A tilting and telescoping mast assembly (110) having a compact device footprint that can be mounted in close proximity to, for example, a front wall of a truck bed (e.g., adjacent the cab) thereby reducing dead space within the truck bed and maximizing cargo space within the bed. The mast of the present disclosure is configured to be supported by its base (118) in a first position when in the horizontal orientation and supported in a second position when in the vertical orientation, with the first and second positions being spaced apart horizontally and/or vertically.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
A tilting and telescoping mast assembly having a compact device footprint that can be mounted in close proximity to, for example, a front wall of a truck bed (e.g., adjacent the cab) thereby reducing dead space within the truck bed and maximizing cargo space within the bed. The mast of the present disclosure is configured to be supported by its base in a first position when in the horizontal orientation and supported in a second position when in the vertical orientation, with the first and second positions being spaced apart horizontally and/or vertically.
E04H 12/34 - Dispositions pour élever ou abaisser des tours, mâts, poteaux, corps de cheminée ou analogues
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
E04H 12/22 - Semelles ou montures pour pylônes ou poteaux
Metal telescoping masts; expandable metal support masts for
general industrial or commercial use; portable mounting
systems comprising metal mounting structures for telescoping
masts; movable mounting systems comprising metal mounting
structures for telescoping masts; telescoping masts of
metal, namely, vehicle roof-mounted masts. Power-operated lifting equipment, namely, scissor lifts. Mobile light towers; portable utility lights for mounting on
utility and emergency vehicles and illuminating rescue
scenes; mobile folding light towers; LED light fixtures for
mobile light towers; remote controlled light positioners
specially adapted for portable lights for utility and
emergency vehicles; telescoping masts specially adapted to
be mounted on first response type vehicles for the purpose
of elevating portable lights.
(1) Metal telescoping masts; expandable metal support masts for general industrial or commercial use; portable mounting systems comprising metal mounting structures for telescoping masts; movable mounting systems comprising metal mounting structures for telescoping masts; telescoping masts of metal, namely, vehicle roof-mounted masts.
(2) Power-operated lifting equipment, namely, scissor lifts.
(3) Mobile light towers; portable utility lights for mounting on utility and emergency vehicles and illuminating rescue scenes; mobile folding light towers; LED light fixtures for mobile light towers; remote controlled light positioners specially adapted for portable lights for utility and emergency vehicles; telescoping masts specially adapted to be mounted on first response type vehicles for the purpose of elevating portable lights.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
20 - Meubles et produits décoratifs
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Metal telescoping masts; Expandable metal support masts for general industrial or commercial use; Portable mounting systems comprising metal mounting structures for telescoping masts; movable mounting systems comprising metal mounting structures for telescoping masts; Telescoping masts of metal, namely, vehicle roof-mounted masts Power-operated lifting equipment, namely, scissor lifts Safety and alarm system used with telescoping masts comprised primarily of overhead line detector in the nature of a built-in high voltage, electromagnetic and electrostatic field detection system and also spotlight for use in spotting obstructions; Mounting devices for microwave antennas, namely, pan and tilt positioning assemblies and accessories therefore, namely, specially adapted cases for use therefor; Portable communication antennas; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment and carrying packs specially adapted therefor; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment, and accessories specially adapted therefor, namely, carrying packs, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment; Mounting devices for microwave antennas, namely, pan and tilt positioning assemblies and accessories therefor, namely, controllers and power supplies; pan and tilt positioning assemblies in the nature of tilting heads for microwave antennas, cameras, and spotlights; Electromechanical controls for use in controlling an extendable mast; Telescoping masts; Motorized extendable masts for supporting surveillance equipment, antennas, and wireless network repeaters; Telescoping masts for wireless aerials Mobile light towers; Portable utility lights for mounting on utility and emergency vehicles and illuminating rescue scenes; Mobile folding light towers; LED light fixtures for mobile light towers; Remote controlled light positioners specially adapted for portable lights for utility and emergency vehicles; Telescoping masts specially adapted to be mounted on first response type vehicles for the purpose of elevating portable lights Security cabinets Manufacture of metal and alloy parts to the order and specification of others
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
20 - Meubles et produits décoratifs
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Metal telescoping masts; expandable metal support masts for
general industrial or commercial use; portable mounting
systems comprising metal mounting structures for telescoping
masts; movable mounting systems comprising metal mounting
structures for telescoping masts; telescoping masts of
metal, namely, vehicle roof-mounted masts, not being
structural parts of vehicles. Power-operated lifting equipment, namely, scissor lifts. Safety and alarm system used with telescoping masts
