Abrégé

An electronic device includes a first circuit board, a first shielding cover and a first solder. The first circuit board has a first surface, a second surface and a first edge. The first and second surfaces are on opposite sides. The first edge is on one side of the circuit board. The first shielding cover is disposed on the first surface and covers a first region of the first circuit board. The first shielding cover includes a first main body and first and second shielding elements. The first shielding element is connected between the first main body and the second shielding element and parallel to the first surface. The second shielding element is parallel to the first edge and perpendicular to the first surface. The first solder is located between the first main body and the first region to connect the first shielding cover to the first circuit board.

Classes IPC  ?

• H05K 1/02 - Circuits imprimés Détails
• H05K 1/14 - Association structurale de plusieurs circuits imprimés
• H05K 9/00 - Blindage d'appareils ou de composants contre les champs électriques ou magnétiques

Abrégé

The present invention is related to a calibration method for parameters of a power amplifier, wherein the power amplifier has N parameters each having a preset range of standard power output value. The method comprises: step 1: manually calibrate parameter values of N1 parameters among the N parameters to obtain calibrated parameter values of the N1 parameters; step 2: input the calibrated parameter values of the N1 parameters into an AI background process program to calculate and derive calculated parameter values of remaining N2 parameters by the AI background process program, wherein N2=N−N1; and step 3: install the calibrated parameter values of the N parameters in the power amplifier to finish calibration of the parameters of the amplifier.

Classes IPC  ?

• H03F 1/02 - Modifications des amplificateurs pour augmenter leur rendement, p. ex. étages classe A à pente glissante, utilisation d'une oscillation auxiliaire
• H03F 3/24 - Amplificateurs de puissance, p. ex. amplificateurs de classe B, amplificateur de classe C d'étages transmetteurs de sortie

Abrégé

The application discloses a radar antenna device and a radar element thereof. The radar antenna device, configured for installation on a side surface of a vehicle, comprises: a base having a surface; a first antenna circuit board disposed on the surface; and a second antenna circuit board disposed on the surface. Wherein a first angle is formed between the first antenna circuit board and the side surface of the vehicle, and a second angle is formed between the second antenna circuit board and the side surface of the vehicle, and both the first angle and the second angle are greater than or equal to 15 degrees and less than or equal to 25 degrees.

Classes IPC  ?

• G01S 13/931 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques pour prévenir les collisions de véhicules terrestres
• H01Q 1/50 - Association structurale d'antennes avec commutateurs de terre, dispositions de descente d'antennes ou parafoudres

Abrégé

A radar calibration device for calibrating a radar system installed on a vehicle, is provided by the present disclosure. The radar system comprises a radar module and a radar control unit configured to receive a first signal output by the vehicle. The radar calibration device comprises a memory storing a configuration software. The radar calibration device also comprises a signal calibration unit providing information. The radar calibration device also comprises a processor coupled to the memory, the signal calibration unit and the radar control unit and configured to executing the configuration software. The processor calibrates the first signal to a second signal based on the information.

Classes IPC  ?

• G01S 7/40 - Moyens de contrôle ou d'étalonnage
• G01S 13/931 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques pour prévenir les collisions de véhicules terrestres

Abrégé

An automotive modular radar device comprises a bracket module and a radar module. The bracket module comprises a bracket. The bracket comprises a connected plate and a fixed plate. The connected plate is used to be fixed to a vehicle. The bottom edge of the fixed plate is disposed on the connected plate. An angle is formed between the bottom edge and the side of the fixed plate, and the angle is between 0 and 90 degrees. The radar module comprises a radar. The radar comprises a casing, a circuit board, an antenna module and a processing unit. One side of the casing is fixed on the side of the fixed plate. The circuit board is disposed in the casing. The antenna module is disposed on the circuit board. The processing unit is disposed on the circuit board and electrically connected to the antenna module.

Classes IPC  ?

• G01S 7/02 - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
• G01S 7/03 - Détails de sous-ensembles HF spécialement adaptés à ceux-ci, p. ex. communs à l'émetteur et au récepteur
• G01S 13/86 - Combinaisons de systèmes radar avec des systèmes autres que radar, p. ex. sonar, chercheur de direction
• G01S 13/931 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques pour prévenir les collisions de véhicules terrestres

Abrégé

An optical transmission and reception carrier includes an optical fiber, an invisible light transmitter, an invisible light receiver, a visible light transmitter and a fiber optic connector. The invisible light transmitter is configured to emit a first invisible light toward the fiber optic connector and includes a first connection element. The invisible light receiver is configured to receive a second invisible light from the fiber optic connector and includes a second connection element. The visible light transmitter is configured to emit a visible light toward the fiber optic connector. One of the first connection element and the second connection element is a flexible flat cable.

Classes IPC  ?

• H04B 10/40 - Émetteurs-récepteurs
• H04B 10/25 - Dispositions spécifiques à la transmission par fibres
• H04J 14/02 - Systèmes multiplex à division de longueur d'onde

Abrégé

A radar device for being installed on a vehicle is provided by the present disclosure. The radar device comprises a radar module configured to generate a radar detection area, and an adjustment mechanism. The adjustment mechanism includes a vehicle installation part configured to be mounted on a first side of the vehicle. The adjustment mechanism also includes a radar mounting part pivotally connected to the vehicle installation part. The radar mounting part is able to be pivoted relative to the vehicle installation part, and the radar mounting part is configured to secure the radar module.

Classes IPC  ?

• G01S 7/02 - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
• G01S 13/931 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques pour prévenir les collisions de véhicules terrestres

Abrégé

The invention discloses radar antenna device and radar system, which the radar antenna device is for installing on side surfaces of vehicle. The radar antenna device comprises two antenna circuit boards, and each antenna circuit board comprises a first surface including a signal transmitting unit and a signal receiving unit. The signal transmitting unit includes a first signal zone, and the first signal zone is located within range of angles between 0 degree and 50 degrees from normal line of center of the first surface. The radar antenna device also comprises a base for installing two antenna circuit boards. One end of each antenna circuit board is coupled to one end of the base, forming an angle of 52.5 degrees to 65 degrees, such that a first direction, parallel to the base, extending from center of the first surface is located in the first signal zone.

Classes IPC  ?

• G01S 7/02 - Détails des systèmes correspondant aux groupes , , de systèmes selon le groupe
• G01S 13/931 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques pour prévenir les collisions de véhicules terrestres

Abrégé

A radar antenna device for being installed on a lateral surface of a vehicle is provided by the present disclosure. The radar antenna device comprises: a base; a first antenna PCB disposed on the base, and including a first radar transmitting unit; and a second antenna PCB disposed on the base, and including a second radar transmitting unit. The first and second radar transmitting units respectively transmit radar signals including a strong signal region and a weak signal region and a signal border therebetween. The average gain of signal strength of the strong signal regions is greater than 0 db, and the average gain of signal strength of the weak signal regions is less than 0 db. An intersection is formed by the signal border of the radar signals, and the shortest distance between the intersection and the second surface is between 30 mm to 80 mm.

Classes IPC  ?

• H01Q 1/32 - Adaptation pour l'utilisation dans ou sur les véhicules routiers ou ferroviaires
• G01S 7/03 - Détails de sous-ensembles HF spécialement adaptés à ceux-ci, p. ex. communs à l'émetteur et au récepteur
• G01S 13/931 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques pour prévenir les collisions de véhicules terrestres

Abrégé

An automatic battery ejection device includes a main body, a push plate, a battery and a plurality of first elastic members. The push plate is disposed in the main body and includes a button and at least one first hook. The battery is disposed in the main body and includes at least one second hook, and the first hook engages with the second hook for connecting the push plate and the battery. The first elastic members are disposed in the main body, penetrated through the push plate, and compressed by the battery. Wherein when the button is pressed, the push plate is moved with respect to the main body toward a first direction, so that the first hook is separated from the second hook, and the first elastic members simultaneously push the battery toward a second direction with their elasticity, the first direction is perpendicular to the second direction.

Classes IPC  ?

