Abrégé

A sieve element of a tubular heat exchanger, with openings for heat exchanger tubes, where formed along a rim (1) of the sieve element are notches (2), edges (2a) of which are given an arched shape, preferably the shape of an elliptical arch, with arms (2a′) parting away from each other towards the rim (1) of the sieve element, where the notches (2) are located behind the openings (3) for the heat exchanger tubes situated closest to the rim (1) of the sieve element.

Classes IPC  ?

• F28F 9/013 - Supports auxiliaires pour les éléments pour les tubes ou les assemblages de tubes
• F28F 9/22 - Dispositions pour diriger les sources de potentiel calorifique dans des compartiments successifs, p. ex. aménagement des plaques de guidage

Abrégé

A heat exchanger comprising packages (A, B) which comprise turbulising elements (1) which turbulise a flow of a working fluid between the two walls (2, 2′) inside the packages (A, B). Packages (A, B) are set together alternately to accommodate the working fluid flowing through them. Packages (A, B) are connected to each other via pass-through connectors (6) which are fitted, respectively, in the inlet openings (4, 5) and outlet openings (4′, 5′) for the working fluids. The connector (6) comprises an external portion (6a) and an internal portion (6b) which are connected to each other with a transverse wall (6c). The internal portion (6b) of the connector (6) is connected to the walls (2, 2′) of the respective package (A, B) and closes the corresponding inlet/outlet opening (4, 4′, 5, 5′), while the external portion (6a) of the connector (6) is connected to the neighbouring walls (2, 2′) of the neighbouring packages (A, B) and connects the neighbouring areas of flow of the same working fluid. The heat exchanger can be manufactured by the diffusion bonding method.

Classes IPC  ?

• F28F 13/12 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en créant une turbulence, p. ex. par brassage, par augmentation de la force de circulation
• F28D 9/00 - Appareils échangeurs de chaleur comportant des ensembles de canalisations fixes en forme de plaques ou de laminés pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation

Abrégé

A system for the laser beam welding of galvanic cells in the process of production of a battery module comprises a pressing set (7), a kinematic set for positioning the said pressing set (7) with respect to the cells of the electric battery module, a laser welding head (1), and a laser beam source. The pressing set (7) comprises at least two pressing elements (8) for pressing the contact element (4) which conducts electric current to the electrodes of the galvanic cells (3) in the area of welding with a laser beam, at least one fixing element (10), movably fitted in which are at least two said pressing elements (8), and further contains a device for activating the said pressing elements (8).

Classes IPC  ?

• B23K 26/035 - Alignement du faisceau laser
• B23K 26/244 - Soudage de joints du type à recouvrement
• B23K 26/70 - Opérations ou équipement auxiliaires
• B23K 37/04 - Dispositifs ou procédés auxiliaires non spécialement adaptés à un procédé couvert par un seul des autres groupes principaux de la présente sous-classe pour maintenir ou mettre en position les pièces
• B23K 101/36 - Dispositifs électriques ou électroniques

Abrégé

A method of laser beam welding of galvanic cells in the process of production of a battery module consists in physical connection and electric serial and/or parallel connection of galvanic cell electrodes via a connecting element of an electrically conducting structure under the laser beam welding method. The process of laser beam welding of the electrodes of the galvanic cells (2) is preceded by a non-contact three-dimensional measurement of the position of the connecting elements (3) which connect the electrodes of the galvanic cells (2), where the measurement is taken using a measurement taking system (8), following which, based on the said measurement the position of welds (6) is determined and the result is sent to the software controlling the welding head (7). Then, the said welding head (7) is used to carry out the process of laser beam welding of the connecting elements (3) to the electrodes of the galvanic cells (2) to achieve the pre-determined connection thereof, where during the said non-contact three-dimensional measurement of the position of the electrodes of the galvanic cells (2) and during the laser beam welding process the connecting element(s) (3) is (are) pressed to the said galvanic cells (2).

Classes IPC  ?

• H01M 10/058 - Structure ou fabrication
• B23K 26/03 - Observation, p. ex. surveillance de la pièce à travailler

Abrégé

The sleeve of a device housing, heat exchanger housing in particular, which contains the cover and cylindrical jacket, characterised in that on the external cylindrical surface (2) of the sleeve there is a thread (3) to cooperate with the thread in the cover, and on the inside of the sleeve there is at least one resilient pressure element (4) shaped around the circumference of the cylindrical surface (5) or around a section of the cylindrical surface (5), where the element is connected to the surface (5) on the one end and features a fixing socket (6) on the other end to accommodate an element of a device therein, heat exchange pack in particular; moreover, the sleeve is fitted with technical means which enable its fixing to the cylindrical jacket of the housing.

Classes IPC  ?

• F28D 7/16 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant espacées parallèlement
• F28F 9/02 - Boîtes de distributionPlaques d'extrémité

Produits et services

Industrial robots; Manipulating devices [machines] for industrial use; Robotic arms for industrial purposes; Industrial robots for use in manufacture; Robots for welding; Robotic electrical welding apparatus.

Abrégé

The fired heat exchanger intended for central heating and/or domestic water installations, having a thermoelectric generator, the functioning of which is based on the Seebeck effect, and fitted with an external jacket, combustion chamber, and flame pipes fixed in the sieve bottoms, according to the invention is characterised in that the thermoelectric generator takes the form of a thin thermoelectric coating (13) applied under the PVD (Physical Vapour Deposition) technology to these elements of the heat exchanger which are in thermal contact with combustion gases, where the coating contains a thermoelectric layer (1) having two semiconductor sub-layers 'p' and 'n' which do not contact each other and are interconnected in series with thin-layered conducting elements (2a, 2b) fitted with connection ends (4, 5) to evacuate the generated electric energy, and where the coating is electrically insulated on both sides with layers (3a, 3b) of electrical insulator based on inorganic oxides.

