Abrégé

A clamping arrangement for a solar module comprises an assembly having at least one essentially C-shaped, longitudinally extended guide rail (110) and a first and a second holder. These holders (120, 130) are essentially L-shaped in the form of an angle with two legs. A first leg comprises a first, extended, straight section (121, 131); the second, angled leg or second section (122, 132) has a gripping section (123, 133) at its end. This serves to positively grip the frame of a solar module. The holders (120, 130) are inserted into the longitudinal ends of the guide rail (110). For this purpose, the inner space of the guide rail (110) has a guide which is dimensioned in such a way that the first section (121, 131) or leg of the holders (120, 130) is displaceably guided therein. One eyelet (128) each on the holder (120) or the guide rail (118) can be connected via a spring (250) in such a way that the holder (120) is pulled into the guide of the guide rail (110) and exerts a tensile force on the gripping section (123, 133). A mounting arrangement for solar cell modules for facades comprises the aforementioned clamping arrangement, a mounting rail and a solar cell module.

Classes IPC  ?

• H02S 20/00 - Structures de support pour modules PV
• H02S 30/00 - Détails structurels des modules photovoltaïques [PV] autres que ceux qui concernent la conversion de la lumière

Produits et services

Metal building materials, namely, rainscreen support systems and parts therefore; Metal building materials, namely, profiles of metal for the building and construction sector, namely, rails, bars, holders, pillars for arranging devices on and in walls, ceilings, and other surfaces; Metal building materials, namely, cables and wire of common metal not for electric purposes; Metal conduit; Tubes of metal; Metal building materials, namely, substructures of metal, especially of aluminum, for the cladding of façades, in particulars, retro-ventilated faces in the form of panels for construction purposes; Metal fasteners, namely, bolts, nails, rivets, screws; Metal building materials, namely, wall mounting brackets for use in building construction; Cladding of metal for construction and building Non-metal construction materials, namely, wood, plastic, ceramics, fiber enforced plastics for use in cladding for façades and substructures; Non-metal construction materials, namely, non-metal tubes, rails, and profiles used in construction for arranging devices on and in walls, ceilings, and other surfaces Building construction services; Building repair; Installation of rainscreen cladding systems; Assembly services relating to the installation of rainscreen cladding systems; Building maintenance and repair of buildings; Construction consultancy Research and development of technology in the field of building façade cladding and building construction; Architectural design in the field of cladding of façades and design of buildings

Abrégé

A method for producing an entirely stainless steel, high-strength self-drilling screw that does not need heat treatment downstream of manufacturing to improve material hardness. A stainless steel wire section blank is provided. A screw head is cold-formed at a first end. Subsequently, the diameter at the second end section is reduced by cold forming. A drill tip is produced at the second end by a tweaking movement transverse to the longitudinal axis. Subsequently, the drill tip is finished. Any protruding material flags remaining on the drill tip cutting edges are sheared off during subsequent thread rolling. During preforming, contour edges are formed in the region of the subsequent cutting edges, with the remaining material thickness between 0.3 mm and 1.0 mm. The drill tip final forming forms these contour edges into the cutting edges, and the remaining material thickness between the cutting edge and the material flag is between 0.05 mm and 0.2 mm.

Classes IPC  ?

• B21K 1/56 - Fabrication d'éléments de machines d'éléments filetés

Produits et services

Machines, machine tools, power-operated tools; machines and mechanical apparatus for placing or removing screws and bolts (included in this class); mechanical apparatus and tools as parts or accessories for the aforementioned products; setting tools for fasteners (machine parts); hand-held tools, other than hand-operated; tools (parts of machines).

Produits et services

Screws, Bolts, Pins and Load-distribution plates of metal Machine tools and power-operated tools and parts and accessories therefor for attaching to screws, bolts, pins and load-distribution plates of metal and plastic Hand tools and implements, hand-operated, and parts and accessories therefor, for attaching to screws, bolts, pins and load-distribution plates of metal and plastic Screws, Bolts, Pins and Load-distribution plates of plastic

Produits et services

Motor-operated tools, particularly battery-operated tools, such as blind riveting tools and apparatus for placing blind nuts.

Produits et services

(1) Screws, Bolts, Pins and Load-distribution plates of metal. (2) Machine tools and power-operated tools and parts and accessories therefor for attaching to screws, bolts, pins and load-distribution plates of metal and plastic. (3) Hand tools and implements, hand-operated, and parts and accessories therefor, for attaching to screws, bolts, pins and load-distribution plates of metal and plastic. (4) Screws, Bolts, Pins and Load-distribution plates of plastic.

Produits et services

Motor-operated tools, particularly battery-operated tools, such as blind riveting tools and apparatus for placing blind nuts.

Produits et services

(1) Machines, machines-outils et outils mécaniques; machines et appareils mécaniques pour placer ou retirer des vis et des boulons (compris dans cette classe); appareils mécaniques et outils en tant que pièces ou accessoires pour les produits précédemment cités; outils de pose pour éléments de fixation (parties de machine); outils tenus à la main actionnés autrement que manuellement; outils (parties de machines).

Produits et services

Machines, machine tools, power-operated tools; machines and mechanical apparatus for placing or removing screws and bolts (included in this class); mechanical apparatus and tools as parts or accessories for the aforementioned products; setting tools for fasteners (machine parts); hand-held tools, other than hand-operated; tools (parts of machines).

Produits et services

Screws, Bolts, Pins and Load-distribution plates of metal. Machine tools and power-operated tools and parts and accessories therefor for attaching to screws, bolts, pins and load-distribution plates of metal and plastic. Hand tools and implements, hand-operated, and parts and accessories therefor, for attaching to screws, bolts, pins and load-distribution plates of metal and plastic. Screws, Bolts, Pins and Load-distribution plates of plastic.

Produits et services

Building materials and building parts of metal, profiles of metal for the building and construction sector, such as rails, bars, holders, pillars; cables and wire of metal (not for electric purposes); hardware; conduits and tubes of metal; substructures of metal, especially of aluminum, for the cladding of facades, in particular retro-ventilated facades; fasteners of metal, wall mounting brackets, metal facade cladding. Construction materials (not of metal) for use in cladding for facades and substructures; non-metal tubes; supports, rails and profiles (terms considered too vague in the opinion of the International Bureau - Rule 13 (2) (b) of the Regulations). Connectors and fasteners (not of metal). Construction service, repair service; installation services; assembly and repair of facade claddings and substructures; consultancy services in the field of construction. Technological services and research services, design services relating to the cladding of facades, creation of buildings; measurement services.

Abrégé

The invention relates to a lightweight panel system and to a method for fastening a screw-in element in a lightweight panel. The lightweight panel system (400) comprises: a lightweight panel (100) having a first cover plate (120) and a second cover plate (120), a support core (110), and a three-dimensional wire structure element (200) for holding a screw-in element (300) therein, the support core (110) and the three-dimensional wire structure element (200) being arranged between the first cover plate (120) and the second cover plate (120), the support core (110) and the three-dimensional wire structure element (200) being connected to one another, and/or the support core (110) and the three-dimensional wire structure element (200) being connected to the first cover plate (120) and to the second cover plate (120); and a screw-in element (300) which corresponds to the three-dimensional wire structure element (200) and which is designed to plastically deform at least sections of the three-dimensional wire structure element (200) when the screw-in element (300) is screwed into the three-dimensional wire structure element (200).

Classes IPC  ?

• F16B 5/01 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation spécialement adaptés pour panneaux en nid d'abeilles
• F16B 37/12 - Écrous ou pièces similaires avec entrées de filetage avec surfaces d'entrée de filetage consistant en une insertion de ressorts hélicoïdaux, de disques ou de pièces analoguesÉcrous constitués par des morceaux indépendants de fil métallique enrouléGarnitures filetées intérieures pour trous
• B29C 65/56 - Assemblage d'éléments préformésAppareils à cet effet en utilisant des moyens mécaniques

Abrégé

A clamping arrangement for solar modules includes an assembly having at least one C-shaped, longitudinally extended guide rail and first and second holders. These holders have an angle with two legs. A first leg includes a first, extended, straight section; the second, angled leg/section has a gripping section at its end to positively grip a solar module frame. The holders are inserted into longitudinal ends of the guide rail. The inner space of the guide rail has a guide dimensioned such that the first leg/section of the holders is displaceably guided therein. One eyelet each on the holder or the guide rail is connectable via a spring such that the holder is pulled into the guide of the guide rail and exerts a tensile force on the gripping section. A mounting arrangement for solar cell modules for façades includes this clamping arrangement, a mounting rail and a solar cell module.

Classes IPC  ?

• F24S 25/636 - Serrage utilisant des éléments filetés
• F24S 25/16 - Agencement de structures dressées interconnectéesStructures dressées comprenant des portions de support séparées pour des modules adjacents
• H02S 20/23 - Structures de support directement fixées sur un objet inamovible spécialement adaptées pour les bâtiments spécialement adaptées aux structures de toit
• H02S 30/10 - Structures de bâti

Abrégé

The invention relates to a hinge assembly (1; 1'; 1001; 2001) for pivotably coupling two components in an aircraft or spacecraft cabin, in particular for pivotably attaching a door (107) of an overhead storage compartment (102). The hinge assembly comprises a first hinge part (2; 1002; 2002) and a second hinge part (3; 1003; 2003) arranged and coupled so as to be pivotable relative to each other about a hinge axis (A), an elastic element (5) capable of providing an elastic torque about the hinge axis (A), and a torque-adjustment piece (6; 6', 6a', 6b'; 1006; 2006). The elastic element is coupled to each of the first hinge part and the torque adjustment piece in a torque-transmitting manner. The hinge assembly includes a positive engagement device (7; 7'; 1007; 2007) configured to be kept positively engaged by elastic action so as to prevent a rotation of the torque-adjustment piece at least in a first direction of rotation (R1), and capable of being disengaged against the elastic action so as to enable a rotation of the torque-adjustment piece in a second direction of rotation (R2) opposite to the first direction of rotation (R1) against a torque provided by the elastic element in order to apply a torsional preload to the elastic element.

Classes IPC  ?

