A cotton harvester for harvesting and baling cotton bolls into a cylindrical bale comprises a cotton picker/stripper for stripping cotton bolls from cotton plants, and a continuous round baler for compressing, rotating and forming the cotton bolls into a round bale cylinder from which round bales are severed. The baler comprises a conical bale chamber and a cylindrical bale chamber. The cotton bolls are continuously blown through the conduit from the picker/stripper into the conical bale chamber and a forward part of the cylindrical bale chamber through a roll gap between spaced apart pairs of frustoconical rolls and cylindrical rolls, forming the conical and cylindrical bale chambers, and the compressed rotating round bale cylinder of cotton bolls protrudes axially through the cylindrical bale chamber. Prior to exiting the cylindrical bale chamber the rotating round bale cylinder is circumferentially wrapped with wrapping material.
A01D 46/12 - Cueillette de fruits, légumes, houblon ou de produits similairesDispositifs pour secouer les arbres ou les arbustes du coton par arrachage de la capsule de la plante
A01F 15/08 - Presses pour mise en balles de la paille, du foin ou de produits similaires Parties constitutives
2.
Bale Severance Mechanism for a Continuous Round Baler (as amended)
A continuous round baler forms a cylindrically-shaped bale by spiral, coiled layers created by a conical portion of a bale-forming chamber and protruded upwardly from a cylindrical portion of the bale-forming chamber. The bale is circumferentially supported by netting applied to the bale in the cylindrical portion. A rotary feed table receives crop from the field and feeds the crop into the conical portion. The bale forming process can be interrupted if an insufficient volume of crop is collected on the rotary feed table. The netting material is provided on short rolls to facilitate loading onto the machine. A cutoff mechanism is coupled to the growth of the bale from the cylindrical portion to sever the bale at a predetermined length with end surfaces that are perpendicular to the axis of the bale. A bale density mechanism supports the distal end of the bale as the bale protrudes upwardly.
A continuous round baler forms a cylindrically-shaped bale by spiral, coiled layers created by a conical portion of a bale-forming chamber and protruded upwardly from a cylindrical portion of the bale-forming chamber. The bale is circumferentially supported by netting applied to the bale in the cylindrical portion. A rotary feed table receives crop from the field and feeds the crop into the conical portion. The bale forming process can be interrupted if an insufficient volume of crop is collected on the rotary feed table. The netting material is provided on short rolls to facilitate loading onto the machine. A cutoff mechanism is coupled to the growth of the bale from the cylindrical portion to sever the bale at a predetermined length with end surfaces that are perpendicular to the axis of the bale. A bale density mechanism supports the distal end of the bale as the bale protrudes upwardly.
A belt baler (1) comprising a chassis (5) supported on ground engaging wheels (6) comprises a housing (3) having a first part (8) and a second part (10) housing belts (20) defining a variable diameter bale chamber (25). The second part (10) is pivotally coupled to the first part (8) about a pivot axis (14) and is pivotal from a closed state for forming a bale and an open state for discharge of a bale from the bale chamber (25). A pair of retaining devices (39) comprising latches (40) on respective opposite sides of the first part (8) are engageable with corresponding latch pins (45) on respective opposite sides of the second part (10) for retaining the second part (10) in the closed state. Load sensors (59) coupled by first and second connecting members (64,65) between distal ends (49) of the respective latch pins (45) and anchor brackets (60) located on the second parts (10) produce signals indicative of the forces induced in the respective retaining devices (39) by the pressure being applied to a bale being formed in the bale chamber (25). A microprocessor (75) reads signals from the load sensors (59) and determines the uniformity or non-uniformity of the density of the bale across the axial length thereof from the signals read from the load sensors (59). An output signal from the microprocessor (75) is applied to a visual display device (77) which presents a display screen (78) to a driver indicating the direction of travel or a change in direction of travel of the baler (1) required to maintain uniform density or to correct for non-uniformity of the density of the bale by appropriately displaying a central cross sign (80), or arrows (83) in respective sections (81) of an area (79) of the screen (78).
A belt baler (1) comprising a chassis (5) supported on ground engaging wheels (6) comprises a housing (3) having a first part (8) and a second part (10) housing belts (20) defining a variable diameter bale chamber (25). The second part (10) is pivotally coupled to the first part (8) about a pivot axis (14) and is pivotal from a closed state for forming a bale and an open state for discharge of a bale from the bale chamber (25). A pair of retaining devices (39) comprising latches (40) on respective opposite sides of the first part (8) are engageable with corresponding latch pins (45) on respective opposite sides of the second part (10) for retaining the second part (10) in the closed state. Load sensors (59) coupled by first and second connecting members (64,65) between distal ends (49) of the respective latch pins (45) and anchor brackets (60) located on the second parts (10) produce signals indicative of the forces induced in the respective retaining devices (39) by the pressure being applied to a bale being formed in the bale chamber (25). A microprocessor (75) reads signals from the load sensors (59) and determines the uniformity or non-uniformity of the density of the bale across the axial length thereof from the signals read from the load sensors (59). An output signal from the microprocessor (75) is applied to a visual display device (77) which presents a display screen (78) to a driver indicating the direction of travel or a change in direction of travel of the baler (1 ) required to maintain uniform density or to correct for non-uniformity of the density of the bale by appropriately displaying a central cross sign (80), or arrows (83) in respective sections (81) of an area (79) of the screen (78).
