A refrigerator door has an inner surface that faces rearward toward an interior compartment of the refrigerator and a front, outer surface opposite the inner surface. A peripheral edge surface of the door is disposed between the inner and outer surfaces. A pocket handle extends along at least a portion of the peripheral edge surface of the door, where the pocket handle defines a recessed surface. A handle assembly includes a mounting portion that is attached to the recessed surface of the pocket handle. The mounting portion extends forward and supports a handle portion at a spaced distance forward from the outer surface of the door.
A refrigerator includes an automatic filing water storage system. The refrigerator includes a cabinet having a fresh-food compartment and a door pivotally mounted to the cabinet. The system includes a dispenser positioned in the fresh-food compartment and a docking base positioned in one of the fresh-food compartment and the door. A container is configured to be supported by the docking base. In a docked position and when the door is in a closed position, the dispenser is configured to selectively dispense liquid into the container based upon a sensed fill level condition. When the door is in an open position, the dispenser is configured to dispense liquid based upon engagement of an actuator by a user.
F25D 23/12 - Aménagements des compartiments annexes aux compartiments de refroidissementRéfrigérateurs combinés avec un autre appareil, p. ex. une cuisinière
A refrigerator includes a water dispenser and a liquid storage receptacle configured to be automatically filled via the water dispenser. The liquid storage receptacle includes a dispenser for opening a fluid channel between the liquid storage receptacle and a fluid container while the liquid storage receptacle is provided in the refrigerator. The liquid storage receptacle is provided in a docking base for supporting the receptacle in the refrigerator. The dispenser is integrated into the docking base and engages an opening in the receptacle which may be selectively opened by the dispenser.
F25D 23/12 - Aménagements des compartiments annexes aux compartiments de refroidissementRéfrigérateurs combinés avec un autre appareil, p. ex. une cuisinière
09 - Appareils et instruments scientifiques et électriques
Produits et services
Televisions; Television monitors; Television monitors with television tuners; Television receivers; Television sets; Television tuners; Televisions and monitors; TV monitors; Ultra high definition televisions; Video monitors; Video receivers; Video screens; HD (High Definition) televisions; High definition televisions (HDTVs); Internet-ready televisions; Smart televisions
In a liquid crystal display module, notches are disposed on limiting sections and opposite to flexible circuit boards disposed on a liquid crystal panel so that the flexible circuit boards protrude through the notches and are bent toward the connecting sections; and moreover first depressed sections configured to accommodate the flexible circuit boards may be disposed on the connecting sections and opposite to the notches; and second depressed sections depressed inward may be disposed on the folded edge and opposite to the first depressed sections so that the first depressed sections and the second depressed sections cooperate with each other.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Television monitors; Television monitors with television tuners; Television sets; Video receivers; Video screens; Audio-video receivers; High definition televisions; Internet-ready televisions; Liquid crystal display (LCD) televisions; Plasma televisions; Ultra high definition televisions; Video monitors; Cell phones; computer programs, downloadable.
The present application discloses a dual-color laser light projection device, wherein the dual-color laser light projection device includes a first blue laser transmitter, a second blue laser transmitter, a red laser transmitter, a light combining component, a fluorescent wheel, a light-pipe; wherein the fluorescent wheel comprises a green fluorescent region provided with a green fluorescent powder and a transmission region, and wherein the green fluorescent region is excited by a first blue laser emitted from the first blue laser transmitter to generates green fluorescence. The light path system of the present application is simple and has a small volume.
H04N 9/31 - Dispositifs de projection pour la présentation d'images en couleurs
G02B 27/18 - Systèmes ou appareils optiques non prévus dans aucun des groupes , pour projection optique, p. ex. combinaison de miroir, de condensateur et d'objectif
G02B 27/10 - Systèmes divisant ou combinant des faisceaux
G02B 27/48 - Systèmes optiques utilisant la granulation produite par laser
G03B 33/08 - Enregistrement ou projection subséquents
F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
G02B 6/42 - Couplage de guides de lumière avec des éléments opto-électroniques
G02B 26/00 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables
G02B 27/14 - Systèmes divisant ou combinant des faisceaux fonctionnant uniquement par réflexion
10.
Laser array, laser light source and laser projection device
A laser array including at least one line of lasers. The at least one line of lasers includes a first laser and a second laser which are adjacent to each other. A first laser beam emitted by the first laser and a second laser beam emitted by the second laser are both in a first color, and the first laser beam has a wavelength less than that of the second laser beam.
H04N 9/31 - Dispositifs de projection pour la présentation d'images en couleurs
H01L 25/075 - Ensembles consistant en une pluralité de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide les dispositifs étant tous d'un type prévu dans une seule des sous-classes , , , , ou , p. ex. ensembles de diodes redresseuses les dispositifs n'ayant pas de conteneurs séparés les dispositifs étant d'un type prévu dans le groupe
H01S 5/40 - Agencement de plusieurs lasers à semi-conducteurs, non prévu dans les groupes
G02B 27/48 - Systèmes optiques utilisant la granulation produite par laser
H01S 5/024 - Dispositions pour la gestion thermique
H01S 5/42 - Réseaux de lasers à émission de surface
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
Disclosed is a device for editing channels of a smart TV. The device includes a memory and at least one processor, wherein the memory stores therein computer readable instructions, wherein the instructions are executed by the at least one processor to enable the at least one processor to: receive an interface calling up instruction, and displaying a channel editing list and an operation prompt on a display screen of the smart TV; receive a channel selecting instruction, and determine a channel to be edited in the channel editing list according to the channel selecting instruction; and receive a channel edit instruction, and edit the channel to be edited according to the channel editing instruction, wherein the operation prompt is configured to remind a user that the channel editing instruction is triggered by using a left arrow key or right arrow key of a remote control, and the channel editing instruction is an instruction indicating deletion or a move of the channel to be edited. Also disclosed are a smart TV, and a method for editing channels of a smart TV.
H04N 21/431 - Génération d'interfaces visuellesRendu de contenu ou données additionnelles
H04N 21/482 - Interface pour utilisateurs finaux pour la sélection de programmes
H04N 21/485 - Interface pour utilisateurs finaux pour la configuration du client
H04N 21/475 - Interface pour utilisateurs finaux pour acquérir des données d'utilisateurs finaux, p. ex. numéro d'identification personnel [PIN] ou données de préférences
12.
Method and apparatus for capturing screen on mobile device
Hisense Mobile Communications Technology Co., Ltd. (Chine)
Hisense USA Corporation (USA)
Hisense International Co., Ltd. (Chine)
Inventeur(s)
Yu, Deyi
Abrégé
Embodiments of the disclosure provide a method and an apparatus for capturing a screen on a mobile device, the method including: receiving, at the mobile device, a screen-capturing request for a current interface, where the current interface includes first data, and the first data includes personal information; and generating, according to screen-capturing request, a screen capture image for the current interface, where the first data in the current interface is replaced in the screen capture image with second data which is predefined. These embodiments avoid the need to manually mask an image by starting a dedicated image editing tool to anonymize a screen capture image, thereby significantly lowering the relatively high technical threshold of anonymization processing, reducing the error rate, and improving the modification quality of anonymization. Moreover, the replacement is directly made to the image while the screen is captured without interfering with normal use of reading.
G06F 17/20 - Manipulation de données en langage naturel
G06F 21/62 - Protection de l’accès à des données via une plate-forme, p. ex. par clés ou règles de contrôle de l’accès
G06F 3/0484 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] pour la commande de fonctions ou d’opérations spécifiques, p. ex. sélection ou transformation d’un objet, d’une image ou d’un élément de texte affiché, détermination d’une valeur de paramètre ou sélection d’une plage de valeurs
13.
Methods and devices for display device notifications and key handling
The present disclosure relates to methods and devices for presentation of display device notifications and key handling. The notifications are visually appealing, employing a common theme and user interface. The notifications are less-intrusive, such that the user experience is improved. The notifications can provide additional information, function as links to destinations, and give the user multiple options, from which the user can make a selection. Actions taken by a user can be controlled and monitored to optimize user interaction with the notifications. By providing display device notifications to a user, the user is able to process important information on a display device in an improved way.