• B64D 11/00 - Arrangements pour passagers ou équipageInstallations de postes de pilotage non prévues ailleurs

Abrégé

A ball screw drive having a threaded spindle and a spindle nut enclosing the spindle coaxially. At least two radially outwardly open channels are oriented axially in parallel and are simultaneously pressed into the lateral surface, the channels open toward a common front face of the spindle nut. Balls circulate in a helical ball race in the space between the spindle and the nut. A ball return guide has two ball deflectors and a transfer channel running therebetween. A drive element is operatively connected coaxially to the spindle nut and applies a torque onto the spindle nut. The operative connection between the drive element and the spindle nut is formed by a contact surface with a connecting contour and a driver element (designed such that in the assembled state it engages in one of the channels. The ball screw drive can be used as an actuating element.

Classes IPC  ?

• F16H 25/12 - Transmissions comportant essentiellement et uniquement des systèmes came et galet ou des mécanismes à vis et écrous pour convertir un mouvement rotatif en mouvement alternatif et vice versa avec mouvement alternatif selon l'axe de rotation, p. ex. transmissions à gorges hélicoïdales et inversion automatique
• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Abrégé

A ball screw drive having a threaded spindle and a spindle nut enclosing the spindle coaxially. At least two radially outwardly open channels are oriented axially in parallel and are simultaneously pressed into the lateral surface, the channels open toward a common front face of the spindle nut. Balls circulate in a helical ball race in the space between the spindle and the nut. A ball return guide has two ball deflectors and a transfer channel running therebetween. A drive element is operatively connected coaxially to the spindle nut and applies a torque onto the spindle nut. The operative connection between the drive element and the spindle nut is formed by a contact surface with a connecting contour and a driver element (designed such that in the assembled state it engages in one of the channels. The ball screw drive can be used as an actuating element.

Classes IPC  ?

• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Produits et services

(1) Vis, boulons, goujons et plaques de répartition en métal. (2) Machines électriques, appareils de montage et accessoires pour poser des vis, boulons, goujons et plaques de répartition en métal et en matières plastiques. (3) Outils et accessoires pour poser des vis, boulons, goujons et plaques de répartition en métal et en matières plastiques. (4) Vis, boulons, goujons et plaques de répartition en matières plastiques.

Abrégé

A sensor arrangement for identifying and measuring environmental parameters, in particular in flat roof structures, including a first group of functional units containing at least one sensor and a transmission/reception antenna for wireless communication, and a second group of functional units containing at least one sensor, a measurement, storage and evaluation unit, and a power supply. The two groups of functional units are accommodated in separate housings, but operatively connected to one another. The first functional group has a sensor for water in liquid form and a humidity sensor, and the second functional group preferably has at least one surface pressure sensor. A measurement network can include a group of the sensor arrangements that are controlled/monitored from a common transmission/reception unit. The installation of such a measurement network is also described.

Classes IPC  ?

• G01M 3/28 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par mesure du taux de perte ou de gain d'un fluide, p. ex. avec des dispositifs réagissant à la pression, avec des indicateurs de débit pour tuyaux, câbles ou tubesExamen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par mesure du taux de perte ou de gain d'un fluide, p. ex. avec des dispositifs réagissant à la pression, avec des indicateurs de débit pour raccords ou joints d'étanchéité de tuyauxExamen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide par mesure du taux de perte ou de gain d'un fluide, p. ex. avec des dispositifs réagissant à la pression, avec des indicateurs de débit pour soupapes

Abrégé

A component holder, in particular for aircraft, for indirectly securing components to the fuselage or body shell. The component holder has a base portion and an attachment element which is lockable to the base portion and has a component receiving member arranged thereon. The base portion has a circular shell form, and the upper edge has retention and locking elements. The lockable attachment element has a s dome-like basic structure, and the lower edge region has retention and locking elements which complement those of the base portion and are lockable therewith. The component receiving member is formed integrally on the attachment element and arranged at a dome zenith on the outer side. The dome is formed from at least three frames which are angularly offset on the circumference. The frames extend from the dome lower edge region to the base location of the component receiving member at the dome zenith.

Classes IPC  ?

• F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique

Produits et services

(1) Matériaux de construction et pièces pour le bâtiment en métal, profilés métalliques destinés au secteur du bâtiment et de la construction, tels que rails, barres, supports, piliers; câbles et fil métalliques (à vocation non électrique); quincaillerie; conduits et tubes métalliques; substructures métalliques, notamment en aluminium, destinées à l'habillage de façades, notamment de façades rétro-ventilées; attaches métalliques, équerres de fixation murale métalliques, habillages de façade métalliques. (2) Matériaux de construction (non métalliques) destinés à une utilisation dans les habillages de façades et dans les substructures; tubes non métalliques; supports, rails et profilés (termes trop vagues de l'avis du Bureau international - règle 13.2.b) du règlement d'exécution). (3) Raccords et attaches (non métalliques). (1) Service de construction, service de réparation; services d'installation; montage et réparation d'habillages de façades et de substructures; services de consultation dans le domaine de la construction. (2) Services technologiques et services de recherches, services de conception en rapport avec les habillages de façades, création de constructions; services de mesures.

Abrégé

The present invention describes a centering device suitable for guiding a fastener or a drill during a setting operation. The centering device is arranged in or at a passage opening of a component, the passage opening forming a fastening point of the component. The component can be a substantially flat, plate-shaped metal part, in particular a lug or a bracket for a fagade element.The centering device is arranged in or near the plane of the back of the passage opening and includes a collar and connecting elements between the collar and the edge of the passage opening itself. The collar has a substantially flat to bead-like annular shape and is formed from the metal of the component. The central opening of the collar forms a centering seat for a fastener or drill during the setting operation.A fastening arrangement consists of a component having such a centering device and a matching screw, wherein the screw forms a form fit in at least one direction via its lower head portion in the passage opening of the component aftercompletion of the setting process.

Classes IPC  ?

• B23B 41/00 - Machines ou dispositifs à aléser ou à percer spécialement adaptés à un travail particulierAccessoires spécialement conçus à cet effet
• B23B 49/00 - Systèmes de mesure ou de calibrage des machines à aléser, pour le positionnement ou le guidage du foretDispositif pour indiquer les défauts des forets pendant l'alésageDispositifs à centrer les trous à aléser

Abrégé

A centering device for guiding a fastener or a drill during a setting operation. The centering device is arranged in or at a passage opening of a component, which forms a fastening point. The component can be a substantially flat metal part, in particular a lug or bracket for a façade element. The centering device is arranged at the plane of the back of the passage opening and includes a collar and connecting elements between the collar and the edge of the passage opening. The collar has a substantially flat to bead-like annular shape and is formed in the component. The central opening of the collar forms a centering seat for a fastener or drill during setting. A fastening arrangement has a component, centering device and matching screw. The screw forms a form fit via its lower head portion in the passage opening after completion of the setting process.

Classes IPC  ?

• B25B 23/00 - Parties constitutives ou accessoires des clés à écrous, clés anglaises, tournevis
• B23B 35/00 - Méthodes d'alésage ou de perçage ou autres méthodes de travail impliquant l'utilisation de machines à aléser ou à percerUtilisation d'équipements auxiliaires en relation avec ces méthodes
• B23B 47/28 - Gabarits de perçage de pièces

Produits et services

Setting tools for fastening elements. Hand-operated hand tools and tools. Installation and maintenance services in buildings; maintenance and repair services for electrical and mechanical apparatus.

Produits et services

Goods of metal for use in the aerospace sector, namely, Fastening devices in the nature of screws, bolts, nuts, washers, rivets, pins, clips, and anchors; Latches of metal, Hinges of metal, Restraint systems comprised of metal retainers for doors, cabins, containers and storage compartments; Spring elements of metal in the nature of coil springs, leaf springs and tension links; Clamping elements of metal in the nature of clamps, grips, clips, crimps; Screws, Bolts, Hardware pins, Nuts, and Rivets all being of metal Goods of plastic, rubber and gum for use in aviation and aerospace, Namely, connectors in particular threaded inserts of plastic and rubber except for textile use, Restraint systems comprised of retainers for doors, cabins, containers and storage compartments; damping elements in the nature of shock-absorbing elements, namely, shock absorbing rubber buffers for industrial machinery; Airtight and waterproof packings materials of plastic, rubber and gum, Guiding and sliding elements in the nature of rubber bearing inserts Wall panels, not of metal; Ceiling panels, not of metal Containers, not of metal, for commercial use in the field of Aerospace; Containers, not of metal, for commercial use in the field of aircraft fuselage furnishing; Furniture and furnishings for use in the field of aerospace, namely, Wall cupboards, Storage racks being furniture, Storage cabinets, Overhead luggage lockers, and shelf brackets, all not of metal; Screws of plastic, rubber, and gum; Hinges of plastic, rubber, and gum; Bolts of plastic, rubber, and gum

Abrégé

A ball screw drive includes a threaded spindle and a spindle nut with a plurality of balls that circulate endlessly in the intermediate space between the nut and the spindle. A ball return guide guides balls at one location out of the helical ball race by a ball deflector and feeds the balls back via a transition channel and another ball deflector. The ball deflectors are arranged in radial through-openings in the lateral surface of the nut. One or more small metal plates are provided on the nut, and are arranged in and/or adjacent to the radial through-openings and offset inwardly away from the lateral surface, and span the ball return guide in a planar manner. The ball return guide is fixed in a target position in the lateral surface of the nut, and when fully assembled the small metal plates do not protrude beyond the lateral surface.

Classes IPC  ?

• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Produits et services

(1) Outils de pose pour éléments de fixation. (2) Outils et outils à main actionnés manuellement. (1) Services d'installation et maintenance dans les bâtiments; services de maintenance et de réparation d'appareils électriques et mécaniques.

Abrégé

A screw having the following successive functional sections: a threaded tip (150) shaped as a cone (A) having a double thread; a milling section (B) having a plurality of milling ribs (160) with outer diameter DF; a cylindrical shank section having the main thread with diameter DN; a thread-free shank section (D); optionally a holding thread section (E); optionally a short thread-free underhead section (F); and a head section (G) having a force engagement. The main thread (110) is guided continuously from the tip section (190) of the cone (A) via the milling section (B) to the head end of the thread-bearing shank section (C) and the ribs of the milling section (B) are arranged recessed in the thread base (140) of the continuous main thread such that the thread tips of the continuous main thread with nominal outer diameter DB project beyond the milling ribs, so that DF

Classes IPC  ?

• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses

Abrégé

In principle, a screw (100, 200) has the following successive functional sections:a threaded tip (150) shaped as a cone (A) having a double thread;a milling section (B) having a plurality of milling ribs (160) with outer diameter DF;a cylindrical shank section having the main thread with diameter DN;a thread-free shank section (D);optionally a holding thread section (E);optionally a short thread-free underhead section (F);a head section (G) having a force engagement.The main thread (110) is guided continuously and with constant pitch from the tipsection (190) of the cone (A) via the milling section (B) to the head end of thethread-bearing shank section (C) and the ribs of the milling section (B) arearranged recessed in the thread base (140) of the continuous main thread (110) insuch a way that the thread tips of the continuous main thread (110) with nominalouter diameter DB project beyond the milling ribs (160), so that DF

Classes IPC  ?

• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses
• F16B 25/10 - Vis exécutant une fonction autre que celle de formation de filets, p. ex. vis-forets

Produits et services

Goods of metal for use in the aerospace sector, namely Fastening devices, Latches, Hinges, Restraint systems, Spring elements and Clamping elements, Connecting rods, Screws, Bolts, Pins, Nuts, Rivets, Discs, Thread inserts and mechanical assemblies containing the aforesaid goods. Goods of plastic, rubber and gum for use in aviation and aerospace, Namely connectors such as threaded inserts, Screws, Washers, Restraint systems, damping elements, Airtight and waterproof packings, Guiding and sliding elements, Hinges, Bolts. Containers, for use in the following fields: Aerospace, Hardware not of metal; Furniture and furnishings for use in the field of aerospace, namely, Wall panels and Ceiling panels, Wall cupboards, Racks [furniture], Storage cabinets and Storage tins, Overhead luggage lockers, file trays and shelf brackets (all not of metal).

Abrégé

A profile element for attachment to the rear side of a façade panel, which in turn is fastened to a base such as a building surface or substructure. The profile element is formed in one piece and includes three functional sections arranged one after another: a fixing section for fixing the profile element to a base; a support section for attachment to the façade panel; and a spacer element which, in the installed state, ensures the correct distance between the base and the rear side of the façade panel. The profile element is extendible by a supplementary element, which has functionally similar elements and is only used if required by the geometry of the façade panel. The supplementary element is usable for positive connection to the profile element of an adjacent façade panel. Such a façade system provides flexibility for a wide variety of types and dimensions of façade panels.

Classes IPC  ?

• E04F 13/08 - Revêtements ou enduits, p. ex. pour murs ou plafonds constitués d'éléments d'habillage ou de garnissageLeurs bâtisLeurs moyens de fixation constitués de plusieurs éléments d'habillage ou de garnissage semblables

Abrégé

The invention relates to a profile element (10) for attachment to the rear side (2) of a facade panel (1), which in turn is fastened to a base (5) such as a building surface or a substructure. The profile element (10) is formed in one piece and comprises three functional sections (20, 30, 40) arranged one after the other: a fixing section (20) for fixing the profile element to a base (5); a support section (30) for attachment to the facade panel (1); and a spacer element (40) which, in the installed state, ensures the correct distance between the base and the rear side of the facade panel. The profile element can be extended by a supplementary element (50), which has functionally similar elements and is only used if required by the geometry of the facade panel. The supplementary element can be used to be positively connected to the profile element of an adjacent facade panel. Such a facade system can be used flexibly for a wide variety of types and dimensions of facade panels.

Classes IPC  ?

• E04B 2/88 - Murs-rideaux
• E04F 13/08 - Revêtements ou enduits, p. ex. pour murs ou plafonds constitués d'éléments d'habillage ou de garnissageLeurs bâtisLeurs moyens de fixation constitués de plusieurs éléments d'habillage ou de garnissage semblables
• E04F 13/24 - Moyens de fixation cachés à l'arrière des éléments d'habillage ou de garnissage

Abrégé

A lightweight-construction fastener (10) having a one-piece clip body (20) made of plastic and a clip nut (40). The clip body has the basic shape of a clamp, having two opposite legs (22, 24) extending in the longitudinal direction and a cage (28) in which the clip nut is floatingly mounted. The clip nut in turn has a nut base (42) which is substantially planar. A main part (44) is structured on the nut base and has a cover surface (41) and a plurality of side walls (51, 51′) which extend between the nut base and the cover surface. The side walls of the main part preferably have a convex curvature and the cage has correspondingly designed concave walls. The sizing is such that the convex-concave surface pairs act as torque supports during use of the lightweight-construction fastener.

Classes IPC  ?

• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques

Abrégé

An operating unit for a parking brake of motor vehicles including an operatively connected unit having of a drive spindle and nut, which forms an axially longitudinally adjustable element of a linear drive. The drive spindle has a drive side for connection to an electric drive and a substantially cylindrical spindle portion having an external thread. The nut has a sleeve-shaped central body having an internal thread and a head portion designed to act as a pressure piston on a brake element of the parking brake. The internal and external threads intermesh in the operative connection and define a common axial axis of rotation. The thread is a symmetrical thread, and the flank angles, relative to a radial reference plane perpendicular to the axis of rotation, have angle values which are substantially equal in magnitude.

Classes IPC  ?

• F16D 65/18 - Mécanismes d'actionnement pour freinsMoyens pour amorcer l'opération de freinage à une position prédéterminée disposés dans, ou sur le frein adaptés pour rapprocher les organes par traction

Abrégé

A retaining device for attachment of objects to a wall surface includes a main body, a fastening arrangement, and a cover lockable to the main body that arches over the fastening arrangement. The main body has a bottom side, that faces the wall during mounting, and a top side, that faces away and includes a retaining ring. The fastening arrangement includes a fastener and a centering cap which fixes the fastener. The bottom side of the main body has a circular-ring-shaped surface, on inner and outer edges of which, in each case, one closed encircling web is provided which faces away from the bottom side. Two passage openings are provided in the circular-ring surface between the top and bottom sides. When attached, the main body is pressed onto the wall and an adhesive is injected through one of the passage openings until it emerges again at the other passage opening.

Classes IPC  ?

• F16B 11/00 - Assemblage d'éléments structuraux ou parties de machines par collage ou en les pressant l'un contre l'autre, p. ex. soudage sous pression à froid
• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques
• F16B 37/14 - Écrous-chapeauxChapeaux d'écrous ou de boulons

Abrégé

An anchor point (10) for a fastening element (30), such as a cable tie, includes a substantially flat anchor plate (12) and a resilient element (14) connected thereto, which in turn has at least two locking tongues (16, 17). The anchor plate has a substantially circular disc shape. The resilient element is preferably designed as a plastic loop in the shape of an omega and exerts its resilient action primarily in a direction perpendicular to the plane of the anchor plate. Via an opening in the anchor plate a fastening element/cable tie can be passed through the anchor plate and is deflected by the locking tongues or the resilient element so that it passes through a second opening again to the surface. By pulling on the cable tie, the locking tongues are spread apart by compression of the resilient element and are fixed in or behind the opening of a surface.

Classes IPC  ?

• F16B 2/22 - Clips, c.-à-d. dispositifs de fixation à serrage effectué uniquement par la résistance à la déformation inhérente au matériau dont est fait le dispositif en matériau élastique, p. ex. un matériau caoutchouteux
• F16B 5/06 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par brides ou clips

Abrégé

A tolerance ring is an intermediate element for a shaft/hub connection that is positioned in a groove between shaft and hub and that produces a force-fitting connection between these two elements. It has substantially the shape of a hollow cylinder, wherein the lateral surface thereof has embossments in the form of radially inwardly and/or outwardly pointing elevations. Here, provision is made at one longitudinal end of a flange-like collar, which is applied in a radial plane with respect to the central longitudinal axis. The tolerance ring is preferably manufactured in one piece with the flange-like collar from metal as a deep-drawn part, preferably being manufactured from aluminum or an aluminum alloy. An assembly method for such a tolerance ring, and a ball screw drive, and a screw drive, having such a tolerance ring are also provided.

Classes IPC  ?

• F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous
• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Abrégé

A centering mechanism with a brake piston of a disk brake of a motor vehicle, with a spindle extending into a cavity in the brake piston, has dimensions that prevent a force equilibrium of a nut-spindle assembly moved completely out of the vertical position. A force vector of the gravitational force on the nut-spindle assembly extends within a contact surface between a nut and the brake piston. Thus, the brake piston can be easily assembled with the nut-spindle assembly.

Classes IPC  ?

• F16D 55/226 - Freins à surfaces de freinage substantiellement radiales pressées l'une contre l'autre dans une direction axiale, p. ex. freins à disques avec disques ou patins déplaçables selon l'axe pressés contre des organes en rotation situés dans l'axe par serrage entre des organes mobiles de freinage, p. ex. des disques ou des patins de freins mobiles avec un organe d'actionnement commun pour les organes de freinage les organes de freinage étant des patins de freins dans lesquels l'organe d'actionnement commun se déplace axialement
• F16D 65/18 - Mécanismes d'actionnement pour freinsMoyens pour amorcer l'opération de freinage à une position prédéterminée disposés dans, ou sur le frein adaptés pour rapprocher les organes par traction
• F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous
• F16D 121/14 - Mécanique
• F16D 125/40 - Vis-écrou
• F16D 125/66 - Cales

Abrégé

A self-drilling, anti-burr, threaded fastener is provided having at least two different thread portions. The first thread portion extends along the tip and the second thread portion extends along the tapered portion adjacent to the tip. A third thread portion can be provided between the first and second thread portions that includes a plurality of axial gaps that extend to the thread root to remove burrs. Alternatively, knurling is provided in an area where the first and second thread portions meet, and the knurling acts to remove burrs.

Classes IPC  ?

• F16B 25/02 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses par une action de coupe et d'enlèvement du matériau, p. ex. vis taraudeuses cannelées

Abrégé

A self-drilling, anti-burr, threaded fastener is provided having at least two different thread portions. The first thread portion extends along the tip and the second thread portion extends along the tapered portion adjacent to the tip. A third thread portion can be provided between the first and second thread portions that includes a plurality of axial gaps that extend to the thread root to remove burrs. Alternatively, knurling is provided in an area where the first and second thread portions meet, and the knurling acts to remove burrs.

Classes IPC  ?

• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses
• F16B 25/10 - Vis exécutant une fonction autre que celle de formation de filets, p. ex. vis-forets

Produits et services

Fasteners of metal, For applying wall elements to interiors of land vehicles and aircraft; Fixings, Connectors, Clips, Fins, Latches, Bolts, All the aforesaid goods of metal, For securing wall elements and panels to load bearing components of land vehicles and aircraft; Detachable connecting elements of metal for wall elements, panels and interior cladding. Wall elements and cladding elements for land vehicles and aircraft; Brackets, fixings, safety devices and locks for wall elements in land vehicles and aircraft. Fastenings of plastic, For applying wall elements to interiors of land vehicles and aircraft; mounts, Connectors, Clips, Fins, Latches, Bolts, All the aforesaid goods of plastic, For securing wall elements and panels to load bearing components of land vehicles and aircraft; Detachable connecting elements of plastic for wall elements, panels and interior cladding.

Produits et services

Motor-operated tools, particularly battery-operated tools, such as blind riveting tools.

Produits et services

Surveying apparatus and instruments; scientific measuring instruments, namely, temperature sensors, moisture sensors; humidity sensors, pressure sensors; sensors for measuring temperature, wetness, humidity, and pressure; apparatus and instruments for recording, transmitting, reproducing, or processing data; computer hardware for storing and reproducing sensor data and position information; Recorded and downloadable computer software for processing and transmitting scientific data; Recorded and downloadable computer software for monitoring conditions of roofs; downloadable and recorded software for processing sensor data, for comparing target and actual values, for detecting hazardous conditions, for alarming; computers and computer peripheral devices; wired and wireless input and output devices for monitoring sensors and their data, screens, touch screens, tablets, acoustic and optical warning devices Roof and facades construction services; roofing services; roofing maintenance services; rental of construction tools, machines, and equipment; installation of building sensors and automation equipment Engineering and scientific and technology consulting services, namely, rendering of evaluations, estimates, research, and reports in the fields of construction; technology and computer technology consultation services in the field of analysis, securing, and transmitting computer data and sensor information; software as a service (SaaS) services featuring software for processing sensor data, for comparing target and actual values, for detecting hazardous conditions, for alarming; platform as a service (PaaS) featuring computer software platforms for processing sensor data, for comparing target and actual values, for detecting hazardous conditions, for alarming

Abrégé

A spindle nut (S) for a ball screw is conventionally designed as a hollow cylinder with a central-symmetrical middle longitudinal axis (Z). The spindle nut has an internal thread, which is designed as a ball groove (K) arranged on the cylinder inner surface. Pairs of load-relief bores (B) serve as substantially cylindrical channels for guiding the balls out of and into the ball channel (K) through the wall of the spindle nut. Each load-relief bore (B) is distinguished by a generatrix (L), which has an intersection point (C) with the thread base line of the ball channel (K) and constitutes the geometric continuation of the traveling path of a ball from the ball channel (K) into the load-relief bore (B). A tangent (T) to the cylinder surface (G) runs in a parallel manner at a spacing a >0 to the generatrix (L), both T and L being perpendicular to a common normal (R) to the middle longitudinal axis (Z).

Classes IPC  ?

• F16H 25/20 - Mécanismes à vis
• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Abrégé

An adjustable hidden or invisible hinge for mounting a door-panel or window sash to a frame is provided that is useable for either rebated or flush mount applications using the same hinge. This is possible due to the use of two different types of arm systems that connect the frame part of the hinge to the sash or door part. These include a rotational lever arm system that allows for 180° guided rotational movement which is combined with a translational arm system that at the same time superimposes a translational movement of the sash movable body relative to the sash body.

Classes IPC  ?

• E05D 3/18 - Charnières ou gonds à broches à plusieurs broches à broches coulissantes ou à glissières
• E05D 7/04 - Charnières ou gonds réglables par rapport au battant ou au dormant

Produits et services

Scientific, research, measuring, signalling, detecting, testing, inspecting apparatus and instruments; Sensors for measuring temperature, Sensors for measuring moisture, Sensors for measuring humidity, Sensors for measuring pressures; Apparatus and instruments for the recording, transmission, reproduction or processing of data; Apparatus for storage and reproducing of sensor data and positioning information; Recorded and downloadable media, computer software; Software for processing sensor data, Software for comparing target and actual values, detecting hazardous conditions and for alerts; Computers and computer peripherals; Wired and wireless input and output apparatus for monitoring sensors and their data, display screens, Touch screens, Tablets, Sound and light warning devices. Construction; Roofing services; rental of construction tools, machines and equipment; Building installation and repair services. Science and technology services, Providing of assessments, research services and reports, Relating to the following sectors: Science, technology, Including consultancy services relating thereto; Computer and technology services for the assessment, protection and transmission of computer data and sensor information; Software as a service [SaaS], Platform as a service [PaaS].

Abrégé

A sleeve for the centering of fasteners when installing structural parts on substructure of a building envelope is designed substantially as a hollow cylindrical sleeve body or split hollow cylindrical sleeve body. It has at least two gutter-like shell elements each having a head end and a rear end. The shell elements are grouped symmetrically about a central axis A and span between them a middle space with inner surfaces facing each other. The shell elements are spaced apart from each other and separated by axially parallel longitudinal slots, except for a connecting joint section at the head end. These sleeves are placed on a fastener and allow a precise centering in the predrilled hole of a facade plate, for example. The sleeve remains in the predrilled hole until such time as the centering of the fastener has been accomplished and is then ejected safely by driving the fastener home.

Classes IPC  ?

• F16B 37/00 - Écrous ou pièces similaires avec entrées de filetage

Produits et services

Motor-operated tools, particularly battery-operated tools, namely, blind riveting tools and apparatus for placing blind nuts

Abrégé

A self-drilling screw (10) having a head (20), a shaft (30) at least partially wearing a thread (35) and a drill point (40). The base material of the screw (10) including the drill point (40) is integrally manufactured from an austenitic 300 series steel with a surface hardness (uncoated) of 400-600 HV 0.3. The surface of the screw has a top coating of Zn—Ni with a Ni-content between 12-15% deposited on the austenitic base material. This self-drilling screw (10) is manufactured from a blank of raw austenite 300 series steel which is initially squeezed by cold forming to reduce its diameter in a first operation and, in following cold forming operations the head, the drill point and a thread are formed.

Classes IPC  ?

• F16B 25/10 - Vis exécutant une fonction autre que celle de formation de filets, p. ex. vis-forets
• C22C 18/00 - Alliages à base de zinc
• C23C 30/00 - Revêtement avec des matériaux métalliques, caractérisé uniquement par la composition du matériau métallique, c.-à-d. non caractérisé par le procédé de revêtement
• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses

Produits et services

Software for planning, execution and modeling of buildings and other construction works; software for digital modeling of works data for graphic modeling of building elements, such as facades, windows and doors as well as for integration thereof in the building envelope, software for the design of facade substructures, for calculating and modeling of roof elements, roof insulation and roof terraces; calculation models (terms too vague in the opinion of the International Bureau - Rule 13(2)(b) of the Common Regulations) and simulation of static stress and thermal properties of flat roofs and facades; software for designing mountings and applied parts for the building envelope and for designing fall-arresting guards; software for supervising and interconnecting building sensors with the Internet. Development and design of computer software, especially for the planning, execution and digital modeling of buildings; evaluation of works data, sensors (terms too vague in the opinion of the International Bureau - Rule 13(2)(b) of the Common Regulations); provision of services and research through the application of such software.

Produits et services

Construction materials of metal; mechanical fasteners of metal, bolts, screws, rivets, pins, threaded inserts (all of metal). Electrically, hydraulically and pneumatically driven tools and apparatus included in this class and parts thereof for setting bolts, screws, rivets and pins. Construction; installation and repair of structures and buildings, load-bearing structures, tanks, silos, racks, walls, roofs, wall coverings, sites, stairs, scaffolding, metal industrial buildings, solar cell substructures.

Produits et services

Construction materials of metal; mechanical fasteners of metal, bolts, screws, rivets, pins, threaded inserts (all of metal). Electrically, hydraulically and pneumatically driven tools and apparatus included in this class and parts thereof for setting bolts, screws, rivets and pins. Construction; installation and repair of construction works, load-bearing structures, tanks, silos, racks, walls, roofs, wall coverings, sites, stairs, scaffolding, metal industrial buildings, solar cell substructures.

Abrégé

A diverter for a ball return of a ball screw configured for lifting in and lifting out balls from a ball channel between the spindle nut and the threaded spindle. The diverter is configured in one piece and has 3 functional units, specifically a positioning element, a deflection element having a spade-like lifting-out region and a diverting surface for balls out of or into the ball channel. All surfaces of the diverter that are provided for guidance of balls are configured as circumferentially open grooves (not closed in the manner of a tunnel). A method for assembling such a ball return includes providing two single-piece, structurally identical diverters; providing a pre-assembled module with a spindle nut and a threaded spindle, the spindle nut having two inwardly fitted apertures; inserting the diverters into the apertures; introducing balls; and securing the ball return by attaching a covering sleeve to the spindle nut.

Classes IPC  ?

• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
• F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous

Abrégé

A method for producing a spindle nut (10) for a ball screw (12) is provided, having the following steps: providing a substantially cylindrical workpiece (50) with first and second end faces (46, 44) and a lateral surface (14), shaping the workpiece (50) by pressing in an axially symmetrical central opening (16) and by simultaneously pressing in at least one first (18) and one second (20) channel which are arranged axially in parallel in the lateral surface (14) of the workpiece (50), the central opening (16) and the channels (18, 20) being open toward the first end face (46), introducing an internal thread (34) into the central opening (16), and introducing at least two radially running through-openings (22, 24) at least into the first channel in the form of a transfer channel for receiving diverting inserts (26, 28). A spindle nut (10) produced by the method and to a ball screw (12) having such a spindle nut (10) are also provided.

Classes IPC  ?

• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
• B21D 28/32 - Perforation, c.-à-d. découpage de trous dans d'autres objets de forme particulière
• F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous

Produits et services

Mechanical fastening elements of metal; metal bolts, screws, rivets; metal cotter pins; metal threaded fasteners

Produits et services

(1) Matériaux de construction métalliques, nommément boulons, vis, rivets, goupilles (tous métalliques).

Produits et services

(1) Matériaux de construction métalliques nommément matériaux composites métalliques, acier, acier brut ou mi-ouvré, charpentes d'acier pour la construction, aluminium, charpentes d'aluminium pour la construction; éléments de fixation mécaniques métalliques nommément écrous métalliques, agrafes métalliques pour le bâtiment ou le secteur industriel, rondelles en métal, clous, boulons, vis, rivets, goupilles. (2) Outils et appareils à entraînement électrique, hydraulique et pneumatique et parties de ceux-ci pour la pose de boulons, de vis, de rivets et de goupilles nommément clés dynamométriques électriques, clés dynamométriques hydrauliques, clés dynamométriques pneumatiques, clés dynamométriques autres qu'à main, ainsi que leurs pièces constitutives.

