A winding method and machine for making multiple coils of conducting wires are described. Step A provides for prearranging a winding machine with a wire guiding device configured for guiding conducting wires in one or more bundles, a winding tool provided with two winding chambers in which the bundles of conducting wires are intended to be wound, a first spindle intended for rotating the winding tool, one or more storage satellites configured for storing a length of the bundles of conducting wires and a second spindle intended for rotating the storage satellites. The bundles of conducting wires are guided on the winding tool through the wire guiding device and are stored on the storage satellites. The first spindle rotates the winding tool on a rotation axis X-X to cause the winding of a first length of the bundles of conducting wires provided by the wire guiding device in a first winding chamber. The second spindle rotates the storage satellites about a rotation axis X-X and about the winding tool to cause the winding, in a second winding chamber, of second lengths of the bundles of conducting wires. The second lengths of the bundles are not withdrawn upstream from the wire guiding device, but downstream from the storage satellites.
H02K 15/04 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques d'enroulements avant leur montage dans les machines
H02K 3/24 - Enroulements caractérisés par la configuration, la forme ou le genre de construction du conducteur, p. ex. avec des conducteurs en barre avec des canaux ou des conduits pour un agent de refroidissement entre les conducteurs
A method and an apparatus for making a stator for axial flux and distributed winding electric motors are described, as well as a stator and a motor obtained with the method described. The method provides for making coils with linear lengths of conducting wire. First linear lengths of coil are inserted into open stator slots of a stator body, so that to occupy all the stator slots. Second linear lengths of coil are gripped by a tool and roto-translated, with respect to the corresponding first linear lengths, up to also being inserted into the stator slots, above the first linear length of a different coil. For this, the apparatus comprises a lower tool having the task of holding the stator body with the open slots facing upward, and an upper tool provided with teeth which jut out towards the lower tool, to grip the coils and impart roto-translation. The linear lengths of the coils are preferably subjected to a pressing and/or carburizing treatment before being inserted into the stator slots.
H02K 15/04 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques d'enroulements avant leur montage dans les machines
H02K 15/06 - Montage d'enroulements préfabriqués dans les machines
H02K 15/043 - Enroulement de fils ou de feuilles conducteurs plats
H02K 15/066 - Enroulements constitués de sections complètes, p.ex. bobines ou enroulements ondulés insérés perpendiculairement à l’axe des encoches ou de canaux interpolaires
3.
Method for the making of a stator for electric motors, and respective stator for electric motors
A method for the making of a stator for electric motors, comprising: providing two jigs, each having a circular opening inside the jig and a series of teeth inside the circular opening extending towards a central axis, the teeth defining a series of slots; arranging the two jigs coaxially spaced along a central axis; winding, between the teeth, a plurality of wires to form a plurality of windings, so the wires of each winding occupy a plurality of the slots of both jigs, the windings including linear wire portions extending between the two jigs; inserting, from the inside, a plurality of first stator portions between the linear wire portions; and inserting, from the outside, a plurality of second stator portions complementary to the first stator portions between the linear wire portions, to form a stator body.
H02K 15/043 - Enroulement de fils ou de feuilles conducteurs plats
B21F 3/02 - Enroulement des fils métalliques selon des formes particulières en hélice
H02K 3/28 - Schémas d'enroulements ou de connexions entre enroulements
H02K 15/06 - Montage d'enroulements préfabriqués dans les machines
H02K 15/066 - Enroulements constitués de sections complètes, p.ex. bobines ou enroulements ondulés insérés perpendiculairement à l’axe des encoches ou de canaux interpolaires
4.
METHOD AND WINDING MACHINE FOR MAKING AN ELECTRIC COMPONENT PROVIDED WITH A SPIRAL-SHAPED WINDING
A method and an automatic winding machine (20) for making an electric component (1) provided with a support (2) inside which at least one winding of a conducting wire (4) is housed, are described. Although the winding extends spirally, the conducting wire with which it is made is not twisted. It is provided to rotate the support on its axis while pushing the conducting wire into a slot (6', 6'') of the support by means of a pressure roller (53) which rolls on the slot. The pressure roller is guided by a wire guiding flange (49, 50) which controls its displacement so as the pressure roller intercepts and travels along the entire length of the slot. In an embodiment, the electric component is provided with a first winding (3') on a front side (2') of the support and with a second winding (3'') on the rear side (2'') of the support. The two windings are made with the same wire, which is overlapped on the perimeter edge of the support. The pressure roller is displaced from the front side to the rear side to perform the insertion of the wire into the slot of the second winding, by using a second wire guiding flange (50) as a guide.