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F01N 5/02 - Silencieux ou dispositifs d'échappement combinés ou associés à des dispositifs bénéficiant de l'énergie des gaz évacués les dispositifs utilisant la chaleur
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives
• H01L 35/08 - Jonctions non amovibles, p.ex. obtenues par cémentation, frittage, soudage
• H01L 35/14 - Emploi d'un matériau spécifié pour les bras de la jonction utilisant des compositions inorganiques
• H01L 35/28 - DISPOSITIFS À SEMI-CONDUCTEURS; DISPOSITIFS ÉLECTRIQUES À L'ÉTAT SOLIDE NON PRÉVUS AILLEURS - Détails fonctionnant exclusivement par effet Peltier ou effet Seebeck

Abrégé

A burner with a thermoelectric generator, the functioning of which is based on the Seebeck effect, having an external jacket, fuel-and-air duct, and nozzles which supply the fuel-and-air mix to the outer surface of the external jacket where the mix burns, according to the invention is characterised in that the thermoelectric generator takes the form of a thin thermoelectric coating (16) applied under the PVD (Physical Vapour Deposition) technology to these elements of the burner which are in thermal contact with combustion gases, where the coating contains a thermoelectric layer (1) having two semiconductor sub-layers 'p' and 'n' which do not contact each other and are interconnected in series with thin-layered conducting elements (2a, 2b) fitted with connection ends (4, 5) to evacuate the generated electric energy, and where the coating is electrically insulated on both sides with layers (3a, 3b) of electrical insulator based on inorganic oxides, while made in the external jacket (6) inside which the duct (7) for the fuel-and-air mix is formed are nozzles (8) for the delivery of the fuel-and-air mix from the duct (7) to the outer surface of the external jacket (6).

Classes IPC  ?

• F23D 14/02 - Brûleurs à gaz avec prémélangeurs, c.-à-d. dans lesquels le combustible gazeux est mélangé à l'air de combustion en amont de la zone de combustion
• H01L 35/32 - DISPOSITIFS À SEMI-CONDUCTEURS; DISPOSITIFS ÉLECTRIQUES À L'ÉTAT SOLIDE NON PRÉVUS AILLEURS - Détails fonctionnant exclusivement par effet Peltier ou effet Seebeck caractérisés par la structure ou la configuration de la cellule ou du thermocouple constituant le dispositif

Abrégé

A thin thermoelectric coating, the functioning of which is based on the Seebeck effect, having a thermoelectric layer with semiconductor elements 'p' and 'n' interconnected in series according to the invention is characterised in that it is produced under the PVD (Physical Vapour Deposition) technology, where the semiconductor elements of the thermoelectric layer (1) are formed into semiconductor sub-layers 'p' and 'n' which do not contact each other, the thickness (d1 of which ranges from 1µm to 10µm, where the sub-layers are interconnected in series with thin-layered conducting elements (2a, 2b) fitted with connection ends (4, 5) to evacuate the generated electric energy, where the thermoelectric layer (1) is insulated on both sides with layers (3a, 3b) of electrical insulator based on inorganic oxides.

Classes IPC  ?

• H01L 35/32 - DISPOSITIFS À SEMI-CONDUCTEURS; DISPOSITIFS ÉLECTRIQUES À L'ÉTAT SOLIDE NON PRÉVUS AILLEURS - Détails fonctionnant exclusivement par effet Peltier ou effet Seebeck caractérisés par la structure ou la configuration de la cellule ou du thermocouple constituant le dispositif
• H01L 35/34 - Procédés ou appareils spécialement adaptés à la fabrication ou au traitement de ces dispositifs ou de leurs parties constitutives

Abrégé

The flame pipe of a fired heat exchanger basically circular in cross section, having at least two inward dents in its walls according to the invention is characterised in that each dent (2) has two surfaces (3, 4) which are not longitudinal to the axis of the pipe, and preferably positioned transversely or slantways with respect to the axis of the pipe (1) and convergent to each other towards the inside of the pipe (1).

Classes IPC  ?

• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F28F 13/12 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en créant une turbulence, p. ex. par brassage, par augmentation de la force de circulation
• F28D 21/00 - Appareils échangeurs de chaleur non couverts par l'un des groupes

Produits et services

Prefabricated metal buildings; metal reinforcement material for building; transportable buildings of metal; metal storage tanks. Electric welding machines; laser welding devices; welding torches; gas welding machines; soldering blow pipes, gas-operated. Electric control devices for heating management; photovoltaic modules; computer operating programs; operating system programs; recorded, computer operating programs; computer software development tools; computer software for processing digital images; computer hardware. Burners, boilers and heaters; heating installations; heating elements; gas water heaters; water heaters; pipes for heating boilers; boilers for heating installations; hot water heating installations; ventilating fans for industrial use; air-conditioning installations; air-conditioning apparatus; solar furnaces. Plastic substances semi-processed; non-metallic flexible pipes; flexible plumbing pipes of plastic; flexible tubes of plastic; insulation jackets for industrial pipes; rings of rubber for use as pipe connection seals; padding materials of rubber or plastic. Heating equipment installation and repair; installation, repair and maintenance of heating equipment; electric appliance installation and repair; installation and repair of computer hardware. Product development; material testing and evaluation; computer software development; computer programming; design, development and implementation of software; industrial design.

Produits et services

Prefabricated metal buildings; metal reinforcement material for building; transportable buildings of metal; metal storage tanks. Electric welding machines; laser welding devices; welding torches; gas welding machines; soldering blow pipes, gas-operated. Electric control devices for heating management; photovoltaic modules; computer operating programs; operating system programs; recorded, computer operating programs; computer software development tools; computer software for processing digital images; computer hardware. Burners, boilers and heaters; heating installations; heating elements; gas water heaters; water heaters; pipes for heating boilers; boilers for heating installations; hot water heating installations; ventilating fans for industrial use; air-conditioning installations; air-conditioning apparatus; solar furnaces. Plastic substances semi-processed; non-metallic flexible pipes; flexible plumbing pipes of plastic; flexible tubes of plastic; insulation jackets for industrial pipes; rings of rubber for use as pipe connection seals; padding materials of rubber or plastic. Heating equipment installation and repair; installation, repair and maintenance of heating equipment; electric appliance installation and repair; installation and repair of computer hardware. Product development; material testing and evaluation; computer software development; computer programming; design, development and implementation of software; industrial design.

