A beauty instrument (100), comprising a main body (10), a xenon lamp tube (50), and a light filter assembly (80). The main body (10) is provided with an accommodation cavity, and a light outlet (11) through which the accommodation cavity and the external environment communicate is formed in the main body (10). The xenon lamp tube (50) is arranged in the accommodation cavity, and light beams emitted from the xenon lamp tube (50) exit by means of the light outlet (11). The light filter assembly (80) is arranged between the xenon lamp tube (50) and the light outlet (11). The light filter assembly (80) comprises a light filter support (81) and light filters (84). At least two mounting positions are arranged on the light filter support (81), and different light filters (84) for different light wave bands are arranged in different mounting positions. The light filter support (81) is rotatably connected in the accommodation cavity of the main body (10) to switch between different mounting positions to correspond to the light outlet (11), so that as the color filters (84) move along with the light filter support (81), the light filter assembly switches between the different light filters (84) to cover the light outlet (11), thereby changing the wave band of the light beams that exit by means of the light outlet (11).
A photographic and video light includes a light head module, an optical module and a power supply module, the light head module includes a first housing and a light source assembly, one end of the first housing being an open end, the other end of the first housing being a mounting end; the optical module comprises a second housing and a light-effect lens, the second housing being mounted at the opening end, a light inlet and a light outlet being respectively provided at two ends of the second housing,; and the power supply module comprises a third housing, with an end of the third housing being detachably connected to the mounting end, and the power supply module supplies power to the light source assembly, wherein the first housing, the second housing and the third housing constitute the complete housing of the photographic and video light.
Alight source module comprises the light-emitting element, a heat radiator and a diffusion lens. The light-emitting element comprises a substrate and a chip module arranged on the substrate. RGB light mixing units and cold and warm light mixing units of the light-emitting element are concentrically arranged, a plurality of RGB light mixing units and a plurality of cold and warm light mixing units are alternately arranged at intervals, and the plurality of RGB light mixing units and the plurality of cold and warm light mixing units are rotationally symmetrical about the center of the chip module.
F21K 9/62 - Agencements optiques intégrés dans la source lumineuse, p. ex. pour améliorer l’indice de rendu des couleurs ou l’extraction de lumière en utilisant des chambres de mélange, p. ex. des enceintes à parois réfléchissantes
F21V 29/67 - Dispositions de refroidissement caractérisées par l’utilisation d’un écoulement forcé de gaz, p. ex. de l’air caractérisées par la disposition de ventilateurs
F21V 29/71 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques utilisant une combinaison d’éléments séparés interconnectés par des moyens thermo-conducteurs, p. ex. tubes caloporteurs ou barres thermiquement conductrices pour conduire la chaleur entre des éléments séparés de puits thermique
F21V 29/76 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames avec ailettes ou lames en plans parallèles essentiellement identiques, p. ex. avec une section en forme de peigne
F21V 29/83 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques les éléments comportant des ouvertures, des conduits ou des canaux, p. ex. des trous de rayonnement thermique
F21Y 105/18 - Sources lumineuses planes comprenant un réseau bidimensionnel d’éléments générateurs de lumière ponctuelle caractérisées par la forme d’ensemble du réseau bidimensionnel annulaireSources lumineuses planes comprenant un réseau bidimensionnel d’éléments générateurs de lumière ponctuelle caractérisées par la forme d’ensemble du réseau bidimensionnel polygonale autre que rectangulaire ou carrée, p. ex. pour les spots lumineux ou pour générer un faisceau lumineux axialement symétrique
F21Y 113/17 - Combinaison de sources lumineuses de couleurs différentes comprenant un ensemble de sources lumineuses ponctuelles formant une seule source lumineuse encapsulée
A condenser (100) and a lighting system (1000). The lighting system (1000) comprises a condenser (100) and a light source (200) connected to the condenser (100), wherein the condenser (100) comprises a condenser body (10), and a light mixing lens (20) and a condensing lens (30) which are arranged on the condenser body (10). The condenser (100) firstly mixes, by means of the light mixing lens (20), light emitted by the light source (200), and then condenses the light by means of the condensing lens (30), such that the projected light is uniform, thereby effectively reducing disordered light spots, making the light integrity better, and having a better lighting effect. The condenser (100) is particularly suitable for the light source (200) having multi-color or double-color lamp beads, can effectively improve the color consistency of light emitted by the light source (200), enhances the light efficiency, and efficiently meets diverse use requirements of users.
An external flash lamp and a flash lamp system. The flash lamp system comprises an external flash lamp and a set-top flash lamp. After the external flash lamp is detachably fixed to the set-top flash lamp, the external flash lamp can be electrically connected to the set-top flash lamp, so as to transmit a control signal and an operating current. The illumination range of the external flash lamp can supplement the illumination range of the set-top flash lamp, thereby solving the problem of low brightness of some areas.
A photography lamp assembly (100) and a photography lighting system (1000). The photography lamp assembly (100) comprises a lamp cover body (10) and a light shielding unit (20). The inner wall of the lamp cover body (10) is a reflection surface (103), the reflection surface (103) is in a gradually expanding parabola shape, and light rays emitted by a light source (200) is reflected by the reflection surface (103) to form parallel light perpendicular to the plane where a light output port (102) is located. A reflection area (105) is formed inside the lamp cover body (10), the light shielding unit (20) is arranged in the reflection area (105), and the peripheral side edges of the light shielding unit (20) are all tangent to the set intersection line of the reflection area (105), so that the light shielding unit (20) can absorb light rays that are emitted by the light source (200) but not reflected by the reflection surface (103), so as to effectively reduce the amount of non-parallel light contained in the light rays emitted from the lamp cover body (10) to improve the uniformity of the entire illumination surface, thereby effectively improving the imaging effect of photography to efficiently meet the photography requirements of a user.
A beauty and hair care instrument, comprising a helmet, side panels, and light sources. The light sources are arranged inside the helmet and inside the side panels. Light emitted by the light source in the helmet can be directed toward the head of a user, and light emitted by the light sources in the side panels can be directed toward the face of the user. When the beauty and hair care instrument is used, the user can select to only use the helmet to carry out hair care or connect the side panels to the helmet to simultaneously carry out hair care and facial beauty care according to beauty requirements. After use, the user can detach the side panels from the helmet and separately store the side panels and the helmet, which facilitates the placement of the beauty and hair care instrument and helps to improve the use experience of the user.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Adapter rings for attaching objectives on cameras; Filters for radio interference suppression; Phototelegraphy apparatus; Computer component testing and calibrating equipment; Cellular phone usage detection system comprising a camera and a mobile phone signal receiving device; Calculating machines; Weighing apparatus and instruments; Semiconductors; Camera tripods; Radar detectors; Flashing safety lights; Optical lenses; Drying racks for photography; Digital cameras; Photography drying racks; Capacitors; Flashlights for use in photography; Record playing apparatus and instruments; Batteries; Cables, electric; Microprocessors Electric torches for lighting; Water purification installations; Electric bath-water purifying apparatus for household purposes; Lighting apparatus, namely, lighting installations; Disinfecting ultraviolet lamps housed in a container or cover for disinfecting objects placed therein; Air sterilizers; Electric flashlights; Lamps; Germicidal lamps for purifying air; Luminous tubes for lighting; Water sterilizers
9.
LIGHT CONTROL METHOD AND SYSTEM, AND ELECTRONIC DEVICE
A light control method and system, and an electronic device and a storage medium. The light control method comprises: acquiring a background video; selecting from the background video a mapping point associated with each light device in a filming site, wherein one mapping point is correspondingly associated with one group of light devices, that is, positions to which the light devices in the filming site are mapped can be specified from the background video; and acquiring a real-time color parameter of each mapping point in the background video, and sending the real-time color parameter to the light device associated with the mapping point, such that the light device can adjust emitted light in real time on the basis of the acquired color parameter of the mapping point, thereby making the light effect produced by the light device matching the background video. In this way, the difference between a light effect on a filmed person and a background in a video can be reduced, thereby improving the realism of the obtained video.
H04N 23/74 - Circuits de compensation de la variation de luminosité dans la scène en influençant la luminosité de la scène à l'aide de moyens d'éclairage
10.
VISUAL MANAGEMENT METHOD FOR LIGHTING, AND LIGHTING CONTROL SYSTEM
A visual management method for lighting, a lighting control system, an electronic device and a storage medium, which belong to the technical field of lighting device control. In the method, firstly, communication connections with lighting devices (200) on a filming site are established, so that basic information of the lighting devices (200) on the filming site can be acquired, and corresponding lighting icons are generated. Then, the lighting icons are arranged in a preset grid diagram according to a lamp position layout of the lighting devices (200) on the filming site, so that the positions of the lighting icons in the grid diagram correspond to the lamp positions of the corresponding lighting devices (200) on the filming site on a one-to-one basis. Then, by triggering a lighting icon which requires to be adjusted in the grid diagram, a corresponding control parameter can be correspondingly input, so as to control the light emission of the corresponding lighting device (200). When a lighting device (200) on the filming site requires to be adjusted and controlled, a corresponding lighting icon can be visually located to perform control, the operation is simple, and the fast pace of working on the filming site can be well satisfied.
A photography/video recording light (100), comprising a light body (10), a light source (20), an electronically controlled film (30) and a power supply module, wherein the electronically controlled film (30) is disposed on a light-emission path of the light source (20), and light rays emitted by the light source (20) can pass through the electronically controlled film (30) and be emitted from the surface of the lamp body (10). The light transmittance of the electronically controlled film (30) can change on the basis of a received voltage value, so as to adjust the degree of haze of the electronically controlled film (30) or adjust the shade of a displayed color, such that the softness or color lightness of light rays, which are emitted by the light source (20), are adjusted.
F21V 14/00 - Commande de la distribution de la lumière émise par réglage d’éléments constitutifs
F21V 9/40 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres avec des dispositions pour commander les propriétés spectrales, p. ex. la couleur, ou l’intensité
12.
