In a method for determining whether a machine tool with a numerical control system for machining a workpiece has warmed up, axis data are obtained which relate to a position of a tool of the machine tool. An indication value is calculated therefrom. It is then determined whether the indication value reaches a predefined threshold value. Furthermore, it is determined whether the machine tool has warmed up, wherein reaching the indication value of the threshold value indicates that the machine tool has warmed up. A method and a machine tool machines workpieces, a computer program product instructs the machine tool, a computer-readable medium stores the computer program product, and a method machines workpieces by the machine tool.
B23Q 15/20 - Commande automatique ou régulation du mouvement d'avance, de la vitesse de coupe ou de la position tant de l'outil que de la pièce avant ou après l'action de l'outil sur la pièce
The invention relates to a machine tool (1) comprising: - a machine frame (6); a first work spindle (7), which is mounted rotatably about a first spindle axis (11); - a second work spindle (8), which is mounted rotatably about a second spindle axis (12); - a workpiece clamping device (19) having a first workpiece receiving space (22), which is designed to receive at least one first workpiece (2), and a second workpiece receiving space (23), which is designed to receive a second workpiece (3), wherein the workpiece clamping device (19) comprises a swivelling bridge (20), which is mounted such that it can swivel about a swivel axis (21). The swivelling bridge (20) is designed in the form of a frame structure. The first workpiece receiving space (22) is located on a first workpiece table (34). The second workpiece receiving space (23) is located on a second workpiece table (38).
B23Q 1/48 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en translation et des guidages en rotation
B23Q 1/54 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec deux guidages en rotation uniquement
B23Q 39/02 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant susceptibles d'être mis en fonctionnement à un seul poste de travail
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
3.
SLAT JOINING DEVICE FOR CONNECTING INDIVIDUAL SLATS TO FORM A SLAT MAT, AND METHOD FOR PRODUCING A COMPOSITE COMPONENT HAVING INDIVIDUAL SLATS
The invention relates to a slat joining device (1) for connecting individual slats (2, 3, 4) to form a slat mat (5), the slat joining device (1) comprising: - a slat feed (14) for feeding the individual slats (2, 3, 4); - an adhesive application device (15) for applying adhesive (16) to at least one narrow face (6, 7, 10, 11) of the slats (2, 3, 4) which are to be connected to one another; - a pressing region (20) for pressing a first slat (2) and a second slat (3) against one another in a conveying direction (17). The adhesive application device (15) comprises at least a first adhesive nozzle (21) and a second adhesive nozzle (22), the first adhesive nozzle (21) and the second adhesive nozzle (22) being spaced apart from one another at a longitudinal distance (24) with respect to a slat longitudinal direction (19), and the first adhesive nozzle (21) and the second adhesive nozzle (22) being movable in the slat longitudinal direction (19) relative to the slat (2, 3, 4) to be provided with adhesive (16).
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machines for metal working and machine tools; metalworking
machines; none of the aforesaid goods being filling and
sealing machines or parts thereof; casting machines for
vacuum dosing, holding, manipulating and dosing of cast
aluminium and filling of casting moulds. Metal treating; woodworking; custom assembling of materials
for others; all the aforesaid services, not in relation to
the following goods: filling and sealing machines, related
parts; metal casting. Industrial analysis and research services; design and
development of computer hardware and software; engineering
services; preparation of engineering drawings; conducting
technical project studies; the aforesaid services, not in
relation to the following goods: filling and sealing
machines, related parts; scientific and technological
services and research and design relating thereto, in
relation to the following goods: casting machines for vacuum
dosing, holding, manipulating and dosing of cast aluminium
and filling of casting moulds.
5.
MACHINE TOOL AND METHOD FOR OPERATING A MACHINE TOOL
A machine tool includes a base frame, a work spindle for receiving a tool, and a swivelling bridge for receiving a workpiece, wherein the swivelling bridge is configured such that it can swivel about a swivel axis, and wherein the swivelling bridge is received such that it can swivel on a first swivel bearing and a second swivel bearing. A workpiece holder for directly or indirectly receiving the workpiece is provided on the swivelling bridge, wherein the workpiece holder is arranged between the first swivel bearing and the second swiven bearing. The movements of the machine tool are controlled by a digital computer. A deflection compensation device for compensating for tilting of the workpiece due to deflection of the swivelling bridge is provided on the swivelling bridge.
B23Q 1/25 - Supports mobiles ou réglables d'outils ou de pièces
B23Q 11/00 - Accessoires montés sur les machines-outils pour maintenir les outils ou les organes de la machine dans de bonnes conditions de travail ou pour refroidir les pièces travailléesDispositifs de sécurité spécialement combinés aux machines-outils, disposés dans ces machines ou spécialement conçus pour être utilisés en relation avec ces machines
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
6.
MACHINE TOOL AND METHOD FOR OPERATING THE MACHINE TOOL
The invention relates to a machine tool (1) comprising: - a machine frame (2); - at least one first working spindle (3), which is rotatably mounted about a first spindle axis (4); - a workpiece clamping device (23), which is designed to receive at least one first workpiece (9); and - a machine controller (37). The machine tool is characterized in that the workpiece clamping device (23) comprises a first workpiece table (24), the first workpiece table (24) being pivotally mounted about a first workpiece table pivot axis (25) which is oriented parallel to a horizontal X axis (6), and in that a first rotary table (26) is provided on the first workpiece table (24) and is pivotally mounted about a first rotary table pivot axis (27) on the first workpiece table (24).
B23Q 1/52 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec un seul guidage en rotation
B23Q 1/54 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec deux guidages en rotation uniquement
B23Q 1/66 - Tables de travail pouvant être interchangées pour être mises en position de travail
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
B23Q 39/02 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant susceptibles d'être mis en fonctionnement à un seul poste de travail
B23Q 5/02 - Entraînement des principaux organes de travail
The invention relates to a machine tool (1) comprising: - a machine frame (3); - at least one working spindle (4) which is mounted so as to be rotatable about a spindle axis (5); - a workpiece clamping device (10), the workpiece clamping device (10) comprising a workpiece table (11) which is designed to receive at least one workpiece (2), a first pivot bearing (13) and a second pivot bearing (14) being formed, by means of which the workpiece table (11) is mounted so as to be pivotable about a workpiece table pivot axis (12), the workpiece table (11) comprising a crossmember (16) which is arranged parallel to the workpiece table pivot axis (12), the workpiece table (11) comprising a first limb (17) by means of which the crossmember (16) is coupled to the first pivot bearing (13), and the workpiece table (11) comprising a second limb (18) by means of which the crossmember (16) is coupled to the second pivot bearing (14); - a machine controller (21). A workpiece distance (22) of the workpiece (2) from the workpiece table pivot axis (12) is adjustable.
B23Q 1/48 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en translation et des guidages en rotation
B23Q 1/52 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec un seul guidage en rotation
B23Q 1/54 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec deux guidages en rotation uniquement
B23Q 1/56 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en translation uniquement
The invention relates to an actuating device (1) for casting molds (2), comprising a pressing element (3) and a first actuating element (4) and a second actuating element (5) which is mounted movably relative to the first actuating element (4) in an actuating direction (6) and is coupled to the pressing element (3). The actuating device (1) also comprises a guide sleeve (7) which is movable, together with the second actuating element (5), in the actuating direction (6), the guide sleeve (7) being mounted on the outside of the first actuating element (4), so that the guide sleeve (7) can be guided over the first actuating element (4) during movement in the actuating direction (6).
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Educational mobile applications; Educational tablet applications; Downloadable application software for virtual environments; Virtual assistant software; downloadable virtual goods, namely Virtual trade fair stands, virtual land, virtual buildings, Virtual sales stations, virtual stores, virtual warehouses, virtual money. Conducting virtual trade show exhibitions online; Sales promotion in virtual environments; Promotion in virtual environments; Marketing in virtual environments; Business consultancy services in virtual environments; Career planning consultancy in virtual environments; Marketing through product placement for others in virtual environments. Arranging and conducting of commercial, trade and business conferences; Arranging and conducting of seminars and workshops; Provision of training courses; Provision of training courses; Provision of training courses; Arranging of classes; Arranging of training courses; Conducting guided tours; Arranging of displays for cultural purposes; Arranging and conducting of games; Provision of online information relating to audio and visual media; Digital video, audio and multimedia entertainment publishing services; Training and further training consultancy; Courses (Training -) relating to research and development; Development of educational courses and examinations; Arranging guides in virtual environments; Arranging of classes In a virtual environment; Seminars In a virtual environment; Arranging of economic, trade and business conferences In a virtual environment; organizing exhibitions In a virtual environment; Arranging and conducting of games In a virtual environment; Training and further training consultancy In a virtual environment. Industrial analysis and research services; Construction drafting; Conducting technical project studies; Scientific services; Technological planning services; Technological research; Technological consultancy; Scientific and technological design; Research relating to mechanical engineering; Engineering services for the analysis of machinery; Engineering services for the design of machinery; Mechanical research; Design services; Computer hardware development.
The invention relates to a machine tool (1) comprising: - a machine frame (4); - a first work spindle (5); - a second work spindle (6); and - a workpiece clamping device (38) having a first workpiece receiving space (59), which is designed to receive at least one first workpiece (2). The first work spindle (5) can be moved along the X-axis (10) by means of a first X-axis adjustment unit (17), and the second work spindle (6) can be moved along the X-axis (10) by means of a second X-axis adjustment unit (18). The first work spindle (5) can be moved along the Z-axis (9) by means of a first Z-axis adjustment unit (25); the second work spindle (6) can be moved along the Z-axis (9) by means of a second Z-axis adjustment unit (26), said first work spindle (5) and second work spindle (6) being movable independently of one another along the Z-axis (9); and the first workpiece receiving space (59) can be moved along a vertical Y-axis (11) by means of a Y-axis adjustment unit (58).
B23Q 1/48 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en translation et des guidages en rotation
B23Q 1/52 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec un seul guidage en rotation
B23Q 1/62 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en translation uniquement avec deux guidages en translation uniquement à axes perpendiculaires, p. ex. chariots à mouvements transversaux
B23Q 39/02 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant susceptibles d'être mis en fonctionnement à un seul poste de travail
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
B23Q 39/00 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal
11.
MACHINE TOOL AND METHOD FOR OPERATING THE MACHINE TOOL
The invention relates to a machine tool (1) comprising: a machine frame (4); at least one first working spindle (5) which is rotatably mounted about a first spindle axis (7), said first spindle axis (7) being parallel to a horizontal Z-axis (9); a workpiece clamping device (38) which is designed to receive at least one first workpiece (2); and a tool magazine (62) which is intended for storing different machining tools (16) and in which at least one storage plane (63) with a plurality of tool receiving spaces (65, 64) arranged next to one another is provided. The tool receiving spaces (64, 65) are oriented parallel to the horizontal Z-axis (9), the machining tools (16) can be received in the tool magazine (62) in an orientation parallel to the horizontal Z-axis (9), and the individual tool receiving spaces (64, 65) are arranged next to one another and spaced apart from one another in a horizontal X-axis (10).
A melt transport device includes a melt container, in which a melt receiving space is formed, and a spout, which is coupled to the melt container, wherein the spout includes a spout orifice which is flow-connected to the melt receiving space. Moreover, a gas valve is formed, which is flow-connected to the melt receiving space and which is configured for regulating the introduction of gas into the melt receiving space.
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
B22D 35/04 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules aux moules, p. ex. plaques de base, chenaux de coulée
B22D 41/16 - Fermetures du type quenouilles de coulée, c.-à-d. la tige de fermeture étant mise en place vers le bas à travers le récipient et le métal qu'il contient, pour faire varier la section de passage du métal dans l'ouverture de coulée
13.
PRODUCTION PLANT AND METHOD FOR PRODUCING A SKI EDGE
The invention relates to a production plant (1) and to a method for producing a ski edge (2), comprising a control device (3), an unwinding device (4) for providing a ski edge blank (5), and an advancing device (6) for conveying the ski edge blank (5) in a transport direction (7). The production plant further comprises a cutting device (8) for cutting the provided ski edge blank (5) to a predetermined length (10) with respect to a longitudinal extent (9), and a deformation device (11) by means of which the ski edge blank (5) can be deformed transversely to the transport direction (7). The invention further relates to a computer-implemented method for providing parameters to a production plant (1), and to a computer program product for managing and providing ski edge data.
