A storage system (1) comprises at least two hang standards (2), which are arranged vertically at a fixed distance from one another Brackets (4) are configured to be arranged on the respective hang standards (2), for arranging supports for articles (4, 5, 8). The system (1) comprises at least one elongated light fitting rod (6), with at least one light source (13), and two ends (14). The rod (6) is telescopic and configured to be arranged horizontally between the hang standards (2). It may be resiliently compressed against a spring force from a maximum length to a minimum length. A light fitting rod (6) for a storage system (1), is elongated with two ends (14) and has at least one light source (13). The light fitting rod (6) is telescopic and may be resiliently compressed against a spring force from a maximum length to a minimum length.
A kit (1, 3, 5) for assembling a sheet metal drawer (51) in a storage system is disclosed, comprising a sheet metal front part (1 ) making up the front wall, a sheet metal rear part (3), making up the rear wall and a sheet metal mid part (5), extending between the rear and front parts. The mid part (5) has a flat main surface (7) formed in one piece of sheet metal and has first (9) and second (11) straight lines of perforations. Folding the main surface (7) upwards to 90 degrees along the lines of perforations (9, 11) form a bottom piece (13) and right (15) and left (17) side walls of the metal drawer. The front (1) and rear (3) parts are configured to connect to the front (19) and rear (21) edges of the bottom piece (13) as well as of said right and left side walls.
A shoe rack (1) in a storage system comprises an extendable, rectangular frame (3) with at least one shoe shelf (2) Each shoe shelf (2) is mounted on the extendable, rectangular frame (3), and is adapted to extend between two opposite sides of the extendable, rectangular frame (3) in a selectable position. A shoe shelf (2) for use in a shoe rack (1) comprises a rectangular panel (5), with two longer and two shorter sides. The shelf (2) is designed to be held at an angle and support one or more pairs of shoes. An attachment clip (4) for a shoe shelf (2) comprises an upper and a lower arm, for a snap fastening of the clip on a support and an angled seat portion for a shoe shelf (2).
A pants rack (1) in a storage system comprises an extendable, rectangular frame (3) with sliders. The pants rack (1) is configured to slide between a retraced position and an extended position and comprises at least one pants hanger (2). Each pants hanger (2) is mounted on the extendable, rectangular frame (3) and comprises a rod (5), which is adapted to extend between two opposite sides of the extendable, rectangular frame (3) in a selectable position. A pants hanger (2) for use in a pants rack (1) comprises a rod (5), and further comprises an attachment clip (4, 4a, 4b) at at least one end of the rod (5). An attachment clip (4, 4a, 4b) for a pants hanger comprises an upper (7a, 7b) and a lower (8, 11) arm for a snap fastening of the clip (4, 4a, 4b) on a support.
A main hang standard (3) is configured to be mounted vertically on a wall The hang standard has a generally U-shaped cross section with a front portion (21, 27) with rows of slots, and legs (23, 29) extending rearwardly towards the wall from the front portion, forming a free space (25) behind the front portion. There is provided an extension hang standard (33) having a corresponding cross section and rows of slots as the main hang standard (3), and an extension connector (35), configured to fit inside said free space (25). The extension connector (35) is elongated with a U- shaped cross section, having a rear portion (37) and forwards extending legs (39), extending from the rear portion (37), and first and second nut portions (41, 43) fixedly connected to the rear portion (37) and adapted to connect with screws (45, 47) extending through holes (49, 51) in the hang standards.
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
6.
MESH CONTAINER AND METHOD FOR PRODUCING A MESH CONTAINER
A mesh container two sets of opposing sides, a bottom, and a rim extending outwardly from the top of the sides is folded from one or more precursors cut from a web comprising a mesh portion formed by perforating and stretching part of a sheet and an unstretched portion. Each precursor is single piece that is folded into at least two side panels made at least partly of mesh and a portion of the outwardly extending rim made of the unstretched portion of the web. One or more portions for a bottom panel may be included with the two side panels, the bottom of the container being formed by folding the bottom panel portions away for the side panels to form an overlapping joint with each other.
B65D 6/08 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement de structure à claire voie ou analogue, p. ex. réalisés en matériau flexible entrelacé ou tressé
7.
PLASTIC SHELF TRIM COMPRISING A FILLER AND A STORAGE SYSTEM COMPRISING THE SHELF TRIM
The present disclosure relates to a shelf trim 5 for a wire shelf 3, the shelf trim com- prising a plastic material with an inorganic filler and being elongated to a length L to fit on the front of a wire shelf 3. The shelf trim has a first cross section 24, along most of said length having a horizontal section 23 presenting a top surface 25 and, under the top surface, a downward facing groove 33 configured to accommodate a first wire 17 of a wire shelf. A vertical section 29 extends downwards from the front of the horizontal section 23 and presents a front surface 31. The shelf trim further has a second cross section 26, at a plurality of locations along the length, where projec- tions 35, 37 extend downwards from lower side of the horizontal section 23 on both sides of the downward facing groove 33. The distance d between the projections closing downwards, thereby providing an opening 39 therebetween that is narrower than the maximum width of the groove 33. This provides a snap fit function when the shelf trim 5 is attached to a wire shelf 3 and allows the shelf trim to be made in one piece by injection moulding.
A47F 5/00 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure
A47B 47/04 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés principalement en bois ou en matière plastique
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
A47B 96/20 - Panneaux de meubles ou éléments de meubles similaires
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
8.
SHEET METAL FITTING FOR MOUNTING IN A BEAM STRUCTURE COMPRISING FLAT ARMS EXTENDING MUTUALLY PERPENDICULARLY IN A SINGLE PLANE
A fitting, for mounting in a beam structure, comprises a first and a second flat arm, which are arranged to extend mutually perpendicularly in a single plane. A cabinet structure comprises a top panel (6), a bottom panel (7), and two side panels (8), of a sheet metal. Each of the panels (6, 7, 8) comprises at least one beam structure at an edge area of the panel (6, 7, 8). The beam structure is formed by at least one bend in the sheet metal along an edge of the panel (6, 7, 8). A cabinet (1) comprises the cabinet structure, a back panel (9), and a door (2). A method for assembling the cabinet structure with at least one fitting, comprises the steps of inserting the fitting into at least two beam structures, aligning bores in the fitting with bores in the beam structures, and securing the beam structures and the fitting with a screw through the bores.
The present disclosure relates to a back panel holder 13 for a storage system 1. The storage system includes first and second hang standards 3, 5, which are arranged vertically on a wall. The back panel 13 holder comprises a first hang standard connector 15, configured to connect with the first hang standard 3, and a second hang standard connector 17, configured to connect with the second hang standard 5. An intermediate portion 19 spanning between the first and second hang standard connectors 15, 17 and comprises a ledge 21 on which a back panel 9 may rest.