DIFFUSER PANEL, DIMMING SYSTEM, CAMERA SYSTEM AND DIMMING CONTROL METHOD
A diffuser panel (10), a dimming system (2), a camera system (3) and a dimming control method. The diffuser panel (10) comprises an electrically-controlled haze film (100) and a control box (200), the electrically-controlled haze film (100) being electrically connected to the control box (200). The control box (200) comprises a communication module (210), a regulation module (220), an inverter circuit module (230) and a direct current module (240), the communication module (210) being electrically connected to the regulation module (220), the regulation module (220) being electrically connected to the inverter circuit module (230), the inverter circuit module (230) being electrically connected to the electrically-controlled haze film (100), and the direct current module (240) being electrically connected to the regulation module (220) and the inverter circuit module (230). On the basis of regulation control signals transmitted by an external control device (20), the control box (200) can regulate the voltage and frequency of an alternating current output to the electrically-controlled haze film (100), so as to regulate the degree of haze of the electrically-controlled haze film (100), and match the frequency of the alternating current input into the electrically-controlled haze film (100) with a photographing frequency of a camera (40), such that frequent diffuser panel (10) change is not needed, operation is convenient, and photographed images are free of flicker banding artifacts, thereby satisfying photographing requirements.
The present application relates to a phototherapy-based skin beauty instrument, and belongs to the technical field of beauty devices. The phototherapy-based skin beauty instrument comprises a housing, an optical unit, and an atomization unit. A care space is formed in the housing. An opening for limbs to enter the care space is formed in the housing. The optical unit is arranged in the housing. The optical unit comprises a xenon lamp tube that is capable of emitting beauty light to the care space so as to irradiate the limbs in the care space by means of the beauty light. The atomization unit is arranged in the housing. A mist outlet of the atomization unit is in communication with the care space. The atomization unit is connected to a liquid source and is capable of atomizing the liquid source to form water mist and making the water mist move into the care space from the atomization unit so as to care the limbs of a user, such that the human body can be cared by means of light waves and a care liquid at the same time, thus enriching the functions of the phototherapy-based skin beauty instrument. In addition, the care effect is better.
The present application provides an optical beauty instrument, which comprises a holding piece, a rotary shaft, and a beauty piece. The beauty piece comprises a beauty housing, and a lighting component and a heat dissipation component which are arranged inside the beauty housing. Light emitted by the lighting component can exit through a light outlet on the beauty housing to achieve a light-based beauty effect. The heat dissipation component can dissipate heat of the lighting component, so that normal and smooth use of the optical beauty instrument is ensured. Moreover, the beauty piece can rotate relative to the holding piece by means of the rotary shaft, so that when performing beauty treatment on some specific areas, a user can adjust the angle of the beauty piece simply by rotating the beauty piece relative to the holding piece, without needing to raise the hand or bending the wrist, so that the comfort level of the user during use is effectively guaranteed, ensuring the high-quality use experience of the user.
A hot shoe assembly, an on-camera device, and a photography system. In the hot shoe assembly (10), a hot shoe connecting plate (12) arranged on a hot shoe body (11) can be used for connection to a camera, and can implement an electrical signal connection between the hot shoe assembly (10) and the camera. In addition, connecting portions (13) arranged on the hot shoe body (11) can enable the hot shoe body (11) to be detachably fixed on a functional assembly (20), and a female connector terminal (14) of the hot shoe assembly (10) can be electrically connected to a male connector terminal (24) of the functional assembly (20) to implement an electrical signal connection between the hot shoe assembly (10) and the functional assembly (20). Therefore, when equipping the functional assembly (20) for different brands and models of cameras, the same functional assembly (20) can be matched with different brands and models of cameras by simply providing the hot shoe assembly (10) comprising the corresponding hot shoe connecting plate (12), thereby effectively reducing the use costs of users and improving user experience.
A control method and system for high-speed synchronous flash of a flash lamp, applied to a mobile terminal such as a camera. A plurality of capacitors of a flash lamp can sequentially and periodically discharge in respective first working cycles, so that the frequency of a flash lamp tube receiving voltages is multiplied, thereby effectively increasing the flash frequency of the flash lamp without improving the hardware performance of the capacitors, achieving the effect of high-speed synchronous flash of the flash lamp.
A lamp for photography and video includes a main body and a lamp head provided on the main body, wherein the lamp head includes: a housing, provided with an accommodation cavity inside, an end of the housing is provided with an opening in communication with the accommodation cavity; a light source, provided in the accommodation cavity of the housing; a light effect lens, provided at the opening of the housing and on a same optical axis as the light source; and a transparent heat insulation member, provided between the light source and the light effect lens for blocking heat emitted from the light source to the light effect lens.
A light emitting diode (LED) module includes a substrate, the substrate includes a light emitting region, the light emitting region includes a plurality of light emitting sub-regions, and a first light emitting sub-region and a second light emitting sub-region are provided symmetrically about a symmetry axis to form a group of symmetric light emitting regions; or the light emitting region includes a first light emitting region and a second light emitting region, and the first light emitting region and the second light emitting region are provided symmetrically about a symmetry axis; an LED array, provided within the light emitting region.
H10H 29/24 - Ensembles de plusieurs dispositifs comprenant au moins un composant émetteur de lumière à semi-conducteurs couvert par le groupe comprenant plusieurs dispositifs émetteurs de lumière à semi-conducteurs
H10H 29/851 - Moyens de conversion de la longueur d’onde
An external flash lamp (10) and a flash lamp system (100). The flash lamp system (100) comprises an external flash lamp (10) and a set-top flash lamp (20). After the external flash lamp (10) is detachably fixed to the set-top flash lamp (20), the external flash lamp (10) can be electrically connected to the set-top flash lamp (20), so as to transmit a control signal and an operating current. The illumination range of the external flash lamp (10) can supplement the illumination range of the set-top flash lamp (20), thereby solving the problem of low brightness of some areas.
A photography and videography lamp (100), comprising a lamp head module (10), an optical module (20) and a power supply module (40), wherein the lamp head module (10) comprises a first housing (11) and a light source assembly (13), one end of the first housing (11) being an open end (1102), the other end of the first housing (11) being a mounting end (1101), and light being capable of exiting through the open end (1102); the optical module (20) comprises a second housing (21) and a light-effect lens (22), the second housing (21) being mounted at the opening end (1102), a light inlet (25) and a light outlet (26) being respectively provided at two ends of the second housing (21), and light being emitted into the second housing (21) through the light inlet (25), passing through the light-effect lens (22), and then exiting through the light outlet (26); and the power supply module (40) comprises a third housing (42), with an end of the third housing (42) being detachably connected to the mounting end (1101), and the power supply module (40) supplies power to the light source assembly (13), wherein the first housing (11), the second housing (21) and the third housing (42) constitute the complete housing of the photography and videography lamp (100).
F21S 2/00 - Systèmes de dispositifs d'éclairage non prévus dans les groupes principaux ou , p. ex. à construction modulaire
F21L 4/00 - Dispositifs d'éclairage électriques avec des accumulateurs ou des piles électriques incorporés
F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
F21V 17/10 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection caractérisée par des moyens de fixation spécifiques
F21V 15/01 - Boîtiers, p. ex. matériau ou assemblage de parties du boîtier
F21V 33/00 - Combinaisons structurales de dispositifs d'éclairage avec d'autres objets, non prévues ailleurs
H04N 23/56 - Caméras ou modules de caméras comprenant des capteurs d'images électroniquesLeur commande munis de moyens d'éclairage
The present invention provides a light-emitting element and a light source module. The light source module comprises the light-emitting element, a heat radiator and a diffusion lens. The light-emitting element comprises a substrate and a chip module arranged on the substrate. RGB light mixing units and cold and warm light mixing units of the light-emitting element are concentrically arranged, a plurality of RGB light mixing units and a plurality of cold and warm light mixing units are alternately arranged at intervals, and the plurality of RGB light mixing units and the plurality of cold and warm light mixing units are rotationally symmetrical about the center of the chip module. In this way, all the RGB chip sets, warm light chips and cold light chips are distributed more uniformly on the substrate, so that different light colors can be fully mixed to achieve a good light mixing effect. Thus, in the light source module, the light mixing effect can be achieved without the need for an additional light mixing cavity structure, thereby simplifying the structure of the light source module, reducing light loss caused by multiple reflections in the light mixing cavity, improving the light efficiency, and ensuring the user experience.
F21K 9/69 - Détails des réfracteurs faisant partie de la source lumineuse
H01L 25/075 - Ensembles consistant en une pluralité de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide les dispositifs étant tous d'un type prévu dans une seule des sous-classes , , , , ou , p. ex. ensembles de diodes redresseuses les dispositifs n'ayant pas de conteneurs séparés les dispositifs étant d'un type prévu dans le groupe
H01L 33/64 - DISPOSITIFS À SEMI-CONDUCTEURS NON COUVERTS PAR LA CLASSE - Détails caractérisés par les éléments du boîtier des corps semi-conducteurs Éléments d'extraction de la chaleur ou de refroidissement
F21K 9/20 - Sources lumineuses comprenant un moyen de fixation
22.
CONDENSER AND PHOTOGRAPHING AND VIDEO RECORDING LIGHT EFFECT SYSTEM
A condenser (100) and a photographing and video recording light effect system, the condenser (100) comprising a main body unit (10) and a moving unit (20). The main body unit (10) comprises a main body (11) and a first lens (12), the main body (11) being open at two ends and being hollow inside so as to form a first optical path channel (103), and the first lens (12) being arranged in the first optical path channel (103). The moving unit (20) comprises a front housing (21) and a second lens (22), the front housing (21) being open at two ends and being hollow inside so as to form a second optical path channel (104), and the second lens (22) being arranged in the second optical path channel (104). The front housing (21) is movably connected to the end of the main body (11) away from the first lens (12), and can move in the axis direction of the main body (11). When the front housing (21) moves in the axis direction of the main body (11) to get away from or get close to a light source, the distance between the first lens (12) and the second lens (22) can be adjusted, so as to change the divergence angle of light passing through the first lens (12) and the second lens (22), thus solving the problem of conventional condensers being incapable of adjusting the divergence angle of light.