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) Agricultural machinery, apparatus, equipment, instruments and implements, namely, combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester, parts and fittings for all the aforesaid goods; tractor mounted agricultural machines, apparatus and implements, namely, combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester, parts and fittings for all the aforesaid goods; agricultural implements being trailer mounted, namely, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester, parts and fittings for all the aforesaid goods; agricultural implements being trailer mounted, namely combination baler and bale wrapper machines, parts and fittings for all the aforesaid goods; agricultural implements being trailer mounted to include combination baler and bale wrapper machines, parts and fittings for all the aforesaid goods; combination baler and bale wrapper machines, parts and fittings for all the aforesaid goods; balers for agricultural use, parts and fittings for all the aforesaid goods; forage handling and working machinery, apparatus, equipment, instruments and implements, namely, tractor-towed agricultural implements, namely, bale handlers, bale wrappers and bale splitters, parts and fittings for all the aforesaid goods; fodder and bedding handling, shredding, wrapping machinery, apparatus, equipment, instruments and implements, namely, tractor-towed agricultural balers, parts and fittings for all the aforesaid goods; agricultural materials handling, compacting, wrapping and disposal machinery, apparatus, equipment, instruments and implements, namely, agricultural materials handling machines in the nature of palletizers, agricultural waste compacting machines, agricultural wrapping machines, tractor-towed agricultural instrument attachments in the nature of mechanical and hydraulic arms for use as bale carriers and agricultural waste disposal units, trailable agricultural implements, namely, wrapping machines, parts and fittings for all the aforesaid goods; agricultural machines for cutting grass, hay and other forage crops, namely, rotary mowers, hay cutters, forage cutters and grass cutters, parts and fittings for all the aforesaid goods; tractor towed mowers, parts and fittings for all the aforesaid goods; hay tedders, parts and fittings for all the aforesaid goods; lawn and agriculture mowing and reaping machines, parts and fittings for all the aforesaid goods; agricultural machines, namely harvesters, for harvesting crops, parts and fittings for all the aforesaid goods; agricultural machines, namely cultivators, for ground cultivation, parts and fittings for all the aforesaid goods; towable agricultural machines, namely, mowers, combine harvesters and bale wrapper machines, parts and fittings for all the aforesaid goods
(2) Downloadable computer software programmes for controlling, operating and managing agricultural machines and equipment, namely combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; downloadable computer software for operating agricultural machines and equipment, namely combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; downloadable computer software applications for mobile phones, namely, software for controlling, operating and managing agricultural machines and equipment, namely combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; recorded computer software for controlling, operating and managing agricultural machines and equipment, namely combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; computer operating software; downloadable interactive computer software for controlling, operating and managing agricultural machines and equipment, namely combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; downloadable computer software platforms for controlling, operating and managing agricultural machines and equipment, namely combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; computer hardware; computer hardware for telecommunications; computer software for transmission and display of digital content, audio files, visual files, audiovisual files, electronic publications and books; computer software for browsing and accessing digital content, computer software, audio files, visual files, audiovisual files, electronic publications and books available online from databases and the Internet; data communication apparatus and instruments, namely global positioning system (GPS) transmitters, radio receivers and radio transmitters for installation within agricultural machinery, apparatus, equipment, instruments and implements for wirelessly transmitting and receiving information and data about agricultural machinery, apparatus, equipment, instruments and implements, and its environment; voice processing systems, namely voice recognition software; computer networking and data communications equipment, namely, computer network routers and adapters; mobile application software for controlling, operating and managing agricultural machines and equipment, namely combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; apparatus and instruments for the processing, transmission, storage, logging, reception and retrieval of data being in the form of encoded data, text, audio, graphic images or video or a combination of these formats, namely computers; customer support and customer service computer software and application software for use in customer relationship management (CRM); instant messaging software; internet messaging software; virtual personal assistant software; computer software for the management of user personal information
09 - Appareils et instruments scientifiques et électriques
Produits et services