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47F 5/10 - Stands d'étalages réglables ou pliants
A47B 47/02 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés uniquement en métal
The disclosure relates to an implement holder (1 ) adapted for attachment to a suspension bar (3), wherein the suspension bar (3) comprises a rail (5) comprising a rear surface (4) configured to be arranged horizontally on a vertical surface, such as a wall or similar, a lower flange (7) and an upper flange (9), each flange (7, 9) having portions that are directed obliquely upwards when the rail (5) is attached to the vertical surface. The implement holder (1 ) comprises a holding element (11 ) for suspending an implement, such as a tool, a piece of garden or sport equipment or another object, and a fastening device (13) which enables the holding element (11 ) to be releasably attached to the suspension bar (3). The fastening device (13) comprises an interface (15), comprising a suspension slot (23) and a mounting slot (25) for retaining engagement with the lower flange (7) and the upper flange (9) of the suspension bar (3), and a locking device (17) comprising a latch element 27 configured to be moved between a locked mode (LM) and an opened mode (OM. The latch element (27) secures the lower flange (7) of the suspension bar (3) in the suspension slot (23) when in locked mode (LM).
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
The present disclosure relates to a frame (1, 3) for a storage system, the frame has a generally rectangular configuration with an open inner area (5) for taking up and carrying a container and lateral connection means (11) for connecting to a canti- levered bracket via a slider unit. The frame has a first part (1), comprising a rear leg (7) bent to form two lateral legs (9A, 9B) comprising the connection means and front end portions (21), and a second part (3) comprising a front bar, attached to said front end portions (21), wherein said first part (1) is formed from an elongated strip of metal comprising upper and lower flanges (13, 15) bent about the elongated axis of the strip and out of the plane of the strip to form an outwardly open channel (17) in the lateral legs.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Metal building materials; small items of metal hardware;
fittings of metal for building and furniture; knobs of
metal; clothes hooks of metal; rails of metal; door frames
and door panels of metal; sliding doors of metal; metal
frames for sliding doors; furniture casters of metal; metal
wires, metal wire netting, rail, brackets, standards,
drawers, boxes, baskets, hooks, all of metal, constituting
components in storing equipment. Building materials (non-metallic); doors, door panels and
door frames, not of metal; cornices, not of metal; wood
panelling; cask wood; folding doors (not of metal); sliding
doors (not of metal). Furniture; mirrors; doors for furniture; lockers; coat
hangers; furniture shelves; edgings of plastic for
furniture; clothes hooks, not of metal; cases of wood and
plastic; furniture casters, not of metal; furniture
partitions of wood; furniture fittings, not of metal;
cupboard; wardrobes; sliding door wardrobes; interior
fittings; shelves; baskets, not of metal; trays, not of
metal; racks; shelf fittings; sliding doors for wardrobes
and cupboards. Retail services in relation to furnishings. Interior decoration consultation; providing information in
the field of interior design via a website; draughtsman's
services; planning and design of storage spaces and storage
solutions.
The present disclosure relates to a mesh container (43, 45) in mesh material (1), comprising expanded sheet metal, the container having a first and a second set of opposing side panels (42, 44), a bottom panel (46), and a flange (48) directed out- wards from the upper edges of the side panels (42, 44). The container is formed in a method including perforating and expanding a web (10) of sheet metal along an expansion direction (3) to form the mesh material (1 ), cutting, from rectangular pieces of the web, at least a first and a second leading precursor (A, C) from the leading part of the web, exiting the perforating and expanding step first, and a first and a second trailing precursor (B, D) from a trailing part of the web, wherein the leading and trailing edges of the rectangular piece are configured each to form an upper edge of a container; and forming a container including either leading precursors of two rectangular pieces or the trailing precursors of two rectangular pieces.
B65D 6/08 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement de structure à claire voie ou analogue, p. ex. réalisés en matériau flexible entrelacé ou tressé
B21D 31/04 - Opérations pour dilater le matériau non prévues dans les groupes , p. ex. pour obtenir du métal déployé
14.
Hang standard and storage system including the hang standard
A hang standard, for mounting vertically and connecting with cantilevered brackets, is elongated and has an approximately U-shaped cross-section with a front portion and two rearwards extending leg portions. The front portion comprises a plurality of slots located in a recess between first and second protruding portions, which are located on first and second side of the slots. The recess is laterally continuous from the first to the second protruding portion and over two columns of slots.
The present disclosure relates to a storage system comprising a container (5), defining a storage space (9) and a circumferential flange (11), which is adapted to rest on a frame or in a rack. The container (5) comprises a mesh material formed by expanding a sheet metal web, the mesh material forming a bottom panel (13) and two opposing pairs (15, 17) of side panels, the mesh material further forming the circumferential flange (11) by extending continuously from each side panel into a flange portion.
The present disclosure relates to a storage device (1) comprising a rectangular frame (3) and a sheet metal component (5), connected to, and suspended therefrom, the sheet metal component being cut and expanded such that a mesh material (41) is formed. The frame (3) has a cross section in the form of an inverted U, comprising an upper, substantially horizontal section (21), as well as inner (23) and outer (25) legs extending downwards from the horizontal section. The inner leg (23) extends further downwards than the outer leg (25), and the sheet metal component (5, 33), is connected to the outer side (27) of the inner leg such that the edge (29) of the sheet metal component (5, 33) is located above the lower end (31) of the outer leg (25).
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Metal building materials; small items of metal hardware; fittings of metal for building and furniture; knobs of metal; clothes hooks of metal; rails of metal; door frames and door panels of metal; sliding doors of metal; metal frames for sliding doors; furniture casters of metal; metal wires, metal wire netting, rail, brackets, standards, drawers, boxes, baskets, hooks, all of metal, constituting components in storing equipment.. Building materials (non-metallic); doors, door panels and door frames, not of metal; cornices, not of metal; wood panelling; cask wood; folding doors (not of metal); sliding doors (not of metal).. Furniture; mirrors; doors for furniture; lockers; coat hangers; furniture shelves; edgings of plastic for furniture; clothes hooks, not of metal; cases of wood and plastic; furniture casters, not of metal; furniture partitions of wood; furniture fittings, not of metal; cupboard; wardrobes; sliding door wardrobes; interior fittings; shelves; baskets, not of metal; trays, not of metal; racks; shelf fittings; sliding doors for wardrobes and cupboards.. Retail services in relation to furnishings.. Interior decoration consultation; providing information in the field of interior design via a website; draughtsman's services; planning and design of storage spaces and storage solutions..
The present disclosure relates to a suspension system with a rear rail, configured to be arranged on a wall or the like, and a hang standard with rear leg portions comprising suspension slots arranged in each of the leg portions and being configured to connect with the lower flange of the rear rail. The rear rail further comprises an upper flange, and each of the hang standard leg portions comprise a mounting slot adapted to connect with the upper flange of the rear rail. The upper and lower flanges at least partially extend in different directions.
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
In a wall-mounted shelving and/or storage system, vertical standards are mounted to a wall using a plurality of individual cleats arranged in vertical columns and horizontal rows. The width of each cleat is smaller than the width of the standard, so that it can be hidden within the standard when mounted. Formed on the back of each vertical standard are a plurality of transverse edges at predefined intervals, in known spatial relationships with bracket connection points, for cooperating with the cleats to properly position and orient the standards at the correct height with respect to each other.
