Some embodiments of the present disclosure relate to an improved toilet flush system that includes a toilet tank flush valve mechanism that includes a flapper chain with an adjustable length. In some embodiments, the system solves common issues associated with traditional flapper chain setups, such as improper chain slack leading to inefficient flushing and potential water wastage. In some embodiments the system includes a toilet kit that includes one or more toilet valve components and two or more chain clips, all housed within a single kit housing. In some embodiments, the chain clips are configured to couple to both the flush chain and the flush arm, allowing for adjustments to the chain length. In some embodiments, the system minimizes the risk of chain tangling or obstruction within the toilet tank, thereby enhancing the reliability and efficiency of the toilet flush mechanism.
E03D 5/094 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un câble, d'une chaîne ou similaire
E03D 1/14 - Réservoirs déversant des quantités d'eau variables
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
The disclosure describes a system for sealing a discharge of a toilet bowl according to some embodiments. In some embodiments, the system includes one or more gaskets that are not wax. In some embodiments, the system includes a plurality of gaskets that are configured to be stacked on top of each other. In some embodiments, the system includes a spacer that is configured to be assembled between two gaskets to add rigidity to the assembled structure. In some embodiments, one or more gaskets and/or spacers include a fastener to prevent movement of the assembled structure. In some embodiments, a spacer includes one or more ribs and/or rings configured to seal against a gasket.
The disclosure is directed to a cistern system which enables maintenance, removal, or adjustment of various components through a maintenance window according to some embodiments. In some embodiments, the cistern system includes screen support members that cooperate with a flush valve to remove fallen components. In some embodiments, the cistern system includes a frame with an adjustable upper bar that can be removed to facilitate the installation of various components. In some embodiments, the frame includes a bar holder fastener that enables vertical leveling when the frame is secured to a wall with one or more wall mounts. In some embodiments, the frame includes adjustable frame supports that can be fixed in position by frame height adjusters when only supporting the weight of the cistern system but can be adjusted in and out of the frame by adding additional downward force to the frame.
Methods and systems described herein are direct to an external lever configured to be positioned external to a toilet tank and actuated by a user to cause a toilet tank to flush. A first component comprising a first longitudinal member may couple to the external lever. A second component comprising a second longitudinal member may engage the first component at a perpendicular angle with respect to the first longitudinal member. The first and second components make up an arm that is configured to pass through a wall of the toilet tank. An internal lever arm may be positioned within the toilet tank such that the internal lever couples to the second component.
E03D 5/092 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un levier
The disclosure is directed to a flapper system and a flapper system kit that is compatible with both 2″ and 3″ flush valve seats. In some embodiments, the flapper system is configured to enable a user to select either a 2″ or 3″ flush valve seal for the flapper system. In some embodiments, the flapper system includes a pivot that enables sealing of a flat flush valve seat or an angled flush valve seat. In some embodiments, the flapper system includes one or more adjustable window assemblies that control a fluid flowrate within an internal portion of the flapper system to control buoyancy. In some embodiments, the flapper system includes a packaging system that includes an external portion of an interior packaging that extends outside of a structural packaging resulting in a greater display area.
Some embodiments described herein are directed to fill valves which offer high flowrate at low pressures. In some embodiments, a valve body includes a through-hole configured to enable the poppet to pass therethrough. In some embodiments, a valve body includes a piston actuator. In some embodiments, a movement a float causes a stem arm to move the stem to a position where a reduced cross-section enables the fluid to leak past the stem through a seal drain. In some embodiments, a diaphragm includes one or more metering holes configured to enable fluid from the inlet conduit to bleed to a back cavity. In some embodiments, the diaphragm is configured to enable fluid to pass through a gap between the valve cap and the inlet conduit in an area where the diaphragm is trapped in position in response to an increase inlet pressure.
F16K 31/18 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
The disclosure is directed to a dynamic siphon assembly according to some embodiments. In some embodiments, the dynamic siphon assembly includes a dynamic siphon that is configured to evacuate fluid from a cistern when pushed down. In some embodiments, the dynamic siphon assembly includes a full flush actuation assembly and a partial flush actuation assembly. In some embodiments, each actuation assembly is configured to break the siphonic action of the dynamic siphon at different times and water level. In some embodiments, the dynamic siphon includes an air trap configured to trap surrounding gas such that the dynamic siphon rises during filling of the cistern. In some embodiments, the rising prevents siphonic action by raising a fluid overflow within the dynamic siphon above a fluid level in the cistern.
The disclosure describes a system for sealing a discharge of a toilet bowl according to some embodiments. In some embodiments, the system includes one or more gaskets that are not wax. In some embodiments, the system includes a plurality of gaskets that are configured to be stacked on top of each other. In some embodiments, the system includes a spacer that is configured to be assembled between two gaskets to add rigidity to the assembled structure. In some embodiments, one or more gaskets and/or spacers include a fastener to prevent movement of the assembled structure. In some embodiments, a spacer includes one or more ribs and/or rings configured to seal against a gasket.
The disclosure is directed to a flapper system and a flapper system kit that is compatible with both 2" and 3" flush valve seats. In some embodiments, the flapper system is configured to enable a user to select either a 2" or 3" flush valve seal for the flapper system. In some embodiments, the flapper system includes a pivot that enables sealing of a flat flush valve seat or an angled flush valve seat. In some embodiments, the flapper system includes one or more adjustable window assemblies that control a fluid flowrate within an internal portion of the flapper system to control buoyancy. In some embodiments, the flapper system includes an adaptor that converts a 2" valve into a 3" valve.
The disclosure is directed to a flapper system and a flapper system kit that is compatible with both 2" and 3" flush valve seats. In some embodiments, the flapper system is configured to enable a user to select either a 2" or 3" flush valve seal for the flapper system. In some embodiments, the flapper system includes a pivot that enables sealing of a flat flush valve seat or an angled flush valve seat. In some embodiments, the flapper system includes one or more adjustable window assemblies that control a fluid flowrate within an internal portion of the flapper system to control buoyancy. In some embodiments, the flapper system includes an adaptor that converts a 2" valve into a 3" valve.
The disclosure is directed to a flapper system and a flapper system kit that is compatible with both 2″ and 3″ flush valve seats. In some embodiments, the flapper system is configured to enable a user to select either a 2″ or 3″ flush valve seal for the flapper system. In some embodiments, the flapper system includes a pivot that enables sealing of a flat flush valve seat or an angled flush valve seat. In some embodiments, the flapper system includes one or more adjustable window assemblies that control a fluid flowrate within an internal portion of the flapper system to control buoyancy. In some embodiments, the flapper system includes an adaptor that converts a 2″ valve into a 3″ valve.
The disclosure is directed to a dynamic siphon assembly according to some embodiments. In some embodiments, the dynamic siphon assembly includes a dynamic siphon that is configured to evacuate fluid from a cistern when pushed down. In some embodiments, the dynamic siphon assembly includes a full flush actuation assembly and a partial flush actuation assembly. In some embodiments, each actuation assembly is configured to break the siphonic action of the dynamic siphon at different times and water level. In some embodiments, the dynamic siphon includes an air trap configured to trap surrounding gas such that the dynamic siphon rises during filling of the cistern. In some embodiments, the rising prevents siphonic action by raising a fluid overflow within the dynamic siphon above a fluid level in the cistern.
