A target (100) for use in surveying applications is provided. The target comprises a plurality of light sources (106) arranged around a longitudinal axis (A) of a base element (108) of the target. The plurality of light sources is configured to emit light radially. The target further comprises a control unit (214). The control unit is configured to control an intensity of the light (440a, 440b) emitted by the plurality of light sources based on a distance (d1, d2) between the target and a surveying instrument (120) aimed towards the target.
The present disclosure relates to a portable casing for transporting a surveying instrument and a method for controlling charging of a plurality of batteries arranged in such a portable casing. The portable casing comprises a primary compartment for lodging the surveying instrument within the portable casing. The portable casing includes a plurality of secondary compartments for housing a plurality of rechargeable batteries. The portable casing also includes a charging unit arranged in the casing and electrically connected to the plurality of primary compartments for transferring electrical energy to and/or from the plurality of rechargeable batteries. Further, a control unit of the portable casing is configured to obtain information about the state of charge of each of the plurality of batteries arranged in the plurality of primary compartments, and control, based on the obtained information, an inter-charging function of the charging unit to cause, among batteries of the plurality of batteries that have a state of charge below a first threshold, a lesser discharged battery to receive electrical energy from at least one more discharged battery.
Electronic distance meter comprising a laser emitting a laser pulse toward a target, a photodetector adapted for receiving a laser pulse reflected by the target and for outputting a corresponding return pulse signal, and a comparison circuit receiving said return pulse signal and comprising a passive signal processing circuit and a comparator provided with a first input and a second input and arranged to output a first fixed value signal when the signal at the first input exceeds the signal at the second input and else to output a second fixed value signal, said comparison circuit being arranged for determining a return pulse time signal based on the output of said comparator, said electronic distance meter being arranged for determining a target distance based on said return pulse time signal, wherein said passive signal processing circuit comprises a first branch receiving said return pulse signal and comprising a transmission line (34) for generating a first twinset signal (24) to said first input, and a second branch receiving said return pulse signal and comprising a transmission line (36) and a delay line for generating a second twinset signal (26) to said second input, the transmission lines being (34,36) chosen such that each twinset signal (24,26) respectively comprises a positive and negative alternating portion which substantially corresponds to a first order derivative of the return pulse signal.
G01S 7/4865 - Mesure du temps de retard, p.ex. mesure du temps de vol ou de l'heure d'arrivée ou détermination de la position exacte d'un pic
G01S 7/487 - Extraction des signaux d'écho désirés
G01S 17/14 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues dans lesquels une impulsion de tension ou de courant est initiée et terminée en fonction respectivement de l'émission d'impulsions et de la réception d'écho, p.ex. en utilisant des compteurs
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
4.
Tracker of a surveying apparatus for tracking a target
The present invention relates to a tracker and a surveying apparatus comprising the tracker, which improve the reliability of tracking a target. The tracker comprises a first imaging region having a plurality of pixels for taking a first image of a scene including the target; a second imaging region having a plurality of pixels for taking a second image of a scene including the target; a control unit to receive a timing signal indicating a time duration during which an illumination illuminating the target in the scene is switched on and off, control the first imaging region to take the first image of the scene when the timing signal indicates that the illumination unit is switched on, and control the second imaging region to take the second image when the illumination is switched off; and a read out unit configured to read out the first image from the first imaging region and the second image from the second imaging region and to obtain a difference image.
G01S 17/66 - Systèmes de poursuite utilisant d'autres ondes électromagnétiques que les ondes radio
G01C 11/06 - Restitution des photos par comparaison de plusieurs photos de la même zone
H04N 23/74 - Circuits de compensation de la variation de luminosité dans la scène en influençant la luminosité de la scène à l'aide de moyens d'éclairage
5.
METHOD FOR OPERATING A GEODETIC INSTRUMENT, AND RELATED GEODETIC INSTRUMENT
The present inventive concept relates to a method for operating a geodetic instrument comprising an optical source for assisting a user in aiming at a target in a scene by emitting optical pulses forming a spot at the target, and an imaging device, wherein the imaging device and the optical source share a common optical channel within the geodetic instrument, the method comprising: capturing a first image of a scene with the optical source turned on; obtaining a reference image from at least the first image, wherein contribution from the scene is suppressed, the reference image representing crosstalk occurring in the common optical channel; capturing a second image with the optical source turned on; and processing the second image with the reference image for removing crosstalk from the second image.
The present inventive concept relates to a method for operating a geodetic instrument comprising an optical source for assisting a user in aiming at a target in a scene and an imaging device, wherein the imaging device and the optical source share a common optical channel within the geodetic instrument, said method comprising: causing emission, by the optical source, of optical pulses towards the target; causing capture, by the imaging device, of images of the scene using a frame sequence, wherein a frame of said frame sequence includes an exposure time during which the imaging device is exposed to light from the scene; synchronizing emission of the optical pulses to the frame sequence for obtaining data from images in which the optical pulses are absent; and processing the obtained data for surveying said scene.
A laser controller having an electronic distance measuring instrument and a laser light transmitter creating a vertical laser plane is used with a remote controller and a movable target for point layout tasks. The electronic distance measurer and laser transmitter are mounted on the same vertical pivot axis. Once the system is set-up for a particular jobsite, the laser plane can be aimed at a specific point of interest on the jobsite floor, and a visible laser light line will then appear on the floor, from the laser controller, all the way to that point of interest. The distance measuring instrument is aimed along the same heading as the laser plane, and it gives the distance to the movable target, which is moved along the visible laser light line, until reaching the specified distance, and thereby find the point of interest.
G01C 3/00 - Mesure des distances dans la ligne de visée; Télémètres optiques
G01S 7/48 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
G01C 3/08 - Utilisation de détecteurs électriques de radiations
G01S 17/74 - Systèmes utilisant la reradiation d'ondes électromagnétiques autres que les ondes radio, p.ex. pour l'identification ami–ennemi
G01S 7/00 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , ,
G01S 17/42 - Mesure simultanée de la distance et d'autres coordonnées
The present disclosure provides a method for determining a direction to a geodetic target from a geodetic instrument. The method includes emitting an optical pulse from the geodetic target, capturing a first image and a second image of the geodetic target using a camera arranged at the geodetic instrument, obtaining a difference image between the first image and the second image, and determining a direction to the geodetic target from the geodetic instrument based on the position of the optical pulse in the difference image. The method further includes synchronizing the geodetic instrument and the geodetic target for emitting the optical pulse concurrently with the capturing of the first image and nonconcurrently with the capturing of the second image. The present disclosure also provides a geodetic instrument, a geodetic target and a geodetic surveying system.
d) arranged in a circular manner such that two adjacent regions have magnetic poles of opposite polarities. The geodetic assembly may further comprise at least one magnetic shield (270) for shielding the geodetic device, or a magnetically sensitive device (280) arranged at the support structure, from the first magnetic unit and the second magnetic unit.
The invention relates to optical surveying such as in building construction, road construction, landscaping and similar. A first image sensor obtains in a first wavelength range a first image of a scene within a field of view captured by an optical arrangement such as a telescope. A light emitter emits light in a second wavelength range and a second image sensor obtains a second image of the field of view in the second wavelength range. A target position of a reflecting target is found in the first image by detecting a known image pattern of the reflecting target in the first image. A region of interest in the second image is then a defined based on the identified target position in the first image, for detecting a reflector position of a reflector of the reflecting target in the region of interest. With the invention it becomes possible to improve the identification of a reflective target at reduced processing time, even if reflections from other objects than the reflective target are present.
G06V 10/60 - Extraction de caractéristiques d’images ou de vidéos relative aux propriétés luminescentes, p.ex. utilisant un modèle de réflectance ou d’éclairage
G02B 23/00 - Télescopes ou lunettes d'approche, p.ex. jumelles; Périscopes; Instruments pour voir à l'intérieur de corps creux; Viseurs; Pointage optique ou appareils de visée
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer software and hardware for aerial mapping and aerial
surveying from manned aircraft and uav's [unmanned aerial
vehicles]; downloadable web application software for aerial
mapping and aerial surveying from manned aircraft and uav's
[unmanned aerial vehicles]. Software as a service [SaaS] provider in the field of
software for aerial mapping and aerial surveying from manned
aircraft and UAV's [unmanned aerial vehicles]; providing
temporary use of web application software for aerial mapping
and aerial surveying from manned aircraft and UAV's
[unmanned aerial vehicles]; computer programming and
software consultancy; computer software installation and
maintenance.
