1.

COATING METHOD AND SHEET MATERIAL


Numéro d'application 18851942
Statut En instance
Date de dépôt 2023-01-11
Date de la première publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Shimomura, Kohei
  • Mizuno, Katsumi
  • Toga, Takashi
  • Tezuka, Makoto

Abrégé

A coating method including: using a coating apparatus including a conveying roller that feeds a substrate; a knife coater that is provided with a knife portion; and a liquid-reserving member having a one end portion positioned on a side of the conveying roller and partitioning a liquid-reserving space together with the conveying roller, wherein the coating liquid contains a resin, a solvent, and a filler, and the filler is contained in a content ratio of 65 to 95 parts by mass with respect to 100 parts by mass of a mixture of the resin and the filler, an outer diameter D1 of the conveying roller is 50 to 270 mm, an outer diameter D2 of the knife coater is 50 to 170 mm, and a distance D3 from the gap to the one end portion is 1 to 120 mm.

Classes IPC  ?

  • C09D 7/61 - Adjuvants non macromoléculaires inorganiques
  • B05D 1/28 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par transfert de liquides ou d'autres matériaux fluides, à partir de la surface d'éléments porteurs, p. ex. de pinceaux, tampons, rouleaux
  • C09D 163/00 - Compositions de revêtement à base de résines époxyCompositions de revêtement à base de dérivés des résines époxy

2.

MEDICAL WIRE


Numéro d'application JP2024041918
Numéro de publication 2025/142276
Statut Délivré - en vigueur
Date de dépôt 2024-11-27
Date de publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Imamura Masaru
  • Kanazawa Asuka
  • Endo Takahiro
  • Hanayama Yukichi

Abrégé

The present invention comprises a bendable first flexible tube body (11) that extends in the front-rear direction, an operation wire (12) that extends in the front-rear direction and is inserted into the first flexible tube body (11), and a support body (14) that is fixed to a rear end part of the first flexible tube body (11). A front end part of the operation wire (12) is fixed to a front end part of the first flexible tube body (11) so as to be spaced from a center axis line (O1) of the first flexible tube body (11) toward one side in the radial direction. An operation part (13) to which the operation wire is fixed and that can move in the front-rear direction relative to the support body is provided to the rear of the support body. A first restriction part (16) and a second restriction part (17) that engage each other and thereby restrict relative movement of the support body and the operation part in the circumferential direction are formed on the support body and the operation part, respectively.

Classes IPC  ?

  • A61M 25/09 - Fils de guidage
  • A61M 25/092 - Commande à distance de l'orientation de l'extrémité distale

3.

PUNCHING DEVICE AND METHOD


Numéro d'application JP2024045851
Numéro de publication 2025/142995
Statut Délivré - en vigueur
Date de dépôt 2024-12-25
Date de publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Machii Toshiyasu
  • Ueda Yoichi

Abrégé

Provided is a punching device capable of punching in which the roundness of an iron core piece is taken into account. In the present invention, punches 9, 11, and 13 are provided corresponding to a plurality of stages 3, 5, and 7 across which a common steel plate 2 is arranged and which sequentially perform punching of the steel plate 2 to form iron core pieces 27, the punches 9, 11, and 13 of the plurality of stages 3, 5, and 7 are lowered together to punch the steel plate 2, and the tip position of the punch 13 in the punching direction is set so that the punching timing thereof is later than that of the punches 9 and 11.

Classes IPC  ?

  • B21D 28/02 - Découpage à l'emporte-pièce ou poinçonnage de flans ou d'objets, avec ou sans production de déchetsEntaillage
  • B30B 13/00 - Méthodes de pressage non liées à l'emploi des presses prévues dans l'un des groupes principaux
  • H02K 15/027 - Étampage des noyaux

4.

SEGMENT COIL MANAGEMENT METHOD AND DEVICE


Numéro d'application JP2024045850
Numéro de publication 2025/142994
Statut Délivré - en vigueur
Date de dépôt 2024-12-25
Date de publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Ueda Ryosuke
  • Okubo Shuhei

Abrégé

Provided is a segment coil management method capable of managing a post-process for a segment coil according to information read from an information display unit. A plurality of segment coils 7 that are used for a stator 1 of a rotating electric machine and that each have an information display unit 11 are held, a target segment coil 7 is taken out for a post-process from the plurality of held segment coils 7, information is read from the information display unit 11 when the target segment coil 7 is taken out, and the post-process is managed according to the read information.

Classes IPC  ?

  • H02K 15/0414 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques d'enroulements avant leur montage dans les machines les enroulements étant constitués d’éléments séparés, p.ex. barres, segments ou demi-bobines

5.

METHOD FOR PRODUCING LAMINATE


Numéro d'application 18849032
Statut En instance
Date de dépôt 2023-01-11
Date de la première publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Mizuno, Katsumi
  • Watanabe, Toshinori
  • Shimomura, Kohei
  • Toga, Takashi

Abrégé

The present invention relates to a laminate that includes a circuit pattern having a thickness of 0.8 mm or more, and a method for producing a laminate capable of preventing defects occurring in an insulating layer is proposed. A method for producing a laminate that is formed by lamination of a metal base substrate, an insulating layer formed by curing a resin composition, and a circuit pattern having a thickness of 1 mm or more includes a step of preparing a laminate before press bonding in which a semi-cured resin composition is interposed between the metal base substrate and the circuit pattern, a step of covering the laminate before press bonding with a film and placing the laminate before press bonding inside an autoclave and a step of exhausting an inside atmosphere of the film and increasing a temperature and a pressure inside the autoclave to cure the semi-cured resin composition.

Classes IPC  ?

  • B32B 15/092 - Produits stratifiés composés essentiellement de métal comprenant un métal comme seul composant ou comme composant principal d'une couche adjacente à une autre couche d'une substance spécifique de résine synthétique comprenant des résines époxy
  • B32B 3/26 - Produits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche continue dont le périmètre de la section droite a une allure particulièreProduits stratifiés comprenant une couche ayant des discontinuités ou des rugosités externes ou internes, ou une couche de forme non planeProduits stratifiés comprenant une couche ayant des particularités au niveau de sa forme caractérisés par une couche comportant des cavités ou des vides internes
  • B32B 37/10 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par la technique de pressage, p. ex. faisant usage de l'action directe du vide ou d'un fluide sous pression

6.

ACCUMULATOR


Numéro d'application 18848331
Statut En instance
Date de dépôt 2023-03-22
Date de la première publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kurokawa, Tomoya
  • Nakano, Naohito

Abrégé

An accumulator includes: an exterior body including a bottom, a shell and a port; and a bellows provided inside the exterior body and having an S-shape being capable of expansion and contraction. In a case where the bellows has expanded maximally in the accumulator, the bellows has expanded from a free state where no load other than gravitational force is being applied to the bellows.

Classes IPC  ?

  • F15B 1/12 - Accumulateurs utilisant un coussin de gazDispositifs de remplissage de gazIndicateurs ou flotteurs à cet effet avec des moyens de séparation flexibles fixés par leur périphérie
  • F16J 3/04 - Soufflets

7.

VEHICLE SEAT AND HEADREST


Numéro d'application JP2024045717
Numéro de publication 2025/142939
Statut Délivré - en vigueur
Date de dépôt 2024-12-24
Date de publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kato, Kazuhito
  • Suzuki, Kousuke
  • Honda, Chikanori

Abrégé

This vehicle seat is equipped with a headrest. A main part disposed to face the head of a seated occupant in the seat front-rear direction is provided in a central part, in the right-left direction, of the headrest. A pair of right-left head support parts that project toward the seat front side with respect to the main part are respectively provided on both the right and left sides of the headrest. The pair of right-left head support parts have two-point support parts for supporting, in the right-left direction, portions of both right and left sides with respect to the upper part of the occipital bone of the seated occupant's head, in a state in which the seated occupant's head is allowed to move in the seat vertical direction.

Classes IPC  ?

  • B60N 2/885 - Appuis-tête pourvus d’appuis latéraux
  • A47C 7/38 - Appuis pour la tête ou le dos pour la tête, p. ex. amovibles
  • B60N 2/90 - Détails ou éléments non prévus ailleurs

8.

MEDICAL WIRE


Numéro d'application JP2024042004
Numéro de publication 2025/142290
Statut Délivré - en vigueur
Date de dépôt 2024-11-27
Date de publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Endo Takahiro
  • Hanayama Yukichi
  • Imamura Masaru

Abrégé

The present invention comprises: a first flexible tube body (11) that extends in the longitudinal direction and is formed so as to be able to bend and deform; an operation wire (12) that extends in the longitudinal direction and is inserted into the first flexible tube body (11); and a support body (14) that is fixed to the rear end of the first flexible tube body (11), wherein a front end (12a) of the operation wire (12) is fixed to the front end of the first flexible tube body (11) in a state of being offset in one radial direction from the central axis (O1) of the first flexible tube body (11), the front end opening of the first flexible tube body is closed by a fixing member (25), the front end of the operation wire is embedded in the fixing member, and an engaging protrusion (12b), which protrudes further in the radial direction than the portion located between the front end and the rear end of the operation wire, is formed on the front end of the operation wire.

Classes IPC  ?

  • A61M 25/09 - Fils de guidage
  • A61M 25/092 - Commande à distance de l'orientation de l'extrémité distale

9.

MEDICAL WIRE


Numéro d'application JP2024042001
Numéro de publication 2025/142289
Statut Délivré - en vigueur
Date de dépôt 2024-11-27
Date de publication 2025-07-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Imamura Masaru
  • Hanayama Yukichi
  • Hayashida Hiroki
  • Endo Takahiro

Abrégé

The present invention comprises a first flexible tube body (11) that extends in the longitudinal direction and is formed so as to be capable of bending deformation, an operation wire (12) that extends in the longitudinal direction and is inserted inside the first flexible tube body (11), and a support body (14) that is fixed to the rear-end part of the first flexible tube body (11). The front-end part of the operation wire (12) is fixed to the front- end part of the first flexible tube body (11) in a state of being set apart from the center axis (O1) of the first flexible tube body (11) in one radial direction. An operation part (13) to which the operation wire is fixed and which is capable of moving in the longitudinal direction with respect to the support body is provided to the rear of the support body. The operation part is formed in a cylindrical shape extending in the longitudinal direction. The rear-end opening of the operation part is closed by a fixation member (24). The rear-end part of the operation wire is embedded in the fixation member. A locking projection (12b) that protrudes further in the radial direction than the portion of the operation wire positioned between the rear-end part and the front-end part is formed at the rear-end part of the operation wire.

Classes IPC  ?

  • A61M 25/09 - Fils de guidage
  • A61M 25/092 - Commande à distance de l'orientation de l'extrémité distale

10.

HEATING METHOD AND HEATING SYSTEM


Numéro d'application 18848292
Statut En instance
Date de dépôt 2022-11-25
Date de la première publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Takeda, Kazuya
  • Yasuda, Hiroyuki
  • Tsukada, Kouta

Abrégé

A heating method for hardening a coil spring includes: fixing one end of the coil spring to an outer peripheral surface of a first shaft member and fixing another end of the coil spring to an outer peripheral surface of a second shaft member; energizing the first and second shaft members to heat up the coil spring; and rotating each of the first and second shaft members in a state where the first and second shaft members are being energized. Rotation axes of the first and second shaft members are positioned on a same straight line that is at an angle of 0 degrees or more and 30 degrees or less to a horizontal direction, and a central axis of the coil spring that has been mounted on the first and second shaft members is parallel to the straight line.

Classes IPC  ?

  • C21D 9/02 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour ressorts
  • B21F 3/02 - Enroulement des fils métalliques selon des formes particulières en hélice
  • C21D 1/40 - Chauffage direct par résistance
  • H05B 3/00 - Chauffage par résistance ohmique

11.

COATING MATERIAL APPLICATION SYSTEM, CONTROL DEVICE, CONTROL METHOD, AND CONTROL PROGRAM


Numéro d'application 18848377
Statut En instance
Date de dépôt 2023-03-29
Date de la première publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kano, Takahiro
  • Uchida, Yasuhide
  • Nakano, Shota
  • Inaba, Gai

Abrégé

A coating material application system includes: a support base configured to rotatably support a coil spring; a sensor configured to measure a position of a strand of the coil spring; a first movement device configured to move the sensor; an application device; a second movement device configured to move the application device; and a control device. The control device is configured to: rotate the support base; a sensor control unit configured to acquire a measurement value of the sensor; move the sensor; calculate, based on a measurement value of the sensor, a position of application of a coating material to the coil spring; move the application device to a position where the application device is caused to apply the coating material to the position of application; and cause the application device to apply the coating material to the position of application.

Classes IPC  ?

  • B05B 13/04 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces les têtes de pulvérisation étant déplacées au cours de l'opération
  • B05B 12/12 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible sensibles à l'état du milieu ambiant ou de la cible, p. ex. à l'humidité, à la température
  • B05B 13/02 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces
  • F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle

12.

METHOD OF MANUFACTURING STABILIZER AND BASE MATERIAL


Numéro d'application 18850973
Statut En instance
Date de dépôt 2023-03-17
Date de la première publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Mori, Shogo
  • Wakabayashi, Yutaka
  • Koga, Takuo

Abrégé

A method of manufacturing a stabilizer having a through hole at each of both ends by performing forging processing on a base material includes: a recess forming step of forming a recess at a through hole formation position corresponding to the through hole of the stabilizer at an end of the base material; and a through hole forming step of forming a through hole by performing perforation at the through hole formation position including the recess.

Classes IPC  ?

  • B21J 5/10 - Perçage des billettes
  • B21K 7/00 - Fabrication de pièces de chemin de ferFabrication de pièces de véhicules
  • B60G 21/055 - Barres stabilisatrices

13.

MOTOR CORE MANUFACTURING DEVICE AND MOTOR CORE MANUFACTURING METHOD


Numéro d'application 18852248
Statut En instance
Date de dépôt 2023-03-31
Date de la première publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Ohmori, Makoto
  • Sato, Kei
  • Furuya, Takumi
  • Kinoshita, Jun
  • Kawasaki, Asuka

Abrégé

A motor core manufacturing device includes: a mold that holds a motor core including a resin filling portion; a chamber communicating with a resin composition filling path, wherein the resin composition filling path is formed in the mold and has one end portion communicating with the resin filling portion; a plunger that conveys a resin composition conveyed to the chamber toward the resin composition filling path; a first heater that is disposed in the mold, or in the mold and around the chamber; and an extruding machine that conveys the resin composition while kneading the resin composition toward the chamber in order to put a previously measured amount of the resin composition into the chamber.

Classes IPC  ?

  • B29C 45/14 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet en incorporant des parties ou des couches préformées, p. ex. moulage par injection autour d'inserts ou sur des objets à recouvrir
  • B29K 705/12 - Fer
  • B29L 31/00 - Autres objets particuliers

14.