A63C 5/12 - Skis ou surfs des neiges leur fabricationSélection de matériaux particuliers
A63C 11/06 - Accessoires pour pratiquer le ski ou le surf des neiges pour l'entretien des skis ou des surfs des neiges pour affûter les carres
B21B 1/16 - Méthodes de laminage ou laminoirs pour la fabrication des produits semi-finis de section pleine ou de profilésSéquence des opérations dans les trains de laminoirsInstallation d'une usine de laminage, p. ex. groupement de cagesSuccession des passes ou des alternances de passes pour laminer du fil métallique ou un matériau semblable de petite section
B21D 7/06 - Cintrage des barres, profilés ou tubes dans des presses particulières ou entre des marteaux et des enclumes ou des butéesPinces comportant des matrices de formage
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machines for metal working and machine tools; metalworking machines; none of the aforesaid goods being filling and sealing machines or parts thereof; casting machines for vacuum dosing, holding, manipulating and dosing of cast aluminium and filling of casting moulds. Metal treating; woodworking; custom assembling of materials for others; all the aforesaid services, not in relation to the following goods: filling and sealing machines, related parts; metal casting. Industrial analysis and research services; design and development of computer hardware and software; engineering services; preparation of engineering drawings; conducting technical project studies; the aforesaid services, not in relation to the following goods: filling and sealing machines, related parts; scientific and technological services and research and design relating thereto, in relation to the following goods: casting machines for vacuum dosing, holding, manipulating and dosing of cast aluminium and filling of casting moulds.
15.
MACHINE TOOL AND METHOD FOR OPERATING THE MACHINE TOOL
The invention relates to a machine tool (1) having: a machine frame (2) in which a loading space (45) and a machining space (44) are formed; a first working spindle (5) which is mounted for rotation about a first spindle axis (7), said first working spindle (5) being accommodated on the machine frame (2) so as to be displaceable along a horizontal Z axis (9), along a horizontal X axis (10) and along a vertical Y axis (11); and a workpiece clamping device (18) which is designed to receive at least a first workpiece (25) and a second workpiece (31). Furthermore, a second working spindle (6) is provided which is mounted for rotation about a second spindle axis (8). The first working spindle (5) and the second working spindle (6) are arranged vertically one above the other, wherein the first working spindle (5) is designed to machine the first workpiece (25), and the second working spindle (6) is designed to machine the second workpiece (31).
B23Q 1/66 - Tables de travail pouvant être interchangées pour être mises en position de travail
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
B23Q 3/157 - Agencements pour insérer ou retirer automatiquement les outils les outils rotatifs
B23Q 39/00 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal
16.
MACHINE TOOL AND METHOD FOR OPERATING THE MACHINE TOOL
The invention relates to a machine tool (1) comprising: a machine frame (2); at least one first working spindle (3); at least one second working spindle (4); and a workpiece clamping device (15) having a first workpiece table (16) and a second workpiece table (19). The workpiece clamping device (15) is designed in such a way that - the first workpiece (18) and the second workpiece (21) can be milled in a milling operating mode, and - the first workpiece (18) and the second workpiece (21) can be turned in a turning operating mode.
B23Q 39/00 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal
B23Q 1/54 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en rotation uniquement avec deux guidages en rotation uniquement
B23B 3/06 - Machines ou dispositifs à tourner caractérisés uniquement par l'agencement particulier des éléments de structure
The invention relates to an attachment (5) for a self-propelled working machine (2), in particular a telescopic loader, the attachment (5) comprising: - a coupling frame (8), wherein the coupling frame (8) is designed for detachable coupling to the interchangeable receptacle (4) of the self-propelled working machine (2); - a holding arm (9) which is arranged on the coupling frame (8); a spectacle lift (10) which is pivotally accommodated on the holding arm (9), wherein the spectacle lift (10) has a first wheel receptacle (12) and a second wheel receptacle (13) for receiving the two front wheels (25) or the two rear wheels (26) of a vehicle (24) to be towed.
The invention relates to a test device (1) for a non-destructive material test, comprising: - a base (2) having a coupling (4) for connecting to a robot (5); - a first test head (6) which is coupled by means of a first test head carrier (7) to the base (2) in a manner displaceable relative to the base (2); - a second test head (8) which is coupled by means of a second test head carrier (9) to the base in a manner displaceable relative to the base (2), wherein the first test head (6) and the second test head (8) are arranged one behind the other in a longitudinal extension direction (3) of the base (2) and the first test head (6) and the second test head (8) are shaped differently to one another, wherein the test heads (6, 8) have a first test direction (12) which lies parallel to the longitudinal extension direction (3) of the base (2).
G01N 29/22 - Recherche ou analyse des matériaux par l'emploi d'ondes ultrasonores, sonores ou infrasonoresVisualisation de l'intérieur d'objets par transmission d'ondes ultrasonores ou sonores à travers l'objet Détails
G01N 29/265 - Dispositions pour l'orientation ou le balayage en déplaçant le capteur par rapport à un matériau fixe
19.
METHOD FOR THE NON-DESTRUCTIVE TESTING OF A COMPONENT, AND ULTRASONIC TEST SYSTEM FOR THE NON-DESTRUCTIVE TESTING OF THE COMPONENT
The invention relates to a method for the non-destructive testing of a component (2), comprising the method steps of: - providing an ultrasonic test system (1) with an ultrasonic test head (3) and with a handling device (6) for moving the ultrasonic test head (3) and a digital computer (7), wherein the digital computer (7) is coupled to the handling device (6), the handling device comprising (6): - a base (8); - a carousel (11); - a rocker (13); - an arm (15); - a hand (17); - a finger (19); - a test head carrier (21); - providing a digital computer (7), wherein the digital computer (7) is coupled to the ultrasonic test system (1) and is used to control the ultrasonic test system (1); - providing the component (2) to be tested using the ultrasonic test system (1); - testing the component (2) by means of the ultrasonic test system (1), wherein the ultrasonic test head (3) is moved relative to the component (2) during the testing process, wherein the movement of the ultrasonic test head (3) is controlled by the digital computer (7).
G01N 29/22 - Recherche ou analyse des matériaux par l'emploi d'ondes ultrasonores, sonores ou infrasonoresVisualisation de l'intérieur d'objets par transmission d'ondes ultrasonores ou sonores à travers l'objet Détails
G01N 29/265 - Dispositions pour l'orientation ou le balayage en déplaçant le capteur par rapport à un matériau fixe
G01N 29/28 - Recherche ou analyse des matériaux par l'emploi d'ondes ultrasonores, sonores ou infrasonoresVisualisation de l'intérieur d'objets par transmission d'ondes ultrasonores ou sonores à travers l'objet Détails pour établir le couplage acoustique
A computer-implemented method for optimizing a numerical control of a machine tool having a tool for machining a workpiece may include obtaining numerical tool information with respect to a machining. The method may further include acquiring, by a trained neural network, timing information based on the obtained tool information and generating a set of path information for machining from the timing information and the tool information. The set of path information may include a travel path of the tool, which may include an approach, tool entry, working, and tool exit phase, and a distance between the tool and the workpiece before the approach phase. The method may include determining a minimum distance between the tool and the workpiece before the approach phase from a plurality of sets of path information of a plurality of previous machinings for a next machining.
G05B 19/4093 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par la programmation de pièce, p. ex. introduction d'une information géométrique dérivée d'un dessin technique, combinaison de cette information avec l'information d'usinage et de matériau pour obtenir une information de commande, appelée programme de pièce, pour la machine à commande numérique [CN]
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
25 - Vêtements; chaussures; chapellerie
28 - Jeux, jouets, articles de sport
41 - Éducation, divertissements, activités sportives et culturelles
Produits et services
Electrical equipment for recording, transmission or reproduction of sound or images; Data carriers, in particular CD-ROMs, floppy disks, magnetic tapes and digital memory components with computer programs, being data carrier components; Computer software, particularly computer software for playing games; Game programs for computers, computer games; Application software; Application development software; Web application software; Application software for mobile phones; Educational mobile applications; Educational tablet applications; Application software for wireless devices; Downloadable application software for smartphones; Application software for mobile devices. Books; Printed books, magazines, newspapers, and other paper-based media; Educational equipment; Manuals for instructional purposes; Educational and instructional material; Printed matter, and stationery and educational supplies; Educational publications. Clothing; Headgear; Footwear. Games; Toys; Toys; Electronic games; Gymnastic and sporting articles not included in other classes. Educational instruction; Training; Entertainment services; Sporting and cultural activities; Organization of exhibitions for cultural or educational purposes; Provision of club entertainment services; Sports facilities and amusement parks; Discotheque services; Holiday camp services [entertainment]; Providing recreation facilities; Gambling; Providing golf facilities; Arranging and conducting of colloquiums; Arranging and conducting of conferences and congresses; Presentation of live performances; Entertainment in the nature of orchestra performances; Arranging and conducting of symposiums; Providing casino facilities [gambling]; Rental of sports equipment, except vehicles; Sport camp services; Organization of sports competitions; Provision of training courses; Provision of training courses; Provision of training courses; Provision of training courses; Organisation of tournaments; Organization of sports competitions; Conducting of educational events; Conducting instructional courses; Arranging and conducting of commercial, trade and business conferences; Arranging and conducting of seminars and workshops; Arranging of classes; Arranging of entertainment shows; Arranging of training courses; Arranging of courses of instruction; Presentation of musical concerts; Arranging of lectures; Organisation of shows; Organisation of training courses; Art exhibition services; Conducting guided tours; Provision of training courses; Provision of training courses; Arranging of displays for cultural purposes; Arranging of competitions for education or entertainment; Organization of exhibitions for cultural or educational purposes; Provision of training courses; Arranging and conducting of games; Arranging, conducting and organisation of seminars; Arranging, conducting and organisation of concerts; Arranging, conducting and organisation of symposiums; Vocational guidance [education or training advice]; Computerised training in career counselling; Vocational testing; Vocational training services in the following fields: Machinery construction, Mechatronics, Installation construction and Automation technology; Training in the following fields: Machinery construction, Mechatronics, Installation construction and Automation technology; Provision of training courses for young people in preparation for careers.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
25 - Vêtements; chaussures; chapellerie
28 - Jeux, jouets, articles de sport
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Electrical equipment for recording, transmission or reproduction of sound or images; Data carriers, in particular CD-ROMs, floppy disks, magnetic tapes and digital memory components with computer programs, being data carrier components; Computer software, particularly computer software for playing games; Game programs for computers, computer games; Application software; Application development software; Web application software; Application software for mobile phones; Educational mobile applications; Educational tablet applications; Application software for wireless devices; Downloadable application software for smartphones; Application software for mobile devices; Laboratory apparatus and instruments; Laboratory instruments [other than for medical use]. Books; Printed books, magazines, newspapers, and other paper-based media; Educational equipment; Manuals for instructional purposes; Educational and instructional material; Printed matter, and stationery and educational supplies; Educational publications. Clothing; Headgear; Footwear. Games and playthings; Toys; Electronic games; Gymnastic and sporting articles not included in other classes. Educational instruction; Training; Entertainment services; Sporting and cultural activities; Organization of exhibitions for cultural or educational purposes; Provision of club entertainment services; Sports facilities and amusement parks; Discotheque services; Holiday camp services [entertainment]; Providing recreation facilities; Gambling; Providing golf facilities; Arranging and conducting of colloquiums; Arranging and conducting of conferences and congresses; Presentation of live performances; Entertainment in the nature of orchestra performances; Arranging and conducting of symposiums; Providing casino facilities [gambling]; Rental of sports equipment, except vehicles; Sport camp services; Organization of sports competitions; Provision of training courses; Provision of training courses; Provision of training courses; Provision of training courses; Organisation of tournaments; Organization of sports competitions; Conducting of educational events; Conducting instructional courses; Arranging and conducting of commercial, trade and business conferences; Arranging and conducting of seminars and workshops; Arranging of classes; Arranging of entertainment shows; Arranging of training courses; Arranging of courses of instruction; Presentation of musical concerts; Arranging of lectures; Organisation of shows; Organisation of training courses; Art exhibition services; Conducting guided tours; Provision of training courses; Provision of training courses; Arranging of displays for cultural purposes; Arranging of competitions for education or entertainment; Organization of exhibitions for cultural or educational purposes; Provision of training courses; Arranging and conducting of games; Arranging, conducting and organisation of seminars; Arranging, conducting and organisation of concerts; Arranging, conducting and organisation of symposiums; Vocational guidance [education or training advice]; Computerised training in career counselling; Vocational testing; Vocational education in the field of mechanics; Provision of training courses for young people in preparation for careers. Research laboratories; Biological laboratory services; Laboratory services; Laboratory services for biomanufacturing; Research services in the field of bionics; Technological services in the field of bionics; Scientific services in the field of bionics.
The invention relates to a method for producing a cast part, comprising the method steps: - providing a casting mold (11) having a sprue (28) and a mold cavity (29); - providing a melt container (3) in which a melt-receiving chamber (4) is formed, wherein the melt container (3) has a nozzle (17) which is in the form of a lance (5) located at the bottom of the melt container (3) and has a nozzle opening (6); - filling the melt container (3) with melt (2); - casting the cast part using melt (2) from the melt container (3), wherein the melt (2) accommodated in the melt-receiving chamber (4) is introduced into the sprue (28) of the casting mold (11) through the nozzle opening (6) in the lance (5), and wherein the casting mold (11) is pivoted towards the sprue (28) at a mold-pivoting angle (34) of greater than 0° at least at one point in time during the casting process, so that at least a portion of the sprue (28) is located lower than the mold cavity (29).
