A golf club head comprises a sole, a recessed sole port in the sole; and a rotatably adjustable sole piece adapted to be at least partially received within the sole port and comprising a central body having a plurality of contact surfaces adapted to contact the sole port and being offset from each other along a central axis extending through the central body of the sole piece. The sole piece can be positioned at least partially within the sole port at five or more rotational and axial positions with respect to the central axis, wherein at each rotational position, at least one of said contact surfaces of the central body contacts the sole port to set the axial position of the sole piece. The sole port and/or the sole piece can be generally pentagonal in shape.
Golf club heads include white diffusing top surfaces to aid in club head alignment. Wood type club heads also include a dark diffusing club face so that a crown/face border is emphasized. Scorelines in wood type clubs can be provided with an intermediate contrast surface, and can be displaced from club face center to accommodate player perception when confronted with a white diffusing crown. Putter heads can include dark diffusing alignment lines, and iron-type club heads can include white diffusing surfaces at a sole portion of a club face, at a top line, or a top portion of a club face.
The present disclosure relates to an apparatus (200) for determining the balance of a sports ball (100), in particular a soccer ball, the apparatus (200) comprising: a. a weight scale (201); b. a support element (202) for supporting the sports ball (100); c. a beam (205), on which the support element (202) is arranged, the beam (205) arranged on a rotational joint (206) on one end and on the weight scale (201) on the opposing end; d. a frame (210) for receiving the ball in a predetermined manner, the frame being mountable to the support element (202).
G01M 1/04 - Adaptation des ensembles de support destinés à recevoir l'objet à tester
G01M 1/16 - Détermination du balourd en donnant à l'objet à tester un mouvement d'oscillation ou de rotation
G01B 5/252 - Dispositions pour la mesure caractérisées par l'utilisation de techniques mécaniques pour mesurer des angles ou des cônesDispositions pour la mesure caractérisées par l'utilisation de techniques mécaniques pour tester l'alignement des axes pour tester l'alignement des axes pour mesurer l'excentricité, c.-à-d. le décalage latéral entre deux axes parallèles
G01B 5/00 - Dispositions pour la mesure caractérisées par l'utilisation de techniques mécaniques
A63B 71/06 - Dispositifs indicateurs ou de marque pour jeux ou joueurs
A63B 71/02 - Accessoires pour jeux ou sports non couverts dans les groupes pour jeux sportifs de plein air ou de gymnase
G01G 3/14 - Appareils de pesée caractérisés par l'utilisation d'organes déformables par élasticité, p. ex. balances à ressort dans lesquels l'élément de pesée est constitué par un corps solide soumis à une pression ou une traction pendant la pesée utilisant la mesure des variations de la résistance électrique
The disclosure relates to a method for producing a particle foam part from foam particles for sports apparel, sports equipment or a ball using electromagnetic waves, comprising the steps of filling a mold cavity, heating the foam particles with electromagnetic waves in order to weld them, demolding, wherein a parameter characteristic of the absorption of the electromagnetic waves is monitored during the heating of the foam particles, and if this parameter changes by a predetermined amount, the heating of the foam particles is ended. This method ensures in a simple manner that the correct quantity of heat is supplied to the foam particles.
Disclosed here is a method of making a golf club head. The method comprises steps of laser ablating a second-part surface of a second part of the golf club head such that a second-part ablated surface is formed in the second part, and bonding together a first-part surface, of a first part of the golf club head, and the second-part ablated surface of the second part of the golf club head.
B23K 26/402 - Enlèvement de matière en tenant compte des propriétés du matériau à enlever en faisant intervenir des matériaux non métalliques, p. ex. des isolants
B23K 26/0622 - Mise en forme du faisceau laser, p. ex. à l’aide de masques ou de foyers multiples par commande directe du faisceau laser par impulsions de mise en forme
B23K 103/18 - Matériaux comportant des matières différentes
A golf club head includes a body defining an interior cavity. The body includes a sole positioned at a bottom portion of the golf club head, a crown positioned at a top portion, and a skirt positioned around a periphery between the sole and crown. The body has a forward portion and a rearward portion. The club head includes a face positioned at the forward portion of the body. In some embodiments, the crown includes a lattice-like structure having thin regions surrounded by a web of relatively thicker regions. In some embodiments, the club head includes one or more stiffening tubes attached between the sole and the crown to improve the acoustic performance of the golf club head.
Disclosed herein is a driver-type golf club head that is made from at least one first material, having a density between 0.9 g/cc and 3.5 g/cc, at least one second material, having a density between 3.6 g/cc and 5.5 g/cc, and at least one third material, having a density between 5.6 g/cc and 20.0 g/cc. The first material has a first mass no more than 55% and no less than 25% of the total mass of the golf club head. The second material has a second mass no more than 65% and no less than 20% of the total mass of the golf club head. The third material has a third mass equal to the total mass of the golf club head less the first mass of the first material and the second mass of the second material.