PERSONAL WATERCRAFT AND CONTROLLING METHOD OF THE SAME


Numéro d'application 18988056
Statut En instance
Date de dépôt 2024-12-19
Date de la première publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Komiya, Minoru

Abrégé

According to an embodiment a personal watercraft includes a hull, an engine, a steering device, a water jetting nozzle, a control unit, a throttle mechanism, and a detection unit including an inertial measurement unit. When the hull turns, an angular velocity and an angular acceleration around a yaw axis are detected by the inertial measurement unit. When at least one of the angular velocity and the angular acceleration exceeds each threshold value, a deceleration control for decelerating the engine is performed by the control unit.

Classes IPC  ?

  • B63H 21/21 - Moyens de commande du moteur ou de la transmission spécialement adaptés à l'utilisation à bord d'un navire
  • B63H 21/38 - Appareils ou procédés spécialement adaptés à la manipulation de liquides pour l'appareil moteur d'un navire ou pour l'un de ses éléments, p. ex. lubrifiants, réfrigérants, carburants ou analogues
  • B63H 25/02 - Moyens amorçant la gouverne
  • F02D 35/00 - Commande non électrique des moteurs en fonction des conditions extérieures ou intérieures aux moteurs, non prévue ailleurs

15.

COIL SPRING, SUSPENSION DEVICE, AND METHOD FOR PRODUCING COIL SPRING


Numéro d'application JP2024037693
Numéro de publication 2025/134521
Statut Délivré - en vigueur
Date de dépôt 2024-10-23
Date de publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Mino, Yoshinobu
  • Yamamoto, Jumpei
  • Takahashi, Keita
  • Kumai, Shintaro

Abrégé

A coil spring according to an embodiment of the present invention is formed from a wire helically wound around a coil axis, and has an end-turn section and an effective section aligned in an axial direction parallel to the coil axis. According to one aspect of the embodiment, the surface of the wire has a first region and a second region that is more pliable than the first region, the first region and the second region are aligned in a circumferential direction centered on the axis of the wire, and in the end-turn section, the difference between the maximum value of tensile residual stress between the center of the second region in the circumferential direction and the axis and the tensile residual stress at a depth of 1 mm from the center or at a depth equal to 10% of the diameter of the wire is 500 MPa or less.

Classes IPC  ?

  • F16F 1/12 - Fixations ou montages
  • B60G 11/15 - Ressorts à boudin résistant à la déformation par enroulement
  • F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle
  • F16F 1/06 - Ressorts enroulés dont les enroulements constituent une surface cylindrique

16.

CONVEYANCE DEVICE AND CONVEYANCE METHOD


Numéro d'application 18978193
Statut En instance
Date de dépôt 2024-12-12
Date de la première publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Nakano, Kenichiro

Abrégé

A conveyance device according to one embodiment is a conveyance device that conveys a part by air. The conveyance device includes a conveying tube that has a first end portion and a second end portion, in which a part is conveyed the first end portion to the second end portion, and a control unit which controls supply of the air to be supplied from the first end portion and stopping of the supply of the air, to stop the supply of the air at least once while the part is being conveyed.

Classes IPC  ?

  • B65G 51/02 - Transport des objets par écoulement direct de gaz, p. ex. fiches, feuilles, bas, réceptacles, pièces à usiner

17.

STAGE


Numéro d'application 19076039
Statut En instance
Date de dépôt 2025-03-11
Date de la première publication 2025-06-26
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Futakuchiya, Jun
  • Aikawa, Naoya

Abrégé

A stage includes a first metal plate, a second metal plate below the first metal plate, a heat insulating portion including a first space provided in the first metal plate and a second space provided in the second metal plate, and a circulating flow path and a heater with the insulating portion therebetween. In a cross-sectional view, a width of the heat insulating portion in the first metal plate is different from a width of the heat insulating portion in the second metal plate.

Classes IPC  ?

  • H01L 21/687 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants pour le maintien ou la préhension en utilisant des moyens mécaniques, p. ex. mandrins, pièces de serrage, pinces
  • H01L 21/683 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants pour le maintien ou la préhension
  • H05B 3/30 - Éléments chauffants ayant une surface s'étendant essentiellement dans deux dimensions, p. ex. plaques chauffantes non flexibles le conducteur chauffant enrobé dans un matériau isolant sur ou entre des plaques métalliques
  • H05K 7/20 - Modifications en vue de faciliter la réfrigération, l'aération ou le chauffage

18.

LAMINATED BODY MANUFACTURING DEVICE AND LAMINATED BODY MANUFACTURING METHOD


Numéro d'application 18840835
Statut En instance
Date de dépôt 2023-02-15
Date de la première publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Hirama, Michinobu
  • Iwata, Kazuo
  • Takahashi, Shuji

Abrégé

A laminated body manufacturing device, includes a supply mechanism configured to supply a plurality of plate-shaped core pieces including locking core pieces, which have locking pieces at a plurality of positions at outer peripheral surfaces thereof, and non-locking core pieces that do not have the locking pieces; a receiving member configured to receive a plurality of the core pieces supplied from the supply mechanism; and an isolation mechanism disposed between the supply mechanism and the receiving member in a conveying direction of the core pieces, and controlling supply of the core pieces to the receiving member, wherein the isolation mechanism has locking portions that can move between locking positions, at which the locking portions respectively lock the plurality of locking pieces of the locking core pieces supplied from the supply mechanism, and non-locking positions at which the locking portions do not lock the respective locking pieces.

Classes IPC  ?

19.

DISC SPRING MEMBER


Numéro d'application 18846493
Statut En instance
Date de dépôt 2023-03-10
Date de la première publication 2025-06-19
Propriétaire NHK SPRING Co., Ltd. (Japon)
Inventeur(s)
  • Tajima, Norihiro
  • Yoneoka, Atsushi
  • Takahashi, Shuji

Abrégé

A disc spring device includes a first member and a second member, in which the second member increases in diameter from a side of a first pressed body to a side of a second pressed body in a state of being provided between the first pressed body and the second pressed body, in a cross-sectional view taken along a first direction, the first member spans the second member in the first direction such that the first member is located at least at a radially inner end portion of an outer peripheral surface of the second member facing radially outward and a radially outer end portion of an inner peripheral surface of the second member facing radially inward, and the second member presses the first pressed body via the first member and presses the second pressed body via the first member.

Classes IPC  ?

  • F16F 1/32 - Ressorts en forme de coupellesRessorts en forme de disques légèrement concaves

20.

BENDING STRUCTURE AND JOINT FUNCTION PART


Numéro d'application 19068874
Statut En instance
Date de dépôt 2025-03-03
Date de la première publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Hirata, Takafumi
  • Kurokawa, Shimpei
  • Hotoda, Yuki

Abrégé

Provided is a bending structure and a joint function part, capable of ensuring sufficient flexibility and rigidity in an axial direction. The bending structure is provided with an outer coiled part formed of a wire wound in a coiled shape and an inner coiled part formed of a wire wound in a coiled shape and arranged in the outer coiled part, wherein the outer coiled part has a plurality of gaps to distance adjacent coils, and coils of the inner coiled part are provided so as to correspond to the gaps of the outer coiled part and fit between the adjacent coils while being in contact with the adjacent coils of the outer coiled part.

Classes IPC  ?

  • A61B 17/29 - Pinces pour la chirurgie faiblement invasive
  • A61B 17/00 - Instruments, dispositifs ou procédés chirurgicaux
  • A61B 17/28 - Pinces chirurgicales
  • A61B 34/00 - Chirurgie assistée par ordinateurManipulateurs ou robots spécialement adaptés à l’utilisation en chirurgie
  • A61B 34/30 - Robots chirurgicaux
  • A61B 34/37 - Robots meneurs-suiveurs
  • B25J 3/00 - Manipulateurs de type à commande asservie, c.-à-d. manipulateurs dans lesquels l'unité de commande et l'unité commandée exécutent des mouvements correspondants dans l'espace
  • B25J 9/10 - Manipulateurs à commande programmée caractérisés par des moyens pour régler la position des éléments manipulateurs
  • B25J 17/02 - Joints articulés
  • F16F 3/06 - Ensembles de ressorts constitués par plusieurs ressorts, p. ex. pour réaliser une caractéristique d'élasticité voulue avec ressorts en acier ou faits d'un autre matériau, ayant une friction intérieure faible composés uniquement de ressorts enroulés une partie desquels sont placés autour des autres de telle sorte qu'ils s'amortissent les uns les autres par frottement mutuel

21.

VEHICLE SUSPENSION DEVICE


Numéro d'application JP2024043255
Numéro de publication 2025/126984
Statut Délivré - en vigueur
Date de dépôt 2024-12-06
Date de publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Tanaka, Yusuke
  • Kajigaya, Suguru
  • Iino, Shinji
  • Sano, Takamichi
  • Sato, Takuya

Abrégé

A vehicle suspension device according to the present invention is provided with a plate spring, a locking member to which one end of the plate spring locks, and a holding member which holds the other end of the plate spring. The holding member holds the other end of the plate spring and has a roller which is capable of rotating along with the displacement of the other end of the plate spring, and also has a pressing member which faces the roller. The roller has a multilayer structure including an elastic material. The other end of the plate spring is provided between the roller and the pressing member.

Classes IPC  ?

  • B60G 11/107 - Fixations du type glissant ou roulant
  • B60G 11/04 - Suspensions élastiques caractérisées par la disposition, l'emplacement ou le type des ressorts ayant des ressorts à lames uniquement disposés sensiblement parallèles à l'axe longitudinal du véhicule

22.

VEHICLE SUSPENSION SYSTEM


Numéro d'application JP2024043957
Numéro de publication 2025/127095
Statut Délivré - en vigueur
Date de dépôt 2024-12-12
Date de publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Tanaka, Yusuke
  • Kajigaya, Suguru
  • Iino, Shinji
  • Sano, Takamichi
  • Sato, Takuya

Abrégé

A vehicle suspension system according to the present invention comprises: a leaf spring; a locking member by which one end of the leaf spring is locked; and a holding member which holds the other end of the leaf spring. The holding member holds the other end of the leaf spring and has a roller that is rotatable so as to follow the displacement of the other end of the leaf spring and a pressing member that faces the roller. The other end of the leaf spring is provided between the roller and the pressing member. The roller and the pressing member are provided so as to allow the manner in which the roller and the pressing member contact the leaf spring to be changed.

Classes IPC  ?

  • B60G 11/107 - Fixations du type glissant ou roulant
  • B60G 11/04 - Suspensions élastiques caractérisées par la disposition, l'emplacement ou le type des ressorts ayant des ressorts à lames uniquement disposés sensiblement parallèles à l'axe longitudinal du véhicule

23.

METHOD FOR MANUFACTURING LAMINATED BODY


Numéro d'application 18849088
Statut En instance
Date de dépôt 2023-03-07
Date de la première publication 2025-06-19
Propriétaire
  • NHK SPRING CO., LTD. (Japon)
  • LPS TECH CO.,LTD (Japon)
Inventeur(s)
  • Saito, Shinji
  • Mizuno, Katsumi
  • Suzuki, Kohei
  • Watanabe, Toshinori
  • Yano, Shinya
  • Fujino, Nijianzu
  • Liang, Xiaoguang

Abrégé

Provided is a method for manufacturing a laminated body that is capable of maintaining stable bonding between the electronic component and the circuit pattern even when the employed electronic component generates a large amount of heat, and suppressing defects caused in the insulating layer. A method for manufacturing a laminated body in which a base substrate, an insulating layer, a circuit pattern, and an electronic component are laminated in this order, the method including: a step of providing the insulating layer on a front surface side of the base substrate; a step of providing the electronic component on a front surface side of the circuit pattern; and a step of laminating the insulating layer provided on the base substrate and the circuit pattern provided with the electronic component with each other.

Classes IPC  ?

  • B32B 37/00 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons
  • B32B 37/18 - Procédés ou dispositifs pour la stratification, p. ex. par polymérisation ou par liaison à l'aide d'ultrasons caractérisés par les propriétés des couches toutes les couches existant et présentant une cohésion avant la stratification impliquant uniquement l'assemblage de feuilles ou de panneaux individualisés

24.

SPRING MEMBER


Numéro d'application 18857500
Statut En instance
Date de dépôt 2023-04-24
Date de la première publication 2025-06-19
Propriétaire NHK SPRING Co., Ltd. (Japon)
Inventeur(s)
  • Tajima, Norihiro
  • Yoneoka, Atsushi
  • Takahashi, Shuji

Abrégé

A spring member presses a first pressed body and a second pressed body in directions away from each other in a first direction, and includes a plurality of spring units each including a first member and a second member, in which the first member is formed of a material having at least one of electrical conductivity and thermal conductivity higher than a material forming the second member, the first member includes first abutting portions and a second abutting portion, both end portions of the second member press the first pressed body via the first abutting portions, and an intermediate portion of the second member presses the second pressed body via the second abutting portion, and one end portion of one spring unit is provided at a position shifted in the second direction from one end portion of another spring unit adjacent to the one spring unit.

Classes IPC  ?

25.

WORKING JIG, DIE SET USING THE WORKING JIG AND MANUFACTURING METHOD FOR WORKING JIG


Numéro d'application 18968995
Statut En instance
Date de dépôt 2024-12-04
Date de la première publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Mitsumori, Yohei

Abrégé

According to an embodiment, a working jig has a body formed of metal having wear-resistance. A tapered surface is formed in an outer circumference of a distal end portion of the body. The tapered surface has a shape in which a diameter decreases toward an end face of the body. A center hole is formed in the body. Slits are formed at a plurality of positions in a circumferential direction of the body. The slits extend from the end face to positions in a length direction of the body in a direction along an axis. Chuck elements are formed between the slits which are adjacent to each other in the circumferential direction of the body. Punching portions are formed at distal ends of the chuck elements, respectively.

Classes IPC  ?

  • B21D 39/04 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des tubesUtilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tubes avec des barres

26.

MULTILAYER STRUCTURE AND METHOD FOR MANUFACTURING MULTILAYER STRUCTURE


Numéro d'application 19070204
Statut En instance
Date de dépôt 2025-03-04
Date de la première publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Otsuka, Yusuke
  • Kaneda, Noriyoshi
  • Sano, Takamichi

Abrégé

A laminated structure includes a substrate having a first surface and a second surface provided continuously with the first surface, a first insulating film on the first surface and the second surface, and a second insulating film on the first insulating film and on a corner portion formed at a boundary between the first surface and the second surface, wherein a difference between a thermal expansion coefficient of the substrate and a thermal expansion coefficient of the second insulating film is smaller than the difference between the thermal expansion coefficient of the substrate and the thermal expansion coefficient of the first insulating film.

Classes IPC  ?

