Produits et services

Scientific, research, weighing, measuring, signaling, detecting, testing, inspecting and teaching apparatus and instruments; apparatus and instruments for sound, image or data recording, transmission, reproduction or processing; downloadable media, software, blank digital or analog recording and storage media; recorded media, namely recorded computer programs, recorded software, recorded software platforms. Recording, transcription, composition, compilation and systematization of written communications and recordings, as well as compilation of mathematical or statistical data; compilation of information in computer databases; data processing services [office functions]; systematization of information in computer databases.

Abrégé

A process for debinding a green part in which powder particles are held together by a polymer compound, the process comprising a heat treatment of the green part under a non-oxidizing atmosphere, and a thermochemical treatment of the green part under an oxidizing atmosphere for a duration less than or equal to a predetermined duration, the heat treatment and the thermochemical treatment being carried out in a same enclosure and at temperatures less than the sintering temperature (Tf) of the powder particles.

Classes IPC  ?

• B22F 10/10 - Formation d’un corps vert
• B22F 10/20 - Frittage ou fusion directs
• B33Y 10/00 - Procédés de fabrication additive
• B33Y 40/20 - Posttraitement, p. ex. durcissement, revêtement ou polissage

Produits et services

Detection apparatus; data processing apparatus; recorded computer programs; electric checking and measuring apparatus; measuring, detection and monitoring instruments, indicators and controllers; pressure, temperature and speed indicators; electric installations for the remote control of industrial operations; voltage surge protectors; recorded software; software dedicated to industrial production management; downloadable software application dedicated to industrial production management; recorded or downloadable software platform dedicated to industrial production management; software for remote control and monitoring of industrial operations; downloadable software application for remote monitoring and control of industrial operations. Advisory, study and assistance services for industrial companies in the conduct of their business; services involving the recording and transcription, composition, compilation or systematization of recordings, of mathematical or statistical data; data search in computer files for others; statistical information, research and studies in the field of industrial production; compilation of information in computerized registers and computer databases in the field of industrial production; compilation of information related to industrial production management; information services in the field of data processing; compilation of statistics in the field of industrial production. Engineering services for industrial production, Platform as a Service (PaaS) dedicated to industrial production management; software service (SaaS) in the field of industrial production; development (design) of software, updating of software and databases, maintenance of software, consultation with respect to computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; conducting of technical projects in product and process engineering in the following fields: aeronautics, space, automotive, defense, energies, railway, industrial vehicles, naval, industries, petrochemical, computing, electronics and telecom, computation and digital simulation, automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services.

Produits et services

Detection apparatus; data processing apparatus; recorded computer programs; electric checking and measuring apparatus; measuring, detection and monitoring instruments, indicators and controllers; pressure, temperature and speed indicators; electric installations for the remote control of industrial operations; voltage surge protectors; recorded software; software dedicated to industrial production management; downloadable software application dedicated to industrial production management; recorded or downloadable software platform dedicated to industrial production management; software for remote control and monitoring of industrial operations; downloadable software application for remote monitoring and control of industrial operations. Advisory, study and assistance services for industrial companies in the conduct of their business; services involving the recording and transcription, composition, compilation or systematization of recordings, of mathematical or statistical data; data search in computer files for others; statistical information, research and studies in the field of industrial production; compilation of information in computerized registers and computer databases in the field of industrial production; compilation of information related to industrial production management; information services in the field of data processing; compilation of statistics in the field of industrial production. Engineering services for industrial production, Platform as a Service (PaaS) dedicated to industrial production management; software service (SaaS) in the field of industrial production; development (design) of software, updating of software and databases, maintenance of software, consultation with respect to computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; conducting of technical projects in product and process engineering in the following fields: aeronautics, space, automotive, defense, energies, railway, industrial vehicles, naval, industries, petrochemical, computing, electronics and telecom, computation and digital simulation, automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services.

Abrégé

A measurement system comprising a sensor and a controller configured to communicate with the sensor, the controller comprising a display. The sensor comprises at least two measurement assemblies and at least one processing circuit connected to one or more sensing elements each measuring a current value of the same parameter. Each processing circuit emits to the controller a measurement signal as a function of the current value measured by the one or more sensing elements and of a stored reference value. The controller is configured: i) to transmit the reference value to each processing circuit that stores it if the reference value is equal to within a margin of the measured current value, and ii) to receive the measurement signals and display respective symbols on the display, the symbols being at least dissimilar or displayed alternately.

Classes IPC  ?

• G01L 5/24 - Appareils ou procédés pour la mesure des forces, du travail, de la puissance mécanique ou du couple, spécialement adaptés à des fins spécifiques pour déterminer la valeur du couple ou du moment de torsion pour le serrage d'un écrou ou d'un autre organe soumis à une contrainte analogue
• G01L 3/10 - Dynamomètres de transmission rotatifs dans lesquels l'élément transmettant le couple comporte un arbre élastique en torsion impliquant des moyens électriques ou magnétiques d'indication

Produits et services

Detection apparatus; data processing apparatus; recorded computer programs; electric checking and measuring apparatus; measuring, detection and monitoring instruments, indicators and controllers; pressure, temperature and speed indicators; electric installations for the remote control of industrial operations; voltage surge protectors; recorded software; software dedicated to industrial production management; downloadable software application dedicated to industrial production management; recorded or downloadable software platform dedicated to industrial production management; software for remote control and monitoring of industrial operations; downloadable software application for remote monitoring and control of industrial operations. Advisory, study and assistance services for industrial companies in the conduct of their business; services involving the recording and transcription, composition, compilation or systematization of recordings, of mathematical or statistical data; data search in computer files for others; statistical information, research and studies in the field of industrial production; compilation of information in computerized registers and computer databases in the field of industrial production; compilation of information related to industrial production management; information services in the field of data processing; compilation of statistics in the field of industrial production. Engineering services for industrial production, Platform as a Service (PaaS) dedicated to industrial production management; software service (SaaS) in the field of industrial production; development (design) of software, updating of software and databases, maintenance of software, consultation with respect to computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; conducting of technical projects in product and process engineering in the following fields: aeronautics, space, automotive, defense, energies, railway, industrial vehicles, naval, industries, petrochemical, computing, electronics and telecom, computation and digital simulation, automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services.

