - Électro-aimantsActionneurs comportant des électro-aimants sans armature
  • B66C 1/06 - Éléments ou dispositifs de prise de la charge adjoints aux mécanismes de levage, de descente ou de halage, ou adaptés pour être utilisés avec ces mécanismes et transmettant les efforts à des articles ou à des groupes d'articles par moyens magnétiques électromagnétiques
  • H01F 7/02 - Aimants permanents

44.

DETERMINATION DEVICE


Numéro d'application JP2024038093
Numéro de publication 2026/088412
Statut Délivré - en vigueur
Date de dépôt 2024-10-25
Date de publication 2026-04-30
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Imai Takanori
  • Furukawa Junichi

Abrégé

A determination device (10) performs determination regarding detection signals (D, D1, D2) of a first detection sensor (22, 22a) and a second detection sensor (22, 22b) attached to mutually different positions (P1, P2) of an actuator (20) having a moving body (24). The determination device comprises a notification unit (78) that, when a determination unit (74) determines that both the detection signal of the first detection sensor and the detection signal of the second detection sensor are a prescribed type of signal indicating HIGH or LOW, performs notification corresponding to the determination result by the determination unit.

Classes IPC  ?

45.

SENSOR UNIT


Numéro d'application JP2024037669
Numéro de publication 2026/088313
Statut Délivré - en vigueur
Date de dépôt 2024-10-23
Date de publication 2026-04-30
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Katsumata Koichi
  • Oshima Yuta

Abrégé

A sensor unit (10) comprises: a rod (20) that extends along a first axis (L1); a support part (16) that movably supports the rod (20) in the direction of the first axis (L1); a first return mechanism (24) that returns the position of the rod (20) in the direction of the first axis (L1) to the initial position; a ball joint (36) that is provided at the tip of the rod (20); a sensor module (12) that is attached to the ball joint (36); and a second return mechanism (26) that restricts the rotation range while returning the sensor module (12) to the initial posture.

Classes IPC  ?

  • G01B 21/00 - Dispositions pour la mesure ou leurs détails, où la technique de mesure n'est pas couverte par les autres groupes de la présente sous-classe, est non spécifiée ou est non significative
  • G01B 7/06 - Dispositions pour la mesure caractérisées par l'utilisation de techniques électriques ou magnétiques pour mesurer la longueur, la largeur ou l'épaisseur pour mesurer l'épaisseur

46.

VACUUM GENERATION UNIT WITH SILENCER AND SILENCER THEREOF


Numéro d'application JP2024034553
Numéro de publication 2026/069553
Statut Délivré - en vigueur
Date de dépôt 2024-09-27
Date de publication 2026-04-02
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Ozaki Mitsutoshi

Abrégé

[Problem] To provide a vacuum generation unit capable of reducing exhaust resistance of a silencer and suppressing the flow rate of compressed air required for generating negative pressure. [Solution] The vacuum generation unit 40 is provided between a manifold block 11 and a switching valve unit 30 and generates negative pressure using compressed air supplied through the switching valve unit 30, the vacuum generation unit comprising: a casing 41 including a first air supply port 42, an ejector part 50, a first negative pressure output port 43, and an exhaust port 44; and a silencer 70 provided to the exhaust port. The silencer has a silencing part 71 comprising a silencing flow passage 72 composed of a silencing material 73, and an exhaust part 80 that discharges exhaust gas silenced by the silencing part to the atmosphere. An exhaust space 82 that is connected to an outlet opening of the silencing flow passage, and an exhaust flow passage 83 that causes the exhaust space to communicate with the outside are formed in an exhaust body of the exhaust part. The flow passage cross-sectional area of the exhaust space is larger than that of the outlet opening, and the exhaust space is formed in a vertically long shape in which the height is greater than the width.

Classes IPC  ?

  • F04F 5/20 - Pompes à jet, p. ex. dispositifs dans lesquels le flux est produit par la chute de pression causée par la vitesse d'un autre fluide le fluide inducteur étant un fluide compressible déplaçant des fluides compressibles pour les évacuer
  • F16K 47/02 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour empêcher les coups de bélier ou le bruit

47.

NEGATIVE PRESSURE GENERATING DEVICE


Numéro d'application JP2024035018
Numéro de publication 2026/069695
Statut Délivré - en vigueur
Date de dépôt 2024-09-30
Date de publication 2026-04-02
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Kashima Katsuhiko
  • Nishimura Toshikatsu
  • Morita Kosuke
  • Aoyama Masaaki

Abrégé

A negative pressure generation device (10) comprises: an intake flow path (20); a compressed air flow path (36) that surrounds the periphery of the intake flow path (20); an exhaust flow path (52) that is provided downstream of the intake flow path (20) and the compressed air flow path (36); and a supply flow path (14a) that supplies compressed air to the compressed air flow path (36). A first center line (B) of the supply flow path (14a) is connected to the compressed air flow path (36) in a direction that does not intersect a central axial line (C).

Classes IPC  ?

  • F04F 5/42 - Pompes à jet, p. ex. dispositifs dans lesquels le flux est produit par la chute de pression causée par la vitesse d'un autre fluide caractérisées par le fait que le flux d'entrée du fluide inducteur est radial ou tangentiel par rapport au flux de sortie

48.

NEGATIVE-PRESSURE-GENERATING DEVICE


Numéro d'application JP2024035025
Numéro de publication 2026/069701
Statut Délivré - en vigueur
Date de dépôt 2024-09-30
Date de publication 2026-04-02
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Kashima Katsuhiko
  • Nishimura Toshikatsu
  • Morita Kosuke
  • Aoyama Masaaki

Abrégé

A negative-pressure-generating device (10) comprises: an air intake flow passage (54); a compressed air flow passage (50) surrounding the periphery of the air intake flow passage (54); an exhaust flow passage (56) provided downstream of the air intake flow passage (54) and the compressed air flow passage (50); and a supply flow passage (24a) for supplying compressed air to the compressed air flow passage (50). The compressed air flow passage (50) is provided with a flow guide member (58) that guides the flow of compressed air in a spiral shape centered on a central axis (C).

Classes IPC  ?

  • F04F 5/20 - Pompes à jet, p. ex. dispositifs dans lesquels le flux est produit par la chute de pression causée par la vitesse d'un autre fluide le fluide inducteur étant un fluide compressible déplaçant des fluides compressibles pour les évacuer

49.

Residual pressure release valve


Numéro d'application 29983253
Numéro de brevet D1118842
Statut Délivré - en vigueur
Date de dépôt 2025-01-09
Date de la première publication 2026-03-17
Date d'octroi 2026-03-17
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kawamura, Shunsuke

50.

INPUT DEVICE


Numéro d'application JP2025030667
Numéro de publication 2026/053883
Statut Délivré - en vigueur
Date de dépôt 2025-09-01
Date de publication 2026-03-12
Propriétaire SMK CORPORATION (Japon)
Inventeur(s)
  • Kataoka Yasutaka
  • Imai Haruka

Abrégé

[Problem] To provide an input device in which a switch independent of a switch on a main surface can be provided on a side surface. [Solution] This input device is provided with: a substrate having a main surface and at least one side surface substantially orthogonal to the main surface; and a side surface detection electrode portion that is formed on the side surface and detects a change in capacitance.

Classes IPC  ?

  • H01H 36/00 - Interrupteurs actionnés par la variation du champ magnétique ou champ électrique, p. ex. par le changement de la position relative d'un aimant et d'un interrupteur, par écran
  • E03D 9/08 - Dispositifs de douches pulvérisées ascendantes, situés dans la cuvetteModifications de la cuvette pour l'utilisation de tels dispositifs

51.

HYDRAULIC CYLINDER


Numéro d'application 19105912
Statut En instance
Date de dépôt 2022-09-02
Date de la première publication 2026-03-12
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kazama, Akihiro

Abrégé

A hydraulic cylinder includes a cylinder housing having an accommodation chamber, and a cylinder unit. The cylinder housing has a first securing portion. The cylinder unit has a piston, a piston rod with which the piston is provided, a sleeve for accommodating the piston and a second securing portion. The cylinder unit is accommodated in the accommodation chamber. The cylinder unit can be detachably attached to the cylinder housing due to engagement of the first securing portion with the second securing portion.

Classes IPC  ?

  • F15B 15/14 - Dispositifs actionnés par fluides pour déplacer un organe d'une position à une autreTransmission associée à ces dispositifs caractérisés par la structure de l'ensemble moteur le moteur étant du type à cylindre droit
  • F15B 15/28 - Moyens pour indiquer la position, p. ex. fin de course

52.

