1.

LOW-EMISSION NOZZLE AND RECEPTACLE COUPLING FOR CRYOGENIC FLUID


Numéro d'application 19575424
Statut En instance
Date de dépôt 2026-03-23
Date de la première publication 2026-08-06
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Grenaway, John

Abrégé

A low-emission nozzle and receptacle coupling for cryogenic fluid is disclosed. A nozzle includes a body defining a chamber through which the cryogenic fluid is to flow. The body includes an outer shell that includes a front end. The nozzle includes a fixed sleeve coupled to the outer shell and a rotating sleeve extending over the front end and configured to rotate relative to the body. The rotating sleeve is configured to couple to the receptacle via locking teeth that rotatably slide into respective cam slots. The nozzle includes a redundant locking mechanism coupled to the outer shell. After the rotating sleeve has rotated to couple to the receptacle, the redundant locking mechanism is configured to actuate to engage and prevent further rotation of the rotating sleeve to lock the nozzle to the receptacle.

Classes IPC  ?

  • F16L 37/244 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette dans lesquels l'accouplement et le tuyau sont coaxiaux
  • F17C 13/00 - Détails des récipients ou bien du remplissage ou du vidage des récipients
  • F16L 37/35 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement au moins un des clapets possédant un canal axial communiquant avec des ouvertures latérales

2.

COUPLING NOZZLE FOR CRYOGENIC FLUID


Numéro d'application 19465017
Statut En instance
Date de dépôt 2026-01-30
Date de la première publication 2026-07-23
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

Methods and apparatus are disclosed for a coupling nozzle for cryogenic fluid. A nozzle for cryogenic fluid includes a flow body, a flow control assembly, a first linear actuator, and a locking actuator. The flow body defines a conduit. The flow control assembly is at least partially disposed in the conduit of the flow body. The flow control assembly is configured to transition between an open position and a closed position to permit and prevent, respectively, the cryogenic fluid to flow through the flow body. The first linear actuator includes an actuator body and a first shaft. The first shaft is configured to slide between an extended position and a contracted position to transition the flow control assembly between the open position and the closed position, respectively. The locking actuator is for locking the nozzle to a receptacle in an automated manner.

Classes IPC  ?

  • F16L 37/096 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen de crochets articulés autour d'un axe
  • F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts
  • F16L 37/42 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un clapet dont l'ouverture se fait automatiquement au moment de l'accouplement le clapet comportant un canal axial communiquant avec des trous radiaux
  • F16L 37/47 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un robinet à boisseau ou à obturateur
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés

3.

MANUALLY-OPERABLE NOZZLE FOR CRYOGENIC FLUID TRANSFER


Numéro d'application CN2025072442
Numéro de publication 2026/152283
Statut Délivré - en vigueur
Date de dépôt 2025-01-15
Date de publication 2026-07-23
Propriétaire
  • ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
  • SHANGHAI REGO FLOW TECHNOLOGY CO., LTD. (Chine)
Inventeur(s)
  • Cao, Guangbin
  • Lu, Huiju
  • Zhang, Zhao

Abrégé

A manually-operable nozzle (100) for cryogenic fluid transfer is disclosed. A nozzle (100) includes a body (125) and a rotary unit (600), which includes a rotary handle (620) fixed relative to and a locking cam (690) fixedly coupled to a rotary shaft (610). The nozzle (100) includes a rotating sleeve (700) defining cam slots (722) and a hole (746) and a rod (910) extending between the locking cam (690) and the rotating sleeve (700). The cam slots (722) slidably receive respective teeth (98) of the receptacle (50) as the rotating sleeve (700) is rotated relative to the body (125) to couple the nozzle (100) to the receptacle (50). When the rotating sleeve (700) is in a rotated position, the hole (746) aligns axially with the rod (910). When the rotary handle (620) is subsequently rotated to the locked position, the locking cam (690) pushes the rod (910) axially to extend into the hole (746) to fix a rotational position of the rotating sleeve (700) relative to the body (125) to securely lock the nozzle (100) to the receptacle (50) during a fill event.

Classes IPC  ?

  • F16L 37/244 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette dans lesquels l'accouplement et le tuyau sont coaxiaux
  • F16L 37/42 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un clapet dont l'ouverture se fait automatiquement au moment de l'accouplement le clapet comportant un canal axial communiquant avec des trous radiaux

4.

TWO-STAGE PRESSURE REGULATOR FOR COMPRESSED GAS


Numéro d'application 19135682
Statut En instance
Date de dépôt 2022-12-07
Date de la première publication 2026-07-09
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Li, Yao
  • Fu, Wen

Abrégé

Two-stage pressure regulators for compressed gas are disclosed. An example two-stage pressure regulator includes a body, an upstream piston, a seat assembly, and a downstream piston. The body defines an inlet, an outlet, a chamber and an upstream valve seat. The upstream piston is slidably positioned in the chamber adjacent the inlet. The upstream piston includes a first plug that is configured to engage the upstream valve seat in a first closed position and be disengaged from the upstream valve seat in a first open position. The seat assembly is housed in the chamber and includes a downstream valve seat. The downstream piston is slidably positioned in the chamber adjacent the outlet. The downstream piston includes a second plug that is configured to engage the downstream valve seat in a second closed position and be disengaged from the downstream valve seat in a second open position.

Classes IPC  ?

  • G05D 16/10 - Commande de la pression d'un fluide sans source d'énergie auxiliaire l'élément sensible étant un piston ou un plongeur

5.

CRYOGENIC FLUID SHUT-OFF VALVE


Numéro d'application 19552786
Statut En instance
Date de dépôt 2026-02-27
Date de la première publication 2026-07-09
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Shut-off valves for cryogenic fluids are disclosed herein. A shut-off valve includes a body defining a flow passage, a valve seat located along the flow passage, a housing including an internal surface and connected to the body, a valve spindle, and a buffer. The valve spindle extends through the housing. The valve spindle includes a seat disc configured to sealingly engage the valve seat and a spindle collar. The buffer circumferentially surrounds and is connected to at least a portion of the valve spindle and is slidingly engaged with the internal surface of the housing. The buffer defines a notch extending circumferentially around a portion of the buffer. The spindle collar extends into the notch to align and position the buffer around the valve spindle.

Classes IPC  ?

  • F16K 1/02 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée
  • F16K 1/48 - Fixation des corps de soupapes aux tiges des soupapes
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
  • F16K 41/10 - Joints d'étanchéité pour tiges avec un diaphragme, p. ex. en forme de soufflet ou de tube

6.

Pressure relief valves for liquid hydrogen tanks


Numéro d'application 18686258
Numéro de brevet 12704190
Statut Délivré - en vigueur
Date de dépôt 2021-08-26
Date de la première publication 2026-06-11
Date d'octroi 2026-08-11
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Pressure relief valves for liquid hydrogen tanks are disclosed. An example pressure relief valve includes a valve body defining a chamber. A seat body defines a valve seat positioned within the chamber. A valve disc includes a flange and defines a sealing surface. The valve disc is configured to engage the valve seat in a closed position. A guide includes a first guide end and a second guide end. The first guide end defines a recessed surface that securely receives the flange of the valve disc. A retainer is coupled to the guide and defines an inner ledge. The flange of the valve disc is secured between the inner ledge and the first guide end. A cap is coupled to the valve body within the chamber. A spring extends between and engages the cap and the second guide end to bias the valve disc to the closed position.

Classes IPC  ?

  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 17/06 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort avec dispositions particulières pour régler la pression d'ouverture
  • F17C 13/04 - Disposition ou montage des soupapes

7.

AUTOMATED NOZZLES FOR CRYOGENIC FLUID TRANSFER


Numéro d'application 19371882
Statut En instance
Date de dépôt 2025-10-28
Date de la première publication 2026-05-28
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Grenaway, John
  • Ervin, Clark

Abrégé

Automated nozzles for cryogenic fluid transfer are disclosed. A nozzle includes a flow body. The nozzle includes a rotating sleeve configured to rotate about the flow body. The rotating sleeve defines cam slot(s) configured to slidably receive respective teeth of a receptacle as the rotating sleeve is rotated from an unlocked position to a locked position. The rotating sleeve defines cutouts and includes helical guide rails. Each of the helical guide rails is located at an innermost wall defining a respective one of the cutouts. The nozzle includes locking/unlocking actuators. Each of the locking/unlocking actuators includes a shaft configured to engage and push against a respective one of the helical guide rails to cause the rotating sleeve to rotate between the unlocked position and the locked position.

Classes IPC  ?

  • F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts
  • F16L 37/62 - Accouplements du type à action rapide actionnés pneumatiquement ou hydrauliquement
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés

8.

AUTOMATED NOZZLES FOR CRYOGENIC FLUID TRANSFER


Numéro d'application US2025052916
Numéro de publication 2026/096508
Statut Délivré - en vigueur
Date de dépôt 2025-10-28
Date de publication 2026-05-07
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Grenaway, John
  • Ervin, Clark

Abrégé

Automated nozzles for cryogenic fluid transfer are disclosed. A nozzle includes a flow body. The nozzle includes a rotating sleeve configured to rotate about the flow body. The rotating sleeve defines cam slot(s) configured to slidably receive respective teeth of a receptacle as the rotating sleeve is rotated from an unlocked position to a locked position. The rotating sleeve defines cutouts and includes helical guide rails. Each of the helical guide rails is located at an innermost wall defining a respective one of the cutouts. The nozzle includes locking/unlocking actuators. Each of the locking/unlocking actuators includes a shaft configured to engage and push against a respective one of the helical guide rails to cause the rotating sleeve to rotate between the unlocked position and the locked position.

Classes IPC  ?

  • F16L 37/107 - Accouplements du type à baïonnette
  • F16L 37/32 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement
  • F16L 37/62 - Accouplements du type à action rapide actionnés pneumatiquement ou hydrauliquement
  • F16L 59/14 - Dispositions pour l'isolation des tuyaux ou des tuyauteries

9.

Nozzle


Numéro d'application 29984917
Numéro de brevet D1125460
Statut Délivré - en vigueur
Date de dépôt 2025-01-15
Date de la première publication 2026-05-05
Date d'octroi 2026-05-05
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Mendenhall, Andrew B.
  • Zink, Paul T.

10.

BREAKAWAY VALVE FOR A CRYOGENIC FLUID TANK


Numéro d'application 18707769
Statut En instance
Date de dépôt 2022-10-17
Date de la première publication 2026-03-12
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Grenaway, John

Abrégé

An example breakaway valve for a cryogenic fluid tank includes a first valve and a second valve. The first valve includes a first valve body that defines through-holes and notches along a distal edge. The second valve includes a second valve body that defines a first set of blind holes and a second set of blind holes. Shear pins are configured to extend through the through-holes and into the first set of blind holes. The shear pins are configured to shear apart when at least a predetermined axial force is applied. Anti-rotation pins are configured to extend through the notches and into the second set of blind holes. The anti-rotation pins are configured to withstand up to at least a predetermined torsional force to deter the second valve from separating from the first valve prior to at least the predetermined axial force is applied.

Classes IPC  ?

  • F16L 37/32 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement
  • F17C 13/04 - Disposition ou montage des soupapes

11.

Nozzle


Numéro d'application 29788940
Numéro de brevet D1087522
Statut Délivré - en vigueur
Date de dépôt 2021-08-16
Date de la première publication 2025-08-12
Date d'octroi 2025-08-12
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Mendenhall, Andrew B.
  • Zink, Paul T.

12.

FIRE-RESISTANT GLOBE VALVE


Numéro d'application US2024061083
Numéro de publication 2025/137318
Statut Délivré - en vigueur
Date de dépôt 2024-12-19
Date de publication 2025-06-26
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Herman, Christopher, Taylor
  • Pardue, James
  • Tickle, Tracy

Abrégé

A fire-resistant globe valve includes a valve body (110) defining an inlet, an outlet, and a flow path (116). The globe valve includes a valve seat (120) located along the flow path between the inlet and the outlet, a stem (140) including a first end and a second end, and a plug (150) coupled to the second end of the stem. The plug includes a plug body (160) and a seat disc (190). The seat disc is coupled to the plug body. The seat disc is configured to sealingly engage the valve seat in a first closed position. The globe valve includes one or more springs (185) positioned between and engaging the second end of the stem and the plug body. The one or more springs are configured to bias the plug body to sealingly engage the valve seat in a second closed position when the seat disc deforms from exposure to fire conditions.

Classes IPC  ?

  • F16K 17/38 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fonctionnant sous l'action de circonstances extérieures, p. ex. un choc, un changement de position d'une température excessive
  • F16K 1/44 - Détails du siège ou du corps de soupape pour les soupapes à double siège

13.