Produits et services

(1) Appareils et instruments scientifiques, de recherche, de pesage, de mesurage, de signalisation, de détection, d'essai, d'inspection et d'enseignement; appareils et instruments pour l'enregistrement, la transmission, la reproduction ou le traitement de sons, d'images ou de données; supports téléchargeables, logiciels, supports d'enregistrement et de stockage numériques ou analogues vierges; supports enregistrés, à savoir programmes informatiques enregistrés, logiciels enregistrés, plateformes logicielles enregistrées. (1) Services d'enregistrement, de transcription, de composition, de compilation et de systématisation de communications écrites et d'enregistrements, ainsi que de compilation de données mathématiques ou statistiques; compilation d'informations dans des bases de données informatiques; services de traitement de données [travaux de bureau]; systématisation d'informations dans des bases de données informatiques.

Produits et services

Scientific, research, weighing, measuring, signaling, detecting, testing, inspecting and teaching apparatus and instruments; apparatus and instruments for sound, image or data recording, transmission, reproduction or processing; downloadable media, software, blank digital or analog recording and storage media; recorded media, namely recorded computer programs, recorded software, recorded software platforms. Recording, transcription, composition, compilation and systematization of written communications and recordings, as well as compilation of mathematical or statistical data; compilation of information in computer databases; data processing services [office functions]; systematization of information in computer databases.

Produits et services

Detection apparatus; data processing apparatus; recorded computer programs; electric checking and measuring apparatus; measuring, detection and monitoring instruments, indicators and controllers; pressure, temperature and speed indicators; electric installations for the remote control of industrial operations; voltage surge protectors; recorded software; software dedicated to industrial production management; downloadable software application dedicated to industrial production management; recorded or downloadable software platform dedicated to industrial production management; software for remote control and monitoring of industrial operations; downloadable software application for remote monitoring and control of industrial operations. Advisory, study and assistance services for industrial companies in the conduct of their business; services involving the recording and transcription, composition, compilation or systematization of recordings, of mathematical or statistical data; data search in computer files for others; statistical information, research and studies in the field of industrial production; compilation of information in computerized registers and computer databases in the field of industrial production; compilation of information related to industrial production management; information services in the field of data processing; compilation of statistics in the field of industrial production. Engineering services for industrial production, Platform as a Service (PaaS) dedicated to industrial production management; software service (SaaS) in the field of industrial production; development (design) of software, updating of software and databases, maintenance of software, consultation with respect to computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; conducting of technical projects in product and process engineering in the following fields: aeronautics, space, automotive, defense, energies, railway, industrial vehicles, naval, industries, petrochemical, computing, electronics and telecom, computation and digital simulation, automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services.

Produits et services

Detection apparatus; data processing apparatus; recorded computer programs; electric checking and measuring apparatus; measuring, detection and monitoring instruments, indicators and controllers; pressure, temperature and speed indicators; electric installations for the remote control of industrial operations; voltage surge protectors; recorded software; software dedicated to industrial production management; downloadable software application dedicated to industrial production management; recorded or downloadable software platform dedicated to industrial production management; software for remote control and monitoring of industrial operations; downloadable software application for remote monitoring and control of industrial operations. Advisory, study and assistance services for industrial companies in the conduct of their business; services involving the recording and transcription, composition, compilation or systematization of recordings, of mathematical or statistical data; data search in computer files for others; statistical information, research and studies in the field of industrial production; compilation of information in computerized registers and computer databases in the field of industrial production; compilation of information related to industrial production management; information services in the field of data processing; compilation of statistics in the field of industrial production. Engineering services for industrial production, Platform as a Service (PaaS) dedicated to industrial production management; software service (SaaS) in the field of industrial production; development (design) of software, updating of software and databases, maintenance of software, consultation with respect to computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; conducting of technical projects in product and process engineering in the following fields: aeronautics, space, automotive, defense, energies, railway, industrial vehicles, naval, industries, petrochemical, computing, electronics and telecom, computation and digital simulation, automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services.

Produits et services

Detection apparatus; data processing apparatus; recorded computer programs; electric checking and measuring apparatus; measuring, detection and monitoring instruments, indicators and controllers; pressure, temperature and speed indicators; electric installations for the remote control of industrial operations; voltage surge protectors; recorded software; software dedicated to industrial production management; downloadable software application dedicated to industrial production management; recorded or downloadable software platform dedicated to industrial production management; software for remote control and monitoring of industrial operations; downloadable software application for remote monitoring and control of industrial operations. Advisory, study and assistance services for industrial companies in the conduct of their business; services involving the recording and transcription, composition, compilation or systematization of recordings, of mathematical or statistical data; data search in computer files for others; statistical information, research and studies in the field of industrial production; compilation of information in computerized registers and computer databases in the field of industrial production; compilation of information related to industrial production management; information services in the field of data processing; compilation of statistics in the field of industrial production. Engineering services for industrial production, Platform as a Service (PaaS) dedicated to industrial production management; software service (SaaS) in the field of industrial production; development (design) of software, updating of software and databases, maintenance of software, consultation with respect to computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; conducting of technical projects in product and process engineering in the following fields: aeronautics, space, automotive, defense, energies, railway, industrial vehicles, naval, industries, petrochemical, computing, electronics and telecom, computation and digital simulation, automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services.

Abrégé

Indirect additive manufacturing installation for indirect additive manufacturing by projection of binder onto a powder bed, comprising a support, a powder supply means configured to form successive powder beds on the support, a print head configured to selectively project the binder onto each of the successive powder beds, and a counting device for counting the drops of binder projected by the print head onto the powder beds. A method for indirect additive manufacturing by projecting binder onto a powder bed, comprising forming successive powder beds on a support, selectively projecting binder onto each of the powder beds, the method further comprising counting the projected binder drops.

Classes IPC  ?

• B29C 64/393 - Acquisition ou traitement de données pour la fabrication additive pour la commande ou la régulation de procédés de fabrication additive
• B29C 64/165 - Procédés de fabrication additive utilisant une combinaison de matériaux solides et liquides, p. ex. une poudre avec liaison sélective par liant liquide, catalyseur, inhibiteur ou absorbeur d’énergie
• B33Y 10/00 - Procédés de fabrication additive
• B33Y 30/00 - Appareils pour la fabrication additiveLeurs parties constitutives ou accessoires à cet effet
• B33Y 50/02 - Acquisition ou traitement de données pour la fabrication additive pour la commande ou la régulation de procédés de fabrication additive

Abrégé

Nut retaining devices and related methods are disclosed. An exemplary nut retaining device may include a housing defining an interior receptacle, the housing including attachment structure configured for fixing the housing to a base structure; a nut received within the receptacle and having screw threads for engaging a threaded fastener; retaining structure engageable with the nut and retaining the nut within the receptacle; anti-rotation structure between the housing and the nut constraining the nut against rotation relative to the housing; the anti-rotation structure configured to provide a clearance movement between the nut and the housing in at least one of a rotation direction rotationally about the screwing axis of the nut, or an axial direction parallel to the screwing axis of the nut, or a radial direction relative to the axial direction that is parallel to the screwing axis of the nut.