GATE AND SLIT VALVE


Numéro d'application JP2025017865
Numéro de publication 2026/053500
Statut Délivré - en vigueur
Date de dépôt 2025-05-16
Date de publication 2026-03-12
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kimori Naoki

Abrégé

A gate (28) comprises: a gate body (42) integrally formed from a metal material; a shaft attachment hole (60) which is positioned at the center of the gate body (42) in a width direction and to which a shaft (38) is attached; a slit hole (58) formed between the shaft attachment hole (60) and a seal surface (46) and extending in the width direction; and a rear surface (56) constituting a rear part of the gate body (42) in a front–rear direction.

Classes IPC  ?

  • F16K 3/02 - Robinets-vannes ou tiroirs, c.-à-d. dispositifs obturateurs dont l'élément de fermeture glisse le long d'un siège pour l'ouverture ou la fermeture à faces d'obturation planesGarnitures d'étanchéité à cet effet
  • F16K 39/04 - Dispositifs pour relâcher la pression sur les faces d'un joint d'étanchéité dans le cas de tiroirs

53.

MAGNET GRIPPER


Numéro d'application JP2025029482
Numéro de publication 2026/053753
Statut Délivré - en vigueur
Date de dépôt 2025-08-22
Date de publication 2026-03-12
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Yajima Hisashi

Abrégé

This magnet gripper (10) grips a workpiece (W) by suction and comprises: a permanent electromagnet (12) that includes a first permanent magnet (12a) and a second permanent magnet (12b); a coil (14) that is wound around the outer periphery of at least the second permanent magnet and can reverse the magnetization direction of the second permanent magnet by the flow of current; a yoke (16) accommodating the permanent electromagnet therein; and a display sheet (30) which changes color when the magnetization direction of the second permanent magnet is reversed, and which has a medium (30a) in which optical crystals of magnetic particles are used.

Classes IPC  ?

54.

MAGNET GRIPPER


Numéro d'application 19312586
Statut En instance
Date de dépôt 2025-08-28
Date de la première publication 2026-03-05
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Yajima, Hisashi

Abrégé

A magnet gripper includes a piston assembly that includes a permanent magnet. An indicator sheet including a print medium in which a photonic crystal is used is attached to a side surface of a cylinder tube.

Classes IPC  ?

  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion

55.

SUCTION DEVICE


Numéro d'application JP2025017513
Numéro de publication 2026/048159
Statut Délivré - en vigueur
Date de dépôt 2025-05-14
Date de publication 2026-03-05
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Groedl Valentin
  • Eusemann Marion
  • Pachnik Peter
  • Peter Thomas
  • Schellaas David

Abrégé

A suction device (10) sucks an object (300) to be sucked using vacuum pressure. The suction device (10) is provided with a base part (14), a first suction pad (12) supported by the base part, a plurality of second suction pads (16) spaced apart from each other around a first axis (Ax1) which is an axis of the first suction pad, and a plurality of arm parts (20) supported by the base part, each of the plurality of second suction pads being supported by the base part via each of the plurality of arm parts, each of the plurality of second suction pads is disposed so that a second axis (Ax2), which is an axis of said second suction pad, is inclined with respect to the first axis.

Classes IPC  ?

  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion
  • A01D 46/30 - Dispositifs robotisés pour cueillir les articles un par un

56.

SUCTIONING DEVICE


Numéro d'application JP2025017514
Numéro de publication 2026/048160
Statut Délivré - en vigueur
Date de dépôt 2025-05-14
Date de publication 2026-03-05
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Groedl Valentin
  • Urban Lars
  • Sugiyama Toru

Abrégé

A suctioning device (10) uses vacuum pressure to suction a to-be-suctioned object (F) and comprises a first suction pad (12) and a second suction pad (14) disposed at the inner side of the first suction pad (12). In a state in which the to-be-suctioned object (F) is not in contact with either the first suction pad (12) or the second suction pad (14), a leading end (30) of the second suction pad (14) protrudes further than a leading end (20) of the first suction pad (12).

Classes IPC  ?

  • A01D 46/30 - Dispositifs robotisés pour cueillir les articles un par un
  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion

57.

MODULE SYSTEM AND EXTERNAL OUTPUT MODULE


Numéro d'application JP2025013530
Numéro de publication 2026/048116
Statut Délivré - en vigueur
Date de dépôt 2025-04-02
Date de publication 2026-03-05
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kobayashi Yuri

Abrégé

A module system (20) includes a safety module (32) and an external output module (36). The external output module has: a first positive input terminal (170a) electrically connected to a positive electrode (26p) of a power supply (26); a negative input terminal (180) electrically connected to a negative electrode (26n) of the power supply; a positive power supply terminal (176) electrically connected to the first positive input terminal and electrically connectable to an external device (22); and a negative power supply terminal (186) electrically connected to the negative input terminal and electrically connectable to the external device.

Classes IPC  ?

  • H02H 7/00 - Circuits de protection de sécurité spécialement adaptés aux machines ou aux appareils électriques de types particuliers ou pour la protection sectionnelle de systèmes de câble ou de ligne, et effectuant une commutation automatique dans le cas d'un changement indésirable des conditions normales de travail
  • G05B 9/02 - Dispositions de sécurité électriques

58.

Valve plate for gate valve


Numéro d'application 29982382
Numéro de brevet D1114189
Statut Délivré - en vigueur
Date de dépôt 2025-01-06
Date de la première publication 2026-02-17
Date d'octroi 2026-02-17
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kimori, Naoki

59.

Valve box


Numéro d'application 29896695
Numéro de brevet D1109701
Statut Délivré - en vigueur
Date de dépôt 2023-07-06
Date de la première publication 2026-01-20
Date d'octroi 2026-01-20
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Phillips, David M.
  • Bregin, Geoffrey M.

60.

Gateway unit


Numéro d'application 29773908
Numéro de brevet D1109098
Statut Délivré - en vigueur
Date de dépôt 2021-03-12
Date de la première publication 2026-01-13
Date d'octroi 2026-01-13
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Ozaki, Norimasa
  • Kunii, Koji

61.

POROUS MICRONEEDLE MANUFACTURING METHOD


Numéro d'application JP2025017103
Numéro de publication 2026/009563
Statut Délivré - en vigueur
Date de dépôt 2025-05-09
Date de publication 2026-01-08
Propriétaire
  • THE UNIVERSITY OF TOKYO (Japon)
  • SMK CORPORATION (Japon)
Inventeur(s)
  • Kim Beomjoon
  • Park Jongho
  • Fujii Katsuhito

Abrégé

[Problem] To provide a porous microneedle capable of collecting a body fluid. [Solution] Provided is a porous microneedle including a water-soluble material and microspheres of a biodegradable material, wherein: the microspheres of the biodegradable material are bonded to each other to form a network of interconnected pores; the microneedle may comprise a microneedle substrate including the microspheres and the water-soluble material; and the volume ratio of the water-soluble material and the biodegradalbe material is 1:2 to 3.

Classes IPC  ?

  • A61M 37/00 - Autres appareils pour introduire des agents dans le corpsPercutanisation, c.-à-d. introduction de médicaments dans le corps par diffusion à travers la peau

62.

Ionizer


Numéro d'application 29960335
Numéro de brevet D1107859
Statut Délivré - en vigueur
Date de dépôt 2024-08-29
Date de la première publication 2025-12-30
Date d'octroi 2025-12-30
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yasuoka, Takashi
  • Konno, Suguru

63.

Ionizer


Numéro d'application 29960331
Numéro de brevet D1107173
Statut Délivré - en vigueur
Date de dépôt 2024-08-29
Date de la première publication 2025-12-23
Date d'octroi 2025-12-23
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yasuoka, Takashi
  • Konno, Suguru

64.

Ionizer


Numéro d'application 29960326
Numéro de brevet D1107172
Statut Délivré - en vigueur
Date de dépôt 2024-08-29
Date de la première publication 2025-12-23
Date d'octroi 2025-12-23
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yasuoka, Takashi
  • Konno, Suguru

65.

SPRAY UNIT FOR LEAKAGE INSPECTION, LEAKAGE INSPECTION SYSTEM, AND LEAKAGE INSPECTION METHOD


Numéro d'application JP2025004602
Numéro de publication 2025/258124
Statut Délivré - en vigueur
Date de dépôt 2025-02-12
Date de publication 2025-12-18
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Kawamura Youichi
  • Yoshida Yasunori

Abrégé

A spray unit (30) for leakage inspection comprises: an inspection liquid pipe (48) for supplying a fluorescent inspection liquid; a spray air pipe (46) for suppling spray air; a two-fluid nozzle (44) for mixing the fluorescent inspection liquid and the spray air, and ejecting mist of the fluorescent inspection liquid; and a housing (40) for housing the inspection liquid pipe (48), the spray air pipe (46), and the two-fluid nozzle (44). The housing (40) has: an ejection port (50) formed in the ejection direction of the two-fluid nozzle (44) for ejecting the mist to the outside of the housing (40); and a dilution port (62) for introducing assist air into a mixing chamber (42) inside the housing (40).

