A fluid heater is configured to increase the temperature of a process fluid flowing through the fluid heater. The fluid heater includes multiple tubes that route the process fluid through the fluid heater. One or more heaters are disposed radially inward of the tubes such that the thermal energy generated by the heaters radiates outwards to heat the process fluid.
F24H 1/14 - Chauffe-eau instantanés, c.-à-d. dans lesquels il n'y a production de chaleur que lorsque l'eau s'écoule, p. ex. avec contact direct de l'eau avec l'agent chauffant dans lesquels l'eau est maintenue séparée de l'agent chauffant par tubes, p. ex. en forme de serpentins
F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives
F24H 9/1818 - Disposition ou montage des éléments chauffants électriques
2.
Pump having opposing magnets between a rotor and stator, and related assemblies, systems, and methods
A pump may include a stator, a rotor, and an impeller. The stator may include one or more electromagnets and one or more permanent magnets. The rotor may include an armature, one or more complementary permanent magnets, and a pull magnet configured to position the rotor in an axial direction. The rotor may be disposed within the stator. The complementary permanent magnets and the one or more permanent magnets of the stator may create magnetic bearings. The armature may be aligned with at least one of the electromagnets of the stator and configured to rotate the rotor with respect to the stator. The impeller may be coupled to the rotor.
A fluid mixing system may include a fluid inlet, a gas inlet, a common outlet, and a mixing chamber. The mixing chamber may be defined between a stator and a magnetically levitated rotor. The rotor may be configured to rotate relative to the stator. The mixing chamber may include an uneven surface. The mixing chamber may operatively couple the fluid inlet and the gas inlet to the common outlet.
A fluid mixing system 100 may include a fluid inlet 1002, a gas inlet 1002, a common outlet 1008, and a mixing chamber 202. The mixing chamber may be defined between a stator 220 and a magnetically levitated rotor 230. The rotor may be configured to rotate relative to the stator. The mixing chamber may include an uneven surface. The mixing chamber may operatively couple the fluid inlet and the gas inlet to the common outlet.
B01F 27/272 - Mélangeurs à système stator-rotor, p. ex. avec des dents ou des cylindres s’engrenant les uns dans les autres ou ayant des orifices avec des moyens pour déplacer les matières à mélanger axialement entre les surfaces du rotor et du stator, p. ex. le système stator-rotor formé par des surfaces coniques ou cylindriques
B01F 23/23 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés
F16C 32/04 - Paliers non prévus ailleurs faisant usage de moyens de support magnétiques ou électriques
A fitting assembly may seal a wire within a tube to inhibit ingress of fluid outside the tube into the tube and into contact with the wire. The fitting assembly may optionally include a body and a nut, with a part of the nut received within the body. The nut may be threadedly connected to the body, such that threading and/or unthreading the nut translates the part of the nut within the body. Optionally, the nut may include a ring extension that is received within a ring cavity of the body, and an interfacing between the ring extension and the ring cavity may create a seal to inhibit leaking of the fluid past the seal. A method of sealing a wire within a tube may comprise positioning a tube with a wire therein within such a fitting assembly.
F16L 19/025 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé les colliers ou les brides formant partie intégrante des extrémités du tuyau
F16L 19/04 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord utilisant des segments rigides additionnels, scellés directement à une extrémité du tuyau au moins, cette extrémité étant rabattue soit avant, soit pendant l'opération d'assemblage
F16L 47/04 - Raccordements ou autres accessoires de raccordement spécialement adaptés pour être en matières plastiques ou pour être utilisés avec des tuyaux en matières plastiques comprenant un écrou ou un collier rotatif s'engageant sur le tuyau
H02G 3/06 - Joints pour connecter des longueurs de tubes de protection les unes aux autres ou à l'enveloppe, p. ex. à la boîte de distributionInstallations de câbles ou de lignes électriques ou de leurs tubes de protection dans ou sur des immeubles, des structures équivalentes ou des véhicules Détails assurant la continuité électrique dans le joint
6.