A47B 47/02 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés uniquement en métal
A47B 57/34 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en rebords, montants ou pieds-droits à rainures ou à encoches les parties rainurées ou encochées constituant les pieds-droits ou les montants eux-mêmes
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
A47F 5/10 - Stands d'étalages réglables ou pliants
The present disclosure relates to a mesh container and a method of making a mesh container that has a first and a second set of opposing side panels, a bottom panel, and a rim directed outwards from the upper edges of the side panels. At least two adjacent sides panels of the container and portion of the rim directed outwardly from the upper edge of the side panels are made from a sheet metal precursor with least one perforated and a stretched portion and unstretched metal portion. The precursor is folded so that the unstretched metal portion joins the two side panels and is bent to form the rim. A notch is cut from the edge of the unstretched metal portion where it is bent at the corner formed by the two side panels.
B65D 6/08 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement de structure à claire voie ou analogue, p. ex. réalisés en matériau flexible entrelacé ou tressé
Rails, tracks; brackets; standards; hooks; rods, racks,
hangers, stands; all foregoing of metal constituting
components in storing equipment; fittings of metal for
storing equipment; shelf supports of metal [other than parts
of furniture]; baskets of metal. Small wooden or plastic details being parts of or components
used in storing equipment; shelves for storage; crates,
drawers, baskets, not of metal; containers of non-metallic
materials for storing of goods; mirrors; wardrobes and
wardrobe interior fittings.
24.
Cantilevered bracket for a cantilevered storage system
A shelf storage system includes hang standards with slots arranged in rows, brackets connectable to the slots to suspend them in a cantilevered manner from the hang standards, and shelves adapted to be supported by brackets when suspended on spaced-apart hang standards. On the bottom side of a shelf are connectors at fixed locations for connecting the shelf to brackets when spaced a predetermined bracket-to-bracket distance apart. The hang standards have a plurality screw holes to connect the hang standard vertically on a vertical surface, such as a wall. The distance between at least two such screw holes corresponds to the predetermined bracket-to-bracket distance. To mark locations to install hang standards with proper spacing for brackets suspended from them to connect with the shelf, one of the hang standards is placed horizontally on the vertical surface to mark locations for the hang standards using the screw holes, thus simplifying installation of the system.
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A storage system comprises a shelf (5) supported by a cantilevered bracket (4) and a connector element (6), connecting the bracket (4) with the shelf (5). The bracket (4) has a U-shaped cross-section. The connector element (6) comprises an insert (9), which is arranged inside the U-shaped cross-section of the bracket (4) and a dowel (10), which extends from the insert (9) into the shelf (5).
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
Apparatus and methods for supporting an extendable and retractable storage component between two cantilevered brackets of a storage or organization system, to which have been mounted drawer slides. A hanging bracket, to which a drawer slide may be joined, is suspended from one side of a cantilevered bracket by a connector that cooperates with a ledge projecting from the side of the cantilevered bracket to position and orient the drawer slide to extend in a direction parallel to the axis of the cantilevered bracket. Spacers mounted on the drawer slide engage the underside of the ledge and the side of the hanging bracket help to stabilize the hanging bracket by interfering with movement of the drawer slide associated with swinging and pivoting of the hanging bracket about it axes parallel and transverse to the axis of the cantilevered bracket that extending through the connector.
Rails, tracks; brackets; standards; hooks; rods, racks, hangers, stands; all foregoing of metal constituting components in storing equipment; fittings of metal for storing equipment; shelf supports of metal [other than parts of furniture]; baskets of metal. Small wooden or plastic details being parts of or components used in storing equipment; shelves for storage; crates, drawers, baskets, not of metal; containers of non-metallic materials for storing of goods; mirrors; wardrobes and wardrobe interior fittings.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
35 - Publicité; Affaires commerciales
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
Metal shelf brackets; hardware, namely, metal brackets for
general use; metal brackets used in the construction and
assembly of shelving; metal hardware used for assembly of
storage racks, namely, metal shelf pins for securing a shelf
to a shelf bracket; metal washers, metal nuts, metal rivets,
metal screws, metal nails, and anchors; metal boxes; baskets
of common metals; metal hooks; wire mesh; metal standards
for securing shelving mounted to a wall; metal tracks for
securing shelving mounted to a wall. Furniture fittings, not of metal; wardrobes; cabinets;
shelves; drawers for furniture; storage racks; shoe racks;
shelf brackets not of metal; ventilated wire shelving and
drawer systems comprised of wood and metal gliding frames
and drawers being furniture parts; gliding and fixed storage
racks made from epoxy coated metal and wood; shelving made
from epoxy coated metal, wood veneer and laminate; shelving
system for storage comprising molded plastic fittings,
braces and brackets for shelves made from epoxy coated metal
with molded plastic fittings; prefabricated closet
organization systems made of wood veneer, epoxy coated
metal, or laminate; drawer organizers; storage organization
system comprising of shelves and drawers sold as a unit;
drawer organizers for cosmetics and brushes; drawer inserts
being organizers and dividers; containers, not of metal for
commercial use; drawer organizers for silverware; non-metal
lock boxes. Nonmetal storage containers for household or domestic use;
trays for domestic purposes, not of metal; trays for
household purposes; household containers for storing and
organizing makeup; holders for makeup being household
containers for storing and organizing makeup; holders for
makeup brushes. Retail store services in the field of household and office
accessories, storage items, storage systems, and space
organizers; on-line retail store services in the area of
household and office accessories, storage items, storage
systems and space organizers; mail order catalog services in
the area of household and office accessories, storage items,
storage systems and space organizers; retail store services
in the field of closet, storage and organizational systems
comprising shelves, clothes rods, hampers, baskets,
cupboards, cabinets, drawers, and shoe racks; on-line retail
store services in the field of closet, storage and
organizational systems comprising shelves, clothes rods,
hampers, baskets, cupboards, cabinets, drawers, and shoe
racks; providing organization services for business
purposes, namely, organizing office spaces. Interior design services, namely, organization and space
planning services; interior design services, namely,
organization and space planning services households and
commercial businesses; closet design services. Organizational services for home or personal purposes,
namely, organizing closet, kitchen, bedroom and living
spaces.
Retail store services featuring household and closet storage and organization accessories, storage items, storage systems, and space organizers; on-line retail store services featuring household and closet storage and organization accessories, storage items, storage systems and space organizers; mail order catalog services featuring household and closet storage and organization accessories, storage items, storage systems and space organizers; retail store services featuring closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, shoe racks, folding furniture, beds, and murphy beds
42.
