A human-powered vehicle control device is provided for a human-powered vehicle. The human-powered vehicle control device includes a first slave electronic controller and a second slave electronic controller. The first slave electronic controller performs autonomous control without relying on control signals from a first operating device, and is provided in a first component, the first component being configured to be supplied with electric power from a battery. The second slave electronic controller performs autonomous control without relying on control signals from a second operating device and is provided in a second component the second component being configured to be supplied with electric power from a battery. The state of autonomous control of the first slave electronic controller or the second slave electronic controller is restricted based on a voltage level of the battery.
A human-powered vehicle component includes an input shaft to which human driving force is input and which has an input center axis, a first housing, a second housing coupled to the first housing, a rotation ratio shifting unit to which rotational force of the input shaft is transmitted, and a transmission unit including a transmission input portion to which rotational force from the rotation ratio shifting unit is input, a transmission output portion that externally outputs rotational force input to the transmission input portion, and a transmission center axis differing from the input center axis. The transmission unit is configured to shift a transmission ratio of rotational speed of the transmission output portion to rotational speed of the transmission input portion. At least part of the rotation ratio shifting unit is provided in the first housing. At least part of the transmission unit is provided in the second housing.
B62M 11/18 - Transmissions caractérisées par l'engrènement de roues dentées ou le contact de roues à friction de rapport variable avec engrenages planétaires avec plusieurs ensembles d'engrenages planétaires
B62M 6/40 - Cycles propulsés par le conducteur avec moteur électrique auxiliaire
F16H 57/08 - Parties constitutives générales des transmissions des transmissions à organes à mouvement orbital
A fishing reel includes a spool provided on a reel body to be rotatable and to wind up a fishing line, a conductive part provided on the spool, a magnet facing the conductive part, a movable part holding the magnet so as to be movable between a first position located in a first direction that is a direction away from the conductive part, and a second position located in a second direction that is a direction opposite to the first direction. The second position located farther in the second direction than the first position is in the first direction with respect to the conductive part. The movable part movable between the first position and the second position in accordance with rotation of the spool, and a contact part on the movable part contacts the spool when the movable part is located at the second position.
A rotational-position sensor unit comprises sensor circuitry configured to detect at least one of: at least one reference sprocket tooth of a sprocket of a human-powered vehicle; and a space provided between adjacent two teeth including the at least one reference sprocket tooth.
B62M 9/122 - Dérailleurs arrière à actionnement électrique ou fluidiqueDérailleurs arrière leurs commandes
G01D 5/12 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens électriques ou magnétiques
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Bicycles, including electric bicycles; parts, fittings and accessories for bicycles, including electric bicycles namely, hubs, internal gear hubs, bicycle hub which contains dynamo inside, bicycle hub which contains bicycle power meter inside, hub quick release levers, hub quick release devices, axles of hubs, gear release levers, gear shift levers, gear shifting apparatus, derailleurs, chain guides, freewheels, sprockets, pulleys adapted for use with bicycles, chains, shift cables, cranks, crank which contains bicycle power meter inside, crank sets, front chain wheels, pedals, pedal which contains bicycle power meter inside, bicycle pedal cleats, toe clips, brake levers, brakes, brake cables, brake shoes, rims, brake rotors, brake pads, wheels, tires, inner tubes, spokes, spoke clips, bottom brackets, seat pillars, head parts for frame-fork assembly, suspensions, handlebars, handlebar stems, grips for handlebars, bar ends, seat posts, saddles, gear position indicators for bicycles, electric motors for bicycles, Electric motors for electrically assisted bicycles, Electric motors for electrical bicycles, drive units for electrically assisted bicycles, drive units for electrical bicycles, shift switches, switches for bicycles
A disc brake caliper of a human-powered vehicle includes a caliper body including a first hole and a second hole, a first piston movably provided in the first hole, and a second piston movably provided in the second hole. The first piston has a first outer diameter. The second piston has a second outer diameter. A ratio of the first outer diameter to the second outer diameter is greater than or equal to 1.15.
