1.

INLINE GAS/LIQUID INFUSION SYSTEM WITH ADJUSTABLE ABSORPTION OUTPUT AND SELF-TUNING CAPACITY


Numéro d'application 18786869
Statut En instance
Date de dépôt 2024-07-29
Date de la première publication 2025-01-09
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Estrada, Jesus

Abrégé

An inline gas/liquid infusion system featuring an electronic control logic and subsystem having a signal processor configured to: receive signaling containing information about a liquid pressure of an incoming liquid provided from a pump to an inline gas liquid absorption device and about a gas pressure of an incoming gas provided to the inline gas liquid absorption device; and determine corresponding signaling containing information to control the liquid pressure of the incoming liquid provided from the pump to the inline gas liquid absorption device in order to provide real time adjustable set point output levels of gas absorption in the inline gas liquid absorption device, based upon the signaling received.

Classes IPC  ?

  • B01F 35/221 - Commande ou régulation des paramètres de fonctionnement, p. ex. du niveau de matière dans le mélangeur, de la température ou de la pression
  • B01F 23/236 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés spécialement adapté à l'aération ou la carbonatation des boissons
  • B01F 23/237 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés caractérisé par les propriétés physiques ou chimiques des gaz ou des vapeurs introduits dans le milieu liquide
  • B01F 35/21 - Mesure
  • B01F 35/22 - Commande ou régulation
  • B01F 35/71 - Mécanismes d'alimentation
  • B01F 101/14 - Mélange d'ingrédients pour boissons non alcooliséesDissolution de sucre dans l'eau
  • B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression

2.

DIAPHRAGM PUMP HOUSING HAVING DIRECT INLET CHANNELS TO EACH CHAMBER


Numéro d'application US2024033748
Numéro de publication 2024/259062
Statut Délivré - en vigueur
Date de dépôt 2024-06-13
Date de publication 2024-12-19
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Rudenko, Anton
  • Patel, Akshay

Abrégé

A diaphragm pump includes a pump housing with a pump head and a pump outlet, and features a splitter and three chambers. The splitter has a splitter inlet configured to receive fluid to be pumped, and having splitter channels configured to split the fluid received and provide splitter fluid from each splitter channel. Each chamber has a separate inlet cavity with a separate chamber inlet configured to receive the splitter fluid from a respective one of the splitter channels, and provide respective chamber fluid from each chamber to be pumped from the pump outlet.

Classes IPC  ?

  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F04B 45/04 - Pompes ou installations de pompage, ayant des organes de travail flexibles, spécialement adaptées pour fluides compressibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F04B 43/00 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles
  • F04B 53/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes ou ou présentant un intérêt autre que celui visé par ces groupes
  • F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide

3.

DUAL FLUSH SYSTEM


Numéro d'application US2024029840
Numéro de publication 2024/238880
Statut Délivré - en vigueur
Date de dépôt 2024-05-17
Date de publication 2024-11-21
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s) Edmond, Matthew

Abrégé

A switchable flushing system has a fresh water pump to pump fresh water from a fresh water supply system to an electric marine toilet, and features a dual flush system having a raw water pump, a solenoid and a user selectable fresh/raw flush switch. The raw water pump responds to user selectable fresh/raw flush switch signaling, and pumps raw water to the electric marine toilet. The solenoid is arranged between the fresh water pump and the raw water pump, and responds to the user selectable fresh/raw flush switch signaling, and either open to allow the fresh water pump to pump the fresh water from the fresh water supply system to the electric marine toilet, or close to prevent the fresh water supply system from receiving either the raw water pumped from raw rinse water pump or waste water from the electric marine toilet.

Classes IPC  ?

  • E03D 5/01 - Installations particulières d'appareils de chasse utilisant des pompes de chasse d'eau
  • B63B 29/14 - Sanitaires ou aménagements analogues avec chasse d'eauLavabos ou baignoires particuliers aux navires
  • E03D 11/11 - Cuvettes combinées avec un réservoir, p. ex. contenant un appareil pour la désinfection ou la désintégration

4.

Compact controlled valve with integrated orifices for precise mixing


Numéro d'application 16875490
Numéro de brevet 11835148
Statut Délivré - en vigueur
Date de dépôt 2020-05-15
Date de la première publication 2023-09-07
Date d'octroi 2023-12-05
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Patel, Akshaykumar
  • Tran, Derrick

Abrégé

A control valve features a first housing and a second housing. The first housing includes a first inlet port having a first inlet port orifice member with a first inlet port orifice size configured to provide a first inlet fluid with a first inlet volumetric flow rate, the first inlet port orifice member being detachably coupled inside the first inlet port; includes a second inlet port having a second inlet port orifice member with a second inlet port orifice size configured to provide a second inlet fluid with a second inlet volumetric flow rate, the second inlet port orifice member being detachably coupled inside the second inlet port; and includes a first housing rim configured to extend from the first fixed inlet and the second fixed inlet. The second housing includes a second housing rim coupled to the first housing rim and configured to form a mixture chamber to mix the first inlet fluid received from the first fixed inlet orifice and the second inlet fluid received from the second fixed inlet orifice and provide a mixture chamber fluid; and an outlet port having an outlet port orifice with an outlet port orifice size configured to provide the mixture chamber fluid as an outlet port fluid having an outlet volumetric flow rate. The outlet port fluid has a mixture ratio of the first inlet fluid and the second inlet fluid for a particular application that depends on dimensions of the first inlet port orifice size, the second inlet port orifice size and the outlet port orifice size.

Classes IPC  ?

  • B01F 23/10 - Mélange de gaz avec des gaz
  • B01F 35/221 - Commande ou régulation des paramètres de fonctionnement, p. ex. du niveau de matière dans le mélangeur, de la température ou de la pression
  • B01F 25/00 - Mélangeurs à écoulementMélangeurs pour matières tombantes, p. ex. particules solides
  • F16K 11/00 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides
  • B01F 23/451 - Mélange de liquides avec des liquidesÉmulsion en utilisant le mélange à écoulement en injectant un liquide dans un autre
  • B01F 23/232 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés en utilisant des moyens de mélange à écoulement pour introduire les gaz, p. ex. des chicanes

5.

BILGE PUMP HAVING OUTSIDE SENSING SURFACE WITH RIBS


Numéro d'application 17522112
Statut En instance
Date de dépôt 2021-11-09
Date de la première publication 2022-05-05
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Carrillo Weber, Francisco Jose
  • Meza, Humberto V.

Abrégé

A pump features a liquid sensing device (LSD) in combination with a housing. The LSD senses the level of a liquid collecting outside the pump and turns the pump on/off for pumping the liquid. The housing includes a housing wall to contain the LSD. The housing wall has an outside wall surface with an outside sensing surface. The housing includes an inside mounting structure to mount the LSD inside the housing in relation to the outside sensing surface. The outside sensing surface has ribs extending or projecting outwardly away from the outside wall surface in order to prevent an object from being stuck on the outside sensing surface, and allow the LSD to sense the level of the liquid collecting outside the pump and touching the outside sensing surface, reducing a malfunction of the pump due to the object contacting the outside sensing surface.

Classes IPC  ?

  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges
  • F04D 13/08 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité pour utilisation en position immergée
  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable
  • E03F 5/22 - Adaptations d'installations de pompage pour remonter les eaux d'égout
  • B63B 29/14 - Sanitaires ou aménagements analogues avec chasse d'eauLavabos ou baignoires particuliers aux navires
  • G01F 23/263 - Indication ou mesure du niveau des liquides ou des matériaux solides fluents, p. ex. indication en fonction du volume ou indication au moyen d'un signal d'alarme en mesurant des variables physiques autres que les dimensions linéaires, la pression ou le poids, selon le niveau à mesurer, p. ex. par la différence de transfert de chaleur de vapeur ou d'eau en mesurant les variations de capacité ou l'inductance de condensateurs ou de bobines produites par la présence d'un liquide ou d'un matériau solide fluent dans des champs électriques ou électromagnétiques en mesurant les variations de capacité de condensateurs
  • F04D 13/00 - Installations ou systèmes de pompage

6.

Single piston foundation bag-in-box (BIB) pump


Numéro d'application 17488669
Numéro de brevet 11592013
Statut Délivré - en vigueur
Date de dépôt 2021-09-29
Date de la première publication 2022-04-28
Date d'octroi 2023-02-28
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Verdugo, Christopher H.
  • Villagomez, Manuel
  • Meza, Humberto V.

Abrégé

A pump includes a liquid housing having a liquid chamber with a piston/diaphragm assembly arranged therein that responds to a suction stroke and draws liquid into the liquid chamber, and responds to a pressure stroke and provides liquid from the liquid chamber; and a gas housing having a slide valve assembly separating first and second gas chambers. The slide valve assembly responds to a suction-to-pressure-force at the suction stroke conclusion, changes from a suction-to-pressure stroke state, provides gas from the first to second gas chamber through the slide valve assembly, and provides the pressure stroke so liquid passes from the liquid chamber; and responds to a pressure-to-suction-force at the pressure stroke conclusion, changes from the pressure-to-suction stroke state, provides gas from the second chamber through the slide valve assembly, and provides the suction stroke so liquid is drawn into the liquid chamber.

Classes IPC  ?

  • F04B 9/123 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air avec une seule chambre de pompage
  • F04B 43/073 - Pompes ayant un entraînement par fluide le fluide d'entraînement étant commandé par au moins un clapet
  • F04B 45/053 - Pompes à entraînement par fluide
  • F04B 53/10 - ClapetsAgencement des clapets
  • F04B 43/06 - Pompes ayant un entraînement par fluide
  • F04B 9/127 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air avec une seule chambre de pompage le mouvement rectiligne de l'organe de pompage dans le sens de travail étant obtenu par un moteur à simple effet à fluide compressible, p. ex. actionné dans l'autre sens par gravité ou par un ressort
  • F04B 9/135 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant à fluide le fluide étant compressible, p. ex. de la vapeur ou de l'air avec plusieurs chambres de pompage avec deux organes de pompage liés mécaniquement le mouvement alternatif des organes de pompage étant obtenu par deux moteurs hydrauliques à simple effet, chacun agissant dans un sens

7.

QUICK RELEASE MOTOR PUMP ASSEMBLY FOR ELECTRIC MARINE TOILET


Numéro d'application 17026584
Statut En instance
Date de dépôt 2020-09-21
Date de la première publication 2022-03-24
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Edmond, Matthew

Abrégé

Apparatus featuring a toilet base having a wall forming a chamber for receiving waste, the wall having a toilet base coupling portion; a pump/motor assembly having a pump inlet configured to receive the waste pumped from the chamber, the pump inlet having a pump inlet coupling portion arranged inside the toilet base coupling portion when the pump/motor assembly and the toilet base are coupled together; and a quick release coupling mechanism having a clip receiving portion and a clip configured to slide within the clip receiving portion from a disengage position to an engage position to engage the pump inlet coupling portion and couple the toilet base and the pump/motor assembly together, and also configured to slide from the engage position to the disengage position to disengage the pump inlet coupling portion and decouple the pump/motor assembly from the toilet base.

Classes IPC  ?

  • B63B 29/14 - Sanitaires ou aménagements analogues avec chasse d'eauLavabos ou baignoires particuliers aux navires
  • E03D 5/01 - Installations particulières d'appareils de chasse utilisant des pompes de chasse d'eau

8.

Livewell pump


Numéro d'application 29733068
Numéro de brevet D0943006
Statut Délivré - en vigueur
Date de dépôt 2020-04-29
Date de la première publication 2022-02-08
Date d'octroi 2022-02-08
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Edmond, Matthew B.
  • Irving, Michael H.

9.

QUICK RELEASE MOTOR/PUMP ASSEMBLY FOR ELECTRIC MARINE TOILET


Numéro d'application US2020051734
Numéro de publication 2021/055921
Statut Délivré - en vigueur
Date de dépôt 2020-09-21
Date de publication 2021-03-25
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Meza, Humberto, V.
  • Edmond, Matthew

Abrégé

Apparatus featuring a toilet base having a wall forming a chamber for receiving waste, the wall having a toilet base coupling portion; a pump/motor assembly having a pump inlet configured to receive the waste pumped from the chamber, the pump inlet having a pump inlet coupling portion arranged inside the toilet base coupling portion when the pump/motor assembly and the toilet base are coupled together; and a quick release coupling mechanism having a clip receiving portion and a clip configured to slide within the clip receiving portion from a disengage position to an engage position to engage the pump inlet coupling portion and couple the toilet base and the pump/motor assembly together, and also configured to slide from the engage position to the disengage position to disengage the pump inlet coupling portion and decouple the pump/motor assembly from the toilet base.

Classes IPC  ?

  • E03D 5/01 - Installations particulières d'appareils de chasse utilisant des pompes de chasse d'eau
  • E03D 11/13 - Éléments ou parties constitutives des cuvettesAdaptations particulières de raccords ou accouplements de tuyaux pour leur utilisation avec des cuvettes
  • E03D 11/17 - Moyens pour relier la cuvette au tuyau de chasse
  • F16L 37/086 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'éléments d'enclenchement poussés radialement par des éléments faisant ressort
  • F16L 37/088 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'un segment élastique fendu

10.

IN-LINE GAS LIQUID INFUSION SMART SYSTEM


Numéro d'application 17013955
Statut En instance
Date de dépôt 2020-09-08
Date de la première publication 2021-03-11
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Tran, Derrick
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

An in-line gas liquid infusion smart system, featuring a controller having a signal processer configured to receive signaling containing information about parameters or settings related to dispensing a non-infused liquid and a gas-infused mixture of gas and liquid from a dispense point; and determine corresponding signaling containing information to dispense the non-infused liquid and the gas-infused mixture from the dispense point, and also containing further information about the parameters or settings for providing to a remote controller for controlling, monitoring or troubleshooting the in-line gas liquid infusion smart system, based upon the signaling received.

Classes IPC  ?

  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
  • B01F 15/00 - Accessoires pour mélangeurs

11.

IN-LINE GAS LIQUID INFUSION SMART SYSTEM


Numéro d'application US2020049637
Numéro de publication 2021/046503
Statut Délivré - en vigueur
Date de dépôt 2020-09-08
Date de publication 2021-03-11
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Tran, Derrick
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

An in-line gas liquid infusion smart system, featuring a controller having a signal processer configured to receive signaling containing information about parameters or settings related to dispensing a non-infused liquid and a gas-infused mixture of gas and liquid from a dispense point; and determine corresponding signaling containing information to dispense the non-infused liquid and the gas-infused mixture from the dispense point, and also containing further information about the parameters or settings for providing to a remote controller for controlling, monitoring or troubleshooting the in-line gas liquid infusion smart system, based upon the signaling received.

Classes IPC  ?

  • B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression

12.

INFUSION/MIXER PUMP SYSTEM - PUMP WITH INTEGRATED GAS LIQUID MIXING VALVE IN AN ENCLOSURE


Numéro d'application 17014086
Statut En instance
Date de dépôt 2020-09-08
Date de la première publication 2021-03-11
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Patel, Akshaykumar
  • Tran, Derrick
  • Meza, Humberto V.

