Produits et services

Sign-manufacturing machines; Printing machines for commercial or industrial use; Typesetting machines (printing)

Abrégé

A transport aid arrangement having at least one support body (100) having at least one inner support surface (110B) and provided with a curved outer support surface (100A) arranged to be attached to a transport object (TO) enabling controlled pivoting of the transport object (TO) along the curved outer support surface (100A) from a vertical position into a horizontal position. The support body (100) creates a distance between the at least one inner support surface (110B) and an outer part of the curved outer support surface (100A). The support body (100) is divided into at least two body parts (110, 120), an inner body part (110) and an outer body part (120) each provided with a portion (110A, 120A) of the curved outer support surface (100A), releasably connectable with each other by a coupling (130). The width (WI) of the inner body part (110) is less than the total width (W) of the curved outer support surface (100A).

Classes IPC  ?

• B62B 3/10 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des supports spécialement adaptés à des objets de forme définie
• B65G 7/08 - Dispositifs adaptés pour être interposés entre les charges et le sol ou le plancher, p. ex. pinces avec moyens pour aider au déplacement des charges pour basculer les charges
• B66C 13/08 - Dispositifs auxiliaires pour commander les mouvements des charges suspendues ou pour empêcher le câble de prendre du mou pour déposer les charges selon un orientement ou dans une position donnés

Abrégé

The invention relates to a transport aid arrangement, comprising at least one support body (100) having at least one inner support surface (110B) and provided with a curved outer support surface (100A) arranged to be attached to a transport object (TO) enabling controlled pivoting of the transport object (TO) along said curved outer support surface (100A) from a vertical position into a horizontal position, wherein the support body (100) creates a distance between said at least one inner support surface (110B) and an outer part of said curved outer support surface (100A), wherein said support body (100) is divided into at least two body parts (110, 120), an inner body part (110) and an outer body part (120) each provided with a portion (110A, 120A) of said curved outer support surface (100A), releasably connectable with each other by means of a coupling (130), wherein the width (W1) of said inner part (110) is substantially less than the total width (W) of said curved outer support surface (100A),

Classes IPC  ?

• B66C 13/08 - Dispositifs auxiliaires pour commander les mouvements des charges suspendues ou pour empêcher le câble de prendre du mou pour déposer les charges selon un orientement ou dans une position donnés
• B65G 7/08 - Dispositifs adaptés pour être interposés entre les charges et le sol ou le plancher, p. ex. pinces avec moyens pour aider au déplacement des charges pour basculer les charges
• B62B 3/10 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des supports spécialement adaptés à des objets de forme définie

Abrégé

The invention relates to a method for and a flatbed applicator, comprising a table (2) and a roll (1) movably guided vertically and horizontally along the table (2) by means of post members (3), a horizontal guiding structure comprising fixed parallel profiles (40) attached to the table (2) and guide members (41) fixedly attached to a support structure (4) carrying each of said post members (3), each of said post members (3) including a vertically moveable support structure (34) and a vertical guiding arrangement (30) arranged to guide said vertically moveable support structure (34), a power unit (5) and transmission (6A, 6B, 7) arranged to enable vertical movement of said vertically moveable support structure (34),said roll (1) comprises shaft ends (10A, 10C) that are connected to said vertically moveable support structure (34), wherein, said power unit (5) is in the form of a motor attached to said support structure (4) and arranged under said table (2) that said transmission (6A, 6B, 7) is in the form of a single reduction gear mechanism (7) attached to said transversal support member (42) and that said single reduction gear mechanism (7) is arranged to synchronously transmit torque to one or a pair of drive shaft (6A, 6B), which via a mechanical transmission (31, 33) drives said vertically movable support structure (34).

Classes IPC  ?

• B32B 37/00 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons
• H05B 3/00 - Chauffage par résistance ohmique

Abrégé

The invention relates to a method for and a flatbed applicator, comprising a table (2) and a roll (1) movably guided vertically and horizontally along the table (2) by means of posts (3), a horizontal guiding structure comprising fixed parallel profiles (40) attached to the table (2) and guide members (41) fixedly attached to a support structure (4) carrying each of said post members (3), each of said posts (3) including a vertically moveable support structure (34) and a vertical guiding arrangement (32) arranged to guide said vertically moveable support structure (34), said roll (1) comprising a fixed shaft (10) and coaxial shaft ends (10A, 10C) that are connected to said vertically moveable support stmcture (34), said fixed shaft (10) coaxially and rotatably supporting a cylindrical roll member (11, 100) with gables (110), and wherein a heating arrangement (120) is arranged within said cylindrical roll member (11, 100), wherein, said heating arrangement (120) comprises a heating rod (122) that forms a loop by means of having a first rod half (122 A) extending longitudinally within said cylindrical roll member (11, 100) on a first side of a centre plane (CP) including the centre axis (C) of said cylindrical roll member (11, 100) and a second rod half (122B) extending longitudinally within said cylindrical roll member (11, 100) on a second side of said centre plane (CP).

Classes IPC  ?