B62L 1/12 - FreinsLeurs aménagements dans lesquels les organes de freinage attaquent les roues en agissant sur la jante par des organes se déplaçant sensiblement parallèlement à l'axe de la roue les organes étant montés sur des leviers pivotant autour d'un axe commun
F16D 55/228 - Freins à surfaces de freinage substantiellement radiales pressées l'une contre l'autre dans une direction axiale, p. ex. freins à disques avec disques ou patins déplaçables selon l'axe pressés contre des organes en rotation situés dans l'axe par serrage entre des organes mobiles de freinage, p. ex. des disques ou des patins de freins mobiles avec un organe d'actionnement séparé pour chaque face
F16D 65/00 - Éléments constitutifs ou détails des freins
F16D 65/12 - DisquesTambours pour freins à disques
F16D 65/18 - Mécanismes d'actionnement pour freinsMoyens pour amorcer l'opération de freinage à une position prédéterminée disposés dans, ou sur le frein adaptés pour rapprocher les organes par traction
F16D 55/00 - Freins à surfaces de freinage substantiellement radiales pressées l'une contre l'autre dans une direction axiale, p. ex. freins à disques
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Bicycles, including electric bicycles; parts, fittings and accessories for bicycles, including electric bicycles namely, hubs, internal gear hubs, bicycle hub which contains dynamo inside, bicycle hub which contains bicycle power meter inside, hub quick release levers, hub quick release devices, axles of hubs, gear release levers, gear shift levers, gear shifting apparatus, derailleurs, chain guides, freewheels, sprockets, pulleys adapted for use with bicycles, chains, shift cables, cranks, crank which contains bicycle power meter inside, crank sets, front chain wheels, pedals, pedal which contains bicycle power meter inside, bicycle pedal cleats, toe clips, brake levers, brakes, brake cables, brake shoes, rims, brake rotors, brake pads, wheels, tires, inner tubes, spokes, spoke clips, bottom brackets, seat pillars, head parts for frame-fork assembly, suspensions, handlebars, handlebar stems, grips for handlebars, bar ends, seat posts, saddles, gear position indicators for bicycles, electric motors for bicycles, Electric motors for electrically assisted bicycles, Electric motors for electrical bicycles, drive units for electrically assisted bicycles, drive units for electrical bicycles, shift switches, switches for bicycles.
A master bicycle electric component includes a bicycle mounting part and a master two-way wireless communication unit. The bicycle mounting part is configured to mount the master bicycle electric component to a bicycle. The master two-way wireless communication unit is configured to wirelessly receive update information from an external terminal device that is not mounted to the bicycle. The external terminal device is separate and remote from the master bicycle electric component. In a case where the update information includes information for updating at least one of software and firmware of at least one slave bicycle electric component, the master bicycle electric component is configured to wirelessly transmit the update information to the at least one slave bicycle electric component directly.
B62M 25/08 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission électrique ou par fluide
B62K 19/36 - Parties du cadre profilées pour recevoir d'autres parties ou accessoires du cycle pour la fixation des supports de selle, p. ex. de manière réglable durant la marche
B62K 23/02 - Partie initiale des commandes actionnée par le conducteur et spécialement adaptée aux cycles, p. ex. leviers, poignées actionnée à la main
B62K 25/04 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche
B62K 25/08 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche avec fourche télescopique, p. ex. comportant des bras basculants auxiliaires pour roue avant
B62K 25/28 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche avec support de chaînes à pivot
A control device for a human-powered vehicle includes an electronic controller configured to control a transmission device for shifting a transmission ratio that is a ratio of a rotational speed of a wheel to a rotational speed of a crank axle. In a case where the electronic controller controls the transmission device to decrease the transmission ratio based on a first shifting condition, the electronic controller controls the transmission device so that the transmission ratio does not become less than a first transmission ratio that is greater than a minimum transmission ratio. In a case where the electronic controller controls the transmission device to decrease the transmission ratio based on a second shifting condition, the electronic controller controls the transmission device so that the transmission ratio does not become less than a second transmission ratio that is greater than the first transmission ratio.
B62M 25/08 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission électrique ou par fluide
A hub for a wheel of a human-powered vehicle comprises, a hub body and first and second spoke seats portions arranged at opposite sides of the hub body. The first spoke seats portion includes a first outer surface extending circumferentially, inner recesses, each receiving an inner spoke, and outer recesses, each receiving an outer spoke. The inner recesses and the outer recesses are arranged in the first outer surface. The inner spoke intersects with the outer spoke as viewed axially. Each inner recess has an axial inner opening and an inner additional opening which opens in the first outer surface. The inner spoke extends through the inner additional opening. The outer recess has an axial outer opening facing away from the axial inner opening and an outer additional opening which opens in the first outer surface. The outer spoke extends through the outer additional opening.
A fishing reel is capable of adding drag force without an increase in reel size. The fishing reel includes a reel body. A handle is rotatably mounted on the reel body and a drive shaft is configured to rotate integrally with the handle. A drive gear is arranged around the drive shaft. In the fishing reel, a first drag mechanism configured to restrict relative rotation between the drive gear and the drive shaft, and a second drag mechanism is configured to restrict rotation of the drive gear relative to the reel body.
