An exhaust noise attenuation system and method for dampening and attenuation of noise from flows of exhaust gases from gas turbine engines such as for use in powering direct drive turbine fracturing systems includes an exhaust duct assembly, an upper noise attenuation assembly moveably mounted over an upper plenum portion of the exhaust duct assembly, and a conveying system. A flow path is defined along lower and upper plenum portions of the exhaust duct assembly and receives flows of exhaust gasses from the gas turbine engine. The conveying system is configured to selectively move the upper noise attenuation assembly between a stowed position substantially covering an outlet defined at an upper end of the upper plenum portion to prevent rain and snow from entering the exhaust duct assembly; and a deployed position in which the upper noise attenuation assembly is extended, extending the flow path of the exhaust gasses and redirecting the exhaust gasses away from the exhaust duct assembly and the gas turbine engine to enable a reduction of noise levels experienced at ground level.
An example fluid manifold, for a fracturing system, includes one or more spool sections and a flow passage at least partially defined by the spool sections that extends along a longitudinal axis. In addition, the manifold includes a first flow altering assembly positioned along the flow passage and including a diverter surface positioned to divert fluid radially away from the axis. Further, the manifold includes a second flow altering assembly positioned along the flow passage and spaced from the first flow altering assembly. The second flow altering assembly includes an annular flange and a flow altering tube extending axially from the annular flange such that the annular flange and the flow altering tube define an annular cavity that extends radially between the flow altering tube and an inner wall of the flow passage and that extends axially along the flow altering tube to the annular flange.
37 - Services de construction; extraction minière; installation et réparation
Produits et services
(1) Hydraulic fracturing and fleet services
(2) Fleet services, namely business operation of hydraulic fracturing equipment, namely, a fleet consisting of high-pressure fracturing pumps, slurry fracturing blender machines, and power generation units for use in oil and gas well hydraulic fracturing operations, for others
37 - Services de construction; extraction minière; installation et réparation
Produits et services
(1) Hydraulic fracturing and fleet services
(2) Fleet services, namely business operation of hydraulic fracturing equipment, namely, a fleet consisting of high-pressure fracturing pumps, slurry fracturing blender machines, and power generation units for use in oil and gas well hydraulic fracturing operations, for others
Blenders for use in oil and gas well services, namely, slurry blender machines for use in oil or gas well completion and hydraulic fracturing service operations
A multi-blender system for blending liquid and solid particulates together to prepare a fracturing fluid, the blender system can include a plurality of independently operable blender units each having components that can operate with either blender unit. Each component may be a modular blender component mounted to respective independent frames. The independent frames are configured to be independently removable, replaceable and movable to multiple positions in the blender system. In some aspects the multi-blender system can operate at different sand concentrations, instantaneously adjust flow rate to one or more of the components in either blender unit, provide control redundancy, and may continue to operate despite a failure of one of the major components.
B01F 35/222 - Commande ou régulation du fonctionnement du système d'entraînement, p. ex. du couple, de la vitesse ou de la puissance des moteursCommande ou régulation de la position des dispositifs ou des éléments de mélange
A power generation assembly and related methods to enhance power efficiency and reduce greenhouse gas emissions associated with a power-dependent operation, may include a gas turbine engine. The power generation assembly also may include a heat exchanger positioned to receive exhaust gas from the gas turbine engine during operation. The heat exchanger may include an exhaust gas inlet positioned to receive exhaust gas and a liquid inlet positioned to receive liquid. The heat exchanger may be positioned to convert liquid into steam via heat from the exhaust gas. The power generation assembly further may include a steam turbine positioned to receive steam from the heat exchanger and convert energy from the steam into mechanical power. The power generation assembly still further may include an electric power generation device connected to the steam turbine and positioned to convert the mechanical power from the steam turbine into electrical power.
F01K 17/06 - Récupération dans le cycle de fonctionnement de l'énergie de la vapeur, sous forme dégradée, p. ex. utilisation de la vapeur d'évacuation pour sécher le combustible solide utilisé dans l'ensemble fonctionnel
F01K 23/10 - Ensembles fonctionnels caractérisés par plus d'une machine motrice fournissant de l'énergie à l'extérieur de l'ensemble, ces machines motrices étant entraînées par des fluides différents les cycles de ces machines motrices étant couplés thermiquement la chaleur de combustion provenant de l'un des cycles chauffant le fluide dans un autre cycle le fluide à la sortie de l'un des cycles chauffant le fluide dans un autre cycle
F01K 23/16 - Ensembles fonctionnels caractérisés par plus d'une machine motrice fournissant de l'énergie à l'extérieur de l'ensemble, ces machines motrices étant entraînées par des fluides différents les machines motrices étant couplées mécaniquement toutes les machines motrices étant des turbines
32.
MULTI-STAGE POWER GENERATION USING BYPRODUCTS FOR ENHANCED GENERATION
A power generation assembly and related methods to enhance power efficiency and reduce greenhouse gas emissions associated with a power-dependent operation, may include a gas turbine engine. The power generation assembly also may include a heat exchanger positioned to receive exhaust gas from the gas turbine engine during operation. The heat exchanger may include an exhaust gas inlet positioned to receive exhaust gas and a liquid inlet positioned to receive liquid. The heat exchanger may be positioned to convert liquid into steam via heat from the exhaust gas. The power generation assembly further may include a steam turbine positioned to receive steam from the heat exchanger and convert energy from the steam into mechanical power. The power generation assembly still further may include an electric power generation device connected to the steam turbine and positioned to convert the mechanical power from the steam turbine into electrical power.
F01K 23/10 - Ensembles fonctionnels caractérisés par plus d'une machine motrice fournissant de l'énergie à l'extérieur de l'ensemble, ces machines motrices étant entraînées par des fluides différents les cycles de ces machines motrices étant couplés thermiquement la chaleur de combustion provenant de l'un des cycles chauffant le fluide dans un autre cycle le fluide à la sortie de l'un des cycles chauffant le fluide dans un autre cycle
F01K 17/06 - Récupération dans le cycle de fonctionnement de l'énergie de la vapeur, sous forme dégradée, p. ex. utilisation de la vapeur d'évacuation pour sécher le combustible solide utilisé dans l'ensemble fonctionnel
F01K 23/16 - Ensembles fonctionnels caractérisés par plus d'une machine motrice fournissant de l'énergie à l'extérieur de l'ensemble, ces machines motrices étant entraînées par des fluides différents les machines motrices étant couplées mécaniquement toutes les machines motrices étant des turbines
33.