FIRE-RESISTANT GLOBE VALVE


Numéro d'application 18988217
Statut En instance
Date de dépôt 2024-12-19
Date de la première publication 2025-06-26
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Herman, Christopher Taylor
  • Pardue, James
  • Tickle, Tracy

Abrégé

A fire-resistant globe valve includes a valve body defining an inlet, an outlet, and a flow path. The globe valve includes a valve seat located along the flow path between the inlet and the outlet, a stem including a first end and a second end, and a plug coupled to the second end of the stem. The plug includes a plug body and a seat disc. The seat disc is coupled to the plug body. The seat disc is configured to sealingly engage the valve seat in a first closed position. The globe valve includes one or more springs positioned between and engaging the second end of the stem and the plug body. The one or more springs are configured to bias the plug body to sealingly engage the valve seat in a second closed position when the seat disc deforms from exposure to fire conditions.

Classes IPC  ?

  • F16K 1/04 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée et dont l'élément de fermeture fait corps avec la tige, p. ex. soupapes principales
  • F16K 1/08 - Dispositions particulières pour améliorer l'écoulement, p. ex. formes particulières des passages ou des chambres dans lesquelles la tige est perpendiculaire à la direction générale de l'écoulement

14.

Display screen or portion thereof with animated graphical user interface


Numéro d'application 29911810
Numéro de brevet D1078768
Statut Délivré - en vigueur
Date de dépôt 2023-09-08
Date de la première publication 2025-06-10
Date d'octroi 2025-06-10
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Reeves, Cody
  • Courson, Paul A.
  • Hegman, Thomas
  • Rutherford, Scott

15.

Nozzle


Numéro d'application 29788939
Numéro de brevet D1071479
Statut Délivré - en vigueur
Date de dépôt 2021-08-16
Date de la première publication 2025-04-22
Date d'octroi 2025-04-22
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Mendenhall, Andrew B.
  • Zink, Paul T.

16.

Nozzle


Numéro d'application 29788938
Numéro de brevet D1071087
Statut Délivré - en vigueur
Date de dépôt 2021-08-16
Date de la première publication 2025-04-15
Date d'octroi 2025-04-15
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Mendenhall, Andrew B.
  • Zink, Paul T.

17.

Nozzle


Numéro d'application 29826417
Numéro de brevet D1071097
Statut Délivré - en vigueur
Date de dépôt 2022-02-11
Date de la première publication 2025-04-15
Date d'octroi 2025-04-15
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Mendenhall, Andrew B.
  • Zink, Paul T.

18.

SP SUPERIOR PRODUCTS, LLC


Numéro d'application 238841900
Statut Enregistrée
Date de dépôt 2025-03-27
Date d'enregistrement 2026-08-07
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 06 - Métaux communs et minerais; objets en métal

Produits et services

(1) Compressed gas fittings made of metal, namely, adapters, bushings, couplers, caps; manifolds of metal for pipes; check valves, demand valves, release valves, and shutoff valves of metal

19.

Nozzle


Numéro d'application 29788937
Numéro de brevet D1068026
Statut Délivré - en vigueur
Date de dépôt 2021-08-16
Date de la première publication 2025-03-25
Date d'octroi 2025-03-25
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Mendenhall, Andrew B.
  • Zink, Paul T.

20.

Breakaway valve for a cryogenic fluid tank


Numéro d'application 18731711
Numéro de brevet 12565957
Statut Délivré - en vigueur
Date de dépôt 2024-06-03
Date de la première publication 2025-03-20
Date d'octroi 2026-03-03
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Grenaway, John

Abrégé

A breakaway valve for a cryogenic fluid tank includes a tank-side valve and a nozzle-side valve. The tank-side valve is connected to and forms a first vacuum-insulation layer with a first jacketed hose. The first jacket support includes first bellows configured to reduce heat transfer with the first vacuum-insulation layer and one or more first bellow supports that include first teeth inserted between and engaging the first bellows to provide structural support to the first bellows. The nozzle-side valve is connected to and forms a second vacuum-insulation layer with a second jacketed hose. The second jacket support includes second bellows configured to reduce heat transfer with the second vacuum-insulation layer and one or more second bellow supports that include second teeth inserted between and engaging the second bellows to provide structural support to the second bellows.

Classes IPC  ?

  • F16L 37/32 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement
  • B67D 7/32 - Aménagements des dispositifs de sécurité ou d'alarmeMoyens pour empêcher un débit non autorisé du liquide
  • F16L 37/14 - Raccords par insertion d'un élément entre surfaces à unir, p. ex. par un bout de fil, une goupille, une chaîne
  • F16L 55/10 - Moyens pour arrêter l'écoulement dans les tuyaux ou manches

21.

BREAKAWAY VALVE FOR A CRYOGENIC FLUID TANK


Numéro d'application US2024037209
Numéro de publication 2025/019213
Statut Délivré - en vigueur
Date de dépôt 2024-07-09
Date de publication 2025-01-23
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Herman, Christopher, Taylor
  • Li, Xin, Ming
  • Grenaway, John

Abrégé

A breakaway valve for a cryogenic fluid tank is disclosed. A breakaway valve includes a first valve, a second valve, and a breakaway assembly. The first valve defines a through-hole. The second valve defines a counterbore having a primary hole and a major hole. The breakaway assembly is configured to fasten the first valve to the second valve. The breakaway assembly comprises a bushing, a pin, and one or more nuts. The bushing extends through the through- hole, is fixedly coupled to the first valve, and is received by the major hole of the counterbore. The pin extends through the bushing and the through-hole and is fixedly received by the primary hole of the counterbore. The one or more nuts retain the pin in place. The pin breaks apart to decouple the first valve and the second valve when at least a predefined tensile force is applied.

Classes IPC  ?

  • F16L 55/10 - Moyens pour arrêter l'écoulement dans les tuyaux ou manches
  • F16K 17/40 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage avec élément de rupture, p. ex. un diaphragme de rupture, un joint fusible

22.

Cryogenic fluid shut-off valve


Numéro d'application 18736008
Numéro de brevet 12595852
Statut Délivré - en vigueur
Date de dépôt 2024-06-06
Date de la première publication 2025-01-16
Date d'octroi 2026-04-07
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Shut-off valves for cryogenic fluids are disclosed herein. A shut-off valve includes a body that defines void(s) in fluid communication with a valve inlet and a valve outlet. The shut-off valve includes a valve seat defined by the body, a housing connected to the body, and a valve spindle disposed within the housing. The valve spindle includes a seat disc configured to sealingly engage with the valve seat. The shut-off valve includes a buffer composed of a cryogenic temperature resistant material circumferentially surrounding and connected to at least a portion of the valve spindle and slidingly engaged with an internal surface of the housing. The shut-off valve includes a valve actuating member operatively connected to the valve spindle and configured to cause an axial movement of the valve spindle, the seat disc, and the buffer to control a flow of a fluid.

Classes IPC  ?

  • F16K 1/02 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée
  • F16K 1/48 - Fixation des corps de soupapes aux tiges des soupapes
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
  • F16K 41/10 - Joints d'étanchéité pour tiges avec un diaphragme, p. ex. en forme de soufflet ou de tube

23.

EXCESS FLOW VALVE FOR CRYOGENIC FLUID TANK


Numéro d'application 18682562
Statut En instance
Date de dépôt 2021-08-30
Date de la première publication 2024-12-26
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Zhang, Zhao
  • Cao, Guangbin

Abrégé

An excess flow valve for cryogenic fluid is disclosed. An example excess flow valve includes a body, a piston plug, and a spring. The body includes a valve seat and an inner body surface that defines an inlet, an outlet, and a chamber. The piston plug is disposed within the chamber. The piston plug includes a plug that is configured to engage the valve seat in a closed position and be disengaged from the valve seat in an open position. The piston plug includes an inner piston surface, an outer piston surface, and an flange that extends from the outer piston surface and defines a flange surface. The flange, the outer piston surface, and the inner body surface at least partially define a spring slot outside of the fluid flow path. The spring is disposed in the spring slot to bias the piston plug toward the open position.

Classes IPC  ?

  • F16K 17/30 - Soupapes ou clapets limiteurs de débit fonctionnant par différence de pression entre deux points de l'écoulement et agissant directement sur l'élément d'obturation dans un sens uniquement sous l'action d'un ressort
  • F17C 13/04 - Disposition ou montage des soupapes

24.

Coupling nozzle for cryogenic fluid


Numéro d'application 18814156
Numéro de brevet 12612987
Statut Délivré - en vigueur
Date de dépôt 2024-08-23
Date de la première publication 2024-12-19
Date d'octroi 2026-04-28
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

Methods and apparatus are disclosed for a coupling nozzle for cryogenic fluid. A nozzle for cryogenic fluid includes a flow body, a flow control assembly, a first linear actuator, and a locking actuator. The flow body defines a conduit. The flow control assembly is at least partially disposed in the conduit of the flow body. The flow control assembly is configured to transition between an open position and a closed position to permit and prevent, respectively, the cryogenic fluid to flow through the flow body. The first linear actuator includes an actuator body and a first shaft. The first shaft is configured to slide between an extended position and a contracted position to transition the flow control assembly between the open position and the closed position, respectively. The locking actuator is for locking the nozzle to a receptacle in an automated manner.

Classes IPC  ?

  • F16L 37/096 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen de crochets articulés autour d'un axe
  • F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts
  • F16L 37/42 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un clapet dont l'ouverture se fait automatiquement au moment de l'accouplement le clapet comportant un canal axial communiquant avec des trous radiaux
  • F16L 37/47 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un robinet à boisseau ou à obturateur
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés

25.

SOLENOID PILOT VALVES FOR CRYOGENIC FLUID


Numéro d'application CN2023093906
Numéro de publication 2024/234147
Statut Délivré - en vigueur
Date de dépôt 2023-05-12
Date de publication 2024-11-21
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Tu, Xiang

Abrégé

Solenoid pilot valves for cryogenic fluid are disclosed. An example valve includes a body defining an inlet side and an outlet side. The valve includes a coil assembly coupled to the body. The valve includes a poppet that is configured to translate between a closed position and an open position. The poppet defines a pilot hole that is configured to fluidly connect a chamber and the outlet side. The valve includes a plunger assembly positioned in the chamber. The plunger assembly includes a first plunger that is positioned such that the coil assembly is configured to cause the first plunger to translate. The plunger assembly includes a second plunger that is slidably coupled to the first plunger. The second plunger is configured to close the pilot hole in a second extended position and is configured to open the pilot hole in a partially retracted position and a second retracted position.

Classes IPC  ?

  • F16K 3/00 - Robinets-vannes ou tiroirs, c.-à-d. dispositifs obturateurs dont l'élément de fermeture glisse le long d'un siège pour l'ouverture ou la fermeture
  • F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort

26.

PRESTO-LINK


Numéro d'application 1823460
Statut Enregistrée
Date de dépôt 2024-10-21
Date d'enregistrement 2024-10-21
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Classes de Nice  ? 09 - Appareils et instruments scientifiques et électriques

Produits et services

Pressure gauge for liquid propane gas containers and regulators.

27.

Pressure relief valve


Numéro d'application 18747149
Numéro de brevet 12392418
Statut Délivré - en vigueur
Date de dépôt 2024-06-18
Date de la première publication 2024-11-14
Date d'octroi 2025-08-19
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Pressure-relief valves are disclosed. A valve for conveying fluid includes a body, a valve seat, and a valve seat disc. The body includes a plurality of inner surfaces. The valve seat includes a curved outer surface. A first portion of the curved outer surface is configured to contact at least one of the plurality of inner surfaces of the body to secure the valve seat in the body. The valve seat disc is configured to move between a closed position at which the valve seat disc sealingly engages a second outer portion of the curved outer surface of the valve seat and an open position at which the valve seat disc is disengaged from the curved outer surface of the valve seat.

Classes IPC  ?

  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 15/06 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés par tige-guide
  • F16K 17/06 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort avec dispositions particulières pour régler la pression d'ouverture

28.

Low-emission nozzle and receptacle coupling for cryogenic fluid


Numéro d'application 18750910
Numéro de brevet 12601435
Statut Délivré - en vigueur
Date de dépôt 2024-06-21
Date de la première publication 2024-11-14
Date d'octroi 2026-04-14
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Grenaway, John
  • Rakos, David Michael

Abrégé

A low-emission nozzle and receptacle coupling for cryogenic fluid is disclosed. A nozzle includes a body, a shaft, a poppet eat, and a poppet. The body includes an outer shell, body segment(s), and interior walls sealingly coupled together. At least one of the interior walls is coupled to the outer shell. The interior walls extend longitudinally back-and-forth in a zig-zag pattern to define an elongated conduction path between the chamber and an exterior of the nozzle to impede a heat leak between the chamber and the exterior. The shaft is housed within and slidably extends through the chamber. The poppet is coupled to the shaft and is configured to engage a receptacle poppet when the receptacle is coupled to the nozzle. The poppet is configured to engage the poppet seat in a closed position and be disengaged from the poppet seat in an open position.