Abrégé

An integrated infuser/mixer pump system features a liquid inlet configured to receive a liquid drawn from a liquid source, a gas inlet configured to receive an inlet gas from a gas source, a pump and motor combination configured to received the liquid and provide pumped liquid, a gas/liquid mixture chamber configured to receive the pumped liquid and the inlet gas, and mix the liquid and the inlet gas into a gas-infused mixture, and a gas-infused mixture outlet configured to provide the gas-infused mixture; the gas inlet having a gas liquid mixing valve with a mixing orifice that has a mixing orifice size dimensioned to provide the inlet gas to the gas/liquid mixture chamber with an inlet gas volumetric flow rate in order to mix the pumped liquid and the inlet gas with a predetermined mixture ratio that depends on the mixing orifice size.

Classes IPC  ?

  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides

13.

INFUSION/MIXER PUMP SYSTEM - PUMP WITH INTEGRATED GAS LIQUID MIXING VALVE IN AN ENCLOSURE


Numéro d'application US2020049650
Numéro de publication 2021/046507
Statut Délivré - en vigueur
Date de dépôt 2020-09-08
Date de publication 2021-03-11
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Patel, Akshaykumar
  • Tran, Derrick
  • Meza, Humberto, V.

Abrégé

An integrated infuser/mixer pump system features a liquid inlet configured to receive a liquid drawn from a liquid source, a gas inlet configured to receive an inlet gas from a gas source, a pump and motor combination configured to received the liquid and provide pumped liquid, a gas/liquid mixture chamber configured to receive the pumped liquid and the inlet gas, and mix the liquid and the inlet gas into a gas-infused mixture, and a gas-infused mixture outlet configured to provide the gas-infused mixture; the gas inlet having a gas liquid mixing valve with a mixing orifice that has a mixing orifice size dimensioned to provide the inlet gas to the gas/liquid mixture chamber with an inlet gas volumetric flow rate in order to mix the pumped liquid and the inlet gas with a predetermined mixture ratio that depends on the mixing orifice size.

Classes IPC  ?

  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
  • B01F 15/00 - Accessoires pour mélangeurs
  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation
  • B01F 3/00 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger
  • B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression Détails
  • B67D 1/12 - Dispositifs ou systèmes de commande du débit ou de la pression
  • A23L 2/54 - Mélange avec des gaz

14.

COMPACT CONTROLLED VALVE WITH INTEGRATED ORIFICES FOR PRECISE MIXING


Numéro d'application US2020033163
Numéro de publication 2020/232364
Statut Délivré - en vigueur
Date de dépôt 2020-05-15
Date de publication 2020-11-19
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Patel, Akshaykumar
  • Tran, Derrick

Abrégé

A control valve features a first housing and a second housing. The first housing includes a first inlet port having a first inlet port orifice member providing a first inlet fluid with a first inlet volumetric flow rate, the first inlet port orifice member being detachably coupled inside the first inlet port; includes a second inlet port having a second inlet port orifice member with a second inlet port orifice size configured to provide a second inlet fluid with a second inlet volumetric flow rate, the second inlet port orifice member being detachably coupled inside the second inlet port; and includes a first housing rim configured to extend from the first fixed inlet and the second fixed inlet. The second housing includes a second housing rim coupled to the first housing rim and providing a mixture chamber fluid; and an outlet port having an outlet port orifice.

Classes IPC  ?

  • B01F 5/00 - Mélangeurs à écoulement; Mélangeurs pour matériaux tombants, p.ex. particules solides

15.

PAR-MAX


Numéro de série 90312380
Statut Enregistrée
Date de dépôt 2020-11-11
Date d'enregistrement 2021-08-24
Propriétaire Flow Control LLC ()
Classes de Nice  ? 07 - Machines et machines-outils

Produits et services

Electric diaphragm pumps; Electrical water pumps for use in boats, campers, and domestic water supply systems

16.

Gas liquid absorption device (GLAD) with replaceable gas orifice fittings and sensors


Numéro d'application 16830960
Numéro de brevet 11498036
Statut Délivré - en vigueur
Date de dépôt 2020-03-26
Date de la première publication 2020-10-08
Date d'octroi 2022-11-15
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Patel, Akshaykumar
  • Tran, Derrick

Abrégé

A gas liquid absorption device (GLAD), featuring a gas inlet manifold, a liquid inlet manifold and a gas/liquid mixing foamer. The gas inlet manifold has a gas inlet configured to receive and provide an inlet gas, and also has a gas foamer cavity formed therein and coupled fluidically to the gas inlet to receive the inlet gas. The liquid inlet manifold has a liquid inlet configured to receive and provide a non-infused liquid, and also has a liquid foamer cavity formed therein and coupled fluidically to the liquid inlet to receive the non-infused liquid. The gas/liquid mixing foamer is configured between the gas inlet manifold and the liquid inlet manifold and arranged in the gas foamer cavity and the liquid foamer cavity. The gas/liquid mixing foamer has a gas foamer wall configured to form a gas receiving foamer chamber that is fluidically coupled to the gas foamer cavity. The gas foamer wall has gas provisioning holes formed therein to provide dispersed inlet gas from the gas receiving foamer chamber. The gas/liquid mixing foamer has a liquid foamer wall configured to form a liquid receiving foamer chamber that is fluidically coupled to the liquid foamer cavity. The liquid foamer wall having liquid provisioning holes formed therein to provide dispersed non-infused liquid from the liquid receiving foamer chamber. The mixing chamber is configured to receive the dispersed inlet gas and the dispersed non-infused liquid, infuse the dispersed inlet gas and the dispersed non-infused liquid, and provide a foamed gas/liquid mixture from the mixing chamber.

Classes IPC  ?

  • B01F 23/23 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés
  • B01F 23/231 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés par barbotage

17.

GAS LIQUID ABSORPTION DEVICE (GLAD) WITH REPLACEABLE GAS ORIFICE FITTINGS AND SENSORS


Numéro de document 03096308
Statut Délivré - en vigueur
Date de dépôt 2020-03-26
Date de disponibilité au public 2020-10-01
Date d'octroi 2023-01-24
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Patel, Akshaykumar
  • Tran, Derrick

Abrégé

A gas liquid absorption device (GLAD) features a gas inlet manifold, a liquid inlet manifold and a gas/liquid mixing foamer. The gas inlet manifold has a gas inlet that receives an inlet gas, and has a gas foamer cavity and coupled fluidically to the gas inlet to receive the inlet gas. The liquid inlet manifold has a liquid inlet to provide a noninfused liquid, and has a liquid foamer cavity and coupled fluidically to the liquid inlet to receive the non-infused liquid. The gas/liquid mixing foamer is between the gas inlet manifold and the liquid inlet manifold and arranged in the gas foamer cavity and the liquid foamor cavity. The gas/liquid mixing foamer has a gas foamer wall that forms a gas receiving foamer chamber that is fluidically coupled to the gas foamer cavity.

Classes IPC  ?

  • A23L 2/54 - Mélange avec des gaz
  • B01D 53/14 - Séparation de gaz ou de vapeursRécupération de vapeurs de solvants volatils dans les gazÉpuration chimique ou biologique des gaz résiduaires, p. ex. gaz d'échappement des moteurs à combustion, fumées, vapeurs, gaz de combustion ou aérosols par absorption
  • B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression Détails

18.

GAS LIQUID ABSORPTION DEVICE (GLAD) WITH REPLACEABLE GAS ORIFICE FITTINGS AND SENSORS


Numéro d'application US2020024973
Numéro de publication 2020/198482
Statut Délivré - en vigueur
Date de dépôt 2020-03-26
Date de publication 2020-10-01
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Patel, Akshaykumar
  • Tran, Derrick

Abrégé

A gas liquid absorption device (GLAD) features a gas inlet manifold, a liquid inlet manifold and a gas/liquid mixing foamer. The gas inlet manifold has a gas inlet that receives an inlet gas, and has a gas foamer cavity and coupled fluidically to the gas inlet to receive the inlet gas. The liquid inlet manifold has a liquid inlet to provide a noninfused liquid, and has a liquid foamer cavity and coupled fluidically to the liquid inlet to receive the non-infused liquid. The gas/liquid mixing foamer is between the gas inlet manifold and the liquid inlet manifold and arranged in the gas foamer cavity and the liquid foamor cavity. The gas/liquid mixing foamer has a gas foamer wall that forms a gas receiving foamer chamber that is fluidically coupled to the gas foamer cavity.

Classes IPC  ?

  • A23L 2/38 - Autres boissons non alcoolisées
  • A23L 2/54 - Mélange avec des gaz
  • B01D 53/22 - Séparation de gaz ou de vapeursRécupération de vapeurs de solvants volatils dans les gazÉpuration chimique ou biologique des gaz résiduaires, p. ex. gaz d'échappement des moteurs à combustion, fumées, vapeurs, gaz de combustion ou aérosols par diffusion
  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
  • B01F 5/04 - Mélangeurs à injecteurs
  • B01F 5/06 - Mélangeurs dans lesquels les composants du mélange sont pressés ensemble au travers de fentes, d'orifices, ou de tamis
  • B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression

19.

Cartridge accumulator


Numéro d'application 16784652
Numéro de brevet 11339768
Statut Délivré - en vigueur
Date de dépôt 2020-02-07
Date de la première publication 2020-09-10
Date d'octroi 2022-05-24
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s) Meza, Humberto V.

Abrégé

A filter manifold is provided for processing fluid being provided to a fluid dispenser, featuring a new and unique combination of a mounting bracket, a filter cartridge and an accumulator cartridge. The mounting bracket is configured with porting connections. The filter cartridge may include a filter cartridge porting connection configured to plumb into one of the porting connections on the mounting bracket and also configured to filter the fluid being provided to the fluid dispenser. The accumulator cartridge includes an accumulator cartridge porting connection configured to plumb into another one of the porting connections on the mounting bracket and also configured to receive, accumulate and provide the fluid to the filter cartridge to be filtered before being provided to the fluid dispenser.

Classes IPC  ?

  • B01D 35/02 - Filtres adaptés à des endroits particuliers, p. ex. conduites, pompes, robinets
  • B01D 29/96 - Filtres à éléments filtrants stationnaires pendant la filtration, p. ex. filtres à aspiration ou à pression, non couverts par les groupes Leurs éléments filtrants dans lesquels les éléments filtrants sont déplacés entre les opérations de filtrationDispositions particulières pour enlever ou remplacer les éléments filtrantsSystèmes de transport pour filtres
  • B01D 35/26 - Filtres à pompes incorporées
  • B01D 61/02 - Osmose inverseHyperfiltration
  • B01D 35/30 - Structure du carter de filtre
  • B01D 35/147 - Soupapes de dérivation ou de sécurité
  • B67D 1/10 - Mécanismes de pompage
  • C02F 1/00 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout
  • F04B 53/20 - Filtrage
  • F04B 1/00 - "Machines" ou pompes multicylindres caractérisées par le nombre ou la disposition des cylindres
  • F04B 53/22 - Dispositions pour l'assemblage ou le démontage rapide
  • C02F 1/44 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout par dialyse, osmose ou osmose inverse
  • B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression
  • C02F 1/28 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout par absorption ou adsorption

20.

Diaphragm pump utilizing duckbill valves, multi-directional ports and flexible electrical connectivity


Numéro d'application 16748166
Numéro de brevet 11898548
Statut Délivré - en vigueur
Date de dépôt 2020-01-21
Date de la première publication 2020-05-21
Date d'octroi 2024-02-13
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Tran, Derrick T.
  • Perkins, Bernard L

Abrégé

Diaphragm pump features upper/lower diaphragm pumping assemblies (U/LDPAs) for pumping fluid and a manifold assembly arranged therebetween. The manifold assembly include a manifold body having an inlet with dual inlet ports and an inlet chamber to receive the fluid from a source; an inlet check valve assembly channel having an inlet duckbill check valve assembly (DCVA) arranged therein to receive the fluid from the dual inlet ports; U/LDPAs orifices having the U/LDPA arranged therein to receive the fluid from the inlet DCVA via first upper/lower manifold conduits and provide the fluid from the U/LDPAs via second upper/lower manifold conduits; an outlet check valve assembly channel having an outlet DCVA arranged therein to receive the fluid from the U/LDPAs; and an outlet having dual outlet ports and an outlet chamber to receive the fluid from the U/LDPAs and provide the fluid from the pump to a outlet source.

Classes IPC  ?

  • F04B 45/04 - Pompes ou installations de pompage, ayant des organes de travail flexibles, spécialement adaptées pour fluides compressibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F04C 15/06 - Dispositions pour l'admission ou l'échappement du fluide de travail, p. ex. caractéristiques de structure de l'admission ou de l'échappement
  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F04B 53/10 - ClapetsAgencement des clapets
  • F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide
  • F04B 15/02 - Pompes adaptées pour travailler avec des fluides particuliers, p. ex. grâce à l'emploi de matériaux spécifiés pour la pompe elle-même ou certaines de ses parties les fluides étant visqueux ou non homogènes
  • F04B 43/04 - Pompes ayant un entraînement électrique

21.

Full size rocker housing with piezo buzzer


Numéro d'application 16158503
Numéro de brevet 12051551
Statut Délivré - en vigueur
Date de dépôt 2018-10-12
Date de la première publication 2019-07-11
Date d'octroi 2024-07-30
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s) Irving, Michael Howard

Abrégé

A rocker switch assembly features a rocker switching mechanism and a rocker base housing. The rocker switching mechanism has a switch cover and rocker configured to rock between rocking positions in response to rocking switch forces applied thereon, and provide a rocking switch actuator force. The rocker base housing has a piezo buzzer and rocker switch circuitry, e.g., including contacts/terminals. The piezo buzzer is configured to respond to the rocking switch actuator force, and provide signaling from the piezo buzzer to rocker switch circuitry, based upon the rocking switch actuator force applied.

Classes IPC  ?

  • H01H 23/14 - Culbuteurs
  • H01H 23/02 - Interrupteurs à bascule ou à berceau, c.-à-d. interrupteurs caractérisés en ce qu'ils sont actionnés par basculement d'un organe de l'interrupteur en forme de bouton à bascule Détails
  • H01H 23/12 - Organes mobilesContacts montés sur l'organe mobile
  • H01H 23/00 - Interrupteurs à bascule ou à berceau, c.-à-d. interrupteurs caractérisés en ce qu'ils sont actionnés par basculement d'un organe de l'interrupteur en forme de bouton à bascule

22.

Dispense tap with integral infusion


Numéro d'application 16031331
Numéro de brevet 10961104
Statut Délivré - en vigueur
Date de dépôt 2018-07-10
Date de la première publication 2019-05-09
Date d'octroi 2021-03-30
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Meza, Humberto V.

Abrégé

A dispense tap with integral gas/liquid infusion for dispensing a beverage at a given dispensing point inside a restaurant, a coffee shop, a bar, or a convenience store, features a mixing chamber having at least one gas input port configured to receive at least one incoming gas stream; at least one liquid input port configured to receive at least one incoming liquid or concentrate stream; and an infuser configured to mix the at least one incoming gas stream and the at least one incoming liquid or concentrate stream at the given dispensing point within the dispensing tap, and provide a mixing chamber stream containing a gas infused liquid mixture of the at least one incoming gas stream and the at least one incoming liquid or concentrate stream for dispensing as a beverage. The degree of absorption of the at least one incoming gas stream and the at least one incoming liquid or concentrate stream in the gas infused liquid mixture depends at least in part on sensed gas, liquid or concentrate pressure characteristics of one or more of the at least one incoming gas stream received by the infuser, the at least one incoming liquid or concentrate stream received by the infuser, or the gas infused liquid mixture provided from the infuser.

