12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
25 - Vêtements; chaussures; chapellerie
Produits et services
Bicycles; panniers adapted for bicycles; saddlebags adapted
for bicycles; bicycle saddles; electric bicycles; bicycle
racks for vehicles; tires; bicycle kickstands being parts of
bicycles; bicycle brakes; pedals for cycles. Clothing.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
25 - Vêtements; chaussures; chapellerie
Produits et services
Bicycles; panniers adapted for bicycles; saddlebags adapted for bicycles; bicycle saddles; electric bicycles; bicycle racks for vehicles; tires; bicycle kickstands being parts of bicycles; bicycle brakes; pedals for cycles Clothing, namely, shirts, t-shirts, tank tops, hoodies, clothing jackets, base layers, arm warmers, leg warmers, socks, tops as clothing, bottoms as clothing, headwear, hats, caps being headwear, bandanas, footwear, sports jerseys, shorts, pants, gloves as clothing, shoes, and cyclists' jerseys; Cyclists' clothing, namely, cycling shirts, cycling bib shorts
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
25 - Vêtements; chaussures; chapellerie
Produits et services
(1) Bicycles; panniers adapted for bicycles; saddlebags adapted for bicycles; bicycle saddles; electric bicycles; bicycle racks for vehicles; tires; bicycle kickstands being parts of bicycles; bicycle brakes; pedals for cycles.
(2) Clothing.
A brake handlebar (2) for a bicycle (1), the brake handlebar comprising an elongate main body (16) having a longitudinal axis (12) and a brake assembly comprising: a brake actuator (4) rotatably coupled to the elongate main body and pivotable about a pivot axis (7); a master cylinder (22); and a master cylinder piston (38) received in and movable relative to the master cylinder; wherein the master cylinder and the master cylinder piston are located inside the elongate main body and inboard of the pivot axis; and wherein the master cylinder piston is movable along a piston axis substantially parallel to the longitudinal axis.
A frame, for a bicycle, comprising a rear frame member having a forward end, connectable to a pedal crank assembly, and a rear end, connectable to a rear wheel assembly; a pylon, in use, connected to and extending upwardly from the rear frame member between its forward and rear ends; and a rear carrier, in use, connected to and extending from the pylon such that the rear carrier is spaced apart from the rear frame member. Also disclosed is a kickstand assembly comprising a body and first and second legs. Each leg is coupled to the body and rotatable between stowed and deployed configurations about respective first and second axes extending non-parallel relative to one another. Each leg has a bevel gear configured to mesh with the bevel gear of the other leg such that a rotation of either leg causes a corresponding rotation of the other leg.
B62J 7/04 - Porte-bagages caractérisés par leur disposition sur les cycles montés au-dessus ou derrière la roue arrière
B62K 19/46 - Porte-bagages formant corps avec le cadre
B62H 1/02 - Béquilles articulées, p. ex. en forme de bras à charnières
B62K 19/06 - Cadres de cycle caractérisés par le matériau ou la section transversale des éléments du cadre le matériau étant entièrement ou principalement métallique, p. ex. à haute élasticité tubulaire
B62K 19/16 - Cadres de cycle caractérisés par le matériau ou la section transversale des éléments du cadre le matériau étant entièrement ou principalement en plastique
An injection moulded cantilevered single side mountable wheel for a bicycle, a rim; a central hub; and a plurality of hollow spokes connecting the rim to the central hub.
B29C 45/00 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet
22.
Front Motor Drive Bicycle With Side Mounted Wheels
A drive system for a side mounted cycle wheel, comprising a wheel hub for mounting the side mounted cycle wheel; a motor drive for driving the side mounted cycle wheel, the motor drive comprising an electric motor and a planetary gear reduction assembly positioned at least partially within the wheel hub and comprising one or more planetary gears; and, a rotary wheel hub bearing rotatably coupling the wheel hub to the motor drive, wherein the rotary wheel hub bearing is positioned laterally between the electric motor and the planetary gears.