• H01M 50/262 - MonturesBoîtiers secondaires ou cadresBâtis, modules ou blocsDispositifs de suspensionAmortisseursDispositifs de transport ou de manutentionSupports avec des moyens de fixation, p. ex. des serrures
• H01M 50/202 - Boîtiers ou cadres autour du boîtier primaire d’une seule cellule ou d’une seule batterie

Abrégé

An injection molding method and a deformable molding unit are provided. The method includes the following steps. First, a mold positioning step is performed to define a mold cavity. The step includes: providing a deformable molding unit on a first axis, the deformable molding unit having a deformable cavity and including a bottom portion and a first elastic portion being elastically deformable with respect to the bottom portion; and applying a first compression force to the first elastic portion by a first drive module along a second axis, reducing the size of the deformable cavity to a reduced dimension. Next, plastic is injected into the mold cavity including the deformable cavity with the reduced dimension to form a workpiece. Then, the first compression force is released, allowing the deformable cavity to return to its original dimension. Afterward, the deformable molding unit is retracted along the first axis.

Classes IPC  ?

• B29C 45/56 - Moyens pour plastifier ou homogénéiser la matière à mouler ou pour la forcer dans le moule utilisant des éléments de moules mobiles pendant ou après l'injection, p. ex. pour le moulage par injection-pressage

Abrégé

A temperature managing system, is for managing a temperature of an electronic device, and the electronic device includes a first key component having a first temperature. The temperature managing system includes the following components. A fan module, includes a rotating speed controller and a fan with a rotating speed. A temperature sensor, senses a temperature of the first key component in the electronic device and generates a temperature information accordingly. A processor, coupled to the fan module through the first interface and coupled to the temperature sensor through the second interface. The processor is configured to receive the temperature information through the second interface, correspondingly generate a rotating speed control signal according to the temperature information, and send the rotating speed control signal to the rotating speed controller through the first interface, so as to control the rotating speed of the fan.

Classes IPC  ?

• H05K 7/20 - Modifications en vue de faciliter la réfrigération, l'aération ou le chauffage

Abrégé

A vehicle trajectory recording system and method for vehicles with a sensor is disclosed. The system includes a sensor arranged on a vehicle; a control module, electrically connected to the sensor and configured to receive a piece of sensing information from the sensor, analyze the sensing information to determine a traveling direction change event of the vehicle, and analyze the traveling direction change event and determine a driving event of the vehicle; and a recording module, electrically connected to the control module and configured to record a position of the vehicle where the vehicle performed the driving event, mark the position of the vehicle on a map where the driving event occurred, and adjust a driving trajectory of the vehicle.

Classes IPC  ?

• G01S 19/47 - Détermination de position en combinant les mesures des signaux provenant du système de positionnement satellitaire à radiophares avec une mesure supplémentaire la mesure supplémentaire étant une mesure inertielle, p. ex. en hybridation serrée

Abrégé

A communication device with multiple antennas is provided, which includes the following elements. An antenna module, including a plurality of first antennas and a plurality of second antennas, has the first antennas operating in a first frequency band and a second frequency band, and the second antennas operate in the second frequency band. A performance evaluation module, for evaluating a communication quality between each of the first antennas and a base station in the first frequency band, and marking a base station region, the base station region is related to the base station. A decision module, for selecting one of the first antennas as a transmitting (TX) antenna for an uplink communication of the first frequency band according to the communication quality, and selecting two of the second antennas as two TX antennas for an uplink communication of the second frequency band according to the base station region.

Classes IPC  ?

• H01Q 21/28 - Combinaisons d'unités ou systèmes d'antennes sensiblement indépendants et n’interagissant pas entre eux
• H01Q 5/30 - Dispositions permettant un fonctionnement sur différentes gammes d’ondes

Abrégé

An antenna structure includes a ground surface, a first antenna, a second antenna, and a printed-type guiding structure located between the first antenna and the second antenna. The first antenna, the second antenna, and the printed-type guiding structure are electrically connected to the ground surface. The printed-type guiding structure includes a first hollow portion, a second hollow portion, and a protruding portion. The angle between the axes of the two hollow portions is 30°-50°. The protruding portion is disposed between the external of the first side of the first hollow portion and the interior of the first side of the second hollow portion. The second hollow portion has a short arm on the first side and a long arm on the second side. The total length of the short arm and the long arm is 0.2-0.3 times the operating frequency wavelength.

Classes IPC  ?

• H01Q 1/52 - Moyens pour réduire le couplage entre les antennesMoyens pour réduire le couplage entre une antenne et une autre structure
• H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids

Abrégé

Provided is an asymmetric Chebyshev array antenna, comprising a substrate, a power divider, a ground plane, and a serial antenna unit. The serial antenna unit includes at least one middle radiating element, a plurality of first radiating elements, and a plurality of second radiating elements. An original current value of the middle radiating element is defined as A, original current values of the first radiating elements from a first end toward a second end of the serial antenna unit are defined as B1, B2, . . . , Bn, original current values of the second radiating elements from the second end toward the first end of the serial antenna unit are defined as C1, C2, . . . , Cn, a sum of original current values of the power divider and the ground plane is defined as D, current compensation values of the second radiating elements from the second end toward the first end of the serial antenna unit are defined as δ1, δ2, . . . , δn, n≥1 and n is a positive integer, Bn=Cn, D

Classes IPC  ?

• H01Q 21/06 - Réseaux d'unités d'antennes, de même polarisation, excitées individuellement et espacées entre elles
• H01Q 9/04 - Antennes résonnantes
• H01Q 21/00 - Systèmes ou réseaux d'antennes

Abrégé

A multi-antenna module system includes a substrate, a plurality of first antenna modules, a plurality of second antenna modules, and a plurality of third antenna modules. The substrate has an opening. The first antenna modules are respectively disposed on the substrate and located on two opposite first sides and two opposite second sides for transmitting and receiving a first frequency band signal. The second antenna modules are respectively disposed on the substrate and located on two opposite third sides for transmitting and receiving a second frequency band signal. The third antenna modules are respectively disposed on the substrate and located on two opposite third sides and two opposite fourth sides for transmitting and receiving a third frequency band signal. The second antenna modules and the third antenna modules are respectively located between the first antenna modules.

Classes IPC  ?

• H01Q 21/24 - Combinaisons d'unités d'antennes polarisées dans des directions différentes pour émettre ou recevoir des ondes polarisées circulairement ou elliptiquement ou des ondes polarisées linéairement dans n'importe quelle direction
• H01Q 3/02 - Dispositifs pour changer ou faire varier l'orientation ou la forme du diagramme de directivité des ondes rayonnées par une antenne ou un système d'antenne utilisant un mouvement mécanique de l'ensemble d'antenne ou du système d'antenne

Abrégé

An auxiliary installation tool for a vehicle radar includes an angle ruler. The angle ruler includes a first reference section, a second reference section, and a radar installation section. The first reference section and the second reference section are connected and intersect at a right angle, wherein during measurement, the first reference section is configured for aligning with a vehicle body horizontal line, the second reference section is configured for aligning with or parallel to a vehicle rear horizontal line, the vehicle body horizontal line and the vehicle rear horizontal line respectively extend along the body and the rear of a vehicle and intersect at a corner of the vehicle. The radar installation section is correspondingly located at the corner of the vehicle, and the radar installation section and the second reference section are connected and intersect at a radar installation angle.

Classes IPC  ?

• G01S 13/46 - Détermination indirecte des données relatives à la position

Abrégé

A high-frequency switching extender is provided, used to receive signals from external routers and devices and transmit transmission signals to external routers and devices. The high-frequency switching extender includes a high-frequency transceiver module, a high-frequency switching module, a high-frequency RF front-end module, a high-frequency filter module, a high-frequency antenna switching unit, and a high-frequency antenna. Wherein, the high-frequency switching extender has a transmission mode and a receiving mode. In transmission mode, the high-frequency switching module switches the transmission signal to the preset frequency band according to the control voltage, and the transmission signal switched to the preset frequency band is transmitted to the high-frequency antenna for transmission. In receiving mode, the high-frequency antenna switching unit switches the received signal to the preset frequency band according to the control voltage, and the received signal switched to the preset frequency band is transmitted to the high-frequency transceiver module.

Classes IPC  ?

• H04B 1/00 - Détails des systèmes de transmission, non couverts par l'un des groupes Détails des systèmes de transmission non caractérisés par le milieu utilisé pour la transmission
• H04B 1/44 - Commutation transmission-réception

Abrégé

A case with screw thread in a sealed manner for communication equipment includes an upper cover and a bottom cover. The inner surface of the upper cover has an internal screw thread. The outer surface of the bottom cover has an external screw thread. When the external screw thread is fixed with the internal screw thread, the inner surface of the upper cover is in contact with the outer surface of the bottom cover in a sealed state, and the upper cover and the bottom cover form a receiving space. The case provides the following advantages: quickly and repeated assembly and disassembly; no need for any space for bolts so as to minimizes the size; without bolt, no need for washers or sealant; good sealing properties and good waterproof effect so as to prevent water from entering the case.