H04L 29/08 - Procédure de commande de la transmission, p.ex. procédure de commande du niveau de la liaison
G06F 3/0482 - Interaction avec des listes d’éléments sélectionnables, p. ex. des menus
G06F 3/0484 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] pour la commande de fonctions ou d’opérations spécifiques, p. ex. sélection ou transformation d’un objet, d’une image ou d’un élément de texte affiché, détermination d’une valeur de paramètre ou sélection d’une plage de valeurs
G06F 3/0485 - Défilement ou défilement panoramique
H04L 12/24 - Dispositions pour la maintenance ou la gestion
G06F 3/0488 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] utilisant des caractéristiques spécifiques fournies par le périphérique d’entrée, p. ex. des fonctions commandées par la rotation d’une souris à deux capteurs, ou par la nature du périphérique d’entrée, p. ex. des gestes en fonction de la pression exercée enregistrée par une tablette numérique utilisant un écran tactile ou une tablette numérique, p. ex. entrée de commandes par des tracés gestuels
G06F 3/0481 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] fondées sur des propriétés spécifiques de l’objet d’interaction affiché ou sur un environnement basé sur les métaphores, p. ex. interaction avec des éléments du bureau telles les fenêtres ou les icônes, ou avec l’aide d’un curseur changeant de comportement ou d’aspect
G06F 3/01 - Dispositions d'entrée ou dispositions d'entrée et de sortie combinées pour l'interaction entre l'utilisateur et le calculateur
G06F 3/14 - Sortie numérique vers un dispositif de visualisation
G09G 5/00 - Dispositions ou circuits de commande de l'affichage communs à l'affichage utilisant des tubes à rayons cathodiques et à l'affichage utilisant d'autres moyens de visualisation
H04N 21/458 - Ordonnancement de contenu pour créer un flux personnalisé, p. ex. en combinant une publicité stockée localement avec un flux d'entréeOpérations de mise à jour, p. ex. pour modules de système d'exploitation
H04N 21/482 - Interface pour utilisateurs finaux pour la sélection de programmes
H04N 21/488 - Services de données, p. ex. téléscripteur d'actualités
H04N 21/4402 - Traitement de flux élémentaires vidéo, p. ex. raccordement d'un clip vidéo récupéré d'un stockage local avec un flux vidéo en entrée ou rendu de scènes selon des graphes de scène du flux vidéo codé impliquant des opérations de reformatage de signaux vidéo pour la redistribution domestique, le stockage ou l'affichage en temps réel
H04N 21/442 - Surveillance de procédés ou de ressources, p. ex. détection de la défaillance d'un dispositif d'enregistrement, surveillance de la bande passante sur la voie descendante, du nombre de visualisations d'un film, de l'espace de stockage disponible dans le disque dur interne
H04N 21/45 - Opérations de gestion réalisées par le client pour faciliter la réception de contenu ou l'interaction avec le contenu, ou pour l'administration des données liées à l'utilisateur final ou au dispositif client lui-même, p. ex. apprentissage des préférences d'utilisateurs pour recommander des films ou résolution de conflits d'ordonnancement
H04L 12/28 - Réseaux de données à commutation caractérisés par la configuration des liaisons, p. ex. réseaux locaux [LAN Local Area Networks] ou réseaux étendus [WAN Wide Area Networks]
A dual-color projector is disclosed that includes a blue laser device configured to emit a blue laser light, a red laser device configured to emit a red laser light, and a fluorescent wheel whose surface is coated with green fluorescent powder which is excitable by the blue laser light to emit a green fluorescent light. The dual-color projector may also include a first diffusion element and a second diffusion element.
One or more embodiments of the present application disclose a backlight source control method of a display device, the display device and a storage medium. The method includes: determining a display subregion corresponding to a backlight source to be turned off; determining a first backlight source brightness value of an adjacent display subregion of the display subregion corresponding to the backlight source to be turned off; lowering the first backlight source brightness value to obtain a second backlight source brightness value; and setting the backlight source brightness value corresponding to the adjacent display subregion to be the second backlight source brightness value.
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
H04N 5/445 - Circuits de réception pour visualisation d'information additionnelle
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
H04N 21/488 - Services de données, p. ex. téléscripteur d'actualités
An adjusting device for a light-pipe includes an outer tube, a rotatable ball, an inner tube and an adjustment member. The inner tube is configured to accommodate the light-pipe. The outer tube comprises a first end and a second end disposed oppositely, and a receiving cavity constructed to receive the rotatable ball is formed in the first end of the outer tube. The rotatable ball is hinged in the receiving cavity, and a through-hole is opened in the rotatable ball. One end of the inner tube is fixedly connected to the through-hole, and the other end is disposed inside the second end of the outer tube through the adjustment member. The adjustment member is configured to drive the inner tube to swing along the center of the rotatable ball within the outer tube.
A laser array including at least one line of lasers. The at least one line of lasers includes a first laser and a second laser which are adjacent to each other. A first laser beam emitted by the first laser and a second laser beam emitted by the second laser are both in a first color, and the first laser beam has a wavelength less than that of the second laser beam.
H01S 5/024 - Dispositions pour la gestion thermique
H01S 5/42 - Réseaux de lasers à émission de surface
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
A color wheel includes a base substrate and at least one fluorescent block. The base substrate includes a first annular portion and a second annular portion. The at least one fluorescent block is arranged on the first annular portion. The fluorescent block is configured to emit fluorescent light in a predetermined wavelength band after being irradiated with a laser beam. The second annular portion includes at least one color filtering portion, and the color filtering portion is configured to filter the fluorescent light. An inner circumference of the second annular portion is not smaller than an outer circumference of the first annular portion, or an outer circumference of the second annular portion is not larger than an inner circumference of the first annular portion.
This disclosure relates to the field of projection display technologies, and discloses a projection system and a projection screen supporting device, the projection system including a projection screen and a projection device, and further a projection screen supporting device, the projection screen being installed on a bracket body of the projection screen supporting device, where the projection screen supporting device includes the bracket body, a supporting assembly, and a projection screen hanging assembly; the bracket body includes a first standing pole and a second standing pole, both of which are arranged substantially parallel to each other; the supporting assembly is fixed on the bracket body to support the bracket body; and the projection screen hanging assembly is arranged on the bracket body, at an adjustable position in the direction in which the first standing pole and the second standing pole extend, to hang a projection screen on the bracket body.
F16M 11/04 - Moyens pour la fixation des appareilsMoyens permettant le réglage des appareils par rapport au banc
F16M 11/22 - Infrastructure avec ou sans roues à hauteur sensiblement constante, p. ex. avec colonne ou pieds de longueur constante
F16M 13/02 - Autres supports ou appuis pour positionner les appareils ou les objetsMoyens pour maintenir en position les appareils ou objets tenus à la main pour être portés par un autre objet ou lui être fixé, p. ex. à un arbre, une grille, un châssis de fenêtre, une bicyclette
F16M 11/18 - Têtes des supports avec mécanisme déplaçant les appareils par rapport au banc
20.
System and method for digital television operation and control-contextual interface
The present disclosure relates to digital television processes and systems. In one embodiment, a method of controlling a display device includes presenting, by a display device, display content. The display device can identify content titles associated with the display content, detection selection of a command, present a contextual overlay representation including content elements, detect a selection of the content overlay, and update presentation of the display device based on the selection of the content overlay.
H04N 21/431 - Génération d'interfaces visuellesRendu de contenu ou données additionnelles
H04N 21/45 - Opérations de gestion réalisées par le client pour faciliter la réception de contenu ou l'interaction avec le contenu, ou pour l'administration des données liées à l'utilisateur final ou au dispositif client lui-même, p. ex. apprentissage des préférences d'utilisateurs pour recommander des films ou résolution de conflits d'ordonnancement
H04N 21/422 - Périphériques d'entrée uniquement, p. ex. système de positionnement global [GPS]
H04N 21/466 - Procédé d'apprentissage pour la gestion intelligente, p. ex. apprentissage des préférences d'utilisateurs pour recommander des films
H04N 21/482 - Interface pour utilisateurs finaux pour la sélection de programmes
HISENSE MOBILE COMMUNICATIONS TECHNOLOGY CO., LTD. (Chine)
HISENSE INTERNATIONAL CO., LTD. (Chine)
HISENSE USA CORPORATION (USA)
Inventeur(s)
Zheng, Weibo
Geng, Bingyu
Abrégé
The disclosure provides a noise reduction method and an electronic device. In an embodiment of the disclosure, when determining that a plurality of first applications occupy a plurality of first audio channels connected with a microphone and a second application occupies a second audio channel connected with a speaker, the electronic device resamples the audio data of the second audio channel according to the sampling rates corresponding to the plurality of first audio channels and then performs the noise reduction processing on the audio data of each of the plurality of first audio channels respectively according to the audio data obtained by resampling.
HISENSE MOBILE COMMUNICATIONS TECHNOLOGY CO., LTD. (Chine)
HISENSE USA CORPORATION (USA)
HISENSE INTERNATIONAL CO., LTD. (Chine)
Inventeur(s)
Jiang, Peng
Yang, Xing
He, Qi
Abrégé
The present disclosure provides a mobile terminal and a method for filling light for same, and relates to the field of electronic technologies. The method includes: upon receiving an activating instruction for a target camera, activating the target camera; displaying an image acquired by the target camera on a display screen which is located on a surface different from a surface where the target camera is located; detecting brightness of present ambient light, and in response to that the brightness of the present ambient light is less than a preset brightness threshold, illuminating the display screen on the same surface where the target camera is located.
An optical module includes a laser transmitter driver chip, a Distributed Bragg reflection (DBR) raster, a laser transmitter, a first resistor, a first capacitor, a second resistor, a second capacitor and a power source. The first resistor is connected between a power source and a differential signal output positive terminal of the laser transmitter; the first capacitor is connected between the differential signal output positive terminal and the a positive terminal of the laser transmitter; the second resistor is connected between the power source and a differential signal output negative terminal of the laser transmitter driver chip; the second capacitor is connected between the differential signal output negative terminal and a negative terminal of the laser transmitter; and the negative terminal of the laser transmitter and a negative terminal of the DBR raster are grounded.
H01S 5/0625 - Dispositions pour commander les paramètres de sortie du laser, p. ex. en agissant sur le milieu actif en faisant varier le potentiel des électrodes dans des lasers à plusieurs sections
QINGDAO HISENSE HITACHI AIR-CONDITIONING SYSTEMS CO., LTD. (Chine)
HISENSE USA CORPORATION (USA)
HISENSE INTERNATIONAL CO., LTD. (Chine)
Inventeur(s)
Liu, Min
Wang, Yuanpeng
Zhang, Wenqiang
Cao, Rui
Li, Yajun
Li, Yongmei
Abrégé
A heat recovery variable-frequency multi-split heat pump system and a control method thereof. The system includes an outdoor unit and at least two indoor units. The system is a three-pipe heating recovery multi-split heat pump system designed on the basis of a four-way reversing valve, and one indoor unit thereof is provided with two electronic expansion valves and two heat exchangers so that any indoor unit in the system can operate independently under three working conditions of refrigeration, heating or heat recovery dehumidification. Under multi-split condition, the system can operate under six working conditions, namely, the full-refrigeration working condition, the full-heating working condition, the common-heat-recovery working condition, the common-heat-recovery-dehumidification working condition, the heat recovery dehumidification-refrigeration-combination working condition and the heat recovery dehumidification-heating-combination working condition. Under the heat recovery dehumidification condition, a lower outlet air temperature, during low-temperature dehumidification, is raised by means of heat removal of a condenser so as to achieve the purpose of dehumidification without temperature fall or temperature rise, so that the thermal comfort and efficiency of the system are improved, and the refrigerating capacity and heating capacity of the system are effectively improved.