HYDRAULIC FRACTURING PUMPS TO ENHANCE FLOW OF FRACTURING FLUID INTO WELLHEADS AND RELATED METHODS
Systems and methods to enhance the flow of fracturing fluid into a wellhead during a high-pressure fracturing operation may include providing a pump frame and a crankshaft. A plurality of first plungers may be connected to the crankshaft and may reciprocate in a first plane. The hydraulic fracturing pump also may include a plurality of second plungers connected to the crankshaft and positioned to reciprocate in a second plane. The first plane and the second plane may define a non-zero offset angle between the first plane and the second plane. The crankshaft may include a plurality of crankpins, and each of the crankpins may be connected to one of the first plungers and one of the second plungers. The first plungers may pump a first fracturing fluid and the second plungers may pump a second fracturing fluid different from the first fracturing fluid.
F04B 9/04 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant mécaniques constitués par des cames, des excentriques ou des mécanismes à téton et rainure guide
F04B 23/06 - Combinaisons de plusieurs pompes les pompes étant toutes du type à déplacement positif alternatif
F04B 47/00 - Pompes ou installations de pompage spécialement adaptées pour élever un fluide à partir d'une grande profondeur, p. ex. pompes de puits
34.
HYDRAULIC FRACTURING PUMPS TO ENHANCE FLOW OF FRACTURING FLUID INTO WELLHEADS AND RELATED METHODS
Systems and methods to enhance the flow of fracturing fluid into a wellhead during a high-pressure fracturing operation may include providing a pump frame and a crankshaft. A plurality of first plungers may be connected to the crankshaft and may reciprocate in a first plane. The hydraulic fracturing pump also may include a plurality of second plungers connected to the crankshaft and positioned to reciprocate in a second plane. The first plane and the second plane may define a non-zero offset angle between the first plane and the second plane. The crankshaft may include a plurality of crankpins, and each of the crankpins may be connected to one of the first plungers and one of the second plungers. The first plungers may pump a first fracturing fluid and the second plungers may pump a second fracturing fluid different from the first fracturing fluid.
F04B 47/00 - Pompes ou installations de pompage spécialement adaptées pour élever un fluide à partir d'une grande profondeur, p. ex. pompes de puits
F04B 9/04 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant mécaniques constitués par des cames, des excentriques ou des mécanismes à téton et rainure guide
F04B 23/06 - Combinaisons de plusieurs pompes les pompes étant toutes du type à déplacement positif alternatif
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Business operation of hydraulic fracturing equipment, namely, a fleet consisting of high-pressure fracturing pumps, slurry fracturing blender machines, and power generation units for use in oil or gas well hydraulic fracturing operations, for others Hydraulic fracturing services
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Business operation of hydraulic fracturing equipment, namely, a fleet consisting of high-pressure fracturing pumps, slurry fracturing blender machines, and power generation units for use in oil or gas well hydraulic fracturing operations, for others Hydraulic fracturing services
38.
METHODS, SYSTEMS, AND DEVICES FOR FRACTURING FLUID DELIVERY TO SUBSURFACE FORMATIONS
Methods, systems, and devices to enhance fracturing fluid delivery to subsurface fomiations to enhance hydrocarbon production from the subsurface formations may include providing a manifold coupling having a manifold coupling passage with a manifold coupling axis. The manifold coupling may include a first inlet passage positioned to provide fluid flow between a first fracturing fluid output and the manifold coupling passage, and a second inlet passage positioned opposite the first inlet passage to provide fluid flow between a second fracturing fluid output and the manifold coupling passage. The first inlet passage may have a first inlet passage cross-section at least partially defining a first inlet axis extending transverse relative to the manifold coupling axis. The second inlet passage may have a second inlet passage cross-section at least partially defining a second inlet axis extending transverse relative to the manifold coupling axis and not being co-linear with the first inlet axis.
Methods, systems, and devices to enhance fracturing fluid delivery to subsurface formations to enhance hydrocarbon production from the subsurface formations may include providing a manifold coupling having a manifold coupling passage with a manifold coupling axis. The manifold coupling may include a first inlet passage positioned to provide fluid flow between a first fracturing fluid output and the manifold coupling passage, and a second inlet passage positioned opposite the first inlet passage to provide fluid flow between a second fracturing fluid output and the manifold coupling passage. The first inlet passage may have a first inlet passage cross-section at least partially defining a first inlet axis extending transverse relative to the manifold coupling axis. The second inlet passage may have a second inlet passage cross-section at least partially defining a second inlet axis extending transverse relative to the manifold coupling axis and not being co-linear with the first inlet axis.
Systems and methods for identifying a status of components of hydraulic fracturing units including a prime mover and a hydraulic fracturing pump to pump fracturing fluid into a wellhead via a manifold may include a diagnostic control assembly. The diagnostic control assembly may include sensors associated with the hydraulic fracturing units or the manifold, and a supervisory control unit to determine whether the sensors are generating signals outside a calibration range, determine whether a fluid parameter associated with an auxiliary system of the hydraulic fracturing units is indicative of a fluid-related problem, determine whether lubrication associated with the prime mover, the hydraulic fracturing pump, or a transmission of the hydraulic fracturing units has a lubrication fluid temperature greater than a maximum lubrication temperature, or determine an extent to which a heat exchanger assembly associated with the hydraulic fracturing units is cooling fluid passing through the heat exchanger assembly.