Produits et services

(1) Logiciels informatiques pour la planification, la réalisation et la modélisation de bâtiments et autres ouvrages de construction, nommément bâtiments résidentiels, bâtiments commerciaux, bâtiments industriels; logiciels de conception de substructures de façades, de calcul et de modélisation d'éléments de toits, d'isolations de toits et de toits-terrasses; logiciels informatiques permettant d'évaluer le comportement structural et les caractéristiques thermiques de toits plats et de façades dans diverses conditions environnementales et thermiques; logiciels téléchargeables pour la simulation de contraintes statiques et de propriétés thermiques de toits plats et de façades dans diverses conditions environnementales et thermiques; logiciels informatiques pour la conception de fixations et de pièces rapportées de l'enveloppe de bâtiment, nommément des façades; logiciels informatiques pour la conception d'équipements de protection pour la prévention des chutes; logiciels de supervision et d'interconnexion de capteurs de bâtiment avec Internet, nommément logiciels informatiques pour surveiller et connecter des capteurs d'humidité, de la qualité de l'air, de vitesse du vent et de précipitations installés sur un bâtiment, à Internet. (1) Développement et conception de logiciels informatiques, destinés notamment à la planification, à la réalisation et à la modélisation numérique de bâtiments; analyses et évaluations de données d'ouvrages liées à la conception, construction, exploitation et maintenance de bâtiments, d'infrastructures et de structures architecturales pour assurer la qualité, la sécurité et l'efficacité des projets de construction; analyse et évaluation des données d'humidité, de la qualité de l'air, de vitesse du vent et de précipitations récupérées par des capteurs installés sur des bâtiments, infrastructures et structures architecturales; réalisation de travaux de recherche, de développement et d'évaluation dans le domaine de la planification, de la réalisation et de la modélisation numérique de bâtiments.

Abrégé

A method of fixing a membrane to a surface is disclosed. The method includes affixing a metallic washer having a heat-activated adhesive layer on a surface; arranging a membrane on top of the surface and the heat-activated adhesive layer of the metallic washer; heating the metallic washer to activate the heat-activated adhesive layer such that the membrane is fixable to the metallic washer; positioning a magnetic clamping heat sink assembly on the membrane; magnetically clamping the magnetic clamping heat sink assembly to the metallic washer causing the magnetic clamping heat sink assembly to apply a force against the membrane when the magnetic clamping heat sink assembly sufficiently overlaps the metallic washer to form a secure bond; and cooling the metallic washer, the heat-activated adhesive layer, and the membrane by removing heat through the magnetic clamping heat sink assembly.

Classes IPC  ?

• B23K 13/01 - Soudage par chauffage au moyen d'un courant haute fréquence par chauffage par induction
• E04D 15/04 - Équipement ou outils de couvreur pour couvertures en plaques, feuilles ou matériaux flexibles
• B23K 37/00 - Dispositifs ou procédés auxiliaires non spécialement adaptés à un procédé couvert par un seul des autres groupes principaux de la présente sous-classe

Produits et services

Construction materials of metal; locksmithing products and small hardware articles of metal; pipes and tubes of metal; screws, nuts, rivets, bolts, nails, fittings, dowels, plates and disks for load distribution; fixing elements and devices for industry and building, as well as component parts therefor and metallic accessories, included in this class; dowels; metal fittings and hinges; metal products that have been machined to obtain corrosion or wear resistance. Conducting of technical project studies; surveying (engineering work); research regarding building construction; mechanical research; research and development of new products for third parties; testing of materials; quality control; technological consultancy services; technological research services; technical writing.

Produits et services

Machines, machine tools and mechanical tools; machines for machining of metals; machines and mechanical apparatus for placing or removing screws and bolts (included in this class 7); mechanical apparatus and tools as parts or accessories for the aforementioned products; torque limiter as part of a machine; hand-held tools, other than hand-operated; machine parts. Hand-operated hand tools and instruments; manual apparatus for machining screws and bolts; torque wrenches; torque limiter; wrenches (tools). Construction services; installation and repair services; construction services; repair services; installation services; installation of structures, supporting structures, tanks, silos, racks, walls, roofing, wall coverings, guard rails, staircases, frames, industrial constructions of metal, solar paneling.

Produits et services

(1) Conduite d'études de projets techniques, nommément études de projets techniques dans le domaine de la construction, préparation de rapports relatifs à des études de projets techniques pour des projets de construction; expertises (travaux d'ingénieurs), nommément préparation d'opinions d'experts concernant des projets de construction, planification et organisation de travaux de constructions par des ingénieurs; recherches en matière de construction immobilière; recherches en ingénierie mécanique; recherche et développement de nouveaux produits pour des tiers; essai de matériaux; contrôle de qualité pour l'industrie de la construction; services de conseils technologiques dans le domaine de la construction; recherches technologiques, nommément extraction de documents publics sous forme de services de recherche technologique, recherche technologique en matière de planification de construction, recherches technologiques dans le domaine du génie civil et de l'ingénierie mécanique; rédaction technique.

Produits et services

Construction materials of metal, namely, metal fasteners if the form of bolts, nails, and screws; pipes and tubes of metal; metal screws, nuts, rivets, bolts, nails, dowels, and steel plates and disks for load distribution; metal dowels; metal hinges Conducting of technical project studies in the field of new technologies; surveying; research regarding building construction; mechanical research; research and development of new products for third parties; testing of materials; quality control; technological surveying consultancy services; technological research services in the field of fasteners provided to and for the benefit of third parties; technical writing

Abrégé

A facade element holder includes first and second profile elements, the first profile element having two sections A and B. Here, section A has a first surface shape X and section B as a second surface shape Y. The second profile element has two sections C and D with a first surface shape X′ and a second surface shape Y′. X and X′ and Y and Y′ have substantially the same contour diametrically oppositely in pairs, the spacings from A to B and from C to D being chosen to be substantially equal. The first and second profile elements can thus inter-engage in a form-fitting manner in section A and C and in section B and D. A method for mounting facade elements with such a facade element holder includes providing first and second profile elements and facade elements, and fitting the second profile elements to the rear side of the facade elements and installing the first profile elements horizontally as outer terminating elements of a substructure on a load-bearing building envelope. Individual facade elements are mounted by the second profile element(s) being brought into engagement with the first profile elements such that a form-fitting connection is achieved.

Classes IPC  ?

• E04F 13/08 - Revêtements ou enduits, p. ex. pour murs ou plafonds constitués d'éléments d'habillage ou de garnissageLeurs bâtisLeurs moyens de fixation constitués de plusieurs éléments d'habillage ou de garnissage semblables

Abrégé

A fastening arrangement including a grommet, which is configured as a substantially cylindrical sleeve with a head part, with a hollow-cylindrical shaft and with a conical tip, and also a fastener and a nut, for example made of plastic, which is fitted on the first threaded portion of the fastener. The fastener has two threaded portions, wherein one threaded portion is configured as a right-hand thread and the other threaded portion is configured as a left-hand thread (or vice versa). Moreover, the invention comprises a mounting method for such a fastening arrangement, in which the setting operation (anchoring of the fastener, adjustment of the sheath) can be managed in one step without changing the driving direction of the setting tool.

Classes IPC  ?

• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses
• E04D 3/36 - AssemblageFixation
• F16B 25/10 - Vis exécutant une fonction autre que celle de formation de filets, p. ex. vis-forets

Produits et services

(1) Machines, machines-outils et outils mécaniques, nommément machines à visser les boulons et les vis ainsi que leurs pièces constitutives; machines pour l'usinage des métaux ainsi que leurs pièces constitutives; machines et appareils mécaniques pour placer ou retirer des vis et des boulons, nommément clés dynanométriques électriques, clés dynanométriques hydrauliques, ainsi que leurs pièces constitutives; limiteur de couple en tant qu'élément d'une machine; outils tenus à la main actionnés autrement que manuellement, nommément perceuses à main électriques, perceuses à main pneumatiques, outils à actionnement explosif pour l'enfoncement de rivets, marteaux pneumatiques à main, marteaux électriques à main, perforatrices à percussion à main; parties de machines, nommément foreuses rotatives, fraises pour perceuses, mandrins de perceuses électriques, mèches de perçage et de centrage, sous forme de pièces de machines, mèches pour perceuse électrique, perceuses à colonnes, machines rotatives pour machines, convertisseurs de couple, convertisseurs hydrauliques de couple pour machines, dispositifs pivotants. (2) Outils et instruments à main à fonctionnement manuel, nommément marteaux manuel, outils à main à fonctionnement manuel, outils à main entraînés manuellement, outils à riveter manuels, perceuses manuelles; appareils manuels d'usinage de vis et de boulons, nommément outils à main pour la fabrication de vis et de boulons; clés dynamométriques; limiteur de couple; clés (outils). (1) Services de construction, nommément constructions de bâtiments, de toits, de façades de bâtiments, ainsi que construction de murs; services d'installation et de réparation de bâtiments, de toits, de façades de bâtiments et de murs; travaux d'installation de réservoirs d'eau pluviale, de réservoirs de stockage, de silos à ciment, à grains, de silos en béton, en ciment, de silos métalliques et de silos-élévateurs, installation d'étagères de rangement, de présentoirs, de râteliers d'entreposage pour équipements sportifs, pour oeuvres d'art et pour bicyclettes, installation d'escaliers en bois, en métal et d'escalier non métalliques, installation d'armatures de portes métalliques, installation de cadres de porte métalliques et non-métalliques, installation de cadre de fenêtre métallique et de cadres de fenêtres en bois, installation de cadres métalliques pour portes coulissantes, installation de châssis de fenêtre métalliques et non métalliques, installation de châssis de portes métalliques, installation de rails d'acier, de rail de guidage métallique, de rails de fenêtre métalliques, de rails métalliques pour portes coulissantes, assemblage et installation de charpentes, installation de couvertures de toits métalliques, de cornières pour toitures métalliques, installation de carrelage mural métallique pour le bâtiment, d'ossatures de mur de bâtiment constituée principalement de métal, installation de panneaux muraux métalliques, de plaques murales décoratives, de revêtements muraux de doublage métalliques pour la constructions, de revêtements muraux d'insonorisation acoustiques, revêtements muraux de placages métalliques pour la construction, de revêtements muraux métalliques pour construction, de revêtements muraux en plastiques, de revêtement muraux en vinyle; installation de constructions, structures portantes, nommément installation de citernes à eau métalliques et non métalliques, de citernes en métal pour le stockage de liquides, de rayonnages métalliques et non métalliques, de murs en béton, de toitures métalliques, installation de balustrades, installation de constructions industrielles en métal à savoir installation d'entrepôts métalliques, d'échafaudages métalliques, d'installation de supports métalliques pour fondations de panneaux solaires extérieurs pour la production d'électricité.