Classes IPC  ?

  • F16L 37/24 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette
  • F16L 37/244 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette dans lesquels l'accouplement et le tuyau sont coaxiaux
  • F16L 37/35 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement au moins un des clapets possédant un canal axial communiquant avec des ouvertures latérales
  • F17C 13/00 - Détails des récipients ou bien du remplissage ou du vidage des récipients

29.

Combination regulator valve


Numéro d'application 18767542
Numéro de brevet 12638093
Statut Délivré - en vigueur
Date de dépôt 2024-07-09
Date de la première publication 2024-10-31
Date d'octroi 2026-05-26
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Morefield, Patrick N.

Abrégé

A combination regulator valve for conveying fluid is disclosed. A valve for conveying fluid includes a body, a bonnet secured to the body, a diaphragm compressed between the bonnet and the body, and a bonnet screw that is ring-shaped and configured to thread into the body to secure the bonnet with respect to the body.

Classes IPC  ?

  • F16K 17/30 - Soupapes ou clapets limiteurs de débit fonctionnant par différence de pression entre deux points de l'écoulement et agissant directement sur l'élément d'obturation dans un sens uniquement sous l'action d'un ressort
  • F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
  • G05D 16/06 - Commande de la pression d'un fluide sans source d'énergie auxiliaire l'élément sensible étant un organe élastique cédant à la pression, p. ex. un diaphragme, un soufflet, une capsule

30.

PRESTO-LINK


Numéro d'application 236368400
Statut Enregistrée
Date de dépôt 2024-10-21
Date d'enregistrement 2026-03-18
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Classes de Nice  ? 09 - Appareils et instruments scientifiques et électriques

Produits et services

(1) Pressure gauge for liquid propane gas containers and regulators.

31.

PRESSURE RELIEF VALVE FOR CRYOGENIC FUEL TANKS


Numéro d'application CN2023085492
Numéro de publication 2024/197819
Statut Délivré - en vigueur
Date de dépôt 2023-03-31
Date de publication 2024-10-03
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Hamm, Mark Kendrick

Abrégé

A pressure relief valve (100) for a cryogenic fuel tank, the pressure relief valve includes a valve body (200) that includes a valve seat (240), defines an inlet (210) and an outlet (220), and at least partially defines a chamber (230). The pressure relief valve includes a poppet (800) that is at least partially housed in the chamber and is configured to slide between a closed position and an open position. The poppet includes a poppet body (820) and a seat disc (870) coupled to the poppet body. The poppet body defines a bleed hole (860) that fluidly connects the chamber to the outlet such that a chamber pressure in the chamber is to equalize with an outlet-side pressure over time when the poppet is in the closed position or the open position. The pressure relief valve includes a spring (700) at least partially housed in the chamber and configured to bias the poppet toward the closed position.

Classes IPC  ?

  • F16K 15/18 - Soupapes, clapets ou valves de retenue à mécanisme de commandeSoupape de retenue et soupape à mécanisme de commande combinées
  • F16K 15/02 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés
  • F17C 13/04 - Disposition ou montage des soupapes

32.

Rapid-connect coupler and receptacle having anti-rotation feature


Numéro d'application 18639043
Numéro de brevet 12429156
Statut Délivré - en vigueur
Date de dépôt 2024-04-18
Date de la première publication 2024-08-08
Date d'octroi 2025-09-30
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Tickle, Tracy N.
  • Howard, Jeffrey S.
  • Thomas, Chad

Abrégé

A rapid-connect coupler having an anti-rotation feature is disclosed. A coupler includes a housing, a probe configured to translate longitudinally within the housing, a ball cage, a plurality of balls disposed in the ball cage, and a slidable sleeve coupled to the probe and configured to translate longitudinally with the probe. The slidable sleeve includes a collar that defines a plurality of channels positioned radially about and extending axially along an outer surface. The plurality of channels of the collar are configured to receive bearings of the receptacle to prevent rotation of the coupler relative to the receptacle. To couple the coupler to the receptacle, the slidable sleeve is configured to slide in a longitudinal direction into the receptacle to cause the plurality of channels to receive the bearings of the receptacle and subsequently cause the plurality of balls to lock the coupler to the receptacle.

Classes IPC  ?

  • F16L 37/36 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets qui sont actionnés de façon que le courant à travers l'accouplement ne s'établisse qu'après l'accouplement sans désengagement possible
  • F16L 37/12 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage utilisant des crochets, cliquet, ou autres organes de blocage mobiles ou que l'on peut insérer
  • F16L 37/23 - Accouplements du type à action rapide dans lesquels l'assemblage est maintenu par des billes, rouleaux ou ressorts hélicoïdaux sous pression radiale entre parties au moyen de billes
  • F16L 55/07 - Aménagement ou montage de dispositifs, p. ex. soupapes, pour ventiler ou aérer ou purger
  • B67D 7/36 - Aménagements des vannes de commande du débit ou de la pression

33.

Cryogenic cylinder control system, globe valve, and solenoid valve


Numéro d'application 18634398
Numéro de brevet 12338899
Statut Délivré - en vigueur
Date de dépôt 2024-04-12
Date de la première publication 2024-08-01
Date d'octroi 2025-06-24
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Cryogenic solenoid valves are disclosed. A solenoid valve assembly includes a valve body that includes a valve seat. The solenoid valve assembly includes a cartridge mounted to the valve body, a plunger slidably received by the cartridge, and a seat disc holder slidably received by the cartridge. The solenoid valve assembly includes a retainer attached to the seat disc holder such that the retainer and the seat disc holder form a plunger head receiving cavity that houses a head of the plunger. The solenoid valve assembly includes a seat disc attached to the seat disc holder. The solenoid valve assembly includes an electromagnetic coil energizable to cause the solenoid valve assembly to move from a closed configuration in which the seat disc sealingly engages the valve seat and an open configuration in which the seat disc is disengaged from the valve seat.

Classes IPC  ?

  • F16K 1/04 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée et dont l'élément de fermeture fait corps avec la tige, p. ex. soupapes principales
  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
  • F17C 13/04 - Disposition ou montage des soupapes
  • G05D 16/20 - Commande de la pression d'un fluide caractérisée par l'utilisation de moyens électriques
  • F16K 1/36 - Corps de soupapes
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
  • F16K 41/04 - Joints d'étanchéité pour tiges avec un presse-étoupe avec une bague au moins, en caoutchouc ou d'un matériau analogue, entre la tige et son logement

34.

Actuating assembly for an internal valve


Numéro d'application 18608464
Numéro de brevet 12442457
Statut Délivré - en vigueur
Date de dépôt 2024-03-18
Date de la première publication 2024-07-04
Date d'octroi 2025-10-14
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Combs, Elijah Marshall

Abrégé

A valve actuating assembly for actuating an internal valve between a closed position and an open position is provided. The valve actuating assembly comprises a cam holder stem securely connected to a valve body of the internal valve; a cam holder operably coupled to the cam holder stem; a cam operably mounted to the cam holder; an actuating shaft extending through at least a portion of the valve body, rotation of the actuating shaft causing rotation of the cam holder and the cam; and a locking ring configured to rotatably secure the cam holder to the cam holder stem, wherein the actuating shaft is removably coupled to the cam holder such that the actuating shaft can be removed from the valve body while the cam and cam holder remain coupled to the valve body.

Classes IPC  ?

  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 15/18 - Soupapes, clapets ou valves de retenue à mécanisme de commandeSoupape de retenue et soupape à mécanisme de commande combinées
  • F16K 31/524 - Moyens mécaniques d'actionnement à manivelle, excentrique ou came à came

35.

TWO-STAGE PRESSURE REGULATOR FOR COMPRESSED GAS


Numéro d'application CN2022137173
Numéro de publication 2024/119390
Statut Délivré - en vigueur
Date de dépôt 2022-12-07
Date de publication 2024-06-13
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Li, Yao
  • Fu, Wen

Abrégé

A two-stage pressure regulator (100) for compressed gas is provided. The two-stage pressure regulator (100) includes a body (110), an upstream piston (200), a seat assembly, and a downstream piston (400). The body (110) defines an inlet (160), an outlet (170), a chamber (120) and an upstream valve seat (164). The upstream piston (200) is slidably positioned in the chamber (120) adjacent the inlet (160). The upstream piston (200) includes a first plug (250) that is configured to engage the upstream valve seat(164) in a first closed position and be disengaged from the upstream valve seat (164) in a first open position. The seat assembly is housed in the chamber (120) and includes a downstream valve seat (340). The downstream piston (400) is slidably positioned in the chamber (120) adjacent the outlet (170). The downstream piston (400) includes a second plug (450) that is configured to engage the downstream valve seat (340) in a second closed position and be disengaged from the downstream valve seat (340) in a second open position.

Classes IPC  ?

  • F16K 17/20 - Soupapes ou clapets limiteurs de débit
  • G05D 16/00 - Commande de la pression d'un fluide
  • B09B 1/00 - Mise à la décharge des déchets solides

36.

Nozzle


Numéro d'application 29789593
Numéro de brevet D1029992
Statut Délivré - en vigueur
Date de dépôt 2021-10-01
Date de la première publication 2024-06-04
Date d'octroi 2024-06-04
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Mendenhall, Andrew
  • Zink, Paul

37.

Cryogenic fluid shut-off valve


Numéro d'application 18550961
Numéro de brevet 12435793
Statut Délivré - en vigueur
Date de dépôt 2021-11-17
Date de la première publication 2024-05-02
Date d'octroi 2025-10-07
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Shut-off valves for cryogenic fluids are disclosed herein. An example valve includes a valve body defining a flow path and a valve seat, a bonnet coupled to the valve body and defining a bonnet chamber, a plug, and a stem coupled to the plug. The stem is configured to slide to cause the plug to slide. The valve includes a spindle that includes external threads. The spindle is configured to move along a longitudinal axis of the bonnet as the spindle is rotated about the longitudinal axis via the external threads to cause the stem to slide linearly along the longitudinal axis. The valve includes a pivot ball positioned between and operatively coupled to the stem and the spindle. The pivot ball is configured to translate linear and rotational movement of the spindle into linear movement of the stem and the plug.

Classes IPC  ?

  • F16K 1/02 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée
  • F16K 1/48 - Fixation des corps de soupapes aux tiges des soupapes
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
  • F16K 41/10 - Joints d'étanchéité pour tiges avec un diaphragme, p. ex. en forme de soufflet ou de tube

38.

REGO


Numéro de série 98527156
Statut En instance
Date de dépôt 2024-04-30
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Classes de Nice  ? 09 - Appareils et instruments scientifiques et électriques

Produits et services

downloadable mobile app being downloadable software in the nature of a mobile application for wirelessly connecting to, testing, and monitoring gauges for propane-system components; downloadable mobile app being downloadable software in the nature of a mobile application for providing information relating to valves, regulators, piping and tubing used with propane and anhydrous ammonia

39.

PRESTO-LINK


Numéro de série 98512033
Statut Enregistrée
Date de dépôt 2024-04-22
Date d'enregistrement 2025-02-04
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC ()
Classes de Nice  ? 09 - Appareils et instruments scientifiques et électriques

Produits et services

pressure gauge for liquid propane gas containers and regulators

40.

Low-emission nozzle and receptacle coupling for cryogenic fluid


Numéro d'application 18510322
Numéro de brevet 12429153
Statut Délivré - en vigueur
Date de dépôt 2023-11-15
Date de la première publication 2024-03-14
Date d'octroi 2025-09-30
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Grenaway, John
  • Rakos, David Michael

Abrégé

A low-emission nozzle and receptacle coupling for cryogenic fluid is disclosed. An example nozzle includes a body including a front end and a back end and defining a chamber through which the cryogenic fluid is to flow to the receptacle. The nozzle includes a shaft having a first end and a second end. The shaft is housed within and slidably extending through the chamber. The nozzle includes a poppet coupled to the first end of the shaft and an actuator including a stem coupled to the second end of the shaft. The stem is configured to linearly actuate to cause the shaft and the poppet to linearly actuate. The nozzle includes a coupling assembly coupling the actuator to the back end of the body. The coupling assembly includes insulating material to thermally isolate the actuator from the chamber through which the cryogenic fluid is to flow.