B62M 6/65 - Cycles propulsés par le conducteur avec moteur électrique auxiliaire motopropulsés au niveau de parties de l'axe de moyeu l'axe de moyeu et l'arbre de commande étant disposés coaxialement
B62M 6/75 - Cycles propulsés par le conducteur avec moteur électrique auxiliaire motopropulsés par des rouleaux à friction ou des pignons en prise avec la roue porteuse
23.
Belt driven pedal cycle employing a slim protective belt drive cover
A pedal driven cycle comprising a belt drive connecting a power input sprocket to a driven sprocket along a chain line; an outer protective belt drive cover plate having a footprint which substantially coincides with a side profile of the belt drive along at least a major portion of its length of travel so that the outer cover plate does not extend beyond an outer surface of the belt drive; and fixtures for mounting the outer protective belt drive cover plate to the cycle in parallel with the chain line and laterally spaced apart from a side edge of the belt drive to provide a clearance, with fore and aft adjustment.
B62J 13/06 - Carters de chaîne, de l'entraînement par chaîne ou organe équivalent, p. ex. de l'entraînement par courroie protégeant la totalité de l'entraînement par chaîne ou par organe similaire permettant accès rapide à la chaîne ou à l'organe similaire
24.
BICYCLE WITH CANTILEVERED SINGLE SIDE MOUNTED WHEELS
An injection moulded cantilevered single side mountable wheel for a bicycle, a rim; a central hub; and a plurality of hollow spokes connecting the rim to the central hub.
A drive system for a side mounted cycle wheel, comprising a wheel hub for mounting the side mounted cycle wheel; a motor drive for driving the side mounted cycle wheel, the motor drive comprising an electric motor and a planetary gear reduction assembly positioned at least partially within the wheel hub and comprising one or more planetary gears; and, a rotary wheel hub bearing rotatably coupling the wheel hub to the motor drive, wherein the rotary wheel hub bearing is positioned laterally between the electric motor and the planetary gears.
B62M 6/65 - Cycles propulsés par le conducteur avec moteur électrique auxiliaire motopropulsés au niveau de parties de l'axe de moyeu l'axe de moyeu et l'arbre de commande étant disposés coaxialement
B60K 7/00 - Disposition du moteur dans ou jouxtant une roue motrice
B60L 1/00 - Fourniture de l'énergie électrique à l'équipement auxiliaire des véhicules à traction électrique
26.
BELT DRIVE PEDAL CYCLE WITH SIDE MOUNTED WHEELS, CANTILEVER CHAIN STAY AND BELT TENSIONER
A pedal driven cycle comprising a cantilevered frame member coupled to a power input sprocket and a driven sprocket; a belt drive connecting the power input sprocket to the driven sprocket; and a side mounted rear wheel releasably coupled to a multi-speed gear hub that is coaxial with the side mounted rear wheel, wherein the multi-speed gear hub is coupled to the driven sprocket and a tension adjustment mechanism coupling the driven sprocket to the cantilevered frame member, the tension adjustment mechanism being slidably moveable along at least a part of the cantilevered frame member thereby to adjust a tension in the belt drive, and comprising a first member and a second member, wherein the first and second members are arranged on opposing sides of the cantilevered frame member and clamped to the cantilevered frame member.
B62K 3/04 - Cadres ayant une barre supérieure sensiblement horizontale
B62K 25/28 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche avec support de chaînes à pivot
B62M 9/08 - Transmissions caractérisées par l'emploi d'une chaîne sans fin, d'une courroie ou d'un organe similaire de rapport variable utilisant une seule chaîne, courroie ou organe similaire comportant une roue, motrice ou entraînée, montée excentriquement ou de forme elliptiqueTransmissions caractérisées par l'emploi d'une chaîne sans fin, d'une courroie ou d'un organe similaire de rapport variable utilisant une seule chaîne, courroie ou organe similaire avec une roue motrice ou entraînée expansible
B62M 9/16 - Dispositifs de mise en tension ou de réglage pour chaînes, courroies ou organes similaires
27.