Golf club heads are provided for selectively increasing or optimizing the coefficient of restitution (COR) at likely impact locations on the striking face of the golf club heads, while simultaneously maintaining characteristic time (CT) below a threshold value in those likely impact locations. By analyzing historical impact locations of a large cross-section of golfers, golf club head COR values can be increased or optimized in preferential locations on the striking face, such as using weighting factors for a predefined set of locations on the striking face. Therefore, instead of increasing COR uniformly across the face and/or increasing COR at impact locations on the face where golfers are unlikely to strike the golf ball, the sweet spot of the golf club head can be increased at the impact locations where golfers typically strike the golf ball.
Some disclosed golf club heads include body having at least one raised sole portion and a cantilevered ledge extending down around a perimeter of the club head below the level of the raised sole portion. Some disclosed golf club heads include one or more sole openings in the body and a sole insert that is mounted inside the body over the sole openings. The sole can include weight tracks as well, and a rear weight track can extend between a toe side sole opening and a heel side sole opening. A crown insert can also be included that is mounted over an upper opening in the body.
An iron-type golf club head is disclosed having a heel portion, a sole portion, a toe portion, a top-line portion, a front portion, a rear portion, and a striking face. A back wall is also disclosed in the rear portion enclosing a portion of the rear portion to create an enclosed cavity. The cavity is defined by at least a rear surface of the striking face, an inner back wall surface, and the sole portion. A plug and a filler material is located within the enclosed cavity. The filler material surrounds the plug and is configured to hold the plug in place. The plug is lighter than the filler material.
A63B 53/08 - Clubs de golf avec des dispositions particulières pour faire varier l'impact
A63B 60/00 - Détails ou accessoires des clubs de golf, des battes, des raquettes ou analogues
A63B 60/42 - Dispositifs de mesure, de vérification, de correction ou de personnalisation des caractéristiques inhérentes aux clubs de golf, battes, raquettes ou analogues, p. ex. mesure du couple de torsion maximale que le manche d'une batte peut supporter
B23P 17/04 - Opérations d'usinage non couvertes par une seule autre sous-classe ou un autre groupe de la présente sous-classe caractérisées par la nature du matériau considéré, ou par le genre de produit quelle que soit sa forme
A sole for an article of footwear includes an outsole that has longitudinal ribs and a midsole that is disposed above the outsole and that defines notches. The longitudinal ribs arc disposed in the notches.
A midsole for an article of footwear including a three-dimensional mesh including interconnected unit cells and methods of making the same. The interconnected unit cells each include a plurality of struts defining a three-dimensional shape. The interconnected unit cells are connected at nodes having a valence number defined by the number of struts connected at that node. The valence number of the nodes may vary to provide customized characteristics to zones or portions of the midsole. The plurality of interconnected unit cells may be organized in a warped cubic lattice structure. The warped cubic lattice structure and the size/shape of interconnected unit cells may vary to provide customized characteristics to zones or portions of the midsole. The three-dimensional mesh may be customized based on a biometric data profile for an individual, or group of individuals. The midsole may be manufactured using an additive manufacturing process.
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/0205 - Évaluation simultanée de l'état cardio-vasculaire et de l'état d'autres parties du corps, p. ex. de l'état cardiaque et respiratoire
A61B 5/024 - Mesure du pouls ou des pulsations cardiaques
A61B 5/103 - Dispositifs de mesure pour le contrôle de la forme, du dessin, de la dimension ou du mouvement du corps ou de parties de celui-ci, à des fins de diagnostic
A61B 5/11 - Mesure du mouvement du corps entier ou de parties de celui-ci, p. ex. tremblement de la tête ou des mains ou mobilité d'un membre
B29C 64/124 - Procédés de fabrication additive n’utilisant que des matériaux liquides ou visqueux, p. ex. dépôt d’un cordon continu de matériau visqueux utilisant des couches de liquide à solidification sélective
B29C 64/393 - Acquisition ou traitement de données pour la fabrication additive pour la commande ou la régulation de procédés de fabrication additive
B29L 31/50 - Chaussures ou leurs parties constitutives
Systems and method disclosed herein provide a digital asset system that interconnects the processing of digital assets and related physical products within an enterprise network. Digital assets may be generated and updated based on a number of factors including the interactions with the digital asset within the enterprise network and the physical and commercial attributes of the related physical products. Digital assets may be dynamically updated on real-world conditions and utilized to facilitate cross-system interaction between users, manufacturing, and user engagement systems.
G06F 16/27 - Réplication, distribution ou synchronisation de données entre bases de données ou dans un système de bases de données distribuéesArchitectures de systèmes de bases de données distribuées à cet effet
G06F 21/10 - Protection de programmes ou contenus distribués, p. ex. vente ou concession de licence de matériel soumis à droit de reproduction
The present invention generally relates to soles in particular midsoles for sports shoes. According to an aspect, an additively manufactured sole is provided. The sole comprises a lattice structure, the lattice structure comprising a plurality of cell elements. The sole further comprises a heel element, three-dimensionally encompassing the heel. Moreover, the sole comprises a base portion interconnecting the heel element and the lattice structure, wherein the base portion has an extension arranged to connect to a plurality of adjacent cell elements, wherein the plurality of adjacent cell elements is not positioned along an edge of the lattice structure.
