Abrégé

A label applicator pad (1) configured for transporting a label (L) from a label feeding device (F) to an object (O) and applying the label (L) to the object (O). The label applicator pad (1) comprises an ejector structure (3) and a flexible deformation structure (4). The flexible deformation structure (4) comprises a flexible label holding surface (2a) having one or more suction openings (2b), and the flexible label holding surface (2a) is adapted for holding the label (L) upon transportation from the label feeding device (F) to the object (O). The label applicator pad (1) further comprises one or more flexible suction channels (5) arranged within the flexible deformation structure (4) and connected to one or more corresponding suction openings (2b). The one or more flexible suction channels (5) are fluidly connecting the one or more suction openings (2b) to the ejector structure (3). The flexible deformation structure (4) and the one or more flexible suction channels (5) are configured for being compressed upon application of the label (L) to the object (O), enabling deformation of the flexible label holding surface (2a) for adapting the flexible label holding surface (2a) to a surface shape (S) of the object (O).

Classes IPC  ?

• B65C 9/36 - EssuyeursPresseurs

Abrégé

A safety labelling system (S) comprising a lifting device (1) for positioning a labelling unit (2) in a vertical direction (Z) in relation to a flow of objects (3). The lifting device (1) comprises an upper section (1a) and a lower section (1b), wherein the upper section (1a) is movably arranged relative to the lower section (1b) by means of a balancing displacement unit (U). The labelling unit (2) is attached to the upper section (1a). The balancing displacement unit (U) comprises a cylinder barrel (5), a piston (6) movably arranged in the cylinder barrel (5), a piston rod (7), and a cylinder nut (8). The piston rod (7) and the cylinder nut (8) are rotatably engaged with each other, wherein the piston rod (7) at an inner end (7a) is connected to the piston (6) and the cylinder nut (8) is connected to the cylinder barrel (5). An actuator (M) is configured for rotatably displacing the piston rod (7) or the cylinder nut (8) resulting in linear displacement of the labelling unit (2) in the vertical direction (Z). The balancing displacement unit (U) further comprises a load balancing pressure chamber (9) arranged in the cylinder barrel (5) in connection to the piston (6), configured for counterbalancing a gravitational force (FG) exerted on the piston rod (7) by means of fluid pressure (P).

Classes IPC  ?

• B65C 1/02 - Pose d'étiquettes sur la surface plane d'objets, p. ex. sur des emballages, des bandes plates

Produits et services

Thermal printer heads; print heads for printers; print heads for inkjet printers; print heads for computer printers; computer software; software for printers, computer software for computer printer and software for inkjet printers; software for print heads and computer software, for use in relation to the following goods: thermal printer heads.

Produits et services

Thermal printer heads; Print heads for printers; Print heads for inkjet printers; Print heads for computer printers; Computer software; Software for printers, Computer software for computer printer and software for inkjet printers; software for print heads and Computer software, for use in relation to the following goods: Thermal printer heads.

Produits et services

Machines for printing labels; apparatus and machines for mainly labeling but also for printing labels; labeling machines [other than for office use]; machines for printing and labeling radio-frequency identification markers (tags); apparatus and machines for mainly printing but also labeling labels not for household or stationery use. Computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printers, all for industrial or commercial purposes; readers and coders for radio-frequency identification markers (tags); readers and coders for intelligent labels; computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software for communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software for communicating with industrial marking apparatus.

Produits et services

Machines for printing labels; apparatus and machines for mainly labeling but also for printing labels; labeling machines [other than for office use]; machines for printing and labeling radio-frequency identification markers (tags); apparatus and machines for mainly printing but also labeling labels not for household or stationery use. Computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printers, all for industrial or commercial purposes; readers and coders for radio-frequency identification markers (tags); readers and coders for intelligent labels; computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software for communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software for communicating with industrial marking apparatus.

Produits et services

Machines for printing labels; industrial apparatus and machines for mainly labeling but also for printing labels; labeling machines [other than for office use]; machines for printing and labeling Radio-frequency identification markers (tags); apparatus and machines for mainly printing but also labeling labels not for household or stationery use. Computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for radio-frequency identification markers (tags); readers and coders for intelligent labels; computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software communicating with industrial marking apparatus. Ribbons for printers for industrial or commercial purposes; labels [not made of textile] for printers for industrial or commercial purposes.