The disclosure is directed to a cistern system which enables maintence, removal, or adjustment of various components through a maintenance window according to some embodiments. In some embodiments, the cistern system includes screen support members that cooperate with a flush valve to remove fallen components. In some embodiments, the cistern system includes a frame with an adjustable upper bar that can be removed to facilitate the installation of various components. In some embodiments, the frame includes a bar holder fastener that enables vertical leveling when the frame is secured to a wall with one or more wall mounts. In some embodiments, the frame includes adjustable frame supports that can be fixed in position by frame height adjusters when only supporting the weight of the cistern system but can be adjusted in and out of the frame by adding additional downward force to the frame.
A modular poppet assembly system for a toilet tank flush valve assembly, the modular system comprising a first float portion; and two or more second float portions; wherein, the first float portion is configured to removably attach to each of the two or more second float portions to form two or more poppet assemblies, each of the two or more poppet assemblies comprise a different buoyancy, each of the two or more poppet assemblies allow the toilet tank to fill to substantially a same water volume, and as the poppet assembly buoyancy increases, an increase in flush volume is provided.
The system includes a fluid valve with a modular and/or replaceable fluid control assembly that requires maintenance over a product life of the fluid valve. The modular and/or replaceable fluid control assembly includes at least one portion including a setting or presetting configured and arranged to control fluid flow behavior in the fluid valve. The setting or presetting is useable to control fluid flow in the modular and/or replaceable fluid control assembly after an upgrade or replacement of at least a portion of the modular and/or replaceable fluid control assembly. Further, the setting or presetting enables the modular and/or replaceable fluid control assembly to retain the fluid flow behavior following one or more upgrades or replacements of one or more portions of the modular and/or replaceable fluid control assembly.
Some embodiments include a valve assembly with a metering seal including a main channel including regions with a first diameter and regions with a second diameter, where the first diameter is smaller than the second diameter. Some embodiments include a stem positioned in the metering seal extending from at least a first end of the metering seal to a second end of the metering seal. In some embodiments, the stem has a fluted section positioned between two non-fluted sections, where the diameter of stem in the fluted section is smaller than the diameter of the stem in the non-fluted sections. Some embodiments include a first and second flow channel extending across at least a partial width of the metering seal, where the first flow channel is positioned at the first end of the metering seal, and the second flow channel is positioned at the second end of the metering seal.
F16K 3/24 - Robinets-vannes ou tiroirs, c.-à-d. dispositifs obturateurs dont l'élément de fermeture glisse le long d'un siège pour l'ouverture ou la fermeture à faces d'obturation en forme de surfaces de solides de révolution avec corps de tiroir cylindrique
F16K 27/04 - Structures des logementsMatériaux utilisés à cet effet des tiroirs
F16K 3/34 - Dispositions pour modifier la façon dont le débit varie pendant le fonctionnement du tiroir
22.
Pneumatic lost motion/binary device system and method
Some embodiments include an assembly with an inlet housing enclosing an outlet housing that includes an inlet. The outlet housing includes an outlet port and a channel or aperture coupled to an outlet and apertures coupled to atmosphere. A moveable or flexible member is positioned in the inlet housing coupled to the outlet housing, and can deform, flex and/or move based on a flow and/or pressure of fluid from the inlet. Based on the flow and/or pressure of fluid from the inlet, the moveable or flexible member can reversibly move from a first position to a second position and/or from a second position to a first position. The first position is characterized by the moveable or flexible member being coupled to, proximate to, sealed to the aperture, and the second position is characterized by the moveable or flexible member being moved away from the aperture.
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
F16K 27/00 - Structures des logementsMatériaux utilisés à cet effet
F16K 7/17 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol disposé pour être déformé contre un siège plat le diaphragme étant actionné par pression d'un fluide
F16K 11/02 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout
F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles
The disclosure is directed to an exchangeable fill valve system. In some embodiments, the system includes an interchangeable shank that enables attachment of different fill valve types. In some embodiments, the interchangeable shank enables different fill valve types to be removed from a fluid tank without also removing the interchangeable shank from the tank wall. In some embodiments, the interchangeable shank also houses an inline filter, where the filter can be accessed by disconnecting the fill valve. In some embodiments, the exchangeable fill valve system includes floats that capture fill water drives the floats down actuating a fill valve lever. In some embodiments, the floats include one or more holes that enable a timed discharge of the fill water from the floats.
F16K 31/34 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur commandant une soupape-pilote commandant à son tour le dispositif obturateur
The disclosure is directed to an exchangeable fill valve system. In some embodiments, the system includes an interchangeable shank that enables attachment of different fill valve types. In some embodiments, the interchangeable shank enables different fill valve types to be removed from a fluid tank without also removing the interchangeable shank from the tank wall. In some embodiments, the interchangeable shank also houses an inline filter, where the filter can be accessed by disconnecting the fill valve. In some embodiments, the exchangeable fill valve system includes floats that capture fill water drives the floats down actuating a fill valve lever. In some embodiments, the floats include one or more holes that enable a timed discharge of the fill water from the floats.
F16K 1/02 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à tige filetée
F16K 1/52 - Dispositifs pour le réglage additionnel du débit
F16K 27/00 - Structures des logementsMatériaux utilisés à cet effet
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
F16K 31/18 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur
Some embodiments include a fluid control system with an outlet valve assembly, an inlet valve assembly including a venturi inlet valve, and an actuator coupled to the inlet valve assembly. In some embodiments, the actuator can enable a user to control a flush volume of fluid control system. Some embodiments include a moveable float positioned in a chamber of the outlet valve assembly, where the chamber includes a variably-sized upper portion with a volume that is based at least in part on a variable position of the moveable float in the chamber. Some embodiments include a adjustable control valves coupled to an outer surface of the outlet valve assembly and the inlet valve assembly. Some embodiments also include a bellows positioned in and coupled to the variably-sized upper portion. In some embodiments, the bellows are fluidly coupled to the venturi inlet valve and at least one of the control valves.
B67D 7/02 - Appareils ou dispositifs pour transférer des liquides à partir de récipients ou de réservoirs de stockage en vrac vers des véhicules ou des récipients portables, p. ex. pour la vente au détail pour transférer des liquides autres que des carburants ou des lubrifiants
E03D 3/12 - Dispositifs de chasse déversant des quantités d'eau variables
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
F16K 31/18 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur
A modular poppet assembly system for a toilet tank flush valve assembly, the modular system comprising a first float portion; and two or more second float portions; wherein, the first float portion is configured to removably attach to each of the two or more second float portions to form two or more poppet assemblies, each of the two or more poppet assemblies comprise a different buoyancy, each of the two or more poppet assemblies allow the toilet tank to fill to substantially a same water volume, and as the poppet assembly buoyancy increases, an increase in flush volume is provided.
A modular poppet assembly system for a toilet tank flush valve assembly, the modular system comprising a first float portion; and two or more second float portions; wherein, the first float portion is configured to removably attach to each of the two or more second float portions to form two or more poppet assemblies, each of the two or more poppet assemblies comprise a different buoyancy, each of the two or more poppet assemblies allow the toilet tank to fill to substantially a same water volume, and as the poppet assembly buoyancy increases, an increase in flush volume is provided.
