A dispersing unit for dispersing a feed material in a dispersant, including a stationary dispersing basket, the lateral surface of which has outlet openings and one end of which is preferably at least partly closed and into which a shaft stub of a drive shaft protrudes, wherein, within the dispersing basket, the shaft stub bears a dispersing disk, which rotates during operation and thereby sucks feed-material-laden dispersant into the region between the dispersing disk and the closed end of the dispersing basket and discharges the feed-material-laden dispersant from said region largely via the outlet openings in the lateral surface of the dispersing basket
B01F 27/1152 - Agitateurs caractérisés par la configuration des agitateurs comprenant des disques ou des éléments en forme de disque essentiellement perpendiculaires à l'axe de l'arbre de l'agitateur avec des éléments séparés autres que des disques fixés sur les disques, p. ex. des aubes fixées sur les disques
B01F 27/2123 - Arbres comportant à la fois des moyens de brassage et des moyens d'alimentation ou d'évacuation
B01F 27/271 - Mélangeurs à système stator-rotor, p. ex. avec des dents ou des cylindres s’engrenant les uns dans les autres ou ayant des orifices avec des moyens pour déplacer les matières à mélanger radialement entre les surfaces du rotor et du stator
2.
Separator Wheel with Hybrid Separator Wheel Vanes for Wear Protection Purposes
A separator wheel with hybrid separator wheel vanes, which each consist of at least one vane base body, the radially outward area of which is provided at least on the side, which leads during operation as intended with at least one plating strip made of a wear protection material, which differs from the material of the vane carrier, ideally a carbide material or a ceramic material, which is wherein the at least one plating strip has at least one, preferably several positive-locking elements, which each engages or engage with a corresponding positive-locking element of the vane base body.
B02C 13/18 - Désagrégation par appareils à batteurs rotatifs à arbre du rotor vertical, p. ex. combinés avec des dispositifs de tamisage à batteurs fixés rigidement sur le rotor
A device for processing a product mass, including a container for receiving the product mass, at least one product mass processing tool in the container, which is provided to act on the product mass, and at least one sensor means having a dielectric sensor, wherein the sensor means is arranged and formed in such a way that dielectric properties of the product mass can be detected continuously or at least temporarily by means of the dielectric sensor in an environment of the dielectric sensor. The invention further relates to a method for processing a product mass, in particular by means of a device of this type.
An agitator mill including a milling chamber and a milling rotor, which forms a circumferential boundary wall of the milling chamber during operation. The milling elements are made to execute a milling movement in the milling chamber by the milling rotor. There is also a slit tube for removing the milled material while separating out the milling elements.
An agitator mill including a grinding chamber containing grinding bodies and an agitator shaft, which revolves therein about a horizontal agitator shaft axis, which supports several grinding members, which are connected to it in a rotationally fixed manner and which are spaced apart from one another in the direction of the horizontal axis, preferably in the shape of grinding disks, which move the grinding bodies, whereby, on the outlet side, the agitator shaft has a basket, which is preferably studded with grinding members on its outer circumference and which overlaps the split tube-supporting outlet, whereby a separation chamber is formed between the inner surface of the basket and the split tube-supporting outlet, whereby the basket has slits for returning grinding bodies from the separation chamber into the grinding chamber, which slits lead into the free front surface of the basket, which faces away from the grinding chamber.
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
Agitator mill including a grinding chamber containing grinding bodies and an agitator shaft, which revolves therein about a horizontal agitator shaft axis, which supports several grinding members, which are connected to it in a rotationally fixed manner and which are spaced apart from one another in the direction of the horizontal axis, preferably in the shape of grinding disks, which move the grinding bodies, whereby, on the outlet side, the agitator shaft has a basket, which is preferably studded with grinding members on its outer circumference and which overlaps the split tube-supporting outlet, characterized in that in the region of its free end, the basket has a section with an enlarged outer diameter.
The invention relates to an agitator mill (1), in particular in the form of a full-volume disc mill, having a grinding container (2) and an agitator shaft (3) which rotates therein about a horizontal axis (6) and supports a plurality of grinding discs (4) which are connected to this shaft for conjoint rotation and are spaced apart from one another in the direction of the horizontal axis (6), the grinding discs (4) each having slots or openings, characterised in that, in the region between two grinding discs (4), the agitator mill (1) has drivers which rotate synchronously with the grinding discs (4) during grinding and which impart a movement component in the radially outwards direction to at least some of the grinding bodies coming into contact with these discs, by directly moving these grinding bodies as they rotate, preferably in the radial direction.
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
An agitator mill, in particular an agitator bead mill having a mill housing, in which an agitator shaft, preferably bearing agitator elements, circulates in such a way that a grinding chamber is configured between the agitator shaft and the mill housing, and into the chamber the grist is fed, transported by a fluid carrier substance, as a rule in the form of a suspension, wherein the grinding chamber is partially filled with grinding media, which are set in motion by the circulating agitator shaft and thereby the grist, carried through the grinding chamber by a fluid carrier substance, is crushed, wherein the grist, transported by the fluid carrier substance, is discharged together with the carrier substance through a sieve, which retains grinding media that arrive as far as the area of the sieve, wherein the sieve consists of several sieve elements arranged one after the other along the longitudinal axis of the agitator mill, the sieve elements being penetrated in parallel manner, with their surfaces flowing from the grinding chamber, and extend diagonally or radially to the axis, around which the agitator shaft circulates.
A method for preparing a pumpable batch composition of stone fruit and/or nut fruit seeds, in particular nuts, almonds or nut and almond mixtures, with the following steps: Breaking open of the already pitted or stoned stone-fruit or nut-fruit seeds first takes place by pre-crushing. A hot air and/or vacuum exposure of the composition arising from the pre-crushing then takes place for the purpose of breaking open its cells. This is followed by a usually single-stage, optionally also multi-stage, further grinding of the composition arising from the pre-crushing and the hot air or vacuum exposure to form a pumpable batch composition.
A23L 25/00 - Aliments contenant principalement des noix ou des grainesLeur préparation ou leur traitement
A23N 5/00 - Machines à écaler, cerner ou casser les noix
A23N 12/08 - Machines à nettoyer, blanchir, sécher, griller ou torréfier les fruits ou les légumes, p. ex. le café, le cacao, les noix à sécher, griller ou torréfier
A23L 3/48 - Séchage en couche mince, au tambour ou au rouleau
01 - Produits chimiques destinés à l'industrie, aux sciences ainsi qu'à l'agriculture
07 - Machines et machines-outils
09 - Appareils et instruments scientifiques et électriques
Produits et services
Chemicals for use in the manufacture of battery and
accumulator. Equipment for grinding and dispersing, preferably agitator
bead mills, dissolvers, jet mills. Batteries, accumulators.
A high pressure homogenizer for flowable substances charged with particles, having a high pressure chamber and a homogenizer unit that is located fluidically downstream thereof and, by swirling, expands the fluid to be homogenized which has previously been brought to a pressure of more than 500 bar in the high pressure chamber, and a plunger pump associated with the homogenizer unit, the plunger of which plunger pump pressurizes the high pressure chamber, wherein the high pressure homogenizer has a low pressure chamber which surrounds the plunger shaft to cool the plunger and which has an operating pressure of PN≤25 bar, wherein the low pressure chamber and the high pressure chamber are separated from each other by a seal which is penetrated by the plunger, the seal being a throttle gap which is formed between the plunger shaft and a bushing that does not contact the plunger shaft, the ratio S/L of the length to the radial annular gap height of the throttle gap being ≤0.0015.
F04B 15/02 - Pompes adaptées pour travailler avec des fluides particuliers, p. ex. grâce à l'emploi de matériaux spécifiés pour la pompe elle-même ou certaines de ses parties les fluides étant visqueux ou non homogènes
F04B 53/08 - RefroidissementChauffagePrévention du gel
01 - Produits chimiques destinés à l'industrie, aux sciences ainsi qu'à l'agriculture
07 - Machines et machines-outils
09 - Appareils et instruments scientifiques et électriques
Produits et services
Chemicals for use in the manufacture of battery and accumulator Equipment for grinding and dispersing, namely agitator bead milling machines, dissolving machines for chemical processing, jet milling machines Batteries, accumulators
The invention relates to a dispersing unit (1) for dispersing a feed material in a dispersant, comprising a stationary dispersing basket (2), the lateral surface of which has outlet openings (3) and one end of which is preferably at least partly closed and into which a shaft stub of a drive shaft (4) protrudes, wherein, within the dispersing basket (2), the shaft stub bears a dispersing disk (5), which rotates during operation and thereby sucks feed-material-laden dispersant into the region between the dispersing disk and the closed end of the dispersing basket (2) and discharges the feed-material-laden dispersant from said region largely via the outlet openings (3) in the lateral surface of the dispersing basket (2).