A method and an apparatus for manufacturing a star yoke stator for electric motors with distributed winding, as well as a stator achieved with the method described, are described. A two-component stator is provided with a central star-shaped element provided with radial stator teeth and stator slots interposed between the teeth, and a yoke into which the star is inserted with the windings included in the stator slots. The assembly method provides for positioning the star on a rotating spindle and for inserting the linear portions of coils of wire, previously formed on a winding tool and preferably pressed and carburized, into the stator slots, so that to keep the arrangement of the wires in order. The windings are completed by alternating the movements of inserting coils into the stator slots and of rotating the star. The yoke can be coupled to the star in a final step, whenever the yoke is made in one piece, or can be constructed around the star by coupling sectors of the yoke as the windings are completed. An apparatus configured for implementing the method described is further described. The invention further concerns a stator directly obtained with the method described and an electric motor integrating the stator. Greater filling coefficient, greater efficiency, less leakage currents and reduced stator height are achieved.
H02K 15/04 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques d'enroulements avant leur montage dans les machines
H02K 15/06 - Montage d'enroulements préfabriqués dans les machines
6.
WINDING METHOD AND MACHINE FOR WINDING CONDUCTING WIRE ON POLE PIECES OF ELECTRIC MOTO ROTORS
A method and an automatic winding machine for making high quality windings on pole pieces of rotors of electric motors with the direct in slot winding technique, thus overcoming the problem related to the elasticity of the pack of laminations that defines the body of the rotor, are described. While winding, the conducting wire is guided by means of a wire guiding cap movable in the rotor slots between which the pole piece to be wound at that moment extends. The body of the rotor is compacted by means of a pressing device internal to the wire guiding cap. The axial pressing of the body, performed parallel to the rotation axis Z of the rotor for preventing the umbrella effect, is thus formed thanks to a specific device integrated into the wire guiding cap, i.e. by exploiting the volume inside the wire guiding cap and providing the axial pressing device therein.
H02K 15/095 - Exécution des enroulements par pose des conducteurs dans ou autour des parties formant le noyau par pose des conducteurs autour de pôles saillants
H01F 41/082 - Dispositifs de guidage ou de positionnement du matériau enroulé sur la forme d’enroulement
H01F 41/088 - Dispositifs de guidage ou de positionnement du matériau enroulé sur la forme d’enroulement à ailettes rotatives
7.
Method and processing line for manufacturing a stator for electric motors
A method, a processing line and components of the processing line for making a stator for electric motors, and the resultant stator. The conducting wire is wound in coils having at least one straight portion which is inserted into a corresponding stator sector. The sector is thus deformed to move its teeth close to each other and to close the straight portion of the coil. Multiple stator sectors so made are assembled together to form a stator complete with windings. During the production of stator sectors, the coils and/or stator sectors are rototranslated to bring them to the final position they must take inside the finished stator. Measures are provided to maximize the filling factor, to minimize torque ripple phenomena, to minimize noise and the vibrations of the electric motor achieved with the stator, and to maximize its performance, under other equal conditions.
H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques
H02K 15/04 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques d'enroulements avant leur montage dans les machines
H02K 15/085 - Exécution des enroulements par pose des conducteurs dans ou autour des parties formant le noyau par pose des conducteurs dans des stators encochés
H02K 15/12 - Imprégnation, chauffage ou séchage des bobinages, des stators, des rotors ou des machines
8.
