The invention relates to a cell contacting system for an electrochemical module which comprises a plurality of cell groups, each of which comprises a plurality of electrochemical cells, each electrochemical cell having a first cell terminal and a second cell terminal, the cell terminals being contacted by means of electrically conductive contact regions which follow the associated cell terminal along a contacting direction, the first cell terminals of a first cell group having the highest electric potential and the second cell terminals of a second cell group having the lowest electric potential and the first cell terminals of the first cell group being electrically connected to a first busbar and the second cell terminals of the second cell group being electrically connected to a second busbar, the electrochemical cells of the first cell group following one another along the longitudinal direction and the electrochemical cells of the second cell group following one another along the longitudinal direction and at least one of the busbars having a main surface which extends parallel to the longitudinal direction. In order to provide a cell contacting system of this type which at least partially overcomes the problems of known cell contacting systems, according to the invention the main surface of the at least one busbar extends substantially parallel to the contacting direction of the electrochemical module.
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 50/30 - Aménagements pour faciliter l’échappement des gaz
H01M 50/507 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie comprenant un arrangement de plusieurs barres omnibus réunies dans une structure de conteneur, p. ex. modules de barres omnibus
A control device having a control unit for a battery system that has a number of storage cells, which are connected to a control unit and also to one another, wherein each of the storage cells is assigned a cell supervision circuit having connected sensors. In order to eliminate disadvantages in scalability and achieve the most accurate possible control and monitoring even for a large battery system, it is proposed to provide subgroups of interconnected storage cells and/or modules within the battery system, with each subgroup having a respective micro-master to which all of the cell supervision circuits of the relevant subgroup are connected and the micro-master being embodied to evaluate and filter all of the data from the cell supervision circuits and being connected to a battery management system by means of the control unit for the data transfer.
H01M 10/42 - Procédés ou dispositions pour assurer le fonctionnement ou l'entretien des éléments secondaires ou des demi-éléments secondaires
H01M 10/48 - Accumulateurs combinés à des dispositions pour mesurer, tester ou indiquer l'état des éléments, p. ex. le niveau ou la densité de l'électrolyte
In order to provide a shielding element for the electromagnetic shielding of an electronic component, said shielding element having a low weight, being able to be produced cost-effectively and having a simple structure, it is proposed that the shielding element comprises a main body with a coupling device by means of which the main body can be coupled to a corresponding device, and at least one electrically conductive layer which is provided at and/or in the main body, at least in some regions, wherein the main body and the at least one electrically conductive layer are interconnected, in particular are joined together by means of an injection-moulding operation, a injection compression moulding operation and/or a pressing operation.
A pack and/or module based on elementary cells of a cylindrical design, in which the elementary cells are electrically connected to one another in series and parallel circuits by a cell contacting system, wherein a contacting of both poles of each elementary cell is provided on a free upper side of the module or pack, and to a battery system constructed therefrom, which is provided as a device for outputting and storing electrical energy. In order to produce a module and/or a pack that can be used to achieve customer-specific solutions, a carrier is spatially predefined as a module or pack format with a fixed number of elementary cells, wherein the electrical properties of the module and/or pack can be adjusted by selecting a cell contacting system with a respectively adapted interconnection of the elementary cells and these are connected on the free upper side of the module or pack.
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
H01M 50/509 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par le type de connexion, p. ex. connexions mixtes
5.
INSULATION ELEMENT, METHOD FOR PRODUCING AN INSULATION ELEMENT, AND HOUSING COMPONENT HAVING AN INSULATION ELEMENT
The present invention relates to an insulation element (100), in particular for insulating housing components of energy stores or energy converters, for example for an electrically operated motor vehicle, the insulation element (100) comprising or being made of an insulation material (102), the insulation material (102) comprising or being made of at least one additive (104a, 104b), in particular for increasing a thermal and/or electrical and/or mechanical resistance of the insulation element (100). The invention also relates to a method for producing an insulation element (100).
H01M 50/124 - Boîtiers primairesFourreaux ou enveloppes caractérisés par le matériau ayant une structure en couches
H01M 50/131 - Boîtiers primairesFourreaux ou enveloppes caractérisés par les propriétés physiques, p. ex. la perméabilité au gaz, les dimensions ou la résistance à la chaleur
H01M 50/231 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par le matériau des boîtiers ou des bâtis ayant une structure en couches
H01M 50/233 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions
H01M 50/242 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions adaptés pour protéger les batteries contre les vibrations, les collisions ou le gonflement
H01M 50/249 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports spécialement adaptés aux aéronefs ou aux véhicules, p. ex. aux automobiles ou aux trains
H01M 10/658 - Moyens de commande de la température associés de façon structurelle avec les éléments par isolation ou protection thermique
6.
STRUCTURAL COMPONENT AND METHOD FOR PRODUCING A STRUCTURAL COMPONENT
In order to provide a structural component, in particular a cockpit cross-member for a motor vehicle, which can be produced simply and cost-effectively, according to the invention the structural component comprises the following: a profile element which has a peripheral wall that delimits an interior of the profile element at least in regions, and at least one through opening provided in the peripheral wall of the profile element; at least one fastening element which is arranged in the interior of the profile element so as to correspond to the at least one through opening; and at least one pressure-forming portion which is formed on the profile element and/or on the fastening element and positions the fastening element with respect to the through opening.
The invention relates to a storage device (200) for receiving, storing and releasing electrical energy, the storage device (200) comprising the following: a storage cell (140); a packing unit (110), the packing unit (110) exhibiting a sealing element (120); and a temperature control zone (130) on one side of the packing unit (110), wherein at least one region of the storage cell (140) extends into the temperature-control zone (130); wherein the sealing element (120) surrounds a cell casing (144) of the storage cell (140) and delimits the temperature-control zone (130) from an adjacent zone.
H01M 50/289 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par des éléments d’espacement ou des moyens de positionnement dans les racks, les cadres ou les blocs
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
8.
PRODUCTION METHOD FOR A COMBINATION COMPONENT WITH A PTFE MATERIAL AND COMBINATION COMPONENT PRODUCED BY MEANS OF SAID PRODUCTION METHOD
The present invention relates to a production method for a combination component with a PTFE material integrally joined thereto and to a combination component produced by means of said production method. The aim of the invention is to improve a production method for a combination component with a PTFE material such that the molded part is manufactured more quickly and more economically with less material use while greater reliability in continuous operation is obtained. To achieve this aim, the part made of the material having higher temperature resistance is inserted or laid into a lower part (10) of a sintering mold (11) such that a portion of the part that is widened and/or provided with undercuts (8) protrudes freely into a space between the lower part (10) and an associated upper part (12) of the sintering mold (11), and a predefined amount of a pulverous PTFE material is introduced into the lower part (10) of the sintering mold (11), the sintering mold (11) is closed, pressed and then, while at a specific pressure, heated up to a melting temperature of the PTFE material over a process time in a specified way and subsequently cooled while at a defined pressure, and finally the combination component (1) is removed from the opened sintering mold (11).
B29C 43/00 - Moulage par pressage, c.-à-d. en appliquant une pression externe pour faire couler la matière à moulerAppareils à cet effet
B29C 43/18 - Moulage par pressage, c.-à-d. en appliquant une pression externe pour faire couler la matière à moulerAppareils à cet effet pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés en incorporant des parties ou des couches préformées, p. ex. moulage par pressage autour d'inserts ou sur des objets à recouvrir
The invention relates to an energy storage unit, wherein the energy storage unit can in particular be an energy storage module and/or the energy storage unit can make available energy, in particular electrical energy, for driving a motor vehicle, the energy storage unit comprising the following: multiple energy storage elements, preferably multiple electrochemical energy storage elements, for example multiple battery cells; and a temperature-control fluid barrier, wherein said temperature-control fluid barrier extends around a temperature-control space and in said temperature-control space at least a plurality of the energy storage elements can be temperature-controlled by means of a temperature-control fluid.
H01M 10/6556 - Composants solides comprenant des canaux d'écoulement ou des tubes pour un échange de chaleur
H01M 50/209 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules prismatiques ou rectangulaires
10.
ENERGY STORAGE UNIT, MONITORING UNIT AND CONTACTING SYSTEM
The invention relates to an energy storage unit, wherein the energy storage unit can be in particular an energy storage module and/or the energy storage unit can make available energy, in particular electrical energy, for driving a motor vehicle, the energy storage unit comprising the following: multiple energy storage elements, preferably multiple electrochemical energy storage elements, for example multiple battery cells; and a temperature-control fluid barrier, wherein said temperature-control fluid barrier extends around a temperature-control space and in said temperature-control space at least a plurality of the energy storage elements can be temperature-controlled by means of a temperature-control fluid.
H01M 10/6556 - Composants solides comprenant des canaux d'écoulement ou des tubes pour un échange de chaleur
H01M 50/209 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules prismatiques ou rectangulaires
11.
ENERGY STORAGE UNIT AND METHOD FOR CONTROLLING THE TEMPERATURE OF AN ENERGY STORAGE UNIT
The invention relates to an energy storage unit, wherein the energy storage unit can in particular be an energy storage module and/or the energy storage unit can make available energy, in particular electrical energy, for driving a motor vehicle, the energy storage unit comprising the following: multiple energy storage elements, preferably multiple electrochemical energy storage elements, for example multiple battery cells; and a temperature-control fluid barrier, wherein said temperature-control fluid barrier extends around a temperature-control space and in said temperature-control space at least a plurality of the energy storage elements can be temperature-controlled by means of a temperature-control fluid.
The invention relates to an energy storage unit, wherein the energy storage unit can in particular be an energy storage module and/or the energy storage unit can make available energy, in particular electrical energy, for driving a motor vehicle, the energy storage unit comprising the following: multiple energy storage elements, preferably multiple electrochemical energy storage elements, for example multiple battery cells; and a temperature-control fluid barrier, wherein said temperature-control fluid barrier extends around a temperature-control space and in said temperature-control space at least a plurality of the energy storage elements can be temperature-controlled by means of a temperature-control fluid.
H01M 50/204 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 10/613 - Refroidissement ou maintien du froid
H01M 50/242 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions adaptés pour protéger les batteries contre les vibrations, les collisions ou le gonflement
H01M 50/249 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports spécialement adaptés aux aéronefs ou aux véhicules, p. ex. aux automobiles ou aux trains
13.
ENERGY STORAGE UNIT, SUPERVISORY UNIT AND METHOD FOR PRODUCING AN ENERGY STORAGE UNIT
The invention relates to an energy storage unit, wherein the energy storage unit can in particular be an energy storage module and/or the energy storage unit can make available energy, in particular electrical energy, for driving a motor vehicle, the energy storage unit comprising the following: multiple energy storage elements, preferably multiple electrochemical energy storage elements, for example multiple battery cells; and a temperature-control fluid barrier, wherein said temperature-control fluid barrier extends around a temperature-control space and in said temperature-control space at least a plurality of the energy storage elements can be temperature-controlled by means of a temperature-control fluid.
H01M 50/204 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
The invention relates to an energy storage unit, wherein the energy storage unit can in particular be an energy storage module and/or the energy storage unit can make available energy, in particular electrical energy, for driving a motor vehicle, the energy storage unit comprising the following: multiple energy storage elements, preferably multiple electrochemical energy storage elements, for example multiple battery cells; and a temperature-control fluid barrier, wherein said temperature-control fluid barrier extends around a temperature-control space and in said temperature-control space at least a plurality of the energy storage elements can be temperature-controlled by means of a temperature-control fluid.