B01F 23/53 - Mélange de liquides avec des solides en utilisant des agitateurs entraînés
B01F 27/1151 - Agitateurs caractérisés par la configuration des agitateurs comprenant des disques ou des éléments en forme de disque essentiellement perpendiculaires à l'axe de l'arbre de l'agitateur avec des trous à la surface
B01F 27/81 - Mélangeurs à agitateurs tournant dans des récipients fixesPétrins avec des agitateurs tournant autour d'un axe sensiblement vertical les agitateurs ayant des entrées de flux axiales centrales et des sorties de flux sensiblement radiales
B01F 27/93 - Mélangeurs à agitateurs tournant dans des récipients fixesPétrins avec des agitateurs tournant autour d'un axe sensiblement vertical avec des disques rotatifs
The invention relates to an agitating mill (1), in particular to an stirred ball mill, having a grinding container (2) in which an agitator shaft (3) which preferably bears agitating elements (8) revolves in such a way that a grinding space (7) is formed between the agitator shaft (3) and the grinding container (2), into which grinding space the grinding stock, which is conveyed via a free-flowing carrier substance, usually in the form of a suspension, is fed, wherein the grinding space (7) is in part filled with grinding elements which are set into motion by the revolving agitator shaft (3), and the grinding stock which is carried via a free-flowing carrier substance through the grinding space (7) is comminuted as a result, wherein the grinding stock conveyed via the free-flowing carrier substance is discharged, together with the carrier substance, through a screen (4) which holds back grinding elements reaching the area of the screen (4), characterised in that the screen (4) consists of a plurality of screen elements (12) which are arranged one behind the other along the longitudinal axis of the stirred ball mill (1), through which screen elements a flow passes in parallel, and the large areas of which screen elements, against which large areas the flow flows from the grinding space (7), extend obliquely or radially with respect to the axis about which the agitator shaft (3) revolves.
A centrifugal classifier including a classifier housing having at least one coarse material outlet and a classifier wheel, revolving in the classifier housing. The classifier wheel is comprised of a classifier drum and a classifier wheel shaft forming the axis of rotation of the classifier drum. A guide member is arranged near the coarse material outlet, at a set distance from the inner jacket surface of the classifier housing section surrounding the classifier drum. The guide member is configured such that classifying material flowing along the inner jacket surface at a radial distance less than or equal to the set distance circumvents the guide member and is discharged into the coarse material outlet and classifying material flowing along the inner jacket surface at a radial distance greater than the set distance is deflected in a radially inward direction toward the classifying drum.
B07B 11/06 - Dispositifs d'alimentation ou de déchargement
B07B 7/08 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la force centrifuge
B07B 7/083 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la force centrifuge produite par la rotation d'ailettes, de disques, de tambours ou de brosses
F04B 53/08 - RefroidissementChauffagePrévention du gel
F04B 53/16 - Carcasses d'enveloppeCylindresChemises de cylindre ou culassesConnexions des tubulures pour fluide
F04B 53/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes ou ou présentant un intérêt autre que celui visé par ces groupes
F04B 53/02 - Garnissage de l'espace libre entre des cylindres et des pistons
F04B 15/02 - Pompes adaptées pour travailler avec des fluides particuliers, p. ex. grâce à l'emploi de matériaux spécifiés pour la pompe elle-même ou certaines de ses parties les fluides étant visqueux ou non homogènes
B01F 5/06 - Mélangeurs dans lesquels les composants du mélange sont pressés ensemble au travers de fentes, d'orifices, ou de tamis
A temperature-controlled component and a method for producing a temperature-controlled component, the temperature-controlled component includes a base body including at least one hollow space, through which a temperature control medium can flow. It is provided that in a first region, a first wall thickness is formed between an inner jacket surface of the hollow space and a jacket surface of the base body, and that in a second region, a second wall thickness is formed between an inner jacket surface of the hollow space and a jacket surface of the base body. The second region is a wear region of the component, and the second wall thickness is larger than the first wall thickness in this wear region.
F24H 9/06 - Disposition des fixations ou des supports
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B33Y 80/00 - Produits obtenus par fabrication additive
B33Y 50/02 - Acquisition ou traitement de données pour la fabrication additive pour la commande ou la régulation de procédés de fabrication additive
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Mechanical, industrial stirrers; machines and machinery for
mixing, conching, dispersing and grinding of food; chocolate
and compound machines as well as related parts; machines and
machinery for the food industry as well as for the
production of food; machines and machinery for the
manufacture of confectionery. Processing of foodstuff, namely, stirring, mixing, conching
and grinding of food; processing of foodstuff, namely,
stirring, mixing, conching and grinding of ingredients of
confectionery on behalf of others; services in the field of
processing substances and mixtures of substances, in
particular for the food industry; services in the field of
processing food, in particular for confectionery.
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
Produits et services
Mechanical, industrial stirrers in the nature of industrial mixers for industrial and commercial applications; machines and machinery for mixing, conching, dispersing and grinding of food; chocolate and compound machines as well as related parts in the nature of industrial mixers for mixing chocolate, cylinders for mills for use in the manufacture of chocolate, machines for compounding chocolate to conform to a shape of a mold, and machines for dissolving, grinding, classifying, dispersing, and homogenizing chocolate; machines and machinery for the food industry as well as for the production of food, namely, packaging machines for food, food chopping machines for commercial use, and machines for milling, mixing, dissolving, grinding, classifying, dispersing, and homogenizing food; machines and machinery for the manufacture of confectionery Processing of foodstuff, namely, stirring, mixing, conching and grinding of food; processing of foodstuff, namely, stirring, mixing, conching and grinding of ingredients of confectionery on behalf of others; food processing services in the nature of processing substances and mixtures of substances, in particular for the food industry; food processing services in the nature of processing food, in particular for confectionery
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Manufacturing plants and machines for the production of raw
material and components for electric batteries; machines and
equipment for grinding, dispersing, emulsifying and
homogenizing, as well as related components; agitator ball
mills and related components; dispersers and related
components; homogenizers [machines for industrial purposes]
and components therefor, pumps; transporting devices
(conveyors); manufacturing plants consisting of the
aforementioned goods as well as components and accessories
for all aforementioned goods, as far as included in this
class. Repairs of manufacturing plants and machines for the
production of raw material and components for electric
batteries; repairs of agitator bead mills, dispersers,
homogenizers and pumps.
A stirring mill, including a horizontally arranged milling vessel and a stirring shaft which is arranged therein so that it can be rotationally driven are provided. The stirring shaft has a first stirring shaft section adjacent to an inlet for material to be ground, which has a smaller diameter D24, and a second stirring shaft section adjacent to an outlet for material to be ground, which has a larger diameter D25 and in which a separating device is formed. Bypass channels leading into the separating device are formed in the first stirring shaft section.
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Manufacturing plants comprising agitator mills, mixing machines, dissolving machines, dispersing machines, emulsifying machines, and homogenizing machines and machines for the treatment of raw material in the nature of lithium, nickel, cobalt, aluminum, iron, manganese, and oxides, phosphates, and compounds thereof, as well as graphite, carbon, carbon nano tubes (CNT), graphene, sodium, sulphur, silicon, binders, namely, PVDF, CMC, and SBR, and solvents, namely, NMP and DI water used as and components for electric batteries; machines for grinding, dispersing, emulsifying and homogenizing lithium, nickel, cobalt, aluminum, iron, manganese, and oxides, phosphates, and compounds thereof, as well as graphite, carbon, carbon nano tubes (CNT), graphene, sodium, sulphur, silicon, binders, namely, PVDF, CMC, and SBR, and solvents, namely, NMP and DI water used as components for electric batteries; agitator ball mills; machines for use to disperse raw materials in the nature of lithium, nickel, cobalt, aluminum, iron, manganese, and oxides, phosphates, and compounds thereof, as well as graphite, carbon, carbon nano tubes (CNT), graphene, sodium, sulphur, silicon, binders, namely, PVDF, CMC, and SBR, and solvents, namely, NMP and DI water used as components for electric batteries; homogenizers in the nature of machines for industrial purposes; pneumatic pumps; transporting devices in the nature of belt conveyors and roller conveyors Repairs of manufacturing plants and machines for the production of raw material and components for electric batteries; repairs of agitator bead mills, dispersers, homogenizers and pumps
23.
Centrifugal separator comprising special separator wheel
A centrifugal separator including a separator housing and a separator wheel revolving in the housing. The separator housing has an inlet for material, a coarse material outlet, and a fine material outlet. The wheel is formed by a drum and a wheel shaft, which supports the drum and rotates around a horizontal axis. The circumferential jacket surface of the drum is interrupted such that it sets the material to be separated, which hits the drum on the outer jacket side, into rotation during operation and the separation air flows through it in the radially inwards direction. The fine material outlet is arranged on the end of the drum and fine material is discharged from the interior of the drum into the fine material outlet via the free front face of the drum. The wheel shaft consists of two parts, which are not directly connected to one another in a supporting manner.