comprised of overhead line detector and spotlight for use in
spotting obstructions; mounting devices for microwave
antennas, namely, pan and tilt positioning assemblies and
accessories therefore; portable communication antennas;
tripods, namely, a tripod with a telescoping mast feature
used to elevate antennas, surveillance and target
acquisition equipment and elevated testing equipment and
carrying packs therefor; tripods, namely, a tripod with a
telescoping mast feature used to elevate antennas,
surveillance and target acquisition equipment, and elevated
testing equipment, and accessories therefor, namely,
carrying packs, guy collars, multiple mounting collars,
mounting and adapter plates, and extension arms; tripods,
namely, a tripod with a telescoping mast feature used to
elevate antennas, surveillance and target acquisition
equipment and elevated testing equipment; mounting devices
for microwave antennas, namely, pan and tilt positioning
assemblies and accessories therefor, namely, controllers and
power supplies; pan and tilt positioning assemblies, namely,
electrically driven pan and tilt apparatus for antennas and
cameras; electromechanical controls for use in controlling
an extendable mast; telescoping masts for elevating antenna
and camera; motorized extendable masts for supporting
surveillance equipment, antennas, and wireless network
repeaters. Mobile light towers; portable utility lights for mounting on
utility and emergency vehicles and illuminating rescue
scenes; mobile folding light towers; LED light fixtures for
mobile light towers; remote controlled light positioners for
utility and emergency vehicles, not being structural parts
of vehicles; telescoping masts for elevating lighting
equipment; telescoping masts of metal that can be mounted on
first response type vehicles for the purpose of elevating
scene lighting. Security cabinets. Manufacture of metal and alloy parts to the order and
specification of others.
An inverted telescoping mast configured to be mounted to a ceiling or other structure within a building for supporting a payload at a range of heights within the building. The mast can include cable management for routing of cables external the mast for supplying/exchanging power, control signals, data etc. to the payload. An internal spring retains the mast in the retracted position. A tension control system restricts extension and/or retraction of the mast when actuating cable tension is above or below respective tension thresholds.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
F16M 11/28 - Soubassements pour supports à pilier télescopique unique
F16M 13/02 - Autres supports ou appuis pour positionner les appareils ou les objetsMoyens pour maintenir en position les appareils ou objets tenus à la main pour être portés par un autre objet ou lui être fixé, p. ex. à un arbre, une grille, un châssis de fenêtre, une bicyclette
An inverted telescoping mast configured to be mounted to a ceiling or other structure within a building for supporting a payload at a range of heights within the building. The mast can include cable management for routing of cables external the mast for supplying/exchanging power, control signals, data etc, to the payload. An internal spring retains the mast in the retracted position. A tension control system restricts extension and/or retraction of the mast when actuating cable tension is above or below respective tension thresholds.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
B60Q 1/26 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules
B66F 3/10 - Dispositifs, p. ex. crics, adaptés pour lever des charges d'un mouvement continu à vis à manchons télescopiques
B66F 3/32 - Moyens pour éviter les à-coups excessifs en fin de mouvement
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
20 - Meubles et produits décoratifs
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Metal telescoping masts; expandable metal support masts for
general industrial or commercial use; portable hardware
mounting systems comprising metal mounting structures for
telescoping masts; movable hardware mounting systems
comprising metal mounting structures for telescoping masts;
telescoping masts of metal, namely, vehicle roof-mounted
masts. Power-operated lifting equipment, namely, scissor lifts;
motorized extendable masts for supporting surveillance
equipment, antennas, and wireless network repeaters. Safety and alarm system used with telescoping masts
comprised of overhead line detector and spotlight for use in
spotting obstructions; mounting devices for microwave
antennas, namely, pan and tilt positioning assemblies and
accessories therefore; portable communication antennas;
tripods, namely, a tripod with a telescoping mast feature
used to elevate antennas, surveillance and target
acquisition equipment and elevated testing equipment and
carrying packs therefor; tripods, namely, a tripod with a
telescoping mast feature used to elevate antennas,
surveillance and target acquisition equipment, and elevated
testing equipment, and accessories therefor, namely,
carrying packs, guy collars, multiple mounting collars,
mounting and adapter plates, and extension arms; tripods,
namely, a tripod with a telescoping mast feature used to
elevate antennas, surveillance and target acquisition
equipment and elevated testing equipment; mounting devices
for microwave antennas, namely, pan and tilt positioning
assemblies and accessories therefor, namely, controllers and
power supplies; pan and tilt positioning assemblies;
telescoping masts for mounting on first response type
vehicles for the purpose of elevating lights;
electromechanical controls for use in controlling an
extendable mast; telescoping masts. Mobile light towers; portable utility lights for mounting on
utility and emergency vehicles and illuminating rescue