Systems and methods for monitoring, detecting, and/or intervening with respect to cavitation and pulsation events during hydraulic fracturing operations may include a supervisory controller. The supervisory controller may be configured to receive pump signals indicative of one or more of pump discharge pressure, pump suction pressure, pump speed, or pump vibration associated with operation of the hydraulic fracturing pump. The supervisory controller also may be configured to receive blender signals indicative of one or more of blender flow rate or blender discharge pressure. Based on one or more of these signals, the supervisory controller may be configured to detect a cavitation event and/or a pulsation event. The supervisory controller may be configured to generate a cavitation notification signal indicative of detection of cavitation associated with operation of the hydraulic fracturing pump, and/or a pulsation notification signal indicative of detection of pulsation associated with operation of the hydraulic fracturing pump.
Systems and methods for operating hydraulic fracturing units, each including a hydraulic fracturing pump to pump fracturing fluid into a wellhead and an internal combustion engine to drive the hydraulic fracturing pump, may include receiving signals indicative of operational parameters. The systems and methods also may include determining an amount of required fracturing power sufficient to perform the hydraulic fracturing operation, determining an available power to perform the hydraulic fracturing operation and a difference between the available power and the required power, and controlling operation of the hydraulic fracturing units based at least in part on the power difference. When the power difference is indicative of excess power available, the system and methods may include causing at least one of the hydraulic fracturing units to idle, and when the power difference is indicative of a power deficit, increasing a power output of at least one of the hydraulic fracturing units.
A methods and system to operate hydraulic fracturing units may include utilizing hydraulic fracturing unit profiles. The system may include hydraulic fracturing units may include various components. The components may include an engine and associated local controller and sensors, a transmission connected to the engine, transmission sensors, and a pump connected to the transmission and powered by the engine via the transmission and associated local controller and sensors. A supervisory controller may control the hydraulic fracturing units. The supervisory controller may be in communication with components of each hydraulic fracturing unit. The supervisory controller may include instructions to, for each hydraulic fracturing units, obtain hydraulic fracturing unit parameters, determine a hydraulic fracturing unit health assessment, and build a hydraulic unit profile including the health assessment and parameters. The supervisory controller may, based on the health assessment, determine the hydraulic fracturing unit's capability to be operated at a maximum power output.
Embodiments of a power generation system and methods to be used in conjunction with a high-powered turbine engine are disclosed. The power generation system includes a turbine engine having an exhaust diffuser section installed on the exhaust duct of the turbine engine and a turbine engine exhaust stack assembly connected to the turbine engine exhaust diffuser section. An embodiment further includes thermo-electric generator (TEGs) sub-assemblies connected to the turbine engine exhaust stack assembly. In other embodiments electrical storage devices such as batteries are used.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F02C 6/00 - Ensembles fonctionnels multiples de turbines à gazCombinaisons d'ensembles fonctionnels de turbines à gaz avec d'autres appareilsAdaptations d'ensembles fonctionnels de turbines à gaz à des applications particulières
F02C 6/18 - Utilisation de la chaleur perdue dans les ensembles fonctionnels de turbines à gaz à l'extérieur des ensembles eux-mêmes, p. ex. ensembles fonctionnels de chauffage à turbine à gaz
F02C 7/32 - Aménagement, montage ou entraînement des auxiliaires
F04B 17/03 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs électriques
F04B 17/05 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci entraînées par des moteurs à combustion interne
G05B 19/042 - Commande à programme autre que la commande numérique, c.-à-d. dans des automatismes à séquence ou dans des automates à logique utilisant des processeurs numériques
H02J 7/00 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries
H10N 10/00 - Dispositifs thermoélectriques comportant une jonction de matériaux différents, c.-à-d. dispositifs présentant l'effet Seebeck ou l'effet Peltier
45.
SYSTEMS AND METHODS PROVIDING A CONFIGURABLE STAGED RATE INCREASE FUNCTION TO OPERATE HYDRAULIC FRACTURING UNITS
Systems and methods for operating hydraulic fracturing units to pump fracturing fluid into a wellhead may include receiving a target flow rate and/or a target pressure for fracturing fluid supplied to the wellhead. The systems and methods may increase a flow rate from the hydraulic fracturing units according to a controlled increasing flow rate schedule toward the target flow rate and/or target pressure. When it has been determined the target flow rate and/or target pressure has been achieved, the systems and methods also may include operating the hydraulic fracturing units to maintain the target flow rate and/or target pressure. When the target flow rate has not been achieved, the systems and methods also may include generating notification signals, and/or when the target pressure has not been achieved, the systems and methods further may include operating the hydraulic fracturing units to maintain a maximum flow rate.
Systems and methods to pump fracturing fluid into a wellhead may include a gas turbine engine including a compressor turbine shaft connected to a compressor, and a power turbine output shaft connected to a power turbine. The compressor turbine shaft and the power turbine output shaft may be rotatable at different rotational speeds. The systems may also include a transmission including a transmission input shaft connected to the power turbine output shaft and a transmission output shaft connected to a hydraulic fracturing pump. The systems may also include a fracturing unit controller configured to control one or more of the rotational speeds of the compressor turbine shaft, the power turbine output shaft, or the transmission output shaft based at least in part on target signals and fluid flow signals indicative of one or more of pressure or flow rate associated with fracturing fluid pumped into the wellhead.
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F01D 15/08 - Adaptations pour la commande des pompes ou combinaisons avec celles-ci
F02C 7/36 - Transmission de puissance entre les différents arbres de l'ensemble fonctionnel de turbine à gaz, ou entre ce dernier et l'utilisateur de puissance
F04B 49/20 - Commande des "machines", pompes ou installations de pompage ou mesures de sécurité les concernant non prévues dans les groupes ou présentant un intérêt autre que celui visé par ces groupes en modifiant la vitesse d'entraînement
47.