Classes IPC  ?

• H05K 5/00 - Enveloppes, coffrets ou tiroirs pour appareils électriques
• F16B 43/00 - Rondelles ou dispositifs équivalentsAutres dispositifs de support pour têtes de boulons ou d'écrous

Abrégé

A 5G outdoor unit having a heat dissipation function includes a main body and a support frame. The main body includes a housing, a cover, and an antenna, the cover is mounted on one side of the housing, and the antenna is disposed on an inner side of the cover. The support frame includes a first side plate, a second side plate, and a plurality of heat dissipation fins. The first side plate is mounted on an outer side of the cover, the fins are arranged between the first side plate and the second side plate at intervals, and a channel is formed between the two adjacent heat dissipation fins. As such, the main body and the support frame are two separate elements. The volume of the main body is reduced, and the weight of the main body is less.

Classes IPC  ?

• H05K 7/20 - Modifications en vue de faciliter la réfrigération, l'aération ou le chauffage

Abrégé

A tri-band antenna module includes a substrate, a first radiator, a second radiator, and a short-circuit structure. The substrate has a signal feed-in terminal and a ground terminal. The signal feed-in terminal is connected to the first radiator, and the ground terminal is connected to the second radiator. The first radiator includes a first extension block and a second extension block, and the second radiator includes a third extension block and a fourth extension block. The first extension block and the second extension block are separated by a first interval, and the third extension block and the fourth extension block are separated by a second interval. The short-circuit structure is connected between the first extension block and the third extension block, and the short-circuit structure is respectively separated from the first extension block and the third extension block by a first slot and a second slot.

Classes IPC  ?

• H01Q 5/307 - Éléments rayonnants individuels ou couplés, chaque élément étant alimenté d’une façon non précisée
• H01Q 9/04 - Antennes résonnantes

Abrégé

The present invention relates to a network connection system. The network connection system includes a gateway, an extender, and a wireless access point. Wherein, the gateway can be used as one of the enrollee router and the registrar router, and the extender can be used as the other of the enrollee router and the registrar router, and the extender can send authentication information to the gateway. After the gateway confirms that the extender is a model supported by the gateway according to the authentication information, the gateway sends a credential to the extender, allowing the extender to establish a wireless mesh network through the wireless access point. In this way, the purpose of seamless connection is achieved. In addition, the network connection system of the present invention has functions such as high security and convenience.

Classes IPC  ?

• H04W 12/06 - Authentification
• H04W 12/73 - Identité logique du point d’accès

Abrégé

The present invention relates to a detection method for a multi-access edge computing architecture. The multi-access edge computing architecture uses the technology of bump-in-the-wire (BITW) to be deployed between the user device and the core network. The multi-access edge computing architecture includes a baseboard management controller, an edge computing service module, a central processing unit module, and a switching module. When any function in the multi-access edge computing architecture fails, the detection method of the present invention is used to actively detect and directly connect the base station to the core network. When the function is restored, the detection method of the present invention can actively restore the original path of the base station and the core network connected to the multi-access edge computing architecture to achieve seamless debugging and other purposes.

Classes IPC  ?

• H04L 12/26 - Dispositions de surveillance; Dispositions de test
• H04L 43/0823 - Erreurs, p. ex. erreurs de transmission
• H04L 41/0654 - Gestion des fautes, des événements, des alarmes ou des notifications en utilisant la reprise sur incident de réseau
• H04W 24/04 - Configurations pour maintenir l'état de fonctionnement
• H04L 43/0817 - Surveillance ou test en fonction de métriques spécifiques, p. ex. la qualité du service [QoS], la consommation d’énergie ou les paramètres environnementaux en vérifiant la disponibilité en vérifiant le fonctionnement
• H04L 41/40 - Dispositions pour la maintenance, l’administration ou la gestion des réseaux de commutation de données, p. ex. des réseaux de commutation de paquets en utilisant la virtualisation des fonctions réseau ou ressources, p. ex. entités SDN ou NFV
• H04L 41/0659 - Gestion des fautes, des événements, des alarmes ou des notifications en utilisant la reprise sur incident de réseau en isolant ou en reconfigurant les entités défectueuses
• H04L 41/04 - Architectures ou dispositions de gestion de réseau
• H04L 43/20 - Dispositions pour la surveillance ou le test de réseaux de commutation de données le système de surveillance ou les éléments surveillés étant des entités virtualisées, abstraites ou définies par logiciel, p. ex. SDN ou NFV

Abrégé

An antenna structure is provided, including a substrate, an impedance control line, a first impedance control area, and a metal element. The impedance control line is located on the first side of the substrate. The first impedance control area is arranged on the substrate, located on one side of the impedance control line, close to the second end of the impedance control line, and separated from the impedance control line by a first hollow part. The metal element is arranged on the substrate and connected to the first end and the second end of the impedance control line, and the first impedance control area. As such, the present invention controls the impedance in the high frequency range between 5.85 and 7.25 GHz through the impedance control line and the first impedance control area, provides a complete current flow area, and improves the impedance control effect, efficiency, and gain.

Classes IPC  ?

• H01Q 5/50 - Dispositions d’alimentation ou d’adaptation pour un fonctionnement à large bande ou multibande
• H01Q 9/04 - Antennes résonnantes
• H04W 84/12 - Réseaux locaux sans fil [WLAN Wireless Local Area Network]

Abrégé

A wireless communication system using wireless LAN channels for wireless communication is disclosed, comprising: master access point, slave access points, and computing unit. First, the master access point creates a collision record table and a usage time record table. After that, the master access point updates the collision record table and usage time record table based on the usage information, and transmits the collision record table and usage time record table to the slave access points. The computing unit generates the channel collision probability through the number of collisions, and calculates the usage weight of the dynamic frequency selection channel through the channel collision probability. Finally, the wireless communication system automatically selects the wireless LAN channels of the master access point and the slave access points according to the usage weight and usage time record table. As such, the wireless communication system has high efficiency and low delay.

Classes IPC  ?

• H04W 16/10 - Répartition dynamique des ressources
• H04W 72/02 - Sélection de ressources sans fil par un utilisateur ou un terminal
• H04W 72/04 - Affectation de ressources sans fil
• H04W 84/12 - Réseaux locaux sans fil [WLAN Wireless Local Area Network]
• H04W 72/0453 - Ressources du domaine fréquentiel, p. ex. porteuses dans des AMDF [FDMA]

Abrégé

A transmission structure with a dual-frequency antenna is provided. The transmission structure includes a substrate, a first radiator and a second radiator. The first radiator has a first electrical connection portion. The first radiator extends from the first electrical connection portion in a first direction and a second direction, wherein the first direction is opposite to the second direction. The second radiator has a second electrical connection portion adjacent to the first electrical connection portion. The second electrical connection portion has a first side and a second side, wherein the first side is closer to the first electrical connection portion than the second side, the second electrical connection portion forms a ground area between the first side and the second side, and the length of the ground area is greater than a first set value.

Classes IPC  ?

• H01Q 9/28 - Éléments coniques, cylindriques, en cage, en ruban, en treillis ou éléments analogues ayant une surface de rayonnement étendueÉléments comportant deux surfaces coniques ayant le même axe et opposées par leurs sommets et alimentés par des lignes de transmission à deux conducteurs
• H01Q 1/38 - Forme structurale pour éléments rayonnants, p. ex. cône, spirale, parapluie formés par une couche conductrice sur un support isolant
• H01Q 5/371 - Parcours de courants avec ramifications

Abrégé

An antenna for suppressing the gain of side lobes includes a substrate, tandem antenna units arranged on the substrate and each including a first feed line and radiating elements, and the width of the radiating elements decreasing gradually from the middle of the first feed line to the two ends; and a power divider disposed on the substrate and including a feeding port, a second feed line with middle connected to the feeding port, and transmission lines, connected to the second feed line respectively. The output powers of the transmission lines decrease gradually from the middle of the second feed line to the two ends, and the transmission lines are respectively connected to the first feed lines. Thereby, the present invention can effectively suppress the gain of the side lobe both in YZ plane and the XZ plane, and improve target detection.

Classes IPC  ?