B07B 11/06 - Dispositifs d'alimentation ou de déchargement
B07B 7/08 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la force centrifuge
B07B 7/083 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la force centrifuge produite par la rotation d'ailettes, de disques, de tambours ou de brosses
A method for the production of a product mass, in particular a chocolate mass, as a basic mass for foodstuffs, with a plurality of ingredients and a recipe total fat content, using a conching device with a conching container, which can be opened and closed hermetically sealed. The method includes filling of the conching container with a low-fat partial mass, which includes at least a part of the plurality of ingredients and has a fat content which is smaller than the recipe total fat content. Furthermore, the method includes a first conching of the low-fat partial mass with a closed conching container and second conching of the low-fat partial mass with an opened conching container with simultaneous active drying of the low-fat partial mass. Before the second conching, the method includes an addition of a further part of the plurality of ingredients to the low-fat partial mass until a fat content is reached in the range from approximately 11% to approximately 17%. The method also includes liquefaction of the partial mass while adding the rest of the plurality of ingredients and mixing the latter with the low-fat partial mass to form a total mass representing the product mass, which at least essentially includes the recipe total fat content.
An agitator ball mill including an in particular horizontal grinding container, which has a first end area having a grinding material inlet and a second end area having a grinding material outlet, and a method for operating an agitator ball mill. The agitator ball mill includes a shaft, which can be rotated in the grinding container or in the grinding chamber, respectively, by means of a drive unit and which is formed as agitator shaft at least in sections and which is equipped with agitator elements, as well as a separating device. The separating device includes a classifier rotor, which is arranged on the agitator shaft axially spaced apart from the grinding material outlet and has a rotatable rotor cage, as well as a screen unit, which is arranged within the rotor cage and which is fastened to the classifier rotor.
B02C 17/02 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets à cuves perforées
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B07B 7/083 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la force centrifuge produite par la rotation d'ailettes, de disques, de tambours ou de brosses
26.
Conching device and method for conching a product mass
A conching apparatus having: a container, which forms an accommodating space for a product mass, a shaft, which is accommodated, at least in part, in the container and is designed to rotate about its longitudinal axis, and at least one conching tool, which is coupled to the shaft for joint rotation therewith, the conching tool therefore, during conching operation of the conching apparatus, moving in a first direction of circulation along a circulatory path. The conching tool here includes an operative surface, which is directed towards the inner wall of the container and is designed such that a radial gap between the inner wall of the container and the operative surface decreases, at least in part, counter to the first direction of circulation. The invention also relates to a method for conching a product mass.
A stirred ball mill including a grinding container, in which an agitator shaft having grinding elements is arranged, whereby a grinding chamber is formed between the grinding container and the agitator shaft, into which chamber the grinding elements extend and into which at least one inlet duct for grinding material opens and in which a dynamic separation device for grinding bodies is provided, the separation device having recesses for feeding back the grinding bodies, and in which the agitator shaft has at least one recess, which widens the separation device and extends in the axial direction into the grinding chamber for improved distribution of the grinding bodies in the grinding chamber.
A method and crushing device for coarse-grained material. The crushing device includes one first axially rotatable grinding mechanism and a second grinding mechanism which is fixed with respect to the first axially rotatable grinding mechanism. The second grinding mechanism accommodates the first axially rotatable grinding mechanism and is in operative connection with the first axially rotatable grinding mechanism for the purpose of crushing the coarse-grained material. The axially rotatable grinding mechanism has one transport channel for the respective material to be crushed. The transport channel includes a first section extending axially and a second section which adjoins the first section at an angle and passes through an outer lateral surface of the axially rotatable grinding mechanism.
The invention relates to a conching apparatus (10) having: - a container (22), which forms an accommodating space (24) for a product mass, - a shaft (16), which is accommodated, at least in part, in the container (22) and is designed to rotate about its longitudinal axis (L), and - at least one conching tool (38), which is coupled to the shaft (16) for joint rotation therewith, the conching tool (38) therefore, during conching operation of the conching apparatus (10), moving in a first direction of circulation (U1) along a circulatory path (58). The conching tool (38) here comprises an operative surface (52), which is directed towards the inner wall of the container (22) and is designed such that a radial gap (S) between the inner wall of the container and the operative surface (52) decreases, at least in part, counter to the first direction of circulation (U1). The invention also relates to a method for conching a product mass.
A cleaning device including a housing which can be arranged on a feed line for cleaning fluid is disclosed. The housing includes an exit opening for the cleaning fluid, wherein a nozzle head rotatable about a first rotary axis is arranged in the region of the exit opening. A distributing device rotating about a second rotary axis different from the first rotary axis and having at least one blade element or at least one pendulum element is arranged on the rotatable nozzle head. The invention also describes a product-processing plant with at least one cleaning device for cleaning a product tank.
B05B 3/04 - Appareillages de pulvérisation ou d'arrosage avec des éléments de sortie mobiles ou des éléments déflecteurs mobiles avec des éléments rotatifs entraînés par le liquide ou autre matériau fluide refoulé, p. ex. le liquide actionnant un moteur avant de parvenir à l'orifice de sortie
B08B 9/093 - Nettoyage de récipients, p. ex. de réservoirs par la force de jets ou de pulvérisations
B05B 3/06 - Appareillages de pulvérisation ou d'arrosage avec des éléments de sortie mobiles ou des éléments déflecteurs mobiles avec des éléments rotatifs entraînés par le liquide ou autre matériau fluide refoulé, p. ex. le liquide actionnant un moteur avant de parvenir à l'orifice de sortie à propulsion par réaction
33.
Device and method for dispersing at least one substance in a fluid
A device and a method for dispersing at least one substance in a fluid is disclosed. The device includes a process housing with a rotor, a fluid supply, a feed line for the at least one substance to be dispersed having at least one outlet opening, as well as a product outlet. The rotor brings about an axial delivery of a supplied fluid at least in some sections. Furthermore, the rotor brings about a radial delivery of the supplied fluid at least in some sections.
The invention relates to an agitator ball mill, with a grinding container, the inner side of which is made of a ceramic material, a rotor arranged inside the grinding container with a grinding gap formed between the surface of rotor and the inner side of the grinding container, a plurality of cams, fitted to the inner side of the grinding container and extend radially inwards. Wherein the ratio of the height of each cam and the inner diameter of the grinding container is ≤0.05, and wherein the ratio of the height of each cam and the grinding gap width is ≤0.35.
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
The invention relates to a stirring mill, comprising a horizontally arranged milling vessel (6) and a stirring shaft (22) which is arranged therein so that it can be rotationally driven. The stirring shaft (22) has a first stirring shaft section (24) adjacent to an inlet for material to be ground (18), which has a smaller diameter D24, and a second stirring shaft section (25) adjacent to an outlet for material to be ground (19), which has a larger diameter D25 and in which a separating device (31) is formed. Bypass channels (39') leading into the separating device (31) are formed in the first stirring shaft section (24).
An invention relating to a tensioning device for the belt or chain drive of a stirred ball mill and to a stirred ball mill. The tensioning device includes a tensioning lever which is arranged on a rotatable tensioning foot and which includes a tensioning wheel. A rotatable adjusting disk with a guide contour is arranged on the rotatable tensioning foot. The position of the adjusting disk can be fixed on the machine housing of the stirred ball mill by means of a securing means paired with the guide contour of the adjusting disk. The tensioning device further includes a longitudinally variable tensioning element for rotating the adjusting disk relative to the machine housing of the stirred ball mill.
F16H 7/12 - Moyens pour faire varier la tension des courroies, des câbles ou des chaînes par réglage de la position de l'axe d'une poulie d'une poulie folle
Classifiers and parts therefor, dynamic air separators and parts therefor, filtering and separating installations and parts therefor; Separators; Filters (parts of machines); Separating machines; Sieves [machines or parts of machines].
Mixing machines, homogenising machines, agitator bead mills and parts therefor, grinding machines and parts therefor, classifiers, dust filters, dust separators, magnetic separators and feed apparatus.
Ball mills and parts therefor; Crushing machines; Mills [machines]; Mixers [machines]; None of the aforesaid goods for household utensils or parts therefor.
Classifiers and parts therefor, dynamic air separators and parts therefor, filtering and separating installations and parts therefor; Separators; Filters (parts of machines); Separating machines; Sieves [machines or parts of machines]; None of the aforesaid goods being intended for ventilation systems for buildings or for extractor equipment or components therefor.