Classes IPC  ?

  • G01M 3/20 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par détection de la présence du fluide à l'emplacement de la fuite en utilisant des révélateurs particuliers, p. ex. teinture, produits fluorescents, produits radioactifs
  • G01M 3/22 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par détection de la présence du fluide à l'emplacement de la fuite en utilisant des révélateurs particuliers, p. ex. teinture, produits fluorescents, produits radioactifs pour tuyaux, câbles ou tubesExamen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par détection de la présence du fluide à l'emplacement de la fuite en utilisant des révélateurs particuliers, p. ex. teinture, produits fluorescents, produits radioactifs pour raccords ou étanchéité de tuyauxExamen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par détection de la présence du fluide à l'emplacement de la fuite en utilisant des révélateurs particuliers, p. ex. teinture, produits fluorescents, produits radioactifs pour soupapes

66.

Ionizer


Numéro d'application 29960337
Numéro de brevet D1106385
Statut Délivré - en vigueur
Date de dépôt 2024-08-29
Date de la première publication 2025-12-16
Date d'octroi 2025-12-16
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yasuoka, Takashi
  • Konno, Suguru

67.

FLUID CONTROL DEVICE, FLUID PRESSURE SUPPLY APPARATUS, AND FLUID CONTROL METHOD


Numéro d'application 18875771
Statut En instance
Date de dépôt 2022-06-29
Date de la première publication 2025-12-11
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Oe, Natsuki

Abrégé

A fluid control device includes a pressure regulating valve control unit that controls a pressure regulating valve so as to output a fluid from the pressure regulating valve at a second pressure lower than a first pressure when the flowrate of the fluid is determined to be equal to or lower than a threshold value continuously for a first prescribed time or longer, and when a standby mode is permitted by an operator. A shutoff valve control unit controls a shutoff valve so as to shut off supplying of the fluid to an external device when a second prescribed time has elapsed in the standby mode.

Classes IPC  ?

  • G05D 16/20 - Commande de la pression d'un fluide caractérisée par l'utilisation de moyens électriques

68.

Electrical connector


Numéro d'application 29833934
Numéro de brevet D1104980
Statut Délivré - en vigueur
Date de dépôt 2022-04-08
Date de la première publication 2025-12-09
Date d'octroi 2025-12-09
Propriétaire SMK Corporation (Japon)
Inventeur(s) Takano, Ryutaro

69.

Ionizer


Numéro d'application 29960325
Numéro de brevet D1105345
Statut Délivré - en vigueur
Date de dépôt 2024-08-29
Date de la première publication 2025-12-09
Date d'octroi 2025-12-09
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yasuoka, Takashi
  • Konno, Suguru

70.

Ionizer


Numéro d'application 29960339
Numéro de brevet D1105346
Statut Délivré - en vigueur
Date de dépôt 2024-08-29
Date de la première publication 2025-12-09
Date d'octroi 2025-12-09
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Yasuoka, Takashi
  • Konno, Suguru

71.

MAGNET GRIPPER AND INDUSTRIAL ROBOT


Numéro d'application JP2024019866
Numéro de publication 2025/248705
Statut Délivré - en vigueur
Date de dépôt 2024-05-30
Date de publication 2025-12-04
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Hammen Florian

Abrégé

A magnet gripper (14) comprises: a first gripper unit (16) having a first magnet (28) magnetized in the diameter direction; a second gripper unit (16A) having a second magnet (28A) magnetized in the diameter direction; and a rotating shaft (20) that connects the first magnet (28) and the second magnet (28A) so as cause the magnets to rotate around the rotational axis of the rotating shaft. The second gripper unit (16A) is disposed so as to be separated by a distance such that the second gripper is not affected by the adsorption force of the first gripper unit (16).

Classes IPC  ?

  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion

72.

Valve box


Numéro d'application 29970584
Numéro de brevet D1102559
Statut Délivré - en vigueur
Date de dépôt 2024-10-29
Date de la première publication 2025-11-18
Date d'octroi 2025-11-18
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Fujitsuka, Naoto

73.

MAGNET CHUCK


Numéro d'application JP2025000715
Numéro de publication 2025/234161
Statut Délivré - en vigueur
Date de dépôt 2025-01-10
Date de publication 2025-11-13
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Sebastian Bialas
  • Ando Mizuki

Abrégé

This magnet chuck (10) is provided with: a housing (20) comprising a magnetic chucking surface (27); and a magnet unit (56) that is provided inside the housing (20) and that is for attracting and holding a workpiece (12) to the magnetic chucking surface (27). The magnet unit (56) is formed of a plurality of permanent magnets (57). The plurality of permanent magnets (57) are arranged so that different magnetic poles are adjacent to each other. At least one permanent magnet (57) is surrounded by multiple other permanent magnets (57).

Classes IPC  ?

74.

Controller for ionizer


Numéro d'application 29958799
Numéro de brevet D1101121
Statut Délivré - en vigueur
Date de dépôt 2024-08-21
Date de la première publication 2025-11-04
Date d'octroi 2025-11-04
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Toshida, Takayuki

75.

HORIZONTAL ARTICULATED ROBOT


Numéro d'application JP2024016282
Numéro de publication 2025/224933
Statut Délivré - en vigueur
Date de dépôt 2024-04-25
Date de publication 2025-10-30
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Miyahara Masaki

Abrégé

This horizontal articulated robot (10) is provided with a base part (14) and a robot body (16). The robot body is provided with a first arm (30), a second arm (32), a first motor (36), a second motor (40), a first power transmission part (38), and a second power transmission part (42). The first arm is positioned below the base part, the second arm is positioned below the first arm, and the second motor is positioned so as not to interfere with the second arm in a state in which the tip (32t) of the second arm is located below the first arm.

Classes IPC  ?

  • B25J 9/06 - Manipulateurs à commande programmée caractérisés par des bras à articulations multiples
  • B25J 17/00 - Joints

76.

PRESSURE BOOSTER


Numéro d'application JP2024038337
Numéro de publication 2025/225056
Statut Délivré - en vigueur
Date de dépôt 2024-10-28
Date de publication 2025-10-30
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Onuki Kenta

Abrégé

A pressure booster (10) comprises: an inlet port (12) into which compressed air flows; drive chambers (32, 42) that drive a first piston (24) by means of the compressed air; a second piston (26) that is coupled to the first piston (24); pressure boosting chambers (34, 44) in which compression of the compressed air is performed by the second piston (26); an outlet port (14) that causes the compressed air having undergone compression in the pressure boosting chamber (44) to flow out; an exhaust part (16) through which the compressed air in the drive chamber (32) is discharged; and a selector valve (30) that connects the drive chamber (32) to the inlet port (12) or to the exhaust part (16) by switching therebetween. A common drive flow path (60) for connecting the inlet port (12) to the drive chamber (32) has a throttle part (62) that regulates the flow rate of the compressed air flowing toward the drive chamber (32) and that does not hinder the discharge of the compressed air from the drive chamber (32).

Classes IPC  ?

  • F15B 3/00 - Amplificateurs ou convertisseurs de pression de fluide, p. ex. échangeurs de pressionTransmission de la pression d'un système à fluide à un autre, sans contact entre les fluides

77.

ATTACHMENT FIXTURE FOR IONIZER, IONIZER HAVING THE SAME, AND ATTACHMENT STRUCTURE USING THE SAME


Numéro d'application JP2025015221
Numéro de publication 2025/225523
Statut Délivré - en vigueur
Date de dépôt 2025-04-18
Date de publication 2025-10-30
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Toshida Takayuki
  • Fukawa Takehito

Abrégé

[Problem] To provide, with regard to an ionizer that has a long and narrow housing in which a plurality of discharge needles are retained in a row, an attachment fixture that increases the efficiency of the work of attaching and detaching said housing to and from an installation site, as well as to provide an ionizer having said attachment fixture, and an attachment structure using said attachment fixture. [Solution] An attachment fixture 6 that attaches a housing 20, in which a plurality of discharge needles 31 are retained in a row along a long axis L1, to an installation location F is provided with: an axial direction support member 60 that has a locking engagement piece 61 capable of being manually manipulated between a locked position, in which the same is engaged with an end section of the housing and restricts movement of the housing along the long axis, and an unlocked position, in which said engagement is released; and a suspension support member 65 that has a sliding engagement piece 66 engaging, in a freely slidable manner, with a long axis direction slide groove 28 in the housing, and supporting the housing upward from below, wherein a pair of said attachment fixtures are used to retain both end sections of the housing.