H01M 50/242 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions adaptés pour protéger les batteries contre les vibrations, les collisions ou le gonflement
H01M 50/502 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
The invention concerns a sealing element (10) for a sealing arrangement (40) for sealing a transition between two devices, wherein the sealing element (10) has a flat carrier means (12) formed of an electrically conductive material and having a first side (24) and a second side (26) in each case for abutting against one of the devices, wherein the carrier means (12) has a sealing region (13) and a contacting region (16), wherein the carrier means (12) has a sealing coating (14) on its surface in the sealing region (13), wherein the carrier means (12) has an opening (18) which defines an interior of the sealing element (10), wherein the sealing element (10) has a sealing abutment structure (28, 30) in the sealing region (13) on each of the first side (24) and second side (26) and an electrical contacting abutment structure (34, 38) in the contacting region (16) on each of the first and second sides. A sealing arrangement (46) has a plurality of such sealing elements (10), wherein the sealing elements (10) are arranged abutting one another in such a way that in each case first sides (24) of neighbouring sealing elements (10) abut one another and second sides (26) of neighbouring sealing elements (10) abut one another.
F16J 15/08 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre exclusivement par garniture métallique
To improve a vehicle body unit (210), comprising at least one support element (212) extending in particular longitudinally, at least one injection moulding element (214) and at least one functional element (310), the invention proposes that at least one functional element (310), in particular with a retaining part (312), is arranged at least partially in contact with the at least one support element (212) and that at least one retaining component (362) of at least one injection moulding element (214) is at least partially moulded onto the at least one support element (212) and the at least one adjacently arranged functional element (310).
B60R 19/04 - Pare-chocs, c.-à-d. éléments pour recevoir ou absorber les chocs pour protéger les véhicules ou dévier les chocs provenant d'autres véhicules ou objets formés de plusieurs sections
To create a cell connector for electrically conductively connecting at least one first cell terminal of a first electrochemical cell and at least one second cell terminal of a second electrochemical cell, comprising at least one first contact area, for electrically conductively connecting the cell connector to the at least one first cell terminal, at least one second contact area, for electrically conductively connecting the cell connector to the at least one second cell terminal, and at least one elastically and/or plastically deformable connection area, arranged in the flow path between the at least one first contact area and the at least one second contact area, the cell connector requiring little installation space and allowing a small distance between the electrochemical cells that are electrically conductively connected to one another by the cell connector, it is proposed that the connection area is formed at least partially from a work-hardened metallic material.
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
H01M 50/521 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par le matériau
20.
HOUSING OR PORTION OF A HOUSING FOR AN ELECTRONIC CIRCUIT
A housing or a portion of a housing for an electronic circuit, preferably an electrical system component of a vehicle. In order to provide a housing for an electronic circuit, preferably an electrical system component of a vehicle and in particular a battery storage device, which has improved properties, even beyond a thermal runaway or comparable exceptional thermal conditions, it is proposed for the housing or a portion of the housing to have a surface, which is embodied as a shielding device with an insulating layer facing the electronic circuit and a metallic outer layer, and for the housing or a portion of the housing to have a heat sink.
Described is a cover element for a battery housing of a battery storage device, in particular a high-voltage battery, including a plurality of battery cells, of an at least partially electrically driven motor vehicle. The cover element has a sandwich design including a first cover layer, a second cover layer, and an intermediate layer arranged between the cover layers. When the cover element is mounted on the battery housing, the first cover layer faces the battery storage device and the second cover layer faces away from the battery storage device. The first cover layer has a plurality of breaking portions which are movable relative to the first cover layer according to a pressure prevailing in a region of a relevant breaking portion, so that a break opening is formed, Also described in the context of the cover element is a battery housing and a motor vehicle.
H01M 50/282 - Couvercles des boîtiers secondaires, des bâtis ou des blocs caractérisés par le matériau ayant une structure en couches
H01M 50/231 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par le matériau des boîtiers ou des bâtis ayant une structure en couches
H01M 50/249 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports spécialement adaptés aux aéronefs ou aux véhicules, p. ex. aux automobiles ou aux trains
H01M 50/28 - Matériau composite constitué d’un mélange de matériaux organiques et inorganiques
The present invention relates to a control method for a battery system which is designed for use in an electric vehicle. In order to improve a control method for battery systems such that it permits changes in a current pulse concept in adaptation to particular elementary storage cells used, and preventatively counteracts a rapidly advancing ageing of the storage cells in a more reliable manner, the invention proposes that the control method for implementing a current pulse concept is adjusted accordingly to a respective battery system with the cell types provided therein and their designs and cell chemistry, wherein a current above a permitted constant current is used and the control is carried out on the basis of an estimate of a temperature change in the storage cells.
Galvanic cells and/or battery modules comprising several galvanic cells, which have an increased service life and which are in particular easy and inexpensive to manufacture.
H01M 50/291 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par des éléments d’espacement ou des moyens de positionnement dans les racks, les cadres ou les blocs caractérisés par leur forme
H01M 10/6555 - Barres ou plaques disposées entre les éléments
H01M 50/209 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules prismatiques ou rectangulaires
H01M 50/242 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions adaptés pour protéger les batteries contre les vibrations, les collisions ou le gonflement
H01M 50/474 - Éléments d'espacement à l'intérieur des cellules autres que les séparateurs, les membranes ou les diaphragmesLeurs procédés de fabrication caractérisés par leur position dans les cellules
H01M 50/477 - Éléments d'espacement à l'intérieur des cellules autres que les séparateurs, les membranes ou les diaphragmesLeurs procédés de fabrication caractérisés par leur forme
24.
DISCHARGE UNIT, DISCHARGE ARRANGEMENT AND FORCE TRANSMISSION ARRANGEMENT
The invention relates to a discharge unit (128) for arrangement on a moveable force transmission element (103) which extends along a longitudinal axis, for example for arrangement on a shaft (104) the rotational axis (107) of which forms the longitudinal axis, wherein either the discharge unit (128) comprises the following: - an outer carrier element (132) and - a discharge element (150) fastened to the outer carrier element (132) and extending in the direction towards the longitudinal axis (106) or extending radially inwardly, or the discharge unit comprises the following: - an inner carrier element (218) and - a discharge element (150) fastened to the inner carrier element (218) and extending in the direction away from the longitudinal axis (106) and/or extending radially outwardly.
F16J 15/3212 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques avec au moins une lèvre pourvue d’éléments de tension, p. ex. de bagues élastiques avec des ressorts métalliques
F16J 15/3228 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques avec au moins une lèvre formée par déformation d’une bague plate
F16J 15/3284 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques caractérisés par leur structureEmploi des matériaux
A sealing element made of a plastic, which is embodied to seal against an actuator and consists of a plastic or resin that can be handled in an injection molding process. In order to significantly improve a sealing tightness of injection molded sealing elements made of a plastic, according to the invention the sealing element, as a direct product of an injection molding process, is provided with a structure in the form of a groove in the sealing surface, which groove is distributed over the periphery of the sealing surface.
B29K 21/00 - Utilisation de caoutchouc non spécifié ou élastomères non spécifiés comme matière de moulage
B29L 31/26 - Dispositifs d'étanchéité, p. ex. garniture pour pistons ou raccords de tuyaux
F16J 15/3284 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques caractérisés par leur structureEmploi des matériaux
The invention relates to an electric housing as a housing for an electric circuit which is designed in particular as a module made of a plurality of elementary electric storage cells in order to form a battery module, wherein the electric housing comprises a lower part (10) or a trough and a cover (11). The aim of the invention is to provide an electric housing which is improved with respect to the properties thereof during use. This is achieved in that the lower part (10) and/or the cover (11) of the electric housing consists of a multilayer composite (1) comprising at least one insulating layer (2), by means of which a conductive outer layer (3) is electrically separated or insulated from a conductive inner layer (4) when the electric housing is closed.
H01M 50/126 - Boîtiers primairesFourreaux ou enveloppes caractérisés par le matériau ayant une structure en couches comprenant au moins trois couches
H01M 50/231 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par le matériau des boîtiers ou des bâtis ayant une structure en couches
H01M 50/282 - Couvercles des boîtiers secondaires, des bâtis ou des blocs caractérisés par le matériau ayant une structure en couches
H05K 5/00 - Enveloppes, coffrets ou tiroirs pour appareils électriques
27.
METHOD FOR PRODUCING AN EMBOSSING TOOL FOR BIPOLAR PLATES AND EMBOSSING TOOL
The invention relates to a method for producing an embossing tool (10) for producing bipolar plates, which has an embossing field (12), said method comprising the following steps: milling, in a first step (102), an erosion electrode and eroding, in a second step (104), the embossing field (12) or an embossing plate (18) of the embossing field (12) by means of the erosion electrode. The invention also relates to an embossing tool (10) for producing bipolar plates, which has an embossing field (12), wherein the embossing field (12) has a plurality of embossing plates (18) arranged adjacent to one another.
H01M 8/02 - Éléments à combustibleLeur fabrication Détails
B23H 3/04 - Électrodes spécialement adaptées à cet effet ou leur fabrication
B23P 15/24 - Fabrication d'objets déterminés par des opérations non couvertes par une seule autre sous-classe ou un groupe de la présente sous-classe de matrices
28.
PROTECTIVE ELEMENT, METHOD FOR PRODUCTION THEREOF, ENERGY STORAGE SYSTEM AND MOTOR VEHICLE
The invention relates to a protective element, in particular for an energy storage system or for a motor vehicle, the protective element comprising the following: a shielding element, e.g. a wall, and protective material arranged or formed on a surface of the shielding element.
H01M 10/658 - Moyens de commande de la température associés de façon structurelle avec les éléments par isolation ou protection thermique
C23C 4/08 - Matériaux métalliques ne contenant que des éléments métalliques
C23C 4/10 - Oxydes, borures, carbures, nitrures ou siliciuresLeurs mélanges
C23C 30/00 - Revêtement avec des matériaux métalliques, caractérisé uniquement par la composition du matériau métallique, c.-à-d. non caractérisé par le procédé de revêtement
H01M 50/231 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par le matériau des boîtiers ou des bâtis ayant une structure en couches
H01M 50/24 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions adaptés pour protéger les batteries de leur environnement, p. ex. de la corrosion
H01M 50/242 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions adaptés pour protéger les batteries contre les vibrations, les collisions ou le gonflement
29.
PROTECTIVE ELEMENT, ENERGY SUPPLY SYSTEM, COMMUNICATIONS SYSTEM AND MOTOR VEHICLE
A protective element (102) for improving electromagnetic compatibility, the protective element (102) comprising the following: a shielding layer (114) for protection against electric, magnetic or electromagnetic fields.
H05K 9/00 - Blindage d'appareils ou de composants contre les champs électriques ou magnétiques
H01M 50/231 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par le matériau des boîtiers ou des bâtis ayant une structure en couches
30.