• H01Q 13/20 - Antennes constituées par un guide non résonnant à ondes de fuite ou une ligne de transmissionStructures équivalentes produisant un rayonnement le long du trajet de l'onde guidée
• H01Q 21/00 - Systèmes ou réseaux d'antennes
• H01Q 1/32 - Adaptation pour l'utilisation dans ou sur les véhicules routiers ou ferroviaires
• H01Q 21/22 - Réseaux d'unités d'antennes, de même polarisation, excitées individuellement et espacées entre elles les unités d'antennes du réseau étant excitées d'une façon non uniforme en amplitude ou en phase, p. ex. réseau à prises ou réseau bidirectionnel

Abrégé

The present invention discloses a printed circuit board (PCB). The printed circuit board includes a plurality of layers, a first antenna, a second antenna, a third antenna and an isolator. The first antenna is arranged on a first layer of the layers. The second antenna is arranged on the first layer. The isolator is arranged on the first layer and located between the first antenna and the second antenna. The third antenna is arranged on a second layer of the layers, wherein the second layer is different from the first layer. A position of the third antenna overlaps a position of the isolator in a direction perpendicular to a surface of the printed circuit board.

Classes IPC  ?

• H01Q 1/52 - Moyens pour réduire le couplage entre les antennesMoyens pour réduire le couplage entre une antenne et une autre structure
• H01Q 5/307 - Éléments rayonnants individuels ou couplés, chaque élément étant alimenté d’une façon non précisée
• H01Q 1/38 - Forme structurale pour éléments rayonnants, p. ex. cône, spirale, parapluie formés par une couche conductrice sur un support isolant

Abrégé

A communication system, a data transmission method and a base station thereof are provided. The communication system includes a first base station and a second base station. The first base station includes a physical layer unit, a MAC layer unit and a PDCP layer unit. The physical layer unit is configured to transmit with a user equipment through a transmission channel. The MAC layer unit is configured to determine whether a retransmission ratio of the transmission channel is higher than a first threshold and to determine whether a transmission speed of the transmission channel is lower than a second threshold. If the retransmission ratio is higher than the first threshold and/or the transmission speed is lower than the second threshold, the first base station copy a packet and then transmits the copied packet to the second base station which accordingly transmits the copied packet to the user equipment.

Classes IPC  ?

• H04L 1/18 - Systèmes de répétition automatique, p. ex. systèmes Van Duuren
• H04W 28/22 - Négociation du débit de transmission
• H04W 80/02 - Protocoles de couche liaison de données

Abrégé

A communication system, a data transmission method thereof, and a user device thereof are provided. The data transmission method includes the following steps. A first transmitting Radio Link Control (Tx RLC) entity of a first base station transmits a first Protocol Data Unit (PDU) to a first receiving Radio Link Control (Rx RLC) entity of a user equipment via a first leg. A second Tx RLC entity of a second base station transmits a second PDU to a second Rx RLC entity of the user equipment via a second leg. If the first Rx RLC entity successfully receives the first PDU or the second Rx RLC entity successfully receives the second PDU, the first Rx RLC entity and the second RLC entity return Acknowledgement (ACK) messages.

Classes IPC  ?

• H04L 5/00 - Dispositions destinées à permettre l'usage multiple de la voie de transmission

Abrégé

An antenna for improving an influence of surface waves and increasing a beamwidth includes: a substrate, a first metal ground, a second metal ground, an emitting end and a receiving module. The first metal ground and the second metal ground are disposed on a first surface of the substrate. The second metal ground is completely separated from the first metal ground by a first gap. The emitting end is disposed on the first metal ground and includes a transmission line and a plurality of radiating elements. The receiving module is disposed on the second metal ground and includes a first receiving end and a second receiving end. The first receiving end includes a transmission line and a plurality of radiating elements. The second receiving end includes a transmission line and a plurality of radiating elements.

Classes IPC  ?

• H01Q 1/32 - Adaptation pour l'utilisation dans ou sur les véhicules routiers ou ferroviaires
• G01S 7/03 - Détails de sous-ensembles HF spécialement adaptés à ceux-ci, p. ex. communs à l'émetteur et au récepteur
• H01Q 1/38 - Forme structurale pour éléments rayonnants, p. ex. cône, spirale, parapluie formés par une couche conductrice sur un support isolant
• H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids
• G01S 13/32 - Systèmes pour mesurer la distance uniquement utilisant la transmission d'ondes continues, soit modulées en amplitude, en fréquence ou en phase, soit non modulées
• G01S 13/58 - Systèmes de détermination de la vitesse ou de la trajectoireSystèmes de détermination du sens d'un mouvement

Abrégé

A network path selection method and a network node device using the same are disclosed. The network path selection method includes: determining whether a first uplink time parameter table is received from the first relay node device and whether a second uplink time parameter table is received from the second relay node device; when the first uplink time parameter table is received from the first relay node device and the second uplink time parameter table is received from the second relay node device, calculating a first estimated uplink time parameter according to the first uplink time parameter table and a second estimated uplink time parameter according to the second uplink time parameter table; and determining to connect to a gateway via one of the first relay node device and the second relay node device according to the first estimated uplink time parameter and the second estimated uplink time parameter.

Classes IPC  ?

• H04W 40/12 - Sélection d'itinéraire ou de voie de communication, p. ex. routage basé sur l'énergie disponible ou le chemin le plus court sur la base de la qualité d'émission ou de la qualité des canaux
• H04L 45/021 - Mises à jour des tables d’acheminement avec garantie de cohérence, p. ex. en utilisant des nombres d’époque
• H04L 45/121 - Évaluation de la route la plus courte en minimisant les retards
• H04L 45/16 - Routage multipoint
• H04W 40/24 - Gestion d'informations sur la connectabilité, p. ex. exploration de connectabilité ou mise à jour de connectabilité
• H04W 40/28 - Gestion d'informations sur la connectabilité, p. ex. exploration de connectabilité ou mise à jour de connectabilité pour acheminement réactif
• H04W 88/16 - Dispositions de passerelles

Abrégé

A network device including a main bridge, a first bridge, a controller, and an Ethernet port is provided. When the Ethernet port is connected to a mesh network, the processing unit performs the following steps: controlling the Ethernet port to transmit a first broadcast packet; when the Ethernet port receives a second broadcast packet, parsing the second broadcast packet to extract the packet path information to determine whether a path loop exists; determining, according to the Ethernet interface weight (EIW), the slave interface uplink weight (SIUW), and the master device weight (MW) carried by the first broadcast packet and the second broadcast packet, (1) whether the network device plays a master device role, (2) whether the bridge of the Ethernet port is set as the main bridge or the first bridge, and (3) whether the Ethernet port allows data transmission.

Classes IPC  ?

• H04W 24/04 - Configurations pour maintenir l'état de fonctionnement
• H04L 41/0654 - Gestion des fautes, des événements, des alarmes ou des notifications en utilisant la reprise sur incident de réseau
• H04L 69/22 - Analyse syntaxique ou évaluation d’en-têtes
• H04W 84/18 - Réseaux auto-organisés, p. ex. réseaux ad hoc ou réseaux de détection

Abrégé

A transmission system, a transmission device and a transmission path allocation method are provided. The transmission path allocation method is configured to transmit a plurality of data packets through at least two transmission paths. Each of the transmission paths has a send buffer. The transmission path allocation method includes the following steps. A transmission time length for each of the transmission paths is analyzed according to an output data variation of each of the send buffers. Each of the data packets is allocated to the transmission paths according to each of the transmission time lengths. A sequential code is attached to each of the data packets. Each of the data packets is transmitted.

Classes IPC  ?

• H04L 12/721 - Procédures de routage, p.ex. routage par le chemin le plus court, routage par la source, routage à état de lien ou routage par vecteur de distance
• H04L 12/26 - Dispositions de surveillance; Dispositions de test
• H04L 12/801 - Commande de flux ou commande de congestion

Abrégé

A backhaul bandwidth management method for a wireless network is provided. Firstly, a backhaul connection mode is adjusted by a network device in a backhaul network according to a wireless capability. Then, a backhaul guaranteed bandwidth is guaranteed by the network device according to at least one of a dedicated service set identifier (SSID), a dedicated radio frequency (RF) band and a dedicated wireless mode. Then, a bandwidth allocation algorithm is executed by the network device to ensure that at least one backhaul transmission connection has the backhaul guaranteed bandwidth. Finally, a backhaul SSID is set to a first wireless network standard only mode by the network device to ensure that data transmission will not be interfered with by other network devices transmitting data according to a second wireless network standard in the backhaul network.

Classes IPC  ?