Classes IPC  ?

  • H01T 19/04 - Dispositifs prévus pour la décharge corona munis d'électrodes pointues
  • H01T 23/00 - Appareils pour la production d'ions destinés à être introduits dans des gaz à l'état libre, p. ex. dans l'atmosphère
  • H05F 3/04 - Enlèvement des charges électrostatiques au moyen d'éclateurs ou d'autres dispositifs à décharge

78.

CHUCK DEVICE AND CHUCK SYSTEM


Numéro d'application JP2024041275
Numéro de publication 2025/220259
Statut Délivré - en vigueur
Date de dépôt 2024-11-21
Date de publication 2025-10-23
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kuroda Akito

Abrégé

A chuck device (10) comprises: a first movable part (14) and a second movable part (16) for gripping a workpiece (W); and a cylinder device (18) for moving the first movable part and the second movable part closer to and away from each other. The cylinder device is disposed between the first movable part and the second movable part in a movable direction in which the first movable part and the second movable part move closer to and away from each other.

Classes IPC  ?

  • B25J 15/08 - Têtes de préhension avec des éléments en forme de doigts

79.

VALVE UNIT AND BOOSTER VALVE


Numéro d'application JP2024042485
Numéro de publication 2025/210958
Statut Délivré - en vigueur
Date de dépôt 2024-12-02
Date de publication 2025-10-09
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Someya Kazutaka

Abrégé

A valve unit (10) comprising: a main valve (12) that alternately connects an exhaust port (14a) and a compressed air supply source (22) to a compressed air device; a main valve casing (14) that houses the main valve (12); a dew condensation prevention cover (16) that covers the outside of the main valve casing (14) and forms a cover air flow path (18) together with the main valve casing (14); and a cover air supply port (32) that communicates with one end of the cover air flow path (18) and supplies a portion of compressed air supplied from the compressed air supply source (22).

Classes IPC  ?

  • F16K 27/12 - Couvercles de logements
  • F16K 31/122 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un piston

80.

X-RAY IMAGING APPARATUS


Numéro d'application JP2025013803
Numéro de publication 2025/211447
Statut Délivré - en vigueur
Date de dépôt 2025-04-04
Date de publication 2025-10-09
Propriétaire
  • KINKI UNIVERSITY (Japon)
  • SMK CORPORATION (Japon)
Inventeur(s)
  • Monzen Hajime
  • Kosaka Hiroyuki
  • Nozaki Mitsugu
  • Komuro Masaji

Abrégé

Although it is desirable to perform imaging after knowing the state of respiration during X-ray testing, such imaging has not been carried out in actual medical sites at present. In addition, since the respiration state and information indicating under what respiration state the testing has been performed have not been stored along with a testing image, it had not been clear how much the respiration state has an effect on the test result during imaging. This X-ray imaging apparatus comprises: an X-ray imaging unit; a millimeter wave radar that irradiates a subject; a display unit that displays an X-ray image obtained by the X-ray imaging unit; and a control unit that displays, on the display unit, an output provided by the millimeter wave radar and a shutter time of the X-ray imaging unit. The X-ray imaging apparatus, by recording the state at the time of imaging instead of suppressing the movement of the body of the subject at the time of imaging, increases reproducibility, eliminates an increase in exposure amount due to re-testing, and provides great additional material when interpreting images.

Classes IPC  ?

  • A61B 6/00 - Appareils ou dispositifs pour le diagnostic par radiationsAppareils ou dispositifs pour le diagnostic par radiations combinés avec un équipement de thérapie par radiations
  • A61B 5/11 - Mesure du mouvement du corps entier ou de parties de celui-ci, p. ex. tremblement de la tête ou des mains ou mobilité d'un membre
  • A61B 5/113 - Mesure du mouvement du corps entier ou de parties de celui-ci, p. ex. tremblement de la tête ou des mains ou mobilité d'un membre se produisant au cours de la respiration
  • A61B 6/46 - Agencements pour l’interface avec l’opérateur ou avec le patient

81.

Electrical connector


Numéro d'application 29833932
Numéro de brevet D1096636
Statut Délivré - en vigueur
Date de dépôt 2022-04-08
Date de la première publication 2025-10-07
Date d'octroi 2025-10-07
Propriétaire SMK Corporation (Japon)
Inventeur(s) Takano, Ryutaro

82.

POWER SUPPLY DEVICE


Numéro d'application JP2024046035
Numéro de publication 2025/203953
Statut Délivré - en vigueur
Date de dépôt 2024-12-25
Date de publication 2025-10-02
Propriétaire SMK CORPORATION (Japon)
Inventeur(s)
  • Hasegawa Tomonari
  • Fujikawa Hiroshi
  • Mori Katsuya

Abrégé

The present invention provides a power supply device having a shape that enables said device to be a replacement for existing batteries. The power supply device includes: a first substrate that has a first electrode and a storage battery; a second electrode; a second substrate that has a control unit; and a third substrate that is disposed between the first substrate and the second substrate and has a conductor part of which a portion of the peripheral edge is connected to the second electrode.

Classes IPC  ?

  • H01M 50/202 - Boîtiers ou cadres autour du boîtier primaire d’une seule cellule ou d’une seule batterie
  • H01M 50/50 - Connexions conductrices de courant pour les cellules ou les batteries
  • H01M 50/284 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports comprenant l’insertion de cartes de circuits, p. ex. de cartes de circuits imprimés
  • H01M 50/296 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les bornes des blocs de batterie

83.

Electrical connector


Numéro d'application 29855488
Numéro de brevet D1095434
Statut Délivré - en vigueur
Date de dépôt 2022-10-04
Date de la première publication 2025-09-30
Date d'octroi 2025-09-30
Propriétaire SMK Corporation (Japon)
Inventeur(s) Tokita, Junichi

84.