A43B 1/00 - Chaussures caractérisées par les matériaux
A43B 3/00 - Chaussures caractérisées par la forme ou l'utilisation
A43B 7/08 - Chaussures avec dispositions médicales ou hygiéniques ventilées à trous d'aération, avec ou sans fermetures
A43B 7/1405 - Chaussures avec dispositions médicales ou hygiéniques avec éléments pour soutenir le pied munies de coussinets ou de trous à un ou plusieurs endroits, ou ayant une forme anatomique ou courbe
A43B 7/144 - Chaussures avec dispositions médicales ou hygiéniques avec éléments pour soutenir le pied munies de coussinets ou de trous à un ou plusieurs endroits, ou ayant une forme anatomique ou courbe caractérisés par leur emplacement sous le pied situés sous le talon, c.-à-d. sous le calcanéus
A43B 9/20 - Chaussures à semelles surmoulées sur les tiges ou soudées aux tiges sans collage soudées
A43B 13/02 - SemellesSemelle et talon d'un seul tenant caractérisées par les matériaux
A43B 13/04 - Matières plastiques, caoutchouc ou fibre vulcanisée
A43B 13/12 - Semelles à plusieurs couches de matériaux différents
A43B 13/14 - SemellesSemelle et talon d'un seul tenant caractérisées par leur structure
A sports ball, for example a soccer ball, comprising a hollow shell and a pit suspended within the hollow shell by a plurality of cords. In some embodiments, the plurality of cords may comprise a first end coupled to the hollow shell at a first location, a second end coupled to the hollow shell at a second location, and a center portion coupled to the pit. In some embodiments, the pit may be suspended within the hollow shell by a plurality of cords, with each of the plurality of cords comprising a frayed end secured to the hollow shell at one of a plurality of spaced apart locations.
An iron-type golf club head is disclosed having a heel portion, a sole portion, a toe portion, a top-line portion, a front portion, a rear portion, and a striking face. A back wall is also disclosed in the rear portion enclosing a portion of the rear portion to create an enclosed cavity. The cavity is defined by at least a rear surface of the striking face, an inner back wall surface, and the sole portion. A plug and a filler material is located within the enclosed cavity. The filler material surrounds the plug and is configured to hold the plug in place. The plug is lighter than the filler material.
A63B 53/08 - Clubs de golf avec des dispositions particulières pour faire varier l'impact
A63B 60/00 - Détails ou accessoires des clubs de golf, des battes, des raquettes ou analogues
A63B 60/42 - Dispositifs de mesure, de vérification, de correction ou de personnalisation des caractéristiques inhérentes aux clubs de golf, battes, raquettes ou analogues, p. ex. mesure du couple de torsion maximale que le manche d'une batte peut supporter
B23P 17/04 - Opérations d'usinage non couvertes par une seule autre sous-classe ou un autre groupe de la présente sous-classe caractérisées par la nature du matériau considéré, ou par le genre de produit quelle que soit sa forme
Disclosed herein is a driver-type golf club head that has a strike face. The strike face has a central region, defined by a 40 mm by 20 mm rectangular area centered on a geometric center of the strike face and elongated in a heel-to-toe direction. The driver-type golf club head is configured such that after 500 impacts of a standard golf ball at the geometric center of the strike face, where at each impact the standard golf ball has a velocity of 52 meters per second, the CT of the strike face at any point within the central region is less than 256 microseconds and the CT at the geometric center of the strike face is no more than five microseconds different than the initial CT value.
A golf club head comprises a body having a face, a crown and a sole together defining an interior cavity. The body having a head-shaft connection system, a rear weight fastened to the golf club head proximate the rear end of the club head and proximate the Y-Z plane, and a front weight port or an internal cap connection system for securing the rear weight; in combination with specific windows regarding the moments of inertia and center of gravity.
An aerodynamic golf club head producing reduced aerodynamic drag forces. The club head has crown section attributes and material attributes that impart beneficial aerodynamic properties and performance.
A golf club head is described having a body defining an interior cavity and comprising a heel portion, a toe portion, and a sole portion positioned at a bottom portion of the golf club head, and a crown positioned at a top portion. The body has a forward portion and a rearward portion. The club head can have a non-metallic striking surface positioned at the forward portion of the body.
A putter-type golf club head comprises a unitary construction metallic frame having a thin wall crown region, and a crown damping member attached to thin wall crown region. The unitary construction metallic frame has a frame mass of 250-370 grams, a frame density of at least 2.5 g/cc, a frame length of 40-130 mm, a frame width of 75-130 mm, a frame height of 17-30 mm, a frame front forming a portion of a striking face, a frame rear, a frame top, and a frame bottom, wherein the frame top includes a thin wall crown region having a TWCR thickness of 0.6-1.2 mm, a TWCR length, a TWCR width, and a TWCR area of at least 600 mm2.