Fluid pump with dual plungers and related systems and methods
A reciprocating fluid pump includes a pump body, a subject fluid chamber, a first plunger located within the subject fluid chamber of the pump body and having a first head portion and a first bellows, the first plunger configured to expand and compress in a reciprocating action to pump the subject fluid through the subject fluid chamber within the pump body, wherein the first head portion and the first bellows have a first cross-sectional dimension, and a second plunger located within the subject fluid chamber of the pump body and having a second head portion and a second bellows, the second plunger configured to expand and compress in a reciprocating action to pump the subject fluid through the subject fluid chamber within the pump body, wherein the second head portion and the second bellows have a second cross-sectional dimension that is smaller than the first cross-sectional dimension.
F04B 5/02 - "Machines" ou pompes avec pistons à surfaces différentielles avec des pistons à double action
F04B 9/133 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air avec plusieurs chambres de pompage avec deux organes de pompage liés mécaniquement le mouvement alternatif des organes de pompage étant obtenu par un moteur à double effet à fluide compressible
F04B 43/00 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles
F04B 43/08 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles tubulaires
F04B 43/10 - Pompes ayant un entraînement par fluide
F04B 43/113 - Pompes ayant un entraînement par fluide le fluide d'entraînement étant commandé par au moins un clapet
F04B 45/02 - Pompes ou installations de pompage, ayant des organes de travail flexibles, spécialement adaptées pour fluides compressibles ayant des soufflets
7.
Reciprocating fluid pump including at least one magnet on a spool of a shuttle valve
A reciprocating fluid pump may include a pump body, one or more subject fluid chambers within the pump body, one or more drive fluid chambers within the pump body, and a shuttle valve for shifting flow of pressurized drive fluid between two or more conduits. The shuttle valve includes a valve body and a spool disposed within the valve body and configured to move between a first position and a second position within the valve body. The shuttle valve also includes one or more magnets carried by the spool. The magnets are located and configured to impart a force on the spool responsive to a magnetic field such that the spool is magnetically biased away from an intermediate position between the first position and the second position.
F04B 19/22 - Autres pompes à déplacement positif du type à piston alternatif
F04B 9/133 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air avec plusieurs chambres de pompage avec deux organes de pompage liés mécaniquement le mouvement alternatif des organes de pompage étant obtenu par un moteur à double effet à fluide compressible
F04B 17/00 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci
F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
F04B 9/12 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air
8.
Pump having magnets for journaling and magnetically axially positioning rotor thereof, and related methods
A pump may include a stator, a rotor, and an impeller. The stator may include one or more electromagnets and one or more permanent magnets. The rotor may include an armature, one or more complementary permanent magnets, and a pull magnet configured to position the rotor in an axial direction. The rotor may be disposed within the stator. The complementary permanent magnets and the one or more permanent magnets of the stator may create magnetic bearings. The armature may be aligned with at least one of the electromagnets of the stator and configured to rotate the rotor with respect to the stator. The impeller may be coupled to the rotor.
An on-demand heater includes a plurality of heater banks disposed in series with one another between a heater fluid inlet and heater fluid outlet. Power to one or more of the heater banks is adjusted when a sensed exit fluid temperature from a heater bank differs from the partial fluid temperature increase assigned to that heater bank, such that the total desired fluid temperature increase is achieved at the heater fluid outlet in a controlled manner.
A reciprocating fluid pump includes a pump body, a subject fluid chamber, a first plunger located within the subject fluid chamber of the pump body and having a first head portion and a first bellows, the first plunger configured to expand and compress in a reciprocating action to pump the subject fluid through the subject fluid chamber within the pump body, wherein the first head portion and the first bellows have a first cross-sectional dimension, and a second plunger located within the subject fluid chamber of the pump body and having a second head portion and a second bellows, the second plunger configured to expand and compress in a reciprocating action to pump the subject fluid through the subject fluid chamber within the pump body, wherein the second head portion and the second bellows have a second cross-sectional dimension that is smaller than the first cross-sectional dimension.
F04B 43/08 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles tubulaires
F04B 5/02 - "Machines" ou pompes avec pistons à surfaces différentielles avec des pistons à double action
F04B 43/00 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles
F04B 45/02 - Pompes ou installations de pompage, ayant des organes de travail flexibles, spécialement adaptées pour fluides compressibles ayant des soufflets
F04B 43/10 - Pompes ayant un entraînement par fluide
F04B 43/113 - Pompes ayant un entraînement par fluide le fluide d'entraînement étant commandé par au moins un clapet
11.