CONTACTING UNIT, ENERGY STORAGE UNIT, AND CONSTRUCTION KIT FOR PRODUCING A CONTACTING UNIT
The invention relates to a contacting unit, preferably for an energy storage unit for receiving, storing, and/or providing electric energy, said contacting unit comprising the following: a delimiting element, preferably for delimiting the interior of the energy storage unit from the exterior located outside of the energy storage unit; a current-conducting element or a part of a current-conducting element, wherein the current-conducting element or the part of the current-conducting element extends through the delimiting element, and an electric current can be conducted through the delimiting element via the current-conducting element or the part of the current-connecting element; and a separating element which separates the current-conducting element or the part of the current-conducting element from the delimiting element.
The invention relates to a contacting unit, preferably for an energy storage unit for receiving, storing, and/or providing electric energy, said contacting unit comprising the following: a delimiting element, preferably for delimiting the interior of the energy storage unit from the exterior located outside of the energy storage unit; a current-conducting element or a part of a current-conducting element, wherein the current-conducting element or the part of the current-conducting element extends through the delimiting element, and an electric current can be conducted through the delimiting element via the current-conducting element or the part of the current-connecting element; and a separating element which separates the current-conducting element or the part of the current-conducting element from the delimiting element.
The invention relates to a contacting unit, preferably for an energy storage unit for receiving, storing, and/or providing electric energy, said contacting unit comprising the following: a delimiting element, preferably for delimiting the interior of the energy storage unit from the exterior located outside of the energy storage unit; a current-conducting element or a part of a current-conducting element, wherein the current-conducting element or the part of the current-conducting element extends through the delimiting element, and an electric current can be conducted through the delimiting element via the current-conducting element or the part of the current-connecting element; and a separating element which separates the current-conducting element or the part of the current-conducting element from the delimiting element.
A gasket (120), in particular for an electrical or automotive assembly, for sealing between mating parts (112, 114), comprising a sealing section (212) and at least one electrically connecting unit (252), wherein the sealing section (212) comprises a first group of at least one sealing face (216, 218) for one mating part (112, 114) and a second group of at least one sealing face (216, 218) for the other mating part (112, 114) and wherein the electrically connecting unit (252) comprises a first group of at least one electrically conductive contacting face (264) for the one mating part (112, 114) and a second group of at least one electrically conductive contacting face (264) for the other mating part (112, 114), wherein a sealing face (216, 218) and an electrically conductive contacting face (264) of the first group and/or of the second group are different faces.
H01R 4/64 - Connexions entre ou avec des parties conductrices n'ayant pas au premier chef de fonction électrique, p. ex. châssis, boîtier, rail
F16J 15/08 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre exclusivement par garniture métallique
B60R 16/00 - Circuits électriques ou circuits de fluides spécialement adaptés aux véhicules et non prévus ailleursAgencement des éléments des circuits électriques ou des circuits de fluides spécialement adapté aux véhicules et non prévu ailleurs
F16J 15/12 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre par garniture non métallique par renforcement ou couverture métallique
H05K 9/00 - Blindage d'appareils ou de composants contre les champs électriques ou magnétiques
36.
RUPTURE DEVICE, WALL, HOUSING COMPONENT, HOUSING ASSEMBLY, HOUSING, ELECTROCHEMICAL CELL, ELECTROCHEMICAL SYSTEM, VEHICLE, AND METHOD FOR PRODUCING A RUPTURE DEVICE
The invention relates to a rupture device (110) comprising a barrier zone (132) and a rupture bridge (130), wherein the rupture device (110) has a depression (134), wherein a depression inner surface (170) extending into the depression (134) forms a surface (172) of the rupture bridge (130), wherein it is preferred if the rupture bridge (130) forms at least a part (153) of a base region (152) of the depression (134).
H01M 50/204 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules
H01M 50/249 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports spécialement adaptés aux aéronefs ou aux véhicules, p. ex. aux automobiles ou aux trains
A control device of a battery storage device, preferably a control device for and/or in a high-voltage battery storage device of an electric vehicle, wherein modules (Mod 1, . . . , Mod 16) are interconnected in the battery storage device via electromechanical components, e.g. in the form of contactors, fuses, and busbars, and are connected to a battery management system for controlling charging and discharging. In order to create a control device for a battery storage device by means of which the string currents are measured with a high degree of accuracy, it is proposed that in addition to a sensor for a total current, the control device is also connected to a sensor, which is embodied to measure a differential current between two strings.
In order to provide a pressure relief device for opening a relief opening in a housing, in particular a battery storage housing, said pressure relief device providing a safe mode of functioning and having a simple structure, it is proposed that the pressure relief device has a main body which can be arranged in the relief opening and has a passage which connects an inlet and an outlet through which a medium can flow, a closing element which, if a defined activation pressure is exceeded, can be transferred from a closed position, in which the closing element closes the passage, to an open position in which the closing element releases the passage, and a cover which at least partly covers the closing element and/or passage and performs a setting movement with the closing element in order to release the passage.
METHOD FOR PRODUCING A FLAT PLASTIC COMPONENT, IN PARTICULAR AN UNDERFLOOR PROTECTION ELEMENT OF A MOTOR VEHICLE, PLASTIC COMPONENT, AND MOTOR VEHICLE COMPRISING AN UNDERFLOOR PROTECTION ELEMENT
The invention relates to a method (500) for producing a flat plastic component (18), in particular an underfloor protection element (40) for covering a battery storage unit of a motor vehicle, the method (500) comprising the following steps: providing (S501) at least one plastic insert element (10) comprising continuous fibres; providing (S501) a moulding compound volume (12) made of plastic; arranging (S503) the moulding compound volume (12) and the at least one insert element (10) in a compression moulding tool (14) having a tool half (14-2) which faces the insert element (10) and in which a plurality of cavities (16) are formed; closing (S504) the compression moulding tool (14) and building up an internal pressure in the compression moulding tool (14). According to the invention: when the internal pressure is built up, the insert element (10) arranged on the relevant mould half (14-2), in particular adjacent to said mould half, is draped (S505) locally in the region of the cavities (16) so that the insert element (10) is pressed in part into a relevant cavity (16) of the mould half (14-2) and deformed, while the density of fibres in the insert element (10) is at least in part locally reduced; and the internal pressure in the moulding tool (14) is increased so that moulding compound (12) in the region of the deformed insert element (10), which is more permeable due to the reduced fibre density, is pressed (S506) through the insert element (10), which is locally at least partially structurally weakened, and is distributed in the cavity (16), in particular along the insert element (10).
B29C 43/02 - Moulage par pressage, c.-à-d. en appliquant une pression externe pour faire couler la matière à moulerAppareils à cet effet pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés
B29C 43/20 - Fabrication d'objets multicouches ou polychromes
B29C 43/18 - Moulage par pressage, c.-à-d. en appliquant une pression externe pour faire couler la matière à moulerAppareils à cet effet pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés en incorporant des parties ou des couches préformées, p. ex. moulage par pressage autour d'inserts ou sur des objets à recouvrir
B29C 43/00 - Moulage par pressage, c.-à-d. en appliquant une pression externe pour faire couler la matière à moulerAppareils à cet effet
B29K 105/08 - Présentation, forme ou état de la matière moulée contenant des agents de renforcement, charges ou inserts de grande longueur, p. ex. ficelles, mèches, mats, tissus ou fils
B29L 31/30 - Véhicules, p. ex. bateaux ou avions, ou éléments de leur carrosserie
The invention relates to a storage device for receiving, storing and releasing electrical energy, the storage device comprising the following: a plurality of storage cells; a connecting element that connects at least two of the storage cells; and a temperature control zone on one side of the connecting element; wherein the storage cells that are connected by the connecting element extend into the temperature control zone or through the temperature control zone; wherein the connecting element surrounds the cell casings of the storage cells that are connected by the connecting element and delimits the temperature control zone with respect to an adjacent zone; and wherein the connecting element may preferably form a barrier by means of which a passage of a temperature control fluid, which can be conducted in the temperature control zone, from the temperature control zone into the adjacent zone can be counteracted.
H01M 10/60 - Chauffage ou refroidissementCommande de la température
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 50/289 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par des éléments d’espacement ou des moyens de positionnement dans les racks, les cadres ou les blocs
H01M 50/293 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par des éléments d’espacement ou des moyens de positionnement dans les racks, les cadres ou les blocs caractérisés par le matériau
41.
Functional Part, and Functional System Comprising a Functional Part
In order to improve a functional part, in particular a fitting, for example for a housing, comprising a connection receptacle or a plurality of connection receptacles, wherein the connection receptacle or each of the plurality of connection receptacles is configured to receive a connection mating piece of another part, in particular a connection mating piece of a housing part, in particular in the form of a bayonet closure in order to securely and releasably connect the functional part to the other part, it is proposed that the one connection receptacle or at least one connection receptacle, in particular some or each of the plurality of connection receptacles, is configured to receive connection mating pieces of different sizes, in particular so as to produce a secure connection.
In order to provide a structural component (100) for a vehicle (102), in particular a bulkhead (104) for a road vehicle, for example for a passenger car (106), which can be produced simply and cost-effectively and preferably simultaneously meets requirements relating to weight reduction and structural integrity, according to the invention the structural component (100), in particular the bulkhead (104), comprises the following: a main body (108), which comprises one or more foamed portions (124) and one or more compact portions (130), the structural component (100) preferably also comprising one or more cover elements (126) which cover the main body (108) in one or more foamed portions (124) and/or in one or more compact portions (130).
B29C 44/14 - Incorporation ou surmoulage de parties préformées, p. ex. des inserts ou des renforcements la partie préformée étant une couche de garnissage
B29C 44/34 - Éléments constitutifs, détails ou accessoiresOpérations auxiliaires
B29C 44/42 - Alimentation en matière à mouler dans une cavité de moulage fermée, c.-à-d. pour la fabrication d'objets de longueur définie par différence de pression, p. ex. par injection ou sous vide
B29C 44/56 - Post-traitement d'objets, p. ex. pour changer leur forme
B29L 31/30 - Véhicules, p. ex. bateaux ou avions, ou éléments de leur carrosserie
43.
CELL HOUSING, ELEMENTARY ELECTRIC STORAGE CELL AND METHOD FOR PRODUCTION
The present invention relates to a cell housing and to an elementary electric storage cell constructed herewith for constructing a rechargeable battery module which is in particular intended for a high-voltage battery system, such as that installed in electric vehicles, for example. The invention also relates to a method for producing such a housing. In order to create an improved cell housing (5) of an elementary storage cell (3) comprising a cell cup (6) or cell casing (6a) and a cell cover (7), in which at least one electric pole (8) is arranged as a contact, and an elementary electric storage cell constructed herewith, it is proposed that the cell housing (5) comprises a cell cup (6) or cell casing (6a) with an aluminium-steel composite and a cell cover (7) of aluminium, which are integrally bonded to one another.
The present invention relates to a moulded element for arrangement on a temperature-controlled element, wherein the temperature-controlled element can preferably be an energy storage element, e.g. an electrochemical energy storage cell, wherein the moulding element comprises: at least one receiving zone for receiving at least a portion of the temperature-controlled element in the moulding element and a moulding element material, the density of which is at most 0.75 g/cm3, preferably at most 0.65 g/cm3, particularly preferably at most 0.55 g/cm3.