Produits et services

Prefabricated metal buildings; metal reinforcement material for building; transportable buildings of metal; metal storage tanks. Electric welding machines; laser welding devices; welding torches; gas welding machines; soldering blow pipes, gas-operated. Electric control devices for heating management; photovoltaic modules; computer operating programs; operating system programs; recorded, computer operating programs; computer software development tools; computer software for processing digital images; computer hardware. Burners, boilers and heaters; heating installations; heating elements; gas water heaters; water heaters; pipes for heating boilers; boilers for heating installations; hot water heating installations; ventilating fans for industrial use; air-conditioning installations; air-conditioning apparatus; solar furnaces. Plastic substances semi-processed; non-metalic flexible pipes; flexible plumbing pipes of plastic; flexible tubes of plastic; insulation jackets for industrial pipes; rings of rubber for use as pipe connection seals; padding materials of rubber or plastic. Heating equipment installation and repair; installation, repair and maintenance of heating equipment; electric appliance installation and repair; installation and repair of computer hardware. Product development; material testing and evaluation; computer software development; computer programming; design, development and implementation of software; industrial design.

Produits et services

Prefabricated metal buildings; metal reinforcement material for building; transportable buildings of metal; metal storage tanks. Electric welding machines; laser welding devices; welding torches; gas welding machines; soldering blow pipes, gas-operated. Electric control devices for heating management; photovoltaic modules; computer operating programs; operating system programs; recorded, computer operating programs; computer software development tools; computer software for processing digital images; computer hardware. Burners, boilers and heaters; heating installations; heating elements; gas water heaters; water heaters; pipes for heating boilers; boilers for heating installations; hot water heating installations; ventilating fans for industrial use; air-conditioning installations; air-conditioning apparatus; solar furnaces. Plastic substances semi-processed; non-metalic flexible pipes; flexible plumbing pipes of plastic; flexible tubes of plastic; insulation jackets for industrial pipes; rings of rubber for use as pipe connection seals; padding materials of rubber or plastic. Heating equipment installation and repair; installation, repair and maintenance of heating equipment; electric appliance installation and repair; installation and repair of computer hardware. Product development; material testing and evaluation; computer software development; computer programming; design, development and implementation of software; industrial design.

Abrégé

The heat exchange device is provided with a coil heat exchanger with inlets and outlets for the heat exchanging agents and a tank (1) for one of the agents, where the tank is provided with an inlet and outlet stub pipes and characterized in that the coil heat exchanger consists of at least one coil (2A,2B) wound spirally around the tank (1} on its outside. The coil takes the form of three coaxial tubes, where at the first end of the coil (2A,2B) its outer tube (3) and inner tube (4) are connected by way of the first collector (6) to the in!et stub pipe (7) for the supply of the first agent, and the central tube (5) is connected by way of the second collector (8) to the outlet (9) of the second agent, while at the other end of the coil (2A,2B) its outer and inner tubes are connected with the inside of the tank (1) by way of the third collector (10) and a supply stub pipe (11), and the central tube is connected to the inlet (14) of the second agent by way of the fourth collector (12) and a supply pipe (13).

Classes IPC  ?

• F28D 7/10 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant disposées l'une dans l'autre, p. ex. concentriquement
• F28D 7/02 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant enroulées en hélice

Abrégé

The fired heat exchanger fitted with a chamber for the liquid encased in an outer jacket (1) which features a liquid inlet (7) and outlet (8), where inside the chamber there is a set of vertical tubular elements (2) for the flow of the fumes and at least one transverse baffle, and where the ends of the tubular elements are anchored in the sieve bottom (3) of the combustion chamber (4) on the one side, and in the sieve wall (5) of the condensate tank (6) featuring gas and condensate discharge stub pipes on the opposite side is characterized in that mounted close to the sieve bottom (3) of the combustion chamber (4), inside the chamber for the liquid, is a horizontal top baffle (9) with a single central opening (12) for the flow of the liquid, fitted with at least one vertical spiral baffle (11) adhering tightly to the sieve bottom (3) and to the top horizontal baffle (9), where the spiral baffle forms spiral ducts (13) for the flow of the liquid under the sieve bottom (3).

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 8/00 - Appareils de chauffage de fluides caractérisés par des moyens pour extraire par condensation la chaleur latente des fumées
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives

Produits et services

[ Prefabricated metal buildings; metal reinforcement material for building; transportable buildings of metal; ] metal storage tanks [ Electric welding machines; laser welding machines; welding torches; gas welding machines; soldering blow pipes, gas-operated ] [ Electric control devices for heating management; photovoltaic modules ] [ Gas burners, electric burners, electric boilers, gas boilers, electric space heaters, gas space heaters; heating installations; ] heating elements; gas water heaters; water heaters; pipes for heating boilers; [ boilers for heating installations; ] hot water heating installations [ ; ventilating fans for industrial use; air-conditioning installations; air-conditioning apparatus; solar furnaces ] [ Semi-processed plastics; non-metallic flexible pipes; flexible plumbing pipes of plastic; flexible tubes of plastic; insulation jackets for industrial pipes; rings of rubber for use as pipe connection seals; padding materials of rubber or plastic ] [ Heating equipment installation and repair; installation, repair and maintenance of heating equipment; electric appliance installation and repair ] [ Product development; material testing and evaluation; industrial design ]

Produits et services

[ Prefabricated metal buildings; metal reinforcement material for building; transportable buildings of metal; ] metal storage tanks [ Electric welding machines; laser welding machines; welding torches; gas welding machines; soldering blow pipes, gas-operated ] [ Electric control devices for heating management; photovoltaic modules; computer operating programs; operating system programs; computer operating programs, recorded; computer software development tools; computer software for processing digital images; computer hardware ] [ Gas burners, electric burners, electric boilers, gas boilers, electric space heaters, gas space heaters; heating installations; ] heating elements; gas water heaters; water heaters; pipes for heating boilers; [ boilers for heating installations; ] hot water heating installations [ ; ventilating fans for industrial use; air-conditioning installations; air-conditioning apparatus; solar furnaces ] [ Semi-processed plastics; non-metallic flexible pipes; flexible plumbing pipes of plastic; flexible tubes of plastic; insulation jackets for industrial pipes; rings of rubber for use as pipe connection seals; padding materials of rubber or plastic ] [ Heating equipment installation and repair; installation, repair and maintenance of heating equipment; electric appliance installation and repair; installation and repair of computer hardware ] [ Product development; material testing and evaluation; computer software development; computer programming; design, development and implementation of software; industrial design ]

Abrégé

A fired heat exchanger having a burner, a combustion chamber, and a chamber for the flow of the heated liquid, fitted with stub pipes for the inlet and outlet of the heated liquid according to the invention is characterised in that it contains a pipe (1) with a combustion chamber (3) formed inside, where there is a perforation (2) on a part of the wall of the pipe (1) which serves as the burner, and it further contains an external jacket (4) encasing the pipe (1), with a chamber (5) for the flow of the heated liquid formed inside the jacket, and a chamber (6) for the fuel mix fitted over the fragment of the pipe wail featuring the perforation (2).

