Abrégé

A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base forming a bottom portion of the housing and a case cover forming a top portion of the housing, the heatsink base being configured to channel heat away from the lighting system, the heatsink base including a base plate; a base post configured to couple the base plate and the case cover; and a base sidewall extending from the base plate and configured to mate with cover sidewalls of the case cover.

Classes IPC  ?

• F21V 29/507 - Dispositions de refroidissement caractérisées par l’adaptation au refroidissement de composants spécifiques de moyens de protection des dispositifs d’éclairage contre les détériorations, p. ex. boîtiers
• F21V 29/74 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames
• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21K 9/238 - Agencement ou montage d’éléments de circuit intégrés dans la source lumineuse
• F21V 5/04 - Réfracteurs pour sources lumineuses de forme lenticulaire
• F21K 9/69 - Détails des réfracteurs faisant partie de la source lumineuse
• F21V 7/00 - Réflecteurs pour sources lumineuses
• F21K 9/68 - Détails des réflecteurs faisant partie de la source lumineuse
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A lighting system including a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal based on the rectified signal; a light source configured to emit light based on the drive signal; and a housing configured to encapsulate the power supply and the light driver and the light source, the housing including a heatsink base configured to channel heat away from the lighting system, the heatsink base including a base plate, and a pedestal structure protruding from the base plate toward an interior of the housing.

Classes IPC  ?

• F21V 29/74 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames
• F21V 7/00 - Réflecteurs pour sources lumineuses
• F21V 5/04 - Réfracteurs pour sources lumineuses de forme lenticulaire
• F21K 9/68 - Détails des réflecteurs faisant partie de la source lumineuse
• F21K 9/69 - Détails des réfracteurs faisant partie de la source lumineuse
• F21K 9/237 - Détails des enceintes ou des boîtiers, c.-à-d. des parties entre l’élément générateur de lumière et le socleAgencement des composants à l’intérieur des enceintes ou des boitiers
• H05B 45/40 - Détails des circuits de charge à LED
• F21K 9/66 - Détails des globes ou des couvercles faisant partie de la source lumineuse
• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage

Abrégé

A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base forming a bottom portion of the housing and a case cover forming a top portion of the housing, the heatsink base being configured to channel heat away from the lighting system, the heatsink base including a base plate; and a pedestal structure protruding from the base plate toward the case cover.

Classes IPC  ?

• F21V 29/74 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames
• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21V 23/06 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des dispositifs de couplage
• F21K 9/238 - Agencement ou montage d’éléments de circuit intégrés dans la source lumineuse
• H05B 45/20 - Commande de la couleur de la lumière
• H05B 47/175 - Commande de la source lumineuse par télécommande
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A method of driving a light source by a light driver includes determining a dimming value based on an input from a phase-cut dimmer at the input of the light driver, determining an offset for a dimmer transfer function of the light driver based on the dimming value and a minimum set point of the dimmer transfer function, applying the offset to the dimmer transfer function of the light driver to generate an adjusted dimmer transfer function, and determining a target light output of the light source based on the dimming value and the adjusted dimmer transfer function.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/31 - Circuits de commande de phase
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/59 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection pour réduire ou supprimer les effets de scintillement ou de lueur

Abrégé

A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base forming a bottom portion of the housing and a case cover forming a top portion of the housing, the heatsink base being configured to channel heat away from the lighting system, the heatsink base including a base plate; and a pedestal structure protruding from the base plate toward the case cover.

Classes IPC  ?

• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21V 23/06 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des dispositifs de couplage
• F21V 29/70 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/24 - Commande de la couleur de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 47/165 - Commande de la source lumineuse en suivant une séquence programmée pré-assignéeCommande logique [LC]

Abrégé

A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base forming a bottom portion of the housing and a case cover forming a top portion of the housing, the heatsink base being configured to channel heat away from the lighting system, the heatsink base including a base plate; a base post configured to couple the base plate and the case cover; and a base sidewall extending from the base plate and configured to mate with cover sidewalls of the case cover. A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base forming a bottom portion of the housing and a case cover forming a top portion of the housing, the heatsink base being configured to channel heat away from the lighting system, the heatsink base including a base plate; a base post configured to couple the base plate and the case cover; and a base sidewall extending from the base plate and configured to mate with cover sidewalls of the case cover. AXM/axm

Classes IPC  ?

• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21V 23/06 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des dispositifs de couplage
• F21V 29/70 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 45/24 - Commande de la couleur de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 45/375 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de dévoltage

Abrégé

A light driver includes a phase-cut detector configured to determine whether phase-cut dimming is present at an input of the light driver and to generate a phase-cut detection signal in response to presence of the phase-cut dimming; and a channel controller coupled to the phase-cut detector and configured to perform receiving a current correlated color temperature (CCT) value for adjusting a CCT of an output light of a light source coupled to the light driver; and in response to receiving the phase-cut detected signal from the phase-cut detector, disregarding the CCT value by maintaining a fixed CCT at the output light and adjusting an intensity of the output light based on a level of phase-cutting at the input of the light driver.

Classes IPC  ?

• H05B 45/20 - Commande de la couleur de la lumière
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/31 - Circuits de commande de phase
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]

Abrégé

A lighting system including a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal based on the rectified signal; a light source configured to emit light based on the drive signal; and a housing configured to encapsulate the power supply and the light driver and the light source, the housing including a heatsink base configured to channel heat away from the lighting system, the heatsink base including a base plate, and a pedestal structure protruding from the base plate toward an interior of the housing.

Classes IPC  ?

• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21V 7/00 - Réflecteurs pour sources lumineuses
• F21V 17/06 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection sur le support de la source lumineuse ou par son intermédiaire
• F21V 29/70 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques

Abrégé

A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base configured to be attached to a heatsink mount.

Classes IPC  ?

• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21V 7/04 - Structure de l'optique
• F21V 15/01 - Boîtiers, p. ex. matériau ou assemblage de parties du boîtier
• F21V 19/00 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage
• F21V 29/10 - Disposition des composants générant de la chaleur afin de réduire les détériorations thermiques, p. ex. en éloignant les composants générant de la chaleur d'autres composants à protéger
• F21V 29/70 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques
• F21Y 113/17 - Combinaison de sources lumineuses de couleurs différentes comprenant un ensemble de sources lumineuses ponctuelles formant une seule source lumineuse encapsulée
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A lighting system includes a converter configured to receive a rectified input voltage and to generate an output voltage based on a control signal; a primary controller configured to generate the control signal to adjust the output voltage of the converter; and a startup circuit configured to power the primary controller based on the rectified input voltage in response to the output voltage being below a threshold, and to power the primary controller based on the output voltage in response to the output voltage being greater than or equal to the threshold.