Classes IPC  ?

  • B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression
  • B67D 1/12 - Dispositifs ou systèmes de commande du débit ou de la pression
  • B01F 3/00 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger
  • B01F 15/00 - Accessoires pour mélangeurs
  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
  • B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression Détails
  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation

23.

FULL SIZE ROCKER HOUSING WITH PIEZO BUZZER


Numéro d'application US2018055550
Numéro de publication 2019/075288
Statut Délivré - en vigueur
Date de dépôt 2018-10-12
Date de publication 2019-04-18
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Irving, Michael Howard

Abrégé

A rocker switch assembly features a rocker switching mechanism and a rocker base housing. The rocker switching mechanism has a switch cover and rocker configured to rock between rocking positions in response to rocking switch forces applied thereon, and provide a rocking switch actuator force. The rocker base housing has a piezo buzzer and rocker switch circuitry, e.g., including contacts/terminals. The piezo buzzer is configured to respond to the rocking switch actuator force, and provide signaling from the piezo buzzer to rocker switch circuitry, based upon the rocking switch actuator force applied.

Classes IPC  ?

  • H01H 23/00 - Interrupteurs à bascule ou à berceau, c.-à-d. interrupteurs caractérisés en ce qu'ils sont actionnés par basculement d'un organe de l'interrupteur en forme de bouton à bascule
  • H01H 23/02 - Interrupteurs à bascule ou à berceau, c.-à-d. interrupteurs caractérisés en ce qu'ils sont actionnés par basculement d'un organe de l'interrupteur en forme de bouton à bascule Détails
  • H01H 23/04 - EnveloppesCouvercles

24.

DISPENSE TAP WITH INTEGRAL INFUSION


Numéro de document 03069297
Statut Délivré - en vigueur
Date de dépôt 2018-07-10
Date de disponibilité au public 2019-01-17
Date d'octroi 2021-06-01
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Meza, Humberto V.

Abrégé

A dispense tap with integral gas/liquid infusion for dispensing a beverage at a given dispensing point features a mixing chamber having at least one gas input port configured to receive at least one incoming gas stream; at least one liquid input port configured to receive at least one incoming liquid or concentrate stream; and an infuser configured to mix the at least one incoming gas stream and the at least one incoming liquid or concentrate stream at the given dispensing point within the dispensing tap, and provide a mixing chamber stream containing a gas infused liquid mixture of the at least one incoming gas stream and the at least one incoming liquid or concentrate stream for dispensing as a beverage.

Classes IPC  ?

  • A23L 2/54 - Mélange avec des gaz
  • A47F 10/06 - Meubles ou installations spécialement adaptés à des systèmes de service particuliers, non prévus ailleurs pour des systèmes de service de restaurants
  • B01F 23/23 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés
  • B01F 35/213 - Mesure des propriétés des mélanges, p. ex. de la température, de la densité ou de la couleur
  • B01F 35/222 - Commande ou régulation du fonctionnement du système d'entraînement, p. ex. du couple, de la vitesse ou de la puissance des moteursCommande ou régulation de la position des dispositifs ou des éléments de mélange
  • B01F 35/75 - Mécanismes d’évacuation
  • B67D 1/04 - Appareils utilisant l'air comprimé ou un autre gaz agissant directement ou indirectement sur les boissons dans les récipients de stockage
  • B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression Détails
  • C12C 11/11 - Traitements après fermentation, p. ex. carbonatation ou concentration

25.

DISPENSE TAP WITH INTEGRAL INFUSION


Numéro d'application US2018041406
Numéro de publication 2019/014193
Statut Délivré - en vigueur
Date de dépôt 2018-07-10
Date de publication 2019-01-17
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Meza, Humberto V.

Abrégé

A dispense tap with integral gas/liquid infusion for dispensing a beverage at a given dispensing point features a mixing chamber having at least one gas input port configured to receive at least one incoming gas stream; at least one liquid input port configured to receive at least one incoming liquid or concentrate stream; and an infuser configured to mix the at least one incoming gas stream and the at least one incoming liquid or concentrate stream at the given dispensing point within the dispensing tap, and provide a mixing chamber stream containing a gas infused liquid mixture of the at least one incoming gas stream and the at least one incoming liquid or concentrate stream for dispensing as a beverage.

Classes IPC  ?

  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
  • B01F 3/00 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger
  • B01F 15/00 - Accessoires pour mélangeurs
  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation
  • B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression
  • B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression Détails
  • B67D 1/12 - Dispositifs ou systèmes de commande du débit ou de la pression

26.

GAS/LIQUID INFUSION SYSTEM WITH INTELLIGENT LEVEL MANAGEMENT AND ADJUSTABLE ABSORPTION OUTPUT


Numéro de document 03058449
Statut Délivré - en vigueur
Date de dépôt 2018-03-28
Date de disponibilité au public 2018-10-04
Date d'octroi 2022-04-05
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

A system features a controller having a signal processor configured to: receive signaling containing information about a liquid level of a gas infused liquid in a liquid/gas infusion tank/vessel, one or more gas input characteristics of a gas provided to the liquid/gas infusion tank/vessel, and one or more liquid input characteristics of an incoming non-infused liquid provided to the liquid/gas infusion tank/vessel; and determine corresponding signaling containing information to control a pump that provides the incoming non-infused liquid to the infusion tank/vessel on demand each time a beverage is dispensed with the gas infused liquid from the liquid/gas infusion tank/vessel and to maintain a desired liquid level and target equilibrium gas pressure in the liquid/gas infusion tank/vessel at a given temperature.

Classes IPC  ?

  • A47J 31/40 - Appareils à préparer des boissons avec des moyens de distribution pour ajouter une quantité mesurée d'ingrédients, p. ex. du café, de l'eau, du sucre, du cacao, du lait, du thé
  • B67D 1/04 - Appareils utilisant l'air comprimé ou un autre gaz agissant directement ou indirectement sur les boissons dans les récipients de stockage
  • B67D 1/12 - Dispositifs ou systèmes de commande du débit ou de la pression

27.

GAS/LIQUID INFUSION SYSTEM WITH INTELLIGENT LEVEL MANAGEMENT AND ADJUSTABLE ABSORPTION OUTPUT


Numéro d'application US2018024815
Numéro de publication 2018/183477
Statut Délivré - en vigueur
Date de dépôt 2018-03-28
Date de publication 2018-10-04
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

A system features a controller having a signal processor configured to: receive signaling containing information about a liquid level of a gas infused liquid in a liquid/gas infusion tank/vessel, one or more gas input characteristics of a gas provided to the liquid/gas infusion tank/vessel, and one or more liquid input characteristics of an incoming non-infused liquid provided to the liquid/gas infusion tank/vessel; and determine corresponding signaling containing information to control a pump that provides the incoming non-infused liquid to the infusion tank/vessel on demand each time a beverage is dispensed with the gas infused liquid from the liquid/gas infusion tank/vessel and to maintain a desired liquid level and target equilibrium gas pressure in the liquid/gas infusion tank/vessel at a given temperature.

Classes IPC  ?

  • B67D 1/00 - Appareils ou dispositifs pour débiter des boissons à la pression
  • B67D 1/12 - Dispositifs ou systèmes de commande du débit ou de la pression

28.

Gas/liquid infusion system with intelligent level management and adjustable absorption output


Numéro d'application 15938512
Numéro de brevet 11266956
Statut Délivré - en vigueur
Date de dépôt 2018-03-28
Date de la première publication 2018-10-04
Date d'octroi 2022-03-08
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

A system features a controller having a signal processor configured to: receive signaling containing information about a liquid level of a gas infused liquid in a liquid/gas infusion tank/vessel, one or more gas input characteristics of a gas provided to the liquid/gas infusion tank/vessel, and one or more liquid input characteristics of an incoming non-infused liquid provided to the liquid/gas infusion tank/vessel; and determine corresponding signaling containing information to control a pump that provides the incoming non-infused liquid to the infusion tank/vessel on demand each time a beverage is dispensed with the gas infused liquid from the liquid/gas infusion tank/vessel and to maintain a desired liquid level and target equilibrium gas pressure in the liquid/gas infusion tank/vessel at a given temperature.

Classes IPC  ?

  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
  • B67D 1/04 - Appareils utilisant l'air comprimé ou un autre gaz agissant directement ou indirectement sur les boissons dans les récipients de stockage
  • B67D 1/12 - Dispositifs ou systèmes de commande du débit ou de la pression
  • B01F 15/00 - Accessoires pour mélangeurs

29.

BILGE PUMP HAVING OUTSIDE SENSING SURFACE WITH RIBS


Numéro de document 03050537
Statut Délivré - en vigueur
Date de dépôt 2018-02-05
Date de disponibilité au public 2018-08-09
Date d'octroi 2025-05-13
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Weber, Francisco Carrillo
  • Meza, Humberto V.

Abrégé

A pump features a liquid sensing device (LSD) in combination with a housing. The LSD senses the level of a liquid collecting outside the pump and turns the pump on/off for pumping the liquid. The housing includes a housing wall to contain the LSD. The housing wall has an outside wall surface with an outside sensing surface. The housing includes an inside mounting structure to mount the LSD inside the housing in relation to the outside sensing surface. The outside sensing surface has ribs extending or projecting outwardly away from the outside wall surface in order to prevent an object from being stuck on the outside sensing surface, and allow the LSD to sense the level of the liquid collecting outside the pump and touching the outside sensing surface, reducing a malfunction of the pump due to the object contacting the outside sensing surface.

Classes IPC  ?

  • F04D 13/08 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité pour utilisation en position immergée
  • F04D 15/00 - Commande, p. ex. régulation de pompes, d'installations ou de systèmes de pompage
  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges

30.

BILGE PUMP HAVING OUTSIDE SENSING SURFACE WITH RIBS


Numéro d'application US2018016858
Numéro de publication 2018/145000
Statut Délivré - en vigueur
Date de dépôt 2018-02-05
Date de publication 2018-08-09
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Weber, Francisco Carrillo
  • Meza, Humberto V.

Abrégé

A pump features a liquid sensing device (LSD) in combination with a housing. The LSD senses the level of a liquid collecting outside the pump and turns the pump on/off for pumping the liquid. The housing includes a housing wall to contain the LSD. The housing wall has an outside wall surface with an outside sensing surface. The housing includes an inside mounting structure to mount the LSD inside the housing in relation to the outside sensing surface. The outside sensing surface has ribs extending or projecting outwardly away from the outside wall surface in order to prevent an object from being stuck on the outside sensing surface, and allow the LSD to sense the level of the liquid collecting outside the pump and touching the outside sensing surface, reducing a malfunction of the pump due to the object contacting the outside sensing surface.

Classes IPC  ?

  • F04D 13/16 - Installations ou systèmes de pompage avec des réservoirs de stockage
  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable

31.

Check valve with plastic lip seal


Numéro d'application 15638675
Numéro de brevet 10221954
Statut Délivré - en vigueur
Date de dépôt 2017-06-30
Date de la première publication 2018-05-10
Date d'octroi 2019-03-05
Propriétaire Flow Control LLC (USA)
Inventeur(s) Fong, John J.

Abrégé

A check valve is provided having a seat and a poppet. The seat is made of a plastic material, has an aperture for enabling fluid to flow through the seat, and also has one end portion that has a circumferential edge with a thin sealing lip. The poppet is slidably arranged in the aperture of the seat and has an elastic member. The poppet is configured for opening to enable fluid to flow in one direction when fluid pressure is detected. The elastic member is configured for ensuring sealing between an outer surface of the poppet and the thin sealing lip of the seat when there is no fluid flow in the one direction so as to substantially prevent fluid flow in the opposite direction. According to some embodiments of the present invention, the thin plastic sealing lip may have a thickness of about 0.01″ Embodiments are also envisioned where the thickness may be in a range of 0.003″-0.03″.

Classes IPC  ?

  • F16K 15/06 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés par tige-guide
  • F04B 53/10 - ClapetsAgencement des clapets

32.

Centrifugal pump


Numéro d'application 29592375
Numéro de brevet D0817361
Statut Délivré - en vigueur
Date de dépôt 2017-01-30
Date de la première publication 2018-05-08
Date d'octroi 2018-05-08
Propriétaire Flow Control LLC (USA)
Inventeur(s)
  • Weber, Francisco Carrillo
  • Meza, Humberto V.

33.

SHOWER DRAIN BOX


Numéro d'application US2017052935
Numéro de publication 2018/057876
Statut Délivré - en vigueur
Date de dépôt 2017-09-22
Date de publication 2018-03-29
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Irving, Michael H.

Abrégé

A drain or sump box features a combination of a housing, a pump, a float switch and a deodorant bar retainer. The housing may include a housing floor and a wall structure attached thereto and configured to receive and contain waste water. The pump is arranged in the housing to respond to signaling for pumping the waste water from the housing. The float switch is arranged in the housing to sense the level of the waste water and provide the signaling to turn the pump on when the waste water exceeds a certain level. The deodorant bar retainer is arranged in the housing in the housing to receive and retain a deodorant bar for preventing, reducing or masking waste water odor and associated bacteria causing the waste water odor.

Classes IPC  ?

  • E03C 1/12 - Installations de plomberie pour l'évacuation des eaux uséesCuvettes ou postes d'eau qui leur sont reliésÉviers
  • B01D 35/00 - Dispositifs filtrants ayant des particularités non couvertes spécifiquement par les groupes , applications non couvertes spécifiquement par les groupes Dispositifs auxiliaires pour la filtrationStructure du carter de filtre
  • B01D 21/24 - Mécanismes d'alimentation ou d'évacuation pour bacs de décantation
  • B01D 24/38 - Dispositifs d'alimentation ou d'évacuation
  • B01D 25/30 - Dispositifs d'alimentation
  • B01J 20/00 - Compositions absorbantes ou adsorbantes solides ou compositions facilitant la filtrationAbsorbants ou adsorbants pour la chromatographieProcédés pour leur préparation, régénération ou réactivation

34.

INLINE GAS/LIQUID INFUSION SYSTEM WITH ADJUSTABLE ABSORPTION OUTPUT AND SELF-TUNING CAPABILITY


Numéro de document 03037191
Statut Délivré - en vigueur
Date de dépôt 2017-09-18
Date de disponibilité au public 2018-03-22
Date d'octroi 2023-01-24
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Estrada, Jesus

Abrégé

An inline gas/liquid infusion system featuring an electronic control logic and subsystem having a signal processor configured to: receive signaling containing information about a liquid pressure of an incoming liquid provided from a pump to an inline gas liquid absorption device and about a gas pressure of an incoming gas provided to the inline gas liquid absorption device; and determine corresponding signaling containing information to control the liquid pressure of the incoming liquid provided from the pump to the inline gas liquid absorption device in order to provide real time adjustable set point output levels of gas absorption in the inline gas liquid absorption device, based upon the signaling received.

Classes IPC  ?

  • B01F 23/20 - Mélange de gaz avec des liquides
  • B01F 35/83 - Formation d'un rapport prédéterminé des substances à mélanger en commandant le rapport entre plusieurs débits, p. ex. en utilisant des dispositifs de détection ou de commande du débit

35.