scenes; mobile folding light towers; led light fixtures for
mobile light towers; remote controlled light positioners for
utility and emergency vehicles. Security cabinets. Manufacture of metal and alloy parts to the order and
specification of others.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Telescopic cable-drive mast systems, namely, telescoping masts made of metal specially adapted for elevating antennas, cameras, and lighting equipment in the nature of outdoor security lights; Telescopic spindle-drive mast systems, namely, telescoping masts made of metal specially adapted for elevating antennas, cameras, and lighting equipment in the nature of outdoor security lights Telescopic cable-drive mast systems, namely, telescoping masts made of metal specially adapted for elevating lighting equipment in the nature of spot lights, flood lights, and spot lights for use on vehicles; Telescopic spindle-drive mast systems, namely, telescoping masts made of metal specially adapted for elevating antenna, camera, and lighting equipment in the nature of spot lights, flood lights, and spot lights for use on vehicles
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
20 - Meubles et produits décoratifs
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Metal telescoping masts; Expandable metal support masts for general industrial or commercial use; Portable mounting systems comprising metal mounting structures for telescoping masts; movable mounting systems comprising metal mounting structures for telescoping masts; Telescoping masts of metal, namely, vehicle roof-mounted masts Power-operated lifting equipment, namely, scissor lifts Safety and alarm system used with telescoping masts comprised primarily of overhead line detector in the nature of a built-in high voltage, electromagnetic and electrostatic field detection system and also spotlight for use in spotting obstructions; Mounting devices for microwave antennas, namely, pan and tilt positioning assemblies and accessories therefore, namely, specially adapted cases for use therefor; Portable communication antennas; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment and carrying packs specially adapted therefor; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment, and accessories specially adapted therefor, namely, carrying packs, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment; Mounting devices for microwave antennas, namely, pan and tilt positioning assemblies and accessories therefor, namely, controllers and power supplies; pan and tilt positioning assemblies in the nature of tilting heads for microwave antennas, cameras, and spotlights; Electromechanical controls for use in controlling an extendable mast; Telescoping masts; Motorized extendable masts for supporting surveillance equipment, antennas, and wireless network repeaters; Telescoping masts for wireless aerials Mobile light towers; Portable utility lights for mounting on utility and emergency vehicles and illuminating rescue scenes; Mobile folding light towers; LED light fixtures for mobile light towers; Remote controlled light positioners specially adapted for portable lights for utility and emergency vehicles; Telescoping masts specially adapted to be mounted on first response type vehicles for the purpose of elevating portable lights Security cabinets Manufacture of metal and alloy parts to the order and specification of others
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
20 - Meubles et produits décoratifs
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Metal telescoping masts; Expandable metal support masts for general industrial or commercial use; Portable mounting systems comprising metal mounting structures for telescoping masts; movable mounting systems comprising metal mounting structures for telescoping masts; Telescoping masts of metal, namely, vehicle roof-mounted masts Power-operated lifting equipment, namely, scissor lifts Safety and alarm system used with telescoping masts comprised primarily of overhead line detector in the nature of a built-in high voltage, electromagnetic and electrostatic field detection system and also spotlight for use in spotting obstructions; Mounting devices for microwave antennas, namely, pan and tilt positioning assemblies and accessories therefore, namely, specially adapted cases for use therefor; Portable communication antennas; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment and carrying packs specially adapted therefor; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment, and accessories specially adapted therefor, namely, carrying packs, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms; Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment in the nature of microwave antennas, cameras, and spotlights, and elevated testing equipment; Mounting devices for microwave antennas, namely, pan and tilt positioning assemblies and accessories therefor, namely, controllers and power supplies; pan and tilt positioning assemblies in the nature of tilting heads for microwave antennas, cameras, and spotlights; Electromechanical controls for use in controlling an extendable mast; Telescoping masts; Motorized extendable masts for supporting surveillance equipment, antennas, and wireless network repeaters; Telescoping masts for wireless aerials Mobile light towers; Portable utility lights for mounting on utility and emergency vehicles and illuminating rescue scenes; Mobile folding light towers; LED light fixtures for mobile light towers; Remote controlled light positioners specially adapted for portable lights for utility and emergency vehicles; Telescoping masts specially adapted to be mounted on first response type vehicles for the purpose of elevating portable lights Security cabinets Manufacture of metal and alloy parts to the order and specification of others