Three layered bands that comprise one half of a hexagon shape
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
35 - Publicité; Affaires commerciales
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
(1) Metal shelf brackets; hardware, namely, metal brackets for general use; metal brackets used in the construction and assembly of shelving; metal hardware used for assembly of storage racks, namely, metal shelf pins for securing a shelf to a shelf bracket; metal washers, metal nuts, metal rivets, metal screws, metal nails, and anchors; boxes of common metal; baskets of common metal, namely, metal storage baskets for household use and for industrial and household transportation and storage purposes; hung metal hooks for clothes, bags, towels and for hanging home accessories and parts and fittings therefor; wire mesh; metal standards for securing shelving mounted to a wall; metal tracks for securing shelving mounted to a wall.
(2) Furniture fittings, not of metal; wardrobes; non-metal and plastic storage cabinets; shelves; drawers for furniture; storage racks; shoe racks; shelf brackets not of metal; ventilated wire shelving and drawer systems comprised of wood and metal gliding frames and drawers being furniture parts; gliding and fixed storage racks made from epoxy coated metal and wood; shelving made from epoxy coated metal, wood veneer and laminate; shelving system for storage comprising molded plastic fittings, braces and brackets for shelves made from epoxy coated metal with molded plastic fittings; prefabricated closet organization systems made of wood veneer, epoxy coated metal, or laminate; drawer organizers; storage organization system comprising of shelves and drawers sold as a unit; drawer organizers for cosmetics and brushes; drawer inserts being organizers and dividers; general purpose storage containers, not of metal; drawer organizers for silverware; non-metal lock boxes.
(3) Nonmetal storage containers for household or domestic use; trays for domestic purposes, not of metal; trays for household purposes; household containers for storing and organizing makeup; holders for makeup being household containers for storing and organizing makeup; holders for makeup brushes. (1) Retail store services in the field of household and office accessories, storage items, storage systems, and space organizers comprising shelves, boxes, hooks, clothes rods, hampers, baskets, cupboards, cabinets, drawers, shelving and shoe racks and parts therefor; on-line retail store services in the area of household and office accessories, storage items, storage systems and space organizers comprising shelves, boxes, hooks, clothes rods, hampers, baskets, cupboards, cabinets, drawers, shelving and shoe racks and parts therefor; mail order catalog services in the area of household and office accessories, storage items, storage systems and space organizers comprising shelves, boxes, hooks, clothes rods, hampers, baskets, cupboards, cabinets, drawers, shelving and shoe racks and parts therefor; retail store services in the field of closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks; on-line retail store services in the field of closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks; providing organization services for business purposes, namely, organizing office spaces.
(2) Interior design services, namely, organization and space planning services; interior design services, namely, organization and space planning services households and commercial businesses; closet design services.
(3) Organizational services for home or personal purposes, namely, organizing closet, kitchen, bedroom and living spaces.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Metal building materials; small items of metal hardware;
fittings of metal for building and furniture; knobs of
metal; clothes hooks of metal; rails of metal; doors frames
and door panels of metal; sliding doors of metal; metal
frames for sliding doors; furniture casters of metal; metal
wires, metal wire netting, rail, brackets, crates and trays
of metal, drawers of metal, boxes, baskets, hooks, all of
metal, constituting components in storing equipment. Building materials (non-metallic); doors, doors panels and
door frames, not of metal; cornices, not of metal; wood
panelling; cask wood; folding doors (not of metal); sliding
doors (not of metal). Furniture; mirrors; doors for furniture; lockers; coat
hangers; furniture shelves; edgings of plastic for
furniture; clothes hooks, not of metal; cases of wood and
plastic; furniture casters, not of metal; furniture
partitions of wood; furniture fittings, not of metal;
cupboard; wardrobes; sliding door wardrobes; furniture
fittings, not of metal; door fittings, not of metal;
fittings (non-metallic -) for cabinets; fittings
(non-metallic -) for cupboards; non-metal door fittings;
shelves; baskets, not of metal; trays, not of metal; racks;
shelf fittings; sliding doors for wardrobes and cupboards. Retail services in relation to furnishings. Interior decoration consultation; providing information in
the field of interior design via a website; draughtsman's
services; planning and design of storage spaces and storage
solutions.
44.
Storage components for a configurable storage system
A storage system in which storage components are connected in a cantilevered fashion to vertical standard uses thin cantilevered brackets support storage components. Despite the tendency of such brackets to swing when attached to the vertical standard, the cantilevered brackets are constructed and support the storage components in a sturdy and aesthetically pleasing manner. A thin cantilevered bracket made from a single, flat piece of metal oriented vertically and projecting from a connection interface includes a ledge extending from its side surface below a top edge of the bracket to support one end of a shelf or other planar member forming a storage component. A thin cantilevered bracket with an offset projection that attaches to an inside surface of a side panel of an enclosure that allows the side panel to align with the bracket connection interface.
A47B 47/02 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés uniquement en métal
A47B 57/34 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en rebords, montants ou pieds-droits à rainures ou à encoches les parties rainurées ou encochées constituant les pieds-droits ou les montants eux-mêmes
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
A47F 5/10 - Stands d'étalages réglables ou pliants
Closet, storage and organizational systems comprising shelves, clothes rods, baskets, drawers, cabinets, shoe racks, and laundry hampers for household use sold as unit
The present disclosure relates to a mesh container and a method of making a mesh container. The method may include perforating and expanding a web of sheet metal along an expansion direction, while leaving leading and a trailing portion of the web unstretched with an intervening stretched portion. Then, the web is cut across the intervening stretched portion to form a first and a second container precursor. A first container is formed from the first container precursor wherein the leading unstretched portion forms the rim of the first container, and correspondingly a second container is formed from the second container precursor wherein the trailing unstretched portion forms the rim of the second container.
B65D 6/08 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement de structure à claire voie ou analogue, p. ex. réalisés en matériau flexible entrelacé ou tressé
A mesh container two sets of opposing sides, a bottom, and a rim extending outwardly from the top of the sides is folded from one or more precursors cut from a web comprising a mesh portion formed by perforating and stretching part of a sheet and an unstretched portion. Each precursor is single piece that is folded into at least two side panels made at least partly of mesh and a portion of the outwardly extending rim made of the unstretched portion of the web. One or more portions for a bottom panel may be included with the two side panels, the bottom of the container being formed by folding the bottom panel portions away for the side panels to form an overlapping joint with each other.
B65D 6/08 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement de structure à claire voie ou analogue, p. ex. réalisés en matériau flexible entrelacé ou tressé
The present disclosure relates to a suspension system with a rear rail, configured to be arranged on a wall or the like, and a hang standard with rear leg portions comprising suspension slots arranged in each of the leg portions and being configured to connect with the lower flange of the rear rail. The rear rail further comprises an upper flange, and each of the hang standard leg portions comprise a mounting slot adapted to connect with the upper flange of the rear rail. The upper and lower flanges at least partially extend in different directions.
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
50.