4BAR FACTORY


Numéro de série 99400357
Statut En instance
Date de dépôt 2025-09-19
Propriétaire SMC Corporation (Japon)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
  • 37 - Services de construction; extraction minière; installation et réparation
  • 41 - Éducation, divertissements, activités sportives et culturelles
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Metal pipe fittings for compressed air pipes; Metal couplings for flexible tubing; Valve manifolds of metal for use with hydraulic and pneumatic systems; Joints and manifolds of metal for compressed pneumatic and hydraulic equipment; metal, wash down, spray nozzles for commercial and industrial use; Valves of metal, namely, smooth vent valves for fluid, other than parts of machines; metal slit valves for fluid, other than parts of machines; Manually air operated metal valves; Manually operated metal finger valves; Manually operated metal hand valves; Multifunctional manually operated metal valves; Manually operated metal pressure release valves; Manually operated metal angle valves; Manually operated metal vacuum valves; Manually operated metal straight valves; Manually operated metal smooth vent valves; Manually operated metal drain valves; Manually operated metal slit valves; Floating joint connectors of metal; Air storage tanks of metal, not for use in scuba diving; Cylinders of metal for compressed air, gas and liquid, sold empty Pneumatic valve actuators; compressed air machine components, namely, cylinders, valves, and air grips; valves being parts of machines operated pneumatically and by air; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems being sold as a unit with manufacturing machines; pressure reducers as parts of machines; Back pressure valves as parts of machines; Pressure transducers as parts of machines; Pressure switches as parts of machines; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems sold as a unit with manufacturing machines; Pressure regulators being parts of machines; Pressure switches being replacement parts of compressed air machines; Air filters for pneumatic controls being part of machines; Air filters being replacement parts of compressed air machines; air compressors; gas compressors; compressors for machines; compressors as parts of machines, motors and engines; Pneumatic air preparation equipment, namely, airline filters, lubricators, and regulators, all being parts of machines; Pneumatic linear actuators, other than for land vehicles; Parts for pneumatic blow guns, namely, inflator tips, inflator valves, valve adapters, nozzles, nipples, couplers, connectors and pivots; Rotary compressors; rotary blowers; rotary pumps; pneumatic lubricators, pneumatic and hydraulic valves for use in machines, pneumatic and hydraulic actuators, pneumatic and hydraulic filters for use in machines, pneumatic and electric positioners, and pneumatic and hydraulic parts for all of the above; Filters for hydraulic machines; Filter parts being parts of pneumatic filters for industrial automation machines, namely, filter elements and bowls; Silencers for pneumatic components of industrial automation machines; Air operated valves being parts of machines; Finger valves being parts of machines; Hand valves ; being parts of machines; Multi-functional valves being parts of machines; Non-electric couplers being parts of machines sold in combination with pneumatic and hydraulic equipment; Compressed air cylinders being pneumatic control devices for industrial automation machines; Residual pressure released valves being parts of machines; Check valves being parts of machines; Exhaust valves being parts of machines; Safety speed control valves being parts of machines; Air saving valves being parts of machines; Air filters for mechanical purposes; Pneumatic lubrication machines; Vacuum regulators being parts of machines; Electro pneumatic and hydraulic regulators being parts of machines; Electronic vacuum regulators being parts of machines; Booster regulators being parts of machines; Electro pneumatic and hydraulic proportional control valve; Ejector valves being parts of machines; Free mount cylinders being parts of machines; Pneumatically operated regulators; Hydraulic cylinders being parts of machines; Cylinder auto-switches for machines; Electropneumatic positioners being parts of machines; Pneumatic positioners being parts of machines; Valve positioners being parts of machines; Cylinder positioners being parts of machines; Dual positioners being parts of machines; Lock-up valves sold as a unit for pneumatic instrumentation equipment; Actuators for use in switching valves of metal; Odor removal filters being parts of machines; Hydraulic mechanical and pneumatic controllers including multi-channel controllers, all the foregoing being parts of machines; Regulator manifolds being parts of machines for industrial automation machines; Vacuum ejectors being parts of machines; Pressure control equipment, namely, pressure regulators being parts of machines; Flow switches as parts of machines; mechanical valves being parts of machines Pressure sensors; Pressure recorders; Pressure gauges; Automatic pressure control machines and instruments; Manometers being pressure gauges; Manifold absolute pressure (MAP) sensors; Pressure transmitters; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems; Testing equipment for measuring the temperature, pressure, position or form of workpieces in a machine tool; Pressure indicators; Pressure regulators for pneumatic systems; Pressure test connectors for testing pressure of fluids in hydraulic or pneumatic systems; Pressure relief valves for pneumatic systems; Control valves for regulating the flow of gases and liquids; Automatic inlet control valves for reciprocating air compressors; Pneumatic and hydraulic directional control valves for use in automated production machinery; Pressure indicator plugs for valves; boost gauges; Control valves for regulating the flow or the pressure of gases and liquids, namely, pneumatic regulators, pneumatic relays, pneumatic and hydraulic switches and pressure and flow switches; Cylinder auto-switches, electric; Solenoid switches for water, oil, air, high pressure, gas, vacuum, steam and dust collectors; Electronic relay valves for controlling gas or fluids; Pneumatically operated micro mist separator regulators; Pneumatically operated pressure regulators for industrial automation equipment; Manifolds for electric regulators for industrial automation machines; Pneumatically direct operated precision regulators for industrial automation equipment; Electronic vacuum regulators; Electropneumatic regulators for industrial automation equipment; Booster regulator for industrial automation equipment; Pressure gauges for clean room; Pressure gauges for clean regulator; Pressure gauges with switch; Electric flow switches for industrial automation machines; Downloadable computer software for selection of optimal system models for the operation of air pressure systems; Downloadable computer software for analysis of pneumatic energy savings Pressure regulators for gas installations; Pressure regulators for gas pipes and lines; Air filters for industrial installations; Air filtering installations; Bag filters, namely, air filters for industrial use; Drain valves sold as a unit for air preparation equipment Non-metal fittings for flexible compressed air pipes; Non-metal couplings for flexible tubing; Nonmetallic tube fittings; Nylon tubing for connecting pneumatic components Providing expert advice on the installation, repair and maintenance of pneumatic and hydraulic apparatus and other machinery by way of computer network Providing recognition by the way of awards and contests to reward participants who demonstrate lower energy consumption and reduced CO2 emissions by reducing air pressure in industrial manufacturing facilities Software as a service (SAAS) services, namely, hosting software for use by others for selection of optimal system models for the operation of air pressure systems; Software as a service (SAAS) services, namely, hosting software for use by others for analysis of pneumatic energy savings; Providing expert advice on the design of pneumatic and hydraulic apparatus and other machinery by way of computer network

85.

4BAR FACTORY


Numéro de série 99400345
Statut En instance
Date de dépôt 2025-09-18
Propriétaire SMC Corporation (Japon)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
  • 37 - Services de construction; extraction minière; installation et réparation
  • 41 - Éducation, divertissements, activités sportives et culturelles
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Metal pipe fittings for compressed air pipes; Metal couplings for flexible tubing; Valve manifolds of metal for use with hydraulic and pneumatic systems; Joints and manifolds of metal for compressed pneumatic and hydraulic equipment; metal, wash down, spray nozzles for commercial and industrial use; Valves of metal, namely, smooth vent valves for fluid, other than parts of machines; metal slit valves for fluid, other than parts of machines; Manually air operated metal valves; Manually operated metal finger valves; Manually operated metal hand valves; Multifunctional manually operated metal valves; Manually operated metal pressure release valves; Manually operated metal angle valves; Manually operated metal vacuum valves; Manually operated metal straight valves; Manually operated metal smooth vent valves; Manually operated metal drain valves; Manually operated metal slit valves; Floating joint connectors of metal; Air storage tanks of metal, not for use in scuba diving; Cylinders of metal for compressed air, gas and liquid, sold empty Pneumatic valve actuators; compressed air machine components, namely, cylinders, valves, and air grips; valves being parts of machines operated pneumatically and by air; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems being sold as a unit with manufacturing machines; pressure reducers as parts of machines; Back pressure valves as parts of machines; Pressure transducers as parts of machines; Pressure switches as parts of machines; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems sold as a unit with manufacturing machines; Pressure regulators being parts of machines; Pressure switches being replacement parts of compressed air machines; Air filters for pneumatic controls being part of machines; Air filters being replacement parts of compressed air machines; air compressors; gas compressors; compressors for machines; compressors as parts of machines, motors and engines; Pneumatic air preparation equipment, namely, airline filters, lubricators, and regulators, all being parts of machines; Pneumatic linear actuators, other than for land vehicles; Parts for pneumatic blow guns, namely, inflator tips, inflator valves, valve adapters, nozzles, nipples, couplers, connectors and pivots; Rotary compressors; rotary blowers; rotary pumps; pneumatic lubricators, pneumatic and hydraulic valves for use in machines, pneumatic and hydraulic actuators, pneumatic and hydraulic filters for use in machines, pneumatic and electric positioners, and pneumatic and hydraulic parts for all of the above; Filters for hydraulic machines; Filter parts being parts of pneumatic filters for industrial automation machines, namely, filter elements and bowls; Silencers for pneumatic components of industrial automation machines; Air operated valves being parts of machines; Finger valves being parts of machines; Hand valves ; being parts of machines; Multi-functional valves being parts of machines; Non-electric couplers being parts of machines sold in combination with pneumatic and hydraulic equipment; Compressed air cylinders being pneumatic control devices for industrial automation machines; Residual pressure released valves being parts of machines; Check valves being parts of machines; Exhaust valves being parts of machines; Safety speed control valves being parts of machines; Air saving valves being parts of machines; Air filters for mechanical purposes; Pneumatic lubrication machines; Vacuum regulators being parts of machines; Electro pneumatic and hydraulic regulators being parts of machines; Electronic vacuum regulators being parts of machines; Booster regulators being parts of machines; Electro pneumatic and hydraulic proportional control valve; Ejector valves being parts of machines; Free mount cylinders being parts of machines; Pneumatically operated regulators; Hydraulic cylinders being parts of machines; Cylinder auto-switches for machines; Electropneumatic positioners being parts of machines; Pneumatic positioners being parts of machines; Valve positioners being parts of machines; Cylinder positioners being parts of machines; Dual positioners being parts of machines; Lock-up valves sold as a unit for pneumatic instrumentation equipment; Actuators for use in switching valves of metal; Odor removal filters being parts of machines; Hydraulic mechanical and pneumatic controllers including multi-channel controllers, all the foregoing being parts of machines; Regulator manifolds being parts of machines for industrial automation machines; Vacuum ejectors being parts of machines; Pressure control equipment, namely, pressure regulators being parts of machines; Flow switches as parts of machines; mechanical valves being parts of machines Pressure sensors; Pressure recorders; Pressure gauges; Automatic pressure control machines and instruments; Manometers being pressure gauges; Manifold absolute pressure (MAP) sensors; Pressure transmitters; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems; Testing equipment for measuring the temperature, pressure, position or form of workpieces in a machine tool; Pressure indicators; Pressure regulators for pneumatic systems; Pressure test connectors for testing pressure of fluids in hydraulic or pneumatic systems; Pressure relief valves for pneumatic systems; Control valves for regulating the flow of gases and liquids; Automatic inlet control valves for reciprocating air compressors; Pneumatic and hydraulic directional control valves for use in automated production machinery; Pressure indicator plugs for valves; boost gauges; Control valves for regulating the flow or the pressure of gases and liquids, namely, pneumatic regulators, pneumatic relays, pneumatic and hydraulic switches and pressure and flow switches; Cylinder auto-switches, electric; Solenoid switches for water, oil, air, high pressure, gas, vacuum, steam and dust collectors; Electronic relay valves for controlling gas or fluids; Pneumatically operated micro mist separator regulators; Pneumatically operated pressure regulators for industrial automation equipment; Manifolds for electric regulators for industrial automation machines; Pneumatically direct operated precision regulators for industrial automation equipment; Electronic vacuum regulators; Electropneumatic regulators for industrial automation equipment; Booster regulator for industrial automation equipment; Pressure gauges for clean room; Pressure gauges for clean regulator; Pressure gauges with switch; Electric flow switches for industrial automation machines; Downloadable computer software for selection of optimal system models for the operation of air pressure systems; Downloadable computer software for analysis of pneumatic energy savings Pressure regulators for gas installations; Pressure regulators for gas pipes and lines; Air filters for industrial installations; Air filtering installations; Bag filters, namely, air filters for industrial use; Drain valves sold as a unit for air preparation equipment Non-metal fittings for flexible compressed air pipes; Non-metal couplings for flexible tubing; Nonmetallic tube fittings; Nylon tubing for connecting pneumatic components Providing expert advice on the installation, repair and maintenance of pneumatic and hydraulic apparatus and other machinery by way of computer network Providing recognition by the way of awards and contests to reward participants who demonstrate lower energy consumption and reduced CO2 emissions by reducing air pressure in industrial manufacturing facilities Software as a service (SAAS) services, namely, hosting software for use by others for selection of optimal system models for the operation of air pressure systems; Software as a service (SAAS) services, namely, hosting software for use by others for analysis of pneumatic energy savings; Providing expert advice on the design of pneumatic and hydraulic apparatus and other machinery by way of computer network