A fill valve system with a float nested in a container connected to the fill valve and a siphon device passing water out of the container into the toilet tank, with the siphon device having an air vent dimensioned such that: (i) tank refilling is delayed until after the flush valve closes; (ii) the fill valve is not turned on by small leaks in the tank; and (iii) the fill valve turns off when it encounters large leaks in the tank.
F16K 11/08 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des robinets à boisseau
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
E03D 3/06 - Clapets de chasse à fermeture automatique avec soupape à diaphragme et chambre de pression pour retarder le mouvement de fermeture du clapet
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
B67D 7/48 - Buses de remplissage se fermant automatiquement lorsque le liquide atteint un niveau prédéterminé dans le récipient à remplir en utilisant une aspiration d'air à travers un orifice fermé par la montée du liquide
F16K 31/365 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation le fluide agissant sur un diaphragme
F16K 21/20 - Obturateurs à fermeture automatique, c.-à-d. se fermant d'eux-même après fonctionnement fermés quand la montée du liquide atteint un niveau prédéterminé par des moyens utilisant la succion de l'air au travers d'une ouverture fermée par la montée du liquide
F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte
F16K 11/085 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des robinets à boisseau à noix cylindrique
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
E03D 5/094 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un câble, d'une chaîne ou similaire
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
E03C 1/02 - Installations de plomberie pour l'alimentation en eau
Some embodiments include a fluid valve assembly with an outlet base dimensioned to be positioned through a drain in a fluid tank, and a float assembly including a moveable float. The moveable float can form a fluid-tight seal at a first end when the moveable float is coupled to the outlet base, and a flow opening when the moveable float is at least partially decoupled from the outlet base. Some embodiments include a housing positioned with the moveable float, where the housing encloses a suction device coupled to a moveable piston. Some embodiments include an actuable diaphragm positioned in the outlet base, and a compressed air tube or passageway coupled to one side the actuable diaphragm. In some embodiments, the actuable diaphragm is configured and arranged to be actuated by compressed air to move the moveable piston.
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
F16K 31/22 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur commandant une soupape de levage le flotteur étant rigidement lié à la soupape
F16K 3/02 - Robinets-vannes ou tiroirs, c.-à-d. dispositifs obturateurs dont l'élément de fermeture glisse le long d'un siège pour l'ouverture ou la fermeture à faces d'obturation planesGarnitures d'étanchéité à cet effet
F04B 43/02 - "Machines", pompes ou installations de pompage ayant des organes de travail flexibles ayant des organes flexibles du genre plat, p. ex. des diaphragmes
F16K 1/26 - Forme ou disposition du joint d'étanchéité
F16K 7/02 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire
F16K 33/00 - Flotteurs pour actionner les soupapes ou autres dispositifs
F16K 1/30 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation spécialement adaptées pour réceptacles sous pression
E03D 1/14 - Réservoirs déversant des quantités d'eau variables
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
This disclosure describes a kit comprising component for removing, replacing, and/or sealing toilet parts. In some embodiments, the kit comprises a flush valve assembly, fill valve assembly, a handle assembly, two tools, two gaskets, and packaging that also serves as one or more water containers. In some embodiments, the two gaskets are two conventional gaskets that can be combined to make a third gasket. In some embodiments, the combination of the two gaskets allows the creation of a synergistic gasket for sealing a tank-to-bowl interface than neither gasket could seal individually.
B25B 27/24 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher pour monter ou démonter des soupapes
E03D 1/26 - Cuvette avec réservoir monté sur le prolongement arrière de la cuvette
E03D 1/34 - Clapets de chasse pour vidangeDisposition des vannes de vidange
E03D 1/36 - Fonctionnement combiné des clapets d'alimentation et d'évacuation
This disclosure describes a kit comprising component for removing, replacing, and/or sealing toilet parts. In some embodiments, the kit comprises a flush valve assembly, fill valve assembly, a handle assembly, two tools, two gaskets, and packaging that also serves as one or more water containers. In some embodiments, the two gaskets are two conventional gaskets that can be combined to make a third gasket. In some embodiments, the combination of the two gaskets allows the creation of a synergistic gasket for sealing a tank-to-bowl interface than neither gasket could seal individually.
This disclosure describes a kit comprising component for removing, replacing, and/or sealing toilet parts. In some embodiments, the kit comprises a flush valve assembly, fill valve assembly, a handle assembly, two tools, two gaskets, and packaging that also serves as one or more water containers. In some embodiments, the two gaskets are two conventional gaskets that can be combined to make a third gasket. In some embodiments, the combination of the two gaskets allows the creation of a synergistic gasket for sealing a tank-to-bowl interface than neither gasket could seal individually.
E03D 1/34 - Clapets de chasse pour vidangeDisposition des vannes de vidange
E03D 1/26 - Cuvette avec réservoir monté sur le prolongement arrière de la cuvette
E03D 1/36 - Fonctionnement combiné des clapets d'alimentation et d'évacuation
B25B 27/24 - Outils à main ou outillage d'établi, spécialement conçus pour assembler ou séparer des pièces ou des objets, que cela entraîne ou non une certaine déformation, non prévus ailleurs pour assembler des objets autrement que par ajustage à la presse, ou pour les détacher pour monter ou démonter des soupapes
Methods and systems described herein are direct to an external lever configured to be positioned external to a toilet tank and actuated by a user to cause a toilet tank to flush. A first component comprising a first longitudinal member may couple to the external lever. A second component comprising a second longitudinal member may engage the first component at a perpendicular angle with respect to the first longitudinal member. The first and second components make up an arm that is configured to pass through a wall of the toilet tank. An internal lever arm may be positioned within the toilet tank such that the internal lever couples to the second component.
Embodiments include an assembly including a fluid valve assembly including an outlet, and a filling tube adjacent to the fluid valve assembly, where the filling tube includes an inlet aperture at least partially axially aligned with the outlet. An outlet aperture is positioned at a specific distance from the inlet aperture forming a space or air gap between the inlet aperture and the outlet aperture. A moveable float is configured and arranged to control a sealing member of the fluid valve based at least in part on the position of the moveable float relative to the outlet.
Embodiments include a fluid valve with a modular and/or replaceable fluid control assembly configured and arranged to require maintenance over a product life of the fluid valve. The modular and/or replaceable fluid control assembly includes at least one portion including a setting or presetting configured and arranged to control fluid flow behavior in the fluid valve. The setting or presetting is useable to control fluid flow in the modular and/or replaceable fluid control assembly after an upgrade or replacement of at least a portion of the modular and/or replaceable fluid control assembly. Further, the setting or presetting enables the modular and/or replaceable fluid control assembly to retain the fluid flow behavior following one or more upgrades or replacements of one or more portions of the modular and/or replaceable fluid control assembly.
A fluid valve with a modular and/or replaceable fluid control assembly is disclosed, and is configured and arranged to require maintenance over a product life of the fluid valve. The modular and/or replaceable fluid control assembly includes at least one portion including a setting or presetting configured and arranged to control fluid flow behavior in the fluid valve. The setting or presetting is useable to control fluid flow in the modular and/or replaceable fluid control assembly after an upgrade or replacement of at least a portion of the modular and/or replaceable fluid control assembly. Further, the setting or presetting enables the modular and/or replaceable fluid control assembly to retain the fluid flow behavior following one or more upgrades or replacements of one or more portions of the modular and/or replaceable fluid control assembly.