  • H01L 21/687 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants pour le maintien ou la préhension en utilisant des moyens mécaniques, p. ex. mandrins, pièces de serrage, pinces
  • B05D 1/02 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces réalisés par pulvérisation
  • C23C 4/11 - Oxydes
  • C23C 4/123 - Pulvérisation de métal fondu
  • C23C 4/18 - Post-traitement
  • C25D 11/04 - Anodisation de l'aluminium ou de ses alliages

27.

VEHICULAR SUSPENSION DEVICE


Numéro d'application JP2024043844
Numéro de publication 2025/127067
Statut Délivré - en vigueur
Date de dépôt 2024-12-11
Date de publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Tanaka, Yusuke
  • Kajigaya, Suguru
  • Iino, Shinji
  • Sano, Takamichi
  • Sato, Takuya

Abrégé

According to the present invention, a vehicular suspension device, which is provided on the body of a vehicle and supports an axle, is equipped with: a plate spring; a locking member to which one end of the plate spring is locked; a holding member that holds the other end of the plate spring; and a support member that is swingably attached to the body and supports the holding member, wherein the holding member has a pair of pressing members that sandwich and hold the other end of the plate spring, and a connection part that connects the pair of pressing members.

Classes IPC  ?

  • B60G 11/107 - Fixations du type glissant ou roulant
  • B60G 11/04 - Suspensions élastiques caractérisées par la disposition, l'emplacement ou le type des ressorts ayant des ressorts à lames uniquement disposés sensiblement parallèles à l'axe longitudinal du véhicule
  • B60G 11/12 - Bielles, broches ou bagues

28.

VEHICLE SUSPENSION DEVICE


Numéro d'application JP2024043958
Numéro de publication 2025/127096
Statut Délivré - en vigueur
Date de dépôt 2024-12-12
Date de publication 2025-06-19
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Tanaka, Yusuke
  • Kajigaya, Suguru
  • Iino, Shinji
  • Sano, Takamichi
  • Sato, Takuya

Abrégé

This vehicle suspension device includes: a plate spring; a locking member to which one end of the plate spring is locked; and a holding member that holds the other end of the plate spring. The holding member includes: a roller that holds the other end of the plate spring and is capable of rotation following displacement of the other end of the plate spring; and a pressing member that faces the roller. The other end of the plate spring is provided between the roller and the pressing member. With regard to the thickness, the other end of the plate spring includes a portion in which, at an end on the side opposite the one end, the length in the thickness direction is greater than the thickness of other portions.

Classes IPC  ?

  • B60G 11/107 - Fixations du type glissant ou roulant
  • B60G 11/04 - Suspensions élastiques caractérisées par la disposition, l'emplacement ou le type des ressorts ayant des ressorts à lames uniquement disposés sensiblement parallèles à l'axe longitudinal du véhicule

29.

TORSION BAR UNIT


Numéro de document 03245557
Statut En instance
Date de dépôt 2023-02-28
Date de disponibilité au public 2025-06-13
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Iino, Shinji
  • Uetsuhara, Saiji
  • Sato, Takuya

Abrégé

A height torsion bar unit according to an embodiment of the present invention comprises: a cylindrical torsion bar composed of a fibrous composite material; a first holding member having a first groove for holding an end of the torsion bar; and a second holding member which has, at a position facing the first groove, a second groove for holding an end of the torsion bar, and which overlaps the first holding member to sandwich and hold the ends of the torsion bar by means of the first groove and the second groove. The height torsion bar unit further comprises a core rod which is inserted into a cylindrical hollow at an end.

Classes IPC  ?

  • B60G 11/18 - Suspensions élastiques caractérisées par la disposition, l'emplacement ou le type des ressorts ayant des ressorts à barre de torsion uniquement
  • B60G 21/055 - Barres stabilisatrices
  • F16B 5/02 - Jonction de feuilles ou de plaques soit entre elles soit à des bandes ou barres parallèles à elles par organes de fixation utilisant un filetage
  • F16F 1/16 - Fixations ou montages
  • F16F 1/36 - Ressorts en matière plastique, p. ex. en caoutchoucRessorts faits d'un matériau à friction intérieure élevée
  • F16F 1/366 - Ressorts en matière plastique, p. ex. en caoutchoucRessorts faits d'un matériau à friction intérieure élevée en matière plastique renforcée avec des fibres

30.

N.S.PRO


Numéro d'application 1859207
Statut Enregistrée
Date de dépôt 2025-01-24
Date d'enregistrement 2025-01-24
Propriétaire NHK SPRING CO., LTD. (Japon)
Classes de Nice  ?
  • 21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
  • 24 - Tissus et produits textiles
  • 32 - Bières; boissons non alcoolisées

Produits et services

Gloves for household purposes; cooking pots and pans, non-electric; kettles, non-electric; kitchen implements and containers, not including gas water heaters for household use, non-electric cooking heaters for household purposes, kitchen sinks incorporating integrated worktops for household purpose and kitchen sinks for household purpose; tea services [tableware]; coffee services [tableware]; chopping boards; lunch boxes; hot pads [trivets]; coasters, not of paper or textile; tablemats, not of paper or textile; dinnerware, other than knives, forks and spoons; drinking flasks for travellers; tumblers; mugs; holders of portable beverage container with heat and cold retention property; food jars; food storage jars of glass; soup jars; portable coolers, non-electric; insulating flasks; cosmetic utensils; feeding vessels for pets; brushes for pets; clothes brushes; piggy banks; flower vases; prize cups of porcelain, ceramic, earthenware, terra-cotta or glass; commemorative shields of porcelain, ceramic, earthenware, terra-cotta or glass; shoe brushes; shoe horns; shoe shine cloths; shoe-trees [stretchers]; trays for household purposes; chopsticks; chopstick cases; combs; comb cases; hair brushes; toothbrushes, non-electric; toothbrush cases; toothbrushes, electric; toothpick holders; toothpicks; soap holders and boxes; shaving brushes; bath sponges; abrasive cloths for scrubbing the skin; toilet cases. Towels of textile; Japanese cotton towels [Tenugui]; handkerchiefs of textile; Japanese general wrapping cloth [Furoshiki]; woven textile goods for personal use; blankets; table napkins of textile; dish towels for drying; banners and flags, not of paper; seat covers of textile; wall hangings of textile; table cloths, not of paper; bath linen, except clothing. Beer; carbonated drinks [refreshing beverages]; fruit juices; whey beverages; vegetable juices [beverages]; non-alcoholic beverages.

31.

VEHICLE SEAT


Numéro d'application JP2024042220
Numéro de publication 2025/121248
Statut Délivré - en vigueur
Date de dépôt 2024-11-28
Date de publication 2025-06-12
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Murayama, Koji
  • Otake, Yoshinori
  • Nguyen, The Van

Abrégé

This vehicle seat includes a plurality of spring members which are bridged between a front part and a rear part of a seat cushion frame and are arranged in a seat width direction, and support plates provided on respective outer sides of the plurality of spring members in the seat width direction so to be capable of imparting a reaction force to a load directed in the downward direction of the seat, the support plates respectively supporting opposite outer ends of the cushion pad in the seat width direction.

Classes IPC  ?

32.

NS


Numéro d'application 1859206
Statut Enregistrée
Date de dépôt 2025-01-24
Date d'enregistrement 2025-01-24
Propriétaire NHK SPRING CO., LTD. (Japon)
Classes de Nice  ?
  • 21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
  • 24 - Tissus et produits textiles
  • 32 - Bières; boissons non alcoolisées

Produits et services

Gloves for household purposes; cooking pots and pans, non-electric; kettles, non-electric; kitchen implements and containers, not including gas water heaters for household use, non-electric cooking heaters for household purposes, kitchen sinks incorporating integrated worktops for household purpose and kitchen sinks for household purpose; tea services [tableware]; coffee services [tableware]; chopping boards; lunch boxes; hot pads [trivets]; coasters, not of paper or textile; tablemats, not of paper or textile; dinnerware, other than knives, forks and spoons; drinking flasks for travellers; tumblers; mugs; holders of portable beverage container with heat and cold retention property; food jars; food storage jars of glass; soup jars; portable coolers, non-electric; insulating flasks; cosmetic utensils; feeding vessels for pets; brushes for pets; clothes brushes; piggy banks; flower vases; prize cups of porcelain, ceramic, earthenware, terra-cotta or glass; commemorative shields of porcelain, ceramic, earthenware, terra-cotta or glass; shoe brushes; shoe horns; shoe shine cloths; shoe-trees [stretchers]; trays for household purposes; chopsticks; chopstick cases; combs; comb cases; hair brushes; toothbrushes, non-electric; toothbrush cases; toothbrushes, electric; toothpick holders; toothpicks; soap holders and boxes; shaving brushes; bath sponges; abrasive cloths for scrubbing the skin; toilet cases. Towels of textile; Japanese cotton towels [Tenugui]; handkerchiefs of textile; Japanese general wrapping cloth [Furoshiki]; woven textile goods for personal use; blankets; table napkins of textile; dish towels for drying; banners and flags, not of paper; seat covers of textile; wall hangings of textile; table cloths, not of paper; bath linen, except clothing. Beer; carbonated drinks [refreshing beverages]; fruit juices; whey beverages; vegetable juices [beverages]; non-alcoholic beverages.

33.

INSPECTION DEVICE AND INSPECTION METHOD


Numéro d'application 18969387
Statut En instance
Date de dépôt 2024-12-05
Date de la première publication 2025-06-12
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Uetake, Hiroyoshi

Abrégé

According to an embodiment, an inspection device inspects a target object including a hole and a component inserted into the hole. The inspection device includes a plurality of light sources configured to illuminate an area including the hole in different directions in series, a camera configured to generate a plurality of digital images of the area illuminated by the light sources in series, and a controller configured to determine whether the component is normally inserted into the hole based on a shadow included in each of the digital images generated by the camera.

Classes IPC  ?

  • G06T 7/00 - Analyse d'image
  • G06T 7/60 - Analyse des attributs géométriques
  • H04N 23/56 - Caméras ou modules de caméras comprenant des capteurs d'images électroniquesLeur commande munis de moyens d'éclairage

34.

MOISTURE-PROOF COVER FOR HEATER


Numéro d'application JP2024041282
Numéro de publication 2025/121149
Statut Délivré - en vigueur
Date de dépôt 2024-11-21
Date de publication 2025-06-12
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Sato Takahiko
  • Furugori Nobuyuki
  • Aikawa Naoya
  • Ito Motoi

Abrégé

This moisture-proof cover for a heater covers a heater that is exposed from a shaft of a stage. The moisture-proof cover for a heater comprises: a cylindrical body including a first opening end portion that is detachably fitted to the shaft, a second opening end portion on the opposite side from the first opening end portion, and a partition wall portion that separates the first opening end portion and the second opening end portion; a lid body that is fitted to the second opening end portion and closes off the second opening end portion; and a moisture-absorbing material stored in a space that is closed off by the lid body. The partition wall portion has a plurality of through-holes.

Classes IPC  ?

  • H01L 21/683 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants pour le maintien ou la préhension

35.

CIRCUIT BOARD, METHOD FOR MANUFACTURING CIRCUIT PATTERN, AND ETCHING DEVICE


Numéro d'application 18842080
Statut En instance
Date de dépôt 2023-02-17
Date de la première publication 2025-06-05
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Yano, Shinya
  • Uetake, Misao

Abrégé

There are provided a circuit board, a method for manufacturing a circuit board, and an etching device capable of suppressing side etching and suppressing a takt time even when etching is performed on a thick workpiece. An etching device includes a conveyance means that conveys a workpiece, a spray pipe that extends along a conveyance direction of the workpiece by the conveyance means and feeds an etching solution, a plurality of spray nozzles capable of injecting the etching solution to the workpiece and provided in the spray pipe in a row in the conveyance direction, and a movement means that is capable of moving the spray pipe in a conveyance orthogonal direction orthogonal to the conveyance direction, and moves the spray pipe so that the etching solution injected from the spray nozzles is sprayed to the workpiece over the entire predetermined region in the conveyance orthogonal direction.

Classes IPC  ?

  • H05K 3/06 - Élimination du matériau conducteur par voie chimique ou électrolytique, p. ex. par le procédé de photo-décapage
  • H05K 1/02 - Circuits imprimés Détails

36.

WORKPIECE MANUFACTURING DEVICE AND WORKPIECE MANUFACTURING METHOD


Numéro d'application 18966280
Statut En instance
Date de dépôt 2024-12-03
Date de la première publication 2025-06-05
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Nakano, Kenichiro

Abrégé

A workpiece manufacturing device includes a cylinder mechanism, an electro-pneumatic regulator, a load sensor, an image capturing device. The cylinder mechanism is operated by driving gas. A piezoelectric element as an example of the fragile component, is sucked by a sucking portion and then is arranged on a piezo mounting portion. Information on the pressure of the driving gas at the time of the arrangement of the piezoelectric element is input to the recording unit. The pressing load at the time of the arrangement of the piezoelectric element is input to the recording unit. An image of the piezoelectric elements is captured by the image capturing device, and information (for example, on presence or absence of cracks) on the image is recorded in the recording unit.

Classes IPC  ?

  • B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion

37.

COMPOSITE BODY, METHOD FOR MANUFACTURING COMPOSITE BODY, LAMINATE, AND METHOD FOR MANUFACTURING LAMINATE


Numéro d'application JP2024040094
Numéro de publication 2025/115588
Statut Délivré - en vigueur
Date de dépôt 2024-11-12
Date de publication 2025-06-05
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Mizuno, Katsumi
  • Shimomura, Kohei
  • Toga, Takashi

Abrégé

Provided is a technique that makes it possible to ensure insulating properties in an insulation layer that constitutes a laminate even when a circuit pattern having a thickness of 0.5 mm or greater is used. A composite body (1) comprises: an electrical member (2) provided with a circuit portion (2a) and a gap portion (2b), the electrical member (2) having a thickness of 0.5 mm or greater; and an elastic member (3) that is disposed on one surface side of the electrical member (2) in a state in which a portion of the elastic member (3) enters the gap portion (2b).

Classes IPC  ?

  • H05K 3/20 - Appareils ou procédés pour la fabrication de circuits imprimés dans lesquels le matériau conducteur est appliqué au support isolant de manière à former le parcours conducteur recherché par apposition d'un parcours conducteur préfabriqué

38.

REMOTE SHIP MANEUVERING SYSTEM, SHIP CONTROL DEVICE, INPUT DEVICE, REMOTE SHIP MANEUVERING METHOD, AND PROGRAM


Numéro d'application 18851333
Statut En instance
Date de dépôt 2023-03-23
Date de la première publication 2025-06-05
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Tokushige, Jun
  • Tsuda, Yuto
  • Sato, Marino

Abrégé

A remote watercraft maneuvering system includes a watercraft and an input device. The watercraft includes an actuator having a function of generating a propulsion force of the watercraft and a function of causing the watercraft to generate a moment, a manipulation unit, a watercraft control device, a watercraft position detection unit, and a communication unit. The input device includes a communication unit, an input device position detection unit, a manipulation unit, and a notification unit. The watercraft control device has a normal watercraft maneuvering mode and a remote watercraft maneuvering mode. In the remote watercraft maneuvering mode, the communication unit of the watercraft receives information indicating the position of the input device from the input device, the watercraft control device calculates a distance between the input device and the watercraft, and the communication unit of the watercraft transmits information indicating that the distance between the input device and the watercraft is greater than or equal to a threshold value to the input device and the notification unit provides a notification for a remote watercraft maneuverer using the input device when the distance between the input device and the watercraft is greater than or equal to the threshold value. The threshold value is smaller than a maximum value of the distance between the input device and the watercraft when communication between the communication unit of the input device and the communication unit of the watercraft is possible.