Produits et services

Electronic label printing machines for commercial use; apparatus and machines for labeling and printing labels, namely, automatic industrial labeling machines for applying labels to containers and bottles; labeling machines other than for office use, namely, electronic label printing machines for commercial and industrial use; electronic label printing machines for printing and labeling radio-frequency identification markers in the nature of tags for commercial use; apparatus and machines for printing and labeling labels, namely, electronic label printing machines not for household or stationery use Downloadable computer programs and downloadable software for industrial marking for use with apparatus, namely, printers; document printers, laser document printers, ink jet document printers, thermal printers and heat transfer printers in the nature of thermal printers, all for industrial or commercial purposes; RFID readers and coders in the nature of electronic coding units for radiofrequency identification markers being tags; RFID readers and coders in the nature of electronic coding units for intelligent labels; downloadable computer programs and downloadable software for label printing and label application for industrial or commercial purposes; recorded computer programs and recorded software for industrial marking; recorded computer programs and recorded software for communicating with industrial marking apparatus; downloadable computer programs and downloadable software for industrial marking; downloadable computer programs and downloadable software for communicating with industrial marking apparatus

Produits et services

Electronic label printing machines for commercial use; apparatus and machines for labeling and printing labels, namely, automatic industrial labeling machines for applying labels to containers and bottles; labeling machines other than for office use, namely, electronic label printing machines for commercial and industrial use; electronic label printing machines for printing and labeling radio-frequency identification markers in the nature of tags for commercial use; apparatus and machines for printing and labeling labels, namely, electronic label printing machines not for household or stationery use Downloadable computer programs and downloadable software for industrial marking for use with apparatus, namely, printers; document printers, laser document printers, ink jet document printers, thermal printers and heat transfer printers in the nature of thermal printers, all for industrial or commercial purposes; RFID readers and coders in the nature of electronic coding units for radiofrequency identification markers being tags; RFID readers and coders in the nature of electronic coding units for intelligent labels; downloadable computer programs and downloadable software for label printing and label application for industrial or commercial purposes; recorded computer programs and recorded software for industrial marking; recorded computer programs and recorded software for communicating with industrial marking apparatus; downloadable computer programs and downloadable software for industrial marking; downloadable computer programs and downloadable software for communicating with industrial marking apparatus

Produits et services

(1) Machines for printing labels; industrial apparatus and machines for mainly labeling but also for printing labels; labeling machines [other than for office use]; machines for printing and labeling Radio-frequency identification markers (tags); apparatus and machines for mainly printing but also labeling labels not for household or stationery use. (2) Computer programs and computer software for the operation of apparatus for industrial marking, namely, lasers for engraving, portable laser engraving machines, dye-sublimation printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines; printers, namely, dye-sublimation printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for radio-frequency identification markers (tags); readers and coders for intelligent labels; computer programs and computer software for the operation of label printing machines and label applicator machines, for industrial or commercial purposes; computer programs and computer software for industrial marking, namely, computer programs and computer software for the designing of labels on label printing machines, computer programs and computer software for the design, development and updating of digital electronic labels; downloadable computer programs and downloadable computer software for the operation of industrial marking apparatus, namely, lasers for engraving, portable laser engraving machines, dye-sublimation printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines. (3) Ribbons for printers for industrial or commercial purposes, namely, computer printer ribbons, office machine ribbons, barcode ribbons, ribbons for hand-held label printers; labels, not made of textile, namely, labels of paper or cardboard, paper bar code labels, adhesive labels of paper, partially pre-printed paper labels, printed novelty paper labels, all for printers for industrial and commercial purposes.