F25B 43/02 - Dispositions pour la séparation ou la purification des gaz ou des liquidesDispositions pour la vaporisation des résidus de fluides frigorigènes, p. ex. par la chaleur pour la séparation des lubrifiants du frigorigène
F25B 41/34 - Soupapes de détente l’organe de soupape étant actionné par des moyens électriques, p. ex. par des actionneurs piézo-électriques
F25B 41/385 - Dispositions avec plusieurs moyens de détente disposés en parallèle sur une conduite de réfrigérant menant au même évaporateur
The light source device includes a laser for generating laser light, a fluorescent wheel, a filter wheel and a control unit. The fluorescent wheel includes a reflection section, and a transmission section. First and second phosphors are attached on a surface of the reflection section, and the first phosphor is excited by the laser light to emit yellow light and the second phosphor is excited by the laser light to emit green light. The filter wheel comprises a transparent section, a red filter section and a green filter section. The control unit controls the fluorescent wheel and the filter wheel to rotate in synchronization. the laser light emitted from the transmission section of the fluorescent wheel and a part of the yellow light enter into the transparent section, another part of the yellow light enter into the red filter section, and the green light enter into the green filter section.
Embodiments of the disclosure provide a method and apparatus for controlling a startup bootstrap program of an intelligent TV set, and relate to the field of an embedded system so as to shorten a period of time for startup boot while initializing a screen normally. In the disclosure, after a system is powered on, a first task of initializing a screen in a startup bootstrap program is executed, and the length of preset time required for executing the first task is obtained, wherein the startup bootstrap program is a bootstrap program for initializing pieces of software/hardware of the system; executing a second initialization task unrelated to initializing the screen in the startup bootstrap program is executed while the first task is being executed, thus addressing the problem in the related art.
The present disclosure relates to device control and multiple input event handling. In one embodiment, a process includes detecting a plurality of input commands for control of a display device, determining a multiple input event based on the plurality of input commands, and determining a multiple input control function for the display device based on the multiple input event. The multiple input control function is determined based on input type of the multiple input event and a function of the input type of the multiple input event. The process can also includes controlling operation of the display device based on the multiple input control function, wherein controlling includes modifying display device operation from a control function associated with the plurality of input commands to a multiple input event control function.
The disclosure provides an optical module that includes a circuit board, a first chip, a second chip, and a lens assembly, wherein the first chip and the second chip are arranged respectively on the surface of the circuit board, and the lens assembly is arranged above the first chip and the second chip; the lens assembly includes a first optic fiber insertion port, a second optic fiber insertion port, a first reflecting surface, and a second reflecting surface; the distance between the axis of the first optic fiber insertion port, and the axis of the second optic fiber insertion port is less than the distance between the first chip and the second chip; and the first reflecting surface faces the first chip, the first reflecting surface faces the second reflecting surface, and the second reflecting surface faces the first optic fiber insertion port.
This present disclosure relates to the field of display technologies and provides an edge-lit backlight module and a liquid crystal display device. The edge-lit backlight module of the present disclosure includes a light source, a light guide panel and a reflector. The light source is arranged on a light entering side of the light guide panel, and the reflector is arranged below the light guide panel, a bottom surface of the light guide panel faces towards the reflector, and a plurality of dots are arranged on the bottom surface at intervals. The reflector is bonded on the bottom surface of the light guide panel through a glue layer, and the glue layer is provided with light transmission holes at positions of the dots.
The DMD assembly in present disclosure includes a base mounted on a first side of a driver board; a chip substrate; a DMD chip mounted on the chip substrate; and a fixing frame fixed with driver board on the first side; a second side of the base includes a mounting groove configured to mount the chip substrate; the fixing frame includes an insertion hole, and the base is received in the insertion hole; an elastic protrusion is positioned beside the inserting hole, and the elastic protrusion comprises a fixing portion and a pressing portion, the fixing portion is connected to the fixing frame on a side of the fixing frame facing away from the driver board, the pressing portion is positioned on the fixing portion; a surface of the pressing portion facing the chip substrate contacts the chip substrate to clamp the chip substrate against the base.
G03B 21/16 - RefroidissementPrévention de la surchauffe
G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière
G03B 21/00 - Projecteurs ou visionneuses du type par projectionLeurs accessoires
G03B 21/14 - Projecteurs ou visionneuses du type par projectionLeurs accessoires Détails
G02B 7/00 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques
H04N 9/31 - Dispositifs de projection pour la présentation d'images en couleurs
H01L 23/40 - Supports ou moyens de fixation pour les dispositifs de refroidissement ou de chauffage amovibles
G02B 7/18 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour prismesMontures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour miroirs
Disclosed are a voice control method, device and terminal, and the method includes: after a terminal has been triggered into voice control mode, receiving input voice data and obtaining corresponding speech text according to the voice data; matching the speech text with an interface word list corresponding to a current operating interface, wherein the interface word list includes text information of the current operating interface; in response to determining that the speech text matches an interface word list successfully, obtaining in the current operating interface an operation link which corresponds to the speech text; and performing an operation corresponding to the operation link.
G10L 15/22 - Procédures utilisées pendant le processus de reconnaissance de la parole, p. ex. dialogue homme-machine
G10L 15/18 - Classement ou recherche de la parole utilisant une modélisation du langage naturel
G10L 25/51 - Techniques d'analyse de la parole ou de la voix qui ne se limitent pas à un seul des groupes spécialement adaptées pour un usage particulier pour comparaison ou différentiation
An optical module includes a housing, a circuit board, a connecting finger and a reflector. The circuit board is provided inside the housing. The connecting finger is provided on the circuit board. The reflector is provided between the circuit board and the housing, and is located between the connecting finger and an optical port of the optical module. The reflector is configured to reflect electromagnetic waves radiated onto a surface of the reflector.
Disclosed are a method for querying information of a TV program broadcasted currently and a smart TV, to solve the problem that the descriptive information of a TV program broadcasted currently displayed by the smart TV doesn't match the actual video image broadcasted. The method comprises: obtaining a program information list corresponding to a channel identification from an EPG server according to the channel identification of a channel broadcasted currently, where the program information list includes correspondence between program identifications and program descriptive information; after obtaining a real time video stream from a program source server corresponding to the channel identification, parsing and obtaining a program identification in the real-time video stream; and obtaining program descriptive information corresponding to the program identification from the correspondence.
G06F 3/00 - Dispositions d'entrée pour le transfert de données destinées à être traitées sous une forme maniable par le calculateurDispositions de sortie pour le transfert de données de l'unité de traitement à l'unité de sortie, p. ex. dispositions d'interface
G06F 13/00 - Interconnexion ou transfert d'information ou d'autres signaux entre mémoires, dispositifs d'entrée/sortie ou unités de traitement
H04N 5/445 - Circuits de réception pour visualisation d'information additionnelle
H04N 21/262 - Ordonnancement de la distribution de contenus ou de données additionnelles, p. ex. envoi de données additionnelles en dehors des périodes de pointe, mise à jour de modules de logiciel, calcul de la fréquence de transmission de carrousel, retardement de la transmission de flux vidéo, génération de listes de reproduction
H04N 21/231 - Opération de stockage de contenu, p. ex. mise en mémoire cache de films pour stockage à court terme, réplication de données sur plusieurs serveurs, ou établissement de priorité des données pour l'effacement
H04N 21/44 - Traitement de flux élémentaires vidéo, p. ex. raccordement d'un clip vidéo récupéré d'un stockage local avec un flux vidéo en entrée ou rendu de scènes selon des graphes de scène du flux vidéo codé
H04N 21/24 - Surveillance de procédés ou de ressources, p. ex. surveillance de la charge du serveur, de la bande passante disponible ou des requêtes effectuées sur la voie montante
H04N 21/266 - Gestion de canal ou de contenu, p. ex. génération et gestion de clés et de messages de titres d'accès dans un système d'accès conditionnel, fusion d'un canal de monodiffusion de VOD dans un canal multidiffusion
H04N 21/84 - Génération ou traitement de données de description, p. ex. descripteurs de contenu
H04N 21/61 - Structure physique de réseauTraitement de signal
34.
Method of driving dynamic backlight and display device
The embodiments of the disclosure discloses a method of driving a dynamic backlight and a display device. In this method, a vertical synchronization signal corresponding to an input image signal is received; a first level signal and a second level signal are outputted alternately in response to a change edge of the vertical synchronization signal, where the total duration of the first level signal and the second level signal is 1/m of the duration between the change edge and a first change edge before the change edge, wherein the change edge and the first change edge before the change edge are change edges of a same changing direction; m is a positive integer; and the drive chip receives the first level signal and the second level signal and generates a PWM signal according to the first level signal and the second level signal.
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
The disclosure discloses an optical module, and relates to the field of optic fiber communications. A circuit according to an embodiment of the disclosure includes: a chip, which includes at least one wiring side, and on which there are arranged first signal interface pads arranged parallel to the wiring side; a circuit board on which there are arranged a number of second signal interface pads corresponding to the first signal interface pads, wherein at least two of the distances between the respective second signal interface pads and the wiring side are different from each other; and signal wires configured to connect the corresponding first signal interface pads and second signal interface pads.
Hisense Mobile Communications Technology Co., Ltd. (Chine)
HISENSE USA CORP. (USA)
Hisense International Co., Ltd. (Chine)
Inventeur(s)
Yin, Yanyan
Wang, Haiying
Abrégé
A method of answering an incoming call on a dual-screen mobile device comprising a main body, and two screens and two sound openings which are respectively located on two opposite surfaces of the main body is provided. The method includes: upon receiving an incoming call, an incoming call operation option is displayed on a first screen of the dual-screen mobile, an answer option is determined based on an answer operation which is performed by a user in response to the incoming call operation option, where the answer option includes answering on a second screen opposite to the first screen, and a sound of the incoming call is output from the sound opening on the surface where the second screen is located in response to that the answer option indicates answering on the second screen.