STAGE PROFILES FOR OPERATIONS OF HYDRAULIC SYSTEMS AND ASSOCIATED METHODS
A system and method of enhancing operation of hydraulic fracturing equipment at a hydraulic fracturing wellsite may include determining if a hydraulic fracturing stage profiles are available for use for hydraulic fracturing equipment at a wellsite. The method may include prompting an acceptance or amendment of one of the hydraulic fracturing stage profiles for a hydraulic fracturing pumping stage. The method may include, in response to an amendment of one of the hydraulic fracturing stage profiles, prompting acceptance of the amended hydraulic fracturing stage profile as the current hydraulic fracturing stage profile for use in association with the controller. The method may include, when a hydraulic fracturing stage profile is not available, prompting configuration of hydraulic fracturing pumping stage parameters for the current hydraulic fracturing stage profile. The method may include storing the current hydraulic fracturing stage profile as the previous hydraulic fracturing stage profile in association with the controller.
Systems and methods for operating hydraulic fracturing units to pump fracturing fluid into a wellhead may include receiving a target flow rate and/or a target pressure for fracturing fluid supplied to the wellhead. The systems and methods may increase a flow rate from the hydraulic fracturing units according to a controlled increasing flow rate schedule toward the target flow rate and/or target pressure. When it has been determined the target flow rate and/or target pressure has been achieved, the systems and methods also may include operating the hydraulic fracturing units to maintain the target flow rate and/or target pressure. When the target flow rate has not been achieved, the systems and methods also may include generating notification signals, and/or when the target pressure has not been achieved, the systems and methods further may include operating the hydraulic fracturing units to maintain a maximum flow rate.
Systems and methods to monitor a condition of a fracturing component section including a section frame and a hydraulic fracturing component of a hydraulic fracturing unit to pump fracturing fluid connected to the section frame may include a condition monitoring controller configured to receive one or more signals from one or more sensors configured to be connected to the fracturing component section and generate signals indicative of operating parameters associated with operation of the fracturing component. The condition monitoring controller may be configured to generate, based at least in part on the signals, condition signals indicative of approaching maintenance due to be performed, predicted component damage, predicted component failure, existing component damage, existing component failure, irregularities of component operation, and/or operation exceeding rated operation. The systems and methods also may include exchanging the fracturing component for another fracturing component based at least in part on the condition signals.
Methods, systems, and controllers for detecting and mitigating well screen outs may include a controller configured to operate a fracturing pump to supply fluid at a discharge rate to a wellhead at a fracturing well site. The controller may also operate a blender positioned to deliver a blend of proppant and fluid to the fracturing pump. The controller may compare a fluid pressure increase rate to a preselected increase rate indicative of a potential well screen out. The controller may incrementally decrease the discharge rate of the fracturing pump and a flow rate of a blender when the fluid pressure increase rate of the wellhead exceeds the preselected increase rate and the fluid pressure is within a preselected percentage of a maximum wellhead pressure until the fluid pressure of the fluid supplied to the wellhead is stabilized.
Abstract Systems and methods for exchanging fracturing components of a hydraulic fracturing unit and may include an exchangeable fracturing component section to facilitate quickly exchanging a fracturing component of a hydraulic fracturing unit. The fracturing component section may include a section frame including a base, and a fracturing component connected to the base. The fracturing component section also may include a component electrical assembly and a component fluid assembly connected to the section frame. The fracturing component section further may include a coupling plate connected to the section frame. The fracturing component section also may include one or more of a plurality of quick-connect electrical couplers or a plurality of quick- connect fluid couplers connected to a coupling plate. The quick-connect electrical and fluid couplers may be positioned to receive respective electrical and fluid connections of the component electrical and fluid assemblies and connect to other portions of the hydraulic fracturing unit. Date Recue/Date Received 2021-04-01
Embodiments of drive equipment for mobile hydraulic fracturing power units and methods for changing and controlling the drive equipment are disclosed. The mobile power units include a gas turbine engine that provides mechanical power to drive shaft which is connected to the drive equipment such that the drive equipment is driven by the engine. The drive equipment may be a hydraulic fracturing pump or an electrical generator. The drive shaft is rotated at a speed suitable for the hydraulic fracturing pump and the electrical generator includes a step up gearbox to increase a rotational speed of the drive shaft for use by the electrical generator. The drive equipment may be secured to a skid that is field changeable with a crane or a fork lift to change the drive equipment at a well pad based on the demands of the well pad.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F01D 15/00 - Adaptations des "machines" ou machines motrices à des usages particuliersCombinaisons des machines motrices avec les dispositifs qu'elles entraînent
F01D 15/08 - Adaptations pour la commande des pompes ou combinaisons avec celles-ci
F01D 15/10 - Adaptations pour la commande des générateurs électriques ou combinaisons avec ceux-ci
F01D 15/12 - Combinaisons avec des transmissions mécaniques
F02C 7/36 - Transmission de puissance entre les différents arbres de l'ensemble fonctionnel de turbine à gaz, ou entre ce dernier et l'utilisateur de puissance
H02K 7/18 - Association structurelle de génératrices électriques à des moteurs mécaniques d'entraînement, p. ex. à des turbines
53.
SYSTEMS AND METHODS TO ENHANCE INTAKE AIR FLOW TO A GAS TURBINE ENGINE OF A HYDRAULIC FRACTURING UNIT
Systems and methods to increase intake air flow to a gas turbine engine of a hydraulic fracturing unit when positioned in an enclosure may include providing an intake expansion assembly to enhance intake air flow to the gas turbine engine. The intake expansion assembly may include an intake expansion wall defining a plurality of intake ports positioned to supply intake air to the gas turbine engine. The intake expansion assembly also may include one or more actuators connected to a main housing of the enclosure and the intake expansion assembly. The one or more actuators may be positioned to cause the intake expansion wall to move relative to the main housing between a first position preventing air flow through the plurality of intake ports and a second position providing air flow through the plurality of intake ports to an interior of the enclosure.
F01D 25/28 - Dispositions pour le support ou le montage, p. ex. pour les carters de turbines
F02C 7/055 - Entrées d'air pour ensembles fonctionnels de turbines à gaz ou de propulsion par réaction comportant des dispositifs pour empêcher la pénétration d'objets ou de particules endommageantes comportant des grilles, des écrans ou des dispositifs protecteurs
F04B 17/00 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci
54.