Produits et services

Electronic label printing machines for commercial use; industrial apparatus and machines for labeling and printing labels, namely, automatic industrial labeling machines for applying labels to containers and bottles; labeling machines other than for office use, namely, electronic label printing machines for commercial and industrial use; electronic label printing machines for printing and labeling radio- frequency identification markers in the nature of tags for commercial use; apparatus and machines for printing and labeling labels, namely, electronic label printing machines not for household or stationery use Downloadable computer programs and downloadable software for industrial marking for use with apparatus, namely, printers; document printers, laser document printers, ink jet document printers, thermal printers and heat transfer printers in the nature of thermal printers, all for industrial or commercial purposes; RFID readers and coders in the nature of electronic coding units for radiofrequency identification markers being tags; RFID readers and coders in the nature of electronic coding units for intelligent labels; downloadable computer programs and downloadable software for label printing and label application for industrial or commercial purposes; recorded computer programs and recorded software for industrial marking; recorded computer programs and recorded software for communicating with industrial marking apparatus; downloadable computer programs and downloadable software for industrial marking; downloadable computer programs and downloadable software for communicating with industrial marking apparatus Ribbons for computer printers for industrial or commercial purposes; labels not made of textile in the nature of paper labels for printers for industrial or commercial purposes

Abrégé

A system for printing and applying labels to a flow of objects, including a labelling unit, an object transporting device, an object detection sensor, and a control unit, wherein the labelling unit comprises a label printing unit for printing labels to be applied to the objects, wherein the object transporting device is transporting individual objects in a random flow to the labelling unit in an object transporting direction, wherein the object detection sensor is arranged upstream the labelling unit and is detecting a position of the objects when they are transported past the object detection sensor towards the labelling unit, wherein two directly after each other transported objects arranged on the object transporting device are separated by a separation distance, wherein the separation distance is calculated by the control unit based on position detection by the object detection sensor of reference points between a preceding object and a directly subsequent object being transported on the object transporting device, wherein the label printing unit if the separation distance is equal to or less than a predetermined first trigger distance value is printing labels to be applied to the objects in a continuous printing mode, wherein the label printing unit if the separation distance is greater than the predetermined first trigger distance value, is printing labels to be applied to the objects in an intermittent printing mode.

Classes IPC  ?

• B32B 41/00 - Dispositions pour le contrôle ou la commande des procédés de stratificationDispositions de sécurité
• B65C 9/46 - Application de marques de dates, de marques codées ou d'un genre similaire, sur des étiquettes pendant l'étiquetage
• B65C 1/02 - Pose d'étiquettes sur la surface plane d'objets, p. ex. sur des emballages, des bandes plates
• B65C 9/02 - Dispositifs pour déplacer les objets, p. ex. des réceptacles, devant le poste d'étiquetage
• B65C 9/40 - CommandesDispositifs de sécurité

Produits et services

Machines for printing labels; apparatus and machines for mainly labeling but also for printing labels; Labeling machines [other than for office use]; machines for printing and labeling Radio-frequency identification markers (tags); Apparatus and machines for mainly printing but also labeling labels not for household or stationery use. Computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for Radio-frequency identification markers (tags); readers and coders for intelligent labels; Computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software communicating with industrial marking apparatus.

Produits et services

Machines for printing labels; apparatus and machines for mainly labeling but also for printing labels; Labeling machines [other than for office use]; machines for printing and labeling Radio-frequency identification markers (tags); Apparatus and machines for mainly printing but also labeling labels not for household or stationery use. Computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for Radio-frequency identification markers (tags); readers and coders for intelligent labels; Computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software communicating with industrial marking apparatus.

Produits et services

Machines for printing labels; apparatus and machines for mainly labeling but also for printing labels; Labeling machines [other than for office use]; machines for printing and labeling Radio-frequency identification markers (tags); Apparatus and machines for mainly printing but also labeling labels not for household or stationery use. Computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for Radio-frequency identification markers (tags); readers and coders for intelligent labels; Computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software communicating with industrial marking apparatus. Ribbons for printers for industrial or commercial purposes; labels [not made of textile] for printers for industrial or commercial purposes.