Agricultural machinery, apparatus, equipment, instruments and implements, namely, combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; tractor mounted agricultural machines, apparatus and implements, namely, combination baler and bale wrapper machines, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; agricultural implements being trailer mounted, namely, integrated baler wrappers, tubeline bale wrappers, fixed chamber round balers, variable chamber round balers, round bale wrappers, square bale wrappers, raking machines, hay rakes, mowers, straw bale tightening machines, straw blowers, silage feeder and harvester; agricultural implements being trailer mounted, namely combination baler and bale wrapper machines; combination baler and bale wrapper machines for agricultural use; balers for agricultural use; tractor-towed agricultural implements, namely, bale handlers, bale wrappers and bale splitters; working machinery, apparatus, equipment, instruments and implements for agricultural purposes, namely, tractor-towed agricultural instruments in the nature of balers; trailable agricultural implements, namely, balers, fodder and bedding handling machinery, and wrapping machinery, apparatus, equipment, instruments and implements for agricultural purposes, namely, wrapping machines; fodder presses; fodder cutting and mixing machines; agricultural machines, namely, bedding machines; shredding machines for agricultural use; wrapping machines; agricultural materials handling, compacting, wrapping machinery, apparatus, equipment, instruments and implements for agricultural purposes, namely, hay balers; garbage disposal machines; agricultural machines, namely, disk harrows; tractor towed mowers; tractor towed agricultural implements, namely, hay rakes; agricultural machines, namely, tedders; mowing and reaping machines; agricultural machines, namely, combine harvesters and harvesters; agricultural machines, namely, cultivators; tractor-towed harrows; tractor-towed rotary cutters; replacement parts and fittings for all the aforesaid goods Downloadable computer networking software; downloadable computer software programs for use in software development, machine learning, machine management, database management and for spreadsheet management; downloadable computer software and firmware for operating system programs and for computer system and application development, deployment and management; downloadable computer software applications for mobile phones, namely, software for database management; recorded computer software for mobile phones, namely, software for electronic storage of data; recorded computer operating software; downloadable interactive software for use in database management, for use as a spreadsheet and in word processing; downloadable computer software platforms for web hosting, application development and database management; computer hardware; computer hardware for telecommunications; downloadable computer software for transmission and display of digital content, audio works, visual works, audiovisual works, electronic publications and books; downloadable computer software for browsing and accessing digital content, audio works, visual works, audiovisual works, electronic publications and books; wireless communication devices for voice, data or image transmission; downloadable intelligent personal assistant software for voice recognition; computer network routers and adapters; computer hardware for communicating audio, video and data between computers via a global computer network, wide-area computer networks, and peer-to-peer computer networks; downloadable software in the nature of a mobile application for electronic storage of data and for use in database management; wireless communication devices for voice, data or image transmission; Apparatus for recording, transmission, processing and reproduction of sound, images or data; downloadable computer software for use in customer relationship management (CRM); Downloadable messaging software for the redirection of electronic messages to alternate addresses; Intelligent personal assistant devices comprised of voice activated speakers, computer hardware, and recorded software to communicate, control and operate agricultural machinery, equipment and implements; downloadable computer software that provides real-time, integrated business management intelligence by combining information from various databases and presenting it in an easy-to-understand user interface; all of the foregoing in the field of agricultural machinery and none of the foregoing relating to the fields of insurance, fire protection and risk analysis and rating relating to fire
A continuously operating round baler (10) forms axially extending round bales of crop material. A rotary feed table (20) transfers crop material elevated by a pick-up mechanism (19) in a longitudinal direction and in tum a transverse direction to an infeed apparatus (200). The infeed apparatus (200) feeds the crop material into a conical bale chamber (26) to form a conical core that protrudes into a cylindrical bale chamber (28) into which crop material is also fed to wrap around the core to create an axially extending round bale with a diameter larger than the protruding diameter of the conical core. Netting material is wrapped around the axially formed round bale in the cylindrical bale chamber (28) towards an upstream end thereof. A severance mechanism (80) severs a desired length of round bale after protruding from the cylindrical bale chamber (28). A drop assist apparatus (l45) receives the severed round bale and lowers the severed bale to the ground. The cylindrical bale chamber (28) is formed to be selectively configured in a selected diameter size for the round bale.
A continuously operating round baler (10) forms axially extending round bales of crop material. A rotary feed table (20) transfers crop material elevated by a pick-up mechanism (19) in a longitudinal direction and in turn a transverse direction to an infeed apparatus (200). The infeed apparatus (200) feeds the crop material into a conical bale chamber (26) to form a conical core that protrudes into a cylindrical bale chamber (28) into which crop material is also fed to wrap around the core to create an axially extending round bale with a diameter larger than the protruding diameter of the conical core. Netting material is wrapped around the axially formed round bale in the cylindrical bale chamber (28) towards an upstream end thereof. A severance mechanism (80) severs a desired length of round bale after protruding from the cylindrical bale chamber (28). A drop assist apparatus (145) receives the severed round bale and lowers the severed bale to the ground. The cylindrical bale chamber (28) is formed to be selectively configured in a selected diameter size for the round bale.
