An autonomous drop cart processing system is described. The system is configured to communicably couple with a drop cart that includes an array of cashbox data readers configured to interface with cashbox data transmitters associated with cashboxes inserted into compartments of the drop cart. As a result of this construction, the autonomous drop cart processing system can remove contents of each cashbox on the drop cart without needing to remove the cashbox from the drop cart in order to read the data from the cashbox data transmitter.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
H04B 5/70 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive spécialement adaptés à des fins spécifiques
A system evaluates currency in an area using image processing. In some examples, the system receives an image of an area from an image sensor, processes the image to identify at least one item of currency in the area, determine a value of the currency irrespective of validity, and counts the currency. In various examples, the system receives an image of an area from an image sensor; processes the image to identify at least one item of currency in the area; determines whether the currency has an error condition; and when the currency is determined to have the error condition, provides output on the error condition. In a number of examples, the system receives an image of an area from an image sensor; processes the image to identify at least one item of currency in the area; determines whether the currency is valid; and when the currency is determined to be suspect, provides output on the currency.
G07D 7/00 - Vérification spécialement adaptée à la détermination de l’identité ou de l’authenticité de papiers de valeur ou pour discriminer ceux qui sont inacceptables, p. ex. qui ne correspondent pas à une monnaie
G06V 10/98 - Détection ou correction d’erreurs, p. ex. en effectuant une deuxième exploration du motif ou par intervention humaineÉvaluation de la qualité des motifs acquis
G06V 20/52 - Activités de surveillance ou de suivi, p. ex. pour la reconnaissance d’objets suspects
A bill processor is provided with a bill validator that may receive, from a mobile terminal, telecommunication signals inclusive of electronic currency information to store it in a stacker memory of a bill stacker. The bill processor includes an interface (80) for receiving electronic currency information transmitted from a mobile terminal (70), a bill validator (1) that has a validation transceiver (3) for receiving the electronic currency information transmitted from the interface (80) and a bill stacker (2) for accumulating bills considered genuine by and forwarded from the bill validator (1) so that the validation transceiver (3) of the bill validator (1) transmits electronic currency information to a stacker transceiver (21) of a bill stacker (2) that then sends the information to a stacker memory (22) of the bill stacker (2) to finally store the information in the stacker memory (22).
The present invention includes a friction transport device and a paper sheet transport device that can correct paper sheets inserted from various positions or angles to a normal transport state while continuously transporting the paper sheets without any deformation due to contact with a sidewall or the like. A drive-side unit 20 includes a drive roller 25 that rotates on a shaft part 22, a rocking arm 30 that includes the shaft part 22 at one portion thereof and that has another portion thereof pivotally supported by a rocking shaft 50a so as to change a transport grip by rocking the drive roller to change a distance from a driven roller 102, and an elastic biasing member 40 that elastically biases the drive roller toward the driven roller via the rocking arm.
[Problem] To provide a banknote-processing apparatus for emitting, from a portable terminal, a remote communication signal including information pertaining to electronic money or other electronic currency, and saving/accumulating the electronic currency information in a storage saving device of a banknote storage device via a banknote-sorting device. [Solution] In the present invention, a banknote-processing apparatus has: a banknote-sorting device (1) having an interface (80) for receiving electronic currency information from a portable terminal (70), and a sorting transmission/reception device (3) for receiving the electronic currency information transmitted from the interface (80); and a banknote storage device (2) for storing supplied banknotes assessed by the banknote-sorting device (1) to be authentic. The electronic currency information transmitted from the sorting transmission/reception device (3) of the banknote-sorting device (1) is received by a storage transmission/reception device (21) ofthe banknote storage device (2), and the electronic currency information ultimately transmitted from the storage transmission/reception device (21) is saved and accumulated in a storage saving device (22).
G07F 7/02 - Mécanismes actionnés par des objets autres que des pièces de monnaie pour déclencher ou actionner des appareils de vente, de location, de distribution de pièces de monnaie ou de papier-monnaie, ou de remboursement par des clés ou d'autres dispositifs enregistrant un crédit
A camera device is mounted in a bezel attached to a bill validator to take user's clear face image. A bezel (8) includes a frame (4a) secured to a housing (1a) of a bill validator (1), a camera device (4) attached to the frame (4a) for taking images of user's face and a cover (4c) attached to the frame (4a) for covering the camera device (4), the cover (4c) being made of translucent and optically reflective materials.
H04N 23/695 - Commande de la direction de la caméra pour modifier le champ de vision, p. ex. par un panoramique, une inclinaison ou en fonction du suivi des objets
H04N 23/73 - Circuits de compensation de la variation de luminosité dans la scène en influençant le temps d'exposition
7.
FRAUD PREVENTION MECHANISM, PAPER SHEET TRANSPORT DEVICE, AND PAPER SHEET HANDLING DEVICE
The present invention includes an opening/closing member, a rotary member that rotates integrally with the opening/closing member, a driving member for opening/closing member driving, that is arranged to oppose the rotary member and that is axially supported to be capable of relatively rotating with respect to the rotary member, and a drive transmission mechanism that transmits a drive force from the driving member to the rotary member, in which the drive transmission mechanism includes a driven piece, and a driving piece that rotationally drives the rotary member by pressing the driven piece, and a value of a circumferential backlash (θ3) between the driven piece and the driving piece is set to a value that enables prevention of the opening/closing member from being rotated to transition to the initial rotational posture by an operation from outside while the opening/closing member is stopped in the non-initial rotational posture.
G07D 11/237 - Moyens de mesure ou de détection pour surveiller ou indiquer les conditions de fonctionnementMoyens de mesure ou de détection pour détecter les dysfonctionnements pour détecter les dysfonctionnements de transport, p. ex. le bourrage ou le blocage
It is the purpose of the present invention to provide an article conveying system that can efficiently proceed conveying work even when the number of articles placed at each shelf position is different in a situation where a plurality of the articles is placed side by side along the depth direction of a shelf. An article conveying system 100 according to the present invention comprises a conveying device 400, a distance measuring device 690, and a management unit 900. The conveying device is capable of conveying an article BL, BS. The distance measuring device measures a distance from a predetermined position to an object in a predetermined direction. The management unit manages presence or absence of the article based on information about the distance to the object measured by the distance measuring device located at the predetermined position.
B65G 1/137 - Dispositifs d'emmagasinage mécaniques avec des aménagements ou des moyens de commande automatique pour choisir les objets qui doivent être enlevés
The present invention enables determination as to whether a banknote 100 is to be discharged even when only the feature quantity of a portion of the banknote is acquired at the time of discharging the banknote in a case in which a transport route length L1 from a reading position 18a of an optical recognition sensor 18 to an inlet/outlet 12 as a banknote discharge port is shorter than a total length LA of the banknote in a transport direction. At the time of discharging the banknote 100 already authenticated, a control unit 200 judges the type (denomination) of the banknote on the basis of a feature quantity of a reading target 103 that passes the optical recognition sensor 18 before a leading end 100a of the banknote 100 transported in a discharge direction protrudes to outside the device from the inlet/outlet 12.
A banknote handling system includes an unlocking system. The unlocking system includes a camera, a first mechanical arm to which one or a plurality of keys are affixed, and a controller that determines a position of a keyhole based on an image from the camera, and controls the first arm to insert one of the one or the plurality of keys into the keyhole and turn the inserted key for unlocking. In many examples, the unlocking system is configured to unlock a banknote cashbox.
G07D 11/34 - Surveillance du contenu des dispositifs, p. ex. de la quantité de papiers de valeur
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
An object of the present invention is to easily assemble and exchange a reflection type optical device and their parts in an optical sensor for bill validation by fitting unitized housings into openings of partitions. The optical sensor for bill validation includes a reflection type optical device (13, 30) that has a housing (41) for receiving an optical component (40) and also forming a part of a bill passageway (20). The housing (41) has a lid (42) and a box (43), the lid (42) being formed of light-permeable materials to allow lights irradiated from the inner optical component (40) and lights reflected on the bill to pass through the lid (42), and the box (43) surrounding the inner optical component (40) in combination with the lid (42) that is fit into an opening (53) formed in a partition (11, 12).