Classes IPC  ?

• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques

Classes IPC  ?

• F16B 39/10 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par une plaque ou un anneau immobile par rapport au boulon ou à l'objet
• F16B 39/24 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet
• F16B 39/32 - Blocage par cliquet ou languette genre cliquet

Abrégé

The invention relates to a retaining part (20) comprising elastic bearing elements configured to secure rotary assembly elements (4). The invention also relates to a wheel of an aircraft landing gear, equipped with such a retaining part (20). The invention also relates to a method for manufacturing such a retaining part (20).

Classes IPC  ?

• F16B 39/10 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par une plaque ou un anneau immobile par rapport au boulon ou à l'objet
• F16B 39/24 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet
• F16B 39/32 - Blocage par cliquet ou languette genre cliquet

Abrégé

Couplers configured to connect a first reinforcing bar end portion of a first reinforcing bar with a second reinforcing bar end portion of a second reinforcing bar are disclosed. In some embodiments, the first and second reinforcing bar end portions include radially outwardly facing, substantially parallel, circumferentially oriented reinforcing bar end portion grooves. An exemplary coupler includes a first reinforcing bar connecting portion configured to receive the first reinforcing bar end portion, the first reinforcing bar connecting portion comprising a plurality of first reinforcing bar connecting portion engagement elements arranged to extend radially inward into the first reinforcing bar end portion grooves, and a second reinforcing bar connecting portion configured to receive the second reinforcing bar end portion, the second reinforcing bar connecting portion comprising a plurality of second reinforcing bar connecting portion engagement elements arranged to extend radially inward into the second reinforcing bar end portion grooves.

Classes IPC  ?

• E04C 5/16 - Pièces auxiliaires pour armatures, p. ex. pièces de séparation, étriers
• E04G 21/12 - Montage d'éléments d'armatureApplication de la précontrainte

Abrégé

Nut retaining devices and related methods are disclosed. An exemplary nut retaining device may include a housing defining an interior receptacle, the housing including attachment structure configured for fixing the housing to a base structure; a nut received within the receptacle and having screw threads for engaging a threaded fastener; retaining structure engageable with the nut and retaining the nut within the receptacle; anti-rotation structure between the housing and the nut constraining the nut against rotation relative to the housing; the anti-rotation structure configured to provide a clearance movement between the nut and the housing in at least one of a rotation direction rotationally about the screwing axis of the nut, or an axial direction parallel to the screwing axis of the nut, or a radial direction relative to the axial direction that is parallel to the screwing axis of the nut.

Classes IPC  ?

• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques

Abrégé

Nut retaining devices and related methods are disclosed. An exemplary nut retaining device may include a housing defining an interior receptacle, the housing including attachment structure configured for fixing the housing to a base structure; a nut received within the receptacle and having screw threads for engaging a threaded fastener; retaining structure engageable with the nut and retaining the nut within the receptacle; anti-rotation structure between the housing and the nut constraining the nut against rotation relative to the housing; the anti-rotation structure configured to provide a clearance movement between the nut and the housing in at least one of a rotation direction rotationally about the screwing axis of the nut, or an axial direction parallel to the screwing axis of the nut, or a radial direction relative to the axial direction that is parallel to the screwing axis of the nut.

Classes IPC  ?

• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques

Abrégé

A locking fitting assembly that can be removably installed in a tapped hole on a housing and resists unintended loosening of the fitting assembly. The fitting assembly maybe installed at a mounting location for receiving the fitting assembly, and includes abase with engagement structure configured to engage corresponding structure adjacent the mounting location to secure the base against rotation. The fitting assembly further includes a nipple fitting received on the base and having first and second oppositely disposed coupling features. The first coupling feature is configured to mate with a complementary coupling feature of the housing, such as the tapped hole, whereby the nipple fitting can be sealingly secured to the housing. Locking structure disposed between the base and the nipple fitting is configured to resist relative rotation between the base and the nipple fitting.

Classes IPC  ?

• F16L 15/08 - Raccords avec filetageFormes des filetages pour ces raccords avec des éléments supplémentaires

Abrégé

An instrumented, load-sensing washer that can be used on a bolted joint to facilitate determining an axial clamping load of the bolted joint. The washer includes an annular washer body having first and second oppositely disposed axial ends and an outer circumferential sidewall. At least one strain gauge is provided on the circumferential sidewall and is configured to sense a deformation of the washer body do to clamping forces of the bolted joint. The washer further includes a communication assembly operatively coupled with the at least one strain gauge. The communication assembly may include an integrated circuit adapted to receive electrical signals from the at least one strain gauge related to the axial load borne by the washer.

Classes IPC  ?

• F16B 31/02 - Assemblages à vis spécialement modifiés en vue de résister à une charge de tractionBoulons de rupture signalant ou limitant la charge de traction
• G01L 5/24 - Appareils ou procédés pour la mesure des forces, du travail, de la puissance mécanique ou du couple, spécialement adaptés à des fins spécifiques pour déterminer la valeur du couple ou du moment de torsion pour le serrage d'un écrou ou d'un autre organe soumis à une contrainte analogue
• G01L 1/22 - Mesure des forces ou des contraintes, en général en mesurant les variations de la résistance ohmique des matériaux solides ou des fluides conducteurs de l'électricitéMesure des forces ou des contraintes, en général en faisant usage des cellules électrocinétiques, c.-à-d. des cellules contenant un liquide, dans lesquelles un potentiel électrique est produit ou modifié par l'application d'une contrainte en utilisant des jauges de contrainte à résistance

Abrégé

A nut includes locking jaws, a floating end of which is actuated by cam profiles inside a rotary actuation ring. The jaws are produced by removing material from the body of the nut, and shift from a locking state to a release state and vice versa by elastic bending deformation. A locking surface on the inside of the jaws has the same thread as the body of the nut.

Classes IPC  ?

• F16B 39/284 - Blocage par déformation élastique

Abrégé

A fluid-tight fitting includes at least one strain gauge or includes at least one passage, said passage extending radially through a nut and communicating with an interior chamber defined by a first conduit, a second conduit, and the nut, or includes a visual indicator associated with at least one of a nut or a first conduit of the fitting.

Classes IPC  ?