Abrégé

A safety lifting device for positioning a labelling unit in a vertical direction (Z) in relation to a flow of objects where the labelling unit is arranged for printing labels and/or applying labels to the objects. The lifting device includes a linear actuator, a balancing unit, a drive unit connected to the linear actuator, and a movable section. The labelling unit is connected to the movable section. The linear actuator is connected to the movable section and arranged to control the position of the labelling unit. The balancing unit is arranged to counterbalance the gravitational force exerted on the linear actuator. The movable section of the lifting device includes an upper stand unit, and the lifting device further includes a lower stand unit. The upper stand unit is movably arranged in relation to the lower stand unit in the vertical direction.

Classes IPC  ?

• B65C 1/00 - Étiquetage sur surfaces planes pratiquement rigides
• B65C 9/00 - Parties constitutives ou détails des machines ou appareils à étiqueter
• B65C 1/02 - Pose d'étiquettes sur la surface plane d'objets, p. ex. sur des emballages, des bandes plates
• B65C 9/26 - Dispositifs pour appliquer les étiquettes
• B65C 9/46 - Application de marques de dates, de marques codées ou d'un genre similaire, sur des étiquettes pendant l'étiquetage
• B65G 41/00 - Châssis ou bases de support pour transporteurs dans leur ensemble, p. ex. châssis transportables
• F16F 9/02 - Ressorts, amortisseurs de vibrations, amortisseurs de chocs ou amortisseurs de mouvement de structure similaire, utilisant un fluide ou moyen équivalent comme agent d'amortissement utilisant un gaz uniquement
• F16F 9/32 - Ressorts, amortisseurs de vibrations, amortisseurs de chocs ou amortisseurs de mouvement de structure similaire, utilisant un fluide ou moyen équivalent comme agent d'amortissement Parties constitutives
• F16F 9/43 - Dispositions de remplissage, p. ex. pour l'alimentation en gaz
• F16F 9/56 - Moyens pour régler la longueur du ressort ou de l'amortisseur, ou pour les bloquer, p. ex. en fin de course
• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
• F16H 25/20 - Mécanismes à vis
• F16M 11/28 - Soubassements pour supports à pilier télescopique unique

Abrégé

A system for printing and applying labels (2) to a flow of objects (3), comprising a labelling unit (1), an object transporting device (4), an object detection sensor (5), and a control unit (8), wherein the labelling unit (1) comprises a label printing unit (6) for printing labels (2) to be applied to the objects (3), wherein the object transporting device (4) is transporting individual objects (3) in a random flow to the labelling unit (1) in an object transporting direction (X), wherein the object detection sensor (5) is arranged upstream the labelling unit (1) and is detecting a position of the objects (3) when they are transported past the object detection sensor (5) towards the labelling unit (1), wherein two directly after each other transported objects (3) arranged on the object 10transporting device (4) are separated by a separation distance (DS), wherein the separation distance (DS) is calculated by the control unit (8) based on position detection by the object detection sensor (5) of reference points (PR) between a preceding object (3.1) and a directly subsequent object (3.2) being transported on the object transporting device (4), wherein the label printing unit (6) if the separation distance (DS) is equal to or less than a predetermined first trigger distance value (DT1) is printing labels (2) to be applied to the objects (3) in a continuous printing mode (MC), wherein the label printing unit (6) if the separation distance (DS) is greater than the predetermined first trigger distance value (DT1), is printing labels (2) to be applied to the objects (3) in an intermittent printing mode (MI).

Classes IPC  ?

• B65C 9/02 - Dispositifs pour déplacer les objets, p. ex. des réceptacles, devant le poste d'étiquetage

Abrégé

LL) of the labelling unit, where in the labelling position the labels are printed and/or applied to the objects. The balancing unit is connected to the movable section and arranged to interact with and support the linear actuator and counterbalancing the gravitational force exerted on the linear actuator by the labelling unit and the movable section preventing high loads on the linear actuator. The movable section of the lifting device comprises an upper stand unit (17), and the lifting device further comprises a stationary lower stand unit (16) arranged on a support surface (18). The upper stand unit is movably arranged in relation to the lower stand unit in the vertical direction, and the labelling unit is attached to the movable section. The linear actuator and the balancing unit are arranged inside the lower stand unit and the upper stand unit.

Classes IPC  ?