INLINE GAS/LIQUID INFUSION SYSTEM WITH ADJUSTABLE ABSORPTION OUTPUT AND SELF-TUNING CAPACITY


Numéro d'application US2017052003
Numéro de publication 2018/053394
Statut Délivré - en vigueur
Date de dépôt 2017-09-18
Date de publication 2018-03-22
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Perkins, Bernard L.
  • Estrada, Jesus

Abrégé

An inline gas/liquid infusion system featuring an electronic control logic and subsystem having a signal processor configured to: receive signaling containing information about a liquid pressure of an incoming liquid provided from a pump to an inline gas liquid absorption device and about a gas pressure of an incoming gas provided to the inline gas liquid absorption device; and determine corresponding signaling containing information to control the liquid pressure of the incoming liquid provided from the pump to the inline gas liquid absorption device in order to provide real time adjustable set point output levels of gas absorption in the inline gas liquid absorption device, based upon the signaling received.

Classes IPC  ?

  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation
  • B01F 15/00 - Accessoires pour mélangeurs
  • B01F 5/06 - Mélangeurs dans lesquels les composants du mélange sont pressés ensemble au travers de fentes, d'orifices, ou de tamis
  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides

36.

Shower drain box


Numéro d'application 15712805
Numéro de brevet 10415228
Statut Délivré - en vigueur
Date de dépôt 2017-09-22
Date de la première publication 2018-03-22
Date d'octroi 2019-09-17
Propriétaire Flow Control LLC (USA)
Inventeur(s) Irving, Michael H.

Abrégé

A drain or sump box features a combination of a housing, a pump, a float switch and a deodorant bar retainer. The housing may include a housing floor and a wall structure attached thereto and configured to receive and contain waste water. The pump is arranged in the housing to respond to signaling for pumping the waste water from the housing. The float switch is arranged in the housing to sense the level of the waste water and provide the signaling to turn the pump on when the waste water exceeds a certain level. The deodorant bar retainer is arranged in the housing in the housing to receive and retain a deodorant bar for preventing, reducing or masking waste water odor and associated bacteria causing the waste water odor.

Classes IPC  ?

  • E03F 5/10 - Réservoirs collecteursRéservoirs compensateurs pour la régulation du débitBassins d'accumulation
  • E03F 5/18 - Réservoirs pour la désinfection, la neutralisation ou le refroidissement des eaux d'égout
  • E03F 7/10 - Appareils roulants pour la vidange des égouts ou des fosses d'aisances
  • B60R 15/00 - Aménagements ou adaptations des appareils sanitaires

37.

MODULAR BIB PUMP


Numéro d'application US2017025015
Numéro de publication 2017/173077
Statut Délivré - en vigueur
Date de dépôt 2017-03-30
Date de publication 2017-10-05
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Verdugo, Christopher H
  • Meza, Humberto V.
  • Allen, David
  • Hayashi, Rick

Abrégé

A modular pump features a gas-control-and-drive-unit (GCDU), a cartridge-style-pumping-module (CSPU) and a retainer clip (RC). The GCDU includes a GCDU-housing to receive/provide gas to a gas-passageway causing a GCDU-force in one direction; an actuator-rod-and-slide-valve-arrangement (AR/SVA) to respond to a CSPM-force and exhaust the gas from the GCDU-housing causing a GCDU-exhaustion-force in an opposite direction; and a GCDU-coupling-member. The CSPM includes a CSPM-housing to receive a fluid to be pumped, and a piston-and-dual-diaphragm-arrangement (PDDA) to respond to the GCDU-force, provide the CSPM-force and pump the fluid from the CSPM, and to respond to the GCDU-exhaustion-force and pump the fluid from the CSPM. The CSPM-housing includes a CSPM coupling member to detachably couple to the GCDU-coupling-member. The RC detachably couples a piston of the PDDA and an actuator rod of the AR/SVA, so the CSPM attaches/detaches from the GCDU using a three-step process for field replacement using the RC.

Classes IPC  ?

  • F04B 53/22 - Dispositions pour l'assemblage ou le démontage rapide

38.

JABSCO


Numéro de série 87614217
Statut Enregistrée
Date de dépôt 2017-09-19
Date d'enregistrement 2018-08-21
Propriétaire FLOW CONTROL LLC ()
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 08 - Outils et instruments à main
  • 09 - Appareils et instruments scientifiques et électriques
  • 11 - Appareils de contrôle de l'environnement
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
  • 20 - Meubles et produits décoratifs

Produits et services

Electric pumps; water pumps for water filtering units; water pumps for showers; bilge pumps; centrifugal pumps; clutch pumps; flexible impeller pumps; diaphragm pumps; refueling pumps, namely, fuel dispensing pumps for service stations; rotary vane pumps; rotary pumps; rotary lobe pumps; macerator pumps; oil drain pumps; sludge pumps; sewage pumps; circulating pumps; pumps for cooling engines; Pump parts, namely, valves for pumps, shafts for pumps, shaft bearings for vacuum pumps, pump impellers, pump diaphragms, and metal or non-metal filters, strainers, and intake screens for pump fluid lines; Pumps as parts of motors; water pumps for marine washdown systems; Valves being parts of machines; Valves for pumps, namely, check valves; Power operated blowers; Variable speed drives for use with fluid pumping systems; portable and stationary oil changer systems for marine vehicles comprised primarily of oil drain pumps Hand tools, namely, hand-operated pumps; impeller pullers, namely hand tools for extracting pump impellers from pumps Control valves for regulating the flow of gases and liquids; Electric switches; electrical float switches; bilge pump electric switches; Solenoid valves; Level switches for monitoring and controlling liquids in tanks and vessels; Electronic controls for pump motors; electronic controllers for marine ballast tank systems; electric wire and cable; Remote controls for searchlights Portable toilets; toilet systems for marine vessels comprised of toilets for marine vessels, toilet bowls, toilet seats, flush valves; Strainers for water lines; Strainers for plumbing drains; Water filters; Water filtering apparatus; Water filtration and purification units and replacement cartridges and filters therefor; Water purification tanks; Pressure regulators for water installations; searchlights; floodlights; Lighting apparatus, namely, lighting installations; light bulbs; plumbing valves, namely check valves Non-metallic hoses, flexible pipes and fittings for pipes; Rubber clack valves for use in marine toilets Valves of plastic being other than machine parts; Y-valves of plastic being other than machine parts; Water tanks of plastic for household, industrial, and agricultural purposes [; Winding spools, not of metal, non-mechanical, for flexible hoses ]

39.

Low profile pump with the ability to be mounted in various configurations


Numéro d'application 15593597
Numéro de brevet 10323646
Statut Délivré - en vigueur
Date de dépôt 2017-05-12
Date de la première publication 2017-08-31
Date d'octroi 2019-06-18
Propriétaire Flow Control LLC (USA)
Inventeur(s)
  • Gell, Iii, William A.
  • Lopes, Jeffrey D.
  • Estrada, Jesus
  • Moormann, Randall H.

Abrégé

A pumping system featuring a pump chamber configured with a central portion having a tangential outlet, and configured with a tubular coupling end portion having inwardly flexible rim portions on one side; and a mounting base, having a circular portion with an inner circumferential rim configured to receive and engage the inwardly flexible rim portions of the tubular coupling portion of the pump chamber so as to be rotationally coupled to the pumping chamber so that the pumping chamber may be rotated 360° in relation to the mounting base.

Classes IPC  ?

  • F04D 13/06 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité
  • F04D 13/08 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité pour utilisation en position immergée
  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable
  • F04D 29/40 - Carters d'enveloppeTubulures pour le fluide énergétique
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges
  • F04D 29/60 - MontageAssemblageDémontage
  • B63B 13/00 - Conduits pour l'épuisement ou le ballastageÉquipement automatique pour l'assèchementDalots
  • F04D 13/02 - Ensembles comprenant les pompes et leurs moyens d'entraînement

40.

SOLENOID PUMP MOUNTING METHOD


Numéro d'application US2016056397
Numéro de publication 2017/062979
Statut Délivré - en vigueur
Date de dépôt 2016-10-11
Date de publication 2017-04-13
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Lopes, Jeffrey

Abrégé

A pump mounting system for mounting a pump to a beverage dispensing system, the pump mounting system featuring a pump, an elastic pump mounting bracket, the elastic pump mounting bracket dampening the transmission of vibration from one end of the pump to the system; and a flexible looped hose connection having a corresponding pump-to-hose connector portion to coupled to the pump-to- hose connector portion of the pump, and having a hose-to-system connector portion to couple to a corresponding hose-to-system connector portion of the system, an intermediate looped hose connection portion to couple together the corresponding pump-to-hose connector portion and the hose-to-system connector portion, the flexible looped hose connection to provide a flow path connection to the system and dampen the transmission of the vibration of the pump to the system via the flow path connection.

Classes IPC  ?

  • F04B 39/00 - Parties constitutives, détails ou accessoires de pompes ou de systèmes de pompage spécialement adaptés aux fluides compressibles, non prévus dans les groupes ou présentant un intérêt autre que celui visé par ces groupes

41.

CARTRIDGE ACCUMULATOR


Numéro d'application US2016051671
Numéro de publication 2017/048802
Statut Délivré - en vigueur
Date de dépôt 2016-09-14
Date de publication 2017-03-23
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Meza, Humberto

Abrégé

A filter manifold is provided for processing fluid being provided to a fluid dispenser, featuring a new and unique combination of a mounting bracket, a filter cartridge and an accumulator cartridge. The mounting bracket is configured with porting connections. The filter cartridge may include a filter cartridge porting connection configured to plumb into one of the porting connections on the mounting bracket and also configured to filter the fluid being provided to the fluid dispenser. The accumulator cartridge includes an accumulator cartridge porting connection configured to plumb into another one of the porting connections on the mounting bracket and also configured to receive, accumulate and provide the fluid to the filter cartridge to be filtered before being provided to the fluid dispenser.

Classes IPC  ?

  • B01D 25/02 - Filtres formés par l'assemblage de plusieurs éléments filtrants fixés ensemble ou parties de tels éléments dont les éléments sont constitués par des unités filtrantes indépendantes et préfabriquées, p. ex. systèmes modulaires
  • B01D 35/00 - Dispositifs filtrants ayant des particularités non couvertes spécifiquement par les groupes , applications non couvertes spécifiquement par les groupes Dispositifs auxiliaires pour la filtrationStructure du carter de filtre
  • B01D 35/30 - Structure du carter de filtre
  • B01D 61/02 - Osmose inverseHyperfiltration
  • B01D 61/08 - Appareils à cet effet
  • E03B 7/07 - Disposition des appareils, p. ex. filtres, commandes du débit, dispositifs de mesure, siphons ou valves, dans les réseaux de canalisations

42.

CARTRIDGE ACCUMULATOR


Numéro de document 02998354
Statut Délivré - en vigueur
Date de dépôt 2016-09-14
Date de disponibilité au public 2017-03-23
Date d'octroi 2023-06-13
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Meza, Humberto

Abrégé

A filter manifold is provided for processing fluid being provided to a fluid dispenser, featuring a new and unique combination of a mounting bracket, a filter cartridge and an accumulator cartridge. The mounting bracket is configured with porting connections. The filter cartridge may include a filter cartridge porting connection configured to plumb into one of the porting connections on the mounting bracket and also configured to filter the fluid being provided to the fluid dispenser. The accumulator cartridge includes an accumulator cartridge porting connection configured to plumb into another one of the porting connections on the mounting bracket and also configured to receive, accumulate and provide the fluid to the filter cartridge to be filtered before being provided to the fluid dispenser.

Classes IPC  ?

  • B01D 27/08 - Construction du bâti
  • B01D 35/30 - Structure du carter de filtre
  • B01D 61/02 - Osmose inverseHyperfiltration
  • B01D 61/08 - Appareils à cet effet
  • E03B 7/07 - Disposition des appareils, p. ex. filtres, commandes du débit, dispositifs de mesure, siphons ou valves, dans les réseaux de canalisations

43.

Cartridge pump


Numéro d'application 15167534
Numéro de brevet 11020695
Statut Délivré - en vigueur
Date de dépôt 2016-05-27
Date de la première publication 2017-01-26
Date d'octroi 2021-06-01
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Perkins, Bernard L.

Abrégé

The present invention provides a pump cartridge, which is directly connected in-line with one or more filter cartridges in a mounting bracket. It may be paired with an accumulator tank for a pump version, and with no accumulator tank for a smart pump version. The inline design reduces the size of the system, the amount of connections, and the amount of hose required to install the system, which in turn reduces the space required for installation, the number of potential leak paths, and the likelihood of failure of the system due to issues with the hose.

Classes IPC  ?

  • B01D 35/26 - Filtres à pompes incorporées
  • B01D 29/96 - Filtres à éléments filtrants stationnaires pendant la filtration, p. ex. filtres à aspiration ou à pression, non couverts par les groupes Leurs éléments filtrants dans lesquels les éléments filtrants sont déplacés entre les opérations de filtrationDispositions particulières pour enlever ou remplacer les éléments filtrantsSystèmes de transport pour filtres
  • B01D 35/02 - Filtres adaptés à des endroits particuliers, p. ex. conduites, pompes, robinets
  • B67D 1/10 - Mécanismes de pompage
  • C02F 1/00 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout
  • C02F 1/44 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout par dialyse, osmose ou osmose inverse
  • B67D 7/76 - Aménagements des dispositifs de purification des liquides à transférer, p. ex. des filtres, des séparateurs à air ou eau
  • F04B 1/00 - "Machines" ou pompes multicylindres caractérisées par le nombre ou la disposition des cylindres
  • F04B 53/20 - Filtrage
  • F04B 53/22 - Dispositions pour l'assemblage ou le démontage rapide
  • F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide

44.

CARTRIDGE PUMP


Numéro d'application US2016034789
Numéro de publication 2016/191731
Statut Délivré - en vigueur
Date de dépôt 2016-05-27
Date de publication 2016-12-01
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Perkins, Bernard L.

Abrégé

The present invention provides a pump cartridge, which is directly connected in-line with one or more filter cartridges in a mounting bracket. It may be paired with an accumulator tank for a pump version, and with no accumulator tank for a smart pump version. The inline design reduces the size of the system, the amount of connections, and the amount of hose required to install the system, which in turn reduces the space required for installation, the number of potential leak paths, and the likelihood of failure of the system due to issues with the hose.

Classes IPC  ?

  • A47J 31/40 - Appareils à préparer des boissons avec des moyens de distribution pour ajouter une quantité mesurée d'ingrédients, p. ex. du café, de l'eau, du sucre, du cacao, du lait, du thé
  • A47J 31/44 - Éléments ou parties constitutives des appareils à préparer des boissons
  • A47J 31/46 - Becs verseurs, pompes, soupapes de vidange ou dispositifs analogues pour le transport de liquides
  • B67D 7/76 - Aménagements des dispositifs de purification des liquides à transférer, p. ex. des filtres, des séparateurs à air ou eau
  • G01F 3/36 - Mesure du débit volumétrique des fluides ou d'un matériau solide fluent dans laquelle le fluide passe à travers le compteur par quantités successives et plus ou moins séparées, le compteur étant entraîné par l'écoulement avec des chambres de mesure fixes ayant un volume constant au cours du mesurage

45.

CARTRIDGE PUMP


Numéro de document 02986904
Statut Délivré - en vigueur
Date de dépôt 2016-05-27
Date de disponibilité au public 2016-12-01
Date d'octroi 2022-03-22
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Perkins, Bernard L.