• F16L 19/06 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord dans lesquels le serrage radial est obtenu par une action de coincement entre les extrémités non déformées du tuyau
• F16L 19/025 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé les colliers ou les brides formant partie intégrante des extrémités du tuyau

Abrégé

A locking fitting assembly that can be removably installed in a tapped hole on a housing and resists unintended loosening of the fitting assembly. The fitting assembly maybe installed at a mounting location for receiving the fitting assembly, and includes a base with engagement structure configured to engage corresponding structure adjacent the mounting location to secure the base against rotation. The fitting assembly further includes a nipple fitting received on the base and having first and second oppositely disposed coupling features. The first coupling feature is configured to mate with a complementary coupling feature of the housing, such as the tapped hole, whereby the nipple fitting can be sealingly secured to the housing. Locking structure disposed between the base and the nipple fitting is configured to resist relative rotation between the base and the nipple fitting.

Classes IPC  ?

• F16L 15/08 - Raccords avec filetageFormes des filetages pour ces raccords avec des éléments supplémentaires
• F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents
• F16B 39/284 - Blocage par déformation élastique

Abrégé

A locking fitting assembly that can be removably installed in a tapped hole on a housing and resists unintended loosening of the fitting assembly. The fitting assembly maybe installed at a mounting location for receiving the fitting assembly, and includes a base with engagement structure configured to engage corresponding structure adjacent the mounting location to secure the base against rotation. The fitting assembly further includes a nipple fitting received on the base and having first and second oppositely disposed coupling features. The first coupling feature is configured to mate with a complementary coupling feature of the housing, such as the tapped hole, whereby the nipple fitting can be sealingly secured to the housing. Locking structure disposed between the base and the nipple fitting is configured to resist relative rotation between the base and the nipple fitting.

Classes IPC  ?

• F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents
• F16B 39/284 - Blocage par déformation élastique
• F16L 15/08 - Raccords avec filetageFormes des filetages pour ces raccords avec des éléments supplémentaires

Abrégé

An instrumented, load-sensing washer that can be used on a bolted joint to facilitate determining an axial clamping load of the bolted joint. The washer includes an annular washer body having first and second oppositely disposed axial ends and an outer circumferential sidewall. At least one strain gauge is provided on the circumferential sidewall and is configured to sense a deformation of the washer body do to clamping forces of the bolted joint. The washer further includes a communication assembly operatively coupled with the at least one strain gauge. The communication assembly may include an integrated circuit adapted to receive electrical signals from the at least one strain gauge related to the axial load borne by the washer.

Classes IPC  ?

• F16B 31/02 - Assemblages à vis spécialement modifiés en vue de résister à une charge de tractionBoulons de rupture signalant ou limitant la charge de traction
• G01L 1/22 - Mesure des forces ou des contraintes, en général en mesurant les variations de la résistance ohmique des matériaux solides ou des fluides conducteurs de l'électricitéMesure des forces ou des contraintes, en général en faisant usage des cellules électrocinétiques, c.-à-d. des cellules contenant un liquide, dans lesquelles un potentiel électrique est produit ou modifié par l'application d'une contrainte en utilisant des jauges de contrainte à résistance
• G01L 5/24 - Appareils ou procédés pour la mesure des forces, du travail, de la puissance mécanique ou du couple, spécialement adaptés à des fins spécifiques pour déterminer la valeur du couple ou du moment de torsion pour le serrage d'un écrou ou d'un autre organe soumis à une contrainte analogue

Abrégé

An instrumented, load-sensing washer that can be used on a bolted joint to facilitate determining an axial clamping load of the bolted joint. The washer includes an annular washer body having first and second oppositely disposed axial ends and an outer circumferential sidewall. At least one strain gauge is provided on the circumferential sidewall and is configured to sense a deformation of the washer body do to clamping forces of the bolted joint. The washer further includes a communication assembly operatively coupled with the at least one strain gauge. The communication assembly may include an integrated circuit adapted to receive electrical signals from the at least one strain gauge related to the axial load borne by the washer.

Classes IPC  ?

• G01L 5/24 - Appareils ou procédés pour la mesure des forces, du travail, de la puissance mécanique ou du couple, spécialement adaptés à des fins spécifiques pour déterminer la valeur du couple ou du moment de torsion pour le serrage d'un écrou ou d'un autre organe soumis à une contrainte analogue
• F16B 31/02 - Assemblages à vis spécialement modifiés en vue de résister à une charge de tractionBoulons de rupture signalant ou limitant la charge de traction
• G01L 1/22 - Mesure des forces ou des contraintes, en général en mesurant les variations de la résistance ohmique des matériaux solides ou des fluides conducteurs de l'électricitéMesure des forces ou des contraintes, en général en faisant usage des cellules électrocinétiques, c.-à-d. des cellules contenant un liquide, dans lesquelles un potentiel électrique est produit ou modifié par l'application d'une contrainte en utilisant des jauges de contrainte à résistance

Abrégé

A nut is prevented from turning during screwing by a body attached to one of the parts to be tightened by rivets. The body prevents the nut from rotating via a ring coupled without clearance with the nut and coupled with radial clearance to the body, in order to allow the nut to self-position itself along the axis imposed on the screw by the bores traversed by the screw. The nut can thus be a standard nut or a floating cage nut. Application to the retaining of nuts that are inaccessible and/or require a high level of security against unintentional unscrewing.

Classes IPC  ?

• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques

Abrégé

The nut comprises locking jaws (14), a floating end of which is actuated by cam profiles inside a rotary actuation ring (19). The jaws are produced by removing material from the body (11) of the nut and shift from the locking state to the release state and vice versa by elastic bending deformation. The locking surface (16) on the inside of the jaws lias the same thread as the body of the nut.

Classes IPC  ?

• F16B 39/12 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par écrous de blocage, c.-à-d. contre-écrous
• F16B 39/284 - Blocage par déformation élastique

Abrégé

The nut comprises locking jaws (14), a floating end of which is actuated by cam profiles inside a rotary actuation ring (19). The jaws are produced by removing material from the body (11) of the nut and shift from the locking state to the release state and vice versa by elastic bending deformation. The locking surface (16) on the inside of the jaws has the same thread as the body of the nut.

Classes IPC  ?