Classes IPC  ?

• H05B 45/375 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de dévoltage
• H05B 45/34 - Stabilisation de la tensionMaintien d'une tension constante
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H05B 47/16 - Commande de la source lumineuse par des moyens de minutage

Abrégé

A lighting system includes a converter configured to receive a rectified input voltage and to generate an output voltage based on a gate control signal; a PFC controller including a zero-crossing input, and configured to generate the gate control signal to adjust the output voltage of the converter based on a zero-crossing voltage at the zero-crossing input; a zero-crossing delay circuit coupled between an output of the converter and the zero-crossing input, and configured to slow a rate of change of the zero-crossing voltage based on one or more delay control signals; and a channel controller configured to identify a low-load state of the lighting system, and, in response, to generate the one or more delay control signals.

Classes IPC  ?

• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H05B 45/50 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection

Abrégé

A programmable lighting system includes a plurality of color channels configured to generate light of different colors, and a light driver configured to drive the plurality of color channels according to a dimmer setting and a correlated color temperature (CCT) setting, and to maintain a constant maximum lumen output across a range of CCT values based on a dim-stop limit.

Classes IPC  ?

• H05B 45/30 - Circuits de commande
• H05B 45/28 - Commande de la couleur de la lumière à l'aide d'un retour de température

Abrégé

A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base configured to be attached to a heatsink mount.

Classes IPC  ?

• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21V 7/04 - Structure de l'optique
• F21V 15/01 - Boîtiers, p. ex. matériau ou assemblage de parties du boîtier
• F21V 19/00 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage
• F21V 29/10 - Disposition des composants générant de la chaleur afin de réduire les détériorations thermiques, p. ex. en éloignant les composants générant de la chaleur d'autres composants à protéger
• F21V 29/70 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques
• F21Y 113/17 - Combinaison de sources lumineuses de couleurs différentes comprenant un ensemble de sources lumineuses ponctuelles formant une seule source lumineuse encapsulée
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A lighting system includes a power supply configured to receive an AC input signal and to generate a rectified signal; a light driver configured to generate a drive signal to drive a light source based on the rectified signal; and a housing configured to encapsulate the power supply and the light driver, the housing including a heatsink base configured to be attached to a heatsink mount.

Classes IPC  ?

• F21K 9/233 - Sources lumineuses rétrocompatibles pour dispositifs d’éclairage avec un seul culot pour chaque source lumineuse, p. ex. pour le remplacement de lampes à incandescence avec un culot à baïonnette ou à vis spécialement adaptées à la génération d’une lumière ponctuelle, p. ex. pour le remplacement de lampes à réflecteur
• F21K 9/237 - Détails des enceintes ou des boîtiers, c.-à-d. des parties entre l’élément générateur de lumière et le socleAgencement des composants à l’intérieur des enceintes ou des boitiers
• F21V 29/70 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques
• F21V 29/71 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques utilisant une combinaison d’éléments séparés interconnectés par des moyens thermo-conducteurs, p. ex. tubes caloporteurs ou barres thermiquement conductrices pour conduire la chaleur entre des éléments séparés de puits thermique
• F21V 29/74 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames
• F21V 29/77 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames avec ailettes ou lames en plans divergents essentiellement identiques, p. ex. avec une section en forme d’éventail ou d’étoile
• F21V 29/83 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques les éléments comportant des ouvertures, des conduits ou des canaux, p. ex. des trous de rayonnement thermique
• F28F 3/02 - Éléments ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des évidements, avec des ondulations
• F28F 3/06 - Éléments ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des évidements, avec des ondulations les moyens pouvant être fixés sur l'élément
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/20 - Commande de la couleur de la lumière

Abrégé

A method of controlling a light driver includes determining, by a secondary controller of the light driver, an actual voltage drop across a regulator of the light driver; determining, by the secondary controller, a target voltage drop of the regulator; calculating, by the secondary controller, a theoretical input voltage of the regulator based on the target voltage drop and an output voltage of the regulator; determining, by the secondary controller, whether the theoretical input voltage is within a first range; and in response to determining that the theoretical input voltage is within the first range, generating, by the secondary controller, a first feedback signal for transmission to a primary controller of the light driver based on the target voltage drop and the actual voltage drop.

Classes IPC  ?

• H05B 45/59 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection pour réduire ou supprimer les effets de scintillement ou de lueur
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 45/36 - Circuits pour réduire ou supprimer les harmoniques, les ondulations ou les interférences électromagnétiques [EMI]

Abrégé

A light driver includes a converter configured to generate a drive signal for driving an output load based on a rectified input signal; a regulator coupled between the converter and the output load, and configured to generate a regulated signal based on the drive signal; a secondary controller configured to detect a voltage of the regulator, to generate a first feedback signal to dynamically control a DC-level of the drive signal based on the voltage of the regulator, and to generate a second feedback signal for controlling a DC-level of the regulated signal.

Classes IPC  ?

• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED

Abrégé

A light driver includes a pulse generator circuit configured to generate a pulsed signal based on a rectified input line voltage, a dimming detection circuit configured to determine whether phase-cut dimming is present at an input of the light driver based on the pulsed signal and to generate a phase-cut detection signal, and an input selection circuit configured to apply a first voltage or a second voltage to a reference input of a power factor correction (PFC) circuit of the light driver based on the phase-cut detection signal.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance

Abrégé

An integrated multi-layered lighting system includes a first board having a first component area and a first light area, a second board coupled to and offset from the first board, the second board having a first opening overlapping the first light area of the first board in a plan view, and a second component area overlapping the first component area of the first board in a plan view, a plurality of light emitting diodes (LEDs) coupled to the first board and positioned in the first light area corresponding to the first opening of the second board, and a light driver configured to drive the plurality of LEDs and including a plurality of first components coupled to the first board and positioned in the first component area and a plurality of second components coupled to the second board and positioned in the second component area.

Classes IPC  ?

• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• F21K 9/238 - Agencement ou montage d’éléments de circuit intégrés dans la source lumineuse
• F21V 19/00 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance

Abrégé

A light driver includes a converter configured to generate a drive signal for powering a light source based on a control signal, a modular controller board electrically coupled to a sensor board and configured to receive sensor data from the sensor board and to generate a first sensor control signal corresponding to the sensor data, and a primary controller configured to control the converter by generating the control signal based on the first sensor control signal.

Classes IPC  ?

• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/12 - Commande de l'intensité de la lumière à l'aide d'un retour optique
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 47/105 - Commande de la source lumineuse en réponse à des paramètres détectés
• H05B 47/19 - Commande de la source lumineuse par télécommande via une transmission sans fil

Produits et services

Electronic control devices for cooling and energy management for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls; Downloadable mobile application for electronic control devices for cooling and energy management for use in LED lighting systems Light fixtures; Heat sinks for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; LED lighting systems, namely, LED modules, power supplies, and wiring; Accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; LED lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications Engineering design and consulting for lighting systems and lighting applications; Lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications

Produits et services

Electronic control devices for cooling and energy management for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls; Downloadable mobile application for electronic control devices for cooling and energy management for use in LED lighting systems Light fixtures; Heat sinks for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; LED lighting systems, namely, LED modules, power supplies, and wiring; Accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; LED lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications Engineering design and consulting for lighting systems and lighting applications; Lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications

Produits et services

Electronic control devices for cooling and energy management for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls; Downloadable mobile application for electronic control devices for cooling and energy management for use in LED lighting systems Light fixtures; Heat sinks for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; LED lighting systems, namely, LED modules, power supplies, and wiring; Accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; LED lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications Engineering design and consulting for lighting systems and lighting applications; Lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications

Produits et services

Electronic control devices for cooling and energy management for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls; Downloadable mobile application for electronic control devices for cooling and energy management for use in LED lighting systems Light fixtures; Heat sinks for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; LED lighting systems, namely, LED modules, power supplies, and wiring; Accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; LED lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications Engineering design and consulting for lighting systems and lighting applications; Lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications

Produits et services

Electronic control devices for cooling and energy management for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls; Downloadable mobile application for electronic control devices for cooling and energy management for use in LED lighting systems Light fixtures; Heat sinks for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; LED lighting systems, namely, LED modules, power supplies, and wiring; Accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; LED lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications Engineering design and consulting for lighting systems and lighting applications; Lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications

Abrégé

A multi-channel power supply system including a power supply circuit configured to generate a drive signal for powering a plurality of color channels based on an input power signal, a first current control circuit coupled to a first color channel of the plurality of color channels and configured to adjust a first channel current of the first color channel based on the drive signal and a first reference signal, and a channel controller configured generate the first reference signal based on a color temperature according to a black body curve.

Classes IPC  ?

• H05B 45/20 - Commande de la couleur de la lumière
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/382 - Alimentation du circuit à découpage [SMPS] avec une isolation galvanique entre entrée et sortie
• H05B 45/46 - Détails des circuits de charge à LED avec un contrôle actif à l'intérieur d'une matrice de LED les diodes étant disposées parallèlement

Abrégé

A multi-channel power supply system includes a power supply circuit configured to generate a drive signal for powering a plurality of color channels based on an input power signal, a channel controller configured to generate a first pulse width modulated (PWM) signal for controlling an output light intensity of a first color channel of the plurality of color channels, a filter circuit configured to generate a first pseudo-sawtooth signal based on the first PWM signal, and a first current control circuit coupled to a first color channel of the plurality of color channels and configured to adjust a first channel current of the first color channel based on the drive signal and the first pseudo-sawtooth signal.

Classes IPC  ?

• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/375 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de dévoltage
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED

Abrégé

A light driver includes a pulse generator circuit configured to generate a pulsed signal based on a rectified input line voltage, a dimming detection circuit configured to determine whether phase-cut dimming is present at an input of the light driver based on the pulsed signal and to generate a phase-cut detection signal, and an input selection circuit configured to apply a first voltage or a second voltage to a reference input of a power factor correction (PFC) circuit of the light driver based on the phase-cut detection signal.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance

Abrégé

A programmable lighting system includes a plurality of color channels configured to generate light of different colors, and a light driver configured to drive the plurality of color channels according to a dimmer setting and a correlated color temperature (CCT) setting, and to maintain a constant maximum lumen output across a range of CCT values based on a dim-stop limit.

Classes IPC  ?

• H05B 45/28 - Commande de la couleur de la lumière à l'aide d'un retour de température

Abrégé

A lighting system includes a light engine including a correlated color temperature (CCT) terminal configured to transmit a first power signal having a first variance and to receive a CCT signal, the light engine being configured to emit light according to the CCT signal, and a CCT clamp coupled to the CCT terminal, and configured to receive the first power signal and to generate the CCT signal having a second variance, the first variance of the first power signal being greater than the second variance of the CCT signal.

Classes IPC  ?

• H05B 45/20 - Commande de la couleur de la lumière
• H05B 45/10 - Commande de l'intensité de la lumière

Abrégé

A programming device includes a plurality of signal lines including a first signal line and a common ground line, and a first programming circuit coupled between the first signal line and the common ground line, and including a first configurable switch configured to receive a first switch configuration, the first programming circuit being configured to receive a first power signal from the first signal line and to supply a first programming signal to the first signal line, the first programming signal having a level corresponding to the first switch configuration.

Classes IPC  ?

• H05B 45/20 - Commande de la couleur de la lumière

Abrégé

An integrated multi-layered lighting system includes a first board having a first component area and a first light area, a second board coupled to and offset from the first board, the second board having a first opening overlapping the first light area of the first board in a plan view, and a second component area overlapping the first component area of the first board in a plan view, a plurality of light emitting diodes (LEDs) coupled to the first board and positioned in the first light area corresponding to the first opening of the second board, and a light driver configured to drive the plurality of LEDs and including a plurality of first components coupled to the first board and positioned in the first component area and a plurality of second components coupled to the second board and positioned in the second component area.

Classes IPC  ?

• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• F21K 9/238 - Agencement ou montage d’éléments de circuit intégrés dans la source lumineuse
• F21V 19/00 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage

Abrégé

A method of driving a light source by a light driver includes measuring a current output signal of the light driver, calculating a percent change in output signal, determining whether the percent change in output signal is greater than or equal to a first threshold, and in response to determining that the percent change in the output signal is greater than or equal to the first threshold, calculating a percent change in reference voltage based on a current reference voltage and a previous reference voltage, determining whether the percent change in reference voltage is less than a second threshold, and in response to determining that the percent change in reference voltage is less than the second threshold, deactivating filtering and averaging of a dimmer signal received from a dimmer for a period of time, and reactivating the filtering and the averaging of the dimmer signal.

Classes IPC  ?

• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]

Abrégé

A method of initiating power-on of a light driver for driving a light source, the method including retrieving a stored load voltage of the light driver from a memory, determining a turn-on delay based on the stored load voltage, stalling power-on of the light driver for a period of time equal to the turn-on delay, initiating startup of the light driver based on the stored load voltage, determining whether current is flowing to the light source, in response to determining that current is flowing to the light source, measuring a load voltage of the light driver, and storing the load voltage in the memory.

Classes IPC  ?

• H05B 47/14 - Commande de la source lumineuse en réponse à des paramètres détectés en détectant les paramètres électriques de la source lumineuse
• H05B 47/16 - Commande de la source lumineuse par des moyens de minutage
• H05B 47/165 - Commande de la source lumineuse en suivant une séquence programmée pré-assignéeCommande logique [LC]

Abrégé

A light driver includes a converter configured to generate a drive current based on a rectified input signal for driving a light source, and an output correction circuit coupled to an output of the converter and configured to measure the drive current and to generate a correction signal to dynamically control a DC-level of the drive current of the converter based on the drive current and a reference signal corresponding to a desired DC-level of the drive current.

Classes IPC  ?

• H05B 45/50 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection
• G01R 19/165 - Indication de ce qu'un courant ou une tension est, soit supérieur ou inférieur à une valeur prédéterminée, soit à l'intérieur ou à l'extérieur d'une plage de valeurs prédéterminée
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance

Abrégé

A light driver includes a converter configured to generate a drive signal for powering a light source based on a control signal, a modular controller board electrically coupled to a sensor board and configured to receive sensor data from the sensor board and to generate a first sensor control signal corresponding to the sensor data, and a primary controller configured to control the converter by generating the control signal based on the first sensor control signal.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 47/11 - Commande de la source lumineuse en réponse à des paramètres détectés en détectant la luminosité ou la température de couleur de la lumière ambiante
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H05B 47/19 - Commande de la source lumineuse par télécommande via une transmission sans fil
• H05B 47/105 - Commande de la source lumineuse en réponse à des paramètres détectés
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 45/12 - Commande de l'intensité de la lumière à l'aide d'un retour optique

Abrégé

A sensor board includes a plurality of sensors configured to sense parameters from the environment and to generate sensory outputs, a transmission circuit configured to receive sensory output from the plurality of sensors and to generate sensor data for transmission to a light driver through a wired connection, and a regulator configured to receive a variable input voltage and to generate a regulated voltage for powering the plurality of sensors and the transmission circuit.

Classes IPC  ?

• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/12 - Commande de l'intensité de la lumière à l'aide d'un retour optique
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 47/105 - Commande de la source lumineuse en réponse à des paramètres détectés
• H05B 47/19 - Commande de la source lumineuse par télécommande via une transmission sans fil

Abrégé

According to some embodiments, there is provided a power supply system including a converter configured to generate an output signal based on a rectified input signal for driving a light source, an output correction circuit coupled to an output of the converter and configured to measure a ripple in the output signal and to generate a correction signal to dynamically control a DC-level of the output signal of the converter based on the measured ripple and a reference signal corresponding to a desired DC-level of the output signal.

Classes IPC  ?

• H05B 45/36 - Circuits pour réduire ou supprimer les harmoniques, les ondulations ou les interférences électromagnétiques [EMI]
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance

Abrégé

An active gain control circuit includes a dynamic voltage divider having a variable resistance configured to attenuate a rectified input line voltage to produce a reference signal, a filter-divider circuit configured to extract a DC-level attenuated reference voltage from the reference signal, and an operational amplifier configured to receive the DC-level attenuated reference voltage and a regulation voltage, and to generate a gate control signal based on a difference between the regulation voltage and the DC-level attenuated reference voltage, the variable resistance of the dynamic voltage divider being controlled by the gate control signal, and a comparison voltage generator configured to attenuate a comparison voltage to generate the regulation voltage.

Classes IPC  ?

• H05B 45/30 - Circuits de commande
• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H02M 1/42 - Circuits ou dispositions pour corriger ou ajuster le facteur de puissance dans les convertisseurs ou les onduleurs
• H05B 45/38 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de survoltage
• H05B 45/12 - Commande de l'intensité de la lumière à l'aide d'un retour optique

Abrégé

A method of overpower protection in a power supply system for driving a light source includes determining a voltage drop across a voltage-controlled resistor (VCR) coupled in series with the light source, calculating a power dissipation of the VCR based on the voltage drop and an output current of the power supply system, determining whether the power dissipation is greater than a power threshold, and in response to determining that the power dissipation is less than or equal to the power threshold, determining that an accumulated energy of the VCR is greater than zero, and decrementing the accumulated energy based on the power threshold and the power dissipation of the VCR.

Classes IPC  ?

• H02H 3/42 - Circuits de protection de sécurité pour déconnexion automatique due directement à un changement indésirable des conditions électriques normales de travail avec ou sans reconnexion sensibles au produit de la tension et du courant
• G01R 19/165 - Indication de ce qu'un courant ou une tension est, soit supérieur ou inférieur à une valeur prédéterminée, soit à l'intérieur ou à l'extérieur d'une plage de valeurs prédéterminée
• H05B 47/20 - Circuits pour faire fonctionner des sources lumineuses en général, c.-à-d. où le type de source lumineuse n'est pas important réagissant aux dysfonctionnements ou à la durée de fonctionnementCircuits pour faire fonctionner des sources lumineuses en général, c.-à-d. où le type de source lumineuse n'est pas important pour la protection
• H02H 1/00 - Détails de circuits de protection de sécurité
• G01R 19/10 - Mesure d'une somme, d'une différence, ou d'un rapport

Abrégé

A negative injection circuit is coupled to a power factor correction (PFC) controller of a power supply system and includes a downshifter configured to downshift a ground signal to generate a negative voltage signal, a variable impedance coupled between the downshifter and the PFC controller, and configured to inject a negative injection voltage into a voltage sampling input of the PFC controller, the variable impedance including a first current limiting resistor and a second current limiting resistor coupled in series with one another and between the downshifter and the voltage sampling input of the PFC controller, and a bypass switch configured to selectively short across the second current limiting resistor in response a range selection signal.