H01M 10/653 - Moyens de commande de la température associés de façon structurelle avec les éléments caractérisés par des matériaux électriquement isolants ou thermiquement conducteurs
H01M 10/658 - Moyens de commande de la température associés de façon structurelle avec les éléments par isolation ou protection thermique
The present invention relates to a cell separator which is arranged between adjacent elementary storage cells in a battery module, and to a battery module which is constructed with the cell separator and is provided in particular for a high-voltage battery system, as is provided for electric vehicles. In order to improve a cell separator and a battery module which is constructed with the cell separator, the invention proposes that an active heating measure is arranged integrated in the cell separator (4).
The present invention relates to a protective element (102) for arrangement on a device which emits electromagnetic radiation, wherein the device can be, for example, an at least partially electrically powered motor vehicle, the protective element (102) comprising the following: a shield layer (114) for shielding against electromagnetic radiation, a plastic layer (118), and a contacting zone (120) by means of which electrical contact can be established between the shield layer (114) and the device.
H01M 50/249 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports spécialement adaptés aux aéronefs ou aux véhicules, p. ex. aux automobiles ou aux trains
B32B 5/02 - Produits stratifiés caractérisés par l'hétérogénéité ou la structure physique d'une des couches caractérisés par les caractéristiques de structure d'une couche comprenant des fibres ou des filaments
B32B 5/26 - Produits stratifiés caractérisés par l'hétérogénéité ou la structure physique d'une des couches caractérisés par la présence de plusieurs couches qui comportent des fibres, filaments, grains ou poudre, ou qui sont sous forme de mousse ou essentiellement poreuses une des couches étant fibreuse ou filamenteuse un autre couche également étant fibreuse ou filamenteuse
B32B 7/12 - Liaison entre couches utilisant des adhésifs interposés ou des matériaux interposés ayant des propriétés adhésives
B32B 15/04 - Produits stratifiés composés essentiellement de métal comprenant un métal comme seul composant ou comme composant principal d'une couche adjacente à une autre couche d'une substance spécifique
B32B 15/14 - Produits stratifiés composés essentiellement de métal adjacent à une couche fibreuse ou filamenteuse
B32B 15/20 - Produits stratifiés composés essentiellement de métal comportant de l'aluminium ou du cuivre
H01M 10/42 - Procédés ou dispositions pour assurer le fonctionnement ou l'entretien des éléments secondaires ou des demi-éléments secondaires
H01M 10/658 - Moyens de commande de la température associés de façon structurelle avec les éléments par isolation ou protection thermique
The invention relates to a stator device (100) for an electric machine. The stator device (100) comprises the following: a stator unit (102) and a seal element (106), wherein a cooling zone with a cooling channel region (110, 111) is formed on a surface of the stator unit (102), e.g. on the surface of a stator packet of the stator unit (102), and the seal element (106) at least partly seals the cooling zone in the axial direction.
H02K 1/20 - Parties fixes du circuit magnétique avec des canaux ou des conduits pour l'écoulement d'un agent de refroidissement
H02K 5/20 - Enveloppes ou enceintes caractérisées par leur configuration, leur forme ou leur construction avec des canaux ou des conduits pour la circulation d'un agent de refroidissement
H02K 9/19 - Dispositions de refroidissement ou de ventilation pour machines avec enveloppe fermée et circuit fermé de refroidissement utilisant un agent de refroidissement liquide, p. ex. de l'huile
48.
DEFORMATION ELEMENT AND USE OF A DEFORMATION ELEMENT AND ASSEMBLY COMPRISING A DEFORMATION ELEMENT
In order to improve a deformation element comprising an at least partly elastically deformable deformation body that has two supporting portions which are arranged off-set from each other in a vertical direction and a connection portion interconnecting the supporting portions, the deformation body has precisely one stabilizing structure or a number of stabilizing structures at the connection portion.
F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle
49.
BRAKING SYSTEM COMPRISING A FRICTION RING AND A BRAKE HAT
A braking system for a motor vehicle is proposed, comprising a friction ring and a brake hat, which is configured for fastening the friction ring to a motor vehicle axle, wherein the friction ring and the brake hat are connected to one another by a self-locking and/or self-braced connection.
In order to create a cover for a battery module or for a battery store that comprises a plurality of battery cells, said cover serving not only as contact protection or as protection from the ingress of particles, but also fulfilling the function of a propagation protection by means of which a propagation of a thermal fault from one battery cell of the battery module or the battery store to other battery cells of the battery module or the battery store is able to be prevented or at least delayed, it is proposed that the cover comprises a first layer facing toward the battery cells in the mounted state of the cover and a second layer facing away from the battery cells in the mounted state of the cover, wherein the first layer comprises at least one penetration device, which enables a passage of hot gas from a battery cell through the first layer at a penetration point, and wherein the gas that has passed through the first layer is able to be dissipated from the penetration point in an interspace between the first layer and the second layer.
H01M 50/367 - Passages internes d’évacuation des gaz dans le couvercle ou le boîtier de la batterieSystèmes d’évent à double couvercle
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 50/271 - Couvercles des boîtiers secondaires, des bâtis ou des blocs
H01M 50/383 - Moyens pare-flammes ou moyens de prévention de l’allumage
The present invention relates to a battery management system (BMS) in a battery system (1) such as is used, inter alia, in a hybrid vehicle or electric vehicle. In order to improve a battery management system (BMS) in a battery system (1), said battery management system being provided for constantly monitoring currents, voltages and temperatures within modules (2) of the battery system (1) which are interconnected in parallel, according to the invention only one superordinate battery management system (NV-BMS-) is provided in the battery system (1) having a parallel circuit of modules (2), said superordinate battery management system being connected to one cell supervisory circuit (CSC+) per module (2), and each cell supervisory circuit (CSC+) being connected to a current-measurement shunt device and being expanded to control switches.
H02J 7/00 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries
52.
PROTECTIVE DEVICE, ENERGY-STORE PROTECTIVE DEVICE, PROTECTIVE SYSTEM, METHOD FOR PRODUCING A PROTECTIVE SYSTEM, METHOD FOR PRODUCING A MOTOR VEHICLE, AND MOTOR VEHICLE
The present invention relates to a protective device (100) for arranging on an impact-sensitive element (102), for example on a battery element (106), wherein the protective device (100) comprises the following: a wall element (108) and an adaptation element (116) arranged on the wall element (108).
The invention relates to a protective element (114) for an electrochemical energy storage device (102), e.g. for a battery cell (104), wherein the protective element (114) comprises the following: a protective layer (116), e.g. a hot gas particle flow abrasion protection layer (118), said protective layer (116) comprising a protective material (120), e.g. a hot gas particle flow abrasion protection material (122).
H01M 10/658 - Moyens de commande de la température associés de façon structurelle avec les éléments par isolation ou protection thermique
H01M 50/293 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par des éléments d’espacement ou des moyens de positionnement dans les racks, les cadres ou les blocs caractérisés par le matériau
H01M 50/383 - Moyens pare-flammes ou moyens de prévention de l’allumage
In order to provide an electrochemical cell (100) that can be produced as simply as possible and has as long a service life as possible, according to the invention an electrochemical cell (100), in particular a cylindrical cell, is provided, which comprises: an electrochemical element (104), a housing (106), a first cell terminal (118) and a second cell terminal (120); wherein the electrochemical cell (100) also comprises a cast element, in particular a first cast element (128), for connecting the housing (106) and the first cell terminal (118) and/or a cast element, in particular a second cast element (154), for connecting the housing (106) and the second cell terminal (120).
H01M 50/107 - Boîtiers primairesFourreaux ou enveloppes caractérisés par leur forme ou leur structure physique ayant une section transversale courbe, p. ex. ronde ou elliptique
H01M 50/152 - Couvercles caractérisés par leur forme pour des cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 50/188 - Éléments de scellement caractérisés par la position des éléments de scellement les éléments de scellement étant arrangés entre le couvercle et la borne
The invention relates to a discharge element (100) for establishing an electrically conductive connection between a force-transmitting, movable device element (102), e.g. a shaft (104) or a piston rod, and a sealing arrangement (114), wherein the discharge element (100) comprises the following: a contact element (110), which can be brought into electrically conductive contact with at least one surface contact zone (112) of the device element (102) by mounting the discharge element (100) on the sealing arrangement (114), and a connection zone (106) for mounting the discharge element (100) on the sealing arrangement (114).
F16J 15/3204 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques avec au moins une lèvre
F16J 15/3284 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques caractérisés par leur structureEmploi des matériaux
The invention relates to a composite element (140), e.g. for a discharge element (100) or for a contact element (110), the composite element (140) comprising: a discharging material (176) and a reinforcing material (178).
F16J 15/06 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre
F16J 15/08 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre exclusivement par garniture métallique
F16J 15/3284 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques caractérisés par leur structureEmploi des matériaux
Elringklinger Automotive Manufacturing, Inc. Inc. (USA)
ElringKlinger AG (Allemagne)
Inventeur(s)
Clemons, Douglas
Schaefer, Gunnar
Abrégé
A shielding part, in particular a heat shield, having at least one shielding layer with at least one fastening opening through which a fastener can be inserted, wherein the fastener is coupled to the shielding layer via at least one decoupling element with regard to axial and/or radial force transmission to the shielding layer and from the shielding layer to the fastener, wherein the at least one decoupling element is composed of a metal wire and cooperates in a surrounding region around the fastening opening on opposite outer sides of the shielding layer and/or with a frontal hole edge of the fastening opening of the shielding layer, wherein at least one intermediate layer is positioned between the decoupling element and the outer sides of the shielding layer and between the decoupling element and the frontal hole edge of the fastening opening of the shielding layer.
The present invention relates to a high-voltage battery system (1) for storing electrical energy in a number of electrically interconnected elementary storage cells (4) that are under monitoring and control by way of a battery management system (7) via an analogue line and/or a data line (6) and, when the interconnected elementary storage cells (4) are electrically connected, via high-voltage paths (5) with circuit breakers (8) in a high-voltage distributor box (9) towards external high-voltage terminals (10). In order to provide a high-voltage battery system that is easier to transport and construct with an adjustable capacity, it is proposed that the high-voltage battery system (1) comprises a base system (2), has in the base system (2) at least one node (3) to an essentially electrically identical subsystem (12), wherein the node (3) is formed as an interface for an analogue line (6) and/or a data line of the subsystem (12) to the battery management system (7) of the base system (2) and as an interface for a high-voltage path (5) of the subsystem (12), and a subsystem (12) itself comprises essentially only one interconnected module (Mod).
The aim of the invention is to provide a battery module support which facilitates a compact battery module assembly and which is simple and inexpensive to produce. According to the invention, this is achieved by the battery module support having the following: at least one support element which is designed to receive a battery module, a first connecting section, and at least one additional connecting section, said sections being provided in opposite directions on opposing outer faces of the at least one support element, wherein the first connecting section and the at least one additional connecting section have connection profiles which are designed to complement each other.
H01M 50/207 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme
H01M 50/22 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par le matériau des boîtiers ou des bâtis
H01M 50/244 - Boîtiers secondairesBâtisDispositifs de suspensionDispositifs de manutentionSupports caractérisés par leur procédé de montage
H01M 50/258 - Batteries modulairesBoîtiers pourvus de moyens d’assemblage
H01M 50/264 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports avec des moyens de fixation, p. ex. des serrures pour des cellules ou des batteries, p. ex. cadres périphériques, courroies ou tiges
60.