Group performance monitoring systems and methods are provided. A system for monitoring a plurality of individuals engaged in an activity may include a base station, a plurality of individual monitors to communicate wirelessly with the base station, a plurality of sensors, each sensor in communication with an individual monitor, each to be coupled to an individual, and each to sense a characteristic of the individual and to transmit, during the activity, data indicative of the characteristic to the individual monitor, and a group monitoring device to communicate wirelessly with the base station. Each individual monitor may transmit, during the activity, the data to the base station. The base station may receive the data and to transmit, during the activity, a metric based on the data to the group monitoring device. The group monitoring device may display a representation of the metric.
G16H 20/30 - TIC spécialement adaptées aux thérapies ou aux plans d’amélioration de la santé, p. ex. pour manier les prescriptions, orienter la thérapie ou surveiller l’observance par les patients concernant des thérapies ou des activités physiques, p. ex. la physiothérapie, l’acupression ou les exercices
A63B 24/00 - Commandes électriques ou électroniques pour les appareils d'exercice des groupes
Disclosed herein are various embodiments of a golf club head having improved mass distribution characteristics. The golf club head includes a body and a face positioned at a forward portion of the body. The golf club head also includes one or more mass elements positioned at predetermined locations about the head. The mass elements assist in achieving a desired relationship between the moment of inertia about a center of gravity x-axis and the moment of inertia about a center of gravity z-axis.
Disclosed herein is a golf club head that comprises a strike face. The strike face has a central region, defined by a forty millimeter by twenty millimeter rectangular area centered on a center of the strike face and elongated in a heel-to-toe direction. Within the central region, the strike face has a characteristic time (CT) of no more than 257 microseconds. Within the central region, no less than 25% of the strike face has a coefficient of restitution (COR) of at least 0.8. Within the central region, no less than 60% of the strike face has a CT of at least 235 microseconds. Within the central region, no less than 35% of the strike face has a CT of at least 240 microseconds.
A shim or badge is affixed to a golf cub body to produce a cap-back iron, giving the appearance of a hollow-body iron. In this way, the golf club can be manufactured with the performance benefits of a game improvement iron, while providing the appearance of a blade, player's iron, and/or a hollow-body iron. For example, by using a lightweight and rigid shim or badge to close a cavity opening and extend into the toe portion of the golf club body, the golf club head can provide increased stiffness in the topline, while lowering CG. Various shim or badge arrangements and materials can be used, and a filler material and/or damper can be included within the cavity to improve sound and feel, while minimizing loss in COR.
The present invention provides a group monitoring device for monitoring a plurality of individuals engaged in an athletic activity, the device including a display configured to display, during an athletic activity: a metric relating to each of a plurality of individuals engaged in the athletic activity, and a status of a system component used to monitor the athletic activity. The group monitoring device may also include an input configured to allow manipulation of the display.
G16H 20/30 - TIC spécialement adaptées aux thérapies ou aux plans d’amélioration de la santé, p. ex. pour manier les prescriptions, orienter la thérapie ou surveiller l’observance par les patients concernant des thérapies ou des activités physiques, p. ex. la physiothérapie, l’acupression ou les exercices
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/0205 - Évaluation simultanée de l'état cardio-vasculaire et de l'état d'autres parties du corps, p. ex. de l'état cardiaque et respiratoire
A61B 5/024 - Mesure du pouls ou des pulsations cardiaques
A61B 5/11 - Mesure du mouvement du corps entier ou de parties de celui-ci, p. ex. tremblement de la tête ou des mains ou mobilité d'un membre
A63B 24/00 - Commandes électriques ou électroniques pour les appareils d'exercice des groupes
G06F 11/34 - Enregistrement ou évaluation statistique de l'activité du calculateur, p. ex. des interruptions ou des opérations d'entrée–sortie
G06Q 10/0639 - Analyse des performances des employésAnalyse des performances des opérations d’une entreprise ou d’une organisation
G16H 40/63 - TIC spécialement adaptées à la gestion ou à l’administration de ressources ou d’établissements de santéTIC spécialement adaptées à la gestion ou au fonctionnement d’équipement ou de dispositifs médicaux pour le fonctionnement d’équipement ou de dispositifs médicaux pour le fonctionnement local
G16H 40/67 - TIC spécialement adaptées à la gestion ou à l’administration de ressources ou d’établissements de santéTIC spécialement adaptées à la gestion ou au fonctionnement d’équipement ou de dispositifs médicaux pour le fonctionnement d’équipement ou de dispositifs médicaux pour le fonctionnement à distance
A method for determining a rotation rate of a ball used for an athletic activity comprises: sensing acceleration data for the ball using a sensor coupled to the ball, identifying a repeating portion of the sensed acceleration data, determining a time period of the repeating portion of the sensed acceleration data, determining an inverse of the time period of the repeating portion, and determining the rotation rate of the ball based on the determination of the inverse of the time period.