Classes IPC  ?

• F23C 3/00 - Appareils à combustion caractérisés par la forme de la chambre de combustion
• F23D 14/02 - Brûleurs à gaz avec prémélangeurs, c.-à-d. dans lesquels le combustible gazeux est mélangé à l'air de combustion en amont de la zone de combustion
• F23D 99/00 - Matière non prévue dans les autres groupes de la présente sous-classe
• F24H 1/26 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc
• F23D 14/10 - Brûleurs à gaz avec prémélangeurs, c.-à-d. dans lesquels le combustible gazeux est mélangé à l'air de combustion en amont de la zone de combustion du type à induction, p. ex. becs Bunsen avec la tête de brûleur tubulaire allongée
• F28D 7/14 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant disposées l'une dans l'autre, p. ex. concentriquement les deux tubes étant courbés

Abrégé

A fired water heater has an external jacket (1), where in its upper part there is a combustion chamber (2) with an opening for a burner. Under the combustion chamber (2) there is chamber (3) for the flow of the heater water, inside which there are vertical flame pipes (4) fixed in sieve bottoms (5, 6). In the lower part of the external jacket (1) there is a first inlet pipe (7) for cold water, and in its upper part there is an outlet pipe (9) for hot water. Cold water is supplied via the first inlet pipe (7) and a second inlet pipe (8) pointing towards the upper sieve bottom (6) is fitted in the mouth of the first inlet pipe (7), where formed in between the pipes is an aperture (10). There are partitions over the lower sieve bottom (5) and the upper sieve bottom (6).

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives

Abrégé

1. Flame pipe of a condensing heat exchanger features pairs of longitudinal dents (2) shaped coaxially with respect to the axis of the pipe (1), where the dents are trapezoid in longitudinal section, positioned opposite each other, pointing towards the centre of the pipe (1) and forming a section, and the distance between the dents (2) in the section measured inside the pipe (1 ) is 0.5 mm or less, and the adjacent dent sections are positioned at an angle of 90° to one another, where the ratio of the pipe length (L) to the inner diameter (S) of the pipe (1) measured in the cylindrical part devoid of dents falls within the range from 26 to 29.

Classes IPC  ?

• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F24H 1/36 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec réservoir d'eau adjacent à la chambre ou aux chambres de combustion, p. ex. au-dessus ou à côté le réservoir d'eau renfermant un ou plusieurs tubes de feu
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives
• F28F 13/08 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en faisant varier la section transversale des canaux d'écoulement
• F28F 1/02 - Éléments tubulaires de section transversale non circulaire
• F28F 1/06 - Éléments tubulaires de section transversale non circulaire gaufrés ou ondulés transversalement

Abrégé

A flue tube of a condensing heat exchanger characterised in that it features a dents (2) formed along the length of the tube (1), and said dents (2) are pointed towards the centre of the tube (1), and said dents (2) are positioned opposite each other, and two opposite dents (2) mark out a section, where the distance between the lowest points in the dents (2) measured inside the tube (1) in the section is 1.0 mm or less, and the ratio of the length (L) of the tube (1) to the tube cross section circumference around which the combustion gases flow falls within the range from 2.5 to 6.5.

Classes IPC  ?

• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F28F 13/08 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en faisant varier la section transversale des canaux d'écoulement
• F28F 13/12 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en créant une turbulence, p. ex. par brassage, par augmentation de la force de circulation
• F28D 21/00 - Appareils échangeurs de chaleur non couverts par l'un des groupes
• F28F 1/06 - Éléments tubulaires de section transversale non circulaire gaufrés ou ondulés transversalement
• F28F 1/08 - Éléments tubulaires gaufrés ou ondulés longitudinalement

Abrégé

A condensing heat exchanger comprising a combustion chamber fitted in its top section which features an opening for inserting the burner, as well as flue tubes anchored in the sieve bottoms and encased in an outer jacket, where there is a chamber to accommodate the heated liquid formed inside the jacket and the jacket is fitted with stub tubes for the supply and discharge of the heated liquid, with a condensate container featuring the condensate discharge stub tube and a stub tube for the discharge of fumes to the vent, is characterised in that the flue tubes (1) feature dents (2) formed along the length of the tube (1), and said dents (2) are pointed towards the centre of the tube (1), and said dents (2) are positioned opposite each other, and two opposite dents (2) mark out a section, where the distance between the lowest points in the dents (2) measured inside the tube (1) in the section is 1.0 mm or less, and the ratio of the length (L) of the tube (1) to the tube cross section circumference around which the combustion gases flow falls within the range from 2.5 to 6.5.

Classes IPC  ?

• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F28F 13/08 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en faisant varier la section transversale des canaux d'écoulement
• F28F 13/12 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en créant une turbulence, p. ex. par brassage, par augmentation de la force de circulation
• F28D 21/00 - Appareils échangeurs de chaleur non couverts par l'un des groupes
• F28F 1/06 - Éléments tubulaires de section transversale non circulaire gaufrés ou ondulés transversalement
• F28F 1/08 - Éléments tubulaires gaufrés ou ondulés longitudinalement

Abrégé

A casing of a tube heat exchanger which, on the top, closes a wall of a combustion chamber placed inside a jacked fitted with openings to accommodate a stub pipes for the supply and discharge of the heated liquid, characterised in that it features two welds or fewer, where the wall (1) of the combustion chamber is shaped to form a container open on the top with its bottom formed to make an upper sieve bottom (2), the container encased in the jacket (4), where the jacket (4) is bound on the top with a weld (3) to the top section of the combustion chamber wall (1).

Classes IPC  ?