COMPONENT, METHOD FOR PRODUCING A COMPONENT, AND ASSEMBLY
The aim of the invention is to provide a particularly planar component that is as simple as possible to produce and has an optimized stability. In order to achieve said aim, a component is proposed which comprises or is formed from a polymer matrix material and at least one non-compressible filler, wherein an average proportion of the at least one non-compressible filler is preferably approximately 75 wt. % or more, based on the total mass of the component and/or based on a local mass of the component in a locally compacted region of the component, wherein the component has one or more attachment regions for attaching the component to an additional component, and wherein a material of the component is compressed at least in the one or more attachment regions.
B29C 70/16 - Façonnage de matières composites, c.-à-d. de matières plastiques comprenant des renforcements, des matières de remplissage ou des parties préformées, p. ex. des inserts comprenant uniquement des renforcements, p. ex. matières plastiques auto-renforçantes des renforcements fibreux uniquement caractérisées par la structure des renforcements fibreux utilisant des fibres de grande longueur, ou des fibres continues
B32B 3/30 - Produits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche continue dont le périmètre de la section droite a une allure particulièreProduits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche comportant des cavités ou des vides internes caractérisés par une couche comportant des retraits ou des saillies, p. ex. des gorges, des nervures
H01M 50/00 - Détails de construction ou procédés de fabrication des parties non actives des cellules électrochimiques autres que les piles à combustible, p. ex. piles hybrides
H01M 50/229 - Matériau composite constitué d'un mélange de matériaux organiques et inorganiques
H01M 50/242 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par les propriétés physiques des boîtiers ou des bâtis, p. ex. dimensions adaptés pour protéger les batteries contre les vibrations, les collisions ou le gonflement
H01M 50/249 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports spécialement adaptés aux aéronefs ou aux véhicules, p. ex. aux automobiles ou aux trains
The present invention relates to a connection system for mechanically fixing neighbouring or adjacent bodies or modules (2) in a plane, more particularly flat solar modules, which are arranged above a substrate (3). To create a connection system (1) for mechanically fixing neighbouring bodies in a plane with free accessibility to any module for installation and/or deinstallation, the invention proposes that at the edge regions (4) of adjacent modules (2) a recess consisting of in each case two half-spaces (6) arranged flush with one another is provided, in the recess a fixing body (7) with a longitudinal cross-sectional surface (Q) can be rotated into the half-spaces (6) in an engaging manner approximately 90° about an axis (M) perpendicular to a surface normal (N) of the modules (2).
The present invention relates to a cooling device on a closed housing of an electronic component or a circuit. In order to provide a cooling device for an electronic component or a circuit in a closed housing, according to the invention a heat sink is disposed on a back side of the electronic component or circuit with good thermal coupling, the heat sink comprising at least one first metal plate (11) having a three-dimensional structure, heat being input via a flat base (13) of the first metal plate (11), and the heat being dissipated toward peaks (14) of the three-dimensional structure; at least one second metal plate (15) is disposed adjacent to the first metal plate (11) or the peaks (14) thereof, with contact, and thus dissipates heat further.
The invention relates to a method for producing a sealing element (100), wherein a flowable material is guided in a casting tool (192), for example in a compact casting tool (198), in such a way that (a) a sealing element moulded portion (148) corresponding to a sealing element portion (126) of the sealing element (100) is at least partially filled with the flowable material, (b) an intermediate moulding zone (184) which does not correspond to any sealing element portion (126, 128, 130) of the sealing element (100) is at least partially filled with the flowable material, and (c) a further sealing element moulded portion (150) corresponding to a further sealing element portion (128) of the sealing element (100) is at least partially filled with the flowable material.
B29C 45/56 - Moyens pour plastifier ou homogénéiser la matière à mouler ou pour la forcer dans le moule utilisant des éléments de moules mobiles pendant ou après l'injection, p. ex. pour le moulage par injection-pressage
The aim of the invention is to provide an electrochemical cell which is as simply constructed as possible and which requires as little production effort as possible. This is achieved by an electrochemical cell, in which a first connection conductor is secured to a cover element in a first connection region by means of a first potting element, said first potting element being surrounded and/or accommodated by a first compensation element of the electrochemical cell in the first connection region, and/or in which a second connection conductor is secured to the cover element in a second connection region by means of a second potting element, said second potting element being surrounded and/or accommodated by a second compensation element of the electrochemical cell in the second connection region.
H01M 50/536 - Connexions d’électrodes dans un boîtier de batterie caractérisées par le procédé de fixation des conducteurs aux électrodes, p. ex. soudage
H01M 50/55 - Bornes caractérisées par la position des terminaux sur les cellules sur le même côté de la cellule
H01M 50/15 - Couvercles caractérisés par leur forme pour des cellules prismatiques ou rectangulaires
65.
LAMINATED ELECTRICAL STEEL CORE ARRANGEMENT, LAMINATED STATOR CORE ARRANGEMENT AND STATOR DEVICE FOR AN ELECTRIC MACHINE, ELECTRIC MACHINE AND MOTOR VEHICLE
The invention relates to a laminated electrical steel core arrangement for an electric machine, wherein the laminated electrical steel core arrangement comprises the following: an laminated electrical steel core (100) that comprises electrical sheets (128) and wherein adjacent electrical sheets (128) are connected via composite layers (130), a separating element (112) and optionally a laminated electrical steel core carrier (108), wherein the separating element (112) is arranged on a surface (116) of the laminated electrical steel core (100) and/or on a surface (114) of the laminated electrical steel core carrier (108).
H02K 1/04 - Détails du circuit magnétique caractérisés par le matériau employé pour l'isolation du circuit magnétique ou de parties de celui-ci
H02K 1/18 - Moyens de montage ou de fixation des parties magnétiques fixes sur ou aux structures constituant le stator
H02K 5/20 - Enveloppes ou enceintes caractérisées par leur configuration, leur forme ou leur construction avec des canaux ou des conduits pour la circulation d'un agent de refroidissement
H02K 5/10 - Enveloppes ou enceintes caractérisées par leur configuration, leur forme ou leur construction avec des dispositions empêchant l'introduction de corps étrangers, p. ex. de l'eau ou des doigts
The aim of the invention is to provide a component, preferably a component for a vehicle, which is as stable as possible and which has an optimized electromagnetic compatibility. This is achieved by providing a component comprising a base element, which comprises or is made of at least one composite element, and a shielding element for electrically and/or electromagnetically shielding the component, wherein the shielding element comprises or is made of one or more foils, for example one or more metal foils, and is connected to the base element.
B32B 15/20 - Produits stratifiés composés essentiellement de métal comportant de l'aluminium ou du cuivre
B32B 15/085 - Produits stratifiés composés essentiellement de métal comprenant un métal comme seul composant ou comme composant principal d'une couche adjacente à une autre couche d'une substance spécifique de résine synthétique comprenant des polyoléfines
B32B 27/32 - Produits stratifiés composés essentiellement de résine synthétique comprenant des polyoléfines
B32B 5/02 - Produits stratifiés caractérisés par l'hétérogénéité ou la structure physique d'une des couches caractérisés par les caractéristiques de structure d'une couche comprenant des fibres ou des filaments
B32B 15/14 - Produits stratifiés composés essentiellement de métal adjacent à une couche fibreuse ou filamenteuse
B32B 37/04 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par la fusion partielle d'au moins une couche
B32B 37/06 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par le procédé de chauffage
H01M 50/124 - Boîtiers primairesFourreaux ou enveloppes caractérisés par le matériau ayant une structure en couches
H01M 50/164 - Couvercles caractérisés par le matériau ayant une structure en couches
H01M 50/129 - Boîtiers primairesFourreaux ou enveloppes caractérisés par le matériau ayant une structure en couches comprenant au moins trois couches dont au moins deux couches de matériaux organiques uniquement
A device for measuring cell voltages in a module that is composed of a plurality of individual cells inside a rechargeable battery. In order to create a device of the above-mentioned kind with reduced production complexity, the invention proposes measuring devices for voltage measurement via a housing of a respective cell to be electrically connected to a busbar.
G01R 31/3835 - Dispositions pour la surveillance de variables des batteries ou des accumulateurs, p. ex. état de charge ne faisant intervenir que des mesures de tension
H01M 50/569 - Détails de construction des connexions conductrices de courant pour détecter les conditions à l'intérieur des cellules ou des batteries, p. ex. détails des bornes de détection de tension
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 50/514 - Procédés pour interconnecter les batteries ou cellules adjacentes
H01M 10/653 - Moyens de commande de la température associés de façon structurelle avec les éléments caractérisés par des matériaux électriquement isolants ou thermiquement conducteurs
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
The invention relates to a rotor device (100) for an electric machine, wherein the rotor device (100) comprises the following: a rotor shaft (102), a rotor laminated core (105), which is held non-rotatably on the rotor shaft (102), and a temperature control fluid diverting unit (111, 115), which delimits a temperature control fluid diversion zone (110, 114) in a radially outward direction, wherein the rotor laminated core (105) comprises a rotor laminated core region (107), and a temperature control fluid channel (112) extends through the rotor laminated core region (107) and merges into the temperature control fluid diversion zone (110, 114).
H02K 9/19 - Dispositions de refroidissement ou de ventilation pour machines avec enveloppe fermée et circuit fermé de refroidissement utilisant un agent de refroidissement liquide, p. ex. de l'huile
H02K 1/32 - Parties tournantes du circuit magnétique avec des canaux ou des conduits pour l'écoulement d'un agent de refroidissement
H02K 15/03 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques comportant des aimants permanents
69.
STORAGE DEVICE, CELL MODULE, COMPONENT SET, SEALING ELEMENT SUPPORT, AND PRODUCTION METHODS AND USES RELATED THERETO
The invention relates to a storage device (200) for receiving, storing and releasing electrical energy, the storage device (200) comprising the following: a storage cell (140); a sealing unit (110), the sealing unit (110) having a sealing element (120); and a temperature control zone (130) on one side of the sealing unit (110), into which temperature control zone (130) at least one region of the storage cell (140) extends; wherein the sealing element (120) surrounds a cell casing (144) of the storage cell (140) and delimits the temperature control zone (130) with respect to an adjacent zone.
In order to provide a structural component, in particular a cockpit cross-member for a motor vehicle, which can be produced simply and cost-effectively, according to the invention the structural component comprises the following: a profile element which has a peripheral wall that delimits an interior of the profile element at least in regions, and at least one through opening provided in the peripheral wall of the profile element; at least one fastening element which is arranged in the interior of the profile element so as to correspond to the at least one through opening; and at least one pressure-forming portion which is formed on the profile element and/or on the fastening element and positions the fastening element with respect to the through opening.
The invention relates to a method for producing a laminar composite (102) of a laminar-composite semi-finished product or of a laminar-composite structural component (100), wherein a layer arrangement (106) is provided comprising a reinforcement layer (110, 120), e.g. a fibre-reinforced reinforcement layer, and a polymer layer (130) arranged on a surface of the reinforcement layer, wherein the polymer layer (130) comprises a thermoplastic polymer material (131), the layer arrangement (106) is transformed into a laminar composite (102) by heating, in which laminar composite the polymer layer (130) has a deformable polymer layer (132), and the form of the laminar composite (102) is changed by applying force.