Methods of manufacturing a pneumatic reciprocating fluid pump with improved check valve assembly
A pneumatic reciprocating fluid pump for pumping a fluid includes at least one check valve assembly that includes a check valve body insert, a ball within the valve body insert, and an annular sealing ring member disposed within a seat ring receptacle. The sealing ring member has dimensions smaller than corresponding dimensions of the seat ring receptacle, such that the sealing ring member is capable of moving within the seat ring receptacle. The ball is configured to slide back and forth between a first position and a second position within the check valve body insert responsive to forward and reverse flow of fluid therethrough. In one position, the ball is seated against the sealing ring member and prevents reverse flow of the fluid through the check valve assembly, and forward flow of the fluid through the check valve assembly is enabled when the ball is in another position.
F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
12.
Multi-port metering pump assembly and related methods
A multi-port metering pump assembly includes a manifold coupled to a metering pump. The manifold defines a central passage in fluid communication with a plurality of intermediate passages defined in the manifold. The manifold includes a plurality of outer passages. Each intermediate passage provides fluid communication between the central passage and a corresponding outer passage. A plurality of valves is coupled to the manifold. Each valve of the plurality of valves is located between an intermediate passage and a corresponding outer passage, and is configured to enable or prevent passage of fluid between a corresponding intermediate passage of the plurality of intermediate passages and a corresponding outer passage. The multi-port metering pump assembly also includes an electronic controller coupled to the plurality of valves, the electronic controller having an associated electronic interface and being programmable to selectively and independently open and close the valves of the plurality of valves.
F04B 13/00 - Pompes spécialement modifiées pour débiter des quantités fixes ou prédéterminées
B05B 7/14 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz agencés pour projeter des matériaux en particules
F04B 43/067 - Pompes ayant un entraînement par fluide le fluide étant déplacé directement par un piston
F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide
F04B 49/22 - Commande des "machines", pompes ou installations de pompage ou mesures de sécurité les concernant non prévues dans les groupes ou présentant un intérêt autre que celui visé par ces groupes par clapets
B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
B65G 53/28 - Systèmes utilisant une combinaison de pression et d'aspiration de gaz
Reciprocating fluid pumps include a pump body including a cavity therein, a plunger located at least partially within the cavity, and a shift canister assembly disposed within the cavity. The shift canister assembly includes a sealing surface for forming a seal against the pump body. An area covered by the seal between the sealing surface and the pump body is less than about 75% of an outer cross-sectional area of the shift canister assembly. The shift canister assembly may include a shift canister and a shift canister cap attached thereto, the shift canister cap comprising the sealing surface. Reciprocating fluid pumps include a shift canister, a shift piston at least partially disposed within the shift canister, and a shift canister cap attached to the shift canister on a longitudinal end of the shift canister opposite the shift piston. Methods include forming such reciprocating pumps.
F04B 9/131 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air avec plusieurs chambres de pompage avec deux organes de pompage liés mécaniquement
F04B 23/02 - Installations ou systèmes de pompage comportant des réservoirs
F04B 19/22 - Autres pompes à déplacement positif du type à piston alternatif
F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
A multi-port metering pump assembly includes a manifold coupled to a metering pump. The manifold defines a central passage in fluid communication with a plurality of intermediate passages defined in the manifold. The manifold includes a plurality of outer passages. Each intermediate passage provides fluid communication between the central passage and a corresponding outer passage. A plurality of valves is coupled to the manifold. Each valve of the plurality of valves is located between an intermediate passage and a corresponding outer passage, and is configured to enable or prevent passage of fluid between a corresponding intermediate passage of the plurality of intermediate passages and a corresponding outer passage. The multi-port metering pump assembly also includes an electronic controller coupled to the plurality of valves, the electronic controller having an associated electronic interface and being programmable to selectively and independently open and close the valves of the plurality of valves.
