Produits et services

Pliers; hand tools, hand operated, other than bladed or pointed hand tools; tweezers; bladed or pointed hand tools and swords.

Produits et services

Pliers; hand tools, hand operated, other than bladed or pointed hand tools; tweezers; bladed or pointed hand tools and swords.

Produits et services

Pliers; hand tools, hand operated, other than bladed or pointed hand tools; tweezers; edge tools [hand tools].

Abrégé

Provided is a pinching tool excellent in convenience. A pinching portion (30) is formed at a front end of an arm (10) forming the pinching tool, and a dovetail groove (50) which increases in width from the front side toward the rear side of the pinching portion (30) is formed in an opposing surface (40) of the pinching portion.

Classes IPC  ?

• B25B 7/02 - Mâchoires

Abrégé

[Problem] To provide a gripping tool having improved operability. [Solution] This gripping tool is provided with a first arm 11 and a second arm 12, which have jaws 111, 121 at the front end portions thereof which are rotatably connected. Longitudinal gripping teeth 115, 125 having a plurality of ridges extending rearward from the front ends are present on a first facing surface 114 and a second facing surface 124, which are present at the front end portions of the jaw 111 and the jaw 121. The width of the longitudinal gripping teeth 115, 125 is less than the width of the first facing surface 114 and the second facing surface 124. At the front ends of the first facing surface 114 and the second facing surface 124, the center 1141, 1241, in a width direction, of each of the first facing surface 114 and the second facing surface 124 and the center, in the width direction, of each of the longitudinal gripping teeth 115, 125 are located at different positions, and one of the side sections of the longitudinal gripping teeth 115 is not contiguous to one of the side sections of the first facing surface 114 and to one of the side sections of the second facing surface 124.

Classes IPC  ?

• B25B 7/02 - Mâchoires
• B25B 7/22 - Pinces munies de dispositifs auxiliaires, p. ex. à arêtes tranchantes, avec arrache-clous

Abrégé

[Problem] To provide a screw extraction tool with which a screw having a distorted engagement groove structure can be easily extracted. [Solution] This screw extraction tool 1 for extracting a screw having a distorted engagement groove structure in a screw head portion is provided with: a shaft body 101; and a screw extraction part 102 formed on the tip portion of the shaft body 101 and having a shape in which an end narrows toward the tip, wherein one or more blades 104, which extend from the tip side of the screw extraction part 102 toward the rear end side in a spiral shape and in which a blade edge is provided on the outer circumferential side, are formed on the outer circumferential side of the screw extraction part 102; and the inclination angle of a tapered surface 105 including the blade edges 104a of one or more blades 104 with respect to the axial center 101a of the shaft body 101 is configured to be greater than 26.5 degrees.

Classes IPC  ?

• B25B 27/18 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher pour extraire des pièces filetées ou des forets hélicoïdaux brisés

Abrégé

The objective of the present invention is to provide a clamping tool capable of preventing degradation and appropriately clamping a thin object to be clamped. Lateral pinching teeth (11) configured from ridges (111) and valleys (112) arranged in a front-back direction are formed in a second region (6) rearward of opposing surfaces of a jaw portion, the configuration being such that when both jaw portions (4) are closed, the ridges (111) of one jaw portion (4) enter valleys (112) adjacent to the ridges (111) of the other jaw portion (4), and the ridges (111) and the valleys (112) are not in contact with one another. In a state in which the two jaw portions have been assembled in such a way that the tip ends of the ridges (111) of the lateral pinching teeth (11) of one jaw portion and bottom ends of the valleys (112) of the lateral pinching teeth (11) of the other jaw portion into which the ridges (111) enter face one another directly in the height direction of the ridges (111), a gap between opposing side surfaces of the ridges (111) of one jaw portion and the valleys (112) of the other jaw portion into which the ridges (111) enter is configured to be wider than a gap between the tip ends of the ridges (111) and the bottom ends of the valleys (112).

Classes IPC  ?

• B25B 7/02 - Mâchoires

Abrégé

The objective of the present invention is to provide water pump pliers with which it is possible for a range of suitable usage applications to be expanded. These water pump pliers are provided with a linking portion (103) rotatably linking a first arm (101) and a second arm (102), and a locking structure (104) for locking the linking portion (103) in at least two different positions in a hole to adjust an opening width between jaw portions. A first opposing surface (20) and a second opposing surface (30) are provided respectively at tip ends of jaw portions (1011, 1021) provided at first ends of the first arm (101) and the second arm (102), and in a state in which the linking portion (103) is locked by means of the locking structure (104) in a position in which the opening width between the jaw portions (1011, 1021) is narrowest, a center of rotation (1031) of the linking portion (103) is positioned on a plane equidistant from the first opposing surface (20) and the second opposing surface (30).

Classes IPC  ?