B22D 1/00 - Traitement des métaux en fusion dans la poche ou dans les chenaux de coulée avant le moulage
B22D 35/04 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules aux moules, p. ex. plaques de base, chenaux de coulée
24.
MACHINE TOOL AND METHOD FOR OPERATING THE MACHINE TOOL
A machine tool includes: a machine frame; at least a first working spindle which is pivoted about a first spindle axis; at least a second working spindle which is pivoted about a second spindle axis; a workpiece clamping device which is configured to receive at least a first workpiece and a second workpiece. The first working spindle and the second working spindle are arranged vertically one above the other.
In an expanding device for expanding an expandable particle foam material with an expansion furnace which has an interior space for receiving the expandable particle foam material, a radiator is formed which is arranged in the interior space of the expansion furnace, and a conveying device with a conveying surface is formed, which serves to guide a particle foam material received on the conveying surface in a conveying direction through the interior space of the expansion furnace.
B29C 44/34 - Éléments constitutifs, détails ou accessoiresOpérations auxiliaires
B29C 44/54 - Alimentation en matière à mouler dans une cavité de moulage ouverte ou sur une surface mobile, c.-à-d. pour la fabrication d'objets de longueur indéfinie sous forme de particules ou de grains expansibles
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machines for metal working and machine tools; Foundry machines; Metalworking machines. Metal treating; Woodworking; Custom assembling of materials for others; Metal casting. Scientific and technological services and research and design relating thereto; Industrial analysis and research services; Design and development of computer hardware and software; Engineering services; Engineering drawings; Conducting technical project studies.
A method and a device for measuring a physical object, wherein image data of uniquely identifiable points on the object is captured from different perspectives by means of at least one camera, and a spatial position of the uniquely identifiable points are ascertained from this image data, and at least one three-dimensional point cloud of the uniquely identifiable points is created as a global map of the object. To detect a surface quality of the object, light beam bundles are reflected on a surface of the object and are captured as image data. The image data obtained from the light beam bundles reflected on the surface of the object comprises at least some of the uniquely identifiable points as well as surface regions located between the uniquely identifiable points.
G01B 11/25 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer des contours ou des courbes en projetant un motif, p. ex. des franges de moiré, sur l'objet
G01N 35/00 - Analyse automatique non limitée à des procédés ou à des matériaux spécifiés dans un seul des groupes Manipulation de matériaux à cet effet
G06T 7/521 - Récupération de la profondeur ou de la forme à partir de la télémétrie laser, p. ex. par interférométrieRécupération de la profondeur ou de la forme à partir de la projection de lumière structurée
G06T 7/586 - Récupération de la profondeur ou de la forme à partir de plusieurs images à partir de plusieurs sources de lumière, p. ex. stéréophotométrie
G06T 7/73 - Détermination de la position ou de l'orientation des objets ou des caméras utilisant des procédés basés sur les caractéristiques
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machines for metal working and machine tools; Foundry machines; Metalworking machines; Handling apparatus for loading and unloading. Metal treating; Woodworking; Custom assembling of materials for others; Metal casting. Scientific and technological services and research and design relating thereto; Industrial analysis and research services; Design and development of computer hardware and software; Engineering services; Engineering drawings; Conducting technical project studies.
29.
METHOD FOR DETERMINING WHETHER A MACHINE TOOL HAS WARMED UP, MACHINE TOOL AND METHOD FOR MACHINING WORKPIECES
The invention relates to a method for determining whether a machine tool having a numerical controller for machining a workpiece has warmed up. Axis data are obtained that relate to a position of a tool of the machine tool. An indication value is computed therefrom. It is then determined whether the indication value reaches a predefined threshold value. Furthermore, it is determined whether the machine tool has warmed up, the indication value's reaching of the threshold value indicating that the machine tool has warmed up. A method and a machine tool for machining workpieces, a computer program product, a computer-readable medium and a method for machining workpieces are provided.
G05B 19/404 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par des dispositions de commande pour la compensation, p. ex. pour le jeu, le dépassement, le décalage d'outil, l'usure d'outil, la température, les erreurs de construction de la machine, la charge, l'inertie
B23Q 11/00 - Accessoires montés sur les machines-outils pour maintenir les outils ou les organes de la machine dans de bonnes conditions de travail ou pour refroidir les pièces travailléesDispositifs de sécurité spécialement combinés aux machines-outils, disposés dans ces machines ou spécialement conçus pour être utilisés en relation avec ces machines
The invention relates to a machine tool (1) comprising: - a base frame (2); - a work spindle (4) for receiving a tool (5); - a swivelling bridge (7) for receiving a workpiece (8, 9), wherein the swivelling bridge (7) is configured such that it can swivel about a swivel axis (10), wherein the swivelling bridge (7) is received such that it can swivel on a first swivel bearing (11) and a second swivel bearing (12), wherein a workpiece holder (13, 14) for directly or indirectly receiving the workpiece (8, 9) is provided on the swivelling bridge (7), wherein the workpiece holder (13, 14) is arranged between the first swivel bearing (11) and the second swivel bearing (12); - a digital computer (27) for controlling the movements of the machining tool (1). A deflection compensation device (28) for compensating for tilting of the workpiece (8, 9) due to deflection of the swivelling bridge (7) is provided on the swivelling bridge (7).
B23Q 11/00 - Accessoires montés sur les machines-outils pour maintenir les outils ou les organes de la machine dans de bonnes conditions de travail ou pour refroidir les pièces travailléesDispositifs de sécurité spécialement combinés aux machines-outils, disposés dans ces machines ou spécialement conçus pour être utilisés en relation avec ces machines
31.
MELT TRANSPORT DEVICE WITH A MELT CONTAINER AND A PLUG
The invention relates to a lance (5) for a melt transport device (1). The lance (5) comprises: a connection end (20) for connecting to the melt transport device (1); a siphon (10); and a tubular flow connection section (21) extending between the connection end (20) and the siphon (10) and forming a flow connection channel (22) between the connection end (20) and the siphon (10). The lance (5) has a main part (26) and a siphon cap (27), wherein the main part (26) and the siphon cap (27) are each independent components, which are coupled to one another, wherein the siphon (10) is formed via cooperation of the main part (26) and the siphon cap (27).
The invention relates to a lance (5) for a melt transport device (1). The lance (5) comprises: a connection end (20) for connecting to the melt transport device (1); a siphon (10); and a tubular flow connection section (21) extending between the connection end (20) and the siphon (10) and forming a flow connection channel (22) between the connection end (20) and the siphon (10). The lance (5) has a main part (26) and a siphon cap (27), wherein the main part (26) and the siphon cap (27) are each independent components, which are coupled to one another, wherein the siphon (10) is formed via cooperation of the main part (26) and the siphon cap (27).
B22D 41/16 - Fermetures du type quenouilles de coulée, c.-à-d. la tige de fermeture étant mise en place vers le bas à travers le récipient et le métal qu'il contient, pour faire varier la section de passage du métal dans l'ouverture de coulée
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machines for metal working and machine tools; Metalworking machines; None of the aforesaid goods being filling and sealing machines or parts thereof; Casting machines for vacuum dosing, holding, manipulating and dosing of cast aluminium and filling of casting moulds. Metal treating; Woodworking; Custom assembling of materials for others; all the aforesaid services, not in relation to the following goods: Filling and sealing machines, related parts; Metal casting. Industrial analysis and research services; Design and development of computer hardware and software; Engineering services; Engineering drawings; Conducting technical project studies; The aforesaid services, not in relation to the following goods: Filling and sealing machines, related parts; Scientific and technological services and research and design relating thereto, in relation to the following goods: Casting machines for vacuum dosing, holding, manipulating and dosing of cast aluminium and filling of casting moulds.
The invention relates to a method for optimising numeric control of a machine tool having a tool for machining a workpiece. Numeric tool information relating to machining is received. Then, time information is determined by means of a trained neural network based on the received tool information. From the determined points in time and tool information, a set of path information is generated for machining, and a minimum distance of the tool to the workpiece before the approach phase is ascertained for the next machining operation from several sets of path information from several previous machining operations. Provided are a method for optimising numeric control of a machine tool and a device for carrying out the method, a machine tool for machining workpieces by carrying out the method, a computer program product, a computer-readable medium, a method for machining workpieces, a method for training a neural network, and the data structure of a trained neural network.
G05B 13/02 - Systèmes de commande adaptatifs, c.-à-d. systèmes se réglant eux-mêmes automatiquement pour obtenir un rendement optimal suivant un critère prédéterminé électriques
G05B 19/18 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique
G05B 19/416 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par la commande de vitesse, d'accélération ou de décélération
35.
COMPUTER-IMPLEMENTED METHOD FOR MACHINING A WORKPIECE ON A MACHINE TOOL, MACHINE TOOL, COMPUTER PROGRAM PRODUCT, AND COMPUTER-READABLE MEDIUM
The invention relates to a computer-implemented method for machining a workpiece (9) on a machine tool (1) using a tool (6) which is received in a work spindle (4). The method has the steps of: - carrying out control commands of a computing unit (20) in order to move the tool (6) and/or the workpiece (9) and in order to bring the tool (6) into engagement with the workpiece (9) for machining purposes, said control commands being configured so as to machine the workpiece (9) at a machining depth (25) relative to a target outer contour (23) which is specified on the basis of a CAD model of the workpiece (9); - automatically detecting when the tool (6) engages with an actual outer contour (24) of the real workpiece (9), wherein a detection criterion is requested; and - automatically adapting the control commands in the computing unit (20) in order to offset the machining depth (25) ascertained on the basis of the target outer contour (23) of the workpiece (9) with respect to the detected actual outer contour (24) of the workpiece (9).
G05B 19/18 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique
B23Q 17/22 - Agencements sur les machines-outils pour indiquer ou mesurer pour indiquer ou mesurer la position réelle ou désirée de l'outil ou de la pièce
The invention relates to a melt transportation device (1) comprising a melt container (3) in which a melt-receiving space (4) is formed and an outlet (5) which is coupled to the melt container (3), wherein the outlet (5) has an outlet opening (6) which is fluidically connected to the melt-receiving space (4). A gas valve (7) is also provided, which is fluidically connected to the melt-receiving space (4) and which is designed for controlling the entry of gas into the melt-receiving space (4).
B22D 35/00 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules
B22D 35/04 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules aux moules, p. ex. plaques de base, chenaux de coulée
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
B22D 41/16 - Fermetures du type quenouilles de coulée, c.-à-d. la tige de fermeture étant mise en place vers le bas à travers le récipient et le métal qu'il contient, pour faire varier la section de passage du métal dans l'ouverture de coulée
37.
PREHEATING STATION FOR PREHEATING A MELT TRANSPORTATION DEVICE
The invention relates to a preheating station (12) for preheating a melt transportation device (1), said preheating station (12) comprising: a base assembly (13); a flow channel (14) for transporting an air volume, wherein the flow channel (14) is arranged on the base assembly (13); a coupling (16) for coupling the melt transportation device (1) to the base assembly (13), wherein the coupling (16) is designed for producing a fluidic connection between the flow channel (14) and the melt transportation device (1); an air heater (20) for heating the air volume, wherein the air heater (20) is coupled to the flow channel (14); a fan (21) for conveying the air volume in the flow channel (14) in a flow direction (22).
A method for casting a melt uses a melt container in which a melt receiving space is formed. The melt container has a spout in the form of a lance on the bottom on the melt container. The method includes the following steps: filling the melt container with melt, wherein the melt is introduced into the melt receiving space of the melt container from a crucible using a spout orifice of the lance; casting at least one cast workpiece with melt; filling the melt container with melt again. When filling the melt container with melt, more melt is received in the melt receiving space than is needed for casting the cast workpiece. Directly before the renewed filling of the melt container, a remainder of melt having an oxide skin formed at the melt surface is present in the melt receiving space of the melt container.
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
B22D 11/10 - Alimentation en métal liquide ou traitement du métal liquide
B22D 17/30 - Accessoires pour l'alimentation en métal liquide, p. ex. en quantités bien définies
B22D 35/04 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules aux moules, p. ex. plaques de base, chenaux de coulée
B22D 41/08 - Récipients de maintien d'un bain de fusion, p. ex. poches, paniers de coulée, bassins de coulée ou systèmes analogues pour coulée par le fond
39.