B29C 70/08 - Façonnage de matières composites, c.-à-d. de matières plastiques comprenant des renforcements, des matières de remplissage ou des parties préformées, p. ex. des inserts comprenant uniquement des renforcements, p. ex. matières plastiques auto-renforçantes des renforcements fibreux uniquement comprenant des combinaisons de différentes formes de renforcements fibreux incorporés dans une matrice, formant une ou plusieurs couches, avec ou sans couches non renforcées
B29C 35/04 - Chauffage ou durcissement, p. ex. réticulation ou vulcanisation avec des liquides, des gaz ou de la vapeur d'eau
B29C 35/08 - Chauffage ou durcissement, p. ex. réticulation ou vulcanisation utilisant l'énergie ondulatoire ou un rayonnement corpusculaire
B29C 44/02 - Moulage par pression interne engendrée dans la matière, p. ex. par gonflage ou par moussage pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés
B29C 44/04 - Moulage par pression interne engendrée dans la matière, p. ex. par gonflage ou par moussage pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés formés d'au moins deux parties en matière chimiquement ou physiquement différente, p. ex. ayant des densités différentes
B29C 44/34 - Éléments constitutifs, détails ou accessoiresOpérations auxiliaires
B29C 70/46 - Façonnage ou imprégnation par compression pour la fabrication d'objets de longueur définie, c.-à-d. d'objets distincts utilisant des moules opposables, p. ex. pour déformer des préimprégnés [SMC] ou des "prepregs"
B32B 5/24 - Produits stratifiés caractérisés par l'hétérogénéité ou la structure physique d'une des couches caractérisés par la présence de plusieurs couches qui comportent des fibres, filaments, grains ou poudre, ou qui sont sous forme de mousse ou essentiellement poreuses une des couches étant fibreuse ou filamenteuse
B32B 27/12 - Produits stratifiés composés essentiellement de résine synthétique adjacente à une couche fibreuse ou filamenteuse
B62D 29/04 - Carrosseries caractérisées par le matériau utilisé principalement en matières synthétiques
B29C 35/02 - Chauffage ou durcissement, p. ex. réticulation ou vulcanisation
09 - Appareils et instruments scientifiques et électriques
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Components, for use in relation to the following goods: Machines made from lightweight building materials; Components, for use in relation to the following goods: Machines made from thermoplastic composites; Cylinder head caps, for use in relation to the following goods: Motors for landvehicles; Oil pan for land vehicle engines; Charge-air components, for use in relation to the following goods: Motors for landvehicles; Holding devices, for use in relation to the following goods: Motors for landvehicles; Holding devices, for use in relation to the following goods: Gear boxes for land vehicles; Holding devices, for use in relation to the following goods: Batteries, for land vehicles; Thermal and acoustic shields for vehicles (parts of engines); Thermal and acoustic shields for exhaust gas systems of engines; Covers for engines; Base trays, for use in relation to the following goods: machines; Covers for undercoating for machines; Covers being undercoating for machines; Underrun protection components, for use in relation to the following goods: machines; Parts and fittings the aforesaid goods. Covers, for use in relation to the following goods: on-board chargers for land vehicles; Inverter covers, for land vehicles; High-voltage covers, for land vehicles; Battery covers, for land vehicles; Battery-module covers, for land vehicles; battery trays, for land vehicles; Battery-module housings, for land vehicles; Components for the mechanical protection of batteries, battery modules and battery systems; Vent covers, for use in relation to the following goods: Batteries for land vehicles; Insulation components, for use in relation to the following goods: Batteries for land vehicles; Covers, for use in relation to the following goods: Electric drive units for land vehicles; Parts and fittings the aforesaid goods. Structural parts of vehicles, made from lightweight building materials; Structural parts of vehicles, made from thermoplastic composites; Door-module beams, for land vehicles; Undercoating components, for land vehicles; Underrun protection components, for land vehicles; Battery trays for vehicles; Vehicle engine floors; Underfloor components for vehicles; Boot lids, for land vehicles; fender flares, for land vehicles; Roof-liner components for vehicles; Interior panels for vehicles; Engine-compartment components for vehicles; Spare wheel arches, for land vehicles; Front components for vehicles; Rear components for vehicles; Components for the insulation of vehicle engines; Components for the enclosing of vehicle engines; Undercoating components, for land vehicles; Boot components, for land vehicles; Cockpit cross-members, for land vehicles; Dashboards, for land vehicles; Steering columns for land vehicles; airbags for land vehicles; glove compartments, for land vehicles; Centre consoles, for land vehicles; Pressure-compensation units, for land vehicles; Ladder frames, for land vehicles; Oil covers, for use in relation to the following goods: Gear boxes for land vehicles; Brake-disc covers, for land vehicles; Heat insulation components being parts for motor vehicles; Sound insulation components being parts for motor vehicles; Thermal shields being parts for motor vehicles; Thermal and acoustic shields for vehicles (other than parts of engines); Wheel arch linings for vehicles; Floor pans for vehicles; Covers for the undersealing of vehicles; Covers being undercoating for vehicles; Bonnet absorbers for the acoustic and/or thermal insulation of vehicle bonnets; Dashboard linings for the dashboard in the passenger space of a vehicle; Roofs for vehicles; Hat racks for vehicles; Boot linings for vehicles; Interior lining parts for vehicles; Upholstery for vehicles; Sound and/or heat insulating covers for vehicles; Sound and/or heat insulating lining parts for vehicles; Parts and fittings for the aforesaid goods.
09 - Appareils et instruments scientifiques et électriques
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Components, for use in relation to the following goods: Machines made from lightweight building materials; Components, for use in relation to the following goods: Machines made from thermoplastic composites; Cylinder head caps, for use in relation to the following goods: Motors for landvehicles; Oil pan for land vehicle engines; Charge-air components, for use in relation to the following goods: Motors for landvehicles; Holding devices, for use in relation to the following goods: Motors for landvehicles; Holding devices, for use in relation to the following goods: Gear boxes for land vehicles; Holding devices, for use in relation to the following goods: Batteries, for land vehicles; Thermal and acoustic shields for vehicles (parts of engines); Thermal and acoustic shields for exhaust gas systems of engines; Covers for engines; Base trays, for use in relation to the following goods: machines; Covers for undercoating for machines; Covers being undercoating for machines; Underrun protection components, for use in relation to the following goods: machines; Parts and fittings the aforesaid goods. Covers, for use in relation to the following goods: on-board chargers for land vehicles; Inverter covers, for land vehicles; High-voltage covers, for land vehicles; Battery covers, for land vehicles; Battery-module covers, for land vehicles; battery trays, for land vehicles; Battery-module housings, for land vehicles; Components for the mechanical protection of batteries, battery modules and battery systems; Vent covers, for use in relation to the following goods: Batteries for land vehicles; Insulation components, for use in relation to the following goods: Batteries for land vehicles; Covers, for use in relation to the following goods: Electric drive units for land vehicles; Parts and fittings the aforesaid goods. Structural parts of vehicles, made from lightweight building materials; Structural parts of vehicles, made from thermoplastic composites; Door-module beams, for land vehicles; Undercoating components, for land vehicles; Underrun protection components, for land vehicles; Battery trays for vehicles; Vehicle engine floors; Underfloor components for vehicles; Boot lids, for land vehicles; fender flares, for land vehicles; Roof-liner components for vehicles; Interior panels for vehicles; Engine-compartment components for vehicles; Spare wheel arches, for land vehicles; Front components for vehicles; Rear components for vehicles; Components for the insulation of vehicle engines; Components for the enclosing of vehicle engines; Undercoating components, for land vehicles; Boot components, for land vehicles; Cockpit cross-members, for land vehicles; Dashboards, for land vehicles; Steering columns for land vehicles; airbags for land vehicles; glove compartments, for land vehicles; Centre consoles, for land vehicles; Pressure-compensation units, for land vehicles; Ladder frames, for land vehicles; Oil covers, for use in relation to the following goods: Gear boxes for land vehicles; Brake-disc covers, for land vehicles; Heat insulation components being parts for motor vehicles; Sound insulation components being parts for motor vehicles; Thermal shields being parts for motor vehicles; Thermal and acoustic shields for vehicles (other than parts of engines); Wheel arch linings for vehicles; Floor pans for vehicles; Covers for the undersealing of vehicles; Covers being undercoating for vehicles; Bonnet absorbers for the acoustic and/or thermal insulation of vehicle bonnets; Dashboard linings for the dashboard in the passenger space of a vehicle; Roofs for vehicles; Hat racks for vehicles; Boot linings for vehicles; Interior lining parts for vehicles; Upholstery for vehicles; Sound and/or heat insulating covers for vehicles; Sound and/or heat insulating lining parts for vehicles; Parts and fittings for the aforesaid goods.
74.
CYLINDER HEAD COVER FOR AN INTERNAL COMBUSTION ENGINE
The invention relates to a cylinder head cover for an internal combustion engine which has further integrated functions in addition to the pure covering function, wherein the cylinder head cover according to the invention comprises the following: a cover body, which, when the cylinder head cover is assembled, is mounted on an engine block of the internal combustion engine and covers a cylinder head of the internal combustion engine; a separator, through which a gas flow can be conducted for the purpose of cleaning, the separating device being formed and/or delimited, at least in sections, by the cover body and the separating device comprises a ventilation device.
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
11 - Appareils de contrôle de l'environnement
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
Produits et services
Plastic parts for machines, apparatus, motors, engines and
gears [except motors, engines and gears for vehicles],
namely, pistons and piston guides, nozzles, fixing and
transport rollers, expansion bellows and slide bearings
[parts of machines] for machines and apparatus; plastic
parts for motors and engines, namely pistons and piston
guides, nozzles, expansion bellows and slide bearings; seals
as parts of machines and seals as parts of motors and gears,
made of elastomer materials and/or of plastics, in
particular radial shaft seals [as parts of machines, motors
and gears], axial shaft seals [as parts of machines, motors
and gears], valve shaft seals [as parts of machines, motors
and gears], O-rings [as parts of machines, motors and gears]
and shaped rings [as parts of machines, motors and gears];
attachments for machines and apparatus and for motors,
engines and gears, made of plastics, namely, housings,
housing covers, covers and oil pans; plastic parts for
machines and apparatus and for motors, engines and gears
[except motors, engines and gears for vehicles], namely,
membranes for pumps and valve membranes; plastic parts for
gears for vehicles, namely, pistons and piston guides. Membranes for scientific apparatus; switches, in particular
switches for household appliances; circuit boards; electric
capacitors; electric cables; electric wires; electric solar
cells; housings for solar cells; photocells; housings for
photocells; parts of and fittings for the aforesaid goods,
as far as contained in this class. Plastic parts being parts for technical medical apparatus,
namely, medical tubes, membranes, trocars, seals and slide
bearings. Heating elements of plastic, being plastic parts for
machines, apparatus, motors, engines and gears. Plastic parts for gears for vehicles, namely, nozzles,
expansion bellows and slide bearing, all being parts of
gears for land vehicles. Pieces made of elastomer materials and/or of plastics, in
particular radial shaft seals, axial shaft seals, valve
shaft seals, O-rings and shaped rings, being seals for use
in the manufacture of machines, apparatus, motors, engines
and gears; plastic waterproof membranes, electric
insulators, heat insulators, grooved rings [sealing
elements], collars for insulating motors and power
transmission components, collar seals for sealing motors and
engines, support rings and tubes for use in the manufacture
of machines, apparatus, motors, engines and gears [except
the manufacture of motors, engines and gears for vehicles];
plastic membranes, electric insulators, heat insulators,
grooved rings, collar seals, support rings and tubes for use
in the manufacture of motors, engines and gears for
vehicles; plastic film (except film for packaging); tubes
(not made of metal); semi-finished products made of
plastics; recycled composite plastic materials; insulators
for cables; sleeves of plastic for cables for insulation
purposes.