A conveying device for conveying crop material from a pick-up mechanism to a baler comprises a conveying channel having a base comprising an upstream base part and a downstream base part. The downstream end of the upstream base part is supported on a pair of first resilient mounting members and the upstream end of the downstream base part is supported on a pair of second resilient support members. The first and second resilient support members, in response to the force with which crop material is being urged by the feed rotor against the upstream and downstream base parts exceeding respective first and second predefined values, yield. This results in downward displacement of the upstream base part and the downstream base part to permit crop material to pass through the conveying channel.
A01F 15/10 - Dispositifs d'alimentation en produits récoltés
A01D 78/04 - Faneuses à dents mobiles par rapport à la machine à barres porte-dents ou organes équivalents qui viennent en engagement avec des têtes rotatives selon des axes horizontaux, p. ex. du type à tambour rotatif les organes porte-dents se déplaçant obliquement ou perpendiculairement par rapport à la direction de déplacement de la machine
B65G 19/04 - Transporteurs comportant un impulseur ou une série d'impulseurs portés par un élément de traction sans fin et disposés de façon à déplacer objets ou matériaux sur une surface porteuse ou sur un matériau de base, p. ex. transporteurs sans fin à raclettes pour déplacer un matériau en vrac dans des augets ou des canaux ouverts
B65G 41/00 - Châssis ou bases de support pour transporteurs dans leur ensemble, p. ex. châssis transportables
A01D 87/00 - Chargeurs à foin ou à récolte similaire
Combination baler wrappers, integrated baler wrappers and bale wrapper machines for agricultural use; bale wrappers and tubeline bale wrappers for agricultural use; balers for agricultural use; tractor-towed agricultural implements, namely, bale handlers, bale wrappers; working machinery, apparatus, equipment, instruments and implements for agricultural purposes, namely, tractor-towed agricultural instruments in the nature of balers; agricultural implements being trailer-mounted, namely, balers; trailable agricultural implements, namely, balers, fodder and bedding handling machinery, and wrapping machinery, apparatus, equipment, instruments and implements for agricultural purposes, namely, wrapping machines; agricultural materials handling, compacting, wrapping machinery, apparatus, equipment, instruments and implements for agricultural purposes, namely, hay balers, and structural parts and fittings for all the aforesaid goods
(1) Combination baler/bale wrapper machines for agricultural use, parts and fittings for all the aforesaid goods; agricultural balers, parts and fittings for all the aforesaid goods; bale handlers, bale wrappers, bale splitters for agricultural use, parts and fittings for all the aforesaid goods; agricultural machinery, namely, bale handlers, bale wrappers and bale splitters; silage handling and working machinery for agricultural use, apparatus, equipment, instruments and implements for silage handling in the field of agriculture, namely silage feeders, parts and fittings for all the aforesaid goods; agricultural apparatus, namely, tractor-towed and ride-on mowers, tractor-towed and ride-on rotary mowers, rotary brush cutters, tractor-towed and rideon disc mowers, reapers, tandem disc harrows, offset disc harrows, field cultivators, power tillers, shredders, box blade for tractors for use in the field of agriculture, windrowers, tractor mounted blades and rakes, parts and fittings for all the aforesaid goods; tractor mounted agricultural machines, apparatus and implements, namely, mowers, rotary mowers, rotary brush cutters, disc mowers, reapers, balers, tandem disc harrows, offset disc harrows, field cultivators, tillers, shredders, blade boxes, windrowers, tractor mounted blades and rakes; agricultural implements being trailer mounted, namely, mowers, rotary mowers, rotary brush cutters, disc mowers, reapers, balers, tandem disc harrows, offset disc harrows, field cultivators, tillers, shredders, blade boxes, windrowers, tractor mounted blades and rakes; trailable agricultural implements, namely, mowers, rotary mowers, rotary brush cutters, disc mowers, reapers, balers, tandem disc harrows, offset disc harrows, field cultivators, tillers, shredders, blade boxes, windrowers, tractor mounted blades and rakes; agricultural machines for cutting grass, hay and other forage crops, namely hay cutters, forage cutters and grass cutters, parts and fittings for all the aforesaid goods; tractor towed mowers; tractor mounted mowers; agricultural machinery, namely, rear tractor towed mowers, front tractor mounted mowers, side tractor mounted mowers and combination tractor towed and mounted mowers; agricultural machinery, namely, autonomous lawn mowers, parts and fittings for all the aforesaid goods; mowing and reaping machines for agricultural use, parts and fittings for all the aforesaid goods; harvesters for agricultural use, parts and fittings for all the aforesaid goods; agricultural cultivators, parts and fittings for all the aforesaid goods; fodder and animal bedding, shredding, and wrapping machines for agricultural use, parts and fittings for all the aforesaid goods; tractor-towed agricultural instruments, namely, handling machine for agricultural use, namely, bale forks, bale splitters, bale handlers, parts and fittings for all the aforesaid goods; agricultural materials handling and waste handling, compacting, wrapping and disposal of agricultural materials, namely, waste compacting machines, machines for shredding agricultural waste, wrapping machines, parts and fittings for all the aforesaid goods.