[Problem] To provide different kinds of special treatment through a paper sheet handling device to persons who charge paper sheets to a discrimination device, according to the charging records of the persons. [Solution] This paper sheet handling device comprises a discrimination storage device (18) in which paper sheet image information output from a paper sheet sensor (16) and face image information output from a camera device (4) are stored with identical management codes, and a search comparison device (20) that compares the face image information stored in the discrimination storage device (18) and the face image information output from the camera device (4), searches for the face image information about a person who charges paper sheets and the history of paper sheet charges along with the paper sheet image information when there is a match in the face image information, and displays the face image information and the history of paper sheet charges. The search comparison device (20) provides various kinds of special treatment to persons who charge paper sheets, according to the history of paper sheet charges of the persons.
G07D 7/00 - Vérification spécialement adaptée à la détermination de l’identité ou de l’authenticité de papiers de valeur ou pour discriminer ceux qui sont inacceptables, p. ex. qui ne correspondent pas à une monnaie
Provided is an article conveyance processing system in which article(s) are efficiently taken out from a mobile cart and/or article(s) are placed on a mobile cart even when various types of mobile carts are used. Using the cart coordinate system obtained such that the horizontal, vertical and depth axes of the cart coordinate system substantially coincide with the horizontal, vertical and depth directions of the mobile cart, respectively, the article conveyance processing system performs the control of moving the robot hand and the attitude control of the robot hand; thus, the article conveyance processing system can efficiently take out an article from a mobile cart and/or place an article on a mobile cart regardless of in what orientation a wide variety of mobile carts are placed.
System and method for systematically changing the color of lighting associated with a peripheral device (e.g., NFC device) based on the status or condition of the machine (e.g., EGM) to which it is connected and/or the status of another peripheral device connected to the machine. The system and method permit the operator of the machine to program unique illumination schemes corresponding to various machine and/or peripheral conditions. For example, the peripheral device may be illuminated with a unique color for each of a bill validator being offline, a cashbox being near full and a player being near to earning a promotion. The system and method may also be used to visually communicate information related to player tracking, mobile wallet, security issues and any other information concerning a EGM, player or casino.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
H04B 5/70 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive spécialement adaptés à des fins spécifiques
A transport system 10 C has a configuration to move a transport body 500 in conjunction with movement of a moving body 200 by using repulsion based on a magnetic force applied between moving body magnets 213 and a transport body magnet 523 when there is a proximal positional relation between these magnets. The transport system 10 C includes a control coil 903 that controls a traveling state of the moving body 200, and a coil drive control unit that drives and controls the control coil. The control coil 903 is configured to apply a magnetic force to the moving body magnets 213. The coil drive control unit supplies the control coil 903 with power to cause the control coil 903 to attract the moving body magnets 213 against an air flow flowing within an air blowing tube 100 in order to control and prevent the moving body 200 from traveling.
B65G 51/36 - Autres appareils pour indiquer ou commander les mouvements des cartouches, p. ex. pour contrôler des sections particulières de tubes, pour compter les cartouches, pour signaler les embouteillages ou autres difficultés de fonctionnement
B65G 54/02 - Transporteurs non mécaniques, non prévus ailleurs électrostatiques, électriques ou magnétiques
To downsize a curved transport route through which a transport target is transported without being deformed.
To downsize a curved transport route through which a transport target is transported without being deformed.
A transport path 401 includes a first curved transport tubular-body unit 415B having a first curved shape in which a bottom surface 411B located beside an air blowing tube 100 bulges into a convex shape toward the air blowing tube. The first curved transport tubular-body unit is configured to increase a distance H between the bottom surface and a top surface 413B opposite to the bottom surface from each end portion toward an intermediate portion in a transport direction x to prevent a banknote P retained by a transport body 500 from coming into contact with the top surface.
Various system, method, and device embodiments are disclosed for establishing and utilizing a wireless connection between an electronic gaming machine and a mobile device associated with a player. Such embodiments include use of a first component configured to communicate information with the mobile device using near-field communications and use of a second component configured to automatically pair the mobile device with the mobile interface device, using a Bluetooth connection, wherein the pairing of the mobile device with the mobile interface device utilizes the information communicated to the mobile device using the first component.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
H04W 4/80 - Services utilisant la communication de courte portée, p. ex. la communication en champ proche, l'identification par radiofréquence ou la communication à faible consommation d’énergie
H04W 76/14 - Établissement de la connexion en mode direct
18.
DIRECTION SWITCHING AND TRANSFERRING DEVICE OF PAPER SHEET
The present invention includes a stacker unit SU that includes a transport body 500 moving along a transport route 400 while retaining paper sheets in an upright state and stopped at a paper sheet extraction position PP, and clamping means 812 and 803 clamping the paper sheets on the transport body, and that switches the direction of the paper sheets in a process of reciprocatively rotationally moving between an upper limit position and a lower limit position, and an operating mechanism 730 that rotationally moves the stacker unit forward and reversely. The clamping means performs an opening/closing operation to clamp paper sheets when the stacker unit is at the upper limit position, and performs an opening operation to cancel clamping of paper sheets after a time when the stacker unit reaches the lower limit position.
A direction switching and transferring device H, an error paper sheet processing device 970, and a cashbox 950 are accommodated in a cashbox unit 700, and the error paper sheet processing device includes a paper sheet inlet 971 that receives error paper sheets, an error paper sheet transport route 972 that is provided along a place away from the direction switching and transferring device and that transports the error paper sheets input from the paper sheet inlet to the cashbox 950, and a recognition unit 974 that judges the authenticity and the denominations of the error paper sheets received from the paper sheet inlet and counts the paper sheets.
An autonomous drop cart processing system is described. The system is configured to communicably couple with a drop cart that includes an array of cashbox data readers configured to interface with cashbox data transmitters associated with cashboxes inserted into compartments of the drop cart. As a result of this construction, the autonomous drop cart processing system can remove contents of each cashbox on the drop cart without needing to remove the cashbox from the drop cart in order to read the data from the cashbox data transmitter.
G06F 7/00 - Procédés ou dispositions pour le traitement de données en agissant sur l'ordre ou le contenu des données maniées
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
H05B 47/105 - Commande de la source lumineuse en réponse à des paramètres détectés
H05B 47/155 - Commande coordonnée de plusieurs sources lumineuses
H05B 47/16 - Commande de la source lumineuse par des moyens de minutage
H05B 47/19 - Commande de la source lumineuse par télécommande via une transmission sans fil
H04B 5/70 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive spécialement adaptés à des fins spécifiques
21.
NETWORK ARCHITECTURE FOR GAMING INDUSTRY ACCOUNTING
A peripheral device is installed in a cabinet of an electronic gaming machine and configured to detect and communicate with a personal electronic device of a player of a casino game. The personal electronic device is configured to communicate identity information and/or account information to the peripheral device that, in turn, can be used to enable gameplay on the electronic gaming machine. Other embodiments described herein reference a network architecture facilitating cryptographically-secure and verifiable accounting of all point or real-money transactions in a casino environment.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
09 - Appareils et instruments scientifiques et électriques
Produits et services
Currency validators; money counting and sorting machines
including currency validators; money counting and sorting
machines; apparatus for checking the authenticity of
banknotes; currency authentication apparatus and equipment;
cash registers; automated teller machines [ATM].
23.
PAPER SHEET PROCESSING SYSTEM, PAPER SHEET PROCESSING METHOD, AND PROGRAM
To provide a paper sheet processing system that can prevent theft of paper sheets. This paper sheet processing system comprises: a paper sheet processing device that counts number of paper sheets; and a paper sheet management device that is communicable with the paper sheet processing device, wherein the paper sheet processing device includes an acquiring unit that acquires paper sheet identification information uniquely identifying the paper sheets from corresponding paper sheets, and a transmission unit that transmits the acquired paper sheet identification information to the paper sheet management device, and the paper sheet management device includes a reception unit that receives the paper sheet identification information, a specifying unit that specifies the paper sheet identification information of lost ones among the paper sheets, and a notification unit that notifies the paper sheet identification information specified by the specifying unit to an external device.
To reduce the processing load on a paper sheet identification device and to make an appropriate identification strength settable. There is provided a paper sheet processing system comprising: a paper sheet identification device that identifies paper sheets having been taken out from a paper sheet receiving device; and a paper sheet management device that is communicable with the paper sheet identification device, wherein the paper sheet management device includes a decision unit that decides strength information based on model information specifying a type of the paper sheet receiving device, and a transmission unit that transmits the decided strength information, and the paper sheet identification device includes a reception unit that receives the strength information, a strength setting unit that sets an identification strength using the received strength information, and an identification unit that identifies the paper sheets with the set identification strength.