The present disclosure provides a geodetic instrument (100) adapted to determine a direction and/or a distance to a target. The geodetic instrument includes an attachment device (120) for attaching the geodetic instrument to a holding arrangement (122); a motorized position arrangement for aiming a line of sight (L) of the geodetic instrument via rotation and/or translation of at least a part of the motorized position arrangement relative to the holding arrangement, and a controller (130). The controller is configured to, upon determining that a setting up of the geodetic instrument is required, provide a control sequence to the motorized positioning arrangement for causing a series of oscillatory rotational and/or translational movements of the at least a part of the motorized positioning arrangement. A method of setting up a geodetic instrument is also provided.
A surveying system, comprises a support; a rotating mirror unit including a mounting structure, a motor mounted on the mounting structure and having a shaft rotatable about a first axis, and a mirror mounted on the shaft; a measuring unit including a mounting structure and a light source and optics mounted on the mounting structure for directing a beam of measuring light onto the mirror surface; and a window mechanically connecting the mounting structure of the measuring unit and the mounting structure of the rotating mirror unit.
A surveying system comprises a controller; a support; a mounting structure mounted on the support, wherein the mounting structure is rotatable about a first axis relative to the support; a first motor to rotate the mounting structure relative to the support; a first mirror mounted on the mounting structure, wherein the first mirror is rotatable relative to the mounting structure about a second axis, wherein the second axis substantially coincides with the first axis; a second motor to rotate the first mirror relative to the mounting structure; and a first light source configured to direct a light beam onto the first mirror.
G01S 7/48 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
G01S 7/481 - Caractéristiques de structure, p.ex. agencements d'éléments optiques
G01S 17/86 - Combinaisons de systèmes lidar avec des systèmes autres que lidar, radar ou sonar, p.ex. avec des goniomètres
G01S 17/89 - Systèmes lidar, spécialement adaptés pour des applications spécifiques pour la cartographie ou l'imagerie
16.
Electronic distance meter and method of determining a distance with an electronic distance meter
An electronic distance meter comprises a coupler located between a laser source and a target and adapted to divert a portion of measurement light emitted by the laser source into a calibration portion connected to a photodetector and comprising an attenuator between said coupler and said photodetector for varying the luminance value of the light passing through the calibration portion, said calibration portion having a known length and said processor being configured to perform distance measurements through the calibration portion at a variety of luminance values achieved by said attenuator to derive calibration values from said distance measurements and said known length, said processor being further configured to use said calibration values for determining a target distance based on a return pulse signal.
G01S 7/48 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
G01S 7/4865 - Mesure du temps de retard, p.ex. mesure du temps de vol ou de l'heure d'arrivée ou détermination de la position exacte d'un pic
G01S 7/487 - Extraction des signaux d'écho désirés
17.
Surveying instrument and method of calibrating a survey instrument
A surveying instrument comprises a base; an alidade rotatable about a first axis relative to the base; and an optical measuring instrument having a measuring axis rotatable about a second axis relative to the alidade. A beam path can be provided for a light beam using components including a light source, lenses, mirrors, beam splitters, and a position-sensitive detector. The surveying can be calibrated by performing plural measurements at different orientations of the alidade relative to the base and different orientations of the measuring instrument relative to the alidade using the above components.
G01C 15/00 - Instruments de géodésie ou accessoires non prévus dans les groupes
G01C 25/00 - Fabrication, étalonnage, nettoyage ou réparation des instruments ou des dispositifs mentionnés dans les autres groupes de la présente sous-classe
A surveying instrument comprises a base; an alidade rotatable about a first axis relative to the base; and an optical measuring instrument having a measuring axis rotatable about a second axis relative to the alidade. A beam path can be provided for a light beam using components including a light source, lenses, mirrors, beam splitters, and a position-sensitive detector. The surveying can be calibrated by performing plural measurements at different orientations of the alidade relative to the base and different orientations of the measuring instrument relative to the alidade using the above components.
G01C 15/00 - Instruments de géodésie ou accessoires non prévus dans les groupes
G01C 25/00 - Fabrication, étalonnage, nettoyage ou réparation des instruments ou des dispositifs mentionnés dans les autres groupes de la présente sous-classe
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Downloadable computer software and hardware for aerial mapping and aerial surveying from manned aircraft and unmanned aerial vehicles; recorded computer software and hardware for aerial mapping and aerial surveying from manned aircraft and unmanned aerial vehicles; downloadable web application software for aerial mapping and aerial surveying from manned aircraft and unmanned aerial vehicles Software as a service [SaaS] provider featuring software for aerial mapping and aerial surveying from manned aircraft and unmanned aerial vehicles; providing temporary use of web-based application software for aerial mapping and aerial surveying from manned aircraft and unmanned aerial vehicles; computer programming and software consultancy; computer software installation and maintenance
20.
GEODETIC ASSEMBLY WITH MAGNETIC ATTACHING ARRANGEMENT
Embodiments provide for a geodetic assembly (200) for land surveying. The geodetic assembly (200) may include a first element (210) including a first magnetic unit (270) and a second element (250) including a second magnetic unit (260). The second element may be part of a support structure (240) of the geodetic assembly and is adapted to mate with the first element for supporting a geodetic device (230), the first element being attached to the geodetic device (or vice versa). The second magnetic unit is arranged to interact with the first magnetic unit for locking or unlocking the first element on the support structure. Each of the first magnetic unit and the second magnetic unit is divided in a plurality of regions (320a-d, 360a-d) arranged in a circular manner such that two adjacent regions have magnetic poles of opposite polarities. The geodetic assembly may further comprise at least one magnetic shield (270) for shielding the geodetic device, or a magnetically sensitive device (280) arranged at the support structure, from the first magnetic unit and the second magnetic unit.
The present invention relates to a tracker and a surveying apparatus comprising the tracker, which improve the reliability of tracking a target. The tracker comprises a first imaging region having a plurality of pixels for taking a first image of a scene including the target; a second imaging region having a plurality of pixels for taking a second image of a scene including the target; a control unit to receive a timing signal indicating a time duration during which an illumination illuminating the target in the scene is switched on and off, control the first imaging region to take the first image of the scene when the timing signal indicates that the illumination unit is switched on, and control the second imaging region to take the second image when the illumination is switched off; and a read out unit configured to read out the first image from the first imaging region and the second image from the second imaging region and to obtain a difference image.
The present invention relates to a surveying apparatus for surveying an object as well as a surveying system comprising the surveying apparatus having a simple and compact optical setup. The surveying apparatus comprises a lens arrangement including at least one movably arranged focus lens element for focusing to sight an object; an imaging unit configured to obtain an image of at least a part of the object; a distance measuring unit configured to measure a distance to the object along the optical axis of the distance measuring unit; and a beam splitter/combiner configured to combine a part of the optical imaging path of the imaging unit and a part of the optical distance measuring path of the distance measuring unit so that the optical axis of the imaging unit and the optical axis of the distance measuring unit are at least coaxially arranged with the optical axis of the lens arrangement between the lens arrangement and the beam splitter/combiner.
The present invention relates to a tracker and a surveying apparatus comprising the tracker, which improve the reliability of tracking a target. The tracker comprises a an image sensor arrangement having an imaging region composed of a plurality of pixels arranged in a matrix of columns and rows. The imaging region is arranged to take an image of a scene including the target. A controller receives or generates a timing signal indicating a time duration during which an illumination unit is switched on and off, controls the imaging region to take an image of the scene when the illumination unit is switched on, and reads out a subgroup of neighboring columns or rows constituting a stripe window of the imaging region so that an image section including the target is obtained, controls the imaging region to take another image of the scene when the illumination unit is switched off, and reads out another subgroup of neighboring columns or rows constituting another stripe window of the imaging region so that another image section including the target is obtained, and calculates a difference image section by determining a difference between the pixel values of the pixels of the image section and the other image section.
H04N 5/378 - Circuits de lecture, p.ex. circuits d’échantillonnage double corrélé [CDS], amplificateurs de sortie ou convertisseurs A/N
G01C 15/00 - Instruments de géodésie ou accessoires non prévus dans les groupes
H04N 5/345 - Extraction de données de pixels provenant d'un capteur d'images en agissant sur les circuits de balayage, p.ex. en modifiant le nombre de pixels ayant été échantillonnés ou à échantillonner en lisant partiellement une matrice de capteurs SSIS
24.
Method, processing unit and surveying instrument for improved tracking of a target
A method implemented in a processing unit controlling a surveying instrument is provided. The method comprises obtaining a first set of data from optical tracking of a target with the surveying instrument, and identifying from the first set of data a dependence over time of at least one parameter representative of movements of the target. The method further comprises receiving a second set of data from a sensor unit via a communication channel, the second set of data including information about the at least one parameter over time, and determining whether a movement pattern for the optically tracked target as defined by the dependence over time of the at least one parameter is the same as, or deviates by a predetermined interval from, a movement pattern as defined by the dependence over time of the at least one parameter obtained from the second set of data.