The present application relates to an angle adjustment mechanism and a soft light cover, belonging to the technical field of photographic equipment. The angle adjustment mechanism comprises a chuck and a handle, wherein the chuck comprises an annular disc body and a rotating block, the disc body is used for mounting an umbrella cover of a soft light cover, a clamping position for mounting a lamp is provided in the disc body, and the rotating block is fixedly arranged on the outer side face of the disc body; the handle comprises a rod body and a locking member; the rotating block is rotatably connected to the top end of the rod body, so as to enable the disc body to rotate at the top end of the rod body; and the locking member is arranged on the outside of the rotating block, and the current rotation angle of the rotating block is locked or unlocked by adjusting the distance between the locking member and the rotating block. The technical problem whereby the angle of the soft light cover needs to be controlled by a user by means of an arm and a wrist is solved. (FIG. 4)
A softbox angle adjusting mechanism and a softbox. The softbox angle adjusting mechanism comprises a handle (60), a locking assembly (80), and a second adjusting member (90). The handle (60) is configured to be connected to a dome (10), and the handle (60) is internally provided with a mounting cavity (61) for mounting the locking assembly (80) and the second adjusting member (90). The locking assembly (80) comprises a latch member (81) and a locking button (82). The latch member (81) is slidably connected into the mounting cavity (61), and a first locking portion (811) is provided at the bottom of the latch member (81). The locking button (82) extends into the mounting cavity (61) and is exposed from the handle (60). The locking button (82) is connected to the latch member (81) so as to enable the latch member (81) to stop sliding. The second adjusting member (90) is rotatably mounted at the lower end of the handle (60), and a second locking portion (91) is provided at the top of the second adjusting member (90) and can engage with the first locking portion (811), that is, when the latch member (81) slides along the mounting cavity (61), the second adjusting member (90) can be locked or unlocked. In cooperation with the locking button (82), the latch member (81) enables the second adjusting member (90) to stop rotating or to rotate relative to the handle (60), so as to adjust the attitude and angle of the handle (60) and the dome (10).
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Couplers for data processing equipment; monitors for
computer hardware; computer programs, downloadable;
interactive touch screen terminals; microphones; flashlights
for use in photography; flashlamps for cameras; flash-bulbs
for photography; flashlights for photography; flash lamps
for smartphones. Light-emitting diode [LED] lights; light-emitting diode
[LED] light bulbs; lampshades; lamp chimneys; spotlights;
light projectors; spotlights for photography; bath
installations.
A photographing panel lamp, comprising a lamp panel and a plurality of lamp beads, the plurality of lamp beads being arranged on the lamp panel in an array. Each of the lamp beads comprises a main body part and a plurality of chips arranged on the main body part; the plurality of chips can be divided into a plurality of groups on the basis of different colors of light rays emitted by the chips; the colors of the light rays emitted by each group of chips are identical; and the plurality of chips are centrally symmetrically arranged on the main body part. On the lamp panel, reference angles formed by all the lamp beads are identical in size; due to such an arrangement, all the lamp beads can be centrally symmetrically arranged around the center point of the lamp panel; and by combining said arrangement with the arrangement that the plurality of groups of chips have a plurality of different colors and the plurality of chips are centrally symmetrically arranged on the main body part, the light rays emitted by the plurality of chips of different colors on the lamp panel can be uniformly mixed, to reduce the difference caused by the superposition of light rays of different colors and make the overall color of the photographing panel lamp more uniform, thereby effectively improving the photographing/video recording effect.
A light receiving lens assembly (30) and a projection cylinder (100). The light receiving lens assembly (30) comprises: a housing (31) provided with a front light receiving port (316) and a rear light receiving port (317), wherein a light receiving channel (318) is provided between the front light receiving port (316) and the rear light receiving port (317); and a light receiving lens (32) disposed in the light receiving channel (318), wherein the light receiving lens (32) comprises a front lens (321) and a rear lens (322); the front lens (321) is disposed at the front end of the housing (31), and the rear lens (322) is disposed at the rear end of the housing (31); the end of the housing (31) close to the front light receiving port (316) is provided with a front mounting recess (314), and the end of the housing (31) close to the rear light receiving port (317) is provided with a rear mounting recess (315); the front lens (321) is detachably mounted in the front mounting recess (314), and the rear lens (322) is detachably mounted in the rear mounting recess (315). The replacement and maintenance operation of the light receiving lens is more convenient, thereby improving the replacement and maintenance efficiency of the light receiving lens.
G03B 17/00 - Parties constitutives des appareils ou corps d'appareilsLeurs accessoires
G03B 17/54 - Parties constitutives des appareils ou corps d'appareilsLeurs accessoires prévus pour être combinés à d'autres appareils photographiques ou optiques avec projecteur
G02B 7/02 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles
The present application relates to the technical field of photographing devices, and relates to a projection attachment. The projection attachment comprises an attachment body and a light-converging lens set. The front end surface of the attachment body is provided with an opening and is communicated with the internal space of the attachment body, so as to form a mounting cavity at the front end of the attachment body; the rear end surface of the attachment body is provided with a light outlet; and a light effect device for changing a light effect is provided inside the internal space between the light outlet and the opening. The light-converging lens set comprises a housing and light-converging lenses provided inside the housing; the light-converging lens set can enter the mounting cavity through the opening on the front end surface of the attachment body, and thus be accommodated in the mounting cavity, so that light emitted by a photographic lamp enters from the opening, then sequentially passes through the light-converging lens set inside the mounting cavity and the light effect device at the rear end, and is transmitted out from the light outlet. The light-converging lens set enters the mounting cavity through the opening of the front end of the attachment body, so that the technical problem of complicated detaching of light-converging lens sets of conventional projection attachments is solved.
A projection tube (10) and a photographing projection system, the projection tube (10) comprising a body (100) and a cover (300), wherein the body (100) is provided with a light inlet and a light outlet; the light inlet can be connected to an external light source; an optical channel is provided between the light inlet and the light outlet, and is arranged in an inner cavity of the body (100), so as to accommodate an optical device; and the optical device comprises a light collection lens group (400) and a light effect device (130). The body (100) comprises an accommodating housing (200), which is arranged close to the light inlet, wherein the cover (300) is detachably connected to the accommodating housing (200), and the cover (300) and the accommodating housing (200) can enclose to form an accommodating cavity; the accommodating cavity is configured to accommodate and limit the light collection lens group (400); and the light effect device (130) is arranged in the inner cavity of the body (100) between the accommodating cavity and the light outlet. When the light collection lens group (400) is replaced, a housing of the entire projection tube (10) does not need to be disassembled, and no other components are involved during a replacement operation process, thereby improving the working efficiency of replacing the light collection lens group (400).
A chuck assembly comprises a base plate, a sliding ring, and a top plate. The base plate is used for bearing umbrella ribs hinged to the base plate. The sliding ring is fixed to the base plate and comprises an annular side wall and a guide rail, and the guide rail extends in the circumferential direction of the annular side wall. The top plate is rotatably sleeved on the sliding ring and is fixedly provided with a guide shaft facing the sliding ring, and the guide shaft is movably provided on the guide rail. The top plate rotates in the circumferential direction of the sliding ring, the guide shaft moves along the guide rail, and the top plate ascends and descends in the axial direction of the sliding ring; and the ascending and descending movement of the top plate presses the hinged ends of the umbrella ribs to rotate.
A light effect device (100) having a light diffusion function and a lighting system, relating to the technical field of photographing apparatuses. The light effect device (100) comprises a main body (10) and a light diffusion assembly (20), and the main body (10) is provided with a channel (101) along an axial direction of the main body (10); the channel (101) is provided with a projection assembly (13), one end of the main body (10) is used for being connected to a light source (40), and light generated by the light source (40) enters the channel (101) by means of an inlet end of the channel (101); the light diffusion assembly (20) comprises a light diffuser (22) and a fixing assembly (201), the light diffuser (22) is provided at the inlet end of the channel (101) by means of the fixing assembly (201), and the light emitted by the light source (40) passes through the light diffuser (22) and the projection assembly (13) and is emitted from an outlet end of the channel (101); the light diffuser (22) converts the light from direct light to scattered light, so that the light emitted from the light effect device (100) has a soft lighting effect. The technical problem that light emitted from conventional light effect devices is not soft enough is solved.
A photography lamp (100), which comprises a lamp body (10), a light source assembly (20) and a lens assembly (30). An inner wall and an outer wall of the lamp body (10) are respectively provided with an inner guide slot (11) and an outer guide slot (12) which are formed spirally, bayonet guide ribs (23) are arranged on a bayonet shell (21) of the light source assembly (20), the bayonet guide ribs (23) spirally adapt to the inside of the inner guide slot (11) of the lamp body (10), fixed guide ribs (33) are arranged on an inner wall of a lens shell (31), and the fixed guide ribs (33) spirally adapt to the inside of the outer guide slot (12) of the lamp body (10). When focusing is required, only the lamp body (10) needs to be rotated, such that the bayonet shell (21) and the lens shell (31) move in an axial direction of the lamp body (10), and then a light source (22) and a lens (32) move closer to or away from each other, thereby achieving focusing of the photography lamp (100). The entire photography lamp (100) has a simple structure, high structural strength, involves a simple and feasible focusing operation, and is convenient for a user to operate.