• F16B 39/12 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par écrous de blocage, c.-à-d. contre-écrous
• F16B 39/284 - Blocage par déformation élastique
• F16B 39/32 - Blocage par cliquet ou languette genre cliquet
• F16B 21/18 - Dispositifs sans filetage pour empêcher le mouvement relatif selon l'axe d'une broche, d'un ergot, d'un arbre ou d'une pièce analogue par rapport à l'organe qui l'entoureFixations à ergots et douilles largables sans filetage à parties séparées par gorges ou encoches pratiquées dans l'axe ou l'arbre et avec bague annulaire formant ressort insérée dans la gorge (circlip) ou autre dispositif élastique de fixation du même genreDispositifs sans filetage pour empêcher le mouvement relatif selon l'axe d'une broche, d'un ergot, d'un arbre ou d'une pièce analogue par rapport à l'organe qui l'entoureFixations à ergots et douilles largables sans filetage à parties séparées par gorges ou encoches pratiquées dans l'axe ou l'arbre Détails

Abrégé

The invention relates to a fluid-tight connector which includes: - either at least one strain gauge (80; 86), - either at least one passage (78), said passage extending radially through a nut (22) and communicating with an interior chamber (76) defined by a first conduit (12) of the connector, a second conduit (14) and the nut (22), - either a visual indicator (40; 50; 60; 62) associated with at least one of a nut or a first conduit.

Classes IPC  ?

• F16L 19/02 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé
• F16L 19/025 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé les colliers ou les brides formant partie intégrante des extrémités du tuyau
• G01L 5/24 - Appareils ou procédés pour la mesure des forces, du travail, de la puissance mécanique ou du couple, spécialement adaptés à des fins spécifiques pour déterminer la valeur du couple ou du moment de torsion pour le serrage d'un écrou ou d'un autre organe soumis à une contrainte analogue

Abrégé

The invention relates to a fluid-tight connector which includes: - either at least one strain gauge (80; 86), - either at least one passage (78), said passage extending radially through a nut (22) and communicating with an interior chamber (76) defined by a first conduit (12) of the connector, a second conduit (14) and the nut (22), - either a visual indicator (40; 50; 60; 62) associated with at least one of a nut or a first conduit.

Classes IPC  ?

• F16L 19/025 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé les colliers ou les brides formant partie intégrante des extrémités du tuyau
• F16L 19/02 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé
• G01L 5/24 - Appareils ou procédés pour la mesure des forces, du travail, de la puissance mécanique ou du couple, spécialement adaptés à des fins spécifiques pour déterminer la valeur du couple ou du moment de torsion pour le serrage d'un écrou ou d'un autre organe soumis à une contrainte analogue

Produits et services

Advisory, study and assistance services to industrial companies in conducting their business, business organization and management consulting, business information and inquiries, administrative management of computers; market studies and research, information search in computer files for others; statistical studies, research and information, compilation of information on the management of industrial production; organization of exhibitions for commercial or advertising purposes, public relations. Engineering services for industrial production, platform as a service (PaaS) dedicated to the management of industrial production; software service (SaaS) in the field of industrial production; development (design) of software, updating of software and databases, software maintenance, consulting regarding computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; conducting technical engineering projects for products and processes in the following fields: aeronautics, space, automotive, defense, energy, rail, industrial vehicles, naval, industrial, petrochemical, IT, electronics and telecom, digital calculation and simulation, automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services; industrial design, graphic arts designer services.

Produits et services

(1) Services d'ingénierie de la production industrielle, plateforme en tant que service (Paas) dédiée à la gestion de la production industrielle; logiciel service (Saas) dans le domaine de la gestion de la production industrielle; élaboration (conception) de logiciels, mise à jour de logiciels et de bases de données, maintenance de logiciels, consultation en matière d'ordinateur, d'intelligence artificielle, programmation pour ordinateurs, installation de logiciels; services de normalisation technique, à savoir: élaboration et conception de normes pour l'industrie et la gestion de production industrielle; services d'aide technique à l'exploitation et à la supervision dans le domaine de l'informatique, des bases de données et des télécommunications appliqués à la production industrielle; assistance technique aux industries pour la conception et la production de biens et de services; réalisation de projets techniques d'ingénierie pour produits et procédés dans les domaines suivants, aéronautique, spatial, automobile, défense, énergies, ferroviaire, véhicules industriels, naval, industries, pétrochimie, informatique, électronique et télécom, calcul et simulation numérique, automatisme; consultations et recherches dans le domaine de l'ingénierie et de la production industrielle; services de consultations techniques en matière d'ordinateurs et d'informatique appliquée à la production, étude de projets techniques, conception de systèmes de production; études et recherches techniques dans le domaine de la gestion de capteurs et logiciels de surveillance de suivi de production; services de certification nommément contrôle de qualité et d'origine; dessin industriel, services de dessinateurs d'art graphique.

Produits et services

Engineering services for industrial production; platform as a service (PaaS) dedicated to the management of industrial production, featuring software platforms for managing manufacturing production through the use of monitoring, tracking and collecting data on systems and equipment; technical standardization services, namely, design and development of voluntary standards for industry and the management of industrial production; conducting technical engineering projects for products and processes in the fields of aeronautics, space, automotive, defense, energy, rail, industrial vehicles, naval, industrial, petrochemical, IT, electronics and telecom, digital calculation and simulation, automation; technology consulting and research in the field of engineering and manufacturing production processes; design of manufacturing production systems

Produits et services

Advisory, study and assistance services to industrial companies in conducting their business, business organization and management consulting, business information and inquiries, administrative management of computers; market studies and research, information search in computer files for others; statistical studies, research and information, compilation of information on the management of industrial production; organization of exhibitions for commercial or advertising purposes, public relations; updating and maintenance of data in computer databases. Engineering services for industrial production, platform as a service (PaaS) dedicated to the management of industrial production; software service (SaaS) in the field of industrial production; software development (design), updating of software, maintenance of software, consultancy relating to computers, artificial intelligence, computer programming, software installation; technical standardization services, namely: design and development of standards for industry and the management of industrial production; technical support services for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services; implementation of technical projects, engineering products and processes in the following fields: aeronautics, space, automotive field, defense, energy, rail, industrial vehicles, naval field, industries, petrochemicals, computing, electronics and telecom, computation and digital simulation and automation; consulting and research in the field of engineering and industrial production; technical consultancy relating to computers and information technology applied to production, technical project studies, design of production systems; technical research and studies in the field of operation and maintenance of production equipment, tools and automated systems; certification and authentication (monitoring) of messages and data transmitted via telecommunications; certification (quality and origin control) services; industrial design, graphic arts designer services.