An auto-lock assembly for a telescoping mast having a plurality of telescoping tube sections configurable between a retracted position and an extended position is disclosed herein. Also disclosed herein is a telescoping mast, which includes a plurality of telescoping mast sections including a base tube, an intermediate tube, and an end tube, the intermediate and end tube adapted to be telescopically received in the base tube, a base auto-lock having a collar for mounting to the base tube, and an intermediate autolock having a collar for mounting to the intermediate tube. Further disclosed herein is an auto-lock for use with a telescoping mast having a plurality of tube sections.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
An auto-lock assembly for a telescoping mast having a plurality of telescoping tube sections configurable between a retracted position and an extended position is disclosed herein. Also disclosed herein is a telescoping mast, which includes a plurality of telescoping mast sections including a base tube, an intermediate tube, and an end tube, the intermediate and end tube adapted to be telescopically received in the base tube, a base auto-lock having a collar for mounting to the base tube, and an intermediate auto-lock having a collar for mounting to the intermediate tube. Further disclosed herein is an auto-lock for use with a telescoping mast having a plurality of tube sections.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
B66C 23/70 - Flèches assemblées à partir de sections séparées pour former des flèches de différentes longueurs
Remote controlled light positioners for utility and
emergency vehicles (terms too vague in the opinion of the
International Bureau – Rule 13(2)(b) of the Common
Regulations).
A folding light tower is provided that utilizes a 4-bar linkage mechanism which enables full vertical extension of the tower with the use of one actuator. The exemplary tower generally includes a base, a lower lift arm, and an upper lift arm. Spring elements are used near the rotating joints of the lower lift arm and upper lift arm of the tower. The spring elements act to preload the joints and help to remove play and movement when the tower is unfolded/during the vertical extension process.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
A folding light tower is provided that utilizes a 4-bar linkage mechanism which enables full vertical extension of the tower with the use of one actuator. The exemplary tower generally includes a base, a lower lift arm, and an upper lift arm. Spring elements are used near the rotating joints of the lower lift arm and upper lift arm of the tower. The spring elements act to preload the joints and help to remove play and movement when the tower is unfolded/during the vertical extension process.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
09 - Appareils et instruments scientifiques et électriques
Produits et services
Telescoping masts; Photographic apparatus and instruments; Cinematographic machines and apparatus; Optical apparatus and instruments; Weighing apparatus and instruments; Nautical apparatus and instruments; Surveying apparatus and instruments; Measuring apparatus and instruments; Checking (supervision) apparatus and instruments; Signalling apparatus and instruments; Life-saving apparatus and instruments; Scientific apparatus and instruments; Teaching apparatus and instruments; Sound transmitting apparatus; Apparatus for the transmission of images; Apparatus for the reproduction of images; Sound reproduction apparatus; Apparatus for recording images; Sound recording apparatus; Fire-extinguishing apparatus; tripods, especially tripods with a telescoping mast feature used to elevate antennas; Antenna masts.
An automatic locking latch system is provided that is driven by the normal extension and retraction of the mast, reduces the inherent rotation and deflection of the mast due to clearances, and operates more smoothly and quietly than conventional locking systems. The locking latch system also fits reasonably within the existing footprint of a typical mechanical mast.
B60Q 1/05 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs étant principalement destinés à éclairer la route en avant du véhicule ou d'autres zones de la route ou des environs les dispositifs étant des phares escamotables
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
A latch assembly and telescoping mast having a plurality of telescoping tube sections including the same wherein the latch assembly includes a first latch member mounted to an associated first tube section, a second latch member mounted to an associated second tube section and configured to selectively engage the first latch member to interlock the first and second associated tubes when the associated first tube section is at least partially extended from the associated second tube section, and a trigger member mounted to an associated third tube section. The second latch member includes a latch housing having an opening configured to receive the trigger post when the second associated tube section is retracted into the third associated tube section.
A telescoping mast assembly having a mast axis and comprising a plurality of telescoping mast sections having axially opposite ends and being axially slidable relative to one another along the mast axis between retracted and extended positions, the telescoping mast sections including a base tube adapted to be fixed to a support surface and an innermost telescoping section, and wherein the innermost telescoping section supports a cylindrical nest lock platform assembly adapted to cover an axial end of the base tube when the mast assembly is in the retracted position, wherein each telescoping mast section includes an internal collar and a cylindrical body and the nest lock platform assembly includes a payload platform and one or more wedges that mate with corresponding notches in the internal collar.