• F28D 7/16 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant espacées parallèlement
• F28F 9/00 - CartersBoîtes de distributionSupports auxiliaires pour les élémentsÉléments auxiliaires dans les carters
• F28F 9/02 - Boîtes de distributionPlaques d'extrémité
• F28F 9/16 - Dispositions pour obturer des éléments dans les boîtes de distribution ou plaques d'extrémité par joints permanents, p. ex. par dudgeonnage
• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 9/18 - Disposition ou montage des grilles ou des éléments chauffants

Abrégé

Condensing heat exchanger flue tube for installation in the holes of a tube sheets of the heat exchanger has a dents (2) formed along the length of the tube (1), and said dents (2) are pointed towards the inside of the tube (1), and said dents (2) are positioned opposite each other, and two opposite dents (2) mark out a section, where the distance between the lowest points in the dents (2) measured inside the tube (1) in the section is 1.0 mm or less, and the ratio of the length (L) of the tube (1) to the tube cross section circumference around which the combustion gases flow falls within the range from 2.5 to 6.5. The maximum outer linear dimension of the tube's (1) cross section at any point along its length, corresponding to the maximum diameter of the circle circumscribed on the outer contour of that cross-section, is not greater than the minimum transverse linear dimension at its upper and/or lower end, corresponding to the minimum diameter of the circle inscribed within the outer contour of the upper and/or lower end of the tube (1).

Classes IPC  ?

• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F28D 21/00 - Appareils échangeurs de chaleur non couverts par l'un des groupes

Abrégé

Condensing heat exchanger having in its upper part a combustion chamber equipped with a hole for a burner pipe, flue tubes mounted in a tube sheets, encircled by an outer shell, inside of which is created a chamber for the liquid being heated, and equipped with a heated liquid inlet port and outlet port, a condensate tank equipped with a condensate drain discharge and an exhaust outlet into the chimney, characterised in that the ratio of the length (L) of the flue tube (1) to its cross-sectional circumference washed by flue gas is between 2.5 and 6.5, while the flue tubes (1) have embossed pits (2) directed toward the centre of the tube (1), facing each other and forming a section in which the distance between the tips of the pits (2) inside the flue tube (1) is 1.0 mm at most.

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 8/00 - Appareils de chauffage de fluides caractérisés par des moyens pour extraire par condensation la chaleur latente des fumées
• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F28F 1/40 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant uniquement à l'intérieur de l'élément tubulaire
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives

Abrégé

A flue tube of a condensing heat exchanger has embossed pits (2) formed along the length of the tube (1), and said pits (2) are pointed towards the centre of the tube (1), and said pits (2) are placed facing each other, and two opposite pits (2) create a section, where the distance between the tips of the pits (2) measured inside the tube (1) in the section being 1.0 mm at most, and the ratio of the length (L) of the tube (1) to its cross-sectional circumference washed by flue gas is between 2.5 and 6.5, and the tube (1) at the top and bottom has a cylindrical shape.

Classes IPC  ?

• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F28F 13/08 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en faisant varier la section transversale des canaux d'écoulement
• F28F 13/12 - Dispositions pour modifier le transfert de chaleur, p. ex. accroissement, diminution en affectant le mode d'écoulement des sources de potentiel calorifique en créant une turbulence, p. ex. par brassage, par augmentation de la force de circulation
• F28D 21/00 - Appareils échangeurs de chaleur non couverts par l'un des groupes
• F28F 1/06 - Éléments tubulaires de section transversale non circulaire gaufrés ou ondulés transversalement
• F28F 1/08 - Éléments tubulaires gaufrés ou ondulés longitudinalement

Produits et services

Building and construction materials and elements of metal; Metal hardware; Tanks of metal; Structures and transportable buildings of metal. Machines and machine tools for treatment of materials and for manufacturing; Engines, powertrains, and generic machine parts; Moving and handling equipment; Robots. Apparatus and instruments for accumulating and storing electricity; Photovoltaics; Programs for computers; Computer hardware; Computer networks; Measuring, detecting and monitoring instruments, indicators and controllers; Heat regulating apparatus. Burners, boilers and heaters; Heat exchangers, not parts of machines; Flues and installations for conveying exhaust gases; Regulating and safety accessories for water and gas installations; Heating, ventilating, and air conditioning and purification equipment (ambient); Solar thermal collectors [heating]; Sanitary installations, water supply and sanitation equipment. Flexible pipes, tubes, hoses, and fittings therefor, including valves, non-metallic; Insulation and barrier articles and materials; Seals, sealants and fillers; Semi-processed plastics. HVAC (Heating, ventilation and air conditioning) installation, maintenance and repair. Technical research; Research and development services; Materials testing and analysing; Software development, programming and implementation; Industrial design.

Produits et services

Flexible pipes, tubes, hoses, and fittings therefor, including valves, non-metallic; Insulation and barrier articles and materials; Seals, sealants and fillers; Plastic substances, semi-processed. HVAC (Heating, ventilation and air conditioning) installation, maintenance and repair.

Abrégé

The method of protecting the sieve wall of the combustion chamber of a fired heat exchanger is characterised in that before a fired heat exchanger (1) is started, the control unit (9) of the fired heat exchanger (1) is pre-programmed with a limit temperature Tg adopted for the sieve wall (5) of the combustion chamber (3), whereupon, during the operation of the fired heat exchanger (1) the actual temperature Ta of the sieve wall (5) of the combustion chamber (3) is measured on the side of the water chamber (4) using an additional temperature sensor (T4), the signal from which is supplied to the control unit (9) and processed, following which the value of the actual temperature Ta is compared against the limit temperature Tg, and when both values are equal, the control unit (9) generates an alarm signal off. Once the fired heat exchanger is off, the limescale accumulated on the sieve wall (5) of the combustion chamber (3) is removed in any known way. The fired heat exchanger is fitted with additional sensor of temperature (T4) fixed in the socket (12) on the sieve wall (5} of the combustion chamber (3) on the side of the water chamber (4), and connected, either via a wire or wirelessly, to the control unit (9).

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives
• F24H 9/20 - Disposition ou montage des dispositifs de commande ou de sécurité
• G05D 23/00 - Commande de la température
• F28F 9/22 - Dispositions pour diriger les sources de potentiel calorifique dans des compartiments successifs, p. ex. aménagement des plaques de guidage

Abrégé

A combustion chamber for a gas-fired heat exchanger according to the invention, open on one side and fitted with a burner, is characterised in that there is a space (3) formed between its inner jacket (2) and its outer jacket (1) to accommodate the mixture of gas and air supplied to the burner (4), where the latter is fitted with a perforated wall (5) and where there is a ventilator (6) and a gas valve mounted in the outer jacket (1). Preferably, the perforated wall (5) of the burner (4) is made of a material resistant to high temperatures, preferably a perforated steel sheet and/or mesh and/or a woven and/or non-woven material.