Provided is a coin processing device (100) comprising: a processing unit (110) that is for receiving coins or tokens and feeding the same one at a time with an interval therebetween; and a sorting unit (120) that receives the coins or tokens from the processing unit one at a time, that determines the types of the coins or tokens while causing the coins or tokens to move along an arc, and that guides the coins or tokens to paths for respective types.
G07D 3/06 - Tri de pièces de monnaie au moyen d'orifices calibrés aménagés le long d'une piste circulaire
G07D 11/18 - Dérivation vers des trajets ou récipients différents
G07D 11/235 - Moyens de mesure ou de détection pour surveiller ou indiquer les conditions de fonctionnementMoyens de mesure ou de détection pour détecter les dysfonctionnements
Provided is a coin processing device (100) comprising: a separating unit (110) for receiving coins or medals and feeding out the coins or medals one at a time; a sorting unit (120) that receives the coins or medals one at a time from the separating unit, determines the types of coins or medals while moving the coins or medals along an arc, and guides the coins or medals to paths for each type; a shared motor (106) that applies a driving force to the separating unit and the sorting unit; and a computer (191) that controls the motor. The computer reversely rotates the motor when the sorting unit has rotated by a first prescribed amount in a state in which the rotation of the separating unit has stopped.
G07D 3/06 - Tri de pièces de monnaie au moyen d'orifices calibrés aménagés le long d'une piste circulaire
G07D 11/235 - Moyens de mesure ou de détection pour surveiller ou indiquer les conditions de fonctionnementMoyens de mesure ou de détection pour détecter les dysfonctionnements
G07D 11/26 - Entretien, réparation ou traitement des anomalies, p. ex. des coupures de courant ou du vandalisme
The present invention provides a coin-processing device (100) comprising a sorting unit (110) for receiving coins or medals and sending them out at intervals one at a time. The sorting unit includes: a rotating member (113) in which a plurality of hole units (113X, 113X) having at least one coin or medal positioned therein are formed at intervals; projections (114) for guiding the coin or the medal to the outlet (112X) of the sorting unit, said projections (114) being disposed below the rotating member; and shutters (215, 115) that are biased in the outlet-closing direction, and are pushed away by coins or medals guided by the projections.
A system evaluates currency in an area using image processing. In some examples, the system receives an image of an area from an image sensor, processes the image to identify at least one item of currency in the area, determine a value of the currency irrespective of validity, and counts the currency. In various examples, the system receives an image of an area from an image sensor; processes the image to identify at least one item of currency in the area; determines whether the currency has an error condition; and when the currency is determined to have the error condition, provides output on the error condition. In a number of examples, the system receives an image of an area from an image sensor; processes the image to identify at least one item of currency in the area; determines whether the currency is valid; and when the currency is determined to be suspect, provides output on the currency.
A system evaluates currency in an area using image processing. In some examples, the system receives an image of an area from an image sensor, processes the image to identify at least one item of currency in the area, determine a value of the currency irrespective of validity, and counts the currency. In various examples, the system receives an image of an area from an image sensor; processes the image to identify at least one item of currency in the area; determines whether the currency has an error condition; and when the currency is determined to have the error condition, provides output on the error condition. In a number of examples, the system receives an image of an area from an image sensor; processes the image to identify at least one item of currency in the area; determines whether the currency is valid; and when the currency is determined to be suspect, provides output on the currency.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
31.
PAPER SHEET DISCHARGE ACCUMULATION DEVICE AND REFLUX-TYPE PAPER SHEET PROCESSING DEVICE
Provided are a paper sheet discharge accumulation device and a reflux-type paper sheet processing device that prevent a paper sheet drawn from a reflux unit from causing accumulation failure on a dispensing tray. The present invention comprises: a discharge conveyance path 510 on which a paper sheet drawn from a reflux unit 30, 40 is conveyed to a discharge tray 700 with its short side at the head; and a shaping mechanism 550 that performs shaping such that the short-side shape of the paper sheet conveyed on the discharge conveyance path becomes a predetermined shape over the entire length in the longitudinal direction, and discharges the paper sheet onto the discharge tray.
Provided are a paper sheet discharge and collection device and a circulation-type paper sheet processing device which prevent paper sheets delivered from a circulation unit from causing a collection defect on a withdrawal tray. The present invention comprises: a discharge conveyance path 510 for conveying, to a discharge tray 700, the paper sheets delivered from circulation units 30, 40 with the short sides thereof on a leading end; and a shaping mechanism 550 which shapes the paper sheets so that the short side shape thereof conveyed through the discharge conveyance path is a predetermined shape over the total longitudinal length thereof, and then discharges the paper sheet onto the discharge tray.
G07D 11/175 - Aplanissement, p. ex. redressage de plis
33.
PAPER SHEET HANDLING DEVICE, GAME MACHINE MANAGEMENT DEVICE USING PAPER SHEET HANDLING DEVICE, AND DEGRADATION LEVEL DISPLAY METHOD FOR PAPER SHEET HANDLING DEVICE
[Problem] To provide a paper sheet handling device and a game machine management device in which a drive unit is replaced before the operational lifetime thereof is reached. [Solution] A paper sheet handling device (1) comprises a distinction device (2) that distinguishes the authenticity of paper sheets, a distinction transport passage (10) that is formed inside the distinction device (2), and a drive unit (13) that is detachably installed inside the distinction device (2). The drive unit (13) transports paper sheets inside the distinction device (2) along the distinction transport passage (10). The drive unit (13) comprises a drive sensor (24) that detects a physical value for the inside of the drive unit (13) and a physical property storage device (25) that stores the physical value detected by the drive sensor (24). The physical value for the inside of the drive unit (13) is retrieved from the physical property storage device (25) to display the degradation level of the drive unit (13).
G07D 7/00 - Vérification spécialement adaptée à la détermination de l’identité ou de l’authenticité de papiers de valeur ou pour discriminer ceux qui sont inacceptables, p. ex. qui ne correspondent pas à une monnaie
G07D 11/235 - Moyens de mesure ou de détection pour surveiller ou indiquer les conditions de fonctionnementMoyens de mesure ou de détection pour détecter les dysfonctionnements
G07D 11/26 - Entretien, réparation ou traitement des anomalies, p. ex. des coupures de courant ou du vandalisme
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) Automated cash box systems comprising industrial grade robots, recorded software, and automation equipment for processing cash boxes and counting and sorting money.
35.
PAPER SHEET PROCESSING DEVICE, AND PAPER SHEET PROCESSING METHOD
The purpose of the present invention is to suppress a disadvantage such that, in a configuration in which an accommodation part is detachably provided to a paper sheet processing device, the accommodation part which was removed from the paper sheet processing device is inconveniently attached to another paper sheet processing device. Provided is a paper sheet processing device that is capable of receiving paper sheets and that comprises: an accommodation part which is capable of accommodating the received paper sheets, and which is capable of discharging the accommodated paper sheets; and a body part in which the accommodation part is provided in a detachable manner. The body part comprises a storage part that stores identification information with which an accommodation part corresponding to the body part can be identified, and accommodation information with which the number of paper sheets accommodated in the accommodation part can be specified.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Coin counting machines; coin sorting machines; currency
sorting machines in the nature of coins recycling unit which
handles deposits and dispenses coins, and also recycles
deposited coins to dispense them; currency recognition
machines; cash dispensers; change machines, being cash
dispensing machines; cash dispensing machines; coin
changers; automatic cash sorting and counting machines;
automatic cash registers; cash registers; automated cash
accounting and settlement machines; accounting machines;
measuring apparatus, validators and discriminators for
banknotes, currencies, coupons or printed securities;
currency sorting machines in the nature of banknotes and
coins recycling unit which handles deposits, dispenses
banknotes and coins, and also recycles deposited banknotes
and coins to dispense them; banknotes dispensers; money
dispensers; banknotes and coins counters; money sorting
machine in the nature of sorters for banknotes, currencies,
coupons or other printed securities; paper currency
detectors; currency detectors; banknote sorting machines;
banknote counting machines; automated bank note sorting
machines; banknote acceptors; apparatus for checking the
authenticity of banknotes; counterfeit coin detectors;
currency authentication apparatus and equipment; money
counting and sorting machines; automated teller machines
[ATM].