Classes IPC  ?

• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H02M 1/42 - Circuits ou dispositions pour corriger ou ajuster le facteur de puissance dans les convertisseurs ou les onduleurs
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]

Abrégé

A multi-channel power supply system includes a power supply circuit configured to generate a drive signal for powering a plurality of color channels based on an input power signal, a first current control circuit coupled to a first color channel of the plurality of color channels and configured to adjust a first channel current of the first color channel based on the drive signal and a first reference signal, and to generate a feedback signal to control the drive signal of the power supply circuit, and a channel controller configured generate the first reference signal based on a color temperature according to a black body curve.

Classes IPC  ?

• H05B 45/22 - Commande de la couleur de la lumière à l'aide d'un retour optique
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 45/20 - Commande de la couleur de la lumière
• H05B 45/30 - Circuits de commande
• H05B 45/10 - Commande de l'intensité de la lumière

Abrégé

A multi-channel power supply system including a power supply circuit configured to generate a drive signal for powering a plurality of color channels based on an input power signal, a first current control circuit coupled to a first color channel of the plurality of color channels and configured to adjust a first channel current of the first color channel based on the drive signal and a first reference signal, and a channel controller configured generate the first reference signal based on a color temperature according to a black body curve.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/20 - Commande de la couleur de la lumière
• H05B 45/32 - Circuits de commande par impulsion
• H05B 45/38 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de survoltage
• H05B 45/46 - Détails des circuits de charge à LED avec un contrôle actif à l'intérieur d'une matrice de LED les diodes étant disposées parallèlement
• H05B 45/382 - Alimentation du circuit à découpage [SMPS] avec une isolation galvanique entre entrée et sortie
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]

Abrégé

A zero-crossing detection circuit coupled to a power factor correction (PFC) controller of a power supply system includes a zener diode configured to generate a zener reference signal, and an operational amplifier coupled to the zener diode and configured to receive the zener reference signal and a feedback signal corresponding to an output current of the power supply system, and to generate a zero-crossing signal to a zero-crossing input of the PFC controller.

Classes IPC  ?

• H05B 45/38 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de survoltage
• H02M 1/12 - Dispositions de réduction des harmoniques d'une entrée ou d'une sortie en courant alternatif
• H02M 1/08 - Circuits spécialement adaptés à la production d'une tension de commande pour les dispositifs à semi-conducteurs incorporés dans des convertisseurs statiques
• H02M 1/42 - Circuits ou dispositions pour corriger ou ajuster le facteur de puissance dans les convertisseurs ou les onduleurs
• H02M 7/06 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge sans électrode de commande ou des dispositifs à semi-conducteurs sans éléctrode de commande
• H02M 7/217 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs
• H05B 45/375 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de dévoltage
• H05B 47/105 - Commande de la source lumineuse en réponse à des paramètres détectés

Abrégé

A power supply system includes a converter configured to generate a drive signal based on a rectified input signal for powering a light source, a ripple control system including a voltage-controlled resistor (VCR) coupled to a secondary-side of the converter and configured to dynamically adjust a resistance of the VCR to compensate for ripples in the drive signal, and a controller configured to sense an output voltage of the converter, to calculate a voltage drop across the VCR, and to generate a feedback signal to control the drive signal of the converter based on the sensed output voltage and the calculated voltage drop.

Classes IPC  ?

• H05B 45/38 - Alimentation du circuit à découpage [SMPS] en utilisant une topologie de survoltage
• H05B 45/36 - Circuits pour réduire ou supprimer les harmoniques, les ondulations ou les interférences électromagnétiques [EMI]
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED

Abrégé

A power supply system includes a rectifier configured to rectify an input signal to generate a rectified signal having a single polarity, a converter configured to generate a drive signal for powering a light source, and a ripple control system including a voltage-controlled resistor (VCR) coupled to a secondary-side of the converter and configured to dynamically adjust a resistance of the VCR to compensate for ripples in the drive signal.

Classes IPC  ?

• H05B 45/36 - Circuits pour réduire ou supprimer les harmoniques, les ondulations ou les interférences électromagnétiques [EMI]
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/345 - Stabilisation du courantMaintien d'un courant constant

Produits et services

Electrical apparatus, namely, power supplies housed in a metal or plastic case for providing constant voltage, constant current, or both; electrical apparatus, namely, power supplies in the form of a printed circuit board (pcb) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both; apparatus for environmental control, namely, led (light emitting diode) driver housed in a metal or plastic case or no case at all for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a led or string of multiple leds; apparatus for environmental control, namely, led (light emitting diode) driver in the form of a printed circuit board (pcb) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a led or string of multiple leds; electronic control devices for cooling and energy management for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls. light fixtures; heat sinks for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; led lighting systems, namely, led modules, power supplies, and wiring; accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; led lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications. engineering design and consulting for lighting systems and lighting applications; lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications.

Produits et services

(1) LED lighting systems, namely, LED modules, power supplies, and wiring

Produits et services

(1) Electrical apparatus, namely, power supplies housed in a metal or plastic case for providing constant voltage, constant current, or both; electrical apparatus, namely, power supplies in the form of a printed circuit board (pcb) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both; apparatus for environmental control, namely, led (light emitting diode) driver housed in a metal or plastic case or no case at all for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a led or string of multiple leds; apparatus for environmental control, namely, led (light emitting diode) driver in the form of a printed circuit board (pcb) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a led or string of multiple leds; electronic control devices for cooling and energy management for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls (2) Light fixtures; heat sinks for use in led lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; led lighting systems, namely, led modules, power supplies, and wiring; accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; led lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications (1) Engineering design and consulting for lighting systems and lighting applications; lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications

Produits et services

Power supplies, and wiring. Led lighting systems, namely led modules.