Classes IPC  ?

• F23M 5/08 - Refroidissement des armatures, enveloppes ou paroisTubes de parois
• F23D 14/66 - Préchauffage de l'air de combustion ou du gaz
• F23D 14/02 - Brûleurs à gaz avec prémélangeurs, c.-à-d. dans lesquels le combustible gazeux est mélangé à l'air de combustion en amont de la zone de combustion
• F23D 14/14 - Brûleurs à rayonnement utilisant des écrans ou des plaques perforées

Abrégé

A fired heat exchanger module having at least one set of heat exchange elements, at least one fluid inlet stub pipe, and at least one fluid outlet stub pipe, characterised in that at its top there is a segment of the combustion chamber (2) encased in a segment of the water jacket (3) fitted with at least one fluid outlet stub pipe (4), wherein, connected to the segment of the combustion chamber (2) is at least one set (5) of the elements for the exchange of heat between the combustion gases and the fluid, at the bottom fitted with at least one fluid inlet stub pipe (6), where the chamber through which the fluid flows in each set (5) of heat exchange elements is connected to a segment of the water jacket (3). The module (1) connected to each other form a heat exchanger with a single combustion chamber, heated with a single burner.

Classes IPC  ?

• F24H 1/32 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant réalisée par sections avec sections verticales disposées côte à côte
• F24H 1/44 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec combinaison de plusieurs types couverts par les groupes
• F24H 1/46 - Appareils de chauffage d'eau avec plusieurs chambres de combustion
• F28F 7/02 - Blocs traversés par des passages pour sources de potentiel calorifique
• F28D 7/16 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant espacées parallèlement
• F24H 8/00 - Appareils de chauffage de fluides caractérisés par des moyens pour extraire par condensation la chaleur latente des fumées

Produits et services

Building and construction materials and elements of metal; Metal hardware; Vats of metal; Structures and transportable buildings of metal. Machines and machine tools for treatment of materials and for manufacturing; Engines, powertrains, and generic machine parts; Moving and handling equipment; Robots. Apparatus and instruments for accumulating and storing electricity; Photovoltaics; Programs for computers; Computer hardware; Computer networks; Measuring, detecting and monitoring instruments, indicators and controllers; Heat regulating apparatus. Burners, boilers and heaters; Heat exchangers, not parts of machines; Flues and installations for conveying exhaust gases; Regulating and safety accessories for water and gas installations; Heating, ventilating, and air conditioning and purification equipment (ambient); Solar thermal collectors [heating]; Sanitary installations, water supply and sanitation equipment. Flexible pipes, tubes, hoses, and fittings therefor, including valves, non-metallic; Insulation and barrier articles and materials; Seals, sealants and fillers; Plastic substances, semi-processed. HVAC (Heating, ventilation and air conditioning) installation, maintenance and repair. Technical research; Research and development services; Materials testing and analysing; Software development, programming and implementation; Industrial design.

Produits et services

Building and construction materials and elements of metal; Metal hardware; Vats of metal; Structures and transportable buildings of metal. Machines and machine tools for treatment of materials and for manufacturing; Engines, powertrains, and generic machine parts; Moving and handling equipment; Robots. Apparatus and instruments for accumulating and storing electricity; Photovoltaics; Programs for computers; Computer hardware; Computer networks; Measuring, detecting and monitoring instruments, indicators and controllers; Heat regulating apparatus. Burners, boilers and heaters; Heat exchangers, not parts of machines; Flues and installations for conveying exhaust gases; Regulating and safety accessories for water and gas installations; Heating, ventilating, and air conditioning and purification equipment (ambient); Solar thermal collectors [heating]; Sanitary installations, water supply and sanitation equipment. Flexible pipes, tubes, hoses, and fittings therefor, including valves, non-metallic; Insulation and barrier articles and materials; Seals, sealants and fillers; Plastic substances, semi-processed. HVAC (Heating, ventilation and air conditioning) installation, maintenance and repair. Technical research; Research and development services; Materials testing and analysing; Software development, programming and implementation; Industrial design.

Abrégé

Pipe of a fired heat exchanger with changing cross-section and at least one cylindrical end circular in cross-section which transitions into the corrugated flattened central part (2) with two essentially parallel walls is characterised in that the section (3) of transition between the cylindrical end (1A) and the corrugated flattened central part (2) is spherical in shape.

Classes IPC  ?

• F28F 1/06 - Éléments tubulaires de section transversale non circulaire gaufrés ou ondulés transversalement

Abrégé

Fired heat exchanger, in its top section having a combustion chamber (1) with an opening (2) for the insertion of the burner, and in its bottom section fitted with a condensate accumulation bowl (3) and vertical pipe elements (4) for the flow of fumes, which connect the combustion chamber (1) with the condensate accumulation bowl (3), fixed to the sieve bottoms (5, 6) of the jacket (7), inside which the heated fluid flows. The inlet stub pipe (8) and outlet stub pipe (9) are fitted in the lower sieve bottom (5) and end outside, which is achieved with the inlet connection stub pipe (10) and outlet connection stub pipe (1 1) integrally built into the flange (12) of the condensate accumulation bowl (3). The flange (12) is fitted with sockets (13) for the elements fixing the heat exchanger to the casing. Under the upper sieve bottom (6) there is a partition (16) fixed and fitted with at least one slot (17) for the flow of the fluid above the partition. There is a pipe (18) fixed to the partition (16) so as to drain the heated fluid from above the partition (16), connected to the fluid outlet stub pipe (9).