• H04W 28/08 - Équilibrage ou répartition des charges
• H04B 17/318 - Force du signal reçu
• H04W 76/11 - Attribution ou utilisation d'identifiants de connexion
• H04W 8/24 - Transfert des données du terminal
• H04W 88/14 - Dispositifs formant réseau fédérateur

Abrégé

A holder for antennas includes at least one circuit board, at least one carrier and at least one antenna. The at least one carrier, disposed to a lateral side of the at least one circuit board, has at least one honeycomb structure. The at least one antenna, disposed at the at least one carrier, is electrically connected with the at least one circuit board. The antenna, the carrier and the circuit board are formed as a modular structure beneficial to be assembled into or disassembled from the casing of the electronic device.

Classes IPC  ?

• H01Q 1/24 - SupportsMoyens de montage par association structurale avec d'autres équipements ou objets avec appareil récepteur
• H01Q 21/20 - Réseaux d'unités d'antennes, de même polarisation, excitées individuellement et espacées entre elles les unités étant espacées le long d'un trajet curviligne ou adjacent à celui-ci
• H01Q 21/28 - Combinaisons d'unités ou systèmes d'antennes sensiblement indépendants et n’interagissant pas entre eux

Abrégé

A repeater configured to be connected to a network is provided. The repeater includes an uplink wireless transmission interface, a downlink wireless transmission interface, and a processing unit. The uplink wireless transmission interface is configured to establish an external wireless connection with the network. The downlink wireless transmission interface is configured to perform data transmission with the uplink wireless transmission interface and has an external wireless transmission function. The processing unit is configured to turn off the external wireless transmission function of the downlink wireless transmission interface when the connection between the uplink wireless transmission interface and the network is disconnected.

Classes IPC  ?

• H04L 45/18 - Opérations sans boucle
• H04W 76/15 - Établissement de connexions à liens multiples sans fil
• H04W 76/14 - Établissement de la connexion en mode direct
• H04W 76/11 - Attribution ou utilisation d'identifiants de connexion
• H04B 7/155 - Stations terrestres
• H04W 40/10 - Sélection d'itinéraire ou de voie de communication, p. ex. routage basé sur l'énergie disponible ou le chemin le plus court sur la base des ressources nodales sans fil sur la base de la puissance ou de l'énergie disponible
• H04W 40/22 - Sélection d'itinéraire ou de voie de communication, p. ex. routage basé sur l'énergie disponible ou le chemin le plus court utilisant la retransmission sélective en vue d'atteindre une station émettrice-réceptrice de base [BTS Base Transceiver Station] ou un point d'accès
• H04W 52/02 - Dispositions d'économie de puissance
• H04W 52/46 - Commande de puissance d'émission [TPC Transmission power control] le TPC étant effectué dans des situations particulières dans des réseaux à bonds multiples, p. ex. des réseaux de retransmission sans fil

Abrégé

An antenna with pin header is provided, which may include a substrate, a feed point, a radiator and a metallic pin header. The feed point may be disposed on the substrate. The radiator may be printed on the substrate and connected to the feed point. The metallic pin header may penetrate through the radiator and the substrate. The metallic pin header may be connected to the feed point via the radiator, and the radiator and the metallic pin header may have a common feedline, whereby the metallic pin header can enhance the gain pattern, in the direction which the metallic pin header points in, of the radiator.

Classes IPC  ?

• H01Q 9/04 - Antennes résonnantes
• H04B 7/0413 - Systèmes MIMO
• H05K 1/16 - Circuits imprimés comprenant des composants électriques imprimés incorporés, p. ex. une résistance, un condensateur, une inductance imprimés

Abrégé

A high-isolation dual-band antenna is provided, which may be operated in a first frequency band and a second frequency band, and include a ground zone, two radiators and an isolation zone. The radiators may be disposed at the both sides of the ground zone respectively. The isolation zone may include a main body, a first-slot and two second-slots; the first-slot may be disposed at one end of the main body and the second-slots may be disposed at the both sides of the main body respectively. At least a portion of the first-slot and the second-slots may serve as the isolation section of the first frequency band, and at least a portion of each second-slot may serve as the isolation section of the second frequency band, such that the isolation section of the first frequency band may partially overlap the isolation section of the second frequency band.

Classes IPC  ?

• H01Q 21/28 - Combinaisons d'unités ou systèmes d'antennes sensiblement indépendants et n’interagissant pas entre eux
• H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids
• H01Q 5/50 - Dispositions d’alimentation ou d’adaptation pour un fonctionnement à large bande ou multibande
• H01Q 5/307 - Éléments rayonnants individuels ou couplés, chaque élément étant alimenté d’une façon non précisée

Abrégé

A network device, which can be disposed in a mesh network, and include a WPS button and a processing circuit. The WPS button may trigger a WPS connection process. The processing circuit may be connected to the WPS button. The processing circuit can determine whether the uplink connection of the network device exists; if the uplink connection of the network device does not exist, the processing circuit can implement an uplink connection process; if the uplink connection of the network device exists, the processing circuit can implement a downlink connection process.

Classes IPC  ?

• H04W 12/50 - Appariement sécurisé de dispositifs
• H04W 76/10 - Établissement de la connexion
• H04W 12/06 - Authentification
• H04W 48/16 - ExplorationTraitement d'informations sur les restrictions d'accès ou les accès
• H04W 84/18 - Réseaux auto-organisés, p. ex. réseaux ad hoc ou réseaux de détection
• H04W 84/12 - Réseaux locaux sans fil [WLAN Wireless Local Area Network]
• H04W 88/04 - Dispositifs terminaux adapté à la retransmission à destination ou en provenance d'un autre terminal ou utilisateur

Abrégé

A network device including an Ethernet transmission interface and a processing unit is provided. The Ethernet transmission interface is provided with at least one Ethernet transmission port. The processing unit is coupled to the Ethernet transmission interface and is configured to: in order to detect whether a packet looping exists, send out a dynamic host configuration protocol (DHCP) discover message through a linked Ethernet transmission port in response to linking one of the at least one Ethernet transmission port to a network and determine whether a DHCP offer message is received; determine whether to prohibit data transmission of the linked Ethernet transmission port according to whether the DHCP discover message returned through the packet looping is detected; classify the linked Ethernet transmission port as an uplink transmission port or a downlink transmission port according to whether the DHCP offer message is received.

Classes IPC  ?

• H04L 12/851 - Actions liées au type de trafic, p.ex. qualité de service ou priorité
• H04L 12/705 - Prévention de création de boucles de routage ou de blocages, p.ex. durée de vie du paquet [TTL] ou topologie de réseau type "spanning tree"
• H04L 29/12 - Dispositions, appareils, circuits ou systèmes non couverts par un seul des groupes caractérisés par le terminal de données
• H04L 12/28 - Réseaux de données à commutation caractérisés par la configuration des liaisons, p. ex. réseaux locaux [LAN Local Area Networks] ou réseaux étendus [WAN Wide Area Networks]
• H04L 12/46 - Interconnexion de réseaux
• H04L 12/24 - Dispositions pour la maintenance ou la gestion
• H04L 12/751 - Mise à jour ou découverte de la topologie
• H04L 12/721 - Procédures de routage, p.ex. routage par le chemin le plus court, routage par la source, routage à état de lien ou routage par vecteur de distance
• H04L 12/741 - Traitement de l'adressage d’en-tête pour le routage, p.ex. table de correspondance
• H04W 84/22 - Réseaux auto-organisés, p. ex. réseaux ad hoc ou réseaux de détection avec accès aux réseaux câblés
• H04L 12/18 - Dispositions pour la fourniture de services particuliers aux abonnés pour la diffusion ou les conférences

Abrégé

A dipole antenna is provided, which may include a substrate, a first radiator and a second radiator disposed thereon. The substrate may include a first metal layer and a second metal layer; the first metal layer may include a feed point connected to the signal wire of a coaxial cable; the second metal layer may include a ground point connected to the ground layer of the coaxial cable. The first radiator may include a first planar connection part and a first solid radiating part; the first planar connection part may be disposed on one end of the first solid radiating part and connected to the first metal layer. The second radiator may include a second planar connection part and a second solid radiating part; the second planar connection part may be disposed on one end of the second solid radiating part and connected to the second metal layer.

Classes IPC  ?