A spinning reel includes a spool, a rotor, a bail arm, a moving member, detected part, and a detected part. The bail arm pivots between a first posture in which a fishing line can be wound onto the spool by rotation of the rotor, and a second posture in which the fishing line is released from the spool. The moving member is at a first position when the bail arm is in the first posture, is positioned at a second position when the bail arm is in the second posture, and returns the bail arm from the second posture of the bail arm to the first posture of the bail arm by shifting from the second position to the first position. The detected part is on the moving member, and the first detecting part is on the reel body and detects a position of the detected part.
09 - Appareils et instruments scientifiques et électriques
18 - Cuir et imitations du cuir
25 - Vêtements; chaussures; chapellerie
28 - Jeux, jouets, articles de sport
Produits et services
Life-saving apparatus; parts and fittings for life-saving
equipment; life jackets [clothing]; life vests [clothing];
life belts; life nets; fishing life jackets [clothing];
life-saving swim floats; flotation vests; air inflatable
life jackets; gas inflatable life jackets; knee pads for
protection against accidents; elbow pads for protection
against accidents; clothing for protection against
accidents; light-reflective clothing for protection against
accidents; gloves for protection against accidents; shoes
for protection against accidents; computer programs; covers
for smartphones; cases for smartphones; straps for
smartphones; covers for personal digital assistants; cases
for personal digital assistants; sports whistles; air tanks
for scuba diving; snorkels; measurement instruments; bicycle
speedometers equipped with mechanism that displays riding
conditions, namely, riding speed, travel distance, gear
ratio; telecommunication machines and apparatus; protective
helmets for sports; protective helmets for bicycle racing. Tool bags sold empty; tote bags; shoulder bags; duffle bags;
duffle bags with rolling wheels; backpacks; backpacks with
rolling wheels; rucksacks; waist bags; belt bags; belt
pouches; travel duffle bags; bags for clothes; garment bags;
shoe bags for travel; shoe bags for outdoor activities;
trunks [luggage]; travel luggage; travel cases; luggage
organizers; cases for organizing travel luggage; all-purpose
carrying bags; backpacks for transporting luggage; bag
straps; leather straps for luggage; umbrellas; umbrella
covers; industrial packaging containers of leather; walking
sticks. Clothing; shoes [other than special footwear for sports];
boots [other than special footwear for sports]; outdoor
clothing; coats; trousers; raincoats; vests; fishing vests;
windbreaker; windcheaters; sports shirts; polo shirts;
parkas; sweatshirts; sweatpants; hooded sweatshirts;
breeches for wear; sports breeches; tee-shirts; blousons;
socks; socks and stockings other than special sportswear;
mufflers [clothing]; ear muffs [clothing]; gloves
[clothing]; fishing gloves [clothing]; neck warmers; arm
warmers [clothing]; leg warmers; knee warmers; fishing
waders; anglers' shoes; winter boots; fishing shirts;
fishermen's jackets; waterproof boots for fishing; caps
[headwear]; hats; sock suspenders; gaiter straps; belts
[clothing]; leather clothes; artificial leather clothes. Fishing tackle; fishing floats; fishing sinkers; landing
nets for anglers; fishing lines; fishing reels; fishing
rods; reel seats for fishing; cases for fishing reels; cases
for fishing rods; fishing hooks; lures for fishing; line
guides for fishing rods; artificial fishing bait; fishing
plugs; handheld fishing nets; bags adapted for fishing
tackle; cases for fishing tackle; bite sensors being fishing
tackle; bite indicators being fishing tackle; creels being
fishing traps; fishing bags.
A derailleur hanger includes first and second portions. The first portion mountable to a hub axle, and the second portion coupled to the first portion, to support a derailleur. The first portion includes a frame contact surface disposed in a reference plane extending perpendicular to a center axis of the hub axle, and an axle contact surface to contact a hub axle. The second portion includes a first surface on a first side of the reference plane and a second surface on a second side of the reference plane, the first side being opposite to the second side with respect to the reference plane, a vehicle center plane being positioned at the second side in the installed state. The axle contact surface is on the second side of the reference plane, and the axle contact surface is farther from the reference plane than the second surface.