Classifiers and parts therefor, dynamic air separators and parts therefor, filtering and separating installations and parts therefor; Separators; Filters (parts of machines); Separating machines; Sieves [machines or parts of machines]; None of the aforesaid goods for use with compressors.
Classifiers and parts therefor, dynamic air separators and parts therefor, filtering and separating installations and parts therefor; Separators; Filters (parts of machines); Separating machines; Sieves [machines or parts of machines].
High-pressure homogenisers, painting machines, painting, dispersing and emulsifying machine assemblies, and parts therefor, other than machines and apparatus for producing compressed air, vacuum and flows.
Classifiers and parts therefor, dynamic air separators and parts therefor, filtering and separating installations and parts therefor; Separators; Filters (parts of machines); Separators; Sieves (machines or parts of machines); None of the aforesaid goods including products, structural parts or components consisting wholly or predominantly of technical ceramics.
Filters being parts of machines; Filters for machines; Filters [parts of machines or engines]; Separating machines; Separators for liquid solutions; Heavy media separators [machines]; Separators for separating solids from liquids; Separating machines; Fluid separation machines; Vibrating separators [machines]; Separating machines; Filtering machines, separators and centrifuges; Perforated screens being parts of machines for sorting of materials; Perforated plates being parts of machines for sorting materials; Soil screening apparatus [machines]; Soil screening apparatus [machines]; Screening machines; Sifting installations; Filters for machines; Sieves [machines or parts of machines]; Screens for grading ore [parts of machines]; Screens for grading gravel [parts of machines]; Screens for separating ore [parts of machines]; Screens for separating gravel [parts of machines]; Sifting machines.
The invention relates to a crushing device consisting of at least two parts, for crushing coarse-grained material, especially coarse-grained materials (R) from the foodstuff sector. The crushing device comprises at least one first axially rotatable grinding means and at least one second grinding means which is fixed in relation to the at least one first axially rotatable grinding means, said second grinding means receiving the at least one first axially rotatable grinding means and being actively connected to the first axially rotatable grinding means for the crushing of the coarse-grained material. According to the invention, the at least one axially rotatable grinding means has at least one transport channel for the material to be respectively crushed. The at least one transport channel comprises at least one first section extending in the axial direction and at least one second section which is connected to the at least one first section in an angled manner and penetrates an outer envelope surface of the axially rotatable grinding means. The invention also relates to a method for crushing a coarse-grained material.
The invention relates to a cleaning device comprising a housing (2) that can be arranged on a feed line (100) for cleaning fluid (RF). The housing comprises an outlet opening (3) for the cleaning fluid, wherein in the region of the outlet opening a nozzle head (4) is arranged which can rotate about a first axis of rotation (D1). A distribution unit (9) which rotates about a second axis of rotation (D2) that is different from the first axis of rotation, is arranged on the rotatable nozzle head, and comprises at least one blade element (10) or at least one pendulum element. The invention further relates to a product processing system comprising at least one cleaning device for cleaning a product tank.
B05B 3/04 - Appareillages de pulvérisation ou d'arrosage avec des éléments de sortie mobiles ou des éléments déflecteurs mobiles avec des éléments rotatifs entraînés par le liquide ou autre matériau fluide refoulé, p. ex. le liquide actionnant un moteur avant de parvenir à l'orifice de sortie
B05B 3/06 - Appareillages de pulvérisation ou d'arrosage avec des éléments de sortie mobiles ou des éléments déflecteurs mobiles avec des éléments rotatifs entraînés par le liquide ou autre matériau fluide refoulé, p. ex. le liquide actionnant un moteur avant de parvenir à l'orifice de sortie à propulsion par réaction
58.
DEVICE AND METHOD FOR DISPERSING AT LEAST ONE SUBSTANCE IN A FLUID
The invention relates to a device and a method for dispersing at least one substance in a fluid. Said device comprises a process housing (5) with a rotor (3), a fluid supply (7), a feed line (6) for the at least one substance being dispersed and having at least one outlet opening (21), and a product outlet (8). The rotor (3) causes, in at least some sections, a supplied fluid to be conveyed axially. The rotor (3) also causes, in at least some sections, the supplied fluid to be coveyed radially.
The invention relates to a separating device for classifying product mixtures consisting of at least two different components. The separating device comprises a shaft, a stationary screen unit and at least one classifying rotor. At least particles of the at least one component of the product mixture can pass through the screen unit up to a determined diameter. The classifying rotor comprises a support plate mounted on the shaft in a non-rotational manner, as well as one or more attachments that are mechanically coupled to the support plate. The attachments influence a flow behavior of the product mixture in the region of the screen unit. The one or more attachments can be fixed in different positions on the support plate relative to the rotating shaft such that, depending on the respective positions, different flow behaviors of the product mixture can be achieved in the region of the screen unit. The invention also relates to an agitator bead mil having a separating device and a method for classifying product mixtures by means of a separating device.
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machinery, equipment and systems for the processing and
treatment of minerals; sorting machines for industrial use;
mills and grinding machines; grinding machines; industrial
mixing machines. Construction, installation, repair and maintenance of
machinery, equipment and systems for sorting, grinding and
mixing, applied to processing and treatment of minerals;
advice, consulting and information regarding the aforesaid
services. Technological research services; engineering services;
design services; development of new products; technological
project studies; engineering project management services;
advice, consulting and information regarding the aforesaid
services, all relating to machinery, equipment and systems,
applied to processing and treatment of minerals.
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Screw pumps; Rotary lobe pumps; Screw pumps; Centrifugal pumps for dosing; Controlled volume pumps; Electrical pumps; Pneumatic pumps; Pumps being machines; Pumps (parts of machines, engines or motors); Valves in the form of parts for pumps; Piston pumps; Diaphgram pumps; Pump systems; Industrial crushing machines; Rotary crushing machines; Rammers, Crushing machines, Rammers in the form of machines; Shredders [machines] for industrial use; Control mechanisms for machines, engines or motors; Positive displacement pumps; Multi-phase screw spindle pumps; Mills in the form of machines; Grinding machines, in particular ball mills; Motors, other than for land vehicles; Machine coupling and transmission components other than for land vehicles; Agitators; filters, being parts for machines or engines; Strainers being machines or machine parts; Separating machines; Sealing joints (parts of motors and engines); Gaskets of metal in the form of parts of machines; Non-metallic gaskets in the form of parts of machines; Rotor arms for machines; Stators in the form of parts for machines; Transmission shafts, other than for land vehicles; Crankcases for machines, motors and engines; Machines for emptying containers; Cutting tools being power-operated; Electric machines for mixing liquids, powders, paints, lacquers, adhesives, foodstuffs; Filling machines; Machines for bottling liquids, powders, paints, lacquers, adhesives, foodstuffs; Machines for dosing liquids, powders, paints, lacquers, adhesives, foodstuffs; Fluid energy mills; Exhausters being suction ventilators; Centrifuges in the form of machines; Homogenizors; Machines for manufacturing and processing chocolate, namely coating machines, mechanical mass pumps, decorating machines, strewing and sprinkling machines, deflection conveyor belts, conveyors (machines), casting and modelling machines, and parts for the aforesaid machines; Machines for briquetting, compacting, compressing, pelletising and granulating powdery, granular, pasty and slurried products; Powder treatment and processing installations and equipment; Granulators, Air separators, Classifiers, Air jigs, Sifting machines, Dust separators, Mechanical discharge apparatus; Mechanical apparatus and devices for stirring, mixing, pureeing, dicing, chopping, pressing, squeezing, reducing and sorting solids, sludge, pulpy masses and viscose materials; Controls (Hydraulic -) for machines, motors and engines; Hydraulic valves; Hydraulic pumps; Hydraulic circuits for machines; Hydraulic lift tables; Hydraulic lifting blocks; Couplings other than for land vehicles; Hydraulic motor controls; Agitators for chemical processing; Cyclone separators; Bearing rod ends; Propeller shafts; Rotary pistons in the form of parts for machines and pumps; Spindles in the form of parts for machines and pumps. Design of advertising materials; Marketing services, In particular online marketing; Production of advertising matter and commercials; Provision of computerised advertising services; Layout services for advertising purposes; Writing of publicity texts; Services of an advertising agency; Preparing of advertisements; Publicity material rental; Publicity material rental; Demonstration of goods for promotional purposes; Distribution of advertising matter and advertising material; Developing promotional campaigns for business; Exhibitions for commercial or advertising purposes. Dismantling, construction, installation, maintenance and repair of machines; Building of trade fair and exhibition stands; Providing of information relating to the repair or maintenance of measuring and testing apparatus; Dismantling, construction, installation, maintenance and repair of measuring, signalling and monitoring apparatus and instruments; Machinery retrofit and conversion services; Pumping of liquids and oil; Rental of worm-type pumps, rotary piston pumps, screw pumps, centrifugal pumps for dosing, dosing pumps, electric pumps, pneumatic pumps, pumps in the form of machines, pump systems, industrial crushing machines, rotary crushing machines, crushers, crushing machines, rammers in the form of machines, crushing machines for industrial purposes; Rental of control mechanisms for machines, engines or motors, positive displacement pumps, multi-phase screw spindle pumps, mills in the form of machines, motors and engines (except for land vehicles), machine coupling and transmission components (except for land vehicles), agitators, sieves in the form of machines, testing apparatus not for medical purposes, measuring apparatus, electric measuring devices, voltage testers, electric couplings, calorimeters, scientific apparatus and instruments; Rental of machines for emptying containers, electric cutters (machines), electric machines for mixing liquids, powders, paints, lacquers, adhesives, foodstuffs, machines for bottling liquids, powders, paints, lacquers, adhesives, foodstuffs; Rental of machines for dosing liquids, powders, paints, lacquers, adhesives, foodstuffs, fluid energy mills, extractor fans in the form of suction ventilators, centrifuges in the form of machines, homogenisers; Rental of surveying apparatus and surveying instruments, optical apparatus and instruments, weighing apparatus and weighing instruments, measuring apparatus and measuring instruments, signalling apparatus and signalling instruments, checking (supervision) apparatus and checking (supervision) instruments. Millworking. Technology research; Project studies (Technical-); Research and development of new products; Design of computer systems; Material testing; Scientific laboratory services; Mechanical research, conducting of technical measurements; Consultancy in the field of technical and scientific measurements and analysis; Design and development of computers and software; Installation, maintenance and repair of software; Software as a service (SaaS); Engineering relating to the planning, development, project planning and manufacture of components and installations for the food, beverage and tobacco industries, mechanical process engineering and for laboratory use; Animation design for others; Animation and special-effects design for others.