The present application provides a hair removal device, pertaining to the technical field of beauty instruments. The hair removal device comprises a housing, a pulse light source, an air duct, and a fan. The housing is hollow inside and provided with a light outlet, an air inlet, and an air outlet; the pulse light source is arranged in the housing, and pulse light emitted by the pulse light source is emitted from the light outlet; the air duct is arranged in the housing and is in communication with the air inlet and the air outlet; the air duct passes through both sides of the pulse light source; the fan is arranged in the air duct and used for generating gas flow, so that the airflow enters through the air inlet and flows out through the air outlet by means of the air duct. Part of the air duct is arranged on both sides of the pulse light source, so that the technical problem of poor heat dissipation effect of traditional hair removal devices, which restricts the improvement of hair removal efficiency of the devices, is solved.
A61B 18/18 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
H05K 7/20 - Modifications en vue de faciliter la réfrigération, l'aération ou le chauffage
H05K 5/02 - Enveloppes, coffrets ou tiroirs pour appareils électriques Détails
A61N 5/06 - Thérapie par radiations utilisant un rayonnement lumineux
Provided are a projection tube (100) and a photography lighting system. The projection tube (100) comprises a body (10), a lighting effect assembly (21) and a fan (30), wherein a light inlet (101) and a light outlet (102) are provided in the body (10); the light inlet (101) can be connected to an external light source; an optical channel (103) is arranged between the light inlet (101) and the light outlet (102), and is arranged in an inner cavity of the body (10); air inlets (1130) and air outlets (1120) are provided in side walls of the body (10); an air duct (104) is formed between each air inlet (1130) and the corresponding air outlet (1120), and intersects with the optical channel (103); the lighting effect assembly (21) is arranged in the optical channel (103); light emitted by means of the light source enters through the light inlet (101), passes through the lighting effect assembly (21), and is then emitted via the light outlet (102) to produce various lighting effects; a fan (30) is arranged in the inner cavity, and generates an airflow; and the airflow enters through the air inlets (1130) and flows out through the air outlets (1120) to bring heat out of the inner cavity, such that the heat can be prevented from accumulating on a housing, and thus the temperature of the housing can be effectively reduced, and damage to people or ignition of various indoor combustibles caused by the temperature of the housing being excessively high can be prevented.
The present application relates to the field of production and manufacture of photography accessories. Disclosed are a condenser cylinder (2) and a photography lighting effect apparatus (1). The condenser cylinder (2) comprises a rear housing (300), a main body (200) and a lamp cylinder (100), wherein the main body (200) is arranged between the rear housing (300) and the lamp cylinder (100). A fixing member (800) fixed to the surroundings is arranged on the rear housing (300), which is used for integrally mounting the condenser cylinder (2) to an external support or a wall. A rear end of the rear housing (300) is provided with a light inlet (330) matching an external light source (10); a front end of the lamp cylinder (100) is provided with a light outlet (110); the lamp cylinder (100), the main body (200) and the rear housing (300) are internally provided with a light channel (20) in communication with each other; and light enters the light channel (20) from the light inlet (330), passes through a projection film (620), is emitted from the light outlet (110) and is projected onto a human and an object. A slot (202) for inserting the projection film (620) is provided in the main body (200), and if the projection film (620) is inserted into the slot (202), the light projects a pattern in the projection sheet (620) onto the human and the object so as to form a light shadow pattern. The main body (200) is rotationally connected to one end of the rear housing (300) by means of an adjustment assembly (30); and the main body (200) can rotate along a central axis of the rear housing (300), so as to drive the projection film (620) mounted on the main body (200) to rotate, thus an angle of the light shadow pattern can be adjusted.
G03B 21/14 - Projecteurs ou visionneuses du type par projectionLeurs accessoires Détails
G03B 21/64 - Moyens pour le montage des vues individuelles à projeter, p. ex. cadres pour des diapositives
F21V 17/16 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection caractérisée par des moyens de fixation spécifiques par déformation de parties du dispositif d'éclairageMontage du type à action rapide
A lamp (100) for photography and video recording. The lamp comprises a main body (10) and a lamp head (20), which is arranged on the main body (10). The lamp head (20) comprises a housing (21), a light source (22), a lighting-effect lens (23) and a heat insulation member (24), wherein the housing (21) is internally provided with an accommodating cavity (212), and an opening (211), which is in communication with the accommodating cavity (212), is set on one end of the housing (21); the light source (22) is arranged in the accommodating cavity (212) of the housing (21), and the lighting-effect lens (23) is arranged at the opening (211) of the housing (21) and is located on the same optical axis as the light source (22); and the heat insulation member (24) is arranged between the light source (22) and the lighting-effect lens (23). The heat insulation member (24) can block high-temperature heat that is emitted from the light source (22) to the lighting-effect lens (23), such that high temperature causing hot melt damage to the lighting-effect lens (23) is prevented, and thus the number of consecutive flashes or the continuous lighting time of the lamp (100) for photography and video recording can be greatly increased, and the service life of the lamp (100) for photography and video recording is also prolonged, thereby meeting the requirement of a user for high-speed continuous photographing or long operating time, and effectively improving the usage experience of the user.
A flash lamp (100). The flash lamp (100) comprises a body (10), a cover body unit (20) and an assembly unit (101). The cover body unit (20) comprises a rotating shaft (21) and a cover plate (22) connected to the rotating shaft (21), and the assembly unit (101) comprises a lamp tube assembly (30) and a reflective cover (40) arranged on the rotating shaft (21). In the flash lamp (100), the body (10) is provided with a storage space (11), and the rotating shaft (21) is rotatably arranged on the body (10), so that the cover plate (22) connected to the rotating shaft (21) can open or close the storage space (11). The lamp tube assembly (30) and the reflective cover (40) in the flash lamp (100) are both arranged on the rotating shaft (21), so as to rotate along with the rotating shaft (21). When the rotating shaft (21) rotates such that the cover plate (22) closes the storage space (11), the lamp tube assembly (30) and the reflective cover (40) are both stored in the storage space (11). By means of the arrangement, the overall size of the flash lamp (100) can be effectively reduced, thereby facilitating the overall storage and carrying of the flash lamp (100).
Provided in the present application is a focusing spotlight system. The focusing spotlight system comprises a base, a lamp body and a lens barrel. A support is arranged on the base, the support is movably arranged on the base, and the support can move in the front-back direction of the base. The lamp body comprises a lamp shell and a light source arranged in the lamp shell, the light source being used for providing illumination light ray, and the lamp shell being detachably connected to the support by means of a quick-detach structure. The lens barrel is fixedly arranged on the base. A focusing lens is mounted on the lens barrel, and the focusing lens is located in the light emitting direction of the lamp body. The support can drive the lamp body to enter the lens barrel and move close to or away from the focusing lens. Users can quickly assemble and disassemble the focusing spotlight system by means of the quick-detach structure.
F21V 14/02 - Commande de la distribution de la lumière émise par réglage d’éléments constitutifs par un mouvement de sources lumineuses
F21V 19/04 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage avec possibilité de changer la source lumineuse, p. ex. un barillet
F21V 21/34 - Éléments de support déplaçables le long d'un élément de guidage
F21V 14/00 - Commande de la distribution de la lumière émise par réglage d’éléments constitutifs
The present application discloses a fabric LED lamp. The fabric LED lamp comprises: a sealing film (100), a first thermally conductive adhesive layer (200), a plurality of flexible lamp strips (310), a flexible connecting plate (330) and a light-transmitting film (500). The plurality of flexible lamp strips (310) are attached to a side surface of the first thermally conductive adhesive layer (200) facing away from the sealing film (100). When light-emitting units (320) emit light, the first thermally conductive adhesive layer (200) absorbs heat from the plurality of flexible lamp strips (310) and from the plurality of light-emitting units (320), and performs heat exchange with the outside, thereby increasing the heat dissipation efficiency and service life of the fabric LED lamp.
F21V 29/71 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques utilisant une combinaison d’éléments séparés interconnectés par des moyens thermo-conducteurs, p. ex. tubes caloporteurs ou barres thermiquement conductrices pour conduire la chaleur entre des éléments séparés de puits thermique
F21V 19/00 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage
A roll-up fabric lamp and a lamp light system. The roll-up fabric lamp comprises: a long-strip-shaped main body portion, the main body portion comprising a first flexible light film (510), first flexible light-emitting members (410), a first thermally conductive adhesive layer (310), a flexible support member (210), and a first water-resistant fabric (110); the first flexible light-emitting members (410) are attached to one side surface of the first flexible light film (510), and the first flexible light-emitting members (410) emit light toward one side surface of the first flexible light film (510); the first thermally conductive adhesive layer (310) is attached to a side surface of the first flexible light-emitting members (410) facing away from the first flexible light film (510); the flexible support member (210) is provided on a side of the first thermally conductive adhesive layer (310) facing away from the first flexible light-emitting members (410); and the first water-resistant fabric (110) is provided on a side surface of the flexible support member (210) facing away from the first thermally conductive adhesive layer (310). The flexible support member (210) in the roll-up fabric lamp can support the main body portion while being folded according to user requirements. Following use, the roll-up fabric lamp can be bent and folded, facilitating transportation and storage.
A focusing lamp, comprising a light source (100), a zoom box (200), a focusing lens group (400), a plurality of screw rods (500), and a driving device (600). After the light source (100) is energized and then emits light, a user can adjust the position of the focusing lens group (400) on each screw rod (500) by means of the driving device (600), so as to adjust the focal point of the light source (100), such that the focusing lamp is suitable for various scenes, and has the light and shadow effects of beautifying videography and photography, and light art.