Tweezers; kitchen knives; utility knives; knives for hobby
use; utility knives for fishing; fish knives; fishing
knives; fishing scoops; scaling knives; fishing picks for
dispatching fish; hand tools for fishing, namely,
dispatching pointed tools for fish; hand tools for fishing,
namely, dispatching edge tools for squids and octopuses;
fish line cutters; folding knives; wire cutters; diving
knives; hunting knives; knife sheaths; pre-filled tool bags
containing hand tools for fishing; scissors for household;
scissors for fishing lines; fishing line scissors with
carabiners; fishing line cutters with carabiners; cutting
pliers; pliers being hand tools; nippers; cutting pliers for
fishing; pliers for fishing; nippers for fishing; hand
operated line winders for fishing reels; clamps being hand
tools; bench vises being hand operated implements; hand
operated mixing devices for fishing; hand operated blending
device for mixing fishing bait; hand operated blending
spatulas for mixing fishing bait; hand operated tools for
blending fishing bait; hand operated tools for braiding;
hand operated hoes; digging forks; hand operated lasts for
shoe making; electric irons; razors; hair clippers; forks
and spoons being tableware; can openers, non-electric;
dressmakers' chalk sharpeners; bludgeons; hand-operated
insecticide sprayers; ice axes; palette knives. Fishing tackle; fishing floats; fishing sinkers; landing
nets for anglers; fishing lines; fishing reels; fishing
rods; reel seats for fishing; cases for fishing reels; cases
for fishing rods; fishing hooks; lures for fishing; line
guides for fishing rods; artificial fishing bait; fishing
plugs; handheld fishing nets; bags adapted for fishing
tackle; cases for fishing tackle; bite sensors being fishing
tackle; bite indicators being fishing tackle; creels being
fishing traps.
A relay unit comprises first interface circuitry, second interface circuitry, and controller circuitry. The first interface circuitry is configured to be electrically connected to an assist drive unit of a human-powered vehicle. The assist drive unit is configured to assist propulsion of the human-powered vehicle. The second interface circuitry is configured to be electrically connected to a transmission device of the human-powered vehicle. The transmission device is configured to execute a gear shifting of the human-powered vehicle. The controller circuitry is electrically connected to the first interface circuitry and the second interface circuitry. The controller circuitry is configured to receive information relating to the human-powered vehicle from a sensor configured to detect the information. The controller circuitry is configured to change a timing of the gear shifting of the transmission device based on the information.
B62M 25/08 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission électrique ou par fluide
A human-powered vehicle component comprises wireless communicator circuitry. The wireless communicator circuitry is configured to transmit a first wireless signal to a first additional human-powered vehicle component using a first communication protocol in response to a first user input. The wireless communicator circuitry is configured to transmit a second wireless signal to a second additional human-powered vehicle component using a second communication protocol different from the first communication protocol in response to a second user input different from the first user input.
B62M 25/08 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission électrique ou par fluide
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Containers for transport, not of metal; storage containers,
not of metal; tool boxes, not of metal [empty]; plastic
boxes; packaging containers of plastic; general purpose
storage containers, not of metal; containers, not of metal,
for storage and transport. Food preserving jars of glass; drinking flasks; vacuum
bottles; portable cooler box, non-electric; non-electric
portable food and drink ice box; thermally insulated
containers for food; non-electric portable coolers; portable
beverage coolers, non-electric; non-electric portable ice
chests for food and beverages; heat-insulated containers for
beverages; heat-insulated containers for foods;
heat-insulated containers; non-electric portable cool boxes
for fishing.
A fishing tackle includes a detection unit that detects an operating state of a fishing tackle in a casting operation, and a calculation unit that estimates the water landing location of the rig that has been cast on the basis of the detection result of the detection unit.
A derailleur hanger includes a first portion, a second portion, a third portion and a pin. The first portion includes an axle receiving bore for receiving a hub axle. The second portion includes a derailleur support surface for supporting a derailleur. The third portion includes a first surface facing in a first direction, a second surface facing in a second direction opposite the first direction, and a third surface facing in the first direction. The pin includes a first part coupled to the third portion, a second part projecting in the first direction from the third surface to be received in a pin receiving portion of a bicycle frame, and a frangible part disposed between the first part and the second part. The frangible part breaks relative to the first part and the second part upon application of a predetermined force or higher to the pin.
A derailleur hanger assembly includes a derailleur hanger, a hanger washer and a hanger bolt. The derailleur hanger includes an axle receiving bore having an internal thread and a frame attachment surface that contacts a bicycle frame in a mounted state. The hanger washer has a bolt receiving opening extending between a frame contact surface and a bolt contact surface. The hanger bolt includes a shaft portion and a head portion. The head portion has an axial contact surface facing in an axial direction of the shaft portion. The shaft portion includes an externally threaded portion that is threadedly coupled to the internal thread of the derailleur hanger. A distance between the axial contact surface and the frame attachment surface is larger than a thickness of the bicycle frame in a state where the hanger bolt is tightened to the derailleur hanger without the hanger washer.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Bicycles, including electric bicycles; parts, fittings and
accessories for bicycles, including electric bicycles,
namely, hubs, internal gear hubs, bicycle hub which contains
dynamo inside, bicycle hub which contains bicycle power
meter inside, hub quick release levers, hub quick release
devices, axles of hubs, gear release levers, gear shift
levers, gear shifting apparatus, derailleurs, chain guides,
freewheels, sprockets, pulleys adapted for use with
bicycles, chains, shift cables, cranks, crank which contains
bicycle power meter inside, crank sets, front chain wheels,
pedals, pedal which contains bicycle power meter inside,
bicycle pedal cleats, toe clips, brake levers, brakes, brake
cables, brake shoes, rims, brake rotors, brake pads, wheels,
tires, inner tubes, spokes, spoke clips, bottom brackets,
seat pillars, head parts for frame-fork assembly,
suspensions, handlebars, handlebar stems, grips for
handlebars, bar ends, seat posts, saddles, gear position
indicators for bicycles, electric motors for bicycles,
electric motors for electrically assisted bicycles, electric
motors for electrical bicycles, drive units for electrically
assisted bicycles, drive units for electrical bicycles,
shift switches, switches for bicycles.