(2) Agricultural hand tools, instruments and implements, namely, splitters and pullers, scrapers, picks, augers, rammers, gimlets, reamers, gouges, holing axes, milling cutters, hand-operated sharpening tools and instruments, and parts and fittings for these goods.
(1) Combination baler/bale wrapper machines for agricultural use, parts and fittings for all the aforesaid goods; agricultural balers, parts and fittings for all the aforesaid goods; bale handlers, bale wrappers, bale splitters for agricultural use, parts and fittings for all the aforesaid goods; agricultural machinery, namely, bale handlers, bale wrappers and bale splitters; silage handling and working machinery for agricultural use, apparatus, equipment, instruments and implements for silage handling in the field of agriculture, namely silage feeders, parts and fittings for all the aforesaid goods; agricultural apparatus, namely, tractor-towed and ride-on mowers, tractor-towed and ride-on rotary mowers, rotary brush cutters, tractor-towed and rideon disc mowers, reapers, tandem disc harrows, offset disc harrows, field cultivators, power tillers, shredders, box blade for tractors for use in the field of agriculture, windrowers, tractor mounted blades and rakes, parts and fittings for all the aforesaid goods; tractor mounted agricultural machines, apparatus and implements, namely, mowers, rotary mowers, rotary brush cutters, disc mowers, reapers, balers, tandem disc harrows, offset disc harrows, field cultivators, tillers, shredders, blade boxes, windrowers, tractor mounted blades and rakes; agricultural implements being trailer mounted, namely, mowers, rotary mowers, rotary brush cutters, disc mowers, reapers, balers, tandem disc harrows, offset disc harrows, field cultivators, tillers, shredders, blade boxes, windrowers, tractor mounted blades and rakes; trailable agricultural implements, namely, mowers, rotary mowers, rotary brush cutters, disc mowers, reapers, balers, tandem disc harrows, offset disc harrows, field cultivators, tillers, shredders, blade boxes, windrowers, tractor mounted blades and rakes; agricultural machines for cutting grass, hay and other forage crops, namely hay cutters, forage cutters and grass cutters, parts and fittings for all the aforesaid goods; tractor towed mowers; tractor mounted mowers; agricultural machinery, namely, rear tractor towed mowers, front tractor mounted mowers, side tractor mounted mowers and combination tractor towed and mounted mowers; agricultural machinery, namely, autonomous lawn mowers, parts and fittings for all the aforesaid goods; mowing and reaping machines for agricultural use, parts and fittings for all the aforesaid goods; harvesters for agricultural use, parts and fittings for all the aforesaid goods; agricultural cultivators, parts and fittings for all the aforesaid goods; fodder and animal bedding, shredding, wrapping machines for agricultural use, parts and fittings for all the aforesaid goods; tractor-towed agricultural instruments, namely, handling machine for agricultural use, namely, bale forks, bale splitters, bale handlers, parts and fittings for all the aforesaid goods; agricultural materials handling and waste handling, compacting, wrapping and disposal of agricultural materials, namely, waste compacting machines, machines for shredding agricultural waste, wrapping machines, parts and fittings for all the aforesaid goods.
(2) Agricultural hand tools, instruments and implements, namely, splitters and pullers, scrapers, picks, augers, rammers, gimlets, reamers, gouges, holing axes, milling cutters, hand-operated sharpening tools and instruments, and parts and fittings for these goods.
16.
A CONVEYING DEVICE AND A METHOD FOR CONVEYING MATERIAL THROUGH A CONVEYING CHANNEL
A conveying device (1) for picking up a sward of crop material from the ground and feeding the crop material comprises a conveying channel (28), wherein the conveying channel (28) comprises a base (30) comprising an upstream base part (43) and a downstream base part (44). The upstream base part (43) is pivotal adjacent its upstream end (45) about a transversely extending first pivot axis (57). The downstream base part (44) is pivotal about a second transversely extending second pivot axis (76) towards the downstream end (51) thereof. The downstream end (46) of the upstream base part (43) is supported on a pair of first resilient mounting members (59) and the upstream end (50) of the downstream base part (44) is supported on a pair of second resilient support members (85) through a pair of carrier arms (78) which are pivotal about a transversely extending carrier pivot axis (74). The resilience of the first and second resilient support members (59) and (85) is such that on the force with which crop material is being urged by the feed rotor (34) against the upstream and downstream base parts (43) and (44) exceeding respective predefined values, the resilient support members (59) and (85) yield, thereby permitting downward displacement of the downstream end (46) of the upstream base part (43) and the upstream end (50) of the downstream base part (44) in order to permit crop material to pass through the conveying channel (28) without becoming jammed.