76.
FEEDTHROUGH SYSTEM, METHOD FOR PRODUCING A FEEDTHROUGH SYSTEM, ELECTROCHEMICAL CELL, AND ELECTROCHEMICAL SYSTEM
In order to provide a feedthrough system which can be produced as easily as possible and has an optimized service life, it is proposed that the feedthrough system comprises a wall component which has one or more feedthrough openings, one or more lines which are guided through the one or more feedthrough openings, and a fastening device, the fastening device connecting the one or more lines to the wall component in one or more connection regions of the feedthrough system.
The invention relates to a seal assembly (100) for sealing between two accommodating spaces (102) for accommodating two media in the region of a force-transmitting, movable device element (103), for example a shaft (104) or a piston rod, wherein the seal assembly (100) comprises: an annular sealing element (108) which bears against the device element (103) for sealing when in the mounted state; and a discharge element (150) which is in electrically conductive contact with at least one surface contact region (105) of the device element (103) via at least one discharge contact region (152) when in the mounted state.
F16J 15/3212 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques avec au moins une lèvre pourvue d’éléments de tension, p. ex. de bagues élastiques avec des ressorts métalliques
F16J 15/3228 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques avec au moins une lèvre formée par déformation d’une bague plate
F16J 15/3284 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par joints élastiques, p. ex. joints toriques caractérisés par leur structureEmploi des matériaux
78.
CELL CONTACTING SYSTEM FOR AN ELECTROCHEMICAL DEVICE
A cell contacting system for an electrochemical device is provided, which includes a plurality of cell groups having one or more electrochemical cells, each having a first and a second cell terminal. The first cell terminals follow each other along the longitudinal direction in a first cell terminal region of the electrochemical device and the second cell terminals follow each other along the longitudinal direction in a second cell terminal region of the electrochemical device. The cell contacting system includes at least one cell connector extending obliquely to the longitudinal direction and configured for electrically conductively connecting cell terminals of a first cell group in the first cell terminal region to cell terminals of a second cell group in the second cell terminal region, which cell contacting system reliably enables a relative movement between the cell terminals to be electrically connected to each other.
H01M 50/30 - Aménagements pour faciliter l’échappement des gaz
H01M 50/209 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules prismatiques ou rectangulaires
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
H01M 50/502 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie
H01M 50/20 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports
79.
COVER ELEMENT IN SANDWICH DESIGN HAVING A FUSIBLE INTERMEDIATE LAYER FOR A BATTERY HOUSING, BATTERY HOUSING AND MOTOR VEHICLE
The invention relates to a cover element (16) for a battery housing (10) of a battery storage device (20), in particular a high-voltage battery, comprising a plurality of battery cells (18), of an at least partially electrically driven motor vehicle, wherein the cover element (16) has a sandwich design comprising a first cover layer (26), a second cover layer (28) and an intermediate layer (30) arranged between the cover layers (26, 28), wherein, when the cover element (16) is mounted on the battery housing (10), the first cover layer (26) faces the battery storage device (20) and the second cover layer (28) faces away from the battery storage device (20). According to the invention, the first cover layer (26) has a plurality of breaking portions (32) which are movable relative to the first cover layer (26) according to a pressure prevailing in the region of a relevant breaking portion (32), so that a break opening (36) is formed. The invention also relates to a battery housing and to a motor vehicle.
H01M 50/231 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par le matériau des boîtiers ou des bâtis ayant une structure en couches
In order to improve a body unit comprising a body component that comprises an elongate carrier element and at least one injection molded part, it is proposed that at least one injection molded part that is molded onto the carrier element should hold at least one functional element at a holding part of the functional element.
The aim of the invention is to provide a busbar (100) for electrically conductively connecting a first component of a first electrochemical device and a second component of a second electrochemical device, comprising a first contact region (112) for electrically conductively connecting the busbar to the first component and a second contact region (114) for electrically conductively connecting the busbar to the second component, which reduces or delays with a justifiable amount of effort a thermal propagation from the first component of the electrochemical device to the second component of the electrochemical cell via the busbar, such that the risk is reduced that a "thermal runaway" of an electrochemical cell connected to the first component triggers even after a short time a "thermal runaway" of an electrochemical cell connected to the second component. In order to achieve said aim, it is proposed that the busbar has at least one region (142) with a reduced cross-section in the current path between the first contact region and the second contact region, in which the electrically conductive cross-section of the busbar is reduced by at least one recess (144).
H01M 10/6551 - Surfaces spécialement adaptées à la dissipation de la chaleur ou à la radiation, p. ex. nervures ou revêtements
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
H01M 50/517 - Procédés pour interconnecter les batteries ou cellules adjacentes par des moyens de fixation, p. ex. vis, rivets ou boulons
In order to provide a pressure equalization apparatus (10) by means of which a pressure equalization can be brought about in the event of an overpressure—in particular, in an electrochemical system—and which is as simple as possible to produce, according to the invention, the pressure equalization apparatus comprises a main element (110), a sealing device (112), and a connection device (114) for connecting the main element and the sealing device, wherein the sealing device sealingly bears against the main element when the pressure equalization apparatus is in a closed state and is fixed relative to the main element by means of the connection device, and wherein a fixing connection between the main element and the sealing device which is formed thereby can be released in order to unblock a fluid connection between the interior of the pressure equalization apparatus and surroundings of the pressure equalization apparatus, and wherein the connection device comprises a spring element (150), the spring force of which acts in particular in a direction extending crosswise to an opening direction of the pressure equalization apparatus.
F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
F16K 24/04 - Dispositifs, p. ex. soupapes, pour la mise à l'air libre ou l'aération d'enceintes pour la mise à l'air libre uniquement
ElringKlinger Automotive Manufacturing, Inc. (USA)
Inventeur(s)
Pupsys, Tomas
Eidam, Kirk
Anhorn, Thomas
Abrégé
A functional element is provided which comprises a functional layer with at least one filter portion, a covering part on each side of the functional layer, at least one fluid passage in the functional element which passes through a passage area of the at least one filter portion, and a sealing segment which surrounds the passage area in a circumferentially closed manner with sealing material of the sealing segment permeating the filter portion to provide a seal in the filter portion and between the covering parts and the filter portion.
F16J 15/08 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre exclusivement par garniture métallique
F16J 15/12 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre par garniture non métallique par renforcement ou couverture métallique
84.
HOUSING OR PORTION OF A HOUSING FOR AN ELECTRONIC CIRCUIT
The present invention relates to a housing or a portion of a housing for an electronic circuit, preferably an onboard electrical system component of a vehicle. In order to provide a housing for an electronic circuit, preferably an onboard electrical system component of a vehicle and in particular of a battery store, said housing also having improved properties beyond thermal runaway or comparable exceptional thermal states, according to the invention the housing (2) or a portion of the housing has a surface which is in the form of a shielding device (3) having an insulating layer (10) facing the electronic circuit and having a metal outer layer (11), and the housing (2) or a portion of the housing (2) has a heat sink (4).
In order to create a housing element, comprising a housing wall and a receiving structure for a pressure compensation element, wherein the receiving structure comprises a through-opening for the passage of a gas, said housing element being configured such that a collection of liquid on a pressure compensation element mounted on the housing element is prevented or at least reduced, it is proposed that the receiving structure comprises at least one pressure compensation element abutment face that is raised, at least in sections, relative to an outer face of a base region of the housing wall.
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
11 - Appareils de contrôle de l'environnement
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
Produits et services
Plastic parts for machines, apparatus, motors, engines and
gears [except motors, engines and gears for vehicles],
namely, pistons and piston guides, nozzles, fixing and
transport rollers, expansion bellows and slide bearings
[parts of machines] for machines and apparatus; plastic
parts for motors and engines, namely pistons and piston
guides, nozzles, expansion bellows and slide bearings; seals
for machines and apparatus and for motors and gears [as
parts of machines and motors], made of elastomer materials
and/or of plastics, in particular radial shaft seals, axial
shaft seals, valve shaft seals, o-rings and shaped rings;
attachments for machines and apparatus and for motors,
engines and gears, made of plastics, namely, housings,
housing covers, covers and oil pans; plastic parts for
machines and apparatus and for motors, engines and gears
[except motors, engines and gears for vehicles], namely,
membranes for pumps and valve membranes. Membranes for scientific apparatus; switches, in particular
switches for household appliances; circuit boards; electric
capacitors; electric cables; electric wires; electric solar
cells; housings for solar cells; photocells; housings for
photocells; parts of and fittings for the aforesaid goods,
as far as contained in this class. Plastic parts being parts for technical medical apparatus,
namely, medical tubes, membranes, trocars, seals and slide
bearings. Heating elements of plastic, being plastic parts for
machines, apparatus, motors, engines and gears. Plastic parts for gears for vehicles, namely, pistons and
piston guides, nozzles, expansion bellows and slide
bearings. Pieces made of elastomer materials and/or of plastics, in
particular radial shaft seals, axial shaft seals, valve
shaft seals, o-rings and shaped rings, being seals for use
in the manufacture of machines, apparatus, motors, engines
and gears; plastic waterproof membranes, electric
insulators, heat insulators, grooved rings [sealing
elements], collars for insulating motors and power
transmission components, collar seals for sealing motors and
engines, support rings and tubes for use in the manufacture
of machines, apparatus, motors, engines and gears [except
the manufacture of motors, engines and gears for vehicles];
plastic membranes, electric insulators, heat insulators,
grooved rings, collars, support rings and tubes for use in
the manufacture of motors, engines and gears for vehicles;
plastic film (except film for packaging); tubes (not made of
metal); semi-finished products made of plastics; recycled
composite plastic materials; insulators for cables; sleeves
of plastic for cables for insulation purposes.
The present invention relates to an electrical current feedthrough (1) at an opening (7) of a thin-walled sheet metal part (5) which, for use as a thermal and/or acoustic shielding device (2), is provided with thermal insulation and is designed, in one application, to enclose at least part of a temperature-controlled object, in particular a fuel cell, an internal combustion engine, a temperature-controlled fluid line or an exhaust tract of a motor vehicle, the electrical current feedthrough (1) having a connection (8) which is mounted at the opening (7) of the sheet metal part (5) in an electrically insulated manner. In order to create an electrical current feedthrough of the aforementioned type, which takes up less installation space with a simplified structure, according to the invention the connection (8) is fixed in the region of the opening (7) by an insulating body (9) on the sheet-metal part (5) of the shielding device (2), the connection (8) being extended through the opening (7) and carrying, at a free end region (10), an electrical distribution device (11) having several internal connections, a layer (3) of the insulation of the shielding device (2) being located between the sheet-metal part (5) of the shielding device (2) and the distribution device (11).