A bicycle derailleur includes a base member, a movable member, a linkage structure, a wireless communicator, an electrical connector receiving portion, and a battery. The base member is configured to be attached to a bicycle frame. The movable member is movable with respect to the base member. The linkage structure is connected with the base member and the moveable member. The wireless communicator is disposed at at least one of the base member, the movable member and the linkage structure. The electrical connector receiving portion is configured to receive a connector. The battery is disposed at the base member. The electrical connector receiving portion is configured to be electrically connected to the battery. The battery is configured to be charged with electricity through the electrical connector receiving portion.
B62M 25/08 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission électrique ou par fluide
B62M 9/122 - Dérailleurs arrière à actionnement électrique ou fluidiqueDérailleurs arrière leurs commandes
A lure comprises a plurality of line eyes. The plurality of line eyes can be connected to a line. The plurality of line eyes are connected to each other via a communication hole.
A lure is provided that improves usability of a propeller. The lure according to one embodiment includes a body, a rotatable portion, and a propeller. The rotatable portion is rotatably attached to the body. The propeller is configured to be detachably attached to the rotatable portion.
A01K 85/12 - Amorces artificielles pour la pêche à la ligne comprenant un corps rotatif autour de son axe longitudinal, p. ex. devons
A01K 85/00 - Amorces artificielles pour la pêche à la ligne
61.
CONTROL SYSTEM FOR HUMAN-POWERED VEHICLE, COMPONENT FOR HUMAN-POWERED VEHICLE, CONTROL PROGRAM RELATED TO COMPONENT FOR HUMAN-POWERED VEHICLE, AND METHOD FOR CONTROLLING COMPONENT FOR HUMAN-POWERED VEHICLE
A component includes a second controller, a second wireless communication unit and a second storage. The second storage is configured to store first identification information of a first component of a human-powered vehicle and second identification information of the component. The second controller is configured to control the second wireless communication unit so that the second wireless communication unit transmits the second identification information stored in the second storage to a communication device. The second controller is configured to control the second storage so that the second storage stores the first identification information in response to receipt of the first identification information from the first component by the second wireless communication unit after the second identification information is transmitted to the communication device.
B62J 45/20 - Calculateurs pour cycles en tant qu’accessoires de cycle
B62J 50/22 - Dispositifs fournissant des informations ayant pour objet de fournir des informations au conducteur ou au passager électroniques, p. ex. écrans
A lure includes a plate member and a body. The plate member has a line eye to which a line can be connected. The plate member is attached to the body. The body has a restricting portion. The restricting portion restricts the movement of the plate member relative to the body.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Parts, fittings and accessories for bicycles, including electric bicycles, namely, hubs, internal gear hubs, bicycle hub which contains dynamo inside, bicycle hub which contains bicycle power meter inside
Tweezers; kitchen knives; utility knives; knives for hobby use; utility knives for fishing; fish knives; fishing knives; fishing scoops; scaling knives; fishing picks for dispatching fish; hand tools for fishing, namely, dispatching pointed tools for fish; hand tools for fishing, namely, dispatching edge tools for squids and octopuses; fish line cutters; folding knives; wire cutters; diving knives; hunting knives; knife sheaths; pre-filled tool bags containing hand tools for fishing; scissors for household; scissors for fishing lines; fishing line scissors with carabiners; fishing line cutters with carabiners; cutting pliers; pliers being hand tools; nippers; cutting pliers for fishing; pliers for fishing; nippers for fishing; hand operated line winders for fishing reels; clamps being hand tools; bench vises being hand operated implements; hand operated mixing devices for fishing; hand operated blending device for mixing fishing bait; hand operated blending spatulas for mixing fishing bait; hand operated tools for blending fishing bait; hand operated tools for braiding; hand operated hoes; digging forks; hand operated lasts for shoe making; electric irons; razors; hair clippers; forks and spoons being tableware; can openers, non-electric; dressmakers' chalk sharpeners; bludgeons; hand-operated insecticide sprayers; ice axes; palette knives Fishing tackle; fishing lines; fishing reels; fishing rods; lures for fishing; artificial fishing bait