CASTING INSTALLATION AND METHOD FOR PRODUCING A CAST WORKPIECE
The invention relates to a casting installation (1) for producing a cast workpiece (2), the casting installation (1) comprising: - a casting chamber (4) for receiving a melt (14), the casting chamber (4) having a casting-chamber longitudinal extent (6); - a casting plunger (5) which is accommodated in the casting chamber (4) so as to be displaceable in the casting-chamber longitudinal extent (6) between a front position (7) and a rear position (8) and serves for moving the melt (14) received in the casting chamber (4); - a melt transport device (17), comprising a melt container (18), in which a melt-receiving space (19) is formed, and a lance (20) with an outlet (24), the lance (20) being coupled to the melt container (18). The casting chamber (4) has, on a first end side (10) with respect to the casting-chamber longitudinal extent (6), a chamber opening (11) for filling the casting chamber (4), wherein an opening width (16) of the chamber opening (11) is greater than an outside diameter (21) of the lance (20).
B22D 17/08 - Machines à chambre froide, c.-à-d. dont la chambre de presse où on verse le métal liquide, n'est pas préchauffée
B22D 17/30 - Accessoires pour l'alimentation en métal liquide, p. ex. en quantités bien définies
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
40.
FOAMING DEVICE FOR FOAMING AN EXPANDABLE PARTICULATE FOAM MATERIAL
The invention relates to a foaming device (1) for foaming an expandable particulate foam material (2), comprising a foaming oven (6) which has an interior (5) for receiving the expandable particulate foam material (2), wherein an emitter (11) is provided which is arranged in the interior (5) of the foaming oven (6), and a conveyor device (4) is provided which comprises a conveyor surface (13) and which is used to pass a particulate foam material (2) received on the conveyor surface (13) through the interior (5) of the foaming oven (6) in a conveyor direction (14).
The invention relates to a casting device (1) for casting a molten metal material (4), said casting device (1) having a flow connection element (11) for conducting the molten metal (4). A first electrode (20) and a second electrode (21) are arranged on the flow connection element (11), wherein the first electrode (20) has a first molten metal contact surface (24), and the second electrode (21) has a second molten metal contact surface (25). When the electrodes (20, 21) are installed, the molten metal contact surfaces (24, 25) are designed to contact the molten metal (4) being conducted in the flow connection element (11), and the flow connection element is equipped with a magnet element (16) which is designed to apply a magnetic field to the molten metal (4) region that is supplied with a current.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
25 - Vêtements; chaussures; chapellerie
28 - Jeux, jouets, articles de sport
41 - Éducation, divertissements, activités sportives et culturelles
Produits et services
Electrical equipment for recording, transmission or reproduction of sound or images, in relation to the following fields: Education, training and Studies, for children, For young adults, For adults; Data carriers, in particular CD-ROMs, floppy disks, magnetic tapes and digital memory components with computer programs, being data carrier components, in relation to the following fields: Education, training and Studies, for children, For young adults, For adults; Computer software, for use in the following fields: Education, training and Studies, for children, For young adults, For adults; Application software, for use in the following fields: Education, training and Studies, for children, For young adults, For adults; Application development software, for use in the following fields: Education, training and Studies, for children, For young adults, For adults; Web application software, for use in the following fields: Education, training and Studies, for children, For young adults, For adults; Application software for mobile phones, for use in the following fields: Education, training and Studies, for children, For young adults, For adults; Educational mobile applications; Educational tablet applications; Application software for wireless devices, for use in the following fields: Education, training and Studies, for children, For young adults, For adults; Downloadable application software for smartphones, for use in the following fields: Education, training and Studies, for children, For young adults, For adults; Application software for mobile devices, for use in the following fields: Education, training and Studies, for children, For young adults, For adults. Books; Printed books, magazines, newspapers, and other paper-based media; Educational equipment; Manuals for instructional purposes; Educational and instructional material; Printed matter, and stationery and educational supplies; Educational publications. Clothing; Headgear; Footwear. Gymnastic and sporting articles not included in other classes. Educational instruction; Training; Entertainment without the providing of services in connection with computer games, electronic games and gaming software or applications; Sporting and cultural activities, Except in relation to the following fields: E-sports; Organization of exhibitions for cultural or educational purposes; Operating of a club [entertainment] without the providing of services in connection with computer games, electronic games and gaming software or applications; Sports facilities and amusement parks; Discotheque services; Holiday camp services [entertainment]; Providing recreation facilities; Gaming other than such services that are rendered through computer games, electronic games and gaming software or applications; Providing golf facilities; Arranging and conducting of colloquiums; Arranging and conducting of conferences and congresses; Presentation of live performances; Entertainment in the nature of orchestra performances; Arranging and conducting of symposiums; Rental of sports equipment, except vehicles; Sport camp services, Except in relation to the following fields: E-sports; Organization of sports competitions, Except in relation to the following fields: E-sports; Provision of training courses; Provision of training courses; Provision of training courses; Provision of training courses; Organisation of tournaments, Except in relation to the following fields: E-sports; Organization of sports competitions, Except in relation to the following fields: E-sports; Conducting of educational events; Conducting instructional courses; Arranging and conducting of commercial, trade and business conferences; Arranging and conducting of seminars and workshops; Arranging of classes; Arranging of entertainment shows without the providing of services in connection with computer games, electronic games and gaming software or applications; Arranging of training courses; Arranging of courses of instruction; Presentation of musical concerts; Arranging of lectures; Organisation of shows; Organisation of training courses; Art exhibition services; Conducting guided tours; Provision of training courses; Provision of training courses; Arranging of displays for cultural purposes; Arranging of competitions for education or entertainment, Except in relation to the following fields: E-sports; Organization of exhibitions for cultural or educational purposes; Provision of training courses; arranging and conducting, in relation to the following goods: Recreational activities, not in relation to the following goods: computer games, Electronic game services and Games software, game applications; Arranging, conducting and organisation of seminars; Arranging, conducting and organisation of concerts; Arranging, conducting and organisation of symposiums; Vocational guidance [education or training advice]; Computerised training in career counselling; Vocational testing; Vocational education in the field of mechanics; Provision of training courses for young people in preparation for careers.
09 - Appareils et instruments scientifiques et électriques
16 - Papier, carton et produits en ces matières
25 - Vêtements; chaussures; chapellerie
28 - Jeux, jouets, articles de sport
41 - Éducation, divertissements, activités sportives et culturelles
Produits et services
Electrical equipment for recording, transmission or reproduction of sound or images; Data carriers, in particular CD-ROMs, floppy disks, magnetic tapes and digital memory components with computer programs, being data carrier components; Computer software, particularly computer software for playing games; Game programs for computers, computer games; Application software; Application development software; Web application software; Application software for mobile phones; Educational mobile applications; Educational tablet applications; Application software for wireless devices; Downloadable application software for smartphones; Application software for mobile devices. Books; Printed books, magazines, newspapers, and other paper-based media; Educational equipment; Manuals for instructional purposes; Educational and instructional material; Printed matter, and stationery and educational supplies; Educational publications. Clothing; Headgear; Footwear. Games and playthings; Toys; Electronic games; Gymnastic and sporting articles not included in other classes. Educational instruction; Training; Entertainment services; Sporting and cultural activities; Organization of exhibitions for cultural or educational purposes; Provision of club entertainment services; Sports facilities and amusement parks; Discotheque services; Holiday camp services [entertainment]; Providing recreation facilities; Gambling; Providing golf facilities; Arranging and conducting of colloquiums; Arranging and conducting of conferences and congresses; Presentation of live performances; Entertainment in the nature of orchestra performances; Arranging and conducting of symposiums; Providing casino facilities [gambling]; Rental of sports equipment, except vehicles; Sport camp services; Organization of sports competitions; Provision of training courses; Provision of training courses; Provision of training courses; Provision of training courses; Organisation of tournaments; Organization of sports competitions; Conducting of educational events; Conducting instructional courses; Arranging and conducting of commercial, trade and business conferences; Arranging and conducting of seminars and workshops; Arranging of classes; Arranging of entertainment shows; Arranging of training courses; Arranging of courses of instruction; Presentation of musical concerts; Arranging of lectures; Organisation of shows; Organisation of training courses; Art exhibition services; Conducting guided tours; Provision of training courses; Provision of training courses; Arranging of displays for cultural purposes; Arranging of competitions for education or entertainment; Organization of exhibitions for cultural or educational purposes; Provision of training courses; Arranging and conducting of games; Arranging, conducting and organisation of seminars; Arranging, conducting and organisation of concerts; Arranging, conducting and organisation of symposiums; Vocational guidance [education or training advice]; Computerised training in career counselling; Vocational testing; Vocational education in the field of mechanics; Provision of training courses for young people in preparation for careers.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machine tools; foundry machines; metalworking machines;
woodworking machines; machines for processing plastics;
robots; machinery for manufacturing components of composite
materials. Software for controlling machines; computer software for
quality control; electronic control systems for machines. Building construction; machinery installation, maintenance
and repair. Woodworking; custom assembling of materials (for others);
metal casting. Scientific and technological services and research and
design relating thereto; industrial analysis and research
services; design and development of computer hardware and
computer software; engineering services; preparation of
engineering drawings; technical project studies.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machine tools for forming, riveting, swaging, and flaring of metal and plastics; foundry machines being casting machines; metalworking machines; woodworking machine, namely, bandsaws, presses, machines for repairing defects in wood, conveyors, transportation; machines for processing plastics; industrial robots; machinery for manufacturing components of composite materials Downloadable software for controlling machines; downloadable computer software for quality control; electronic control systems for machines Building construction; machinery installation, maintenance and repair Woodworking; custom assembling of materials for others, namely, assembly of metalworking machines, woodworking machines, casting machines and plastics processing machines; metal casting Scientific and technological services, namely, research and design relating thereto in the field of metalworking, woodworking and plastics processing; industrial analysis and research services, namely, analyzing technology requirements in the field of metalworking, woodworking and plastics processing; design and development of computer hardware and computer software; engineering services; engineering services, namely, preparation of engineering drawings; technical project studies in the field of metalworking, woodworking and plastics processing
46.
VIBRATORY DEVICE WITH DISPLACEABLE ECCENTRIC MASSES
The invention relates to a vibratory device (1), comprising: - a first machine frame (2); - a machine bench (4) which is coupled to the first machine frame (2) in such a way that it can be displaced relative to the first machine frame (2) at least in a main movement direction (3); - a first eccentric mass (5) which is mounted rotatably on the machine bench (4), wherein the first eccentric mass (5) is coupled to a first drive motor (6); - a second eccentric mass (7) which is mounted rotatably on the machine bench (4), wherein the second eccentric mass (7) is coupled to a second drive motor (8). The first eccentric mass (5) and the second eccentric mass (7) are arranged on the machine bench (4) such that they can be displaced relative thereto in the main movement direction (3).
B06B 1/16 - Procédés ou appareils pour produire des vibrations mécaniques de fréquence infrasonore, sonore ou ultrasonore utilisant l'énergie mécanique fonctionnant avec des systèmes impliquant des masses rotatives non équilibrées
47.
MACHINE TOOL AND METHOD FOR OPERATING THE MACHINE TOOL
The invention relates to a machine tool (1) comprising: a machine frame (2); at least a first working spindle (5) which is rotatably mounted about a first spindle axis (7); at least a second working spindle (6) which is rotatably mounted about a second spindle axis (8); a workpiece clamping device (18) which is designed to receive at least a first workpiece (32) and a second workpiece (33). The first working spindle (5) and the second working spindle (6) are disposed vertically on top of one another.
B23Q 3/157 - Agencements pour insérer ou retirer automatiquement les outils les outils rotatifs
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
The invention relates to an accumulator (1) for storing electrical energy comprising: - an accumulator housing (2) with a bottom plate (3) and a top plate (4); - at least one accumulator cell (5, 6) which is accommodated in the accumulator housing (2), characterized in that the accumulator housing (2) comprises at least one solid wood plate (8, 9).
H01M 50/249 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports spécialement adaptés aux aéronefs ou aux véhicules, p. ex. aux automobiles ou aux trains
H01M 50/293 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports caractérisés par des éléments d’espacement ou des moyens de positionnement dans les racks, les cadres ou les blocs caractérisés par le matériau
H01M 10/60 - Chauffage ou refroidissementCommande de la température
H01M 10/42 - Procédés ou dispositions pour assurer le fonctionnement ou l'entretien des éléments secondaires ou des demi-éléments secondaires
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machines and machine tools, namely, for the cutting and forming of materials; foundry machines being casting machines; metal-working machines Treatment of materials, namely, metal, wood and plastics; timber processing; custom assembling of materials for others, namely, assembly of metalworking machines, woodworking machines, casting machines and plastics processing machines; metal casting Scientific and technological services, namely, research and design relating thereto for computer networking hardware in the field of metalworking, woodworking and plastics processing; industrial analysis and research services in the field of metalworking, woodworking and plastics processing; design and development of computer hardware and software; engineering; engineering drawing; technical project studies in the field of metalworking, woodworking and plastics processing
The invention relates to a method and a device for measuring a physical object (1). Image data of uniquely identifiable points (3, 4, 5, 6, 7) on the object (1) are recorded from different perspectives (A, B, C) using at least one camera (2), spatial positions of the uniquely identifiable points (3, 4, 5, 6) are ascertained from the image data, and a first three-dimensional point cloud (8) of the uniquely identifiable points (3, 4, 5, 6, 7) is generated as a global map of the object (1), wherein light beam bundles reflected on a surface of the object (1) are detected as image data in order to detect a surface quality of the object (1), the image data obtained from the light beam bundles reflected on the surface of the object comprises at least some of the uniquely identifiable points (3, 4, 5, 6, 7) as well as surface regions lying between the uniquely identifiable points, and a second three-dimensional point cloud (9) is ascertained as a local map of the object from the detected image data of the light beam bundles reflected on the surface of the object, said first point cloud (8) and second point cloud (9) being combined into a third point cloud (10) using the uniquely identifiable points as reference points.