The present invention addresses the problem of facilitating manual storage of objects being stored that are in a stacked state. This storage chamber 100 comprises: a box body 110 having a front opening 111 in a front-side surface thereof and having an upper opening 113 in an upper surface thereof, the upper opening communicating with an upper section of the front opening; an upper lid body 140 that opens and closes the upper opening, the upper lid body being pivotably supported at a rear section of the upper opening such that a rear section of the upper lid body can turn in a vertical direction; a front lid body 130 that opens and closes the front opening, the front lid body being pivotably supported at a front section of the upper lid body such that an upper section of the front lid body can turn; a raising/lowering plate 170 that advances and retreats between a lowered position at which the raising/lowering plate is lowered to a lowermost position in an accommodation section 101 provided inside the box body and a raised position at which the raising/lowering plate is raised from the lowermost position in the accommodation section; and an elastic member 190 that elastically presses the raising/lowering plate when the upper lid body closes the upper opening, the elastic member linking the inner surface of the upper lid body and the raising/lowering plate. The storage chamber is configured such that the raising/lowering plate is raised via the elastic member when the upper lid body opens the upper opening.
B65H 1/26 - Supports ou magasins pour les piles dans lesquelles on prélève des articles avec supports auxiliaires pour faciliter l'introduction ou le remplacement de la pile
G07D 11/12 - Récipients pour les papiers de valeur
G07D 11/13 - Récipients pour les papiers de valeur avec des moyens internes de manipulation des papiers de valeur
38.
PAPER SHEET HANDLING DEVICE, CALCULATION METHOD OF NUMBER OF PAPER SHEETS IN PAPER SHEET BATCH, AND PROGRAM
The present invention provides a paper sheet handling device that can calculate the number of paper sheets in a paper sheet batch being transported on a transport route without requiring complicated processing. The paper sheet handling device includes a transport unit that can transport a paper sheet batch, a shifting unit that shifts according to the thickness of the paper sheet batch when the paper sheet batch is transported, a generating unit that generates thickness information based on a shift amount of the shifting unit, a memory unit that memorizes reference information determined based on the thickness of one paper sheet, and a calculating unit that calculates the number of paper sheets in the paper sheet batch from the thickness information and the reference information.
G07D 11/50 - Tri ou comptage des papiers de valeur
B65H 31/30 - Dispositions pour enlever les piles achevées
B65H 43/00 - Utilisation de dispositifs de commande de vérification ou de sécurité, p. ex. dispositifs automatiques comportant un élément pour détecter une variable
A banknote storage handling device 300 includes a lid unit opening/closing mechanism 410 that moves a lid unit 170 to an open position by moving to a spaced position in a state where the lid body 171 is latched, a loading table 450 that is configured to receive and load paper sheet bundles Bs moved outward from a lateral opening by a paper sheet bundle moving member in accordance with movement of the lid unit to the open position when at a lifted standby position, and to be capable of being lowered from the standby position to a lowered position in a state where the paper sheet bundles are loaded thereon, and a loading table movement mechanism 560 that moves the loading table located at the lowered position to a predetermined paper sheet bundle discharge position.
Provided is a locking/unlocking device having a simpler structure and capable of automatically unlocking a paper sheet storage. The locking/unlocking device comprises: a key unit 330 having a key 331 for locking/unlocking a lock, and a key rotation motor 333 for providing the key with a rotational driving force to lock/unlock the lock; and a key moving mechanism 360 for moving the key unit forward and backward. The key moving mechanism comprises: a rack plate 365 for providing a driving force to the key unit by moving forward and backward between an initial position to allow the key unit to be moved to a spaced position where the key is spaced apart from the lock and a forward position to allow the key unit to be moved to a locking/unlocking position where the key locks/unlocks the lock; and an extension coil spring 371 interposed between the key unit and a driving force providing member. The extension coil spring 371 normally causes the key unit to be moved forward and backward integrally with the driving force providing member. On the other hand, when the key unit is subjected to an external force opposite to the forward/backward direction of the driving force providing member, the extension coil spring 371 causes the key unit to be moved forward/backward relative to the driving force providing member.
The present invention is a paper sheet transport system including: an air blowing device that generates an air flow for transporting paper sheets; a transport device that transports paper sheets with the air flow; and a control device that controls the air blowing device, and the control device includes a measuring unit that measures the speed of paper sheets on the transport device, and an adjusting unit that adjusts the air flow according to a result of the measurement. The control device includes a detecting unit that detects arrival of paper sheets at a deceleration region, and, when paper sheets in the deceleration region are faster than a specific speed, the adjusting unit causes the air blowing device to generate an air flow in an opposite direction to that of an air flow for transporting the paper sheets.
B65H 29/24 - Délivrance ou progression des articles à la sortie des machinesProgression des articles vers ou dans les piles par appareil à jet d'air ou aspirant
B65H 29/68 - Réduction de la vitesse des articles en mouvement
B65H 43/00 - Utilisation de dispositifs de commande de vérification ou de sécurité, p. ex. dispositifs automatiques comportant un élément pour détecter une variable
F04D 27/00 - Commande, p. ex. régulation, des pompes, des installations ou des systèmes de pompage spécialement adaptés aux fluides compressibles
42.
DEVICES AND SYSTEMS FOR PAYMENT ENTRY AND GAMING FUNDS TRANSFER
A gaming funds transaction device is disclosed that includes a user interface device, and in some embodiments a keypad section having input keys and a display, by which a gamer may obtain a gaming ticket with value added using a credit or debit card. The gaming funds transaction device may have a communication link to a financial institution or another validation service to obtain validation of a request to charge a credit or debit card. The user interface device may be connected to an input and printing section by a flexible arm, or may be an integrated component.
G07F 17/42 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour appareils pour imprimer des tickets ou analogues
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
The present invention prevents a reduction in conveyance power in a section where a high travel energy is required. A conveyance path 401 comprises an assitance-required section 410 in at least a portion thereof. A banknote conveyance system 10 comprises: an assistive power application section 803 disposed adjacent to a section of an airflow path 101 along the assistance-required section; and an assistive body 900 that travels along the assistive power application section. The assistive body comprises an assistive-body-side magnet 901. The banknote conveyance system 10 uses the magnetic power acting between the assistive-body-side magnet and a moving-body-side magnet 213 to apply motive power that assists movement of a moving body 200 so as to intermittently assist the conveyance power of the conveyance body 500.
B65H 29/00 - Délivrance ou progression des articles à la sortie des machinesProgression des articles vers ou dans les piles
A63F 7/02 - Jeux d'intérieur utilisant de petits éléments de jeu mobiles, p. ex. des boules, billes, disques ou cubes utilisant des éléments de jeu tombant ou des éléments de jeu roulant sur une surface inclinée, p. ex. billards électriques
09 - Appareils et instruments scientifiques et électriques
Produits et services
Automated cash box systems comprising industrial grade robots, recorded software, and automation equipment for processing cash boxes and counting and sorting money
09 - Appareils et instruments scientifiques et électriques
Produits et services
Coin counting machines; coin sorting machines; currency sorting machines in the nature of coins recycling unit which handles deposits and dispenses coins, and also recycles deposited coins to dispense them; currency recognition machines; cash dispensers; coin acceptors for separating good coins from counterfeits; change machines, being cash dispensing machines; cash dispensing machines; coin changers; automatic cash sorting and counting machines; automatic cash registers; cash registers; accounting machines; currency sorting machines in the nature of a banknotes and coins recycling unit which handles deposits, dispenses banknotes and coins, and also recycles deposited banknotes and coins to dispense them; banknotes and coins counting machines; money sorting machines in the nature of sorters for banknotes, currencies, coupons and other printed securities; paper currency detectors being currency recognition machines; currency detectors being currency recognition machines; currency sorting machines; currency counting machines; automated paper money sorting machines; banknote acceptors for separating good banknotes from counterfeits; apparatus for checking the authenticity of banknotes; counterfeit coin detectors; money counting and sorting machines; automatic teller machines (ATM)
46.
METHOD FOR TAKING OUT PAPER SHEETS AND PAPER SHEET TAKE-OUT PROCESSING SYSTEM
A method for taking out paper sheets that is capable of accurately taking out paper sheets (for example, separator cards) stored in a paper sheet storage container one-by-one at low cost. In this paper sheet taking-out method, air is blown from the side of or below the paper sheet while it is in a spread state, so that the upper surface of the paper sheet is raised. In this state, sucking the upper surface of the paper sheet by a suction mechanism allows for taking out the paper sheet with high accuracy.