A63B 60/42 - Dispositifs de mesure, de vérification, de correction ou de personnalisation des caractéristiques inhérentes aux clubs de golf, battes, raquettes ou analogues, p. ex. mesure du couple de torsion maximale que le manche d'une batte peut supporter
A golf club head having a planar strike face formed of oxidizable metal substrate including an unplated portion of the oxidizable metal substrate that is not plated and defines an oxidizable strike face surface area. A first oxidation-prevention coating permanently covers at least a portion of the body including at least a portion of the rear portion and the heel portion, and a temporary user-removable cover is located over at least a portion of the oxidizable strike face surface area and may temporarily regulate oxidation. The club head has performance and confidence inspiring ratios of the oxidizable strike face surface area divided by the total volume, as well as the oxidizable strike face surface area divided by the total planar strike face surface area, and the oxidizable strike face surface area divided by the total surface area.
Described are methods for manufacturing a plastic component, in particular a cushioning element for sports apparel, a plastic component manufactured with such methods, for example a sole or a part of a sole for a shoe, and a shoe with such a sole. The method for the manufacture of a plastic component includes loading a mold with a first material includes particles of an expanded material and fusing the surfaces of the particles by supplying energy. The energy is supplied in the form of at least one electromagnetic field.
A43B 7/32 - Chaussures avec dispositions médicales ou hygiéniques avec dispositifs amortisseurs de chocs
A41D 13/015 - Vêtements protecteurs de travail ou de sport, p. ex. blouses de chirurgien ou vêtements protégeant des coups ou des chocs avec des moyens absorbeurs de chocs
A43B 5/06 - Chaussures de courseChaussures de piste d’athlétisme
A43B 13/04 - Matières plastiques, caoutchouc ou fibre vulcanisée
A43B 13/12 - Semelles à plusieurs couches de matériaux différents
B29C 35/08 - Chauffage ou durcissement, p. ex. réticulation ou vulcanisation utilisant l'énergie ondulatoire ou un rayonnement corpusculaire
B29C 67/20 - Techniques de façonnage non couvertes par les groupes , ou pour la fabrication d'objets poreux ou cellulaires, p. ex. des mousses plastiques, des mousses alvéolaires
B29D 35/12 - Fabrication de leurs parties constitutives, p. ex. semelles, talons ou empeignes, par une technique de moulage
B29K 67/00 - Utilisation de polyesters comme matière de moulage
B29K 75/00 - Utilisation de polyurées ou de polyuréthanes comme matière de moulage
Articles comprises iron oxide colloidal nanocrystals arranged within chains, wherein the chains of nanocrystals are embedded within a material used to form the article or a transfer medium used to transfer a color to the article are described. The material or transfer medium includes elastic properties that allow the nanocrystals to display a temporary color determined by the strength of an external force applied to the article, and the material or transfer medium includes memory properties that cause the displayed temporary color to dissipate when the external force is removed, wherein the dissipation of the displayed temporary color is sufficiently slow as to be visually observable by an average observer's unaided eye.
G02B 26/00 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables
B01J 13/02 - Fabrication de microcapsules ou de microbilles
B82Y 30/00 - Nanotechnologie pour matériaux ou science des surfaces, p. ex. nanocomposites
C09D 11/50 - Encres sympathiques, encres changeant de couleur ou encres similaires
C09K 9/00 - Substances devenant sombres, c.-à-d. substances pour lesquelles la gamme de longueurs d'onde absorbées est modifiée par excitation avec une énergie sous une forme quelconque
Fraunhofer-Gesellschaft zur Förderung der angewandten Forschung e.V. (Allemagne)
NOWOFOL Kunststoffprodukte GmbH & Co. KG (Allemagne)
adidas AG (Allemagne)
Inventeur(s)
Haala, Oliver
Spies, Peter
Zessin, Henrik
Vesa-Pekka, Torvinen
Hartl, Sabine
Luft, Konstantin
Von Großmann, Ulrich
Jensen, Ulf
Dümler, Burkhard
Abrégé
An electrical component having: a sensor cell; the sensor cell being configured to, firstly, detect a physical quantity and output an electrical measurement signal having at least three differentiable states based on the detected physical quantity and to, secondly, provide electrical energy when the physical quantity is applied.
A golf club head that comprises a hollow interior cavity, a first piece, a second piece, adhesively bonded to the first piece along a first bonded joint, a third piece, adhesively bonded to the first piece along a second bonded joint, and a fourth piece, adhesively bonded to the first piece along a third bonded joint. A volume of the golf club head is at least 120 cubic centimeters (cc) and at most 600 cc. The first bonded joint has a first-joint bond area. The second bonded joint has a second-joint bond area. The third bonded joint has a third-joint bond area. A summation of the first-joint bond area, the second-joint bond area, and the third-joint bond area is at least 1,950 mm2 and at most 3,400 mm2.
Iron-type golf club heads are disclosed having a heel portion, a sole portion, a toe portion, a top-line portion, a front portion, a rear portion, and a striking face. The iron-type golf club heads include a localized stiffened region that is located on the striking face of the club head such that the localized stiffened region alters the launch conditions of golf balls struck by the club head in a way that wholly or partially compensates for, overcomes, or prevents the occurrence of a rightward deviation. In particular, the localized stiffened region is located on the striking face such that a golf ball struck under typical conditions will not impart a right-tending sidespin to the golf ball.