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Computer Software and Hardware for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Downloadable web application software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles] (1) Software as a service [SAAS] provider in the field of software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Providing temporary use of web application software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Computer programming and software consultancy; Computer software and hardware installation and maintenance
The present disclosure provides a method for determining a direction to a geodetic target from a geodetic instrument. The method includes emitting an optical pulse from the geodetic target, capturing a first image and a second image of the geodetic target using a camera arranged at the geodetic instrument, obtaining a difference image between the first image and the second image, and determining a direction to the geodetic target from the geodetic instrument based on the position of the optical pulse in the difference image. The method further includes synchronizing the geodetic instrument and the geodetic target for emitting the optical pulse concurrently with the capturing of the first image and nonconcurrently with the capturing of the second image. The present disclosure also provides a geodetic instrument, a geodetic target and a geodetic surveying system.
A measurement instrument is disclosed. The measurement instrument comprises a front lens assembly, a distance measurement module and a deflection module. The front lens assembly comprises an optical path along an instrument optical axis and the distance measurement module is configured to transmit and receive optical radiation along a measurement path. The deflection module is arranged between the distance measurement module and the front lens assembly to deflect the measurement path across the instrument optical axis.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Downloadable Computer Software and Hardware for mobile marine mapping and mobile marine surveying; recorded Computer Software and Hardware for mobile marine mapping and mobile marine surveying
09 - Appareils et instruments scientifiques et électriques
Produits et services
Downloadable Computer software and hardware for mobile land-based mapping and mobile land-based surveying; recorded Computer software and hardware for mobile land-based mapping and mobile land-based surveying
The present disclosure provides a geodetic instrument (100) adapted to determine a direction and/or a distance to a target. The geodetic instrument includes an attachment device (120) for attaching the geodetic instrument to a holding arrangement (122); a motorized positioning arrangement for aiming a line of sight (L) of the geodetic instrument via rotation and/or translation of at least a part of the motorized position arrangement relative to the holding arrangement, and a controller (130). The controller is configured to, upon determining that a setting up of the geodetic instrument is required, provide a control sequence to the motorized positioning arrangement for causing a series of oscillatory rotational and/or translational movements of the at least a part of the motorized positioning arrangement. A method of setting up a geodetic instrument is also provided.
An electronic distance meter comprises a laser emitting a laser pulse toward a target, a photodetector adapted for receiving a laser pulse reflected by the target and for outputting a corresponding return pulse signal, and a comparison circuit receiving said return pulse signal and comprising a comparator provided with a first input and a second input and arranged to output a first fixed value signal when the signal at the first input exceeds the signal at the second input and else to output a second fixed value signal, said comparison circuit being arranged for determining a return pulse time signal based on the output of said comparator, said electronic distance meter being arranged for determining a target distance based on said return pulse time signal.
The comparison circuit comprises a first branch connected to said first input and provided with an integrator which receives a signal derived from said return pulse signal and comprises an output connected to said first input, and a second branch connected to said second input which receives a signal derived from said return pulse signal.
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
G01S 7/4865 - Mesure du temps de retard, p.ex. mesure du temps de vol ou de l'heure d'arrivée ou détermination de la position exacte d'un pic
32.
QUEUE OF DATA COLLECTION TASKS FOR SURVEYING INSTRUMENT
Methods (300), controllers (150) and computer program products for efficient utilization of a surveying instrument (100, 200) are provided. The surveying instrument may perform different types of data collection tasks, at least one of which includes measuring a direction and/or a distance to a target. The surveying instrument is controlled (310) to perform one or more data collection tasks in accordance with a queue (400) of one or more data collection tasks. The queue includes a data collection task (410) of at least one of the different types of data collection tasks. During an ongoing data collection task or during an ongoing sequence of data collection tasks, an instruction is received (320). The instruction indicates an additional data collection task to be performed by the surveying instrument in addition to the one or more tasks already in the queue. The surveying instrument is controlled (330) to perform data collection tasks in an order determined based on the queue and the received instruction.
An integrated sensing device with a suite of sensors assists construction machine operators in finding the correct level to dig a ditch/trench. The sensing device includes a gravity sensor to determine angles, a laser distance meter (LDM), and a laser receiver for detecting a known jobsite elevation. The sensing device is mounted to the dipper stick of an excavator; the gravity sensor detects the angle of the stick, and the laser receiver detects a laser plane of light that represents a known jobsite elevation. The LDM is aimed at another member of the machine that moves in a predetermined path as the bucket is rotated, and the distance between the LDM and the target member is used to calculate the vertical elevation of the working tool edge. A display graphically shows the operator the proper dig depth and the present position of the working tool edge.
G01B 11/14 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer la distance ou la marge entre des objets ou des ouvertures espacés
G01M 1/12 - Equilibrage statique; Détermination de la position du centre de gravité
34.
METHOD, PROCESSING UNIT AND SURVEYING INSTRUMENT FOR IMPROVED TRACKING OF A TARGET
A method (500) implemented in a processing unit (160) controlling a surveying instrument (100) is provided. The method (500) comprises obtaining (510) a first set of data from optical tracking of a target (140) with the surveying instrument (100), and identifying (520) from the first set of data a dependence over time of at least one parameter representative of movements of the target (140). The method (500) further comprises receiving (530) a second set of data from a sensor unit (150) via a communication channel, the second set of data including information about the at least one parameter over time, and determining (540) whether a movement pattern for the optically tracked target (140) as defined by the dependence over time of the at least one parameter is the same as, or deviates by a predetermined interval from, a movement pattern as defined by the dependence over time of the at least one parameter obtained from the second set of data.
The present disclosure relates to a surveying instrument including a chassis, an optical system having an optical axis, a stage attached to the chassis and an optical component. The optical system may be adapted to receive and/or transmit light. The optical component is located at, or in proximity to, the optical axis. The received and/or transmitted light passes through the optical component. The stage includes an actuating member arranged to act on the optical component for movement thereof. The actuating member may be responsive to temperature so as to induce a displacement of the optical component relative to the chassis along the optical axis in response to a temperature change.
G01C 15/00 - Instruments de géodésie ou accessoires non prévus dans les groupes
G02B 7/00 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques
G01S 7/481 - Caractéristiques de structure, p.ex. agencements d'éléments optiques
G01C 19/50 - Dispositifs de redressage pour ramener l'axe du rotor à une position désirée fonctionnant par des moyens mécaniques
G02F 1/225 - Dispositifs ou dispositions pour la commande de l'intensité, de la couleur, de la phase, de la polarisation ou de la direction de la lumière arrivant d'une source lumineuse indépendante, p.ex. commutation, ouverture de porte ou modulation; Optique non linéaire pour la commande de l'intensité, de la phase, de la polarisation ou de la couleur par interférence dans une structure de guide d'ondes optique
A method of colorizing a 3D point cloud includes receiving the 3D point cloud, receiving a 2D color image acquired by a camera, creating a 2D intensity image of the 3D point cloud based on intrinsic and extrinsic parameters of the camera, generating a set of refined camera parameters by matching the 2D intensity image and the 2D color image, creating a depth buffer for the 3D point cloud using the set of refined camera parameters, determining a foreground depth for each respective pixel of the depth buffer, and coloring the point cloud by, for each respective point of the 3D point cloud: upon determining that the respective point is in the foreground, assigning a color of a corresponding pixel in the 2D color image to the respective point; and upon determining that the respective point is not in the foreground, not assigning any color to the respective point.
H04N 13/15 - Aspects des signaux d’images en rapport avec la couleur
G06T 19/20 - Transformation de modèles ou d'images tridimensionnels [3D] pour infographie Édition d'images tridimensionnelles [3D], p.ex. modification de formes ou de couleurs, alignement d'objets ou positionnements de parties
G06T 7/70 - Détermination de la position ou de l'orientation des objets ou des caméras
G06T 7/55 - Récupération de la profondeur ou de la forme à partir de plusieurs images
H04N 13/271 - Générateurs de signaux d’images où les signaux d’images générés comprennent des cartes de profondeur ou de disparité
A method of rendering a three-dimensional point cloud in a two-dimensional display includes inputting the three-dimensional point cloud that includes three-dimensional coordinates of a set of points, creating a depth buffer for the three-dimensional point cloud that includes depth data for the set of points from a viewpoint location. The method further includes determining a foreground depth buffer by, for each respective pixel area of the two-dimensional display, determining a foreground depth by detecting a closest point to the viewpoint location among a subset of the set of points corresponding to the respective pixel area, and assigning a depth of the closest point as the foreground depth for the respective pixel area. The method further includes filtering the depth buffer to obtain a filtered depth buffer by removing points that are not in the foreground, and outputting the filtered depth buffer to the two-dimensional display.