HISENSE MOBILE COMMUNICATIONS TECHNOLOGY CO., LTD. (Chine)
HISENSE USA CORPORATION (USA)
HISENSE INTERNATIONAL CO., LTD. (Chine)
Inventeur(s)
Ding, Chao
Abrégé
A method includes processing a plurality of descriptors received from an electronic device. Each descriptor corresponds to a function of the electronic device. The processing includes determining a virtual function device corresponding to execution of at least one function based on a successful matching of one or more of the received descriptors with one or more driver files corresponding to at least one of the plurality of functions. The method also includes communicating an operating command to the virtual function device corresponding to execution of the at least one function based on an indication that the at least one function is to be executed. The operating command causes the virtual function device corresponding to execution of the at least one function to be operated on the electronic device. Two or more functions of the plurality of functions associated with different resources of the electronic device are selectable for execution.
The application provides a printed circuit board and an optical module so as to alleviate poor contact between the electro-conductive contact sheet group and the clamping piece due to the solder resist. The printed circuit board includes a substrate, and electro-conductive contact sheet group positioned on the surface of the substrate, where a part of the substrate is overlaid with solder resist, and there is a gap between the solder resist and the electro-conductive contact sheet group.
A laser light source is provided. The laser light source includes: a laser device; a first color wheel and a second color wheel, on both of which there are corresponding color regions, wherein the laser device emits laser which illuminates the first color wheel and the second color wheel sequentially, and exits from the color regions on the second color wheel; a first marker and a second marker arranged respectively on the first and the second color wheels; a first sensor configured to detect the first marker, and to generate a first sense signal; a second sensor configured to detect the second marker, and to generate a second sense signal; and a control unit configured to synchronize the first color wheel and the second color wheel.
G03B 21/14 - Projecteurs ou visionneuses du type par projectionLeurs accessoires Détails
H04N 9/31 - Dispositifs de projection pour la présentation d'images en couleurs
F21V 9/45 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres avec des dispositions pour commander les propriétés spectrales, p. ex. la couleur, ou l’intensité en ajustant des éléments photoluminescents
F21V 9/08 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres pour produire une lumière colorée, p. ex. monochromatiqueÉléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres pour réduire l’intensité de la lumière
G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière
G03B 33/08 - Enregistrement ou projection subséquents
40.
Backlight control method and device and liquid crystal display device
A backlight control method is provided. The method includes: determining, based on a global backlight brightness value, a backlight brightness interval in which the global backlight brightness value is located; determining, according to a correspondence between the backlight brightness interval and a backlight gain coefficient table, a backlight gain coefficient table corresponding to the backlight brightness interval, where the backlight gain coefficient table is configured to indicate a gain coefficient corresponding to a partition backlight brightness value; determining, according to a partition backlight brightness value of each of backlight partitions and the backlight gain coefficient table, a gain coefficient of each of the backlight partitions; and driving each of the backlight partitions according to the gain coefficient of each of the backlight partition and the partition backlight brightness value of each of the backlight partitions.
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
Methods and apparatuses that provide a technical solution for handling a microphone operation request from more than one application is disclosed. The technical solution for processing data obtained by a microphone of a terminal device includes receiving an audio recording start command sent by a second application running on the terminal while the microphone is being used by a first application running on the terminal. The technical solution further includes assigning an unoccupied data receiving port to the second application, acquiring and broadcasting audio recording data collected by the microphone through a data sending port, receiving the audio recording data by the assigned data receiving port, and sending the audio recording data to the second application by the assigned data receiving port.
Hisense Mobile Communications Technology Co., Ltd. (Chine)
Hisense USA Corp. (USA)
Hisense International Co., Ltd. (Chine)
Inventeur(s)
Geng, Bingyu
An, Liang
Zheng, Weibo
Abrégé
Methods and apparatuses that provide a technical solution for handling a microphone operation request from more than one application is disclosed. The technical solution for processing data obtained by a microphone of a terminal device includes receiving an audio recording start command sent by a second application running on the terminal while the microphone is being used by a first application running on the terminal. The technical solution further includes assigning an unoccupied data receiving port to the second application, acquiring and broadcasting audio recording data collected by the microphone through a data sending port, receiving the audio recording data by the assigned data receiving port, and sending the audio recording data to the second application by the assigned data receiving port.
A laser light source is provided. The laser light source includes: a laser device; a first color wheel and a second color wheel, on both of which there are corresponding color regions, wherein the laser device emits laser which illuminates the first color wheel and the second color wheel sequentially, and exits from the color regions on the second color wheel; a first marker and a second marker arranged respectively on the first and the second color wheels; a first sensor configured to detect the first marker, and to generate a first sense signal; a second sensor configured to detect the second marker, and to generate a second sense signal; and a control unit configured to synchronize the first color wheel and the second color wheel.
HISENSE MOBILE COMMUNICATIONS TECHNOLOGY CO., LTD. (Chine)
HISENSE USA CORP. (USA)
HISENSE INTERNATIONAL CO., LTD (Chine)
Inventeur(s)
Song, Tao
Abrégé
A wearable device is provided. The wearable device includes a host. A wristband is connected to both sides of the host. A support assembly is connected to a back shell of the host. The support assembly includes a cushion block. The cushion block is a hollow structure. The cushion block is recessed inwardly on a surface of the cushion block toward the back shell of the host to form a groove. The back shell of the host is able to extend into the groove. An elastic member is provided in the groove. One end of the elastic member is connected to the back shell of the host, and another end of the elastic member is connected to a bottom surface of the groove.
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/02 - Détection, mesure ou enregistrement en vue de l'évaluation du système cardio-vasculaire, p. ex. mesure du pouls, du rythme cardiaque, de la pression sanguine ou du débit sanguin
A61B 5/01 - Mesure de la température de parties du corps
A61B 5/024 - Mesure du pouls ou des pulsations cardiaques
45.
Grayscale compensating method and apparatus for self-luminous display, and self-luminous display device
A grayscale compensating method, an apparatus for a self-luminous display and a self-luminous display device are provided. The method includes: obtaining each driving voltage corresponding to each grayscale signal of the self-luminous display; determining, according to intervals to which each driving voltage belongs, each preset driving function corresponding to each driving voltage; determining each first driving current corresponding to each driving voltage according to each preset driving function; detecting each second driving current of pixel units of the self-luminous display in case of being driven at each driving voltage; comparing the first driving current with the second driving current, and determining compensating voltages corresponding to each grayscale signal according to each preset driving function, and differences between each first driving current and each second driving current.
G09G 3/3258 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice utilisant des sources lumineuses commandées utilisant des panneaux électroluminescents semi-conducteurs, p. ex. utilisant des diodes électroluminescentes [LED] organiques, p. ex. utilisant des diodes électroluminescentes organiques [OLED] utilisant une matrice active avec un circuit de pixel pour commander la tension aux bornes de l'élément électroluminescent
G09G 3/3241 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice utilisant des sources lumineuses commandées utilisant des panneaux électroluminescents semi-conducteurs, p. ex. utilisant des diodes électroluminescentes [LED] organiques, p. ex. utilisant des diodes électroluminescentes organiques [OLED] utilisant une matrice active avec un circuit de pixel pour commander le courant à travers l'élément électroluminescent le courant à travers l'élément électroluminescent étant fixé en utilisant un courant de données fourni par le circuit de commande de données, p. ex. à l'aide d'un miroir de courant à deux transistors
46.
Backlight control method and liquid crystal display device
Disclosed are a backlight control method and a liquid crystal display device, where the backlight control method includes generating backlight data of a backlight partition corresponding to an image partition according to grayscale data of each of the image partition in an image to be displayed; generating a PWM backlight control signal for the each of the backlight partition according to a grayscale interval where the backlight data of the each of the backlight partition lies, where current amplitudes of PWM backlight control signals corresponding to backlight data in different grayscale intervals are different; and controlling a backlight source of the each of the backlight partition according to the PWM backlight control signal for the each of the backlight partition.
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
G02F 1/1335 - Association structurelle de cellules avec des dispositifs optiques, p. ex. des polariseurs ou des réflecteurs
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
47.
Character inputting method and device and intelligent terminal
Disclosed is a character inputting method, device and an intelligent terminal, the method including: when a virtual key in a virtual on-screen keyboard layout is selected, invoking a first probability statistical table matching at least one character having been displayed by at least one virtual key having been selected; displaying a part of the candidate characters with the highest combination probabilities or all of the candidate characters in the invoked first probability statistical table respectively on virtual keys in the virtual on-screen keyboard layout, and resetting focus on a preset virtual key, wherein any candidate character displayed on a virtual key configured with higher level has higher combination probability; and performing operations above periodically until an ideogram or a character sequence to be input is selected, and inputting the selected ideogram or the character sequence selected in an input area.
G06F 3/048 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI]
G06F 3/0488 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] utilisant des caractéristiques spécifiques fournies par le périphérique d’entrée, p. ex. des fonctions commandées par la rotation d’une souris à deux capteurs, ou par la nature du périphérique d’entrée, p. ex. des gestes en fonction de la pression exercée enregistrée par une tablette numérique utilisant un écran tactile ou une tablette numérique, p. ex. entrée de commandes par des tracés gestuels
G06F 3/023 - Dispositions pour convertir sous une forme codée des éléments d'information discrets, p. ex. dispositions pour interpréter des codes générés par le clavier comme codes alphanumériques, comme codes d'opérande ou comme codes d'instruction
G06F 3/01 - Dispositions d'entrée ou dispositions d'entrée et de sortie combinées pour l'interaction entre l'utilisateur et le calculateur
A laser light source is disclosed that includes a laser device, a first diffusion element, a fluorescence wheel, and a second diffusion element. The fluorescence wheel emits a fluorescent light when excited by the laser light, and before reaching the fluorescence wheel, the laser light emitted by the laser device is transmitted through the first diffusion element that is fixedly arranged. As the second diffusion plate rotates about its axis, the laser light from the first diffusion element and the fluorescent light from the fluorescence wheel transmit through the second diffusion plate.