A sole for an article of footwear includes an upper sole. The upper sole forms a sidewall of the sole. The sole includes a pod assembly coupled to the upper sole and disposed below the upper sole. The pod assembly includes a strip of pods fluidly connected in series. The strip of pods includes at least one pod disposed in each of a forefoot region, a midfoot region, and a heel region of the sole. The strip of pods extends from the heel region of the sole to the forefoot region of the sole in a linear arrangement. The strip of pods is disposed along a central longitudinal axis of the sole.
A golf club incorporating a stress reducing feature, including an aperture, located at least partially on the sole of the club head. The location and size of the stress reducing feature and aperture, and their relationship to one another, play a significant role in selectively improving the performance of the golf club.
Midsoles for articles of footwear are formed of a variety of three dimensional mesh lattices. The lattices can be populated by unit cells of various base geometries. Some base geometries are structures of struts and nodes that approximate the overall shape of an implicit surface. Some base geometries are structures of struts and nodes that include struts having at least two different effective diameters. Some lattices are compound lattices that include and blend together at least two lattices populated by cells having different base geometries. Some compound lattices have a skin that includes beams extending across multiple cells at the exterior of the compound lattice.
Midsoles for articles of footwear are formed of a variety of three dimensional mesh lattices. The lattices can be populated by unit cells of various base geometries. Some base geometries are structures of struts and nodes that approximate the overall shape of an implicit surface. Some base geometries are structures of struts and nodes that include struts having at least two different effective diameters. Some lattices are compound lattices that include and blend together at least two lattices populated by cells having different base geometries. Some compound lattices have a skin that includes beams extending across multiple cells at the exterior of the compound lattice.
Some disclosed golf club heads include body having at least one raised sole portion and a cantilevered ledge extending down around a perimeter of the club head below the level of the raised sole portion. Some disclosed golf club heads include one or more sole openings in the body and a sole insert that is mounted inside the body over the sole openings. The sole can include weight tracks as well, and a rear weight track can extend between a toe side sole opening and a heel side sole opening. A crown insert can also be included that is mounted over an upper opening in the body.
An inflatable ball (such as a soccer ball) may have an outer shell comprising panels. The panels may include at least one surface texture. At least a subset of the panels may include indentations in addition to the surface texture. An overall roughness volume of the outer ball surface of the inflatable ball may range between 7000 and 30000 mm3, e.g., factoring in and/or resulting from the presence of both the surface texture and the indentations.
Disclosed golf club heads include a body defining an interior cavity, a face, a sole, a crown, and a hosel. Certain embodiments include a weight channel positioned in the sole and defining a path along the sole. Some embodiments include a weight member positioned in the weight channel that is configured to be adjusted to any of a range of selectable positions to adjust mass properties of the golf club head. A fastener may be configured to secure the weight member in any of the selectable positions, while the fastener itself, regardless of where the weight member is positioned along the path, may be secured to the body at a fixed location that is independent of the position of the weight member along the path.
Described herein is a golf club head that comprises a body and a strike plate. The body comprises a heel portion, a sole portion, a toe portion, and a top portion. The strike plate comprises an outer peripheral edge and at least a portion of a strike face. Furthermore, the strike plate is welded to the body via a peripheral weld between the outer peripheral edge of the strike plate and the body. The outer peripheral edge of the strike plate comprises at least one welded portion, welded to the body via the peripheral weld, and at least one non-welded portion, not welded to the body.
Apparatus, systems, and methods for tracking the location of an individual during a fitness activity are disclosed. A method of tracking a participant engaged in a fitness activity includes determining a location of the participant during the fitness activity based on data received at a portable fitness device used by the participant; determining a location of a spectator during the fitness activity based on data received at a mobile spectator device used by the spectator; from a server, sending an alert to a spectator at a spectator device during the fitness activity indicating that the participant is within a predetermined distance of the spectator; and sending an alert to the portable fitness device during the fitness activity indicating that the spectator is within a predetermined distance of the participant.
G06Q 50/00 - Technologies de l’information et de la communication [TIC] spécialement adaptées à la mise en œuvre des procédés d’affaires d’un secteur particulier d’activité économique, p. ex. aux services d’utilité publique ou au tourisme
G16H 20/30 - TIC spécialement adaptées aux thérapies ou aux plans d’amélioration de la santé, p. ex. pour manier les prescriptions, orienter la thérapie ou surveiller l’observance par les patients concernant des thérapies ou des activités physiques, p. ex. la physiothérapie, l’acupression ou les exercices
G16H 40/67 - TIC spécialement adaptées à la gestion ou à l’administration de ressources ou d’établissements de santéTIC spécialement adaptées à la gestion ou au fonctionnement d’équipement ou de dispositifs médicaux pour le fonctionnement d’équipement ou de dispositifs médicaux pour le fonctionnement à distance
H04L 67/12 - Protocoles spécialement adaptés aux environnements propriétaires ou de mise en réseau pour un usage spécial, p. ex. les réseaux médicaux, les réseaux de capteurs, les réseaux dans les véhicules ou les réseaux de mesure à distance
H04L 67/52 - Services réseau spécialement adaptés à l'emplacement du terminal utilisateur
A high forgiveness wood-type golf club head comprises a body and a face. The body comprises a sole that forms a bottom portion of the golf club head, a crown that forms a top portion of the golf club head and a skirt that forms a periphery of the golf club head between the sole and the crown. The face place is positioned at a front portion of the golf club head opposite a rear portion of the golf club head. The body defines an outer periphery having a generally triangular shape in plan.