Abrégé

A method of controlling a power supply electrically coupled to a dimmer, the method including receiving a plurality of pulse-width-modulated (PWM) pulses corresponding to one or more dimmer levels of the dimmer, generating a first sample value and a second sample value of a plurality of sample values corresponding to duty cycles of the plurality of PWM pulses, determining a rate of change of the one or more dimmer levels based on the first and second sample values, comparing the rate of change with a threshold value to identify a mode of operation of the power supply, and generating a control signal for transmission to the power supply based on the identified mode of operation.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/37 - Circuits de conversion

Abrégé

A method of controlling a power supply in a multi-input power supply system includes retrieving a prior input state flag from a memory of the multi-input power supply system, determining a first dimmer input of the multi-input power supply system based on the prior input state flag, determining whether the first dimmer input is currently valid, and in response to determining that the first dimmer input is not valid, determining whether a second dimmer input of the multi-input power supply system is currently valid, and in response to determining that the second dimmer input is valid, controlling the power supply based on a second input signal received through the second dimmer input.

Classes IPC  ?

• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/37 - Circuits de conversion
• H05B 47/14 - Commande de la source lumineuse en réponse à des paramètres détectés en détectant les paramètres électriques de la source lumineuse
• G01R 23/15 - Indication de ce qu'une fréquence d'impulsions est, soit supérieure ou inférieure à une valeur prédéterminée, soit à l'intérieur ou à l'extérieur d'une plage de valeurs prédéterminée, en utilisant des éléments non linéaires ou numériques
• H05B 45/10 - Commande de l'intensité de la lumière
• G01R 19/165 - Indication de ce qu'un courant ou une tension est, soit supérieur ou inférieur à une valeur prédéterminée, soit à l'intérieur ou à l'extérieur d'une plage de valeurs prédéterminée
• G01R 29/027 - Indication de ce qu'une caractéristique d'impulsion est, soit supérieure ou inférieure à une valeur prédéterminée, soit à l'intérieur ou à l'extérieur d'une plage de valeurs prédéterminée
• H05B 47/19 - Commande de la source lumineuse par télécommande via une transmission sans fil

Abrégé

According to some embodiments of the present disclosure, there is provided a method of controlling a power supply electrically coupled to a dimmer, the method including receiving a current sample value of a plurality of sample values corresponding to dimmer levels, determining a dynamic weight based on the current sample value, filtering the plurality of sample values based on the dynamic weight to generate a plurality of filtered values, and generating a control signal based on the filtered values for transmission to the power supply.

Classes IPC  ?

• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED

Abrégé

A method of controlling a power supply electrically coupled to a dimmer includes receiving a current pulse-width-modulated (PWM) pulse of a plurality of PWM pulses corresponding to a dimmer level, calculating a current duty cycle of the current PWM pulse, comparing the current duty cycle with a window of validity to determine whether the current duty cycle is within the window of validity, and in response to determining that the current duty cycle is not within the window of validity, determining whether a count of out-of-range PWM pulses having duty cycles not within the window of validity is greater than a threshold, and in response to determining that the count of out-of-range PWM pulses is greater than the threshold generating a sample value corresponding to the current duty cycle for transmission to the power supply.

Classes IPC  ?

• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/10 - Commande de l'intensité de la lumière

Abrégé

A method of controlling a power supply electrically coupled to a dimmer and a light source includes receiving a plurality of sample values corresponding to dimmer levels, comparing a sample value of the plurality of sample values with one or more inflection points, the one or more inflection points being associated with a plurality of slew-rates, identifying a particular slew-rate among the plurality of slew-rates based on the comparison, and generating a control signal based on the particular slew-rate for transmission to the power supply.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/37 - Circuits de conversion
• H03K 5/12 - Mise en forme d'impulsions par redressement des fronts avant ou arrière
• H03K 5/24 - Circuits présentant plusieurs entrées et une sortie pour comparer des impulsions ou des trains d'impulsions entre eux en ce qui concerne certaines caractéristiques du signal d'entrée, p. ex. la pente, l'intégrale la caractéristique étant l'amplitude
• H05B 47/14 - Commande de la source lumineuse en réponse à des paramètres détectés en détectant les paramètres électriques de la source lumineuse

Abrégé

A method of controlling a power supply electrically coupled to a dimmer includes receiving a current sample value of a plurality of sample values corresponding to dimmer levels, determining whether there is a change in the dimmer levels, determining a dynamic weight of the current sample value based on the determining whether there is a change in the dimmer levels, filtering the plurality of sample values based on the dynamic weight to generate a plurality of filtered values, and generating a control signal based on the filtered values for transmission to the power supply.

Classes IPC  ?

• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/37 - Circuits de conversion
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED

Abrégé

A hot-pluggable barrel jack connection system includes a male barrel jack connector including a tip connector at a distal end of the male barrel jack connector and configured to conduct a ground reference voltage, a first ring connector electrically isolated from the tip connector by a first insulator, and configured to conduct a first data signal, and a sleeve connector adjacent to a base of the male barrel jack connector electrically isolated from the first ring connector, and configured to conduct a power signal.

Classes IPC  ?

• G06F 13/40 - Structure du bus
• H01R 24/62 - Engagements par glissement avec une face uniquement, p. ex. dispositifs de couplage à prise modulaire
• H01R 24/58 - Contacts espacés le long de l'axe longitudinal d’engagement

Abrégé

A power supply system for driving a light source includes a transformer including a primary winding and a plurality of secondary windings including an output bias winding, a control bias winding, and an RF bias winding, the output bias winding being electrically coupled to and configured to supply electrical power to the light source, a control circuit electrically coupled to and configured to receive electrical power from the control bias winding; and an RF communication circuit electrically coupled to and configured to receive electrical power from the RF bias winding.

Classes IPC  ?

• H05B 41/24 - Circuits dans lesquels la lampe est alimentée par courant alternatif à haute fréquence
• H04B 1/04 - Circuits
• H05B 45/37 - Circuits de conversion

Abrégé

An active gain control circuit includes a voltage divider having a variable resistance configured to attenuate a rectified input line voltage to produce a reference signal, a filter circuit configured to extract a DC-level reference voltage from the reference signal, and an operational amplifier configured to receive the DC-level reference voltage and a comparison voltage, and to generate a gate control signal based on a difference between the comparison voltage and the DC-level reference voltage, wherein a resistance of the voltage divider is controlled by the gate control signal.

Classes IPC  ?