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Screw pumps; Rotary lobe pumps; Screw pumps; Centrifugal pumps for dosing; Controlled volume pumps; Electrical pumps; Pneumatic pumps; Pumps being machines; Pumps (parts of machines, engines or motors); Valves in the form of parts for pumps; Piston pumps; Diaphgram pumps; Pump systems; Industrial crushing machines; Rotary crushing machines; Rammers, Crushing machines, Rammers in the form of machines; Shredders [machines] for industrial use; Control mechanisms for machines, engines or motors; Positive displacement pumps; Multi-phase screw spindle pumps; Mills in the form of machines; Grinding machines, in particular ball mills; Motors, other than for land vehicles; Machine coupling and transmission components other than for land vehicles; Agitators; filters, being parts for machines or engines; Strainers being machines or machine parts; Separating machines; Sealing joints (parts of motors and engines); Sealing gaskets of metal; Non-metallic gaskets; Rotor arms for machines; Stators in the form of parts for machines; Transmission shafts, other than for land vehicles; Crankcases for machines, motors and engines; Machines for emptying containers; Cutting tools being power-operated; Electric machines for mixing liquids, powders, paints, lacquers, adhesives, foodstuffs; Filling machines; Machines for bottling liquids, powders, paints, lacquers, adhesives, foodstuffs; Machines for dosing liquids, powders, paints, lacquers, adhesives, foodstuffs; Fluid energy mills; Exhausters being suction ventilators; Centrifuges in the form of machines; Homogenizors; Machines for manufacturing and processing chocolate, namely coating machines, mechanical mass pumps, decorating machines, strewing and sprinkling machines, deflection conveyor belts, conveyors (machines), casting and modelling machines, and parts for the aforesaid machines; Machines for briquetting, compacting, compressing, pelletising and granulating powdery, granular, pasty and slurried products; Powder treatment and processing installations and equipment; Granulators, Air separators, Classifiers, Air jigs, Sifting machines, Dust separators, Mechanical discharge apparatus; Mechanical apparatus and devices for stirring, mixing, pureeing, dicing, chopping, pressing, squeezing, reducing and sorting solids, sludge, pulpy masses and viscose materials; Controls (Hydraulic -) for machines, motors and engines; Hydraulic valves; Hydraulic pumps; Hydraulic circuits for machines; Hydraulic lift tables; Hydraulic lifting blocks; Couplings other than for land vehicles; Hydraulic motor controls; Agitators for chemical processing; Cyclone separators; Bearing rod ends; Propeller shafts; Rotary pistons in the form of parts for machines and pumps; Spindles in the form of parts for machines and pumps. Design of advertising materials; Marketing services, In particular online marketing; Production of advertising matter and commercials; Provision of computerised advertising services; Layout services for advertising purposes; Writing of publicity texts; Services of an advertising agency; Preparing of advertisements; Publicity material rental; Publicity material rental; Demonstration of goods for promotional purposes; Distribution of advertising matter and advertising material; Developing promotional campaigns for business; Exhibitions for commercial or advertising purposes. Dismantling, construction, installation, maintenance and repair of machines; Building of trade fair and exhibition stands; Providing of information relating to the repair or maintenance of measuring and testing apparatus; Dismantling, construction, installation, maintenance and repair of measuring, signalling and monitoring apparatus and instruments; Machinery retrofit and conversion services; Pumping of liquids and oil; Rental of worm-type pumps, rotary piston pumps, screw pumps, centrifugal pumps for dosing, dosing pumps, electric pumps, pneumatic pumps, pumps in the form of machines, pump systems, industrial crushing machines, rotary crushing machines, crushers, crushing machines, rammers in the form of machines, crushing machines for industrial purposes; Rental of control mechanisms for machines, engines or motors, positive displacement pumps, multi-phase screw spindle pumps, mills in the form of machines, motors and engines (except for land vehicles), machine coupling and transmission components (except for land vehicles), agitators, sieves in the form of machines, testing apparatus not for medical purposes, measuring apparatus, electric measuring devices, voltage testers, electric couplings, calorimeters, scientific apparatus and instruments; Rental of machines for emptying containers, electric cutters (machines), electric machines for mixing liquids, powders, paints, lacquers, adhesives, foodstuffs, machines for bottling liquids, powders, paints, lacquers, adhesives, foodstuffs; Rental of machines for dosing liquids, powders, paints, lacquers, adhesives, foodstuffs, fluid energy mills, extractor fans in the form of suction ventilators, centrifuges in the form of machines, homogenisers; Rental of surveying apparatus and surveying instruments, optical apparatus and instruments, weighing apparatus and weighing instruments, measuring apparatus and measuring instruments, signalling apparatus and signalling instruments, checking (supervision) apparatus and checking (supervision) instruments. Millworking. Technology research; Project studies (Technical-); Research and development of new products; Design of computer systems; Material testing; Scientific laboratory services; Mechanical research, conducting of technical measurements; Consultancy in the field of technical and scientific measurements and analysis; Design and development of computers and software; Installation, maintenance and repair of software; Software as a service (SaaS); Engineering relating to the planning, development, project planning and manufacture of components and installations for the food, beverage and tobacco industries, mechanical process engineering and for laboratory use; Animation design for others; Animation and special-effects design for others.
63.
Installation for producing and/or processing confectionery masses and method for producing and/or processing confectionery masses
An installation and method for producing and/or processing confectionery masses which are made from at least one liquid raw material and granular and/or powdery raw materials. The installation includes at least a first mixing container and at least one further product-processing device. The first mixing container has at least one raw-material inlet and a product outlet and a mixing device for mixing the raw materials at least largely homogeneously. At least the mixing container includes at least one spraying device in an upper container region, which at least one spraying device serves to feed the at least one liquid raw material, wherein at least one outlet cone of the spraying device is directed, at least in some regions, toward an inner wall surface of the first mixing container.
The invention relates to an agitator ball mill (1) having a cylindrical grinding container (2). At least one inlet for material to be ground is formed at a first end region of the grinding container (2) and at least one ground-material outlet is formed at an opposite end region of the grinding container. A separating device (12) is arranged upstream of the ground-material outlet. An agitating shaft (3) connected to a drive via a drive shaft (4) is arranged within the grinding container (2). On an outer lateral surface of the agitating shaft (3) there are formed pins (6) as agitating elements (5) which transmit the drive energy of the agitating shaft (3) at least partially to grinding bodies (MK) arranged loosely within the grinding container (2). The agitating shaft (3) is designed to be at least partially hollow cylindrical. An end of the agitating shaft opposite to the drive is at least partially open. An inner shaft (10) is formed in the hollow cylindrical interior (9) of the agitating shaft (3), wherein a first end of the inner shaft is fastened, within the hollow cylindrical interior (9) of the agitating shaft (3), coaxially to the drive shaft (4) and/or coaxially to the agitating shaft (3) and wherein the opposite second end of the inner shaft (10) projects out of the hollow cylindrical interior (9) of the agitating shaft (3). The separating device (12) is arranged on the projecting, second end (11) of the inner shaft (10). The invention further relates to a method for operating an agitator ball mill.