86.

4BAR FACTORY


Numéro de série 99400350
Statut En instance
Date de dépôt 2025-09-18
Propriétaire SMC Corporation (Japon)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
  • 37 - Services de construction; extraction minière; installation et réparation
  • 41 - Éducation, divertissements, activités sportives et culturelles
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Metal pipe fittings for compressed air pipes; Metal couplings for flexible tubing; Valve manifolds of metal for use with hydraulic and pneumatic systems; Joints and manifolds of metal for compressed pneumatic and hydraulic equipment; metal, wash down, spray nozzles for commercial and industrial use; Valves of metal, namely, smooth vent valves for fluid, other than parts of machines; metal slit valves for fluid, other than parts of machines; Manually air operated metal valves; Manually operated metal finger valves; Manually operated metal hand valves; Multifunctional manually operated metal valves; Manually operated metal pressure release valves; Manually operated metal angle valves; Manually operated metal vacuum valves; Manually operated metal straight valves; Manually operated metal smooth vent valves; Manually operated metal drain valves; Manually operated metal slit valves; Floating joint connectors of metal; Air storage tanks of metal, not for use in scuba diving; Cylinders of metal for compressed air, gas and liquid, sold empty Pneumatic valve actuators; compressed air machine components, namely, cylinders, valves, and air grips; valves being parts of machines operated pneumatically and by air; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems being sold as a unit with manufacturing machines; pressure reducers as parts of machines; Back pressure valves as parts of machines; Pressure transducers as parts of machines; Pressure switches as parts of machines; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems sold as a unit with manufacturing machines; Pressure regulators being parts of machines; Pressure switches being replacement parts of compressed air machines; Air filters for pneumatic controls being part of machines; Air filters being replacement parts of compressed air machines; air compressors; gas compressors; compressors for machines; compressors as parts of machines, motors and engines; Pneumatic air preparation equipment, namely, airline filters, lubricators, and regulators, all being parts of machines; Pneumatic linear actuators, other than for land vehicles; Parts for pneumatic blow guns, namely, inflator tips, inflator valves, valve adapters, nozzles, nipples, couplers, connectors and pivots; Rotary compressors; rotary blowers; rotary pumps; pneumatic lubricators, pneumatic and hydraulic valves for use in machines, pneumatic and hydraulic actuators, pneumatic and hydraulic filters for use in machines, pneumatic and electric positioners, and pneumatic and hydraulic parts for all of the above; Filters for hydraulic machines; Filter parts being parts of pneumatic filters for industrial automation machines, namely, filter elements and bowls; Silencers for pneumatic components of industrial automation machines; Air operated valves being parts of machines; Finger valves being parts of machines; Hand valves ; being parts of machines; Multi-functional valves being parts of machines; Non-electric couplers being parts of machines sold in combination with pneumatic and hydraulic equipment; Compressed air cylinders being pneumatic control devices for industrial automation machines; Residual pressure released valves being parts of machines; Check valves being parts of machines; Exhaust valves being parts of machines; Safety speed control valves being parts of machines; Air saving valves being parts of machines; Air filters for mechanical purposes; Pneumatic lubrication machines; Vacuum regulators being parts of machines; Electro pneumatic and hydraulic regulators being parts of machines; Electronic vacuum regulators being parts of machines; Booster regulators being parts of machines; Electro pneumatic and hydraulic proportional control valve; Ejector valves being parts of machines; Free mount cylinders being parts of machines; Pneumatically operated regulators; Hydraulic cylinders being parts of machines; Cylinder auto-switches for machines; Electropneumatic positioners being parts of machines; Pneumatic positioners being parts of machines; Valve positioners being parts of machines; Cylinder positioners being parts of machines; Dual positioners being parts of machines; Lock-up valves sold as a unit for pneumatic instrumentation equipment; Actuators for use in switching valves of metal; Odor removal filters being parts of machines; Hydraulic mechanical and pneumatic controllers including multi-channel controllers, all the foregoing being parts of machines; Regulator manifolds being parts of machines for industrial automation machines; Vacuum ejectors being parts of machines; Pressure control equipment, namely, pressure regulators being parts of machines; Flow switches as parts of machines; mechanical valves being parts of machines Pressure sensors; Pressure recorders; Pressure gauges; Automatic pressure control machines and instruments; Manometers being pressure gauges; Manifold absolute pressure (MAP) sensors; Pressure transmitters; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems; Testing equipment for measuring the temperature, pressure, position or form of workpieces in a machine tool; Pressure indicators; Pressure regulators for pneumatic systems; Pressure test connectors for testing pressure of fluids in hydraulic or pneumatic systems; Pressure relief valves for pneumatic systems; Control valves for regulating the flow of gases and liquids; Automatic inlet control valves for reciprocating air compressors; Pneumatic and hydraulic directional control valves for use in automated production machinery; Pressure indicator plugs for valves; boost gauges; Control valves for regulating the flow or the pressure of gases and liquids, namely, pneumatic regulators, pneumatic relays, pneumatic and hydraulic switches and pressure and flow switches; Cylinder auto-switches, electric; Solenoid switches for water, oil, air, high pressure, gas, vacuum, steam and dust collectors; Electronic relay valves for controlling gas or fluids; Pneumatically operated micro mist separator regulators; Pneumatically operated pressure regulators for industrial automation equipment; Manifolds for electric regulators for industrial automation machines; Pneumatically direct operated precision regulators for industrial automation equipment; Electronic vacuum regulators; Electropneumatic regulators for industrial automation equipment; Booster regulator for industrial automation equipment; Pressure gauges for clean room; Pressure gauges for clean regulator; Pressure gauges with switch; Electric flow switches for industrial automation machines; Downloadable computer software for selection of optimal system models for the operation of air pressure systems; Downloadable computer software for analysis of pneumatic energy savings Pressure regulators for gas installations; Pressure regulators for gas pipes and lines; Air filters for industrial installations; Air filtering installations; Bag filters, namely, air filters for industrial use; Drain valves sold as a unit for air preparation equipment Non-metal fittings for flexible compressed air pipes; Non-metal couplings for flexible tubing; Nonmetallic tube fittings; Nylon tubing for connecting pneumatic components Providing expert advice on the installation, repair and maintenance of pneumatic and hydraulic apparatus and other machinery by way of computer network Providing recognition by the way of awards and contests to reward participants who demonstrate lower energy consumption and reduced CO2 emissions by reducing air pressure in industrial manufacturing facilities Software as a service (SAAS) services, namely, hosting software for use by others for selection of optimal system models for the operation of air pressure systems; Software as a service (SAAS) services, namely, hosting software for use by others for analysis of pneumatic energy savings; Providing expert advice on the design of pneumatic and hydraulic apparatus and other machinery by way of computer network

87.

