Abrégé

A folding structure of a toy gun has a main structure that includes a gun body section, a guard section pivotally mounted to one side of the gun body section, a gun barrel portion movably arranged in interiors of the gun body section and the guard section, an internal bore module arranged at an end of the gun barrel portion, an elastic element fit over the gun barrel portion, a bore latch pivotally mounted in the interior of the guard section, a bullet loading latch pivotally mounted in the interior of the gun body section and operatively collaborating with the magazine, a bore driving member arranged at a front end of the internal bore module, a driving pull handle for pushing the bore driving member, and a fixing pull handle for fixing the guard section.

Classes IPC  ?

• F41A 11/04 - Armes à feu articulées ou repliables, c. à d. avec des pièces articulées ou télescopiques pour le transport ou le stockage

Abrégé

The electronic target includes a front plate, a chamber behind the front plate, a MEMS (Micro Electro Mechanical Systems) sensor element inside the chamber joined to the front plate by at least a connection element, a main control device electrically connected to the MEMS sensor element, and a signal processing element electrically connected to the MEMS sensor element and the main control device. Due to the MEMS sensor element's small dimension, light weight, low power consumption, high durability, low cost, and stable performance, it can be integrated into the electronic target simply by the connection element without being constrained by its shape and size, and the electronic target can be installed more conveniently and quickly.

Classes IPC  ?

• F41J 5/056 - Actionnement des commutateurs ou des contacts par les vibrations mécaniques du corps de la cible, créées par l'impact d'un projectile, p.ex. utilisant des transducteurs de choc ou de vibrations

Abrégé

A conducting hinge device is adapted to be mounted to an electric toy gun that includes a first body-section, a second body-section pivotally connected to the first body-section, an electric motor unit, and a battery unit. The conducting hinge device includes a conducting unit and a hinge conductor unit. The conducting unit is installed between the first body-section and the second body-section, and includes two pin members for being electrically connected to the electric motor unit. The hinge conductor unit includes two hinge leaves that are mounted co-movably to the second body-section, and that are each sleeved on a respective one of the pin members and electrically connected to the battery.

Classes IPC  ?

• F41B 11/89 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur spécialement adaptées à des utilisations particulières pour des jouets
• F41B 4/00 - Appareils de jet à roues à friction
• F41B 7/08 - Fusils jouets
• F41C 23/04 - Crosses ou parties de crosses articulées ou télescopiques

Abrégé

A multi-channel magazine for a toy gun includes a magazine body, a dividing unit formed within the magazine body, and a bullet pressing unit. The dividing unit cooperates with the magazine body to define at least one storage channel, a plurality of first narrow channels in spacial communication with the storage channel, and a converging channel in communication with the first narrow channels and a bullet outlet. Each of the first narrow channels and the converging channel is configured to allow only one bullet to pass through. The bullet pressing unit is mounted on the magazine body to press the bullets from the storage channel through the first narrow channels and discharge the bullets from the converging channel. The bullets can be moved and converged gradually to a one-by-one arrangement to the bullet outlet so as to facilitate smooth pressing and discharging of bullets and increase the capacity of magazine.

Classes IPC  ?

• F41B 11/55 - Chargeurs pour armes à gaz comprimé; Dispositifs pour alimenter ou charger des projectiles à partir de chargeurs les projectiles étant rangés de manière ordonnée dans un chargeur amovible, un chargeur râtelier ou tubulaire

Abrégé

An expandable magazine for a toy gun for receiving and holding bullets. Conventional magazines have limited capacity and require frequent bullet feeding operations for loading the bullets. The invention alleviates these drawbacks by providing an expandable magazine having a magazine body and a bullet pressing unit movably disposed thereon, the magazine body including a magazine housing having a bullet outlet, an expansion housing and a magazine cap. Each of the expansion housing and the magazine cap is selectively and removably connected with and mounted on the magazine housing. The expansion housing defines therein an expansion channel which is in spacial communication with the magazine housing when the expansion housing is mounted on the magazine housing to have the bullet pressing unit movably disposed in the expansion channel and the magazine housing so as to increase the capacity of the magazine and decrease the times of bullet filling operation.