E04H 12/34 - Dispositions pour élever ou abaisser des tours, mâts, poteaux, corps de cheminée ou analogues
H01Q 1/32 - Adaptation pour l'utilisation dans ou sur les véhicules routiers ou ferroviaires
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
E04H 12/00 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures
A telescoping mast assembly having a mast axis and comprising a plurality of telescoping mast sections having axially opposite ends and being axially slidable relative to one another along the mast axis between retracted and extended positions, the telescoping mast sections including a base tube adapted to be fixed to a support surface and an innermost telescoping section, and wherein the innermost telescoping section supports a cylindrical nest lock platform assembly adapted to cover an axial end of the base tube when the mast assembly is in the retracted position, wherein each telescoping mast section includes an internal collar and a cylindrical body and the nest lock platform assembly includes a payload platform and one or more wedges that mate with corresponding notches in the internal collar.
B66F 11/04 - Dispositifs de levage spécialement adaptés à des buts particuliers, non prévus ailleurs pour plates-formes ou cabines mobiles, p. ex. sur des véhicules, permettant à des ouvriers d'occuper toute position convenable pour exécuter les travaux demandés
B60Q 1/24 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs étant principalement destinés à éclairer la route en avant du véhicule ou d'autres zones de la route ou des environs pour éclairer des zones autres que la route, à l'avant du véhicule uniquement
B60Q 1/26 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules
A telescoping mast having a latch assembly includes a latch body mountable to a first tube section, a latch mechanism supported by the latch body, a toggle mechanism operatively connected to the latch mechanism, and a latch plate mountable to a second tube section. The latch mechanism includes a pawl member pivotably between an engaged position for interlocking with a corresponding recess in the latch plate to thereby restrict axial movement between the first and second tube sections, and a disengaged position allowing relative axial movement between the first and second tube sections. The toggle mechanism is movable between an over-center locked configuration corresponding to the engaged position of the latch mechanism and an unlocked configuration corresponding to the disengaged position of the latch member.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
B60Q 1/05 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs étant principalement destinés à éclairer la route en avant du véhicule ou d'autres zones de la route ou des environs les dispositifs étant des phares escamotables
A mast assembly including a locking actuator for locking a cradle of the mast in position. The locking actuator includes a housing having a first lock pin extending in a first direction and a movable member supported by the housing having a second lock pin extending in a second direction opposite the first, the locking actuator being slideably mounted to the cradle for sliding movement along an axis parallel to an axis of extension/retraction of the locking actuator. When the locking actuator is extended the first and second lock pins are inserted into respective lock holes in a base member thereby locking the cradle against pivoting movement relative to the base member.
E04H 12/34 - Dispositions pour élever ou abaisser des tours, mâts, poteaux, corps de cheminée ou analogues
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
Described herein is a safety restraint mechanism for a mast assembly. The safety restraint mechanism comprises a tension line attached to a lever and a winch mechanism such that operation of the winch mechanism translates a carriage assembly along the mast. A cam brake including an engagement profile at a first end thereon is pivotally attached to the lever at a second end. The cam brake is also pivotally attached to the carriage assembly such that the engagement profile pivots into a brake position or a free lift position relative to a tension force acting on the lever. The lever is pivotally attached to the second end and includes a kickstand. The engagement profile having a protruded portion to abut the tubes in a brake position and a relief portion to space the cam brake from the tubes in a free lift position.
B66F 1/00 - Dispositifs, p. ex. crics, pour lever des charges à des paliers prédéterminés
B66F 3/00 - Dispositifs, p. ex. crics, adaptés pour lever des charges d'un mouvement continu
E04H 12/20 - Moyens de support latéraux à cet effet, p. ex. utilisant des amarres ou des entretoises
F16M 11/26 - Infrastructure avec ou sans roues à hauteur ou longueur modifiables des pieds, avec utilisation possible pour le transport également par action télescopique, avec ou sans pliage
F21V 21/06 - Socles pour lampadaires mobilesFixation des corps de lampadaires aux socles
Described herein is a safety restraint mechanism for a mast assembly. The safety restraint mechanism comprises a tension line attached to a lever and a winch mechanism such that operation of the winch mechanism translates a carriage assembly along the mast. A cam brake including an engagement profile at a first end thereon is pivotally attached to the lever at a second end. The cam brake is also pivotally attached to the carriage assembly such that the engagement profile pivots into a brake position or a free lift position relative to a tension force acting on the lever. The lever is pivotally attached to the second end and includes a kickstand. The engagement profile having a protruded portion to abut the tubes in a brake position and a relief portion to space the cam brake from the tubes in a free lift position.