A guide for a fishing rod includes a rod body, a guide ring configured to have a fishing line inserted therethrough, and a guide frame fixed to the rod body, extending outward in a radial direction of the rod, and holding the guide ring. The guide frame having an inner circumferential groove and a frame comprising a ring-shaped wire material holding the guide ring, a supporting leg portion fixed to the rod body and connecting to and supporting the frame, and a first opposing surface of the inner circumferential groove opposing at least a portion of the ring. A second opposing surface of the ring opposes the first opposing surface, the first and second opposing surfaces having different shapes.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
(1) Bicycles, including electric bicycles; parts, fittings and accessories for bicycles, including electric bicycles, namely, hubs, internal gear hubs, bicycle hub which contains dynamo inside, bicycle hub which contains bicycle power meter inside, hub quick release levers, hub quick release devices, axles of hubs, gear release levers, gear shift levers, gear shifting apparatus, derailleurs, chain guides, freewheels, sprockets, pulleys adapted for use with bicycles, chains, shift cables, cranks, crank which contains bicycle power meter inside, crank sets, front chain wheels, pedals, pedal which contains bicycle power meter inside, bicycle pedal cleats, toe clips, brake levers, brakes, brake cables, brake shoes, rims, brake rotors, brake pads, wheels, tires, inner tubes, spokes, spoke clips, bottom brackets, seat pillars, head parts for frame-fork assembly, suspensions, handlebars, handlebar stems, grips for handlebars, bar ends, seat posts, saddles, gear position indicators for bicycles, electric motors for bicycles, electric motors for electrically assisted bicycles, electric motors for electrical bicycles, drive units for electrically assisted bicycles, drive units for electrical bicycles, shift switches, switches for bicycles.
(1) Tweezers; kitchen knives; utility knives; knives for hobby use; utility knives for fishing; fish knives; fishing knives; fishing scoops; scaling knives; fishing picks for dispatching fish; hand tools for fishing, namely, dispatching pointed tools for fish; hand tools for fishing, namely, dispatching edge tools for squids and octopuses; fish line cutters; folding knives; wire cutters; diving knives; hunting knives; knife sheaths; pre-filled tool bags containing hand tools for fishing; scissors for household; scissors for fishing lines; fishing line scissors with carabiners; fishing line cutters with carabiners; cutting pliers; pliers being hand tools; nippers; cutting pliers for fishing; pliers for fishing; nippers for fishing; hand operated line winders for fishing reels; clamps being hand tools; bench vises being hand operated implements; hand operated mixing devices for fishing; hand operated blending device for mixing fishing bait; hand operated blending spatulas for mixing fishing bait; hand operated tools for blending fishing bait; hand operated tools for braiding; hand operated hoes; digging forks; hand operated lasts for shoe making; electric irons; razors; hair clippers; forks and spoons being tableware; can openers, non-electric; dressmakers' chalk sharpeners; bludgeons; hand-operated insecticide sprayers; ice axes; palette knives.
(2) Fishing tackle; fishing floats; fishing sinkers; landing nets for anglers; fishing lines; fishing reels; fishing rods; reel seats for fishing; cases for fishing reels; cases for fishing rods; fishing hooks; lures for fishing; line guides for fishing rods; artificial fishing bait; fishing plugs; handheld fishing nets; bags adapted for fishing tackle; cases for fishing tackle; bite sensors being fishing tackle; bite indicators being fishing tackle; creels being fishing traps.
A control system includes at least one sensor configured to detect detection information regarding a traveling state of a human-powered vehicle, and a controller configured to control a motor and at least one transmission. A shift operation by the at least one transmission includes a first shift operation involving driving of a chain by the motor. The controller is configured to selectively stop or continue driving of the motor in accordance with a first detection result of the at least one sensor in a case where a shifter is operated during the first shift operation.
B62M 6/50 - Dispositifs de commande ou d'actionnement s'y rapportant caractérisés par des détecteurs ou des capteurs, ou leur disposition
B62M 25/08 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission électrique ou par fluide
A drive unit is configured to be provided to a human-powered vehicle. The drive unit basically includes a support, a drive shaft, an output portion, a motor, a transmission mechanism, and a motor output shaft. The drive shaft is configured to receive a human driving force, and includes a first axis. The output portion is provided on the drive shaft. The motor includes a rotor and a stator. The transmission mechanism is configured to transmit a motor torque of the motor to the output portion. The motor output shaft is connected to the rotor, and includes a second axis. The transmission mechanism includes a first transmission unit including a planetary gear mechanism. At least part of the planetary gear mechanism is configured to rotate about the second axis and overlaps the motor as viewed in a first direction that is orthogonal to the second axis.