Coupling apparatus for coupling a mower to a front three-point linkage of a tractor includes a mounting element for coupling to the three-point linkage and a carrier element to which the mower is coupled. A linkage mechanism including upper link members and a lower link member couples the carrier element to the mounting element. The lower link member is pivotally coupled to the mounting element about a first lower pivot axis. A pair of take-up springs act between the lower link member and the mounting element to take up a portion of the weight of the mower. The take-up springs are coupled between corresponding anchor elements and corresponding anchor brackets on the lower link member. The anchor elements are carried on respective compensating arms, which in turn are pivotal on pivot shafts carried on the mounting element. Actuator arms acting between the lower link member and the compensating arms urge the anchor element upwardly and downwardly as the carrier element moves upwardly and downwardly for controlling the turning moment induced by the take-up springs in the linkage mechanism, in order to maintain the effective weight of the mower bearing on the ground substantially constant.
A01B 59/043 - Dispositifs particuliers pour l'attelage des animaux ou des tracteurs aux machines ou instruments agricoles pour machines tirées ou poussées par tracteurs dont les moyens de traction sont disposés à l'arrière du tracteur avec attelage à trois points, p. ex. par accouplement à déclenchement rapide
A01B 63/14 - Dispositifs ou agencements de levage ou de réglage pour machines ou instruments agricoles pour instruments à traction animale ou mécanique
A01B 59/06 - Dispositifs particuliers pour l'attelage des animaux ou des tracteurs aux machines ou instruments agricoles pour machines montées sur tracteurs
A continuous round baler forms a cylindrically-shaped bale by spiral, coiled layers created by a conical portion of a bale-forming chamber and protruded upwardly from a cylindrical portion of the bale-forming chamber. The bale is circumferentially supported by netting applied to the bale in the cylindrical portion. A rotary feed table receives crop from the field and feeds the crop into the conical portion. The bale forming process can be interrupted if an insufficient volume of crop is collected on the rotary feed table. The netting material is provided on short rolls to facilitate loading onto the machine. A cutoff mechanism is coupled to the growth of the bale from the cylindrical portion to sever the bale at a predetermined length with end surfaces that are perpendicular to the axis of the bale. A bale density mechanism supports the distal end of the bale as the bale protrudes upwardly.
Coupling apparatus (1) for coupling a mower (3) to a carrier arm (18) which is coupled to a rearward three-point linkage of a tractor comprises a linkage mechanism (20) which couples the mower (3) to the carrier arm (18). The linkage mechanism (20) comprises a first link member (25), a second link member (26) and a third link member (27) which are pivotally coupled between the carrier arm (18) and a mounting member (21) which rigidly carries the mower (3). The linkage mechanism (20) is configured, so that in the event of the mower (3) striking an obstruction, the mounting member (21) and in turn the mower (3) moves from an operative state with a skid plate (7) of the mower (3) engaging and riding along the ground, to a displaced state with the mounting member (21) and the mower (3) urged upwardly rearwardly with the skid plate (7) of the mower (3) spaced apart above the ground. A pair of tension springs (80) acting between the mounting member (21) and the carrier arm (18) resiliency urge the mounting member (21) and in turn the mower (3) into the operative state. The linkage mechanism (20) also defines a secondary pivot axis (97) about which the mounting member (21) and the mower (3) are tiltable.
A01B 61/04 - Dispositifs ou pièces des machines ou instruments agricoles pour éviter un effort excessif des points de fixation des outils de travail aux flèches ou bâtis
A01B 59/06 - Dispositifs particuliers pour l'attelage des animaux ou des tracteurs aux machines ou instruments agricoles pour machines montées sur tracteurs
20.