METHOD FOR THE MAKING OF A STATOR FOR ELECTRIC MOTORS, AND RESPECTIVE STATOR FOR ELECTRIC MOTORS
Method for the making of a stator for electric motors comprising a stator body (10) which comprises a plurality of stator teeth arranged radially about a common central axis (Y) and defining, between them, a plurality of sectors (3) in which one or more windings (4) of conducting wire (14) are inserted, comprising the steps of: - providing two jigs (2, 2'), each of which has an inner circumference defining a circular opening (20', 20") inside the jig (2, 2') and a series of teeth (21, 21') jutting out inside the circular opening (20, 20") towards a common central axis (Y), the teeth defining, between them, a series of slots (22', 22"); - arranging the two jigs (2, 2') coaxially, centered along a same common central axis (Y) and spaced along the central axis (Y); - winding or inserting, between the teeth (21, 21') of the jigs (2, 2'), a plurality of conducting wires (14) so as to form a plurality of windings (4), such as the conducting wires (14) of each winding (4) occupy a plurality of the slots (22', 22") of both jigs (2, 2'), the windings (4) comprising linear wire portions (4a, 4b) extending between the two jigs (2, 2'); - inserting, from the inside, a plurality of first stator portions (6) between the linear wire portions (4a, 4b); - inserting, from the outside, a plurality of second stator portions (7) complementary to the first stator portions (6) between the linear wire portions (4a, 4b), such as the joining of the first (6) and second (7) stator portions forms a stator body (10).
H02K 3/12 - Enroulements caractérisés par la configuration, la forme ou le genre de construction du conducteur, p. ex. avec des conducteurs en barre disposés dans des encoches
H02K 1/16 - Noyaux statoriques à encoches pour enroulements
H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques
H02K 15/04 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques d'enroulements avant leur montage dans les machines
H02K 15/06 - Montage d'enroulements préfabriqués dans les machines
A method, a processing line and components of the processing line for the making of a stator for electric motors, and a stator achieved with the method described, are disclosed. The conducting wire is wound in coils having at least one straight portion which is inserted into a corresponding stator sector; the sector is thus deformed to move its teeth close to each other and to close the straight portion of the coil. Multiple stator sectors so made are assembled together to form a stator complete with windings. During the production of stator sectors, the coils and/or stator sectors are rototranslated to bring them to the final position they must take inside the finished stator. Measures are provided to maximize the filling factor, to minimize the torque ripple phenomena, to minimize noise and the vibrations of the electric motor achieved with the stator and to maximize its performance, under other equal conditions.
H02K 3/48 - Fixation des enroulements sur la structure statorique ou rotorique dans les encoches
H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques
H02K 15/04 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques d'enroulements avant leur montage dans les machines
H02K 29/03 - Moteurs ou génératrices à dispositifs de commutation non mécaniques, p. ex. tubes à décharge ou dispositifs à semi-conducteurs avec un circuit magnétique spécialement adapté pour éviter des ondulations du couple ou des problèmes de démarrage autonome
Coil winding machines; winding machines; Automatic assembly line machinery, featuring [ or not featuring ] coil winding machine components, for assembling components and for generally manufacturing goods to the specific needs of a customer, and comprised of pick-up arms and grips, positioners, [ joiners, ] fastening robots, sorters, holders, assemblers, loaders and unloaders, palletizers, welders, tapers; automation specialty machines for assembling components, namely, machines for tinning, autogenous soldering, electric machines for welding enameled magnetic wire on the terminals, machines for taping coils, machines for inserting terminals, machines for joining components, machines for inserting one component into another, machines for fastening one component to another, machines for holding two components in a given position; conveyor machinery and parts therefor sold as a unit; rotating tables for machine tools; machines for wire stripping; machines for wire tensioning
Reeling apparatus; Automatic winding installations; Automated assembly machines; Automatic assembly lines; Coil winding machines; Automated assembly machines; Machines for use in assembly; Machines for the assembly of semiconductor components; Industrial robots for use in the mounting of workpieces to be worked on; Assembly line conveyor machinery; Stator coil winding machines; Bobbin winding machines; Electric welding machines; Wire-coiling machines; Tensioners (thread lever); Yarn winding machines; Chucks [parts of machines]; Conveyers; Belts for conveyors; Laser welding machines; Rotary tables for machine tools; Palletisation machines; Wire stripping heads.
12.