Classes IPC  ?

• F41B 11/55 - Chargeurs pour armes à gaz comprimé; Dispositifs pour alimenter ou charger des projectiles à partir de chargeurs les projectiles étant rangés de manière ordonnée dans un chargeur amovible, un chargeur râtelier ou tubulaire
• F41B 11/50 - Chargeurs pour armes à gaz comprimé; Dispositifs pour alimenter ou charger des projectiles à partir de chargeurs

Abrégé

A fast expansion structure of a toy gun buttstock is provided. The structure includes a main body, a plurality of slide bars, a plurality of coupling portions, a plurality of fixing members, a butt piece, a plurality of rotating and retaining members, a plurality of first engaging surfaces, a plurality of second engaging surfaces, a limiting member, and a first elastic member. With the above structure, a user may pull the butt piece to cause the fixing members that are provided on the slide bars to push the rotating and retaining members for rotation so as to cause the first elastic member to push the limiting member to change the limiting member from an initial condition of contacting and pushing the first engaging surfaces to a condition of contacting and pushing the second engaging surfaces.

Classes IPC  ?

• F41C 23/04 - Crosses ou parties de crosses articulées ou télescopiques
• F41B 7/08 - Fusils jouets

Abrégé

A cutting-power-off detection structure of a toy gun has a main structure that includes a gun body, a muzzle defined at one side of the gun body, a feeding channel defined in the gun body, a chamber defined in the gun body and in communication with the muzzle and the feeding channel, a circuit device arranged in the gun body, at least one wireless detection device arranged in the gun body and electrically connected with the circuit device, and a shot forwarding device arranged in the chamber and electrically connected with the circuit device. The feeding channel is connectable to a magazine and the wireless detection device is operable to detect a shot fed from the magazine. When the magazine runs out of shots and the wireless detection device detects no shot, a signal is transmitted to the circuit device to cut off electricity supplied to the shot forwarding device.

Classes IPC  ?

• F41B 11/71 - Systèmes de commande électriques ou électroniques, p.ex. à des fins de sécurité
• F41B 11/89 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur spécialement adaptées à des utilisations particulières pour des jouets
• F41A 17/06 - Sûretés électriques ou électromécaniques
• F41B 11/643 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur caractérisées par l’alimentation en gaz comprimé comportant un piston effectuant une course de compression lors de chaque tir le piston étant mû par un ressort le piston étant disposé de manière concentrique avec le canon

Abrégé

A toy gun magazine constant gas flow valve structure is coupled with a magazine of a pneumatic toy gun and structurally includes a gas valve body fixed in the magazine and includes a gas inlet end portion, a gas discharge portion, and a coupling end portion, a driving rod movably disposed in the gas valve body, a control member coupled with one end of the driving rod, a stroke limiting trough having a front limiting portion and a rear limiting portion, and a stop element. Before the toy gun is firing, the stop element abuts the front limiting portion to control the extent by which the driving rod presses against the leak-sealing element and after the firing of the toy gun, the stop element abuts the rear limiting portion to control the extent of opening of the gas inlet end portion and the gas discharge portion.

Classes IPC  ?

• F16K 1/30 - Soupapes ou clapets, c. à d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation spécialement adaptées pour réceptacles sous pression
• F41B 11/723 - Soupapes; Agencement des soupapes pour commander la pression du gaz pour tirer le projectile uniquement
• F16K 1/52 - Dispositifs pour le réglage additionnel du débit

Abrégé

A handguard quick dismantling structure is provided for a toy gun and includes a barrel portion that has a barrel pivoting portion, a handguard portion that has a handguard pivoting portion, a barrel retaining piece including a barrel connecting portion and barrel coupling portion respectively arranged at opposite locations, and a handguard retaining piece including a handguard connecting portion and a handguard coupling portion respectively arranged at opposite ends. The handguard retaining piece is such that when the handguard portion and the barrel portion are combined, the handguard coupling portion is in coupling engagement with and fixed to the barrel coupling portion, and when the handguard portion and the barrel portion are separated, the handguard coupling portion is disengageble from the barrel coupling portion to achieve an effect of quick dismantling of the handguard.