The present invention includes a configuration to move a transport body 500 in conjunction with movement of a moving body 200 due to repulsion applied between respective magnetic materials 213 and 523 when the moving body and the transport body are in a close location relation, and, when the moving body separates from a range of the close location relation due to halfway stop of the transport body, the transport body is moved in the opposite direction to stop at a predetermined end portion stop position, subsequently only the moving body is caused to travel in a direction further away from the transport body, and the moving body is returned into the range of the close location relation by causing the moving body to travel toward the transport body at a speed resistible against the repelling force.
A paper sheet storage container capable of accurately taking out paper sheets one-by-one. A paper sheet group is held by a paper sheet placing table and holding members, while the paper sheet placing table is being biased upward by an elastic member so that the position of an uppermost paper sheet of the paper sheet group placed on the paper sheet placing table is substantially the same position as the positions of holes through which air flows. In this state, in the paper sheet storage container, air is blown from a side to the uppermost paper sheet of the paper sheet group placed on the paper sheet placing table thereby allowing the uppermost paper sheet to be brought into a state in which the vicinity of the center thereof has been raised.
B65H 1/12 - Supports ou magasins pour les piles dans lesquelles on prélève des articles avec moyens pour faire avancer la pile en vue de présenter les articles à un dispositif d'enlèvement comportant des ressorts
B65H 3/08 - Enlèvement des articles des piles en utilisant la force pneumatique
The present invention has a simple configuration and decelerates a mobile body and a transport body within a deceleration section in which the mobile body and the transport body are to be decelerated. A deceleration mechanism 800 comprises a mobile body 200 that has a mobile body–side magnet 213 and is moved through an airflow passage 101 by an airflow, a transport body 500 that has a magnetic body (a transport body–side magnet 523/a mobile body–side magnetic body 525) and is transported through a transport passage 401 in conjunction with the mobile body on the basis of magnetic force that acts between the mobile body–side magnet and the magnetic body, which is repelled or attracted by the mobile body–side magnet, and a braking means 815 that is arranged in a deceleration section 804 of the airflow passage and decelerates the mobile body. The braking means comprises an electric conductor 821 at which an eddy current is generated by the movement of the mobile body–side magnet.
H02K 49/02 - Embrayages dynamo-électriquesFreins dynamo-électriques du type à induction asynchrone
A63F 7/02 - Jeux d'intérieur utilisant de petits éléments de jeu mobiles, p. ex. des boules, billes, disques ou cubes utilisant des éléments de jeu tombant ou des éléments de jeu roulant sur une surface inclinée, p. ex. billards électriques
G07D 11/00 - Dispositifs acceptant des pièces de monnaieDispositifs acceptant, distribuant, triant ou comptant des papiers de valeur
51.
FRICTION CONVEYANCE DEVICE AND PAPER SHEET CONVEYANCE DEVICE
Provided are a friction conveyance device and a paper sheet conveyance device capable of correcting paper sheets, which are inserted from various positions and angles, to a normal conveying state while continuously conveying, without causing deformation due to contact with side walls, etc. A drive-side unit 20 comprises: a drive roller 25 that rotates about a shaft part 22; a rocking arm 30 comprising the shaft part 22 at one part thereof and the other part supported by a rocking shaft 50a so as to change the distance from a driven roller 102 by rocking a drive roller to change a conveyance grip; and an elastic biasing member 40 that elastically biases the drive roller toward the driven roller via the swing arm.
The present invention provides a conveyance guide drive mechanism which makes, in a paper sheet conveying device provided with a wide conveyance surface that can be used in common for paper sheets with different width dimensions, correction so as to achieve a normal conveyance state while preventing deformation and damage during continuous and non-intermittent conveyance. The conveyance guide drive mechanism comprises conveyance guides 310 which are disposed facing each other along both widthwise side edges of a conveyance surface 11 to respectively guide both side edges of paper sheets being conveyed, an advancing/retracting mechanism 350 that synchronously moves each of the conveyance guides to protrude and retract in a predetermined direction, stoppers 440 which respectively define protruding positions where each of the conveyance guides 310 protrudes most from the conveyance surface 11 and retracted positions where each of the conveyance guides 310 is retracted toward the conveyance surface side from the protruding positions, and a DC motor 450 that drives the advancing/retracting mechanism 350.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Automated cash box system comprising industrial grade
robots, recorded software and automation equipment for
processing cash boxes and counting and sorting money.
[Problem] To capture a clear face image of a user by providing a camera device on a bezel attached to a bill validator device. [Solution] A bezel (8) is provided with: a frame body (4a) fixed to a housing (1a) of a bill validator device (1); a camera device (4) attached to the frame body (4a) and which captures a face image of a user; and a lid (4c) attached to the frame body (4a) and covering the camera device (4), the lid (4c) being formed of a light-transmissive and light-reflective material.
G07F 7/04 - Mécanismes actionnés par des objets autres que des pièces de monnaie pour déclencher ou actionner des appareils de vente, de location, de distribution de pièces de monnaie ou de papier-monnaie, ou de remboursement par du papier-monnaie
G07D 7/00 - Vérification spécialement adaptée à la détermination de l’identité ou de l’authenticité de papiers de valeur ou pour discriminer ceux qui sont inacceptables, p. ex. qui ne correspondent pas à une monnaie
[Problem] To provide a banknote-processing apparatus for emitting, from a portable terminal, a remote communication signal including information pertaining to electronic money or other electronic currency, and saving/accumulating the electronic currency information in a storage saving device of a banknote storage device via a banknote-sorting device. [Solution] In the present invention, a banknote-processing apparatus has: a banknote-sorting device (1) having an interface (80) for receiving electronic currency information from a portable terminal (70), and a sorting transmission/reception device (3) for receiving the electronic currency information transmitted from the interface (80); and a banknote storage device (2) for storing supplied banknotes assessed by the banknote-sorting device (1) to be authentic. The electronic currency information transmitted from the sorting transmission/reception device (3) of the banknote-sorting device (1) is received by a storage transmission/reception device (21) of the banknote storage device (2), and the electronic currency information ultimately transmitted from the storage transmission/reception device (21) is saved and accumulated in a storage saving device (22).
G07F 7/02 - Mécanismes actionnés par des objets autres que des pièces de monnaie pour déclencher ou actionner des appareils de vente, de location, de distribution de pièces de monnaie ou de papier-monnaie, ou de remboursement par des clés ou d'autres dispositifs enregistrant un crédit
System and method for funding wagers at live casino gaming tables. The systems and methods may use various interconnections of components including, but not limited to, mobile devices, mobile wallet systems, bill validators, TITO Systems, printers, peripheral systems (e.g., FUZION), player interface devices, wireless interfaces, payment processing systems, casino management systems and others. Wireless interface units may be integrated into casino gaming tables (or positioned nearby) and configured to communicate with mobile devices of the players. The system and methods allow players to use mobile wallets, virtual TITO tickets, physical TITO tickets, and other sources to obtain gaming chips for wagering and receiving cash outs in the same forms.
G06Q 20/32 - Architectures, schémas ou protocoles de paiement caractérisés par l'emploi de dispositifs spécifiques utilisant des dispositifs sans fil
G06Q 20/36 - Architectures, schémas ou protocoles de paiement caractérisés par l'emploi de dispositifs spécifiques utilisant des portefeuilles électroniques ou coffres-forts électroniques
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
60.
SYSTEMS AND METHODS FOR FUNDING GAME PLAY AT CASINO GAMING TABLES
System and method for funding wagers at live casino gaming tables. The systems and methods may use various interconnections of components including, but not limited to, mobile devices, mobile wallet systems, bill validators, TITO Systems, printers, peripheral systems (e.g., FUZION), player interface devices, wireless interfaces, payment processing systems, casino management systems and others. Wireless interface units may be integrated into casino gaming tables (or positioned nearby) and configured to communicate with mobile devices of the players. The system and methods allow players to use mobile wallets, virtual TITO tickets, physical TITO tickets, and other sources to obtain gaming chips for wagering and receiving cash outs in the same forms.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
G06Q 20/32 - Architectures, schémas ou protocoles de paiement caractérisés par l'emploi de dispositifs spécifiques utilisant des dispositifs sans fil
G06Q 20/36 - Architectures, schémas ou protocoles de paiement caractérisés par l'emploi de dispositifs spécifiques utilisant des portefeuilles électroniques ou coffres-forts électroniques
61.