• B32B 37/00 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons
• H05B 3/00 - Chauffage par résistance ohmique

Abrégé

The invention relates to a reciprocing arrangement, preferably a flatbed applicator, comprising a base (2), preferably a table (2), and a movable arrangement (1,3,4), preferably including a roll (1) movably guided vertically and horizontally along the table (2) by means of post members (3), a guiding structure (40) along said base (2), preferably comprising fixed parallel profiles (40) attached to the table (2), and a movable support structure (4) included in said movable arrangement (1,3,4) movably arranged along said base (2), preferably further including guide members (41) fixedly attached to said support structure (4) carrying each of said post members (3), wherein a drive unit (400) including an electric drive motor (440) is attached to said support structure (4) and said electric drive motor (440) is enabled to drive a drive wheel (441) that may interact with a drive path (200) attached to said base (2), and wherein said drive unit (400) further includes fixed body member (410) and a pivotal body member (420) and an electric pivoting motor (430) enabled to pivot said pivotal body member (420) to either connect and disconnect, respectively, said drive wheel (441) from said drive path (200).

Classes IPC  ?

• B32B 37/00 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons
• H05B 3/00 - Chauffage par résistance ohmique

Produits et services

Cutters [machines]; shaper cutters [machines]; metal cutting tools [machines]; longitudinal cutters [machines]; cutting tools being power-operated; knife blades for electric knives; knives, electric; knives [parts of machines]; cutter bar knives [parts for machines]; blade holders [parts of machines]; cutting insert holders [parts of machines]; die holders for use with machines; machine holders being stands [being adapted for the machine]; machine guides [parts of machines]; splines (sliding -) [parts of machines]; workpiece slide tables [parts of machines]; roller conveyors; lamination coating machines other than for office use; linear actuators; industrial cutting machines. Glass cutters; foil cutters; wire cutters; cutter bars [hand tools]; miter cutters being hand tools; stencil cutters [hand-operated tools]; scoring knife for veneer sheets; knives; drawing knives; utility knives; die holders for use with hand operated tools; grindstones [hand tools]. Industrial work tables; worktables.

Produits et services

(1) Machine Cutters, namely, linear cutting machines for cutting soft PVC, banner, foam, textile, vinyl, extruded PVC, aluminum composite, leather and flute board; machine shaper cutters for use with power tools and power operated machines; machine tools, namely, powered machines for cutting, namely for shaping and finishing metals or other materials; machine longitudinal cutters for cutting soft PVC, banner, foam, textile, vinyl, extruded PVC, aluminum composite, leather and flute board; cutting tools being power-operated, namely, machine tools for the cutting and forming of materials; knife blades for electric knives; knives, electric; knives, being parts of machines; cutter bar knives being parts for machines; blade holders being parts of machines; cutting insert holders being parts of machines; die holders for use with machines; machine holders being stands, being adapted for linear cutting machines; parts of machines, namely linear cutting machine guides; sliding splines being parts of machines; workpiece slide tables being parts of machines; roller conveyors; lamination coating machines other than for office use; linear actuators; industrial cutting machines for use in graphic industry (2) Glass cutters; foil cutters; wire cutters; cutter bars being hand tools; miter cutters being hand tools; stencil cutters being hand-operated tools; scoring knife for veneer sheets; trimming knives; drawing knives; utility knives; die holders for use with hand operated tools; grindstones being hand tools (3) Industrial work tables; worktables

Produits et services

Machine cutters, namely, linear cutting machines for cutting soft PVC, banner, foam, textile, vinyl, extruded PVC, aluminum composite, leather and flute board; machine shaper cutters for use with power tools and power operated machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machine longitudinal cutters; cutting tools being power-operated, namely, machine tools for the cutting and forming of materials; knife blades for electric knives; knives, namely, electric knives; parts of machines, namely, electric knives; parts of machines, namely, cutter bar knives; parts of machines, namely, blade holders; parts of machines, namely, cutting insert holders; die holders for use with machines; machine holders being stands, being adapted for the machine; parts of machines, namely, machine guides; parts of machines, namely, sliding splines; parts of machines, namely, workpiece slide tables; roller conveyors; lamination coating machines other than for office use; linear actuators; industrial cutting machines [ Glass cutters; foil cutters; wire cutters; hand tools, namely, cutter bars; miter cutters being hand tools; hand-operated tools, namely, stencil cutters; scoring knife for veneer sheets; knives; drawing knives; utility knives; die holders for use with hand operated tools for stamping, perforating, notching, and cutting sheet metal and other sheet material; hand tools, namely, grindstones ] Industrial work tables; worktables

Produits et services

Cutters [machines]; Shaper cutters [machines]; Metal cutting tools [machines]; Longitudinal cutters [machines]; Cutting tools being power-operated; Knife blades for electric knives; Knives, electric; Knives [parts of machines]; Cutter bar knives [parts for machines]; Blade holders [parts of machines]; Cutting insert holders [parts of machines]; Die holders for use with machines; Machine holders being stands [being adapted for the machine]; Machine guides [parts of machines]; Splines (sliding -) [parts of machines]; Workpiece slide tables [parts of machines]; Roller conveyors; Lamination coating machines other than for office use; Linear actuators; Industrial cutting machines. Glass cutters; Foil cutters; Wire cutters; Cutter bars [hand tools]; Miter cutters being hand tools; Stencil cutters [hand-operated tools]; Scoring knife for veneer sheets; Knives; Drawing knives; Utility knives; Die holders for use with hand operated tools; Grindstones [hand tools]. Industrial work tables; Worktables.