• H05B 45/355 - Correction du facteur de puissance [PFC]Compensation réactive de la puissance
• H02M 1/42 - Circuits ou dispositions pour corriger ou ajuster le facteur de puissance dans les convertisseurs ou les onduleurs
• H03G 3/30 - Commande automatique dans des amplificateurs comportant des dispositifs semi-conducteurs
• H03F 3/45 - Amplificateurs différentiels
• H02M 7/06 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge sans électrode de commande ou des dispositifs à semi-conducteurs sans éléctrode de commande

Produits et services

ELECTRICAL APPARATUS, namely, POWER SUPPLIES HOUSED IN A METAL OR PLASTIC CASE FOR PROVIDING CONSTANT VOLTAGE, CONSTANT CURRENT, OR BOTH; ELECTRICAL APPARATUS, namely, POWER SUPPLIES IN THE FORM OF A PRINTED CIRCUIT BOARD (PCB) WITH ALL OF THE ELECTRONIC COMPONENTS MOUNTED ON THE BOARD, FOR PROVIDING CONSTANT VOLTAGE, CONSTANT CURRENT, OR BOTH; APPARATUS FOR ENVIRONMENTAL CONTROL, namely, LED (LIGHT EMITTING DIODE) DRIVER HOUSED IN A METAL OR PLASTIC CASE OR NO CASE AT ALL FOR PROVIDING CONSTANT VOLTAGE, CONSTANT CURRENT, OR BOTH, AND FOR CONTROLLING THE CURRENT AND/OR VOLTAGE THAT FLOWS INTO A LED OR STRING OF MULTIPLE LEDS; APPARATUS FOR ENVIRONMENTAL CONTROL, namely, LED (LIGHT EMITTING DIODE) DRIVER IN THE FORM OF A PRINTED CIRCUIT BOARD (PCB) WITH ALL OF THE ELECTRONIC COMPONENTS MOUNTED ON THE BOARD, FOR PROVIDING CONSTANT VOLTAGE, CONSTANT CURRENT, OR BOTH, AND FOR CONTROLLING THE CURRENT AND/OR VOLTAGE THAT FLOWS INTO A LED OR STRING OF MULTIPLE LEDS; ELECTRONIC CONTROL DEVICES FOR COOLING AND ENERGY MANAGEMENT FOR USE IN LED LIGHTING SYSTEMS USED IN DISPLAY, COMMERCIAL, INDUSTRIAL, RESIDENTIAL, AND ARCHITECTURAL ACCENT LIGHTING APPLICATIONS; LIGHTING CONTROLS; HEAT SINKS FOR USE IN LED LIGHTING SYSTEMS USED IN DISPLAY, COMMERCIAL, INDUSTRIAL, RESIDENTIAL, AND ARCHITECTURAL ACCENT LIGHTING APPLICATIONS LIGHT FIXTURES; LED LIGHTING SYSTEMS, namely, LED MODULES, POWER SUPPLIES, AND WIRING; ACCESSORIES FOR LIGHTING SYSTEMS, namely, LOW-PROFILE LINEAR FIXTURE HOUSINGS, LANTERN HOUSINGS, DOME HOUSINGS, RECESSED CAN HOUSINGS, SUSPENDED BOWL HOUSINGS, DECORATIVE BACKLIGHTING HOUSINGS, PARKING DECK HOUSINGS, WALL PACK HOUSINGS BEING LIGHTING FIXTURES; LED LIGHTING FIXTURES FOR USE IN DISPLAY, COMMERCIAL, INDUSTRIAL, RESIDENTIAL, AND ARCHITECTURAL ACCENT LIGHTING APPLICATIONS ENGINEERING DESIGN AND CONSULTING FOR LIGHTING SYSTEMS AND LIGHTING APPLICATIONS; LIGHTING TECHNOLOGY SPECIFICATION SERVICES PERTAINING TO PERMANENT OR TEMPORARY ARCHITECTURAL, THEATRICAL, ENTERTAINMENT, COMMERCIAL AND/OR RESIDENTIAL APPLICATIONS

Abrégé

An LED driver includes a power input configured to receive an input power; a dimmer switch input configured to receive a brightness input; and a power supply coupled to the power input and the dimmer switch input, the power supply having a plurality of selectable transfer functions and a currently selected transfer function of the plurality of selectable transfer functions, the power supply being configured to generate an output power from the input power, the output power having a level based on a value of the brightness input and the currently selected transfer function.

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• F21K 9/00 - Sources lumineuses utilisant des dispositifs à semi-conducteurs en tant qu’éléments générateurs de lumière, p. ex. utilisant des diodes électroluminescentes [LED] ou des lasers
• H05B 37/00 - Circuits pour sources lumineuses électriques en général
• H05B 37/02 - Commande

Abrégé

An LED driver includes a power input configured to receive an input power; a dimmer switch input configured to receive a brightness input; and a power supply coupled to the power input and the dimmer switch input, the power supply having a plurality of selectable transfer functions and a currently selected transfer function of the plurality of selectable transfer functions, the power supply being configured to generate an output power from the input power, the output power having a level based on a value of the brightness input and the currently selected transfer function.

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• H05B 37/02 - Commande

Abrégé

An active preload circuit includes: a rectifier configured to receive an AC input from a TRIAC dimmer and to generate DC power; a preload; and a phase angle controller configured to selectively couple the preload to the DC power.

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• H05B 45/14 - Commande de l'intensité de la lumière à l'aide d'une rétroaction électrique provenant de LED ou de modules de LED
• H05B 45/37 - Circuits de conversion
• H05B 47/10 - Commande de la source lumineuse

Abrégé

An active preload circuit includes: a rectifier configured to receive an AC input from a TRIAC dimmer and to generate DC power; a preload; and a phase angle controller configured to selectively couple the preload to the DC power.

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• H05B 35/00 - Sources lumineuses électriques utilisant une combinaison des différents types de génération de lumière

Abrégé

A touch sensor for controlling intensity of lighting electrically connected thereto, the touch sensor including a touch sensor interface for detecting a touch of a user, a power supply connected to the touch sensor for controlling the intensity of the lighting, and a backlight behind the touch sensor interface, and including a plurality of light sources for illuminating different portions of the touch sensor interface.

Classes IPC  ?