G01B 11/25 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer des contours ou des courbes en projetant un motif, p. ex. des franges de moiré, sur l'objet
The invention relates to a machine tool (1), comprising: a machine frame (2); a first working spindle (5), which is mounted so as to be rotatable about a first spindle axis (7); a workpiece clamping device (19), wherein the workpiece clamping device (19) comprises at least a first workpiece platform (20) for receiving at least a first workpiece (26) and a second workpiece platform (21) for receiving at least a second workpiece (27), wherein the first workpiece platform (20) is mounted so as to be pivotable about a first pivot axis (22) and the second workpiece platform (21) is mounted so as to be pivotable about a second pivot axis (23), wherein the first pivot axis (22) and the second pivot axis (23) are situated in parallel with one another. The first workpiece platform (20) and the second workpiece platform (21) can be equipped with workpieces (26, 27) in a manner that is readily accessible in a workpiece-changing direction (31), wherein the first pivot axis (22) and the second pivot axis (23) are situated perpendicularly to the workpiece-changing direction (31) and at a distance (32) from one another.
B23Q 1/01 - Bâtis, bancs, colonnes ou éléments similairesAgencement des glissières de guidage
B23Q 7/04 - Agencements pour la manipulation des pièces, spécialement combinés aux machines-outils ou disposés dans ces machines ou spécialement conçus pour être utilisés en relation avec ces machines, p. ex. pour le transport, le chargement, le positionnement, le déchargement, le triage au moyen de pinces
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
52.
FRICTION STIR WELDING TOOL RETAINER HAVING AN ANGLE DRIVE, AND METHOD FOR OPERATING A MACHINE TOOL HAVING SUCH AN ANGLE DRIVE
The invention relates to a friction stir welding tool retainer (14) for holding a friction stir welding tool (15) in a machine tool (1), comprising: a main body (16), a tool clamping holder (17) for holding the friction stir welding tool (15), a machine tool interface (18) for coupling the friction stir welding tool retainer (14) to a tool holder (4) of a working spindle (3) of the machine tool (1). Furthermore, an angle drive (23) is formed, by means of which the tool clamping holder (17) is torque-transmittingly coupled to the machine tool interface (18). A machine tool interface rotational axis (24) and a tool clamping holder rotational axis (25) are angled relative to each other at a friction stir angle (26).
B23K 20/12 - Soudage non électrique par percussion ou par une autre forme de pression, avec ou sans chauffage, p. ex. revêtement ou placage la chaleur étant produite par frictionSoudage par friction
53.
Method for casting a melt of a metal material, and casting device designed for carrying out the method
The invention relates to a method and a device for casting a melt 4 of a metallic material by means of a furnace 2 of a low pressure casting device, which furnace 2 has a receiving space 3 and a riser tube protruding into said receiving space 3. By pressurizing the receiving space 3 with compressed air, the melt 4 in the riser tube 12 of the furnace 2 is pressed into a mold cavity 10 of a mold 7, wherein simultaneously, a magnetic field acting against the conveying direction 23 of the melt 4 is applied to the melt 4 of the metallic material by means of a magnetic element 16 arranged in the region of the riser tube 12.
B22D 18/04 - Coulée basse pression, c.-à-d. utilisant une pression de quelques bars au maximum pour remplir le moule
B22D 18/02 - Coulée avec pression, utilisant des dispositifs presseurs mécaniques, p. ex. matriçage semi-liquide
B22D 11/00 - Coulée continue des métaux, c.-à-d. en longueur indéfinie
B22D 21/00 - Coulée de métaux non ferreux ou de composés métalliques, dans la mesure où leurs propriétés métallurgiques affectent le procédé de couléeUtilisation de compositions appropriées
G01B 11/24 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer des contours ou des courbes
G06F 30/12 - CAO géométrique caractérisée par des moyens d’entrée spécialement adaptés à la CAO, p. ex. interfaces utilisateur graphiques [UIG] spécialement adaptées à la CAO
G06F 30/27 - Optimisation, vérification ou simulation de l’objet conçu utilisant l’apprentissage automatique, p. ex. l’intelligence artificielle, les réseaux neuronaux, les machines à support de vecteur [MSV] ou l’apprentissage d’un modèle
G06T 17/20 - Description filaire, p. ex. polygonalisation ou tessellation
55.
METHOD FOR CASTING A MELT BY MEANS OF A MELT CONTAINER IN WHICH A MELT RECEIVING SPACE IS FORMED
The invention relates to a method for casting a melt (2) by means of a melt container (3) in which a melt receiving space (4) is formed, wherein the melt container (3) has an outlet (5) in the form of a lance (20) below the melt container (3), wherein the method comprises the following method steps: filling the melt container (3) with a melt (2), wherein the melt (2) is transferred via an outlet opening (6) of the lance (20) from a crucible (25) into the melt receiving space (4) of the melt container (3); casting at least one cast workpiece with a melt (2); re-filling the melt container (3) with a melt (2), and, as the melt container (3) is filled with the melt (2), more melt is received in the melt receiving space (4) than is required during the casting of the cast workpiece, wherein a remaining amount of melt (2), which has an oxide layer formed on the surface (19) of the melt, is located in the melt receiving space (3) of the melt container (3) directly before the re-filling of the melt container (3).
B22D 35/00 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules
B22D 35/04 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules aux moules, p. ex. plaques de base, chenaux de coulée
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
B22D 41/12 - Poches de transfert ou récipients similairesChariots pour poches
The invention relates to a casting device (37) comprising a melt transport device (1) having at least one melt container (3a, 3b) in which a melt receiving space (4a, 4b) and an outlet (5a, 5b) in the form of a lance (20a, 20b) below the melt container (3a, 3b) are formed, wherein the outlet (5a, 5b) has an outlet opening (6a, 6b) which is fluidically connected to the melt receiving space (4a, 4b).
B22D 35/00 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules
B22D 35/04 - Équipement de transport du métal liquide jusqu'aux sillons de lingotage ou aux moules aux moules, p. ex. plaques de base, chenaux de coulée
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
B22D 41/12 - Poches de transfert ou récipients similairesChariots pour poches
The invention relates to a method for operating a machining plant (1) for the mechanical machining of workpieces (8), wherein a machining tool (7) is accommodated in the machining plant (1), wherein, during the machining of the workpiece (8), the machining tool (7) and the workpiece (8) are moved relative to one another and the machining tool (7) is engaged with the workpiece (8), wherein the set movements for the machining plant (1) are input into a machine controller (23). The set movements are adapted by modification parameters in a computer-implemented manner, such that at least individual ones of the movements of the machining plant (1) that are actually carried out differ from the input set movements.
B23Q 15/08 - Commande ou régulation de la vitesse de coupe
B23Q 15/12 - Commande auto-adaptative, c.-à-d. s'ajustant elle-même de façon à procurer le meilleur rendement en fonction de critères fixés au préalable
B23Q 17/09 - Agencements sur les machines-outils pour indiquer ou mesurer pour indiquer ou mesurer la pression de coupe ou l'état de l'outil de coupe, p. ex. aptitude à la coupe, charge sur l'outil
B23Q 17/12 - Agencements sur les machines-outils pour indiquer ou mesurer pour indiquer ou mesurer les vibrations
G05B 19/19 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par systèmes de commande de positionnement ou de commande de contournage, p. ex. pour commander la position à partir d'un point programmé vers un autre point ou pour commander un mouvement le long d'un parcours continu programmé
A method for producing a cast workpiece includes the following method steps: providing a mold having at least one mold core arranged in the mold; inserting a metal melt into the mold; waiting for a period of time until at least the outer contour of the metal melt has solidified and the workpiece has been formed from the metal melt; removing the workpiece from the mold; shattering the mold core, wherein this method step is carried out before the workpiece has entirely cooled down from the casting process. For shattering the mold core, a hammer head is applied on a defined energy transmission surface of the workpiece and the energy transmission surface is acted on, in particular hit on, by the hammer head.
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
B22C 9/10 - NoyauxFabrication ou mise en place des noyaux
B22C 9/02 - Moules en sable ou moules analogues pour pièces coulées
B22D 31/00 - Coupage du matériau en excès après coulée, p. ex. des jets ou masselottes
The invention relates to a method for surface treatment of workpieces. The method comprises the following method steps: - providing the workpiece (1, 2); - providing a blasting material (8), wherein the blasting material (8) comprises individual particles (30); - moving the blasting material (8) relative to the workpiece (1, 2) and, in doing so, treating the surface of the workpiece (1, 2); between 70 wt.% and 100 wt.%, in particular between 92 wt.% and 99.9 wt.%, preferably between 98 wt.% and 99.5 wt.% of the particles (30) of the blasting material (8) having a diameter between 1.2 mm and 3 mm at a bulk density between 0.3 kg/dm3 and 0.85 kg/dm3, in particular between 0.5 kg/dm3and 0.75 kg/dm3, preferably between 0.56 kg/dm3and 0.6 kg/dm3.
B22D 11/126 - Accessoires pour le traitement ultérieur ou le travail sur place des barres coulées pour la coupe
B24C 1/08 - Méthodes d'utilisation de jet abrasif en vue d'effectuer un travail déterminéUtilisation d'équipements auxiliaires liés à ces méthodes pour polir des surfaces, p. ex. en utilisant des abrasifs entraînés par un liquide
B24C 11/00 - Emploi de matériaux abrasifs spécifiés pour les jets abrasifs
60.
Decoring machine for decoring cast workpieces, and method for producing cast workpieces
a workpiece carrier (21) for receiving the cast workpiece (2) to be decored, wherein the workpiece carrier (21) is coupled to the machine table (6) by means of a rotary mounting (22), wherein the rotary mounting (22) is configured in such a way that the workpiece carrier (21) is mounted so as to be rotatable about a horizontal axis of rotation (23) relative to the machine table (6).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
B06B 1/16 - Procédés ou appareils pour produire des vibrations mécaniques de fréquence infrasonore, sonore ou ultrasonore utilisant l'énergie mécanique fonctionnant avec des systèmes impliquant des masses rotatives non équilibrées
B22D 29/02 - Appareillage vibrant spécialement conçu pour le décochage des châssis
61.
Repair device, and method for repairing a defect in a wooden workpiece
A repair device for repairing a defect in a wooden workpiece includes: a setting punch for inserting a repair patch into a recess formed in a wooden workpiece; a feed device for feeding the repair patches to the setting punch; and a detector for detecting the orientation of the repair patch with the aid of a marking arranged on the repair patch. A rotary device may be used for rotating the repair patch about a rotational axis. The detector may include a first sensor and a second sensor, which are arranged at the repair device in such a way that they are used for detecting the marking of detection regions disposed at a distance from one another, the marking being arranged on the repair patch.
The invention relates to a melt transporting device (1) comprising a melt container (3) in which a melt receiving chamber (4) is formed and comprising a spout (5), said spout (5) having a spout opening (6). A gas valve (7) is provided which is fluidically connected to the melt receiving chamber (4) and which is designed to regulate the introduction of gas into the melt receiving chamber (4). Furthermore, a) the spout (5) is equipped with a siphon (13) which has a reservoir (14) that is arranged between the melt receiving chamber (4) and the spout opening (6), and the reservoir (14) has an overflow level (17), wherein a siphon wall (15) is provided which has a siphon wall lower edge (41), and the siphon wall (15) protrudes into the reservoir (14) such that the siphon wall lower edge (41) is arranged on a lower level than the overflow level (17) of the reservoir (14), and/or b) the spout (5) is equipped with a filter (24) which has a mesh width (25) between 0.05 mm and 10 mm.
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
63.