Classes IPC  ?

  • G05D 1/227 - Transfert de la commande entre la commande à distance et la commande embarquéeTransfert de la commande entre plusieurs dispositions de commande à distance
  • B63H 21/22 - Aménagements de l'appareil moteur de propulsion ou de certains de ses éléments pour utilisation à bord des navires les éléments moteurs étant commandés de l'extérieur de la salle des machines, p. ex. de la passerelle de navigationAménagements relatifs aux transmetteurs d'ordres
  • G05D 1/222 - Dispositions de commande à distance actionnées par des humains
  • G05D 1/228 - Dispositions d’entrée de commande situées à bord de véhicules sans pilote
  • G05D 107/80 - Plateformes de transport
  • G05D 109/30 - Véhicules aquatiques
  • G05D 111/30 - Signaux radio
  • H04B 17/318 - Force du signal reçu
  • H04W 4/40 - Services spécialement adaptés à des environnements, à des situations ou à des fins spécifiques pour les véhicules, p. ex. communication véhicule-piétons

39.

COILING MACHINE AND COIL SPRING MANUFACTURING METHOD


Numéro d'application 19049337
Statut En instance
Date de dépôt 2025-02-10
Date de la première publication 2025-06-05
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Iwata, Hisashi
  • Ichikawa, Shogo
  • Yamauchi, Yuichiro
  • Tanaka, Ryo

Abrégé

A coiling machine comprises a feed unit feeding a wire in a feed direction, a helix formation unit bending the wire in a perpendicular direction, thereby forming a coil spring extending into a helical shape toward a formation direction, a laser heater heating a portion of the wire, and a cutting unit cutting a site of the wire. When the formation direction is defined as 0°, and an opposite side of the feed direction is defined as 90°, and an opposite side of the formation direction is defined as 180°, and the feed direction is defined as 270°, an irradiation direction of the laser light forms a first angle which is greater than or equal to 0° and less than or equal to 270° with the formation direction.

Classes IPC  ?

  • B21F 3/02 - Enroulement des fils métalliques selon des formes particulières en hélice
  • B23K 26/352 - Travail par rayon laser, p. ex. soudage, découpage ou perçage pour le traitement de surface

40.

COILING MACHINE AND PRODUCTION METHOD FOR COIL SPRINGS


Numéro d'application 19049752
Statut En instance
Date de dépôt 2025-02-10
Date de la première publication 2025-06-05
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Iwata, Hisashi
  • Ichikawa, Shogo
  • Yamauchi, Yuichiro
  • Tanaka, Ryo

Abrégé

A coiling machine comprises a laser heater which emits laser light to a wire formed into a helical shape, thereby heating a portion of the wire, and a cutting unit which cuts a site of the wire heated by irradiation with the laser light. An output density of the laser light is greater than or equal to 10 W/mm2 and less than or equal to 100 W/mm2.

Classes IPC  ?

  • B21F 3/02 - Enroulement des fils métalliques selon des formes particulières en hélice
  • B23K 26/352 - Travail par rayon laser, p. ex. soudage, découpage ou perçage pour le traitement de surface

41.

VEHICULAR SEAT FRAME AND VEHICULAR SEAT


Numéro d'application JP2024038400
Numéro de publication 2025/109957
Statut Délivré - en vigueur
Date de dépôt 2024-10-28
Date de publication 2025-05-30
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Tanaka, Daisuke
  • Nguyen, The Cuong

Abrégé

Provided is a vehicular seat frame capable of suppressing shifting of a seated occupant's back and having a simple configuration. This vehicular seat frame (20) comprises: a floor attachment part (21) attached to a vehicle body floor part; a cushion frame rear part (50) constituting a rear part of the skeleton of a seat cushion (12); a cushion frame front part (48) constituting a front part of the skeleton of the seat cushion (12) and connected to the cushion frame rear part (50) so as to be rotatable around a middle folding shaft (52); a front link (26) rotatably connected to the cushion frame front part (48) and the floor attachment part (21); a seat back frame (24) that is provided on the rear end side of the cushion frame rear part (50) and constitutes the skeleton of a seat back (14); and a recliner (28) that is disposed between the cushion frame rear part (50) and the floor attachment part (21) and that allows the cushion frame rear part (50) to rotate relative to the floor attachment part (21) around the axis of the recliner in a state in which a recline lever (84) that can be operated by the occupant is unlocked.

Classes IPC  ?

  • B60N 2/22 - Sièges spécialement adaptés aux véhiculesAgencement ou montage des sièges dans les véhicules le siège ou l'une de ses parties étant mobile, p. ex. réglable le dossier étant réglable
  • A47C 1/032 - Chaises ou fauteuils de relaxation ou liseuses ayant des éléments de soutien à réglage interdépendant les éléments étant un siège et un dossier à déplacement combiné
  • B60N 2/10 - Sièges spécialement adaptés aux véhiculesAgencement ou montage des sièges dans les véhicules le siège ou l'une de ses parties étant mobile, p. ex. réglable le siège entier étant mobile basculant
  • B60N 2/68 - Armatures de sièges

42.

APPARATUS FOR MANUFACTURING STATOR, METHOD FOR MANUFACTURING STATOR, AND STATOR


Numéro d'application 18841146
Statut En instance
Date de dépôt 2022-12-08
Date de la première publication 2025-05-22
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kameda, Yohei
  • Yoda, Yu

Abrégé

An apparatus for manufacturing a stator that includes a stator core, in which a plurality of core pieces formed of electrical steel sheets are stacked, and coils inserted into slots of the stator core. The apparatus for manufacturing a stator includes a pair of coil holding jigs and an activation mechanism. The coil holding jigs hold, of the coils disposed in the slots, coil ends projecting from both of axial direction end portions of the stator core. The activation mechanism rotates at least one of the pair of coil holding jigs holding the coil ends in a circumferential direction of the stator, in order to form skew in the stator.

Classes IPC  ?

  • H02K 15/025 - Noyaux magnétiques caractérisés par des structures obliques dans les noyaux
  • H02K 1/16 - Noyaux statoriques à encoches pour enroulements
  • H02K 3/34 - Enroulements caractérisés par la configuration, la forme ou la réalisation de l'isolement entre conducteurs ou entre conducteur et noyau, p. ex. isolement d'encoches
  • H02K 29/03 - Moteurs ou génératrices à dispositifs de commutation non mécaniques, p. ex. tubes à décharge ou dispositifs à semi-conducteurs avec un circuit magnétique spécialement adapté pour éviter des ondulations du couple ou des problèmes de démarrage autonome

43.

CONTACT PROBE, PROBE HOLDER AND PROBE UNIT


Numéro d'application 19036108
Statut En instance
Date de dépôt 2025-01-24
Date de la première publication 2025-05-22
Propriétaire NHK Spring Co., Ltd. (Japon)
Inventeur(s)
  • Arai, Hajime
  • Soma, Kazuya

Abrégé

A contact probe includes: a first plunger; a second plunger; and a coil spring provided between the first and second plungers and configured to connect the first and second plungers to each other so as to freely advance and retreat. The first plunger is provided with a groove portion formed on a side surface of the first plunger.

Classes IPC  ?

44.

METHOD FOR MANUFACTURING SPRING MEMBER AND CONTROL DEVICE


Numéro d'application JP2024040276
Numéro de publication 2025/105386
Statut Délivré - en vigueur
Date de dépôt 2024-11-13
Date de publication 2025-05-22
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Mino, Yoshinobu
  • Takami, Haruki
  • Inaba, Gai
  • Takeda, Kazuya

Abrégé

2111, which is the ratio of the area of contact of one holding member with the molding material to the sum of the areas of contact of the molding material and the holding members in the energizing members.

Classes IPC  ?

  • C21D 9/02 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour ressorts
  • C21D 1/40 - Chauffage direct par résistance

45.

HEATER UNIT


Numéro d'application 19028362
Statut En instance
Date de dépôt 2025-01-17
Date de la première publication 2025-05-22
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Araki, Yoshihito

Abrégé

A heater unit includes a heater, a first plate including a groove portion in which the heater is disposed, a second plate overlapping the first plate so as to cover the groove portion, and a block body disposed between the heater and the second plate. The block body is in contact with the second plate. The groove portion includes a first region having a first depth and a second region having a second depth greater than the first depth. The block body is disposed in the second region.

Classes IPC  ?

  • H05B 3/30 - Éléments chauffants ayant une surface s'étendant essentiellement dans deux dimensions, p. ex. plaques chauffantes non flexibles le conducteur chauffant enrobé dans un matériau isolant sur ou entre des plaques métalliques
  • H01L 21/67 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants

46.

HEAD FOR EJECTING REACTIVE GAS FOR FILM FORMATION AND METHOD FOR MANUFACTURING THE SAME


Numéro d'application 19030499
Statut En instance
Date de dépôt 2025-01-17
Date de la première publication 2025-05-22
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Araki, Yoshihito
  • Kaneda, Noriyoshi

Abrégé

Disclosed is a method for manufacturing a head including: diffusion-bonding a first plate and a second plate to each other; and forming, after the diffusion bonding, a nickel-containing film on surfaces of the first plate and the second plate with electroless plating. The first plate and the second plate are configured to have a channel through which the reactive gas passes from a side of the first plate to a side of the second plate in a state where the first plate and the second plate are bonded.

Classes IPC  ?

  • C23C 16/455 - Revêtement chimique par décomposition de composés gazeux, ne laissant pas de produits de réaction du matériau de la surface dans le revêtement, c.-à-d. procédés de dépôt chimique en phase vapeur [CVD] caractérisé par le procédé de revêtement caractérisé par le procédé utilisé pour introduire des gaz dans la chambre de réaction ou pour modifier les écoulements de gaz dans la chambre de réaction
  • B23K 20/02 - Soudage non électrique par percussion ou par une autre forme de pression, avec ou sans chauffage, p. ex. revêtement ou placage au moyen d'une presse
  • C23C 18/16 - Revêtement chimique par décomposition soit de composés liquides, soit de solutions des composés constituant le revêtement, ne laissant pas de produits de réaction du matériau de la surface dans le revêtementDépôt par contact par réduction ou par substitution, p. ex. dépôt sans courant électrique
  • C23C 18/32 - Revêtement avec l'un des métaux fer, cobalt ou nickelRevêtement avec des mélanges de phosphore ou de bore et de l'un de ces métaux

47.

BENT-SHAPE MEASUREMENT METHOD, BENT-SHAPE MEASUREMENT PROGRAM, AND BENT-SHAPE MEASUREMENT DEVICE


Numéro d'application JP2024040581
Numéro de publication 2025/105456
Statut Délivré - en vigueur
Date de dépôt 2024-11-15
Date de publication 2025-05-22
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Arai, Fumitaka
  • Mori, Yukiya
  • Tadano, Atsuya

Abrégé

This bent-shape measurement method is for measuring the shape of a molding material to which bending has been applied, and includes: a data acquisition step for acquiring profile data generated by imaging a part of a side surface of the molding material; a detection step for detecting, by using the profile data, straight sections, in which the molding material extends linearly, for a plurality of areas set for the molding material; a calculation step for calculating the intersection point of two straight sections in each area; and a conversion step for converting the intersection point into a setting value on the basis of the coordinates of the intersection point in each area.

Classes IPC  ?

  • G01B 11/24 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer des contours ou des courbes

48.

SHEATH HEATER AND STAGE


Numéro d'application 19006584
Statut En instance
Date de dépôt 2024-12-31
Date de la première publication 2025-05-15
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Aikawa, Naoya
  • Kida, Naoya
  • Futakuchiya, Jun
  • Fujino, Daisuke
  • Takanashi, Masaya

Abrégé

A sheath heater includes a metal sheath, a heater wire disposed in the metal sheath, an insulating material filled in the metal sheath so as to separate the metal sheath and the heater wire, a lead wire for supplying power to the heater wire, a crimp sleeve connecting the heater wire extending from an end of the metal sheath with the lead wire, a cylindrical member covering the end of the metal sheath, and a lid member engaging with the cylindrical member and including an opening into which the lead wire is inserted. The crimp sleeve is disposed in the cylindrical member. The end of the metal sheath includes a first insulating tube including a first through hole into which the heater wire is inserted and a sealing material filling a gap between the metal sheath and the first insulating tube. The sealing material includes a ceramic binder.

Classes IPC  ?

  • H05B 3/48 - Éléments chauffants ayant la forme de tiges ou de tubes non flexibles le conducteur chauffant enrobé dans un matériau isolant
  • H05B 3/04 - Joints étanches à l'eau ou à l'air pour appareils de chauffage
  • H05B 3/28 - Éléments chauffants ayant une surface s'étendant essentiellement dans deux dimensions, p. ex. plaques chauffantes non flexibles le conducteur chauffant enrobé dans un matériau isolant

49.

VESSEL CONTROL DEVICE, VESSEL, VESSEL CONTROL METHOD, AND PROGRAM


Numéro d'application JP2024039407
Numéro de publication 2025/100434
Statut Délivré - en vigueur
Date de dépôt 2024-11-06
Date de publication 2025-05-15
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Shirao Masato
  • Kamiya Takafumi
  • Tokushige Jun
  • Sato Marino

Abrégé

This vessel control device comprises: a setting unit that sets a transit order of at least two points; a movement direction calculation unit that calculates a movement direction from the current position of a ship to a first target point, which is set by the setting unit as a first transit point; an angle calculation unit that calculates an angle formed by the movement direction calculated by the movement direction calculation unit and a direction from the first target point to a second target point, which is set by the setting unit as a second transit point; a speed calculation unit that calculates a target speed of the ship toward the first target point when entering a target area set ahead of the first target point, on the basis of the angle formed; a detection unit that detects that the ship has entered the range of the target area; and a target point switching unit that switches a traveling direction of the ship from the first target point to the second target point on the basis of the detection.

Classes IPC  ?

  • B63H 25/04 - Moyens amorçant la gouverne à fonctionnement automatique, p. ex. asservis au compas
  • B63H 21/21 - Moyens de commande du moteur ou de la transmission spécialement adaptés à l'utilisation à bord d'un navire
  • G01C 21/20 - Instruments pour effectuer des calculs de navigation

50.