ENCLOSURE ASSEMBLY FOR ENHANCED COOLING OF DIRECT DRIVE UNIT AND RELATED METHODS
Embodiments of an enclosure assembly to enhance cooling of a hydraulic fracturing direct drive unit (DDU) during operation are included. The enclosure assembly may include an enclosure body extending at least partially around an enclosure space to house the DDU for driving a fluid pump. The enclosure assembly may include one or more heat exchanger assemblies connected to the enclosure body for cooling a process fluid associated with one or more of the DDU and the fluid pump, and which may be configured to draw air into the enclosure space from and external environment, toward one or more radiator assemblies to cool the process fluid, and along an airflow path through the enclosure space. One or more outlet fan assemblies may be operative to discharge air from the enclosure space to the external environment to maintain a desired temperature of the enclosure space.
Systems and methods for supplying primary fuel and secondary fuel to an internal combustion engine may include supplying a first amount of the primary fuel and a second amount of the secondary fuel to the internal combustion engine. The system may include a first manifold to provide primary fuel to the internal combustion engine, and a primary valve associated with the first manifold to provide fluid flow between a primary fuel source and the internal combustion engine. A second manifold may provide secondary fuel to the internal combustion engine, and a fuel pump and/or a secondary valve may provide fluid flow between a secondary fuel source and the internal combustion engine. A controller may determine a total power load, the first amount of primary fuel, and the second amount of secondary fuel to supply to the internal combustion engine to meet the total power load.
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F02B 63/06 - Adaptations des moteurs pour entraîner des pompes, des outils tenus à la main ou des génératrices électriquesCombinaisons portatives de moteurs avec des dispositifs entraînés par des moteurs pour pompes
F02D 19/08 - Commande des moteurs caractérisés par l'emploi de combustible non liquide, de combustibles multiples ou de substances non combustibles ajoutées au mélange carburant particulière aux moteurs fonctionnant avec des combustibles multiples, p. ex. alternativement du fuel léger et du fuel lourd, et autres que les moteurs indifférents au combustible utilisé utilisant simultanément des combustibles multiples
F02M 25/00 - Appareils spécifiques conjugués aux moteurs pour ajouter des substances non combustibles ou de petites quantités de combustible secondaire, à l’air comburant, au combustible principal ou au mélange air-combustible
56.
ONBOARD HEATER OF AUXILIARY SYSTEMS USING EXHAUST GASES AND ASSOCIATED METHODS
An exhaust energy recovery system (EERS) and associated methods for an engine are disclosed. An embodiment of an EERS, for example, includes an inlet duct that is configured to divert exhaust gas from an exhaust duct of the engine into the recovery system and an outlet duct configured to return the exhaust gas to the exhaust duct downstream of the inlet duct. The recovery system is configured to heat components or fluids associated with engine to operating temperatures. The recovery system may be part of a mobile power system that is mounted to a single trailer and includes an engine and a power unit such as a high pressure pump or generator mounted to the trailer. Methods of operating and purging recovery systems are also disclosed.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F01D 15/08 - Adaptations pour la commande des pompes ou combinaisons avec celles-ci
F02C 6/18 - Utilisation de la chaleur perdue dans les ensembles fonctionnels de turbines à gaz à l'extérieur des ensembles eux-mêmes, p. ex. ensembles fonctionnels de chauffage à turbine à gaz
F16N 39/04 - Dispositions pour conditionner des lubrifiants dans les circuits de lubrification par chauffage
F28F 9/00 - CartersBoîtes de distributionSupports auxiliaires pour les élémentsÉléments auxiliaires dans les carters
57.
SYSTEMS AND METHODS UTILIZING TURBINE COMPRESSOR DISCHARGE FOR HYDROSTATIC MANIFOLD PURGE
Embodiments of systems and methods for air recovery are disclosed. The diverted pressurized air may be used to supply a hydrostatic purge to the unutilized portion of a turbine engine fuel manifold circuit to ensure that exhaust gases from the utilized side of the fuel manifold circuit do not enter the portion of the alternative fuel manifold circuit rack. The assembly used to remove compressor section pressurized air may include a flow control orifice, line pressure measuring instrumentation, non-return valves, isolation valves and hard stainless-steel tubing assemblies. In some embodiments, a turbine compressor section diverter system may include a small air receiver used to increase the volume of air supplying the manifold to aid in potential pressure and flow disruptions from a turbine engine compressor section.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F02C 6/00 - Ensembles fonctionnels multiples de turbines à gazCombinaisons d'ensembles fonctionnels de turbines à gaz avec d'autres appareilsAdaptations d'ensembles fonctionnels de turbines à gaz à des applications particulières
F02C 7/232 - Soupapes pour combustibleSystèmes ou soupapes de drainage
58.
SYSTEMS AND METHODS UTILIZING TURBINE COMPRESSOR DISCHARGE FOR HYDROSTATIC MANIFOLD PURGE
Embodiments of systems and methods for air recovery are disclosed. The diverted pressurized air may be used to supply a hydrostatic purge to the unutilized portion of a turbine engine fuel manifold circuit to ensure that exhaust gases from the utilized side of the fuel manifold circuit do not enter the portion of the alternative fuel manifold circuit rack. The assembly used to remove compressor section pressurized air may include a flow control orifice, line pressure measuring instrumentation, non-return valves, isolation valves and hard stainless-steel tubing assemblies. In some embodiments, a turbine compressor section diverter system may include a small air receiver used to increase the volume of air supplying the manifold to aid in potential pressure and flow disruptions from a turbine engine compressor section.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F02C 6/00 - Ensembles fonctionnels multiples de turbines à gazCombinaisons d'ensembles fonctionnels de turbines à gaz avec d'autres appareilsAdaptations d'ensembles fonctionnels de turbines à gaz à des applications particulières
F02C 7/232 - Soupapes pour combustibleSystèmes ou soupapes de drainage
Embodiments of a high-pressure, high power, reciprocating positive displacement fluid pumping system and methods are included. The system may include a high- pressure, high power, reciprocating positive displacement pump including a pump plunger, a fluid end block assembly, and a fluid cover. The fluid end block assembly may include a fluid end block body, a suction port, a discharge port, a pump bore positioned in and extending through the fluid end block body, and a fluid chamber positioned in the fluid end block body and in fluid communication with each of the suction port, the discharge port, and the pump bore. The fluid chamber has an open end portion, and the pump plunger may be positioned to move in the pump bore to pressurize one or more fluids in the fluid chamber. The fluid cover includes a monolithic body having a first portion and a second portion, the first portion being received in the open end portion and sealably engaged with the fluid end block body, the second portion being mechanically connected to the fluid end block body.