This application provides a TV screenshot method and an associated television (TV). The method includes: upon receiving a screenshot request, acquiring a layer range of On Screen Display (OSD) sub-layers corresponding to windows of every application displayed on an OSD layer; and generating the screenshot image by taking a snap shot of the OSD sub-layers in the layer range. This application can prevent unwanted system notification information image from being captured when a snap shot is taken.
The present application provides a light-pipe adjusting apparatus comprising: a first support; a light-pipe component, slidably connected to the first support via a first rail; and a first drive device, provided on the first support and connected to the light-pipe component for driving the light-pipe component to slide along the first rail. The present application can improve the accuracy and reliability of the position adjustment of the light-pipe component.
G03B 21/14 - Projecteurs ou visionneuses du type par projectionLeurs accessoires Détails
G02B 7/00 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques
G02B 27/09 - Mise en forme du faisceau, p. ex. changement de la section transversale, non prévue ailleurs
F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière
The disclosure discloses a mobile terminal, a DC-charging power source adaptor, and a charging method, where the mobile terminal detects whether two communication pins of a USB interface thereof are shorted, and if an inserted external device is a power source adaptor, then the mobile terminal communicates with the power source adaptor, so that the mobile terminal identifies automatically the type of the externally connected charging device. Also a specialized rapid charging mode is designed for a DC-charging power adaptor, so that a battery being charged routinely is DC-charged at large current using charging voltage output by the DC-charging power source adaptor, and a volt value of the charging voltage is adjusted dynamically to the varying voltage of the battery core.
H02J 7/00 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries
H02J 7/04 - Régulation du courant ou de la tension de charge
H02J 50/10 - Circuits ou systèmes pour l'alimentation ou la distribution sans fil d'énergie électrique utilisant un couplage inductif
H02J 7/02 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries pour la charge des batteries par réseaux à courant alternatif au moyen de convertisseurs
H02J 50/12 - Circuits ou systèmes pour l'alimentation ou la distribution sans fil d'énergie électrique utilisant un couplage inductif du type couplage à résonance
A connection structure for a laser and a laser assembly are provided. The connection structure for a laser includes a first insulation substrate, where the first insulation substrate includes a conductive path separately on an upper surface and a lower surface thereof. A second insulation substrate is disposed on the upper surface of the first insulation substrate. An upper surface of the second insulation substrate includes a conductive path. The conductive path on the upper surface of the second insulation substrate is electrically connected to the conductive path on the lower surface of the first insulation substrate via a through-hole. The connection structure for a laser and the laser assembly in the present disclosure are configured to supplying power to a laser.
This disclosure provides a laser speckle-removing optical component, including a beam-shrinking lens group and a diffusion sheet arranged on a laser emergent optical path, where the beam-shrinking lens group includes a first beam-shrinking lens and a second beam-shrinking lens, and the diffusion sheet is located between the first beam-shrinking lens and the second beam-shrinking lens, and a distance between the diffusion sheet and the first beam-shrinking lens is shorter than a focal length of the first beam-shrinking lens. The arrangement of the diffusion sheet between the first beam-shrinking lens and the second beam-shrinking lens is able to alleviate the accumulation phenomenon of dust particles on the diffusion sheet, therefore, alleviating light attenuation phenomenon, and prolonging the service life of the laser source. This disclosure also provides a double-color laser source, a three-color laser source and a laser projection equipment applying the above laser speckle-removing optical component.
Disclosed are a device and method for displaying a video over a network, the method includes: determining a first resolution of a target video frame input over network, and comparing the first resolution with a screen resolution of a mobile terminal, and the first resolution with a resolution of a video frame displayed by the mobile terminal; if the first resolution is different from the screen resolution of the mobile terminal, determining a first ratio of a row resolution of the screen resolution to a row resolution of the first resolution, and a second ratio of a column resolution of the screen resolution to a column resolution of the first resolution; determining the size of a display window according to the smaller one of the first ratio and the second ratio, which is a display scale, and the first resolution; and displaying the target video frame in the display window.
G09G 5/00 - Dispositions ou circuits de commande de l'affichage communs à l'affichage utilisant des tubes à rayons cathodiques et à l'affichage utilisant d'autres moyens de visualisation
H04N 21/40 - Dispositifs clients spécialement adaptés à la réception de contenu ou à l'interaction avec le contenu, p. ex. boîtier décodeur [STB]Leurs opérations
Disclosed are a controlling device and method for frequency synchronization as well as a LCD TV. The method is applied to an LCD TV, wherein the LCD TV includes a front-end motherboard chip, a main drive control chip and a plurality of column drive control chips, the method includes: when the main drive control chip recognizes that its operating frequency is unstable, it generates a clock turn-off signal; the main drive control chip transmits fixed data to each column drive control chip according to the clock turn-off signal and receives a clock training request initiated by each column drive control chip according to the fixed data; and when recognizing that the operating frequency synchronizes with a frequency corresponding to front-end data transmitted by the front-end motherboard chip, the main drive control chip responds to the clock training request and transmits clock training data to each column drive control chip.
H04N 9/475 - Synchronisation de couleurs pour verrouiller mutuellement différentes sources de synchronisation
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
56.
Method and apparatus for controlling transmission of VBO signal and display terminal
The present application discloses a method and an apparatus for controlling transmission of a VBO signal and a display terminal. The method is applied in the display terminal, where the display terminal includes a mainboard and a Tcon board which use a VBO interface for communications, and the method includes: after a system is powered on, performing multiple interactions between the Tcon board and the mainboard according to a VBO signal transmission protocol; after each of the interactions, acquiring, by the Tcon board, a timing control signal by parsing valid image data of a received VBO signal transmitted by the mainboard, and if the timing control signal acquired by parsing successively satisfies a preset condition in a preset number of handshakes, then stopping repeating the interaction, and only performing transmission of display image data in the VBO signal.
G09G 5/00 - Dispositions ou circuits de commande de l'affichage communs à l'affichage utilisant des tubes à rayons cathodiques et à l'affichage utilisant d'autres moyens de visualisation
G09G 3/20 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
H04N 7/015 - Systèmes de télévision à haute définition
An optical component includes: a first substrate, a second substrate, and a transfer board. A first electrically conductive path is disposed on a top surface of the first substrate. A second electrically conductive path is disposed on a bottom surface of the first substrate. A third electrically conductive path is disposed on a top surface of the second substrate. A microstrip line structure is disposed on the transfer board. The microstrip line structure includes a transfer line disposed on a top surface of the transfer board. The top surface of the second substrate is opposite to the bottom surface of the first substrate, where the second electrically conductive path fits the third electrically conductive path. The transfer board is disposed on the top of the top surface of the second substrate. One end of the transfer line is electrically connected to the first electrically conductive path by a wire bonding.
H01S 5/024 - Dispositions pour la gestion thermique
H01S 5/068 - Stabilisation des paramètres de sortie du laser
H01S 5/0683 - Stabilisation des paramètres de sortie du laser en surveillant les paramètres optiques de sortie
H01S 5/0687 - Stabilisation de la fréquence du laser
H01S 5/062 - Dispositions pour commander les paramètres de sortie du laser, p. ex. en agissant sur le milieu actif en faisant varier le potentiel des électrodes
58.
Method for setting universal serial bus (USB) interface of electronic device, and electronic device
HISENSE MOBILE COMMUNICATIONS TECHNOLOGY CO., LTD. (Chine)
HISENSE USA CORPORATION (USA)
HISENSE INTERNATIONAL CO., LTD. (Chine)
Inventeur(s)
Ding, Chao
Abrégé
Certain aspects of the disclosure relates to a method for operating an electronic device. A control device detects a Universal Serial Bus (USB) interface being connected to the electronic device, where the USB interface has a plurality of virtual ports. Then the control device receives one or more descriptors through the USB interface, each descriptor corresponding to a function of the electronic device. Then the control device matches each descriptor corresponding to each function with one driver file corresponding to each function, and after the matching is successful, determines a virtual function device corresponding to execution of each function. In response to receiving an operating command for executing one function, the control device sends the operating command to the corresponding virtual function device to the function to be executed through a corresponding driver interface, such that the corresponding virtual function device is operated on the electronic device.
Embodiments of the present application provide a method and apparatus for controlling liquid crystal display brightness, and a liquid crystal display device. The method for controlling liquid crystal display brightness according to the present application determines a backlight adjustment rule according to a grayscale value distribution of an image signal and a first preset rule, adjusts a zoned backlight value corresponding to a zoned image data block according to the backlight adjustment rule, as well as drives and controls the backlight source brightness of the corresponding backlight zone by using the adjusted zoned backlight value, thereby adjusting the zoned backlight values for image signals of different grayscale value distributions by using different backlight adjustment rules, significantly improving the picture hierarchy of different image signals, and enhancing the displaying quality of the picture.
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
60.
Method and apparatus for controlling backlight brightness, and liquid crystal display device
The present application provides a method and an apparatus for controlling backlight brightness, and a liquid crystal display device. The method includes: determining, in an image to be displayed, an image block corresponding to each backlight partition of a plurality of backlight partitions, and determining an initial backlight value for each backlight partition; determining brightness distribution information for pixels in an image partition; determining a backlight adjusting curve corresponding to the image partition; and determining a backlight adjusting factor for a backlight partition corresponding to the image partition according to the initial backlight value of the backlight partition corresponding to the image partition and the backlight adjusting curve corresponding to the image partition, and determining a target backlight value for the backlight partition corresponding to the image partition according to the initial backlight value for the backlight partition and the corresponding backlight adjusting factor.