Abrégé

The present invention provides a pump cartridge, which is directly connected in-line with one or more filter cartridges in a mounting bracket. It may be paired with an accumulator tank for a pump version, and with no accumulator tank for a smart pump version. The inline design reduces the size of the system, the amount of connections, and the amount of hose required to install the system, which in turn reduces the space required for installation, the number of potential leak paths, and the likelihood of failure of the system due to issues with the hose.

Classes IPC  ?

  • A47J 31/40 - Appareils à préparer des boissons avec des moyens de distribution pour ajouter une quantité mesurée d'ingrédients, p. ex. du café, de l'eau, du sucre, du cacao, du lait, du thé
  • A47J 31/44 - Éléments ou parties constitutives des appareils à préparer des boissons
  • A47J 31/46 - Becs verseurs, pompes, soupapes de vidange ou dispositifs analogues pour le transport de liquides
  • B67D 7/76 - Aménagements des dispositifs de purification des liquides à transférer, p. ex. des filtres, des séparateurs à air ou eau
  • G01F 3/36 - Mesure du débit volumétrique des fluides ou d'un matériau solide fluent dans laquelle le fluide passe à travers le compteur par quantités successives et plus ou moins séparées, le compteur étant entraîné par l'écoulement avec des chambres de mesure fixes ayant un volume constant au cours du mesurage

46.

FLUID RELEASE VALVE


Numéro d'application US2016034745
Numéro de publication 2016/191721
Statut Délivré - en vigueur
Date de dépôt 2016-05-27
Date de publication 2016-12-01
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Kenney, Joel A.
  • King, Robert W.

Abrégé

A fluid release valve includes valve housing (VH) coupled between a pump and an outlet pipe, VH chamber providing fluid from its inlet and outlet when the pump starts, and fluid release orifice (FRO) draining outlet pipe fluid flowing back into the VH when the pump stops; and check valve (CV) combination having a CV shuttle that moves towards/away from the inlet/outlet and an internal shuttle chamber (ISC), and having a CV that moves towards/away from the inlet/outlet within the ISC. The CV combination responds to a pumped fluid pressure when the pump's pumping and stops the fluid from flowing from the inlet around the CV shuttle and out the FRO. The CV combination responds to a fluid differential pressure (FDP) when the pump stops and allows the outlet pipe fluid to drain out the FRO until the FDP reaches an equilibrium.

Classes IPC  ?

  • F16K 15/00 - Soupapes, clapets ou valves de retenue
  • F16K 17/28 - Soupapes ou clapets limiteurs de débit fonctionnant par différence de pression entre deux points de l'écoulement et agissant directement sur l'élément d'obturation dans un sens uniquement
  • F16K 17/20 - Soupapes ou clapets limiteurs de débit
  • F16K 17/34 - Soupapes ou clapets limiteurs de débit dans lesquels l'énergie provenant du courant du fluide actionne le mécanisme de fermeture
  • F16K 15/02 - Soupapes, clapets ou valves de retenue à corps de soupapes rigides guidés
  • F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles

47.

IMPELLER WITH AXIALLY CURVING VANE EXTENSIONS TO PREVENT AIRLOCK


Numéro d'application 14819800
Statut En instance
Date de dépôt 2015-08-06
Date de la première publication 2016-06-30
Propriétaire Flow Control LLC. (USA)
Inventeur(s) Lopes, Jeffrey D.

Abrégé

A pump has a housing that includes an inlet to receive a liquid to be pumped, an outlet to provide the liquid being pumped, a pumping chamber between the inlet/outlet; and a motor shaft to rotate in the pumping chamber. The impeller is arranged on the motor shaft, includes radially curved vanes to rotate inside the pumping chamber to pump the liquid from the pumping chamber to the outlet; and includes anti-airlock vanes formed as a set of axially curving vane extensions that extend along the axis of the shaft, rotate with one part inside the pumping chamber, protrude through the inlet and rotate with another part outside the inlet for submerging in liquid to be pumped underneath the pump, draw the liquid through the inlet into the pumping chamber, and provide the liquid to the radially curved vanes to generate pressure to force entrapped air from the pumping chamber.

Classes IPC  ?

  • F04D 9/00 - AmorçagePrévention du blocage par la vapeur
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges
  • F04D 29/24 - Aubes
  • F04D 1/14 - Pompes élevant le fluide par la force centrifuge dans un bol conique tournant autour d'un axe vertical
  • F04D 13/02 - Ensembles comprenant les pompes et leurs moyens d'entraînement

48.

Debris removing impeller back vane


Numéro d'application 14899894
Numéro de brevet 10514042
Statut Délivré - en vigueur
Date de dépôt 2014-06-23
Date de la première publication 2016-05-19
Date d'octroi 2019-12-24
Propriétaire Flow Control LLC (USA)
Inventeur(s) Lopes, Jeffrey D.

Abrégé

A pump features an impeller having a rotating disk with a front side and a back side. The impeller is arranged to rotate on a shaft with the front side nearest an inlet and the back side nearest a motor housing, so as to provide a main flow of liquid being pumped and a rear impeller flow of the liquid being pumped in an area between the back side of the impeller and the motor housing. The back side has a spiral-shaped vane configured to constantly sweep, and expel any debris from the area between the back side of the impeller and the motor housing. The spiral-shaped vane is formed as a curve that emanates from a central point defined by an axis of the impeller and gets progressively farther away as the curve revolves at least one complete revolution around the central point or axis.

Classes IPC  ?

  • F04D 1/00 - Pompes à flux radial, p. ex. pompes centrifugesPompes hélicocentrifuges
  • F04D 7/04 - Pompes adaptées à la manipulation de liquides particuliers, p. ex. par choix de matériaux spéciaux pour les pompes ou pièces de pompe du type centrifuge les fluides étant visqueux ou non homogènes
  • F04D 13/02 - Ensembles comprenant les pompes et leurs moyens d'entraînement
  • F04D 29/00 - Parties constitutives, détails ou accessoires
  • F04D 29/10 - Joints d'étanchéité pour arbre
  • F04D 29/22 - Rotors spécialement pour les pompes centrifuges
  • F04D 29/24 - Aubes
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges
  • F04D 29/70 - Grilles d'aspirationFiltresSéparateurs de poussièreNettoyage

49.

Method and means for detecting motor rotation


Numéro d'application 14860202
Numéro de brevet 09825563
Statut Délivré - en vigueur
Date de dépôt 2015-09-21
Date de la première publication 2016-04-07
Date d'octroi 2017-11-21
Propriétaire Flow Control LLC (USA)
Inventeur(s)
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

Apparatus features a microcontroller configured to: receive signaling containing information about a measured change of a magnetic field created by a magnetic circuit driving a motor; and determine corresponding signaling containing information about the speed of rotation of the motor, based upon the signaling received. The microcontroller provides control signaling containing information to control the operation of the motor, including where the motor control is used to control the flow of fluids from a pump. A Hall Effect Sensor is used to sense the magnetic flux and provide the signaling in the form of a feedback signal for implementing motor control. The motor housing has a slot, the Hall Effect sensor is mounted external the motor housing over the slot, and a ferromagnetic bridge is arranged over the Hall Effect sensor to close the magnetic circuit and cause more flux to go through the Hall Effect sensor.

Classes IPC  ?

  • H02P 6/16 - Dispositions de circuits pour détecter la position
  • H02P 6/17 - Dispositions de circuits pour détecter la position et pour l’obtention d’informations sur la vitesse
  • H02K 11/215 - Dispositifs utilisant un effet magnétique, p. ex. des éléments à effet Hall ou magnéto-résistifs
  • F04B 1/00 - "Machines" ou pompes multicylindres caractérisées par le nombre ou la disposition des cylindres
  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes

50.

AUTOMATIC FILL CONTROL TECHNIQUE


Numéro de document 02961763
Statut Délivré - en vigueur
Date de dépôt 2015-09-21
Date de disponibilité au public 2016-03-24
Date d'octroi 2019-01-08
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

Apparatus features a microcontroller configured to receive signaling containing information about a measured change of a magnetic field created by a magnetic circuit driving a motor; and determine corresponding signaling containing information about the speed of rotation of the motor, based upon the signaling received. The microcontroller provides control signaling containinginformation to control the operation of the motor, including where the motor control is used to control the flow of fluids from a pump A Hall Effect Sensor is used to sense the magnetic flux and provide the signaling m the form of a feedback signal for implementingmotor control The motor housing has a slot, the Hall Effect sensor is mounted external the motor housing over the slot, and a ferromagnetic bridge is arranged over the Hall Effect sensor to close the magnetic circuit and cause more flux to go through the Hall Effect sensor

Classes IPC  ?

  • H02K 11/215 - Dispositifs utilisant un effet magnétique, p. ex. des éléments à effet Hall ou magnéto-résistifs
  • H02P 29/00 - Dispositions pour la régulation ou la commande des moteurs électriques, adaptées à des moteurs à courant alternatif et à courant continu

51.

AUTOMATIC FILL CONTROL TECHNIQUE


Numéro d'application US2015051232
Numéro de publication 2016/044838
Statut Délivré - en vigueur
Date de dépôt 2015-09-21
Date de publication 2016-03-24
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Estrada, Jesus
  • Patel, Akshaykumar

Abrégé

Apparatus features a microcontroller configured to: receive signaling containing information about a measured change of a magnetic field created by a magnetic circuit driving a motor; and determine corresponding signaling containing information about the speed of rotation of the motor, based upon the signaling received. The microcontroller provides control signaling containing information to control the operation of the motor, including where the motor control is used to control the flow of fluids from a pump. A Hall Effect Sensor is used to sense the magnetic flux and provide the signaling in the form of a feedback signal for implementing motor control. The motor housing has a slot, the Hall Effect sensor is mounted external the motor housing over the slot, and a ferromagnetic bridge is arranged over the Hall Effect sensor to close the magnetic circuit and cause more flux to go through the Hall Effect sensor.

Classes IPC  ?

  • H02P 7/00 - Dispositions pour réguler ou commander la vitesse ou le couple de moteurs électriques à courant continu

52.

Low profile pump


Numéro d'application 29520980
Numéro de brevet D0752110
Statut Délivré - en vigueur
Date de dépôt 2015-03-19
Date de la première publication 2016-03-22
Date d'octroi 2016-03-22
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Cook, Gregory
  • Lopes, Jeffrey D.

53.

AUTOMATIC FILL CONTROL TECHNIQUE


Numéro de document 02958750
Statut Délivré - en vigueur
Date de dépôt 2015-08-17
Date de disponibilité au public 2016-02-18
Date d'octroi 2020-10-13
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Phillips, David L.
  • Estrada, Jesus

Abrégé

A pump includes a signal processor that receives signaling containing information about a low level of a liquid sensed in an appliance reservoir to be supplied to an appliance that uses the liquid to dispense a flavored beverage, and also about when the appliance reservoir is refilled based upon an indication that forms part of an appliance reservoir refill level calibration procedure programmed by an appliance user; and determines corresponding signaling containing information about automatically refilling the liquid in the appliance reservoir, based upon the signaling received.

Classes IPC  ?

  • B67D 1/08 - Appareils ou dispositifs pour débiter des boissons à la pression Détails
  • G05D 9/12 - Commande du niveau, p. ex. en commandant la quantité du matériau emmagasiné dans un réservoir caractérisée par l'utilisation de moyens électriques

54.

Automatic fill control technique


Numéro d'application 14827430
Numéro de brevet 10838436
Statut Délivré - en vigueur
Date de dépôt 2015-08-17
Date de la première publication 2016-02-18
Date d'octroi 2020-11-17
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Phillips, David L.
  • Estrada, Jesus

Abrégé

A pump includes a signal processor that receives signaling containing information about a low level of a liquid sensed in an appliance reservoir to be supplied to an appliance that uses the liquid to dispense a flavored beverage, and also about when the appliance reservoir is refilled based upon an indication that forms part of an appliance reservoir refill level calibration procedure programmed by an appliance user; and determines corresponding signaling containing information about automatically refilling the liquid in the appliance reservoir, based upon the signaling received.

Classes IPC  ?

  • G05D 9/12 - Commande du niveau, p. ex. en commandant la quantité du matériau emmagasiné dans un réservoir caractérisée par l'utilisation de moyens électriques
  • G05D 7/06 - Commande de débits caractérisée par l'utilisation de moyens électriques
  • G05D 9/00 - Commande du niveau, p. ex. en commandant la quantité du matériau emmagasiné dans un réservoir

55.

AUTOMATIC FILL CONTROL TECHNIQUE


Numéro d'application US2015045463
Numéro de publication 2016/025939
Statut Délivré - en vigueur
Date de dépôt 2015-08-17
Date de publication 2016-02-18
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Phillips, David L.
  • Estrada, Jesus

Abrégé

A pump includes a signal processor that receives signaling containing information about a low level of a liquid sensed in an appliance reservoir to be supplied to an appliance that uses the liquid to dispense a flavored beverage, and also about when the appliance reservoir is refilled based upon an indication that forms part of an appliance reservoir refill level calibration procedure programmed by an appliance user; and determines corresponding signaling containing information about automatically refilling the liquid in the appliance reservoir, based upon the signaling received.

Classes IPC  ?

  • G01F 23/00 - Indication ou mesure du niveau des liquides ou des matériaux solides fluents, p. ex. indication en fonction du volume ou indication au moyen d'un signal d'alarme

56.

IMPELLER WITH AXIALLY CURVING VANE EXTENSIONS TO PREVENT AIRLOCK


Numéro d'application US2015043982
Numéro de publication 2016/022781
Statut Délivré - en vigueur
Date de dépôt 2015-08-06
Date de publication 2016-02-11
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Lopes, Jeffrey D.

Abrégé

A pump has a housing that includes an inlet to receive a liquid to be pumped, an outlet to provide the liquid being pumped, a pumping chamber between the inlet/outlet; and a motor shaft to rotate in the pumping chamber. The impeller is arranged on the motor shaft, includes radially curved vanes to rotate inside the pumping chamber to pump the liquid from the pumping chamber to the outlet; and includes anti-airlock vanes formed as a set of axially curving vane extensions that extend along the axis of the shaft, rotate with one part inside the pumping chamber, protrude through the inlet and rotate with another part outside the inlet for submerging in liquid to be pumped underneath the pump, draw the liquid through the inlet into the pumping chamber, and provide the liquid to the radially curved vanes to generate pressure to force entrapped air from the pumping chamber.

Classes IPC  ?

  • F04D 7/04 - Pompes adaptées à la manipulation de liquides particuliers, p. ex. par choix de matériaux spéciaux pour les pompes ou pièces de pompe du type centrifuge les fluides étant visqueux ou non homogènes

57.

IMPELLER WITH AXIALLY CURVING VANE EXTENSIONS TO PREVENT AIRLOCK


Numéro de document 02957279
Statut Délivré - en vigueur
Date de dépôt 2015-08-06
Date de disponibilité au public 2016-02-11
Date d'octroi 2020-08-04
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Lopes, Jeffrey D.