A method of rendering a three-dimensional point cloud in a two-dimensional display includes inputting the three-dimensional point cloud that includes three-dimensional coordinates of a set of points, creating a depth buffer for the three-dimensional point cloud that includes depth data for the set of points from a viewpoint location. The method further includes determining a foreground depth buffer by, for each respective pixel area of the two-dimensional display, determining a foreground depth by detecting a closest point to the viewpoint location among a subset of the set of points corresponding to the respective pixel area, and assigning a depth of the closest point as the foreground depth for the respective pixel area. The method further includes filtering the depth buffer to obtain a filtered depth buffer by removing points that are not in the foreground, and outputting the filtered depth buffer to the two-dimensional display.
The present disclosure provides a method for determining a direction to a geodetic target from a geodetic instrument. The method includes emitting an optical pulse from the geodetic target, capturing a first image and a second image of the geodetic target using a camera arranged at the geodetic instrument, obtaining a difference image between the first image and the second image, and determining a direction to the geodetic target from the geodetic instrument based on the position of the optical pulse in the difference image. The method further includes synchronizing the geodetic instrument and the geodetic target for emitting the optical pulse concurrently with the capturing of the first image and nonconcurrently with the capturing of the second image. The present disclosure also provides a geodetic instrument, a geodetic target and a geodetic surveying system.
A laser controller having an electronic distance measuring instrument and a laser light transmitter creating a vertical laser plane is used with a remote controller and a movable target for point layout tasks. The electronic distance measurer and laser transmitter are mounted on the same vertical pivot axis. Once the system is set-up for a particular jobsite, the laser plane can be aimed at a specific point of interest on the jobsite floor, and a visible laser light line will then appear on the floor, from the laser controller, all the way to that point of interest. The distance measuring instrument is aimed along the same heading as the laser plane, and it gives the distance to the movable target, which is moved along the visible laser light line, until reaching the specified distance, and thereby find the point of interest.
A laser controller having an electronic distance measuring instrument and a laser light transmitter creating a vertical laser plane is used with a remote controller and a movable target for point layout tasks. The electronic distance measurer and laser transmitter are mounted on the same vertical pivot axis. Once the system is set-up for a particular jobsite, the laser plane can be aimed at a specific point of interest on the jobsite floor, and a visible laser light line will then appear on the floor, from the laser controller, all the way to that point of interest. The distance measuring instrument is aimed along the same heading as the laser plane, and it gives the distance to the movable target, which is moved along the visible laser light line, until reaching the specified distance, and thereby find the point of interest.
G01S 17/74 - Systèmes utilisant la reradiation d'ondes électromagnétiques autres que les ondes radio, p.ex. pour l'identification ami–ennemi
G01S 7/00 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , ,
G01S 17/42 - Mesure simultanée de la distance et d'autres coordonnées
A method for determining a distance to a target by a geodetic instrument is disclosed. The method comprises emitting an optical pulse towards a target at an emission time, applying a bias adjustment to a photodiode that is arranged to receive a return optical pulse reflected at the target, obtaining a reference signal that is indicative of a transient behavior of the photodiode for the bias adjustment, obtaining a difference signal by subtracting, from a signal output from the photodiode, a signal that resembles, or is equal to, the transient behavior of the photodiode in response to the bias adjustment based on the reference signal, extracting a reception time that corresponds to reception of the return optical pulse at the photodiode based at least in part on the difference signal, and determining the distance to the target based on the emission time and the reception time.
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
G01S 7/4861 - Circuits pour la détection, d'échantillonnage, d'intégration ou de lecture des circuits
G01S 7/4865 - Mesure du temps de retard, p.ex. mesure du temps de vol ou de l'heure d'arrivée ou détermination de la position exacte d'un pic
A point layout system is described that identifies points and their coordinates, using laser transmitters that are attached to at least three base units. The laser transmitters rotate about the azimuth and emit vertical laser planes. After being setup using control points, the projection lines of the laser planes will intersect on the floor of a jobsite at any point of interest, under command of the user with a remote unit. Once the first two base units are registered with the virtual floor plan, the third base unit can be automatically setup, using an automatic procedure that creates alignment axes with the first two base units. Once all three base units are registered with the floor plan, any one of the three base units can then be moved to a new physical location on the jobsite floor, and the automatic setup routine can be used to register its new position.
Methods and apparatus are provided for measuring distance from an instrument origin to each of a plurality of points in an environment. Laser pulses are emitted along a measurement axis at successive displacements about the origin. The emission time of each pulse is time-shifted relative to a fixed rate. The time shift corresponds to an index of a repetitive sequential pattern. Received pulses are detected at respective arrival times. For each received pulse: a current apparent distance is determined, a measured delta distance is calculated, a range interval is assigned by comparing measured delta distance with an expected delta distance synchronized with the index of the latest emitted pulse, the current apparent distance is defined to be a true measured distance for any received pulse assigned to a first time interval, otherwise the current apparent distance is defined to be a false measured distance.
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
G01S 17/42 - Mesure simultanée de la distance et d'autres coordonnées
46.
Display screen or portion thereof with animated graphical user interface
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer software and hardware for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; downloadable web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; computer software and hardware for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; cameras; robots for use for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; downloadable web application software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces. Computer hardware installation and maintenance. Software as a service [SAAS] provider in the field of software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; providing temporary use of web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; software as a services [SAAS] providing in the field of software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; providing temporary use of web application software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; computer programming and software consultancy; computer software installation and maintenance.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer software and hardware for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; downloadable web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; computer software and hardware for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; cameras; robots for use for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; downloadable web application software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces. Computer hardware installation and maintenance. Software as a service [SAAS] provider in the field of software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; providing temporary use of web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; software as a services [SAAS] providing in the field of software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; providing temporary use of web application software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; computer programming and software consultancy; computer software installation and maintenance.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer Software and Hardware for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Downloadable software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying that may be downloaded from a global computer network; Computer software and hardware for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Cameras; Robots, namely, laboratory robots for use in for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Downloadable software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces that may be downloaded from a global computer network Computer hardware installation and maintenance Software as a service provider in the field of software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Providing temporary use of non-downloadable web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Software as a services provider in the field of software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Providing temporary use of non-downloadable web application software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Computer programming and software consultancy; Computer software installation and maintenance
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer Software and Hardware for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Downloadable software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying that may be downloaded from a global computer network; Computer software and hardware for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Cameras; Robots, namely, laboratory robots for use in for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Downloadable software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces that may be downloaded from a global computer network Computer hardware installation and maintenance Software as a service provider in the field of software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Providing temporary use of non-downloadable web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Software as a services provider in the field of software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Providing temporary use of non-downloadable web application software for navigation, mapping and digital environment detection for creation of maps and models of interior spaces and contents of interior spaces; Computer programming and software consultancy; Computer software installation and maintenance
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Computer Software and Hardware for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying
(2) Downloadable web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying
(3) Computer software and hardware for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces; Cameras; Robots, namely, laboratory robots for use in for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces; Downloadable web application software for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces (1) Software as a service [SAAS] provider in the field of software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Providing temporary use of web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying
(2) Software as a services [SAAS] providing in the field of software for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces; Providing temporary use of web application software for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces
(3) Computer programming and software consultancy; Computer software and hardware installation and maintenance.
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Computer Software and Hardware for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Downloadable web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying.
(2) Computer software and hardware for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces; Cameras; Robots, namely, laboratory robots for use in for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces; Downloadable web application software for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces. (1) Software as a service [SAAS] provider in the field of software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying; Providing temporary use of web application software for use in marine, aerial and land mobile mapping and for use in marine, aerial and land mobile surveying.
(2) Software as a services [SAAS] providing in the field of software for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces; Providing temporary use of web application software for marine, aerial and land navigation, mapping and electromagnetic radiation digital environment detection for creation of maps and 3-dimensional building models of building interior spaces.
(3) Computer programming and software consultancy; Computer software and hardware installation and maintenance.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer Software and Hardware for mobile mapping and mobile surveying; downloadable web application software for mobile mapping and mobile surveying. Computer hardware installation, repair and maintenance. Software as a service [SAAS] provider in the field of software for mobile mapping and mobile surveying; providing temporary use of web application software for mobile mapping and mobile surveying; computer programming and software consultancy; computer software installation and maintenance.