Needle winding machine, particularly for winding poles arranged inside a cylindrical surface
A needle winding machine, particularly for winding poles arranged inside a cylindrical surface, the machine comprising a main supporting structure that supports at least one spindle that is extended around an axis and is provided, at an axial end thereof, with a head that supports a wire guiding tube; the spindle can move on command parallel to its own axis and can rotate on command about its own axis with respect to the main supporting structure; the wire guiding tube can rotate on command, with respect to the remaining part of the spindle, about a rotation axis that is substantially perpendicular to the axis of the wire guiding tube and can move on command, with respect to the remaining part of the spindle, along a direction that is oriented radially with respect to the axis of the spindle.
H02K 15/095 - Exécution des enroulements par pose des conducteurs dans ou autour des parties formant le noyau par pose des conducteurs autour de pôles saillants
H02K 15/085 - Exécution des enroulements par pose des conducteurs dans ou autour des parties formant le noyau par pose des conducteurs dans des stators encochés
H01F 41/088 - Dispositifs de guidage ou de positionnement du matériau enroulé sur la forme d’enroulement à ailettes rotatives
13.
NEEDLE WINDING MACHINE, PARTICULARLY FOR WINDING POLES ARRANGED INSIDE A CYLINDRICAL SURFACE
A needle winding machine, particularly for winding poles arranged inside a cylindrical surface, the machine comprising a main supporting structure (2) that supports at least one spindle (3) that is extended around an axis (3a) and is provided, at an axial end thereof, with a head (4) that supports a wire guiding tube (5); the spindle (3) can move on command parallel to its own axis (3a) and can rotate on command about its own axis (3a) with respect to the main supporting structure (2); the wire guiding tube (5) can rotate on command, with respect to the remaining part of the spindle (3), about a rotation axis that is substantially perpendicular to the axis of the wire guiding tube (5) and can move on command, with respect to the remaining part of the spindle (3), along a direction (6) that is oriented radially with respect to the axis (3a) of the spindle (3).
H02K 15/095 - Exécution des enroulements par pose des conducteurs dans ou autour des parties formant le noyau par pose des conducteurs autour de pôles saillants
Machine tools and parts of machine tools including gears, conveyor belts and pneumatic conveyors, turntables and furniture, transmission chains, steering and braking apparatus, chucks; coil winder machines; automatic coil winding installations; automatic assembly systems; automatic assembly lines; machines for manufacturing electrolytic condensers; machines for applying coverings to electroconductor cores; machines for inserting microcomponents in circuit boards; manipulators and industrial robots; welding machinery.
15.
sam smartautomotion the newest platform from MARSILLI
Platforms for automatic assembly lines for assembling components and for generally manufacturing goods to the specific needs of a customer or manufacturer, being said platforms both sold as a unit and in modules; components of said platforms including a bench, rails, programmable motorised carriages with their control boards, programmable or pneumatic shifters, pallets, controllers.
Coil winders; automatic assembly lines, including or not coil winders, for assembling components and for generally manufacturing goods to the specific needs of a customer, comprised of pick-up arms and grips, positioners, joiners, fastening robots, sorters, holders, assemblers, loaders and unloaders, palletizers, welders, [ tapes ] *tapers*; automation specialty machines for assembling components, namely, machines for tinning, autogenous soldering, electric machines for welding enameled magnetic wire on the terminals, machines for taping coils, machines for inserting terminals, machines for joining components, machines for inserting one component into another, machines for fastening one component to another, machines for holding two components in a given position; conveyors and parts therefor sold as a unit
Coil winders; automatic assembly lines, including or not coil winders, for assembling components and for generally manufacturing goods to the specific needs of a customer, comprised of pick-up arms and grips, positioners, joiners, fastening robots, sorters, holders, assemblers, loaders and unloaders, palletizers, welders, tapers; automation specialty machines for assembling components, namely, machines for tinning, autogenous soldering, electric machines for welding enameled magnetic wire on the terminals, machines for taping coils, machines for inserting terminals, machines for joining components, machines for inserting one component into another, machines for fastening one component to another, machines for holding two components in a given position; conveyors and parts therefor sold as a unit