Classes IPC  ?

• F41C 23/16 - Fûts ou devants; Poignées; Garde-mains
• F41A 21/48 - Moyens de montage des tubes d'arme, p.ex. montures amovibles des tubes d'arme interchangeables
• F41C 3/00 - Pistolets

Abrégé

The valve device includes a main member for installing on a toy gun and connecting to a high-pressure gas source. Inside the main member, there is a first chamber, a second chamber connected to the first chamber, and an inlet channel. A valve member is movably housed in the main member. The valve member includes a valve channel, a through hole, an inlet blocking element, and an outlet blocking element. The valve member selectively blocks the connection between the first chamber and the inlet channel. As such, the pressure difference between the second chamber and the high-pressure gas source drives the valve member to selectively block the inlet channel, without using a spring to control the valve member. The valve device therefore has enhanced operation life and reduced cost.

Classes IPC  ?

• F41B 11/723 - Soupapes; Agencement des soupapes pour commander la pression du gaz pour tirer le projectile uniquement
• F41B 11/62 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur caractérisées par l’alimentation en gaz comprimé dans lesquelles la pression est fournie par une cartouche de gaz
• F16K 15/18 - Soupapes, clapets ou valves de retenue à mécanisme de commande; Soupape de retenue et soupape à mécanisme de commande combinées
• F16K 1/30 - Soupapes ou clapets, c. à d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation spécialement adaptées pour réceptacles sous pression

Abrégé

An automatic magazine ejection structure is combinable with a toy gun body that includes an action structure and includes: a magazine receptacle, at least one pellet holder for receiving BBs or pellets, a holder latch, a pellet advancing member, a pellet-advancing elastic member, an extendible pushing rod, and at least one action driving section. When the BBs or pellets have been completely shot out, the pellet advancing member pushes the extendible pushing rod to partly project out of one side of the holder latch. Then, an operation of backward pulling the action structure synchronously drives the extendible pushing rod to move backward so as to release retaining engagement of the holder latch thereby allowing the pellet holder to automatically eject out of the magazine receptacle. As such, the operation is made simple and simulation of an operation of an actual firearm is enhanced.

Classes IPC  ?

• F41B 11/00 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur
• F41B 11/55 - Chargeurs pour armes à gaz comprimé; Dispositifs pour alimenter ou charger des projectiles à partir de chargeurs les projectiles étant rangés de manière ordonnée dans un chargeur amovible, un chargeur râtelier ou tubulaire

Abrégé

A structure is mounted in a gun barrel and includes an adjustment assembly arranged at a front end of the gun barrel, a connection tube arranged in the gun barrel in abutting engagement with the adjustment assembly to be driven by the adjustment assembly for movement, a plurality of thread sections formed on the adjustment assembly and in threading engagement with the gun barrel for fine adjustment of the adjustment assembly, at least one transmission sleeve arranged at one end of the connection tube that is distant from the adjustment assembly, and a press-down member arranged at one side of the transmission sleeve to be abutted on by the transmission sleeve for pressing inwardly of the gun barrel.

Classes IPC  ?

• F41B 11/00 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur
• F41B 11/70 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur - Parties constitutives non prévues dans le groupe  ou
• F41B 11/89 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur spécialement adaptées à des utilisations particulières pour des jouets

Abrégé

An active magazine disengagement structure includes: a magazine body, adapted to be in engagement with at least one gun body; at least one trigger device, movably configured on the magazine body; at least one trigger device, movably configured on the magazine body, and positioned on one side of the trigger device and operated in coordination therewith; and at least one on-off device, movably configured on the magazine body, adapted to retain the magazine body with the gun body, and positioned on one side of the interlocking device and operated in coordination therewith to allow the magazine body to be separated from the gun body actively without any manual operation.

Classes IPC  ?