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 8/00 - Appareils de chauffage de fluides caractérisés par des moyens pour extraire par condensation la chaleur latente des fumées
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives
• F24H 9/12 - Raccordement des éléments chauffants, de transfert ou de production de chaleur aux tuyauteries de circulation
• F24H 9/14 - Raccordement de sections différentes, p. ex. dans les chauffe-eau

Abrégé

The fired heat exchanger, having an outer shell (1), water inlet pipe (4) at the bottom and water outlet pipe (3) at the top part, with a combustion chamber (7) enclosed at the bottom with a bonnet (8) with a burner hole (9), connected with tubes (10) for combustion gas flow, through a flue duct (12), to the stack, whereby the tubes (10) for combustion gas flow are arranged in the water tank (14) around the combustion chamber (7) side wall and are connected with the flue duct (12) to the stack with the tube sheet (13) of the water tank (14), according to the invention, is characterised in that the tubes (10) for combustion gas flow are connected to the combustion chamber (7) through holes (11) made in the upper part of the combustion chamber (7) side wall. The tubes (10) for combustion gas flow are conveniently close in shape to an inverse letter "L", with its shorter arm connected to the combustion chamber (7) and having embossed ribs (15).

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 8/00 - Appareils de chauffage de fluides caractérisés par des moyens pour extraire par condensation la chaleur latente des fumées

Abrégé

Method for increasing the heat exchange area in a heat exchanger, consisting in connecting fins, made of metal strip with any surface profile, to the surface of the exchanger members, between which, a space is formed for the flow of the heat exchange medium. The fins are joined to the surface of the exchanger member at an angle, preferably 90°, to that surface, along the fin side, forming open passages between the fins for the flow of the medium. In the heat exchanger pack with an increased heat exchange area, the fins (1) are conveniently joined between flat tubes (4) or plates (8), in the medium flow space, forming open passages (5) for the flow of that medium.

Classes IPC  ?

• F28F 3/02 - Éléments ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des évidements, avec des ondulations
• F28F 1/12 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements ces moyens étant uniquement à l'extérieur de l'élément tubulaire

Abrégé

Soldering component designed primarily for reinforcing steel structures or for increasing the rigidity of metallic structural parts, extending the heat exchange area in heat exchangers and changing the flow direction of liquid or gas. The component has at least one fin (1) made of metal strip with any surface shape, with soldering foil material (2) attached to at least one side of the fin (1) and at an angle to the fin (1) surface. Preferably, the component has a pack of fins (1).

Classes IPC  ?

• F28F 3/02 - Éléments ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des évidements, avec des ondulations
• F28F 21/08 - Structure des appareils échangeurs de chaleur caractérisée par l'emploi de matériaux spécifiés de métal
• B23K 1/00 - Brasage ou débrasage
• B23K 35/02 - Baguettes, électrodes, matériaux ou environnements utilisés pour le brasage, le soudage ou le découpage caractérisés par des propriétés mécaniques, p. ex. par la forme

Abrégé

Fired heat exchanger comprising an external jacket (2) in a cylindrical shape, closed on one end with a bottom (9) and on the other with a bottom (10) fitted with a hole. The external jacket (2) houses an internal jacket (1) also of a cylindrical shape, closed on one end like the external jacket (2) with a bottom (11) and on the other with a bottom (12) fitted with a hole. Between the holes in the bottoms (10, 12), a common passage (5) is formed to introduce a burner into the combustion chamber (13) located inside the internal jacket (1). A common outlet hole (14) for exhaust is made in the side wall of the internal jacket (1) and the side wall of the external jacket (2). A sealed heated fluid flow chamber (4) is formed between the internal jacket (1) and external jacket (2). The chamber (4) is equipped with an inlet and outlet stub pipe for fluid.

Classes IPC  ?

• F24H 1/26 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc
• F24H 1/40 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec un ou plusieurs tubes d'eau
• F24H 1/44 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec combinaison de plusieurs types couverts par les groupes

Abrégé

A dual purpose heat exchanger comprises a central heating fluid circuit and hot utility water circuit. The exchanger contains fired or heated by flow of water or steam main heat exchanger and coil (2) enclosed by an external jacket (3) equipped with an inlet stub pipe (6) for fluid heating the utility water in the coil (2) as well as an inlet stub pipe (4) and outlet stub pipe (5) for utility water; however, the flow chamber of fluid heating the utility water in the coil (2) is connected with the flow chamber (8) of heated fluid in the main exchanger. Preferably, the coil (2) is wound on the jacket (1) of the main exchanger, and the flow chamber of fluid heating the utility water in the coil (2) is connected through at least one overflow hole (7) with the flow chamber (8) of heated fluid in the main exchanger.

Classes IPC  ?

• F24H 1/52 - Appareils de chauffage de l'eau pour chauffage central comprenant des moyens pour chauffer l'eau sanitaire comprenant des échangeurs de chaleur pour l'eau sanitaire
• F28F 9/013 - Supports auxiliaires pour les éléments pour les tubes ou les assemblages de tubes
• F28D 7/00 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation
• F28D 7/02 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant enroulées en hélice
• F28D 7/16 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant espacées parallèlement
• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives
• F28F 1/42 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements les moyens étant à la fois à l'extérieur et à l'intérieur de l'élément tubulaire
• F28F 3/04 - Éléments ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des évidements, avec des ondulations les moyens faisant partie intégrante de l'élément

Abrégé

The connection pipe stub for a heat exchanger in the form of a body (KK) fitted with a pipe connection (ZR) of any type on one side, characterised in that its body (KK) has an in-driven end on the side of the assembly opening in the heat exchanger jacket (P).

Classes IPC  ?

• F16L 41/00 - Tuyaux de branchementRaccordements des tuyaux aux parois
• F16L 37/133 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage utilisant des crochets, cliquet, ou autres organes de blocage mobiles ou que l'on peut insérer utilisant des crochets flexibles
• F28F 9/02 - Boîtes de distributionPlaques d'extrémité
• F24D 19/00 - SYSTÈMES DE CHAUFFAGE DE LOCAUX DOMESTIQUES OU D'AUTRES LOCAUX, p. ex. SYSTÈMES DE CHAUFFAGE CENTRALSYSTÈMES D'ALIMENTATION EN EAU CHAUDE À USAGE DOMESTIQUELEURS ÉLÉMENTS OU PARTIES CONSTITUTIVES Détails

Abrégé

The heat exchanger for the condensing boiler fitted with liquid, gas, and fume inlet and outlet stub pipes, having an outer jacket which encases the combustion chamber mounted in the top section thereof, under which a set of vertical pipe elements is fitted, both ends of which are fixed to the sieve walls, where the top sieve wall serves as the bottom of the combustion chamber and where partitions of any desired shape or number may be fitted crosswise in relation to the pipe elements, wherein the combustion chamber (3) is given the shape of a truncated cone with the diameter decreasing towards the top, and the space between the side wall (5) of the combustion chamber (3) and the outer jacket (7), and the space under the combustion chamber (3) where the pipe element set (1) is mounted are mutually connected to form the fluid chamber (10).

