Produits et services

Machines and machine tools for treating metals and plastics, namely riveting machines and metal forming machines, machine tools for forming, riveting, waging, and flaring of metal and plastics

Abrégé

The application relates to a device for applying an applied force to a connection element such that the connection element is plastically deformed by the application of force. The device comprises a movably mounted head part with a machining head which is designed to contact the connection element; a drive which is designed to drive a translation of the head part in the longitudinal axis thereof; a second drive which is designed to drive a rotation of the machining head about a longitudinal axis; and a housing for receiving the first drive, the second drive, and the head part. The first drive and the second drive are electrically driven and are arranged coaxially. The application further relates to a method for operating a device according to the application and to the use of a device according to the application as an electric riveting machine.

Classes IPC  ?

• B21J 15/12 - Machines à riveter avec outils ou parties d'outils possédant un mouvement propre s'ajoutant au mouvement d'avance, p. ex. repoussage
• B21J 15/28 - Dispositifs de commande spécialement adaptés aux machines à riveter, non limités à l'un des sous-groupes précédents
• B21J 9/02 - Réalisations ou structures particulières
• H02K 7/06 - Moyens de transformation d'un mouvement alternatif en un mouvement circulaire ou vice versa

Abrégé

The invention relates to a device (1) for applying an applied force to a connection element such that the connection element is plastically deformed by the application of force. The device comprises a movably mounted head part (16) with a machining head (7) which is designed to contact the connection element; a drive (13) which is designed to drive a translation of the head part in the longitudinal axis thereof; a second drive (8) which is designed to drive a rotation of the machining head (7) about a longitudinal axis; and a housing (3, 4) for receiving the first drive (13), the second drive (8), and the head part (16). The first drive (13) and the second drive (8) are electrically driven and are arranged coaxially. The invention further relates to a method for operating a device according to the invention and to the use of a device according to the invention as an electric riveting machine.

Classes IPC  ?

• B21J 9/02 - Réalisations ou structures particulières
• B21J 15/12 - Machines à riveter avec outils ou parties d'outils possédant un mouvement propre s'ajoutant au mouvement d'avance, p. ex. repoussage
• B23Q 5/32 - Avance des broches de travail
• H02K 7/06 - Moyens de transformation d'un mouvement alternatif en un mouvement circulaire ou vice versa

Produits et services

(1) Machine tools for the treatment of metal, plastic and synthetic material. Machine tools, especially transform-machines; riveters; riveter presses, presses and powerpresses.

Produits et services

Machines and machine attachments for the treatment of metal and synthetic; machine tool, especially transform-machines; riveters; riveters presses, presses and powerpresses

Produits et services

Machines for processing metal, wood and plastic materials.

Produits et services

(1) Stamping presses and riveting machines, and controls, accessories and parts therefor.

Produits et services

Machines and machine tools for treating metals and plastics.