A method of manufacturing a skate boot shell, and more particularly a non-lasted skate boot shell, including shaping tridimensional outer and inner sub-shells, and bonding the shaped sub-shells together through lamination. The lamination is performed after the sub-shells are shaped and includes applying heat to the sub-shells and/or pressure on one of the sub-shells toward the other against a mold surface. A skate boot shell with multiple sub-shells is also discussed, including an outer sub-shell, and inner sub-shell and a reinforcement sub-shell.
B29C 51/14 - Façonnage par thermoformage, p. ex. façonnage de feuilles dans des moules en deux parties ou par emboutissage profondAppareils à cet effet de préformes ou de feuilles multicouches
B29C 51/28 - Éléments constitutifs, détails ou accessoiresOpérations auxiliaires pour l'application d'une pression à travers les parois d'un sac gonflé ou d'une membrane
B29C 70/34 - Façonnage par empilage, c.-à-d. application de fibres, de bandes ou de feuilles larges sur un moule, un gabarit ou un noyauFaçonnage par pistolage, c.-à-d. pulvérisation de fibres sur un moule, un gabarit ou un noyau et façonnage ou imprégnation par compression
A method of removing a backing layer from a panel, made of an uncured pre-impregnated fiber-reinforced polymer, comprises a step of orienting the panel into a backing-separation orientation relative to an edge-engagement tool. The method also comprises a step of positioning the panel into a backing-separation position relative to the edge-engagement tool. The method further comprises a step of moving the edge-engagement tool, when the panel is in the backing-separation orientation and the backing-separation position, so that backing-engagement features of the edge-engagement tool engage the backing layer, at only an edge portion of the backing layer, and just the edge portion of the backing layer separates from the panel. The method additionally comprises a step of gripping the edge portion of the backing layer, and, when gripped, moving the backing layer relative to the panel so that an entirety of the backing layer separates from the panel.
B32B 38/00 - Opérations auxiliaires liées aux procédés de stratification
B32B 37/02 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par la séquence des opérations de stratification, p. ex. par addition de nouvelles couches à des postes successifs de stratification
B32B 37/14 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par les propriétés des couches
B32B 41/00 - Dispositions pour le contrôle ou la commande des procédés de stratificationDispositions de sécurité
Described herein is a golf club head that includes a body with a sole portion, a crown portion, a skirt portion, a forward region, and a rearward region. The golf club head also includes a face portion including a striking face with a maximum height from the ground plane of at least about 50 mm. A volume of the golf club head is at least about 370 cm3. The golf club head has a total club head mass between 190 grams and 210 grams, and the mass of the club head located above half of the peak crown height is less than or equal to 77 grams, and the percentage of the mass above half of the peak crown height is less than or equal to 39% of the total mass of the golf club head.
Described are shoes, in particular a sports shoe, wherein at least a portion of an upper of the shoe includes a first layer and a functional second layer, wherein the functional second layer is directly printed onto the first layer.
The invention refers to a method for producing expanded polymer pellets, which comprises the following steps: melting a polymer comprising a polyamide; adding at least one blowing agent; expanding the melt through at least one die for producing an expanded polymer; and pelletizing the expanded polymer. The invention further concerns polymer pellets produced with the method as well as their use, e.g. for the production of cushioning elements for sports apparel, such as for producing soles or parts of soles of sports shoes. A further aspect of the invention concerns a method for the manufacture of molded components, comprising loading pellets of an expanded polymer material into a mold, and connecting the pellets by providing heat energy, wherein the expanded polymer material of the pellets or beads comprises a chain extender. The molded components may be used in broad ranges of application.