Installations and apparatus, all for water supply and sanitary purposes; plumbing apparatus; water supply valves; toilet valves; parts and fittings for the aforesaid goods.
38.
BALANCED ACTIVATION FORCE AND BISTABLE VALVE SYSTEM AND METHOD
Some embodiments include a valve assembly with a metering seal including a main channel including regions with a first diameter and regions with a second diameter, where the first diameter is smaller than the second diameter. Some embodiments include a stem positioned in the metering seal extending from at least a first end of the metering seal to a second end of the metering seal. In some embodiments, the stem has a fluted section positioned between two non-fluted sections, where the diameter of stem in the fluted section is smaller than the diameter of the stem in the non-fluted sections. Some embodiments include a first and second flow channel extending across at least a partial width of the metering seal, where the first flow channel is positioned at the first end of the metering seal, and the second flow channel is positioned at the second end of the metering seal.
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
F16K 47/08 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour diminuer la pression, l'organe régulateur étant distinct de l'élément de fermeture
Some embodiments include a fluid valve assembly with an outlet base dimensioned to be positioned through a drain in a fluid tank, and a float assembly including a moveable float. The moveable float can form a fluid-tight seal at a first end when the moveable float is coupled to the outlet base, and a flow opening when the moveable float is at least partially decoupled from the outlet base. Some embodiments include a housing positioned with the moveable float, where the housing encloses a suction device coupled to a moveable piston. Some embodiments include an actuable diaphragm positioned in the outlet base, and a compressed air tube or passageway coupled to one side the actuable diaphragm. In some embodiments, the actuable diaphragm is configured and arranged to be actuated by compressed air to move the moveable piston.
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
F16K 31/18 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur
40.
PNEUMATIC LOST MOTION/BINARY DEVICE SYSTEM AND METHOD
Some embodiments include an assembly with an inlet housing enclosing an outlet housing that includes an inlet. The outlet housing includes an outlet port and a channel or aperture coupled to an outlet and apertures coupled to atmosphere. A moveable or flexible member is positioned in the inlet housing coupled to the outlet housing, and can deform, flex and/or move based on a flow and/or pressure of fluid from the inlet. Based on the flow and/or pressure of fluid from the inlet, the moveable or flexible member can reversibly move from a first position to a second position and/or from a second position to a first position. The first position is characterized by the moveable or flexible member being coupled to, proximate to, sealed to the aperture, and the second position is characterized by the moveable or flexible member being moved away from the aperture.
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
41.
BALANCED ACTIVATION FORCE AND BISTABLE VALVE SYSTEM AND METHOD
Some embodiments include a valve assembly with a metering seal including a main channel including regions with a first diameter and regions with a second diameter, where the first diameter is smaller than the second diameter. Some embodiments include a stem positioned in the metering seal extending from at least a first end of the metering seal to a second end of the metering seal. In some embodiments, the stem has a fluted section positioned between two non-fluted sections, where the diameter of stem in the fluted section is smaller than the diameter of the stem in the non-fluted sections. Some embodiments include a first and second flow channel extending across at least a partial width of the metering seal, where the first flow channel is positioned at the first end of the metering seal, and the second flow channel is positioned at the second end of the metering seal.
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
F16K 47/08 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour diminuer la pression, l'organe régulateur étant distinct de l'élément de fermeture
F16K 27/02 - Structures des logementsMatériaux utilisés à cet effet des soupapes de levage
Some embodiments include a fluid valve assembly with an outlet base dimensioned to be positioned through a drain in a fluid tank, and a float assembly including a moveable float. The moveable float can form a fluid-tight seal at a first end when the moveable float is coupled to the outlet base, and a flow opening when the moveable float is at least partially decoupled from the outlet base. Some embodiments include a housing positioned with the moveable float, where the housing encloses a suction device coupled to a moveable piston. Some embodiments include an actuable diaphragm positioned in the outlet base, and a compressed air tube or passageway coupled to one side the actuable diaphragm. In some embodiments, the actuable diaphragm is configured and arranged to be actuated by compressed air to move the moveable piston.
F16K 31/18 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
Some embodiments include an assembly with an inlet housing enclosing an outlet housing that includes an inlet. The outlet housing includes an outlet port and a channel or aperture coupled to an outlet and apertures coupled to atmosphere. A moveable or flexible member is positioned in the inlet housing coupled to the outlet housing, and can deform, flex and/or move based on a flow and/or pressure of fluid from the inlet. Based on the flow and/or pressure of fluid from the inlet, the moveable or flexible member can reversibly move from a first position to a second position and/or from a second position to a first position. The first position is characterized by the moveable or flexible member being coupled to, proximate to, sealed to the aperture, and the second position is characterized by the moveable or flexible member being moved away from the aperture.
F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
F16K 27/00 - Structures des logementsMatériaux utilisés à cet effet
F16K 7/17 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol disposé pour être déformé contre un siège plat le diaphragme étant actionné par pression d'un fluide
F16K 11/02 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout
A flow diverter for diverting flow between a toilet bowl and a toilet tank, having: a body having an inlet, a first outlet and a second outlet; and a flow adjustment mechanism rotatable within the body to selectively divert different percentages of flow between the first outlet and the second outlet; and an air vent and diaphragm in the body to prevent a siphon flow from the first or second outlet back to the inlet.
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
E03D 3/06 - Clapets de chasse à fermeture automatique avec soupape à diaphragme et chambre de pression pour retarder le mouvement de fermeture du clapet
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
B67D 7/48 - Buses de remplissage se fermant automatiquement lorsque le liquide atteint un niveau prédéterminé dans le récipient à remplir en utilisant une aspiration d'air à travers un orifice fermé par la montée du liquide
F16K 31/365 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation le fluide agissant sur un diaphragme
F16K 21/20 - Obturateurs à fermeture automatique, c.-à-d. se fermant d'eux-même après fonctionnement fermés quand la montée du liquide atteint un niveau prédéterminé par des moyens utilisant la succion de l'air au travers d'une ouverture fermée par la montée du liquide
F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte
F16K 11/085 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des robinets à boisseau à noix cylindrique
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
E03D 5/094 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un câble, d'une chaîne ou similaire
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
Some embodiments include a fluid control system with an outlet valve assembly, an inlet valve assembly including a venturi inlet valve, and an actuator coupled to the inlet valve assembly. In some embodiments, the actuator can enable a user to control a flush volume of fluid control system. Some embodiments include a moveable float positioned in a chamber of the outlet valve assembly, where the chamber includes a variably-sized upper portion with a volume that is based at least in part on a variable position of the moveable float in the chamber. Some embodiments include a adjustable control valves coupled to an outer surface of the outlet valve assembly and the inlet valve assembly. Some embodiments also include a bellows positioned in and coupled to the variably-sized upper portion. In some embodiments, the bellows are fluidly coupled to the venturi inlet valve and at least one of the control valves.