Classes IPC  ?

  • F17C 13/00 - Détails des récipients ou bien du remplissage ou du vidage des récipients
  • F16L 37/244 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette dans lesquels l'accouplement et le tuyau sont coaxiaux
  • F16L 37/35 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement au moins un des clapets possédant un canal axial communiquant avec des ouvertures latérales

41.

Cryogenic cylinder control system, globe valve, and solenoid valve


Numéro d'application 18479673
Numéro de brevet 12173810
Statut Délivré - en vigueur
Date de dépôt 2023-10-02
Date de la première publication 2024-01-25
Date d'octroi 2024-12-24
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Cryogenic valves are disclosed. A valve for includes a valve body, a valve seat, a gland nut coupled to the valve body, and a lower spindle threadably engaged to the valve body. The lower spindle defines a first bore. The valve includes a seat disc mounted to the lower spindle and configured to engage the valve seat in a closed configuration and be disengaged from the valve seat in an open configuration. The valve includes an upper spindle defining a spring bore. A portion of the upper spindle is received in the first bore to matingly engage the upper spindle to the lower spindle such that rotation of the upper spindle causes rotation of the lower spindle. The valve includes a spring that is at least partially disposed in the spring bore of the upper spindle and is configured to bias the upper spindle to sealingly engage the gland nut.

Classes IPC  ?

  • F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
  • F16K 1/04 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée et dont l'élément de fermeture fait corps avec la tige, p. ex. soupapes principales
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 41/04 - Joints d'étanchéité pour tiges avec un presse-étoupe avec une bague au moins, en caoutchouc ou d'un matériau analogue, entre la tige et son logement

42.

Low emission receptacles


Numéro d'application 18475764
Numéro de brevet 12297961
Statut Délivré - en vigueur
Date de dépôt 2023-09-27
Date de la première publication 2024-01-18
Date d'octroi 2025-05-13
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Thomas, Chad
  • Konishi, Howard M.
  • Howard, Jeffrey S.

Abrégé

Low emission nozzles and receptacles are disclosed. A receptacle includes a main body, a first stem, a first poppet connected to the first stem, a valve seat disposed in the main body, a first spring configured to bias the first poppet to a first closed position, a second stem slidingly engaged to the first poppet and the first stem, a second poppet connected to the second stem, and a second spring configured to bias the second poppet to a second closed position.

Classes IPC  ?

  • F17C 13/04 - Disposition ou montage des soupapes
  • F16K 15/02 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés
  • F17C 5/06 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz comprimés
  • F17C 6/00 - Procédés ou appareils pour remplir des récipients non sous pression de gaz liquéfiés ou solidifiés
  • F17C 9/00 - Procédés ou appareils pour vider les gaz liquéfiés ou solidifiés contenus dans des récipients non sous pression

43.

REGOMAC


Numéro de série 98330842
Statut Enregistrée
Date de dépôt 2023-12-26
Date d'enregistrement 2025-11-04
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC ()
Classes de Nice  ? 09 - Appareils et instruments scientifiques et électriques

Produits et services

Semi-automatic fueling nozzles; and automatic fueling nozzles

44.

Cleaning receptacle for cryogenic fluid fueling nozzle


Numéro d'application 18251329
Numéro de brevet 12551916
Statut Délivré - en vigueur
Date de dépôt 2021-11-17
Date de la première publication 2023-12-14
Date d'octroi 2026-02-17
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

A cleaning receptacle for cleaning a fueling nozzle used to transfer cryogenic fluid is disclosed. An example cleaning receptacle includes an outer body. The outer body includes an outer wall that extends circumferentially around a center axis of the cleaning receptacle. The outer wall has a first inner surface. The outer body includes a plurality of locating members extending inwardly from the first inner surface toward the center axis. The example cleaning receptacle includes a flow body. The flow body includes a second inner surface that defines a cavity and a lip at an outer end of the flow body. The example cleaning receptacle includes a spray body disposed at an inner end of the flow body. The spray body includes a spray head that defines a plurality of spray holes configured to spray air through the cavity of the flow body and onto surfaces of the fueling nozzle.

Classes IPC  ?

  • B05B 15/555 - Aménagements pour le nettoyageAménagements pour empêcher les dépôts, le séchage ou un blocageAménagements pour détecter une évacuation incorrecte en raison de la présence d’un corps étranger en utilisant des fluides nettoyants délivrés par des buses de nettoyage
  • B05B 1/14 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie
  • B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
  • B08B 5/02 - Nettoyage par la force de jets, p. ex. le soufflage de cavités
  • B05B 15/63 - Poignées

45.

Cleaning nozzle for cryogenic fluid fueling receptacle


Numéro d'application 18251344
Numéro de brevet 12661676
Statut Délivré - en vigueur
Date de dépôt 2021-11-17
Date de la première publication 2023-12-07
Date d'octroi 2026-06-23
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

A cleaning nozzle for cleaning a fueling receptacle capable of receiving a separate fueling nozzle for transferring cryogenic fluid from a fueling station is disclosed. An example cleaning nozzle includes a body that defines a cavity. The example cleaning nozzle includes a nozzle head coupled to and extending from a distal end of the body. The nozzle head defines a plurality of spray holes to spray pressurized air onto the fueling receptacle. The example cleaning nozzle includes a blower that defines a blower inlet, a blower outlet, and a blower flow path extending between the blower inlet and the blower outlet. The blower comprises a valve and a lever operatively coupled to the valve. The example cleaning nozzle includes an insert defining an insert flow path that is fluidly coupled to the blower outlet. The example cleaning nozzle includes a connector fluidly connecting the insert and the nozzle head.

Classes IPC  ?

  • B05B 15/555 - Aménagements pour le nettoyageAménagements pour empêcher les dépôts, le séchage ou un blocageAménagements pour détecter une évacuation incorrecte en raison de la présence d’un corps étranger en utilisant des fluides nettoyants délivrés par des buses de nettoyage
  • B05B 1/14 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie
  • B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
  • B08B 5/02 - Nettoyage par la force de jets, p. ex. le soufflage de cavités
  • B05B 15/63 - Poignées

46.

REGO


Numéro d'application 229686600
Statut En instance
Date de dépôt 2023-12-05
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement

Produits et services

(1) Manifolds of metal; metal pipes for liquefied natural gas transfer; screw connections, namely, connectors of metal for pipes; compressed gas fittings made of metal, namely, self-tapping bushings of metal; metal connectors for pipes and pipe clamps of metal; Manually operated ball valves of metal; manually operated butterfly values of metal; manually operated diaphragm sampling valves of metal; non-machine element metal valves, namely, manually operated metal valves noting being parts of machines for filling cylinders and tanks with gasses or air; metal valves sold as a component of cylinders for compressed gas or liquids, sold empty; apparatus for filling cylinders with gasses and air, namely, valve stems of metal for manually operated valves of metal; valves of metal, namely, needle valves, control valves, and excess flow valves and pressure relief valves for metering or controlling the flow rate of liquids, gases and air; manually operated butterfly valves of metal and parts therefor made of metal for liquids, gases and air, namely, metal valves sold as a component of cylinders for compressed gas or liquids, sold empty; fueling nozzles of metal; fueling nozzles of metal for liquefied petroleum, gases, cryogenic liquids and fuels (2) Check valves for cryogenic liquids and gases and air; check valves for metering or controlling the flow rate of liquids, gases and air (3) Regulators being flow conditioners, namely, devices for regulating fluid flow in pressurized pipelines; pressure gauges for filling cylinders with gases, cryogenic liquids, and fuels and air (4) Pressure regulators for filling cylinders with gases, cryogenic liquids, and fuels and air

47.

Pressure relief valve


Numéro d'application 17675712
Numéro de brevet 12044324
Statut Délivré - en vigueur
Date de dépôt 2019-08-29
Date de la première publication 2023-11-02
Date d'octroi 2024-07-23
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

A valve for conveying fluid has a closed position and an open position and comprises a body, a valve seat disposed in the body, a holder disposed in the body, and a valve seat disc. The valve seat comprises one or more inner surfaces and an outer surface, and the one or more inner surfaces define an inner void. The valve seat disc is connected to and movable with the holder between a first position in which the valve seat disc sealingly engages the outer surface of the valve seat and a second position in which the valve seat disc is disengaged from the outer surface of the valve seat. The valve is in the closed position when the valve seat disc is in the first position and the valve is in the open position when the valve seat disc is in the second position.

Classes IPC  ?

  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 15/06 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés par tige-guide
  • F16K 17/06 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort avec dispositions particulières pour régler la pression d'ouverture

48.

Nozzle


Numéro d'application 29789594
Numéro de brevet D1002802
Statut Délivré - en vigueur
Date de dépôt 2021-10-01
Date de la première publication 2023-10-24
Date d'octroi 2023-10-24
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Mendenhall, Andrew B.
  • Zink, Paul T.

49.

REGO


Numéro de série 98187242
Statut Enregistrée
Date de dépôt 2023-09-19
Date d'enregistrement 2024-12-17
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC ()
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement

Produits et services

Manifolds of metal; metal pipes; screw connections in the nature of metal pipe connectors; compressed gas fittings made of metal, namely, bushings of metal; metal pipe connectors and metal clamps; valves of metal, other than parts of machines and apparatus, namely, manually operated metal valves for filling cylinders and tanks with gasses or air; valves made of metal other than parts of machines for liquids, gases and air; valves of metal, other than parts of machines, namely, check valves, excess flow valves and pressure relief valves for liquids, gases and air; non-automatic fueling nozzles; non-automatic fueling nozzles for liquefied petroleum, gases, cryogenic liquids and fuel; all of the foregoing for use in connection with liquefied petroleum, gases, cryogenic liquids and fuels Pressure regulators and parts, namely, pressure gauges, high pressure regulators, low pressure regulators, multi-stage regulators, single-stage regulators, pressure relief valves, pressure compensated valves and pressure relief manifolds for cryogenic liquids and fuel; pressure regulators for filling cylinders cryogenic liquids Pressure regulators and parts, namely, pressure gauges, high pressure regulators, low pressure regulators, multi-stage regulators, single-stage regulators, pressure relief valves, pressure compensated valves and pressure relief manifolds for gases; pressure regulators for filling cylinders with gasses or air

50.

Coupling nozzle for cryogenic fluid


Numéro d'application 18319258
Numéro de brevet 12152713
Statut Délivré - en vigueur
Date de dépôt 2023-05-17
Date de la première publication 2023-09-14
Date d'octroi 2024-11-26
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

Methods and apparatus are disclosed for a coupling nozzle for cryogenic fluid. A coupling nozzle includes a flow body. The coupling nozzle includes a mount, a flow control assembly, and a pneumatic cylinder. The pneumatic cylinder includes a cylinder body and a shaft. The shaft is coupled to and configured to actuate the flow body. The coupling nozzle includes a first locking mechanism coupled to the mount and configured to secure the coupling nozzle to a receptacle in a locked position. When the first locking mechanism is in the locked position, the shaft is configured to actuate the flow control assembly. The coupling nozzle includes a redundant locking mechanism including one or more feet and a lock. The one or more feet are configured to engage the lock to prevent the first locking mechanism from transitioning from the locked position when the shaft is in the extended position.

Classes IPC  ?

  • F16L 37/096 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen de crochets articulés autour d'un axe
  • F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts
  • F16L 37/42 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un clapet dont l'ouverture se fait automatiquement au moment de l'accouplement le clapet comportant un canal axial communiquant avec des trous radiaux
  • F16L 37/47 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un robinet à boisseau ou à obturateur
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés

51.

Cryogenic cylinder control system, globe valve, and solenoid valve


Numéro d'application 18169648
Numéro de brevet 12560241
Statut Délivré - en vigueur
Date de dépôt 2023-02-15
Date de la première publication 2023-06-22
Date d'octroi 2026-02-24
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Hamm, Mark Kendrick

Abrégé

A cryogenic cylinder control system for regulating fluid within a cryogenic cylinder is disclosed. The system includes a pressure relief and vent module fluidly connectable to a head space above liquid within the cryogenic cylinder, a manual valve module fluidly connectable to the liquid within the cryogenic cylinder and to an external device, a solenoid valve module fluidly connectable to the manual valve module and to the head space within the cryogenic cylinder, a build-up coil fluidly connectable to the manual valve module and to the solenoid valve module, and a controller operatively connected to the solenoid valve module to control fluid flow through the solenoid valve module.

Classes IPC  ?