A human-powered vehicle component comprises wireless communicator circuitry and electronic controller circuitry. The electronic controller circuitry is configured to receive a first signal from the additional wireless communicator circuitry via the wireless communicator circuitry. The electronic controller circuitry is configured to change the communication protocol of the wireless communicator circuitry from a second communication protocol to a first communication protocol based on the first signal in a case where the first signal includes first information indicative of the first communication protocol. The electronic controller circuitry is configured to control the wireless communicator circuitry to maintain use of the second communication protocol in a case where the electronic controller circuitry does not receive, via the wireless communicator circuitry, the first signal including the first information indicative of the first communication protocol.
B62M 25/08 - Commandes pour mécanismes de changement de vitesses spécialement adaptées aux cycles avec systèmes de transmission électrique ou par fluide
B62M 6/45 - Dispositifs de commande ou d'actionnement s'y rapportant
B62M 9/122 - Dérailleurs arrière à actionnement électrique ou fluidiqueDérailleurs arrière leurs commandes
A fixing structure for line slack prevention to be disposed on a bail support member of a spinning reel for fishing, the fixing structure includes a line slack prevention member having a cylindrical mounting portion to be inserted into a mounting hole on the bail support member and a fin portion extending radially outward from the mounting portion, and an expanding member to be inserted in a through-hole in the mounting portion of the line slack prevention member to fix the mounting portion of the line slack prevention member to the bail support member in an expanded state.
A01K 89/01 - Moulinets pour la pêche à la ligne à enrouleur de fil "pick-up", c.-à-d. avec l'élément de guidage du fil tournant et la bobine fixe pendant la récupération normale du fil
80.
LINE SLACK PREVENTION MEMBER AND SPINNING REEL FOR FISHING
A line slack prevention member to be disposed on a bail support member having a line roller, the line slack prevention member includes a base portion attached to the bail support member, and a fin portion extending from the base portion toward the line roller, the fin portion having a distal end part configured to face the line roller and curving and bulging in a direction in which a fishing line passes.
A01K 89/01 - Moulinets pour la pêche à la ligne à enrouleur de fil "pick-up", c.-à-d. avec l'élément de guidage du fil tournant et la bobine fixe pendant la récupération normale du fil
A pedal assembly is provided for a human powered vehicle. The pedal assembly comprises a pedal body and at least one adapter. The pedal body includes at least one adapter receiving portion. The at least one adapter is configured to be received in the adapter receiving portion. The at least one adapter has at least one threaded hole configured to engage with at least one fastening member so that a plurality of pedal components different from each other can be mounted to the pedal body through the at least one adapter. The at least one adapter has a non-circular shape in a cross-section view. The non-circular shape is configured to restrict a relative rotation between the at least one adapter and the adapter receiving portion.
A fishing reel in which a maximum drag force can be increased as needed while the size of the reel is kept from increasing includes: a reel body; a handle rotatably mounted on the reel body; a drive shaft configured to rotate integrally with the handle; a spool rotatably supported by the reel body; a drive gear configured to rotate integrally with the spool; a first drag mechanism for restricting relative rotation between the drive shaft and the drive gear; a spool shaft configured to rotate integrally with the spool; a second drag mechanism configured to restrict relative rotation between the spool shaft and the reel body; and a restriction switching mechanism configured to switch the second drag mechanism between a restricted state and a non-restricted state.
fishing equipment; fishing tackle; reels for fishing; fishing rods; fishing lines; bite sensors (fishing tackle); fishing bobbers; fishing creels; gut for fishing; lures for fishing, including artificial fishing bait; fishing plugs; handheld fishing nets; fishing tackle bags, cases and pouches for fishing equipment; parts of the aforementioned products.
A control system includes a controller configured to control an actuator and at least one transmission such that a chain is driven by the actuator and a shifting operation is performed by the at least one transmission. In a case where a pedal is operated during the shifting operation, the controller is configured to control the actuator so that the shifting operation is stopped in accordance with a result of comparison with a predetermined threshold.
A spool for a dual-bearing reel, includes a bobbin trunk having an outer circumferential surface around which a fishing line is capable of being wound, and a through-hole extending through the outer circumferential surface in a radial direction of a rotational axis of the spool, a pillar portion extending from an inner circumferential surface of the bobbin trunk toward the rotational axis, and being disposed at a position that does not overlap with the through-hole as viewed from the radial direction, and first and second flanges extending from first and second ends of the bobbin trunk, respectively, in a direction away from the rotational axis, the outer circumferential surface of the bobbin trunk having a tapered surface inclined in a direction approaching the rotational axis toward the first and second flanges.