Some embodiments include a fluid control system with an outlet valve assembly, an inlet valve assembly including a venturi inlet valve, and an actuator coupled to the inlet valve assembly. In some embodiments, the actuator can enable a user to control a flush volume of fluid control system. Some embodiments include a moveable float positioned in a chamber of the outlet valve assembly, where the chamber includes a variably-sized upper portion with a volume that is based at least in part on a variable position of the moveable float in the chamber. Some embodiments include a adjustable control valves coupled to an outer surface of the outlet valve assembly and the inlet valve assembly. Some embodiments also include a bellows positioned in and coupled to the variably-sized upper portion. In some embodiments, the bellows are fluidly coupled to the venturi inlet valve and at least one of the control valves.
F16K 31/18 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur
B67D 7/02 - Appareils ou dispositifs pour transférer des liquides à partir de récipients ou de réservoirs de stockage en vrac vers des véhicules ou des récipients portables, p. ex. pour la vente au détail pour transférer des liquides autres que des carburants ou des lubrifiants
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
E03D 3/12 - Dispositifs de chasse déversant des quantités d'eau variables
Some embodiments include a flow regulator with a main body dimensioned to be received within a flow passageway that includes an inlet and an adjustable outlet. Further, some embodiments include an inner chamber positioned in the main body extending from at least proximate the inlet of the main body along at least a partial length of the main body and positioned as an upstream section. Some embodiments include a compressible or expandable extending vane extending from the main body and extending around the inner chamber. Some further embodiments include an adjustable fluid flow space extending around or over at least a portion of the extended vane that is configured to receive at least some fluid from at least a portion of the flow passageway, where the fluid comprises a fluid flow rate and a fluid pressure.
Some embodiments include a flow regulator with a main body dimensioned to be received within a flow passageway that includes an inlet and an outer surface, and an inner volume positioned within the main body and extending from the inlet along at least a partial length of the main body. Some embodiments includes two separate spiral structures positioned spiraled around the main body where one spiral extends further from the outer surface than the other. Some embodiments include a fluid flow space extending between the spirals. Based on a fluid pressure, the spirals can expand and contract to control the fluid flow space and affect downstream, fluid flow rate as a function of upstream fluid pressure.
G05D 7/01 - Commande de débits sans source d'énergie auxiliaire
G05D 16/06 - Commande de la pression d'un fluide sans source d'énergie auxiliaire l'élément sensible étant un organe élastique cédant à la pression, p. ex. un diaphragme, un soufflet, une capsule
Some embodiments include a flow regulator with a main body dimensioned to be received within a flow passageway that includes an inlet and an outer surface, and an inner volume positioned within the main body and extending from the inlet along at least a partial length of the main body. Some embodiments includes two separate spiral structures positioned spiraled around the main body where one spiral extends further from the outer surface than the other. Some embodiments include a fluid flow space extending between the spirals. Based on a fluid pressure, the spirals can expand and contract to control the fluid flow space and affect downstream, fluid flow rate as a function of upstream fluid pressure.
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
F16K 47/06 - Moyens incorporés aux soupapes pour absorber l'énergie d'un fluide pour diminuer la pression, l'organe régulateur étant incorporé dans l'élément de fermeture l'organe régulateur étant en forme de canal hélicoïdal
F15D 1/02 - Action sur l'écoulement des fluides dans les tuyaux ou les conduits
Some embodiments include a fluid control assembly with a flapper canister, a linkage rotatably coupled to the flapper canister and to a support of a mount. In some embodiments, the flapper canister can be angled with respect to the mount to enable the flapper canister to be coupled to various sizes, types and orientations of flush valves. In some embodiments, by rotating the linkage about pivots coupled to the flapper canister and the support and pivoting or rotating about a motion-enabling element coupling the mount and a support, the flapper canister can be raised, lowered, and/or rotated or pivoted enabling the flapper canister to be sealed against a flush valve orifice. In some embodiments, the flapper canister includes a buoyancy control tube providing fluid coupling between one side of the flapper canister to an opposite side and enabling buoyancy-assist to the position or motion of the flapper canister.
F16K 21/16 - Obturateurs à fermeture automatique, c.-à-d. se fermant d'eux-même après fonctionnement assurant la fermeture après passage d'un volume prédéterminé de fluide
E03D 1/33 - Adaptations ou aménagements des flotteurs
A toilet flush lever assembly having an adjustable length internal lever arm with a variable angle of connection to a short arm that passes through the wall of the toilet tank such that the angle of mounting of the adjustable length internal lever arm to an external flush lever arm is adjustable.
E03D 5/092 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un levier
E03D 1/34 - Clapets de chasse pour vidangeDisposition des vannes de vidange
A toilet having a tank to receive water and a bowl connected with the tank. Water travels from the tank to the bowl to discharge waste in the bowl through a manifold connected to the bowl and into a drain line. The toilet has a jet trapway portion having a jet inlet with a nozzle connected with the tank. The nozzle directs water from the jet inlet to overcome an upward bend in the jet trapway portion until received by the manifold at an inlet below the upward bend. A waste trapway portion extends from the manifold opposite the jet trapway portion and connects with the drain line. Waste is discharged from the bowl through the manifold over a bend in the waste trapway portion by combining water flowing from the jet trapway portion into the manifold with waste flowing from the manifold into the waste trapway portion.
A fill valve with pressure chamber having an open bottom end and a diaphragm at a top end such that falling water level in the toilet tank causes the diaphragm to flex in a first direction, thereby moving a sealing member to an open position, with a venturi in the fill valve keeping the sealing member in the open position until water refilling the tank causes the diaphragm to flex in a second direction, thereby moving the sealing member back to the closed position.
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
B67D 7/48 - Buses de remplissage se fermant automatiquement lorsque le liquide atteint un niveau prédéterminé dans le récipient à remplir en utilisant une aspiration d'air à travers un orifice fermé par la montée du liquide
F16K 31/365 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation le fluide agissant sur un diaphragme
E03D 3/06 - Clapets de chasse à fermeture automatique avec soupape à diaphragme et chambre de pression pour retarder le mouvement de fermeture du clapet
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte
F16K 11/085 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des robinets à boisseau à noix cylindrique
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
E03D 5/094 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un câble, d'une chaîne ou similaire
F16K 21/20 - Obturateurs à fermeture automatique, c.-à-d. se fermant d'eux-même après fonctionnement fermés quand la montée du liquide atteint un niveau prédéterminé par des moyens utilisant la succion de l'air au travers d'une ouverture fermée par la montée du liquide
Embodiments of the invention provide a gasket for a fluidic seal. Some embodiments include a flush valve to a toilet tank, where the gasket has a raised center portion and lowered inner and outer portions. In some embodiments, the gasket includes a plurality of recesses, troughs or grooves. Each of the three portions of the gasket has a bottom groove that can permit deformation and increases sealing capabilities when the groove either widens or narrows. Additionally, some embodiments include an inner support ring that extends inwardly from the lowered inner portion, and can center the gasket onto the flush valve.
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
F16J 15/10 - Joints d'étanchéité entre surfaces immobiles entre elles avec garniture solide comprimée entre les surfaces à joindre par garniture non métallique
A fill valve system with a float nested in a container connected to the fill valve and a siphon device passing water out of the container into the toilet tank, with the siphon device having an air vent dimensioned such that: (i) tank refilling is delayed until after the flush valve closes; (ii) the fill valve is not turned on by small leaks in the tank; and (iii) the fill valve turns off when it encounters large leaks in the tank.