DECORING HAMMER FOR DECORING CASTINGS AND DECORING MACHINE AND METHOD FOR DECORING A CASTING
The invention relates to a decoring hammer (1) for decoring castings (2), comprising: - a housing (3) and an impulse member (4), which is coupled to the housing (3) and has a contact surface (5), which serves for coming into contact with the casting (2) to be decored. Also provided is a hold-down device (14), which is coupled to the housing (3) and has a holding-down surface (15), which serves for coming into contact with the casting (2) to be decored, the impulse member (4) being movable in relation to the hold-down device (14).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
B25D 17/00 - Parties constitutives ou accessoires d'outils portatifs à percussion actionnés mécaniquement
The invention relates to a melting furnace (1) and a method for melting and/or controlling the temperature of metal melt (3). The melting furnace (1) according to the invention comprises a furnace housing (4) having a foundation (5) and a side wall (6), which delimits a receiving chamber (7) for receiving metal melt (3). The foundation (5) comprises a platform (9) and a floor plate inner surface (10) facing the receiving chamber (7), wherein the side wall (6) is formed connected to the foundation (5) and comprises an inner shell surface (11) facing the receiving chamber (7) and an outer shell surface facing outward. The side wall (6) further comprises a lower wall region facing the foundation (5) and an upper wall region. The melting furnace (1) according to the invention comprises at least one heating device (18), which comprises at least one heating element (19), wherein at least one cavity (20) is provided in the foundation (5), which cavity (20) is delimited by at least one cavity floor surface (21), at least one peripheral cavity side surface (22) and at least one cavity ceiling surface (23) and wherein the heating device (18) is arranged in the cavity (20).
An articulated-arm robot and a method for machining a workpiece by means of the articulated-arm robot includes a base; a working head holder; several lever arms, which are arranged between the base and the working head holder, the lever arms being coupled to one another by means of revolute joints; a working head which is arranged on the working head holder, the working head comprising a working spindle which is arranged in a spindle housing and is mounted in the spindle housing at least at a first bearing point and a second bearing point. At least one sensor for sensing a radial force is formed at each of the first bearing point and the second bearing point. At least one sensor for sensing an axial force is formed at least one of the two bearing points.
G01H 9/00 - Mesure des vibrations mécaniques ou des ondes ultrasonores, sonores ou infrasonores en utilisant des moyens sensibles aux radiations, p. ex. des moyens optiques
G01H 11/08 - Mesure des vibrations mécaniques ou des ondes ultrasonores, sonores ou infrasonores par détection des changements dans les propriétés électriques ou magnétiques par des moyens électriques utilisant des dispositifs piézo-électriques
G01L 9/14 - Mesure de la pression permanente, ou quasi permanente d’un fluide ou d’un matériau solide fluent par des éléments électriques ou magnétiques sensibles à la pressionTransmission ou indication par des moyens électriques ou magnétiques du déplacement des éléments mécaniques sensibles à la pression, utilisés pour mesurer la pression permanente ou quasi permanente d’un fluide ou d’un matériau solide fluent impliquant le déplacement d'aimants, p. ex. d'électro-aimants
66.
Machining facility and method for changing a tool in the machining facility
a tool change device (5) comprising at least one first gripper device (13) for exchanging the processing tool (4) held in the working spindle (2), wherein the gripper device (13) comprises at least one first gripper unit (15) and one second gripper unit (16) which are positioned at a gripper-unit distance (17) from one another.
The gripper units (15, 16) can be displaced between the working spindle (2) and the tool magazine (6).
The invention relates to a machine tool (1) comprising: a spindle adjustment device (3); at least one first work spindle (5) wherein the work spindle (5) is received on the spindle adjustment device (3); a workpiece clamping device (20) which is mounted on the machine frame (2). The spindle adjustment device (3) has a work head (4) on which the work spindle (5) is mounted. The workpiece clamping device (20) comprises at least one first workpiece table (21) and a second workpiece table (22), wherein the first workpiece table (21) is pivotably mounted about a first pivoting axis (23). The second workpiece table (22) is pivotably mounted about a second pivoting axis (24). The first work spindle (5) is associated with the first workpiece table (21) and the second work spindle (6) is associated with the second workpiece table (22).
B23Q 39/02 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant susceptibles d'être mis en fonctionnement à un seul poste de travail
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
The invention relates to a method for producing a cast part from metal and to a casting machine (1) for a metal casting, comprising at least one mould (2), having mould impression parts (4, 5, 6, 7), defining a cavity (3), characterized in that each mould impression part (4, 5, 6, 7) of at least a first subset of the mould impression parts (4, 5, 6, 7) is mounted pivotably about at least one first axis of rotation (a, b, c, d) of its own, wherein the entire mould together with all of the mould impression parts is mounted about at least one second axis of rotation (e).
B22D 9/00 - Machines ou installations pour la coulée des lingots
B22D 17/22 - Moules métalliquesPlaques de moulesSupports de moulesÉquipement de refroidissement des moulesAccessoires pour l'extraction et l'éjection des pièces hors du moule
B22D 17/26 - Mécanismes ou dispositifs de fermeture ou d'ouverture des moules
B22D 33/04 - Équipement pour la manutention des moules pour rassembler ou séparer les moules
The invention relates to a panel saw (1) for dividing sheet-like workpieces (2) into multiple portions, comprising: - a machine main frame (3); - a workpiece support (4) having a saw slot (5); - a saw aggregate (7) which is arranged underneath the workpiece support (4), wherein a circular saw blade (6) is provided on the saw aggregate (7), said circular saw blade, in a sawing position (34), projecting through the saw slot (5) and being displaceable in a sawing direction (8); - a clamping device (9) for clamping the workpiece (2) against the workpiece support (4); - a positioning device (12) for positioning the workpiece (2).
B27B 5/065 - Machines à scier travaillant avec des lames de scie circulairesOrganes ou équipements ad hoc ayant la particularité de n'avoir qu'une seule utilisation pour le débitage des plaques en éléments de dimensions déterminées, p. ex. scies à panneaux avec des lames de scies mobiles, p. ex. montées sur un chariot
B27B 5/18 - Scies circulaires à table à lame circulaire mobile, p. ex. montée sur un chariot
B23D 45/06 - Machines à scier ou dispositifs de sciage à lames circulaires ou à disques à friction la lame circulaire étant fixée sous une table de travail fixe
B23D 59/00 - Dispositifs annexes spécialement conçus pour les machines à scier ou les dispositifs de sciage
B23D 47/00 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers
B23D 47/02 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers des bâtisMachines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers d'agencements de guidage de la table de travail ou du chariot porte-scie
B23D 47/04 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers des dispositifs d'alimentation, de mise en place, de serrage ou de rotation de la pièce
B23D 59/02 - Dispositifs pour la lubrification ou le refroidissement des lames de scies circulaires
B27B 27/04 - Guides ou butées pour les bois dans les scieries ou les machines à scierAppareils de mesure adaptés disposés perpendiculairement au plan de la lame de scie
B27B 31/00 - Aménagements pour transporter, charger, tourner, centrer ou décharger la grume ou le bois spécialement conçus pour les scieries ou les machines à scier
B27G 19/02 - Protecteurs ou dispositifs de sécurité adaptés aux scies à boisDispositifs auxiliaires facilitant une bonne utilisation des scies à bois pour scies circulaires
70.
METHOD FOR STORING REAL DATA RELATING TO A BODY CONTOUR OF A BODY
The invention relates to a method for storing real data relating to a real body contour (11) of a body (8). The method comprises the following method steps: - creating a model surface grid (6) having a plurality of grid points (7), which model surface grid (6) represents a model body contour (5); - manufacturing the body (8) on the basis of the model body contour (5) from the CAD data; - determining real data relating to the manufactured body (8); - creating a storage surface grid (15) of the real body contour (11) by means of the computer (3); - storing the storage surface grid (15) on a data storage medium (19) for further processing of the data.
The invention relates to a method and to a device for casting a melt (4) of a metal material by means of a furnace (2) of a low-pressure casting device, which has a receiving space (3) and a riser protruding into the receiving space (3). By admitting compressed air into the receiving space (3), the melt (4) is forced in the riser (12) of the furnace (2) into a mould cavity (10), while at the same time a magnetic field acting against the delivery direction (23) of the melt (4) is applied to the melt (4) of the metal material by means of a magnetic element (16) arranged in the region of the riser (12).
B22D 11/00 - Coulée continue des métaux, c.-à-d. en longueur indéfinie
B22D 11/18 - Commande ou régulation des opérations ou du fonctionnement de la coulée
B22D 18/04 - Coulée basse pression, c.-à-d. utilisant une pression de quelques bars au maximum pour remplir le moule
B22D 18/08 - Commande, surveillance, p. ex. pour raison de sécurité
B22D 21/00 - Coulée de métaux non ferreux ou de composés métalliques, dans la mesure où leurs propriétés métallurgiques affectent le procédé de couléeUtilisation de compositions appropriées
B22D 39/00 - Équipement pour l'alimentation en métal liquide en quantités bien définies
H02K 44/00 - Machines dans lesquelles l'interaction dynamo-électrique entre un plasma ou un courant de liquide conducteur ou de particules conductrices ou magnétiques portées par un fluide et un système de bobines ou un champ magnétique, transforme l'énergie de la masse en mouvement en énergie électrique, ou vice versa
The invention relates to a method and a device for core removal from a cast part (1) by breaking down at least one core (2) located in an interior of the cast part (1), wherein, in a step i), a, particularly minimal, dissociation energy necessary for crushing the core (2) is determined.
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
73.
MACHINING FACILITY AND METHOD FOR CHANGING A TOOL IN THE MACHINING FACILITY
The invention relates to a machining facility (1) comprising: at least one first work spindle (2); a tool magazine (6) for storing different machining tools (4), said tool magazine (6) being provided with at least one storage plane (10) having multiple adjacent tool receiving spaces (11); a tool change device (5) comprising at least one first gripper device (13) for exchanging the machining tool (4) held in the work spindle (2), the gripper device (13) having at least one first gripper unit (15) and second gripper unit (16) which are positioned at a gripper-unit distance (17) from one another. The gripper units (15, 16) can be moved between the work spindle (2) and the tool magazine (6).
B23Q 3/155 - Agencements pour insérer ou retirer automatiquement les outils
B23Q 3/157 - Agencements pour insérer ou retirer automatiquement les outils les outils rotatifs
B23Q 39/00 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal
74.
METHOD AND DEVICE FOR FOAMING AN EXPANDABLE PARTICULATE FOAM MATERIAL
The invention relates to a foaming device and to a method for foaming an expandable particlulate foam material (2) in the form of granules, wherein the method comprises the following method steps: introducing the particulate foam material (2) into an interior (5) of a foaming oven (6); irradiating the particulate foam material (2) by means of an infrared emitter (11) arranged in the interior (5) of the foaming oven (6); leading the particulate foam material (2) out of the interior (5) of the foaming oven (6). Here, the emission power of the infrared emitter (11) is determined and the temperature in the interior (5) of the foaming oven (6) is regulated actively by means of a temperature control device (14), such that the temperature in the interior (5) of the foaming oven (6) is regulated to a predeterminable temperature range irrespective of the determined emission power of the infrared emitter (11).
B29C 44/34 - Éléments constitutifs, détails ou accessoiresOpérations auxiliaires
B29C 44/54 - Alimentation en matière à mouler dans une cavité de moulage ouverte ou sur une surface mobile, c.-à-d. pour la fabrication d'objets de longueur indéfinie sous forme de particules ou de grains expansibles
The invention relates to a repair device (6) for repairing a defect (5) in a wooden workpiece (1), said device comprising: - a setting punch (21) for inserting a repair patch (12) into a recess (8) formed in the wooden workpiece (1); - a feed device (23) for feeding the repair patches (12) to the setting punch (21); and - a detection means (47) for detecting the orientation of the repair patch (12) with the aid of a marking (19) arranged on the repair patch (12). A rotary device (39) is also provided and is used to rotate the repair patch (12) about an axis of rotation (40), and the detection means (47) has a first sensor (48) and a second sensor, which are arranged on the repair device (6) in such a way that they are used to detect the marking (19) of detection regions (50, 51) disposed at a distance from one another, the marking being arranged on the repair patch (12).
The invention relates to a machine tool (1) for machining workpieces (2), comprising: a spindle receiver (3) having at least one rotationally driveable tool spindle (4); a machine bed (10) having a swivel bridge (11) which is mounted such that in can be swivellably driven about an A-axis (12) parallel to the X-axis (5), wherein at least one rotary table (17) is arranged on the swivel bridge (11), which is mounted such that it can be rotationally driven about a B-axis (19) perpendicular to the A-axis (12), wherein the rotary table (17) is designed for receiving a pallet (20) for at least one of the workpieces (2) to be machined; and a machining space (21) which is formed in the region of the swivel bridge (11) and which is accessible via a machining tool (7) accommodated in the spindle receiver (3). The swivel bridge (11) and/or pallet-receiving shelves (25) can be shifted along a vertical Y-axis (9) running perpendicular to the X-axis (5) and the Z-axis (6).