A system and method for operating a fleet of pumps for a turbine driven fracturing pump system used in hydraulic fracturing is disclosed. In an embodiment, a method of operating a fleet of pumps associated with a hydraulic fracturing system includes receiving a demand Hydraulic Horse Power (HHP) signal. The demand HHP signal may include the Horse Power (HP) required for the hydraulic fracturing system to operate and may include consideration for frictional and other losses. The method further includes operating all available pump units at a percentage of rating below Maximum Continuous Power (MCP) level, based at least in part on the demand HHP signal. Furthermore, the method may include receiving a signal for loss of power from one or more pump units. The method further includes operating one or more units at MCP level and operating one or more units at Maximum Intermittent Power (MIP) level to meet the demand HHP signal.
Methods and systems for supply of fuel for a turbine-driven fracturing pump system used in hydraulic fracturing may be configured to identify when the supply pressure of primary fuel to a plurality of gas turbine engines of a plurality of hydraulic fracturing units falls below a set point, identify a gas turbine engine of the fleet of hydraulic fracturing units operating on primary fuel with highest amount of secondary fuel available, and to selectively transfer the gas turbine engine operating on primary fuel with the highest amount of secondary fuel from primary fuel operation to secondary fuel operation. Some methods and systems may be configured to transfer all gas turbine engines to secondary fuel operation and individually and/or sequentially restore operation to primary fuel operation and/or to manage primary fuel operation and/or secondary fuel operation for portions of the plurality of gas turbine engines.
Embodiments of system and methods for supplying fuel, enabling communications, and conveying electric power associated with operation of a hydraulic fracturing unit of a plurality of hydraulic fracturing units are disclosed and may include a fuel line connection assembly configured to be connected to the first hydraulic fracturing unit and to supply fuel from a fuel source to a gas turbine engine connected to the hydraulic fracturing unit. A system also may include a communications cable assembly configured to be connected to the hydraulic fracturing unit and to enable data communications between the hydraulic fracturing unit and a data center or another hydraulic fracturing unit. A system further may include a power cable assembly configured to be connected to the hydraulic fracturing unit and to convey electric power between the hydraulic fracturing unit and a remote electrical power source or the plurality of hydraulic fracturing units.
Embodiments of systems and methods disclosed provide a hydraulic fracturing unit that includes a reciprocating plunger pump configured to pump a fracturing fluid and a powertrain configured to power the reciprocating plunger pump. The powertrain includes a prime mover and a drivetrain, the prime mover including a gas turbine engine. The hydraulic fracturing unit also includes auxiliary equipment configured to support operation of the hydraulic fracturing unit including the reciprocating plunger pump and the powertrain. A power system is configured to power the auxiliary equipment. The power system includes a power source and a power network. The power source is configured to generate power for the auxiliary equipment. The power network is coupled to the power source and the auxiliary equipment, and configured to deliver the power generated by the power source to the auxiliary equipment. Associated systems including a plurality of hydraulic fracturing units are also provided.
A mobile fracking system and methods may include a gas turbine housed at least partially inside a trailer and an exhaust attenuation system configured to receive exhaust gas from the gas turbine. The exhaust attenuation system may include a lower elongated plenum configured to receive exhaust gas from the gas turbine and an upper noise attenuation system that is movably connected relative to a distal end of the lower elongated plenum.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F01N 1/08 - Silencieux caractérisés par leur principe de fonctionnement réduisant l'énergie des gaz évacués par étranglement ou tourbillon
F01N 1/10 - Silencieux caractérisés par leur principe de fonctionnement réduisant l'énergie des gaz évacués par étranglement ou tourbillon en combinaison avec des matériaux absorbant le son
A pump system may include a pump, a driveshaft, driving equipment, and a vibration dampening assembly configured to reduce pump-imposed high frequency/low amplitude and low frequency/high amplitude torsional vibrations. The pump may have an input shaft connected to the driveshaft. The driving equipment may include an output shaft having an output flange connected to the driveshaft. The driving equipment may be configured to rotate the driveshaft to rotate the input shaft of the pump therewith. The vibration dampening assembly may include one or more flywheels operably connected to the input shaft and configured to rotate therewith.
F04B 53/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes ou ou présentant un intérêt autre que celui visé par ces groupes
F16F 15/121 - Suppression des vibrations dans les systèmes rotatifs par utilisation d'organes mobiles avec le système lui-même utilisant des organes élastiques ou des organes amortisseurs de friction, p. ex. entre un arbre en rotation et une masse giratoire montée dessus utilisant des ressorts comme organes élastiques, p. ex. des ressorts métalliques
Described herein are embodiments of systems and methods for the removal of a direct drive unit (DDU) housed in an enclosure, such as a direct drive turbine (DDT) connected to a gearbox for driving a driveshaft connected to a pump for use in a hydraulic fracturing operations.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F01D 15/08 - Adaptations pour la commande des pompes ou combinaisons avec celles-ci
F01D 25/28 - Dispositions pour le support ou le montage, p. ex. pour les carters de turbines
F02C 7/36 - Transmission de puissance entre les différents arbres de l'ensemble fonctionnel de turbine à gaz, ou entre ce dernier et l'utilisateur de puissance
F16H 57/02 - Boîtes de vitessesMontage de la transmission à l'intérieur
69.