• G06F 3/041 - Numériseurs, p. ex. pour des écrans ou des pavés tactiles, caractérisés par les moyens de transduction
• G08B 5/36 - Systèmes de signalisation optique, p. ex. systèmes d'appel de personnes, indication à distance de l'occupation de sièges utilisant une transmission électriqueSystèmes de signalisation optique, p. ex. systèmes d'appel de personnes, indication à distance de l'occupation de sièges utilisant une transmission électromécanique utilisant des sources de lumière visible
• H05B 37/00 - Circuits pour sources lumineuses électriques en général

Abrégé

A method of monitoring a power factor correcting (PFC) power supply is provided. The method includes: powering on the PFC power supply with a constant current; starting a runtime counter that increments a count value; measuring an output voltage; calculating an output power by multiplying the constant current by the output voltage; storing the output power in a random-access memory (RAM); calculating an input power by multiplying the output power by an efficiency curve factor; and storing the input power in the RAM.

Classes IPC  ?

• H02M 1/00 - Détails d'appareils pour transformation

Abrégé

A touch sensor for controlling intensity of lighting electrically connected thereto, the touch sensor including a touch sensor interface for detecting a touch of a user, a power supply connected to the touch sensor for controlling the intensity of the lighting, and a backlight behind the touch sensor interface, and including a plurality of light sources for illuminating different portions of the touch sensor interface.

Classes IPC  ?

• G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
• H05B 45/10 - Commande de l'intensité de la lumière
• H05B 47/105 - Commande de la source lumineuse en réponse à des paramètres détectés

Abrégé

A method of monitoring a power factor correcting (PFC) power supply is provided. The method includes: powering on the PFC power supply with a constant current; starting a runtime counter that increments a count value; measuring an output voltage; calculating an output power by multiplying the constant current by the output voltage; storing the output power in a random-access memory (RAM); calculating an input power by multiplying the output power by an efficiency curve factor; and storing the input power in the RAM.

Classes IPC  ?

• H02M 1/42 - Circuits ou dispositions pour corriger ou ajuster le facteur de puissance dans les convertisseurs ou les onduleurs
• G05F 1/70 - Régulation du facteur de puissanceRégulation du courant réactif ou de la puissance réactive
• G01R 21/06 - Dispositions pour procéder aux mesures de la puissance ou du facteur de puissance par mesure du courant et de la tension
• G01R 21/133 - Dispositions pour procéder aux mesures de la puissance ou du facteur de puissance en utilisant des techniques numériques

Produits et services

Electrical apparatus, namely, power supplies housed in a metal or plastic case for providing constant voltage, constant current, or both; electrical apparatus, namely, power supplies in the form of a printed circuit board (PCB) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both; apparatus for environmental control, namely, LED (light emitting diode) driver housed in a metal or plastic case or no case at all for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a LED or string of multiple LEDs; apparatus for environmental control, namely, LED (light emitting diode) driver in the form of a printed circuit board (PCB) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a LED or string of multiple LEDs.

Abrégé

A dual stage power converter capable of being installing in a one-gang box and powering an LED load is presented. The dual stage converter can include a power factor correction (PFC) stage operating in transition mode and a resonant converter stage operating at a fixed frequency with a fixed duty cycle and dead time. A dimmer input may be included to select a desired luminosity of the LED load. A main controller adjusts the value of the voltage output from the PFC stage in order to maintain the voltage output from the resonant stage at the desired level.

Classes IPC  ?

• H05B 37/02 - Commande
• H03K 5/07 - Mise en forme d'impulsions par augmentation de duréeMise en forme d'impulsions par diminution de durée par l'utilisation de circuits résonnants
• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes

Abrégé

A dual stage power converter capable of being installing in a one-gang box and powering an LED load is presented. The dual stage converter includes a power factor correction (PFC) stage operating in transition mode and a resonant converter stage operating at a fixed frequency with a fixed duty cycle and dead time. A dimmer input is included to select a desired luminosity of the LED load. A main controller adjusts the value of the voltage output from the PFC stage in order to maintain the voltage output from the resonant stage at the desired level.

Classes IPC  ?

• H05B 37/02 - Commande
• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes

Produits et services

Electrical apparatus, namely, power supplies housed in a metal or plastic case for providing constant voltage, constant current, or both; electrical apparatus, namely, power supplies in the form of a printed circuit board (PCB) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both; apparatus for environmental control, namely, LED (light emitting diode) driver housed in a metal or plastic case or no case at all for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a LED or string of multiple LEDs; apparatus for environmental control, namely, LED (light emitting diode) driver in the form of a printed circuit board (PCB) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a LED or string of multiple LEDs

Produits et services

Electrical apparatus, namely, electronic power supplies

Produits et services

Electrical apparatus, namely, power supplies housed in a metal or plastic case for providing constant voltage, constant current, or both; electrical apparatus, namely, power supplies in the form of a printed circuit board (PCB) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both; apparatus for environmental control, namely, LED (Light Emitting Diode) driver housed in a metal or plastic case or no case at all for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a LED or string of multiple LEDs; apparatus for environmental control, namely, LED (Light Emitting Diode) driver in the form of a printed circuit board (PCB) with all of the electronic components mounted on the board, for providing constant voltage, constant current, or both, and for controlling the current and/or voltage that flows into a LED or string of multiple LEDs

Abrégé

A resonant DC to DC converter circuit receiving an input voltage and capable of delivering multiple output voltages, while maintaining excellent cross-regulation with only one power transformer. The circuit of the invention uses trailing edge modulation, along with a new amplitude modulation arrangement which allows for the use of resonance with synchronous rectification and only a single power transformer. Thus, the circuit provides for DC to DC conversion, as well as an amplitude modulation arrangement.

Classes IPC  ?

• H02M 7/217 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs
• H02M 3/335 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu avec transformation intermédiaire en courant alternatif par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrodes de commande pour produire le courant alternatif intermédiaire utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs

Produits et services

electronic control devices for cooling and energy management for use in LED lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; lighting controls Light fixtures; heat sinks for use in LED lighting systems used in display, commercial, industrial, residential, and architectural accent lighting applications; LED lighting systems, namely, LED modules, power supplies, and wiring; accessories for lighting systems, namely, low-profile linear fixture housings, lantern housings, dome housings, recessed can housings, suspended bowl housings, decorative backlighting housings, parking deck housings, wall pack housings; LED lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications Engineering design and consulting for lighting systems and lighting applications; Lighting technology specification services pertaining to permanent or temporary architectural, theatrical, entertainment, commercial and/or residential applications