4BAR FACTORY


Numéro de série 99400339
Statut En instance
Date de dépôt 2025-09-18
Propriétaire SMC Corporation (Japon)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
  • 37 - Services de construction; extraction minière; installation et réparation
  • 41 - Éducation, divertissements, activités sportives et culturelles
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Metal pipe fittings for compressed air pipes; Metal couplings for flexible tubing; Valve manifolds of metal for use with hydraulic and pneumatic systems; Joints and manifolds of metal for compressed pneumatic and hydraulic equipment; metal, wash down, spray nozzles for commercial and industrial use; Valves of metal, namely, smooth vent valves for fluid, other than parts of machines; metal slit valves for fluid, other than parts of machines; Manually air operated metal valves; Manually operated metal finger valves; Manually operated metal hand valves; Multifunctional manually operated metal valves; Manually operated metal pressure release valves; Manually operated metal angle valves; Manually operated metal vacuum valves; Manually operated metal straight valves; Manually operated metal smooth vent valves; Manually operated metal drain valves; Manually operated metal slit valves; Floating joint connectors of metal; Air storage tanks of metal, not for use in scuba diving; Cylinders of metal for compressed air, gas and liquid, sold empty Pneumatic valve actuators; compressed air machine components, namely, cylinders, valves, and air grips; valves being parts of machines operated pneumatically and by air; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems being sold as a unit with manufacturing machines; pressure reducers as parts of machines; Back pressure valves as parts of machines; Pressure transducers as parts of machines; Pressure switches as parts of machines; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems sold as a unit with manufacturing machines; Pressure regulators being parts of machines; Pressure switches being replacement parts of compressed air machines; Air filters for pneumatic controls being part of machines; Air filters being replacement parts of compressed air machines; air compressors; gas compressors; compressors for machines; compressors as parts of machines, motors and engines; Pneumatic air preparation equipment, namely, airline filters, lubricators, and regulators, all being parts of machines; Pneumatic linear actuators, other than for land vehicles; Parts for pneumatic blow guns, namely, inflator tips, inflator valves, valve adapters, nozzles, nipples, couplers, connectors and pivots; Rotary compressors; rotary blowers; rotary pumps; pneumatic lubricators, pneumatic and hydraulic valves for use in machines, pneumatic and hydraulic actuators, pneumatic and hydraulic filters for use in machines, pneumatic and electric positioners, and pneumatic and hydraulic parts for all of the above; Filters for hydraulic machines; Filter parts being parts of pneumatic filters for industrial automation machines, namely, filter elements and bowls; Silencers for pneumatic components of industrial automation machines; Air operated valves being parts of machines; Finger valves being parts of machines; Hand valves ; being parts of machines; Multi-functional valves being parts of machines; Non-electric couplers being parts of machines sold in combination with pneumatic and hydraulic equipment; Compressed air cylinders being pneumatic control devices for industrial automation machines; Residual pressure released valves being parts of machines; Check valves being parts of machines; Exhaust valves being parts of machines; Safety speed control valves being parts of machines; Air saving valves being parts of machines; Air filters for mechanical purposes; Pneumatic lubrication machines; Vacuum regulators being parts of machines; Electro pneumatic and hydraulic regulators being parts of machines; Electronic vacuum regulators being parts of machines; Booster regulators being parts of machines; Electro pneumatic and hydraulic proportional control valve; Ejector valves being parts of machines; Free mount cylinders being parts of machines; Pneumatically operated regulators; Hydraulic cylinders being parts of machines; Cylinder auto-switches for machines; Electropneumatic positioners being parts of machines; Pneumatic positioners being parts of machines; Valve positioners being parts of machines; Cylinder positioners being parts of machines; Dual positioners being parts of machines; Lock-up valves sold as a unit for pneumatic instrumentation equipment; Actuators for use in switching valves of metal; Odor removal filters being parts of machines; Hydraulic mechanical and pneumatic controllers including multi-channel controllers, all the foregoing being parts of machines; Regulator manifolds being parts of machines for industrial automation machines; Vacuum ejectors being parts of machines; Pressure control equipment, namely, pressure regulators being parts of machines; Flow switches as parts of machines; mechanical valves being parts of machines Pressure sensors; Pressure recorders; Pressure gauges; Automatic pressure control machines and instruments; Manometers being pressure gauges; Manifold absolute pressure (MAP) sensors; Pressure transmitters; Pressure switches and sensors for monitoring, controlling, and switching hydraulic or pneumatic systems; Pressure transducers and transmitters that convert hydraulic or pneumatic pressure into analog electrical signals for monitoring and controlling hydraulic or pneumatic systems; Testing equipment for measuring the temperature, pressure, position or form of workpieces in a machine tool; Pressure indicators; Pressure regulators for pneumatic systems; Pressure test connectors for testing pressure of fluids in hydraulic or pneumatic systems; Pressure relief valves for pneumatic systems; Control valves for regulating the flow of gases and liquids; Automatic inlet control valves for reciprocating air compressors; Pneumatic and hydraulic directional control valves for use in automated production machinery; Pressure indicator plugs for valves; boost gauges; Control valves for regulating the flow or the pressure of gases and liquids, namely, pneumatic regulators, pneumatic relays, pneumatic and hydraulic switches and pressure and flow switches; Cylinder auto-switches, electric; Solenoid switches for water, oil, air, high pressure, gas, vacuum, steam and dust collectors; Electronic relay valves for controlling gas or fluids; Pneumatically operated micro mist separator regulators; Pneumatically operated pressure regulators for industrial automation equipment; Manifolds for electric regulators for industrial automation machines; Pneumatically direct operated precision regulators for industrial automation equipment; Electronic vacuum regulators; Electropneumatic regulators for industrial automation equipment; Booster regulator for industrial automation equipment; Pressure gauges for clean room; Pressure gauges for clean regulator; Pressure gauges with switch; Electric flow switches for industrial automation machines; Downloadable computer software for selection of optimal system models for the operation of air pressure systems; Downloadable computer software for analysis of pneumatic energy savings Pressure regulators for gas installations; Pressure regulators for gas pipes and lines; Air filters for industrial installations; Air filtering installations; Bag filters, namely, air filters for industrial use; Drain valves sold as a unit for air preparation equipment Non-metal fittings for flexible compressed air pipes; Non-metal couplings for flexible tubing; Nonmetallic tube fittings; Nylon tubing for connecting pneumatic components Providing expert advice on the installation, repair and maintenance of pneumatic and hydraulic apparatus and other machinery by way of computer network Providing recognition by the way of awards and contests to reward participants who demonstrate lower energy consumption and reduced CO2 emissions by reducing air pressure in industrial manufacturing facilities Software as a service (SAAS) services, namely, hosting software for use by others for selection of optimal system models for the operation of air pressure systems; Software as a service (SAAS) services, namely, hosting software for use by others for analysis of pneumatic energy savings; Providing expert advice on the design of pneumatic and hydraulic apparatus and other machinery by way of computer network

88.

POSITION DETECTION DEVICE AND ACTUATOR


Numéro d'application 19068269
Statut En instance
Date de dépôt 2025-03-03
Date de la première publication 2025-09-11
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Ozaki, Norimasa

Abrégé

A position detection device includes a first sensor that outputs a first detection signal when a piston is located within a first detection range, a detection unit that detects the piston position based on the first detection signal, an antenna that receives power wirelessly, a power supply line through which the power is supplied from the antenna to the first sensor when the piston is located within the first detection range, and a power output line configured to output, when the piston is located outside the first detection range, the power to a sensor module used for detecting the piston position.

Classes IPC  ?

  • G01D 5/14 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens électriques ou magnétiques influençant la valeur d'un courant ou d'une tension
  • H02J 50/00 - Circuits ou systèmes pour l'alimentation ou la distribution sans fil d'énergie électrique

89.

ELECTRIC ACTUATOR


Numéro d'application JP2024038487
Numéro de publication 2025/182143
Statut Délivré - en vigueur
Date de dépôt 2024-10-29
Date de publication 2025-09-04
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Nakazawa Toshiya
  • Tanimura Masaki

Abrégé

An electric actuator (10) comprises: an end plate (32) that covers an end portion of a ball screw (14); a housing (34) through which the ball screw (14) passes; and a top cover (18) that is attached to a first upper end surface (38) of the end plate (32) and a second upper end surface (40) of the housing (34) and covers the upper side of the ball screw (14). A total length (L) of the top cover (18) in a longitudinal direction is longer than a gap (G) between the end plate (32) and the housing (34) in the longitudinal direction, and is shorter than a dimension (A) obtained by adding a length (S2) of the second upper end surface (40) in the longitudinal direction and the gap (G).