MOVING BODY CONTROL DEVICE, MOVING BODY, MOVING BODY CONTROL METHOD, AND PROGRAM


Numéro d'application JP2024039435
Numéro de publication 2025/100439
Statut Délivré - en vigueur
Date de dépôt 2024-11-06
Date de publication 2025-05-15
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Shirao Masato
  • Kamiya Takafumi
  • Tokushige Jun
  • Sato Marino

Abrégé

Provided is a moving body control device comprising: a disturbance direction estimation unit that estimates the direction of a disturbance that applies a force from the outside to a moving body; a target position setting unit that sets a target position of the moving body; a return point setting unit that sets, as a return point, a position including the target position in the direction of the disturbance; a movement control unit that generates thrust and moves the moving body to the return point; and a heading control unit that, when the moving body is caused to drift by the disturbance, directs the head of the moving body in a prescribed direction with respect to the direction of the disturbance.

Classes IPC  ?

  • B63H 25/42 - Gouverne ou ancrage dynamique à l'aide d'éléments propulsifsGouverne ou ancrage dynamique à l'aide d'hélices uniquement utilisées à cet effetGouverne ou ancrage dynamique à l'aide de gouvernails portant des hélices
  • B63H 25/00 - GouverneRalentissement par d'autres moyens que les éléments propulsifsAncrage dynamique, c.-à-d. positionnement des navires au moyen d'éléments de propulsion auxiliaires ou principaux
  • B63H 25/04 - Moyens amorçant la gouverne à fonctionnement automatique, p. ex. asservis au compas
  • G01C 21/20 - Instruments pour effectuer des calculs de navigation

51.

DIE SET FOR FORMING A WORK HAVING A PAIR OF FLANGE BENDING PARTS


Numéro d'application 19021851
Statut En instance
Date de dépôt 2025-01-15
Date de la première publication 2025-05-15
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kurebayashi, Sosuke
  • Mitsumori, Yohei
  • Iwamoto, Naoki

Abrégé

A die set to bend a work including a pair of flange bending parts. The die set includes: a die supporting a first part of the work in a length direction; a pad including a pressure surface which holds the work with the die; and a punch which presses a second part of the work in the length direction in a thickness direction of the work while the first part of the work is held between the die and the pad. The die includes: a flat supporting surface supporting the work; a first relief part including a first inclined surface; and a second relief part including a second inclined surface.

Classes IPC  ?

  • G11B 5/48 - Disposition ou montage des têtes par rapport aux supports d'enregistrement

52.

PROCESSING METHOD FOR FORMING A WORK HAVING A PAIR OF FLANGE BENDING PARTS


Numéro d'application 19021924
Statut En instance
Date de dépôt 2025-01-15
Date de la première publication 2025-05-15
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kurebayashi, Sosuke
  • Mitsumori, Yohei
  • Iwamoto, Naoki

Abrégé

A processing method of a work includes: forming flange bending parts at respective side parts of the work, the flange bending parts including first bending parts extending in a length direction of the work; holding a first part of the work in the length direction where the flange bending parts are formed between a die and a pad; and pressing a second part of the work in the length direction in a thickness direction to form a second bending part extending in a width direction of the work between the first part and the second part. The die includes a supporting surface supporting the work, a first relief part including a first inclined surface, and a second relief part including a second inclined surface.

Classes IPC  ?

  • G11B 5/48 - Disposition ou montage des têtes par rapport aux supports d'enregistrement

53.

CIRCUIT BOARD AND MANUFACTURING METHOD THEREFOR


Numéro d'application JP2024031386
Numéro de publication 2025/100064
Statut Délivré - en vigueur
Date de dépôt 2024-08-30
Date de publication 2025-05-15
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Tanaka Ryo

Abrégé

Provided is a circuit board wherein it is possible to minimize damage to an insulating layer due to heat that is inputted to an additional metal layer. The present invention comprises: a circuit pattern 3 that is provided on insulating substrates 5, 7; and an additional metal layer 9 that is layered on the circuit pattern 3 and bonded thereto, and is for connecting another member 11 by welding. The additional metal layer 9 comprises a bonding surface 10 that is bonded to the circuit pattern 3. The bonding surface 10 comprises a bonding section 10a that is bonded to the circuit pattern 3 in an area facing the circuit pattern 3 in the layering direction, and a non-bonding section 10b other than the bonding section 10a. The thickness of the additional metal layer 9 and the circuit pattern 3 in the layering direction is 1.2 mm to 3.0 mm.

Classes IPC  ?

  • H05K 1/02 - Circuits imprimés Détails
  • H01L 23/12 - Supports, p. ex. substrats isolants non amovibles
  • H05K 1/09 - Emploi de matériaux pour réaliser le parcours métallique
  • H05K 3/32 - Connexions électriques des composants électriques ou des fils à des circuits imprimés

54.

CIRCUIT BOARD AND METHOD FOR PRODUCTION THEREOF


Numéro d'application JP2024031388
Numéro de publication 2025/100065
Statut Délivré - en vigueur
Date de dépôt 2024-08-30
Date de publication 2025-05-15
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Tanaka Ryo

Abrégé

Provided is a circuit board which makes it possible to connect a conductive member to an additional metal layer by welding. This circuit board comprises: a circuit pattern 3 provided on an insulation layer 7; an additional metal layer 9 that is laminated and joined on the circuit pattern 3; and a lead frame 11 that is laminated on the additional metal layer 9 and connected thereto by welding. The total thickness of the additional metal layer 9 and the circuit pattern 3 in the lamination direction is 1.5-3.0 mm, and the lead frame 11 has a thickness of 0.2-1.2 mm in the lamination direction.

Classes IPC  ?

  • H05K 1/02 - Circuits imprimés Détails
  • H01L 23/12 - Supports, p. ex. substrats isolants non amovibles
  • H05K 1/09 - Emploi de matériaux pour réaliser le parcours métallique
  • H05K 3/32 - Connexions électriques des composants électriques ou des fils à des circuits imprimés

55.

CAP BELLOWS ASSEMBLY AND ACCUMULATOR


Numéro d'application 18726139
Statut En instance
Date de dépôt 2023-01-20
Date de la première publication 2025-05-08
Propriétaire NHK SPRING CO., LTD (Japon)
Inventeur(s)
  • Nakano, Naohito
  • Ohta, Daijiro
  • Doi, Takashi
  • Kurokawa, Tomoya

Abrégé

A cap bellows assembly seals one end of a bellows provided inside an exterior body of an accumulator, the accumulator including a bottom, a shell, and a port, and includes: a cap body configured to cover an opening of the bellows; and a cap elastic portion provided between the cap body and the port and fixed to the cap body. A bonding surface of the cap body, to which the cap elastic portion is bonded, is subjected to a zinc calcium phosphate treatment, and a hopeite amount on the bonding surface is 4.8% or less.

Classes IPC  ?

  • F15B 1/10 - Accumulateurs utilisant un coussin de gazDispositifs de remplissage de gazIndicateurs ou flotteurs à cet effet avec des moyens de séparation flexibles

56.

SHIP CONTROL DEVICE, SHIP, SHIP CONTROL METHOD, AND PROGRAM


Numéro d'application JP2024038636
Numéro de publication 2025/094973
Statut Délivré - en vigueur
Date de dépôt 2024-10-30
Date de publication 2025-05-08
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Shirao Masato
  • Kamiya Takafumi
  • Tokushige Jun
  • Sato Marino

Abrégé

A ship control device according to the present invention comprises an area information acquisition unit that acquires area information that specifies a first area that is near a target location and a second area that is farther from the target location than the first area but is near the first area, a self location information acquisition unit that acquires location information for a self ship, a direction control unit that, when the location of the self ship as acquired by the self location information acquisition unit is in the second area, controls the direction in which the bow is pointed to be toward the target location, and an output control unit that, when the location of the self ship as acquired by the self location information acquisition unit is in a third area that is farther from the target location than the first area and the second area but is near the second area, controls thrust such that the self ship moves toward the target location.

Classes IPC  ?

  • B63H 25/42 - Gouverne ou ancrage dynamique à l'aide d'éléments propulsifsGouverne ou ancrage dynamique à l'aide d'hélices uniquement utilisées à cet effetGouverne ou ancrage dynamique à l'aide de gouvernails portant des hélices

57.

SHIP CONTROL DEVICE, SHIP, SHIP CONTROL METHOD, AND PROGRAM


Numéro d'application JP2024038712
Numéro de publication 2025/094999
Statut Délivré - en vigueur
Date de dépôt 2024-10-30
Date de publication 2025-05-08
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Shirao Masato
  • Kamiya Takafumi
  • Tokushige Jun
  • Sato Marino

Abrégé

This ship control device comprises: a mode detection unit that detects entry into a trailer removal mode; a speed detection unit that detects the speed of an own ship; and an output control unit that, in the trailer removal mode, performs control to increase astern thrust when the speed of the own ship detected by the speed detection unit is lower than a prescribed speed, and performs control to lower the astern thrust when the speed of the ship detected by the speed detection unit is equal to or higher than the prescribed speed.

Classes IPC  ?

  • B63C 3/12 - Lancement ou halage des navires, p. ex. par rampes à terreRampes de lancement utilisant des berceaux
  • B63H 21/21 - Moyens de commande du moteur ou de la transmission spécialement adaptés à l'utilisation à bord d'un navire

58.

SURFACE TREATMENT JIG


Numéro d'application 18834762
Statut En instance
Date de dépôt 2023-03-22
Date de la première publication 2025-05-01
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Nozawa, Takahiro
  • Kurokawa, Tomoya
  • Doi, Takashi

Abrégé

A surface treatment jig for performing surface treatment of an exterior body of an accumulator including a bottom, a shell and a port in a state where the surface treatment jig is connected to the exterior body and supports the exterior body includes: a support portion configured to support the accumulator; and a hook portion connected with the support portion. The support portion has a shape tapered near the hook portion.

Classes IPC  ?

  • B05B 13/02 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces

59.

AIRBAG DEVICE


Numéro d'application JP2023038605
Numéro de publication 2025/088745
Statut Délivré - en vigueur
Date de dépôt 2023-10-25
Date de publication 2025-05-01
Propriétaire
  • MITSUBISHI JIDOSHA KOGYO KABUSHIKI KAISHA (Japon)
  • NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Mizutani Natsuki
  • Murabayashi Tomohiro
  • Miyabata Makoto
  • Ishii Sadayuki
  • Yasuda Shintaro
  • Imai Nobuaki
  • Shimizu Noriaki
  • Ohtsuki Satoru
  • Seki Takamitsu
  • Tokiwa Yuji

Abrégé

The present invention provides an airbag device that deploys an airbag body toward the outer side, in the vehicle width direction, of an occupant seated in a seat. An accommodating body that accommodates the airbag body is formed in a tubular shape with an opening. The accommodating body has a first tear line portion and a first guide portion. The first tear line portion extends vertically from an upper end to a lower end at a front end portion of the accommodating body and is formed so as to be ruptured by the forward deployment of the airbag body. The first guide portion covers at least part of the opening.

Classes IPC  ?

  • B60R 21/207 - Dispositions pour ranger les éléments gonflables non utilisés ou à l'état dégonfléAgencement ou montage des composants ou modules des coussins gonflables dans les sièges du véhicule
  • B60N 2/427 - Sièges spécialement adaptés aux véhiculesAgencement ou montage des sièges dans les véhicules à des fins particulières ou pour des véhicules particuliers le siège étant construit pour protéger son occupant des effets des forces d'accélération anormales, p. ex. sièges anticollision ou sièges de sécurité le siège ou ses parties constitutives se déplaçant lors d'une collision

60.

COIL SPRING AND SUSPENSION FOR VEHICLE


Numéro d'application US2023077735
Numéro de publication 2025/090079
Statut Délivré - en vigueur
Date de dépôt 2023-10-25
Date de publication 2025-05-01
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Furuse, Takeshi
  • Moriyama, Senri
  • Tanaka, Yusuke

Abrégé

A coil spring (1B) includes a wire rod (2) including a round section portion (30) and a flat section portion (100). The round section portion(30) includes a first cross section (S1) whose cross section is round. The flat section portion (100) includes a second cross section (S2) that is flat. The second cross section (S2) has a width greater than or equal to the diameter of the first cross section (S1) and a thickness less than the width. A polar moment of inertia of area of the second cross section (S2) is smaller than that of the first cross section (S1). A variable section portion (32) is formed between the round section portion (30) and the flat section portion (100). The variable section portion (32) changes its cross section from circular to flat from the round section portion (30) towards the flat section portion (100).

Classes IPC  ?

  • F16F 1/06 - Ressorts enroulés dont les enroulements constituent une surface cylindrique
  • B60G 11/16 - Suspensions élastiques caractérisées par la disposition, l'emplacement ou le type des ressorts ayant des ressorts hélicoïdaux, spirales ou en bobines uniquement caractérisés par des moyens spécialement conçus pour la fixation du ressort à l'essieu ou à une partie suspendue du véhicule
  • F16F 1/04 - Ressorts enroulés
  • B60G 11/14 - Suspensions élastiques caractérisées par la disposition, l'emplacement ou le type des ressorts ayant des ressorts hélicoïdaux, spirales ou en bobines uniquement
  • F16F 1/12 - Fixations ou montages

61.

STATOR


Numéro d'application 18719232
Statut En instance
Date de dépôt 2022-12-22
Date de la première publication 2025-04-24
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Ito, Keiichi

Abrégé

End portions of coils that are wound round teeth of a stator core of a stator are joined to joining portions of busbars that are disposed adjacent to the stator core. The busbars include extending portions that extend in the circumferential direction of the stator core. An insulating resin is molded integrally with the busbars. The extending portions are partially exposed through the insulating resin. These exposed portions of the extending portions are sealed in by a sealing resin that is formed of a resin with higher thermal conductivity than the insulating resin.

Classes IPC  ?

  • H02K 3/32 - Enroulements caractérisés par la configuration, la forme ou la réalisation de l'isolement
  • H02K 1/14 - Noyaux statoriques à pôles saillants
  • H02K 1/20 - Parties fixes du circuit magnétique avec des canaux ou des conduits pour l'écoulement d'un agent de refroidissement

62.

COVER AND RECORDING DEVICE


Numéro d'application 18682399
Statut En instance
Date de dépôt 2022-08-23
Date de la première publication 2025-04-24
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Araki, Toshimitsu
  • Okawara, Osamu
  • Takahashi, Shuji

Abrégé

Provided is a cover capable of adapting to a case requiring properties hard to be compatible for a gasket of a recording device. The cover attached to a base of a recording device to close the base, comprises a gasket having a loop shape and provided to a cover body, wherein the gasket has an inner gasket portion and an outer gasket portion arranged adjacent to each other on an inward side and an outward side of the loop shape, the outer gasket portion has a first property and a second property that are different properties and is superior to the inner gasket portion in the first property, and the inner gasket portion has the first property and the second property and is superior to the outer gasket portion in the second property.

Classes IPC  ?