  • F17C 13/04 - Disposition ou montage des soupapes
  • F16K 1/04 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée et dont l'élément de fermeture fait corps avec la tige, p. ex. soupapes principales
  • F16K 31/06 - Moyens de fonctionnementDispositifs de retour à la position de repos électriquesMoyens de fonctionnementDispositifs de retour à la position de repos magnétiques utilisant un aimant
  • G05D 16/20 - Commande de la pression d'un fluide caractérisée par l'utilisation de moyens électriques
  • F16K 1/36 - Corps de soupapes
  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
  • F16K 41/04 - Joints d'étanchéité pour tiges avec un presse-étoupe avec une bague au moins, en caoutchouc ou d'un matériau analogue, entre la tige et son logement

52.

CRYO-FLOW


Numéro d'application 226339600
Statut Enregistrée
Date de dépôt 2023-06-12
Date d'enregistrement 2025-08-22
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

(1) Valves, namely, needle valves, control valves, and check valves for cryogenic liquids and gases and air (2) Valves, namely, pressure relief valves for cryogenic liquids and gases and air

53.

BREAKAWAY VALVE FOR A CRYOGENIC FLUID TANK


Numéro d'application CN2022125644
Numéro de publication 2023/088010
Statut Délivré - en vigueur
Date de dépôt 2022-10-17
Date de publication 2023-05-25
Propriétaire
  • ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
  • SHANGHAI REGO FLOW TECHNOLOGY, CO., LTD. (Chine)
Inventeur(s)
  • Cao, Guangbin
  • Grenaway, John

Abrégé

An example breakaway valve for a cryogenic fluid tank includes a first valve and a second valve. The first valve includes a first valve body that defines through-holes and notches along a distal edge. The second valve includes a second valve body that defines a first set of blind holes and a second set of blind holes. Shear pins are configured to extend through the through-holes and into the first set of blind holes. The shear pins are configured to shear apart when at least a predetermined axial force is applied. Anti-rotation pins are configured to extend through the notches and into the second set of blind holes. The anti-rotation pins are configured to withstand up to at least a predetermined torsional force to deter the second valve from separating from the first valve prior to at least the predetermined axial force is applied.

Classes IPC  ?

  • F16L 29/04 - Raccords comportant des moyens pour couper le courant de fluide comportant un obturateur dans chacune des deux extrémités de tuyau, les obturateurs s'ouvrant automatiquement lors de l'accouplement
  • F16L 37/32 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement
  • F16L 59/075 - Dispositions utilisant une couche d'air ou le vide la couche d'air ou le vide étant délimités par des canaux longitudinaux répartis sur la périphérie d'un tube
  • F16K 15/06 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés par tige-guide
  • F16K 17/30 - Soupapes ou clapets limiteurs de débit fonctionnant par différence de pression entre deux points de l'écoulement et agissant directement sur l'élément d'obturation dans un sens uniquement sous l'action d'un ressort

54.

BREAKAWAY VALVE FOR A CRYOGENIC FLUID TANK


Numéro d'application CN2021131494
Numéro de publication 2023/087216
Statut Délivré - en vigueur
Date de dépôt 2021-11-18
Date de publication 2023-05-25
Propriétaire
  • ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
  • SHANGHAI REGO FLOW TECHNOLOGY, CO., LTD. (Chine)
Inventeur(s)
  • Cao, Guangbin
  • Grenaway, John

Abrégé

A breakaway valve for a cryogenic fluid tank is disclosed. An example breakaway valve includes a tank-side valve connected to a cryogenic tank and a nozzle-side valve connected to a nozzle. The tank-side valve includes a tank-side valve body that defines tank-side pin holes. The nozzle-side valve includes a nozzle-side valve body that defines nozzle-side pin holes. The breakaway valve includes pins configured to extend through the tank-side pin hole and the nozzle-side pin hole to securely couple the tank-side valve and the nozzle-side valve together. When the tank-side valve and the nozzle-side valve are decoupled from each other in a breakaway event, the tank-side valve and the nozzle-side valve are in respective closed positions to prevent cryogenic fluid from being emitted.

Classes IPC  ?

  • F16L 29/04 - Raccords comportant des moyens pour couper le courant de fluide comportant un obturateur dans chacune des deux extrémités de tuyau, les obturateurs s'ouvrant automatiquement lors de l'accouplement
  • F16L 37/32 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement
  • F16L 59/075 - Dispositions utilisant une couche d'air ou le vide la couche d'air ou le vide étant délimités par des canaux longitudinaux répartis sur la périphérie d'un tube
  • F16K 15/06 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés par tige-guide
  • F16K 17/30 - Soupapes ou clapets limiteurs de débit fonctionnant par différence de pression entre deux points de l'écoulement et agissant directement sur l'élément d'obturation dans un sens uniquement sous l'action d'un ressort

55.

Combination valve for pressure building and final-line gas regulation


Numéro d'application 17304302
Numéro de brevet 11650605
Statut Délivré - en vigueur
Date de dépôt 2021-06-17
Date de la première publication 2023-05-16
Date d'octroi 2023-05-16
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Hamm, Mark Kendrick
  • Grenaway, John

Abrégé

A combination valve for pressure building and final-line gas regulation is disclosed. An example valve includes a body defining a first tank port and a second tank port, an outlet port, and a linking chamber fluidly connected to the second tank port. The valve includes a first piston diaphragm at least partially defining a first pressure cavity fluidly connected to the first tank port and a first plug operatively connected to the first piston diaphragm. The first pressure cavity is fluidly connected to the linking chamber when the first plug is in an open position. The valve includes a second piston diaphragm at least partially defining a second pressure cavity fluidly connected to the outlet port and a second plug operatively connected to the second piston diaphragm. The second pressure cavity is fluidly connected to the linking chamber when the second plug is in an open position.

Classes IPC  ?

  • G05D 7/03 - Commande de débits avec source d'énergie auxiliaire non électrique

56.

CRYO-FLOW


Numéro de série 97927175
Statut Enregistrée
Date de dépôt 2023-05-09
Date d'enregistrement 2025-08-26
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC ()
Classes de Nice  ? 06 - Métaux communs et minerais; objets en métal

Produits et services

valves of metal, other than parts of machines, namely, needle valves, control valves, check valves, and pressure relief valves for cryogenic liquids and gases and air

57.

ROTOGAGE


Numéro d'application 018863434
Statut Enregistrée
Date de dépôt 2023-04-18
Date d'enregistrement 2023-09-09
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 09 - Appareils et instruments scientifiques et électriques

Produits et services

Liquid level gauges for use in conjunction with liquefied gas containers, and parts or accessories for use therewith.

58.

EXCESS FLOW VALVE FOR CRYOGENIC FLUID TANK


Numéro d'application CN2021115338
Numéro de publication 2023/028759
Statut Délivré - en vigueur
Date de dépôt 2021-08-30
Date de publication 2023-03-09
Propriétaire
  • ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
  • SHANGHAI REGO FLOW TECHNOLOGY, CO., LTD. (Chine)
Inventeur(s)
  • Zhang, Zhao
  • Cao, Guangbin

Abrégé

An excess flow valve for cryogenic fluid is disclosed. An example excess flow valve (100) includes a body (200), a piston plug (300), and a spring (400). The body (200) includes a valve seat (246) and an inner body surface (240) that defines an inlet (215), an outlet (225), and a chamber (250). The piston plug (300) is disposed within the chamber (250). The piston plug (300) includes a plug (330) that is configured to engage the valve seat (246) in a closed position and be disengaged from the valve seat (246) in an open position. The piston plug (300) includes an inner piston surface (354), an outer piston surface (352), and a flange (340) that extends from the outer piston surface (352) and defines a flange surface (342). The flange (340), the outer piston surface (352), and the inner body surface (240) at least partially define a spring slot (256) outside of the fluid flow path. The spring (400) is disposed in the spring slot (256) to bias the piston plug toward the open position. The excess flow valve is more effective.

Classes IPC  ?

  • F16K 17/06 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort avec dispositions particulières pour régler la pression d'ouverture
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 31/122 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un piston

59.

PRESSURE RELIEF VALVES FOR LIQUID HYDROGEN TANKS


Numéro d'application CN2021114819
Numéro de publication 2023/024033
Statut Délivré - en vigueur
Date de dépôt 2021-08-26
Date de publication 2023-03-02
Propriétaire
  • ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
  • SHANGHAI REGO FLOW TECHNOLOGY, CO., LTD. (Chine)
Inventeur(s) Cao, Guangbin

Abrégé

Pressure relief valves for liquid hydrogen tanks are disclosed. An example pressure relief valve includes a valve body defining a chamber. A seat body defines a valve seat positioned within the chamber. A valve disc includes a flange and defines a sealing surface. The valve disc is configured to engage the valve seat in a closed position. A guide includes a first guide end and a second guide end. The first guide end defines a recessed surface that securely receives the flange of the valve disc. A retainer is coupled to the guide and defines an inner ledge. The flange of the valve disc is secured between the inner ledge and the first guide end. A cap is coupled to the valve body within the chamber. A spring extends between and engages the cap and the second guide end to bias the valve disc to the closed position.

Classes IPC  ?

  • F16K 17/06 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort avec dispositions particulières pour régler la pression d'ouverture

60.

Actuating assembly for an internal valve


Numéro d'application 17812654
Numéro de brevet 11933412
Statut Délivré - en vigueur
Date de dépôt 2022-07-14
Date de la première publication 2023-01-19
Date d'octroi 2024-03-19
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Combs, Elijah Marshall

Abrégé

A valve actuating assembly is provided that comprises a cam holder positioned within a valve body of an internal valve, a cam operably coupled to the cam holder and configured to engage a valve stem of the internal valve for moving the internal valve between a first position and a second position, and an actuating shaft extending through at least a portion of the valve body, rotation of the actuating shaft causing rotation of the cam holder and the cam, wherein the actuating shaft is removably coupled to the cam holder such that the actuating shaft can be decoupled from the cam holder and removed from the valve body, the cam holder and the cam being configured to remain positioned within the valve body when the actuating shaft is decoupled from the cam holder and removed from the valve body.

Classes IPC  ?

  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 15/18 - Soupapes, clapets ou valves de retenue à mécanisme de commandeSoupape de retenue et soupape à mécanisme de commande combinées
  • F16K 31/524 - Moyens mécaniques d'actionnement à manivelle, excentrique ou came à came
  • F16K 3/18 - Robinets-vannes ou tiroirs, c.-à-d. dispositifs obturateurs dont l'élément de fermeture glisse le long d'un siège pour l'ouverture ou la fermeture à faces d'obturation planesGarnitures d'étanchéité à cet effet avec dispositions particulières pour tenir écartées les faces d'obturation ou pour les presser l'une contre l'autre du fait du mouvement des éléments de fermeture

61.

ACTUATING ASSEMBLY FOR AN INTERNAL VALVE


Numéro d'application US2022073738
Numéro de publication 2023/288276
Statut Délivré - en vigueur
Date de dépôt 2022-07-14
Date de publication 2023-01-19
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s) Combs, Elijah, Marshall

Abrégé

A valve actuating assembly is provided that comprises a cam holder positioned within a valve body of an internal valve, a cam operably coupled to the cam holder and configured to engage a valve stem of the internal valve for moving the internal valve between a first position and a second position, and an actuating shaft extending through at least a portion of the valve body, rotation of the actuating shaft causing rotation of the cam holder and the cam, wherein the actuating shaft is removably coupled to the cam holder such that the actuating shaft can be decoupled from the cam holder and removed from the valve body, the cam holder and the cam being configured to remain positioned within the valve body when the actuating shaft is decoupled from the cam holder and removed from the valve body.

Classes IPC  ?

  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 31/524 - Moyens mécaniques d'actionnement à manivelle, excentrique ou came à came

62.

Rapid-connect coupler and receptacle having anti-rotation feature


Numéro d'application 17823633
Numéro de brevet 11988315
Statut Délivré - en vigueur
Date de dépôt 2022-08-31
Date de la première publication 2022-12-29
Date d'octroi 2024-05-21
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Tickle, Tracy N.
  • Howard, Jeffrey S.
  • Thomas, Chad

Abrégé

A coupler for connecting a tank to a receptacle includes a housing, a probe configured to translate longitudinally within the housing, and a handle assembly configured to cause the probe to translate within the housing. The handle assembly is movable between a decoupled position, a coupled position, and a venting position. The coupler includes a ball cage, a plurality of balls disposed in the ball cage, and a slidable sleeve coupled to the probe and configured to translate longitudinally with the probe. The slidable sleeve is configured to slide in a first longitudinal direction to cause the plurality of balls to translate radially to lock the coupler to the receptacle. The slidable sleeve includes a collar defining a plurality of channels that are positioned radially and extending axially along the collar and configured to receive bearings of the receptacle in the coupled position and the venting position to prevent rotation.