09 - Appareils et instruments scientifiques et électriques
Produits et services
tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment, and elevated testing equipment, and accessories therefor, namely, carrying packs specifically adapted for tripds, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms
52.
TOGGLE LATCH FOR SEQUENTIALLY EXTENDED MECHANICAL MAST
An automatic locking system is provided that is driven by the normal extension and retraction of the mast, reduces the inherent rotation and deflection of the mast due to clearances, and operates more smoothly and quietly than conventional locking systems. The locking system also fits reasonably within the existing footprint of a typical mechanical mast.
B60Q 1/05 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs étant principalement destinés à éclairer la route en avant du véhicule ou d'autres zones de la route ou des environs les dispositifs étant des phares escamotables
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
This disclosure pertains to a lockdown mechanism for an electric drive screw telescoping mast. The lockdown mechanism comprising a plurality of elongated tube sections which are telescopingly attached to each other, each tube section comprising a substantially hollow body. An elongated drive screw is disposed within the hollow body and includes a plurality of threads for extending and retracting the elongated tube sections. A lock subassembly includes a housing and a center hub, the housing comprises a load bearing top and a hollow cavity, the lock subassembly being rigidly attached to said center tube and axially aligned along a central axis with said plurality of elongated tube sections. The center hub is movably engaged within the hollow cavity of the housing and includes at least one locking pin adapted to the center hub that is movably engaged to the structural envelope when the mast is in the lockdown position.
F16M 11/26 - Infrastructure avec ou sans roues à hauteur ou longueur modifiables des pieds, avec utilisation possible pour le transport également par action télescopique, avec ou sans pliage
F16M 11/28 - Soubassements pour supports à pilier télescopique unique
55.
Lockdown mechanism for an electric drive screw telescoping mast system
This disclosure pertains to a lockdown mechanism for an electric drive screw telescoping mast. The lockdown mechanism comprising a plurality of elongated tube sections which are telescopingly attached to each other, each tube section comprising a substantially hollow body. An elongated drive screw is disposed within the hollow body and includes a plurality of threads for extending and retracting the elongated tube sections. A lock subassembly includes a housing and a center hub, the housing comprises a load bearing top and a hollow cavity, the lock subassembly being rigidly attached to said center tube and axially aligned along a central axis with said plurality of elongated tube sections. The center hub is movably engaged within the hollow cavity of the housing and includes at least one locking pin adapted to the center hub that is movably engaged to the structural envelope when the mast is in the lockdown position.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
A rapid deployment and retraction telescoping mast system for controlling the height of a mast. A retraction mechanism including a resilient member, a retraction reel, a reel shaft, and a motor disposed about a frame. The resilient member extends from the retraction reel and is rigidly attached to a top tube of the mast through a sealed passage. The reel shaft rotates the retraction reel and winds the resilient member creating a retraction force on the top tube causing controlled retraction of the mast. A deployment mechanism including a compressor, storage tank, exhaust valve and isolation valve arranged about the frame and in communication with the mast. The compressor generates pressurized air to be communicated to the mast when the isolation valve is in the open position. The increase of pressure generated by the deployment mechanism provides a force within the mast thereby controlling its deployment.