F21V 17/00 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection
F21V 14/00 - Commande de la distribution de la lumière émise par réglage d’éléments constitutifs
F21V 14/06 - Commande de la distribution de la lumière émise par réglage d’éléments constitutifs par un mouvement de réfracteurs
A light effect device and a flash. Of the light effect device (100), an adapter (1000) is connected to a focusing assembly (2000) by means of a first connection member (3000). The first connection member (3000) comprises a second connection portion (3200) and a first connection portion (3100), the first connection portion (3100) being arranged on the adapter (1000), and the second connection portion (3200) being arranged on the focusing assembly (2000). The second connection portion (3200) and the first connection portion (3100) are in a snap-fit connection, so as to limit the focusing assembly (2000) and the adapter (1000) in the axial direction of the light effect device (100), thus connecting the adapter (1000) and the focusing assembly (2000) together and helping to change the adapter (1000) on the focusing assembly (2000), so as to adapt to flashes of different lamp bases (4000). When the light effect device (100) needs to be additionally mounted on a flash having a lamp base (4000) in a different shape, it is simply required to select an adapter (1000) in a shape matching that of the lamp base (4000), thereby expanding the application range of the light effect device (100) and effectively reducing use cost for users.
(1) Lampshades; stage spotlights; light-emitting diode [LED] mood lights; germicidal lamps for purifying air; spotlights for photography; arc lamps; lighting apparatus, especially electric lamps and luminaires; refrigerating cabinets; drying apparatus and installations, namely, electric body air dryers; germicidal burners.
Disclosed in the present application is an LED light-emitting module, comprising: a light-emitting area, the light-emitting area comprising a plurality of sub-light-emitting areas, and a set of symmetrical light-emitting areas being formed by a first sub-light-emitting area and a second sub-light-emitting area which are symmetrically arranged relative to a symmetric axis, or, the light-emitting area comprising a first light-emitting area and a second light-emitting area, and the first light-emitting area and the second light-emitting area being symmetrically arranged relative to a symmetric axis; and an LED array, arranged in the light-emitting area. Therefore, by means of the symmetrical arrangement of the light-emitting area, light mixing and light complementation of light emitted by the LED array in the light-emitting area are facilitated.
H01L 25/075 - Ensembles consistant en une pluralité de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide les dispositifs étant tous d'un type prévu dans une seule des sous-classes , , , , ou , p. ex. ensembles de diodes redresseuses les dispositifs n'ayant pas de conteneurs séparés les dispositifs étant d'un type prévu dans le groupe
H01L 33/50 - DISPOSITIFS À SEMI-CONDUCTEURS NON COUVERTS PAR LA CLASSE - Détails caractérisés par les éléments du boîtier des corps semi-conducteurs Éléments de conversion de la longueur d'onde
G09F 9/33 - Dispositifs d'affichage d'information variable, dans lesquels l'information est formée sur un support, par sélection ou combinaison d'éléments individuels dans lesquels le ou les caractères désirés sont formés par une combinaison d'éléments individuels à semi-conducteurs, p. ex. à diodes
The present invention provides an LED light source module, comprising: a substrate; and a plurality of light mixing units, provided on the substrate. Each light mixing unit comprises a micro substrate, and a warm white light chip, a cold white light chip, a red light chip, a blue light chip, and a green light chip which are integrated on the micro substrate. In this way, during working, light mixing can be performed by means of different light colors, so that mixed light having a better effect is achieved, and then a high-quality light effect is obtained.
H01L 25/075 - Ensembles consistant en une pluralité de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide les dispositifs étant tous d'un type prévu dans une seule des sous-classes , , , , ou , p. ex. ensembles de diodes redresseuses les dispositifs n'ayant pas de conteneurs séparés les dispositifs étant d'un type prévu dans le groupe
H01L 33/58 - DISPOSITIFS À SEMI-CONDUCTEURS NON COUVERTS PAR LA CLASSE - Détails caractérisés par les éléments du boîtier des corps semi-conducteurs Éléments de mise en forme du champ optique
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Flash units for photography; Flashes for cameras; microphones; flashlights for use in photography; Face recognition apparatus; batteries; Video monitors; Photographic Lightboxes; remote control devices for photographic cameras; Electrical distribution boxes Followspot lights for photography being spotlights; light projectors; LED lighting apparatus; Spotlights; LED light bulbs; Lamplight shades being lampshades; lampshades; bath installations; bath plumbing fixtures, namely aerators; disinfectant apparatus; Electric radiators
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Flash for photography; Flash for camera; microphones; flashlights [photography]; Face recognition apparatus; batteries; Video monitor; Lightbox; remote control device; distribution boxes. Followspot for photography; light projectors; LED lights; Spotlight; LED bulbs; Lamplight shades; lampshades; bath installations / bath plumbing fixtures; disinfectant apparatus; radiators [heating].
A chuck assembly (10) and a reflector comprising same. The chuck assembly (10) comprises a base plate (11), a sliding ring (12), and a top plate (13). The base plate (11) is used for bearing a plurality of umbrella ribs (20) hinged to the base plate. The sliding ring (12) is fixed to the base plate (11), and comprises an annular side wall (121) and a guide rail (122) provided on the annular side wall (121), and the guide rail (122) extends in the circumferential direction of the annular side wall (121). The top plate (13) is rotatably sleeved on the sliding ring (12), and is fixedly provided with a guide shaft (131) facing the sliding ring (12), and the guide shaft (131) is movably provided on the guide rail (122). The top plate (13) rotates in the circumferential direction of the sliding ring (12), the guide shaft (131) moves along the guide rail (122), and the top plate (13) ascends and descends in the axial direction of the sliding ring (12); and the ascending and descending movement of the top plate (13) presses the hinged ends (21) of the umbrella ribs (20) to rotate. When a reflector is opened or folded, the chuck assembly (10) can avoid laborious operation of an operator, and the operation is convenient.
Disclosed is a photographic lamp chuck compatible with different lamp holders. The photographic lamp chuck comprises a main chuck body (100), wherein an accessory installation position is provided on the main chuck body (100), a first insertion hole (101) for accommodating a lamp holder of a first-type photographic lamp is provided in the main chuck body (100), an arc-shaped positioning face (103) and a groove body (102) are formed in an inner wall of the first insertion hole (101), a positioning inserting member (200) is movably inserted into the groove body (102), a first positioning face is arranged on the positioning inserting member (200), a second insertion hole (202) is enclosed by the first positioning face of the positioning inserting member (200) and the inner wall of the first insertion hole (101), and the second insertion hole is used for accommodating a lamp holder of a second-type photographic lamp.
G03B 15/04 - Combinaisons d'appareils photographiques avec des générateurs d'éclairs non électriquesFlash non électronique
F21V 17/02 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection avec possibilité de réglage
Disclosed is an air filtration and sterilization device, comprising a main housing, wherein an air flow path for airflow circulation is provided inside the main housing, a filtration assembly is arranged at an air inlet end of the airflow channel, a fan is connected to an air outlet end of the air flow path, a gas containing cavity is connected between the filtration assembly and the fan, and a pulse flashing unit is arranged in the gas containing cavity. The pulse flashing unit comprises a charging circuit connected to an external power supply. The current output from the charging circuit passes through a capacitor and a discharging circuit in sequence and then flows into an insert gas lamp.
F24F 3/16 - Systèmes de conditionnement d'air dans lesquels l'air conditionné primaire est fourni par une ou plusieurs stations centrales aux blocs de distribution situés dans les pièces ou enceintes, blocs dans lesquels il peut subir un traitement secondaireAppareillage spécialement conçu pour de tels systèmes caractérisés par le traitement de l'air autrement que par chauffage et refroidissement par purification, p. ex. par filtrageSystèmes de conditionnement d'air dans lesquels l'air conditionné primaire est fourni par une ou plusieurs stations centrales aux blocs de distribution situés dans les pièces ou enceintes, blocs dans lesquels il peut subir un traitement secondaireAppareillage spécialement conçu pour de tels systèmes caractérisés par le traitement de l'air autrement que par chauffage et refroidissement par stérilisationSystèmes de conditionnement d'air dans lesquels l'air conditionné primaire est fourni par une ou plusieurs stations centrales aux blocs de distribution situés dans les pièces ou enceintes, blocs dans lesquels il peut subir un traitement secondaireAppareillage spécialement conçu pour de tels systèmes caractérisés par le traitement de l'air autrement que par chauffage et refroidissement par ozonisation
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer monitor; face recognition apparatus;
electro-dynamic apparatus for the remote control of signals;
video monitor; microphones; flashlights [photography];
camera tripod; remote control apparatus; plugs, sockets and
other contactors (electrical connection); batteries. Ultraviolet halogen metal vapor lamp; germicidal lamps for
purifying air; ultraviolet ray lamps, not for medical
purposes; air purifying apparatus and machines; germicidal
burners; radiators [heating]; bath installations;
disinfectant apparatus.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer monitor; face recognition apparatus;
electro-dynamic apparatus for the remote control of signals;
video monitor; microphones; flashlights [photography];
camera tripod; remote control apparatus; plugs, sockets and
other contactors (electrical connection); batteries. Ultraviolet halogen metal vapor lamp; germicidal lamps for
purifying air; ultraviolet ray lamps, not for medical
purposes; air purifying apparatus and machines; germicidal
burners; radiators [heating]; bath installations;
disinfectant apparatus.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer monitor; face recognition apparatus;
electro-dynamic apparatus for the remote control of signals;
video monitor; microphones; flashlights [photography];
camera tripod; remote control apparatus; plugs, sockets and
other contactors (electrical connection); batteries. Ultraviolet halogen metal vapor lamp; germicidal lamps for
purifying air; ultraviolet ray lamps, not for medical
purposes; air purifying apparatus and machines; germicidal
burners; radiators [heating]; bath installations;
disinfectant apparatus.
The present disclosure provides a soft light box and a chuck assembly thereof. The chuck assembly includes a chuck and a rotating plate. The chuck includes a carrying ring and a sleeve. The carrying ring is arranged on the outer side of the sleeve and used to carry a plurality of umbrella ribs hingedly connected with the carrying ring. The rotating plate is rotatably sleeved on the sleeve, rotates in a circumferential direction of the sleeve, and moves up and down along the axial direction of the sleeve. The up-down motion of the rotating plate presses the hinged ends of the umbrella ribs, and drives the umbrella ribs to swing relative to the carrying ring.