Classes IPC  ?

  • F16L 37/36 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets qui sont actionnés de façon que le courant à travers l'accouplement ne s'établisse qu'après l'accouplement sans désengagement possible
  • F16L 37/12 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage utilisant des crochets, cliquet, ou autres organes de blocage mobiles ou que l'on peut insérer
  • F16L 37/23 - Accouplements du type à action rapide dans lesquels l'assemblage est maintenu par des billes, rouleaux ou ressorts hélicoïdaux sous pression radiale entre parties au moyen de billes
  • F16L 55/07 - Aménagement ou montage de dispositifs, p. ex. soupapes, pour ventiler ou aérer ou purger
  • B67D 7/36 - Aménagements des vannes de commande du débit ou de la pression

63.

Low-emission nozzle and receptacle coupling for cryogenic fluid


Numéro d'application 17804484
Numéro de brevet 11821557
Statut Délivré - en vigueur
Date de dépôt 2022-05-27
Date de la première publication 2022-12-01
Date d'octroi 2023-11-21
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Grenaway, John

Abrégé

Methods and apparatus are disclosed for a low-emission nozzle and receptacle coupling for cryogenic fluid. An example nozzle includes a body defining a chamber through which cryogenic fluid is to flow. The body includes an outer shell that includes an outer shell surface. The nozzle includes a locking assembly configured to securely couple the nozzle to a receptacle. The locking assembly includes an inner sleeve fixedly coupled to the outer shell surface and an outer sleeve extending over and rotatably coupled to the inner sleeve. One or more locking teeth are fixedly coupled to the outer sleeve and configured to be slidably received by respective one or more coupling slots of the receptacle. The one or more locking teeth are configured to rotatably slide within the respective one or more coupling slots to couple the nozzle to the receptacle as the outer sleeve rotates relative to the inner sleeve.

Classes IPC  ?

  • F16L 37/244 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette dans lesquels l'accouplement et le tuyau sont coaxiaux
  • F17C 13/00 - Détails des récipients ou bien du remplissage ou du vidage des récipients
  • F16L 37/35 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets dont l'un au moins est ouvert automatiquement au moment de l'accouplement au moins un des clapets possédant un canal axial communiquant avec des ouvertures latérales

64.

LOW-EMISSION NOZZLE AND RECEPTACLE COUPLING FOR CRYOGENIC FLUID


Numéro d'application US2022072628
Numéro de publication 2022/251878
Statut Délivré - en vigueur
Date de dépôt 2022-05-27
Date de publication 2022-12-01
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Jordan, Kevin
  • Grenaway, John

Abrégé

Methods and apparatus are disclosed for a low-emission nozzle and receptacle coupling for cryogenic fluid. An example nozzle (1200) includes a body (1240) defining a chamber through which cryogenic fluid is to flow. The body includes an outer shell (1245) that includes an outer shell surface. The nozzle includes a locking assembly (1210) configured to securely couple the nozzle to a receptacle. The locking assembly includes an inner sleeve (1230) fixedly coupled to the outer shell surface and comprising guide extensions (1233) and an outer sleeve (1214) extending over and rotatably coupled to the inner sleeve. One or more locking teeth (1215) are fixedly coupled to the outer sleeve and configured to be slidably received by respective one or more coupling slots of the receptacle. The one or more locking teeth are configured to rotatably slide within the respective one or more coupling slots to couple the nozzle to the receptacle as the outer sleeve rotates relative to the inner sleeve.

Classes IPC  ?

  • F16L 37/244 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette dans lesquels l'accouplement et le tuyau sont coaxiaux
  • F16L 37/248 - Accouplements du type à baïonnette
  • F16L 37/252 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette dans lesquels l'accouplement et le tuyau sont coaxiaux la partie mâle étant munie sur son pourtour de tenons qui pénètrent dans des encoches correspondantes aménagées dans la partie femelle
  • B05B 1/00 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage

65.

CRYOGENIC FLUID SHUT-OFF VALVE


Numéro d'application CN2021082371
Numéro de publication 2022/198439
Statut Délivré - en vigueur
Date de dépôt 2021-03-23
Date de publication 2022-09-29
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

Disclosed is a shut-off valve (100) for use with cryogenic fluids having a body (110) including a valve inlet (112a), a valve outlet (112d), and one or more internal surfaces (111) that define at least one void (112) in fluid communication with the valve inlet and the valve outlet. The shut-off valve further includes a valve seat (116) defined by the one or more internal surfaces, a housing connected to the body and a valve spindle disposed within the housing and including a seat disc (126a) that engages with the valve seat. A buffer (124) composed of cryogenic resistant material circumferentially surrounds the valve spindle and is slidingly engaged with an internal surface of the housing. The shut-off valve further includes a valve actuating member (140) connected to the valve spindle to cause an axial movement of the valve spindle, valve seat, and buffer to control fluid flow from the valve inlet to the valve outlet.

Classes IPC  ?

  • F16K 1/00 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation
  • F16K 1/32 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation Détails
  • F16K 1/36 - Corps de soupapes
  • F16K 31/60 - Poignées
  • F16K 41/00 - Joints d'étanchéité pour tiges

66.

CRYOGENIC FLUID SHUT-OFF VALVE


Numéro d'application CN2021131141
Numéro de publication 2022/199057
Statut Délivré - en vigueur
Date de dépôt 2021-11-17
Date de publication 2022-09-29
Propriétaire
  • ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
  • SHANGHAI REGO FLOW TECHNOLOGY, CO., LTD. (Chine)
Inventeur(s) Cao, Guangbin

Abrégé

Shut-off valves for cryogenic fluids are disclosed herein. An example valve includes a valve body defining a flow path and a valve seat, a bonnet coupled to the valve body and defining a bonnet chamber, a plug configured to slide between a closed position, and a stem coupled to the plug. The stem is configured to slide to cause the plug to slide. The valve includes a spindle that includes external threads. The spindle is configured to move along a longitudinal axis of the bonnet as the spindle is rotated about the longitudinal axis via the external threads to cause the stem to slide linearly along the longitudinal axis. The valve includes a pivot ball positioned between and operatively coupled to the stem and the spindle. The pivot ball is configured to translate linear and rotational movement of the spindle into linear movement of the stem and the plug.

Classes IPC  ?

  • F16K 1/50 - Dispositifs empêchant la rotation des corps de soupapes
  • F16K 1/48 - Fixation des corps de soupapes aux tiges des soupapes
  • F16K 1/00 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation
  • F16K 41/10 - Joints d'étanchéité pour tiges avec un diaphragme, p. ex. en forme de soufflet ou de tube
  • F16K 31/60 - Poignées
  • F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme

67.

Low-profile paired relief valve


Numéro d'application 17662490
Numéro de brevet 12473987
Statut Délivré - en vigueur
Date de dépôt 2022-05-09
Date de la première publication 2022-08-18
Date d'octroi 2025-11-18
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Hamm, Mark Kendrick
  • Herman, Christopher Taylor

Abrégé

A pressure relief valve assembly is disclosed. The pressure relief valve assembly comprises an inlet manifold, a first pressure relief valve, a second pressure relief valve, and an outlet manifold. The first pressure relief valve is connected to and in fluid communication with the inlet manifold. The second pressure relief valve is connected to and in fluid communication with the inlet manifold and parallel to the first pressure relief valve. The outlet manifold is connected to and in fluid communication with the first pressure relief valve and the second pressure relief valve.

Classes IPC  ?

  • F16K 17/10 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort avec soupape auxiliaire agissant par un fluide sur la soupape principale
  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 27/00 - Structures des logementsMatériaux utilisés à cet effet

68.

Low pressure shut off valve and system


Numéro d'application 17594731
Numéro de brevet 11655908
Statut Délivré - en vigueur
Date de dépôt 2020-04-30
Date de la première publication 2022-07-07
Date d'octroi 2023-05-23
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Hamm, Mark Kendrick
  • Herman, Christopher Taylor
  • Combs, Elijah M.

Abrégé

A CO2 low-pressure shut-off system is described. The low-pressure shut-off system may include a low-pressure shut-off valve including a first valve inlet, a second valve inlet and at least one valve outlet, a solenoid valve including a valve inlet, a first valve outlet, and a second valve outlet. The solenoid may be configured to direct a flow of a pressurized gas from the valve inlet into at least one of the first valve outlet and the second valve outlet. The CO2 low-pressure shut-off system further includes a gas monitor electrically coupled to the solenoid valve. The gas monitor may be configured to transmit one of a first signal and a second signal to the solenoid valve to control the flow of the pressurized gas through the solenoid valve.

Classes IPC  ?

  • F16K 17/04 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort
  • F16K 31/40 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation avec un organe actionné électriquement dans la décharge du moteur

69.

Combination regulator valve


Numéro d'application 17666330
Numéro de brevet 12066120
Statut Délivré - en vigueur
Date de dépôt 2022-02-07
Date de la première publication 2022-07-07
Date d'octroi 2024-08-20
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Cao, Guangbin
  • Morefield, Patrick N.

Abrégé

A combination regulator valve for conveying fluid is disclosed. The valve comprises a bonnet, a body, a flexible diaphragm, a first spring, and a spindle unit. The spindle unit comprises a pin, a first seat disc, and a seat screw. The bonnet is secured to the body. The flexible diaphragm is compressed between the bonnet and the body. The first spring is disposed in the bonnet. The spindle unit is disposed in the body. The first seat disc is disposed between the pin and the diaphragm. The first seat disc and the pin define a first void. The first spring biases the diaphragm toward the first seat disc. The seat screw is engaged with the body and is slidably engaged with the pin. The seat screw and the pin define a fluid passage in fluid communication with the first void.

Classes IPC  ?

  • F16K 17/30 - Soupapes ou clapets limiteurs de débit fonctionnant par différence de pression entre deux points de l'écoulement et agissant directement sur l'élément d'obturation dans un sens uniquement sous l'action d'un ressort
  • F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
  • G05D 16/06 - Commande de la pression d'un fluide sans source d'énergie auxiliaire l'élément sensible étant un organe élastique cédant à la pression, p. ex. un diaphragme, un soufflet, une capsule

70.

CLEANING NOZZLE FOR CRYOGENIC FLUID FUELING RECEPTACLE


Numéro d'application US2021072470
Numéro de publication 2022/109569
Statut Délivré - en vigueur
Date de dépôt 2021-11-17
Date de publication 2022-05-27
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

A cleaning nozzle (1000) for cleaning a fueling receptacle (4) capable of receiving a separate fueling nozzle (700) for transferring cryogenic fluid from a fueling station is disclosed. An example cleaning nozzle includes a body (1010) that defines a cavity (1070). The example cleaning nozzle includes a nozzle head (1020) coupled to and extending from a distal end of the body. The nozzle head defines a plurality of spray holes (1025, 1026) to spray pressurized air onto the fueling receptacle. The example cleaning nozzle includes a blower (1090) that defines a blower inlet (1092), a blower outlet (1093), and a blower flow path (1091) extending between the blower inlet and the blower outlet. The blower comprises a valve (1097) and a lever (1095) operatively coupled to the valve. The example cleaning nozzle includes an insert (1060) defining an insert flow path (1063) that is fluidly coupled to the blower outlet. The example cleaning nozzle includes a connector (1080) fluidly connecting the insert and the nozzle head.

Classes IPC  ?

  • B08B 5/02 - Nettoyage par la force de jets, p. ex. le soufflage de cavités
  • F17C 13/10 - Dispositions contre le gel
  • B05B 1/00 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage

71.

CLEANING RECEPTACLE FOR CRYOGENIC FLUID FUELING NOZZLE


Numéro d'application US2021072463
Numéro de publication 2022/109564
Statut Délivré - en vigueur
Date de dépôt 2021-11-17
Date de publication 2022-05-27
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

A cleaning receptacle (800) for cleaning a fueling nozzle (700) used to transfer cryogenic fluid is disclosed. An example cleaning receptacle includes an outer body (810). The outer body includes an outer wall (816) that extends circumferentially around a center axis of the cleaning receptacle. The outer wall has a first inner surface (820). The outer body includes a plurality of locating members (822) extending inwardly from the first inner surface toward the center axis. The example cleaning receptacle includes a flow body (830). The flow body includes a second inner surface (832) that defines a cavity (836) and a lip (838) at an outer end of the flow body. The example cleaning receptacle includes a spray body (860) disposed at an inner end of the flow body. The spray body includes a spray head (862) that defines a plurality of spray holes ()866 configured to spray air through the cavity of the flow body and onto surfaces of the fueling nozzle.