SUSPENSION SYSTEM COMPRISING A REAR RAIL ARRANGED WITH FLANGES AT LEAST PARTIALLY EXTENDING IN DIFFERENT DIRECTIONS AND A HANGSTANDARD ARRANGABLE THERETO
The present disclosure relates to a suspension system with a rear rail 3, configured to be arranged on a wall or the like, and a hang standard 1 with rear leg portion 15 comprising suspension slots 17 arranged in each of the leg portions and being configured to connect with the lower flange of the rear rail. The rear rail further comprises an upper flange, and each of the hang standard leg portions comprise a mounting slot 19 adapted to connect with the upper flange of the rear rail. The upper and lower flanges at least partially extend in different directions.
A hang standard (1, 1a), for mounting vertically and connecting with cantilevered brackets (11), is elongated and has an approximately U-shaped cross- section with a front portion (2, 2a) and two rearwards extending leg portions (3, 3a). The front portion (2, 2a) comprises a plurality of slots (4, 4a) located in a recess (5, 5a) between first and second protruding portions (6, 6a), which are located on first and second side of the slots (4, 4a). The recess (5, 5a) is laterally continuous from the first to the second protruding portion (6, 6a) and over two columns of slots (4, 4a). In some embodiments there is a transition portion (7, 7a) which extends into a protruding portion (6, 6a) with an outer lateral wall (19, 19a) facing away from the front portion (2, 2a) and an inner lateral (20, 20a) wall facing towards the front portion (2, 2a), and the outer (19, 19a) and inner (20, 20a) lateral walls together comprise a double layer of sheet metal. A storage system includes a plurality of hang standards (1, 1a), mounting means, brackets (11), and storage means supported by the brackets (11).
A hang standard, for mounting vertically and connecting with cantilevered brackets, is elongated and has an approximately U-shaped cross-section with a front portion and two rearwards extending leg portions. The front portion comprises a plurality of slots located in a recess between first and second protruding portions, which are located on first and second side of the slots. The recess is laterally continuous from the first to the second protruding portion and over two columns of slots.
Retail store services in the field of household and office accessories, storage items, storage systems, and space organizers; on-line retail store services in the area of household and office accessories, storage items, storage systems and space organizers; mail order catalog services in the area of household and office accessories, storage items, storage systems and space organizers; retail store services in the field of closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks; on-line retail store services in the field of closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks; providing organization services for business purposes, namely, organizing office spaces
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
35 - Publicité; Affaires commerciales
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
metal shelf brackets; hardware, namely, metal brackets for general use; metal brackets used in the construction and assembly of shelving; metal hardware used for assembly of storage racks, namely, metal shelf pins for securing a shelf to a shelf bracket; metal washers, metal nuts, metal rivets, metal screws, metal nails, and anchors; metal boxes; baskets of common metals; metal hooks; wire mesh; metal standards for securing shelving mounted to a wall; metal tracks for securing shelving mounted to a wall; non-metal lock boxes furniture fittings, not of metal; wardrobes; cabinets; shelves; drawers for furniture; storage racks; shoe racks; shelf brackets not of metal; ventilated wire shelving and drawer systems comprised of wood and metal gliding frames and drawers being furniture parts; gliding and fixed storage racks made from epoxy coated metal and wood; shelving made from epoxy coated metal, wood veneer and laminate; shelving system for storage comprising molded plastic fittings, braces and brackets for shelves made from epoxy coated metal with molded plastic fittings; prefabricated closet organization systems made of wood veneer, epoxy coated metal, or laminate; drawer organizers; storage organization system comprising of shelves and drawers sold as a unit; drawer organizers for cosmetics and brushes; drawer inserts being organizers and dividers; containers, not of metal for commercial use; drawer organizers for silverware nonmetal storage containers for household or domestic use; trays for domestic purposes, not of metal; trays for household purposes; household containers for storing and organizing makeup; holders for makeup being household containers for storing and organizing makeup; holders for makeup brushes Retail store services in the field of household and office accessories, storage items, storage systems, and space organizers; on-line retail store services in the area of household and office accessories, storage items, storage systems and space organizers; mail order catalog services in the area of household and office accessories, storage items, storage systems and space organizers; retail store services in the field of closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks; on-line retail store services in the field of closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks; providing organization services for business purposes, namely, organizing office spaces Interior design services, namely, organization and space planning services; interior design services, namely, organization and space planning services households and commercial businesses; closet design services Organizational services for home or personal purposes, namely, organizing closet, kitchen, bedroom and living spaces
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Drawer organizers; storage organization system comprising of shelves and drawers sold as a unit; drawer organizers for cosmetics and brushes; drawer inserts. Nonmetal storage containers for household or domestic use; trays for domestic purposes, not of metal; trays for household purposes; household containers for storing and organizing makeup; holders for makeup and makeup brushes.
56.
SUSPENSION SYSTEM AND GLIDER UNIT ARRANGED TO PREVENT TILTING
The present disclosure relates to a suspension system comprising a hang standard (1), having slots (3) and being configured to be vertically arranged, and a bracket (9), configured to be attached to the hang standard (1) in a cantilevered fashion, wherein connector features (13, 15) of the bracket (9) enter slots (3) of the hang standard (1). A slider unit (23) is adapted to be attached to the bracket (9) and to carry a container (5). A portion (27) of the slider unit (23) is arranged to reach into the same slot (3) of the hang standard (1) as a connector feature of the bracket (9), to prevent the slider unit from tilting forward.
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
The present disclosure relates to a suspension system comprising a hang standard having slots and being configured to be vertically arranged, and a bracket configured to be attached to the hang standard in a cantilevered fashion using connectors on a proximal end of the bracket that enter slots on along the hang standard. A slider unit is adapted to be mounted on the bracket and to carry a container or other component. A rearwardly extending portion of the slider unit is arranged on the slider unit to reach into one of the slots of the hang standard occupied by a connector of the bracket to prevent the slider unit from tilting forward on the bracket.
A47B 88/40 - Tiroirs coulissantsGlissières ou guides pour ceux-ci
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 88/423 - Dispositifs de fixation pour glissières ou guides
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
A47B 96/07 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons réglables en eux-mêmes
F16M 13/02 - Autres supports ou appuis pour positionner les appareils ou les objetsMoyens pour maintenir en position les appareils ou objets tenus à la main pour être portés par un autre objet ou lui être fixé, p. ex. à un arbre, une grille, un châssis de fenêtre, une bicyclette
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Metal building materials; small items of metal hardware; fittings of metal for building and furniture; knobs of metal; clothes hooks of metal; rails of metal; doors frames and door panels of metal; sliding doors of metal; metal frames for sliding doors; furniture casters of metal; metal wires, metal wire netting, rail, brackets, standards, drawers, boxes, baskets, hooks, all of metal, constituting components in storing equipment. Building materials (non-metallic); doors, doors panels and door frames, not of metal; cornices, not of metal; wood panelling; cask wood; folding doors (not of metal); sliding doors (not of metal). Furniture; mirrors; doors for furniture; lockers; coat hangers; furniture shelves; edgings of plastic for furniture; clothes hooks, not of metal; cases of wood and plastic; furniture casters, not of metal; furniture partitions of wood; furniture fittings, not of metal; cupboard; wardrobes; sliding door wardrobes; interior fittings; shelves; baskets, not of metal; trays, not of metal; racks; shelf fittings; sliding doors for wardrobes and cupboards. Retail services in relation to furnishings. Interior decoration consultation; providing information in the field of interior design via a website; draughtsman's services; planning and design of storage spaces and storage solutions.