A distance measurement instrument and a method of operating a distance measurement instrument are disclosed. According to some embodiments, a transmit light signal is transmitted by a transmitter unit along a transmit path at an emission time and a return light signal is received by a receiver unit at a receive time along a receive path. The return light signal is converted to a return electrical signal. At least one of the transmit path and the receive path is deflected by a deflection module at a deflection angle relative to an optical axis of the instrument. A time-dependent attenuation function is selected based on information relative to the deflection angle and attenuation is applied by an attenuator to at least one of the return light signal and the return electrical signal according to the selected time-dependent function. A measured distance may be determined by a processor unit based on at least the emission time and the receive time.
G01S 7/48 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
G01S 7/481 - Caractéristiques de structure, p.ex. agencements d'éléments optiques
G01S 7/489 - Récepteurs le gain du récepteur variant automatiquement pendant la période de récurrence des impulsions
G01S 17/42 - Mesure simultanée de la distance et d'autres coordonnées
G01S 7/4865 - Mesure du temps de retard, p.ex. mesure du temps de vol ou de l'heure d'arrivée ou détermination de la position exacte d'un pic
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
G01S 17/89 - Systèmes lidar, spécialement adaptés pour des applications spécifiques pour la cartographie ou l'imagerie
58.
SURVEYING INSTRUMENT WITH OPTICAL STAGE COMPENSATING FOR TEMPERATURE VARIATIONS
The present disclosure relates to a surveying instrument (300) including a chassis (320), an optical system (310) having an optical axis (315), a stage (350) attached to the chassis (320) and an optical component (330). The optical system (310) may be adapted to receive and/or transmit light. The optical component (330) is located at, or in proximity to, the optical axis (315). The received and/or transmitted light passes through the optical component (330). The stage (350) includes an actuating member (370) arranged to act on the optical component (330) for movement thereof. The actuating member (370) may be responsive to temperature so as to induce a displacement of the optical component (330) relative to the chassis (320) along the optical axis (315) in response to a temperature change.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer Software and Hardware for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Downloadable web application software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]. Computer hardware installation and maintenance. Software as a service [SAAS] provider in the field of software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Providing temporary use of web application software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Computer programming and software consultancy; Computer software installation and maintenance.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer Software and Hardware for aerial mapping and aerial surveying from manned aircraft and UAV's; Downloadable web application software for aerial mapping and aerial surveying from manned aircraft and UAV's Computer hardware installation and maintenance Software as a service featuring software for aerial mapping and aerial surveying from manned aircraft and UAV's; Providing temporary use of non-downloadable web application software for aerial mapping and aerial surveying from manned aircraft and UAV's; Computer programming and software consultancy; Computer software installation and maintenance
62.
METHOD OF SOLVING INITIAL AZIMUTH FOR SURVEY INSTRUMENTS, CAMERAS, AND OTHER DEVICES WITH POSITION AND TILT INFORMATION
A method for solving the initial azimuth for a survey instrument, and other devices, with position and tilt information. The method may be part of bundle adjustment performed during the processing of image and position data collected from each camera of a survey instrument. The use of the initial azimuth generation method (and initial azimuth generator) makes it possible to get accurate azimuth orientation of a camera, such as each camera of a multi-camera survey instrument, without using data from a compass-like sensor. The initial azimuth generated by this method can then be used in later steps/processes of the bundle adjustment to find tie-points with an automatic tie-point finder. Prior to this method, the automatic tie-point finding algorithm relied on the compass and its accuracy, and inaccurate compass values would cause a complete failure, slow runtimes, or less accurate results for the bundle adjustment.
G01C 11/02 - Dispositions de prises de vues spécialement adaptées pour la photogrammétrie ou les levers photographiques, p.ex. pour commander le recouvrement des photos
63.
Method and measuring instrument for target detection and/or identification
The present disclosure relates to a measuring instrument and a method implemented in such a measuring instrument. The measuring instrument includes an image sensor, an actuator, a control unit and a processor. The actuator is arranged to move a field of view of the image sensor. The control unit is configured to cause the image sensor to capture at least one digital image during motion of the field of view of the image sensor by the actuator. The exposure time for capturing the digital image is longer than an identifiable section of a regulating pattern for modulation of an optical radiation either emitted or reflected by at least one target. The processor is configured to process at least a portion of the captured image for detecting in the at least one portion the identifiable section of the regulating pattern. Such a measuring instrument is advantageous for detecting and/or identifying a target in the vicinity of the instrument.
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Computer Software and Hardware for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Downloadable web application software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles] (1) Software as a service [SAAS] provider in the field of software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Providing temporary use of web application software for aerial mapping and aerial surveying from manned aircraft and UAV's [unmanned aerial vehicles]; Computer programming and software consultancy; Computer software and hardware installation and maintenance
A method for determining a distance to a target by a geodetic instrument is disclosed. The method comprises emitting an optical pulse towards a target at an emission time, applying a bias adjustment to a photodiode that is arranged to receive a return optical pulse reflected at the target, obtaining a reference signal that is indicative of a transient behavior of the photodiode for the bias adjustment, obtaining a difference signal by subtracting, from a signal output from the photodiode, a signal that resembles, or is equal to, the transient behavior of the photodiode in response to the bias adjustment based on the reference signal, extracting a reception time that corresponds to reception of the return optical pulse at the photodiode based at least in part on the difference signal, and determining the distance to the target based on the emission time and the reception time.
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
Embodiments provide for a geodetic instrument comprising a scanning head, a reflecting optical element, a radiation source, a control unit and an electronic distance measurement (EDM) unit. The scanning head is rotatable about a first axis. The reflecting optical element mounted in the scanning head and rotatable about the same first axis. The radiation source is adapted to emit light to be output along a light beam path from the geodetic instrument via light reflection against the reflecting optical element. The control unit is adapted to adjust an angular displacement profile of the reflecting optical element about the first axis relative to an angular displacement profile of the scanning head such that an angular displacement of the light beam path about the first axis as a function of time presents a stair-like profile. The EDM unit is adapted to determine a distance to a target during a flat portion of the stair-like profile.
An apparatus for use with a commercial vehicle comprises a media recorder configured to receive video from one or more cameras. The media recorder comprises a memory configured to store a loop of the video as a circular buffer having a predetermined duration. A transceiver is communicatively coupled to the media recorder and configured to receive a video request command generated at a central office. An event detector is configured to communicate with a vehicle computer and detect predetermined events occurring during vehicle operation. The media recorder is configured to retrieve a portion of the loop of video stored in the memory and the transceiver is configured to transmit the portion of the loop of video to the central office in response to the video request command.
G06F 17/30 - Recherche documentaire; Structures de bases de données à cet effet
H04N 5/77 - Circuits d'interface entre un appareil d'enregistrement et un autre appareil entre un appareil d'enregistrement et une caméra de télévision
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
H04N 5/907 - Enregistrement du signal de télévision utilisant des mémoires, p.ex. des tubes à mémoires ou des mémoires à semi-conducteurs
G07C 5/00 - Enregistrement ou indication du fonctionnement de véhicules
G07C 5/08 - Enregistrement ou indication de données de marche autres que le temps de circulation, de fonctionnement, d'arrêt ou d'attente, avec ou sans enregistrement des temps de circulation, de fonctionnement, d'arrêt ou d'attente
68.
Compensated distance measurement methods and apparatus
A transmit light signal is emitted toward a target at an emission time. An optical subsystem of a receiving system receives a return light signal which is converted to a return electrical signal. At least one attenuator applies an attenuation to at least one of the return light signal and the return electrical signal. The attenuation varies, as time passes, after emission of the transmit light signal, according to a time-dependent attenuation function such that the attenuation is maximum at a critical time elapsed since an emission time of the transmit light signal. The critical time is dependent on at least one geometrical parameter of the optical subsystem. A receive time is determined from the return electrical signal. The emission time and the receive time are used to calculate a measured distance.
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
Embodiments provide for a geodetic instrument comprising a scanning head, a reflecting optical element, a radiation source, a control unit and an electronic distance measurement (EDM) unit. The scanning head is rotatable about a first axis. The reflecting optical element mounted in the scanning head and rotatable about the same first axis. The radiation source is adapted to emit light to be output along a light beam path from the geodetic instrument via light reflection against the reflecting optical element. The control unit is adapted to adjust an angular displacement profile of the reflecting optical element about the first axis relative to an angular displacement profile of the scanning head such that an angular displacement of the light beam path about the first axis as a function of time presents a stair-like profile. The EDM unit is adapted to determine a distance to a target during a flat portion of the stair-like profile.