FUEL, COMMUNICATIONS, AND POWER CONNECTION SYSTEMS AND RELATED METHODS
Embodiments of systems and methods for supplying fuel, enabling communications, and conveying electric power associated with operation of a hydraulic fracturing unit of a plurality of hydraulic fracturing units are disclosed and may include a fuel line connection assembly configured to be connected to the first hydraulic fracturing unit and to supply fuel from a fuel source to a gas turbine engine connected to the hydraulic fracturing unit. A system also may include a communications cable assembly configured to be connected to the hydraulic fracturing unit and to enable data communications between the hydraulic fracturing unit and a data center or another hydraulic fracturing unit. A system further may include a power cable assembly configured to be connected to the hydraulic fracturing unit and to convey electric power between the hydraulic fracturing unit and a remote electrical power source or the plurality of hydraulic fracturing units.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F01D 15/08 - Adaptations pour la commande des pompes ou combinaisons avec celles-ci
F02C 7/22 - Systèmes d'alimentation en combustible
F02C 7/232 - Soupapes pour combustibleSystèmes ou soupapes de drainage
F02C 7/236 - Systèmes d'alimentation en combustible comprenant au moins deux pompes
F02C 9/42 - Commande de l'alimentation en combustible spécialement adaptée à la commande simultanée d'au moins deux ensembles fonctionnels
G01M 3/26 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par mesure du taux de perte ou de gain d'un fluide, p. ex. avec des dispositifs réagissant à la pression, avec des indicateurs de débit
70.
MOBILE GAS TURBINE INLET AIR CONDITIONING SYSTEM AND ASSOCIATED METHODS
A system, as well as associated methods, for increasing the efficiency of a gas turbine including an inlet assembly and a compressor may include a housing configured to channel airstream towards the inlet assembly, an air treatment module positioned at a proximal end the housing, and at least one air conditioning module mounted downstream of the air treatment module for adjusting the temperature of the airstream entering the compressor. The air treatment module may include a plurality of inlet air filters and at least one blower configured to pressurize the air entering the air treatment module.
F02C 7/12 - Refroidissement des ensembles fonctionnels
F02M 35/00 - Épurateurs d'air comburant, tubulures d'admission de l'air, silencieux d'admission ou bien systèmes d'introduction spécialement adaptés pour moteurs à combustion interne ou aménagés pour ces moteurs
F24F 5/00 - Systèmes ou appareils de conditionnement d'air non couverts par ou
71.
METHODS AND SYSTEMS FOR SUPPLYING FUEL TO GAS TURBINE ENGINES
Methods and systems for supply of fuel for a turbine-driven fracturing pump system used in hydraulic fracturing may be configured to identify when the supply pressure of primary fuel to a plurality of gas turbine engines of a plurality of hydraulic fracturing units falls below a set point, identify a gas turbine engine of the fleet of hydraulic fracturing units operating on primary fuel with highest amount of secondary fuel available, and to selectively transfer the gas turbine engine operating on primary fuel with the highest amount of secondary fuel from primary fuel operation to secondary fuel operation. Some methods and systems may be configured to transfer all gas turbine engines to secondary fuel operation and individually and/or sequentially restore operation to primary fuel operation and/or to manage primary fuel operation and/or secondary fuel operation for portions of the plurality of gas turbine engines.
E21B 41/00 - Matériel ou accessoires non couverts par les groupes
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F02C 7/22 - Systèmes d'alimentation en combustible
F02C 9/40 - Commande de l'alimentation en combustible spécialement adaptée à l'utilisation d'un combustible particulier ou de plusieurs combustibles
F02C 9/42 - Commande de l'alimentation en combustible spécialement adaptée à la commande simultanée d'au moins deux ensembles fonctionnels
G01F 23/00 - Indication ou mesure du niveau des liquides ou des matériaux solides fluents, p. ex. indication en fonction du volume ou indication au moyen d'un signal d'alarme
G01L 13/00 - Dispositifs ou appareils pour la mesure des différences entre plusieurs valeurs de la pression des fluides
G05B 19/04 - Commande à programme autre que la commande numérique, c.-à-d. dans des automatismes à séquence ou dans des automates à logique
72.
FUEL, COMMUNICATIONS, AND POWER CONNECTION SYSTEMS AND RELATED METHODS
Embodiments of systems and methods for supplying fuel, enabling communications, and conveying electric power associated with operation of a hydraulic fracturing unit of a plurality of hydraulic fracturing units are disclosed and may include a fuel line connection assembly configured to be connected to the first hydraulic fracturing unit and to supply fuel from a fuel source to a gas turbine engine connected to the hydraulic fracturing unit. A system also may include a communications cable assembly configured to be connected to the hydraulic fracturing unit and to enable data communications between the hydraulic fracturing unit and a data center or another hydraulic fracturing unit. A system further may include a power cable assembly configured to be connected to the hydraulic fracturing unit and to convey electric power between the hydraulic fracturing unit and a remote electrical power source or the plurality of hydraulic fracturing units.
E21B 43/26 - Procédés pour activer la production par formation de crevasses ou de fractures
F01D 15/08 - Adaptations pour la commande des pompes ou combinaisons avec celles-ci
F02C 7/22 - Systèmes d'alimentation en combustible
F02C 7/232 - Soupapes pour combustibleSystèmes ou soupapes de drainage
F02C 7/236 - Systèmes d'alimentation en combustible comprenant au moins deux pompes
F02C 9/42 - Commande de l'alimentation en combustible spécialement adaptée à la commande simultanée d'au moins deux ensembles fonctionnels
G01M 3/26 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par mesure du taux de perte ou de gain d'un fluide, p. ex. avec des dispositifs réagissant à la pression, avec des indicateurs de débit
09 - Appareils et instruments scientifiques et électriques
Produits et services
Automated process control system comprised of logic based hardware and recorded software used to monitor the status of industrial machinery, namely, turbines, generators, compressors, blenders, and pumps for hydraulic fracturing fleet operations
04 - Huiles et graisses industrielles; lubrifiants; combustibles
07 - Machines et machines-outils
Produits et services
(1) Oil and gas well stimulation equipment, namely, high-pressure fracturing pumps for use in oil or gas well hydraulic fracturing operations, slurry fracturing blender machines for use in oil or gas well hydraulic fracturing operations, and dry-on-the-fly units for use in oil or gas well hydraulic fracturing operations; oil and gas well equipment for hydraulic fracturing of oil and gas wells, namely, a mobile oil and gas well stimulation system having a rotary mechanical engine to generate electric power for hydraulic fracturing and a coupled fluid pump for supplying fracturing fluid to oil and gas wells
37 - Services de construction; extraction minière; installation et réparation
Produits et services
(1) Oil and gas well stimulation services, namely, hydraulic fracturing; oil and gas well stimulation services, namely, hydraulic fracturing services by supplying fracturing fluid to oil and gas wells using mobile modules having a rotary mechanical engine to generate electric power of hydraulic fracturingand a coupled fluid pump
Oil and gas well stimulation equipment in the nature of equipment for hydraulic fracturing of oil and gas wells, namely, high-pressure fracturing pumps for use in oil or gas well hydraulic fracturing operations, slurry fracturing blender machines for use in oil or gas well hydraulic fracturing operations, and dry-on-the-fly units for use in oil or gas well hydraulic fracturing operations; oil and gas well equipment for hydraulic fracturing of oil and gas wells, namely, a mobile oil and gas well stimulation system comprised of a rotary mechanical engine to generate electric power for hydraulic fracturing, compressor, controller, fuel lines, power lines, data communications lines and fluid pumps for supplying fracturing fluid to oil and gas wells
77.