A rapid deployment and retraction telescoping mast system for controlling the height of a mast. A retraction mechanism including a resilient member, a retraction reel, a reel shaft, and a motor disposed about a frame. The resilient member extends from the retraction reel and is rigidly attached to a top tube of the mast through a sealed passage. The reel shaft rotates the retraction reel and winds the resilient member creating a retraction force on the top tube causing controlled retraction of the mast. A deployment mechanism including a compressor, storage tank, exhaust valve and isolation valve arranged about the frame and in communication with the mast. The compressor generates pressurized air to be communicated to the mast when the isolation valve is in the open position. The increase of pressure generated by the deployment mechanism provides a force within the mast thereby controlling its deployment.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
A portable tripod mast assembly is provided that includes a tripod, a plurality of mast sections and a transport pack. The tripod includes at least three telescoping legs, wherein each leg is moveably attached to a common upper collar. The plurality of mast sections are each adapted to fit together end to end, forming a mast. The transport pack has a center compartment adapted to receive the tripod, wherein the center compartment includes a center panel and two side panels. Each side panel includes a plurality of individual pockets for receiving the mast sections. The transport pack further includes a base portion and a hood capable of extending over the mast sections, securing the sections in the pockets.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Common metals and their alloys; Metal building materials; Transportable buildings of metal; Materials of metal for railway tracks; Non-electric cables and wires of common metal; Ironmongery, small items of metal hardware; Pipes and tubes of metal; Safes; Goods of common metal not included in other classes; expandable metal support masts for general industrial or commercial use; active portable field-erected telescoping mast assemblies and carrying packs therefore; Ores. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers, calculating machines; Fire-extinguishing apparatus; tripods, especially tripods with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment, and elevated testing equipment and accessories therefor, namely specially adapted carrying bags, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms; telescoping masts including antenna masts and safety and alarm systems therefor; alternating current sensing devices. Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes; electric light units including those which are remotely controlled.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Common metals and their alloys; Metal building materials; Transportable buildings of metal; Materials of metal for railway tracks; Non-electric cables and wires of common metal; Ironmongery, small items of metal hardware; Pipes and tubes of metal; Safes; Goods of common metal not included in other classes; expandable metal support masts for general industrial or; commercial use; active portable field-erected telescoping mast assemblies and carrying packs therefore; Ores. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers, calculating machines; Fire-extinguishing apparatus; tripods, especially tripods with a telescoping; mast feature used to elevate antennas, surveillance and target acquisition equipment, and elevated testing equipment and accessories therefor, namely specially adapted carrying bags, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms; telescoping masts including antenna masts and safety and alarm systems therefor; alternating current sensing devices.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Common metals and their alloys; Metal building materials; Transportable buildings of metal; Materials of metal for railway tracks; Non-electric cables and wires of common metal; Ironmongery, small items of metal hardware; Pipes and tubes of metal; Safes; Goods of common metal not included in other classes; expandable metal support masts for general industrial or; commercial use; active portable field-erected telescoping mast assemblies and carrying packs therefore; Ores. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers, calculating machines; Fire-extinguishing apparatus; tripods, especially tripods with a telescoping; mast feature used to elevate antennas, surveillance and target acquisition equipment, and elevated testing equipment and accessories therefor, namely specially adapted carrying bags, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms; telescoping masts including antenna masts and safety and alarm systems therefor; alternating current sensing devices.
09 - Appareils et instruments scientifiques et électriques
Produits et services
tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment, and elevated testing equipment, and accessories therefor, namely, carrying packs, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Common metals and their alloys; Metal building materials; Transportable buildings of metal; Materials of metal for railway tracks; Non-electric cables and wires of common metal; Ironmongery, small items of metal hardware; Pipes and tubes of metal; Safes; Goods of common metal not included in other classes; active portable field-erected telescoping mast assemblies and carrying packs therefore; Ores. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Magnetic data carriers, recording discs; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers, calculating machines, data processing equipment and computers; Fire-extinguishing apparatus; telescoping masts including antenna masts and safety and alarm systems therefor; alternating current sensing devices. Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes; electric light units including those which are remotely controlled.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Common metals and their alloys; Metal building materials; Transportable buildings of metal; Materials of metal for railway tracks; Non-electric cables and wires of common metal; Ironmongery, small items of metal hardware; Pipes and tubes of metal; Safes; Goods of common metal not included in other classes; active portable field-erected telescoping mast assemblies and carrying packs therefore; Ores. Scientific,Nautical, surveying, Photographic,Cinematographic, weighing, signalling and, Teaching apparatus and Instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Magnetic data carriers, recording discs; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers, calculating machines, data processing equipment and computers; Fire-extinguishing apparatus; Telescoping masts including antenna masts and safety and alarm systems therefor; Alternating current sensing devices. Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes; electric light units including those which are remotely controlled.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Common metals and their alloys; Metal building materials; Transportable buildings of metal; Materials of metal for railway tracks; Non-electric cables and wires of common metal; Ironmongery, small items of metal hardware; Pipes and tubes of metal; Safes; Goods of common metal not included in other classes; active portable field-erected telescoping mast assemblies and carrying packs therefore; Ores. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; Apparatus for recording, transmission or reproduction of sound or images; Automatic vending machines and mechanisms for coin-operated apparatus; Cash registers, calculating machines; Fire-extinguishing apparatus; telescoping masts including antenna masts and safety and alarm systems therefor; alternating current sensing devices. Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes; electric light units including those which are remotely controlled.