A measurement instrument is disclosed. The measurement instrument comprises a front lens assembly, a distance measurement module and a deflection module. The front lens assembly comprises an optical path along an instrument optical axis and the distance measurement module is configured to transmit and receive optical radiation along a measurement path. The deflection module is arranged between the distance measurement module and the front lens assembly to deflect the measurement path across the instrument optical axis.
G01S 7/48 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
G01S 7/481 - Caractéristiques de structure, p.ex. agencements d'éléments optiques
G01C 15/00 - Instruments de géodésie ou accessoires non prévus dans les groupes
G01S 17/89 - Systèmes lidar, spécialement adaptés pour des applications spécifiques pour la cartographie ou l'imagerie
G01S 17/42 - Mesure simultanée de la distance et d'autres coordonnées
An optical device is disclosed that may be employed in distance measuring devices. In at least one embodiment, the optical device includes a control unit that is adapted to cause at least one control signal generator unit to generate at least one control signal according to a predetermined temporal function on the basis of an elapsed time from a predetermined point in time. On the basis of the generated at least one control signal, at least one parameter of a receiver unit may be adjusted during the travel time of the optical pulse, wherein the at least one parameter affects the dynamic range of the receiver unit. In this way, the dynamic range of the receiver unit may be increased. A method is further disclosed for operating such an optical device, along with a distance measuring device including such an optical device and a surveying instrument including such a distance measuring device.
G01S 7/489 - Récepteurs le gain du récepteur variant automatiquement pendant la période de récurrence des impulsions
G01S 17/10 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement utilisant la transmission d'ondes à modulation d'impulsion interrompues
G01C 15/00 - Instruments de géodésie ou accessoires non prévus dans les groupes
A connected-slot antenna includes a dielectric substrate, a circular patch overlying the dielectric substrate, and a first conductive ring surrounding the circular patch and overlying the dielectric substrate. The first conductive ring is isolated from the circular patch by a first connected slot. At least four feeds are coupled to the circular patch. Each of the at least four feeds are spaced from adjacent ones of the at least four feeds by approximately equal angular intervals. A metamaterial ground plane includes a plurality of conductive patches and a ground plane. The plurality of conductive patches are separated from the circular patch and the first conductive ring by at least the dielectric substrate. The ground plane is electrically coupled to at least a first portion of the plurality of conductive patches. One or more of the plurality of conductive patches and the ground plane are coupled to ground.
H01Q 15/00 - Dispositifs pour la réflexion, la réfraction, la diffraction ou la polarisation des ondes rayonnées par une antenne, p.ex. dispositifs quasi optiques
H01Q 5/40 - Structures imbriquées ou entrelacées; Dispositions combinées ou présentant un couplage électromagnétique, p.ex. comprenant plusieurs éléments rayonnants alimentés sans connexion commune
A distance measurement instrument (400) and a method of operating a distance measurement instrument are disclosed. According to some embodiments, a transmit light signal is transmitted by a transmitter unit (406) along a transmit path (408) at an emission time and a return light signal is received by a receiver unit (407) at a receive time along a receive path (440). The return light signal is converted to a return electrical signal. At least one of the transmit path and the receive path is deflected by a deflection module (415) at a deflection angle relative to an optical axis (430) of the instrument. A time-dependent attenuation function is selected based on information relative to the deflection angle and attenuation is applied by an attenuator (480, 490) to at least one of the return light signal and the return electrical signal according to the selected time-dependent function. A measured distance may be determined by a processor unit (470) based on at least the emission time and the receive time.
Automatic calibration, tuning and diagnostics improve precision farming by helping farmers obtain best performance from their autopilot-guided vehicles. Automatic calibration procedures that cannot be accurately performed by human drivers, automatic autopilot tuning, and simplified diagnostics are all parts of an advanced farm vehicle autopilot system.
A method of image-based positioning is provided. The method comprises: (A) providing an image-capturing device integrated with an object; (B) providing a pattern-generating device configured to generate a set of patterns; (C) locating the pattern-generating device in a field of view (FOV) of the image-capturing device and capturing an image of the pattern-generating device; (D) generating at least one set of pattern data by using the captured image of the pattern-generating device; and (E) processing each set of generated pattern data by using in order to generate an altitude and/or angular coordinates of the object.
H04N 7/18 - Systèmes de télévision en circuit fermé [CCTV], c. à d. systèmes dans lesquels le signal vidéo n'est pas diffusé
G01B 11/25 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer des contours ou des courbes en projetant un motif, p.ex. des franges de moiré, sur l'objet
G01B 11/02 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer la longueur, la largeur ou l'épaisseur
A radio frequency identification (RFID) tower crane load locator and sway indicator includes: a plurality of RFID tags at different locations on or around the crane; at least two RFID readers at different locations on the crane; a navigation satellite system (NSS) position receiver; and a load information interface. The RFID readers comprise a range determiner to provide range measurements between each of the RFID readers and each of the RFID tags. The sway determiner is coupled with a hook block of the crane. The NSS position receiver is coupled with the crane and comprises an antenna fixedly coupled with approximately the front of a jib of the crane. The load information interface combines information from range measurements, the sway determiner and the NSS position receiver to generate location and sway information of the load with respect to the crane and provide this information in a user accessible format.
B66C 13/16 - Utilisation de dispositifs indicateurs de positionnement ou de pesée
B66C 13/46 - Indicateurs de position pour charges suspendues ou pour éléments de grues
B66C 23/28 - Installations comportant essentiellement un palonnier, une flèche ou une structure triangulaire agissant comme bras de levier, montées de façon à permettre des mouvements de translation ou d'orientation dans des plans verticaux ou horizontaux, ou bie spécialement adaptées pour être utilisées dans des emplacements particuliers ou à des usages particuliers faites, p.ex. de pièces détachées, pour permettre un assemblage ou démontage rapides, pour travailler à des niveaux de plus en plus élevés, pour être transportées par route ou par rail faites pour travailler à des niveaux de plus en plus élevés
G01S 19/46 - Détermination de position en combinant les mesures des signaux provenant du système de positionnement satellitaire à radiophares avec une mesure supplémentaire la mesure supplémentaire étant du type signal d'onde radioélectrique
77.
Micro climate corrections for radar interferometry measurements
A method for monitoring movement of a surface using ground based radar interferometry measurements includes identifying micro climates on the surface and determining boundaries of the micro climates on the surface. One or more first sensors are arranged at a measurement site for measuring first atmospheric conditions at the measurement site. One or more additional sensors are arranged in each of the micro climates for measuring atmospheric conditions in the micro climates. An atmospheric correction is determined for each of the micro climates. The atmospheric correction for each micro climate is based on the first atmospheric conditions at the measurement site and the atmospheric conditions at the micro climate. The ground based radar interferometry measurements are performed across the surface, and the ground based radar interferometry measurements within the boundary of each micro climate are corrected using the atmospheric correction for the micro climate.
G01S 13/90 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques pour la cartographie ou la représentation utilisant des techniques d'antenne synthétique
78.
Distance measurement instrument with scanning function
A measurement instrument is disclosed. The measurement instrument comprises a distance measurement module, a splitter and a deflection module. The distance measurement module is configured to transmit optical radiation along a transmit path and receive optical radiation along a receive path. The transmit path and the receive path are merged in a measurement beam at the splitter. The deflection module is located optically between the distance measurement module and the splitter. The deflection module is configured to aim the transmit path and the receive path at the splitter and to deflect at least one of the transmit path and the receive path across an instrument optical axis.
G01S 7/48 - DÉTERMINATION DE LA DIRECTION PAR RADIO; RADIO-NAVIGATION; DÉTERMINATION DE LA DISTANCE OU DE LA VITESSE EN UTILISANT DES ONDES RADIO; LOCALISATION OU DÉTECTION DE LA PRÉSENCE EN UTILISANT LA RÉFLEXION OU LA RERADIATION D'ONDES RADIO; DISPOSITIONS ANALOGUES UTILISANT D'AUTRES ONDES - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
G01S 7/481 - Caractéristiques de structure, p.ex. agencements d'éléments optiques
G01S 17/08 - Systèmes déterminant les données relatives à la position d'une cible pour mesurer la distance uniquement
G01C 15/00 - Instruments de géodésie ou accessoires non prévus dans les groupes
A laser light reflective target that effectively brightens a laser light line being produced by a laser fan beam emitter. The target is placed on a jobsite floor and when two laser fan beams strike the reflective surface of the target, the laser beams appear much brighter than otherwise. The laser fan beams, when properly aimed at a point of interest, will intersect and produce an "X" shaped pattern of light on the target. The target can be used with a laser plumb beam pointer, which will aim its vertical beam downward directly at the specific point of interest if the target has been properly positioned. The laser plumb line pointer can additionally aim a second vertical beam upward, to produce a plumb line target point on the ceiling of an interior room that is being laid out.