Classes IPC  ?

  • B08B 5/02 - Nettoyage par la force de jets, p. ex. le soufflage de cavités
  • F17C 13/10 - Dispositions contre le gel

72.

Coupling nozzle for cryogenic fluid


Numéro d'application 17582645
Numéro de brevet 11703169
Statut Délivré - en vigueur
Date de dépôt 2022-01-24
Date de la première publication 2022-05-12
Date d'octroi 2023-07-18
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

Methods and apparatus are disclosed for a coupling nozzle for cryogenic fluid. An example nozzle includes a flow body defining a conduit. The flow body is configured to permit cryogenic fluid to flow through the conduit. The nozzle includes a mounting ring through which the flow body slidably extends and a bushing fixedly positioned adjacent the mounting ring. The bushing slidably receives the flow body in a keyed manner to prevent rotation of the flow body. The nozzle includes a flow control assembly at least partially disposed in the conduit of the flow body. The flow control assembly is configured to permit the cryogenic fluid to flow through the flow body in an open position and prevent the cryogenic fluid from flowing through the flow body in a closed position.

Classes IPC  ?

  • F16L 37/096 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen de crochets articulés autour d'un axe
  • F16L 37/42 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un clapet dont l'ouverture se fait automatiquement au moment de l'accouplement le clapet comportant un canal axial communiquant avec des trous radiaux
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés
  • F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts
  • F16L 37/47 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un robinet à boisseau ou à obturateur

73.

Low emission receptacles


Numéro d'application 17453074
Numéro de brevet 11796135
Statut Délivré - en vigueur
Date de dépôt 2021-11-01
Date de la première publication 2022-04-21
Date d'octroi 2023-10-24
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Thomas, Chad
  • Konishi, Howard M.
  • Howard, Jeffrey S.

Abrégé

A receptacle includes a main body, a stem, a poppet connected to the stem and defining an inner check void, a spring configured to bias the poppet to a closed poppet position, and a check assembly at least partially disposed in the inner check void. The check assembly includes a check and a check spring. The check is configured to move relative to the main body. The check spring is configured to bias the check toward a closed check position. The check has a first surface area and the poppet has a second surface area that is larger than the first surface area of the poppet such that a fluid force causes the check to move to an open check position before causing the poppet to move to an open poppet position.

Classes IPC  ?

  • F17C 13/04 - Disposition ou montage des soupapes
  • F17C 6/00 - Procédés ou appareils pour remplir des récipients non sous pression de gaz liquéfiés ou solidifiés
  • F17C 9/00 - Procédés ou appareils pour vider les gaz liquéfiés ou solidifiés contenus dans des récipients non sous pression
  • F16K 15/02 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés
  • F17C 5/06 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz comprimés

74.

Systems and methods to facilitate permanently marking a housing component for a fluid control system product


Numéro d'application 17011443
Numéro de brevet 11181880
Statut Délivré - en vigueur
Date de dépôt 2020-09-03
Date de la première publication 2021-11-23
Date d'octroi 2021-11-23
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • York, Tony
  • Cooke, John

Abrégé

Systems and methods to facilitate permanently marking a housing component for a fluid control system product is disclosed. The system comprises a first processor, a second processor, and a printer. The first processor is configured to receive fixed information. The second processor is configured to receive the fixed information from the first processor, generate variable information, control a laser engraver to engrave the fixed and variable information into a workpiece, generate an information packet including the fixed information and the variable information, and transmit the information packet to the first processor.

Classes IPC  ?

  • G06K 15/12 - Dispositions pour produire une présentation visuelle permanente des données de sortie utilisant des imprimantes par impression photographique
  • G05B 19/05 - Automates à logique programmables, p. ex. simulant les interconnexions logiques de signaux d'après des diagrammes en échelle ou des organigrammes

75.

Leak resistant and serviceable receptacle


Numéro d'application 17131214
Numéro de brevet 11353118
Statut Délivré - en vigueur
Date de dépôt 2020-12-22
Date de la première publication 2021-04-15
Date d'octroi 2022-06-07
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Thomas, Chad
  • Glavin, Michael T.
  • Howard, Jeffrey S.
  • Cao, Guangbin

Abrégé

A receptacle for conveying fluid is disclosed. An example receptacle includes a main body defining an inlet and an outlet, a spring retainer disposed in the main body, a valve seat disposed in the main body, and a poppet configured to slide between a closed position and an open position. The poppet is slidably engaged with the spring retainer between the closed position and the open position and is engaged with the valve seat in the closed position. The example receptacle also includes a spring engaged with the spring retainer and the poppet to bias the poppet to engage the valve seat in the closed position. The spring retainer, the valve seat, the poppet, and the spring are removable from the main body via the inlet without disassembling the main body.

Classes IPC  ?

  • F16K 1/46 - Fixation des segments d'étanchéité
  • F16L 37/40 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un clapet dont l'ouverture se fait automatiquement au moment de l'accouplement
  • F16K 15/06 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés par tige-guide
  • F16K 1/42 - Sièges de soupapes
  • F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte

76.

Low emission nozzles and receptacles


Numéro d'application 17109940
Numéro de brevet 11162641
Statut Délivré - en vigueur
Date de dépôt 2020-12-02
Date de la première publication 2021-03-25
Date d'octroi 2021-11-02
Propriétaire Engineered Controls International (USA)
Inventeur(s)
  • Thomas, Chad
  • Konishi, Howard M.
  • Howard, Jeffrey S.

Abrégé

A nozzle for dispensing fluid includes a probe slidably disposed in a main body. The probe has a probe body defining a check sealing surface and a check void. A check assembly is at least partially disposed in the check void, and includes a check configured to move relative to the main body and the probe body. A spring is configured to bias the check to sealingly engage the check against the check sealing surface of the probe body.

Classes IPC  ?

  • F17C 13/04 - Disposition ou montage des soupapes
  • F17C 6/00 - Procédés ou appareils pour remplir des récipients non sous pression de gaz liquéfiés ou solidifiés
  • F17C 9/00 - Procédés ou appareils pour vider les gaz liquéfiés ou solidifiés contenus dans des récipients non sous pression
  • F16K 15/02 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés
  • F17C 5/06 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz comprimés

77.

Coupling nozzle for cryogenic fluid


Numéro d'application 17016008
Numéro de brevet 11262012
Statut Délivré - en vigueur
Date de dépôt 2020-09-09
Date de la première publication 2021-03-18
Date d'octroi 2022-03-01
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

Methods and apparatus are disclosed for a coupling nozzle for cryogenic fluid. An example nozzle comprises a flow body defining a conduit, an inlet, and an outlet. A pneumatic cylinder is configured to slide between an extended position and a contracted position. The pneumatic cylinder is coupled to and configured to actuate the flow body. A locking mechanism is configured to secure the coupling nozzle to a receptacle. A flow control assembly comprises a valve seat fixed to the flow body adjacent the inlet and a plug configured to slide. When the locking mechanism is locked and the pneumatic cylinder actuates to the extended position, the valve seat is to disengage from the plug to open the flow control assembly. When the locking mechanism is locked and the pneumatic cylinder actuates to the contracted position, the valve seat is to engage the plug to close the flow control assembly.

Classes IPC  ?

  • F16L 37/096 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen de crochets articulés autour d'un axe
  • F16L 37/42 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans une seule des deux extrémités de tuyau avec un clapet dont l'ouverture se fait automatiquement au moment de l'accouplement le clapet comportant un canal axial communiquant avec des trous radiaux
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés

78.

COUPLING NOZZLE FOR CRYOGENIC FLUID


Numéro d'application US2020049872
Numéro de publication 2021/050500
Statut Délivré - en vigueur
Date de dépôt 2020-09-09
Date de publication 2021-03-18
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s) Jordan, Kevin

Abrégé

Methods and apparatus are disclosed for a coupling nozzle for cryogenic fluid. An example nozzle comprises a flow body defining a conduit, an inlet, and an outlet. A pneumatic cylinder is configured to slide between an extended position and a contracted position. The pneumatic cylinder is coupled to and configured to actuate the flow body. A locking mechanism is configured to secure the coupling nozzle to a receptacle. A flow control assembly comprises a valve seat fixed to the flow body adjacent the inlet and a plug configured to slide. When the locking mechanism is locked and the pneumatic cylinder actuates to the extended position, the valve seat is to disengage from the plug to open the flow control assembly. When the locking mechanism is locked and the pneumatic cylinder actuates to the contracted position, the valve seat is to engage the plug to close the flow control assembly.

Classes IPC  ?

  • F16L 37/127 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage utilisant des crochets, cliquet, ou autres organes de blocage mobiles ou que l'on peut insérer utilisant des crochets articulés autour d'un axe
  • F16L 37/30 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau
  • F16L 37/36 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets qui sont actionnés de façon que le courant à travers l'accouplement ne s'établisse qu'après l'accouplement sans désengagement possible

79.

PRESSURE-RELIEF VALVE


Numéro d'application CN2019103340
Numéro de publication 2021/035625
Statut Délivré - en vigueur
Date de dépôt 2019-08-29
Date de publication 2021-03-04
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

A valve for conveying fluid has a closed position and an open position and comprises a body (20), a valve seat (70) disposed in the body, a holder (50) disposed in the body, and a valve seat disc (60). The valve seat comprises one or more inner surfaces (73) and an outer surface (71), and the one or more inner surfaces define an inner void (75). The valve seat disc is connected to and movable with the holder between a first position in which the valve seat disc sealingly engages the outer surface of the valve seat and a second position in which the valve seat disc is disengaged from the outer surface of the valve seat. The valve is in the closed position when the valve seat disc is in the first position and the valve is in the open position when the valve seat disc is in the second position.

Classes IPC  ?

  • F16K 17/06 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage ouvrant sur excès de pression d'un côtéSoupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage fermant sur insuffisance de pression d'un côté actionnés par ressort avec dispositions particulières pour régler la pression d'ouverture

80.

REGO MASTER DISTRIBUTOR NETWORK


Numéro d'application 018412464
Statut Enregistrée
Date de dépôt 2021-03-02
Date d'enregistrement 2021-07-01
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 35 - Publicité; Affaires commerciales

Produits et services

Distributorship services in the field of valves and regulators for use with liquid propane gas, anhydrous ammonia, liquid natural gas, cryogenic fuels and cryogenic fluids.

81.

PRESTO-TAP


Numéro d'application 208521800
Statut Enregistrée
Date de dépôt 2021-02-17
Date d'enregistrement 2025-10-24
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

(1) Valves, namely, valves for propane systems, being metal control valves for controlling the flow of gases and liquids; (2) Pressure and warning gauges for propane tanks which are designed to be applied to existing systems; Gas manifold regulators, manually operated pressure regulators and parts therefor for gases, liquified gases, and cryogenic liquids, namely, pressure gauges, high pressure regulators in the nature of control valves used for regulating the flow of gases and liquids, low pressure regulators in the nature of control valves used for regulating the flow of gases and liquids, multi-stage regulators in the nature of control valves used for regulating the flow of gases and liquids, single stage regulators in the nature of control valves used for regulating the flow of gases and liquids;

82.

PRESTO-TAP


Numéro de série 90524799
Statut Enregistrée
Date de dépôt 2021-02-11
Date d'enregistrement 2022-01-04
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC ()
Classes de Nice  ? 06 - Métaux communs et minerais; objets en métal

Produits et services

valves, namely, manually operated metal valves for propane systems

83.

PRESTO-TAP


Numéro de série 90524805
Statut Enregistrée
Date de dépôt 2021-02-11
Date d'enregistrement 2024-07-02
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC ()
Classes de Nice  ?
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement

Produits et services

manually operated pressure regulators and structural parts therefore for monitoring and controlling the flow of cryogenic liquids, namely, pressure gauges, high pressure regulators, low pressure regulators, multi-stage pressure regulators, and single-stage pressure regulators gas manifold regulators; manually operated pressure regulators and structural parts therefore for gas and liquefied gas installations, namely, high pressure regulators, low pressure regulators, multi-stage gas regulators, and single-stage gas regulators

84.

REGO


Numéro d'application 207859900
Statut Enregistrée
Date de dépôt 2021-01-20
Date d'enregistrement 2025-09-08
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 07 - Machines et machines-outils

Produits et services

(1) Fueling nozzles for liquefied petroleum gases

85.

REGOMAC


Numéro d'application 018363648
Statut Enregistrée
Date de dépôt 2020-12-24
Date d'enregistrement 2021-06-10
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 07 - Machines et machines-outils

Produits et services

Fueling nozzles; semi-automatic fueling nozzles; and automatic fueling nozzles.

