An auxiliary mobility attachment for a wheelchair having an auxiliary frame to support a driving wheel and a handlebar. The auxiliary frame includes an auxiliary connector configured to be releasably attached to a wheelchair connector. The auxiliary connector includes a connector body having an approach slot to receive an approach rod of the wheelchair connector and an anchoring bar configured to fasten the approach rod.
An auxiliary driving device for a wheelchair is provided. The auxiliary driving device comprising: a main wheel steered by a handlebar through a steering column, a bushing arranged around the steering column, a drive mechanism to drive the main wheel, a coupling arm configured for the attachment with the wheelchair, a hinge mechanism configured to allow rotation of the coupling arm with respect to an axis of rotation perpendicular to the length of the steering column and to the length of the coupling arm, and a fastening mechanism configured to fix the position of the coupling arm with respect to the axis of rotation.
An auxiliary frame system for a wheelchair, the wheelchair having a frame comprising two openings to releasably attach axle portions of rear wheels and defining between them a main rear wheel axis; wherein the auxiliary frame system comprises: a pair of wheel displacing elements; fastening elements to releasably attach each wheel displacing element to the frame of the wheelchair through the openings; wheel holders for bearing respective rear wheels of the wheelchair, wherein each of the wheel holders is associated with a respective wheel displacing element, and the wheel holders define between them a shifted rear wheel axis; at least one anchoring link to releasably secure at least one of the wheel displacing elements to the frame of the wheelchair at an additional attachment point. Also provided are wheelchairs comprising such auxiliary frame system and methods to displace the position of rear wheels of a wheelchair.
A61G 5/10 - Parties constitutives, détails ou accessoires
A61G 5/02 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants propulsés par la personne handicapée
A61G 5/08 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants pliables
The invention relates to an auxiliary mobility system for a wheelchair, comprising a frame, at least one wheel-bearing part and at least one steering element or handlebar, said bearing part being connected to the frame such that it can rotate concentrically about its axial axis under the action of the steering element. The system also comprises means for rotating the bearing part concentrically in relation to an axis substantially parallel to the rotation axis of the wheel.
A61G 5/10 - Parties constitutives, détails ou accessoires
B62K 3/16 - Bicyclettes spécialement adaptées pour conducteurs handicapés
B62K 5/025 - Tricycles spécialement adaptés pour conducteurs handicapés, p. ex. véhicules pour personnes à mobilité réduite avec trois roues à propulsion motorisée
A61G 5/04 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants à moteur
A61G 5/02 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants propulsés par la personne handicapée
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
(1) Medical apparatus and instruments namely hand-operated and electric hand-bikes to be attached to the front of wheel chairs and powered add-ons for wheelchairs.
(2) Bicycles, tricycles and unicycles; wheelchairs, powered wheelchairs for the disabled and people with mobility difficulties; electric wheelchairs; bicycles, tricycles and unicycles that may be adapted for use with manual and electric powered wheelchairs; wheelchair bracing systems comprising orthopedic braces, restraint straps, and orthopedic suspenders.
(3) Off-road wheels for handbike.
6.
TRACTIVE MECHANISM FOR AN AUXILIARY MOBILITY SYSTEM FOR A WHEELCHAIR
The invention relates to a tractive mechanism (1) for an auxiliary mobility system for a wheelchair, comprising two separate rotary plates that can be securely coupled to one another in a first position, each of said rotary plates being connected to a corresponding upper limb of a user by means of a connecting rod, with a first driving plate (2) connected to a sprocket chain in order to transmit the movement to a wheel and a second driven plate that receives the movement from the first driving plate (2). The mechanism also includes coupling/uncoupling means for connecting the driving plate to the connecting rod associated with the driving plate (2), and movement detection means linked to the activation of an electric motor and to the movement of the connecting rod, such that it is possible to obtain three different operating positions for the auxiliary system.
A61G 5/02 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants propulsés par la personne handicapée
A61G 5/04 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants à moteur
The invention relates to a gear-change actuating device for an auxiliary mobility system for a wheelchair, vehicles for people with reduced mobility or the like, comprising a plate connected to a driving wheel and at least to an upper extremity of a user by means of a corresponding connecting rod, comprising a number of assemblies for connection between the connecting rod and the handle, one of the connection assemblies being secured to the handle and the other to the connecting rod, and one of the connection assemblies being designed so as to securely carry a gear selector mechanism of the rotatably actuated type, coupling means being provided between the gear selector mechanism and the other connection assembly so as to allow the user to actuate the gear selector mechanism with their upper extremities, without having to move them from the respective handles.