F16M 13/02 - Autres supports ou appuis pour positionner les appareils ou les objetsMoyens pour maintenir en position les appareils ou objets tenus à la main pour être portés par un autre objet ou lui être fixé, p. ex. à un arbre, une grille, un châssis de fenêtre, une bicyclette
G03B 15/06 - Dispositions particulières pour le filtrage, la diffusion ou la réflexion, p. ex. dans les studios
An air sterilization device, comprising: a main housing. A cavity for air circulation is provided in the main housing. The cavity is provided with an air inlet and an air outlet. The air inlet and the air outlet each is provided with a joint. A pulse flashing unit is provided in the cavity, which includes a charging circuit connected to an external power supply. A current output by the charging circuit sequentially passes through a capacitor and a discharging circuit, and then flows into an inert gas lamp.
A softbox and a chuck assembly (10) therefor. The chuck assembly (10) comprises a chuck (12) and a rotating disc (13). The chuck (12) comprises a bearing ring (121) and a sleeve (122). The bearing ring (121) is disposed on the outer side of the sleeve (122), and the bearing ring (121) is used for bearing multiple ribs (20) hinged to the bearing ring (121). The rotating disc (13) is rotatably sleeved on the sleeve (122), the rotating disc (13) rotates in the circumferential direction of the sleeve (122), and the rotating disc (13) vertically moves in the axial direction of the sleeve (122). The vertical movement of the rotating disc (13) presses the hinged ends (21) of the ribs (20), and the vertical movement of the rotating disc (13) drives the ribs (20) to swing with respect to the bearing ring (121). When a softbox is opened, the chuck assembly (10) can avoid laborious operation of an operator, and the operation is convenient.
A set-top flash lamp of a camera, comprising a lamp holder (2) and a lamp cap (1). A battery accommodating cavity (4) and a battery accommodating cavity cover (3) are formed in the lamp holder (2). A lithium battery (5) is accommodated in the battery accommodating cavity (4), and the lithium battery (5) comprises an electrical output contact (6). The electrical output contact (6) is in the shape of a right-angled sheet, and is composed of end surface right-angled sides (61) and bottom surface right-angled sides (62), wherein the end surface right-angled sides (61) are located on the front end surface (51) of the lithium battery (5); and the bottom surface right-angled sides (62) are arranged on the bottom surface (52) of the lithium battery (5). An electrical access contact (7) is contained in the battery accommodating cavity (4), and is arranged on a side wall of the battery accommodating cavity (4) which is opposite to the bottom surface (52) of the lithium battery (5). The set-top flash lamp improves the performance and reduces the costs.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer monitors; face recognition apparatus, namely, downloadable computer programs using artificial intelligence for facial recognition; electro-dynamic apparatus for the remote control of signals; video monitors; microphones; flashlights for use in photography; camera tripods; remote control apparatus, namely, remote controls for televisions, home security systems; electrical plugs, electrical sockets and electrical components in the nature of electric contactors; batteries Ultraviolet halogen metal vapor lamp; germicidal lamps for purifying air; ultraviolet ray lamps, not for medical purposes; air purifying apparatus and machines; germicidal burners; radiators; bath installations; disinfectant apparatus
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer monitors; face recognition apparatus, namely, downloadable computer programs using artificial intelligence for facial recognition; electro-dynamic apparatus for the remote control of signals; video monitors; microphones; flashlights for use in photography; camera tripods; remote control apparatus, namely, remote controls for televisions, home security systems; electrical plugs, electrical sockets and electrical components in the nature of electric contactors; batteries Ultraviolet halogen metal vapor lamp; germicidal lamps for purifying air; ultraviolet ray lamps, not for medical purposes; air purifying apparatus and machines; germicidal burners; radiators; bath installations; disinfectant apparatus
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
11 - Appareils de contrôle de l'environnement
35 - Publicité; Affaires commerciales
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Sharpening instruments; Hand-operated hand tools; Gardening tools; Depilation appliances, electric and non-electric; Non-medical laser hair removal device; Razors, electric or non-electric; Hair clippers for personal use, electric and non-electric; Shearers [hand instruments]; Tweezers; Scissors. Computer monitor; Face recognition apparatus; Electro-dynamic apparatus for the remote control of signals; Video monitor; Microphones; Flashlights [photography]; Camera tripod; Remote control apparatus; Plugs, sockets and other contactors (electrical connection); Batteries. Sterilized medical apparatus; Medical operating lamp; Dental apparatus and instruments; Medical ultraviolet germicidal lamp; Ultraviolet ray lamps for medical purposes; Gloves for medical purposes; Babies' bottles; Artificial limbs; Orthopaedic articles; Suture materials. Light shield; Ultraviolet halogen metal vapor lamp; Germicidal lamps for purifying air; Ultraviolet ray lamps, not for medical purposes; Air purifying apparatus and machines; Germicidal burners; Radiators [heating]; Bath installations; Disinfectant apparatus. Presentation of goods on communication media, for retail purposes; Commercial administration of the licensing of the goods and services of others; Holding, arranging and organizing trade shows and fairs for commercial and advertising purposes; Sales promotion for others; Marketing; Commodity import and export agent; Personnel management consultancy; Administrative services for the relocation of businesses; Web indexing for commercial or advertising purposes; Accounting. Instruction services; Organization of competitions [education or entertainment]; Arranging and conducting of symposiums; Arranging and conducting of workshops [training]; Bookmobile services; Layout services, other than for advertising purposes; Rental of cinematographic apparatus; Microfilming; Rental of video cameras; Rental of lighting apparatus for theatrical sets or television studios. Research and development of new products for others; Research and develop plastic raw materials for third parties; Research and develop new products; Technological research; Surveying; Material testing; Design and development of multimedia products; Development of construction projects; Computer software design; Conversion of data or documents from physical to electronic media.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Computer monitors; Face recognition apparatus, namely, downloadable computer programs using artificial intelligence for facial recognition; Electro-dynamic apparatus for the remote control of signals; Video monitors; microphones; photographic flash units for cameras; Camera tripods; Remote control telemetering apparatus; Electrical plugs; Electrical sockets; Batteries
A flash disinfection box, comprising a housing. The housing comprises a first housing body (110) and a second housing body (120) matching each other; a pulse flash device (130) is mounted in the first housing body (110); a device accommodation chamber is provided in the second housing body (120); the light emitting surface of the pulse flash device (130) is aligned with the device accommodation chamber; the pulse flash device (130) is connected to a power supply assembly; and the power supply assembly is disposed in the housing. Strong light emitted by the pulse flash device (130) can sterilize and disinfect a device in the device accommodation chamber, without generating chemical waste liquid, and the disinfection efficiency is high.
A61L 2/08 - Procédés ou appareils de désinfection ou de stérilisation de matériaux ou d'objets autres que les denrées alimentaires ou les lentilles de contactAccessoires à cet effet utilisant des phénomènes physiques des radiations
Provided in the present invention is a flash sterilization kettle. The flash sterilization kettle comprises an outer housing. A water outlet is formed in the edge of the open end of the outer housing, and the water outlet is provided with a movable cover plate. The outer housing is provided with a light-permeable liquid container, a pulsed flashing apparatus is provided on the outer side of the liquid container, the light exit surface of the pulsed flashing apparatus faces the liquid container, the pulsed flashing apparatus is connected to a power supply assembly, and the power supply assembly is disposed in the outer housing. Strong light emitted by the pulsed flashing apparatus may effectively kill bacteria in the kettle, so a user only needs to pour water that is in a tap water pipe into the kettle of the present disclosure, and may drink after flash sterilization. The user may quickly obtain drinking water suitable for drinking, which greatly improves the use experience of the user and facilitates the promotion of the product in the market.
C02F 1/30 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout par irradiation
A61L 2/08 - Procédés ou appareils de désinfection ou de stérilisation de matériaux ou d'objets autres que les denrées alimentaires ou les lentilles de contactAccessoires à cet effet utilisant des phénomènes physiques des radiations
A47J 27/21 - Récipients pour faire bouillir l'eau, p. ex. bouilloires
Provided is a flashing sterilization toilet lid, comprising a toilet lid plate (110) and a toilet seat (120) hinged to each other. A pulse flashing device (130) is mounted in the toilet lid plate (110), a light emission face of the pulse flashing device (130) faces an inner wall of a toilet, and the pulse flashing device (130) is connected to a power source assembly; and a pulse flasher (134) is arranged in the pulse flashing device (130), and hard light emitted by the pulse flasher (134) can sterilize and disinfect the inner wall of the toilet, so that the problem of cleanliness and hygiene of the toilet is effectively solved, and the hygiene safety of a user is guaranteed.
A flash sterilization device, comprising: a housing (110), a transparent water delivery pipeline (120) being provided in the housing (110), the water delivery pipeline (120) being provided with an inlet end (121) and an outlet end, a pulse flash device (130) being provided on the outer side of the water delivery pipeline (120), and the pulse flash device (130) being connected to a power supply assembly, the power supply assembly being disposed in the housing (110). Also disclosed is a water filtering system comprising a water filter and the flash sterilization device.
A flashing sterilization device, comprising: a housing (110). A liquid storage member (120) is provided in the housing (110), a light-transmitting window (140) is provided in the liquid storage member (120), and a pulse flashing device (130) is provided on the outer side of the liquid storage member (120); the pulse flashing device (130) is aligned with the light-transmitting window (140) in the liquid storage member (120), the pulse flashing device (130) is connected to a power supply assembly, and the power supply assembly is provided in the housing (110).
C02F 1/30 - Traitement de l'eau, des eaux résiduaires ou des eaux d'égout par irradiation
A23L 3/26 - Conservation des aliments ou produits alimentaires, en général, p.ex. pasteurisation ou stérilisation, spécialement adaptée aux aliments ou produits alimentaires par irradiation sans chauffage
A47G 19/22 - Récipients à boissons ou soucoupes utilisés dans le service de table
72.