B29B 9/06 - Fabrication de granulés par division de matière préformée sous forme de filaments, p. ex. combinée avec l'extrusion
B29B 9/10 - Fabrication de granulés par moulage de matière, c.-à-d. par traitement en état de fusion
B29B 9/12 - Fabrication de granulés caractérisés par la structure ou la composition
B29C 44/02 - Moulage par pression interne engendrée dans la matière, p. ex. par gonflage ou par moussage pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés
B29C 45/00 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet
B29K 77/00 - Utilisation de polyamides, p. ex. polyesteramides, comme matière de moulage
B29K 105/04 - Présentation, forme ou état de la matière moulée cellulaire ou poreuse
B29L 31/50 - Chaussures ou leurs parties constitutives
C08G 81/02 - Composés macromoléculaires obtenus par l'interréaction de polymères en l'absence de monomères, p. ex. polymères séquencés au moins un des polymères étant obtenu par des réactions ne faisant intervenir que des liaisons non saturées carbone-carbone
C08J 9/12 - Mise en œuvre de substances macromoléculaires pour produire des matériaux ou objets poreux ou alvéolairesLeur post-traitement utilisant des gaz de gonflage produits par un agent de gonflage introduit au préalable par un agent physique de gonflage
C08J 9/14 - Mise en œuvre de substances macromoléculaires pour produire des matériaux ou objets poreux ou alvéolairesLeur post-traitement utilisant des gaz de gonflage produits par un agent de gonflage introduit au préalable par un agent physique de gonflage organique
E04B 1/74 - Isolation thermique ou acoustique, absorption ou réflexion de la chaleur ou du sonAutres méthodes de construction procurant des conditions thermiques ou acoustiques favorables, p. ex. par accumulation de chaleur à l'intérieur des murs
A sole for an article of footwear includes a base having an outer edge defining a perimeter, the base having a forefoot portion, a midfoot portion and a heel portion; and a plurality of resilient projections extending from the base, wherein the plurality of projections includes a plurality of projections extending non-orthogonally from the base about the perimeter of the base and a plurality of projections extending substantially orthogonally from the base within the non-orthogonal projections.
Articles of apparel and methods of making articles of apparel that include one or more thread layers made by winding a continuous thread around anchor points. In some embodiments, the articles of apparel can include multiple pieces of material, with each piece including a thread layer. In some embodiments, the article of apparel can be steamed to shape the one or more thread layers.
A shoe comprising a sole comprising a female element; and an upper arrangement comprising a corresponding male element configured to be received in the female element upon insertion in an insertion direction. The male and female elements comprise complementary locking features including a first locking feature being provided on a peripheral surface of one of the male or female elements, and a second locking feature being provided on a peripheral surface of the other of the male or female elements. The first locking feature comprises a protrusion that protrudes in a direction transverse to the insertion direction, and the second locking feature comprises a locking recess. The locking protrusion is configured to engage with the locking recess as the male element is inserted into the female element, thereby locking the sole to the upper arrangement.
Disclosed golf club heads include a body defining an interior cavity, a striking surface, a sole, a crown, and a hosel, which is configured to provide improved aerodynamic and inertia generating properties of the golf club head. Certain embodiments include an inertia generator positioned in the sole between an area proximate the club head's center of gravity and a position toeward of the center of gravity at the rear of the golf club head. Some embodiments include fixed or removable mass elements, weights or weight assemblies positioned in the sole, including, in some instances, within or adjacent to the inertia generator. In particular embodiments, one or more weight assemblies are movably retained within a weight channel defining a path along the sole.
A golf club head is provided with an electronic display that is visible to a user of the golf club head when the golf club head is in the address position, such as for displaying one or more images to the user. The electronic display may include a memory, a microprocessor, and a battery, and may be configured to communicate with a user operable electronic device via a wired or a wireless communication protocol. For example, the electronic display may be configured to receive one or more images from the user operable electronic device, to store the one or more images in the memory, and to display the one or more images to the user.
A63B 60/42 - Dispositifs de mesure, de vérification, de correction ou de personnalisation des caractéristiques inhérentes aux clubs de golf, battes, raquettes ou analogues, p. ex. mesure du couple de torsion maximale que le manche d'une batte peut supporter
A63B 71/06 - Dispositifs indicateurs ou de marque pour jeux ou joueurs
A golf club head includes a golf club body including a crown, a sole, and a skirt connected between the crown and the sole, the golf club body including a front including a leading edge and a back including a trailing edge, and a hosel connected to the golf club body; a face connected to the front of the golf club body, the face including a geometric center, the golf club head including modifiable boundary conditions.
A63B 60/42 - Dispositifs de mesure, de vérification, de correction ou de personnalisation des caractéristiques inhérentes aux clubs de golf, battes, raquettes ou analogues, p. ex. mesure du couple de torsion maximale que le manche d'une batte peut supporter
A63B 60/52 - Détails ou accessoires des clubs de golf, des battes, des raquettes ou analogues avec fentes
A golf club head is provided with an electronic display that is visible to a user of the golf club head when the golf club head is in the address position, such as for displaying one or more images to the user. The electronic display may include a memory, a microprocessor, and a battery, and may be configured to communicate with a user operable electronic device via a wired or a wireless communication protocol. For example, the electronic display may be configured to receive one or more images from the user operable electronic device, to store the one or more images in the memory, and to display the one or more images to the user.
A63B 60/42 - Dispositifs de mesure, de vérification, de correction ou de personnalisation des caractéristiques inhérentes aux clubs de golf, battes, raquettes ou analogues, p. ex. mesure du couple de torsion maximale que le manche d'une batte peut supporter
A63B 71/06 - Dispositifs indicateurs ou de marque pour jeux ou joueurs
(Based on 44(e)) ; Sports balls and guards for athletic use, namely, shin guards, knee guards and leg guards; (Based on Intent To Use) Sports balls and guards for athletic use, namely, shin guards, knee guards and leg guards