B62M 25/04 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission mécanique, p. ex. par câbles, leviers actionnés à la main
B62K 5/003 - Cycles avec quatre roues ou plus, spécialement adaptés pour conducteurs handicapées, p. ex. véhicules pour personnes à mobilité réduite avec quatre roues
B62M 1/16 - Propulsion par le conducteur des véhicules à roues actionnée exclusivement par propulsion manuelle au moyen d'un guidon animé d'un mouvement de va-et-vient
A61G 5/02 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants propulsés par la personne handicapée
The invention relates to a safety device for an auxiliary wheelchair element, said auxiliary element being of the type used to convert a wheelchair into a chair in the form of a tricycle or similar. The device comprises a frame that is connected to the auxiliary element, said frame being formed by bars and two segments with different inclinations. The bars are connected by means for protecting and means for covering the lower limbs and the soles of the feet of a disabled person using a wheelchair with such an auxiliary element, as well as covering and protecting the wheelchair against possible irregularities and/or obstacles on the ground, and additionally ensuring that the auxiliary wheelchair element rests on the ground in the upright position when not in use.
A61G 5/02 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants propulsés par la personne handicapée
A61G 5/10 - Parties constitutives, détails ou accessoires
The invention relates to an auxiliary mobility system for a wheelchair, comprising a frame, at least one part bearing a wheel and at least one steering element or handlebar, said bearing part being connected to the frame such that it can rotate concentrically about its axial axis under the action of the steering element. The system also comprises means for rotating the bearing part concentrically in relation to an axis substantially parallel to the rotation axis of the wheel.
A61G 5/02 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants propulsés par la personne handicapée
A61G 5/04 - Fauteuils ou moyens de transport personnels spécialement adaptés pour des personnes handicapées, p. ex. fauteuils roulants à moteur
B62K 3/16 - Bicyclettes spécialement adaptées pour conducteurs handicapés
10.
SYSTEM FOR COUPLING AN AUXILIARY ELEMENT TO A WHEELCHAIR
The invention relates to a system for coupling an auxiliary element to a wheelchair, said auxiliary element being of the type used to convert a wheelchair into a chair in the form of a tricycle or similar, said system comprising a coupling bar for coupling an auxiliary element and a coupling accessory for coupling an auxiliary element, such that the means for coupling the coupling bar can be fitted into the coupling accessory.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
35 - Publicité; Affaires commerciales
Produits et services
Medical apparatus and instruments; orthopedic articles and
apparatus; pads for seats for wheelchairs (for medical
purposes). Apparatus for locomotion by land; bicycles, tricycles and
unicycles; wheelchairs, powered wheelchairs for the disabled
and people with mobility difficulties; electric wheelchairs;
bicycles, tricycles and unicycles that may be adapted for
use with manual or electric powered wheelchairs; bracing
systems for wheelchairs. Advertising services; sales promotion for others (business
services); business management; procurement services for
third parties, business intermediary services, import-export
and retail and wholesale services in stores and via the
internet of medical apparatus and instruments, orthopedic
articles and apparatus, pads for seats for wheelchairs,
apparatus for locomotion by land, bicycles, tricycles and
unicycles, wheelchairs, motorized wheelchairs for the
disabled and people with mobility difficulties, electric
wheelchairs, bicycles, tricycles and unicycles that may be
adapted for use with manual or electric powered wheelchairs,
bracing systems for wheelchairs; presentation of goods on
all kinds of communication media for retail sale purposes;
organization of fairs and exhibitions for commercial or
advertising purposes.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
35 - Publicité; Affaires commerciales
Produits et services
Medical apparatus and instruments; Orthopaedic articles and apparatus; Pads for seats for wheelchairs [for medical use]. Apparatus for locomotion by land; Cycles, Tricycles and Unicycles; Wheel chairs, Motorised wheelchairs for the disabled and those with mobility difficulties; Electric wheelchairs; Bicycles, tricycles and unicycles that can be fitted to manual or electric wheelchairs; Anchoring systems for wheelchairs. Advertisement services; Sales promotion for others (commercial services); Business management; Procurement (for others), commercial intermediation, import-export and retailing and wholesaling in shops and via the Internet of medical apparatus and instruments, orthopaedic goods and apparatus, cushions for wheelchair seats, apparatus for locomotion by land, bicycles, tricycles and unicycles, wheelchairs, motorised wheelchairs for disabled people and people with restricted mobility, electric wheelchairs, bicycles, tricycles and unicycles that can be fitted to manual or electric wheelchairs, anchoring systems for wheelchairs; Presentation of goods by any means of communications for retailing purposes; Organisation of trade fairs and exhibitions for commercial or advertising purposes.