SYSTEMS AND METHODS FOR FUNDING GAME PLAY AT CASINO TABLE GAMES
System and method for funding wagers at live casino gaming tables. The systems and methods may use various interconnections of components including, but not limited to, mobile devices, mobile wallet systems, bill validators, TITO Systems, printers, peripheral systems (e.g., FUZION), player interface devices, wireless interfaces, payment processing systems, casino management systems and others. Wireless interface units may be integrated into casino gaming tables (or positioned nearby) and configured to communicate with mobile devices of the players. The system and methods allow players to use mobile wallets, virtual TITO tickets, physical TITO tickets, and other sources to obtain gaming chips for wagering and receiving cash outs in the same forms.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
09 - Appareils et instruments scientifiques et électriques
Produits et services
Money handling and recognizing devices, namely, banknote acceptors and banknote validators for discriminating true money from counterfeit money and for discriminating between various denominations of money; Money counting and sorting machines.
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) Automated cash box system comprising industrial grade robots, recorded software and automation equipment for processing cash boxes and counting and sorting money.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Money handling and recognizing devices, namely, banknote acceptors and banknote validators for discriminating true money from counterfeit money and for discriminating between various denominations of money; Money counting and sorting machines.
[Problem] To easily construct an optical element of a reflective optical device of a bill validation optical sensor device and replace parts thereof by causing a casing unit accommodating the optical element to engage with an opening of partition walls. [Solution] This bill validation optical sensor device comprises reflective optical devices (13, 30) forming a part of a bill path (20), and the reflective optical devices (13, 30) comprise a casing (41) accommodating an optical element (40). The casing (41) comprises a lid (42) made from an optically transparent material that transmits light radiated from the internal optical element (40) and light reflected by a bill, and a box (43) surrounding the optical element (40) in combination with the lid (42). The lid (42) of the casing (41) engages with an opening (53) of partition walls (11, 12) to form a part of the bill path (20).
G07D 7/00 - Vérification spécialement adaptée à la détermination de l’identité ou de l’authenticité de papiers de valeur ou pour discriminer ceux qui sont inacceptables, p. ex. qui ne correspondent pas à une monnaie
G07D 7/12 - Lumière visible, rayonnement infrarouge ou ultraviolet
The present invention is able to decide whether a note 100 should be discharged even when a transport path length L1 from a reading position 18a for an optical identification sensor 18 to an inlet/outlet 12 that is a note discharging outlet is shorter than the total length LA of the note in a transport direction and a feature quantity from only a portion of the note can be obtained. When an authenticated note 100 is to be discharged, a control means 200 determines the type (denomination) of the note on the basis of a feature quantity for a reading target 103 that passes the optical identification sensor 18 before a leading end 100a of the note 100 as transported in the transport direction protrudes to the outside of the device from the inlet/outlet 12.
Provided is an article conveyance processing system that takes out an article from a mobile cart and/or mounts the article on the mobile cart effectively, even when various types of mobile carts are used. The article conveyance processing system can perform the control of moving a robot hand according to a cart coordinate system having a horizontal axis, a vertical axis, and a depth axis obtained to substantially correspond to a horizontal direction, a vertical direction, and a depth direction of the mobile cart, and a pose control of the robot hand. Thus, the article can be taken out from and/or mounted on the mobile cart effectively, regardless of in what orientation the various types of mobile carts are placed.
The present invention addresses the problem of reducing the possibility that an unintentional entry time or exit time of a person entering or a person leaving a room will be recorded. This entry/exit management system 1 comprises a biometric authentication device 200 and a switch signal transmission means 300A. The biometric authentication device includes a biometric authentication means 200A and a mode switching means 200B. The mode switching means can switch the biometric authentication device between: a stamp mode for recording an entry and/or exit when the biometric authentication means finishes performing authentication; and an authentication mode for only causing the biometric authentication means to perform authentication. The switch signal transmission means transmits, to the biometric authentication device, a switch signal for causing the mode switching means to switch between the modes. The biometric authentication device switches from the authentication mode to the stamp mode when the switch signal is sent from the switch signal transmission means.
G07C 9/37 - Enregistrement de l’entrée ou de la sortie d'une entité isolée ne comportant pas l’utilisation d’un laissez-passer combiné à une vérification d’identité utilisant des données biométriques, p. ex. des empreintes digitales, un balayage de l’iris ou une reconnaissance de la voix
It is the purpose of the present invention to provide an article conveying system that can efficiently proceed conveying work even when the number of articles placed at each shelf position is different in a situation where a plurality of the articles is placed side by side along the depth direction of a shelf. An article conveying system 100 according to the present invention comprises a conveying device 400, a distance measuring device 690, and a management unit 900. The conveying device is capable of conveying an article BL, BS. The distance measuring device measures a distance from a predetermined position to an object in a predetermined direction. The management unit manages presence or absence of the article based on information about the distance to the object measured by the distance measuring device located at the predetermined position.
Provided is an article conveyance processing system that takes out an article from a mobile cart and/or mounts the article on the mobile cart effectively, even when various types of mobile carts are used. The article conveyance processing system can perform the control of moving a robot hand according to a cart coordinate system having a horizontal axis, a vertical axis, and a depth axis obtained to substantially correspond to a horizontal direction, a vertical direction, and a depth direction of the mobile cart, and a pose control of the robot hand. Thus, the article can be taken out from and/or mounted on the mobile cart effectively, regardless of in what orientation the various types of mobile carts are placed.
The present invention addresses the problem of providing an article conveying system that enables a conveyance task to be efficiently carried out even in the case where a plurality of articles are placed side by side along the depth direction of a shelf and where the articles placed in respective placement positions in the shelf vary in number. An article conveying system 100 according to the present invention comprises a conveying device 400, a distance measuring instrument 690, and a management unit 900. The conveying device is capable of conveying articles BL, BS. The distance measuring instrument measures the distance from a prescribed position to an object in a prescribed direction. The management unit manages the presence/absence of articles on the basis of the information on the distance to the object measured by the distance measuring instrument located at the prescribed position.
The present invention effectively prevents deviation in the stopping position of an opening/closing member and fixes the flaw that allows the opening/closing member to be fraudulently returned to an initial rotational posture during standby for reception of a sheet. The present invention comprises an opening/closing member (50), a rotating member (70) that rotates integrally with the opening/closing member, a drive member (90) for driving the opening/closing member that is arranged opposite the rotating member and is axially supported so as to be capable of relative rotation, and a drive transmission mechanism (100) that transmits drive force from the drive member to the rotating member. The drive transmission mechanism comprises a driven piece (74) and a drive piece (92) that presses the driven piece and thereby rotationally drives the rotating member. The value of the circumferential direction play (θ3) between the driven piece and the drive piece is set at a value that can prevent the opening/closing member from being rotated to an initial rotational posture by an external operation when the opening/closing member has stopped in a not-initial rotational posture.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Change machines, being cash dispensing machines; cash
dispensing machines; coin changers; automatic cash sorting
and counting machines; automatic cash registers; cash
registers; automated cash accounting and settlement
machines; accounting machines; acceptors, validators and
discriminators for banknotes, currencies, coupons or printed
securities; banknotes and coins recycling unit which handles
deposits, dispenses banknotes and coins, and also recycles
deposited banknotes and coins to dispense them; banknotes
dispensers; cash dispensers; money dispensers; banknotes and
coins counters; sorters for banknotes, currencies, coupons
or other printed securities; paper currency detectors;
currency detectors; banknote sorting machines; banknote
counting machines; automated bank note sorting machines;
banknote acceptors; apparatus for checking the authenticity
of banknotes; counterfeit coin detectors; currency
authentication apparatus and equipment; money counting and
sorting machines; automated teller machines [ATM].
78.
Information processing device and information processing system
The present invention reduces the amount of data for generating history information that can identify the time when a paper sheet moves along a transport path. The present invention includes an update unit (103) that updates reference timers (Ta and Tb) at predetermined time intervals (10 μs and 1 ms), respectively, an initializing unit (104) that initializes the reference timers at predetermined time intervals (5 s and 25 s), respectively, a storage unit (102) that stores therein the numbers of times of the initialization, and a saving unit (105) that saves difference information (D) identifying current values of the reference timers and the numbers of times of the initialization when a paper sheet moves along a transport path (P).