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
G02F 1/13 - Dispositifs ou dispositions pour la commande de l'intensité, de la couleur, de la phase, de la polarisation ou de la direction de la lumière arrivant d'une source lumineuse indépendante, p. ex. commutation, ouverture de porte ou modulationOptique non linéaire pour la commande de l'intensité, de la phase, de la polarisation ou de la couleur basés sur des cristaux liquides, p. ex. cellules d'affichage individuelles à cristaux liquides
G09G 3/20 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice
61.
TV set base with a supporting and a retracted state
In one aspect, a TV set is provided. A base includes a first member and a second member that have two supporting arms symmetrically disposed on two sides of the first member. One end of each of the two supporting arms is respectively rotatably connected with two side portions of the first member. When the base is in a supporting state, a first angle, a second angle and a third angle is formed between the first member and the display screen assembly, between the first and second members, and between the second member and a supporting object, respectively. When the base is in a retracted state, the first member is substantially parallel to the display screen assembly and is located at a lower portion of the display screen assembly, and the second member is located on a same side of the first member and the display screen assembly.
H04N 5/64 - Détails de structure des récepteurs, p. ex. ébénisterie ou housses
F16M 11/10 - Moyens pour la fixation des appareilsMoyens permettant le réglage des appareils par rapport au banc permettant la rotation autour d'un axe horizontal
F16M 11/38 - Infrastructure avec ou sans roues à hauteur ou longueur modifiables des pieds, avec utilisation possible pour le transport également par pliage
F16M 13/02 - Autres supports ou appuis pour positionner les appareils ou les objetsMoyens pour maintenir en position les appareils ou objets tenus à la main pour être portés par un autre objet ou lui être fixé, p. ex. à un arbre, une grille, un châssis de fenêtre, une bicyclette
F16M 11/00 - Appuis ou tréteaux en tant que supports pour appareils ou objets
62.
System and methods for device control and multiple input handling
The present disclosure relates to device control and multiple input event handling. In one embodiment, a process includes detecting a plurality of input commands for control of a display device, determining a multiple input event based on the plurality of input commands, and determining a multiple input control function for the display device based on the multiple input event. The multiple input control function is determined based on input type of the multiple input event and a function of the input type of the multiple input event. The process can also includes controlling operation of the display device based on the multiple input control function, wherein controlling includes modifying display device operation from a control function associated with the plurality of input commands to a multiple input event control function.
The present application provides a method for configuring a television audio format, a method for transparently transmitting audio and a television, where the method for configuring the television audio format includes: acquiring information regarding an audio format supported to be decoded by an external audio playing device; judging whether EDID information pre-stored in the television includes the information regarding the audio format supported to be decoded by the external audio playing device; if not, supplementing the EDID information with the information regarding the audio format supported to be decoded by the external audio playing device, where the supplemented EDID information is configured for a set top box connected to the television to determine whether to transparently transmit audio data or not based on the supplemented EDID information. The present application can avoid a loss in a tonal quality and improve a tonal quality effect of playing.
H04N 21/442 - Surveillance de procédés ou de ressources, p. ex. détection de la défaillance d'un dispositif d'enregistrement, surveillance de la bande passante sur la voie descendante, du nombre de visualisations d'un film, de l'espace de stockage disponible dans le disque dur interne
H04N 21/439 - Traitement de flux audio élémentaires
H04N 21/45 - Opérations de gestion réalisées par le client pour faciliter la réception de contenu ou l'interaction avec le contenu, ou pour l'administration des données liées à l'utilisateur final ou au dispositif client lui-même, p. ex. apprentissage des préférences d'utilisateurs pour recommander des films ou résolution de conflits d'ordonnancement
H04N 21/4363 - Adaptation du flux vidéo à un réseau local spécifique, p. ex. un réseau Bluetooth®
H04N 21/41 - Structure de clientStructure de périphérique de client
65.
Quantum dot light emitting device, backlight module, and display device
The disclosure provides a quantum dot light emitting device, a backlight module, and a display device. The quantum dot light emitting device arranged on a first substrate which is a printed circuit board of a display device includes at least one backlight light source and a quantum dot optical element, wherein the at least one backlight light source is arranged on the first substrate, and configured to emit light; and the quantum dot optical element is fixed by a bracket on the first substrate above the at least one backlight light source, and configured to transmit the light emitted by the at least one backlight light source; wherein the quantum dot optical element includes two second substrates arranged opposite to each other, at least two blocking layers arranged opposite to each other, and a plurality of quantum dots, wherein the at least two blocking layers are arranged respectively at edges of the two second substrates so that an airtight space is defined by the two second substrates and the at least two blocking layers; and the quantum dots are filled in the airtight space. There will be a smaller number of quantum dots in this disclosure, and thus there will be a lower cost.
This application provides a TV screenshot method and an associated television (TV). The method includes: upon receiving a screenshot request, acquiring a layer range of On Screen Display (OSD) sub-layers corresponding to windows of every application displayed on an OSD layer; and generating the screenshot image by taking a snap shot of the OSD sub-layers in the layer range. This application can prevent unwanted system notification information image from being captured when a snap shot is taken.
Disclosed are a multi-screen projection device and method. The multi-screen projection device disclosed in the present invention comprises: a signal processing system, a lens assembly, and a digital micromirror device (DMD); said signal processing system is used for receiving an N-way image signal, N being an integer greater than or equal to 2, and converting said N-way image signal to a DMD drive signal corresponding to N regions on the DMD; a DMD driver circuit used for driving, according to the received DMD drive signal, the regions corresponding to the DMD to project. The projections of different regions on the DMD are imaged to different regions on a screen by means of the lens assembly. The present invention enables multi-screen projection.
Methods and systems are disclosed for echo suppression of an input audio signal. A multimedia system and a remote control unit are configured to adaptively and dynamically preform calibration processes for obtaining sets of echo suppression parameters. The sets of echo suppression parameters are used to generate an audio signal from an input audio. When rendered by a speaker, the generated audio signal produces echo-suppressed sound of the input audio signal at one of more locations.
This application provides a method for method for television (TV) remote keypress response based on Android operating system (OS) and a TV thereof, and includes: creating a first process when the Android OS is being initialized; executing the first process to obtain a key value of a remote keypress event; and performing a remote keypress operation according to the key value. The method creates and executes the first process during the initialization of the Android OS, thereby realizing responding to remote keypress during TV start-up, greatly enhancing user experience.
Disclosed are a multi-screen projection device and method. The multi-screen projection device disclosed in the present invention comprises: a signal processing system, a lens assembly, a number N of digital micromirror devices (DMD), and a DMD driver circuit; N is a positive integer greater than or equal to 2; said number N of DMDs are arranged, not overlapping one another, within the field of view of said lens assembly; said signal processing system is used for converting a to-be-projected image corresponding to the DMD to obtain a DMD drive signal; the DMD driver circuit is used for driving, according to the received DMD drive signal, the corresponding DMD to project. The projections of different DMDs are imaged to different regions on a screen by means of the lens assembly, such that the present invention enables multi-screen projection.
Disclosed are a multidirectional projection device and method. The multidirectional projection device disclosed in the present invention comprises: a lens assembly, a digital micromirror device (DMD), and a control system; said DMD is mounted on a movable mechanical component; said control system is used for controlling the movable mechanical component, on which the DMD is located, to drive the DMD arranged on the movable mechanical component to move and/or twist, so that the DMD projects in the direction of a target imaging region. The present invention enables multidirectional projection.
The present disclosure provides a picture display method and apparatus that relate to the field of image processing and are increase flexibility of picture display and reducing a memory occupation rate of a terminal on the premise of not modifying an attribute of an original picture. The method and apparatus include receiving an instruction for displaying a picture; obtaining, according to an identifier of a to-be-displayed picture included in the instruction, an original bitmap of the to-be-displayed picture and searching, a database of a current device for a pre-stored first rotation angle corresponding to the to-be-displayed picture; adjusting, according to a resolution of a current screen and/or a current window size, a display size of the original bitmap of the to-be-displayed picture, so as to obtain a compressed bitmap of the original bitmap; and displaying, according to the first rotation angle, a compressed bitmap of the original bitmap.
A device for converting wavelength and a projection light source are disclosed in the present disclosure. According to an example, the device may comprise a roller, a drive motor, a first reflector, a support shaft, a drive module and a dichroic film. An axis of the support shaft may be coincided with an axis of the roller. The support shaft may be not rotated with rotation of the roller. The drive motor may drive the roller rotate around the support shaft and the drive module may drive the roller to move back and forth along an axial direction of the support shaft. So excitation light reflected by the first reflector may be incident uniformly on the sidewall of the roller. Therefore, fluorescent powder conversion efficiency may be improved compared with that of the excitation light incident on a fixed area.
The present application provides a method for controlling a backlight source, a device for controlling a backlight source and a liquid crystal display, where the method includes: determining time intervals of received synchronous signals; determining an output delay compensation value of the synchronous signals, according to the time intervals and fixed response delay time for processing the synchronous signals; generating a compensated synchronous signal according to the output delay compensation value of the synchronous signals; transmitting the compensated synchronous signal to a PWM driver. The application allows a backlight source to perform optical display according to multipath control signals with relatively stable frequency, and reduces backlight blinking of the backlight source.
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
75.