Classes IPC  ?

  • F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
  • B23Q 11/08 - Protecteurs pour des parties des machines-outilsCapots antiprojections
  • H02K 7/06 - Moyens de transformation d'un mouvement alternatif en un mouvement circulaire ou vice versa

90.

BIOLOGICAL SIGNAL PROCESSING DEVICE AND BIOLOGICAL SIGNAL PROCESSING PROGRAM


Numéro d'application JP2024018898
Numéro de publication 2025/182104
Statut Délivré - en vigueur
Date de dépôt 2024-05-22
Date de publication 2025-09-04
Propriétaire SMK CORPORATION (Japon)
Inventeur(s)
  • Honma Naoki
  • Nakayama Ryo
  • Sawada Naoki
  • Okamoto Kohei
  • Watabane Yoshinori
  • Komura Kensuke

Abrégé

[Problem] To acquire vital information having enhanced accuracy from reflected waves obtained by transmitting radio waves to a living body. [Solution] As shown in Fig. 1, a biological signal processing device according to the present embodiment uses one radar module employing array antennas (23, 25), and by subjecting a reception signal to beam forming or using null beams, the ratio of complex signals of two reflected waves, one from a region R1 exhibiting large motion due to inclusion of vitals and the other from a region R2 exhibiting small motion due to absence of vitals, is used to extract a vital signal with body motion components removed. In the present embodiment, as a method for acquiring the reflected wave by designating a specific site, such as the region R2 (shoulder) having small motion due to absence of vitals, the reflected wave is multiplied by weight information w1, w2 obtained in advance by beamforming.

Classes IPC  ?

  • A61B 5/11 - Mesure du mouvement du corps entier ou de parties de celui-ci, p. ex. tremblement de la tête ou des mains ou mobilité d'un membre
  • A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
  • A61B 5/0245 - Mesure du pouls ou des pulsations cardiaques utilisant des capteurs engendrant des signaux électriques
  • A61B 5/08 - Dispositifs de mesure pour examiner les organes respiratoires
  • A61B 5/113 - Mesure du mouvement du corps entier ou de parties de celui-ci, p. ex. tremblement de la tête ou des mains ou mobilité d'un membre se produisant au cours de la respiration
  • G01S 13/34 - Systèmes pour mesurer la distance uniquement utilisant la transmission d'ondes continues, soit modulées en amplitude, en fréquence ou en phase, soit non modulées utilisant la transmission d'ondes continues modulées en fréquence, tout en faisant un hétérodynage du signal reçu, ou d’un signal dérivé, avec un signal généré localement, associé au signal transmis simultanément
  • G01S 13/88 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques

91.

VALVE UNIT


Numéro d'application JP2024037926
Numéro de publication 2025/182136
Statut Délivré - en vigueur
Date de dépôt 2024-10-24
Date de publication 2025-09-04
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Nagatsuma Nobuyuki
  • Yoshida Naoki

Abrégé

A valve unit (10) is configured so that a filter attachment hole (46) and an orifice attachment hole (56) are provided at different locations on a first pilot flow path (42A) that guides water in a valve chamber (34) to a pressure chamber (40). A filter unit (48) is attached to the filter attachment hole (46), and an orifice unit (54) is attached to the orifice attachment hole (56).

Classes IPC  ?

  • F16K 31/40 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation avec un organe actionné électriquement dans la décharge du moteur
  • F16K 7/17 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol disposé pour être déformé contre un siège plat le diaphragme étant actionné par pression d'un fluide
  • F16K 51/00 - Autres détails non particuliers aux types de soupapes ou clapets ou autres appareils d'obturation

92.

ATTACHMENT/DETACHMENT DEVICE


Numéro d'application JP2024039539
Numéro de publication 2025/182150
Statut Délivré - en vigueur
Date de dépôt 2024-11-07
Date de publication 2025-09-04
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) I Shunsuke

Abrégé

A cam member (66) in a first adapter (20) of an attachment/detachment device (10) has a cam-side engagement surface (72), a first cam surface (78), and a second cam surface (80) on a side surface. The first cam surface (78) is adjacent to the cam-side engagement surface (72) in the displacement direction of a piston (64). The second cam surface (80) is adjacent to the first cam surface (78) in the displacement direction of the piston (64). The intersection angle between the first cam surface (78) and the displacement direction of the piston (64) is defined as a first angle (α). The intersection angle between the second cam surface (80) and the displacement direction of the piston (64) is defined as a second angle (β). The first angle (α) is smaller than the second angle (β).

Classes IPC  ?

  • B25J 15/04 - Têtes de préhension avec possibilité pour l'enlèvement ou l'échange à distance de la tête ou de parties de celle-ci

93.

Contact


Numéro d'application 29924827
Numéro de brevet D1090446
Statut Délivré - en vigueur
Date de dépôt 2024-01-22
Date de la première publication 2025-08-26
Date d'octroi 2025-08-26
Propriétaire SMK Corporation (Japon)
Inventeur(s) Tanaka, Yuki

94.

Solenoid valve


Numéro d'application 29878950
Numéro de brevet D1089308
Statut Délivré - en vigueur
Date de dépôt 2023-06-29
Date de la première publication 2025-08-19
Date d'octroi 2025-08-19
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Murakami, Takashi

95.

MAGNETIC CHUCK


Numéro d'application 19020166
Statut En instance
Date de dépôt 2025-01-14
Date de la première publication 2025-08-14
Propriétaire SMC CORPORATION (Japon)
Inventeur(s)
  • Godbey, Craig
  • Okushima, Ryosuke

Abrégé

A cylinder member includes a piston assembly and a cylinder tube, and the piston assembly includes a permanent magnet. A holding force adjustment member includes an adjustment body fixed to the cylinder tube and an adjustment ring having a workpiece holding surface. The adjustment ring is screw-engaged with the adjustment body.

Classes IPC  ?

96.

SMK


Numéro d'application 245256400
Statut En instance
Date de dépôt 2025-08-13
Propriétaire SMK Corporation (Japon)
Classes de Nice  ? 07 - Machines et machines-outils

Produits et services

(1) Arc welding machines; resistance welding machines; electric welding machines; electric metal cutting machines (by arc, gas or plasma); welding electrodes.

97.

SMK


Numéro de série 79442538
Statut Enregistrée
Date de dépôt 2025-08-13
Date d'enregistrement 2026-06-16
Propriétaire SMK Corporation (Japon)
Classes de Nice  ? 07 - Machines et machines-outils

Produits et services

Arc welding machines; resistance welding machines; electric welding machines; electric metal cutting machines by arc, gas or plasma; electrodes for welding machines

98.

Supply and exhaust block for solenoid valve assembly


Numéro d'application 29878960
Numéro de brevet D1087170
Statut Délivré - en vigueur
Date de dépôt 2023-06-29
Date de la première publication 2025-08-05
Date d'octroi 2025-08-05
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Murakami, Takashi

99.

Supply and exhaust block for solenoid valve assembly


Numéro d'application 29878972
Numéro de brevet D1086207
Statut Délivré - en vigueur
Date de dépôt 2023-06-29
Date de la première publication 2025-07-29
Date d'octroi 2025-07-29
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Murakami, Takashi

100.

MAGNET DAMPER FOR SUCTION PAD


Numéro d'application JP2024038262
Numéro de publication 2025/150249
Statut Délivré - en vigueur
Date de dépôt 2024-10-28
Date de publication 2025-07-17
Propriétaire SMC CORPORATION (Japon)
Inventeur(s) Kawano Yoshikazu

Abrégé

The outer circumferential surface (18a) and the inner circumferential surface (18b) of a fixed magnet (18), which is attached to a body (12), comprise cylindrical surfaces each having a uniform diameter. The outer circumferential surface (34a) of a movable magnet (34), which constitutes a movable part (22), comprises a cylindrical surface having a uniform diameter. The inner circumferential surface (34b) of the movable magnet comprises a conical curved surface. The fixed magnet and the movable magnet are magnetized in the axial direction, and the axial polarity of the fixed magnet is the same as the axial polarity of the movable magnet.

Classes IPC  ?

  • F16F 6/00 - Ressorts magnétiquesRessorts magnétiques à fluide
  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion
  • H01F 7/02 - Aimants permanents
  1     2     3     ...     15        Prochaine page