Abrégé

A pump has a housing that includes an inlet to receive a liquid to be pumped, an outlet to provide the liquid being pumped, a pumping chamber between the inlet/outlet; and a motor shaft to rotate in the pumping chamber. The impeller is arranged on the motor shaft, includes radially curved vanes to rotate inside the pumping chamber to pump the liquid from the pumping chamber to the outlet; and includes anti-airlock vanes formed as a set of axially curving vane extensions that extend along the axis of the shaft, rotate with one part inside the pumping chamber, protrude through the inlet and rotate with another part outside the inlet for submerging in liquid to be pumped underneath the pump, draw the liquid through the inlet into the pumping chamber, and provide the liquid to the radially curved vanes to generate pressure to force entrapped air from the pumping chamber.

Classes IPC  ?

  • F04D 1/14 - Pompes élevant le fluide par la force centrifuge dans un bol conique tournant autour d'un axe vertical
  • F04D 9/00 - AmorçagePrévention du blocage par la vapeur
  • F04D 13/02 - Ensembles comprenant les pompes et leurs moyens d'entraînement
  • F04D 29/22 - Rotors spécialement pour les pompes centrifuges
  • F04D 29/24 - Aubes
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges

58.

Pump head coupling with twist-lock connections


Numéro d'application 14794284
Numéro de brevet 10047737
Statut Délivré - en vigueur
Date de dépôt 2015-07-08
Date de la première publication 2016-01-28
Date d'octroi 2018-08-14
Propriétaire Flow Control LLC (USA)
Inventeur(s) Meza, Humberto V.

Abrégé

A pump features: A motor having a front end bell (FEB) with a coupling portion having twist lock style (TLS) connections with locking portions, and an outer surface with a detent; and a pump head (PH) including a PH portion having a PH coupling portion with corresponding TLS connections and corresponding locking portions with locking stops. The PH portion has an outer surface having a threaded orifice. The TLS connections couple together when the FEB and PH coupling portions are pushed together. The locking portions engage when the FEB and PH coupling portions twist together about the longitudinal axis of the pump. The locking stops abut against the locking portions to stop the FEB and PH coupling portions from twisting further, so the detent and the threaded orifice align to receive the LP, locking the motor and PH together.

Classes IPC  ?

  • F04B 39/14 - Dispositions permettant un montage ou démontage commodes
  • F04B 43/04 - Pompes ayant un entraînement électrique
  • F04B 53/22 - Dispositions pour l'assemblage ou le démontage rapide
  • F04B 17/03 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs électriques
  • F04B 35/04 - Pompes à piston spécialement adaptées aux fluides compressibles et caractérisées par les moyens d'entraînement de leurs organes de travail ou par leur combinaison avec les machines motrices ou moteurs qui les entraînent ou bien par leurs adaptations à cet effet, non prévues ailleurs les moyens étant électriques
  • F04B 39/12 - Carcasses d'enveloppeCylindresCulassesConnexions des tubulures pour fluide
  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide

59.

METHOD FOR ATTACHING PUMPS TO ELECTRIC MOTORS


Numéro de document 02954535
Statut Délivré - en vigueur
Date de dépôt 2015-07-08
Date de disponibilité au public 2016-01-14
Date d'octroi 2020-07-14
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Meza, Humberto V.

Abrégé

A pump features a motor, a pump head (PH) and a locking pin (LP) that are uniquely coupled together. The motor has a front end bell (FEB) with a FEB coupling portion configured with twist lock style (TLS) connections with locking portions, and an outer surface with a detent. Each locking portion engages a respective corresponding locking portion when the FEB coupling portion, and the PH coupling portion is twisted together in relation to one another about the longitudinal axis of the pump. Each locking stop abuts against a respective locking portion to stop the FEB coupling portion and the PH coupling portion from twisting together, so the detent and the threaded orifice are aligned to receive the LP, and the motor and pump head are locked together and cannot be pulled apart.

Classes IPC  ?

  • F04B 43/04 - Pompes ayant un entraînement électrique
  • F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide
  • F04B 53/22 - Dispositions pour l'assemblage ou le démontage rapide

60.

METHOD FOR ATTACHING PUMPS TO ELECTRIC MOTORS


Numéro d'application US2015039536
Numéro de publication 2016/007614
Statut Délivré - en vigueur
Date de dépôt 2015-07-08
Date de publication 2016-01-14
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Meza, Humberto V.

Abrégé

A pump features a motor, a pump head (PH) and a locking pin (LP) that are uniquely coupled together. The motor has a front end bell (FEB) with a FEB coupling portion configured with twist lock style (TLS) connections with locking portions, and an outer surface with a detent. Each locking portion engages a respective corresponding locking portion when the FEB coupling portion, and the PH coupling portion is twisted together in relation to one another about the longitudinal axis of the pump. Each locking stop abuts against a respective locking portion to stop the FEB coupling portion and the PH coupling portion from twisting together, so the detent and the threaded orifice are aligned to receive the LP, and the motor and pump head are locked together and cannot be pulled apart.

Classes IPC  ?

  • F04B 39/00 - Parties constitutives, détails ou accessoires de pompes ou de systèmes de pompage spécialement adaptés aux fluides compressibles, non prévus dans les groupes ou présentant un intérêt autre que celui visé par ces groupes
  • F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide
  • F04B 53/22 - Dispositions pour l'assemblage ou le démontage rapide

61.

DIAPHRAGM PUMP UTILIZING DUCKBILL VALVES, MULTI-DIRECTIONAL PORTS AND FLEXIBLE ELECTRICAL CONNECTIVITY


Numéro d'application US2015035968
Numéro de publication 2015/195624
Statut Délivré - en vigueur
Date de dépôt 2015-06-16
Date de publication 2015-12-23
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Tran, Derrick T.
  • Perkins, Bernard L.

Abrégé

Diaphragm pump features upper/lower diaphragm pumping assemblies (U/LDPAs) for pumping fluid and a manifold assembly arranged therebetween. The manifold assembly include a manifold body having an inlet with dual inlet ports and an inlet chamber to receive the fluid from a source; an inlet check valve assembly channel having an inlet duckbill check valve assembly (DCVA) arranged therein to receive the fluid from the dual inlet ports; U/LDPAs orifices having the U/LDPA arranged therein to receive the fluid from the inlet DCVA via first upper/lower manifold conduits and provide the fluid from the U/LDPAs via second upper/lower manifold conduits; an outlet check valve assembly channel having an outlet DCVA arranged therein to receive the fluid from the U/LDPAs; and an outlet having dual outlet ports and an outlet chamber to receive the fluid from the U/LDPAs and provide the fluid from the pump to a outlet source.

Classes IPC  ?

  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes

62.

DIAPHRAGM PUMP UTILIZING DUCKBILL VALVES, MULTI-DIRECTIONAL PORTS AND FLEXIBLE ELECTRICAL CONNECTIVITY


Numéro de document 02952616
Statut Délivré - en vigueur
Date de dépôt 2015-06-16
Date de disponibilité au public 2015-12-23
Date d'octroi 2020-11-10
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Tran, Derrick T.
  • Perkins, Bernard L.

Abrégé

Diaphragm pump features upper/lower diaphragm pumping assemblies (U/LDPAs) for pumping fluid and a manifold assembly arranged therebetween. The manifold assembly include a manifold body having an inlet with dual inlet ports and an inlet chamber to receive the fluid from a source; an inlet check valve assembly channel having an inlet duckbill check valve assembly (DCVA) arranged therein to receive the fluid from the dual inlet ports; U/LDPAs orifices having the U/LDPA ananged therein to receive the fluid from the inlet DCVA via first upper/lower manifold conduits and provide the fluid from the U/LDPAs via second upper/lower manifold conduits; an outlet check valve assembly channel having an outlet DCVA arranged therein to receive the fluid from the U/LDPAs; and an outlet having dual outlet ports and an outlet chamber to receive the fluid from the U/LDPAs and provide the fluid from the pump to a outlet source.

Classes IPC  ?

  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F04B 53/10 - ClapetsAgencement des clapets
  • F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide

63.

SINGLE PISTON FOUNDATION BAG-IN-BOX (BIB) PUMP


Numéro d'application US2015034703
Numéro de publication 2015/188185
Statut Délivré - en vigueur
Date de dépôt 2015-06-08
Date de publication 2015-12-10
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Verdugo, Christopher H.
  • Villagomez, Manuel
  • Meza, Humberto V.

Abrégé

A pump includes a liquid housing having a liquid chamber with a piston/diaphragm assembly arranged therein that responds to a suction stroke and draws liquid into the liquid chamber, and responds to a pressure stroke and provides liquid from the liquid chamber; and a gas housing having a slide valve assembly separating first and second gas chambers. The slide valve assembly responds to a suction-to-pressure-force at the suction stroke conclusion, changes from a suction-to-pressure stroke state, provides gas from the first to second gas chamber through the slide valve assembly, and provides the pressure stroke so liquid passes from the liquid chamber; and responds to a pressure-to-suction-force at the pressure stroke conclusion, changes from the pressure-to-suction stroke state, provides gas from the second chamber through the slide valve assembly, and provides the suction stroke so the liquid is drawn into the liquid chamber.

Classes IPC  ?

  • F04B 43/06 - Pompes ayant un entraînement par fluide

64.

BILGE PUMP HAVING CONCEALED AIR-LOCK VENT


Numéro de document 02940851
Statut Délivré - en vigueur
Date de dépôt 2015-02-24
Date de disponibilité au public 2015-09-03
Date d'octroi 2019-02-05
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Moormann, Randall H.

Abrégé

The pump has a pump body having a pump body portion with a vent hole allowing air entrapped in the pump body to bleed out to atmosphere and liquid to fill the pump body in order to get the pump running, and includes a tab receiving portion having a rim defining an opening; and a pump/strainer assembly that includes a base with slots/openings formed therein to receive and strain liquid for pumping, and includes a strainer retaining tab with a raised rim received in the opening of the tab receiving portion and circumferentially engaged by the rim of the opening to hold together the pump/strainer assembly and the pump body. The tab receiving portion and the strainer retaining tab are dimensioned to conceal the vent hole and prevent the liquid from bleeding through the vent hole and squirting outside of the pump body when the pump is running.

Classes IPC  ?

  • F04D 9/00 - AmorçagePrévention du blocage par la vapeur
  • F04D 29/40 - Carters d'enveloppeTubulures pour le fluide énergétique
  • F04D 29/70 - Grilles d'aspirationFiltresSéparateurs de poussièreNettoyage

65.

Bilge pump having concealed air-lock vent


Numéro d'application 14193269
Numéro de brevet 09829000
Statut Délivré - en vigueur
Date de dépôt 2014-02-28
Date de la première publication 2015-09-03
Date d'octroi 2017-11-28
Propriétaire Flow Control LLC. (USA)
Inventeur(s) Moormann, Randall H.

Abrégé

The pump has a pump body having a pump body portion with a vent hole to allow air entrapped in the pump body to bleed out to atmosphere and allow liquid to fill the pump body in order to get the pump running, and also includes a tab receiving portion having a rim defining an opening; and a pump/strainer assembly that includes a base with slots/openings formed therein to receive and strain liquid to be pumped, and includes a strainer retaining tab with a raised rim to be received in the opening of the tab receiving portion and circumferentially engaged by the rim of the opening to hold together the pump/strainer assembly and the pump body. The at least one tab receiving portion and the strainer retaining tab are dimensioned to conceal the vent hole and substantially prevent the liquid from bleeding through the vent hole and squirting outside of the pump body when the pump is running.

Classes IPC  ?

  • F04D 29/70 - Grilles d'aspirationFiltresSéparateurs de poussièreNettoyage
  • F04D 9/00 - AmorçagePrévention du blocage par la vapeur
  • F04D 29/40 - Carters d'enveloppeTubulures pour le fluide énergétique

66.

BILGE PUMP ARRANGEMENT HAVING BACK FLOW PREVENTER


Numéro d'application US2015017180
Numéro de publication 2015/130623
Statut Délivré - en vigueur
Date de dépôt 2015-02-24
Date de publication 2015-09-03
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Moormann, Randall H.
  • Raabe, Todd R.

Abrégé

Apparatus includes a pump for pumping liquid having a pump housing outlet nozzle; and a back flow preventer assembly having an inlet end coupled to the outlet nozzle, having an outlet end coupled to an outlet hose for connecting to an outlet exiting a wall of a vehicle, and having a duckbill-type check valve to provide liquid being pumped in one direction from the reservoir of the vehicle to the outlet exiting the wall of the vehicle via the outlet hose, and to prevent residue liquid left in the outlet hose from flowing back into the pump and returning to the reservoir once the pump has completed pumping if the outlet exiting the wall of the vehicle is above the outlet nozzle, and to prevent an on/off oscillation of the pump depending on the volume of residue liquid left in the outlet hose.

Classes IPC  ?

  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable

67.

Bilge pump arrangement having back flow preventer


Numéro d'application 14193324
Numéro de brevet 10302090
Statut Délivré - en vigueur
Date de dépôt 2014-02-28
Date de la première publication 2015-09-03
Date d'octroi 2019-05-28
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Moormann, Randall H.
  • Raabe, Todd R.

Abrégé

Apparatus for providing liquid from a reservoir of liquid contained in a vehicle/vessel or other equipment, featuring a pump for pumping liquid having a pump housing outlet nozzle; and a back flow preventer assembly having an inlet end to couple to the outlet nozzle, having an outlet end to couple to an outlet hose for connecting to an outlet exiting a wall of a vehicle, vessel or other equipment, and having a duckbill-type check valve to provide liquid being pumped in one direction from the reservoir of the vehicle, vessel or other equipment to the outlet exiting the wall of the vehicle, vessel or other equipment via the outlet hose, and also configured to prevent residue liquid left in the outlet hose from flowing back into the pump and returning to the reservoir once the pump has completed pumping if the outlet exiting the wall of the vehicle, vessel or other equipment is above the outlet nozzle, so as to prevent on an on/off oscillation of the pump depending on the volume of residue liquid left in the outlet hose.

Classes IPC  ?

  • F04D 1/04 - Pompes hélicocentrifuges
  • F04D 15/00 - Commande, p. ex. régulation de pompes, d'installations ou de systèmes de pompage
  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges
  • F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles

68.

ANTI-AIRLOCK VALVE ASSEMBLY


Numéro d'application US2015017177
Numéro de publication 2015/130620
Statut Délivré - en vigueur
Date de dépôt 2015-02-24
Date de publication 2015-09-03
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Moormann, Randall H.

Abrégé

A pump, having a pump housing with an impeller arranged therein, features an anti-airlock valve assembly configured with a valve housing having a passageway configured with a vent hole to allow air to bleed out of the pump housing into the atmosphere so liquid can fill the pump housing, rise and engage the impeller in order to get the pump running; and a valve ball arranged in the passageway, the valve ball configured to rest against one part of the passageway so air can pass out of the vent hole, and also configured to be light or buoyant enough to respond to the liquid filling the pump housing, float upwardly and rest against another part of the passageway so as not to allow water to escape readily from the vent hole after the liquid rises to a sufficient level and substantially engages the impeller.

Classes IPC  ?

  • F04D 9/00 - AmorçagePrévention du blocage par la vapeur
  • F04D 9/02 - Pompes à auto-amorçage

69.

BILGE PUMP HAVING CONCEALED AIR-LOCK VENT


Numéro d'application US2015017179
Numéro de publication 2015/130622
Statut Délivré - en vigueur
Date de dépôt 2015-02-24
Date de publication 2015-09-03
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Moormann, Randall H.