• F41A 9/59 - Ejecteurs de lames-chargeurs ou de magasins, p.ex. de chargeurs vides
• F41A 9/65 - Boîtes-chargeurs comportant un élévateur de cartouches

Abrégé

A flow dividing valve structure for a toy gun includes: a propulsion portion; a rotating auxiliary portion extended from one face of the propulsion portion; and a latching portion, configured on one end of the rotating auxiliary portion far away from the propulsion portion, where the rotating auxiliary portion is configured with a plurality of wing portions each twisted toward a direction away from the propulsion portion so as to be allowed to have at least one twisted face. Whereby, high pressure gas will drive the rotating auxiliary portion to rotate through the wing portions when flowing through the rotating auxiliary portion, and further remove the frost generated inside a gas chamber so as to prevent the unsmooth operation of the flow dividing valve.

Classes IPC  ?

• F41B 11/723 - Soupapes; Agencement des soupapes pour commander la pression du gaz pour tirer le projectile uniquement
• F41B 11/89 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur spécialement adaptées à des utilisations particulières pour des jouets

Abrégé

The action module includes an action member, a switch element, and an activation element. The action member includes a power provision device. The switch element is on the action member electrically connected to the power provision device, and includes a switch trigger. The activation element is rotatably configured on the action member adjacent to the switch element, and includes a magazine contact part to be pressed or released when a magazine is mounted to or removed from the action module, and a switch engaging part for engaging the switch trigger. As such, by the interaction between the switch element and the activation element, the toy gun does not function as long as the magazine is not mounted, and therefore electrical power will not be wasted. The action module may work with any type of magazines.

Classes IPC  ?

• F41B 11/00 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur
• F41B 11/71 - Systèmes de commande électriques ou électroniques, p.ex. à des fins de sécurité
• F41B 11/89 - Armes de tir à gaz comprimé, p.ex. armes de tir à air comprimé; Armes de tir à vapeur spécialement adaptées à des utilisations particulières pour des jouets

Produits et services

rubber helmets; steel helmets; protective helmets; safety helmets; protective glasses; goggles for sports; nickel-cadmium storage batteries; personal security alarms; batteries; lithium batteries; anode batteries; galvanic batteries; lithium ion batteries; nickel-cadmium batteries. motors for electric or electronically operated toys; toy target launchers for firearm; air pistols (toys); toy model vehicles and related accessories sold as a unit; toy pistols, toy guns and accessories, namely toy bullets. import and export agency services; price information for bidding purposes for all the following products: toys, namely toy pistols, toy guns and accessories, namely toy bullets, motors for electric or electronically operated toys, toy target launchers for firearm, toy model vehicles and related accessories sold as a unit, air pistols (toys); price information for bidding purposes for all the following products: lithium batteries, anode batteries, galvanic batteries, lithium ion batteries, nickel-cadmium batteries, rubber helmets, steel helmets, protective helmets, safety helmets, protective glasses, goggles for sports, nickel-cadmium storage batteries, personal security alarm.

Produits et services

rubber helmets; steel helmets; protective helmets; safety helmets; protective glasses; goggles for sports; nickel-cadmium storage batteries; personal security alarms; batteries; lithium batteries; anode batteries; galvanic batteries; lithium ion batteries; nickel-cadmium batteries. motors for electric or electronically operated toys; toy target launchers for firearm; air pistols (toys); toy model vehicles and related accessories sold as a unit; toy pistols, toy guns and accessories, namely toy bullets. import and export agency services; price information for bidding purposes for all the following products: toys, namely toy pistols, toy guns and accessories, namely toy bullets, motors for electric or electronically operated toys, toy target launchers for firearm, toy model vehicles and related accessories sold as a unit, air pistols (toys); price information for bidding purposes for all the following products: lithium batteries, anode batteries, galvanic batteries, lithium ion batteries, nickel-cadmium batteries, rubber helmets, steel helmets, protective helmets, safety helmets, protective glasses, goggles for sports, nickel-cadmium storage batteries, personal security alarm.