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
65.
Plant for the manufacture and/or preparation of confectionery masses, and a method for the cleaning of a plant for the manufacture and/or preparation of confectionery masses
The invention relates to a system for producing and/or preparing confectionery compounds from at least one liquid raw material and granular and/or powder raw materials. The system includes at least one first mixing container and at least one other product-processing device. The first mixing container has at least one raw material inlet, a product outlet, and a mixing device for mixing the raw materials in an at least largely homogenous manner. According to the invention, at least the mixing container includes at least one spray device in an upper container region for introducing the at least one liquid raw material, wherein at least one exit cone of the spray device is oriented in the direction of an inner wall surface of the first mixing container at least in some regions. The invention further relates to a method for cleaning a system for producing and/or preparing confectionery compounds.
A23G 7/00 - Autres appareils spécialement adaptés à l'industrie du chocolat ou à la confiserie
A23G 1/10 - MélangeursMoulins à cylindres pour la préparation du chocolat
A23G 3/02 - Appareils spécialement conçus pour la fabrication ou le traitement des sucreries ou de la confiserieLeurs accessoires
B08B 9/093 - Nettoyage de récipients, p. ex. de réservoirs par la force de jets ou de pulvérisations
B08B 9/032 - Nettoyage des surfaces intérieuresÉlimination des bouchons par l'action mécanique d'un fluide en mouvement, p. ex. par effet de chasse d'eau
B01F 3/12 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de liquides avec des solides
An agitator ball mill with a fluid circuit, which includes a grinding container and a casing container disposed around the latter uniformly spaced apart axially with a cavity formed between the containers. The fluid circuit is led at at least one flange through at least one flange lead-through introduced there, wherein a first opening of the at least one flange lead-through is constituted in a side wall of the corresponding flange lying orthogonal to the outer surface of the casing container.
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B02C 17/00 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
67.
TENSIONING DEVICE FOR A STIRRED BALL MILL WITH A BELT OR CHAIN DRIVE, AND STIRRED BALL MILL
The invention relates to a tensioning device (15) for the belt or chain drive of a stirred ball mill (10) and to a stirred ball mill (10). The tensioning device (15) comprises a tensioning lever (16) which is arranged on a rotatable tensioning foot (17) and which comprises a tensioning wheel (18). A rotatable adjusting disk (20) with a guide contour (22) is arranged on the rotatable tensioning foot (17). The position of the adjusting disk (20) can be fixed on the machine housing (11) of the stirred ball mill (10) by means of a securing means (26) paired with the guide contour (22) of the adjusting disk (20). The tensioning device (15) further comprises a longitudinally variable tensioning element (30) for rotating the adjusting disk (20) relative to the machine housing (11) of the stirred ball mill (10).
F16H 7/12 - Moyens pour faire varier la tension des courroies, des câbles ou des chaînes par réglage de la position de l'axe d'une poulie d'une poulie folle
68.
Handling device for the maintenance of agitator ball mills and method for maintaining an agitator ball mill
The invention relates to a method and handling device for the maintenance of agitator ball mills with a horizontally disposed grinding container. The handling device comprises a transport means and at least one holding unit for machine parts of an agitator ball mill, wherein the transport means is connected to the holding unit in a detachable manner.
B62B 3/10 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des supports spécialement adaptés à des objets de forme définie
B02C 17/10 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets avec un petit nombre d'organes de désagrégation disposés sur la cuve
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B66F 9/065 - Dispositifs pour lever ou descendre des marchandises volumineuses ou lourdes aux fins de chargement ou de déchargement se déplaçant, avec leurs charges, sur des roues ou sur un dispositif analogue, p. ex. chariots élévateurs à fourche sans mâts
69.
CLOSURE SYSTEM FOR THE GRINDING CONTAINER OF A COMMINUTING APPARATUS, AND GRINDING CONTAINER HAVING SUCH A CLOSURE SYSTEM, AND COMMINUTING APPARATUS HAVING A GRINDING CONTAINER
The invention describes a closure system for the grinding container of a comminuting apparatus. Said grinding container comprises at least one closure plug, an adapter unit having a through-opening, in which the closure plug can be inserted, the latter therefore closing the opening and being retained by the adapter unit, and also comprises one or more fixing elements, wherein the one or more fixing elements establish a releasable connection between the adapter unit and the grinding container, in order to secure the adapter unit in removable fashion on the grinding container. The invention also describes a grinding container having a closure system and further describes a comminuting apparatus.
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B65D 45/24 - Colliers, crochets ou agrafes, p. ex. en forme de C pivotants comportant des moyens pour exercer une pression, p. ex. des vis ou des clés
B65D 45/32 - Dispositifs de serrage ou autres dispositifs presseurs pour fixer ou retenir les éléments de fermeture exerçant une pression radiale, p. ex. bandes contractables encerclant l'élément de fermeture
70.
METHOD FOR MONITORING A SEALING AGENT CIRCUIT OF A DYNAMIC SEAL AND DEVICE HAVING A DYNAMIC SEAL
The invention relates to a method for monitoring physical parameters of a sealing agent in a sealing agent circuit (13) of a dynamic seal (2) of a device (1). In this case, at least one physical actual parameter of the sealing agent is determined and compared with at least one defined nominal parameter. If a deviation between the actual parameter and the nominal parameter is determined here, this deviation is used to make a prediction about an operating state of the dynamic seal (2). The invention also relates to a device (1) having at least one rotating shaft (11) which is sealed off from a stationary machine part by way of a dynamic seal (2).
B02C 1/00 - Broyage ou désagrégation par des éléments à mouvement alternatif
F16J 15/34 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par bague glissante pressée contre la face plus ou moins radiale d'une des deux parties
F16J 15/40 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par un fluide
G01M 3/02 - Examen de l'étanchéité des structures ou ouvrages vis-à-vis d'un fluide par utilisation d'un fluide ou en faisant le vide
Machines and machine arrangements for grinding, dispersing
and emulsifying as well as their parts; agitator bead mills
and their parts; pumps; transport devices; motors; drives
and general machine parts; spreaders, as well as parts and
accessories for all the above-mentioned goods as far as they
are included in this class.
72.
MIXING DEVICE AND A METHOD FOR COMMINUTING COARSE COMPONENTS WHEN DISCHARGING A PRODUCT MIXTURE FROM A MIXING DEVICE
The invention relates to a mixing device 1 and to a method for comminuting coarse components within a mixing device 1. Said mixing device 1 for producing product mixtures in the form of suspensions comprises at least one raw material inlet 3 for the raw materials being mixed, a mixing tool 6, and a product outlet 8 for the product mixture. A comminution device 30 is arranged in the product outlet 8.
B01F 7/00 - Mélangeurs à agitateurs tournant dans des récipients fixes; Pétrins
B01F 7/04 - Mélangeurs à agitateurs tournant dans des récipients fixes; Pétrins avec agitateurs tournant autour d'un axe horizontal ou incliné à pales ou à bras
B01F 7/18 - Mélangeurs à agitateurs tournant dans des récipients fixes; Pétrins avec agitateurs tournant autour d'un axe vertical à pales ou à bras
B01F 13/10 - Installations pour effectuer des mélanges comprenant des combinaisons de mélangeurs de types différents
A23G 1/00 - CacaoProduits à base de cacao, p. ex. chocolatLeurs succédanés
37 - Services de construction; extraction minière; installation et réparation
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machines for processing minerals; sorting machines for industrial use; mills and grinding machines for the treatment of minerals; grinding machines for the treatment of minerals; industrial mixing machines [ Installation, repair and maintenance of mineral ore processing machinery; consulting services relating to the installation, repair and maintenance of mineral ore processing machinery ] [ Research services in the field of treatment of minerals, engineering services in the field of treatment of minerals; design and development of new products for the treatment of minerals; consulting services relating to research, engineering, design and development of new products for the treatment of minerals ]
74.
Preliminary size reduction device for a ball mill or agitator ball mill and ball mill with a preliminary size reduction device
A preliminary size reduction device for a ball mill or agitator ball mill and a ball mill with a preliminary size reduction device, wherein the preliminary size reduction device is disposed between a grinding stock inlet of the ball mill or agitator ball mill and a grinding chamber and includes a first size reduction mechanism constituted stationary and a second, rotationally mobile size reduction mechanism, between which a size reduction gap is formed. The first size reduction mechanism constituted stationary is a size reduction ring disposed in the grinding container.
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B02C 23/38 - Addition de fluide, dans un but autre que celui de broyer ou de désagréger par l'énergie du fluide dans des appareils comportant plusieurs zones de broyage ou de désagrégation
B02C 2/10 - Broyage ou désagrégation par broyeurs giratoires ou à cônes à mouvement concentriqueBroyeurs coniques
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
75.