Abrégé

The pump has a pump body having a pump body portion with a vent hole allowing air entrapped in the pump body to bleed out to atmosphere and liquid to fill the pump body in order to get the pump running, and includes a tab receiving portion having a rim defining an opening; and a pump/strainer assembly that includes a base with slots/openings formed therein to receive and strain liquid for pumping, and includes a strainer retaining tab with a raised rim received in the opening of the tab receiving portion and circumferentially engaged by the rim of the opening to hold together the pump/strainer assembly and the pump body. The tab receiving portion and the strainer retaining tab are dimensioned to conceal the vent hole and prevent the liquid from bleeding through the vent hole and squirting outside of the pump body when the pump is running.

Classes IPC  ?

  • B01D 35/28 - Filtres non prévus ailleurs
  • B63B 13/00 - Conduits pour l'épuisement ou le ballastageÉquipement automatique pour l'assèchementDalots
  • F04B 53/20 - Filtrage

70.

Low profile pump


Numéro d'application 29480850
Numéro de brevet D0735240
Statut Délivré - en vigueur
Date de dépôt 2014-01-30
Date de la première publication 2015-07-28
Date d'octroi 2015-07-28
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Cook, Gregory
  • Lopes, Jeffrey D.

71.

DISPENSING SYSTEM, INCLUDING FOR DISPENSING FLAVORED COFFEE SYRUPS


Numéro d'application US2014054739
Numéro de publication 2015/035369
Statut Délivré - en vigueur
Date de dépôt 2014-09-09
Date de publication 2015-03-12
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Phillips, David L.
  • King, Robert W.
  • Webber, David S.

Abrégé

A dispensing system for dispensing flavored liquids, e.g., flavored coffee syrups, featuring a signal processor in combination with a flavored liquid dispenser system. The signal processor is configured to receive signaling containing information about a flavored liquid selected from a plurality of flavors and a quantity selected from a plurality of quantities, and provide corresponding signaling containing information to dispense the flavored liquid selected in the quantity selected. The flavored liquid dispenser system is configured to receive the corresponding signaling and provide the flavored liquid selected in the quantity selected.

Classes IPC  ?

  • A23F 5/46 - Arômes de caféHuile de caféAromatisation du café ou de l'extrait de café
  • A47J 31/40 - Appareils à préparer des boissons avec des moyens de distribution pour ajouter une quantité mesurée d'ingrédients, p. ex. du café, de l'eau, du sucre, du cacao, du lait, du thé
  • A47J 31/41 - Appareils à préparer des boissons avec des moyens de distribution pour ajouter une quantité mesurée d'ingrédients, p. ex. du café, de l'eau, du sucre, du cacao, du lait, du thé d'ingrédients liquides
  • A47J 42/50 - Dispositifs d'alimentation, p. ex. entonnoirsRécipients d'alimentation
  • B65D 81/32 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu pour emballer plusieurs matériaux différents qui doivent être maintenus séparés avant d’être mélangés

72.

HIGH VISCOSITY PORTION PUMP


Numéro d'application US2014053682
Numéro de publication 2015/031884
Statut Délivré - en vigueur
Date de dépôt 2014-09-02
Date de publication 2015-03-05
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Verdugo, Christopher H.
  • Perkins, Bernard L.
  • Meza, Humberto V.

Abrégé

A high viscosity portion pump system has a single piston portion pump having a piston/diaphragm assembly arranged on a piston shaft forming liquid and gas chambers, which moves from a starting-position and provides high viscosity fluid from the liquid chamber when gas is received by the gas chamber; has an elastic member arranged on a retainer coupled to the shaft in a compartment in a pump housing, which moves the assembly back to the position and draws further fluid into the liquid chamber when the gas is released; and has a piston position sensor that responds to the position of the shaft and provides signaling containing information about when the assembly is in the position or completed a stroke from the position. A gas control system includes a signal processor that receives the signaling, and provides corresponding signaling containing information about when to provide or release the gas.

Classes IPC  ?

  • F04B 43/06 - Pompes ayant un entraînement par fluide

73.

High viscosity portion pump


Numéro d'application 14474775
Numéro de brevet 10267303
Statut Délivré - en vigueur
Date de dépôt 2014-09-02
Date de la première publication 2015-03-05
Date d'octroi 2019-04-23
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Verdugo, Christopher H.
  • Perkins, Bernard L.
  • Meza, Humberto V.

Abrégé

A high viscosity portion pump system has a single piston portion pump having a piston/diaphragm assembly arranged on a piston shaft forming liquid and gas chambers, which moves from a starting-position and provides high viscosity fluid from the liquid chamber when gas is received by the gas chamber; has an elastic member arranged on a retainer coupled to the shaft in a compartment in a pump housing, which moves the assembly back to the position and draws further fluid into the liquid chamber when the gas is released; and has a piston position sensor that responds to the position of the shaft and provides signaling containing information about when the assembly is in the position or completed a stroke from the position. A gas control system includes a signal processor that receives the signaling, and provides corresponding signaling containing information about when to provide or release the gas.

Classes IPC  ?

  • F04B 7/02 - "Machines" ou pompes à piston caractérisées par un entraînement desmodromique des organes du mécanisme de distribution le mécanisme de distribution étant actionnés par un fluide
  • F04B 43/00 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles
  • F04B 49/03 - Commande d'arrêt, de démarrage, de décharge ou de ralenti par clapets
  • F04B 49/06 - Commande utilisant l'électricité
  • F04B 43/067 - Pompes ayant un entraînement par fluide le fluide étant déplacé directement par un piston
  • F04B 43/073 - Pompes ayant un entraînement par fluide le fluide d'entraînement étant commandé par au moins un clapet

74.

Air operated diaphragm pump


Numéro d'application 14391110
Numéro de brevet 10240591
Statut Délivré - en vigueur
Date de dépôt 2013-04-09
Date de la première publication 2015-02-19
Date d'octroi 2019-03-26
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Verdugo, Christopher H.
  • Wright, Peter M.
  • Jackson, Jr., Jimmie L.

Abrégé

An air operated diaphragm pump is provided a housing having an orifice formed therein; a gas passageway configured to provide gas through the air operated diaphragm pump in order to pump syrup through the air operated diaphragm pump; a syrup passageway configured to provide the syrup through the air operated diaphragm pump when the gas is passed though the gas passageway, part of the syrup passageway configured in fluidic communication with the orifice of the housing with an inside pressure greater than an external pressure of the outside atmosphere when the syrup is provided through the air operate diaphragm pump; and an indicator arrangement configured or arranged in the orifice of the housing to communicate with the syrup passageway, and to respond or activate when a vacuum force exceeds a predetermined level and provide a visual indication when the syrup is no longer provided through the air operated diaphragm pump.

Classes IPC  ?

  • F04B 49/03 - Commande d'arrêt, de démarrage, de décharge ou de ralenti par clapets
  • F04B 43/073 - Pompes ayant un entraînement par fluide le fluide d'entraînement étant commandé par au moins un clapet
  • F04B 43/00 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles
  • F04B 49/10 - Autres mesures de sécurité
  • G01L 19/10 - Moyens pour l'indication ou l'enregistrement, p. ex. pour l'indication à distance mécaniques

75.

DEBRIS REMOVING IMPELLER BACKVANE


Numéro de document 02915631
Statut Délivré - en vigueur
Date de dépôt 2014-06-23
Date de disponibilité au public 2014-12-24
Date d'octroi 2020-06-02
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Lopes, Jeffrey D.

Abrégé

A pump having an impeller with front and back sides, for rotating on a shaft with the front side nearest an inlet and the back side nearest a motor housing, to provide a main flow of the liquid from the inlet to the outlet and a rear impeller flow of the liquid in an area between the impeller's back side and the motor housing. The back side having a logarithmic spiral-shaped vane to constantly sweep, and expel debris from, the area.

Classes IPC  ?

76.

DEBRIS REMOVING IMPELLER BACKVANE


Numéro d'application US2014043660
Numéro de publication 2014/205439
Statut Délivré - en vigueur
Date de dépôt 2014-06-23
Date de publication 2014-12-24
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Lopes, Jeffrey D.

Abrégé

A pump having an impeller with front and back sides, for rotating on a shaft with the front side nearest an inlet and the back side nearest a motor housing, to provide a main flow of the liquid from the inlet to the outlet and a rear impeller flow of the liquid in an area between the impeller's back side and the motor housing. The back side having a logarithmic spiral-shaped vane to constantly sweep, and expel debris from, the area.

Classes IPC  ?

77.

SOLAR POWERED PORTABLE SUBMERSIBLE WATER PUMP


Numéro d'application US2014040858
Numéro de publication 2014/197563
Statut Délivré - en vigueur
Date de dépôt 2014-06-04
Date de publication 2014-12-11
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s) Rulli, Samuel R.

Abrégé

A pumping system for pumping water from streams, ponds or shallow wells having a predetermined depth, featuring a reel assembly to rotate so as to receive, roll-up and retain a hose; a submersible pump assembly having submersible pumps, each connected to a manifold in parallel so as to form a parallel pump configuration, the manifold having a hose connection to couple to the hose; a solar panel to couple and electrically power the submersible pump assembly; and a portable cart having a frame with a first frame part to affix to the reel assembly, a second frame part to affix to the solar panel, a third frame part to detachably receive and retain the submersible pump assembly, and a fourth frame part to affix to the wheel assembly to roll the pump system to a remote location for pumping water in areas with little or no access to grid electricity or liquid fuel.

Classes IPC  ?

  • B01D 35/00 - Dispositifs filtrants ayant des particularités non couvertes spécifiquement par les groupes , applications non couvertes spécifiquement par les groupes Dispositifs auxiliaires pour la filtrationStructure du carter de filtre
  • B01D 35/02 - Filtres adaptés à des endroits particuliers, p. ex. conduites, pompes, robinets
  • C02F 1/00 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout

78.

Low profile pump with the ability to be mounted in various configurations


Numéro d'application 14219508
Numéro de brevet 09810241
Statut Délivré - en vigueur
Date de dépôt 2014-03-19
Date de la première publication 2014-11-20
Date d'octroi 2017-11-07
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Gell, Iii, William A.
  • Lopes, Jeffrey D.
  • Estrada, Jesus
  • Moormann, Randall H.

Abrégé

A pumping system featuring a pump chamber configured with a central portion having a tangential outlet, and configured with a tubular coupling end portion having inwardly flexible rim portions on one side; and a mounting base, having a circular portion with an inner circumferential rim configured to receive and engage the inwardly flexible rim portions of the tubular coupling portion of the pump chamber so as to be rotationally coupled to the pumping chamber so that the pumping chamber may be rotated 360° in relation to the mounting base.

Classes IPC  ?

  • F04D 29/60 - MontageAssemblageDémontage
  • F04D 13/02 - Ensembles comprenant les pompes et leurs moyens d'entraînement
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges
  • F04D 13/08 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité pour utilisation en position immergée
  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable
  • F04D 29/46 - Moyens de guidage du fluide, p. ex. diffuseurs réglables

79.

PUMP USING MULTI VOLTAGE ELECTRONICS WITH RUN DRY AND OVER CURRENT PROTECTION


Numéro de document 02910409
Statut Délivré - en vigueur
Date de dépôt 2014-04-30
Date de disponibilité au public 2014-11-06
Date d'octroi 2017-09-26
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Phillips, David L.
  • Meza, Humberto Valenzuela
  • Tran, Derrick T.

Abrégé

A pump system features a power adapter and a pump having a signal processor. The power adapter includes voltage settings that respond to a voltage setting by a user and provide a selected voltage. The signal processor receives signaling containing information about the selected voltage supplied to a motor to run the pump, and also containing information about whether a current draw of the pump is lower than a predetermined low current level or is higher than a predetermined high current level; and determines whether to shut off the pump after a predetermined time, based on the signaling received.

Classes IPC  ?

  • F04B 17/03 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs électriques
  • F04B 49/06 - Commande utilisant l'électricité
  • H02P 7/14 - Dispositions pour réguler ou commander la vitesse ou le couple de moteurs électriques à courant continu pour réguler ou commander individuellement un moteur dynamo-électrique à courant continu en faisant varier le champ ou le courant d'induit par commande manuelle, sans puissance auxiliaire de la tension appliquée à l'induit avec ou sans commande du champ

80.

PUMP USING MULTI VOLTAGE ELECTRONICS WITH RUN DRY AND OVER CURRENT PROTECTION


Numéro d'application US2014036029
Numéro de publication 2014/179394
Statut Délivré - en vigueur
Date de dépôt 2014-04-30
Date de publication 2014-11-06
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Phillips, David L.
  • Meza, Humberto Valenzuela
  • Tran, Derrick T.

Abrégé

A pump system features a power adapter and a pump having a signal processor. The power adapter includes voltage settings that respond to a voltage setting by a user and provide a selected voltage. The signal processor receives signaling containing information about the selected voltage supplied to a motor to run the pump, and also containing information about whether a current draw of the pump is lower than a predetermined low current level or is higher than a predetermined high current level; and determines whether to shut off the pump after a predetermined time, based on the signaling received.

Classes IPC  ?

  • F04B 17/03 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs électriques

81.

Pump using multi voltage electronics with run dry and over current protection


Numéro d'application 14265587
Numéro de brevet 09745974
Statut Délivré - en vigueur
Date de dépôt 2014-04-30
Date de la première publication 2014-10-30
Date d'octroi 2017-08-29
Propriétaire FLOW CONTROL LLC (USA)
Inventeur(s)
  • Phillips, David L.
  • Meza, Humberto V.
  • Tran, Derrick T.

Abrégé

A pump system features a power adapter and a pump having a signal processor. The power adapter includes voltage settings that respond to a voltage setting by a user and provide a selected voltage. The signal processor receives signaling containing information about the selected voltage supplied to a motor to run the pump, and also containing information about whether a current draw of the pump is lower than a predetermined low current level or is higher than a predetermined high current level; and determines whether to shut off the pump after a predetermined time, based on the signaling received.

Classes IPC  ?

  • F04B 17/03 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs électriques
  • F04B 49/06 - Commande utilisant l'électricité

82.

Methodology to define optimal sun position using the capability provided by smart phone technology


Numéro d'application 14208300
Numéro de brevet 09325364
Statut Délivré - en vigueur
Date de dépôt 2014-03-13
Date de la première publication 2014-10-23
Date d'octroi 2016-04-26
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Teichmann, Keith L.
  • Toporkov, Leonid

Abrégé

A smart phone for using to optimize the energy production of a solar panel in real time by a user features a signal processor to receive GPS signaling containing information about the global position of the smart phone, and input signaling containing control information to initiate a GUI algorithm in the signal processor to determine visual and/or audio cues for a user on a proper alignment of a solar panel for optimal solar energy collection efficiency; and provide display imaging signaling from a screen of the smart phone, or audio signaling from a speaker in the smart phone containing information about the visual and/or audio cues for the user on the proper alignment of the solar panel for optimal solar efficiency, so as to enable the user to simultaneously adjust the planar orientation of the solar panel having the smart phone placed thereon, based on the visual and audio cues.

Classes IPC  ?

  • H04M 1/00 - Équipement de sous-station, p. ex. pour utilisation par l'abonné
  • H04B 1/3827 - Émetteurs-récepteurs portatifs
  • H04N 5/232 - Dispositifs pour la commande des caméras de télévision, p.ex. commande à distance

83.