G01S 17/87 - Combinaisons de systèmes utilisant des ondes électromagnétiques autres que les ondes radio
G02B 27/64 - Systèmes pour donner des images utilisant des éléments optiques pour la stabilisation latérale et angulaire de l'image
G09F 13/16 - Enseignes formées d'éléments ou de surfaces réfléchissantes, ou en comportant, p.ex. enseignes d'avertissement ayant une forme triangulaire ou de forme géométrique autre
An omnidirectional lens is disclosed of the type which captures light from virtually all angles of incidence, and also emits light in all directions. Embodiments are specifically disclosed as a two-way lens that receives light beams from all directions of the compass and directs those light beams to a photosensor. The same two-way lens acts in a "beacon mode" to produce light beams from one or more LEDs, and to emit such light beams (again) in all directions of the compass. The emitted light beams can also be used to signal various functions as visible signals to users on a jobsite.
A radio frequency identification (RFID) tag distance measuring system and method is disclosed. One example includes a first replica path that receives a signal that is simultaneously transmitted to an RFID tag. The first replica path includes a plurality of taps at known distances along the first replica path. Each of the plurality of taps has a first tap input coupled with the first replica path. In addition, an RFID signal receiver receives a return signal from the RFID tag and provides the return signal along a measurement input, wherein each of the plurality of taps have a second tap input coupled with the measurement path. A distance determiner detects at least the first of the plurality of taps to have an output and determine a distance measurement to the RFID tag based thereon.
G06K 7/00 - Méthodes ou dispositions pour la lecture de supports d'enregistrement
G01S 5/14 - Localisation par coordination de plusieurs déterminations de direction ou de ligne de position; Localisation par coordination de plusieurs déterminations de distance utilisant les ondes radioélectriques déterminant des distances absolues à partir de plusieurs points espacés d'emplacement connu
G01S 5/30 - Détermination de distances absolues à partir de plusieurs points espacés d'emplacement connu
G01S 13/08 - Systèmes pour mesurer la distance uniquement
G01S 13/78 - Systèmes utilisant la reradiation d'ondes radio, p.ex. du type radar secondaire; Systèmes analogues dans lesquels des signaux de type pulsé sont transmis effectuant la discrimination entre différents types de cibles, p.ex. radar pour l'identification ami–ennemi
G01S 13/74 - Systèmes utilisant la reradiation d'ondes radio, p.ex. du type radar secondaire; Systèmes analogues
G01S 5/02 - Localisation par coordination de plusieurs déterminations de direction ou de ligne de position; Localisation par coordination de plusieurs déterminations de distance utilisant les ondes radioélectriques
G06K 19/077 - Supports d'enregistrement avec des marques conductrices, des circuits imprimés ou des éléments de circuit à semi-conducteurs, p.ex. cartes d'identité ou cartes de crédit avec des puces à circuit intégré - Détails de structure, p.ex. montage de circuits dans le support
82.
OBJECT ASSOCIATION USING DYNAMIC OBJECT LOCATION CORRELATION
A method of object association is disclosed. The method includes receiving object location information for a first object, receiving object location information for a second object, determining an existence of a correlation between a varying position of the first object and a varying position of the second object over for a predetermined amount of time and dynamically associating the first object with the second object based on the correlation.
An integrated auto-level and electronic rod reader is disclosed. In one embodiment, the integrated auto-level and electronic rod reader comprises a telescope and an image delivery device integrated with the auto-level which is configured for capturing an image of a standard grade rod visible through the telescope and a crosshair. Logic implemented by a processor automatically recognizes the crosshair, automatically compares the crosshair against a scale of the standard grade rod, and automatically determines an elevation of the standard grade rod based upon the comparing.
G01C 5/02 - Mesure des hauteurs; Mesure des distances transversales par rapport à la ligne de visée; Nivellement entre des points séparés; Niveaux à lunette impliquant une stabilisation automatique de la ligne de visée
Reflective target for surveying instruments having a plurality of planar reflective sections arranged to form a shape having a target axis. Each reflective section includes a plurality of prisms, each prism constituted by a corner cube having three surfaces oriented perpendicular to one another and forming a base for receiving incident light, and each of the prisms is oriented such that a common edge formed by two of the three surfaces of the prism is oriented such that the common edge and the target axis or a line parallel to the target axis lie in a common plane.
G02B 5/124 - Réflecteurs reflex du type en sommet de cube, en trièdre ou en réflecteur triple plusieurs éléments réfléchissants faisant partie d'une plaque ou d'une feuille formant un tout
G02B 5/122 - Réflecteurs reflex du type en sommet de cube, en trièdre ou en réflecteur triple
G01C 15/02 - Moyens pour marquer les points de mesure
An electronic rod reader and field notebook is disclosed. In one embodiment, the electronic rod reader and field notebook comprises an image capture device for capturing an image through the eyepiece of an auto-level. The electronic rod reader and field notebook further comprises logic implemented by a processor of the electronic rod reader for automatically recognizing a crosshair viewed through the eyepiece of the auto-level, for automatically comparing the crosshair against a scale of a standard grade rod viewed through the eyepiece of the auto-level, and for automatically determining an elevation of the standard grade rod based upon the comparing. The electronic rod reader and field notebook further comprises a non-transitory computer readable data storage medium coupled with the processor for storing the elevation as a first reading.
G01C 5/00 - Mesure des hauteurs; Mesure des distances transversales par rapport à la ligne de visée; Nivellement entre des points séparés; Niveaux à lunette
H04N 7/18 - Systèmes de télévision en circuit fermé [CCTV], c. à d. systèmes dans lesquels le signal vidéo n'est pas diffusé
87.
EXTERNAL GNSS RECEIVER MODULE WITH MOTION SENSOR SUITE FOR CONTEXTUAL INFERENCE OF USER ACTIVITY
A method for contextual inference of user activity is disclosed. In one embodiment, an indication of the motion of a pole mounted sensing device comprising at least one motion sensor and a Global Navigation Satellite System (GNSS) receiver configured to at least generate raw GNSS observables is received from the at least one motion sensor. The indication of the motion of the pole mounted sensing device is correlated with an operation defined in a gesture library regarding GNSS data collect by the GNSS receiver at a time when the indication of the motion is detected. The indication and the GNSS data are stored.
G01S 19/39 - Détermination d'une solution de navigation au moyen des signaux émis par un système de positionnement satellitaire à radiophares le système de positionnement satellitaire à radiophares transmettant des messages horodatés, p.ex. GPS [Système de positionnement global], GLONASS [Système mondial de satellites de navigation] ou GALILEO
G01S 19/43 - Détermination de position utilisant l'interférométrie à ligne de base longue ou courte
G01S 19/49 - Détermination de position en combinant ou en commutant entre les solutions de position dérivées du système de positionnement par satellite à radiophares et les solutions de position dérivées d'un autre système l'autre système étant un système de position inertielle, p.ex. en hybridation lâche
Disclosed is a guidance system that helps an earthmoving machine operator to control exactly to what elevation to dig. The system includes an electronic sensing device (10, 30, 50, 70, 100) and a display monitor (140). In one embodiment, the electronic sensing device includes a distance measuring sensor (16, Laser Distance Meter), an elevation detecting sensor (12), an orientation sensor (14), and a steering mechanism (18) for the LDM. The sensing device is mounted to an earthmoving machine (200), and sends signals to the display showing the machine operator where to move the digging tool for digging to the desired elevation. The various sensors in the sensing device are calibrated at the factory, so the sensing device can be mounted to an earthmoving machine and then be immediately used by that machine without needing any calibration that involves the machine itself, which is a huge advantage for the equipment operator. The measurements are made via non-contact sensors, thereby preserving the jobsite surface.
Disclosed is a guidance system that helps an earthmoving machine operator to control exactly to what elevation to dig. The system includes an electronic sensing device and a display monitor. In one embodiment, the electronic sensing device includes a distance measuring sensor (LDM), an elevation detecting sensor, an orientation sensor, and a steering mechanism for the LDM. The sensing device is mounted to an earthmoving machine, and sends signals to the display showing the machine operator where to move the digging tool for digging to the desired elevation. The various sensors in the sensing device are calibrated at the factory, so the sensing device can be mounted to an earthmoving machine and then be immediately used by that machine without needing any calibration that involves the machine itself, which is a huge advantage for the equipment operator. The measurements are made via non-contact sensors, thereby preserving the jobsite surface.
A multiband antenna apparatus for high-precision GNSS positioning is proposed. The multiband antenna apparatus comprises a first antenna configured for reception of GNSS signals in a first multiband of electromagnetic spectrum, a second multiband antenna configured for reception of GNSS signals in a second multiband of electromagnetic spectrum, and an antenna phase reference point configured to represent an integrated electric phase data. The antenna phase reference point is related to a physical reference point of the antenna apparatus.