  • G11B 33/02 - ÉbénisterieBoîtiersBâtisDisposition des appareils dans ou sur ceux-ci
  • G11B 33/14 - Diminution de l'influence des paramètres physiques, p. ex. changements de température, humidité, poussière

63.

TENSION BALANCER


Numéro d'application JP2024031845
Numéro de publication 2025/074805
Statut Délivré - en vigueur
Date de dépôt 2024-09-05
Date de publication 2025-04-10
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Tasho Yohei

Abrégé

This tension balancer is provided with first through n-th cylindrical members, first through (n − 1)th coil springs, a first hook that is attached to the first cylindrical member, a second hook that is attached to the n-th cylindrical member, and a scale that is attached to the n-th cylindrical member. The scale extends in a first direction that is parallel to a central axis of the first through n-th cylindrical members, is located outside the n-th cylindrical member, overlaps with the n-th cylindrical member in a second direction that is perpendicular to the first direction, and can expand and contract in the first direction. The first through n-th cylindrical members are disposed so that each (j + 1)th cylindrical member selected from among the first through n-th cylindrical members is surrounded by the j-th cylindrical member. The cylindrical members and the coil springs mutually alternate. n is a natural number of 3 or greater, and j is a variable selected from natural numbers and at least 1 and no more than (n − 1).

Classes IPC  ?

  • B60M 1/26 - Dispositifs de compensation pour variation de longueur
  • F16F 3/04 - Ensembles de ressorts constitués par plusieurs ressorts, p. ex. pour réaliser une caractéristique d'élasticité voulue avec ressorts en acier ou faits d'un autre matériau, ayant une friction intérieure faible composés uniquement de ressorts enroulés
  • H02G 7/02 - Dispositifs pour ajustage ou maintien de la tension mécanique, p. ex. organe de compensation

64.

METHOD OF MANUFACTURING ARMATURE


Numéro d'application 18832039
Statut En instance
Date de dépôt 2022-11-18
Date de la première publication 2025-04-10
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kobayashi, Dai
  • Hirota, Yuji

Abrégé

This production method produces a stator that includes a plurality of segment coils that are annularly arranged in a plurality of layers that overlap in the radial direction of a stator core. The production method involves a tool that has teeth being moved by a robot manipulator and the teeth being inserted between the ends of leg parts of the layers. The ends that engage the teeth are thereby bent so as to be substantially crank-shaped. Before the teeth are inserted between the ends, a restraining jig is inserted between bend parts of the segment coils of the layers and an end surface of the stator core that is on one side in the axial direction.

Classes IPC  ?

  • H02K 15/24 - Façonnage ou compression des têtes de bobinage
  • B21D 11/06 - Cintrage en hélice, ou en spiraleFaçonnage en une succession de coudes, p. ex. en forme de serpentins

65.

TERMINAL CONNECTION PORTION FOR ELECTRONIC DEVICE


Numéro d'application 18985392
Statut En instance
Date de dépôt 2024-12-18
Date de la première publication 2025-04-10
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Yamada, Yukie

Abrégé

A terminal connection portion for an electronic device includes a first terminal of a wiring portion. The wiring portion includes a base insulating layer, conductors formed on the base insulation layer, a cover layer which covers the conductors, and the first terminal which is formed at an end of each of the conductors and is integral with each of the conductors. The first terminal includes a base portion including a first surface fixed to the base insulation layer along the base insulation layer and a second surface opposite the first surface, a bent portion reversed in a thickness direction of the base portion from an end of the base portion towards the second surface, and an overlapping portion extending from the bent portion in a direction along the second surface.

Classes IPC  ?

  • G11B 5/48 - Disposition ou montage des têtes par rapport aux supports d'enregistrement
  • H01R 12/65 - Connexions fixes pour circuits imprimés flexibles, câbles plats ou à rubans ou structures similaires caractérisées par les bornes

66.

SPRING MEMBER


Numéro d'application JP2024034589
Numéro de publication 2025/074947
Statut Délivré - en vigueur
Date de dépôt 2024-09-27
Date de publication 2025-04-10
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Tajima, Norihiro
  • Nishimoto, Shigekazu
  • Shimizu, Daisuke

Abrégé

A spring member according to the present invention is disposed between two bodies to be pressed and applies pressure to said bodies to be pressed. The spring member includes a support portion, a plurality of band-shaped spring portions each having a portion thereof curved in an arc shape, and a plurality of first connecting portions that extend in a first direction and connect the support portion and the spring portions. The support portion and the plurality of first connecting portions are located on a same plane parallel to the first direction. From among the plurality of spring portions, the spring portions located closest to each other are disposed at positions where the spring portions partially overlap each other in the first direction and in a second direction orthogonal to the first direction on the plane.

Classes IPC  ?

  • F16F 3/02 - Ensembles de ressorts constitués par plusieurs ressorts, p. ex. pour réaliser une caractéristique d'élasticité voulue avec ressorts en acier ou faits d'un autre matériau, ayant une friction intérieure faible

67.

PRESSURE SPRING, PRESSURE SPRING STRUCTURE, AND METHOD FOR MANUFACTURING PRESSURE SPRING


Numéro d'application JP2024035651
Numéro de publication 2025/075161
Statut Délivré - en vigueur
Date de dépôt 2024-10-04
Date de publication 2025-04-10
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Sano Takamichi
  • Uetsuhara Saiji
  • Imamura Masaru
  • Suzuki Takuto

Abrégé

Provided is a method for manufacturing a pressure spring comprising a first plate spring and a second plate spring that extend in a length direction, wherein both end parts in the length direction of the first plate spring are stacked in a plate thickness direction on and joined to both end parts in the length direction of the second plate spring, intermediate parts in the length direction of the respective first plate spring and second plate spring face each other in a state of being separated from each other in the plate thickness direction, a length of the intermediate part of the second plate spring along a surface of the second plate spring as viewed from a plate width direction is shorter than a length of the intermediate part of the first plate spring along a surface of the first plate spring as viewed from the plate width direction, and, in the intermediate part of the first plate spring, a stress in the direction of stretching along an outer surface of the first plate spring as viewed from the plate width direction is applied to the outer surface side that is the opposite side to the second plate spring along the plate thickness direction. The method performs a joining step for joining both end parts in the length direction of the first plate spring to a long second plate spring material configured by integrally connecting a plurality of second plate springs in the length direction, and a cutting step for cutting at least the second plate spring material to obtain a pressure spring, in this order.

Classes IPC  ?

  • F16F 1/18 - Ressorts à lames
  • F16F 1/20 - Ressorts à lames avec interlames, p. ex. des interlames antifriction, ou avec rouleaux entre les lames

68.

JIG AND DEVICE FOR STATOR TWISTING


Numéro d'application JP2024033829
Numéro de publication 2025/070346
Statut Délivré - en vigueur
Date de dépôt 2024-09-24
Date de publication 2025-04-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Otsuka Motoyuki
  • Kobayashi Dai
  • Chiba Yuto

Abrégé

Provided is a jig for stator twisting, with which it is possible to easily suppress radial-direction deformation of a projecting portion of a segment coil that projects from a stator core during twisting. A jig 9A for twisting a stator 1, in which projecting portions 7A that include coil ends 7a of a segment coil 7 held by a stator core 3 are bent in a circumferential direction by twisting, comprises: a twisting member 13 having a grasping portion 17 that grasps and displaces the coil ends 7a in an axial direction and a circumferential direction relative to the stator core 3 so as to bend the projecting portions 7A; and a restraint wall 31 which is supported so as to be movable in an axial direction on a radially outer side with respect to the twisting member 13 and which restrains the projecting portions 7A on the radially outer side during bending in the state of projecting in an axial direction with respect to the grasping portion 17.

Classes IPC  ?

  • H02K 15/085 - Exécution des enroulements par pose des conducteurs dans ou autour des parties formant le noyau par pose des conducteurs dans des stators encochés

69.

METHOD FOR PRODUCING ROTOR


Numéro d'application JP2024033832
Numéro de publication 2025/070349
Statut Délivré - en vigueur
Date de dépôt 2024-09-24
Date de publication 2025-04-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Kameda Yohei

Abrégé

The present invention provides a method for producing a rotor which can suppress the occurrence of a defect such as damage on an inner periphery of an annular member when the annular member is attached to an outer periphery of a rotor core. Provided is a method for producing a rotor 1 in which an annular member 5 is attached to the outer periphery of a rotor core 3 obtained by layering a plurality of plate-like core pieces 9, wherein the rotor core 3, the outer periphery of which is fitted to the annular member 5, is obtained by: disposing, in the annular member 5, the plurality of core pieces 9 in a curved state in which the plurality of core pieces 9 are curved to have a smaller outer diameter; and pressing the plurality of core pieces 9 in the curved state through openings 5a on both sides of the annular member 5 so that the plurality of core pieces 9 each have a flat plate shape.

Classes IPC  ?

  • H02K 15/035 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques comportant des aimants permanents sur le rotor
  • H02K 1/276 - Aimants encastrés dans le noyau magnétique, p. ex. aimants permanents internes [IPM]

70.

METHOD AND DEVICE FOR PRODUCING LAMINATION CORE


Numéro d'application JP2024034268
Numéro de publication 2025/070537
Statut Délivré - en vigueur
Date de dépôt 2024-09-25
Date de publication 2025-04-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Kawarabayashi Tomohiro

Abrégé

Provided are a method and a device for producing a lamination core, which make it possible to predict occurrence of weld cracks and further facilitate prevention of the weld cracks. The method is for producing a lamination core 1 in which a plurality of core pieces 7 are laminated, and involves welding by applying pressure to the lamination core 1 in the lamination direction, and setting the cumulation of the compression amount of the lamination core 1 by application of the pressure, the contraction amount of the lamination core 1 in the lamination direction at a welded portion, and the spring back amount of the lamination core 1 by release of the pressure, to be within the compression limitation of the lamination core 1.

Classes IPC  ?

  • H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques

71.

COVER, RECORDING DEVICE, AND METHOD FOR MANUFACTURING COVER


Numéro d'application 18833185
Statut En instance
Date de dépôt 2023-02-02
Date de la première publication 2025-04-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Araki, Toshimitsu
  • Miyazaki, Wataru
  • Takahashi, Shuji

Abrégé

A cover is provided with a connection portion on an outer peripheral portion for conducting fastening. The connection portion is provided with a fastening face that is fastened by a bolt on a top face and a connecting face that is connected to the base on a bottom face, and the connection portion is formed into a stepped shape with steps that form a recessed shape on the top face and a projected shape on the bottom face with respect to the outer peripheral portion. The steps are set to have dimensions less than a thickness of a plate material. The stepped shape is provided with an outer face of the step and an inner face of the step that do not overlap each other in a planer direction of the connecting face.

Classes IPC  ?

  • G11B 33/02 - ÉbénisterieBoîtiersBâtisDisposition des appareils dans ou sur ceux-ci
  • G11B 33/12 - Disposition des éléments de structure dans les appareils, p. ex. d'alimentation, des modules

72.

OPERATION MEMBER FOR GUIDE WIRE


Numéro d'application JP2024024013
Numéro de publication 2025/069631
Statut Délivré - en vigueur
Date de dépôt 2024-07-03
Date de publication 2025-04-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Uetsuhara Saiji
  • Nakazono Miho

Abrégé

The present invention comprises a first cylindrical member which extends in the longitudinal direction, a second cylindrical member which extends in the longitudinal direction, and an outer cylinder which is externally mounted to the first cylindrical member and the second cylindrical member so as to be rotatable around an axis extending in the longitudinal direction and which extends in the longitudinal direction. The first cylindrical member and the second cylindrical member are provided in a state in which relative movement in the longitudinal direction is possible and relative rotation around the axis is restricted. The outer cylinder is provided to one cylindrical member among the first cylindrical member and the second cylindrical member in a state in which movement in the longitudinal direction is restricted. A first guiding part is formed on the inner circumferential surface of the outer cylinder and on the outer circumferential surface of the other cylindrical member of the first cylindrical member and the second cylindrical member, said first guiding part allowing the other cylindrical member to move longitudinally relative to the one cylindrical member such that the distance between a fastened body and the front end of a supporting tube of a guide wire changes with the relative rotation of the outer cylinder and the other cylindrical member around the axis.

Classes IPC  ?

  • A61M 25/09 - Fils de guidage
  • A61M 25/092 - Commande à distance de l'orientation de l'extrémité distale

73.

METHOD AND DEVICE FOR MANUFACTURING STATOR


Numéro d'application JP2024033830
Numéro de publication 2025/070347
Statut Délivré - en vigueur
Date de dépôt 2024-09-24
Date de publication 2025-04-03
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kobayashi Dai
  • Chiba Yuto

Abrégé

Provided is a method for manufacturing a stator with which it is possible to easily form a power line by bending of protrusions. In the method for manufacturing a stator by which protrusions 9 of a segment coil 7 held by a stator core 3 are bent, the tips 10a of the protrusions 9 are displaced to the radially outer side of the stator core 3, the protrusions 9 are bent so as to be positioned at first positions, the tips 10a of the bent protrusions 9 are displaced to the radially innter side thereof, and the bent portions 12a and 12b of the protrusions 9 are bent back so as to be positioned at second positions further to the radially outer side than the initial positions before the bending.

Classes IPC  ?

  • H02K 15/085 - Exécution des enroulements par pose des conducteurs dans ou autour des parties formant le noyau par pose des conducteurs dans des stators encochés

74.

DISK DRIVE SUSPENSION


Numéro d'application 18896917
Statut En instance
Date de dépôt 2024-09-26
Date de la première publication 2025-03-27
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Hanya, Masao
  • Ando, Toshiki

Abrégé

According to one embodiment, a suspension includes a load beam having a dimple portion and a flexure having a slider mounting portion. The dimple portion has a convex surface in contact with the slider mounting portion. The slider mounting portion is swingably supported by a gimbal component member. The radius of curvature of the convex surface is less than 0.15 mm. The flexure pitching resistance acting on the contact portion when the slider mounting portion swings in the pitching direction is 0.005 N or less. The phase delay of the slider mounting portion in the pitching direction relative to an undulation of a rotating disk is 200 or less.

Classes IPC  ?

  • G11B 5/48 - Disposition ou montage des têtes par rapport aux supports d'enregistrement

75.