• H01Q 9/16 - Antennes résonnantes avec alimentation intermédiaire entre les extrémités de l'antenne, p. ex. dipôle alimenté par le centre
• H01Q 5/335 - Éléments rayonnants individuels ou couplés, chaque élément étant alimenté d’une façon non précisée utilisant des circuits ou des composants dont la réponse dépend de la fréquence, p. ex. des circuits bouchon ou des condensateurs au point d’alimentation, p. ex. aux fins d’adaptation d’impédance
• H01Q 9/28 - Éléments coniques, cylindriques, en cage, en ruban, en treillis ou éléments analogues ayant une surface de rayonnement étendueÉléments comportant deux surfaces coniques ayant le même axe et opposées par leurs sommets et alimentés par des lignes de transmission à deux conducteurs
• H01Q 5/10 - Antennes résonnantes
• H01Q 21/06 - Réseaux d'unités d'antennes, de même polarisation, excitées individuellement et espacées entre elles

Abrégé

An antenna structure including a substrate, a grounding layer, a first antenna layer, a second antenna layer, an inductance element and a capacitance element is provided. The substrate has a surface. The grounding layer is formed on the surface of the substrate. The first antenna layer includes a first radiating portion and a second radiating portion. The second antenna layer includes a third radiating portion and a fourth radiating portion. The third radiating portion is connected to the first radiating portion at a connection portion. The connection portion is separated from the grounding player, and the fourth radiating portion and the second radiating portion are disposed oppositely and separated from each other. The inductance element bridges the grounding layer and the connection portion. The capacitance element bridges the fourth radiating portion and the second radiating portion.

Classes IPC  ?

• H01Q 1/24 - SupportsMoyens de montage par association structurale avec d'autres équipements ou objets avec appareil récepteur
• H01Q 1/52 - Moyens pour réduire le couplage entre les antennesMoyens pour réduire le couplage entre une antenne et une autre structure
• H01Q 5/35 - Alimentation simultanée en plusieurs points
• H01Q 5/40 - Structures imbriquées ou entrelacéesDispositions combinées ou présentant un couplage électromagnétique, p. ex. comprenant plusieurs éléments rayonnants alimentés sans connexion commune
• H01Q 9/42 - Antennes résonnantes avec alimentation à l'extrémité d'un élément actif allongé, p. ex. unipôle avec éléments repliés, les parties repliées étant espacées l'une de l'autre d'une petite fraction de la longueur d'onde émise
• H01Q 21/28 - Combinaisons d'unités ou systèmes d'antennes sensiblement indépendants et n’interagissant pas entre eux
• H01Q 5/321 - Éléments rayonnants individuels ou couplés, chaque élément étant alimenté d’une façon non précisée utilisant des circuits ou des composants dont la réponse dépend de la fréquence, p. ex. des circuits bouchon ou des condensateurs situés dans un élément rayonnant ou entre des éléments rayonnants connectés
• H01Q 5/328 - Éléments rayonnants individuels ou couplés, chaque élément étant alimenté d’une façon non précisée utilisant des circuits ou des composants dont la réponse dépend de la fréquence, p. ex. des circuits bouchon ou des condensateurs situés entre un élément rayonnant et la mise à la terre

Abrégé

The disclosure is related to a method and a system for selecting a communication interface. The method is applicable to a local area network including multiple access points. A main access point is first selected. The main access point acquires every access point's information within a local area network. The information relates to the access points that are in an idle state or not performing a critical task. A target antenna can be selected for performing a specific function. For example, the target antenna can be used to scan for the channels specified in dynamic frequency selection. After that, the scan result may result in changing channels. Through the above mechanism, the resources in every AP within the LAN can be adequately used, and the performance of wireless communication can be effectively improved.

Classes IPC  ?

• H04W 36/06 - Resélection d'une ressource de communication au point d'accès serveur
• H04W 48/16 - ExplorationTraitement d'informations sur les restrictions d'accès ou les accès
• H04W 48/20 - Sélection d'un point d'accès
• H04W 72/04 - Affectation de ressources sans fil
• H04W 36/30 - La resélection étant déclenchée par des paramètres spécifiques par des données de mesure ou d’estimation de la qualité des liaisons
• H04L 12/26 - Dispositions de surveillance; Dispositions de test
• H04W 84/12 - Réseaux locaux sans fil [WLAN Wireless Local Area Network]
• H04W 88/08 - Dispositifs formant point d'accès

Abrégé

A dual-band antenna includes a substrate, a first antenna assembly, an isolation metal sheet, and a second antenna assembly. The first antenna assembly includes a first and a second planar inverted-F antennas, which are symmetric with each other and disposed on the first side of the substrate. The first planar inverted-F antenna includes a first radiation portion and a first ground portion. The second planar inverted-F antenna includes a second radiation portion and a second ground portion. The isolation metal sheet is coupled between the first ground portion and the second ground portion. The second antenna assembly includes a third and a fourth antennas, which are coupled to the first and the second ground portions, respectively, and are symmetric with each other and are disposed on the second side of the substrate. The first and the second antenna assemblies are operated at a first and a second frequencies, respectively.

Classes IPC  ?

• H01Q 1/24 - SupportsMoyens de montage par association structurale avec d'autres équipements ou objets avec appareil récepteur
• H01Q 9/04 - Antennes résonnantes
• H01Q 5/30 - Dispositions permettant un fonctionnement sur différentes gammes d’ondes
• H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids

Abrégé

The present invention discloses a method and an apparatus to automatically remove crosstalk, which can automatically determine and set the start frequency in the G.fast system without unnecessary manual operation to automatically remove crosstalk interference between VDSL and G.fast. The present invention allows the time required to complete the setting of the start frequency in the G.fast system corresponding to each port of a unit of DPU/DSLAM equipment and the related work therefor to be reduced to less than 2 minutes. Therefore, the installation time is greatly reduced, human errors are also reduced, and the installation can be done correctly by ordinary technicians, which is advantageous to the promotion of G.fast systems.

Classes IPC  ?

• H04B 15/00 - Suppression ou limitation du bruit ou des interférences
• H04N 11/02 - Systèmes de télévision en couleurs avec réduction de la largeur de bande
• H03D 1/00 - Démodulation d'oscillations modulées en amplitude
• H04J 1/12 - Dispositions pour réduire la diaphonie entre canaux
• H04B 3/32 - Réduction de la diaphonie, p. ex. par compensation
• H04L 12/28 - Réseaux de données à commutation caractérisés par la configuration des liaisons, p. ex. réseaux locaux [LAN Local Area Networks] ou réseaux étendus [WAN Wide Area Networks]
• H04B 3/487 - Tests des effets de diaphonie
• H04M 3/30 - Test de service automatique pour les lignes d'abonnés

Abrégé

An antenna structure is disclosed. The antenna structure includes a signal-feeding terminal; a first radiating conductor extending from the signal-feeding terminal along a first direction to include a first gradually widening path; a ground terminal configured to be separated from the signal-feeding terminal by a first gap; and a second radiating conductor extending from the ground terminal along a second direction perpendicular to the first direction to include a second gradually widening path.

Classes IPC  ?

• H01Q 1/38 - Forme structurale pour éléments rayonnants, p. ex. cône, spirale, parapluie formés par une couche conductrice sur un support isolant
• H01Q 9/28 - Éléments coniques, cylindriques, en cage, en ruban, en treillis ou éléments analogues ayant une surface de rayonnement étendueÉléments comportant deux surfaces coniques ayant le même axe et opposées par leurs sommets et alimentés par des lignes de transmission à deux conducteurs
• H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids
• H01Q 21/24 - Combinaisons d'unités d'antennes polarisées dans des directions différentes pour émettre ou recevoir des ondes polarisées circulairement ou elliptiquement ou des ondes polarisées linéairement dans n'importe quelle direction
• H01Q 9/26 - Antennes résonnantes avec alimentation intermédiaire entre les extrémités de l'antenne, p. ex. dipôle alimenté par le centre avec élément replié ou éléments repliés, les parties repliées étant espacées l'une de l'autre d'une petite fraction de la longueur d'onde émise

Abrégé

A dual-band antenna disposed on the both sides of a substrate, including: a substrate, a first radiator and a second radiator. The substrate includes a first surface and a second surface; a feeding point is disposed at the edge of the first surface which may have a penetration hole electrically connected the first surface to the second surface. The first radiator extends from the first direction of the feeding point to the edge of the substrate, bend at the first corner, continues to extend toward the edge of the substrate, bends again at the second corner and then extend toward the third corner along the edge of the substrate. The second radiator straightly extends toward the second direction of the feeding point and the second direction's projection on the first surface is vertical to the first direction.

Classes IPC  ?