F04B 13/00 - Pompes spécialement modifiées pour débiter des quantités fixes ou prédéterminées
B05B 7/14 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz agencés pour projeter des matériaux en particules
B65G 53/28 - Systèmes utilisant une combinaison de pression et d'aspiration de gaz
F04B 7/00 - "Machines" ou pompes à piston caractérisées par un entraînement desmodromique des organes du mécanisme de distribution
F04B 7/02 - "Machines" ou pompes à piston caractérisées par un entraînement desmodromique des organes du mécanisme de distribution le mécanisme de distribution étant actionnés par un fluide
F04B 49/22 - Commande des "machines", pompes ou installations de pompage ou mesures de sécurité les concernant non prévues dans les groupes ou présentant un intérêt autre que celui visé par ces groupes par clapets
B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
15.
Fluid-driven pump having a modular insert and related methods
A fluid pump includes a pump body enclosing a first cavity and a second cavity, a first flexible member disposed within the first cavity, a second flexible member disposed within the second cavity, and a drive shaft extending between and attached to each of the first flexible member and the second flexible member. The drive shaft is configured to slide back and forth within the pump body. The pump also includes a first shift valve and a second shift valve disposed between the first flexible member and the second flexible member, operatively coupled to deliver a drive fluid to drive fluid chambers in alternating sequence. Some fluid pumps disclosed herein include a housing defining a modular-receiving cavity and a modular insert secured within the modular-receiving cavity by an interference fit. Methods of manufacturing and using fluid pumps are also disclosed.
F04B 45/04 - Pompes ou installations de pompage, ayant des organes de travail flexibles, spécialement adaptées pour fluides compressibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
F04B 49/22 - Commande des "machines", pompes ou installations de pompage ou mesures de sécurité les concernant non prévues dans les groupes ou présentant un intérêt autre que celui visé par ces groupes par clapets
F04B 53/22 - Dispositions pour l'assemblage ou le démontage rapide
F04B 43/113 - Pompes ayant un entraînement par fluide le fluide d'entraînement étant commandé par au moins un clapet
16.
Pneumatic reciprocating fluid pump with improved check valve assembly, and related methods
A pneumatic reciprocating fluid pump for pumping a fluid includes at least one check valve assembly that includes a check valve body insert, a ball within the valve body insert, and an annular sealing ring member disposed within a seat ring receptacle. The sealing ring member has dimensions smaller than corresponding dimensions of the seat ring receptacle, such that the sealing ring member is capable of moving within the seat ring receptacle. The ball is configured to slide back and forth between a first position and a second position within the check valve body insert responsive to forward and reverse flow of fluid therethrough. In one position, the ball is seated against the sealing ring member and prevents reverse flow of the fluid through the check valve assembly, and forward flow of the fluid through the check valve assembly is enabled when the ball is in another position.
F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
17.
Pneumatic reciprocating fluid pump with reinforced shaft
Reciprocating fluid pumps include a reinforced shaft including an inner shaft and a protective cover. The protective cover at least substantially encapsulates the inner shaft. The inner shaft exhibits a greater resistance to mechanical deformation than the protective cover, and the protective cover exhibits a greater resistance to chemical corrosion by the subject fluid than the inner shaft. Methods of forming a reciprocating fluid pump include forming a reinforced shaft and positioning the reinforced shaft within a subject fluid chamber and between two plungers.
F04B 9/131 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air avec plusieurs chambres de pompage avec deux organes de pompage liés mécaniquement
F04B 39/00 - Parties constitutives, détails ou accessoires de pompes ou de systèmes de pompage spécialement adaptés aux fluides compressibles, non prévus dans les groupes ou présentant un intérêt autre que celui visé par ces groupes
F04B 53/14 - Pistons, tiges de piston ou liaisons piston-tige
F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
18.
Modular fluid-driven diaphragm pump and related methods
A fluid pump includes a pump body enclosing a first cavity and a second cavity, a first flexible member disposed within the first cavity, a second flexible member disposed within the second cavity, and a drive shaft extending between and attached to each of the first flexible member and the second flexible member. The drive shaft is configured to slide back and forth within the pump body. The pump also includes a first shift valve and a second shift valve disposed between the first flexible member and the second flexible member, operatively coupled to deliver a drive fluid to drive fluid chambers in alternating sequence. Some fluid pumps disclosed herein include a housing defining a modular-receiving cavity and a modular insert secured within the modular-receiving cavity by an interference fit. Methods of manufacturing and using fluid pumps are also disclosed.