BELT DRIVEN PEDAL CYCLE EMPLOYING A SLIM PROTECTIVE BELT DRIVE COVER
A pedal driven cycle comprising a belt drive connecting a power input sprocket to a driven sprocket along a chain line; an outer protective belt drive cover plate having a footprint which substantially coincides with a side profile of the belt drive along at least a major portion of its length of travel so that the outer cover plate does not extend beyond an outer surface of the belt drive; and fixtures for mounting the outer protective belt drive cover plate to the cycle in parallel with the chain line and laterally spaced apart from a side edge of the belt drive to provide a clearance, with fore and aft adjustment.
B62J 13/06 - Carters de chaîne, de l'entraînement par chaîne ou organe équivalent, p. ex. de l'entraînement par courroie protégeant la totalité de l'entraînement par chaîne ou par organe similaire permettant accès rapide à la chaîne ou à l'organe similaire
B62M 9/02 - Transmissions caractérisées par l'emploi d'une chaîne sans fin, d'une courroie ou d'un organe similaire de rapport invariable
B62M 1/36 - Propulsion par le conducteur des véhicules à roues avec vilebrequins rotatifs, p. ex. manivelles de pédalier
There is described a quick-release arrangement for mounting a bicycle wheel (2) to a hub of a bicycle frame (1) using a single-sided mount. The quick-release arrangement includes a number of levers (12) each movable between a closed position, in which the wheel is retained to the bicycle hub, and an open position in which the wheel is freely removable. A locking ring (21) is mounted to the bicycle wheel and is rotatable between an open position and a locked position. When the locking ring (21) is in the locked position, hooks (24) on the locking ring (21) are engageable with pins (26) mounted on the levers (12), to prevent the levers (12) from moving out of their closed positions. The locking ring (21) may be mounted to a lever cover plate (18) which is fixed to the wheel and arranged so as to partially cover the levers (12) when they are in their closed positions. The lever cover plate (18) may have a window (27) through which an indicator is visible to indicate the position of the locking ring (21).
B62K 25/08 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche avec fourche télescopique, p. ex. comportant des bras basculants auxiliaires pour roue avant
B60B 3/16 - Fixation du disque au moyeu par boulons ou similaires
B62K 25/20 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche avec bras basculant pivotant sur chaque jambe de fourche avec bras unique sur chaque jambe de fourche pour roue arrière
30.
Handlebar mountable light pipe apparatus for a bicycle
There is described a handlebar mountable bicycle light for fitting to a bicycle handlebar (3) between brake levers (4). The bicycle light comprises an upper cover (5) and a lower cover (6) which are preferably made from injection molded plastics and of a clam shell type arrangement able to receive handlebar (3) and rigidly retain light pipe assembly (7) with cover screws (8). Lower cover (6) contains an aperture (14) through which the handlebar stem (9) extends. The light pipe assembly (7) comprises a transparent rod-like light pipe (18) with LEDs (26) mounted at each end of the light pipe (18). The light pipe assembly 7 further includes heat sinks (24) to draw heat away from the LEDs (26). The arrangement is such that when the bicycle light is mounted to the handlebar, the heat sinks (24) are in contact with the handlebar so that heat from the LEDs may be conducted via the heat sinks (24) to the handlebar material.
F21W 107/13 - Utilisation ou application de dispositifs d’éclairage sur ou dans des types véhicules spécifiques pour les véhicules terrestres pour les cycles
31.
LOCKING DEVICE FOR BICYCLE WHEEL QUICK RELEASE MECHANISM
There is described a quick-release arrangement for mounting a bicycle wheel (2) to a hub of a bicycle frame (1) using a single-sided mount. The quick-release arrangement includes a number of levers (12) each movable between a closed position, in which the wheel is retained to the bicycle hub, and an open position in which the wheel is freely removable. A locking ring (21) is mounted to the bicycle wheel and is rotatable between an open position and a locked position. When the locking ring (21) is in the locked position, hooks (24) on the locking ring (21) are engageable with pins (26) mounted on the levers (12), to prevent the levers (12) from moving out of their closed positions. The locking ring (21) may be mounted to a lever cover plate (18) which is fixed to the wheel and arranged so as to partially cover the levers (12) when they are in their closed positions. The lever cover plate (18) may have a window (27) through which an indicator is visible to indicate the position of the locking ring (21).