Produits et services

rubber helmets; steel helmets; protective helmets; safety helmets; protective glasses; goggles for sports; nickel-cadmium storage batteries; personal security alarms; batteries; lithium batteries; anode batteries; galvanic batteries; lithium ion batteries; nickel-cadmium batteries. motor for electric or electronically operated toys; toy target launchers for firearm; air pistols (toys); toy model vehicles and related accessories sold as a unit; toy pistols, toy guns and accessories, namely toy bullets. import and export agency services; price information for bidding purposes for all the following products: toys, namely toy pistols, toy guns and accessories, namely toy bullets, motors for electric or electronically operated toys, toy target launchers for firearm, toy model vehicles and related accessories sold as a unit, air pistols (toys); price information for bidding purposes for all the following products: lithium batteries, anode batteries, galvanic batteries, lithium ion batteries, nickel-cadmium batteries, rubber helmets, steel helmets, protective helmets, safety helmets, protective glasses, goggles for sports, nickel-cadmium storage batteries, personal security alarms.

Abrégé

A target pressure detection device (1) includes a housing (10), a resilient membrane (12), and a pressure detection unit (14). The housing (10) forms a chamber (102) having an open end and the housing (10) forms a through hole (104). The resilient membrane (12) is mounted to the housing (10) to cover and close the open end of the housing (10) so as to set the chamber (102) in an air-tight condition. The pressure detection unit (14) is mounted to the through hole (104) and forms therein an accommodation compartment (140) that movably receives therein a floating element (142). The accommodation compartment (140) receives therein a sensor (144). The sensor (144) can effectively detect a movement of the floating element (142) and thus the precision of detection of the target can be improved through detecting change of airflow.

Classes IPC  ?

• G01L 7/22 - Mesure de la pression permanente ou quasi permanente d’un fluide ou d’un matériau solide fluent par des éléments mécaniques ou hydrauliques sensibles à la pression en utilisant un liquide comme milieu sensible à la pression, p.ex. des jauges à colonne de liquide comportant des flotteurs, p.ex. cloches flottantes

Produits et services

Telescopic gun sights; goggles; sports glasses; personal security alarms; helmets; nickel-cadmium storage batteries; protective helmets. Toy pistols, guns and accessories, namely, toy bullets; toy air pistols; toy models; toy target launchers for firearm; toy model vehicles and related accessories sold as a unit. Import and export agency services, price information for bidding purposes for toys, namely, toy pistols, guns and accessories, namely, toy bullets, motors for electric or electronically operated toys, toy target launchers for firearm, toy model vehicles and related accessories sold as a unit, toy air pistols.

Produits et services

Plastic character toys; Toy guns; Toy pistols

Produits et services

Rubber helmets; steel helmets; protective helmets; safety helmets; protective glasses; goggles for sports; nickel-cadmium storage batteries; personal security alarms. Toy pistols, guns and accessories, namely toy bullets; motors for electric or electronically operated toys; toy target launchers for firearm; toy model vehicles and related accessories sols as a unit; air pistols (toys). Import and export agency services; price information for bidding purposes for toys, namely toy pistols, guns and accessories, namely, toy bullets; motors for electric or electronically operated toys, toy target launchers for firearm, toy model vehicles and related accessories sold as a unit, air pistols (toys).

Produits et services

Rubber helmets; steel helmets; protective helmets; safety helmets; protective glasses; goggles for sports; nickel-cadmium storage batteries; personal security alarms. Toy pistols; guns and accessories; namely, toy bullets; motors for electric or electronically operated toys; toy target launchers for firearm; toy model vehicles and related accessories sold as a unit; air pistols (toys). Import and export agency services, price information for bidding purposes for toys, namely, toy pistols, guns and accessories, namely, toy bullets, motors for electric or electronically operated toys, toy target launchers for firearm, toy model vehicles and related accessories sold as a unit, air pistols (toys).

Produits et services

Toy pistols, toy guns and accessories, namely, toy bullets; toy air pistols; target launchers for firearm; toy model vehicles and related accessories sold as units