Abrégé

A nut (2) is prevented from turning during screwing by a body (12) attached to one of the parts to be tightened (6) by rivets (14). The body (12) prevents the nut (19) from rotating via a ring (19) coupled without clearance with the nut (19) and coupled with radial clearance to the body (12), in order to allow the nut to self-position itself along the axis (3) imposed on the screw (4) by the bores (9, 11) traversed by the screw. The nut can thus be a standard nut or a floating cage nut. Application to the retaining of nuts that are inaccessible and/or require a high level of security against unintentional unscrewing.

Classes IPC  ?

• F16B 39/08 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage avec un chapeau agissant contre l'écrou relié au boulon par une broche ou une goupille fendue
• F16B 39/10 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par une plaque ou un anneau immobile par rapport au boulon ou à l'objet

Abrégé

A nut (2) is prevented from turning during screwing by a body (12) attached to one of the parts to be tightened (6) by rivets (14). The body (12) prevents the nut (19) from rotating via a ring (19) coupled without clearance with the nut (19) and coupled with radial clearance to the body (12), in order to allow the nut to self-position itself along the axis (3) imposed on the screw (4) by the bores (9, 11) traversed by the screw. The nut can thus be a standard nut or a floating cage nut. Application to the retaining of nuts that are inaccessible and/or require a high level of security against unintentional unscrewing.

Classes IPC  ?

• F16B 39/10 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage par une plaque ou un anneau immobile par rapport au boulon ou à l'objet
• F16B 39/08 - Blocage des vis, boulons ou écrous dans lequel le verrouillage s'effectue après vissage avec un chapeau agissant contre l'écrou relié au boulon par une broche ou une goupille fendue

Produits et services

Compilation of information into computer databases on the management of industrial production Engineering services for industrial production; platform as a service (PaaS) dedicated to the management of industrial production for use in database management; software service (SaaS) in the field of industrial production for use in database management; technical standardization services, namely, design and development of voluntary standards for industry and the management of industrial production; technical support services, namely, troubleshooting of computer software programs for operating and monitoring in the field of computing, databases and telecommunications applied to industrial production; technical assistance for industries in the design and production of goods and services, namely, consulting in the nature of advising others in the areas of product development and production; technical project studies, namely, scientific study and research in the aerospace, automotive, energy, railway, naval, and digital calculation, simulation, and automation industries; design of production systems in the aerospace, automotive, energy, railway, naval, and digital calculation, simulation, and automation industries

Produits et services

(1) Compilation de renseignements relatifs à la gestion de production industrielle. (2) Services d'ingénierie de la production industrielle, plateforme en tant que service (PaaS) dédiée à la gestion de la production industrielle; logiciel service (SaaS) dans le domaine de la gestion de la production industrielle; services de normalisation technique, à savoir: élaboration et conception de normes pour l'industrie et la gestion de production industrielle; services d'aide technique à l'exploitation et à la supervision dans le domaine de l'informatique, des bases de données et des télécommunications appliqués à la production industrielle; assistance technique aux industries pour la conception et la production de biens et de services; étude de projets techniques, conception de systèmes de production.

Abrégé

A sealing device in the form of a plug that is receivable in a threaded hole of a case includes a threaded central body, a skirt connected to the central body, and locking/unlocking means that opposes spontaneous unscrewing of the plug and is automatically activated by rotation of the plug and corresponding movement along an axis. The locking/unlocking means includes a first releasable coupling component coupled for rotation with the central body, and a second releasable coupling component facing the first coupling component at least during screwing and unscrewing. In at least in a tightened condition of the plug, the second coupling component is secured against rotation relative to the case by rotation restricting means located inside the threaded bore. In the screwed condition, an annular end face of the skirt bears against a bearing face of the second releasable coupling component to transmit tightening thrust to the case.

Classes IPC  ?

• F16B 39/32 - Blocage par cliquet ou languette genre cliquet
• F16B 39/22 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage
• B64F 5/60 - Test ou inspection des composants ou des systèmes d'aéronefs
• F16B 39/24 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet
• F16B 39/26 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet les rondelles à ressort étant fixées à l'écrou ou à la tête du boulon

Abrégé

The present invention relates to a self-locking screwing attachment device. In one embodiment, the device includes a first element 6a having an inner thread, the first element 6a being screwed onto a threaded tip 3a. In other embodiments, the first element has an outer thread and can either be made of a hollow body or have a closed end so as to constitute, for instance, a borescope.

Classes IPC  ?

• F16B 39/24 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet
• F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents

Abrégé

A self-locking screwing attachment device. In one embodiment, the device includes a first element having an inner thread, the first element being screwed onto a threaded tip. In other embodiments, the first element has an outer thread and can either be made of a hollow body or have a closed end so as to constitute, for instance, a borescope.

Classes IPC  ?

• F16B 39/32 - Blocage par cliquet ou languette genre cliquet
• F16B 39/26 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet les rondelles à ressort étant fixées à l'écrou ou à la tête du boulon
• F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents

Abrégé

A nut for securing first and second pipe end-pieces together includes a nut lock having a stop member secured to the nut body, and a second element which is rotatable inside the nut body and having a locking feature adapted to lock onto a corresponding locking structure of the second end-piece. The stop member and the second element include corresponding face teeth which are urged to intermesh by an axial compression spring. At or near the tightened condition of the assembly, the second element is locked onto the second end-piece so that rotation of the nut is possible only if the torque applied exceeds a given threshold, for which the face teeth jump over each other while the spring is alternately stressed. A compact design is obtained with the lock positioned at the rear of the nut thread. The clamping face is axially between the nut thread and the lock.

Classes IPC  ?

• F16B 39/32 - Blocage par cliquet ou languette genre cliquet
• F16B 39/26 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet les rondelles à ressort étant fixées à l'écrou ou à la tête du boulon
• F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents

Abrégé

The device connects a first end-coupler with a second end-coupler, in particular of a piping. A nut is provided with a threaded bore in which the first end-coupler is screwed along a longitudinal axis. In a tightening position, the first end-coupler is in axial stress with a second end-coupler accommodated in the nut. Anti-rotation means are provided between the nut and at least one of the end-couplers to prevent relative rotation except when a torque exceeding a predetermined threshold is applied thereto. The anti-rotation means consist of at least one tab made in the material of the nut to lockingly interfere with substantially planar faces formed on the second end-coupler.

Classes IPC  ?