Produits et services

Machines, namely setting machines with torque control in the nature of machines for precision driving of screws and bolts to a specific torque limit, torque limiting component parts to setting machines in the nature of machines for precision driving of screws and bolts to a specific torque limit, machine tools for setting screws under torque control and mechanical tools, namely, mechanical torque control devices and components in the nature of machines for precision driving of screws and bolts to a specific torque limit; machines for machining of metals; electrically, pneumatically or hydraulically powered machines and mechanical apparatus in the nature machines for precision driving of screws and bolts to a specific torque limit for placing screws and bolts; mechanical apparatus and tools as parts of the aforementioned products in the nature of torque-controlled setting machines in the nature of machines for precision driving of screws and bolts to a specific torque limit; torque limiter as part of a machine; hand-held tools, other than hand-operated, namely, setting tools in the nature of machines for precision driving of screws and bolts to a specific torque limit, rotary units in the nature of machines for precision driving of screws and bolts to a specific torque limit, electric drills Construction of buildings and building components in the nature of roofs, facades, masonry walls, structural walls; installation and repair of buildings and building components in the nature of roofs, facades, masonry walls, structural walls; installation of structures in the nature of buildings, supporting structures in the nature of tanks, silos, racks, walls, roofing, wall coverings, guard rails, staircases, frames, industrial building constructions of metal, solar paneling

Abrégé

A holding device (10) for holding a component (12), the holding device (10) being convertible from a component holding mode into a component release mode by magnetic force. The holding device (10) for holding the component (12) has a movable detent element (14), the position of which is not influenced by the magnetic force. A method for releasing a snap-in connection between a holding device (10) and a component (12) is also provided, having the following steps: generating a magnetic field in the vicinity of the holding device (10); and applying a force that moves the holding device (10) and the component (12) apart from each other to release the snap-in connection.

Classes IPC  ?

• A44B 17/00 - Fermetures à pression
• B64C 1/00 - FuselagesCaractéristiques structurales communes aux fuselages, voilures, surfaces stabilisatrices ou organes apparentés

Produits et services

Machines for metal treatment; machines and mechanical apparatus for processing, placing or removing rivets, screws and bolts (included in this class); mechanical riveting tools, hydraulic, pneumatic and electric devices for placing cap nuts; robots and automated handling devices for positioning riveting devices; mechanical apparatus and tools as parts or accessories for the aforesaid goods, namely for supplying rivets and for carrying out riveting processes; housings and parts of housings for housing machine elements operated by pneumatic, hydraulic or electric means (included in this class). Repair services, repair, maintenance, retrofitting and reconditioning of technical assembly apparatus, repair of riveters, screwdrivers and bolting machines.

Produits et services

Metal protection products, namely wear and corrosion resistant coatings containing metals and metal compounds. Construction materials of metal; metallic wires (non electrical); ironmongery and small items of metal hardware; pipes of metal; mass-produced metal parts of all kinds, including screws and nuts, rivets, bolts, nails, fittings of metal, sockets, dowels, plates and load distribution disks; metallic mounting bolts; fixing elements and devices for industry and building, as well as component parts therefor and metallic accessories, included in this class; dowels; metal fittings and hinges; metal products that have been machined to obtain corrosion or wear resistance. Treatment of metal materials; treatment of metal parts to obtain resistance to corrosion and wear.

Abrégé

A ball screw drive (10) including a threaded spindle (12) and a spindle nut (14) which at least partially coaxially encloses the threaded spindle (12) and has a stop at an axial end face (18). A multiplicity of balls can circulate in the space (16) between the threaded spindle (12) and the spindle nut (14). A radial stop element (22) is connected to the threaded spindle (12) in a force-fitting manner and adapted to interact with the complementary axial end face (18) of the spindle nut (14). A bearing element is provided for receiving a first longitudinal end of the spindle nut (12). The radial stop element (22) and the bearing element are designed in combination as an integral bearing/stop element (24) which has two anti-rotation features (26, 28).

Classes IPC  ?

• F16H 25/20 - Mécanismes à vis
• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Abrégé

n. This threaded section 26 allows a controlled overwinding of the facade panel screw in use. A corresponding fastening arrangement includes a facade panel, a substructure for transferring the load to a building surface and the facade panel screw.

Classes IPC  ?

• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses

Abrégé

A sleeve (20) for centering fasteners during the assembly of components such as facade elements on the substructure of a building envelope includes a sleeve body (23) and a connection bracket (25). The sleeve body (23) has a plurality of sleeve elements (21, 22) which are grouped around a central center axis A and are spaced apart from each other by gaps running in the sleeve longitudinal direction. At least a first (21) and a second (22) sleeve piece are connected to each other at an axial longitudinal end of the sleeve body (23) by a separable connection bracket (25), preferably the connection bracket is separable via predetermined breaking points. Such a sleeve is used in the construction of facades, wherein it is inserted into a pilot hole of a facade element, the connection bracket is broken off and a fastener is inserted into the sleeve. Driving the fastener centers the fastener in the sleeve and the sleeve is removed from the pilot hole.

Classes IPC  ?

• B25B 23/00 - Parties constitutives ou accessoires des clés à écrous, clés anglaises, tournevis
• E04F 13/08 - Revêtements ou enduits, p. ex. pour murs ou plafonds constitués d'éléments d'habillage ou de garnissageLeurs bâtisLeurs moyens de fixation constitués de plusieurs éléments d'habillage ou de garnissage semblables
• B21D 39/00 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes
• F16B 41/00 - Dispositions contre la perte des boulons, écrous, broches ou goupillesDispositions empêchant toute action non autorisée sur les boulons, écrous, broches ou goupilles
• F16B 19/02 - Chevilles ou manchons pour positionner les parties de machines, p. ex. goupilles coniques à encoche, goupilles de montage, manchons, bagues excentriques d'ajustement
• B23B 49/02 - Gabarits ou douilles d'alésage

Abrégé

S; and the facade panel screw does not have a drill tip. Such a facade panel screw is used in a fastening arrangement, which comprises a load-bearing component (substructure) and a facade panel. Due to its design, the facade panel screw is able to simplify the fastening of the facade panel and to at least partially correct an inclined positioning in response to the installation.

Classes IPC  ?

• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses
• E04F 13/08 - Revêtements ou enduits, p. ex. pour murs ou plafonds constitués d'éléments d'habillage ou de garnissageLeurs bâtisLeurs moyens de fixation constitués de plusieurs éléments d'habillage ou de garnissage semblables
• E04F 13/00 - Revêtements ou enduits, p. ex. pour murs ou plafonds

Abrégé

A ball screw drive having a threaded spindle and a spindle nut which coaxially encloses it at least partially. The spindle nut receives a ball deflector and therefore has an imbalance caused thereby. A force transmission element is positively connected to the spindle nut. The outer surface of the spindle nut has a recess which is dimensioned and arranged to serve as a stop or groove for the force transmission element and also contributes to the imbalance compensation of the spindle nut. An imbalance compensation method is also provided by fixing the action surface as a surface recess such that the smallest width of the recess is at least 3 times as large as the maximum radial indentation thereof. The filling up of at least parts of the recess by the force transmission element is accounted for and the recess is lengthened along the spindle nut for imbalance reduction.

Classes IPC  ?

• F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous
• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Abrégé

A fastening arrangement for anchoring facade panel elements includes a substructure on a building shell and a plurality of facade panel elements. The fastening arrangement has an adhesive component and a mechanical securing component. The fastening arrangement is characterized in that per facade panel element, at least two securing straps are provided as mechanical securing components, each having at least two fastening points. At least one fastening point of the two securing straps has a sliding point which uses an oblong hole. Furthermore, the longitudinal extent of this oblong hole defines an axis which is tilted at an angle γ of between 5° and 20° relative to the vertical axis. The fastening arrangement is constructed by preparing the substructure and at least one facade panel element for fastening, attaching the securing straps to the facade element and applying an adhesive component. After aligning and attaching the facade element to the substructure, the securing straps are attached to the substructure, with one attachment point of a first securing strap being the sliding point, and after fastening of the sliding point, the oblong hole is tilted at an angle γ of between 5° and 20° with respect to the vertical axis.

Classes IPC  ?

• E04F 13/08 - Revêtements ou enduits, p. ex. pour murs ou plafonds constitués d'éléments d'habillage ou de garnissageLeurs bâtisLeurs moyens de fixation constitués de plusieurs éléments d'habillage ou de garnissage semblables
• E04B 2/88 - Murs-rideaux
• E04F 13/23 - Ancrages, supports d'angle ou consoles réglables
• F16B 11/00 - Assemblage d'éléments structuraux ou parties de machines par collage ou en les pressant l'un contre l'autre, p. ex. soudage sous pression à froid

Abrégé

A ball screw including a threaded spindle and a spindle nut has a ball deflector arranged in an opening in the lateral surface of the spindle nut. The ball deflector is formed with an upper shell and a lower shell, the lower shell being arranged radially inwardly closer to the spindle nut longitudinal axis than the upper shell. The lower shell has a substantially half-shell-shaped contour. Both the upper shell and the lower shell are fastened in the spindle nut without any further, discrete mechanical fastening elements, and the ball deflector formed thereby does not protrude beyond the outer contour defined by the spindle nut.

Classes IPC  ?

• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes

Abrégé

A method for fastening material webs, such as roofing sheets made of plastic on a surface with fastening points (head disks including a hot-melt adhesive layer) arranged thereon using a self-propelled fastening unit (20) comprising the following steps: (A) detecting a route marking by means of a first detector (22) on the fastening unit (20) and moving the fastening unit along the route marking; (B) detecting and calculating the position of a head disk (14) by means of a second detector (24); (C) approaching and remaining at an operating position during the subsequent fastening process; (D) positioning an induction heater (30) and heating up the head disk (14) for a period of time Th; (E) removing the induction heater (30) and pressing the material web against the head disk by a cooling device (32); (F) taking off the cooling device after a predetermined time Tk has passed; (G) continuing with (A), until an end of the route marking is reached.