09 - Appareils et instruments scientifiques et électriques
Produits et services
tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment, and elevated testing equipment, and accessories therefor, namely, carrying packs, guy collars, multiple mounting collars, mounting and adapter plates, and extension arms
09 - Appareils et instruments scientifiques et électriques
Produits et services
Tripods, namely, a tripod with a telescoping mast feature used to elevate antennas, surveillance and target acquisition equipment and elevated testing equipment and carrying packs therefor
A portable telescopic mast assembly with positive retraction for raising and lowering an associated device includes an outer body and a plurality of mast sections slideably engaged with the outer body. A lifting cable is disposed between the plurality of mast sections. The lifting cable operatively connects the plurality of mast sections so as to urge one or more of the mast sections towards an extended position. The lifting cable includes a first end and a second end, the first end being secured to an inner most mast section of the plurality of mast sections. A retraction cable is disposed at least partially inside the outer body. The retraction cable includes a first end and a second end, the first end being secured to the inner most mast section. A winch is secured to the outer body. The winch includes a first output and a second output, the second end of the lifting cable operatively connected to the first output and the second end of the retraction cable operatively connected to the second output.
A portable telescopic mast assembly with positive retraction for raising and lowering an associated device includes an outer body and plurality of mast sections slideably engaged with the outer body. A lifting cable is disposed between the plurality of mast sections. The lifting cable operatively connects the plurality of mast sections so as to urge one or more of the mast sections towards an extended position. The lifting cable includes a first end and a second end, the first end being secured to an inner most mast section of the pluralit of mast sections. A retraction cable is disposed at least partially inside the outer body. The retraction cable includes a first end and a second end, the first end being secured to the inner most mast section.
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
71.
PNEUMATICALLY TELESCOPING MAST WITH DUAL MODE REMOTE CONTROL
A dual mode handheld remote control for selectively operating and communicating with an associated mast arrangement in one of a wired or a wireless mode is provided. The remote control includes a housing and a controller disposed internally to the housing. The controller includes a wireless communication mode for wirelessly communicating with the mast arrangement and a wired communication mode for communicating with the mast arrangement via a wired connection. An input device is secured to the housing and is operatively connected to the controller. The input device is responsive to an associated command selected by an associated operator and relays the associated command to the controller for controlling the associated mast arrangement. A power source is provided for powering the remote control.
B60Q 1/06 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs étant principalement destinés à éclairer la route en avant du véhicule ou d'autres zones de la route ou des environs les dispositifs étant des phares réglables, p. ex. commandés à distance de l'intérieur du véhicule
A telescoping mast has a plurality of elongate tubular sections which are telescopically attached to each other and an axial drive screw centrally located in the mast for extending and retracting the elongate tubular section. A gear assembly is connected to the drive screw for rotating the drive screw. A nut carrier assembly is secured to tubular sections. Each nut carrier assembly has a threaded nut housed within a nut carrier. The threaded nut engages corresponding threads on the drive screw. A locking mechanism is provided for locking the gear assembly which has a first section surrounding a second section secured to the gear assembly. The second section has an elongated member extending from a surface of the second section. The first section has at least one slot for engaging the elongated member, thereby preventing rotation of the gear assembly.
F16H 1/20 - Transmissions à engrenages pour transmettre un mouvement rotatif sans engrenages à mouvement orbital comportant plus de deux organes engrenés
A rigid support bearing for a rotating shaft has bearings arranged concentrically around the shaft instead of spaced axially and is used in a screw drive telescoping mast assembly. An axial drive screw is centrally located in the mast assembly for extending and retracting the tubular sections. A lower bearing assembly supports the drive screw and uses the concentric bearing arrangement to reduce the nested height of the mast.
E04H 12/34 - Dispositions pour élever ou abaisser des tours, mâts, poteaux, corps de cheminée ou analogues
E04H 12/18 - ToursMâts ou pylônesCheminées d'usineChâteaux d'eauProcédés d'édification de ces structures mobiles ou avec des sections mobiles, p. ex. tournantes ou télescopiques
F16C 19/54 - Systèmes formés d'une pluralité de paliers à frottement de roulement
75.
Pneumatically telescoping mast having DC operated controls
A control system for a pneumatically operated mast has a first control, a second control, and a positioning member. A first serial link communicates the first control with the second control. A second serial link communicates the second control with the positioning member. A relay system communicates with the first and second control and the positioning member. The relay system accommodates a 12 voltage or 24 voltage source.