• F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord
• F16L 19/02 - Extrémités de tuyaux pourvues de colliers ou de brides formant corps ou non avec les tuyaux, maintenues en contact par un organe vissé
• B21K 1/70 - Fabrication d'éléments de machines d'écrous de formes particulières, p. ex. écrous à blocage automatique, écrous à oreilles

Abrégé

The invention relates to a shut-off device comprising a plug intended to be placed over a threaded orifice of a casing, or to be removed therefrom, by screwing and unscrewing respectively, the plug comprising a central body bearing a screw thread, and locking and unlocking means that oppose the spontaneous unscrewing of the plug and that are activated automatically by the turning of the plug and its corresponding progression in the direction of screwing along a longitudinal axis. The locking and unlocking means comprise two releaseable coupling members, of which a first member is coupled to and turns with the central body via a protective skirt and of which a second member can be prevented from turning with respect to the casing during screwing.

Classes IPC  ?

• F16B 39/22 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage
• F16B 39/26 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet les rondelles à ressort étant fixées à l'écrou ou à la tête du boulon
• F01D 21/00 - Arrêt des "machines" ou machines motrices, p. ex. dispositifs d'urgenceDispositifs de régulation, de commande ou de sécurité non prévus ailleurs
• F02B 77/00 - Parties constitutives, détails ou accessoires, non prévus ailleurs
• F16B 39/24 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet
• F16B 39/282 - Blocage par dispositifs dont les surfaces de travail ont une forme particulière, p. ex. écrous à encoches ou à dents
• F16L 55/11 - Bouchons

Abrégé

The device connects a first end-coupler (1) with a second end-coupler (2), in particular of a piping. A nut (15) is provided with a threaded bore (17) in which the first end-coupler (1) is screwed along a longitudinal axis (X). In a tightening position, the first end-coupler (1) is in axial stress with a second end-coupler (2) accommodated in the nut. Anti-rotation means are provided between the nut (15, 115) and at least one (2) of the end-couplers to prevent relative rotation except when a torque exceeding a predetermined threshold is applied thereto. The anti-rotation means consist of at least one tab (21) made in the material of the nut (15) to lockingly interfere with substantially planar faces formed on the second end-coupler (2).

Classes IPC  ?

• F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord
• F16L 25/06 - Structure ou détails de raccords de tuyaux non prévus dans les groupes ou présentant in intérêt autre que celui visé par ces groupes comprenant des moyens de verrouillage radiaux
• F16L 37/084 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique
• F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts

Abrégé

The device connects a first end-coupler (1) with a second end-coupler (2), in particular of a piping. A nut (15) is provided with a threaded bore (17) in which the first end-coupler (1) is screwed along a longitudinal axis (X). In a tightening position, the first end-coupler (1) is in axial stress with a second end-coupler (2) accommodated in the nut. Anti-rotation means are provided between the nut (15, 115) and at least one (2) of the end-couplers to prevent relative rotation except when a torque exceeding a predetermined threshold is applied thereto. The anti-rotation means consist of at least one tab (21) made in the material of the nut (15) to lockingly interfere with substantially planar faces formed on the second end-coupler (2).

Classes IPC  ?

• F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord
• F16L 25/06 - Structure ou détails de raccords de tuyaux non prévus dans les groupes ou présentant in intérêt autre que celui visé par ces groupes comprenant des moyens de verrouillage radiaux
• F16L 37/084 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique
• F16L 37/091 - Accouplements du type à action rapide dans lesquels l'assemblage entre les extrémités s'aboutant ou se chevauchant est maintenu par des organes de blocage combinés à un verrouillage automatique au moyen d'une bague pourvue de dents ou de doigts

Abrégé

The device connects a first end fitting to a second end fitting, particularly of a pipe. A nut is provided with a threaded bore into which the first end fitting is screwed along a longitudinal axis. In the tightened position, the first end fitting is axially stressed relative to the second end fitting housed in the nut. Rotation-proofing structure is provided between the nut and at least one of the first and second end fittings hereafter referred to as the locking end fitting. The rotation-proofing structure includes at least one strip arranged around the locking end fitting. The strip comprises at least one protrusion radially penetrating into at least one concavity.

Classes IPC  ?

• F16L 27/00 - Raccords réglablesRaccords permettant un déplacement des parties raccordées
• F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord

Abrégé

The invention relates to a shut-off device comprising a plug (1) intended to be placed over a threaded orifice (2) of a casing (3), or to be removed therefrom, by screwing and unscrewing respectively, the plug comprising a central body (4) bearing a screw thread (5), and locking and unlocking means that oppose the spontaneous unscrewing of the plug and that are activated automatically by the turning of the plug (1) and its corresponding progression in the direction of screwing along a longitudinal axis (X). The locking and unlocking means comprise two releaseable coupling members (7, 8), of which a first member (7) is coupled to and turns with the central body (4) via a protective skirt (10) and of which a second member (8) can be prevented from turning with respect to the casing (3) during screwing.

Classes IPC  ?

• F01D 21/00 - Arrêt des "machines" ou machines motrices, p. ex. dispositifs d'urgenceDispositifs de régulation, de commande ou de sécurité non prévus ailleurs

Abrégé

The invention relates to a shut-off device comprising a plug (1) intended to be placed over a threaded orifice (2) of a casing (3), or to be removed therefrom, by screwing and unscrewing respectively, the plug comprising a central body (4) bearing a screw thread (5), and locking and unlocking means that oppose the spontaneous unscrewing of the plug and that are activated automatically by the turning of the plug (1) and its corresponding progression in the direction of screwing along a longitudinal axis (X). The locking and unlocking means comprise two releaseable coupling members (7, 8), of which a first member (7) is coupled to and turns with the central body (4) via a protective skirt (10) and of which a second member (8) can be prevented from turning with respect to the casing (3) during screwing.

Classes IPC  ?

• F01D 21/00 - Arrêt des "machines" ou machines motrices, p. ex. dispositifs d'urgenceDispositifs de régulation, de commande ou de sécurité non prévus ailleurs

Abrégé

b) or said adjacent part (5) to be assembled.

Classes IPC  ?

• F16B 39/24 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage par rondelles, rondelles à ressort ou plaques élastiques qui bloquent contre l'objet

Abrégé

The device connects a first end fitting (1, 101) to a second end fitting (2, 102), particularly of a pipe. A nut (15, 115) is provided with a threaded bore (17, 117) into which the first end fitting (1, 101) is screwed along a longitudinal axis (X). In the tightened position, the first end fitting (1, 101) is axially stressed relative to the second end fitting (2, 102) housed in the nut. Rotation-proofing means are provided between the nut (15, 115) and at least one of the first (1, 101) and second (2, 102) end fittings hereafter referred to as the locking end fitting. The rotation-proofing means consist of at least one strip (14, 114) arranged around the locking end fitting. The strip comprises at least one protrusion (23, 23', 123) radially penetrating into at least one concavity (8, 108).