B65H 75/02 - Noyaux, gabarits, supports ou pièces de tenue pour matériau bobiné, enroulé ou plié, p. ex. tourets, broches, bobines, tubes à cannette, boîtes
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
25 - Vêtements; chaussures; chapellerie
Produits et services
Bicycles, including electric bicycles; parts, fittings and
accessories for bicycles, including electric bicycles,
namely, hubs, internal gear hubs, bicycle hub which contains
dynamo inside, bicycle hub which contains bicycle power
meter inside, hub quick release levers, hub quick release
devices, axles of hubs, gear release levers, gear shift
levers, gear shifts for bicycles, derailleurs, chain guides,
freewheels, sprockets, pulleys adapted for use with
bicycles, chains, shift cables, cranks, crank which contains
bicycle power meter inside, crank sets, front chain wheels,
pedals, pedal which contains bicycle power meter inside,
bicycle pedal cleats, toe clips, brake levers, brakes, brake
cables, brake shoes, rims, brake rotors, brake pads, wheels,
tires, inner tubes, spokes, spoke clips, bottom brackets,
seat pillars, head parts for frame-fork assembly, bicycle
suspension forks, suspension systems for bicycles,
handlebars, handlebar stems, grips for handlebars, bar ends,
seat posts, saddles, gear position indicators for bicycles,
electric motors for bicycles, switches for bicycles. Footwear; shoes; boots; shoes for cyclists; cycling shoes;
boots for cyclists; fishing shoes; fishing waders; shoes for
rowing; sandals; sandals for cyclists; sandals for anglers;
overshoes; cycling shoe covers; soles for shoes; shoe soles;
rubber soles for footwear; soles for footwear; soles for
cycling shoes; insoles; insoles for footwear; insoles for
cycling shoes; shoe insoles; midsoles for footwear; outsoles
for footwear; shoe outsoles; rubber outsoles for footwear;
outsoles for shoes; outsoles for cycling shoes; heelpieces
for footwear; heelpieces for boots and shoes; heelpieces for
cycling shoes; clothing; clothing for sports (sports
uniforms); clothing for cyclists; bicycle racing clothing;
clothing for fishing; clothing for rowing; clothing for
gymnastics; outer clothing; cycling tops; rain protection
wear; rain coats; rain suits; hats; caps being headwear;
gloves being clothing; cycling gloves; bicycle racing
gloves; socks; shirts; jackets being clothing; jerseys being
clothing; vests; fishing vests; pants; tights; underwear;
cycling shorts; cycling warmers, namely, neck warmers, arm
warmers, leg warmers; cycling toe covers; toe caps for
waterproofing for cycling shoes; toe caps for cold weather
for cycling shoes; waterproof covers specially adapted for
cycling shoes; cold weather covers specially adapted for
cycling shoes; cycling bandanas; ankle gaiters; cleats for
attachment to cycling shoes; cleats for attachment to sports
shoes.
Fishing tackle; fishing floats; fishing sinkers; landing
nets for anglers; fishing lines; fishing reels; fishing
rods; reel seats for fishing; cases for fishing reels; cases
for fishing rods; fishing hooks; lures for fishing; line
guides for fishing rods; artificial fishing bait; fishing
plugs; handheld fishing nets; bags adapted for fishing
tackle; cases for fishing tackle; bite sensors being fishing
tackle; bite indicators being fishing tackle; creels being
fishing traps.
97.
COVER, DEVICE OF HUMAN-POWERED VEHICLE, DEVICE OF FISHING TACKLE, AND METHOD FOR MOUNTING COVER TO TARGET PORTION OF ONE OF HUMAN-POWERED VEHICLE AND FISHING TACKLE
A cover comprises a cover body. The cover body is configured to be mounted to a target portion of one of a human-powered vehicle and a fishing tackle. The cover body is configured to define at least one interior cavity. The cover body includes: at least one adhesive applied portion to which adhesive is to be applied; and at least one hole configured to be connected to the at least one interior cavity.
A lure comprises a body. The body is configured to have an internal space inside an outer shell. The body has, in the internal space, an array structure in which grid lines are arranged in a generally uniform manner.
A dual bearing reel includes a reel body, a handle rotatably supported by the reel body, a spool shaft rotatably supported by the reel body, a spool to integrally rotate with the spool shaft, a pinion gear to move between a transmitting position to transmit a rotational force of the handle to the spool shaft and a disengaged position to prevent transmission of the rotational force of the handle to the spool shaft, a clutch control mechanism to move the pinion gear between the transmitting position and the disengaged position, and a bearing rotatably supporting the pinion gear relative to the reel body and to move together with the pinion gear when the pinion gear moves between the transmitting position and the disengaged position.
A fishing line guide mountable to a fishing rod body to guide a fishing line, the fishing line guide includes a foam portion made of foamed resin, and a reinforced resin portion made of fiber-reinforced resin and covering a part of the foam portion.