LAMINATE MANUFACTURING APPARATUS AND LAMINATE MANUFACTURING METHOD


Numéro d'application JP2024030715
Numéro de publication 2025/062977
Statut Délivré - en vigueur
Date de dépôt 2024-08-28
Date de publication 2025-03-27
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Mizuno, Katsumi
  • Watanabe, Toshinori
  • Shimomura, Kohei
  • Toga, Takashi

Abrégé

This laminate manufacturing apparatus (10) is used when a pre-compression laminate (1A), in which a metal base substrate (2), a semi-cured resin composition (3A), a circuit pattern (4) with thickness of at least 0.8 mm, or a circuit body (C) which is a mounting body in which an electronic component is mounted on a circuit pattern (4), are laminated is to be heated and pressurized in a chamber (50). The laminate manufacturing apparatus (10) is provided with a base jig (11) to which the pre-compression laminate (1A) is attached, a film (13) that covers at least the resin composition (3A) and the circuit body (C), and a cover jig (12) that grips the film (13) between the base jig (11) and itself. The base jig (11) comprises an exhaust port (11e) that ventilates the interior of the film (13) that covers the resin composition (3A) and the circuit body (C). The cover jig (12) comprises an opening section (12a) that exposes an entire covering portion (13a) of the film (13) which covers the resin composition (3A) and the circuit body (C).

Classes IPC  ?

76.

VIBRATION REDUCTION DEVICE AND VEHICLE SEAT


Numéro d'application JP2024033100
Numéro de publication 2025/063167
Statut Délivré - en vigueur
Date de dépôt 2024-09-17
Date de publication 2025-03-27
Propriétaire
  • NHK SPRING CO., LTD. (Japon)
  • MITSUBISHI JIDOSHA KOGYO KABUSHIKI KAISHA (Japon)
Inventeur(s)
  • Saito, Masahiro
  • Iimura, Kazuya
  • Fushikida, Motohiro
  • Seki, Takamitsu
  • Murabayashi, Tomohiro
  • Miyabata, Makoto
  • Mizutani, Natsuki
  • Kawano, Ryota
  • Suzuki, Masashi
  • Seino, Hiroyuki
  • Nonobe, Katsuhiko
  • Yoshida, Shinji

Abrégé

In the present invention, a vibration reduction device comprises a weight set to a determined heaviness, and a fixed bag which is formed using a cloth-form member and to which the weight is attached. The fixed bag has an insertion part into which an attachment-receiving portion in the vehicle seat is inserted, and is attached to the attachment-receiving portion in a state in which the attachment-receiving portion is inserted into the insertion part.

Classes IPC  ?

  • B60N 2/90 - Détails ou éléments non prévus ailleurs

77.

SPRING MEMBER


Numéro d'application JP2024031663
Numéro de publication 2025/057823
Statut Délivré - en vigueur
Date de dépôt 2024-09-04
Date de publication 2025-03-20
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kobayakawa, Jun
  • Suwa, Taisuke
  • Shibata, Yuichi
  • Sugitani, Tomoya

Abrégé

A spring member according to the present invention comprises a coil spring formed by a spirally wound wire, and a seat part that is provided at one end of the coil spring and bears the coil spring load. The seat part includes a sheet that covers a portion of one end of the coil spring, an insulator that is provided between the sheet and the coil spring, and an adhesive that bonds the insulator and the coil spring. In the seat part, the position of the adhesive on the edge of the one end side of the coil spring is positioned on the edge end of the coil spring or nearer the other end side than the edge end.

Classes IPC  ?

78.

SUSPENSION DEVICE FOR VEHICLE SEAT AND VEHICLE SEAT


Numéro d'application JP2024029334
Numéro de publication 2025/057664
Statut Délivré - en vigueur
Date de dépôt 2024-08-19
Date de publication 2025-03-20
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kamiya, Takafumi
  • Ichinohe, Satoshi
  • Fukuda, Takahiro

Abrégé

A suspension device according to the present disclosure comprises: a lower member; an upper member; a raising/lowering mechanism; a spring; a characteristic-varying damper capable of adjusting damping force; a first sensor that detects the speed in a vertical direction of the upper member; a second sensor that detects the speed in the vertical direction of the lower member; and a control device capable of controlling the damping force of the characteristic-varying damper. The control device is configured so as to selectively execute a first control mode executed when the first sensor detects a first prescribed speed in the downward direction and the second sensor detects a speed greater than the first prescribed speed in the downward direction, a second control mode executed when the first sensor detects a second prescribed speed in the upward direction and the second sensor detects a speed greater than the second prescribed speed in the upward direction, and a third control mode executed when the conditions for executing the first and second control modes are not satisfied.

Classes IPC  ?

  • B60N 2/52 - Dispositifs de suspension des sièges utilisant des moyens à fluide
  • B60N 2/90 - Détails ou éléments non prévus ailleurs

79.

SPRING MEMBER


Numéro d'application JP2024032168
Numéro de publication 2025/057895
Statut Délivré - en vigueur
Date de dépôt 2024-09-09
Date de publication 2025-03-20
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kobayakawa, Jun
  • Suwa, Taisuke
  • Shibata, Yuichi
  • Sugitani, Tomoya

Abrégé

A spring member according to the present invention comprises: a coil spring formed by spirally winding a wire; and a seat part that is provided at an end of the coil spring and bears the load of the coil spring. The seat part has a sheet that covers a portion of one end of the coil spring, an insulator that is provided between the sheet and the coil spring, and an adhesive that bonds the insulator and the coil spring. The insulator forms a shape in which a portion of the surface on the sheet side is notched at the end of the coil spring on the edge end side.

Classes IPC  ?

80.

Vehicle seat


Numéro d'application 18824497
Numéro de brevet 12344186
Statut Délivré - en vigueur
Date de dépôt 2024-09-04
Date de la première publication 2025-03-13
Date d'octroi 2025-07-01
Propriétaire
  • NHK Spring Co., Ltd. (Japon)
  • SUBARU CORPORATION (Japon)
Inventeur(s)
  • Aoki, Jun
  • Takahashi, Tomoya
  • Ishiyama, Yosuke
  • Morishima, Kota
  • Ono, Taiki

Abrégé

A vehicle seat includes: an anchor member, a buckle apparatus, a cushion pad provided with a buckle accommodation cavity, a wire disposed so as to encircle the buckle accommodation cavity and supporting the cushion pad, and a rotation suppression member. The buckle apparatus includes: a coupling member, one end of which is coupled to the anchor member, and a buckle at which a tongue provided at a seatbelt can be removably attached, another end of the coupling member being coupled to the buckle, and the buckle being rotatable substantially in a seat vertical direction. The rotation suppression member is disposed at an upper side of the buckle apparatus, the rotation suppression member is attached to the wire and suppresses rotation in a seat upward direction of the buckle apparatus.

Classes IPC  ?

81.

JIG FOR STAGE AND METHOD FOR MANUFACTURING STAGE


Numéro d'application JP2024030685
Numéro de publication 2025/053019
Statut Délivré - en vigueur
Date de dépôt 2024-08-28
Date de publication 2025-03-13
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Komoda Masaki
  • Takahara Go
  • Arimura Minoru
  • Ohtsu Takashi
  • Kisara Yuta
  • Fujii Masahiro

Abrégé

This jig for a stage is used in the step of processing a thermal spray coating of the stage, and comprises: a body including a first surface on which the stage is placed, a second surface opposite the first surface, and a third surface connecting the first surface and the second surface; a flow path provided inside the body and through which a fluid flows; a flow path entry portion allowing the fluid to flow into the flow path; a flow path exit portion provided on the first surface of the body and allowing the fluid to flow out of the flow path; and a through hole penetrating the substrate from the first surface to the second surface.

Classes IPC  ?

  • H01L 21/683 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants pour le maintien ou la préhension

82.

ROTOR AND DYNAMO-ELECTRIC MACHINE


Numéro d'application 18292630
Statut En instance
Date de dépôt 2022-04-22
Date de la première publication 2025-03-13
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Kameda, Youhei
  • Matsuda, Tsuyoshi
  • Mineda, Yoshikazu
  • Nakayama, Soichi

Abrégé

This rotor includes a rotor shaft, a permanent magnet held at an outer periphery of the rotor shaft, and a magnet reinforcement tube formed in a cylindrical shape and covering the permanent magnet from an outer peripheral side of the permanent magnet. The magnet reinforcement tube includes plural layers layered in a radial direction, and has plural fiber sheets wound individually for each layer, and each fiber sheet being solidified with resin.

Classes IPC  ?

  • H02K 1/28 - Moyens de montage ou de fixation des parties magnétiques tournantes sur ou aux structures constituant le rotor

83.

VEHICLE SEAT


Numéro d'application 18783187
Statut En instance
Date de dépôt 2024-07-24
Date de la première publication 2025-03-06
Propriétaire
  • NHK SPRING CO., LTD. (Japon)
  • SUBARU CORPORATION (Japon)
Inventeur(s)
  • Yasuda, Kenzo
  • Toyoshima, Kazuhiro
  • Ishiyama, Yosuke
  • Fukushima, Masato
  • Takeuchi, Takahide
  • Koshiishi, Kento

Abrégé

A vehicle seat includes a pad main body configuring part of seat cushion pad, a slide pad that configures another part of the seat cushion pad and that approaches or moves away from the pad main body by sliding in a seat front-rear direction, and a flow path that is formed at an opposite side of the pad main body to a seating surface thereof, and an air moving machine that moves air inside the flow path. The flow path reaches as far as an opposing face of the pad main body that opposes the slide pad, and a main body groove portion that is in communication with the flow path and that reaches as far as the seating surface is formed in the opposing face. The main body groove portion is formed narrower at a location on the seating surface side than at a location on the flow path side.

Classes IPC  ?

  • B60N 2/56 - Dispositifs de chauffage ou de ventilation
  • A47C 7/74 - Adaptations pour incorporer des lampes, des postes radios, des bars, des téléphones, des dispositifs de ventilation, de chauffage ou de refroidissement, ou analogues pour la ventilation, le chauffage ou le refroidissement

84.

VEHICLE SEAT


Numéro d'application 18811155
Statut En instance
Date de dépôt 2024-08-21
Date de la première publication 2025-03-06
Propriétaire
  • NHK SPRING CO., LTD. (Japon)
  • SUBARU CORPORATION (Japon)
Inventeur(s)
  • Yasuda, Kenzo
  • Toyoshima, Kazuhiro
  • Ishiyama, Yosuke
  • Fukushima, Masato
  • Takeuchi, Takahide
  • Koshiishi, Kento

Abrégé

In a vehicle seat, a flow path is formed between a pad main body of a seat cushion pad and a seal member, with the flow path reaching to an opposing face of the pad main body opposing the slide pad, and air inside the flow path being moved by an air moving machine. A seat cushion cover includes a porous cover main body portion covering the pad main body, and a movable cover portion that is positioned between the pad main body and the slide pad and that is deformed by sliding the slide pad. The seat cushion cover includes a close-off cover portion that closes off a gap between an end portion on the slide pad side of the seal member and the cover main body portion.

Classes IPC  ?

85.

ROTOR


Numéro d'application JP2024030532
Numéro de publication 2025/047751
Statut Délivré - en vigueur
Date de dépôt 2024-08-27
Date de publication 2025-03-06
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Kameda Yohei

Abrégé

Provided is a rotor that makes it possible for a magnet to be sufficiently fixed while suppressing magnetic resistance. The present invention comprises: a rotor core 3 that has a magnet accommodation hole 13; a magnet 5 that is provided in the magnet accommodation hole 13; and an elastic body 7 that is provided in the magnet accommodation hole 13 in a gap in the magnetization direction between the rotor core 3 and the magnet 5 and holds the magnet 5 in the magnet accommodation hole 13. The elastic body 7 comprises a magnetic body that is separate from the rotor core 3 and the magnet 5.

Classes IPC  ?

  • H02K 1/276 - Aimants encastrés dans le noyau magnétique, p. ex. aimants permanents internes [IPM]

86.

MANUFACTURING METHOD OF DISK-DRIVE SUSPENSION AND MANUFACTURING APPARATUS OF DISK-DRIVE SUSPENSION


Numéro d'application 18951402
Statut En instance
Date de dépôt 2024-11-18
Date de la première publication 2025-03-06
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Ogaki, Shogo

Abrégé

A manufacturing apparatus of a disk-drive suspension including an actuator mounting portion on which a piezoelectric element is to be mounted. The manufacturing apparatus includes a transport shuttle which holds the disk-drive suspension; a drive mechanism which moves the transport shuttle; an adhesive feeding device which applies an adhesive reactive to ultraviolet rays to the actuator mounting portion; a light-irradiation device which irradiates the applied adhesive with ultraviolet rays to thereby increase a viscosity of the adhesive; an element feeding device which arranges the piezoelectric element on the adhesive the viscosity of which is increased; A manufacturing apparatus of a disk-drive suspension including an actuator mounting portion on which a piezoelectric element is to be mounted. The manufacturing apparatus includes a transport shuttle which holds the disk-drive suspension; a drive mechanism which moves the transport shuttle; an adhesive feeding device which applies an adhesive reactive to ultraviolet rays to the actuator mounting portion; a light-irradiation device which irradiates the applied adhesive with ultraviolet rays to thereby increase a viscosity of the adhesive; an element feeding device which arranges the piezoelectric element on the adhesive the viscosity of which is increased; and a heating device which heats the actuator mounting portion on which the piezoelectric element is arranged, to thereby cure the adhesive.

Classes IPC  ?

  • G11B 5/48 - Disposition ou montage des têtes par rapport aux supports d'enregistrement
  • H10N 30/073 - Formation de parties ou de corps piézo-électriques ou électrostrictifs sur un élément électrique ou sur un autre support par laminage ou collage de corps piézo-électriques ou électrostrictifs par fusion de métaux ou par adhésifs

87.

BONDING JIG AND BONDING METHOD


Numéro d'application 18724213
Statut En instance
Date de dépôt 2022-12-28
Date de la première publication 2025-02-27
Propriétaire NHK Spring Co., Ltd. (Japon)
Inventeur(s)
  • Kajigaya, Suguru
  • Fujiwara, Yuuki

Abrégé

A bonding jig for crimping and bonding first and second members constituting a damping member to a bonded member includes: a first bonding member configured to hold the first member; a second bonding member configured to hold the second member and cover the first bonding member to crimp the first and second members onto the bonded member; and a switching mechanism configured to switch, in a space where the first bonding member holds the first member, between a first state in which a gap is formed between the first bonding member and a part of a side surface of the first member continuous with a crimping surface with the second member and a second state in which the gap is filled to control a position of the first member.

Classes IPC  ?

  • B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
  • B29C 65/48 - Assemblage d'éléments préformésAppareils à cet effet en utilisant des adhésifs
  • B29L 31/30 - Véhicules, p. ex. bateaux ou avions, ou éléments de leur carrosserie

88.

MANUFACTURING METHOD AND EXTERIOR BODY OF ACCUMULATOR


Numéro d'application 18724700
Statut En instance
Date de dépôt 2023-01-06
Date de la première publication 2025-02-27
Propriétaire NHK Spring Co., Ltd. (Japon)
Inventeur(s)
  • Nakano, Naohito
  • Ohta, Daijiro
  • Tsujino, Akira
  • Kurokawa, Tomoya

Abrégé

A manufacturing method for manufacturing an exterior body of an accumulator including a bottom, a shell, and a port, includes: press fitting the bottom into the shell; and melting and solidifying a region including a part of a connection portion between the bottom and the shell which has been press fitted.