F04B 45/00 - Pompes ou installations de pompage, ayant des organes de travail flexibles, spécialement adaptées pour fluides compressibles
F04B 47/08 - Pompes ou installations de pompage spécialement adaptées pour élever un fluide à partir d'une grande profondeur, p. ex. pompes de puits dont les ensembles pompe-moteur sont placés à grande profondeur les moteurs étant actionnés par un fluide
F04B 7/04 - "Machines" ou pompes à piston caractérisées par un entraînement desmodromique des organes du mécanisme de distribution dans lesquels le mécanisme de distribution est réalisé par pistons et cylindres agissant en conjugaison pour ouvrir et fermer les orifices d'aspiration ou de refoulement
F04B 43/12 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles à action péristaltique
F04B 43/073 - Pompes ayant un entraînement par fluide le fluide d'entraînement étant commandé par au moins un clapet
Reciprocating fluid pumps include a pump body including a cavity therein, a plunger located at least partially within the cavity, and a shift canister assembly disposed within the cavity. The shift canister assembly includes a sealing surface for forming a seal against the pump body. An area covered by the seal between the sealing surface and the pump body is less than about 75% of an outer cross-sectional area of the shift canister assembly. The shift canister assembly may include a shift canister and a shift canister cap attached thereto, the shift canister cap comprising the sealing surface. Reciprocating fluid pumps include a shift canister, a shift piston at least partially disposed within the shift canister, and a shift canister cap attached to the shift canister on a longitudinal end of the shift canister opposite the shift piston. Methods include forming such reciprocating pumps.
Reciprocating pumps are disclosed. Particularly, reciprocating pumps including pressure chambers and fluid chambers defined by flexible members are disclosed. The volume of the pressure chambers and fluid chamber may be controlled using a piston driven by the flow of a control fluid to a pressure chamber and associated piston chamber. The flow of the control fluid may be directed to a first pressure chamber and associated piston chamber or a second pressure chamber and associated piston chamber. A pneumatically driven switch or an electrically driven switch may direct the flow of control fluid. The electrically driven switch may be controlled with a timer, a pressure sensor, or an optical sensor. The reciprocating pump requires minimal modification to permit the use of a pneumatic switch or electrical switch.
Reciprocating pumps are disclosed. Particularly, reciprocating pumps including pressure chambers and fluid chambers defined by flexible members are disclosed. The volume of the pressure chambers and fluid chamber may be controlled using a piston driven by the flow of a control fluid to a pressure chamber and associated piston chamber. The flow of the control fluid may be directed to a first pressure chamber and associated piston chamber or a second pressure chamber and associated piston chamber. A pneumatically driven switch or an electrically driven switch may direct the flow of control fluid. The electrically driven switch may be controlled with a timer, a pressure sensor, or an optical sensor. The reciprocating pump requires minimal modification to permit the use of a pneumatic switch or electrical switch.
Coupling structures for tubing are disclosed. Particularly, caps (80) configured for receiving one or more tube segments (70) therein, and securing the tube segments to a component (50) having protrusions (60) thereon including bores (62) therethrough in a fluid-tight manner are disclosed. The caps may have bores longitudinally therethrough for receiving the tube segments, the bore walls being free from projections to fit tightly against the tube segments. A longitudinally distal annular recess of the cap may be threaded to be secured to a component. In another alternative, caps having separate apertures for receiving attachment elements to secure the cap and the component are disclosed. Caps configured with a bore for receiving a tube segment, and separate apertures for receiving attachment pins are additionally disclosed.
F16L 19/04 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord utilisant des segments rigides additionnels, scellés directement à une extrémité du tuyau au moins, cette extrémité étant rabattue soit avant, soit pendant l'opération d'assemblage
F16L 41/08 - Raccordements des tuyaux aux parois ou à d'autres tuyaux, dans lesquels l'axe du tuyau est perpendiculaire au plan de la paroi ou à l'axe de l'autre tuyau