• B25B 7/10 - Articulations à point d'appui réglable
• B25B 7/02 - Mâchoires
• B25B 7/22 - Pinces munies de dispositifs auxiliaires, p. ex. à arêtes tranchantes, avec arrache-clous

Produits et services

Tweezers; blades [hand tools]; swords; scissors; scissor blades; hand-operated cutting tools; hand drills, hand operated; hand tools; adjustable spanners; spanners; screwdrivers, non-electric; wrenches [hand-operated]; nippers; pliers; cutting pliers [lineman's pliers]; screw wrenches; screw-thread cutters [hand tools].

Produits et services

Tweezers; bladed or pointed hand tools; swords; scissors; scissor blades; hand-operated cutting tools; drills [hand-held]; hand tools; adjustable spanners; screwdrivers; spanners; wrenches [hand-operated]; nippers; pliers; cutting pliers [linemans' pliers]; screw wrench; screw-thread cutters.

Produits et services

Tweezers; blades [hand tools]; swords; scissors; scissor blades; hand-operated cutting tools; hand drills, hand operated; hand tools; adjustable spanners; spanners; screwdrivers, non-electric; wrenches [hand-operated]; nippers; pliers; cutting pliers [lineman's pliers]; screw wrenches; screw-thread cutters [hand tools].

Produits et services

hand tools, namely, tweezers, swords, scissors, kitchen knives, scissor blades, hand-operated cutting tools, adjustable spanners, screwdrivers, spanners, hand-operated wrenches, trowels, nippers, pliers, cutting pliers in the nature of linemans' pliers, screw wrench, screw-thread cutters in the nature of screw-thread cutting reamers

Abrégé

A loupe with a stand is provided such that a loupe main body is supported in a state that is always stable, such that the attitude of the loupe main body is assuredly supported during long-term use, and such that work can always be carried out in a hands-free state. A loupe is provided with a loupe main body (1) and a stand (2). The stand (2) is constituted of a stand base (10), a first arm (11), a second arm (12), first through third joint structures (H1, H2, H3), and the like. The joint structures (H1, H2, H3) are constituted such that linked members are rotatable relatively centered on first through third linking shafts (45, 58, 77). The stand base (10) has a magnet (13) that adheres to magnetic metal materials affixed therein. Position holding bodies (47, 61, 79) that hold the stand base (10), first arm (11), second arm (12), and loupe main body (1) in any displacement position are provided in the first through third joint structures (H1, H2, H3).

Classes IPC  ?

• G02B 25/00 - OculairesLoupes

Abrégé

b so as not to cause finger pinch.

Classes IPC  ?

• B26B 13/20 - Cisailles à mainCiseaux caractérisés par la forme des poignées avec une poignée en forme d'anneau pour les doigts

Produits et services

Pliers, [ tweezers, hand-operated edging tools, ] screw drivers

Abrégé

The invention provides a pair of pliers capable of properly pinching a screw head and reliably removing a screw from an object to which the screw has been fastened even if the screw has small thickness of a peripheral face to be pinched between pinching teeth. a initially collide with the screw fastened face 22, so that the longitudinal pinching teeth 13 can reliably pinch the peripheral face of the screw head 21.

Classes IPC  ?

• B25B 7/02 - Mâchoires

Abrégé

[Problem] To provide very safe scissors that can more reliably prevent pinching of fingers when being closed. [Solution] The present invention forms, on the left and right handles (7a, 7b), pinched finger-preventing guards (20a, 20b) for preventing the entry of fingertips between the opposing inner surfaces (10a, 10b) from above or below. The invention can prevent a user's fingertips reaching the opposing inner surfaces (10a, 10b) by the user placing the fingertips, which have been inserted into the finger holes (6a, 6b), along the upper and lower surfaces of the pinched finger-preventing guards (20a, 20b). Consequently, when the handles (7a, 7b) are in a closing position, the fingertips being pinched between the opposing inner surfaces (10a, 10b) and causing pinched fingers can be prevented.

Classes IPC  ?

• B26B 13/20 - Cisailles à mainCiseaux caractérisés par la forme des poignées avec une poignée en forme d'anneau pour les doigts

Abrégé

A plier configured by connecting, in an X-shape by means of a connecting shaft (3), a first arm (1) and a second arm (2) which are each provided with a jaw section (4) and a grip handle (5). Clearance surfaces (16, 16) are formed at the left and right of the front end of each jaw section (4, 4) in order to avoid the contact of both the corners of the jaw section (4, 4) with the surface (22) to which a screw is to be fastened. Vertical clamping teeth (13, 13) for clamping and holding the peripheral surface of the head (21) of the screw are formed in a recessed shape on the facing surfaces of the jaw sections (4, 4) at positions each located between the left and right clearance surfaces (16, 16) of each jaw section. Each vertical clamping tooth (13, 13) comprises ridge teeth (13a) which extend in the front-rear direction and continue in a peak-and-valley shape. The clearance recesses (16) enable the front ends (17) of the ridge teeth (13a) to first make contact with the surface (22) to which the screw is to be fastened, and as a result, the peripheral surface of the screw head (21) can be reliably clamped and held by the vertical clamping teeth (13).

Classes IPC  ?

• B25B 7/02 - Mâchoires

Produits et services

Pliers