B23Q 7/14 - Agencements pour la manipulation des pièces, spécialement combinés aux machines-outils ou disposés dans ces machines ou spécialement conçus pour être utilisés en relation avec ces machines, p. ex. pour le transport, le chargement, le positionnement, le déchargement, le triage coordonnés pour permettre un travail en chaîne
B23Q 1/48 - Supports mobiles ou réglables d'outils ou de pièces utilisant des mécanismes particuliers avec des guidages en translation et des guidages en rotation
B23Q 39/00 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal
The invention relates to a production system (1) for laying fiber tapes (2), said production system (1) comprising: a laying device (5) having at least two roll-out devices (9); an application device (6) having an application surface (32) for receiving the fiber tape (2), wherein the fiber tape (2) can be rolled out in strips onto the application surface (32); a manipulation device (7) for manipulating the fiber tape (2) applied to the application device (6), wherein the manipulation device (7) has a receiving surface (59) for receiving the fiber tape (2). The application surface (32) of the application device (6) is divided into at least two sub-regions (35) when seen over the width (34) of the application device (6), wherein each of the sub-regions (35) is assigned to a roll-out device (9) and wherein the at least two sub-regions (35) of the application surface (32) and the respective related roll-out device (9) of the laying device (5) can be moved relative to one another in the longitudinal extension (33) of the application surface (32) independently of the further roll-out device (9) and the further sub-region (35).
The disclosure relates to a method for unpacking at least one component (2), produced by means of an additive manufacturing process, from a particulate material bed of non-consolidated particulate material (3), wherein the non-consolidated particulate material (3) is arranged together with the at least one component (2) in a build box (1) that is open at the top in the vertical direction and delimited by an upper edge (6), and is delimited at the bottom by a base plate (4) and on the sides by a surrounding wall (5), wherein the non-consolidated particulate material (3) is fluidised and the at least one component (2) is transported by means of a transport device (8) from the build box (1), and wherein the non-consolidated particulate material (3) remains in the build box (1).
B29C 64/379 - Manutention des objets en 3D obtenus, p. ex. à l’aide de robots
B08B 5/02 - Nettoyage par la force de jets, p. ex. le soufflage de cavités
B08B 7/02 - Nettoyage par des procédés non prévus dans une seule autre sous-classe ou un seul groupe de la présente sous-classe par distorsion, battage ou vibration de la surface à nettoyer
B22F 3/105 - Frittage seul en utilisant un courant électrique, un rayonnement laser ou un plasma
B33Y 40/00 - Opérations ou équipements auxiliaires, p. ex. pour la manipulation de matériau
79.
MACHINE TOOL, AND METHOD FOR MACHINING A WORKPIECE
The invention relates to a machine tool (1), comprising: a spindle head (3), having a housing (5) and a tool spindle (4), which is rotatably held in the housing (5) by means of a spindle bearing (6), the tool spindle (4) having a tool receptacle (8); a machining tool (9) for machining workpieces (2). The machining tool (9) has a machining head (10) having at least one cutting edge (11) and has a clamping region (13) for being held in the tool receptacle (8) of the tool spindle (4). A support ring (14) is formed on the machining tool (9). Furthermore, at least one bearing (15) is provided, which is arranged between the support ring (14) and the spindle head (3), whereby the support ring (14) is supported on the spindle head (3).
B23Q 3/12 - Dispositifs permettant de maintenir, supporter ou positionner les pièces ou les outils, ces dispositifs pouvant normalement être démontés de la machine destinés à être fixés à une broche en général
B23B 31/26 - Mandrins de serrage caractérisés par le système de commande à distance des moyens de serrage utilisant des transmissions mécaniques dans la broche de travail
B23Q 11/00 - Accessoires montés sur les machines-outils pour maintenir les outils ou les organes de la machine dans de bonnes conditions de travail ou pour refroidir les pièces travailléesDispositifs de sécurité spécialement combinés aux machines-outils, disposés dans ces machines ou spécialement conçus pour être utilisés en relation avec ces machines
B23C 5/26 - Fixation des fraises sur la broche d'entraînement
37 - Services de construction; extraction minière; installation et réparation
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Plant maintenance; Installation of plant; Installation of industrial machinery; Installation of audiovisual equipment; Repair of installations for use in metal production, metal processing and metal working; Repair of machines; Renovation of machinery; Dismantling of machinery; Machinery maintenance services; Overhaul of machines; Dismantling of industrial machinery; Maintenance of industrial machinery; Assembling [installation] of machine plant; Machinery retrofit and conversion services; Machinery installation, maintenance and repair; Installation of electronic conferencing equipment and facilities. Arranging and conducting of commercial, trade and business conferences; Arranging and conducting of seminars and workshops; Provision of training courses; Conducting of educational events; Arranging and conducting of colloquiums; Conducting instructional courses; Arranging of classes; Arranging of entertainment shows; Arranging of training courses; Arranging of courses of instruction; Presentation of musical concerts; Arranging of lectures; Organisation of shows; Organisation of training courses; Art exhibition services; Conducting guided tours; Arranging of displays for cultural purposes; Arranging of competitions for education or entertainment; Organising of education exhibitions; Arranging and conducting of games; Arranging, conducting and organisation of seminars; Arranging, conducting and organisation of concerts; Provision of online information relating to audio and visual media; Digital video, audio and multimedia entertainment publishing services; Training and further training consultancy; Courses (Training -) relating to research and development; Training services relating to computer-aided engineering design; Development of educational courses and examinations. Digitization of documents; Digitalization of sound and images; Digital asset management; Science and technology services; Scientific research; Advisory services relating to science; Scientific services; Computer aided scientific research services; Computer aided scientific analysis services; Scientific testing services; Technological planning services; Technological research; Technological consultancy; Technological services; Technological analysis services; Scientific technological services; Conducting technical project studies; Consultancy services relating to technological research; Scientific and technological design; Research relating to mechanical engineering; Testing of machinery; Testing the functionality of machines; Engineering services for the analysis of machinery; Engineering services for the design of machinery; Mechanical research; Technological advisory services relating to machine engineering analysis; Advisory services relating to man-machine interfaces for computer software; Research services; Design services; Visual design; Technical design; Computer aided design services; Illustration services (design); Scientific design services; New product design; Product design; Industrial engineering design services; Engineering services; Engineering consultancy services; Engineering research; Technological engineering analysis; Engineering and computer-aided engineering services; Mechanical engineering; Computer hardware development; Software development; Construction drafting.
81.
DECORING MACHINE FOR DECORING CAST WORKPIECES, AND METHOD FOR PRODUCING CAST WORKPIECES
The invention relates to a decoring machine (1) for decoring cast workpieces (2). The decoring machine (1) comprises: - a machine frame (3); - a machine table (6), which is coupled to the machine frame (3) by means of a mounting bracket (7); - a first eccentric mass (10), which is mounted in a rotatable manner on the machine table (6); - a second eccentric mass (12), which is mounted in a rotatable manner on the machine table (6), wherein the second eccentric mass (12) is driven in the opposite direction to the first eccentric mass (10); - a workpiece carrier (21) for receiving the cast workpiece (2) to be decored, wherein the workpiece carrier (21) is coupled to the machine table (6) by means of a rotary mounting (22), wherein the rotary mounting (22) is configured such that the workpiece carrier (21) is mounted so as to be rotatable about a horizontal axis of rotation (23) relative to the machine table (6).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
The invention relates to a casting device (1) for casting under pressure, in particular counter-pressure permanent mould casting or low-pressure permanent mould casting, said device comprising: - a furnace (2) in which a receiving space (3) for receiving a melt (4) is formed; - a mould (8), which comprises a lower mould part (9) and an upper mould part (10), wherein at least one of the two mould parts (9, 10) has a media channel (20) for guiding a coolant, wherein the media channel (20) is fluidically connected to at least one coolant hose (21); - an intermediate plate (7); - at least one riser pipe (12) for conducting a melt (4), by means of which the receiving space (3) of the furnace (2) is fluidically connected to the mould cavity (11) of the mould (8). A coupling (22) having a first coupling part (23) and a second coupling part (24) is formed between the coolant hose (21) and the media channel (20), wherein the coupling (22) can be coupled and decoupled by means of an actuator (26) in an automated manner.
The invention relates to a method for deburring casting cores (1) and/or casting moulds (2), comprising the following method steps: providing a casting core (1) or a casting mould (2) with a burr (4) thereon; providing a deburring device (5) having a dousing shower (6) for generating a shower (7) of blasting material; a retaining device (13) for receiving the casting core (1) and/or the casting mould (2); relatively moving the casting core (1) or the casting mould (2) in relation to the blasting material shower (7) such that the blasting material shower (7) impinges on the burr (4) on the casting core (1) or the casting mould (2), and the burr (4) is struck off the casting core (1) or the casting mould (2) by means of the blasting material shower (7). The invention also relates to a device for carrying out the method.
The invention relates to a decoring machine (1) for decoring castings, comprising: a first machine frame (2); a machine table (4); a first eccentric mass (5), wherein the first eccentric mass (5) is coupled to a first output pulley (6); a second eccentric mass (7), wherein the second eccentric mass (7) is coupled to a second output pulley (8); wherein the second eccentric mass (7) is driven in the opposite direction to the first eccentric mass (5); at least one drive motor (9), which is arranged on the first machine frame (2), wherein the drive motor (9) is coupled to a drive pulley (10); a coupling means (11), by means of which the drive motor (9) is coupled to the two eccentric masses (5, 7) driven in opposite directions. The coupling means (11) comprises an endlessly connected flexible drive means (12), which wraps around the first output pulley (6) coupled to the first eccentric mass (5), the second output pulley (8) coupled to the second eccentric mass (7), and the drive pulley (10) coupled to the drive motor (9).
B06B 1/16 - Procédés ou appareils pour produire des vibrations mécaniques de fréquence infrasonore, sonore ou ultrasonore utilisant l'énergie mécanique fonctionnant avec des systèmes impliquant des masses rotatives non équilibrées
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
B22D 29/02 - Appareillage vibrant spécialement conçu pour le décochage des châssis
The invention relates to a method for producing a cast workpiece (1), wherein the method comprises the following method steps: - providing a casting mould (3) with at least one mould core (7) arranged in the casting mould (3); - introducing molten metal (2) into the casting mould (3); - waiting for a period of time until at least the outer contour of the molten metal (2) has solidified and the workpiece (1) has formed from the molten metal (2); - removing the workpiece (1) from the casting mould (3); - shattering the mould core (7), this method step being carried out even before the workpiece (1) has cooled down completely from the casting process. For shattering the mould core (7), a hammer head (10) is brought up against a fixed energy transfer surface (12) of the workpiece (1) and the energy transfer surface (12) is acted upon, in particular struck, by means of the hammer head (10).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
The invention relates to a production system (1) for laying fiber tapes (2), comprising a laying device (6) having an unwinder receptacle (9) and at least two unwinders (8) arranged adjacent to each other on the unwinder receptacle (9), said unwinders (8) each comprising a receptacle device (10) for receiving a raw material reel (11) and a cutting unit (27) for cutting the fiber tape (2); and a depositing device (7) having a depositing surface (12) for receiving the fiber tape (2) unrolled from the raw material reel (11), wherein the depositing surface (12) of the depositing device (7) and the unwinder (8) of the laying device (6) are movable relative to each other in the laying direction (18), and the fiber tape (2) can be unrolled in strips on the depositing surface (12) as a result. The at least two unwinders (8) are coupled to a unwinder receptacle (9) of the laying device (6) by means of a linear guide (17) and are movable independently of each other in the laying direction (18), relative to the unwinder receptacle (9).
B29C 70/38 - Empilage automatisé, p. ex. utilisant des robots, par application de filaments selon des modèles prédéterminés
B29C 70/22 - Façonnage de matières composites, c.-à-d. de matières plastiques comprenant des renforcements, des matières de remplissage ou des parties préformées, p. ex. des inserts comprenant uniquement des renforcements, p. ex. matières plastiques auto-renforçantes des renforcements fibreux uniquement caractérisées par la structure des renforcements fibreux utilisant des fibres de grande longueur, ou des fibres continues orientées dans au moins deux directions formant une structure bidimensionnelle
The invention relates to a casting device (1) and to a method for operating the casting device (1). The casting device (1) comprises: - a furnace (2) in which a receiving chamber (3) is formed for receiving molten metal (4); - a valve block (17); - a pressure sensor (20); - a casting mold (7); - an intermediate plate (6); and - at least one rising pipe (11), by means of which the receiving chamber (3) of the furnace (2) is fluidically connected to the lower casting mold part (8). The valve block (17) comprises at least four individual valves (18), wherein at least two of the individual valves (18) have different characteristic data, and the individual valves (18) are coupled to an electronic digital processor (19), by means of which the individual valves are actuated. The electronic digital processor (19) is coupled to the pressure sensor (20), and the individual valves (18) can be opened individually independently of one another or simultaneously such that different flow rates can be set.