• B65C 1/02 - Pose d'étiquettes sur la surface plane d'objets, p. ex. sur des emballages, des bandes plates
• F15B 15/14 - Dispositifs actionnés par fluides pour déplacer un organe d'une position à une autreTransmission associée à ces dispositifs caractérisés par la structure de l'ensemble moteur le moteur étant du type à cylindre droit
• F16F 9/02 - Ressorts, amortisseurs de vibrations, amortisseurs de chocs ou amortisseurs de mouvement de structure similaire, utilisant un fluide ou moyen équivalent comme agent d'amortissement utilisant un gaz uniquement
• F16H 25/20 - Mécanismes à vis
• B23Q 11/00 - Accessoires montés sur les machines-outils pour maintenir les outils ou les organes de la machine dans de bonnes conditions de travail ou pour refroidir les pièces travailléesDispositifs de sécurité spécialement combinés aux machines-outils, disposés dans ces machines ou spécialement conçus pour être utilisés en relation avec ces machines
• B65C 9/26 - Dispositifs pour appliquer les étiquettes
• F16F 9/43 - Dispositions de remplissage, p. ex. pour l'alimentation en gaz

Abrégé

A method and an arrangement to apply labels on marking objects which are transported on a track. By only two swinging arms, the output printed label is transported away from the label printer, in a first direction of travel, so that the adhesive side of the label is facing the first direction of travel of the label applicator plate, and in an opposite second direction of travel, so that the printed side of the printed label is faces the second direction of travel of the label applicator plate. Continued motion actuation of the label applicator plate by turning the swinging arm carrying the applicator plate and, where appropriate, rotation of the applicator plate provides transportation of the label to and delivery of the label at and application of the label on the marking object with the adhesive side of the label facing the marking object.

Classes IPC  ?

• B65C 1/02 - Pose d'étiquettes sur la surface plane d'objets, p. ex. sur des emballages, des bandes plates

Produits et services

Machines for printing labels; apparatus and machines for mainly labeling but also for printing labels; labeling machines [other than for office use]; machines for printing and labeling radio-frequency identification markers (tags); apparatus and machines for mainly printing but also labeling labels. Computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for radio-frequency identification markers (tags); readers and coders for intelligent labels; computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software communicating with industrial marking apparatus.

Produits et services

(1) Machines for printing labels; labelling machines and label printing machines; machines for printing and labeling Radio-frequency identification markers (tags); computer programs and software for operating labelling machines and label printing machines; computer printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for Radio-frequency identification markers (tags); readers and coders for intelligent labels; computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking, namely printing of signage on containers, packages and boxes and printing of labels for containers, packages and boxes; downloadable computer programs and software for industrial marking, namely printing of signage on containers, packages and boxes and printing of labels for containers, packages and boxes; inking ribbons for computer printers; paper labels for printers (1) Providing temporary use of non-downloadable computer software for sign printing, label printing and label application for industrial or commercial purposes

Produits et services

Machines for printing labels; apparatus and machines for mainly labeling but also for printing labels; Labeling machines [other than for office use]; machines for printing and labeling Radio-frequency identification markers (tags). Apparatus and machines for mainly printing but also labeling labels; computer programs and software for apparatus for industrial marking; printers, laser printers, ink jet printers, thermal printers and heat transfer printing machines, all for industrial or commercial purposes; readers and coders for Radio-frequency identification markers (tags); readers and coders for intelligent labels; Computer programs and software for label printing and label application for industrial or commercial purposes; computer programs and software for industrial marking; computer programs and software communicating with industrial marking apparatus; downloadable computer programs and software for industrial marking; downloadable computer programs and software communicating with industrial marking apparatus. Ribbons for printers for industrial or commercial purposes; labels [not made of textile] for printers for industrial or commercial purposes.

Produits et services

Printing machines for commercial or industrial use; electronic label printing machines for commercial use; automatic industrial labeling machines for applying labels to containers and bottles Computer hardware, computer programs and software for printing machines; computer hardware, computer programs and software for labeling; computer hardware, computer programs and software used to design, print and apply labels; downloadable computer programs and software used to design, print and apply labels