G01S 19/36 - Récepteurs - Détails de construction ou détails de matériel ou de logiciel de la chaîne de traitement des signaux concernant l'étage d'entrée du récepteur
H01Q 21/30 - Combinaisons d'unités d'antennes séparées, fonctionnant sur des bandes d'ondes différentes et connectées à un système d'alimentation commun
H01Q 1/32 - Adaptation pour l'utilisation dans ou sur les véhicules routiers ou ferroviaires
91.
ALL-IN-ONE INTEGRATED SENSING DEVICE FOR MACHINE CONTROL
An integrated sensing device (10) with a suite of sensors assists construction machine operators in finding the correct level to dig a ditch/trench. The sensing device (10) includes a gravity sensor (40) to determine angles, a laser distance meter (LDM) (50), and a laser receiver (20) for detecting a known jobsite elevation. The sensing device is mounted to the dipper stick (208) of an excavator (200); the gravity sensor (40) detects the angle of the stick (208), and the laser receiver (20) detects a laser plane (90) of light that represents a known jobsite elevation. The LDM is aimed at another member of the machine that moves in a predetermined path as the bucket (210) is rotated, and the distance between the LDM and the target member is used to calculate the vertical elevation of the working tool edge (212). A display graphically shows the operator the proper dig depth and the present position of the working tool edge (212).
G01S 1/72 - Radiophares ou systèmes de balisage émettant des signaux ayant une ou des caractéristiques pouvant être détectées par des récepteurs non directionnels et définissant des directions, situations ou lignes de position déterminées par rapport aux émetteu; Récepteurs travaillant avec ces systèmes utilisant des ondes ultrasonores, sonores ou infrasonores
Novel solutions, which can include devices, systems, methods, than can measure earthquakes and other displacement events. Some solutions feature the integration of real-time, high-rate global navigation satellite system ("GNSS") displacement information with acceleration and/or velocity data within a single device to create very high-rate displacement records. The mating of these two instruments allows the creation of a new, very high-rate displacement measurement device that has the full-scale displacement characteristics of GNSS and high-precision dynamic motions of seismic technologies. Such a device can be used for earthquake early warning studies and other mission critical applications, such as volcano monitoring, building, bridge and dam monitoring systems.
Novel tools and techniques for creating and implementing three-dimensional guidance paths for use in conjunction with more or one agricultural vehicles operating in an area of operation.
A system comprises a transmitter unit configured for mounting at a trailer connected to a tractor. The transmitter unit comprises a video input for receiving video data from one or more trailer cameras, a power input for receiving power from a power line of the trailer, and a wireless communication module for communicating with a mobile communication device. A memory is configured to store trailer information received from the wireless communication module, the trailer information uniquely identifying the trailer. A transmitter is configured to wirelessly transmit the video data. A receiver unit is configured for mounting at the tractor and comprises a receiver for wirelessly receiving the video data transmitted by the transmitter, a power input for receiving power from a power line of the tractor, and an output for outputting the received video data. The receiver unit is further configured to receive the trailer information from the transmitter unit.
B60R 1/00 - Dispositions pour la visibilité optique; Dispositions de visualisation en temps réel pour les conducteurs ou les passagers utilisant des systèmes de capture d’images optiques, p.ex. des caméras ou des systèmes vidéo spécialement adaptés pour être utilisés dans ou sur des véhicules
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
H04N 5/247 - Disposition des caméras de télévision
H04N 7/18 - Systèmes de télévision en circuit fermé [CCTV], c. à d. systèmes dans lesquels le signal vidéo n'est pas diffusé
H01R 27/02 - Pièces de couplage adaptées à la coopération avec plusieurs pièces complémentaires dissemblables pour coopération simultanée avec plusieurs pièces complémentaires
95.
All-in-one integrated sensing device for machine control
An integrated sensing device with a suite of sensors assists construction machine operators in finding the correct level to dig a ditch/trench. The sensing device includes a gravity sensor to determine angles, a laser distance meter (LDM), and a laser receiver for detecting a known jobsite elevation. The sensing device is mounted to the dipper stick of an excavator; the gravity sensor detects the angle of the stick, and the laser receiver detects a laser plane of light that represents a known jobsite elevation. The LDM is aimed at another member of the machine that moves in a predetermined path as the bucket is rotated, and the distance between the LDM and the target member is used to calculate the vertical elevation of the working tool edge. A display graphically shows the operator the proper dig depth and the present position of the working tool edge.
G01B 11/14 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer la distance ou la marge entre des objets ou des ouvertures espacés
G01S 19/14 - Récepteurs spécialement adaptés pour des applications spécifiques
G01S 17/02 - Systèmes utilisant la réflexion d'ondes électromagnétiques autres que les ondes radio
G01S 17/88 - Systèmes lidar, spécialement adaptés pour des applications spécifiques
E02F 3/43 - Commande de la position du plongeur ou de l'auge; Commande de la succession des opérations d'entraînement
A new sensor is detected being added to a vehicle sensor bus. A publication topic is created based on the new sensor. The publication topic is made available via at least to a server component operating via the proximity networking radio. Data from the new sensor is added to the publication topic. In response to a subscription to the publication topic via a user device, the data is dynamically presented to the user device via the server component.
At least one of a set of topics published by one or more vehicle-located mobile gateways is subscribed to. A set of publication topics is created based on the first set of topics, the publication topics made available to a client. A subscription request is received from the client corresponding to a selected topic of the set of publication topics. First sequential data is received from the one or more mobile gateways in response to the subscription to the at least one of the set of topics of the one or more mobile gateways. Second sequential data is sent to the client responsive to the subscription request, the second sequential data being based on the first sequential data.
A responder-ready reporting network is disclosed. In one embodiment, the responder-ready reporting network comprises a control system configured for real-time managing of a real-time digital map of a selected environment. The responder-ready reporting network further comprises a data storage repository coupled with the control system and configured to store the real-time digital map of said selected environment. The responder-ready reporting network further comprises an emergency responder reporting component configured to convey data regarding the selected environment, including the real-time digital map, to an emergency responder agent in response to the triggering of an emergency notification regarding the selected environment.
A system comprises a transmitter unit configured for mounting at a trailer connected to a tractor. The transmitter unit comprises a video input for receiving video data from one or more trailer cameras, a power input for receiving power from a power line of the trailer, and a wireless communication module for communicating with a mobile communication device. A memory is configured to store trailer information received from the wireless communication module, the trailer information uniquely identifying the trailer. A transmitter is configured to wirelessly transmit the video data. A receiver unit is configured for mounting at the tractor and comprises a receiver for wirelessly receiving the video data transmitted by the transmitter, a power input for receiving power from a power line of the tractor, and an output for outputting the received video data. The receiver unit is further configured to receive the trailer information from the transmitter unit.
H04N 7/18 - Systèmes de télévision en circuit fermé [CCTV], c. à d. systèmes dans lesquels le signal vidéo n'est pas diffusé
B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
B60R 1/00 - Dispositions pour la visibilité optique; Dispositions de visualisation en temps réel pour les conducteurs ou les passagers utilisant des systèmes de capture d’images optiques, p.ex. des caméras ou des systèmes vidéo spécialement adaptés pour être utilisés dans ou sur des véhicules
G08B 13/196 - Déclenchement influencé par la chaleur, la lumière, ou les radiations de longueur d'onde plus courte; Déclenchement par introduction de sources de chaleur, de lumière, ou de radiations de longueur d'onde plus courte utilisant des systèmes détecteurs de radiations passifs utilisant des systèmes de balayage et de comparaison d'image utilisant des caméras de télévision
100.
VEHICLE DATA SYSTEM UTILIZING PUBLISH/SUBSCRIBE GATEWAYS
At least one of a set of topics published by one or more vehicle-located mobile gateways is subscribed to. A set of publication topics is created based on the first set of topics, the publication topics made available to a client. A subscription request is received from the client corresponding to a selected topic of the set of publication topics. First sequential data is received from the one or more mobile gateways in response to the subscription to the at least one of the set of topics of the one or more mobile gateways. Second sequential data is sent to the client responsive to the subscription request, the second sequential data being based on the first sequential data.
H04W 4/06 - Répartition sélective de services de diffusion, p.ex. service de diffusion/multidiffusion multimédia; Services à des groupes d’utilisateurs; Services d’appel sélectif unidirectionnel
H04W 84/18 - Réseaux auto-organisés, p.ex. réseaux ad hoc ou réseaux de détection