86.

SP


Numéro d'application 018363465
Statut Enregistrée
Date de dépôt 2020-12-23
Date d'enregistrement 2021-05-20
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 06 - Métaux communs et minerais; objets en métal

Produits et services

Compressed gas fittings made of metal, namely, metal adapters, metal bushings, metal couplers, and metal caps; metal pipe fittings; manually operated valves and parts therefor made of metal; and related hose and pipe connecting devices and accessories therefor made of metal for the alternative fuel, welding, cryogenic, medical and specialty gas markets.

87.

REGO


Numéro d'application 018339229
Statut Enregistrée
Date de dépôt 2020-11-17
Date d'enregistrement 2021-05-19
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 35 - Publicité; Affaires commerciales

Produits et services

Manifolds, pipes, screw connections, bushings, connectors and clamps, manually operated valves and parts therefor made of metal for liquids, gasses and air; fueling nozzles; fueling nozzles for liquefied petroleum gases. Valves, regulators, apparatus for filling cylinders with gasses or air. Gauging devices. Manually operated pressure regulators and parts thereof for gas and cryogenic liquids. Distributorship services for LP gas and anhydrous ammonia valves and regulators.

88.

LOW-PRESSURE SHUT-OFF VALVE AND SYSTEM


Numéro d'application US2020030781
Numéro de publication 2020/223513
Statut Délivré - en vigueur
Date de dépôt 2020-04-30
Date de publication 2020-11-05
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Hamm, Mark, Kendrick
  • Herman, Christopher, Taylor
  • Combs, Elijah, M.

Abrégé

A CO2 low-pressure shut-off system is described. The low-pressure shut-off system may include a low-pressure shut-off valve including a first valve inlet, a second valve inlet and at least one valve outlet, a solenoid valve including a valve inlet, a first valve outlet, and a second valve outlet. The solenoid may be configured to direct a flow of a pressurized gas from the valve inlet into at least one of the first valve outlet and the second valve outlet. The CO2 low-pressure shut-off system further includes a gas monitor electrically coupled to the solenoid valve. The gas monitor may be configured to transmit one of a first signal and a second signal to the solenoid valve to control the flow of the pressurized gas through the solenoid valve.

Classes IPC  ?

  • F16K 17/00 - Soupapes ou clapets de sûretéSoupapes ou clapets d'équilibrage
  • F16K 1/00 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation
  • F16K 7/00 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture
  • F16K 15/00 - Soupapes, clapets ou valves de retenue
  • F16K 31/00 - Moyens de fonctionnementDispositifs de retour à la position de repos
  • F15B 20/00 - Dispositions propres à la sécurité pour systèmes de manœuvre utilisant les fluidesUtilisation des dispositifs de sécurité dans les systèmes de manœuvre utilisant des fluidesMesures d'urgence pour les systèmes de manœuvre utilisant des fluides

89.

Rapid-connect coupler and receptacle having anti-rotation feature


Numéro d'application 16838251
Numéro de brevet 11460136
Statut Délivré - en vigueur
Date de dépôt 2020-04-02
Date de la première publication 2020-10-08
Date d'octroi 2022-10-04
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Tickle, Tracy N.
  • Howard, Jeffrey S.
  • Thomas, Chad

Abrégé

A rapid connect coupler for connecting a fluid holding tank to a receptacle in a non-rotatable manner can include a housing, a probe configured to translate in a longitudinal direction within the housing, and a handle assembly configured to cause the probe to translate within the housing. The handle assembly can be movable between a plurality of positions corresponding to decoupled, coupled and venting positions. The coupler can also include a slidable sleeve coupled to an outer surface of the probe and configured to translate with the probe in the longitudinal direction, the sleeve including a collar configured to engage the receptacle in the coupled and uncoupled positions to prevent rotation of the coupler with respect to the receptacle when the two components are engaged to one another.

Classes IPC  ?

  • F16L 37/23 - Accouplements du type à action rapide dans lesquels l'assemblage est maintenu par des billes, rouleaux ou ressorts hélicoïdaux sous pression radiale entre parties au moyen de billes
  • B67D 7/36 - Aménagements des vannes de commande du débit ou de la pression
  • F16L 55/07 - Aménagement ou montage de dispositifs, p. ex. soupapes, pour ventiler ou aérer ou purger

90.

RAPID-CONNECT COUPLER AND RECEPTACLE HAVING ANTI-ROTATION FEATURE


Numéro d'application US2020026388
Numéro de publication 2020/206123
Statut Délivré - en vigueur
Date de dépôt 2020-04-02
Date de publication 2020-10-08
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Inventeur(s)
  • Tickle, Tracy, N.
  • Howard, Jeffrey, S.
  • Thomas, Chad

Abrégé

A rapid connect coupler (700) for connecting a fluid holding tank to a receptacle in a non-rota table manner can include a housing (102), a probe configured to translate in a longitudinal direction within the housing, and a handle assembly (130A, 130B) configured to cause the probe to translate within the housing. The handle assembly can be movable between a plurality of positions corresponding to decoupled, coupled (B) and venting positions. The coupler can also include a slidable sleeve (705) coupled to an outer surface of the probe and configured to translate with the probe in the longitudinal direction, the sleeve including a collar (710) configured to engage the receptacle in the coupled and uncoupled positions to prevent rotation of the coupler with respect to the receptacle when the two components are engaged to one another.

Classes IPC  ?

  • F16L 37/12 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage utilisant des crochets, cliquet, ou autres organes de blocage mobiles ou que l'on peut insérer
  • F16L 37/36 - Accouplements du type à action rapide avec moyens pour couper l'écoulement du fluide avec un obturateur dans chaque extrémité de tuyau avec deux clapets qui sont actionnés de façon que le courant à travers l'accouplement ne s'établisse qu'après l'accouplement sans désengagement possible

91.

Systems and methods to facilitate permanently marking a housing component for a fluid control system product


Numéro d'application 15955138
Numéro de brevet 10768600
Statut Délivré - en vigueur
Date de dépôt 2018-04-17
Date de la première publication 2020-09-08
Date d'octroi 2020-09-08
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • York, Tony
  • Cooke, John

Abrégé

Systems and methods to facilitate permanently marking a housing component for a fluid control system product is disclosed. The system comprises a first processor, a second processor, and a printer. The first processor is configured to receive fixed information. The second processor is configured to receive the fixed information from the first processor, generate variable information, control a laser engraver to engrave the fixed and variable information into a workpiece, generate an information packet including the fixed information and the variable information, and transmit the information packet to the first processor. The printer includes a third processor configured to receive the information packet from the first processor and print the information packet onto a label.

Classes IPC  ?

  • G06K 15/12 - Dispositions pour produire une présentation visuelle permanente des données de sortie utilisant des imprimantes par impression photographique
  • G05B 19/05 - Automates à logique programmables, p. ex. simulant les interconnexions logiques de signaux d'après des diagrammes en échelle ou des organigrammes

92.

REGO


Numéro de série 90069124
Statut Enregistrée
Date de dépôt 2020-07-23
Date d'enregistrement 2021-05-04
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Non-automatic fueling nozzles for liquefied petroleum gases Automatic fueling nozzles for liquefied petroleum gases

93.

SP


Numéro de série 90032616
Statut Enregistrée
Date de dépôt 2020-07-02
Date d'enregistrement 2021-07-20
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC (USA)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement

Produits et services

Compressed gas fittings made of metal, namely, metal adapters, metal bushings, metal couplers, and metal caps; metal pipe fittings; manually operated valves and parts therefor made of metal; and related hose and pipe connecting devices and accessories, namely, metal hose and cable connectors, and crimping therefor made of metal for the alternative fuel, welding, cryogenic, medical and specialty gas markets Flowmeters; electronic manifold valves for controlling gas; manifold switchover devices, namely, electronic controllers for controlling gas valves Gas delivery systems, namely, gas manifolds and gas manifold assemblies, and accessories therefor, namely, gas regulators; gas manifold regulators

94.

Cryogenic cylinder control system, globe valve, and solenoid valve


Numéro d'application 16624239
Numéro de brevet 11592120
Statut Délivré - en vigueur
Date de dépôt 2018-06-13
Date de la première publication 2020-05-14
Date d'octroi 2023-02-28
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s) Cao, Guangbin

Abrégé

A valve assembly (6000) for use with a valve body (7000) having a valve seat (7112) is disclosed, the valve assembly (6000) comprising: a cartridge (6200) threadably engaged with and extending away from the valve body (7000); a poppet (6500) slidably engaged with the cartridge (6200); a plate (6600) engaged with the poppet (6500); a plunger (6400) slidably engaged with the cartridge (6200) and slidably extending through the plate (6600); and a retainer (6450) captured between the plate (6600) and a surface of the poppet (6500), wherein the retainer (6450) is threadably engaged with the plunger (6400). The valve assembly (6000) can regulate fluid flow.

Classes IPC  ?

  • F16K 31/50 - Moyens mécaniques d'actionnement à tige-guide filetée
  • F16K 1/04 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée et dont l'élément de fermeture fait corps avec la tige, p. ex. soupapes principales
  • F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
  • F16K 41/04 - Joints d'étanchéité pour tiges avec un presse-étoupe avec une bague au moins, en caoutchouc ou d'un matériau analogue, entre la tige et son logement

95.

Regulator bonnet


Numéro d'application 29644683
Numéro de brevet D0884125
Statut Délivré - en vigueur
Date de dépôt 2018-04-19
Date de la première publication 2020-05-12
Date d'octroi 2020-05-12
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Morefield, Patrick N.
  • Jordan, Kevin

96.

REGO MASTER DISTRIBUTOR NETWORK


Numéro de série 88891314
Statut Enregistrée
Date de dépôt 2020-04-28
Date d'enregistrement 2020-11-24
Propriétaire ENGINEERED CONTROLS INTERNATIONAL, LLC ()
Classes de Nice  ? 35 - Publicité; Affaires commerciales

Produits et services

Distributorship services in the field of liquid propane gas and anhydrous ammonia valves and regulators

97.

Miscellaneous Design


Numéro d'application 018172969
Statut Enregistrée
Date de dépôt 2019-12-30
Date d'enregistrement 2020-05-22
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 06 - Métaux communs et minerais; objets en métal

Produits et services

Manually operated valves and parts therefor made of metal for liquids, gases and air; regulating and reducing valves and other metallic valves; Non-automatic fuelling nozzles.

98.

SUPERIOR PRODUCTS


Numéro d'application 200268400
Statut En instance
Date de dépôt 2019-12-20
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ? 06 - Métaux communs et minerais; objets en métal

Produits et services

(1) Compressed gas fittings made of metal, namely, adapters, bushings, couplers, caps.

99.

MT


Numéro d'application 200268200
Statut Enregistrée
Date de dépôt 2019-12-20
Date d'enregistrement 2026-06-30
Propriétaire Engineered Controls International, LLC (USA)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

(1) Manually operated metal valves for compressed gas, liquids, and air sold empty, namely, needle valves, control valves, and parts therefor made of metal for liquids, gases and air; Non-automatic fueling nozzles of metal (2) Check valves (3) Regulating and reducing valves, namely, pressure relief valves; manually operated valves, namely, pressure relief valves

100.

Low emission nozzles and receptacles


Numéro d'application 16538534
Numéro de brevet 10883665
Statut Délivré - en vigueur
Date de dépôt 2019-08-12
Date de la première publication 2019-11-28
Date d'octroi 2021-01-05
Propriétaire Engineered Controls International, LLC (USA)
Inventeur(s)
  • Thomas, Chad
  • Konishi, Howard M.
  • Howard, Jeffrey S.

Abrégé

A method consistent with the present disclosure may include: (a) equalizing pressure between a nozzle inner void and a receptacle main inner void by pressing a nozzle check against a receptacle check to open the nozzle check and the receptacle check; (b) extending the nozzle into the receptacle such that a receptacle main body surrounds at least a portion of the nozzle probe; (c) flowing fluid from the nozzle inner void into the receptacle main inner void.

Classes IPC  ?

  • F17C 13/04 - Disposition ou montage des soupapes
  • F17C 6/00 - Procédés ou appareils pour remplir des récipients non sous pression de gaz liquéfiés ou solidifiés
  • F17C 9/00 - Procédés ou appareils pour vider les gaz liquéfiés ou solidifiés contenus dans des récipients non sous pression
  • F16K 15/02 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés
  • F17C 5/02 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz liquéfiés
  • F17C 5/06 - Procédés ou appareils pour remplir des récipients sous pression de gaz liquéfiés, solidifiés ou comprimés pour le remplissage avec des gaz comprimés
  1     2        Prochaine page