BAFFLE SYSTEM FOR FLOWING PARTICULATES INTO A FRAC FLUID BLENDER
The density of slurries produced by mobile blender for injection into oil and gas wells is controlled using a microwave flow meter. Liquid having a known density is provided to the blender. The liquid is flowed through a conduit and discharged into a blending tub on the mobile blender. The amount of liquid introduced into the tub is measured with a liquid flow meter. Solid particulates having a known density are provided to the blender. The particulates are discharged into the tub by allowing them to fall into the tub from a conveyor on the mobile blender. The amount of the particulates falling into the tub are measured with a microwave flow meter. The flow of the liquid and the particulates are controlled in response to the measurements to blend a slurry having a predetermined density. The slurry is provided for injection into the well.
Frac pumps have valve bodies. The valve bodies comprise a head and a compressible seal. The head provides a valve surface adapted to engage the valve seat. The compressible seal is carried on the head radially inward of the valve surface and is adapted to engage the valve seat. It is mounted between the head and a valve guide having a plurality of legs. The face of the compressible seal has a slightly curved, convex sealing surface.
F04B 15/02 - Pompes adaptées pour travailler avec des fluides particuliers, p. ex. grâce à l'emploi de matériaux spécifiés pour la pompe elle-même ou certaines de ses parties les fluides étant visqueux ou non homogènes
Frac pumps have valve seats and bodies. The valve seats comprise a cylindrical body and an annular seat surface. The body has an axial passage and external threads adapted to engage internal threads in a fluid end block of the frac pump. The annular seat surface is at an end of the body and is adapted to engage a valve body. The valve bodies comprise a head and a compressible seal. The head provides a valve surface adapted to engage the valve seat. The compressible seal is carried on the head radially inward of the valve surface and is adapted to engage the valve seat.
E21B 43/12 - Procédés ou appareils pour commander l'écoulement du fluide extrait vers ou dans les puits
F04B 1/0452 - Organes de distribution, p. ex. soupapes
F04B 1/053 - "Machines" ou pompes multicylindres caractérisées par le nombre ou la disposition des cylindres ayant des cylindres disposés en étoile ou en éventail avec des éléments actionnants ou actionnés aux extrémités intérieures des cylindres
F04B 1/0538 - "Machines" ou pompes multicylindres caractérisées par le nombre ou la disposition des cylindres ayant des cylindres disposés en étoile ou en éventail avec des éléments actionnants ou actionnés aux extrémités intérieures des cylindres avec plusieurs ensembles piston-cylindre radiaux montés en série situés côte à côte
01 - Produits chimiques destinés à l'industrie, aux sciences ainsi qu'à l'agriculture
Produits et services
(1) Chemical polymeric additives for fracturing fluids, namely, polymer x-linked fluids; unprocessed polymers, namely, polymer fluids in the used in fracturing fluid for use in oil and gas operations.
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Software for reservoir characterization, completion and fracturing design optimization in the oil and gas industry. (1) Providing online, non-downloadable software for reservoir characterization, completion and fracturing design optimization in the oil and gas industry.
An embodiment includes a method of monitoring a fluid pump that includes receiving time domain measurement data indicating vibrations occurring in a fluid pump, and filtering the measurement data to remove measurement data components having frequencies below a threshold frequency, the removed measurement data components associated with cyclical motions of the fluid pump. The method also includes dividing the filtered measurement data into a plurality of subsets, each subset corresponding to a pump cycle, and estimating a peak count for each subset, the peak count being a number of peaks having an amplitude that exceeds a selected amplitude threshold, the amplitude threshold associated with impacts between internal components of the pump. The method further includes comparing the peak count with an expected peak count, and determining whether the pump is in a condition selected from at least one of a wear condition and a failure condition based on the comparison.
E21B 43/12 - Procédés ou appareils pour commander l'écoulement du fluide extrait vers ou dans les puits
F04B 47/06 - Pompes ou installations de pompage spécialement adaptées pour élever un fluide à partir d'une grande profondeur, p. ex. pompes de puits dont les ensembles pompe-moteur sont placés à grande profondeur
F04B 51/00 - Tests des "machines", pompes ou installations de pompage
F04D 27/00 - Commande, p. ex. régulation, des pompes, des installations ou des systèmes de pompage spécialement adaptés aux fluides compressibles
G01H 17/00 - Mesure des vibrations mécaniques ou des ondes ultrasonores, sonores ou infrasonores non prévue dans les autres groupes de la présente sous-classe
01 - Produits chimiques destinés à l'industrie, aux sciences ainsi qu'à l'agriculture
Produits et services
Chemical polymeric additives for fracturing fluids, namely, polymer x-linked fluids; unprocessed polymers, namely, polymer fluids in the used in fracturing fluid for use in oil and gas operations