• H01Q 1/38 - Forme structurale pour éléments rayonnants, p. ex. cône, spirale, parapluie formés par une couche conductrice sur un support isolant
• H01Q 9/42 - Antennes résonnantes avec alimentation à l'extrémité d'un élément actif allongé, p. ex. unipôle avec éléments repliés, les parties repliées étant espacées l'une de l'autre d'une petite fraction de la longueur d'onde émise
• H01Q 5/371 - Parcours de courants avec ramifications

Produits et services

Networking hardware and related software and operating system for communications over wireless and wired networks, namely network adapter, network hub, network switch, network modem, network access point, network router, network bridge, network gateway, optical communication device, power line communication device, mobile communication device, mobile hotspot device, network server, network interface terminal, personal digital assistants, hand-held computers and internet camera, all aforementioned goods not for the use in the field of marketing through any kind of electronic ways.

Produits et services

Wireless communications hardware and related software, namely network access point, network router, network bridge, network gateway, mobile communication device, mobile hotspot device, mobile small cell, personal digital assistants, and hand-held computers; computer software for wireless communication devices; computer operating system software for wireless communication devices.

Abrégé

An antenna is provided. The antenna includes a substrate having a first end and a second end opposite to the first end, wherein a direction from the first end to the second end is an extending direction of the antenna; a radiating portion; a feed-in conductor; and a ground portion electrically connected to the radiating portion, coupled to the feed-in conductor, disposed on the substrate from the first end along the extending direction, and including a main ground conductor; and a high frequency band bandwidth adjusting conductor extended from the main ground conductor along the extending direction.

Classes IPC  ?

• H01Q 5/307 - Éléments rayonnants individuels ou couplés, chaque élément étant alimenté d’une façon non précisée
• H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids
• H01Q 5/378 - Combinaison d’éléments alimentés et d’éléments passifs
• H01Q 1/38 - Forme structurale pour éléments rayonnants, p. ex. cône, spirale, parapluie formés par une couche conductrice sur un support isolant
• H01Q 9/42 - Antennes résonnantes avec alimentation à l'extrémité d'un élément actif allongé, p. ex. unipôle avec éléments repliés, les parties repliées étant espacées l'une de l'autre d'une petite fraction de la longueur d'onde émise
• H01Q 1/24 - SupportsMoyens de montage par association structurale avec d'autres équipements ou objets avec appareil récepteur
• H01Q 1/08 - Moyens pour replier tout ou partie des antennes

Abrégé

An antenna structure comprising a substrate and an antenna is provided. The substrate comprises an upper surface and an under surface. The antenna comprises a first metal pattern and a second metal pattern. The first metal pattern is disposed on the upper surface. The first metal pattern comprises a feeding portion and a transmission line connected to the feeding portion. The second metal pattern is disposed on the under surface, and comprises a first parasitic grounding arm, a second parasitic grounding arm, a connecting arm, a grounding plane and a grounding strip. The connecting arm has a parasitic slot, and connects the first parasitic grounding arm and the second parasitic grounding arm. The grounding strip connects the connecting arm and the grounding plane.

Classes IPC  ?

• H01Q 1/48 - Moyens de mise à la terreÉcrans de terreContrepoids
• H01Q 1/24 - SupportsMoyens de montage par association structurale avec d'autres équipements ou objets avec appareil récepteur
• H01Q 9/36 - Disposition verticale de l'élément avec charge au sommet
• H01Q 5/392 - Combinaison d’éléments alimentés et d’éléments passifs les éléments passifs étant bibandes ou multibandes

Abrégé

A cooperative apparatus and a resource block allocation method thereof for use in a wireless network are provided. The wireless network comprises a plurality of femtocells. The cooperative apparatus groups the femtocells based on signal interferences between the femtocells. The femtocells with higher signal interferences are joined to the same femtocell group. The cooperative apparatus averagely allocates resource blocks to the femtocells in the same femtocell group, and randomly allocates resource blocks to different femtocell groups.

Classes IPC  ?

• H04W 72/00 - Gestion des ressources locales

Produits et services

Computer hardware; computer programs; computer operating systems; data processors; electrical circuit boards; printed circuit boards; electrical circuits; printed circuits; digital broadcasting systems; digital television systems; communication systems; communication operating programs; communication modems; communication routing apparatus; communications cables; communication networks; communications electronics for computers; communication servers; optical communication apparatus; wireless communication apparatus; power line communication apparatus; telephone apparatus, namely, intercoms. Assembling, maintaining & repairing services for computer hardware; Assembling, maintaining and repairing of communications hardware; Installing of communications networks. Designing & developing services for computer; Designing & developing services for communication systems; Assembling, maintaining & repairing services for computer software; Assembling, maintaining and repairing of communications software.

Abrégé

A communication device adopted for a multi-input multi-output orthogonal frequency division multiplexing (MIMO-OFDM) system and a method thereof are provided. The MIMO-OFDM system comprises the communication device and a corresponding communication device, and they communicate with each other. The communication device comprises a transceiving module, a singular value decomposition (SVD) operation module, and an interpolation operation module. The transceiving module receives a channel state information (CSI) from the corresponding communication device, wherein the CSI comprises CSIs of a plurality of selected subcarriers. For each of the selected subcarriers, the SVD module performs an SVD decomposition operation on the channel matrix representing the CSI of the selected subcarrier to obtain a decomposed result, wherein the decomposed result comprises a beamforming matrix, an SVD matrix, and a decoding matrix. The interpolation operation module performs interpolations on the beamforming matrices of the selected subcarriers to derive beamforming matrices of the unselected subcarriers. The interpolation operation module performs interpolations on the decoding matrixes of the selected subcarriers to derive obtain decoding matrices of the unselected subcarriers.

Classes IPC  ?

• H04B 7/02 - Systèmes de diversitéSystèmes à plusieurs antennes, c.-à-d. émission ou réception utilisant plusieurs antennes

Abrégé

A mobile communication method includes the following steps: several first base stations and at least one second base station are provided. Wherein, each of the first base stations can cover a smaller area than the second base station can. A registration signal is received from a mobile communication device. If the registration signal is received through one of the first base stations, service is provided to the mobile communication device through the first base station receiving the registration signal, and a first base station list, which includes information of the first base stations, is transmitted to the mobile communication device. The mobile communication device measures signal strength of the first base stations according to the first base station list. The mobile communication device transmits another registration signal to the first base station with the strongest measured signal strength.

Classes IPC  ?

• H04W 36/00 - Dispositions pour le transfert ou la resélection
• H04W 4/00 - Services spécialement adaptés aux réseaux de télécommunications sans filLeurs installations

Abrégé

A base station, a mobile station and a communication method thereof are provided. The base station and the mobile station are adapted for use in a wireless network. The wireless network comprises the base station and the mobile station. The mobile station connects with the base station via a physical channel. The physical channel comprises a plurality of resource units. Each resource unit comprises a sub-block. The sub-block comprises a sequence. The mobile station communicates with the base station with the sequence during the sub-block bases on a mapping relation.

Classes IPC  ?

• H04W 4/00 - Services spécialement adaptés aux réseaux de télécommunications sans filLeurs installations

Abrégé

A base station (BS), a subordinate station (SS) and emergency information transmission methods thereof are provided. The SS is in a power-saving state. The BS shall allocate an emergency alert indicator and emergency information in a transmission channel. The SS in the power-saving state receives the emergency information according to the emergency alert indicator and proceeds with a handshake protocol with the BS to establish an emergency service flow between the BS and the SS.

Classes IPC  ?

• H04M 11/04 - Systèmes de communication téléphonique spécialement adaptés pour être combinés avec d'autres systèmes électriques avec systèmes d’alarme, p. ex. systèmes d’alarme d'incendie, de police ou systèmes antivol

Abrégé

A base station, a mobile apparatus, and a communication method thereof for multicast and broadcast service (MBS) are provided. The base station and the mobile apparatus belong to an MBS zone. The base station sets an indicator in a control channel allocation of a frame. The indicator is related to a cell-specific MBS configuration of the base station. The control channel allocation is an allocation that the mobile apparatus has to read when it is in power-saving mode and when it has to receive MBS data. The MBS data is related to the MBS zone. The mobile apparatus reads the indicator in power-saving mode and can derive the cell-specific MBS configuration according to the indicator. The mobile apparatus does not have to search the whole frame to derive the cell-specific MBS configuration.

Classes IPC  ?