G07D 11/20 - Commande ou surveillance du fonctionnement des dispositifsManiement de données
G07D 11/237 - Moyens de mesure ou de détection pour surveiller ou indiquer les conditions de fonctionnementMoyens de mesure ou de détection pour détecter les dysfonctionnements pour détecter les dysfonctionnements de transport, p. ex. le bourrage ou le blocage
A63F 7/02 - Jeux d'intérieur utilisant de petits éléments de jeu mobiles, p. ex. des boules, billes, disques ou cubes utilisant des éléments de jeu tombant ou des éléments de jeu roulant sur une surface inclinée, p. ex. billards électriques
79.
PAPER SHEET PROCESSING SYSTEM, PAPER SHEET PROCESSING METHOD, AND PROGRAM
The present invention addresses the problem of enabling setting of a suitable identification strength while reducing the processing load in a paper sheet identification device. The present invention is a paper sheet processing system comprising a paper sheet identification device that identifies a paper sheet retrieved from a paper sheet receiving device, and a paper sheet management device that is capable of communicating with the paper sheet identification device, wherein: the paper sheet management device is provided with a determination unit that determines strength information on the basis of device type information specifying the type of the paper sheet receiving device, and a transmission unit that transmits the determined strength information; and the paper sheet identification device is provided with a reception unit that receives the strength information, a strength setting unit that sets an identification strength using the received strength information, and an identification unit that identifies the paper sheet using the set identification strength.
G07D 7/00 - Vérification spécialement adaptée à la détermination de l’identité ou de l’authenticité de papiers de valeur ou pour discriminer ceux qui sont inacceptables, p. ex. qui ne correspondent pas à une monnaie
Provided is a paper sheet processing system such that theft of paper sheets is inhibited. This paper sheet processing system comprises a paper sheet processing device that counts paper sheets and a paper sheet management device that is capable of communication with the paper sheet processing device. The paper sheet processing device is provided with: an acquisition unit that acquires, from a paper sheet, paper sheet distinguishing information for uniquely distinguishing the paper sheet; and a transmission unit that transmits the acquired paper sheet distinguishing information to the paper sheet management device. The paper sheet management device comprises a reception unit that receives the paper sheet distinguishing information, an identification unit that identifies the paper sheet distinguishing information of a lost paper sheet, and a notification unit that issues a notification to an external device of the paper sheet distinguishing information identified by the identification unit.
Provided is a paper sheet processing system which enables setting of an appropriate specific accumulation part in a paper sheet processing device. This paper sheet processing system comprises: a paper sheet processing device that is capable of allocating paper sheets constituting a paper sheet bundle to a plurality of accumulation parts; and a paper sheet management device that is capable of communicating with the paper sheet processing device. The paper sheet processing device comprises: an allocation setting unit for setting one of the accumulation parts as a specific accumulation part; an allocation execution unit for allocating specific paper sheets of the paper sheets constituting the paper sheet bundle to the specific accumulation part; and an allocation halting unit for halting the operation of allocating the paper sheets when a predetermined number of paper sheets have been accumulated in the accumulation parts. The paper sheet management device comprises: a storage unit for storing paper sheet information in which the number of the specific paper sheets included in the paper sheet bundle is specified; a determination unit that determines, on the basis of the number of the specific paper sheets specified in the paper sheet information, an accumulation part to be set as the specific accumulation part, and a notification unit that notifies the paper sheet processing device of the information in which the accumulation part determined by the determination unit is specified.
A banknote transport system 10 includes: an air blowing tube 100 that forms an air flow path 101; a moving body 200 that travels inside the air blowing tube while receiving an air flow within the air blowing tube; a transport path 401 (a transport tube 400) having at least a portion arranged along the air blowing tube to be adjacent to the air blowing tube; and a transport body 500 configured to be able to retain a banknote and traveling inside the transport path. The moving body includes a moving body magnet 213, and the transport body includes a transport body magnet 523. The banknote transport system moves the transport body in conjunction with movement of the moving body receiving the air flow due to attraction and/or repulsion based on a magnetic force applied between the moving body magnet and the transport body magnet.
It is an object of the present invention to provide an object conveying robot which is less prone to be limited in the dimensions of shelves. The object conveying robot according to the present invention comprises a robot hand 100 and a hand moving mechanism. The robot hand includes an articulated telescopic link mechanism 130 and a grasping portion 140, 143. The articulated telescopic link mechanism is capable of being telescopic by moving a plurality of nodes K1 to K14 along a first virtual plane Fp. The grasping portion is attached to the distal end side of the articulated telescopic link mechanism. The hand moving mechanism, is connected to the robot hand. Further, the robot hand assumes a posture in which the first virtual plane is parallel to the substantially vertical direction at least at the time of extension and contraction of the articulated telescopic link mechanism. Selected figure: Fig. 1
It is an object of the present invention not only to enable an object to be automatically placed at a conveying-in position of a conveying processing system, but also to enable the object to be placed at the time of conveying in the object in a posture different from a posture at the time of processing the object. The conveying processing system of the present invention comprises a first conveying device, a second conveying device, and a processing device. The first conveying device includes a conveying mechanism for conveying an object, and a posture control mechanism capable of controlling a posture of the object. The first conveying device changes the posture of the object by the posture control mechanism and conveys the object from a first position to a second position. The second conveying device performs at least one operation of a conveying-in operation for conveying in the object in a first posture to the first position of the first conveying device and a conveying-out operation for conveying out the object in a second posture from the second position of the first conveying device. The processing device applies a processing to the object which is made into a third posture by the first conveying device. When the second conveying device performs the conveying-in operation, the posture control mechanism changes the posture of the object from the first posture to the third posture, and when the second conveying device performs the conveying-out operation, the posture control mechanism changes the object in the third posture to the second posture.
B65G 47/248 - Dispositifs pour influencer la position relative ou l'orientation des objets pendant le transport par transporteurs présentant les objets selon un orientement donné en les retournant ou en les intervertissant
A conveying robot/system configured to: (i) operate within limitations of spaces defined by shelving, (ii) remove or place an object in spaces defined by shelving and (iii) enable an object to be automatically placed at a conveying-in position of a conveying processing system and manipulate the object's posture so that the object's posture changes from the object being conveyed to the object being processed. The system includes one or more of a robot hand with a grasping portion, articulated link mechanism, object placing shelf, box body, key and a lock. In one version, the box body is a bill storage container of the type used to store currency, coupons and tickets in electronic gaming devices located in a casino environment.
The present invention addresses the problem of providing an article transporting robot that is hardly restricted by the dimensions of shelves. The article transporting robot according to the present invention comprises a robot hand 100 and a hand moving mechanism. The robot hand includes an articulated flexible link mechanism 130 and gripping parts 140, 143. The articulated flexible link mechanism is formed so as to be capable of expanding and contracting due to the movement of a plurality of joints K1-14 along a first virtual surface Fp. The gripping parts are attached at the distal end side of the articulated flexible link mechanism. The hand moving mechanism is connected to the robot hand. Furthermore, the robot hand is set to an attitude in which a first virtual surface is parallel to a substantially vertical direction when at least the articulated flexible link mechanism is expanded.
This transport processing system enables not only placing an article automatically at an import location of the transport processing system, but also enables, when an article is imported, the article to be placed at an orientation different from the orientation of the article that is taken when the article is processed. The transport processing system according to the present invention is provided with: a first transport device, a second transport device, and a processing device. The first transport device has a transport mechanism that transports an article, and an orientation control mechanism that is capable of controlling the orientation of the article. The first transport device changes, by the orientation control mechanism, the orientation of an article and transports the article from a first location to a second location. The second transport device performs a transport operation of importing an article in a first orientation to a first location of the first transport device, and/or an export operation of exporting an article in a second orientation from a second location of the first transport device. The processing device processes an article which has been set in a third orientation by the first transport device. The orientation control mechanism changes the orientation of an article from the first orientation to the third orientation when the second transport device is to perform the import operation, and changes the orientation of an article from the third orientation to the second orientation when the second transport device is to perform the export operation.