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées

Abrégé

The heat exchanger pipe contains the body (2) and the partition (1) dividing it inside into two separate ducts for the flow of the agent. The partition (1) is spiral in shape and preferably is made of a rectangular metal strip curled around its vertical axis of symmetry and connected tight to the pipe body (2) along its whole length. The partition (1) may be of equal length as the pipe body (2) or shorter, where the ratio between the length of lay (2) of the curl of the partition (1) and the inner diameter (d) of the pipe body (2) is no less than ½, preferably ½. Preferably, the pipe is made of stainless steel.

Classes IPC  ?

• F28D 7/02 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant enroulées en hélice
• F28F 1/00 - Éléments tubulairesEnsembles d'éléments tubulaires
• F28D 1/04 - Appareils échangeurs de chaleur comportant des ensembles de canalisations fixes pour une seule des sources de potentiel calorifique, les deux sources étant en contact chacune avec un côté de la paroi de la canalisation, dans lesquels l'autre source de potentiel calorifique est une grande masse de fluide, p. ex. radiateurs domestiques ou de moteur de voiture avec des canalisations d'échange de chaleur immergées dans la masse du fluide avec canalisations tubulaires
• F28D 7/00 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation

Abrégé

The heat exchanger tube set is designed particularly for the fuel heat exchanger. The set comprises two heat exchange zones positioned one after another with respect to the combustion chamber (8), where zone one (1) is formed exclusively of tubes (3), and zone two (2) is composed of tubes (4) and finned elements (5) positioned in between the tubes (4). Preferably, the tubes (3) of zone one (1) are smooth, of any shape in cross-section, and the tubes (4) of zone two (2) are either flat or oval. Preferably, the finned element (5) consists of a band with profiled plates (6).

Classes IPC  ?

• F28D 7/16 - Appareils échangeurs de chaleur comportant des ensembles de canalisations tubulaires fixes pour les deux sources de potentiel calorifique, ces sources étant en contact chacune avec un côté de la paroi d'une canalisation les canalisations étant espacées parallèlement
• F28F 1/02 - Éléments tubulaires de section transversale non circulaire
• F28F 1/12 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements ces moyens étant uniquement à l'extérieur de l'élément tubulaire
• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 1/40 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec un ou plusieurs tubes d'eau

Abrégé

The heat exchanger tube is fitted with a coaxially positioned inner element to increase the heat exchange surface area and/or agitate the agent flowing through, namely a resilient insert (2) formed out of a rectangular plate into a bushing, with three-face fins (3) shaped outwards, triangular in cross-section, with centrally pointing apexes and the opposite sides touching on the inner wall of the tube body (1), where the surface sections (4) between the fins (3) form the inner cylindrical surface of the insert. Preferably, the fins (3) have additional ribbing formed by deflecting notched sections (5) and/or embossing (6).

Classes IPC  ?

• F28F 1/10 - Éléments tubulaires ou leurs ensembles avec moyens pour augmenter la surface de transfert de chaleur, p. ex. avec des ailettes, avec des saillies, avec des évidements
• F28F 9/24 - Dispositions pour favoriser un écoulement turbulent des sources de potentiel calorifique, p. ex. par des plaques

Abrégé

The fired heat exchanger comprising an outer jacket, which encases a set of vertically running pipe elements anchored in the sieve walls on both ends, a gas combustion chamber positioned over the upper sieve wall, and a baffle mounted crosswise to the pipe elements, with openings through which the pipe elements run, plus liquid, gas, and fume inlet and outlet pipe stubs, is characterised in that the upper sieve wall (2) has a central prominence (7) pointing down towards the bottom sieve wall (3), the baffle (5) has a central opening (6) positioned under the prominence (7) of the upper sieve wall (2), and its circumference matches the circumference of the outer jacket (8).

Classes IPC  ?

• F24H 1/28 - Appareils de chauffage de l'eau autres qu'instantanés ou à accumulation, p. ex. chauffe-eau pour chauffage central avec une chemise d'eau entourant la ou les chambres de combustion la chemise d'eau étant monobloc renfermant un ou plusieurs tubes foyers ou de fumées
• F24H 9/00 - APPAREILS DE CHAUFFAGE DE FLUIDES, p. ex. DE L'AIR OU DE L'EAU, COMPORTANT DES MOYENS DE PRODUCTION DE CHALEUR, p. ex. DES POMPES À CHALEUR, EN GÉNÉRAL Parties constitutives

Abrégé

The fastening of the heat exchanger cover is characterised in that grub screws (3) run through notches (8) in the cover (2), arranged around its circumference and extending beyond the outer wall (1) of the heat exchanger, where the grub screws (3) go into threaded openings in the horizontal pegs (4), each peg placed in between a pair of supporting elements (6) fixed on the outer wall (1) of the heat exchanger near the cover.

Classes IPC  ?

• B65D 90/62 - Portes ou fermetures comportant des éléments de fermeture se déplaçant en dehors du plan de l'ouverture
• F28F 9/00 - CartersBoîtes de distributionSupports auxiliaires pour les élémentsÉléments auxiliaires dans les carters
• F28F 9/02 - Boîtes de distributionPlaques d'extrémité
• F28F 9/26 - Dispositions pour raccorder des sections différentes des éléments d'échangeurs de chaleur, p. ex. de radiateur

Abrégé

A heat exchanger comprising an outer jacket (9) with an inner set of vertical pipe elements (1) fastened at their opposing ends in upper and lower sieve walls (2, 3), and having a gas combustion chamber (4) located above the upper sieve wall, as well as partitions (5, 6, 7) mounted crosswise of the pipe elements. The partitions have openings for the pipe elements. The heat exchanger is also provided with liquid, gas and exhaust fumes inlet and outlet stub pipes. The outer jacket is conically shape with its diameter increasing upwards. An upper sieve wall (2), as well as an upper partition (5) situated below the wall, are shaped as cones with their vertexes pointing down. The upper partition (5) has a central opening (8) in its central region and an outer diameter corresponding to a diameter of the outer jacket (9).

Classes IPC  ?