COUPLING APPARATUS FOR COUPLING AN AGRICULTURAL IMPLEMENT TO A PRIME MOVER
Coupling apparatus (80) for coupling a mower (3) to a front three-point linkage of a tractor comprises a mounting element (17) for coupling to the three-point linkage and a carrier element (19) to which the mower (3) is coupled. A linkage mechanism (20) comprising upper link members (81) and a lower link member (23) couples the carrier element (19) to the mounting element (17). The lower link member (23) is pivotally coupled to the mounting element (17) about a first lower pivot axis (30). A pair of take-up springs (45) act between the lower link member (23) and the mounting element (17) to take up a portion of the weight of the mower (3). The take-up springs (45) are coupled between corresponding anchor elements (60) and corresponding anchor brackets (49) on the lower link member (23). The anchor elements (60) are carried on respective compensating arms (88), which in turn are pivotal on pivot shafts (53) carried on the mounting element (17). Actuator arms (89) acting between the lower link member (23) and the compensating arms (88) urge the anchor element (60) upwardly and downwardly as the carrier element (19) moves upwardly and downwardly for controlling the turning moment induced by the take-up springs (45) in the linkage mechanism (20), in order to maintain the effective weight of the mower (3) bearing on the ground substantially constant.
A01B 59/043 - Dispositifs particuliers pour l'attelage des animaux ou des tracteurs aux machines ou instruments agricoles pour machines tirées ou poussées par tracteurs dont les moyens de traction sont disposés à l'arrière du tracteur avec attelage à trois points, p. ex. par accouplement à déclenchement rapide
A01B 59/06 - Dispositifs particuliers pour l'attelage des animaux ou des tracteurs aux machines ou instruments agricoles pour machines montées sur tracteurs
A01B 63/14 - Dispositifs ou agencements de levage ou de réglage pour machines ou instruments agricoles pour instruments à traction animale ou mécanique
A continuous round baler forms a cylindrically-shaped bale by spiral, coiled layers created by a conical portion of a bale-forming chamber and protruded upwardly from a cylindrical portion of the bale-forming chamber. The bale is circumferentially supported by netting applied to the bale in the cylindrical portion. A rotary feed table receives crop from the field and feeds the crop into the conical portion. The bale forming process can be interrupted if an insufficient volume of crop is collected on the rotary feed table. The netting material is provided on short rolls to facilitate loading onto the machine. A cutoff mechanism is coupled to the growth of the bale from the cylindrical portion to sever the bale at a predetermined length with end surfaces that are perpendicular to the axis of the bale. A bale density mechanism supports the distal end of the bale as the bale protrudes upwardly.
A continuous round baler forms a cylindrically-shaped bale by spiral, coiled layers created by a conical portion of a bale-forming chamber and protruded upwardly from a cylindrical portion of the bale-forming chamber. The bale is circumferentially supported by netting applied to the bale in the cylindrical portion. A rotary feed table receives crop from the field and feeds the crop into the conical portion. The bale forming process can be interrupted if an insufficient volume of crop is collected on the rotary feed table. The netting material is provided on short rolls to facilitate loading onto the machine. A cutoff mechanism is coupled to the growth of the bale from the cylindrical portion to sever the bale at a predetermined length with end surfaces that are perpendicular to the axis of the bale. A bale density mechanism supports the distal end of the bale as the bale protrudes upwardly.
A trailer (1) for round bales of fodder material comprising a bed (19) and a pick-up mechanism (35) for transferring bales from the ground onto the bed (19). A lifting mechanism (38) adjacent the front end (10) of the bed (19) is provided with first and second receiving elements (39,40) for receiving four bales sequentially from the pick-up mechanism (35). The lifting mechanism (38) is urgeable by a main drive ram (60) from a first state adjacent the front end (10) of the bed (19) in a rearward direction for transferring four bales on the lifting mechanism (38) to an intermediate framework (26) of the bed (19). The next four bales on the lifting mechanism (38) urge the bales already on the intermediate framework (26) onto the rear framework (27) as those bales on the lifting mechanism (38) are being urged to the intermediate framework (26), and so on until the trailer has been loaded with sixteen bales. The rear framework (27) is pivotally coupled to the chassis (3) from a hauling state to a discharge state for discharging the bales onto the ground with the longitudinal central geometrical axis of the bales extending vertically.
B60P 1/00 - Véhicules destinés principalement au transport des charges et modifiés pour faciliter le chargement, la fixation de la charge ou son déchargement
B60P 3/035 - Véhicules adaptés pour transporter, porter ou comporter des charges ou des objets spéciaux pour le transport de tourets
B60P 3/06 - Véhicules adaptés pour transporter, porter ou comporter des charges ou des objets spéciaux pour le transport de véhicules
A01D 90/08 - Moyens de chargement avec moyens de mise en balles utilisés additionnellement pour le chargementMoyens de chargement avec moyens de ramassage et de transport des balles dans le véhicule
A combined baler/bale wrapper (1) comprises a baler (10) mounted on a chassis (5) and a bale wrapper (14) mounted on the chassis (5) rearwardly of the baler (10) for wrapping a bale formed by the baler (10). The bale wrapper (14) comprises a pair of first and second bale support rollers (50,51) for supporting and rotating the bale about a first wrapping axis (56). A pair of wrapping film dispensers (60) are carried on a carrier ring (58) which is rotated about a second wrapping axis (61) for dispensing wrapping film onto the bale (2) as the bale (2) is being rotated by the first and second bale support rollers (50,51). The first bale support roller (50) is carried on a transfer element (16) so that as the transfer element (16) is pivoted about a transfer pivot axis (17) from a first state to a second state for transferring the bale (2) onto the bale wrapper (14) the first bale support roller (50) is urged in a downwardly direction (F) in order to maximise the headroom available to the bale (2) as the bale (2) is being transferred by the transfer element (16) to the bale wrapper (14).