B65G 47/248 - Dispositifs pour influencer la position relative ou l'orientation des objets pendant le transport par transporteurs présentant les objets selon un orientement donné en les retournant ou en les intervertissant
It is an object of the present invention to provide an object conveying robot system capable of automatically performing a work of unloading an object placed on a shelf or a work of loading an object on the shelf. An object conveying robot system according to the present invention comprises a robot hand 100 and an object placing shelf 200. The robot hand includes a grasping portion 140, 143. The grasping portion grasps an object Bx. The object placing shelf is for placing the object. The robot hand can move linearly with respect to the object placing shelf. This robot hand is configured to move linearly to pull out the object from the object placing shelf, and to move linearly to store the object in the object placing shelf. The object placing shelf includes a shelf plate 220 and a guide wall Wv. The object is placed on the shelf plate. The guide wall guides the robot hand which is moving linearly. Selected figure: Fig. 11
The present invention addresses the problem of providing an article conveying robot system that makes it possible to automatically load articles onto a shelf or to automatically unload articles that have been stored on the shelf. This article conveying robot system comprises a robot hand 100 and an article storage shelf 200. The robot hand has gripping parts 140, 143. The gripping parts are for gripping articles Bx. The article storage shelf is for storing articles. The robot hand can move rectilinearly relative to the article storage shelf. The robot hand rectilinearly pulls articles off the article storage shelf and rectilinearly stores articles on the article storage shelf. The article storage shelf has a shelf plate 220 and guide walls Wv. Articles are stored on the shelf plate. The guide walls guide the robot hand during the rectilinear movement thereof.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Change machines, being cash dispensing machines; cash dispensing machines; coin changers; automatic cash sorting and counting machines; automatic cash registers; cash registers; accounting machines; acceptors, validators and discriminators for banknotes, currencies, coupons and printed securities; currency sorting machines in the nature of a banknotes and coins recycling unit which handles deposits, dispenses banknotes and coins, and also recycles deposited banknotes and coins to dispense them; cash dispensers; banknotes and coins counters; money sorting machines in the nature of sorters for banknotes, currencies, coupons and other printed securities; paper currency detectors being currency recognition machines; currency detectors being currency recognition machines; currency sorting machines; currency counting machines; automated paper money sorting machines; banknote acceptors for separating good banknotes from counterfeits; apparatus for checking the authenticity of banknotes; counterfeit coin detectors; currency authentication apparatus and equipment, namely, apparatus for checking the authenticity of blockchain tokens; money counting and sorting machines; automatic teller machines (ATM)
91.
Device, system and method for facilitating communications between electronic gaming machines and mobile devices
Various system, method, and device embodiments are disclosed for establishing and utilizing a wireless connection between an electronic gaming machine and a mobile device associated with a player. Such embodiments include use of a first component configured to communicate information with the mobile device using near-field communications and use of a second component configured to automatically pair the mobile device with the mobile interface device, using a Bluetooth connection, wherein the pairing of the mobile device with the mobile interface device utilizes the information communicated to the mobile device using the first component.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
H04W 76/14 - Établissement de la connexion en mode direct
H04W 4/80 - Services utilisant la communication de courte portée, p. ex. la communication en champ proche, l'identification par radiofréquence ou la communication à faible consommation d’énergie
92.
SYSTEM FOR PROVIDING VISUAL DEVICE STATUS VIA A PERIPHERAL DEVICE
System and method for systematically changing the color of lighting associated with a peripheral device (e.g., NFC device) based on the status or condition of the machine (e.g., EGM) to which it is connected and/or the status of another peripheral device connected to the machine. The system and method permit the operator of the machine to program unique illumination schemes corresponding to various machine and/or peripheral conditions. For example, the peripheral device may be illuminated with a unique color for each of a bill validator being offline, a cashbox being near full and a player being near to earning a promotion. The system and method may also be used to visually communicate information related to player tracking, mobile wallet, security issues and any other information concerning a EGM, player or casino.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
93.
SYSTEM FOR PROVIDING VISUAL DEVICE STATUS VIA A PERIPHERAL DEVICE
System and method for systematically changing the color of lighting associated with a peripheral device (e.g., NFC device) based on the status or condition of the machine (e.g., EGM) to which it is connected and/or the status of another peripheral device connected to the machine. The system and method permit the operator of the machine to program unique illumination schemes corresponding to various machine and/or peripheral conditions. For example, the peripheral device may be illuminated with a unique color for each of a bill validator being offline, a cashbox being near full and a player being near to earning a promotion. The system and method may also be used to visually communicate information related to player tracking, mobile wallet, security issues and any other information concerning a EGM, player or casino.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
09 - Appareils et instruments scientifiques et électriques
Produits et services
Automated cash box system comprising industrial grade robots, recorded software and automation equipment for processing cash boxes and counting and sorting money
95.
Crediting and debiting an electronic gaming machine in a casino environment
Devices, systems and methods are provided to enable casino operators to provide printed tangible items for patron uses, such as lottery tickets. Such embodiments accept tangible indicators of financial consideration from patrons, such as currency or tickets associated with certain verifiable values, such as valid and winning lottery tickets and other forms of consideration which a patron can provide to a casino in exchange for one or more points.
G07F 17/32 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions
G07F 17/34 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour jeux, jouets, sports ou distractions dépendant de l'arrêt d'organes mobiles, p. ex. machines à sous
G07F 17/42 - Appareils déclenchés par pièces de monnaie pour la location d'articlesInstallations ou services déclenchés par pièces de monnaie pour appareils pour imprimer des tickets ou analogues
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Providing non-downloadable computer application software for
providing communications and data exchange between programs
and computers in a distributed or networked environment,
namely, gaming software for gambling, computer game software
for video lottery terminals, sports betting software in the
nature of gaming software for gambling, software for
promotional activities, namely, generating and printing
promotional coupons and vouchers, parimutuel betting
software in the nature of gaming software for gambling,
fantasy football software in the nature of gaming software
for gambling, and software for W-2G form filling and
printing; all of the aforementioned excluding internet
promotions.
97.
PAPER SHEET HANDLING DEVICE, METHOD FOR CALCULATING NUMBER OF PAPER SHEETS IN PAPER SHEET BUNDLE, AND PROGRAM
Provided is a paper sheet handling device that can calculate the number of paper sheets in a paper sheet bundle being conveyed in a conveyance path without requiring complicated processing. This paper sheet handling device comprises: a conveying unit that can convey a paper sheet bundle; a changing unit that, when a paper bundle is being conveyed, changes in accordance with the thickness of the paper bundle; a generation unit that generates thickness information based on the amount of change in the changing unit; a storage unit that stores reference information determined on the basis of the thickness of one paper sheet; and a calculation unit that calculates the number of paper sheets in the paper sheet bundle from the thickness information and the reference information.
B65H 43/00 - Utilisation de dispositifs de commande de vérification ou de sécurité, p. ex. dispositifs automatiques comportant un élément pour détecter une variable
A63F 7/02 - Jeux d'intérieur utilisant de petits éléments de jeu mobiles, p. ex. des boules, billes, disques ou cubes utilisant des éléments de jeu tombant ou des éléments de jeu roulant sur une surface inclinée, p. ex. billards électriques
Disclosed herein are devices, systems, and methods for automatic handling of bank notes, gambling tickets, bills, or other types of paper notes. The disclosed devices, systems, and methods are directed to, or include, various robot arms, which may be articulated, that are configured to open a bill storage container, remove a bundle of bills, load the bundle on a bill conveying device, and load the bundle of bills in a bill storage case. The systems include one or more control devices to control the operations of the components that move the bill bundle.
Disclosed herein are devices, systems, and methods for automatic handling of bank notes, gambling tickets, bills, or other types of paper notes. The disclosed devices, systems, and methods are directed to, or include, various robot arms, which may be articulated, that are configured to open a bill storage container, remove a bundle of bills, load the bundle on a bill conveying device, and load the bundle of bills in a bill storage case. The systems include one or more control devices to control the operations of the components that move the bill bundle.
The paper sheet processing device includes a bladed wheel 10, a paper sheet supply/transport unit 30, 100, a stacking tray 50 that holds paper sheets emitted from the bladed wheel one by one in a stacked state, and an extraction area 80. The stacking tray includes a first stacking part 51 that stacks thereon paper sheets being emitted when at a paper sheet stacking position P1, and is rotationally moved to a non-stacking position P2 when a predetermined number of paper sheets are stacked thereon, and a second stacking part 61 that is moved to the paper sheet stacking position to stack paper sheets thereon when being rotated by a predetermined angle from the non-stacking position, and is rotationally moved to the non-stacking position when the predetermined number of paper sheets are stacked thereon.
B65H 29/40 - Éléments tournant autour d'un axe perpendiculaire au sens du déplacement des articles, p. ex. des croisillons formés par des éléments en S
B65H 31/32 - Dispositifs auxiliaires pour recevoir les articles pendant l'enlèvement d'une pile achevée
B65H 31/02 - Récepteurs de piles avec support d'extrémité fixe contre lequel la pile s'entasse
B65H 31/30 - Dispositions pour enlever les piles achevées