B22D 18/04 - Coulée basse pression, c.-à-d. utilisant une pression de quelques bars au maximum pour remplir le moule
B22D 18/08 - Commande, surveillance, p. ex. pour raison de sécurité
B22D 27/13 - Traitement du métal dans le moule pendant qu'il est liquide ou plastique en appliquant une pression en utilisant la pression d'un gaz
B22D 39/06 - Équipement pour l'alimentation en métal liquide en quantités bien définies comportant un réglage de la pression sur le bain de métal liquide
The invention relates to a machine tool (1) comprising: a machine frame (2); a spindle adjustment device (3) which is mounted on the machine frame (2); at least one first work spindle (5) and a second work spindle (6), the work spindles (5, 6) being received on the spindle adjustment device (3); a workpiece clamping device (20) which is mounted on the machine frame (2). The spindle adjustment device (3) has a work head (4) on which the two work spindles (5, 6) are mounted. The workpiece clamping device (20) comprises at least one first workpiece table (21) and a second workpiece table (22), the first workpiece table (21) being pivotably mounted about a first pivoting axis (23). The second workpiece table (22) is pivotably mounted about a second pivoting axis (24). The first work spindle (5) is associated with the first workpiece table (21) and the second work spindle (6) is associated with the second workpiece table (22).
B23Q 39/04 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal les sous-ensembles étant disposés pour fonctionner simultanément à différents postes de travail, p. ex. avec une table de travail annulaire se déplaçant par paliers
89.
MACHINING FACILITY AND METHOD FOR CHANGING A TOOL IN THE MACHINING FACILITY
The invention relates to a machining facility (1) comprising: at least one first work spindle (2); a tool magazine (6) for storing different machining tools (4), said tool magazine (6) being provided with at least one storage plane (10) having multiple adjacent tool receiving spaces (11); a tool change device (5) comprising at least one first gripper device (13) for exchanging the machining tool (4) held in the work spindle (2), the gripper device (13) having at least one first gripper unit (15) and second gripper unit (16) which are positioned at a gripper-unit distance (17) from one another. The gripper units (15, 16) can be moved between the work spindle (2) and the tool magazine (6).
B23Q 3/155 - Agencements pour insérer ou retirer automatiquement les outils
B23Q 3/157 - Agencements pour insérer ou retirer automatiquement les outils les outils rotatifs
B23Q 39/00 - Machines pour le travail des métaux incorporant un grand nombre de sous-ensembles capables chacun de réaliser une opération de travail du métal
90.
ARTICULATED-ARM ROBOT AND METHOD FOR MACHINING A WORKPIECE BY MEANS OF THE ARTICULATED-ARM ROBOT
The invention relates to an articulated-arm robot (1) and to a method for machining a workpiece by means of the articulated-arm robot (1). The articulated-arm robot (1) comprises: a base (2); a working head holder (7); a plurality of lever arms (3) which are arranged between the base (2) and the working head holder (7), the lever arms (3) being coupled to one another by means of revolute joints (4); a working head (8) which is arranged on the working head holder (7), the working head (8) comprising a working spindle (9) which is arranged in a spindle housing (13) and is mounted in the spindle housing (13) at least at a first bearing point (14) and a second bearing point (15). At least one sensor (16) for sensing a radial force (17) is formed at each of the first bearing point (14) and the second bearing point (15). At least one sensor (18) for sensing an axial force (19) is formed at at least one of the two bearing points (14, 15).
The invention relates to a casting device (9) for casting moulded parts, in particular moulded metal parts, in particular chassis parts, the device comprising: at least one casting mould (10) which comprises a lower casting mould part (11) and an upper casting mould part (12); a first platform (1) on which the lower casting mould part (11) is mounted; and a second platform (2) on which the upper casting mould part (12) is mounted and which is connected to the first platform (1), one of the casting mould parts (12), preferably the upper casting mould part, being movable relative to the other casting mould part (11) in a first direction (3) between a closed casting mould position and an open casting mould position, and one of the casting mould parts (12), preferably the upper casting mould part, being pivotable about a pivot axis (4) which runs transversely, preferably substantially perpendicularly, to the first direction (3). To increase the flexibility of the casting device and to facilitate removal of the moulded part and cleaning of the casting mould parts, one of the casting mould parts (12), preferably the upper casting mould part, is movable relative to the other casting mould part (11) in a second direction (5) which is transverse, preferably substantially perpendicular, to the pivot axis (4) and transverse, preferably substantially perpendicular, to the first direction (3).
The invention relates to an apparatus (1a..1i) and a method for destroying a core of a cast workpiece (11, 24) and/or removing core pieces sticking to the workpiece (11, 24); for this purpose, the apparatus (1a..1i) includes at least one hydraulic hammer (2, 2a..2f), and the method involves using at least one hydraulic hammer (2, 2a..2f) for destroying the core and/or removing core pieces sticking to the workpiece (11, 24).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
The invention relates to a decoring hammer (1) for decoring castings, comprising: - a housing (2) with a gas inlet opening (3) and a gas outlet opening (4); - a quill (9) movably held in the housing (2), with an impact piece (12) arranged on the quill (9); an impact ram (29) held in a holding space (28) in the quill (9), which is movably held in the holding space (28) of the quill (9) and is designed for striking the impact piece (12). Arranged in the holding space (28) of the quill (9) is a bearing sleeve (37), wherein the bearing sleeve (37) has on an inner side (40) of a bearing sleeve casing (38) a sliding surface (41) for movably holding the impact ram (29).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
B25D 17/00 - Parties constitutives ou accessoires d'outils portatifs à percussion actionnés mécaniquement
B25D 9/04 - Outils portatifs à percussion entraînés par la pression d'un fluide, p. ex. ayant plusieurs têtes d'outils à percussion actionnées simultanément du type à piston-marteau, c.-à-d. dans lesquels la tête de l'outil ou l'enclume est frappée par une pièce en mouvement
The invention relates to a method for producing a moulded body (7), wherein, in a step i), at least one material (8) is introduced as bulk material or in liquid form into a mould cavity (6) of a moulding tool and distributed therein and, in a step ii), a one-piece body is formed from the at least one material (8), wherein the at least one material is introduced into the mould without pressure and the mould cavity (6) is subdivided into different regions, wherein concentrations of the at least one material and values of at least one process parameter are assigned to these regions on the basis of a structural model of the moulded body (7), wherein, in step i), the at least one material is distributed in the mould cavity in a way corresponding to the assigned concentrations and, in step ii) and/or step i), the at least one process parameter is set according to the predetermined values.
B29C 44/04 - Moulage par pression interne engendrée dans la matière, p. ex. par gonflage ou par moussage pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés formés d'au moins deux parties en matière chimiquement ou physiquement différente, p. ex. ayant des densités différentes
B29C 44/44 - Alimentation en matière à mouler dans une cavité de moulage fermée, c.-à-d. pour la fabrication d'objets de longueur définie sous forme de particules ou de grains expansibles
B29C 39/10 - Moulage par coulée, c.-à-d. en introduisant la matière à mouler dans un moule ou entre des surfaces enveloppantes sans pression significative de moulageAppareils à cet effet pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés en incorporant des parties ou des couches préformées, p. ex. coulée autour d'inserts ou sur des objets à recouvrir
B29C 39/12 - Fabrication d'objets multicouches ou polychromes
B29K 105/04 - Présentation, forme ou état de la matière moulée cellulaire ou poreuse
95.
SHEET LAYING DEVICE FOR PRODUCING A FIBRE-REINFORCED COMPOSITE MATERIAL
The invention relates to a sheet laying device (1) for producing a fibre-reinforced composite material, said sheet laying device (1) comprising: - a lay-up mould (3) for receiving a scrim (4); - a compression device (14) for pressing a web (5) of a sheet-type material onto a lay-up mould (3) or a scrim (4); and - a handling device (16) for displacing the compression device (14) relative to the lay-up mould (3). The invention also relates to the compression device (14) and to a method for producing a fibre-reinforced composite material.
The invention relates to a stretch bending machine (1) for deforming workpieces (2), the stretch bending machine (1) comprising: a machine frame (3); a first clamping holder (4) having a first clamping head (5) for clamping a first side (8) of the workpiece (2); a second clamping holder (6) having a second clamping head (7) for clamping a second side (9) of the workpiece (2); a pressing device (14) having a pressing die (15) for deforming the workpiece (2), wherein the pressing die (15) is designed to apply a pressing force in a pressing direction (16) lying transversely with respect to the pulling direction (13). The invention further relates to a method for deforming a workpiece using this stretch bending machine.
The invention relates to a method for producing slat layers (9) consisting of successively arranged slats (7), said slats (7) being placed one behind the other such that the sum of the slat lengths (11) at least corresponds to the length (17) of the slat layer (9) to be produced. At least two buffer stations (10) are provided for the slats (7) of different lengths (11), the slats (7) being removed from these stations in order to form the slat layers (9) and the slats (7) are intelligently combined on a conveyor means (14) such that the end slat (18) of the slat layer (9) is sufficiently long and separated such that the slat layer (9) is of the required length (17) and that the separated remainder piece (20) of the end slat (18) can be used in a subsequent slat layer (9). The remainder piece (20) of the end slat (18) is removed from the conveyor stream, temporarily stored on a remainder piece conveyor means (27) and used as a slat (7) in a subsequent slat layer (9).
TECHNISCHE UNIVERSITÄT HAMBURG-HARBURG (Allemagne)
Inventeur(s)
Cordes, Marcel
Griefahn, Dominik Manuel
Hintze, Wolfgang
Klingelhöller, Christian
Sehrschön, Harald
Abrégé
The invention relates to a drilling tool (3) and to a method for drilling a hole using the drilling tool (3). The drilling tool (3) comprises a tool body (7) having a receiving side (9) for receiving in a drive spindle (5) and a processing side (10) opposite the receiving side (9), wherein, on the face of the processing side (10), a drilling region (12) having at least one axially aligned cutting edge (13) is formed. A radial processing region (15) having a radially aligned cutting edge (17) is formed on the tool body (7), wherein the radial processing region (15) is arranged between the drilling region (12) and the receiving side (9).
B23B 51/10 - Forets à chanfreiner, p. ex. travaillant comme des fraises
B23B 41/04 - Machines ou dispositifs à aléser ou à percer spécialement adaptés à un travail particulierAccessoires spécialement conçus à cet effet pour aléser des trous polygonaux ou d'autres trous non circulaires
B23B 41/06 - Machines ou dispositifs à aléser ou à percer spécialement adaptés à un travail particulierAccessoires spécialement conçus à cet effet pour aléser des trous coniques
B23B 51/06 - Forets prévus pour être lubrifiés ou refroidis
B23G 1/40 - FiletageMachines automatiques spécialement conçues pour le filetage par meulage avec des meules guidées radialement par rapport à la pièce à usiner
B24D 5/10 - Meules agglomérées, ou meules comportant des segments abrasifs rapportés, conçues pour travailler uniquement par leur périphérieBagues ou accessoires pour le montage des ces meules munies de moyens de refroidissement, p. ex. de rainures radiales
F16C 32/04 - Paliers non prévus ailleurs faisant usage de moyens de support magnétiques ou électriques
The invention relates to a method, with which the core can be removed from cast parts in a more efficient manner in series production, said cast parts having a core made of moulding material which breaks into fragments when applied with impulses. According to the invention, the following working steps are carried out for this purpose: providing a core removal machine (1) having an impact unit (9), wherein, as parameters of the impulse application, the impact position, the shape of the impact surface, the impact direction, the duration of the impulse application, the stroke frequency, the stroke force, the impact speed, the geometry or mass of the impact unit (9) can each be varied individually or as a combination of all or certain parameters; carrying out a pre-investigation to determine adjustment values for the parameters of an impulse application, wherein the impulse application is carried out within a predetermined maximum duration in order to break the core into fragments of a size that guarantees a free loosening of the fragments out of the cast part; arranging the impact unit (9), taking into consideration the adjustment values determined in the pre-investigation, in such a way that the parameters of the impulse application are observed; commencing the series operation, wherein the impact unit (9) is operated in compliance with the determined adjustment values for each of the similar cast parts (G).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
B22D 46/00 - Commande, surveillance, non limitées à un procédé de coulée couvert par un seul groupe principal, p. ex. pour des raisons de sécurité
100.
DEVICE FOR REMOVING THE CORE FROM A CAST WORKPIECE
The invention relates to a device (1, 1a,..., 1c) for removing the core from a cast workpiece (2), said device (1) comprising at least one hammer (3), the at least one hammer (3) being equipped with a hammer head (4) and at least one tappet (6) that transmits energy to the hammer head (4) and is arranged so as to be movable in a working cylinder (5) of the hammer (3), the working cylinder (5) being in permanent fluid connection with at least one working volume (7a, 7b) of a cyclically operated piston compressor (8).
B22D 29/00 - Extraction des pièces hors du moule, non limitée à un procédé de coulée couvert par un seul groupe principalExtraction des noyauxManipulation des lingots
B25D 9/14 - Dispositifs de commande du piston alternatif