Classes IPC  ?

• G05B 19/402 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par des dispositions de commande pour le positionnement, p. ex. centrage d'un outil par rapport à un trou dans la pièce à usiner, moyens de détection additionnels pour corriger la position
• B29C 65/36 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec des éléments chauffés qui restent dans le joint, p. ex. un "élément de soudage perdu" chauffés par induction
• B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
• E04D 15/04 - Équipement ou outils de couvreur pour couvertures en plaques, feuilles ou matériaux flexibles
• E04D 5/14 - Moyens de fixation pour ces matériaux
• B29L 31/10 - Éléments de construction, p. ex. briques, blocs, tuiles, panneaux, mâts, poutres

Abrégé

A ball screw drive (10) including a threaded spindle (12) having a first, free end (16) and a second end (17) which can be connected to a drive, and a spindle nut (14) at least partially enclosing the threaded spindle (12) coaxially. A plurality of balls (26) recirculate in the space between the threaded spindle (12) and the spindle nut (14) form the core element. An extension sleeve (15), which connects coaxially to the spindle nut (14), is fixedly connected to the latter and moves together with it relative to the threaded spindle (12). At the first end (16) of the threaded spindle (12), a substantially circular bearing ring (18, 30, 50, 70) is attached to the outer circumference of the threaded spindle (12), which circular bearing ring serves as a shaft bearing between the threaded spindle (12) and the extension sleeve (15) and which has a noise-dampening effect due to at least one integrated spring/damping element. This spring/damping element of the bearing ring (30, 50, 70) is preferably a combination of at least one notch (32, 52, 72) on the inner circumference of the bearing ring (30, 50, 70) and an annular gap (34, 54, 74).

Classes IPC  ?

• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
• F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous
• F16C 33/58 - Chemins de roulementBagues de roulement
• F16H 25/20 - Mécanismes à vis
• F16F 9/32 - Ressorts, amortisseurs de vibrations, amortisseurs de chocs ou amortisseurs de mouvement de structure similaire, utilisant un fluide ou moyen équivalent comme agent d'amortissement Parties constitutives
• F16C 29/00 - Paliers pour pièces à déplacement uniquement linéaire
• F16C 29/02 - Paliers à contact lisse

Abrégé

A magnetic clamping heat sink assembly is disclosed including a magnetic assembly with a carrier body including a magnet. A spring resiliently biases the carrier body. A base assembly includes a base plate. In a first operating condition, the base assembly of the magnetic clamping heat sink assembly is positioned in a first position away from a ferromagnetic element, and the spring holds the carrier body at a medial position spaced apart from the base plate. In a second operating condition, the base assembly of the magnetic clamping heat sink assembly is positioned in a second position adjacent to the ferromagnetic element, and the carrier body is driven downward against a force of the spring to a lower position and into contact with the base plate by magnetic attraction between the at least one magnet and the ferromagnetic element.

Classes IPC  ?

• E04D 15/04 - Équipement ou outils de couvreur pour couvertures en plaques, feuilles ou matériaux flexibles
• B23K 13/01 - Soudage par chauffage au moyen d'un courant haute fréquence par chauffage par induction
• B23K 37/00 - Dispositifs ou procédés auxiliaires non spécialement adaptés à un procédé couvert par un seul des autres groupes principaux de la présente sous-classe

Abrégé

A grommet (20, 30) as part of a fastening element for a building envelope essentially comprises a head (21), a tip (22) and a sleeve (23) therebetween, wherein the head (21) is essentially constructed as an extensive washer (24), the central hole of which is adjoined by the tubular sleeve (23). The tip (22) narrows essentially in a conical or tapered manner to a smaller diameter. The grommet (20, 30) has a sensor arrangement (25), with at least one RFID transponder with antenna and a sensor operatively connected to the transponder.

Classes IPC  ?

• G06K 19/077 - Détails de structure, p. ex. montage de circuits dans le support
• G01D 11/24 - Boîtiers
• E04B 1/76 - Isolation thermique ou acoustique, absorption ou réflexion de la chaleur ou du sonAutres méthodes de construction procurant des conditions thermiques ou acoustiques favorables, p. ex. par accumulation de chaleur à l'intérieur des murs spécifiquement relatives à la chaleur uniquement
• F16B 13/12 - Chevilles métalliques creuses bloquées par insertion d'un clou, d'une vis ou d'une pièce similaire
• F16B 13/00 - Chevilles ou autres dispositifs fixés à des parois ou autres emplacements par insertion dans des trous préparés à cet effet

Abrégé

A fastening arrangement with a clip body, a fastening device and a panel is provided, with the clip body having a retainer for the fastening device, the clip body being fastenable to the panel which has fastening and positioning openings so that the clip body can be positioned on the panel by a stop of a positioning element on an edge of the positioning opening. The positioning opening has a size which allows the clip body with the fastening device held thereon to be passed at least partially therethrough, the positioning element bearing at least partially against the edge of the positioning opening and the positioning element at the same time being or being connected to a locking element which makes contact with the panel on a side facing away from the retainer. The locking element is arranged opposite the retainer. A clip body and clip are also provided.

Classes IPC  ?

• F16B 21/07 - Dispositifs de fixation largables à action rapide dans lesquels la douille a une partie élastique
• B60R 13/00 - Éléments pour habiller la carrosserie, l'identifier ou la décorerAménagements ou adaptations pour la publicité
• F16B 2/24 - Clips, c.-à-d. dispositifs de fixation à serrage effectué uniquement par la résistance à la déformation inhérente au matériau dont est fait le dispositif en matériau élastique, p. ex. un matériau caoutchouteux métallique
• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques
• F16B 5/06 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par brides ou clips
• B64C 1/06 - CadresLissesLongerons

Abrégé

The invention relates to a clip body (10) with a retainer (12) for a fastening device (14), wherein the clip body (10) can be fastened to a panel (18) provided with at least one fastening opening (16), wherein the clip body (10) has two limbs, of which one can be arranged on a first side of the panel (18) and the other can be arranged on a second side of the panel (18), and for this purpose is placed onto an edge of the panel (18), and the clip body (10) has at least one positioning element (20). According to the invention, the at least one positioning element (20) can be guided through the fastening opening (16) in the panel (18), and the clip body (10) can be positioned on the panel (18) by a stop of the at least one positioning element (20) on an edge (22) of the fastening opening (16). The invention also relates to a clip (30) and a fastening arrangement (50).

Classes IPC  ?

• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques
• F16B 5/06 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par brides ou clips
• F16B 37/08 - Écrous à largage rapide, p. ex. faits de plusieurs partiesÉcrous mobiles le long du boulon après basculement de l’écrou
• F16B 21/07 - Dispositifs de fixation largables à action rapide dans lesquels la douille a une partie élastique

Abrégé

A method for establishing a connection, with the following steps: inserting a sleeve (12) having a stop flange (10) into a bore (14), in such a way that the stop flange (10) is at a distance from a bore edge (16); anchoring at least one elevation (18) of a free end portion (20) of the sleeve (12) in the bore wall (22) by widening the free end portion (20) of the sleeve (12); and moving the stop flange (10) in the direction of the at least one fixed anchored elevation (18) of the free end portion (20) of the sleeve (12), by widening a further portion (24) of the sleeve.

Classes IPC  ?

• F16B 19/10 - Rivets creuxRivets en plusieurs morceaux fixés par action mécanique
• F16B 13/08 - Chevilles ou autres dispositifs fixés à des parois ou autres emplacements par insertion dans des trous préparés à cet effet avec parties s'agrippant dans le trou ou derrière la paroi après insertion les parties s'agrippant étant distinctes du dispositif et amenées dans leur position finale sans opération manuelle ultérieure
• F16B 43/00 - Rondelles ou dispositifs équivalentsAutres dispositifs de support pour têtes de boulons ou d'écrous

Produits et services

Building materials and building parts of metal, sections of metal for the building and construction sector, such as rails, bars, holders, pillars; cables and wire of metal (not for electric purposes); hardware; conduits and tubes of metal; substructures of metal, especially of aluminum, for the cladding of facades, in particular retro-ventilated facades; fasteners of metal, wall mounting brackets, metal facade cladding. Building materials (not of metal) for use in the cladding of facades and substructures, non-metallic tubes, holders, rails and profiles; connectors and fasteners (not of metal). Building, repair; installation services; assembly and repair of facade claddings and substructures. Technological services and research services, design services relating to the cladding of facades, creation of buildings; measurement services; consultancy services in the field of construction.

Abrégé

A ball screw having a spindle nut (21), a threaded spindle, and a retaining element (23) is provided. The retaining element (23) is connected in a form-fitting, play-free manner to the threaded nut (21) by a projection (24) which fits around the outside of the threaded nut (21) in an end region. The threaded nut (21) and the retaining element (23) functioning as a force transmission member are first positioned precisely during manufacture and then connected by a form-fitting, in particular play-free connection, in particular by caulking, crimping, clinching or other deformation processes.

Classes IPC  ?

• F16H 25/22 - Mécanismes à vis avec billes, rouleaux ou organes similaires entre pièces travaillant en conjugaisonÉléments essentiels pour l'utilisation de ces organes
• F16H 25/24 - Éléments essentiels pour ces mécanismes, p. ex. vis, écrous
• F16H 25/20 - Mécanismes à vis
• F16H 25/08 - Transmissions comportant essentiellement et uniquement des systèmes came et galet ou des mécanismes à vis et écrous pour convertir un mouvement rotatif en mouvement alternatif et vice versa

Abrégé

A lightweight construction fastener 30 has two basic elements, a clip body 40 including a connected fastening element 32. The clip body 40 has a first leg 41 and a second leg 42, which are arranged located opposite one another and which are connected to one another by a web 45 on one end. The fastening element 32 includes a flat base plate 34 with two protrusions 35, 36, and a cylindrical holding part 33. On its outer side, the second leg 42 has two frames 43, 44 with apertures 46, 47. They are provided to accommodate the protrusions 35, 36 of the fastening element 32, so that the fastening element is held in the clip body 40 with play, but in a captive manner. The frames 43, 44 are substantially arranged at right angles to the longitudinal axis LA, which is why the orientation of the two protrusions 35, 36 is also oriented along the axis LA.

Classes IPC  ?