F16K 31/126 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide le fluide agissant sur un diaphragme, un soufflet ou un organe similaire
E03D 3/06 - Clapets de chasse à fermeture automatique avec soupape à diaphragme et chambre de pression pour retarder le mouvement de fermeture du clapet
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
B67D 7/48 - Buses de remplissage se fermant automatiquement lorsque le liquide atteint un niveau prédéterminé dans le récipient à remplir en utilisant une aspiration d'air à travers un orifice fermé par la montée du liquide
F16K 31/365 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation le fluide agissant sur un diaphragme
F16K 21/20 - Obturateurs à fermeture automatique, c.-à-d. se fermant d'eux-même après fonctionnement fermés quand la montée du liquide atteint un niveau prédéterminé par des moyens utilisant la succion de l'air au travers d'une ouverture fermée par la montée du liquide
F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte
F16K 11/085 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des robinets à boisseau à noix cylindrique
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
E03D 5/094 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un câble, d'une chaîne ou similaire
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
A flow diverter for diverting flow between a toilet bowl and a toilet tank, the flow diverter having: a body with an inlet, outlet and pressure relief vent; and a flow adjustment mechanism rotatable around the outlet to selectively divert different percentages of flow between the outlet and the pressure relief vent by moving a stopper in and out of the outlet by rotating a sleeve of the flow adjustment mechanism around the outlet.
F16K 1/12 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation à corps de soupape profilé autour duquel le fluide s'écoule quand la soupape est ouverte
F16K 11/085 - Soupapes ou clapets à voies multiples, p. ex. clapets mélangeursRaccords de tuyauteries comportant de tels clapets ou soupapesAménagement d'obturateurs et de voies d'écoulement spécialement conçu pour mélanger les fluides dont toutes les faces d'obturation se déplacent comme un tout comportant uniquement des robinets à boisseau à noix cylindrique
E03D 1/30 - Clapets pour réservoirs hauts ou basLeur disposition
E03D 5/094 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un câble, d'une chaîne ou similaire
F16K 7/12 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme plat, en forme d'assiette ou en forme de bol
B67D 7/48 - Buses de remplissage se fermant automatiquement lorsque le liquide atteint un niveau prédéterminé dans le récipient à remplir en utilisant une aspiration d'air à travers un orifice fermé par la montée du liquide
F16K 31/365 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et dans lesquels il y a alimentation constante du moteur à fluide par le fluide provenant de la canalisation le fluide agissant sur un diaphragme
F16K 21/20 - Obturateurs à fermeture automatique, c.-à-d. se fermant d'eux-même après fonctionnement fermés quand la montée du liquide atteint un niveau prédéterminé par des moyens utilisant la succion de l'air au travers d'une ouverture fermée par la montée du liquide
E03C 1/02 - Installations de plomberie pour l'alimentation en eau
A toilet flush lever assembly having an adjustable length internal lever arm with a variable angle of connection to a short arm that passes through the wall of the toilet tank such that the angle of mounting of the adjustable length internal lever arm to an external flush lever arm is adjustable.
E03D 1/34 - Clapets de chasse pour vidangeDisposition des vannes de vidange
E03D 5/00 - Installations particulières d'appareils de chasse
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
E03D 5/092 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un levier
A toilet flush lever assembly having an adjustable length internal lever arm with a variable angle of connection to a short arm that passes through the wall of the toilet tank such that the angle of mounting of the adjustable length internal lever arm to an external flush lever arm is adjustable.
E03D 5/02 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement
E03D 5/00 - Installations particulières d'appareils de chasse
E03D 5/092 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un levier
E03D 1/34 - Clapets de chasse pour vidangeDisposition des vannes de vidange
A toilet having a tank to receive water and a bowl connected with the tank. Water travels from the tank to the bowl to discharge waste in the bowl through a manifold connected to the bowl and into a drain line. The toilet has a jet trapway portion having a jet inlet with a nozzle connected with the tank. The nozzle directs water from the jet inlet to overcome an upward bend in the jet trapway portion until received by the manifold at an inlet below the upward bend. A waste trapway portion extends from the manifold opposite the jet trapway portion and connects with the drain line. Waste is discharged from the bowl through the manifold over a bend in the waste trapway portion by combining water flowing from the jet tra pway portion into the manifold with waste flowing from the manifold into the waste trapway portion.
A fill valve with pressure chamber having an open bottom end and a diaphragm at a top end such that falling water level in the toilet tank causes the diaphragm to flex in a first direction, thereby moving a sealing member to an open position, with a venturi in the fill valve keeping the sealing member in the open position until water refilling the tank causes the diaphragm to flex in a second direction, thereby moving the sealing member back to the closed position.
F16K 21/20 - Obturateurs à fermeture automatique, c.-à-d. se fermant d'eux-même après fonctionnement fermés quand la montée du liquide atteint un niveau prédéterminé par des moyens utilisant la succion de l'air au travers d'une ouverture fermée par la montée du liquide
B67D 7/48 - Buses de remplissage se fermant automatiquement lorsque le liquide atteint un niveau prédéterminé dans le récipient à remplir en utilisant une aspiration d'air à travers un orifice fermé par la montée du liquide
F04F 5/04 - Pompes à jet, p. ex. dispositifs dans lesquels le flux est produit par la chute de pression causée par la vitesse d'un autre fluide le fluide inducteur étant un liquide déplaçant des fluides compressibles
A flow diverter for diverting flow between a toilet bowl and a toilet tank, the flow diverter having: a body with an inlet, outlet and pressure relief vent; and a flow adjustment mechanism rotatable around the outlet to selectively divert different percentages of flow between the outlet and the pressure relief vent by moving a stopper in and out of the outlet by rotating a sleeve of the flow adjustment mechanism around the outlet.
A fill valve system with a float nested in a container connected to the fill valve and a siphon device passing water out of the container into the toilet tank, with the siphon device having an air vent dimensioned such that: (i) tank refilling is delayed until after the flush valve closes; (ii) the fill valve is not turned on by small leaks in the tank; and (iii) the fill valve turns off when it encounters large leaks in the tank.
F16K 31/18 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur
F16K 31/20 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur commandant une soupape de levage
A fill valve having top and bottom openings that are opened and closed by up and down movement of an upper seal and a lower seal that are both connected to a float, wherein the upper seal is positioned below the top opening and the lower seal is positioned below the bottom opening, and wherein the upper seal is larger than the lower seal such that the total force required to open or close the valve is very small, thereby enabling the float that is used to be small as well.
A toilet sensor and actuator assembly, having: (a) an infrared sensor configured to detect the presence of an object at a far distance from a toilet; (b) an ultrasonic sensor configured to detect the presence of the object at a near distance from the toilet, wherein the ultrasonic sensor remains in a sleep mode until awakened by a signal from the infrared sensor that the infrared sensor has detected the presence of the object at the far distance; and (c) an actuator mechanism that flushes the toilet in response to a signal from the ultrasonic sensor that the ultrasonic sensor has detected the presence of the object at the near distance.