METHODOLOGY TO DEFINE OPTIMAL SUN POSITION USING THE CAPABILITY PROVIDED BY SMART PHONE TECHNOLOGY


Numéro d'application US2014025777
Numéro de publication 2014/160082
Statut Délivré - en vigueur
Date de dépôt 2014-03-13
Date de publication 2014-10-02
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Teichmann, Keith L.
  • Toporkov, Leonid

Abrégé

A smart phone for using to optimize the energy production of a solar panel in real time by a user features a signal processor to receive GPS signaling containing information about the global position of the smart phone, and input signaling containing control information to initiate a GUI algorithm in the signal processor to determine visual and/or audio cues for a user on a proper alignment of a solar panel for optimal solar energy collection efficiency; and provide display imaging signaling from a screen of the smart phone, or audio signaling from a speaker in the smart phone containing information about the visual and/or audio cues for the user on the proper alignment of the solar panel for optimal solar efficiency, so as to enable the user to simultaneously adjust the planar orientation of the solar panel having the smart phone placed thereon, based on the visual and audio cues.

Classes IPC  ?

  • G05D 23/27 - Commande de la température caractérisée par l'utilisation de moyens électriques avec l'élément sensible répondant au rayonnement

84.

LOW PROFILE PUMP WITH THE ABILITY TO BE MOUNTED IN VARIOUS CONFIGURATIONS


Numéro de document 02906969
Statut Délivré - en vigueur
Date de dépôt 2014-03-19
Date de disponibilité au public 2014-09-25
Date d'octroi 2020-01-14
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Gell, William A., Iii
  • Lopes, Jeffrey D.
  • Estrada, Jesus
  • Moormann, Randall H.

Abrégé

A pumping system featuring a pump chamber configured with a central portion having a tangential outlet, and configured with a tubular coupling end portion having inwardly flexible rim portions on one side; and a mounting base, having a circular portion with an inner circumferential rim configured to receive and engage the inwardly flexible rim portions of the tubular coupling portion of the pump chamber so as to be rotationally coupled to the pumping chamber so that the pumping chamber may be rotated 360 in relation to the mounting base.

Classes IPC  ?

  • F04D 1/12 - Pompes avec des godets ou organes d'agitation analogues pénétrant dans le fluide circulant dans un bol
  • F04D 13/08 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité pour utilisation en position immergée
  • F04D 29/42 - Carters d'enveloppeTubulures pour le fluide énergétique pour pompes radiales ou hélicocentrifuges
  • F04D 29/60 - MontageAssemblageDémontage

85.

LOW PROFILE PUMP WITH THE ABILITY TO BE MOUNTED IN VARIOUS CONFIGURATIONS


Numéro d'application US2014031212
Numéro de publication 2014/153403
Statut Délivré - en vigueur
Date de dépôt 2014-03-19
Date de publication 2014-09-25
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Gell, Iii, William, A.
  • Lopes, Jeffrey, D.
  • Estrada, Jesus
  • Moormann, Randall, H.

Abrégé

A pumping system featuring a pump chamber configured with a central portion having a tangential outlet, and configured with a tubular coupling end portion having inwardly flexible rim portions on one side; and a mounting base, having a circular portion with an inner circumferential rim configured to receive and engage the inwardly flexible rim portions of the tubular coupling portion of the pump chamber so as to be rotationally coupled to the pumping chamber so that the pumping chamber may be rotated 360 in relation to the mounting base.

Classes IPC  ?

  • F04D 13/08 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité pour utilisation en position immergée
  • F04D 29/60 - MontageAssemblageDémontage

86.

Diaphragm pump


Numéro d'application 29429114
Numéro de brevet D0712933
Statut Délivré - en vigueur
Date de dépôt 2012-08-07
Date de la première publication 2014-09-09
Date d'octroi 2014-09-09
Propriétaire Flow Control LLC (USA)
Inventeur(s)
  • Deoreo, Daniel J.
  • Kenney, Joel A.

87.

Utility pump


Numéro d'application 29444195
Numéro de brevet D0708648
Statut Délivré - en vigueur
Date de dépôt 2013-01-28
Date de la première publication 2014-07-08
Date d'octroi 2014-07-08
Propriétaire Flow Control LLC. (USA)
Inventeur(s) Orsini, Richard F.

88.

SEALED DIAPHRAGM PUMP


Numéro d'application US2013070739
Numéro de publication 2014/081701
Statut Délivré - en vigueur
Date de dépôt 2013-11-19
Date de publication 2014-05-30
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Villagomez, Manuel

Abrégé

A pump includes a molded housing configured with a rear endbell portion to receive an armature and bearing, an intermediate motor portion to receive a motor shell and magnets arranged around the armature, and a front endbell portion to receive a diaphragm assembly having a diaphragm support plate supporting a diaphragm, the rear endbell portion, the intermediate motor portion and the front endbell portion being configured as an integrated molded housing unit, the diaphragm having two circumferential diaphragm sealing surfaces. The pump also includes an upper housing configured to assemble and couple to the molded housing so as to form a circumferential fluid-tight sealing arrangement that is configured between the front endbell portion and the upper housing on only one end of the pump.

Classes IPC  ?

  • F04B 43/04 - Pompes ayant un entraînement électrique

89.

Sealed diaphragm pump


Numéro d'application 13681971
Numéro de brevet 09845799
Statut Délivré - en vigueur
Date de dépôt 2012-11-20
Date de la première publication 2014-05-22
Date d'octroi 2017-12-19
Propriétaire Flow Control LLC (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Villagomez, Manuel

Abrégé

A pump includes a molded housing configured with a rear endbell portion to receive an armature and bearing, an intermediate motor portion to receive a motor shell and magnets arranged around the armature, and a front endbell portion to receive a diaphragm assembly having a diaphragm support plate supporting a diaphragm, the rear endbell portion, the intermediate motor portion and the front endbell portion being configured as an integrated molded housing unit, the diaphragm having two circumferential diaphragm sealing surfaces. The pump also includes an upper housing configured to assemble and couple to the molded housing so as to form a circumferential fluid-tight sealing arrangement that is configured between the front endbell portion and the upper housing on only one end of the pump.

Classes IPC  ?

  • F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
  • F04B 43/04 - Pompes ayant un entraînement électrique
  • F04B 43/00 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles

90.

Low profile pump


Numéro d'application 29459544
Numéro de brevet D0701246
Statut Délivré - en vigueur
Date de dépôt 2013-07-01
Date de la première publication 2014-03-18
Date d'octroi 2014-03-18
Propriétaire Flow Control LLC. (USA)
Inventeur(s) Cook, Gregory

91.

Diaphragm pump


Numéro d'application 29457195
Numéro de brevet D0698369
Statut Délivré - en vigueur
Date de dépôt 2013-06-07
Date de la première publication 2014-01-28
Date d'octroi 2014-01-28
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Meza, Humberto V.
  • Villagomez, Manuel
  • Tran, Derrick T.

92.

Pump using multi voltage electronics with run dry and over current protection


Numéro d'application 13708075
Numéro de brevet 10024325
Statut Délivré - en vigueur
Date de dépôt 2012-12-07
Date de la première publication 2013-12-26
Date d'octroi 2018-07-17
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Phillips, David L.
  • Meza, Humberto V.
  • Tran, Derrick T.

Abrégé

A pump has a signal processor, including one forming part of a printed circuit board assembly, that receives signaling containing information about a voltage supplied to a motor to run a particular pump model, and also containing information about whether a current draw of the pump is lower than a predetermined low current level or is higher than a predetermined high current level; and determines whether to shut off the pump after a predetermined time, based on the signaling received. The signal processor provides control signalling to shut off the pump after the predetermined time if the current draw of the pump is lower than the predetermined low current level or is higher than the predetermined high current level, where the predetermined low current level and the predetermined high current level depend on the voltage being supplied to the motor to run the particular pump model.

Classes IPC  ?

  • F04D 15/02 - Arrêt de pompes ou de soupapes en cas de fonctionnement indésirable
  • F04B 17/03 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs électriques
  • F04B 49/06 - Commande utilisant l'électricité

93.

TECHNIQUE FOR PREVENTING AIR LOCK THROUGH STUTTERED STARTING AND AIR RELEASE SLIT FOR PUMPS


Numéro de document 02874008
Statut Délivré - en vigueur
Date de dépôt 2013-06-14
Date de disponibilité au public 2013-12-19
Date d'octroi 2020-03-31
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Lopes, Jeffrey
  • Estrada, Jesus
  • Teed, Kevin

Abrégé

Apparatus, including a pumping system, is provided featuring a pump and a control circuit. The pump has an impeller housing configured with a slit at the top for trapped air to leave the impeller housing once the pump has been submerged. The control circuit is configured to cycle the pump on and off for a predetermined number of cycles so that the trapped air will float to the top and be expelled out the slit when the pump is cycled off. The control circuit is configured to leave the pump on after the predetermined number of cycles.

Classes IPC  ?

  • F04D 9/00 - AmorçagePrévention du blocage par la vapeur
  • F04D 15/00 - Commande, p. ex. régulation de pompes, d'installations ou de systèmes de pompage

94.

Technique for preventing air lock through stuttered starting and air release slit for pumps


Numéro d'application 13917970
Numéro de brevet 10267317
Statut Délivré - en vigueur
Date de dépôt 2013-06-14
Date de la première publication 2013-12-19
Date d'octroi 2019-04-23
Propriétaire Flow Control LLC. (USA)
Inventeur(s)
  • Lopes, Jeffrey
  • Estrada, Jesus
  • Teed, Kevin

Abrégé

Apparatus, including a pumping system, is provided featuring a pump and a control circuit. The pump has an impeller housing configured with a slit at the top for trapped air to leave the impeller housing once the pump has been submerged. The control circuit is configured to cycle the pump on and off for a predetermined number of cycles so that the trapped air will float to the top and be expelled out the slit when the pump is cycled off. The control circuit is configured to leave the pump on after the predetermined number of cycles.

Classes IPC  ?

  • F04D 15/00 - Commande, p. ex. régulation de pompes, d'installations ou de systèmes de pompage
  • F04D 9/00 - AmorçagePrévention du blocage par la vapeur
  • F04D 13/08 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité pour utilisation en position immergée

95.

PREVENTING SUBMERSIBLE PUMP AIR LOCK


Numéro d'application US2013045839
Numéro de publication 2013/188741
Statut Délivré - en vigueur
Date de dépôt 2013-06-14
Date de publication 2013-12-19
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Lopes, Jeffrey
  • Estrada, Jesus
  • Teed, Kevin

Abrégé

Apparatus, including a pumping system, is provided featuring a pump and a control circuit. The pump has an impeller housing configured with a slit at the top for trapped air to leave the impeller housing once the pump has been submerged. The control circuit is configured to cycle the pump on and off for a predetermined number of cycles so that the trapped air will float to the top and be expelled out the slit when the pump is cycled off. The control circuit is configured to leave the pump on after the predetermined number of cycles.

Classes IPC  ?

  • B23P 15/02 - Fabrication d'objets déterminés par des opérations non couvertes par une seule autre sous-classe ou un groupe de la présente sous-classe d'aubes de turbine ou d'organes équivalents, en une seule pièce
  • F02M 37/04 - Alimentation au moyen de pompes entraînées
  • F04D 1/04 - Pompes hélicocentrifuges

96.

COMPACT, LIGHTWEIGHT, BATTERY OPERATED, SELF-PRIMING, POSITIVE DISPLACEMENT PUMP


Numéro d'application US2013041335
Numéro de publication 2013/173573
Statut Délivré - en vigueur
Date de dépôt 2013-05-16
Date de publication 2013-11-21
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Irving, Michael H.
  • Schopperle, Jeffrey B.

Abrégé

A compact, lightweight, battery operated, self-priming, positive displacement pump has a combination of an elongated housing having a longitudinal axis; a positive displacement pump assembly configured in the elongated housing, and configured to respond to a motor assembly drive torque, to self-prime, and to pump fluid from an input port to an output port; a motor assembly configured in the elongated housing and configured to respond to signaling and provide the motor assembly drive torque; a pump control interconnect assembly configured in the elongated housing, and configured to provide the signaling to control the operation of the motor assembly by current based on run dry mode.

Classes IPC  ?

  • F04D 13/06 - Ensembles comprenant les pompes et leurs moyens d'entraînement la pompe étant entraînée par l'électricité

97.

Pool cover pump


Numéro d'application 29444189
Numéro de brevet D0693371
Statut Délivré - en vigueur
Date de dépôt 2013-01-28
Date de la première publication 2013-11-12
Date d'octroi 2013-11-12
Propriétaire Flow Control LLC. (USA)
Inventeur(s) Orsini, Richard F.

98.

Hand-held, rechargeable, battery powered diaphragm pump


Numéro d'application 29418986
Numéro de brevet D0692025
Statut Délivré - en vigueur
Date de dépôt 2012-04-24
Date de la première publication 2013-10-22
Date d'octroi 2013-10-22
Propriétaire Flow Control LLC (USA)
Inventeur(s)
  • Cook, Gregory
  • Irving, Michael H.
  • Schopperle, Jeffrey B.
  • Ingersoll, Mark F.

99.

AIR OPERATED DIAPHRAGM PUMP


Numéro de document 02869909
Statut Délivré - en vigueur
Date de dépôt 2013-04-09
Date de disponibilité au public 2013-10-17
Date d'octroi 2020-03-31
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Verdugo, Christopher H.
  • Wright, Peter M.
  • Jackson, Jimmie L., Jr.

Abrégé

An air operated diaphragm pump is provided featuring a housing, a fluid passageway and an indicator arrangement. The housing is configured with an orifice. The fluid passageway responses to a vacuum force and provides fluid, such as syrup from a bag or container to a beverage dispenser, through the air operated diaphragm pump via the fluid passageway, and is configured with a suction plenum or channel formed by an enclosed space with an inside pressure that is greater than an external pressure of the outside atmosphere when the fluid is being provided through the air operated diaphragm pump via the fluid passageway.

Classes IPC  ?

  • F04B 43/06 - Pompes ayant un entraînement par fluide

100.

Adjustable in-line on demand carbonation chamber for beverage applications


Numéro d'application 13649256
Numéro de brevet 09033315
Statut Délivré - en vigueur
Date de dépôt 2012-10-11
Date de la première publication 2013-10-17
Date d'octroi 2015-05-19
Propriétaire FLOW CONTROL LLC. (USA)
Inventeur(s)
  • Phillips, David L.
  • Romero, Robert J.
  • Verdugo, Christopher H.

Abrégé

2, and may be configured to provide a mixture of the fluid and the gas. The gas adjustment member is configured to receive the gas, including from a gas inlet, and to provide the adjustable amount of gas to the mixing and metering member, based at least partly on an adjustable axial relationship between the mixing and metering member and the gas adjustment member in order to control a desired carbonation level of the mixture.

Classes IPC  ?

  • B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
  • A23L 2/00 - Boissons non alcooliséesCompositions sèches ou concentrés pour les fabriquer Leur préparation ou leur traitement
  • B01F 5/00 - Mélangeurs à écoulement; Mélangeurs pour matériaux tombants, p.ex. particules solides
  • B01F 5/06 - Mélangeurs dans lesquels les composants du mélange sont pressés ensemble au travers de fentes, d'orifices, ou de tamis
  • B01F 15/00 - Accessoires pour mélangeurs
  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation
  1     2        Prochaine page