• H04H 20/71 - Systèmes sans fil

Abrégé

A mobile device, base stations, a backhaul network device for a wireless network system, and a method and a computer program storage product for the mobile device are provided. Each of the base stations is connected to the backhaul network device via a wired connection. The mobile device selects a primary base station and a backup base station from the base stations according to base station information of each base station. The mobile device performs a data transmission procedure with the primary base station during an available interval of a low-duty mode to communicate with the backhaul network device via the primary base station, and performs a connection keeping procedure with the backup base station during an unavailable interval of the low-duty mode. While the data transmission procedure fails, the mobile device performs a data transmission recovery procedure with the backup base station immediately so as to continuously communicate with the backhaul network device via the backup base station.

Classes IPC  ?

• H04W 4/00 - Services spécialement adaptés aux réseaux de télécommunications sans filLeurs installations

Abrégé

A signal transmission apparatus, a transmission method and a computer storage medium thereof are provided. The signal transmission apparatus may generate reference signals which are antipodal to each other and transmit the reference signals by subcarriers which are adjacent to each other. Thereby, the communication channel of the wireless network may be estimated accurately to improve the reliability of the following signal transmission.

Classes IPC  ?

• H04L 27/00 - Systèmes à porteuse modulée

Abrégé

A method for operating synchronous HARQ between a transmitting station and a receiving station in a TDD communication system, includes configuring a plurality of HARQ processes at the transmitting station, and transmitting a data burst in a first subframe to the receiving station via one of the plurality of HARQ processes and using a frame structure including a plurality of regions of subframes. The method also includes receiving a second subframe transmitted from the receiving station and containing a HARQ feedback indicative of whether the data burst was correctly received at the receiving station. Further, the method includes determining whether the HARQ feedback is an acknowledgement (ACK) or a negative acknowledgement (NACK), and retransmitting, via the one of the plurality of HARQ processes, the data burst in a third subframe to the receiving station if it is determined that the HARQ feedback is a NACK. A total number of plurality of HARQ processes is determined based on a total number of uplink subframes between the first subframe and the third subframe.

Classes IPC  ?

• H04L 1/16 - Dispositions pour détecter ou empêcher les erreurs dans l'information reçue en utilisant un canal de retour dans lesquelles le canal de retour transporte des signaux de contrôle, p. ex. répétition de signaux de demande

Abrégé

The present invention relates to a method for automatically re-connecting customer premises equipment (CPE) web user interfaces (UIs), capable of continuously sending a login request to a HTTP server to reduce the time for the user to wait, the method comprising: inserting a frame into a web page in a system to be re-connected and logged in; requesting a HTTP server to send a new web page through the frame after a customer premises equipment (CPE) completes software update and receives a response requesting the system to reboot; issuing a re-login request if the new web page is received, indicating the HTTP server has been started up and a new connection is made; and logging in the system.

Classes IPC  ?

• G06F 11/00 - Détection d'erreursCorrection d'erreursContrôle de fonctionnement
• G06F 15/16 - Associations de plusieurs calculateurs numériques comportant chacun au moins une unité arithmétique, une unité programme et un registre, p. ex. pour le traitement simultané de plusieurs programmes
• G06F 15/173 - Communication entre processeurs utilisant un réseau d'interconnexion, p. ex. matriciel, de réarrangement, pyramidal, en étoile ou ramifié
• G06F 3/00 - Dispositions d'entrée pour le transfert de données destinées à être traitées sous une forme maniable par le calculateurDispositions de sortie pour le transfert de données de l'unité de traitement à l'unité de sortie, p. ex. dispositions d'interface
• G06F 3/048 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI]
• H04L 12/28 - Réseaux de données à commutation caractérisés par la configuration des liaisons, p. ex. réseaux locaux [LAN Local Area Networks] ou réseaux étendus [WAN Wide Area Networks]
• H04L 5/16 - Systèmes semi-duplexCommutation duplex-simplexTransmission de signaux de rupture
• G05B 15/00 - Systèmes commandés par un calculateur
• G06Q 30/00 - Commerce

Abrégé

A method of operating synchronous Hybrid Automatic Repeat Request (HARQ) between a transmitting station and a receiving station in a Time-Division Duplex (TDD) communication system includes configuring, at the transmitting station, a plurality of HARQ processes; transmitting data packets to the receiving station using the plurality of HARQ processes, wherein the data packets do not include HARQ process identification information; receiving, from the receiving station, a plurality of HARQ feedback packets indicative of whether the data packets were correctly received at the receiving station, wherein the plurality of HARQ feedback packets do not include HARQ process identification information and wherein the plurality of HARQ feedback packets are received in a downlink slot; and mapping, by the transmitting station, the plurality of HARQ feedback packets to the plurality of HARQ processes.

Classes IPC  ?

• H04J 3/00 - Systèmes multiplex à division de temps
• H04B 7/00 - Systèmes de transmission radio, c.-à-d. utilisant un champ de rayonnement

Abrégé

A method and apparatus for performing resource allocation in a communication system is provided. The method includes receiving a data frame including encapsulated data and a transmission opportunity, the data frame being divided into sub-frames which include primary resource blocks that are divided into secondary resource blocks storing the encapsulated data or the transmission opportunity, deconstructing the data frame to retrieve a portion of the encapsulated data or the transmission opportunity by determining a location of one of the sub-frames and one of the secondary resource block that included the portion of the encapsulated data or the transmission opportunity, wherein the location of the one secondary resource block is determined based on the inner boundaries.

Classes IPC  ?

• H04J 1/00 - Systèmes multiplex à division de fréquence

Abrégé

Embedded system with web-based user interface, firmware structure thereof, and method for providing information thereof are provided. The firmware of the embedded system includes an execution part and a presentation part, which are separated, wherein the execution part includes a web service program and a program interface while the presentation part includes a web page which includes a request for dynamic content associated with the program interface so as to obtain corresponding dynamic content. When the system takes the presentation part as the static content of its web-based user interface, the web service program, in response to a static content request, reads the web page from the non-volatile memory and outputs it to a device, and in response to the dynamic content request, invokes the program interface to obtain the corresponding dynamic content and output it to the device.

Classes IPC  ?

• G06F 17/00 - Équipement ou méthodes de traitement de données ou de calcul numérique, spécialement adaptés à des fonctions spécifiques
• G06F 17/20 - Manipulation de données en langage naturel
• G06F 9/50 - Allocation de ressources, p. ex. de l'unité centrale de traitement [UCT]
• H04L 29/08 - Procédure de commande de la transmission, p.ex. procédure de commande du niveau de la liaison

Abrégé

A key recognition method and a key recognition system are applied to a wireless bridging apparatus and a terminal apparatus with a wireless communication function. When a user uses the wireless bridging apparatus at a first time, the user cannot connect the wireless bridging apparatus to a wireless network through the terminal apparatus until key verification between the terminal apparatus and the wireless bridging apparatus has been conducted and passed. The key recognition method includes the steps of: transmitting, by the wireless bridging apparatus, an original code to the terminal apparatus; encoding, by the terminal apparatus, the original code to obtain a transformed code; encoding, by the terminal apparatus, the original code and the transformed code to obtain a recognition code; and transmitting, by the terminal apparatus, the recognition code to the wireless bridging apparatus for verification and communication establishment.

Classes IPC  ?

• H04Q 7/00 -

Abrégé

The present invention discloses a method for determining the working status of a wireless network communication device. The method includes determining the probe request or broadcast packet or any wireless packet with its destination address equal to this AP address, and then determining whether extending the time interval of signal transmission based on the detection result. Next, when the device does not receive the probe requests or broadcast packet or any wireless packet with its destination address equal to this AP address within the first predetermined interval, the wireless network communication device will switch to the idle mode. Further, the step of the present invention includes determining whether awakening or shutdown the wireless network communication device based on the result of the detection of the probe request or broadcast packet or any wireless packet with its destination address equal to this AP address within the second predetermined interval.

Classes IPC  ?

• H04W 24/00 - Dispositions de supervision, de contrôle ou de test

Produits et services

Personal computer memory cards; universal serial bus cards; gateways; routers; modems; peripheral component interconnects; compact flash cards; media nodes, namely, videos, audios, receivers, blasters; projectors; speakers; computer storages; access points.

Produits et services

Personal computer memory cards; universal serial bus cards; computer network routers; modems; computer peripheral component interconnects; compact flash memory cards; media nodes, namely, computer hardware in the nature of video and audio monitors and sound cards; liquid crystal display (LCD) projectors; audio speakers; computer storages, namely, blank discs for computers; LAN (local area network) access points for connecting network computer users to transmit data over the public Internet; and all the foregoing goods not being comprised of computer software products