A touchless flush system, comprising a toilet bowl, a flush controller, and a sensor unit. The flush controller is operatively connected to the toilet bowl. The sensor unit is operatively connected to the flush controller, the sensor unit being operable to detect changes within the toilet bowl. The sensor unit detects changes in properties of the toilet bowl with respect to contents present therein, wherein if a detected change in properties satisfies a first predetermined threshold, the flush controller causes a flush volume to be delivered to the toilet bowl.
A flush consistency control system may comprise a reservoir with a drain opening for egress of liquids from the reservoir into a toilet tank. The reservoir may comprise a surface with one or more walls and a partition on the surface dividing the reservoir into multiple compartments which may house liquids, wherein the compartments are in fluid communication through a gap so liquids flow at a predetermined rate between the compartments and through a drain opening of the reservoir. A flush consistency control system may also comprise a post with one or more latches extending away from the post, the latch having a lower mounting surface which extends away from the post at a declining angle and a latch-strike end of a float lever that securely engages with the lower mounting surface of the latch when the float descends.
A system for mounting a fill valve in a toilet with a pivotable reservoir is disclosed. The pivotable reservoir is disposed inside the toilet tank. A fill valve is secured in the tank and designed to deliver water to the pivotable reservoir from an external water supply, wherein the fill valve is secured by a valve support mechanism to a lower portion of the tank. The fill valve support mechanism comprises a fluid line support mechanism and a fluid line. The fluid line support mechanism routes the fluid line away from and around the space through which the pivotable reservoir moves when actuated. A plurality of fasteners connect the fluid line to the fluid line support mechanism and the fill valve mechanism to the toilet tank and water supply.
A touchless activation system comprising an infrared detector configured to detect an object within a target range, wherein an initial reading is measured by the infrared detector. A second sensor operatively connected to the infrared detector, wherein the second sensor is turned on when the initial reading is measured. The infrared detector measures whether the object is within the target range by comparing the initial reading with an object initiated reflection and determining if a predetermined threshold is exceeded, wherein the second sensor is configured to receive a system activation request. An activator mechanism configured to process the system request and cause the touchless activation system to execute an action associated with the system request. The system is configured to flush a toilet or other plumbing fixture, wherein the system request causes the activator mechanism to flush a toilet.
An improved flush assembly as described herein may comprise a reservoir with a drain opening for egress of liquids disposed in the reservoir into a surrounding toilet tank. A lock mechanism is slidably received by the reservoir so that the lock mechanism is translatable between one or more fixed positions on the reservoir. In turn, translating the lock mechanism into the reservoir at increasing depths causes a size of the drain opening to be reduced and therefore adjusted.
A flush valve system may comprise a rail guide configured to extend between upper and lower portions of the flush valve system in a toilet tank. A float may be slidably coupled to the rail guide and be configured to be received by a reservoir associated with the float. The float may comprise a closed upper surface with a mating pocket and one or more circumferential walls extending from the closed upper surface. A lock mechanism may be slidably received by the mating pocket of the float. The lock mechanism may comprise one or more bias arms to fixedly engage the lock mechanism to the float and one or more locking members to fixedly engage the lock mechanism to the rail guide.
An improved flush system as described herein may comprise a reservoir with a drain opening for egress of liquids disposed in the reservoir into a surrounding toilet tank. A lock mechanism is slidably received by the reservoir so that the lock mechanism is translatable between one or more fixed positions on the reservoir. In turn, translating the lock mechanism into the reservoir at increasing depths causes a size of the drain opening to be reduced and therefore adjusted.
A flush valve system may comprise a rail guide configured to extend between upper and lower portions of the flush valve system in a toilet tank. A float may be slidably coupled to the rail guide and be configured to be received by a reservoir associated with the float. The float may comprise a closed upper surface with a mating pocket and one or more circumferential walls extending from the closed upper surface. A lock mechanism may be slidably received by the mating pocket of the float. The lock mechanism may comprise one or more bias arms to fixedly engage the lock mechanism to the float and one or more locking members to fixedly engage the lock mechanism to the rail guide.
A device for preventing leaks in a toilet that comprises a fill valve operatively connected to and disposed above a float. In certain embodiments an arm is rotably connected to the fill valve such that the arm comprises a pivot. A lever is, for example, pivotally connected to the pivot of the arm and biased towards the fill valve, wherein a flush actuator causes the lever to pivot away from the fill valve. The lever may comprise a first side and a second side joined at the pivot, wherein the first side weighs less than the second side, and wherein the distribution of weight between the first and second sides of the lever causes the lever to bias towards the fill valve.
A fluid connector assembly comprises an outer fastener and an inner fastener. The outer fastener is comprised of a top surface, a bottom surface, and a plurality of radially extending members on the top surface. The inner fastener is provided comprising a top surface, a bottom surface, and a plurality of radially extending projections. The radially extending projections are dimensioned to be received by the radially extending members when the inner fastener is assembled with the outer fastener. A connector is disposed in the inner fastener, wherein the connector may be externally threaded so as to receive a fluid supply line that is internally threaded. The radially extending projections of the inner fastener may be flexible.
F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord
A toilet lever assembly, including: (a) a sleeve dimensioned to pass through a toilet tank wall; (b) a rotatable post extending through the sleeve; (c) a toilet flush handle mounted to the end of the rotatable post that is positioned outside of the toilet tank; (d) a nut received onto the end of the sleeve that is positioned outside of the toilet tank; and (e) a lever housing mounted to the end of the post that is positioned inside of the toilet tank, the lever housing comprising: (i) an actuator for moving a toilet lever to cause a flush when the post is rotated, and (ii) a biasing mechanism for rotating the post back to a neutral position.
E03D 5/092 - Installations particulières d'appareils de chasse actionnés mécaniquement ou hydrauliquement par la main directement l'élément de chasse, p. ex. cloche de siphon, étant actionné par l'intermédiaire d'un levier
A toilet sensor and actuator assembly, having: (a) an infrared sensor configured to detect the presence of an object at a far distance from a toilet; (b) an ultrasonic sensor configured to detect the presence of the object at a near distance from the toilet, wherein the ultrasonic sensor remains in a sleep mode until awakened by a signal from the infrared sensor that the infrared sensor has detected the presence of the object at the far distance; and (c) an actuator mechanism that flushes the toilet in response to a signal from the ultrasonic sensor that the ultrasonic sensor has detected the presence of the object at the near distance.
A flow valve that maintains a constant flow valve despite varying pressures at its inlet, comprising: (a) an elongated cage with alternating axially-extending pockets and ridges on its inner surface; and (b) an elongated generally conical shaped elastomeric sleeve received within the elongated cage; wherein the sleeve flexes outwardly at higher pressures, thereby decreasing the size of the flow channel between the sleeve and cage, thereby restricting flow to maintain constant flow valve despite varying inlet pressures.
F16K 7/04 - Dispositifs d'obturation à diaphragme, p. ex. dont un élément est déformé, sans être déplacé entièrement, pour fermer l'ouverture à diaphragme tubulaire dont l'étranglement est assuré par une force extérieure radiale
F16K 15/14 - Soupapes, clapets ou valves de retenue à corps de soupapes flexibles
F16K 17/34 - Soupapes ou clapets limiteurs de débit dans lesquels l'énergie provenant du courant du fluide actionne le mécanisme de fermeture
A flow valve that maintains a constant flow valve despite varying pressures at its inlet, comprising: (a) an elongated cage with alternating axially-extending pockets and ridges on its inner surface; and (b) an elongated generally conical shaped elastomeric sleeve received within the elongated cage; wherein the sleeve flexes outwardly at higher pressures, thereby decreasing the size of the flow channel between the sleeve and cage, thereby restricting flow to maintain constant flow valve despite varying inlet pressures.