F01N 3/20 - Silencieux ou dispositifs d'échappement comportant des moyens pour purifier, rendre inoffensifs ou traiter les gaz d'échappement pour rendre les gaz d'échappement inoffensifs par conversion thermique ou catalytique des composants nocifs des gaz d'échappement caractérisés par les méthodes d'opérationCommande spécialement adaptés à la conversion catalytique
F01N 13/14 - Silencieux ou dispositifs d'échappement caractérisés par les aspects de structure comportant une isolation thermique
88.
MODULE AND/OR PACK, AND BATTERY SYSTEM MADE THEREOF
The invention relates to a pack and/or module based on elementary cells with a cylindrical design, in which elementary cells are electrically connected together by a cell contacting system (4) in order to form series and parallel circuits, the two poles (P, N) of each elementary cell (2) being contacted at a free upper face (7) of the module or pack (1). The invention also relates to a battery system which is made of said pack and/or module and is provided as a device for dispensing electric energy and for storing electric energy. The aim of the invention is to provide a pack and/or module which is used to allow customer-specific solutions to be provided without developing a completely new battery system made of a pack and/or module. According to the invention, this is achieved in that a support (3) is spatially predefined in the form of a module or pack format with a defined number of elementary cells (2), wherein the electric properties of the module and/or pack (1) are designed to be adjustable by selecting a cell contacting system (4) with a respective adapted wiring of the elementary cells (2) and the connection thereof to the free upper face (7) of the module or pack (1).
H01M 50/213 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules caractérisés par leur forme adaptés aux cellules ayant une section transversale courbée, p. ex. ronde ou elliptique
H01M 50/502 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie
H01M 50/503 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par la forme des interconnecteurs
H01M 50/509 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie caractérisées par le type de connexion, p. ex. connexions mixtes
89.
LAMINATED SHEET UNIT AND METHOD FOR PRODUCING A LAMINATED SHEET UNIT
The invention relates to a laminated sheet unit (100), the laminated sheet unit (100) comprising the following: two mutually electrically insulated sheets (102, 112, 122); a reinforcing composite layer (104, 114) arranged between the sheets (102, 112, 122) and a punched edge (150) delimiting the planar extent of the laminated sheet unit (100).
H02K 1/04 - Détails du circuit magnétique caractérisés par le matériau employé pour l'isolation du circuit magnétique ou de parties de celui-ci
H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Sheets of metal; stacks of metal sheets. Electric motors, other than for land vehicles; parts of
electric motors; parts of electric motors for land vehicles;
stators [parts of machines]; parts of stators [parts of
machines]; rotors [parts of electric motors]; parts of
rotors [parts of electric motors]. Electric motors for land vehicles.
91.
BATTERY MODULE, BATTERY DEVICES AND METHODS FOR PRODUCING A BATTERY MODULE
H01M 50/204 - Bâtis, modules ou blocs de multiples batteries ou de multiples cellules
H01M 10/653 - Moyens de commande de la température associés de façon structurelle avec les éléments caractérisés par des matériaux électriquement isolants ou thermiquement conducteurs
H01M 50/262 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports avec des moyens de fixation, p. ex. des serrures
H01M 50/271 - Couvercles des boîtiers secondaires, des bâtis ou des blocs
H01M 10/613 - Refroidissement ou maintien du froid
H01M 50/289 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par des éléments d’espacement ou des moyens de positionnement dans les racks, les cadres ou les blocs
92.
FUNCTIONAL PART, AND FUNCTIONAL SYSTEM COMPRISING A FUNCTIONAL PART
The invention relates to a functional part, in particular an add-on part, for example for a housing, comprising a connection receiving area or a plurality of connection receiving areas, wherein the connection receiving area or each of the plurality of connection receiving areas is designed to receive a connection mating piece of another part, in particular a connection mating piece of a housing part, in the form of a bayonet closure in particular in order to securely and releasably connect the functional part to the other part. The aim of the invention is to improve such a functional part. According to the invention, this is achieved in that the one connection receiving area or at least one connection receiving area, in particular some or all, of the plurality of connection receiving areas is designed to receive connection mating pieces of different sizes, in particular so as to produce a secure connection.
The present invention relates to a sealing element made of a plastic, the sealing element being designed for sealing on a control valve and consisting of a plastic or resin processed in an injection-molding process. In order to significantly improve the sealing tightness of injection-molded sealing elements manufactured from a plastic, according to the present invention the sealing element (1), as a direct product of an injection-molding process, is provided, on a sealing surface (2), with a structure in the form of a groove (R) distributed over the periphery of the sealing surface (2).
F16J 15/10 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre par garniture non métallique
F16K 5/06 - Robinets à boisseau consistant seulement en un dispositif obturateur dont au moins une des faces d'obturation a la forme d'une surface de solide de révolution plus ou moins complète, le mouvement d'ouverture et de fermeture étant essentiellement rotatif dont les boisseaux sont à surface sphériqueLeurs garnitures d'étanchéité
An elastomeric material is disclosed, which is suitable, in particular, as a sealing material between the fuel cells of a fuel cell stack and the stacks as such, wherein the hybrid elastomeric material includes a hybrid elastomer with a proportion of a siloxane polymeric material and a proportion of a polyolefin elastomeric material, wherein the two materials are crosslinked with one another by addition. Further aspects relate to polyelectrolyte fuel cells, which include sealing elements made of the hybrid elastomeric material, as well as the use of the hybrid elastomeric material in a screen printing process.
C08L 23/02 - Compositions contenant des homopolymères ou des copolymères d'hydrocarbures aliphatiques non saturés ne possédant qu'une seule liaison double carbone-carboneCompositions contenant des dérivés de tels polymères non modifiées par un post-traitement chimique
C08J 3/24 - Réticulation, p. ex. vulcanisation, de macromolécules
C08J 3/22 - Formation de mélanges de polymères avec des additifs, p. ex. coloration en utilisant les techniques des charges mères
The aim of the invention is to provide an electrochemical cell which can be produced as simply as possible and with which fluid can flow out of the interior in the event of an overpressure in the interior of the electrochemical cell. This is achieved by an electrochemical cell that comprises a housing, which surrounds the interior of the electrochemical cell, and a rupture device, which is arranged on a wall of the housing and is in particular formed integrally with the wall, wherein the rupture device comprises at least one rupture web, wherein the at least one rupture web has a thickness varying in the longitudinal direction, and/or wherein the at least one rupture web is formed by at least one first depression, which is arranged on an inner side, facing the interior, of the wall, and by at least one second depression, which is arranged on an outer side, facing away from the interior, of the wall.
To create a housing cover for fixing to a housing, wherein the housing cover is provided with a plurality of fastening means through openings and with a sealing bead that comprises an elastomeric material, and wherein the sealing bead is arranged on a seal support face of the housing cover, in which housing cover the course of the sealing bead can be more freely designed and, in particular, laid closer to the fastening means through-openings of the housing cover and which, in particular, is producible from a relatively thin starting material, it is proposed that the housing cover comprises at least one deformation limiting element, which projects over the seal support face in the same direction as the sealing bead and limits a deformation of the sealing bead in the assembled state of the housing cover,
To create a housing cover for fixing to a housing, wherein the housing cover is provided with a plurality of fastening means through openings and with a sealing bead that comprises an elastomeric material, and wherein the sealing bead is arranged on a seal support face of the housing cover, in which housing cover the course of the sealing bead can be more freely designed and, in particular, laid closer to the fastening means through-openings of the housing cover and which, in particular, is producible from a relatively thin starting material, it is proposed that the housing cover comprises at least one deformation limiting element, which projects over the seal support face in the same direction as the sealing bead and limits a deformation of the sealing bead in the assembled state of the housing cover,
wherein the deformation limiting element comprises a bending region in which the material of the deformation limiting element is bent out of a reference plane extending substantially in parallel to the seal support face by a bend angle of at least 30°.
In order to provide a rupture device which can be produced as simply as possible and which enables a controlled opening of a container in the event of an overpressure, it is proposed that the rupture device comprise a wall component which has at least one rupture web, wherein the at least one rupture web has a thickness varying in the longitudinal direction, and/or wherein the at least one rupture web is formed by at least one first depression, which is arranged on a first side of the wall component, and at least one second depression, which is arranged on a second side, facing away from the first side, of the wall component.
F16K 17/16 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté avec élément de rupture l'élément étant un diaphragme de rupture
A module layer and to a battery system made therefrom, which, as a device for supplying and storing electrical energy between two final end components, comprises a number of battery modules that are electrically connected to one another in series. Each module here consists of a number of elementary cells, which are generally lithium-ion batteries. The module layer is embodied as a structural unit, wherein the cells in the module layer are positioned next to one another in a tray, in an upright position on a base element of the tray, and are enclosed by an outer frame that is embodied as a heat sink and constitutes the rim of the tray, the outer frame has a seal, and the module layer has a section of a central shaft into which bus bars protrude, which produce a conductive connection with the cells of the respective module layer.
H01M 10/613 - Refroidissement ou maintien du froid
H01M 10/653 - Moyens de commande de la température associés de façon structurelle avec les éléments caractérisés par des matériaux électriquement isolants ou thermiquement conducteurs
H01M 10/6551 - Surfaces spécialement adaptées à la dissipation de la chaleur ou à la radiation, p. ex. nervures ou revêtements
H01M 50/26 - Assemblages scellés l’un à l’autre de manière non séparable
H01M 50/284 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports comprenant l’insertion de cartes de circuits, p. ex. de cartes de circuits imprimés
H01M 50/507 - Interconnecteurs pour connecter les bornes des batteries adjacentesInterconnecteurs pour connecter les cellules en dehors d'un boîtier de batterie comprenant un arrangement de plusieurs barres omnibus réunies dans une structure de conteneur, p. ex. modules de barres omnibus
H01M 50/528 - Connexions électriques fixes, c.-à-d. non prévues pour être déconnectées
In order to provide a structural component (100) for a vehicle (102), in particular a bulkhead (104) for a road vehicle, for example for a passenger car (106), which can be produced simply and cost-effectively and preferably simultaneously meets requirements relating to weight reduction and structural integrity, according to the invention the structural component (100), in particular the bulkhead (104), comprises the following: a main body (108), which comprises one or more foamed portions (124) and one or more compact portions (130), the structural component (100) preferably also comprising one or more cover elements (126) which cover the main body (108) in one or more foamed portions (124) and/or in one or more compact portions (130).
The present invention relates to a control device having a control unit for a battery system that has a number of storage cells, which are connected to a control unit and also to each other, wherein each of the storage cells is assigned a cell-monitoring circuit having connected sensors. In order disadvantages in scalability and most accurate possible control and monitoring even for a large battery system, it is proposed that, within the battery system (1), sub-groups (5) of interconnected storage cells (4) and/or modules (Mod) are provided, each sub-group (5) having a micro-master (7), to which all cell-monitoring circuits (CSC) of the sub-group (5) in question are connected, and the micro-master (7) being designed to evaluate and filter all data from the cell-monitoring circuits (CSC) and being connected to a battery management system (BMS) by means of the control unit for the purpose of data transfer.
H04Q 9/00 - Dispositions dans les systèmes de commande à distance ou de télémétrie pour appeler sélectivement une sous-station à partir d'une station principale, sous-station dans laquelle un appareil recherché est choisi pour appliquer un signal de commande ou pour obtenir des valeurs mesurées