The present disclosure relates to a shelf storage system 1 comprising hang standards 3 with slots 5 arranged in rows therein, brackets 7 comprising connector means 9 for connecting with hang standard slots 5 such that bracket becomes suspended thereby in a cantilevered manner, and shelves 11 adapted to rest on the brackets 7. The shelf 11 comprises on its bottom side at least first and second bracket connecting means, which are adapted to connect with brackets and are mutually spaced apart with a predetermined bracket distance d. The hang standard comprises a plurality screw holes for connecting the hang standard oriented vertically to a wall or the like, and the distance between at least two such screw holes corresponds to said bracket distance. This allows using a hang standard to mark locations for other hang standards, which simplifies assembling of the shelf system.
A storage system comprises a shelf (5) supported by a cantilevered bracket (4) and a connector element (6), connecting the bracket (4) with the shelf (5). The bracket (4) has a U-shaped cross-section. The connector element (6) comprises an insert (9), which is arranged inside the U-shaped cross-section of the bracket (4) and a dowel (10), which extends from the insert (9) into the shelf (5).
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
F16B 12/10 - Jointure des meubles ou objets similaires, p. ex. masquée de l'extérieur par chevilles, boulons, tenons, brides, clips ou dispositifs similaires
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
drawer organizers; storage organization system comprising of shelves and drawers sold as a unit; drawer organizers for cosmetics and brushes; drawer inserts in the nature of dividers and organizers nonmetal storage containers for household or domestic use; trays for domestic purposes, not of metal; trays for household purposes; household containers for storing and organizing makeup; holders for makeup in the nature of household containers for storing and organizing makeup; holder for makeup brushes
Apparatus and methods for supporting an extendable and retractable storage component between two cantilevered brackets of a storage or organization system, to which have been mounted drawer slides. A hanging bracket, to which a drawer slide may be joined, is suspended from one side of a cantilevered bracket by a connector that cooperates with a ledge projecting from the side of the cantilevered bracket to position and orient the drawer slide to extend in a direction parallel to the axis of the cantilevered bracket. Spacers mounted on the drawer slide engage the underside of the ledge and the side of the hanging bracket help to stabilize the hanging bracket by interfering with movement of the drawer slide associated with swinging and pivoting of the hanging bracket about it axes parallel and transverse to the axis of the cantilevered bracket that extending through the connector.
In a wall-mounted shelving and/or storage system, vertical standards are mounted to a wall using a plurality of individual cleats arranged in vertical columns and horizontal rows. The width of each cleat is smaller than the width of the standard, so that it can be hidden within the standard when mounted. Formed on the back of each vertical standard are a plurality of transverse edges at predefined intervals, in known spatial relationships with bracket connection points, for cooperating with the cleats to properly position and orient the standards at the correct height with respect to each other.
A47B 47/02 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés uniquement en métal
A47B 57/34 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en rebords, montants ou pieds-droits à rainures ou à encoches les parties rainurées ou encochées constituant les pieds-droits ou les montants eux-mêmes
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
A47F 5/10 - Stands d'étalages réglables ou pliants
The present disclosure relates to a panel for dividing the interior space of a container. The panel arrangement (1) has a panel (11) provided with an attachment device (17) adapted to affix the panel in relation the container. There is provided at least one opening in the panel, and the attachment device comprises first and second parts (29, 31) located at a respective side of the panel as well as at least one member (39, 41) reaching through the at least one opening (23). A play (49) is provided between the edges of the opening and said at least one member, such that the attachment device can be moved in at least one direction in which the plane of the panel extends.
B65D 6/08 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement de structure à claire voie ou analogue, p. ex. réalisés en matériau flexible entrelacé ou tressé
65.
Storage system, cover strip, and method for producing a cover strip
The present disclosure relates to a flexible cover strip for a storage system including a carrier rail (1) having a U-shaped cross section with first and second parallel rows (3, 5) of elongated substantially identical slots (7) in a front portion to accommodate a suspension element such as e.g. a bracket. The cover strip has an abutment face (17) and an exterior face (31), and a plurality of projections (19), rising from the abutment surface of the strip in first and second parallel rows matching the slots of the carrier rail, such that the cover strip can be fitted on the front portion with the projections entering the slots, and wherein at least some of the projections are provided with a snap element (27) at their distal ends, which snap elements prevent the cover strip from falling off the rail.
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47B 57/16 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des rayons consistant en crochets agissant en liaison avec des ouvertures
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 95/04 - Entrées de serruresOrnements ou similaires
A47B 47/02 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés uniquement en métal
The present disclosure relates to a shelf (1) for a storage system. The shelf is made of sheet metal and, comprises a top surface including an area with an expanded metal mesh panel. The shelf further comprises at least one unexpanded area (7) in between two expanded areas, along the length of shelf. This facilitates the attachment of reinforcement structures to the shelf which provides for a shelf capable of carrying a greater load.
In a wall-mounted shelving and/or storage system, vertical standards are mounted to a wall using a plurality of individual cleats arranged in vertical columns and horizontal rows. The width of each cleat is smaller than the width of the standard, so that it can be hidden within the standard when mounted. Formed on the back of each vertical standard are a plurality of transverse edges at predefined intervals, in known spatial relationships with bracket connection points, for cooperating with the cleats to properly position and orient the standards at the correct height with respect to each other.
A47B 88/407 - Tiroirs montés de manière réglable ou amovible
F16B 2/06 - Brides ou colliers, c.-à-d. dispositifs de fixation dont le serrage est effectué par des forces effectives autres que la résistance à la déformation inhérente au matériau dont est fait le dispositif externes c.-à-d. agissant par contraction
A47B 57/34 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en rebords, montants ou pieds-droits à rainures ou à encoches les parties rainurées ou encochées constituant les pieds-droits ou les montants eux-mêmes
69.
STORAGE COMPONENTS FOR A CONFIGURABLE STORAGE SYSTEM
A storage system in which storage components are connected in a cantilevered fashion to vertical standard uses thin cantilevered brackets support storage components. Despite the tendency of such brackets to swing when attached to the vertical standard, the cantilevered brackets are constructed and support the storage components in a sturdy and aesthetically pleasing manner. A thin cantilevered bracket made from a single, flat piece of metal oriented vertically and projecting from a connection interface includes a ledge extending from its side surface below a top edge of the bracket to support one end of a shelf or other planar member forming a storage component. A thin cantilevered bracket with an offset projection that attaches to an inside surface of a side panel of an enclosure that allows the side panel to align with the bracket connection interface.