METHOD FOR REGULATING THE DELIVERY CAPACITY OF A ROTOR OF A SEPARATING DEVICE OF A STIRRED BALL MILL, AND STIRRED BALL MILL FOR COMMINUTING MATERIAL TO BE GROUND
The invention relates to a method for regulating the output of a rotor of a separating device of a stirred ball mill for comminuting material to be ground with the aid of grinding balls. The stirred ball mill has a preferably cylindrical, horizontally arranged grinding vessel, at least one stirring unit which is driven by means of a drive, a material inlet, and a fine material outlet. At least the fine material outlet is assigned a separating device with a rotor for retaining the grinding balls. The material to be ground is pumped by means of an external pump via the material inlet into the stirred ball mill. According to the invention, the internal volume of the grinding chamber near the separating device and/or the flow cross section near the separating device can be adjusted on the basis of the throughput of material to be ground through the stirred ball mill, that is to say, in particular, according to a pumping speed of the external pump. The invention further relates to a stirred ball mill.
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B02C 25/00 - Systèmes de commande spécialement adaptés au broyage ou à la désagrégation
B02C 23/16 - Séparation ou triage de matériaux, associé au broyage ou à la désagrégation au moyen d'un séparateur délimitant la fin de la zone de broyage ou de désagrégation, p. ex. au moyen d'un tamis empêchant la sortie des matériaux hors dimension
76.
METHOD FOR CONTROLLING THE SEPARATING ACTION OF A SEPARATOR DEVICE, AND A SEPARATOR DEVICE
The invention relates to a method for controlling the separating action of a separator device for separating a product mixture into a fine material fraction and a coarse material fraction. The separator device comprises a material inlet, a coarse material outlet and a fine material outlet, as well as a classifier device which has a classifier rotor for separating said product mixture. The product mixture is pumped by means of an external pump into said separator device via the material inlet. According to the invention, the inner volume of the separating chamber of the separator device and/or a flow cross-section inside the separating chamber of the separator device and/or a distance between a region of the classifier device and a limit of said separating chamber can be set depending on the rotational speed of the classifier rotor and/or depending on a differential pressure between the coarse material outlet and a fine material outlet and/or depending on a differential pressure between the material inlet and a fine material outlet. The invention also relates to a separator device.
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B07B 7/083 - Séparation sélective des matériaux solides portés par des courants de gaz, ou dispersés dans ceux-ci utilisant la force centrifuge produite par la rotation d'ailettes, de disques, de tambours ou de brosses
B02C 23/08 - Séparation ou triage de matériaux, associé au broyage ou à la désagrégation
77.
Separating device for a ball mill or agitator ball mill as well as a ball mill or agitator ball mill with a separating device
A separating device for a ball mill or an agitator ball mill as well as a ball mill or agitator ball mill with a separating device, wherein the ball mill or agitator ball mill includes a cylindrical grinding container with a first end opening and a second end opening, wherein the first and second end openings can be closed by a first and a second closure device, wherein a ground stock inlet is arranged in the region of the second end opening and a ground stock outlet is arranged in the region of the first end opening and wherein the separating device is assigned to the ground stock outlet. The separating device includes a plurality of first and second screen segments with screen apertures, which are arranged in an alternating manner on a frame.
A stirred ball mill including a grinding container, in which an agitator shaft having grinding elements is arranged, whereby a grinding chamber is formed between the grinding container and the agitator shaft, into which chamber the grinding elements extend and into which at least one inlet duct for grinding material opens and in which a dynamic separation device for grinding bodies is provided, the separation device having recesses for feeding back the grinding bodies, and in which the agitator shaft has at least one recess, which widens the separation device and extends in the axial direction into the grinding chamber for improved distribution of the grinding bodies in the grinding chamber.
B02C 17/00 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
Machines and machine tools for grinding, * and * dispersing [ and emulsifying ] for the chemical, cosmetic, pharmaceutical and food industries and structural parts thereof; grinding machines, namely, agitator bead mills and their parts [ ; transport devices, namely, conveyors; mechanical spreaders ]
A method for crushing inorganic solids by adding auxiliaries, in particular by using an agitator ball mill, is intended to reduce the grain size of an inorganic solid further by a grinding process that does not harm the product, without at the same time adversely influencing the reliability and service life of the crushing device. According to the invention, for this purpose the method comprises the following steps: - introducing binder-free tungsten-carbide hard-metal bodies into a grinding chamber as auxiliaries, with an average size of 300 µm or less, and feeding in an inorganic solid, - allowing the inorganic solid to be impacted by the auxiliaries in the grinding chamber for a time period tv to achieve a particle size of the inorganic solid in the sub-micrometre range, - separating the crushed solid from the auxiliaries in the grinding chamber - discharging the crushed solid from the grinding chamber.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Pumps [machines]; Mills [machines]; Disintegrators; Mixing machines; Separating machines; Filtering machines; Centrifugal mills; Axles for machines; Electromechanical machines for chemical industry; Stators [parts of machines]; Packing machines; Mixers [machines]; Metalworking machines; Shredders [machines] for industrial use; Agricultural machines; Grain husking machines; Papermaking machines; Printing machines; Machines for the textile industry; Crushing machines; Grinders/crushers (electric) for household purposes; Mills for household purposes, other than hand-operated; Electric blenders for household purposes; Ore treating machines; Beating machines; Stands for machines; Hoods [parts of machines]; Protective equipment (parts of machines); Milling machines; Hangers [parts of machines]; Lathes; Finishing machines; Handling machines, automatic [manipulators]; Robots [machines]; Centrifugal machines; Bearing brackets for machines. Technical research; Technical project studies; Research and development for others with regard to new products; Computer systems design; Material testing; Scientific laboratory services; Mechanical research.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Pumps [machines]; Mills [machines]; Disintegrators; Mixing machines; Separating machines; Filtering machines; Centrifugal mills; Axles for machines; Electromechanical machines for chemical industry; Stators [parts of machines]; Packing machines; Mixers [machines]; Metalworking machines; Shredders [machines] for industrial use; Agricultural machines; Grain husking machines; Papermaking machines; Printing machines; Machines for the textile industry; Crushing machines; Grinders/crushers (electric) for household purposes; Mills for household purposes, other than hand-operated; Electric blenders for household purposes; Ore treating machines; Beating machines; Stands for machines; Hoods [parts of machines]; Protective equipment (parts of machines); Milling machines; Hangers [parts of machines]; Lathes; Finishing machines; Handling machines, automatic [manipulators]; Robots [machines]; Centrifugal machines; Bearing brackets for machines. Technical research; Technical project studies; Research and development for others with regard to new products; Computer systems design; Material testing; Scientific laboratory services; Mechanical research.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Pumps [machines]; Mills [machines]; Disintegrators; Mixing machines; Separating machines; Filtering machines; Centrifugal mills; Axles for machines; Electromechanical machines for chemical industry; Stators [parts of machines]; Packing machines; Mixers [machines]; Metalworking machines; Shredders [machines] for industrial use; Agricultural machines; Grain husking machines; Papermaking machines; Printing machines; Machines for the textile industry; Crushing machines; Grinders/crushers (electric) for household purposes; Mills for household purposes, other than hand-operated; Electric blenders for household purposes; Ore treating machines; Beating machines; Stands for machines; Hoods [parts of machines]; Protective equipment (parts of machines); Milling machines; Hangers [parts of machines]; Lathes; Finishing machines; Handling machines, automatic [manipulators]; Robots [machines]; Centrifugal machines; Bearing brackets for machines. Technical research; Technical project studies; Research and development for others with regard to new products; Computer systems design; Material testing; Scientific laboratory services; Mechanical research; All the aforesaid services in the field of wet grinding technology, emulsions, milling systems, agitators, mixing systems, grinding systems, and milling and dry grinding technology.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Mills [machines]; Disintegrators; Mixing machines; Separating machines; Filtering machines; Centrifugal mills; Axles for machines; Electromechanical machines for chemical industry; Stators [parts of machines]; Packing machines; Mixers [machines]; Metalworking machines; Shredders [machines] for industrial use; Agricultural machines; Grain husking machines; Papermaking machines; Printing machines; Machines for the textile industry; Crushing machines; Grinders/crushers (electric) for household purposes; Mills for household purposes, other than hand-operated; Electric blenders for household purposes; Ore treating machines; Beating machines; Stands for machines; Hoods [parts of machines]; Protective equipment (parts of machines); Milling machines; Hangers [parts of machines]; Lathes; Finishing machines; Handling machines, automatic [manipulators]; Robots [machines]; Centrifugal machines; Bearing brackets for machines. Technical research; Technical project studies; Research and development for others with regard to new products; Computer systems design; Material testing; Scientific laboratory services; Mechanical research.