• F16B 31/04 - Assemblages à vis spécialement modifiés en vue de résister à une charge de tractionBoulons de rupture maintenant constante la charge de traction
• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques
• F16B 5/01 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation spécialement adaptés pour panneaux en nid d'abeilles
• F16B 37/12 - Écrous ou pièces similaires avec entrées de filetage avec surfaces d'entrée de filetage consistant en une insertion de ressorts hélicoïdaux, de disques ou de pièces analoguesÉcrous constitués par des morceaux indépendants de fil métallique enrouléGarnitures filetées intérieures pour trous

Abrégé

A lightweight construction fastener or clip having a clip body and a fastening element 32. The clip body includes a first leg and a second leg, which are connected with each other by a web 45 at one end. The clip body is formed of one piece, but includes at least two volume sections 61, 62, wherein the first section 61 is formed of a first plastic and the second volume section 62 is formed of a second plastic. The properties of the first and second plastics are different from each other with respect to one or more criteria. A method for producing such a clip body includes manufacturing it in one piece in a multi-component injection molding process from at least two plastics. Further the invention includes a method for manufacturing the lightweight construction fastener or clip by placing a fastening element 32 into the injection molding tool; encapsulating the fastening element 32 and overmolding the fastening element 32 in a multi-component injection molding process.

Classes IPC  ?

• F16B 37/04 - Dispositifs pour fixer les écrous à des surfaces, p. ex. à des feuilles, à des plaques
• F16B 2/22 - Clips, c.-à-d. dispositifs de fixation à serrage effectué uniquement par la résistance à la déformation inhérente au matériau dont est fait le dispositif en matériau élastique, p. ex. un matériau caoutchouteux

Abrégé

A self-drilling, self-countersinking fastener is provided that includes a shaft, a countersunk head located at a first end of the shaft, and a tapered point located at an opposite end of the shaft. A thread integrally extends from the shaft and extends along at least a portion of a length thereof. The countersunk head includes a frustoconical region having a first, smaller diameter in a shaft connection region and a second, larger diameter at a second end defining an edge area of the head. A plurality of radially extending ribs are located on the frustoconical region and extend from an area of the first, smaller diameter to a respective radially outer rib end spaced radially inwardly by a distance X from the edge area of the head. A respective cutting edge is located on each of the ribs.

Classes IPC  ?

• F16B 35/06 - Têtes de forme particulière
• F16B 25/10 - Vis exécutant une fonction autre que celle de formation de filets, p. ex. vis-forets
• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses

Produits et services

Metallic building materials, particularly mass-produced metal parts of all types, such as rivets, blind rivets, nuts and parts thereof, threaded blind rivets, bolts, fittings, dowels, plates and load distribution plates; fastening bolts; fastening elements and devices for industry and construction, as well as components, parts and accessories thereof, all of metal, included in this class.

Produits et services

Metal building materials, in particular standard metal parts, such as screws, nuts, rivets, blind rivets, nuts for blind rivets, washers, bushings, bolts; metal fasteners, elements for assembling, in particular by riveting, bolting, rivets, metal screws and bolts, blind rivets and their parts, threaded blind rivets, profiled blind rivets, progressive blind rivets and nuts for blind rivets. Mechanical machines and apparatus for machining, sealing or removing rivets, screws and bolts (included in this class), mechanical riveting and screwing tools, pneumatic and electric hydraulic nut sealing apparatus for blind rivets, mechanical devices and tools in the form of parts or accessories for the aforementioned products, namely, for bringing in and holding rivets, as well as for making riveting processes; housings and parts of housings for receiving pneumatically, hydraulically or electrically actuated mechanical elements (included in this class). Riveting tools, hand-operated instruments for inserting blind rivets, apparatus for placing blind rivets, screws and bolts.

Abrégé

A door hinge (1) or window hinge (1) having two hinge parts (2,4) which are operatively connected to one another so as to be rotatable about a common hinge axis (2), wherein at least one door-or-window-side first hinge part (3) has a plate-like portion (8) which interacts in a fixedly and releasably connectable manner with a holding piece (9) which can be inserted into a groove in the end side of the door or window, wherein the plate-like portion (8) is oriented in an imaginary plane running parallel to the hinge axis (2) and is adjustable with respect to the holding piece (9) in an imaginary plane running at a right angle to the plane of the plate-like portion (8), and wherein an adjustment screw (11) can be screwed into at least one thread (1) of the holding piece (9). Provision is made for a head (12) of the adjustment screw (11) to be arranged between an intermediate piece (14) and the plate-like portion (8) by a clamping device (5) which applies to force to the plate-like portion (8) and the intermediate piece from opposite side and thus hold them together.

Classes IPC  ?

• E05D 7/04 - Charnières ou gonds réglables par rapport au battant ou au dormant
• E05D 5/02 - Pièces de fixation, p. ex. abattants
• E05D 7/00 - Charnières, gonds ou pivots de structure particulière
• E05D 3/02 - Charnières ou gonds à broches à une broche

Abrégé

A fastener installation tool is provided for installing threaded fasteners through a washer plate having a center hole used in connection with roofing membrane installation. The installation tool is configured to receive different types of washer plates, and is easily dis-assembleable in the field without the need for tools in order to easily and simply clear jams.

Classes IPC  ?

• B25B 21/00 - Outils portatifs à moteur pour serrer ou desserrer les vis ou les écrousAccessoires pour appareils à percer ayant les mêmes buts
• B25B 23/00 - Parties constitutives ou accessoires des clés à écrous, clés anglaises, tournevis
• B25B 23/04 - Dispositions pour manipuler les vis ou écrous pour l'alimentation en vis ou écrous
• E04D 15/00 - Équipement ou outils de couvreur
• B23P 19/08 - Machines pour placer des rondelles, bagues annulaires élastiques ou éléments analogues sur des boulons ou autres éléments
• E04D 15/04 - Équipement ou outils de couvreur pour couvertures en plaques, feuilles ou matériaux flexibles
• E04D 15/06 - Équipement ou outils de couvreur pour la manipulation des matériaux de couverture ou d'étanchéité en rouleaux

Produits et services

Machines and mechanical equipment for placing, fitting or removing rivets, screws and bolts (included in this class); riveting power tools and apparatus for fitting blind nuts including power tools and battery-operated apparatus; mechanical tools and apparatus as parts of or accessories for the previously listed goods, namely for rivet supply and for carrying out riveting processes. Repair, maintenance, refitting and reconditioning services for fitting apparatus, particularly riveting, screwing and bolting machines.

Produits et services

Chemical products intended for industry and science, particularly chemical surface coatings and thin layers of organic and inorganic materials on metal substrates ; tempering and soldering preparations. Metallic building materials, particularly mass-produced metallic parts of metal of all types, such as screws, nuts, rivets, blind rivets and and parts thereof, threaded blind rivets, bolts, hinges, dowels, plates and load distribution plates; securing bolts; fixing elements and devices for industry and construction, and components and accessories thereof, all of metal, included in this class. Machining of materials, particularly services for applying functional coatings and metallization on screws, nuts, rivets, blind rivets and and parts thereof, threaded blind rivets and bolts, including pre-treatment and post-treatment thereof.

Abrégé

A self-drilling screw composed of an austenitic or some other non-corrosive base material (1) is provided, having a shank (12), having a cutting or shaping drilling or threaded tip (16) arranged at one shank end and having a hard coating (3) applied at least to the drilling or threaded tip (16) by electrodeposition, this hard coating (3) having a layer containing a transition metal, for example a hard chromium layer. The shank (12) has a hard edge layer (2) at least under the hard coating (3). A topcoat (4) composed of a lubricating and heat-dissipating material, which preferably is metal, wax and/or lacquer, is applied to the hard coating (3).

Classes IPC  ?

• F16B 35/00 - Boulons filetésBoulons d'ancrageGoujons filetésVisVis de pression
• F16B 33/06 - Traitement de surface des parties où se trouve réalisé le filetage, p. ex. pour empêcher le grippage
• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses

Abrégé

Sf of the shaft (14) in the area of the thread section (20) distant from the head. According to the invention it is provided that the thread (16) extends up to the bottom of the head (12). The invention further relates to a fastening arrangement (24), the use thereof, and a method.

Classes IPC  ?

• F16B 35/04 - Boulons filetésBoulons d'ancrageGoujons filetésVisVis de pression avec tête ou axe de forme particulière permettant de fixer le boulon sur ou dans un objet
• F16B 25/00 - Vis formant des filets dans le matériau dans lequel elles sont vissées, p. ex. vis à bois, vis auto-taraudeuses
• F16B 39/30 - Blocage uniquement par tracé spécial du filetage
• F16B 25/10 - Vis exécutant une fonction autre que celle de formation de filets, p. ex. vis-forets
• F16B 5/02 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation utilisant un filetage

Produits et services

Machines and power tools for placing, inserting, or withdrawing rivets, screws and nuts, namely, riveting guns and battery-powered riveting guns

Produits et services

Building materials of metal, bolts, screws, rivets, tacks (of metal); structures of metal, receptacles, containers, tanks, silos, roofing, sub-flooring, fasteners, frames, guard rails, supporting structures, staircases, door casings, partitions, verandas, stands, fall prevention safeguards (all of metal); coverings for construction, corner pieces, plaques, corner profiles (of metal); ironmongery and small items of hardware. Machines, electrical, hydraulic, pneumatic tools as well as instruments and parts thereof for fastening bolts, screws, rivets, tacks. Shelves, racks. Construction services; repair services; installation work; installation of structures, supporting structures, tanks, silos, racks, walls, roofing, wall coverings, guard rails, staircases, frames, industrial constructions of metal, solar paneling.

Produits et services

[ Machine shop services in the nature of machining of materials, particularly services for applying functional coatings and metallization on screws, nuts, rivets, blind rivets and parts thereof, threaded blind rivets and bolts, including pre-treatment and post-treatment thereof ] Chemical products intended for industry and science, particularly chemical surface coatings and thin layers of organic and inorganic materials in the nature of chemicals, resins, polymers, sealants for use on metal substrates; tempering preparations and soldering preparations in the nature of soldering chemicals, soldering agents Metallic building materials in the nature of mass-produced metallic parts of metal of all types, namely, screws, nuts, rivets, blind rivets and parts thereof, threaded blind rivets, bolts, hinges, dowels, plates and load distribution plates; bolts of metal, namely, securing bolts; metal fixing elements and devices for industry and construction, and components and accessories thereof, namely, metal profiles for arranging devices on and in walls, ceiling and other surfaces