A toilet flush valve that has a moveable buoyant float therein, wherein the float has an open bottom end to trap air therein and wherein the housing includes controls to selectively release air to allow the float to move upwardly therein to permit flushing. By timing when one or two air vents on the housing are open, the duration and volume of the flush can be controlled, with the buoyancy provided by the water lifting the float to open the flush valve. This provides a flushing system with minimal activation energy.
A toilet flush valve that has a moveable buoyant float therein, wherein the float has an open bottom end to trap air therein and wherein the housing includes controls to selectively release air to allow the float to move upwardly therein to permit flushing. By timing when one or two air vents on the housing are open, the duration and volume of the flush can be controlled, with the buoyancy provided by the water lifting the float to open the flush valve. This provides a flushing system with minimal activation energy.
A fluid connector, having: (a) a flexible tube; (b) an outwardly expandable barbed fitting receivable into a distal end of the flexible tube, wherein the outwardly expandable barbed fitting can be deformed outwardly against an inner surface of the flexible tube; (c) a collar received around the flexible tube; and (d) a hose end connector receivable onto the collar.
F16L 33/207 - Segments, manchons ou autres organes d'une seule pièce enserrant la manche ou dilatés à l'intérieur de la manche au moyen d'outilsAgencements utilisant de tels organes avec uniquement un manchon contracté sur la manche
A toilet valve adapter, including: a hollow body having a lower end dimensioned to be received into an outlet and an upper end dimensioned to support a flush valve thereon; a flange extending radially outwards from the hollow circular body; a gasket on the underside of the flange; and prongs projecting radially outwards from the lower end of the hollow circular body.
A toilet valve float adjustment assembly, including: a dual flush valve; a pair of floats disposed within the dual flush valve, wherein the vertical position of one of the floats determines the flush volume for a full flush and the vertical position of the other float determines the flush volume for a partial flush; a pair of adjustment mechanisms, wherein each adjustment mechanism adjusts the vertical height of one of the floats; and a pair of locking mechanisms, wherein each locking mechanism inhibits movement of one of the adjustment mechanisms, thereby keeping its float at a preferred vertical height when locked, and wherein the adjustment and locking mechanisms are controlled at the top of the dual flush valve.
A torque limiting fluid connector system which can be hand screwed to a maximum tightening torque but can be hand loosened, including: an outer member having a front opening, a back opening, and a plurality of outwardly flexible portions separated by axially extending slots; an inner member having a front opening, a back opening, an interior threaded surface and a plurality of outwardly extending projections dimensioned to be received within the axially extending slots when the inner member is received within the outer member; a connector having one end received within the inner member and an opposite end extending out of the back end of the inner member; and a washer mounted onto the end of the connector that is received within the inner member
F16L 3/04 - Supports pour tuyaux, pour câbles ou pour conduits de protection, p. ex. potences, pattes de fixation, attaches, brides, colliers entourant partiellement le tuyau, le câble ou le conduit de protection et le serrant contre un mur ou un autre support
F16L 41/00 - Tuyaux de branchementRaccordements des tuyaux aux parois
A torque limiting fluid connector system which can be hand screwed to a maximum tightening torque and be hand loosened, including: an outer member having a front opening, a back opening, and a plurality of outwardly flexible portions separated by axially extending slots; an inner member having a front opening, a back opening, an interior threaded surface and a plurality of outwardly extending projections dimensioned to be received within the axially extending slots when the inner member is received within the outer member; a connector having one end received within the inner member and an opposite end extending out of the back end of the inner member; and a washer mounted onto the end of the connector that is received within the inner member.
F16L 19/02 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé
F16L 33/207 - Segments, manchons ou autres organes d'une seule pièce enserrant la manche ou dilatés à l'intérieur de la manche au moyen d'outilsAgencements utilisant de tels organes avec uniquement un manchon contracté sur la manche
non-metal hardware, namely, torque nuts constructed primarily with non-metal materials but having some metal parts, for use in connection with waterline connector hoses for toilets, faucets, and other appliances requiring a waterline
An air activated toilet flush system, including: a toilet bowl; a reservoir; a fluid conduit between the reservoir and the toilet bowl; a system for supplying water into the reservoir; and a system for supplying air into the reservoir, wherein a supply of air into the reservoir causes fluid to flow from the reservoir through the fluid conduit and into the toilet bowl.
Non-metal hardware, namely, torque nuts constructed primarily of non-metal materials but having some metal parts for use in connection with waterline connector hoses for toilets, faucets, and other appliances requiring a waterline
non-metal hardware, namely, torque nuts constructed primarily with non-metal materials but having some metal parts, for use in connection with waterline connector hoses for toilets, faucets, and other appliances requiring a waterline
A jet powered toilet flushing system, including: a toilet bowl; a reservoir; a fluid conduit between the reservoir and the toilet bowl; a jet inside the reservoir, the jet having a nozzle directed toward an entrance of the fluid conduit; a fill valve that supplies water to the jet; and a flow diverter in the reservoir, the flow diverter positioned to divert water flow: (a) from the jet nozzle into the entrance of the fluid conduit when the reservoir is full, or (b) from the jet nozzle away from the entrance of the fluid conduit and into the reservoir when the reservoir is empty.
An air activated toilet flush system, including: a toilet bowl; a reservoir; a fluid conduit between the reservoir and the toilet bowl; a system for supplying water into the reservoir; and a system for supplying air into the reservoir, wherein a supply of air into the reservoir causes fluid to flow from the reservoir through the fluid conduit and into the toilet bowl.
A diverter valve including: an inlet port coupled to a refill tube; a first outlet port; a bowl refill tube coupled to the outlet port with its second end adjacent to a toilet tank overflow tube; a second outlet port; a central flow passageway providing a path of fluid communication between the inlet port and the first and second outlet ports, the entrance of the first outlet port and the entrance of the second outlet port being directly opposite one another in the central flow passageway; a poppet in the central flow passageway, the poppet having a raised position obstructing the first outlet port and a lowered position obstructing the second outlet port; an actuating arm, float member and rod coupled to the poppet, wherein movement of the float member translates downward motion of the rod into upward motion of the actuating arm and vice versa.
A flapper flush valve assembly includes a pair of laterally movable mounting arms which may be adjusted to vary a width therebetween to accommodate overflow tubes of different sizes. The flapper valve assembly is coupled to pivot members connected to an overflow tube. Mounting ears on the pivot members may include projections to provide spacing between the rotating mounting arms and adjacent sidewall of a toilet tank, thereby preventing jams.
A flapper flush valve assembly includes a pair of laterally movable mounting arms which may be adjusted to vary a width therebetween to accommodate overflow tubes of different sizes. The flapper valve assembly is coupled to pivot members connected to an overflow tube. Mounting ears on the pivot members may include projections to provide spacing between the rotating mounting arms and adjacent sidewall of a toilet tank, thereby preventing jams.