Classes IPC  ?

  • F15B 1/16 - Accumulateurs utilisant un coussin de gazDispositifs de remplissage de gazIndicateurs ou flotteurs à cet effet avec des moyens de séparation flexibles en forme de tubes

89.

STACK MANUFACTURING DEVICE AND STACK MANUFACTURING METHOD


Numéro d'application JP2024029098
Numéro de publication 2025/041706
Statut Délivré - en vigueur
Date de dépôt 2024-08-15
Date de publication 2025-02-27
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Hirama, Michinobu

Abrégé

A stack manufacturing device according to the present disclosure comprises: a supply mechanism capable of supplying a plurality of iron core members each having a first locking part; a squeeze having a plurality of second locking parts and having a conveyance path formed at the center thereof through which the plurality of iron core members are conveyed in a state of being stacked on each other; a rotation mechanism for rotating the squeeze; and a receiving member for receiving the plurality of iron core members conveyed out of the squeeze. The rotation mechanism rotates the squeeze to either a first rotation position in which the first locking part of one iron core member among the plurality of iron core members supplied to the squeeze is locked to the second locking part, or a second rotation position in which the first locking part of the one iron core member is not locked to the second locking part.

Classes IPC  ?

  • H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques
  • B21D 28/02 - Découpage à l'emporte-pièce ou poinçonnage de flans ou d'objets, avec ou sans production de déchetsEntaillage

90.

PRESSURE-APPLYING MECHANISM AND TESTING DEVICE FOR ALL-SOLID-STATE BATTERY


Numéro d'application JP2024026286
Numéro de publication 2025/041510
Statut Délivré - en vigueur
Date de dépôt 2024-07-23
Date de publication 2025-02-27
Propriétaire
  • NHK SPRING CO., LTD. (Japon)
  • TOYOTA JIDOSHA KABUSHIKI KAISHA (Japon)
Inventeur(s)
  • Uchida Takeshi
  • Nakagome Masashi
  • Ogami Jutaro
  • Kodama Masashi

Abrégé

This pressure-applying mechanism for an all-solid-state battery comprises: an all-solid-state battery cell disposed inside a fluid chamber filled with a fluid; and a pressure-applying part that has the fluid chamber and applies a predetermined pressure to the all-solid-state battery cell via the fluid. The fluid may be oil. The predetermined pressure may be generated by applying pressure to the fluid chamber. The pressure-applying part may include an upper shell member, a lower shell member, and a metal bellows disposed in a space formed by the upper shell member and the lower shell member.

Classes IPC  ?

  • H01M 10/0585 - Structure ou fabrication d'accumulateurs ayant uniquement des éléments de structure plats, c.-à-d. des électrodes positives plates, des électrodes négatives plates et des séparateurs plats
  • H01M 50/202 - Boîtiers ou cadres autour du boîtier primaire d’une seule cellule ou d’une seule batterie

91.

LAMINATE MANUFACTURING APPARATUS AND LAMINATE MANUFACTURING METHOD


Numéro d'application JP2024028817
Numéro de publication 2025/041666
Statut Délivré - en vigueur
Date de dépôt 2024-08-09
Date de publication 2025-02-27
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Hirama, Michinobu
  • Iida, Takayuki
  • Okazaki, Toshiki

Abrégé

A laminate manufacturing apparatus according to the present invention comprises: a squeeze part capable of conveying an iron core member in a downward direction; a conveyor that has a placement surface supporting a portion of one surface of the iron core member fed from the squeeze part, and can convey, in a direction intersecting the conveyance direction of the iron core member in the squeeze part, an iron core member placed on the placement surface and another iron core member stacked on that iron core member; and a first positioning mechanism including a movable member capable of moving between a restriction position protruding further to the side where the iron core member is placed than the placement surface of the conveyor, and a release position set back from the placement surface toward the side opposite the side at which the iron core member is placed. The movable member is disposed in a non-support area in which the conveyor does not support the iron core member.

Classes IPC  ?

  • H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques

92.

METHOD AND DEVICE FOR MANUFACTURING IRON CORE MEMBER


Numéro d'application JP2024028818
Numéro de publication 2025/041667
Statut Délivré - en vigueur
Date de dépôt 2024-08-09
Date de publication 2025-02-27
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Hirama, Michinobu

Abrégé

A method for manufacturing two kinds of iron core members (10, 20) involves: punching, as a single hole with the use of a first die (141), the contour of a portion intended to serve as a recess or a protrusion for cutting in a rotor core member (10) and at least a part of a portion intended to serve as one slot (23) of a stator core member (20), in a metal plate (2); shaping the rotor core member (10) by punching, with the use of a second die, the contour of the outer periphery of a portion intended to serve as the rotor core member (10), in the metal plate (2) having undergone punching with the use of the first die (141); punching, with the use of a third die, the contour of at least the inner periphery of a portion intended to serve as the stator core member (20), in the metal plate (2) from which the rotor core member (10) has been punched out; and shaping the stator core member (20) by punching, with the use of a fourth die, the contour of the outer periphery of a portion intended to serve as the stator core member (20), in the metal plate (2) having undergone punching with the use of the third die.

Classes IPC  ?

  • H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques

93.

LAMINATE MANUFACTURING APPARATUS AND LAMINATE MANUFACTURING METHOD


Numéro d'application JP2024029099
Numéro de publication 2025/041707
Statut Délivré - en vigueur
Date de dépôt 2024-08-15
Date de publication 2025-02-27
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Hirama, Michinobu
  • Takahashi, Shuji

Abrégé

A laminate manufacturing device according to the present disclosure comprises: a squeezer that can transport multiple iron core members, including locking iron core members having locking pieces and non-locking iron core members not having locking pieces, stacked on top of each other and that supports the locking pieces from the sides; a supply mechanism located upstream of the squeezer in the transport direction of the iron core members and capable of selectively supplying locking iron core members and non-locking iron core members to the squeezer; a receiving member capable of receiving multiple iron core members supplied from the downstream side of the squeezer in the transport direction; and a holding member that is arranged between the squeezer and the receiving member and can move between a holding position in which multiple iron core members supplied from the downstream side of the squeezer in the transport direction are held and a non-holding position in which the iron core members are not held.

Classes IPC  ?

  • H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques
  • B21D 28/02 - Découpage à l'emporte-pièce ou poinçonnage de flans ou d'objets, avec ou sans production de déchetsEntaillage

94.

WELDING METHOD AND JIG


Numéro d'application JP2024027420
Numéro de publication 2025/033299
Statut Délivré - en vigueur
Date de dépôt 2024-07-31
Date de publication 2025-02-13
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Ito Keiichi

Abrégé

The present invention provides a welding method which makes it possible to suppress variations in welding inside an assembly. Provided is a welding method in which welding is performed with a conductive wire 15 and a terminal 17 inside an assembly 1 brought into contact with each other, wherein a jig 19 which is operable from the outside of the assembly 1 is driven to cause a contact between the conductive wire 15 and the terminal 17. By managing this drive force of the jig 19, welding is performed with a predetermined pressing force applied between the conductive wire 15 and the terminal 17.

Classes IPC  ?

  • H02K 15/06 - Montage d'enroulements préfabriqués dans les machines
  • B23K 9/00 - Soudage ou découpage à l'arc

95.

POSITIONING METHOD AND JIG


Numéro d'application JP2024028115
Numéro de publication 2025/033436
Statut Délivré - en vigueur
Date de dépôt 2024-08-06
Date de publication 2025-02-13
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Hirota Yuji
  • Shimada Satoru

Abrégé

The present invention provides a positioning method and a jig that enable accurate phase setting of a plurality of iron core pieces. Provided is a positioning method for a rotor core 3 formed by laminating a plurality of core pieces 1 each having a key portion 9. In this method, a fixed abutting portion 13 and a rotating abutting portion 15 which can separately abut one side and the other side of the key portion 9 in the circumferential direction are rotated relative to each other, the relative rotation causes the key portion 9 to rotate and move relatively in the circumferential direction between the fixed abutting portion 13 and the rotating abutting portion 15, and the fixed abutting portion 13 and the rotating abutting portion 15 are respectively caused to abut the one side and the other side, in the circumferential direction, of the key portion 9 of each core piece 1 to sandwich the key portion 9 between the fixed abutting portion 13 and the rotating abutting portion 15, thereby aligning the phases of the laminated core pieces 1.

Classes IPC  ?

  • H02K 15/02 - Procédés ou appareils spécialement adaptés à la fabrication, l'assemblage, l'entretien ou la réparation des machines dynamo-électriques des corps statoriques ou rotoriques
  • H02K 1/30 - Moyens de montage ou de fixation des parties magnétiques tournantes sur ou aux structures constituant le rotor utilisant des pièces intermédiaires, p. ex. des croisillons

96.

COLLECTIVE BOARD, METHOD FOR MANUFACTURING SAME, AND METHOD FOR MANUFACTURING CIRCUIT BOARD


Numéro d'application JP2024014434
Numéro de publication 2025/027940
Statut Délivré - en vigueur
Date de dépôt 2024-04-09
Date de publication 2025-02-06
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Takakura Mitsuaki

Abrégé

The present invention provides a collective board capable of improving work efficiency for obtaining individual circuit boards from a collective board in which the circuit boards are arranged in a lattice pattern. The present invention comprises: a product part 3 in which a plurality of circuit boards 17 respectively having circuit patterns 15 on an insulating board 13 are arranged in a lattice pattern in a first direction and a second direction intersecting each other; slits 7 which extend at least between the ends of the product part 3 in the first direction and penetrate in the plate thickness direction between the adjacent circuit boards 17 in the second direction; coupling parts 9 which couple the adjacent circuit boards 17 in the second direction at at least one end of the product part 3 in the first direction; and grooves 11 which extend between the ends of the product part 3 in the second direction, are positioned between the coupling parts 9 and the circuit boards 17 adjacent in the first direction and between the adjacent circuit boards 17, and are non-penetrating in the plate thickness direction.

Classes IPC  ?

  • H05K 1/02 - Circuits imprimés Détails
  • H05K 1/05 - Substrat en métal isolé
  • H05K 3/00 - Appareils ou procédés pour la fabrication de circuits imprimés

97.

WELDED PART INSPECTION DEVICE AND METHOD


Numéro d'application JP2024026830
Numéro de publication 2025/028444
Statut Délivré - en vigueur
Date de dépôt 2024-07-26
Date de publication 2025-02-06
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s) Okubo Shuhei

Abrégé

Provided is a welded part inspection device with which it is simple to capture an image of a welded part, and the quality of a welded part can be easily and reliably determined. A welded part inspection device 1 for inspecting a welded part 5 of a stator 3 obtained by welding together adjacent coil ends 17 of a plurality of segment coils 10, said device comprising: an image-capture unit 23 which captures an image of a welded part 5; a monitor 25 which is positioned on the reverse side of the welded part 5 from the image-capture unit 23 in the image-capture direction and displays a background image 31 for the welded part 5; and a control unit 27 which causes the monitor 25 to display the background image 31, causes the image-capture unit 23 to capture an image of the welded part 5 together with the background image 31, and determines the shape of the welded part 5 in contrast with the background image 31, on the basis of the captured image.

Classes IPC  ?

  • G01N 21/95 - Recherche de la présence de criques, de défauts ou de souillures caractérisée par le matériau ou la forme de l'objet à analyser

98.

STATOR FOR ROTATING ELECTRICAL MACHINE


Numéro d'application JP2024027217
Numéro de publication 2025/028539
Statut Délivré - en vigueur
Date de dépôt 2024-07-30
Date de publication 2025-02-06
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Yoda, Yu
  • Kameda, Yohei
  • Yamamoto, Tatsuki
  • Minamikawa, Hiroshi

Abrégé

Provided is a stator for a rotating electrical machine, wherein when a slot number per pole per phase, which is a value obtained by dividing the number of slots by the number of magnetic poles of a rotor and the number of phases of an alternating current generated in a stator coil, is 2, a magnetic pole pitch, which is a value obtained by dividing the number of slots by the number of magnetic poles of the rotor, is defined as P, and when the difference between the magnetic pole pitch and a slot pitch, which is the pitch of slots on a side where a segment coil is inserted, is defined as k, one of the slot pitches on the inserted side on the outermost periphery or the innermost periphery of the stator core is P+1 and the other is P-1, and one of the slot pitch on the inserted side in an intermediate layer between the outermost peripheral layer and the innermost peripheral layer of the stator core, or the slot pitch on the side where joint ends, which are joined to each other, protrude is P+k, and the other is P-k.

Classes IPC  ?

  • H02K 3/04 - Enroulements caractérisés par la configuration, la forme ou le genre de construction du conducteur, p. ex. avec des conducteurs en barre
  • H02K 3/28 - Schémas d'enroulements ou de connexions entre enroulements

99.

STATOR FOR ROTARY ELECTRICAL MACHINE


Numéro d'application JP2024027218
Numéro de publication 2025/028540
Statut Délivré - en vigueur
Date de dépôt 2024-07-30
Date de publication 2025-02-06
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Yoda, Yu
  • Yamamoto, Tatsuki
  • Minamikawa, Hiroshi

Abrégé

This stator for a rotary electrical machine comprises: a stator core having a plurality of slots; and a stator coil formed by segment coils, each of which is formed by using a straight-angle wire having a rectangular cross section, is inserted into different slots apart in the circumferential direction of the stator core, and has a pair of insertion parts respectively inserted into the different slots and a connection part that connects the pair of insertion parts to each other. When a slot pitch, which is a pitch of slots into which the pair of insertion parts of the segment coil are inserted, is denoted as Ns and the total number of slots in the stator core is denoted as S, the following relational expression (1) is satisfied. (1): Ns

Classes IPC  ?

  • H02K 3/04 - Enroulements caractérisés par la configuration, la forme ou le genre de construction du conducteur, p. ex. avec des conducteurs en barre
  • H02K 3/28 - Schémas d'enroulements ou de connexions entre enroulements

100.

BENDING STRUCTURAL BODY


Numéro d'application 18279881
Statut En instance
Date de dépôt 2022-03-03
Date de la première publication 2025-01-30
Propriétaire NHK SPRING CO., LTD. (Japon)
Inventeur(s)
  • Hirata, Takafumi
  • Hotoda, Yuki
  • Hayakawa, Yuki

Abrégé

The present invention comprises: a first bending part and a second bending part which are capable of bending elastically; a connection part which connects the first bending part and the second bending part, and which has higher bending rigidity than the first bending part and the second bending part; and a plurality of first cord-like members which are attached to the first bending part, which are inserted through the first bending part, the connection part, and the second bending part, and which are capable of bending the first bending part via tension on the second bending part side. The first cord-like members each have a plurality of divided parts which are divided in the connection part and dispersed in the circumferential direction, and which are inserted through the second bending part in this dispersed state.

Classes IPC  ?

  1     2     3     ...     19        Prochaine page