A47B 96/06 - Tasseaux ou moyens de support analogues pour meubles à tiroirs, étagères ou rayons
A47B 57/40 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47B 57/48 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en languettes, chevilles ou moyens en saillie similaires s'engageant dans des ouvertures
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
Containers, not of metal for commercial use; Drawer organizers; Drawer organizers for silverware Trays for domestic purposes; Trays for domestic purposes, not of metal; Trays for household purposes
Metal building materials; small items of metal hardware;
fittings of metal for building and furniture; knobs of
metal; clothes hooks of metal; rails of metal; doors frames
and door panels of metal; sliding doors of metal; metal
frames for sliding doors; furniture casters of metal; metal
wires, metal wire netting, rail, brackets, supports, storage
containers, boxes, baskets, hooks, all of metal,
constituting components in storing equipment. Building materials (non-metallic); doors, doors panels and
door frames, not of metal; cornices, not of metal; wood
panelling; cask wood; folding doors (not of metal); sliding
doors (not of metal). Furniture; mirrors; doors for furniture; lockers; coat
hangers; furniture shelves; edgings of plastic for
furniture; clothes hooks, not of metal; cases of wood and
plastic; furniture casters, not of metal; furniture
partitions of wood; furniture fittings, not of metal;
cupboard; wardrobes; sliding door wardrobes; indoor
furniture and storage fitments; shelves; baskets, not of
metal; trays, not of metal; racks; shelf fittings; sliding
doors for wardrobes and cupboards.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks sold as unit; free-standing storage closets and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks, sold as a unit (1) Interior design services, namely, customized closet space planning services
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, drawers, cabinets, and shoe racks sold as unit Interior design services, namely, customized closet space planning services
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks sold as unit; free-standing storage closets and organizational systems comprising shelves, clothes rods, hampers, baskets, cupboards, cabinets, drawers, and shoe racks, sold as a unit interior design services, namely, customized closet space planning services
In a wall-mounted shelving and/or storage system, vertical standards are mounted to a wall using a plurality of individual cleats arranged in vertical columns and horizontal rows. The width of each cleat is smaller than the width of the standard, so that it can be hidden within the standard when mounted. Formed on the back of each vertical standard are a plurality of transverse edges at predefined intervals, in known spatial relationships with bracket connection points, for cooperating with the cleats to properly position and orient the standards at the correct height with respect to each other.
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47F 5/08 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure fixés aux murs, plafonds ou similairesDispositifs d'étalage en consoles murales
The present disclosure relates to a suspension system (1) comprising first and second support elements (3), configured to be vertically arranged, and first and second brackets (5), which are attached to a respective one of the support elements in a cantilevered fashion. The system further includes a frame (7, 27), with side portions (27) that are attached to a respective one of the brackets by means of fastening arrangements, such that the frame with a container attached thereto becomes slidable as a drawer. Each fastening arrangement has a mid-section attachment device including a centre cut-out (19) in the mid third of the bracket, an attachment tongue (23) on the side portion (27), which is configured to be inserted into the centre cut-out to clasp its edge, and a bulb (25) which snaps into the cut-out, and a front attachment device with a front cut-out (17) in the bracket, a front attachment tongue (31) on the side portion, which is configured to be inserted into the front cut-out to clasp its edge, and a support tongue (33) which abuts the lower art of the bracket, such that a nose portion (37) of the bracket is wedged in between the front attachment tongue and the support tongue.
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47F 5/00 - Stands d'étalage, systèmes de suspension ou rayonnages caractérisés par leurs particularités de structure
Furniture; mirrors; doors for furniture; lockers; coat hangers; furniture shelves; edgings of plastic for furniture; clothes hooks, not of metal; cases of wood and plastic; furniture casters, not of metal; furniture partitions of wood; furniture fittings, not of metal; cupboards; wardrobes; sliding door wardrobes; furniture and furnishings; shelves; baskets, not of metal; trays, not of metal; racks; shelf fittings; sliding doors for wardrobes and cupboards; closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, drawers, cabinets and shoe racks sold as unit.
81.
Storage system, cover strip, and method for producing a cover strip
The present disclosure relates to a flexible cover strip for a storage system including a carrier rail (1) having a U-shaped cross section with first and second parallel rows (3, 5) of elongated substantially identical slots (7) in a front portion to accommodate a suspension element such as e.g. a bracket. The cover strip has an abutment face (17) and an exterior face (31), and a plurality of projections (19), rising from the abutment surface of the strip in first and second parallel rows matching the slots of the carrier rail, such that the cover strip can be fitted on the front portion with the projections entering the slots, and wherein at least some of the projections are provided with a snap element (27) at their distal ends, which snap elements prevent the cover strip from falling off the rail.
A47B 96/14 - Barreaux, montants, traverses ou supports similaires pour meubles à tiroirs, tasseaux ou analogues
A47B 57/16 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des rayons consistant en crochets agissant en liaison avec des ouvertures
A47B 57/42 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des supports de rayons amovibles consistant en crochets s'engageant dans des ouvertures les supports de rayons étant en porte-à-faux
A47B 95/04 - Entrées de serruresOrnements ou similaires
A47B 47/02 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés uniquement en métal
The present disclosure relates to a shelf (1) for a storage system. The shelf is made of sheet metal and, comprises a top surface including an area with an expanded metal mesh panel. The shelf further comprises at least one unexpanded area (7) in between two expanded areas, along the length of shelf. This facilitates the attachment of reinforcement structures to the shelf which provides for a shelf capable of carrying a greater load.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, drawers, cabinets, and shoe racks sold as unit (1) Interior design services, namely, customized closet space planning services
(1) Metal shelf brackets; hardware, namely, metal brackets for general use; metal brackets used in the contraction and assembly of shelving; metal hardware used for assembly of storage racks, namely, metal shelf pins for securing a shelf to a shelf bracket; metal washers, metal nuts, metal rivets, metal screws, metal nails, and anchors; metal boxes, namely general purpose storage boxes and tins; metal wire baskets for kitchen storage, office storage, toy storage; metal clothes hooks, utility hooks for tools, towel hooks; wire mesh; metal standards for securing shelving mounted to a wall; metal tracks for securing shelving mounted to a wall
(2) Furniture fittings, not of metal; wardrobes; furniture cabinets; shelves; drawers that are furniture parts; non-metal lock boxes; storage racks; shoe racks; shelf brackets not of metal; ventilated wire shelving and drawer systems comprised of wood and metal gliding frames and drawers; gliding and fixed storage racks made from epoxy coated metal and wood; shelving made from epoxy coated metal, wood veneer and laminate; shelving system for storage comprising molded plastic fittings, braces and brackets for shelves made from epoxy coated metal with molded plastic fittings; prefabricated closet organization systems made of wood veneer, epoxy coated metal, and laminate