Classes IPC  ?

• F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord
• F16L 39/00 - Raccords ou accessoires de raccordement pour tuyaux à double paroi ou à canaux multiples ou pour assemblages de tuyaux

Abrégé

The device connects a first end fitting (1, 101) to a second end fitting (2, 102), particularly of a pipe. A nut (15, 115) is provided with a threaded bore (17, 117) into which the first end fitting (1, 101) is screwed along a longitudinal axis (X). In the tightened position, the first end fitting (1, 101) is axially stressed relative to the second end fitting (2, 102) housed in the nut. Rotation-proofing means are provided between the nut (15, 115) and at least one of the first (1, 101) and second (2, 102) end fittings hereafter referred to as the locking end fitting. The rotation-proofing means consist of at least one strip (14, 114) arranged around the locking end fitting. The strip comprises at least one protrusion (23, 23', 123) radially penetrating into at least one concavity (8, 108).

Classes IPC  ?

• F16L 39/00 - Raccords ou accessoires de raccordement pour tuyaux à double paroi ou à canaux multiples ou pour assemblages de tuyaux
• F16L 19/00 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord

Produits et services

Metal self-locking nuts; metal screws; gas or fluid connectors, namely, metal pipes and plugs for gas and fluid transfer; metal pipe clamps; metal junctions for pipes; metal bore scope plugs Airplane engine parts, namely, oilpan and crankcase plugs, bore scope plugs, cam shafts, fuel injectors, ventilating systems sold as an integral part of airplane engines and comprised of ducts and fans, and sensors, particle detectors and pressure regulators for combustion chambers

Produits et services

Metal self-locking nuts; metal screws and plugs; metal bore scope plugs; gas or fluid connectors, namely, metal pipes for gas and fluid transfer; metal pipe clamps; metal junctions for pipes

Produits et services

(1) Parts of aeroplane and motor vehicle engines namely, self locking nuts, screws and plugs, bore scope plugs, pressure and temperature sensors, metal and combustion particle detectors, gas and fluid connectors, pipe clamps, junctions for pipes.

Produits et services

(1) Parts of aeroplane and motor vehicle engines namely, self locking nuts, screws and plugs, bore scope plugs, pressure and temperature sensors, metal and combustion particle detectors, gas and fluid connectors, crank shafts, pipe clamps, junctions for pipes, fuel injectors, pressure regulators and ventilating fans. (1) Research and design of mechanical parts, namely aeroplane and motor vehicle engine parts such as self locking nuts, plugs and screws, drain plugs and bolt locks, gas and fluid fittings, bore scope plugs, clamps, ducting links, chip detectors, fans.

Produits et services

Motors and engines (except for land vehicles); Aeronautical engines; Parts of aeroplane motors and engines, namely self-braking plugs, nuts and screws, borescope plugs, Sensors, Shafts,Pipe clamps, Joints for pipes, Injectors,Particle detectors, fluid or gas connectors; Brake segments other than for vehicles; Metalworking machines; Pressure regulators and ventilating systems (machine parts and motors and engines). Motors and engines for land vehicles; Parts of motors and engines, namely self-braking nuts and screws, connectors, borescope plugs, sensors, shafts, pipe clamps, junctions for pipes, injectors, particle detectors; Hydraulic circuits and ventilation systems for vehicles. Research and design of mechanical parts, scientific and technological services for the design and development of motors and engines, parts of motors and engines, clamping and connection systems, sensors, gas and particle detectors, bore scopes, sockets and plugs for ventilation systems and instruments.

Produits et services

Motors and engines (except for land vehicles); Aeronautical engines; Parts of aeroplane engines, namely self-braking nuts and plugs, bore scope plugs, sensors, particle detectors, gas or fluid connectors, shafts, pipe clamps, junctions for pipes, injectors; Brake segments other than for vehicles; Metalworking machines; Pressure regulators and ventilating systems (machine parts and motors and engines). Motors and engines for land vehicles; Parts of motors and engines, namely self-braking nuts and screws, connectors, bore scope plugs, sensors, particle detectors, shafts, pipe clamps, junctions for pipes, injectors; Hydraulic circuits and ventilation systems for vehicles. Research and design of mechanical parts, scientific and technological services for the design and development of motors and engines, parts of motors and engines, clamping and connection systems, sensors, gas and particle detectors, bore scopes, sockets and plugs for ventilation systems and instruments.

Abrégé

The invention relates to a self-locking screwing attachment device (1a, 1b) including a nut (2a, 2b) screwed onto a threaded tip (3a, 3b) extending in a screwing axis (X), characterised in that the nut (2a, 2b) includes: a first element (6a, 6b) rotating relative to the tip (3a, 3b) when screwing; a second element (13a, 13b) rotatably engaged with the tip (3b) or an adjacent part (5) to be assembled, the tip (3a) passing therethrough; a stop member (23a, 23b) rotatably secured to the first element (6a, 6b); a releasable coupling means (26a, 26b, 27a, 27b, 28a, 28b) between the stop member (23a, 23b) and the second element (13a, 13b), the nut also being provided with an area for direct clamping between a first clamping surface (20a, 20b) of the first element (6a, 6b) and a second clamping surface (21a, 21b) of the second element (13a, 13b), when the second element (13a, 13b) axially engages with the tip (3a, 3b) or said adjacent part (5) to be assembled.

Classes IPC  ?

• F16B 39/22 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage

Abrégé

The invention relates to a self-locking screwing attachment device (1a, 1b) including a nut (2a, 2b) screwed onto a threaded tip (3a, 3b) extending in a screwing axis (X), characterised in that the nut (2a, 2b) includes: a first element (6a, 6b) rotating relative to the tip (3a, 3b) when screwing; a second element (13a, 13b) rotatably engaged with the tip (3b) or an adjacent part (5) to be assembled, the tip (3a) passing therethrough; a stop member (23a, 23b) rotatably secured to the first element (6a, 6b); a releasable coupling means (26a, 26b, 27a, 27b, 28a, 28b) between the stop member (23a, 23b) and the second element (13a, 13b), the nut also being provided with an area for direct clamping between a first clamping surface (20a, 20b) of the first element (6a, 6b) and a second clamping surface (21a, 21b) of the second element (13a, 13b), when the second element (13a, 13b) axially engages with the tip (3a, 3b) or said adjacent part (5) to be assembled.

Classes IPC  ?

• F16B 39/22 - Blocage des vis, boulons ou écrous dans lequel le verrouillage se fait en même temps que le vissage ou le serrage