A01F 15/07 - Presses enrouleuses, c.-à-d. machines pour former des balles cylindriques par enroulement et compression
B65B 11/04 - Enveloppement d'objets ou de quantités de matériaux sans changer leur position durant l'opération, p. ex. dans des moules avec des plieurs à charnières en faisant tourner les objets
B65B 35/30 - Disposition et alimentation des objets en groupes
A combined baler/bale wrapper (1) comprises a baler (10) mounted on a chassis (5) and a bale wrapper (14) mounted on the chassis (5) rearwardly of the baler (10) for wrapping a bale formed by the baler (10). The bale wrapper (14) comprises a pair of first and second bale support rollers (50,51 ) for supporting and rotating the bale about a first wrapping axis (56). A pair of wrapping film dispensers (60) are carried on a carrier ring (58) which is rotated about a second wrapping axis (61) for dispensing wrapping film onto the bale (2) as the bale (2) is being rotated by the first and second bale support rollers (50,51). The first bale support roller (50) is carried on a transfer element (16) so that as the transfer element (16) is pivoted about a transfer pivot axis (17) from a first state to a second state for transferring the bale (2) onto the bale wrapper (14) the first bale support roller (50) is urged in a downwardly direction (F) in order to maximise the headroom available to the bale (2) as the bale (2) is being transferred by the transfer element (16) to the bale wrapper (14).
A combined baler/bale wrapper (1) comprises a baler (10) mounted on a chassis (5) and a bale wrapper (14) mounted on the chassis (5) rearwardly of the baler (10) for wrapping a bale formed by the baler (10). The bale wrapper (14) comprises a pair of first and second bale support rollers (50,51 ) for supporting and rotating the bale about a first wrapping axis (56). A pair of wrapping film dispensers (60) are carried on a carrier ring (58) which is rotated about a second wrapping axis (61) for dispensing wrapping film onto the bale (2) as the bale (2) is being rotated by the first and second bale support rollers (50,51). The first bale support roller (50) is carried on a transfer element (16) so that as the transfer element (16) is pivoted about a transfer pivot axis (17) from a first state to a second state for transferring the bale (2) onto the bale wrapper (14) the first bale support roller (50) is urged in a downwardly direction (F) in order to maximise the headroom available to the bale (2) as the bale (2) is being transferred by the transfer element (16) to the bale wrapper (14).
A01F 15/07 - Presses enrouleuses, c.-à-d. machines pour former des balles cylindriques par enroulement et compression
28.
A METHOD AND A SYSTEM FOR CONTROLLING CIRCUMFERENTIAL WRAPPING OF A CYLINDRICAL BALE IN A BALE FORMING CHAMBER OF A BALER, AND A BALER AND A METHOD FOR PRODUCING A CIRCUMFERENTIALLY WRAPPED BALE
A fixed chamber baler (1) having a bale forming chamber (12) within which a bale (2) of silage is formed and circumferentially wrapped with wrapping film (3) comprises a system for controlling the degree of stretch in the feed direction of the wrapping film (3) with which the bale (2) is wrapped. The system comprises a first rotary encoder (51) for monitoring the rotational speed of a bale rotating roller (18e) of the baler (1), and a second rotary encoder (54) for monitoring the rotational speed of a tensioning roller (32) for tensioning the wrapping film (3). A microprocessor (56) from signals read from the first and second rotary encoders (51,54) computes the ratio of the difference of the linear speeds of the wrapping film (3) adjacent the rotating bale (2) and the tensioning roller (32) to the linear speed of the wrapping film (3) adjacent the tensioning roller (32), which is the value of the degree of stretch being induced in the wrapping film (3) as it is being wrapped onto the bale (2). A torsional load applied to the tensioning roller (32) is varied for varying the rotational speed of the tensioning roller (32) until the degree of stretch with which the wrapping film (3) is being applied to the rotating bale (2) equals a predefined degree of stretch stored in the microprocessor (56).
Agricultural machinery, namely, bale wrappers; agricultural machinery, namely, bale handlers, [ silage grabs, silage cutters ] and bale splitters; and component parts and fittings for the aforesaid agricultural machinery