Method and apparatus for performing touch operation in a mobile device
HISENSE MOBILE COMMUNICATIONS TECHNOLOGY CO., LTD. (Chine)
HISENSE USA CORPORATION (USA)
HISENSE INTERNATIONAL CO., LTD. (Chine)
Inventeur(s)
Sun, Hui
Abrégé
The disclosure provides a method and an apparatus for performing a touch operation in a mobile device, the method includes: activating a target operation mode when monitoring a first target operation in a first user interface; mapping a first touch operation event occurring in a first position to a second touch operation event occurring in a second position in the target operation mode; and reporting the second touch operation event occurring in the second position to the first user interface for performing a corresponding operation. By mapping position in an operable area, operation on an area inoperable with one hand of user is realized, avoiding click-help from another hand and improving simplicity and efficiency of touch operations. Since there is no need to perform transformation operations such as zooming on first user interface, user can operate directly, reducing probability of error due to position error after transformation.
G06F 3/0488 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] utilisant des caractéristiques spécifiques fournies par le périphérique d’entrée, p. ex. des fonctions commandées par la rotation d’une souris à deux capteurs, ou par la nature du périphérique d’entrée, p. ex. des gestes en fonction de la pression exercée enregistrée par une tablette numérique utilisant un écran tactile ou une tablette numérique, p. ex. entrée de commandes par des tracés gestuels
G06F 3/0481 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] fondées sur des propriétés spécifiques de l’objet d’interaction affiché ou sur un environnement basé sur les métaphores, p. ex. interaction avec des éléments du bureau telles les fenêtres ou les icônes, ou avec l’aide d’un curseur changeant de comportement ou d’aspect
G06F 3/0482 - Interaction avec des listes d’éléments sélectionnables, p. ex. des menus
An optical component includes: a first substrate, a second substrate, and a transfer board. A first electrically conductive path is disposed on a top surface of the first substrate. A second electrically conductive path is disposed on a bottom surface of the first substrate. A third electrically conductive path is disposed on a top surface of the second substrate. A microstrip line structure is disposed on the transfer board. The microstrip line structure includes a transfer line disposed on a top surface of the transfer board. The top surface of the second substrate is opposite to the bottom surface of the first substrate, where the second electrically conductive path fits the third electrically conductive path. The transfer board is disposed on the top of the top surface of the second substrate. One end of the transfer line is electrically connected to the first electrically conductive path by a wire bonding.
The present disclosure relates to systems, methods for content streaming with a content buffer. In one embodiment, a method includes detecting, by a content buffer, a request for network content from a player, wherein the request is a network communication detected by the content buffer and the request for network content is directed to a server and identifying, by the content buffer, associated network content, wherein the associated network content is associated with the network content requested by the player. The method may also include pre-downloading associated network content for the player based on the identifying, wherein the content buffer requests associated network content from the server, and providing the associated network content to the player. Another embodiment is directed to a device configured to run a content buffer and provide content for a content player.
The present disclosure relates to a system and method for menu interface presentation. A method for presenting a menu interface (105) by a display device (405) includes detecting a command for presentation of a menu interface (105) of the display device (405), detecting at least one menu interface (105) setting and presenting a menu interface on a display (100) of the display device (405). The menu interface (105) may be presented to include a plurality of tile elements (1101, 1102, 1103, 1104, 1105, 1106, 1107, 110n) associated with a control selection for the display device (405), the tile elements (1101, 1102, 1103, 1104, 1105, 1106, 1107, 110n) presented in a configuration format and including a tile configured for personalization, and a tile element (1101, 1102, 1103, 1104, 1105, 1106, 1107, 110n) for selecting content for presentation by the display device (405). The method also includes tile elements (1101, 1102, 1103, 1104, 1105, 1106, 1107, 110n) in a configuration format, a tile configured for personalization and location of the menu interface (105) based on the at least one menu interface setting.
The disclosure provides an optical module that includes a circuit board, a first chip, a second chip, and a lens assembly, wherein the first chip and the second chip are arranged respectively on the surface of the circuit board, and the lens assembly is arranged above the first chip and the second chip; the lens assembly includes a first optic fiber insertion port, a second optic fiber insertion port, a first reflecting surface, and a second reflecting surface; the distance between the axis of the first optic fiber insertion port, and the axis of the second optic fiber insertion port is less than the distance between the first chip and the second chip; and the first reflecting surface faces the first chip, the first reflecting surface faces the second reflecting surface, and the second reflecting surface faces the first optic fiber insertion port.
Qingdao Hisense Hitachi Air-Conditioning Systems Co., Ltd. (Chine)
Hisense USA Corp. (USA)
Inventeur(s)
Li, Xizhi
Deng, Yuping
Zhang, Xianlin
Huang, Shuliang
Abrégé
A drive control method for an electric expansion valve is disclosed. In the disclosure, before applying a drive pulse signal corresponding to a rotary pulse number to a motor of the electronic expansion valve, a secondary positioning is performed on a relative position between stator magnetic field of the motor and rotor magnetic field of the motor by applying a holding current of a first duration time to the motor, applying an pulse signal of an additional pulse number to the motor, and applying a holding current of a second duration time to the motor, and a same secondary positioning operation is also performed on the motor after applying the drive pulse signal corresponding to the rotary pulse number to the motor of the electronic expansion valve, which ensures that the electronic expansion valve operates according to the drive pulse signal corresponding to the rotary pulse number.
G05B 15/02 - Systèmes commandés par un calculateur électriques
F24F 11/84 - Systèmes de commande caractérisés par leurs grandeurs de sortieDétails de construction de tels systèmes pour la commande de la température de l’air fourni en commandant l’apport en fluides échangeurs de chaleur aux échangeurs de chaleur au moyen de valves
81.
Method of protecting an image based on face recognition, and smart terminal
The disclosure discloses a method and apparatus for protecting an image based on face recognition, the method including: recognizing, by a smart terminal, at least one face image in an image; setting, by the smart terminal, a protection flag for the image, and storing the image, upon determining that one of the at least one face image in the image matches successfully with one of face images in a protection list stored in the smart terminal, wherein the protection flag is configured to protect the image from accidental deletion.
G06K 9/00 - Méthodes ou dispositions pour la lecture ou la reconnaissance de caractères imprimés ou écrits ou pour la reconnaissance de formes, p.ex. d'empreintes digitales
H04N 1/32 - Circuits ou dispositions pour la commande ou le contrôle entre l'émetteur et le récepteur
H04N 5/77 - Circuits d'interface entre un appareil d'enregistrement et un autre appareil entre un appareil d'enregistrement et une caméra de télévision
The present disclosure provides a picture display method and apparatus that relate to the field of image processing and are increase flexibility of picture display and reducing a memory occupation rate of a terminal on the premise of not modifying an attribute of an original picture. The method and apparatus include receiving an instruction for displaying a picture; obtaining, according to an identifier of a to-be-displayed picture included in the instruction, an original bitmap of the to-be-displayed picture and searching, a database of a current device for a pre-stored first rotation angle corresponding to the to-be-displayed picture; adjusting, according to a resolution of a current screen and/or a current window size, a display size of the original bitmap of the to-be-displayed picture, so as to obtain a compressed bitmap of the original bitmap; and displaying, according to the first rotation angle, a compressed bitmap of the original bitmap.
The disclosure provides an apparatus and method for setting antennas of a mobile device, and a mobile device, and the apparatus includes: one or more processors; and a memory, where the memory is configured to store one or more computer readable program codes, and the one or more processors are configured to execute the one or more computer readable program codes to perform operations of: functioning, by the mobile device, as a Wi-Fi relay to be connected with both a wireless access point and an electronic device, wherein the mobile device is provided with at least two Wi-Fi antennas to receive and transmit Wi-Fi data; determining a communication type of communication between the wireless access point and the electronic device; and adjusting the number of receiving antennas and the number of transmitting antennas among the Wi-Fi antennas according to the communication type.
H04B 7/04 - Systèmes de diversitéSystèmes à plusieurs antennes, c.-à-d. émission ou réception utilisant plusieurs antennes utilisant plusieurs antennes indépendantes espacées
H04B 7/0404 - Systèmes de diversitéSystèmes à plusieurs antennes, c.-à-d. émission ou réception utilisant plusieurs antennes utilisant plusieurs antennes indépendantes espacées la station mobile comprenant plusieurs antennes, p. ex. pour mettre en œuvre une diversité en voie ascendante
84.
Controlling device and method for frequency synchronization and LCD television
Disclosed are a controlling device and method for frequency synchronization as well as a LCD TV. The method is applied to an LCD TV, wherein the LCD TV includes a front-end motherboard chip, a main drive control chip and a plurality of column drive control chips, the method includes: when the main drive control chip recognizes that its operating frequency is unstable, it generates a clock turn-off signal; the main drive control chip transmits fixed data to each column drive control chip according to the clock turn-off signal and receives a clock training request initiated by each column drive control chip according to the fixed data; and when recognizing that the operating frequency synchronizes with a frequency corresponding to front-end data transmitted by the front-end motherboard chip, the main drive control chip responds to the clock training request and transmits clock training data to each column drive control chip.
H04N 9/475 - Synchronisation de couleurs pour verrouiller mutuellement différentes sources de synchronisation
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
85.
Coupler and optical waveguide chip applying the coupler
A coupler and a waveguide chip including the coupler are provided. The coupler connects a first optical waveguide to a second optical waveguide and includes an entity region and a first waveguide grating. A first end of the entity region is coupled to the first optical waveguide. A second end of the entity region is coupled to a second end of the first waveguide grating. A first end of the first waveguide grating is coupled to the second optical waveguide. Size of the first end of the entity region matches size of an end plane of the first optical waveguide, size of an end plane of the second end of the entity region matches size of an end plane of the second end of the first waveguide grating, and size of the first end of the first waveguide grating matches size of an end plane of the second waveguide.