The invention relates to a shaft feed-through (2) of a drive shaft (7) of an agitator (6) of an agitating ball mill (1). The agitating ball mill (1) comprises a cylindrical grinding container (3), which is closed on both sides by end walls (4, 5). In the area of one of the end walls, the drive shaft (7) of the agitator (6) is enclosed by a shaft seal sleeve (21) and is guided through a central opening (10) in the end wall (5). The shaft feed-through (2) comprises a sealing module (27) enclosing the drive shaft (7) and the shaft seal sleeve (21) in the area of the central opening (10), which sealing module comprises at least one sealing element (35, 36, 37, 38) for sealing the central opening (10) of the end wall (5) with respect to the drive shaft (7), and a connecting unit (25), to which the at least one sealing element (35, 36, 37, 38) is assigned. The sealing module (27) is anchored to the end wall (5) by way of the connecting unit (25), wherein the anchoring is configured so as to be flexible, and comprises a flexible fastening element (30) between end wall (5) and connecting unit (25).
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
86.
SYSTEM FOR PRODUCING AND/OR PREPARING CONFECTIONERY COMPOUNDS, AND METHOD FOR CLEANING A SYSTEM FOR PRODUCING AND/OR PREPARING CONFECTIONERY COMPOUNDS
The invention relates to a system for producing and/or preparing confectionery compounds from at least one liquid raw material and granular and/or powder raw materials. The system comprises at least one first mixing container and at least one other product-processing device. The first mixing container has at least one raw material inlet, a product outlet, and a mixing device for mixing the raw materials in an at least largely homogenous manner. According to the invention, at least the mixing container comprises at least one spray device in an upper container region for introducing the at least one liquid raw material, wherein at least one exit cone of the spray device is oriented in the direction of an inner wall surface of the first mixing container at least in some regions. The invention further relates to a method for cleaning a system for producing and/or preparing confectionery compounds.
A23G 1/04 - Appareils spécialement adaptés à la fabrication ou au traitement du cacao ou des produits à base de cacao
B08B 3/02 - Nettoyage par la force de jets ou de pulvérisations
B08B 3/08 - Nettoyage impliquant le contact avec un liquide le liquide ayant un effet chimique ou dissolvant
B08B 9/093 - Nettoyage de récipients, p. ex. de réservoirs par la force de jets ou de pulvérisations
A23G 7/00 - Autres appareils spécialement adaptés à l'industrie du chocolat ou à la confiserie
A23G 1/10 - MélangeursMoulins à cylindres pour la préparation du chocolat
A23G 3/02 - Appareils spécialement conçus pour la fabrication ou le traitement des sucreries ou de la confiserieLeurs accessoires
B08B 9/055 - Nettoyage des surfaces intérieuresÉlimination des bouchons utilisant des dispositifs de nettoyage introduits dans et déplacés le long des tubes déplacés le long des tubes par un fluide, p. ex. par pression de fluide ou par aspiration les dispositifs de nettoyage ayant, ou pouvant épouser, la forme de la section des tubes, p. ex. hérissons ou chariots
87.
INSTALLATION FOR PRODUCING AND/OR PROCESSING CONFECTIONERY MASSES AND METHOD FOR PRODUCING AND/OR PROCESSING CONFECTIONERY MASSES
The invention relates to an installation (1, 1b) for producing and/or processing confectionery masses which are made from at least one liquid raw material and granular and/or powdery raw materials. The installation (1, 1b) comprises at least a first mixing container (2, 50) and at least one further product-processing device (4). The first mixing container (2, 50) has at least one raw-material inlet (24) and a product outlet and a mixing device (22) for mixing the raw materials at least largely homogeneously. According to the invention, at least the mixing container (2, 50) comprises at least one spraying device (26) in an upper container region, which at least one spraying device serves to feed the at least one liquid raw material, wherein at least one outlet cone of the spraying device (26) is directed, at least in some regions, toward an inner wall surface of the first mixing container (2, 50). The invention further relates to a method for producing and/or processing confectionery masses in an installation.
Machines and machine arrangements for grinding, dispersing
and emulsifying as well as their parts; agitator bead mills
and their parts; pumps, transport devices; motors, drives
and general machine parts; spreaders as well as parts and
accessories for all the above-mentioned goods as far as they
are included in this class.
Machines and machine arrangements for grinding, dispersing
and emulsifying as well as their parts; agitator bead mills
and their parts; pumps, transport devices; motors, drives
and general machine parts; spreaders as well as parts and
accessories for all the above-mentioned goods as far as they
are included in this class.
Mechanical, industrial machine and its parts; machines for
grinding, cutting, comminuting, chopping, crushing and
deagglomerating as well as their parts.
Mechanical equipment for agriculture, earthworks,
construction works, oil and gas extraction as well as
mining; pumps, compressors and fans; robots; moving and
materials handling equipment; electric generators; machines
and machine tools for material processing and production;
motors, drives and general machine parts; spreaders, street
cleaners, cleaning and washing machines; machines and
machine arrangements for grinding, dispersing and
emulsifying as well as their parts; parts and accessories
for all the above-mentioned goods, included in this class.
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Industrial mixer; mixer (machines); dispersing machines and
mills; machines for mixing; food processing machines and
apparatus; machines, namely machines for the chemical
industry, cosmetic industry and pharmaceutical industry, as
well as food industry and their parts and parts for the
aforesaid goods; mixing and homogenising machines. Headgear; clothing; footwear; parts and fittings for all the
aforesaid goods, included in this class. Consulting in construction planning; consulting in
construction technology; technical consulting services in
civil engineering; engineering services.
The invention relates to a grinding device, comprising: a closed grinding chamber for accommodating a material to be ground and for accommodating a plurality of grinding bodies that can be moved together with the material; a stirring unit accommodated in the grinding chamber, which stirring unit is rotatably operatively connected to a drive unit arranged outside of the grinding chamber; a bearing unit, which guides the shaft and is arranged in the region of an opening of the grinding chamber; and at least one wear disk, which keeps the bearing unit covered at least in some regions with respect to the material to be ground and which lies against a counter surface associated with the bearing unit.
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
Machines and machine arrangements for grinding, dispersing and emulsifying products in the industrial, chemical, pharmaceutical, food and cosmetic industries and their parts; milling machines, namely, agitator bead mills and their parts; parts and accessories for all the above-mentioned goods as far as they are included in this class
Mechanical, industrial machines, namely, grinding, cutting, comminuting, chopping, crushing and deagglomerating machines for the processing and production of nuts, chocolate, pralines and other confectionary sweets, and their parts
Machines, namely, machines for grinding, cutting, comminuting, chopping, crushing and deagglomerating for processing and production of food, as well as their parts
98.
DEVICE AND METHOD FOR STARTING AN AGITATOR BALL MILL
Described is a device for starting an agitator ball mill, wherein the agitator ball mill has a vertical grinding container. In the grinding container is mounted a vertical agitator shaft on which at least one grinding element is mounted. The grinding container is for the most part filled with grinding elements. When the agitator ball mill starts the agitator shaft can be lifted by the claimed device to allow starting.
The invention relates to a pre-comminuting device (7) for a ball mill or agitator ball mill (1), wherein the pre-comminuting device (7) is arranged between a milling material inlet (4) of the ball mill or agitator ball mill (1) and a milling space (2R) and comprises a first stationary comminuting means (20) and a second rotationally movable comminuting means (30) between which a comminuting gap (S) is formed. The first stationary comminuting means (20) is a comminuting ring (21) arranged in the milling container (2). According to the invention, the first stationary comminuting means (20) has an inner toothing (26). The second comminuting means (30) comprises a first subregion (34) and a second subregion (35). The second subregion (35) has guiding structures (37) for the milling material, via which the milling material can be guided in the direction of the first subregion (34). The first subregion (34) of the second comminuting means (30) comprises a first outer toothing (36). The first comminuting means (20) and the second comminuting means (30) are arranged such that the outer toothing (36) of the first subregion (34) of the second comminuting means (30) substantially engages in the inner toothing (26) of the first comminuting means (20) to form the comminuting gap (S). The invention further relates to a ball mill (1) with pre-comminuting device (7).
B02C 17/16 - Appareils comportant des agitateurs placés dans une cuve fixe entraînant le contenu en mouvement
B02C 17/18 - Désagrégation au tonneau, c.-à-d. par des appareils constitués par une cuve où les produits à désagréger sont chargés, avec ou sans éléments particuliers de désagrégation tels que billes ou boulets Parties constitutives
B02C 2/10 - Broyage ou désagrégation par broyeurs giratoires ou à cônes à mouvement concentriqueBroyeurs coniques