B62K 25/08 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche avec fourche télescopique, p. ex. comportant des bras basculants auxiliaires pour roue avant
B62K 25/10 - Suspensions des moyeux de roues pour montage élastique des moyeux sur le cadre ou la fourche avec fourche télescopique, p. ex. comportant des bras basculants auxiliaires pour roue arrière
There is described a handlebar mountable bicycle light for fitting to a bicycle handlebar (3) between brake levers (4). The bicycle light comprises an upper cover (5) and a lower cover (6) which are preferably made from injection moulded plastics and of a clam shell type arrangement able to receive handlebar (3) and rigidly retain light pipe assembly (7) with cover screws (8). Lower cover (6) contains an aperture (14) through which the handlebar stem (9) extends. The light pipe assembly (7) comprises a transparent rod -like light pipe (18) with LEDs (26) mounted at each end of the light pipe (18). The light pipe assembly 7 further includes heat sinks (24) to draw heat away from the LEDs (26). The arrangement is such that when the bicycle light is mounted to the handlebar, the heat sinks (24) are in contact with the handlebar so that heat from the LEDs may be conducted via the heat sinks (24) to the handlebar material.
There is described a torque sensing system for a bicycle (1) having a pair of pedals (8) mounted at respective ends of a pedal shaft (18), and a drive sprocket (12) mounted to the pedal shaft adjacent one end thereof, the torque sensing system comprising first and second encoders (5, 9) mounted at spaced locations for rotation with the pedal shaft and sprocket, respective first and second detectors (4, 16) for sensing angularly spaced points on the said first and second encoders, and control circuitry for receiving input signals from said first and second detectors, the control circuitry being operable to determine the relative angular positions of the first and second encoders and to determine a torque value based on the determined relative angular positions of the first and second encoders.
There is described a bicycle having a steerer tube (3) mounted to the bicycle frame in upper and lower annular bearings (5, 4). Fork blades are mounted to the lower end of the steerer rube. The steerer tube has a non-circular cross-section at the location of the upper bearing (5). A headset (2) is clamped to the steerer tube and is supported in the upper bearing (5). The headset may be clamped to the steerer tube by means of clamp screws (9) engaging with a guide wedge (10). A passage passing through the upper bearing (5) is defined between guide wedge (10) and the steerer tube (3). Control cables from controls on the handlebar may pass through the passage and into the interior of the bicycle frame (7). Control cables may also pass through the lumen of the steerer tube (3) and into the interior of hollow fork blades.
There is described a bicycle seat post (2) having at its lower end to an expandable plug (9) for fixing the seat post (2) relative to the seat tube (22) of a bicycle frame (20). The expandable plug (9) is preferably formed from elastomeric material, and is radially expanded by axial compression of the plug between a pressure surface (7) of the seat post (2) and a pressure plate (8) movable relative to the seat post (2) by means of a cam (6,12) mounted at the upper end of the seat tube and connected to the pressure plate (8) by a tension member (11).
There is a described a bicycle having a motorised front wheel mounting assembly comprising a single-leg fork (9), bearings (19) for mounting a front wheel (10) to one side of the single-leg fork, a motor/gearbox assembly (13) releaseably mountable to the single leg fork and having a driveshaft (22) drivingly engagable with a front wheel mounted to the bearings, and a motor controller (14) mounted within the fork leg (9) and adapted to supply electrical power to the motor/gearbox assembly (13). Other aspects of the invention provide a front fork assembly for mounting to a bicycle frame, and a bicycle frame having a front fork assembly of the above type.
B62M 6/65 - Cycles propulsés par le conducteur avec moteur électrique auxiliaire motopropulsés au niveau de parties de l'axe de moyeu l'axe de moyeu et l'arbre de commande étant disposés coaxialement