(1) Metal shelf brackets; hardware, namely, metal brackets for general use; metal brackets used in the contraction and assembly of shelving; metal hardware used for assembly of storage racks, namely, metal shelf pins for securing a shelf to a shelf bracket; metal washers, metal nuts, metal rivets, metal screws, metal nails, and anchors; metal boxes, namely general purpose storage boxes and tins; metal wire baskets for kitchen storage, office storage, toy storage; metal clothes hooks, utility hooks for tools, towel hooks; wire mesh; metal standards for securing shelving mounted to a wall; metal tracks for securing shelving mounted to a wall
(2) Furniture fittings, not of metal; wardrobes; furniture cabinets; shelves; drawers that are furniture parts; non-metal lock boxes; storage racks; shoe racks; shelf brackets not of metal; ventilated wire shelving and drawer systems comprised of wood and metal gliding frames and drawers; gliding and fixed storage racks made from epoxy coated metal and wood; shelving made from epoxy coated metal, wood veneer and laminate; shelving system for storage comprising molded plastic fittings, braces and brackets for shelves made from epoxy coated metal with molded plastic fittings; prefabricated closet organization systems made of wood veneer, epoxy coated metal, and laminate
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Wire of common metal; metal wire netting; brackets, metal standards for securing shelving mounted to a wall, drawers, boxes, baskets, hooks, all of metal, constituting components in storing equipment for metal shelving units; metal frames for sliding doors
(2) Interior fittings, namely fittings for metal cabinets, fittings for furniture cabinets, fittings for cabinets for display purposes and fittings for storage closets; wardrobes, cabinets, shelves, boxes of wood or plastic, wire baskets, baskets made of epoxy coated metal, organizing trays, accessory trays, storage racks, shoe racks, coat racks, shelving, shelving fittings; furniture doors, storage closet sliding door
(1) Metal shelf brackets; hardware, namely, metal brackets for general use; metal brackets used in the contraction and assembly of shelving; metal hardware used for assembly of storage racks, namely, metal shelf pins for securing a shelf to a shelf bracket; metal washers, metal nuts, metal rivets, metal screws, metal nails, and anchors; metal boxes, namely general purpose storage boxes and tins; metal wire baskets for kitchen storage, office storage, toy storage; metal clothes hooks, utility hooks for tools, towel hooks; wire mesh; metal standards for securing shelving mounted to a wall; metal tracks for securing shelving mounted to a wall
(2) Furniture fittings, not of metal; wardrobes; furniture cabinets; shelves; drawers that are furniture parts; non-metal lock boxes; storage racks; shoe racks; shelf brackets not of metal; ventilated wire shelving and drawer systems comprised of wood and metal gliding frames and drawers; gliding and fixed storage racks made from epoxy coated metal and wood; shelving made from epoxy coated metal, wood veneer and laminate; shelving system for storage comprising molded plastic fittings, braces and brackets for shelves made from epoxy coated metal with molded plastic fittings; prefabricated closet organization systems made of wood veneer, epoxy coated metal, and laminate
In a wall-mounted storage system comprising standard components, from which to assemble and install, and improved drawer. The drawer has a drawer frame with two side rails, a back, and a front, metal bracket extending between and connecting each of the two side rails, defining an opening into which an open topped container may be inserted and supported by the frame. The drawer has a drawer front having a finished outer-facing surface and an inside surface for attaching to the metal bracket, the inside surface having formed thereon a recess extending from a top edge of the drawer front to at least the top edge of the metal bracket.
Metal building materials; small items of metal hardware; fittings of metal for building and furniture; knobs of metal; clothes hooks of metal; rails of metal; doors frames and door panels of metal; sliding doors of metal; metal frames for sliding doors; furniture casters of metal; metal wires, metal wire netting, rail, brackets, standards, drawers, boxes, baskets, hooks, all of metal, constituting components in storing equipment. Building materials (non-metallic); doors, doors panels and door frames, not of metal; cornices, not of metal; wood panelling; cask wood; folding doors (not of metal); sliding doors (not of metal). Furniture; mirrors; doors for furniture; lockers; coat hangers; furniture shelves; edgings of plastic for furniture; clothes hooks, not of metal; cases of wood and plastic; furniture casters, not of metal; furniture partitions of wood; furniture fittings, not of metal; cupboard; wardrobes; sliding door wardrobes; interior fittings; shelves; baskets, not of metal; trays, not of metal; racks; shelf fittings; sliding doors for wardrobes and cupboards.
The present disclosure relates to a sliding door arrangement comprising a top rail (9) and at least one or more sliding doors (3, 5, 7) configured to be suspended from the top rail and to be slidable therein. Brackets (27), located at the ends of the top rail, comprise tongues (33) inserted into slots (25) of the top rail, and are attached to a vertical surface such as a wall besides the top rail. This provides and additional safety measure, should the top rail come loose, which prevents the doors (3, 5, 7) from falling.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
closet, storage and organizational systems comprising shelves, clothes rods, hampers, baskets, drawers, cabinets, and shoe racks sold as unit interior design services, namely, customized closet space planning services
In a wall-mounted storage system comprising standard components, from which to assemble and install, and improved drawer. The drawer has having a drawer frame with two side rails, a back, and a front, metal bracket extending between and connecting each of the two side rails, defining an opening into which an open topped container may be inserted and supported by the frame. The drawer has a drawer front having a finished outer-facing surface and an inside surface for attaching to the metal bracket, the inside surface having formed thereon a recess extending from a top edge of the drawer front to at least the top edge of the metal bracket.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
retail store services featuring household accessories, storage items, storage systems and space organizers [ providing temporary use of a non-downloadable web application that enables users to consult with specialists in the area of interior design services, namely, space planning and organization services; provide in-store interior design services, namely, space planning and organization services ]
The present disclosure relates to a panel for dividing the interior space of a container. The panel arrangement (1) has a panel (11) provided with an attachment device (17) adapted to affix the panel in relation the container. There is provided at least one opening in the panel, and the attachment device comprises first and second parts (29, 31) located at a respective side of the panel as well as at least one member (39, 41) reaching through the at least one opening (23). A play (49) is provided between the edges of the opening and said at least one member, such that the attachment device can be moved in at least one direction in which the plane of the panel extends.
The present disclosure relates to a cabinet adapted to be suspended from vertically oriented carrier elements (11, 13), provided with slots (15). The cabinet has a top (3) and bottom panels (5), as well as first and second side panels (7,9). The side panels comprise rear connector elements (31) for connecting to carrier element slots at the rear of the cabinet, and the top panel comprise connector elements (33) connecting the front corners of the top panel to the front end of a side panel. Thereby a cabinet can be readily assembled by an end user.
A47B 47/00 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés
A47B 47/02 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de les démonter ou de les monter à partir d'éléments séparés uniquement en métal
E05D 15/06 - Suspensions pour battants pour battants coulissant horizontalement sensiblement dans leur propre plan
A47B 57/16 - Meubles à tiroirs, étagères ou rayonnages caractérisés par la possibilité de régler les rayons ou les cloisons comprenant des moyens pour régler la hauteur des rayons consistant en crochets agissant en liaison avec des ouvertures