PHOTOGRAPHIC LAMP CHUCK COMPATIBLE WITH DIFFERENT LAMP HOLDERS
Disclosed is a photographic lamp chuck compatible with different lamp holders. The photographic lamp chuck comprises a main chuck body (100), wherein an accessory installation position is provided on the main chuck body (100), a first insertion hole (101) used for accommodating a lamp holder of a first-type photographic lamp is provided in the main chuck body (100), an arc-shaped positioning face (103) and a groove body (102) are formed in an inner wall of the first insertion hole (101), a positioning insertion member (200) is movably inserted into the groove body (102), a first positioning face is arranged on the positioning insertion member (200), a second insertion hole (202) is enclosed by the first positioning face of the positioning insertion member (200) and the inner wall of the first insertion hole (101), and the second insertion hole (202) is used for accommodating a lamp holder of a second-type photographic lamp.
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer peripheral devices; intercommunication apparatus, namely, telephone; cabinets for loudspeakers; darkroom lamps for use in photography; darkroom lamps for use in photography; flashlights for use in photography; flash-bulbs for use in photography; surveying apparatus and instruments, namely, tripods; materials for electricity mains, namely, wires and cables; remote control apparatus, namely, electronic key fobs; batteries, electric Lighting fixtures and installations; germicidal lamps for purifying air; light-emitting diodes (LED) lighting fixtures; oil lamps; refrigerating appliances and installations; air disinfection equipment, namely, air sterilizers; heating installations; water flushing installations, namely, flus levers; flushing apparatus, namely, automatic flush valves for toilets; disinfection equipment, namely, apparatus for disinfecting water; water purification apparatus
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer peripheral devices; computer software for operation
control of audio and video equipment; intercommunication
apparatus; cabinets for loudspeakers; portable audio player;
flashlights [photography]; surveying apparatus and
instruments; electricity mains (material for wires, cables);
remote control apparatus; batteries, electric. Lighting apparatus and installations; germicidal lamps for
purifying air; oil lamps; cooking utensils, electric;
refrigerating appliances and installations; air disinfection
equipment; heating apparatus; water flushing installations /
flushing apparatus; disinfection equipment; water
purification apparatus.
Sharpening instruments; hand tools, hand-operated; garden
tools, hand-operated; depilation appliances, electric and
non-electric; laser hair removal apparatus, other than for
medical purposes; razors, electric or non-electric; hair
clippers for personal use, electric and non-electric;
shearers [hand instruments]; tweezers; scissors. Sterilized medical instruments; medical or surgical lamps;
dental apparatus and instruments; filters for ultraviolet
rays, for medical purposes; ultraviolet ray lamps for
medical purposes; gloves for medical purposes; feeding
bottles; orthopedic articles; suture materials. Arc lamps; ultraviolet halogen metal vapor lamp; germicidal
lamps for purifying air; ultraviolet ray lamps, not for
medical purposes; air deodorizing apparatus for
refrigerators; air purifying apparatus and machines;
germicidal burners; radiators [heating]; bath installations;
disinfectant apparatus; sterilizers for medical use.
An air sterilization apparatus, comprising: a main housing (100). A cavity (101) for air circulation is provided in the main housing (100). The cavity (101) is provided with an air inlet (102) and an air outlet (103). The air inlet (102) and the air outlet (103) each is provided with a connector. A pulse flash device (300) is provided in the cavity (101). The pulse flash device (300) comprises a charging circuit (301) connected to an external power supply. A current output by the charging circuit (301) sequentially passes through a capacitor (302) and a discharging circuit (303), and is then input into an inert gas bulb (304). Strong light emitted by the pulse flash device (300) kills bacteria in air. No chemical residues would be produced, and the sterilization efficiency is high.
Disclosed is an air filtration and sterilization device, comprising a main housing, wherein an airflow channel for airflow circulation is provided inside the main housing, a filtration assembly is arranged at an air inlet end of the airflow channel, a fan (200) is connected to an air outlet end of the airflow channel, a gas receiving cavity (100) is connected between the filtration assembly and the fan (200), and a pulse flashing apparatus (300) is arranged in the gas receiving cavity (100). The pulse flashing apparatus (300) comprises a charging circuit (301) connected to an external power supply. The current output from the charging circuit (301) passes through a capacitor (302) and a discharging circuit (303) in sequence and then is input into an insert gas bulb (304). The sterilization device uses instantaneous high-strength pulsed light energy to kill various microorganisms with a short sterilization treatment time, and is particularly suitable for a working environment with a large gas flow.
F24F 3/16 - Systèmes de conditionnement d'air dans lesquels l'air conditionné primaire est fourni par une ou plusieurs stations centrales aux blocs de distribution situés dans les pièces ou enceintes, blocs dans lesquels il peut subir un traitement secondaireAppareillage spécialement conçu pour de tels systèmes caractérisés par le traitement de l'air autrement que par chauffage et refroidissement par purification, p. ex. par filtrageSystèmes de conditionnement d'air dans lesquels l'air conditionné primaire est fourni par une ou plusieurs stations centrales aux blocs de distribution situés dans les pièces ou enceintes, blocs dans lesquels il peut subir un traitement secondaireAppareillage spécialement conçu pour de tels systèmes caractérisés par le traitement de l'air autrement que par chauffage et refroidissement par stérilisationSystèmes de conditionnement d'air dans lesquels l'air conditionné primaire est fourni par une ou plusieurs stations centrales aux blocs de distribution situés dans les pièces ou enceintes, blocs dans lesquels il peut subir un traitement secondaireAppareillage spécialement conçu pour de tels systèmes caractérisés par le traitement de l'air autrement que par chauffage et refroidissement par ozonisation
09 - Appareils et instruments scientifiques et électriques
11 - Appareils de contrôle de l'environnement
Produits et services
Computer peripheral devices; downloadable computer software for operation control of audio and video equipment; intercommunication apparatus, namely, mobile phones; cabinets for loudspeakers; portable audio player; flashlights for use in photography; surveying machines and instruments; electricity mains, namely, electric wires and electric cables; remote controls for consumer electronic entertainment, namely, radios, televisions, stereos; batteries, electric Lighting apparatus, namely, lighting installations; germicidal lamps for purifying air; oil lamps; electric cooking utensils, namely, electric cooking ovens; refrigerating appliances and installations; air disinfection equipment, namely, air purifiers; heating apparatus, namely, furnaces; water flushing installations and flushing apparatus, namely, flush levers; disinfection equipment, namely, dish disinfectant apparatus for industrial purposes; water purification apparatus
Hand-operated sharpening instruments; hand-operated hand tools, namely, hand drills, hack saws, cutting tools; hand-operated gardening tools, namely, trowels, weeding forks, spades, hoes; depilation appliances, electric and non-electric; laser hair removal apparatus, other than for medical purposes; razors, electric or non-electric; hair clippers for personal use, electric and non-electric; hand instruments, namely, shearers; tweezers; scissors Sterilized medical instruments for cutting tissue, percutaneous tracheostomy; medical lamps, namely, medical examination lamps, medical operating lamps; surgical lamps; dental apparatus and instruments, namely, prophy angles, oral irrigators, crown and bridge removers; filters for ultraviolet rays, for medical purposes; ultraviolet ray lamps for medical purposes; gloves for medical purposes; feeding bottles; orthopedic articles, namely, walkers, braces, shoes; suture materials Arc lamps; ultraviolet halogen metal vapor lamp; germicidal lamps for purifying air; ultraviolet ray lamps, not for medical purposes; electric air deodorizing apparatus for refrigerators; air purifying apparatus and machines; germicidal lamps for purifying air,namely, germicidal burners; radiators for heating; bath installations; disinfectant apparatus for banknotes, medical purposes, industrial purposes; sterilizer units for medical use
37 - Services de construction; extraction minière; installation et réparation
41 - Éducation, divertissements, activités sportives et culturelles
Produits et services
Water purification installations; lamps; lighting apparatus
and installations; luminous tubes for lighting; electric
torches / electric flashlights; germicidal lamps for
purifying air; air sterilisers; air disinfection equipment;
water sterilizers; household electric water purifier. Advertising / publicity; outdoor advertising; on-line
advertising on a computer network; advertising by mail
order; presentation of goods on communication media, for
retail purposes; telemarketing services; import-export
agency services; procurement services for others [purchasing
goods and services for other businesses]; administrative
processing of purchase orders; rental of sales stands. Providing construction information; construction; mining
extraction; cleaning of buildings [interior]; heating
equipment installation and repair; film projector repair and
maintenance; photographic apparatus repair; clock and watch
repair; carpentry services; disinfecting. Instruction services; arranging and conducting of workshops
[training]; arranging and conducting of symposiums;
organization of competitions [education or entertainment];
organization of exhibitions for cultural or educational
purposes; movie studio services; rental of cinematographic
apparatus; recording studio services; photography; rental of
stage scenery.
37 - Services de construction; extraction minière; installation et réparation
41 - Éducation, divertissements, activités sportives et culturelles
Produits et services
Water purification installations; lamps; lighting apparatus, namely, lighting installations; luminous tubes for lighting; electric torches for lighting; electric flashlights; germicidal lamps for purifying air; air sterilisers; air disinfection equipment composed primarily of ultraviolet lamps; water sterilizers; household electric water purifying apparatus Advertising and publicity services; outdoor advertising; on-line advertising on a computer network; advertising by mail order; providing television home shopping services in the field of general consumer merchandise; telemarketing services; import-export agency services; procurement, namely, purchasing lighting and sterlising apparatus for others; administrative processing of purchase orders; rental of sales stands Providing construction information; building construction; mining extraction; cleaning of the interiors of buildings; heating equipment installation and repair; film projector repair and maintenance; photographic apparatus repair; clock and watch repair; carpentry services; disinfecting Sports instruction services; arranging and conducting of workshops in the field of personnel awareness; arranging and conducting of symposiums in the field of telemarketing; entertainment services in the nature of organization of competitions, namely, sport competitions; organization of exhibitions for cultural or educational purposes; movie studio services; rental of cinematographic apparatus; recording studio services; photography; rental of stage scenery
41 - Éducation, divertissements, activités sportives et culturelles
Produits et services
(1) Electric lamps; sockets for electric lights; lamp shades; light diffusers; arc lamps; light bulbs; lamp reflectors; led light bulbs; led luminaires; electric discharge tubes for lighting; accent lights for indoor use. (1) Advertising flyer distribution; advertising the goods and services of others; advertising the goods and services of others through all public communication means; import-export agency services; magazine mail order services; sales demonstration for others.