Disclosed is a device for editing channels of a smart TV. The device includes a memory and at least one processor, wherein the memory stores therein computer readable instructions, wherein the instructions are executed by the at least one processor to enable the at least one processor to: receive an interface calling up instruction, and displaying a channel editing list and an operation prompt on a display screen of the smart TV; receive a channel selecting instruction, and determine a channel to be edited in the channel editing list according to the channel selecting instruction; and receive a channel edit instruction, and edit the channel to be edited according to the channel editing instruction, wherein the operation prompt is configured to remind a user that the channel editing instruction is triggered by using a left arrow key or right arrow key of a remote control, and the channel editing instruction is an instruction indicating deletion or a move of the channel to be edited. Also disclosed are a smart TV, and a method for editing channels of a smart TV.
H04N 21/482 - Interface pour utilisateurs finaux pour la sélection de programmes
H04N 21/485 - Interface pour utilisateurs finaux pour la configuration du client
H04N 21/431 - Génération d'interfaces visuellesRendu de contenu ou données additionnelles
H04N 21/475 - Interface pour utilisateurs finaux pour acquérir des données d'utilisateurs finaux, p. ex. numéro d'identification personnel [PIN] ou données de préférences
87.
Method and apparatus for capturing screen on mobile device
Hisense Mobile Communications Technology Co., Ltd. (Chine)
Hisense USA Corporation (USA)
Hisense International Co., Ltd. (Chine)
Inventeur(s)
Yu, Deyi
Abrégé
Embodiments of the disclosure provide a method and an apparatus for capturing a screen on a mobile device, the method including: receiving, at the mobile device, a screen-capturing request for a current interface, where the current interface includes first data, and the first data includes personal information; and generating, according to screen-capturing request, a screen capture image for the current interface, where the first data in the current interface is replaced in the screen capture image with second data which is predefined. These embodiments avoid the need to manually mask an image by starting a dedicated image editing tool to anonymize a screen capture image, thereby significantly lowering the relatively high technical threshold of anonymization processing, reducing the error rate, and improving the modification quality of anonymization. Moreover, the replacement is directly made to the image while the screen is captured without interfering with normal use of reading.
G06F 17/20 - Manipulation de données en langage naturel
G06F 21/62 - Protection de l’accès à des données via une plate-forme, p. ex. par clés ou règles de contrôle de l’accès
G06F 3/0484 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] pour la commande de fonctions ou d’opérations spécifiques, p. ex. sélection ou transformation d’un objet, d’une image ou d’un élément de texte affiché, détermination d’une valeur de paramètre ou sélection d’une plage de valeurs
88.
Printed circuit board and optical module comprising solder resist having no contact with an electro-conductive contact sheet group on a same substrate
The application provides a printed circuit board and an optical module so as to alleviate poor contact between the electro-conductive contact sheet group and the clamping piece due to the solder resist. The printed circuit board includes a substrate, and electro-conductive wirings and electro-conductive contact sheet group both laid on the surface of the substrate, where the substrate is overlaid with solder resist, and the solder resist has no contact with the electro-conductive contact sheet group.
A backlight module and a display apparatus are provided. The backlight module includes: a light bar, a quantum dot encapsulated tube and a light guide plate; the light bar and light guide plate are disposed at two sides of quantum dot encapsulated tube respectively, the light bar and quantum dot encapsulated tube are disposed in parallel, the light bar and quantum dot encapsulated tube are located at a light incident surface side of light guide plate, a plurality of LED lights are disposed on the light bar at a side facing towards the quantum dot encapsulated tube, an LED light corresponding to valid area of quantum dot encapsulated tube is monochromatic LED light, an LED light corresponding to invalid area of quantum dot encapsulated tube is white LED light, and invalid area of quantum dot encapsulated tube is within irradiation range of the white LED light.
The present invention provides an optical apparatus, which is configured to output image information and comprises a housing; a light source; an optical device; an optical device carrier, wherein the optical device is mounted on the optical device carrier and positioned on one side of the optical device carrier; a support plate positioned on the other side of the optical device carrier and being one part of the housing; and a connecting piece, wherein one end of the connecting piece penetrates the support plate and then is connected with the optical device carrier, and the relative positions of the connecting piece and the support plate are fixed.
G02B 7/182 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour prismesMontures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour miroirs pour miroirs
Some embodiments of the present disclosure disclose an optical module. The optical module comprises a housing; a circuit board is provided inside the housing, and a connecting finger pluggable in an optical module cage is provided on the circuit board. At least one reflector, which is located between the connecting finger and an optical port of the optical module and can reflect electromagnetic waves radiated onto a surface of the reflector, is provided between the circuit board and the housing.
Some embodiments of the present disclosure disclose a pluggable optical module, comprising a housing and an electromagnetic interference shielding clip clamped on the housing; a conductive member is provided between the housing and the electromagnetic interference shielding clip; and when the pluggable optical module is inserted into an optical module cage, the conductive member can block a gap between the housing and the electromagnetic interference shielding clip.
Embodiments of the disclosure disclose a method and apparatus for determining the radiation strength of a Wi-Fi signal, and the method includes: obtaining Wi-Fi signal sources, and signal strength values of the signal sources when a Wi-Fi function is enabled; and determining the radiation strengths of corresponding Wi-Fi signals according to the number of Wi-Fi signal sources, and the signal strength values of the respective signal sources.
Some embodiments in this disclosure provide a method to control lens of a camera module, a lens control terminal and a storage media, wherein the method to control lens of a camera module includes receiving power-off signal of the camera module; controlling the lens moving towards a zero position gradually, till the lens moves back to the zero position; powering off the camera module.
H04N 5/232 - Dispositifs pour la commande des caméras de télévision, p.ex. commande à distance
G02B 7/10 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles avec mécanisme de mise au point ou pour faire varier le grossissement par déplacement axial relatif de plusieurs lentilles, p. ex. lentilles d'objectif à distance focale variable
G02B 7/02 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles
95.
Method and device for detecting flatness of a fluorescent wheel in a laser light source
An embodiment of the present disclosure discloses a method for detecting flatness of a fluorescent wheel in a laser light source, comprising: acquiring, during the rotation of a fluorescent wheel, a spot of laser light emitted by a laser reflected from a substrate of the fluorescent wheel; determining an inner diameter of the spot; and determining flatness of the fluorescent wheel according to the inner diameter of the spot.
G01B 11/30 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer la rugosité ou l'irrégularité des surfaces
H01S 3/22 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz
96.
METHODS AND DEVICES FOR SWITCHING BETWEEN DIFFERENT TV PROGRAM ACCOMPANYING SOUNDS
The present disclosure relates to TV devices that implement methods for switching an accompanying sound of a TV program. According to the method, the TV device may display a current TV program under a first operation state of a plurality operation state associated with the current TV program; when receiving a first controlling signal, display a target menu on the screen, wherein the target menu includes a target menu option of operation which is a default option and is associated with the plurality of operation states of the current TV program; and when receiving a second controlling signal, directly switch the TV device to a second operation state along a sequence of the plurality of operation states.
An apparatus and method for converting a frame rate, the method including: receiving a first video signal; extracting target frames corresponding to the first video signal, wherein the target frames include same content as original signal frames corresponding to the first video signal; generating a second video signal from the target frame; and performing a Motion Estimation and Motion Compensation (MEMC) process on the second video signal.
H04N 11/20 - Conversion du mode de combinaison des composantes individuelles du signal d'image en couleurs, p. ex. conversion des standards de télévision en couleurs
98.
Method and apparatus for controlling liquid crystal display brightness, and liquid crystal display device
This disclosure provides a method, and a liquid crystal display device, and relates to the field of liquid crystal display technologies, where the method includes: determining grayscale values of pixels in zone image data block under a predetermined rule according to a received image signal, and pre-obtaining a zone backlight value corresponding to the zone image data block according to the grayscale values in the zone image data block; determining a backlight gain coefficient according to a backlight value gain variable and an ambient luminance revision variable, and multiplying the zone backlight value with the backlight gain coefficient to obtain backlight values of a backlight zone corresponding to the zone image data block to which a gain is applied, wherein the backlight value gain variable is determined by the grayscale values, and the ambient luminance revision variable is determined by ambient luminance; and outputting the backlight value of the backlight zone to a driver circuit of backlight source in the backlight zone to control the brightness of the backlight source in the backlight zone as a result of driving, thus improving the effect of the contrast quality of pictures of the liquid crystal display device.
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
G09G 3/20 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
99.
Liquid crystal TV set, and method and apparatus for adjusting backlight driving voltage thereof
This disclosure relates to a liquid crystal TV set, and a method and apparatus for adjusting backlight driving voltage thereof, and the method for adjusting backlight driving voltage includes: comparing backlight driving current with reference driving current to obtain voltage feedback data, while a backlight source is being driven; making overvoltage adjustment to the voltage feedback data to generate overvoltage feedback data; and adjusting backlight driving voltage using the overvoltage feedback data to overvoltage-drive the backlight source by the adjusted backlight driving voltage. The liquid crystal TV set, and the method and apparatus for adjusting backlight driving voltage thereof according to this disclosure can improve the response speed of backlight in the liquid crystal TV set while the backlight source is being driven.
G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
G09G 3/36 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante utilisant des cristaux liquides
Disclosed are a voice control method, device and terminal, and the method includes: after a terminal has been triggered into voice control mode, receiving input voice data and obtaining corresponding speech text according to the voice data; matching the speech text with an interface word list corresponding to a current operating interface, wherein the interface word list includes text information of the current operating interface; in response to determining that the speech text matches an interface word list successfully, obtaining in the current operating interface an operation link which corresponds to the speech text; and performing an operation corresponding to the operation link.
G10L 15/22 - Procédures utilisées pendant le processus de reconnaissance de la parole, p. ex. dialogue homme-machine
G10L 15/18 - Classement ou recherche de la parole utilisant une modélisation du langage naturel
G10L 25/51 - Techniques d'analyse de la parole ou de la voix qui ne se limitent pas à un seul des groupes spécialement adaptées pour un usage particulier pour comparaison ou différentiation