(2) Rental of cinematographic machines; movie studio services; photo editing; photographic composition; photographic computer imaging; microfilming; photographic reporting; recording studio services; rental of show scenery.
A soft box includes a housing and a main body detachably connected to the housing by a connecting device. The connecting device includes a first locking portion and a second locking portion. An installing base is connected to the bottom of the housing and the main body is embedded in the installing base, thereby the housing can rotate around the main body. The first locking portion passes through the installing base and the main body to tightly fix with the second locking portion. The housing includes a snap-fitting member and a light passageway which is a cylindrical hole and a flash lamp cap fixing device formed therein. The flash lamp cap fixing device includes a supporting platform and a pressing plate opposite to the supporting platform and having an adjustable position relative to the supporting platform. The present disclosure can quickly disassembly and be easy to carry.
F21V 17/02 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection avec possibilité de réglage
G03B 15/07 - Agencements de lampes dans les studios
The present utility model relates to the technical field of photography lighting, in particular to a wireless remote control flash lamp and a control system therefor. The present utility model comprises: a first wireless transmission module, a signal decoding and analysis module, a second wireless transmission module, a flash lamp drive module and a light-emitting device, wherein the first wireless transmission module is used for receiving a control instruction sent by a software control module; the signal decoding and analysis module is used for decoding and analysing the control signal; the second wireless transmission module is used for sending the control signal to a controlled photography lighting device; and the flash lamp drive module is connected to the signal decoding and analysis module and is used for driving the light-emitting device. In the present utility model, a wireless remote control flash lamp has the function of forwarding a control signal, so that the control signal may drive other flash lamps at the same time, achieving the effect of simultaneously driving a plurality of flash lamp. The utility model has strong function and good user experience and is conducive to promotion in the market.
A remote control apparatus (10) for a photography lighting device, and a wireless control system therefor. The remote control apparatus comprises: a first wireless transmission module (1), a signal decoding and analysis module (2) and a second wireless transmission module (3), which are sequentially connected, wherein the first wireless transmission module (1) is used for receiving a control instruction sent by a software control module (21), the signal decoding and analysis module (2) is used for decoding and analysing the control instruction, and the second wireless transmission module (3) is used for converting the control instruction into a control signal with a pre-determined signal frequency and sending same to a controlled photography lighting device (30) via a wireless signal; and a power supply module (4) for supplying power to the first wireless transmission module (1), the signal decoding and analysis module (2) and the second wireless transmission module (3). The remote control apparatus (10) cooperates with the software control module (21) of a mobile terminal (20), and the control instruction may be directly input via the mobile terminal (20), such that the user experience is good and promotion in the market is facilitated.
Provided is a portable photography lamp having a replaceable lamp holder, comprising: a main-body part (100) and a lamp holder part (200) insertably connected to said main-body part (100); the main-body part (100) comprises: a main housing (101), said main housing (101) being internally provided with a power-supply control circuit board (102) and a battery compartment (103) used for accommodating a battery; said power-supply control circuit board (102) being connected to a first connection terminal (104), the end face of one end of the main housing (101) is provided with a first insertion slot (105); said lamp holder part (200) comprises: a lamp socket (201); said lamp socket (201) is provided with a lamp tube (202) and the surface of the bottom of the lamp socket (201) is provided with a second insertion slot (203); said second insertion slot (203) is insertably fitted with to the first insertion slot (105); said lamp tube (202) is connected to a second connection terminal (204); the lamp tube (202) is electrically connected to the power-supply control circuit board (102) by means of the fitting of the first and second connection terminals (104, 204). The main-body part (100) and the lamp holder part (200) employ a detachable design for convenience and portability, such that different lamp holders may be inserted, achieving different lighting effects and strengthening functionality.
F21L 4/00 - Dispositifs d'éclairage électriques avec des accumulateurs ou des piles électriques incorporés
F21V 17/10 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection caractérisée par des moyens de fixation spécifiques
F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
F21V 23/06 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des dispositifs de couplage
92.
PORTABLE PHOTOGRAPHY LAMP HAVING REPLACEABLE LAMP HOLDER
Provided is a portable photography lamp having a replaceable lamp holder, comprising a main-body part (100) and a lamp holder part (200) mounted on the main-body part (100). The main-body part (100) comprises a main housing (101); the main housing (101) is internally provided with a power-supply control circuit board (102) and a battery compartment (103) used for accommodating a battery; the power-supply control circuit board (102) is provided with a first connection terminal (104). The lamp holder part (200) comprises a lamp socket (201); the lamp socket (201) is provided with a lamp tube (202); the lamp tube (202) is provided with a second connection terminal (204); the lamp tube (202) is electrically connected to the power-supply control circuit board (102) by means of the fitting of the first and second connection terminals (104, 204). The main housing (101) of the main-body part (100) is secured to the lamp socket (201) of the lamp holder part (200) by means of a removable fixing mechanism, forming an integrated body. The main-body part (100) and the lamp holder part (200) employ a detachable design for convenience and portability, such that different lamp holders may be inserted, achieving different lighting effects.
This invention provides a system and method for projection of an image on any surface, employing a lightweight (typically polymer) housing that removably encloses a slide holder allowing for quick change of the slide. The housing includes a central channel, and allows for the mounting of a conventional camera-mounting-base lens at a front end and the insertion of a standard form factor photographic strobe/flash in the rear end. Light from the strobe passes down the channel, through the slide and is projected by the lens onto the surface. This housing is mountable on a standard tripod. The housing is straightforward to use, with the strobe effect being provided directly by the strobe unit. The system and method avoids the need of a camera body and desirably enables the user to employ one or more lenses, which are often less expensive and already available in a photographer's equipment inventory.
A combination chuck for an on-camera flash lamp comprises a clamping base and a chuck (3). A bearing and connection member (6) and an annular rod hole (1) are formed on the clamping base, and a loophole (4) using an axis of the annular rod hole (1) as a centerline is also formed. A plurality of notches (2) is formed on the periphery of the annular rod hole (1). The notches (2) are L-shaped, and are formed by axial notches (21) and radial notches (22). The chuck (3) is formed on the radial periphery of the annular rod hole (1), and is coaxial with the annular rod hole (1). The combination chuck can be used in multiple types of softboxes.
An on-camera flash, comprising a lamp body (1), a lamp holder (2) and a control circuit device. The lamp body (1) and the lamp holder (2) are connected via a pivot. The lamp holder (2) further comprises a flash-emitting outlet (208), and a light transmissive panel (205) is arranged on the flash-emitting outlet (208). The on-camera flash also comprises an adaptation plugboard (204), wherein a flash tube (201) is fixed on the adaptation plugboard (204) and is electrically connected to a circuit on the adaptation plugboard (204). A first electrical connector (202) is arranged on the adaptation plugboard (204) and is electrically connected to a second electrical connector (203) in the lamp holder (2) in a plugging manner. The lamp holder (2) comprises a front cover housing (22) and a rear cover housing (21) fixedly connected in a detachable manner, the flash-emitting outlet (208) is formed on the front cover housing (22), and the light transmissive panel (205) is snap-fitted on the flash-emitting outlet (208) in a detachable manner. The on-camera flash increases the maintainability.
G03B 15/05 - Combinaisons d'appareils photographiques avec flash électroniqueFlash électronique
H01R 12/71 - Dispositifs de couplage pour circuits imprimés rigides ou structures similaires
F21V 17/00 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection
Provided is a snap-fitting device for a softbox, comprising: a casing, on which a supporting member (6), a snap-fitting member and a light passage hole (4) are formed. The light passage hole (4) is a cylindrical hole and a flash lamp cap fixing device is formed therein. The flash lamp cap fixing device comprises a supporting platform (8) and a pressing plate (7) opposite to the supporting platform (8) and having an adjustable position relative to the supporting platform (8). The snap-fitting device for a softbox enables an on-camera flash lamp to use both an on-camera flash lamp folded softbox and a strobe flash lamp softbox, reducing expenses for a user.
A set-top flash lamp of a camera, comprising a lamp holder (2) and a lamp cap (1). A battery accommodating cavity (4) and a battery accommodating cavity cover (3) are formed in the lamp holder (2). A lithium battery (5) is accommodated in the battery accommodating cavity (4), and the lithium battery (5) comprises an electrical output contact (6). The electrical output contact (6) is in the shape of a right-angled sheet, and is composed of end surface right-angled sides (61) and bottom surface right-angled sides (62), wherein the end surface right-angled sides (61) are located on the front end surface (51) of the lithium battery (5); and the bottom surface right-angled sides (62) are arranged on the bottom surface (52) of the lithium battery (5). An electrical access contact (7) is contained in the battery accommodating cavity (4), and is arranged on a side wall of the battery accommodating cavity (4) which is opposite to the bottom surface (52) of the lithium battery (5). The set-top flash lamp improves the performance and reduces the costs.
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) Stands for photographic apparatus; Flashlights [photography]; Tripods for cameras; Electric converters; Cameras [photography]; Camera shutters; Optical lenses; Remote controls for cameras; Electrical storage batteries; Chargers for rechargeable electric batteries.
